Zenith B27A11Z, B25A11Z, B25A74R, B25A76R, B27A11ZC Service Manuallines

PRODUCT SAFETY SERVICING GUIDELINES FOR AUDIO-VIDEO PRODUCTS

IMPORTANT SAFETY NOTICE

This manual was prepared for use only by properly trained audio-visual service technicians.

When servicing this product, under no circumstances should the original design be modified or altered without permission from Zenith Electronics Corporation. All components should be replaced only with types identical to those in the original circuit and their physical location, wiring and lead dress must conform to original layout upon completion of repairs.

Special components are also used to prevent x-radiation, shock and fire hazard. These components are indicated by the letter “x” included in their component designators and are required to maintain safe performance. No deviations are allowed without prior approval by Zenith Electronics Corporation.

Circuit diagrams may occasionally differ from the actual circuit used. This way, implementation of the latest safety and performance improvement changes into the set is not delayed until the new service literature is printed.

CAUTION: Do not attempt to modify this product in any way. Never perform customized installations without manufacturer’s approval. Unauthorized modifications will not only void the warranty, but may lead to property damage or user injury.

Service work should be performed only after you are thoroughly familiar with these safety checks and servicing guidelines.

GRAPHIC SYMBOLS

The exclamation point within an equilateral triangle is intended to alert the service personnel to important safety information in the service literature.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the service personnel to the presence of noninsulated “dangerous voltage” that may be of sufficient magnitude to constitute a risk of electric shock.

The pictorial representation of a fuse and its rating within an equilateral triangle is intended to convey to the service personnel the following fuse replacement caution notice: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ALL FUSES WITH THE SAME TYPE AND RATING AS MARKED NEAR EACH FUSE.

SERVICE INFORMATION

While servicing, use an isolation transformer for protection from AC line shock. After the original service problem has been corrected, make a check of the following:

FIRE AND SHOCK HAZARD

1. Be sure that all components are positioned to avoid a possibility of adjacent component shorts. This is especially important on items transported to and from the repair shop.

2. Verify that all protective devices such as insulators, barriers, covers, shields, strain reliefs, power supply cords, and other hardware have been reinstalled per the original design. Be sure that the safety purpose of the polarized line plug has not been defeated.

3. Soldering must be inspected to discover possible cold solder joints, solder splashes, or sharp solder points. Be certain to remove all loose foreign particles.

4. Check for physical evidence of damage or deterioration to parts and components, for frayed leads or damaged insulation (including the AC cord), and replace if necessary.

5. No lead or component should touch a receiving tube or a resistor rated at 1 watt or more. Lead tension around protruding metal surfaces must be avoided.

6. After re-assembly of the set, always perform an AC leakage test on all exposed metallic parts of the cabinet (the channel selector knobs, antenna terminals, handle and screws) to be sure that set is safe to operate without danger of electrical shock. DO NOT USE A LINE ISOLATION TRANSFORMER DURING THIS TEST. Use an AC voltmeter having 5000 ohms per volt or more sensitivity in the following manner: Connect a 1500 ohm, 10 watt resistor, paralleled by a .15 mfd 150V AC type capacitor between a known good earth ground water pipe, conduit, etc.) and the exposed metallic parts, one at a time. Measure the AC voltage across the combination of 1500 ohm resistor and .15 mfd capacitor. Reverse the AC plug by using a non-polarized adaptor and repeat AC voltage measurements for each exposed metallic part. Voltage measured must not exceed 0.75 volts RMS. This corresponds to 0.5 milliamp AC. Any value exceeding this limit constitutes a potential shock hazard and must be corrected immediately.

A.C. Voltmeter

Good Earth Ground such as the Water Pipe, Conduit, etc.

0.16uF

1600 OHM

10 WATT

Place this probe on each exposed metal part.

X-RADIATION

1. Be sure procedures and instructions to all service personnel cover the subject of x-radiation. The only potential source of x-rays in current TV receivers is the picture tube. However, this tube does not emit x-rays when the HV is at the factory-specified level. The proper value is given in the applicable schematic. Operation at higher voltages may cause a failure of the picture tube or high-voltage supply and, under certain circumstances may produce radiation in excess of desirable levels.

2. Only factory-specified CRT anode connectors must be used.

3. It is essential that the service personnel have available an accurate and reliable high-voltage meter.

4. When the high-voltage circuitry is operating properly, there is no possibility of an x-radiation problem. Every time a color chassis is serviced, the brightness should be run up and down while monitoring the high voltage with a meter, to be certain that the high voltage does not exceed the specified value and that it is regulating correctly.

5. When troubleshooting and making test measurements in a product with a problem of excessively high voltage, avoid being unnecessarily close to the picture tube and the high voltage power supply. Do not operate the product longer than necessary to locate the cause of excessive voltage.

6. Refer to HV, B+, and shutdown adjustment procedures described in the appropriate schematics and diagrams (where used).

IMPLOSION

1. All direct view picture tubes are equipped with an integral implosion protection system; take care to avoid damage during installation.

2. Use only the recommended factory replacement tubes.

TIPS ON PROPER INSTALLATION

1. Never install any receiver in a closed-in recess, cubbyhole, or closely fitting shelf space over, or close to, a heat duct, or in the path of heated air flow.

2. Avoid conditions of high humidity such as: outdoor patio installations where dew is a factor, near steam radiators where steam leakage is a factor, etc.

3. Avoid placement where draperies may obstruct venting. The customer should also avoid the use of decorative scarves or other coverings that might obstruct ventilation.

4. Wall- and shelf-mounted installations using a commercial mounting kit must follow the factory-approved mounting instructions. A product mounted to a shelf or platform must retain its original feet (or the equivalent thickness in spacers) to provide adequate air flow across the bottom. Bolts or screws used for fasteners must not touch any parts or wiring. Perform leakage tests on customized installations.

5. Caution customers against mounting a product on a sloping shelf or in a tilted position, unless the receiver is properly secured.

6. A product on a roll-about cart should be stable in its mounting to the cart. Caution the customer on the hazards of trying to roll a cart with small casters across thresholds or deep pile carpets.

7. Caution customers against using a cart or stand that has not been listed by Underwriters Laboratories, Inc. for use with its specific model of television receiver or generically approved for use with TVs of the same or larger screen size.

8. Caution customers against using extension cords. Explain that a forest of extensions, sprouting from a single outlet, can lead to disastrous consequences to home and family.

CM151 CA - SAFETY

i

(

)

PRODUCT SAFETY SERVICING GUIDELINES FOR AUDIO-VIDEO PRODUCTS

HIGH VOLTAGE AND X-RADIATION PROTECTION

A potential source of x-rays is the picture tube, if the high voltage (HV) is out of specification. When the HV is operating properly, there is no x-radiation. For the CA chassis family, the HV has no adjustments. A HV shutdown circuit is used to prevent excessive HV and x-ray emissions.

THEORY OF OPERATION (SHUTDOWN CIRCUIT)

This circuit basically monitors the sweep pulse voltage derived from the sweep transformer TX3204 pins 5 & 6. This voltage is rectified, and applied to a 12V zener diode ZDX3004. When the HV reaches its maximum allowed ,value (see drawing) the zener diode conducts, the voltage on pin 29 of the video processor (ICX2200) increases until it reaches the threshold voltage of 3.5 VDC, and shuts down the TV. If the shutdown circuit has operated, the microcontroller will prevent the TV from being turned on again, without first having to unplug the AC cord to reset the microcontroller.

TIP: Make a momentary short between the OUTPUT and GND of the IC6002 (RESET CIRCUIT) this will reset the microcontroller IC6000. Apply signal through the video generator or tune the TV color receiver to crosshatch pattern. Connect an accurate HV meter between the picture tube anode and chassis ground. Access Video Menu and adjust Brightness and Contrast controls for minimum screen luminance. Wait until, the Video Menu or display disappear. Read HV meter.

SCREEN B+ VDC HV NOM HV MAX

SIZE

25 124.0 +/- 2% 28 29 27 124.0 +/- 2% 27 29

32 128.5 +/- 2% 30 31.5 36 128.5 +/- 2% 30 31.5

0 BEAM

COMPONENT LEVEL REPAIR

MODULE LEVEL REPAIR ONLY

KV KV

SAFETY CIRCUIT TEST PROCEDURE

Equipment required: a) Video Generator. b) HV DC meter (0 to 40 KV, high Z). c) External variable power supply (0V to 200 VDC @ 5Amps

minimum).

d) 1 Giga ohm, 5%, 2W film resistor. Before turning the TV on, connect the HV meter’s negative

probe (-) to ground (DAG ground recommended) and the positive probe (+) in the anode of the CRT. Connect a 1 Giga Ohm resistor in parallel with the HV meter. Then connect the external power supply’s negative output (-) to chassis ground, that is, the negative lead of B+ filter capacitor, CX3420. Turn on the TV. Apply a video signal or tune the TV to a raster pattern. Adjust the G2 potentiometer for minimum, and set the brightness and contrast levels to minimum. Now adjust the output voltage of the external power supply to 124 VDC for CA25V/ 27V or 130 VDC for CA32V/36V. Then start increasing the voltage on the external power supply until the TV shuts down, and read the HV on the meter just before the voltage starts dropping.

Note: The external power supply may require a diode for

blocking voltage from the chassis power supply to the external power supply. The diode should be connected between the positive output of the external power and B+ of the chassis. The cathode should be facing the B+ of the chassis. The recommended diode is Part No. 103-00339-04A (400 V of VRRM @ 3 Amps of average rectified forward current).

iiCM151 CA - SAFETY

- iii -

TABLE OF CONTENTS

SECTION 1 GENERAL

OVERVIEW ............................................................. 1-1

MODEL INFORMATION ....................................... 1-1

INTRODUCTION ................................................ 1-2

SC3492Z MODEL REMOTE CONTROL ............................ 1-3

MBR3345Z MODEL REMOTE CONTROL ......................... 1-4

MBR3346Z MODEL REMOTE CONTROL ......................... 1-5

MBR3447Z MODEL REMOTE CONTROL ......................... 1-6

MBR3457Z MODEL REMOTE CONTROL ......................... 1-7

REMOTE PROGRAMMING ........................................... 1-8

AUTO FIND ..................................................... 1-8

CABLE BOX ..................................................... 1-8

VOLUME OVERRIDE........................................... 1-8

SPECIAL FEATURES........................................... 1-8

USER MENUS 221-1384 ......................................... 1-10

SETUP MENU ................................................. 1-10

TIMER MENU ................................................. 1-10

ADVANCED TV CONTROL MENU ......................... 1-11

VIDEO MENU ................................................. 1-13

MPAA RATING SYSTEM .................................... 1-14

TV PARENTAL GUIDELINE RATING SYSTEM........... 1-14

USER MENUS 221-1385 ......................................... 1-15

SETUP MENU ................................................. 1-15

SPECIAL FEATURES MENU .............................. 1-16

TIMER MENU ................................................. 1-16

ADVANCED TV CONTROL .................................. 1-17

AUDIO MENU ................................................ 1-18

VIDEO MENU ................................................. 1-19

MPAA RATING SYSTEM .................................... 1-20

TV PARENTAL GUIDELINE RATING SYSTEM........... 1-20

USER MENUS 221-1386 ......................................... 1-21

SETUP MENU ................................................. 1-21

PARENTAL CONTROL........................................ 1-24

VIDEO MENU ................................................. 1-26

PIP MENU ..................................................... 1-26

MPAA RATING SYSTEM .................................... 1-28

TV PARENTAL GUIDELINE RATING SYSTEM........... 1-28

USER MENUS 221-1387 ......................................... 1-29

SETUP MENU ................................................. 1-29

CLOCK MENU ................................................. 1-29

SPECIAL FEATURES MENU................................ 1-30

TIMER SETUP MENU ....................................... 1-30

ADVANCED TV CONTROL MENU ......................... 1-31

EZ HELP MENU .............................................. 1-33

AUDIO MENU ................................................ 1-33

VIDEO MENU ................................................. 1-34

MPAA RATING SYSTEM .................................... 1-36

TV PARENTAL GUIDELINE RATING SYSTEM........... 1-36

SECTION 2 INSTALLERS MENU

INSTALLERS MENU .................................................. 2-1

SERVICE MENU ADJUSTMENTS ........................... 2-1

INSTALLERS MENU 221-1384 .................................... 2-2

FACTORY MENU RECOMMENDED SETTINGS ........... 2-3

INSTALLERS MENU 221-1385 .................................... 2-4

FACTORY MENU RECOMMENDED SETTINGS ........... 2-5

INSTALLERS MENU 221-1386 .................................... 2-6

FACTORY MENU RECOMMENDED SETTINGS ........... 2-7

INSTALLERS MENU 221-1387 .................................... 2-8

FACTORY MENU RECOMMENDED SETTINGS ........... 2-9

SECTION 3 SERVICING

HIGH VOLTAGE AND X-RADIATION PROTECTION ............ 3-1

GENERAL INFORMATION ........................................... 3-2

COMPONENT-LEVEL SERVICING .................................. 3-2

STEREO MODULE .................................................... 3-2

SERVICING THE POWER SUPPLY ................................. 3-2

SERVICE ADJUSTMENTS (ELECTRICAL) ........................ 3-3

PURITY & CONVERGENCE SETUP PROCEDURE ............... 3-4

VERTICAL-TILT WEDGE ADJUSTMENT ........................... 3-5

HORIZONTAL-TILT WEDGE ADJUSTMENT ....................... 3-5

UNUSUAL TILT CASE ................................................ 3-5

IMPROVING CRT CORNER PURITY ............................... 3-5

MODIFICATION ....................................................... 3-5

SECTION 4 PARTS

B25A02Z ............................................................... 4-1

B25A10Z , B25A10ZC , B25A10Z6 , B25A10ZC6 ......... 4-1

B25A10ZCF ............................................................ 4-1

B25A11Z , B25A11Z6 .............................................. 4-1

B25A11ZF.............................................................. 4-1

B25A24Z , B25A24Z6 .............................................. 4-1

B25A24ZF.............................................................. 4-2

B25A30ZC ............................................................. 4-2

B25A30ZCF ............................................................ 4-2

B25A74R ............................................................... 4-2

B25A74LK ............................................................. 4-3

CB25A25Z , CB25A25Z6 .......................................... 4-3

LGB26A11ZM , LGB26A11ZM6 ................................... 4-3

B27A10Z , B27A10Z6 , B27A10ZC , B27A10ZC6 ......... 4-3

B27A10Z5, B27A10ZC5

B27A10ZCF ............................................................ 4-3

B27A11Z , B27A11Z6 , B27A11ZC ............................ 4-4

B27A11Z5 , B27A11Z65 , B27A11ZC5 ....................... 4-4

B27A24Z , B27A24Z6 .............................................. 4-4

B27A24Z5 , B27A24Z65 .......................................... 4-4

B27A24ZF.............................................................. 4-4

B27A24ZF5 ............................................................ 4-4

B27A30Z , B27A30ZC , B27A30ZC6 ........................... 4-5

B27A30ZC5 , B27A30ZC65 ....................................... 4-5

B27A30ZCF ............................................................ 4-5

B27A30ZCF5 .......................................................... 4-5

B27A34Z , B27A34Z6 .............................................. 4-5

B27A34ZF.............................................................. 4-5

B27A74R ............................................................... 4-6

B27A76R ............................................................... 4-6

LGB29A10ZM .......................................................... 4-6

LGB29A10ZM5 ........................................................ 4-6

LGB29A11ZM .......................................................... 4-6

LGB29A11ZM5 ........................................................ 4-6

LGB29A13ZM .......................................................... 4-7

LGB29A24ZM .......................................................... 4-7

LGB29A24ZM5 ........................................................ 4-7

LGB29A30ZM .......................................................... 4-7

LGB29A30ZM5 ........................................................ 4-7

B32A24Z ............................................................... 4-7

B32A24Z6 ............................................................. 4-8

B32A24ZF.............................................................. 4-8

B32A30Z ............................................................... 4-8

B32A30Z6 ............................................................. 4-8

CM151 TOC - 1 CA -TOC

TABLE OF CONTENTS

B32A30ZF.............................................................. 4-8

B32A34Z ............................................................... 4-9

B32A34Z6 ............................................................. 4-9

B32A34ZF.............................................................. 4-9

B36A24Z ............................................................. 4-10

B36A24Z6 ........................................................... 4-10

B36A24ZF............................................................ 4-10

B36A30Z ............................................................. 4-10

B36A30Z6 ........................................................... 4-10

B36A30ZF............................................................ 4-10

B36A34Z0 ........................................................... 4-10

B36A34Z6 ........................................................... 4-10

B36A34ZF............................................................ 4-11

MODULE PARTS LIST.............................................. 4-12

SECTION 5 EXPLODED VIEWS

B25A10Z/B25A10ZC /B25A11Z/LGB26A11ZM .............. 5-1

B25A24Z ............................................................... 5-2

B25A30ZC ............................................................. 5-3

B27A13ZC/LGB29A10ZM/LGB29A13ZM ....................... 5-4

B27A11Z&C/B27A30ZC/CB27A10Z&C/LGB29A11ZM/

LGB29A30ZM .......................................................... 5-5

B27A24Z/B27A34Z/LGB29A24ZM .............................. 5-6

B25A74R/B27A74R ................................................. 5-7

B25A76R/B27A76R ................................................. 5-8

B32A24Z/B32A30Z/B32A34Z .................................... 5-9

B36A24Z/B36A30Z/B36A34Z .................................. 5-10

SECTION 6 SCHEMATICS

INTERCONNECT DIAGRAM ......................................... 6-1

POWER SUPPLY....................................................... 6-2

AUDIO PROCESSOR STEREO .................................... 6-3A

AUDIO PROCESSOR MTS......................................... 6-3B

AUDIO PROCESSOR MONO ...................................... 6-3C

MAIN MICROPROCESSOR .......................................... 6-4

VIDEO PROCESSOR .................................................. 6-5

HORIZONTAL VERTICAL DEFLECTION ........................... 6-6

JACK AND SWITCH CIRCUIT ...................................... 6-7

PICTURE IN PICTURE ............................................... 6-8

VIDEO OUTPUT ....................................................... 6-9

PCB LAYOUT ........................................................ 6-10

SMD LAYOUT ........................................................ 6-11

CM151 TOC - 2 CA -TOC

SECTION 1

OVERVIEW

Below is detailed Model information on the CA Chassis series. All CA Models include the V-Chip.

CA Chassis Model Information

MODEL SCR CABINET AUDIO PIP JACKS COMB MICRO OP GUIDE

COMPONENT LEVEL REPAIR

B25A10Z 25 TableTop Stereo None 0 Yes 221-01384 206-03476 B25A10ZC 25 TableTop Stereo None 0 No 221-01384 206-03476 B25A11Z 25 TableTop Stereo None 3 No 221-01384 206-03477 B25A24Z 25 TableTop MTS/SAP None 6 Yes 221-01385 206-03479 B25A30ZC 25 TableTop Stereo 1 Tuner 6 No 221-01385 206-03480 B25A74R 25 Console MTS/SAP None 6 Yes 221-01385 206-03450 B25A76R 25 Console MTS/SAP None 6 Yes 221-01385 206-03450 B27A11Z 27 TableTop Stereo None 3 No 221-01384 206-03477 B27A11ZC 27 TableTop Stereo None 3 No 221-01384 206-03477 B27A13Z 27 TableTop Stereo None 0 No 221-01384 206-03478 B27A24Z 27 TableTop MTS/SAP None 0 Yes 221-01385 206-03479 B27A30ZC 27 TableTop Stereo 1 Tuner 6 No 221-01386 206-03480 B27A34Z 27 TableTop MTS/SAP 1 Tuner 6 Yes 221-01387 206-03481 B27A74R 27 Console MTS/SAP None 6 Yes 221-01385 206-03372 B27A76R 27 Console MTS/SAP None 6 Yes 221-01385 206-03372 CB27A10Z 27 TableTop Stereo None 0 No 221-01384 206-03476 CB27A10ZC 27 TableTop Stereo None 0 No 221-01384 206-03476 LGB26A11ZM 25 TableTop Stereo None 3 No 221-01384 206-03494 LGB29A10ZM 27 TableTop Stereo None 0 No 221-01384 206-03495 LGB29A11ZM 27 TableTop Stereo None 3 No 221-01384 206-03498 LGB29A13ZM 27 TableTop Stereo None 0 No 221-01384 206-03498 LGB29A24ZM 27 TableTop MTS/SAP None 6 Yes 221-01385 206-03497 LGB29A30ZM 27 TableTop Stereo 1 Tuner 3 No 221-01386 206-03496

MODULE LEVEL REPAIR ONLY

B32A24Z 32 TableTop MTS/SAP None 6 Yes 221-01385 206-03479 B32A30Z 32 TableTop Stereo 1 Tuner 3 No 221-01386 206-03480 B32A34Z 32 TableTop MTS/SAP 1 Tuner 3 Yes 221-01387 206-03481 B36A24Z 36 TableTop MTS/SAP 1 Tuner 6 No 221-01385 206-03479 B36A30Z 36 TableTop Stereo 1 Tuner 3 No 221-01386 206-03480 B36A34Z 36 TableTop MTS/SAP 1 Tuner 6 Yes 221-01387 206-03481

OVERVIEW

MODEL INFORMATION

CM151 1-1 CA - GENERAL

OVERVIEW

INTRODUCTION

The CA series chassis has been developed for sentry 2 screen sizes 25” through 36” stereo models. The chassis is a single sided printed circuit board (PCB) very similar to the GA Chassis.

During the manufacturing process, the microprocessor will be programmed for any added features. Additional plug in boards with Jack Packs will be added to the chassis to accommodate the different features: Stereo, Mono, Video/ Audio in, etc.

The ICX2200 integrated circuit (IC) handles all of the audio/video, sync, and sweep drive processing. The IC6000 is the main microprocessor and the IC6001 is the EAROM memory. The keyboard and IR detector are tied directly to the IC6000. The IC2100/IC2101 handles the vertical sweep. At power on, voltages for the vertical and video output circuit are derived from this sweep circuit.

CM151 1-2 CA - GENERAL

POWER

Press to turn

TV ON or OFF

Press to access

closed captions.

CC

TIMER

Press (and repeat) to

activate the sleep timer

VOLUME

Press left to reduce

or right to increase

volume level of TV.

NUMBERED BUTTONS

Press repeatedly to

select desired menu.

SC3492Z MODEL REMOTE CONTROL

MUTE

Press to turn off sound while picture remains. Press again to restore sound.

FLSHBK

Press to return to last TV channel you were watching.

CHANNEL Up/Down

Press to select a TV channel by going up/down through channels programmed in the TV memory.

ENTER

Press to view Channel/Time or to remove any on-screen display in TV mode. Press to view the Music menu (active station) listing in FM mode.

TIMER

POWER

VOLUME

1

4

7

0

MUTE

FLSHBK

C

CHANNEL

3

2

6

5

9

8

ENTER

MENU

Display

menu or

ADJUST (Left/Right)

Press during on-screen

menu operations to

adjust an option.

ADJ

SELECT

ADJ

SC3492

124-00213-23

SELECT

Press during on-screen menu operations to select an option.

Note: Keys dedicated to VCR functions will still operate the VCR while the

remote is in TV mode.

CM151 1-3 CA - REMOTES

MBR3345Z MODEL REMOTE CONTROL

Selects Cable operation

CABLE

PRG (Program)

Programs remote to

operate other products.

VCR

Selects VCR operation

TV

Selects TV operation

VOLUME Left/Right

Changes TV's sound

level.

MUTE

Turns sound Off and On

While picture remains.

NUMBERS

Selects channels directly

and enter numeric values

for some options.

MENU / RECORD

Displays on-screen

menus for TV mode

prg

vcr

tv

volume

mute

record

menu quit

source

tv / vcr

play

Stop

power

cable

channel

flshback

enter

pause

f.fwd.rew

CC

POWER

Turns TV On or Off

CC (Closed Captioning) Displays closed caption menu

CHANNEL (Up or Down)

Selects next channel. When "Surf" option is On, you receive only channels set as "Surf" channels.

FLASBK (Flashback)

Returns to previous channel

TV/VCR - Source

Steps through source options

ENTER

Shows Channel/Time display. Press after channel numbers for fast selection.

QUIT/ PAUSE

Removes on-screen display from view. If no display is on, switches front speaker surround sound On and Off for some TVs.

CM151 1-4 CA - REMOTES

MBR3345Z

124-00229

MBR3346Z MODEL REMOTE CONTROL

Selects Cable operation

CABLE

PRG (Program)

Programs remote to

operate other products.

VCR

Selects VCR operation

TV

Selects TV operation

VOLUME Left/Right

Changes TV's sound

level.

MUTE

Turns sound Off and On

While picture remains.

NUMBERS

Selects channels directly

and enter numeric values

for some options.

MENU / RECORD

Displays on-screen

menus for TV mode

prg

vcr

tv

volume

mute

record

menu quit

source

tv / vcr

play

stop

power

cable

channel

flshback

enter

pause

f.fwd.rew

PIP

POWER

Turns TV On or Off

PIP (Picture In Picture)

Selects Picture In Picture Operation

CHANNEL (Up or Down)

Selects next channel. When "Surf" option is On, you receive only channels set as "Surf" channels.

FLASBK (Flashback)

Returns to previous channel

TV/VCR - Source

Steps through source options

ENTER

Shows Channel/Time display. Press after channel numbers for fast selection.

QUIT/ PAUSE

Removes on-screen display from view. If no display is on, switches front speaker surround sound On and Off for some TVs.

CM151 1-5 CA - REMOTES

MBR3346Z

124-00229-01

MBR3447Z MODEL REMOTE CONTROL

FLASHBK (Flashback)

Returns to previous Channel.

SURF

Turns Surf Channel On/Off

CHANNEL (Up/Down)

Selects next channel in

TV’s memory. Press

and hold to repeat.

NUMBER PAD

Selects channels directly.

PRG

CABLE

SURF

VOLUME

1

4

VCR

FLASHBK

CHANNEL

2

POWER

Turns TV On or Off.

POWER

AUX

TV

MUTE

MODE

Selects the remote's mode of operation

MUTE

Turns sound Off and On while picture remains.

VOLUME

VOLUME (Left/Right)

Increases TV’s sound level.

ENTER

3

Shows Channel/Time, enters channel, or removes any

5

6

on-screen menus.

MENU

Displays menus for TV

and other options.

LEFT/RIGHT ARROWS

Chooses and shows the

desired menu option.

A, B, C Keys

Special features of some TV’s

TIMER

Displays the Sleep Timer menu.

Press repeatedly to set desired

TV shut-off time.

7

8

0

MENU

A

B

PAUSE

RECORD

REWIND

PLAY

STOP

MBR3447Z

124-00233

ENTER

C

TIMER

9

TV/VCR

SOURCE

FFWD

QUIT

CC

QUIT/ (Three Functions Key)

Exits from on-screen display, turns the sound enhancement feature on or off, and switches audio between Main source and PIP source.

UP and DOWN ARROWS

Moves highlighted bar within menu to select an option.

CC

Displays closed caption menu.

TV/VCR SOURCE

Steps through source options.

CM151 1-6 CA - REMOTES

FLASHBK (Flashback)

Returns to previous Channel.

SURF

Turns Surf Channel On/Off

CHANNEL (Up/Down)

Selects next channel in

TV’s memory. Press

and hold to repeat.

NUMBER PAD

Selects channels directly.

MBR3457Z MODEL REMOTE CONTROL

POWER

Turns TV On or Off.

PRG

CABLE

SURF

VCR

FLASHBK

CHANNEL

VOLUME

CHANNEL

1

4

POWER

AUX

TV

MUTE

MODE

Selects the remote's mode of operation

MUTE

Turns sound Off and On while picture remains.

VOLUME

VOLUME (Left/Right)

Increases TV’s sound level.

ENTER

3

2

5

6

Shows Channel/Time, enters channel, or removes any on-screen menus.

MENU

Displays menus for TV

and other options.

LEFT/RIGHT ARROWS

Chooses and shows the

desired menu option.

PIP, PIPCh, FREEZ

Picture in Picture functions

TIMER

Displays the Sleep Timer menu.

Press repeatedly to set desired

TV shut-off time.

7

0

MENU

PIP

RECORD

REWIND

PIPCh

PAUSE

8

ENTER

FREEZ

TIMER

PLAY

STOP

MBR3457Z

124-00233-01

9

TV/VCR

SOURCE

FFWD

QUIT

CC

QUIT/ (Three Functions Key)

Exits from on-screen display, turns the sound enhancement feature on or off, and switches audio between Main source and PIP source.

UP and DOWN ARROWS

Moves highlighted bar within menu to select an option.

CC

Displays closed caption menu.

TV/VCR SOURCE

Steps through source options.

CM151 1-7 CA - REMOTES

REMOTE PROGRAMMING

PROGRAMMING THE MBR3447 AND MBR3457Z REMOTES

If you’re using Zenith products, the remote is already programmed for most common codes. For other brands, or if your remote fails to control your Zenith products, you’ll have to program the remote.

After installing the batteries, follow these steps for each product:

1. Press and hold PRG using a blunt pointed object. Release PRG after indicator light turns on.

2. Press the device button to be programmed: CATV, VCR, AUX, or TV.

3. Enter 3-digit product code from chart on next page.

4. Press and release ENTER to save code.

5. Point remote at product and press POWER to test product operation. If it does not turn on, reprogram remote using a different code.

6. Write codes on the label inside battery compartment for future reference.

AUTO FIND

If none of the codes in the code table operate your equipment, use Auto Find to search for the proper code.

1. Turn On the device you want to operate.

2. Press and hold PRG using a blunt pointed object. Release PRG after the indicator light turns on.

3. Press the device button to be programmed: CATV, VCR, AUX, or TV.

4. Enter “000”, then press ENTER within two seconds. Auto Find is active when the indicator light flashes and remains lit.

5. Point the remote at the product.

6. Press and release POWER repeatedly, about once a second, until your product turns Off. The indicator light turns Off when you press POWER, and On when you release it.

7. Press ENTER immediately to save the code. The indicator light flashes to indicate the code has been saved.

8. Press POWER to turn On your product.

9. Test your product. If the remote fails to operate the functions you use most often, use Auto Find again to search for a better code. (Auto Find resumes its search after the last code that was entered and saved in step 7).

NOTE: If the indicator light stays on as you press

POWER, Auto Find has tried all of the codes.

If the product you want to control has not

turned off, your remote will not work with

that product.

To cancel Auto Find, press PRG at any time during Auto Find.

CABLE BOX

These remotes can control cable/converter box volume and muting if available on your equipment.

1. Program the cable/converter box normally.

2. After programming the cable/converter box, Press and hold PRG again using a blunt pointed object. Release PRG after indicator light turns on.

3. Press and release the cable device button.

4. This time, enter the special code 3-9-9 instead of the product code.

5. Press and release ENTER to save.

VOLUME OVERRIDE

These remotes can override TV, VCR, or Video Disk Player volume functions with an amplifier’s volume and muting.

1. Program the amplifier normally.

2. After programming the amplifier, Press and hold PRG again using a blunt pointed object. Release PRG after indicator light turns on.

3. Press and release the device button whose volume control is to be replaced by the amplifier volume control. For example, pressing TV will operate the amplifier’s volume while the remote is in TV mode.

4. This time, enter the special code 4-9-9 instead of the product code.

5. Press and release ENTER to save.

SPECIAL FEATURES

AUX+1, AUX+2, AND AUX+3 Capability These remotes can control up to seven devices. If the remote has been programmed for four components using the TV, VCR, CABLE and AUX keys, you may also program it for up to three additional using AUX+1, AUX+2 and AUX+3.

To Program AUX+1, AUX+2, AND AUX+3

1. Locate three-digit code for product in code table.

2. Press and hold PRG until indicator lights up.

3. Press AUX and “1” simultaneously to select AUX+1.

4. Enter three-digit code, then press ENTER. Indicator light should flash, then turn off to indicate code is accepted. If the light stays on, repeat steps 3 and 4 or try a different code.

5. Repeat steps 2-4 for AUX+2 and AUX+3.

6. Write codes on the label inside battery compartment for future reference. Hold down AUX and press 1, 2, or 3 to access AUX+1. +2 or +3 mode.

CM151 1-8 CA - REMOTES

PROGRAMMING CODES

TV’S

Admiral 116, 121, 130, 133 Adventura TV/VCR 154 Akai 104 Amark 103, 146 AOC 104 Bell & Howell 121 Broksonic 131, 136, 182 Candle 139 Centurion 119 Citizen 121, 139 Contec 141 Coronado 103 Crown 103 Curtis Mathis 116, 119, 121 Daewoo 149, 159 Daytron 119 Elektra 121 Emerson 103,104,123,124, 131,

Fisher 109, 118 General 106, 107, 114, 116, Electric 117, 161 Goldstar Hitachi Inteq 101 J.C. Penney JVC 125, 132, 164 KMC 103 KTV 103, 104, 138 Kurazai 121 LG 184 Lodgenet 121 Logik 121 LXI 133, 137 Magnavox

Majestic 121 Marantz 104, 120, 155 Megatron 146 Memorex 121 MGA/Mitsubishi

Montgomery Ward 103, 104, 105, 113,

NEC 104, 119 Orion 176 Panasonic 106, 107, 160, 166 Philco 103, 104, 112, 113,

Philips 112, 113 Pioneer 135 Portland 103 ProScan 116, 157, 162, 167 Quasar 106, 107 RCA 104, 116, 126,

Realistic 105, 123, 124 Sampo 119 Samsung 103, 119, 134, 141 Sanyo 108, 109, 118 Scott 119, 124 Sears 103, 108, 109, 110,

Sharp 103, 105, 122, 133,

Signature 2000 103, 104, 105, 113,

Sony 115, 143, 151, 170 Soundesign 139 Sylvania 112, 113, 117, 119,

Tatung 106 Teknika Telerent 103, 121 Toshiba 110, 111, 134, 171 XR1000 121, 154 Yorx 119 Zenith 101, 142, 149, 177 Zenith Star Sight 175

136, 145, 176

103, 104, 119, 147, 184 102, 103, 129, 163, 121

104, 110, 114, 117, 119

103, 112, 113, 117, 119, 127, 128, 130, 139, 165

104, 119, 120, 130, 133, 140, 155, 169, 178

114, 119, 121, 130, 133

139

157,161,162,167,168

111, 118, 134

137, 156, 169

114, 119, 121, 130, 133

127, 128, 139

103, 112, 121, 124, 139

VCRS

Admiral 208, 261 Adventura 231 Aiwa 231 Akai 223, 238, 241 Audio Dynamics 202, 206, 218, 247 Bell & Howell 206, 247 Broksonic Canon 214 Citizen 209 Craig 212 Criterion 239 Curtis 214, 259 Mathis Daewoo 244, 246, 248, 254 Daytron 236, 246 DBX 202, 218 Emerson

Fisher 211, 212, 213, 247 Funai 231 General 214, 216, 220 Electric Goldstar 209, 273 Go Video 256, 262, 263, 275 Hitachi 215, 231, 257 Instant 214, 227 Replay Inteq 273 J.C. Penney 214, 215, 218, 227 JVC Kenwood 202 Logik 239 LXI 209, 231 Magnavox 207, 214, 231 Marantz 207, 218 Marta 209 Memorex 206, 212, 214, 231 Mitsubishi 204, 222, 252, 264 Montgomery 208, 214, 216, 219, Ward 231, 249 Multi Tech 239 NEC 202, 218 Optimus 208, 209, 259 Orion 233, 250 Panasonic 214, 251, 259 Pentax 215 Philco 207, 214 Philips 207, 214, 227 Pioneer 210, 215 Portland 246 Pro Scan 216, 260 Quasar 214, 259 RCA

Realistic Samsung 220, 230, 238 Sansui 239 Sanyo 206, 212, 247 Scott 204, 205, 233, 243 Sears Sharp 208, 261, 272 Shintom 239 Signature 2000 208, 214, 216, 219,

Sony 217, 232, 237, 274 Sylvania 207, 214, 227 Symphonic 231 Tashiko 209 Tatung 202 Teac 202, 231 Teknika 209, 234 Toshiba 205, 215, 271 XR1000 239 Vector Research 204, 218 Yamaha 202, 218 Zenith 201, 224, 225, 229,

221, 226, 233, 250, 255

203, 209, 221, 223, 226, 233, 235, 243, 250

202, 224, 225, 258, 263

215, 216, 220, 227, 240, 242, 244, 260 206, 208, 212, 214, 231

206, 209,211, 212, 215

231, 249, 261

237

VCR/TVS

Daewoo 148 Emerson 158 Funai 154 Goldstar 153 Hitachi 154 LXI 154 Magnavox 173, 181 Panasonic 174 RCA 179 Samsung 180 Sansui 182 Sharp 179 Sylvania 154 Symphonic 154 Zenith 153, 154, 172

CABLE/SATELLITE Set-Ups

Allegro 358, 362 Allegro A/B Switch 361 Amerkast 383 Dish Network 389 Gemini 305, 331, 338 General Electric 367 General Instrument Hamlin Jerrold 304, 307, 308, 309,

Kale Vision 335 Macom 314, 321 Magnavox 334 NSC Oak 311, 332, 342 Panasonic 313, 320 Paragon 333 Philips Pioneer 315, 343 Primstar 388 Radio Shack 362 RCA DSS 373, 394 Regal 366 Regency 329 Samsung 335 Scientific Atlanta 316, 323, 336, 364 Sony DSS 387 Sprucer 313 Standard Comp 335 Stargate 379 Texscan 339, 356, 371 Tocom 317, 318, 346 Toshiba DSS 391 Unika 348, 362 United Satellite 344 Universal 358, 362 Vid Tech 340 Video Way 349 Viewstar 354, 355, 372 Zenith 301, 353 Zenith HD Set Top 385 Zenith N/C Set Top 384, 395 Zenith Satellite 312, 328, 330, 351

LASER DISC

Denon 402, 403 Mitsubishi 403 Pioneer 402, 403, 405 Sanyo 401 Sony 404 Zenith 401

AUDIO TAPE DECKS

Denon 455 Harman/Kardon 456 JVC 457 Kenwood 450 Onkyo 458 Philips DCC 454 Pioneer 451, 478 Sony 452 Technics 454, 497 Yamaha 453

305, 306 302, 303, 345, 365, 366

310, 318, 360, 363

335, 339, 368, 369, 370

347, 350, 352, 354, 355

AUDIO CD PLAYERS

Akai 409, 424 Carver 510 Crown 410 Denon 411 Fisher 412, 438 Goldstar 460 Harman/ Kardon 413 JVC 415 Kenwood 412, 416, 417, 441 Magnavox 421, 422, 433, 434 Mitsubishi 423, 424 NAD 425, 426, 447 Nakamichi 427, 428 NEC 429 Onkyo 430 Panasonic 431, 432 Philips 421, 433, 434 Pioneer 431, 435 Quasar 432 Radio Shack 431, 436, 439, 440,

RCA 437 Sanyo 438, 439 Scott 440 Sharp 441, 442 Sony 443, 444, 445 Soundesign 461, 498, 501, 502 Sylvania 433 Teac 446 Technics 432, 459 Toshiba 447 Yamaha 448 Zenith

AUDIO TUNERS AND AMPLIFIERS

Denon 462, 463 Fisher 464 Goldstar 460 Harman Kardon 465 JVC 466 Kenwood 468, 469, 506 Marantz 472, 503 Onkyo 473 Philips 475, 476 Pioneer 477, 478, 479 Radio Shack 487, 488 Realistic 480 Sanyo 481 Scott 482 Sharp 483 Sherwood 487, 488 Sony 489, 490, 491, 492 Soundesign 461, 498, 501, 502 Teac 494, 495 Technics 497, 509, 567, Yamaha 496 Zenith 460, 461, 498, 501,

DVD PLAYERS

Denon 523, 524 Marantz 521 Mitsubishi 525 Panasonic 523, 524 Philips/Magnavox 521 Pioneer 527 Proscan 526 RCA 526 Sony 522 Toshiba 521 Zenith 521

441

460, 461, 498, 501, 502

502, 504, 505

CM151 1-9 CA - REMOTES

USER MENUS 221-1384

SETUP MENU

The Setup Menu for CA chassis with its options for each item are described as follows:

Setup Menu

Ch. Add/Del Clock Set Timer Setup Advanced TV Ctrl Caption/Text Audio Mode Language

AUTO PROGRAM

The Auto Program feature automatically searches for all available channels and marks them as Added so that they may be accessed via the channel Up/Down key.

In the Auto Program screen:

· A message at the top displays “Auto Program” to let the customer know that they have entered the Auto Program feature.

· A line at the bottom of the screen shows that the Up/ Down and Left/Right Arrow keys are used for Auto Program selections.

· The current RF input type (Off Air Antenna or Cable TV) is highlighted. Use the Up/Down Arrow keys to change the RF input type.

To start the Auto Program, press the Left/Right Arrow key. If the Cable TV input type is selected, the Auto Program routine will determine what type of cable system is present.

Notes:

To Program

• Auto program clears all Surfing channels which were

added.

• While searching for channels, all keys except for

the Power key are disabled. This prevents an incomplete Auto Program procedure.

• Running the Auto Program will clear the factory

mode, if it was active. This happens at the end of the Auto Program.

• If the Auto Program line in the Setup Menu is ‘red’,

this indicates that the module did not pass one of the test equipment’s tests.

• If no channels are found then the following message

will appear: “Make sure that the cable/ant. is connected , and try again.”

CHANNEL/ADD/DEL

After running the Auto Program, all channels found by the Auto Program feature will be marked Added. However, some of these channels may be scrambled, or undesired by the customer. This feature allows the customer to selectively mark any channel as Deleted or Added.

To change the status of a channel from Added to Deleted or vice versa, press the Left/Right Arrow key.

To change the channel while adding or deleting channels, use the Channel Up/Down keys, or press the desired channel digits, followed by ‘Enter’. If Channel Up/Down is pressed, the next or previous channel which was marked Added will appear. If only one channel is present, to change the channel the customer must use the digit key pad to select a channel.

CLOCK SET

This Setup Menu Line allows the customer to set the clock time and date.

When no time is set, the display shows: —:— — There are two ways to set the time:

1. Direct Entry (preferred) Use the digit keys, followed by ‘Enter’ or Select Up/Down.

2. Left/Right Arrow keys

When the first digit is introduced, the display shows:

—:-d AM < Timer

When the time is set, the display shows:

hh:mm AM < Timer

where:

d = digit, mm = minutes hh = hours

Entering an invalid time (“0” for example) will result in the clearing of the current time (—:— —). Also when only one digit is pressed and no other is pressed in an interval of seven seconds, the current time will be cleared.

Note: When the first digit is pressed (or the Left/Right

Arrow is pressed), a TIMER icon appears on the right side of the AM/PM status.

TIMER MENU

The Timer Setup line allows entry into the Timer Menu. This feature consists of three menu lines: “On Time”,

“Off Time”, and “On/Off Timer”. This feature allows the set to turn on and off at the times specified in “On Time” and “Off Time”. The “On/Off Timer” turns the feature on and off. Setting the “On Time” or the “Off Time” is identical to the Clock Set feature in the Setup Menu.

CM151 1-10 CA - 1384 MENUS

USER MENUS 221-1384 (continued)

SLEEP TIMER

To set the Sleep Timer use the Left/Right Arrow keys to select a time. Then use the Up/Down keys to select the time desired for the sleep timer to count.

ON TIME

The On Time and can be set the same way as Clock Set.

OFF TIME

The Off Time and can be set the same way as Clock Set.

ON/OFF TIME

The On-Off Timer can be selected using the Left/Right keys.

Pressing the TIMER key will increment the Sleep timer to 0:10 and restore all other key functions.

Timer Menu

Sleep Timer On Time Off Time

On/Off Timer

Must Set Hours

AUXILIARY BLOCK

To Block or Unblock the sources, press the Left/Right Arrow key.

Advanced

TV Control

Aux. Block

MPAA Age Control Content Block Set Hours Set Password Lock On/Off

The SOURCE key may be used to view the video source. The following menu appears:

MPAA

The MPAA selector allows the customer to select either to have the channel Unblocked, From G, From PG, From PG-13, From R, From NC-17, or X.

Sources Blocked

Note: Both the On Time and the Off Time must be

specified, before turning on the “On/Off Timer”—otherwise an error message (“Must Set On/Off”) will be displayed on the On/Off Timer line.

ADVANCED TV CONTROL MENU

The Advanced TV Ctrl line allows entry into the Advanced TV Control Menu.

BLOCK CHANNEL

To Block or Unblock the current channel , press the Left/ Right Arrow key.

To change the channel while Blocking or Unblocking channels, use the Channel Up/Down keys, or press the desired channel digits, followed by ENTER. (If Channel Up/Down is pressed, the next or previous channel which was marked Added will appear.)

AGE BLOCK

Use the Left/Right Arrow keys to select the Age Block Menu.

Age Block

General

Children

GENERAL BLOCK

To block channels for a general age, select either: Unblocked, TV-G, TV-PG, TV-14 or TV-MA.

CHILDREN BLOCK

To block channels for children, select either: Unblocked, TV-Y or TV-Y7.

TV-Y

CM151 1-11 CA - 1384 MENUS

USER MENUS 221-1384 (continued)

CONTENT BLOCK

Use the Left/Right Arrow keys to select the Content Block Menu.

Content Block

Dialog

Language Sex Scenes Violence F Violence

DIALOG BLOCK

To block the dialog, use the Left/Right Arrow keys to select either: Unblocked, TV-PG or TV-14 as shown below.

LANGUAGE

To block the dialog, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA.

SEX SCENES BLOCK

To block the Sex Scenes, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA as shown below.

VIOLENCE BLOCK

To block the Violence, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA as shown below.

F VIOLENCE BLOCK

To block the FViolence, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA as shown below.

SET HOURS

Use the Left/Right Arrow keys to adjust the number of hours the Parental Control feature will be active. The valid hour range is 1 to 99.

SET PASSWORD

Press the Left/Right Arrow key to allow Password entry.

TO ENTER PASSWORD

The software accepts four-digit codes only. A password must be entered by the customer.

TV-PG

REPEAT PASSWORD

After a four-digit code has been entered, the software requires the customer to reenter the same four-digit code.

PASSWORD NOT ACCEPTED

If an invalid code is entered, or the two codes do not match, an error message (“Not Accepted!”) will appear.

This error message also appears when no code is entered for the password or if only one digit is entered and no other digit has been entered.

LOCK ON/OFF

This item turns the Advanced TV feature On / Off. The Adv. TV Ctrl. feature can only be turned on if the hours > 0, and a password has been set. Otherwise the Lock On/ Off line will display either of the following error messages: (“Must Set Hours”) or (“Must Set Password.”).

REENTERING ADVANCED TV CONTROL MENU

If the Parental Control feature has been activated, the software will not allow immediately entry into the Advanced TV Control Menu. Instead, it will prompt for the correct password. If the correct password is entered, the Advanced TV Control menu will appear, with the highlighted item “Lock On/Off”, which assumes that the customer most likely wants to turn the feature off. If an incorrect password is entered, an error message (“Not Accepted!) appears, and will not disappear until 5 seconds has elapsed. This extended time provision increases the amount of time necessary for a child to “crack” the password.

· The Advanced TV Control menu will remain up for 10 seconds after the last key press.

· The QUIT key may be pressed to remove the PC menu.

· Entry into the Factory Menu will immediately turn off the PC feature

· The PC Hours and Password will be cleared upon exit of the Adv. TV Ctrl menu (unless the Adv. TV Ctrl feature has been turned on.)

CAPTION/TEXT

This feature allows the customer to activate or deactivate Captions or Text.

Pressing the Left/Right Arrow keys sequentially through each of the following Caption/Text options.

Caption 1 Caption 2 Caption 3 Caption 4

Text 1 Text 2 Text 3 Text 4

When the Text option is selected and a text box appears, if the CC key is pressed, the Caption box that allows setting to On, Caption When Muted or Off will appear.

CM151 1-12 CA - 1384 MENUS

USER MENUS 221-1384 (continued)

When captions are being displayed, if one of the Volume Up/Down keys is pressed, the volume bar will not appear.

When the Captions are not activated and the CC key is pressed, the Caption Box will appear, that allows choose On, Caption When Muted or Off.

AUDIO MODE

There are two audio modes available: Stereo and Mono.

LANGUAGE

This feature allows the customer to change the menu language to English, Spanish or French by pressing the Left/Right Arrow keys.

VIDEO MENU

All menu items are adjusted with the Left/Right Arrow keys. Each selection of the video menu is shown below.

CONTRAST

Contrast adjustment has 64 steps ( 0 to 63 ).

PICTURE PREF

This feature allows the customer to maintain two separate Contrast, Brightness, Color, Tint, Sharpness setting “Custom” and “Preset”. The “Preset” setting is set by the factory.

MUTE

When the Mute key is pressed, the speakers will be turned off.

WITH CHANNEL DISPLAY

The following display appears when the channel display is on.

Ch. 14

7:30 PM

Muted

Video Menu

Contrast

Brightness Color Tint Sharpness Picture Pref.

BRIGHTNESS

The brightness value sent to the video processor is (RfBrt+Customer Brightness) if the source is the RF source, or (AuxBrt + Customer Brightness) if the source is the AUX source. RfBrt and AuxBrt appear in the factory menu.

COLOR

Color adjustment also has 64 steps ( 0 to 63 ).

TINT

Tint Adjustment has 64 steps ( 0 to 63 ). A center mark indicates step 29.

SHARPNESS

Sharpness adjustment has 64 steps ( 0 to 63 ).

WITHOUT CHANNEL DISPLAY

The following display appears when the channel display is off.

Muted

CHANNEL TIMER DISPLAY

When the ENTER key is pressed the TV display will appear. The first line displays the channel. The second line, the time is displayed. The Audio mode is shown in the last line (either Mono or Stereo).

CM151 1-13 CA - 1384 MENUS

USER MENUS 221-1384 (continued)

Channel Labels

A&E CMTV ESPN HSE NOS TBN VC ABC CNBC ESPN2 HSN PBS TELE VCR ACTS CNN ET IC PLAY TLC VH-1 ADC COM EWTN INSP PTL TMC VISN AMC CSPN FAM JCN QVC TNN VJN BCC CSP2 FNN LIFE RDS TNT WB BET CTN FOX MAX REQ TRAV WGN BRAV CTV F&V ME/U SC TSN WTBS CA DIS FX MMT SCFI TVA WWOR CBC DISC GALA MTV SHOW TWC YTV CBN E! HBO NBC SIN UPN - - - CBS ENC HN NICK TBS USA None NOTE: Selecting the "- - - -" label option means the channel will not be

displayed on the channel/time/audio signal display. Selecting the "None" option means the channel will not have a label.

MOTION PICTURE ASSOCIATION OF AMERICA (MPAA) RATING SYSTEM

G General Audiences Content not offensive to most viewers. PG Parental Guidance Content is such that parents may not want their children to view the program.

Suggested

PG-13 Parental Guidance Program is inappropriate for preteens, with a greater degree of offensive

Suggested material than a PG-rated program.

R Restricted viewing Not for children under age 17. Strong elements of sex and/or violence. NC-17 Restricted Viewing Not for children under age 17 under any circumstances. Strong sexual content. X Hard Core Films Same as NC-17 rating.

Note: Zenith Electronics Corporation is not liable for any program content that appears when using this rating system;

as always, user discretion is advised.

TV PARENTAL GUIDELINE RATING SYSTEM

G General Audiences Content not offensive to most viewers.

TV-G General Audience Considered suitable for all audiences; children may watch unattended.

TV-PG Parental Guidance Unsuitable for younger children, may contain: Suggestive Dialog, Bad Lan-

Suggested guage, Sex, and Violence Scenes.

TV-14 Parents Strongly Unsuitable for children under 14, may contain: Strong Dialog, Bad Language,

Cautioned Sex, and Violence Scenes.

TV-MA Mature Audience Only Adults only, may contain: Strong Dialog, Bad Language, Sex, and Violence Scenes.

CHILDRENS’ CLASSIFICATIONS

TV-Y Children Considered suitable for all children under 7 years old. TV-Y7 Children 7 and over Considered suitable for children over 7, may contain Fantasy Violence Scenes.

CM151 1-14 CA - 1384 MENUS

USER MENUS 221-1385

SETUP MENU

Shown below is the Setup Menu for CA (A24) chassis with its options for each item which are described as follows:

Setup Menu

EZ Program

Add/Del/Surf Clock Set Captions Caption/Text Language

EZ PROGRAM

The EZ Program feature automatically searches for all available channels and marks them as ‘added’ so that they may be accessed via the channel Up/Down key.

In the EZ Program screen:

· A message at the top displays “EZ Program” to let the customer know that he/she has entered the EZ Program feature.

· A line at the bottom of the screen shows that the Up/Down and Left/Right Arrow keys are used for Auto Program selections.

· The current RF input type (Off Air Antenna or Cable TV) is highlighted. Use the Up/Down Arrow keys to change the RF input type.

To start the Auto Program, press the Left/Right Arrow key. If the Cable TV input type is selected, the EZ Program routine will determine what type of cable system is present.

Notes:

To Program

• EZ Program clears all Surfing channels which were

added.

• While searching for channels, all keys except for

the Power key are disabled. This prevents an incomplete EZ Program procedure.

• Running the EZ Program will clear the factory

mode, if it was active. This happens at the end of the EZ Program.

• If the EZ Program line in the Setup Menu is ‘red’,

this indicates that the module did not pass one of the test equipment’s tests.

• If no channels are found then the following

message will appear: “Make sure that the cable/ ant. is connected, and try again.”

CHANNEL Add/Del/Surf

After running the EZ Program, all channels found by the EZ Program feature will be marked ‘Added’. However, some of these channels may be scrambled, or undesired by the customer. The Add/Del/Surf feature allows the customer to selectively mark any channel as ‘Deleted’ or ‘Added’.

To change the status of a channel, press the Right/Left Arrow key.

To change the channel while adding or deleting channels, use the Channel Up/Down keys, or press the desired channel digits, followed by ‘Enter’. If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear. If only one channel is present, to change the channel the customer must use the digit key pad to select a channel.

CLOCK SET

When no time is set, the display shows: —:— — There are two ways to set the time:

1. Direct Entry (preferred)Use the digit keys, followed by ‘Enter’ or Select Up/Down.

2. Left/Right Arrow keys

When the first digit is introduced, the display shows:

—:-d AM < FLSHBK

When the time is set, the display shows:

hh:mm AM < FLSHBK

where:

d = digit, mm = minutes hh = hours

Entering an invalid time (“0” for example) will result in the clearing of the current time (—:— —). Also when only one digit is pressed and no other is pressed in an interval of seven seconds, the current time will be cleared.

Note: When the first digit is pressed (or the Left/

Right Arrow Key is pressed), a TIMER icon appears on the right side of the AM/PM status.

The Left/Right Arrow keys is the other way of setting the time. The drawback with using the Left/Right Arrow keys is if the customer uses the Right Arrow key, the time will increment to the next minute and so on until the customer finds the time desired. On the other hand, if the Left Arrow key is pressed, the time will decrement one minute and so on until the customer finds the time desired.

CM151 1-15 CA - 1385 MENUS

USER MENUS 221-1385 (Continued)

CAPTIONS

This feature allows the customer to select: On, Caption When Muted or Off options.

To change the status of captions, press the Right/Left Arrow key to select either On, Captions When Muted or Off.

CAPTION/TEXT

This feature allows the customer to activate or deactivate Captions or Text.

Pressing the Left/Right Arrow keys sequentially through each of the following Caption/Text options.

Caption 1 Caption 2 Caption 3 Caption 4

Text 1 Text 2 Text 3 Text 4

Notes:

• When the Text option is selected and a text box

appears, if the CC key is pressed, the Caption box will appear.

• When captions are being displayed, if one of the

Volume Up/Down keys is pressed, the volume bar will not appear.

• When the Captions are not activated and the CC

key is pressed, the Caption Box will appear.

LANGUAGE

This feature allows the customer to change the menu language to English, Spanish or French by pressing the Left/Right Arrow keys.

SPECIAL FEATURES MENU

This Menu contains the Timer Setup, Ch. Labels, Adv. TV Ctrl, and EZ Demo.

TIMER MENU

The Timer Menu contains the Sleep Timer and the On/ Off Timer features.

Timer Menu

Sleep Timer On Time Off Time

On/Off Timer

SLEEP TIMER

Sleep Timer (via Timer Menu) The Left / Right Arrows can be used to adjust the current

sleep timer setting: Off, 0:10, 0:20, 0:30, 1:00, 1:30, 2:00, 3:00, 4:00

ON/OFF TIMER

This feature consists of three menu lines: “On Time”, “Off Time”, and “On/Off Timer”. This feature allows the set to turn on and off at the times specified in “On Time” and “Off Time”.

The “On Time” and “Off Time” are set identical to the Clock Set feature in the Setup Menu.

An Off Time must be specified, before turning on the “EZ Timer”—otherwise an error message (“Must Set On/ Off”) will be displayed on the On/Off Timer line.

Must Set Hours

Special Features

Timer Setup

Ch. Labels XDS Display Adv TV Ctrl EZ Demo

CM151 1-16 CA - 1385 MENUS

To Set Timer

The “EZ Timer” option turns the feature on and off.

CH LABELS OPTION

This feature allows the customer to select a channel label for the current station. This channel label is displayed in the Channel/Time display. Initially, all channel labels are set to ‘——‘, which results in no channel being displayed in the Channel/Time display.

To change the current channel label, press the Left/ Right Arrow key.

To change the channel while adjusting channel labels, use the Channel Up/Dn keys, or press the desired channel digits, followed by ‘Enter’. (If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear.)

USER MENUS 221-1385 (Continued)

Notes:

• When the channel label is selected (see 1-20 for

labels), then the Auto channel label is activated, in other words, the program automatically takes the channel label of the signal that is send by broadcasting through the XDS service.

• If the label None is selected, the Auto channel label

is deactivated.

ADVANCED TV CONTROL

This Special Features line allows entry into the Parental Control Menu.

Advanced

TV Control

Aux Block

MPAA Age Control Content Block Set Hours Set Password Lock On/Off

To Block or Unblock the current channel , press the Left/ Right Arrow key.

To change the channel while Blocking or Unblocking channels, use the Channel Up/Down keys, or press the desired channel digits, followed by ENTER.

(If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear.)

AUXILIARY BLOCK

To Block or Unblock the sources, press the Left/Right Arrow key.

The SOURCE key may be used to view the video source.

MPAA

The MPAA selector allows the customer to select either to have the channel Unblocked, From G, From PG, From PG-13, From R, From NC-17, or X.

AGE BLOCK

Use the Left/Right Arrow keys to select the Age Block Menu.

Parental Control

CONTENT BLOCK

Use the Left/Right Arrow keys to select the Content Block Menu.

To block the dialog, use the Left/Right Arrow keys to select either: Unblocked, TV-PG or TV-14.

Content Block

Dialog

Language Sex Scenes Violence F Violence No Content

To block the dialog, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA.

SEX SCENES

To block the Sex Scenes, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA.

To block the Violence, use the Left/Right Arrow keys to select either: Unblocked, TV-PG,TV-14, or TV-MA.

SET HOURS

Use the Left/Right Arrow keys to adjust the number of hours the Parental Control feature will be active. The valid hour range is 1 to 99.

SET PASSWORD

Press the Left/Right Arrow key to allow Password entry. The software accepts four-digit codes only. A password

must be entered by the customer. After a four-digit code has been entered, the software

requires the customer to reenter the same four-digit code.

If an invalid code is entered, or the two codes do not match, an error message (“Not Accepted!”) will appear. This error message also appears when no code is entered for the password or if only one digit is entered and no other digit has been entered.

Unblocked

To block channels for a general age, select either: Unblocked, TV-G, TV-PG, TV-14 or TV-MA.

CM151 1-17 CA - 1385 MENUS

USER MENUS 221-1385 (Continued)

LOCK ON/OFF

This item turns the Parental Control feature On / Off. The PC feature can only be turned on if the hours > 0, and a password has been set. Otherwise the Lock On/ Off line will display either of the following error messages: (“Must Set Hours”) or (“Must Set Password.”)

REENTERING PARENTAL CONTROL

If the Parental Control feature has been activated, the software will not allow immediately entry into the Parental Control Menu—instead, it will prompt for the correct password. If the correct password is entered, the Parental Control menu will appear, with the highlighted item “Lock On/Off”, which assumes that the customer most likely wants to turn the feature off. If an incorrect password is entered, an error message (“Not Accepted!) appears, and will not disappear until 5 seconds has elapsed. This extended time provision increases the amount of time necessary for a child to “crack” the password.

Notes:

• The Parental Control menu will remain up to 10

seconds after the last key is pressed.

• The QUIT key may be pressed to remove the PC menu.

• Zenith VCR, Zenith Cable, and Zenith Private Label

TV codes will not temporarily disable the EZ Demo—only Zenith TV codes will be accepted.

• The Auto Demo on/off setting is not stored to the

EEPROM.

• The Sleep Timer is suspended while the EZ Demo is

set on.

AUDIO MENU

All menu items are adjustment with the Left/Right Arrow keys.

Audio Menu

Bass

Ttreble Balance Audio Mode Front Surr EZ SoundRite Speakers EZ Sound Ctl

• Entry into the Factory Menu will immediately turn

off the PC feature.

• The PC Hours and Password will be cleared upon

exit of the PC menu (unless the PC feature has been turned on).

EZ DEMO

The EZ Demo is designed to show-off the icon menus and other icon displays on the sales floor, it will show also the scroll function. The EZ Demo feature can be turned on/off with the Left/Right Arrow keys.

Initially, when the feature is activated, as soon as the OSD times out, the EZ Demo will start. At this point, pressing any key will temporarily disable the EZ Demo for 18 seconds, and if the EZ Demo is working and Menu key is pressed then the Setup Menu will be displayed and the EZ Demo ON/OFF will be displayed to allow the customer to enable or disable.

Notes:

• When the Setup Menu is displayed, the highlighted

line item is always ‘Add/Del/Surf’ and the current channel is temporarily made to be ‘Surf’ so that the moving surfer can be demonstrated.

• This channel will revert to its original ‘Add/Del/

Surf’ setting with the next channel change.

BASS

Bass adjustment has 15 steps (0 to 14).

TREBLE

Treble adjustment has 15 steps (0 to 14).

BALANCE

Balance adjustment has 29 steps (0 to 28).

AUDIO MODE

There are three audio modes available: Mono, Stereo, 2nd Audio/SAP.

If 2nd Audio/SAP is selected, but the current channel does not support SAP, then either Stereo or Mono will be heard.

FRONT SURROUND

Front Surround can be set ‘ON’ or ‘Off’, regardless of the current Audio Mode setting. However, the Front Surround effect can only be heard when the Audio Mode has been set to ‘Stereo’ and a Stereo signal is present. When this condition exists, there will be a short mute (200ms) while toggling the Surround ‘On’ to ‘Off’, to embellish Front Surround activation.

CM151 1-18 CA - 1385 MENUS

USER MENUS 221-1385 (Continued)

SOUND RITE

The Sound Rite feature is used to obtain a uniform volume level, particularly while changing channels. The Sound Rite feature can be best demonstrated on a channel with no signal (snow).

SPEAKERS

The Speaker feature is used to turn off the internal speakers. It does this by pulling the power amp mute line.

EZ SOUND CONTROL

The EZ Sound Control has six selections the customer can select. The selections available are: Custom, Normal, Stadium, News, Music and Theater. The Left/Right Arrow keys may be used to select any of the choices mentioned.

VIDEO MENU

All menu items are adjusted with the Left/Right Arrow keys.

CONTRAST

Contrast adjustment has 64 steps (0 to 63).

BRIGHTNESS

Sharpness adjustment has 64 steps (0 to 63)

COLOR

Color adjustment has 64 steps (0 to 63).

TINT

Tint Adjustment has 64 steps (0 to 63). A center mark indicates step 29

SHARPNESS

Sharpness adjustment has 64 steps (0 to 63).

EZ PICTURE

This feature allows the customer to maintain two separate Contrast, Brightness, Color, Tint, Sharpness setting “Custom” and “Preset”. The “Preset” setting are set by the factory.

Video Menu

Contrast

Brightness Color Tint Sharpness Picture Pref.

CM151 1-19 CA - 1385 MENUS

USER MENUS 221-1385 (Continued)

Channel Labels

A&E CMTV ESPN HSE NOS TBN VC ABC CNBC ESPN2 HSN PBS TELE VCR ACTS CNN ET IC PLAY TLC VH-1 ADC COM EWTN INSP PTL TMC VISN AMC CSPN FAM JCN QVC TNN VJN BCC CSP2 FNN LIFE RDS TNT WB BET CTN FOX MAX REQ TRAV WGN BRAV CTV F&V ME/U SC TSN WTBS CA DIS FX MMT SCFI TVA WWOR CBC DISC GALA MTV SHOW TWC YTV CBN E! HBO NBC SIN UPN - - - CBS ENC HN NICK TBS USA None NOTE: Selecting the "- - - -" label option means the channel will not be

displayed on the channel/time/audio signal display. Selecting the "None" option means the channel will not have a label.

MOTION PICTURE ASSOCIATION OF AMERICA (MPAA) RATING SYSTEM

G General Audiences Content not offensive to most viewers. PG Parental Guidance Content is such that parents may not want their children to view the program.

Suggested

PG-13 Parental Guidance Program is inappropriate for preteens, with a greater degree of offensive

Suggested material than a PG-rated program.

R Restricted viewing Not for children under age 17. Strong elements of sex and/or violence. NC-17 Restricted Viewing Not for children under age 17 under any circumstances. Strong sexual content. X Hard Core Films Same as NC-17 rating.

Note: Zenith Electronics Corporation is not liable for any program content that appears when using this rating system;

as always, user discretion is advised.

TV PARENTAL GUIDELINE RATING SYSTEM

G General Audiences Content not offensive to most viewers.

TV-G General Audience Considered suitable for all audiences; children may watch unattended.

TV-PG Parental Guidance Unsuitable for younger children, may contain: Suggestive Dialog, Bad Lan-

Suggested guage, Sex, and Violence Scenes.

TV-14 Parents Strongly Unsuitable for children under 14, may contain: Strong Dialog, Bad Language,

Cautioned Sex, and Violence Scenes.

TV-MA Mature Audience Only Adults only, may contain: Strong Dialog, Bad Language, Sex, and Violence Scenes.

CHILDRENS’ CLASSIFICATIONS

TV-Y Children Considered suitable for all children under 7 years old. TV-Y7 Children 7 and over Considered suitable for children over 7, may contain Fantasy Violence Scenes.

CM151 1-20 CA - 1385 MENUS

USER MENUS 221-1386

Ch. 5 Added

Auto Program

Clock Set Captions Caption/Text Audio Mode Language

Add/Del/Surf

Setup Menu

USER MENUS 221-1386

SETUP MENU

Below is the Setup Menu for the CA Domestic (A30) chassis with each of its options described below.

Setup Menu

Auto Program

Add/Del/Surf Clock Set Captions Caption/Text Audio Mode Language

AUTO PROGRAM

The Auto Program feature automatically searches for all available channels and marks them as ‘added’ so that they may be accessed via the channel Up/Down key.

In the Auto Program screen:

· A message at the top displays “Auto Program” to let the customer know that they have entered the Auto Program feature.

· A line at the bottom of the screen shows that the Up/Down and Left/Right Arrow keys are used for Auto Program selections.

· The current RF input type (Off Air Antenna or Cable TV) is highlighted. Use the Up/Down Arrow keys to change the RF input type.

To start the Auto Program, press the Left/Right Arrow key. If the Cable TV input type is selected, the Auto Program routine will determine what type of cable system is present.

To Program

Notes:

• Auto Program clears all Surfing channels, which

were added.

• While searching for channels, all keys except for

the Power key are disabled. This prevents an incomplete Auto Program procedure.

• Running the Auto Program will clear the factory

mode, if it was active. This happens at the end of the Auto Program.

• If the Auto Program line in the Setup Menu is

‘red’, this indicates that the module did not pass one of the test equipment’s tests.

• If no channels are found then the following

message will appear: “Make sure that the cable/ ant. is connected, and try again.”

CHANNEL ADD/DEL/SURF

After running the Auto Program, all channels found by the Auto Program feature, will be marked ‘Added’. However, some of these channels may be scrambled, or undesired by the customer. The Add/Del/Surf feature allows the customer to selectively mark any channel as ‘Deleted’ or ‘Added’.

To change the status of a channel, press the Right/Left Arrow key.

To change the channel while adding or deleting channels, use the Channel Up/Down keys, or press the desired channel digits, followed by the ENTER key. If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear. If only one channel is present, to change the channel the customer must use the digit keypad to select a channel.

The following figure shows the options for the Add/ Del/Surf feature.

Auto Program

Cable TV

Off Air Antenna

Press

CM151 1-21 CA - 1386 MENUS

To Change, To Program

USER MENUS 221-1386 (Continued)

CLOCK SET

When no time is set, the display shows: —:— —

Setup Menu

There are two ways to set the time:

1. Direct Entry (preferred) Use the digit keys, followed by ‘Enter’ or Select Up/Down.

2. Left/Right Arrow keys

When the first digit is introduced, the display shows:

—: -d AM <FLSHBK

When the time is set, the display shows:

hh: mm AM <FLSHBK Where: d = digit, mm = minutes hh = hours

Entering an invalid time (“0” for example) will result in the clearing of the current time (—:— —). Also when only one digit is pressed and no other is pressed in an interval of seven seconds, the current time will be cleared.

Setup Menu

Auto Program Add/Del/Surf

Clock Set

Captions Caption/Text Audio Mode Language

10:30 AM

FLSHBK

Auto Program Add/Del/Surf Clock Set

Captions

Caption/Text Audio Mode Language

To change the status of captions, press the Right/Left Arrow key to select either On, Off or Captions When Muted.

CAPTION/TEXT

This feature allows the customer to activate or deactivate Captions or Text.

Setup Menu

Auto Program Add/Del/Surf Clock Set Captions

Caption/Text

Audio Mode Language

Off

Caption 1

Note: When the first digit is pressed (or the Left/

Right Arrow Key is pressed), a TIMER icon appears on the right side of the AM/PM status.

The Left/Right Arrow keys is the other way of setting the time. The drawback with using the Left/Right Arrow keys is if the customer uses the Right Arrow key, the time will increment to the next minute and so on until the customer finds the time desired. On the other hand, if the Left Arrow key is pressed, the time will decrement one minute and so on until the customer finds the time desired.

CAPTIONS

This feature allows the customer to select: Off, On, or Caption When Muted options.

CM151 1-22 CA - 1386 MENUS

Pressing the Left/Right Arrow keys sequentially through each of the following Caption/Text options.

Caption 1 Caption 2 Caption 3 Caption 4

Text 1 Text 2 Text 3 Text 4

Notes:

• When captions are being displayed, if one of the

Volume Up/Down keys is pressed, the volume bar will not appear.

• When the Captions are not activated and the CC

key is pressed, the Caption Box will appear.

USER MENUS 221-1386 (Continued)

Off

Sleep Timer

On Time Off Time On/Off Timer

Timer Menu

AUDIO MODE

This feature allows the customer to change the audio mode to either Stereo or Mono by pressing the Left/ Right Arrow keys.

Setup Menu

Auto Program Add/Del/Surf Clock Set Captions Caption/Text

Audio Mode

Language

LANGUAGE

This feature allows the customer to change the menu language to English, Spanish or French by pressing the Left/Right Arrow keys.

Setup Menu

Stereo

TIMER MENU

The Timer Menu contains the Sleep Timer and the On/ Off Timer features.

SLEEP TIMER

(via Timer Menu) The Left/Right Arrows can be used to adjust the current

sleep timer setting: Off, 0:10, 0:20, 0:30, 1:00, 1:30, 2:00, 3:00 or 4:00

ON TIME

This feature allows the TV set to turn on at the time specified in On Time.

Auto Program Add/Del/Surf Clock Set Captions Caption/Text Audio Mode

Language

SPECIAL FEATURES MENU

This Menu contains the Timer Setup, Ch. Labels, XDS Display, Parental Ctl, and Auto Demo.

Special Features

Timer Setup

Ch. Labels XDS Display Parental Ctl Auto Demo

CM151 1-23 CA - 1386 MENUS

English

To Set Timers

The “On Time” is set identical to the Clock Set feature in the Setup Menu.

OFF TIME

An Off Time must be specified, before turning on the “On/Off Timer”— otherwise an error message (“Must Set On/Off”) will be displayed on the On/Off Timer line.

This feature allows the TV set to turn off at the time specified in Off Time.

The “Off Time” is set identical to the Clock Set feature in the Setup Menu.

ON/OFF TIMER

The On/Off Timer option turns the Timer On or Off.

CH LABELS OPTION

This feature allows the customer to select a channel label for the current station. This channel label is displayed in the Channel/Time display. Initially, all channel labels are set to ‘——‘, which results in no channel being displayed in the Channel/Time display.

To change the current channel label, press the Left/ Right Arrow key.

USER MENUS 221-1386 (Continued)

To change the channel while adjusting channel labels, use the Channel Up/Down keys, or press the desired channel digits, followed by ‘Enter’. (If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear.)

Notes:

• When the channel label is selected (see 1-28 for labels), then the Auto channel label is activated, in other words, the program automatically takes the channel label of the signal that is send by broadcasting through the XDS service.

• If the label None is selected, the Auto channel label is deactivated.

XDS DISPLAY

Pressing the Left/Right Arrow Keys allows the customer to select the XDS Display either On or Off.

PARENTAL CONTROL

The Parental Control Menu items are adjusted with the Up Arrow key.

Parental Control

Aux Sources

MPAA Age Block Content Block Set Hours Set Password Lock On/Off

Sources Blocked

GENERAL BLOCK

Once entered into the Age Block Menu, the customer has the option to block programs by a General Age Rating or to block programs by a Children Rating.

To block television programs for a General Age Rating use the Left/Right Arrow keys to select either Unblocked, TV-G and Above, TV-PG and Above, TV-14 and Above or TV-MA.

Age Menu

General

Children

CHILDREN BLOCK

To block television programs for Children’s Age Rating, use the Left/Right Arrow keys to select either Unblocked, TV-Y and Above or TV-Y7.

CONTENT BLOCK

Use the Left/Right Arrow keys to select the Content Block Menu.

To block television programs with F Violence rating, use the Left/Right Arrow keys to select either: Unblocked, TV-Y7.

Unblocked

AUXILIARY BLOCK SOURCES

To Block or Unblock the sources, press the Left/Right Arrow key.

The SOURCE key may be used to view the other source.

MPAA

The MPAA selector allows the customer to have television programs blocked using the MPAA rating. The customer may select either Unblocked, G and Above, PG and Above, PG-13 and Above, R and Above, NC-17 and Above, or X.

AGE BLOCK

Use the Left/Right Arrow keys to select the Age Block Menu.

CM151 1-24 CA - 1386 MENUS

Content Block

Dialog Language Sex Scences Violence

F Violence

No Rating

NO RATING BLOCK

To block television programs with No Rating, use the Left/Right Arrow keys to select either: Unblocked and Blocked.

Unblocked

USER MENUS 221-1386 (Continued)

SET HOURS

Use the Left/Right Arrow keys to adjust the number of hours the Parental Control feature will be active. The valid hour range is 1 through 99 hours.

SET PASSWORD

Press the Left/Right Arrow key to allow Password entry

TO ENTER PASSWORD

The software accepts four-digit codes only. The customer must enter a password.

REPEAT PASSWORD

After a four-digit code has been entered, the software requires the customer to reenter the same four-digit code.

PASSWORD NOT ACCEPTED

If an invalid code is entered, or the two codes entered do not match, a blinking error message (“Not Accepted!”) will appear.

This error message also appears when no code is entered for the password or if only one digit is entered and no other digit has been entered.

LOCK ON/OFF

This item turns the Parental feature On or Off. The Parental Ctrl. feature can only be turned on if the hours>0, and a password has been set. Otherwise the Lock On/Off line will display either of the following error messages: “Must Set Hours” or “Must Set Password.”

REENTERING PARENTAL CONTROL MENU

If the Parental Control feature has been activated, the software will not allow immediately entry into the Parental Control Menu. Instead, it will prompt for the correct password.

If the correct password is entered, the Parental Control menu will appear, with the highlighted item “Lock On/ Off”, which assumes that the customer most likely wants to turn the feature off. If an incorrect password is entered, an error message (“Not Accepted!”) appears, and will not disappear until 5 seconds has elapsed. This extended time provision increases the amount of time necessary for a child to “crack” the password.

Notes:

• The Parental Control menu will remain up for 10

seconds after the last key is pressed.

• The QUIT key may be pressed to remove the PC

menu.

• Entry into the Factory Menu will immediately turn

off the PC feature

• The PC Hours and Password will be cleared upon

exit of the Parental Ctrl menu (unless the Parental Ctrl feature has been turned on).

DISPLAY WHEN PARENTAL CONTROL IS ACTIVE

When the Parental Control has been activated the channel is blocked. The display on the screen shows two lines. The first line displays a message saying that the “PARENTAL LOCKOUT IS ACTIVE.”

The second line displays the amount of time (in hours) left in the lockout.

CH 14

3:35 PM

MONO

Parental Control

Password?

CM151 1-25 CA - 1386 MENUS

Enter Code: ----

Parental Lockout Is Active

01:23 Hours Remaining

USER MENUS 221-1386 (Continued)

AUTO DEMO

The Auto Demo is designed to “show-off” the icon menus and other icon displays on the sales floor. The Auto Demo feature can be turned On/Off with the Left/Right Arrow keys.

Initially, when the feature is activated, as soon as the OSD times out, the Auto Demo will start. At this point, pressing any key will temporarily disable the Auto Demo for 18 seconds, and if the Auto Demo is working and the Menu key is pressed then the Setup Menu will be displayed and the Auto Demo feature will be selected allowing the customer to disable it.

VIDEO MENU

All menu items are adjusted with the Left/Right Arrow keys.

Video Menu

Contrast

Brightness Color Tint Sharpness Color Temp Picture Pref.

CONTRAST

Contrast adjustment has 64 steps (0 to 63).

BRIGHTNESS

The brightness value sent to the video processor is (RfBrt + Customer Brightness) if the source is the RF source, or (AuxBrt + Customer Brightness) if the source is the AUX source. RfBrt and AuxBrt appear in the factory menu.

SHARPNESS

Sharpness adjustment has 64 steps (0 to 63).

COLOR TEMP

Sets the color temperature. The two settings are COOL and WARM.

PICTURE PREF

PIP Menu

Contrast

Tint Size

This feature allows the customer to maintain two separate Contrast, Brightness, Color, Tint, Sharpness setting “Custom” and “Preset”. The factory sets the “Preset” setting.

PIP MENU

All menu items are adjusted with the Left/Right Arrow keys.

CONTRAST

Contrast adjustment has 64 steps (0 to 63). A center mark indicates step 31. This item allows the contrast adjustment of the PIP window.

TINT

This item allows adjust the PIP tint. Tint Adjustment has 64 steps (0 to 63).

COLOR

Color adjustment has 64 steps (0 to 63).

TINT

Tint Adjustment has 64 steps (0 to 63). A center mark indicates step 29.

CM151 1-26 CA - 1386 MENUS

SIZE

This option is used to select size of the PIP window. The customer may select the PIP window size either large or small.

USER MENUS 221-1386 (Continued)

SOURCE MENU

This menu has two items, Main Source and PIP Source. The selection of either Main Source or PIP Source determines the signal that feeds the video processor. The options available are Antenna/Cable or Aux. as shown below.

Source Menu

Main Source

Antenna/Cable

PIP Source

MAIN SOURCE

The selection of Main Source determines the signal that feeds the video processor.

CHANNEL/TIME/AUDIO DISPLAY WITHOUT XDS.

CH 14

ABC

3:35 PM

Muted

VOLUME DISPLAY

When the Volume Up/Down key is pressed, the following display appears.

PIP SOURCE

The selection of PIP Source determines the signal that feeds the video processor.

Volume

CM151 1-27 CA - 1386 MENUS

USER MENUS 221-1386 (Continued)

Channel Labels

A&E CMTV ESPN HSE NOS TBN VC ABC CNBC ESPN2 HSN PBS TELE VCR ACTS CNN ET IC PLAY TLC VH-1 ADC COM EWTN INSP PTL TMC VISN AMC CSPN FAM JCN QVC TNN VJN BCC CSP2 FNN LIFE RDS TNT WB BET CTN FOX MAX REQ TRAV WGN BRAV CTV F&V ME/U SC TSN WTBS CA DIS FX MMT SCFI TVA WWOR CBC DISC GALA MTV SHOW TWC YTV CBN E! HBO NBC SIN UPN - - - CBS ENC HN NICK TBS USA None NOTE: Selecting the "- - - -" label option means the channel will not be

displayed on the channel/time/audio signal display. Selecting the "None" option means the channel will not have a label.

MOTION PICTURE ASSOCIATION OF AMERICA (MPAA) RATING SYSTEM

G General Audiences Content not offensive to most viewers. PG Parental Guidance Content is such that parents may not want their children to view the program.

Suggested

PG-13 Parental Guidance Program is inappropriate for preteens, with a greater degree of offensive

Suggested material than a PG-rated program.

R Restricted viewing Not for children under age 17. Strong elements of sex and/or violence. NC-17 Restricted Viewing Not for children under age 17 under any circumstances. Strong sexual content. X Hard Core Films Same as NC-17 rating.

Note: Zenith Electronics Corporation is not liable for any program content that appears when using this rating system;

as always, user discretion is advised.

TV PARENTAL GUIDELINE RATING SYSTEM

G General Audiences Content not offensive to most viewers.

TV-G General Audience Considered suitable for all audiences; children may watch unattended.

TV-PG Parental Guidance Unsuitable for younger children, may contain: Suggestive Dialog, Bad

Suggested Language, Sex, and Violence Scenes.

TV-14 Parents Strongly Unsuitable for children under 14, may contain: Strong Dialog, Bad Language,

Cautioned Sex, and Violence Scenes.

TV-MA Mature Audience Only Adults only, may contain: Strong Dialog, Bad Language, Sex, and Violence Scenes.

CHILDRENS’ CLASSIFICATIONS

TV-Y Children Considered suitable for all children under 7 years old. TV-Y7 Children 7 and over Considered suitable for children over 7, may contain Fantasy Violence Scenes.

CM151 1-28 CA - 1386 MENUS

USER MENUS 221-1387

SETUP MENU

Shown below is the Setup Menu for CA (A34) chassis with its options for each item which are described as follows:

1

AUTO PROGRAM (A34)

The Auto Program feature automatically searches for all available channels and marks them as ‘Added’ so that they may be accessed via the channel Up/Down key.

In the Auto Program screen:

· A message at the top displays “Auto Program” to let the customer know that he/she has entered the Auto Program feature.

· A line at the bottom of the screen shows that the Up/Down and Left/Right Arrow keys are used for Auto Program selections.

CHANNEL Add/Del/Surf

After running the Auto Program, all channels found by the Auto Program feature will be marked ‘Added’. However, some of these channels may be scrambled, or undesired by the customer. The Add/Del/Surf feature allows the customer to selectively mark any channel as ‘Deleted’ or ‘Added’.

To change the status of a channel, press the Right/Left Arrow key.

To change the channel while adding or deleting channels, use the Channel Up/Down keys, or press the desired channel digits, followed by the ENTER key. If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear. If only one channel is present, to change the channel the customer must use the digit key pad to select a channel.

The following figure shows the options for the Add/ Del/Surf feature.

CLOCK MENU

Clock Set feature contains a Clock Menu for Clock Set and Date Set

CLOCK SET

When the Clock Set item is selected, pressing the Left/ Right Arrow keys allows entry into the clock set menu.

· The current RF input type (Off Air Antenna or Cable TV) is highlighted. Use the Up/Down Arrow keys to change the RF input type.

· To start the Auto Program, press the Left/Right Arrow key. If the Cable TV input type is selected, the Auto Program routine will determine what type of cable system is present.

Notes:

• Auto Program clears all Surfing channels which

were added.

• While searching for channels, all keys except for

the Power key are disabled. This prevents an incomplete Auto Program procedure.

• Running the Auto Program will clear the factory

mode, if it was active. This happens at the end of the Auto Program.

• If the Auto Program line in the Setup Menu is

‘red’, this indicates that the module did not pass one of the test equipment’s tests.

• If no channels are found then the following

message will appear: “Make sure that the cable/ ant. is connected, and try again.”

1

When no time is set, the display shows: —:— — There are two ways to set the time:

1. Direct Entry (preferred)Use the digit keys, followed by ‘Enter’ or Select Up/Down.

2. Left/Right Arrow keys

When the first digit is introduced, the display shows:

—:-d AM < Timer

When the time is set, the display shows:

hh:mm AM < Timer

where:

d = digit, mm = minutes hh = hours

CM151 1-29 CA - 1387 MENUS

USER MENUS 221-1387 (Continued)

Entering an invalid time (“0” for example) will result in the clearing of the current time (—:— —). Also when only one digit is pressed and no other is pressed in an interval of seven seconds, the current time will be cleared.

Note: When the first digit is pressed (or the Left/

Right Arrow Key is pressed), a TIMER icon appears on the right side of the AM/PM status.

The Left/Right Arrow keys is the other way of setting the time. The drawback with using the Left/Right Arrow keys is if the customer uses the Right Arrow key, the time will increment to the next minute and so on until the customer finds the time desired. On the other hand, if the Left Arrow key is pressed, the time will decrement one minute and so on until the customer finds the time desired.

DATE SET

When no date is set, the display shows MM/DD/YY blinking.

Like setting the clock, there are two ways to set the date:

1. Direct Entry (preferred)

2. Left/Right and Up/Dn Keys

CAPTION/TEXT

This feature allows the customer to activate or deactivate Captions or Text.

Pressing the Left/Right Arrow keys sequentially through each of the following Caption/Text options.

Caption 1 Caption 2 Caption 3 Caption 4

Text 1 Text 2 Text 3 Text 4

Notes:

• When the Text option is selected and a text box

appears, if the CC key is pressed, the Caption box will appear.

• When captions are being displayed, if one of the

Volume Up/Down keys is pressed, the volume bar will not appear.

• When the Captions are not activated and the CC

key is pressed, the Caption Box will appear, that allows choose On, Caption When Muted or Off.

LANGUAGE

This feature allows the customer to change the menu language to English, Spanish or French by pressing the Left/Right Arrow keys.

Notes:

• When the first digit is introduced (d), the display

shows: dM/DD/YY then, blinking will stop.

• If no other digit is set in a seven second interval,

the current date will be clear. After the last digit has been entered, the following display appears: (eg. 01/02/97) Jan/02/97.

• Another way to set the date is using the Left/

Right and Up/Down Arrow keys. Use the Left/Right key to select either the month, day or year depending which one needs to be changed. Use the Up/Down to change the value of the month, day or year.

• Whichever of the three options is selected (MM,

DD, or YY) , the option selected, will blink.

• If no other Arrow key is entered, then an Auto

Enter is made by the software.

CAPTIONS

This feature allows the customer to select: Off , On, or Caption When Muted options.

To change the status of captions, press the Right/Left Arrow key to select either On, Captions When Muted or Off.

SPECIAL FEATURES MENU

This Menu contains the Timer Setup, Ch. Labels, XDS Display, Adv. TV Ctrl, and Auto Demo.

1

TIMER SETUP MENU

TIMER

The Timer Menu contains the Sleep Timer and the On/ Off Timer features.

SLEEP TIMER

Sleep Timer (via Timer Menu) The Left/Right Arrows can be used to adjust the current

sleep timer setting: Off, 0:10, 0:20, 0:30, 1:00, 1:30, 2:00, 3:00 or 4:00.

CM151 1-30 CA - 1387 MENUS

USER MENUS 221-1387 (Continued)

1

ON/OFF TIMER

This feature consists of three menu lines: “On Time”, “Off Time”, and “On/Off Timer”. This feature allows the set to turn on and off at the times specified in “On Time” and “Off Time”.

The “On Time” and “Off Time” are set identical to the Clock Set feature in the Setup Menu.

An Off Time must be specified, before turning on the “EZ Timer”—otherwise an error message (“Must Set On/ Off”) will be displayed on the On/Off Timer line.

The On/ Off Timer option turns the Timer On or Off.

XDS DISPLAY

Pressing the Left/Right Arrow Keys allows the customer to select the XDS Display either On or Off.

ADVANCED TV CONTROL MENU

The Advanced TV Control Menu items are adjusted with the Up Arrow key.

1

AUXILIARY SOURCES

To Block or Unblock the sources, press the Left/Right Arrow key.

The SOURCE key may be used to view the other source.

If there is no Off Time set, then the On/Off Timer displays the above message saying: “Must Set Off Timer.” Once the Off timer has been set, the customer can then set the option to either On or Off.

CH LABELS OPTION

This feature allows the customer to select a channel label for the current station. This channel label is displayed in the Channel/Time display. Initially, all channel labels are set to ‘——‘, which results in no channel being displayed in the Channel/Time display.

To change the current channel label, press the Left/ Right Arrow key.

To change the channel while adjusting channel labels, use the Channel Up/Down keys, or press the desired channel digits, followed by ‘Enter’. (If Channel Up/Down is pressed, the next or previous channel which was marked ‘Added’ will appear.)

Notes:

• When the channel label is selected (see 1-36 for

labels), then the Auto channel label is activated, in other words, the program automatically takes the channel label of the signal that is send by broadcasting through the XDS service.

• If the label None is selected, the Auto channel label

is disactivated.

MPAA

The MPAA selector allows the customer to select either to have the channel Unblocked, G and Above, PG and Above, PG-13 and Above, R and Above, NC-17 and Above, or X.

AGE BLOCK

Use the Left/Right Arrow keys to select the Age Block Menu.

1

GENERAL BLOCK

Once entered into the Age Block Menu, the customer has the option to block channels for general age or to block channels for children.

To block channels for a general age, the customer may either select: Unblocked, TV-G and Above, TV-PG and Above, TV-14 and Above or TV-MA.

CM151 1-31 CA - 1387 MENUS

USER MENUS 221-1387 (Continued)

CHILDREN BLOCK

To block channels for children, select either: Unblocked, TV-Y and Above or TV-Y7.

CONTENT BLOCK

Use the Left/Right Arrow keys to select the Content Block Menu

1

DIALOG BLOCK

To block the dialog, use the Left/Right Arrow keys to select either: Unblocked, TV-PG and Above or TV-14.

LANGUAGE BLOCK

To block the dialog, use the Left/Right Arrow keys to select either: Unblocked, TV-PG and Above, TV-14 and Above, or TV-MA.

SEX SCENES BLOCK

To block the Sex Scenes, use the Left/Right Arrow keys to select either: Unblocked, TV-PG and Above, TV-14 and Above, or TV-MA.

VIOLENCE BLOCK

To block the Violence, use the Left/Right Arrow keys to select either: Unblocked, TV-PG and Above, TV-14 and Above, or TV-MA.

REPEAT PASSWORD

After a four-digit code has been entered, the software requires the customer to reenter the same four-digit code.

PASSWORD NOT ACCEPTED

If an invalid code is entered, or the two codes entered do not match, a blinking error message (“Not Accepted!”) will appear.

This error message also appears when no code is entered for the password or if only one digit is entered and no other digit has been entered.

LOCK ON/OFF

This item turns the Advanced TV feature On or Off. The Adv. TV Ctrl. feature can only be turned on if the hours > 0, and a password has been set. Otherwise the Lock On/Off line will display either of the following error messages: “Must Set Hours” or “Must Set Password.”

REENTERING ADVANCED TV CONTROL MENU

If the Parental Control feature has been activated, the software will not allow immediately entry into the Advanced TV Control Menu. Instead, it will prompt for the correct password. If the correct password is entered, the Advanced TV Control menu will appear, with the highlighted item “Lock On/Off”, which assumes that the customer most likely wants to turn the feature off. If an incorrect password is entered, an error message (“Not Accepted!”) appears, and will not disappear until 5 seconds has elapsed. This extended time provision increases the amount of time necessary for a child to “crack” the password.

Notes:

• The Advanced TV Control menu will remain up for

10 seconds after the last key is pressed.

F VIOLENCE BLOCK

To block the FViolence, use the Left/Right Arrow keys to select either: Unblocked, TV-Y7.

NO CONTENT BLOCK

Use the Left/Right Arrow keys to adjust the number of hours the Parental Control feature will be active. The valid hour range is 1 through 99 hours.

SET PASSWORD

Press the Left/Right Arrow key to allow Password entry.

TO ENTER PASSWORD

The software accepts four-digit codes only. A password must be entered by the customer.

CM151 1-32 CA - 1387 MENUS

• The QUIT key may be pressed to remove the PC

menu.

• Entry into the Factory Menu will immediately turn

off the PC feature.

• The PC Hours and Password will be cleared upon

exit of the Adv. TV Ctrl menu (unless the Adv. TV Ctrl feature has been turned on.)

DISPLAY WHEN ADVANCED TV CONTROL IS ACTIVE

When the Advanced TV Control has been activated the channel is blocked. The display on the screen shows two lines. The first line displays a message saying that the “PARENTAL LOCKOUT IS ACTIVE.”

The second line displays the amount of time (in hours) left in the lockout.

USER MENUS 221-1387 (Continued)

CH 14

3:35 PM

MONO

Parental L ockout Is Active

01:23 Hours Remaining

AUDIO MENU

All menu items are adjustment with the Left/Right Arrow keys.

1

EZ HELP MENU

The special features EZ Help option may be accessed using the Left/Right Arrow keys. The EZ Help feature provides help on certain options. For example, when the EZ Help feature is activated using the Left/Right Arrow keys, the EZ Program option is available to access through the EZ Help menu. Along with the possibility of accessing any of the following options EZ Program, Add/Surf/Del, Degaussing, EZ Picture and EZ SoundRite, there is a simple explanation of the each of the options.

1

The EZ Help has a main screen called EZ Help. This screen gives a solution to the most common problem that a customer may encounter; i.e., the correct connection of the antenna.

EZ DEMO

The Auto Demo is designed to show-off the icon menus and other icon displays on the sales floor. The Auto Demo feature can be turned On/Off with the Left/Right Arrow keys.

Initially, when the feature is activated, as soon as the OSD times out, the Auto Demo will start. At this point, pressing any key will temporarily disable the Auto Demo for 18 seconds, and if the Auto Demo is working and the Menu key is pressed then the Setup Menu will be displayed and the Auto Demo feature will be selected allowing the customer to disable it.

BASS

Bass adjustment has 15 steps (0 to 14). The following figure shows a mark at the center indicating step 7.

TREBLE

Treble adjustment has 15 steps (0 to 14).

BALANCE

Balance adjustment has 29 steps (0 to 28).

AUDIO MODE

There are three audio modes available: Mono, Stereo, 2nd Audio/SAP.

If 2nd Audio/SAP is selected, but the current channel does not support SAP, then either Stereo or Mono will be heard.

FRONT SURROUND

Front Surround can be set ‘ON’ or ‘Off’, regardless of the current Audio Mode setting. However, the Front Surround effect can only be heard when the Audio Mode has been set to ‘Stereo’ and a Stereo signal is present. When this condition exists, there will be a short mute (200ms) while toggling the Surround ‘On’ to ‘Off’, to embellish Front Surround activation.

SOUND RITE

The Sound Rite feature is used to obtain a uniform volume level, particularly while changing channels. The Sound Rite feature can be best demonstrated on a channel with no signal (snow).

SPEAKERS

The Speaker feature is used to turn off the internal speakers. It does this by pulling the power amp mute line.

CM151 1-33 CA - 1387 MENUS

USER MENUS 221-1387 (Continued)

EZ SOUND

The EZ Sound Control has six selections the customer can select. The selections available are: Custom, Normal, Stadium, News, Music and Theater. The Left/Right Arrow keys may be used to select any of the choices mentioned.

VIDEO MENU

All menu items are adjusted with the Left/Right Arrow keys.

1

CONTRAST

Contrast adjustment has 64 steps (0 to 63).

BRIGHTNESS

Brightness adjustment has 64 steps (0 to 63).

COLOR

Color adjustment has 64 steps (0 to 63).

TINT

Tint Adjustment has 64 steps (0 to 63). A center mark indicates step 29.

SHARPNESS

Sharpness adjustment has 64 steps (0 to 63).

COLOR TEMP

Sets the color temperature. The two settings are COOL and WARM.

EZ PICTURE

This feature allows the customer to maintain two separate Contrast, Brightness, Color, Tint, Sharpness setting “Custom” and “Preset”. The “Preset” setting is set by the factory.

PIP MENU

All menu items are adjusted with the Left/Right Arrow keys.

1

CONTRAST

Contrast adjustment has 64 steps (0 to 63). A center mark indicates step 31. This item allows the contrast adjustment of the PIP window.

TINT

This item allows adjust the PIP tint. Tint Adjustment has 64 steps (0 to 63). A center mark indicates step

31.

SIZE

This option is used to select size of the PIP window. The customer may select the PIP window size either large or small.

SOURCE MENU

This menu has two items, Main Source and PIP Source. The selection of either Main Source or PIP Source determines the signal that feeds the video processor. The options available are Antenna/Cable or Video.



1

CM151 1-34 CA - 1387 MENUS

USER MENUS 221-1387 (Continued)

MAIN SOURCE

The selection of Main Source determines the signal that feeds the video processor

PIP SOURCE

The selection of PIP Source determines the signal that feeds the video processor.

CHANNEL/TIME/AUDIO DISPLAY

CH 5 ABC

10:06 AM

MONO

VOLUME DISPLAY

CLOSED CAPTION DISPLAY

CM151 1-35 CA - 1387 MENUS

USER MENUS 221-1387 (Continued)

Channel Labels

A&E CMTV ESPN HSE NOS TBN VC ABC CNBC ESPN2 HSN PBS TELE VCR ACTS CNN ET IC PLAY TLC VH-1 ADC COM EWTN INSP PTL TMC VISN AMC CSPN FAM JCN QVC TNN VJN BCC CSP2 FNN LIFE RDS TNT WB BET CTN FOX MAX REQ TRAV WGN BRAV CTV F&V ME/U SC TSN WTBS CA DIS FX MMT SCFI TVA WWOR CBC DISC GALA MTV SHOW TWC YTV CBN E! HBO NBC SIN UPN - - - CBS ENC HN NICK TBS USA None NOTE: Selecting the "- - - -" label option means the channel will not be

displayed on the channel/time/audio signal display. Selecting the "None" option means the channel will not have a label.

MOTION PICTURE ASSOCIATION OF AMERICA (MPAA) RATING SYSTEM

G General Audiences Content not offensive to most viewers. PG Parental Guidance Content is such that parents may not want their children to view the program.

Suggested

PG-13 Parental Guidance Program is inappropriate for preteens, with a greater degree of offensive

Suggested material than a PG-rated program.

R Restricted viewing Not for children under age 17. Strong elements of sex and/or violence. NC-17 Restricted Viewing Not for children under age 17 under any circumstances. Strong sexual content. X Hard Core Films Same as NC-17 rating.

Note: Zenith Electronics Corporation is not liable for any program content that appears when using this rating system;

as always, user discretion is advised.

TV PARENTAL GUIDELINE RATING SYSTEM

G General Audiences Content not offensive to most viewers.

TV-G General Audience Considered suitable for all audiences; children may watch unattended.

TV-PG Parental Guidance Unsuitable for younger children, may contain: Suggestive Dialog, Bad Lan-

Suggested guage, Sex, and Violence Scenes.

TV-14 Parents Strongly Unsuitable for children under 14, may contain: Strong Dialog, Bad Language,

Cautioned Sex, and Violence Scenes.

TV-MA Mature Audience Only Adults only, may contain: Strong Dialog, Bad Language, Sex, and Violence Scenes.

CHILDRENS’ CLASSIFICATIONS

TV-Y Children Considered suitable for all children under 7 years old. TV-Y7 Children 7 and over Considered suitable for children over 7, may contain Fantasy Violence Scenes.

CM151 1-36 CA - 1387 MENUS

SECTION 2

SERVICE MENU ADJUSTMENTS

Accessing the Service Menu can only be accomplished by using the remote control. Press and hold the MENU key until the User Menu display disappears, then press

9876, and then ENTER to access the Service Menu.

INSTALLERS MENU

When the Factory Mode is off, only the first twenty items in the Service Menu can be accessed. They appear one at a time near the middle left of the screen. When the Factory Mode is set to 1, 46 menu items are available. In the Factory Mode 2 position, all 49 menu items are available.

In Factory Mode 1 or 2, only the selected menu item is displayed, near the top of the screen, as shown in the figure.

The black bar near the top of the screen indicates the part number of the software in the TV set. To the right is a number indicating that the module has been tested. The date on the black bar near the bottom of the screen indicates the date the module went through the factory.

When the Service menu appears, it displays the fifth Service Menu item: HORIZ POS. Use the SELECT UP/DOWN keys to toggle through all of the adjustments. Use ADJUST to make a change to the selected item.

00 F MODE: (Factory Mode) Use SELECT UP and DOWN Keys to select item #01, the first item in the Service Menu: Factory Mode. This item number is used by the Factory when the module is being tested. It has three positions: 0, 1 and 2. In the field, this item should always be left “Off”. Zero is “Off”.

When the Factory Mode is “On”, the AC Power -On feature is always enabled regardless of the setting of “AC ON” in the Service Menu. The TV set will automatically come on when AC is applied.

Use the remote to reenter the Service Menu to turn Factory Mode off. The Factory Mode may also be turned off by setting the clock, or running the Auto Program feature in the customer Set Up menu.

CM151 2-1 CA - INSTALLER MENUS

INSTALLERS MENU 221-1384

01 PRE PX: Stores customer menu adjustments in the

nonvolatile memory of the EAROM. Selections are Custom/ Preset-Store. Settings for Contrast, Brightness, Color and tint are stored in this manner. 0 is custom and 1 is Preset stored.

02 V P0S: Moves On-Screen Displays vertically. The Range is from 0 - 25. This adjustment is generally set at 5.

03 H POS: Moves On-Screen Displays horizontally. Range is from 1 - 15. Generally set at 9.

04 LEVEL: There are three positions: 0, 1,and 2. The three different positions are used at the factory to program the module for the correct features. In order to change the level, short pins 3 and 4 together on connector 4G9 on the main module. The connector is located on the left hand side of the module.

Note: Be careful, shorting the wrong pins could

damage the module. Always remember to remove the jumper after setting the level.

05 BAND: There are eight positions: 0 - 7.

0 is Broadcast fixed 4 is Broadcast afc 1 is CATV afc 5 is CATV fixed 2 is HRC afc 6 is HRC fixed 3 is ICC afc 7 is ICC fixed

06 AC ON: There are two positions, 0 is off and 1 is on. When set to on, the TV will turn on and off when AC power is applied.

07 RFB PF: (RF Bandpass) Sets adjustment range of the user control brightness in therefore mode. Range is 0 - 1. Set to 1.

08 3.5T: (3.58 MHz Trap) Zero is off, 1 is on. Set to zero. For normal TV operation, set to 1 if Y/C is used or chassis has a comb filter.

09 RF BRT: (RF brightness) Sets adjustment range of customer control for brightness in RF mode. Range is 0 - 63. A typical value is 30.

10 AX BRT: (Auxiliary Brightness) Sets adjustment range of customer control for brightness in AUX mode. Range is 0 - 63. Typical value is 30.the channel number.

11 MAX CON: Sets adjustment range of customer control for contrast. Range is from 0 - 63. Set to 63.

12 V SIZE: (Vertical Size) Range is 0-254.

15 H PHASE: (Horizontal Phase) Range is from 0 - 31.

Set to 18. 16 AUDLVL: Sound Attenuation range is 0-63. Set to

46. 17 RF AGC: (Rf Automatic Gain Control) Range is from 0

- 63. 48 is a general setting. Tune in weakest available channel and adjust for a snow- free picture.

18 H AFC: Range is 0 - 1. Set to 0. 0=AFC2 Normal. 1=AFC2 X 3.

19 WHCOMP: (White Compression)The range is 0 to 1. Set to 0. 0 = Enable and 1 = Disable.

20 60HZSW: A sync stability item. Range is 0 - 1. Zero is off. Set to 0.

21 PIFVCO: Range is 0 - 127. Items 22 through 34 vary with CRT* 22 R CUT: B&W tracking adjustment. Range is

0 to 255. Typical value is 20. 23 G CUT: B&W tracking adjustment. Range is 0 - 255.

Typical value is 0. 24 B CUT: B&W tracking adjustment. Range is

0 - 255. Typical value is 28. 25 G GAIN: B&W tracking adjustment. Range is 0

- 255. Typical value is 45. 26 B GAIN: B&W tracking adjustment. Range is

0 - 254. Typical value is 70.

27 CTYPE: (Chasis Type). 28 SCROLL: Selects the method the User Menus will

appear on the screen. 1 is On which is Scroll Off.

29 KEYS: Set to 1 for the 6 button keyboard. 30 SPKRSW: (Internal Speaker Switch) Range is 0-1. 31 SURF: (Surf Mode) Range is 0-1. 32 A ATT: (Audio Attenuator) Range is 0-15. 33 ASPECTRAL: Adjustment of Stereo seperation (3KHz).

Range is 0-99. 34 WBAND: (Wide Band Low Frequency Seperation)

Range is 0-63. * Adjust only if CRT has been changed. The “CUT”

adjustments affect the Lowlights and the “GAIN” adjustments affect the Highlights.

13 H SIZE: (Horizontal Size) Range is 0-254. 14 V PHASE: (Vertical Phase) Range is 0 - 7. Set to 0.

CM151 2-2 CA - INSTALLER MENUS

INSTALLERS MENU 221-1384 (continued)

CA CONSUMER CHASSIS

FACTORY MENU RECOMMENDED SETTINGS

ITEM RANGE 25” 27” DESCRIPTION

00 F MODE 0-1 0 0 Factory mode - perfer to page 2-1 01 PRE PX 0-1 0 0 Used to store customer menu adjustments 02 V POS 0-24 13 13 Moves On Screen display vertically 03 H POS 0-20 6 6 Moves On Screen display horizontally 04 LEVEL 0-1 1 1 05 BAND 0-7 0 0 Broadcast Band adjustment 06 AC ON 0-1 0 0 AC power feature

TECHNICAL SETTINGS

07 RFB PF 0-1 1 1 Control for brightness in therefore mode 08 3.5T 0-1 0 0 3.58 MHz Trap 09 RF BRT 0-63 33 33 Control for brightness in RF mode 10 AX BRT 0-63 33 33 Control for brightness in AUX mode 11 MAX CON 0-63 63 63 Control for contrast 12 VSIZE 0-63 145 125 Vertical Size 13 HSIZE 0-254 0 0 Horizontal size 14 V PHASE 0-7 2 2 15 H PHASE 0-31 14 14 Shifts picture horizontally 16 AUDLVL 0-63 46 46 Sound Attenuation 17 RF AGC 0-63 31 31 18 H AFC 0-1 1 1 Horizontal Automatic Frquency control 19 WHCOMP 0-1 0 0 White compression 20 60HZSW 0-2 2 2 60 Hertz Switched 21 PIFVCO 1-127 31 31 PIF Voltage Controlled Oscillator

COLOR TEMP STARTING VALUE

22 R CUT 0-254 0 0 B&W tracking adjustment 23 G CUT 0-254 0 0 B&W tracking adjustment 24 B CUT 0-254 0 0 B&W tracking adjustment 25 G GAIN 0-254 103 103 B&W tracking adjustment 26 B GAIN 0-254 75 75 B&W tracking adjustment 27 CTYPE 0-3 2 2 Chasis type 28 SCROLL 0-1 0 0 User Menu scroll type 29 KEYS 0-1 0 0 Keyboard type

AUDIO SETTINGS

30 SPKRSW 0-1 0 0 Internal Speaker Switch 31 SURF 0-1 0 0 Surf Mode 32 A ATT 0-15 9 9 Audio Attenuator 33 ASPECTRAL 0-63 31 31 Adjustment of Stereo seperation 34 WBAND 0-63 31 31 Wide band Low Frequency Seperation

Shifts picture vertically

Weak channel adjustment

CM151 2-3 CA - INSTALLER MENUS

INSTALLERS MENU 221-1385

01 PRE PX: Stores customer menu adjustments in the

nonvolatile memory of the EAROM. Selections are Custom/ Preset-Store. Settings for Contrast, Brightness, Color and tint are stored in this manner. 0 is custom and 1 is Preset stored.

02 V P0S: Moves On-Screen Displays vertically. The Range is from 0 - 25. This adjustment is generally set at 5.

03 H POS: Moves On-Screen Displays horizontally. Range is from 1 - 15. Generally set at 9.

04 LEVEL: There are three positions: 0, 1,and 2. The three different positions are used at the factory to program the module for the correct features. In order to change the level, short pins 3 and 4 together on connector 4G9 on the main module. The connector is located on the left hand side of the module.

Note: Be careful, shorting the wrong pins could damage

the module. Always remember to remove the jumper after setting the level.

05 BAND: There are eight positions: 0 - 7.

0 is Broadcast fixed 4 is Broadcast afc 1 is CATV afc 5 is CATV fixed 2 is HRC afc 6 is HRC fixed 3 is ICC afc 7 is ICC fixed

06 AC ON: There are two positions, 0 is off and 1 is on. When set to on, the TV will turn on and off when AC power is applied.

07 RFB PF: (RF Bandpass) Range is 0-1. 08 3.5T: (3.58 MHz Trap) Zero is off, 1 is on. Set to

zero. For normal TV operation, set to 1 if Y/C is used or chassis has a comb filter.

09 RF BRT: (RF brightness) Sets adjustment range of customer control for brightness in RF mode. Range is 0 - 63. A typical value is 30.

10 AX BRT: (Auxiliary Brightness) Sets adjustment range of customer control for brightness in AUX mode. Range is 0 - 63. Typical value is 30.the channel number.

11 MAX CON: Sets adjustment range of customer control for contrast. Range is from 0 - 63. Set to 63.

12 V SIZE: (Vertical Size) Range is 0-254. 13 H SIZE: (Horizontal Size) Range is 0-254. 14 V PHASE: (Vertical Phase) Range is 0 - 7. Set to 0. 15 H PHASE: (Horizontal Phase) Range is from 0 - 31.

Set to 18. 16 AUDLVL: Sound Attenuation range is 0-63. Set to

46.

17 RF AGC: (Rf Automatic Gain Control) Range is from 0

- 63. 48 is a general setting. Tune in weakest available channel and adjust for a snow- free picture.

18 H AFC: Range is 0 - 1. Set to 0. 0=AFC2 Normal. 1=AFC2 X 3.

19 WHCOMP: (White Compression)The range is 0 to 1. Set to 0. 0 = Enable and 1 = Disable.

20 60HZ SW: A sync stability item. Range is 0 - 1. Zero is off. Set to 0.

21 PIFVCO: Range is 0 - 127. Items 22 through 26 vary with CRT* 22 R CUT: B&W tracking adjustment. Range is

0 to 255. Typical value is 20. 23 G CUT: B&W tracking adjustment. Range is 0 - 255.

Typical value is 0. 24 B CUT: B&W tracking adjustment. Range is

0 - 255. Typical value is 28. 25 G GAIN: B&W tracking adjustment. Range is 0

- 255. Typical value is 45. 26 B GAIN: B&W tracking adjustment. Range is

0 - 254. Typical value is 70. 27 SCROLL: Selects the method the User Menus that

will appear on the screen. 1 is On which is Scroll Off.

28 6 KEYS: Set to 1 for the 6 button keyboard. 29 A ATT: (Audio Attenuator) Range is 0-63. 30 A VCO: (Audio Decoder Oscillator) Range is 0-63. 31 AFILTER: (Audio Filter) Range is 0-63. 32 ASPECTRAL: (High Frequency Seperation) Range is

0-63. 33 WBAND: (Wide Band Low Frequency Seperation)

Range -s 0-63 34 IN OSDC: (On Screen Display Internal Oscillator) Range

is 0-1.

35 OSD FRAME: (On Screen Display Frame) Range is 0-1. 36 ASS ON: (Automatic Sleep System) Range is 0-1.

Differences for 221-1385-01

35 XTAL: External Crystal. Range is 0-1.

* Adjust only if CRT has been changed. The “CUT”

adjustments affect the Lowlights and the “GAIN” adjustments affect the Highlights.

CM151 2-4 CA - INSTALLER MENUS

INSTALLERS MENU 221-1385 (continued)

CA CONSUMER CHASSIS

FACTORY MENU RECOMMENDED SETTINGS

ITEM RANGE 25” 27” 32” 36” DESCRIPTION

00 F MODE 0-1 0 0 0 0 Factory mode - perfer to page 2-1 01 PRE PX 0-7 0 0 0 0 Used to store customer menu adjustments 02 V POS 0-30 15 15 15 15 Moves On Screen display vertically 03 H POS 0-45 9 9 9 9 Moves On Screen display horizontally 04 LEVEL 0-2 1 1 1 1 05 BAND 0-7 0 0 0 0 Broadcast Band adjustment 06 AC ON 0-1 0 0 0 0 AC power feature

TECHNICAL SETTINGS

07 RFB PF 0-1 1 1 1 1 Control for brightness in therefore mode 08 3.5T 0-1 1 1 1 1 3.58 MHz Trap 09 RF BRT 0-63 38 33 38 33 Control for brightness in RF mode 10 AX BRT 0-63 38 33 38 33 Control for brightness in AUX mode 11 MAX CON 0-63 63 63 63 63 Control for contrast 12 V SIZE 0-254 145 125 120 174 Vertical Size 13 H SIZE 0-254 0 0 174 120 Horizontal size 14 V PHASE 0-7 2 0 2 1 Shifts picture vertically 15 H PHASE 0-31 14 17 14 14 Shifts picture horizontally 16 AUDLVL 0-63 46 46 46 46 Sound Attenuation 17 RF AGC 0-63 31 31 31 31 Weak channel adjustment 18 H AFC 0-1 1 1 1 1 Horizontal Automatic Frquency control 19 WHCOMP 0-1 0 0 0 0 White compression 20 60HZSW 0-2 2 2 2 2 60 Hertz Switched 21 PIFVCO 1-127 31 31 31 31 PIF Voltage Controlled Oscillator

COLOR TEMP STARTING VALUE

22 R CUT 0-254 0 0 0 0 B&W tracking adjustment 23 G CUT 0-254 0 0 0 0 B&W tracking adjustment 24 B CUT 0-254 0 0 0 0 B&W tracking adjustment 25 G GAIN 0-254 86 103 81 90 B&W tracking adjustment 26 B GAIN 0-254 82 75 75 90 B&W tracking adjustment 27 SCROLL 0-1 0 0 0 0 User Menu scroll type 28 6 KEYS 0-1 0 0 0 0 Keyboard type

AUDIO SETTINGS

29 A ATT 0-15 9 9 9 9 Audio Attenuator 30 A VCO 0-63 31 31 31 31 Audio Decoder Oscillator 31 AFILTER 0-63 31 31 31 31 Audio Filter 32 ASPECTRAL 0-63 31 31 31 31 Adjustment of Stereo seperation 33 WBAND 0-63 31 31 31 31 Wide band Low Frequency Seperation 34 IN OSDC 0-1 0 0 0 0 On Screen Display Internal Oscillator 35 OSD FRAME 0-1 0 0 0 0 On Screen Display Frame 36 ASS ON 0-1 0 0 0 0 Automatic Sleep System

DIFFERENCES FOR 221-1385-01

35 XTAL 0-1 0 0 0 0 External Crystal

Note: If you change the EPROM, change the microprocessor from 221-1385-00 to 221-1385-01

CM151 2-5 CA - INSTALLER MENUS

INSTALLERS MENU 221-1386

01 PRE PX: Used to store the customer menu adjustments in

the non-volatile memory of the EAROM . Settings for Contrasts, Brightness, Color and Tint are stored in this manner, 0 is custom and 7 is Pre-set stored.

02 V POS: Moves On Screen Displays vertically. Range is 030 .

03 H POS: Moves On Screen Displays horizontally. Range is 0-45 .

04 LEVEL: There are three positions, 0, 1 and 2 . The three different positions are used at the factory to program the module for the correct features . In order to change the level, short pins 3 and 4 together on connector 4G9 on the main module. The connector is located on the left hand side of the module just to the Micro IC6000 .

Note: Be careful, shorting the wrong pins could damage

the module. Always remember to remove the jumper after setting the level.

Level 0 and 2 is used for Private Label sets. Level 1 and 2 are used for Zenith sets . In the private label mode the IR code is 21 or 121 .

05 BAND: There are eight positions. 0 is Broadcast fixed, 1 is CATV afc, 3 is ICC afc, 4 is Broadcast afc, 5 CATV fixed, 6 is HRC fixed, and 7 is ICC fixed.

06 AC ON: There are two positions, 0 is off and I is AC On. In On position set will turn on and off when AC power is applied and removed.

07 RFB PF: (RF Bandpass) Range is 0-1. 08 3.5T: 3.58 MHz trap. Range is 0-1. 09 RF BRT: (RF Brightness) Sets adjustment range of the

customer control, for brightness in RF mode. Range is 0-63 10 AX BRT: (Auxiliary Brightness) Sets adjustment range of

the customer control, for brightness in AUX mode. Range is 0-63.

11 MAX CON: (Max Contrast) Set adjustment range of customer control for contrast. Range is 0-63

12 V SIZE: (Vertical Size) Adjust the size of the picture vertically. Range is 0-254.

13 H SIZE: (Horizontal Size) Adjust the size of the picture horizontally. Range is 0-254.

14 V PHASE: (Vertical Phase) Shifts picture vertically. Range is 0-7

15 H PHASE: (Horizontal Phase) shifts picture horizontally, Range is 0-31.

16 AUDLVL: (Audio Level) Set gain for Composite Audio from Video processor. Range is 0-63.

17 RF AGC: Range is 0-63 18 H AFC: There are two settings 0 and 1 . Settings is

usually 1. 19 WHCOMP: (White Compression) There are two settings 0

and 1 . Settings is 0 .

20 60 HZSW: (60 Hertz compression ) There are two settings 0 and 2 . Settings is 0.

21 PIFVCO: (PIF Voltage Controlled Oscillator) Range is 0-

127.

Items 22 through 26 vary with CRT* 22 R CUT: B&W tracking adjustment. Range is

0 to 255. Typical value is 20. 23 G CUT: B&W tracking adjustment. Range is 0 - 255.

Typical value is 0. 24 B CUT: B&W tracking adjustment. Range is

0 - 255. Typical value is 28. 25 G GAIN: B&W tracking adjustment. Range is 0

- 255. Typical value is 45. 26 B GAIN: B&W tracking adjustment. Range is

0 - 254. Typical value is 70.

27 SCROLL: Selects the method the User Menus that will appear on the screen . Scroll Off is 1, 1 is On.

28 6 KEYS: Set to 1 for the 6 button keyboard. 29 A ATT: (Audio Attenuator) Range is 0-15 30 ASPECTRAL: High Frequency separation . Range is 0-63 31 WBAND: (Wide Band Low Frecuency Separation) Range is

0-63.

32 PIP X1 POS: Range is 0-254 33 PIP Y1 POS: Range is 0-254 34 PIP X2 POS: Range is 0-254 35 PIP Y2 POS: Range is 0-254 36 PIP BRIGHTNESS: Range is 0-254 37 PIPR CONTRAST: Range is 0-127 38 PIPG CONTRAST: Range is 0-127 39 PIPB CONTRAST: Range is 0-127 40 PIP ADJUST: Range is 0-15 41 PIPY DELAY: Range is 0-15 42 PIP BGSTART: (PIP Burst Gate Start) Range is 0-31. 43 PIP ACCLEVEL: Range is 0-63 44 PIP HX: Range is 0-63 45 PIP VXS: Range is 0-63 46 PIP COMP: (Pip External Syncronic) Range is 0-3.

Differences for 221-1386-01

47 XTAL: External Crystal. Range is 0-1. * Adjust only if CRT has been changed. The “CUT”

adjustments affect the Lowlights and the “GAIN” adjustments affect the Highlights.

CM151 2-6 CA - INSTALLER MENUS

INSTALLERS MENU 221-1386 (continued)

CA CONSUMER CHASSIS

FACTORY MENU RECOMMENDED SETTINGS

ITEM RANGE 25” 27” 32” 36” DESCRIPTION

00 F MODE 0-1 0 0 0 0 Factory mode - perfer to page 2-1 01 PRE PX 0-1 0 0 0 0 Used to store customer menu adjustments 02 V POS 0-30 15 15 15 15 Moves On Screen display vertically 03 H POS 0-45 9 9 9 9 Moves On Screen display horizontally 04 LEVEL 0-2 1 1 1 1 05 BAND 0-7 0 0 0 0 Broadcast Band adjustment 06 AC 0-1 0 0 0 0 AC power feature

TECHNICAL SETTINGS

07 RFB PF 0-1 1 1 1 1 Control for brightness in therefore mode 08 3.5T 0-1 0 0 0 0 3.58 MHz Trap 09 RF BRT 0-63 33 33 33 33 Control for brightness in RF mode 10 AX BRT 0-63 33 33 33 33 Control for brightness in AUX mode 11 MAX CON 0-63 63 63 63 63 Control for contrast 12 V SIZE 0-254 145 125 120 175 Vertical Size 13 H SIZE 0-254 0 0 174 120 Horizontal size 14 V PHASE 0-7 2 0 2 1 Shifts picture vertically 15 H PHASE 0-31 14 17 14 14 Shifts picture horizontally 16 AUDLVL 0-63 46 46 46 46 Sound Attenuation 17 RF AGC 0-63 31 31 31 31 Weak channel adjustment 18 H AFC 0-1 1 1 1 1 Horizontal Automatic Frquency control 19 WHCOMP 0-1 0 0 0 0 White Compression 20 60HZSW 0-2 2 2 2 2 60 Hertz Switched 21 PIFVCO 1-127 31 31 31 31 PIF Voltage Controlled Oscillator

COLOR TEMP STARTING VALUE

22 R CUT 0-254 0 0 0 0 B&W tracking adjustment 23 G CUT 0-254 0 0 0 0 B&W tracking adjustment 24 B CUT 0-254 0 0 0 0 B&W tracking adjustment 25 G GAIN 0-254 86 103 81 90 B&W tracking adjustment 26 B GAIN 0-254 82 75 75 90 B&W tracking adjustment 27 SCROLL 0-1 0 0 0 0 User Menu scroll type 28 6 KEYS 0-1 0 1 0 0 Keyboard type

AUDIO SETTINGS

29 A ATT 0-15 9 9 9 9 Audio Attenuator 30 ASPECTRAL 0-63 31 31 31 31 Adjustment of Stereo seperation 31 WBAND 0-63 31 31 31 31 Wide Band Low Frequency Seperation

PIP SETTINGS

32 PIP X1 POS 0-254 17 17 17 17 PIP Position X 33 PIP Y1 POS 0-254 25 25 25 25 PIP Position Y 34 PIP X2 POS 0-254 113 113 113 113 PIP Position X 35 PIP Y2 POS 0-254 143 143 143 143 PIP Position Y 36 PIP BRIGHTNESS 0-254 205 205 205 205 PIP Brightness 37 PIPR CONTRAST 0-127 50 50 50 50 PIP Red Contrast 38 PIPG CONTRAST 0-127 50 50 50 50 PIP Green Contrast 39 PIPB CONTRAST 0-127 50 50 50 50 PIP Blue Contrast 40 PIP ADJUST 0-15 2 2 2 2 PIP Adjust 41 PIPY DELAY 0-15 4 4 4 4 PIP Y Delay Luma 42 PIP BGSTART 0-31 10 10 10 10 PIP Burst Gate Start 43 PIP ACCLEVEL 0-63 20 20 20 20 PIP Color Gain 44 PIP HX 0-63 30 30 30 30 PIP Horizontal Phase 45 PIP VXS 0-63 40 41 41 41 PIP Vertical Phase 46 PIP COMP 0-3 2 2 2 2 PIP External Syncronic

DIFFERENCES FOR 221-1386-01

47 XTAL 0-1 0 0 0 0 External Crystal

1 1 2 2

Note: If you change the EPROM, change the microprocessor from 221-1386-00 to 221-1386-01

CM151 2-7 CA - INSTALLER MENUS

INSTALLERS MENU 221-1387

01 PRE PX: Used to store the customer menu adjustments

in the non-volatile memory of the EAROM . Settings for Contrasts, Brightness, Color and Tint are stored in this manner. 0 is custom and 7 is Pre-set stored.

02 V POS: Moves On Screen Displays vertically. Range is 0-30. Generally set at

03 H POS: Moves On Screen Displays horizontally. Range is 0-45 . Generally set at

04 LEVEL: There are three positions, 0, 1 and 2 . The three different positions are used at the factory to program the module for the correct features . In order to change the level, short pins 3 and 4 together on connector 4G9 on the main module . The connector is located on the left hand side of the module just to the Micro IC6000 .

Note: Be careful, shorting the wrong pins could damage

the module. Always remember to remove the jumper after setting the level.

Level 0 and 2 is used for Private Label sets. Level 1 and 2 are used for Zenith sets . In the private label mode the IR code is 21 or 121 .

05 BAND: There are eight positions. 0 is Broadcast fixed, 1 is CATV afc, 3 is ICC afc, 4 is Broadcast afc, 5 CATV fixed, 6 is HRC fixed, and 7 is ICC fixed.

06 AC ON: There are two positions, 0 is off and I is AC On. In On position set will turn on and off when AC power is applied and removed.

07 RFB PF: (RF Bandpass) Range is 0-1. 08 3.5T: 3.58 MHz trap. Range is 0-1 09 RF BRT: (RF Brightness) Sets adjustment range of

the customer control, for brightness in RIF mode. Range is 0-63

10 AUX BRT: (Auxiliary Brightness) Sets adjustment range of the customer control, for brightness in AUX mode. Range is 0-63,

11 V SIZE: (Vertical Size) Adjust the size of the picture vertically. Range is-0-254.

12 H SIZE: (Horizontal Size) Adjust the size of the picture horizontally. Range is 0-254.

13 V PHASE: (Vertical Phase) Shifts picture vertically . Range is 0-7

14 H PHASE: (Horizontal Phase) shifts picture horizontally. Range is 0-31.

15 AUDLVL: (Audio Level) Set gain for Composite Audio

-from Video processor. Range is 0-63.

16 RIF AGC: Range is 0-63 17 H AFC: There are two settings 0 and 1 . usually 1. 18 60 HZSW: (60 Hertz compression) There are two

seftings 0 and 2. Set to 0.

19 PIFVCO: (PIF Voltage Controlled Oscillator) Range is 0-127.

Items 20 through 24 vary with CRT* 20 R CUT: Range is 0-254

21 G CUT: Range is 0-254 22 B CUT: Range is 0-254 23 G GAIN: (Green Gain) Range is 0-254 24 B GAIN: (Blue Gain) Range is 0-254 25 6 KEYS: Set to 1 for the 6 button keyboard 27 A VCO: (Audio Decoder Oscillator) Range is 0-63. 28 AFILTER: (Audio Filter) Range is 0-63. 29 ASPECTRAL: High Frequency separation . Range is

0-63. 30 WBAND: (Wide Band Low Frecuency Separation)

Range is 0-63.

31 PIP X1 POS: Range is 0-254 32 PIP Y1 POS: Range is 0-254 33 PIP X2 POS: Range is 0-254 34 PIP Y2 POS: Range is 0-254 35 PIP BRIGHTNESS: Range is 0-254 36 PIPR CONTRAST: Range is 0-127 37 PIPG CONTRAST: Range is 0-127 38 PIP B CONTRAST: Range is 0-127 39 PIP ADJUST: Range is 0-15 40 PIPY DELAY: Range is 0-15 41 PIP BGSTART: (PIP Burst Gate Start) Range is 0-31. 42 PIP ACCLEVEL: Range is 0-63. 43 PIP HX: Range is 0-63. 44 PIP VXS: Range is 0-63. 46 PIP COMP: Pip external syncronic. Range is 0-3.

Differences for 221-1387-01

39 PIPY DELAY: Range is 0-15 40 PIP BGSTART: (PIP Burst Gate Start) Range is 0-31. 41 PIP ACCLEVEL: Range is 0-63. 42 PIP HX: Range is 0-63 43 PIP VXS: Range is 0-63 44 PIP COMP: (Pip External Syncronic) Range is 0-3. 45 XTAL: (External Crystal) Range 0-1.

* Adjust only if CRT has been changed. The “CUT”

adjustments affect the Lowlights and the “GAIN” adjustments affect the Highlights.

CM151 2-8 CA - INSTALLER MENUS

INSTALLERS MENU 221-1387 (continued)

CA CONSUMER CHASSIS

FACTORY MENU RECOMMENDED SETTINGS

ITEM RANGE 27” 32” 36” DESCRIPTION

00 F MODE 0-1 0 0 0 Factory mode - perfer to page 2-1 01 PRE PX 0-1 0 0 0 Used to store customer menu adjustments 02 V POS 0-30 15 15 15 Moves On Screen display vertically 03 H POS 0-45 9 9 9 Moves On Screen display horizontally 04 LEVEL 0-2 1 1 1 05 BAND 0-7 0 0 0 Broadcast Band adjustment 06 AC ON 0-1 0 0 0 AC power feature

TECHNICAL SETTINGS

07 RFB PF 0-1 1 1 1 Control for brightness in therefore mode 08 3.5T 0-1 1 1 1 3.58 MHz Trap 09 RF BRT 0-63 33 33 33 Control for brightness in RF mode 10 AX BRT 0-63 33 33 33 Control for brightness in AUX mode 11 V SIZE 0-254 170 120 175 Vertical Size 12 H SIZE 0-254 174 120 Horizontal size 13 V PHASE 0-7 0 2 1 Shifts picture vertically 14 H PHASE 0-31 13 14 14 Shifts picture horizontally 15 AUDLVL 0-63 46 46 46 Sound Attenuation 16 RF AGC 0-63 31 31 31 Weak channel adjustment 17 H AFC 0-1 1 1 1 Horizontal Automatic Frquency control 18 60 HZSW 0-2 2 2 2 60 Hertz Switched 19 PIFVCO 1-127 31 31 31 PIF Voltage Controlled Oscillator

COLOR TEMP STARTING VALUE

20 R CUT 0-254 0 0 0 B&W tracking adjustment 21 G CUT 0-254 0 0 0 B&W tracking adjustment 22 B CUT 0-254 0 0 0 B&W tracking adjustment 23 G GAIN 0-254 103 81 90 B&W tracking adjustment 24 B GAIN 0-254 75 75 90 B&W tracking adjustment 25 6 KEYS 0-1 1 0 0 Keyboard type

AUDIO SETTINGS

26 A ATT 0-15 9 9 9 Audio Attenuator 27 AVCO 0-63 31 31 31 28 AFILTER 0-63 31 31 31 Audio Filter 29 ASPECTRAL 0-63 31 31 31 Adjustment of Stereo seperation 30 WBAND 0-63 31 31 31 Wide band Low Frequency Seperation

PIP SETTINGS

32 PIP X1 POS 0-254 17 17 17 17 PIP Position X 33 PIP Y1 POS 0-254 25 25 25 25 PIP Position Y 34 PIP X2 POS 0-254 113 113 113 113 PIP Position X 35 PIP Y2 POS 0-254 143 143 143 143 PIP Position Y 36 PIP BRIGHTNESS 0-254 205 205 205 205 PIP Brightness 37 PIPR CONTRAST 0-127 50 50 50 50 PIP Red Contrast 38 PIPG CONTRAST 0-127 50 50 50 50 PIP Green Contrast 39 PIP ADJUST 0-15 2 2 2 2 PIP Adjust 40 PIPY DELAY 0-15 10 10 10 10 PIP Y Delay Luma 41 PIP BGSTART 0-31 10 10 10 10 PIP Burst Gate Start 42 PIP ACC LEVEL 0-63 20 20 20 20 PIP Color Gain 43 PIP HX 0-63 30 30 30 30 PIP Horizontal Phase 44 PIP VXS 0-63 40 41 41 41 PIP Vertical Phase 46 PIP COMP 0-3 2 2 2 2 PIP External Syncronic

DIFFERENCES FOR 221-1387-01

39 PIPY DELAY 0-15 10 10 10 10 PIP Y Delay Luma 40 PIP BGSTART 0-31 10 10 10 10 PIP Burst Gate Start 41 PIP ACC LEVEL 0-63 20 20 20 20 PIP Color Gain 42 PIP HX 0-63 30 30 30 30 PIP Horizontal Phase 43 PIP VXS 0-63 40 41 41 41 PIP Vertical Phase 44 PIP COMP 0-3 2 2 2 2 PIP External Syncronic 45 XTAL 0-1 0 0 0 0 External crystal

1 1 2 2

Note: If you change the EPROM, change the microprocessor from 221-1387-00 to 221-1387-01

CM151 2-9 CA - INSTALLER MENUS

SECTION 3

(

)

SERVICING

HIGH VOLTAGE AND X-RADIATION PROTECTION

A potential source of x-rays is the picture tube, if the high voltage (HV) is out of specification . When the HV is operating properly, there is no x-radiation . For the CA chassis family, the HV has no adjustments . A HV shutdown circuit is used to prevent excessive HV and x-ray emissions.

THEORY OF OPERATION (SHUTDOWN CIRCUIT)

This circuit basically monitors the sweep pulse voltage derived from the sweep transformer TX3204 pins 5 & 6.

This voltage is rectified, and applied to a 12V zener diode ZDX3004. When the HV reaches its maximum allowed ,value (see drawing) the zener diode conducts, the voltage on pin 29 of the video processor (ICX2200) increases until it reaches the threshold voltage of 3.5 VDC, and shuts down the TV

If the shutdown circuit has operated, the microcontroller will prevent the TV from being turned on again, without first having to unplug the AC cord to reset the microcontroller.

TIP: Make a momentary short between the OUTPUT and GND of the IC6002 (RESET CIRCUIT) this will reset the microcontroller IC6000.

Apply signal through the video generator or tune the TV color receiver to crosshatch pattern. Connect an accurate HV meter between the picture tube anode and chassis ground. Access Video Menu and adjust Brightness and Contrast controls for minimum screen luminance . Wait until, the Video Menu or display disappear. Read HV meter.

SCREEN B+ VDC HV NOM HV MAX

SIZE

25 124.0 +/- 2% 28 29 27 124.0 +/- 2% 27 29

32 128.5 +/- 2% 30 31.5 36 128.5 +/- 2% 30 31.5

0 BEAM

COMPONENT LEVEL REPAIR

MODULE LEVEL REPAIR ONLY

KV KV

Video Processor

ICX2200

P29

RIN

RL2

C

GND

DX3005

CA CHASSIS

SHUT DOWN CIRCUIT

ZDX3004

RL1

CM151 3-1 CA - SERVICING

SERVICING (continued)

GENERAL INFORMATION

Servicing the CA chassis is the same as with other Zenith single-board chassis. If the set is dead, first check the standby and switched voltages. If the switched voltages do not appear, check the power “On” circuit. If the power supply is OK and the set will turn On, the Horizontal sweep circuit should be checked next. Is horizontal drive available from the video processor chip? If the sweep system does not start up, sweep-derived voltages will not be generated.

If the sweep and high-voltage circuits are OK and video or audio are missing, then the audio/video/tuner circuits should be checked. If the receiver is working but some feature is not working, check the Service Menu. Bring up the Service menu and check to be sure that all items are set correctly.

COMPONENT-LEVEL SERVICING

The following troubleshooting information is intended for component servicing on the 19" through 27" models. Replacement modules are available on an exchange basis for the 32" and 36" models.

WARNING!

DO NOT disconnect the Video output module from the CRT when troubleshooting 32” and 36” receivers. If the video output module is removed on these sets while power is ON, the CRT will arc and can be permanently damaged. Also, the technician is in danger of serious shock. There is a termination circuit (W5101) on the

CRT module to prevent this from happening

SERVICING THE POWER SUPPLY

Check the standby voltages first:

+ VDC at CX3407 (169.7 VDC when 120 VCA) + B at CX3420 (B is about 124 VDC for CA 25v

and 27v and 130 VDC for CA 32v and 36v) +18 DC at CX3424 +5 DC at pin 3 of ICX3402

Check the following:

Keyboard input at IC6000 pin 7 and 8 IR input at IC6000 pin 15 Power On output at IC6000 pin 32 Q3402 power supply “turn On” transistor.

If the CRT or Video processor IC are replaced, Black/ White tracking must be reset. Refer to the Service Menus section of this book for Black/White tracking adjustments.

STEREO MODULE

When the MTS stereo module is replaced, be sure to unplug AC power cord. This will ensure that the replacement module is recognized by the microprocessor when power is reapplied. If the set is only turned off, the audio module may not operate properly.

After the audio module is replaced, access the Service Menu and be sure the seven stereo adjustments are set properly. These adjustments are Service Items #40 through 46 for the 221-1006-04 µP chip, and Service Items #43 through 49 for the 221-1006-05 µP chip. Proper settings for these adjustments are printed on the module label along with the bar code on the bar code label.

When troubleshooting video circuits, remember that all video travels through the PIP IC (if used) and the Video/ Audio switcher IC. A defect in either of these IC’s can result in no video.

Check the Switched Voltages

+9 volts DC at pin 3 of ICX3401 +15 volts DC at CX3430

Sweep-derived Voltages

+25 volts DC at the junction of CX2105 and

RX2124 +35 volts DC at CX3253 and +200 volts DC at the

junction of CX3208 AND RX3208

CRT Filament

Check at pins 1 and 2 of connector 2F5. They should read 6.1 to 6.3 volts AC on a true RMS meter. They will read 7.5 volts AC on a VTVM, and show 22 volts P-P on a scope.

VIDEO PROCESSOR ICX2200

Check the following key operating Signals and voltages:

Composite Video Out at pin 47 Switched Video Out to micro at pin 41 Tuner composite Video in at pin 37 Luminance in from PIP at pin 43 Chroma in from PIP at pin 45

CM151 3-2 CA - SERVICING

SERVICE ADJUSTMENTS

Composite Audio out at pin 2 Horizontal Drive at pin 32 Vertical Drive at pin 24 Video output Blue at 2C5 pin 3 Video output Green at 2C5 pin 2 Video output Red at 2C5 pin 1 B+ 9 volts on pins 9, 23, 46, and 48 Serial Data, Serial Clock at pins 27, 28

HORIZONTAL CIRCUIT

Check the following:

Horizontal drive to base of QX3203 predriver Driver transformer output at base of Q3203 Shutdown voltage at cathode of ZDX3004 Scan-derived voltages +25, +35 and +200 volts

MICROPROCESSOR IC6000

Check the following:

IR inout on pin 2 +5 volts on pin 27

Clock Xtal on pins 24, and 25

Serial Data, Serial Clock on pins 36 and 38 Reset at pin 30 Horiz. Flyback on pin 1, Vert pulse on pin 2 R, G, B out on pins 50, 51, and 52

VERTICAL CIRCUIT IC2100

Check the following:

Vertical drive pulse at pin 3 +25 volts at pins 2,10 and 11 Vertical out at pin 1 Poor Linearity: Check C2102 and C2103

SERVICE ADJUSTMENTS (Electrical)

G2 ADJUST 1 . Set brightness and contrast in the Video menu to

mid range.

2. Set color level to minimum .

3. Connect the output of an NTSC generator to the antenna input on the receiver.

4. Select a color bar signal and turn color off . Adjust the G2 control so that the bar patterns range from completely black to a ‘not overdriven ‘ (Not saturated) white. There should be a distinct difference between the black and white bars . Also the different shades of gray should also be distinguishable if the G2 is set correctly .

5. Return color level control to its normal setting. Leave generator connected if the RGB cutoff is to be adjusted.

VERTICAL SIZE

1. Vertical size adjustment is found in the Factory

Menu (item 12).

2. Horizontal size is on the 32” and 36” models. Adjustment is found in the factory Menu (Item

13).

FOCUS ADJUSTMENT Connect a color bar pattern to the receiver and adjust

the user controls for a good picture . Push the button to the Video Menu, then proceed to adjust the Focus control until distortion of the letters in the menu disappears.

SERVICE ADJUSTMENTS (Service Menu)

CA ADJUSTMENTS OF RGB CUTOFFS

1. If the main module or CRT has been replaced, select “Cool” in the user video menu under Color Temp. The sets items G Gain 1 (Green gain cool) and B Gain 1 (Blue gain cool), in the Service menu to the default setting for correct screen size as listed in the Service Menu (See table ). Set color level and contrast to minimum, and Tint to mid range.

2. Enter the Service menu to gain access to the cutoff adjustments. (Factory mode item 00 must be set to 1 to gain access to these adjustment).

3. Connected the output of an NTSC generator to the antenna input of the receiver, set the generator to a Pure white signal, chroma off. Adjust the color and contrast to obtain a grey raster picture.

4. Carefully observe which color is predominant on the CRT (Red, green, or blue). Do not adjust the cut off control of this color (Leave it zero). Adjust the other two cut off controls for a smog grey color on the display.

6. Set the generator to a color bar pattern and turn the chroma Off. Check that set displays gray scale from black to white. If black level is too high, readjust RF Brightness (Item 9).

7. Return the color level control to preset.

8. Select Warm in the user video menu under Color Temp. Then adjust items R Cut (22), G Cut (23), B Cut (24), G Gain 2 (25) and B Gain 2 (26) according to the Installer’s Menu tables. Readjust each value adding the respective number by looking in the corresponding screen size column.

9. Disable the Factory Menu and select “cool” in the user Video Menu under Color Temp. Factory Mode (Item 00) must be set to zero.

CM151 3-3 CA - SERVICING

SERVICE ADJUSTMENTS (continued)

PURITY & CONVERGENCE SETUP PROCEDURE

PRELIMINARY SETUP

1. Allow the receiver to warm up for 15 to 20 minutes.

2. Degauss the CRT.

3. Connect a crosshatch generator to the receiver and “rough in” the static (center) convergence. Follow the Convergence Procedure.

4. Adjust for best focus.

PURITY ADJUSTMENT

1. Purity tab positioning. Set the 2 pole purity tabs together in the 3 or 9

o’clock positions and the 4-pole and 6-pole purity tabs together in the 12 or 6 o’clock positions.

2. Move yoke to the maximum forward funnel position.

3. Now switch the crosshatch generator to a red field.

4. Pull the yoke toward the rear of the CRT neck, keeping it centered, until a red raster is displayed.

5. If the red raster is not displayed as a pure red field, adjust the 2-pole purity tabs until a pure field is obtained.

CONVERGENCE ADJUSTMENT

1. Release locking assembly.

2. Connect crosshatch generator to the receiver and adjust static (center) convergence as follows:

a. Adjust the 4-pole static control by moving the

two tabs separately to converge the red and blue lines horizontally. Move the two tabs together around the neck of the CRT (in a 45° arc) from the top-dead-center position to converge the red and blue lines vertically.

b. After the 4-pole control has been adjusted to

superimpose the red and blue lines on top of one another. Use the 6-pole static adjustment to place the converged red and blue lines over the green line. Move the two tabs together around the neck of the CRT (in a 30° arc) from the top-dead-center position to move the lines vertically. Adjusting the two tabs separately will move the converged beam to the left or right. Using a crosshatch generator capable of producing individual fields, adjust the generator to produce a red field. Use the purity tabs to center a red stripe.

6. Check for proper yoke tilt setting.

Wedges' Adhesive Tape (3)

Deflection Yoke

Purity & Convergence Magnet Assembly Unit

4 Pole

Yoke's Glass Cloth Tape

Rubber Wedges (3)

6 Pole

Purity Magnet

CRT RingLocation Purity Adjust T absBeam Movement for Convergence

Ring

Pairs

6Pole

Convergence

R&B over G

4Pole

Convergence

RoverB

Rotation direction of Both Tabs

Opposite

Same

Opposite

Same

Movementof Red and Blue Beams

B B

OR

R R

B

OR

R

B

OR

R

OR

B

R

B

R

BR

CM151 3-4 CA - SERVICING

SERVICE ADJUSTMENTS (continued)

VERTICAL-TILT WEDGE ADJUSTMENT

The vertical lines at 6 and 12 o’clock are converged by vertically tilting the yoke and inserting a wedge at the top of the yoke until it is firmly seated between the CRT glass and the horizontal coils.

HORIZONTAL-TILT WEDGE ADJUSTMENT

The vertical lines at 3 o’clock and 9 o’clock are converged by horizontally tilting the yoke and inserting a wedge. Adjust first at 4 or 8 o’clock, whichever has the larger space, until the wedge is firmly seated between the CRT glass and yoke coils. Then, insert the 3rd wedge in the remaining horizontal tilt position until it is firmly seated between the CRT glass and yoke coils. Convergence at 3 and 9 o’clock should be maintained during this operation.

When the 3 wedges are firmly installed and positioned for acceptable convergence, lock the wedges in place by applying a 2.5 inches long strip of tape across the tabs of each wedge, firmly against the CRT glass. The CRT glass surface should be clean and free of dust and other foreign material.

UNUSUAL TILT CASE

There may be some instances where the picture tube and yoke will require vertical tilt in the opposite (up) direction to obtain convergence. In such cases, insert the vertical tilt wedge at the bottom (6 o’clock) position. Follow through on the horizontal tilt adjustment by using the 2 and 10 o’clock positions and secure each wedge with a piece of tape, as described above.

IMPROVING CRT CORNER PURITY

CRTs that display corner purity problems even after following the service procedures can be modified with a picture correction kit (P/N 949-50). The purity can be improved by placing a picture-correction magnet (included in the kit) on the CRT funnel. Refer to the following modification steps and illustration to place the magnet properly. Fully degauss the CRT before installing correction magnets.

MODIFICATION

1. Place the magnet on the CRT funnel as shown in the figure displayed below, in the quadrant exhibiting impurity.

2. Rotate the magnet in place to the position shown for best purity.

3. Place a piece of 1/2" by 2" long Fiberglass tape over the magnet to hold it in place.

4. Degauss the CRT once magnet is in place to insure that the magnet is not over the internal magnet shield.

NOTE: If the magnet is placed over the internal

magnet shield, any apparent purity correction will disappear after degaussing. Reposition the correction magnet off the internal shield and degauss again.

X

Clamp and Screw

6 Pole Magnets

2 Pole Magnets

4 Pole Magnets

CM151 3-5 CA - SERVICING

2" To 3"

MAGNET

IF AND AUDIO ALIGNMENT PROCEDURE

VIDEO DETECTOR

If there is no viewable picture on screen, access the Service Menu and check default settings for the following items:

RFAGC

MICRO LOCATION RANGE PRESET VALUE

221-01384 17 0-63 42 221-01385 17 0-63 42 221-01386 17 0-63 42 221-01387 16 0-63 42

PIFVCO

MICRO LOCATION RANGE PRESET VALUE

221-01384 21 0-127 52 221-01385 21 0-127 52 221-01386 21 0-127 52 221-01387 21 0-127 52

Tune in a good off air signal. Place a high impedance meter at pin 44 of ICX2200. Adjust to 2.5 volts DC.

AGC DELAY

With a strong noise free antenna signal, adjust ITEM therefore RIF AGC on the Service Menu to a lower settings until signal gets noisier. Increase settings for a noise free picture.

Note: If settings goes to high above 50, the tuner

input will overload . Under certain conditions, beats will also occur in the picture .

AUDIO DETECTOR

If no audio is present, access the Service Menu and check default settings for the following items:

AUD LVL

MICRO LOCATION RANGE PRESET VALUE

221-01384 16 0-63 46 221-01385 16 0-63 46 221-01386 16 0-63 46 221-01387 16 0-63 46

MTS AND STEREO DECODER ALIGNMENT

The purpose of this procedure is adjusting registers of SONY audio decoder and processor CXA2054S for MTS models or audio decoder CXA2104S for STEREO models(I 1400 in both cases).

Note: Alignment should be accomplished at least ten

minutes after the TV set had been turned on.

Five register of the audio processor should be adjusted for MTS models and three for STEREO models. Bits TESTDA and TEST1 should be set according with the current adjust for MTS models (for STEREO models bits TEST-DA and TEST1 will not be shown on the service menu because their status do not need to be changed to do the adjustments).

Inside of the service menu (only for MTS models): Both TEST-DA = “0" and TESTI = “0" conditions are

selected when the internal menu is activated. Enter the “SWAP” key of the remote control, then ten

bits registers will display in the bottom of the screen (see the figure 1). The first one is TESTDA register and the second one is TEST1 register.

Enter the “QUIT” key of the remote control in order to set TESTDA = “0” and TEST1 = “1”.

Enter again the “QUIT” of the remote control in order to invert the state of the registers.

AATT Adjust

(for MTS and Stereo models) Set bits TEST-DA = “0” and TEST1 = ‘0" of IC1400.

Set the chassis for RF input.

A ATT

MICRO LOCATION RANGE PRESET VALUE

221-01384 32 0-15 9 221-01385 29 0-15 9 221-01386 29 0-15 9 221-01387 26 0-15 9

Tune in a good strong off air signal. Place a high impedance meter on pin 54 of ICX2200 or

from + side of capacitor C1 214. Adjust Ll 202 for 4 volts DC.

CM151 3-6 CA - SERVICING

Input signal: PIF 30 dBmv modulated with color bars at 85% mod., SIF 19 dBmv modulated with 100 Hz at 25 KHz deviation (100 % mod.), 75 us off.

IF AND AUDIO ALIGNMENT PROCEDURE (continued)

Adjust A ATT register in IC1400 for 490 mVrms (± 10mVrms) in TVOUT-L output, pin 44 of IC1400 for MTS models and at pin 11 for STEREO models.

Stereo, SAP VCO adjustment

(only for MTS models) Set bits TEST-DA = “1” and TEST1 = “0” of IC1400. Monitor the TVOUT-R output frequency (pin 43 of

IC1400) in a no input state. Adjust A VCO register of IC1400 so that frequency is as

close to 62.936 KHz (± 0.5 KHz) as possible.

A VCO

MICRO LOCATION RANGE PRESET VALUE

221-01384 - - 221-01385 30 0-63 31 221-01386 - - 221-01387 27 0-63 31

Stereo, SAP dbx filter adjustment

(only for MTS models) Set bits TEST-DA = “0” and TEST1 = “I” of IC1400.

Input 9.4 KHz, 600mVrms to COMP-IN pin 19 of IC1400. While monitoring the STATUS FLAG (FILADJ bit, see figure

2) of IC1400, adjust A FILTER register. Align with the center of the FILADJ = 1 .

Separation Adjustment (for MTS and Stereo models)

Set bits TEST-DA = 0 and TEST1 = 0 of IC1400 for MTS models.

Set the chassis for RF input. Set IC1400 to stereo mode. a) Input signal: PIF 30 dBmv modulated with color bars

at 85% mod., SIF 19 dBmv modulated with stereo signal, 300 Hz at 12.9 KHz deviation (30 % mod.), left channel only, dbx ON.

b) Adjust WIDEBAND register to reduce right speaker

output at the minimum. Set the frequency only of

ASPECTRAL

MICRO LOCATION RANGE PRESET VALUE

221-01384 33 0-63 31 221-01385 17 0-63 31 221-01386 17 0-63 31 221-01387 16 0-63 31

WBAND

MICRO LOCATION RANGE PRESET VALUE

221-01384 34 0-63 31 221-01385 33 0-63 31 221-01386 31 0-63 31 221-01387 30 0-63 31

SIF signal to 3 KHz. Adjust ASPECTRAL register to reduce right speaker output at the minimum.

CM151 3-7 CA - SERVICING

MODEL PARTS

SECTION 4

MODEL PARTS

B25A02Z

Part # Description

014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 024-03372 COVER, BLANK, 2 X 5 SPEAKER OPENING 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 050-02576-08 CONNECTOR AND CABLE ASSEMBLY 095-04456-06 TRANSFORMER, DEFLECTION, YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-23 SPACE COMMAND TRANSMITTER, TV ONLY SC3492Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00916 LENS, IR 206-03551 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A10Z, B25A10ZC, B25A10Z6, B25A10ZC6

Part # Description

014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY

SC3492Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00916 LENS, IR 206-03476 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A10ZCF

Part # Description

014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY

SC3492Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00916 LENS, IR 206-03476 INSTR BOOK, OPERATION GUIDE

206-03557 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A11Z, B25A11Z6

Part # Description

014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-09 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00916 LENS, IR 206-03477 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A11ZF

Part # Description

014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-09 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00916 LENS, IR 206-03477 INSTR BOOK, OPERATION GUIDE 206-03556 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A24Z, B25A24Z6

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-14 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10554 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL

CM151 4-1 CA - MODEL PARTS

MODEL PARTS (Continued)

A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 194-02535 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY

F-50826 KEYBOARD ASSY, WITH IR RECEIVER, AGUA

CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A24ZF

Part # Description

014-12143-02 CABINET TRAY, MOLDED PLASTIC 014-12181-09 CABINET REAR, TV, MOLDED PLASTIC 014-12187-14 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10554 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00858-01 LENS, PRIMARY CONTROLS AND IR 194-02535 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE 206-03555 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY F-50826 KEYBOARD ASSY, WITH IR RECEIVER, AGUA

CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A30ZC

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00887 LENS, INFRARED 194-02535-01 PAD, PUSHBUTTONS 206-03480 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY

F-50825 KEYBOARD ASSY, WITH IR RECEIVER, AGUA

CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A30ZCF

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 101-08795 LABEL, BLANK, WHITE 112-00932-01 SCREW, THD CUT, 4-24 X 0.312 TP BT BP, PAN

HEAD, PHILLIPS 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00887 LENS, INFRARED 194-02535-01 PAD, PUSHBUTTONS 206-03480 INSTR BOOK, OPERATION GUIDE 206-03554 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY F-50825 KEYBOARD ASSY, WITH IR RECEIVER, AGUA

CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A74R

Part # Description

002-04084-11 CABINET BACK, PRESSED WOOD 012-10810-01 MOLDED PLASTIC, PANEL, JACK PACK, GA CHASSIS 014-12191-03 CABINET MAIN, TV, WOOD 020-04330-35 COIL, DEGAUSSER 030-01455-14 DECORATIVE ITEM, CABINET HARDWARE 046-10555 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS, STR 049-01302-03 SPEAKER, OVAL, 3X5 INCH 057-09067-09 ESCUTCHEON, TV, MOLDED PLASTIC 095-04456-05 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00876 CRYSTAL WINDOW, IR 194-02535 PAD, PUSHBUTTONS 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY F-50961 KEYBOARD ASSY, WITH IR, AGUA CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

CM151 4-2 CA - MODEL PARTS

MODEL PARTS (Continued)

B25A74LK

Part # Description

002-04084-11 CABINET, BACK, PRESSED WOOD 012-10810-01 MOLDED PLASTIC, PANEL, JACK PACK, GA CHASSIS 014-12191-05 CABINET, MAIN 020-04330-35 COIL, DEGAUSSER 030-01455-14 DECORATIVE ITEM, CABINET HARDWARE 046-10555 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS, STR 049-01302-03 SPEAKER, OVAL, 3X5 INCH 057-09067-09 ESCUTCHEON, TV, MOLDED PLASTIC 095-04456-05 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00876 CRYSTAL WINDOW, IR 194-02535 PAD, PUSHBUTTONS 206-03450 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY F-50961 KEYBOARD ASSY, WITH IR, AGUA CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B25A76R5

002-04103-01 CABINET BACK/ / 014-11639-19 CABINET REAR/ TV, MOLDED PLASTIC/ 014-12333 CABINET MAIN/ TV, WOOD/ 020-04330-35 COIL/ DEGAUSSER/ 040-00567 HINGE/ / 049-01302-03 SPEAKER/ OVAL/ 3X5 INCH 057-09067-08 ESCUTCHEON/ TV, MOLDED PLASTIC/ 100-00812-05 VACUUM TUBE/ CRT, COLOR, 25 INCH DIAGONAL/ 110-00687-59 GRILLE CLOTH/ RECTANGULAR/ 152-00335 WEDGE/ YOKE SPACER/POSITIONER/ 192-00876 CRYSTAL WINDOW / IR/ 192-00892 GLASS DOOR/ / 206-03450 INSTR BOOK/ OPERATION GUIDE/ A-07690-06 MAGNET ASSEMBLY/ STATIC CONVERGENCE AND

PURITY/

CB25A25Z, CB25A25Z6

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12038-02 CABINET TRAY, TV, MOLDED PLASTIC 014-12229-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12230-03 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10561 KNOB ARRAY, PUSH BUTTON, 10 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00887 LENS, INFRARED 194-02535-01 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE

A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY

F-50825 KEYBOARD ASSY, WITH IR RECEIVER, AGUA

CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

LGB26A11ZM, LGB26A11ZM6

Part # Description

014-12296-17 CABINET FRONT, TV, MOLDED PLASTIC 014-12297-09 CABINET REAR, TV, MOLDED PLASTIC 020-04330-42 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04456-06 TRANSFORMER, DEFLECTION YOKE, 25V HIBI

COMERCIAL A63AFW38X VACUUM TUBE, CRT, COLOR, 25 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 192-00916 LENS, IR 206-03494 INSTR BOOK, OPERATION GUIDE A-07690-06 MAGNET ASSEMBLY, STATIC CONVERGENCE AND

PURITY A-14323 BALUN ASSEMBLY, A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

B27A10Z, B27A10Z6, B27A10ZC, B27A10ZC6

Part # Description

014-12304-03 CABINET REAR, TV, MOLDED PLASTIC 014-12305-08 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY

SC3492Z 192-00916 LENS, IR 206-03476 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

B27A10Z5, B27A10ZC5

Part # Description

014-12304-03 CABINET REAR, TV, MOLDED PLASTIC 014-12305-08 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00213-23 SPACE COMMAND TRANSMITTER, TV ONLY SC3492Z 192-00916 LENS, IR 206-03476 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE, ASSEMBLY

CM151 4-3 CA - MODEL PARTS

MODEL PARTS (Continued)

B27A10ZCF

Part # Description

014-12304-03 CABINET REAR, TV, MOLDED PLASTIC 014-12305-08 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY

SC3492Z 192-00916 LENS, IR 206-03476 INSTR BOOK, OPERATION GUIDE 206-03557 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

B27A11Z, B27A11Z6, B27A11ZC

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03477 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

B27A11Z5, B27A11Z65, B27A11ZC5

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03477 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-01 CRT AND YOKE, ASSEMBLY

B27A24Z, B27A24Z6

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12317-04 CABINET FRONT, TV, MOLDED PLASTIC

020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 138-01964-02 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE

138-01964-03 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

RIGHT SIDE 192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

B27A24Z5, B27A24Z65

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12317-04 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 138-01964-02 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE 138-01964-03 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

RIGHT SIDE 192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19058-01 CRT AND YOKE, ASSEMBLY

B27A24ZF

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12317-04 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 138-01964-02 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE 138-01964-03 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

RIGHT SIDE 192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE 206-03555 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT

CM151 4-4 CA - MODEL PARTS

MODEL PARTS (Continued)

F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

B27A24ZF5

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12317-04 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 138-01964-02 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE

138-01964-03 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

RIGHT SIDE 192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03479 INSTR BOOK, OPERATION GUIDE 206-03555 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19058-01 CRT AND YOKE, ASSEMBLY

B27A30Z, B27A30ZC, B27A30ZC6

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03480 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-01 CRT AND YOKE, ASSEMBLY

B27A30ZCF

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03480 INSTR BOOK, OPERATION GUIDE 206-03554 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

B27A30ZCF5

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03480 INSTR BOOK, OPERATION GUIDE 206-03554 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-01 CRT AND YOKE, ASSEMBLY

B27A30ZC5, B27A30ZC65

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03480 INSTR BOOK, OPERATION GUIDE

CM151 4-5 CA - MODEL PARTS

B27A34Z, B27A34Z6

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12347 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 138-01965 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE

138-01965-01 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE

MODEL PARTS (Continued)

192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03481 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-21 GND STRAP ASSY, CRT F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19112 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 27V 1.7R

B27A34ZF

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12347 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 138-01965 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE

138-01965-01 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE 192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03481 INSTR BOOK, OPERATION GUIDE 206-03553 INSTR BOOK, OPERATION GUIDE A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-21 GND STRAP ASSY, CRT F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19112 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 27V 1.7R

B27A74R

Part # Description

002-04084-13 CABINET BACK, PRESSED WOOD 012-10810-01 MOLDED PLASTIC, PANEL, JACK PACK, GA CHASSIS 014-12326 CABINET MAIN, TV, WOOD 020-04330-30 COIL, DEGAUSSER 030-01455-09 DECORATIVE ITEM, CABINET HARDWARE 046-10555 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS, STR 049-01334-02 SPEAKER, OVAL, 3X6.500 057-09055-43 ESCUTCHEON, CRT 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00872 CRYSTAL WINDOW, IR, STEREO, AND COLOR SENTRY 194-02535 PAD, PUSHBUTTONS 197-00180-01 CUP, CABINET BACK 206-03372 INSTR BOOK, OPERATION GUIDE F-50961 KEYBOARD ASSY, WITH IR, AGUA CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-03 CRT AND YOKE ASSEMBLY

B27A74R5

Part # Description

002-04084-13 CABINET BACK, PRESSED WOOD 012-10810-01 MOLDED PLASTIC, PANEL, JACK PACK, GA CHASSIS 014-12326 CABINET MAIN, TV, WOOD

020-04330-30 COIL, DEGAUSSER 030-01455-09 DECORATIVE ITEM, CABINET HARDWARE 046-10555 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS, STR 049-01334-02 SPEAKER, OVAL, 3X6.500 057-09055-43 ESCUTCHEON, CRT 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00872 CRYSTAL WINDOW, IR, STEREO, AND COLOR SENTRY 194-02535 PAD, PUSHBUTTONS 197-00180-01 CUP, CABINET BACK 206-03372 INSTR BOOK, OPERATION GUIDE F-50961 KEYBOARD ASSY, WITH IR, AGUA CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE ASSEMBLY

B27A76R

Part # Description

002-04103-02 CABINET BACK, 014-11639-20 CABINET REAR, TV, MOLDED PLASTIC 014-12327 CABINET MAIN, TV, WOOD 020-04330-30 COIL, DEGAUSSER 040-00567 HINGE, 046-10555 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS, STR 049-01334-02 SPEAKER, OVAL, 3X6.500 057-09055-42 ESCUTCHEON, CRT 110-00687-59 GRILLE CLOTH, RECTANGULAR 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00872 CRYSTAL WINDOW, IR, STEREO, AND COLOR SENTRY 192-00892 GLASS DOOR, 194-02535 PAD, PUSHBUTTONS 206-03372 INSTR BOOK, OPERATION GUIDE F-50961 KEYBOARD ASSY, WITH IR, AGUA CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-03 CRT AND YOKE ASSEMBLY

B27A76R5

Part # Description

002-04103-02 CABINET BACK, 014-11639-20 CABINET REAR, TV, MOLDED PLASTIC 014-12327 CABINET MAIN, TV, WOOD 020-04330-30 COIL, DEGAUSSER 040-00567 HINGE, 046-10555 KNOB ARRAY, PUSH-BUTTON, 10 POSITIONS, STR 049-01334-02 SPEAKER, OVAL, 3X6.500 057-09055-42 ESCUTCHEON, CRT 110-00687-59 GRILLE CLOTH, RECTANGULAR 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00872 CRYSTAL WINDOW, IR, STEREO, AND COLOR SENTRY 192-00892 GLASS DOOR, 194-02535 PAD, PUSHBUTTONS 206-03372 INSTR BOOK, OPERATION GUIDE F-50961 KEYBOARD ASSY, WITH IR, AGUA CHASSIS A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE ASSEMBLY

CM151 4-6 CA - MODEL PARTS

MODEL PARTS (Continued)

LGB29A10ZM

Part # Description

014-12304-03 CABINET REAR, TV, MOLDED PLASTIC 014-12305-08 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01526-03 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00213-23 SPACE COMMAND, TRANSMITTER, TV ONLY

SC3492Z 192-00916 LENS, IR 206-03495 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY, A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

LGB29A10ZM5

Part# Description

014-12304-03 CABINET REAR, TV, MOLDED PLASTIC 014-12305-08 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01526-03 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00213-23 SPACE COMMAND TRANSMITTER, TV ONLY, SC3492Z 192-00916 LENS, IR 206-03495 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE, ASSEMBLY

LGB29A11ZM

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01526-03 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03494 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY, A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

LGB29A11ZM5

Part# Description

012-10858-03 MOLDED PLASTIC PANEL, JACK PACK 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01526-03 DECORATIVE ITEM, LOGO, ZENITH

049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03494 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE ASSEMBLY F-52954 KEYBOARD ASSY, 6 KEY

LGB29A13ZM

Part # Description

014-12304-03 CABINET REAR, TV, MOLDED PLASTIC 014-12305-08 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-30 COIL, DEGAUSSER 030-01526-03 DECORATIVE ITEM, LOGO, ZENITH 046-10578 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3345Z 192-00916 LENS, IR 206-03498 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY, A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE, ASSEMBLY

LGB29A24ZM

Part # Description

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12317-04 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10589 KNOB ARRAY, PUSH-BUTTON, 6 POSITIONS 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 138-01964-02 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

LEFT SIDE 138-01964-03 CABINET GRILLE, CLOTH OVER PLASTIC FRAME,

RIGHT SIDE 192-00923 LENS, IR 194-02665 PAD, PUSHBUTTONS 206-03497 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY, A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-53039 KEYBOARD ASSY, 6 BUTTON, 27V GB CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

LGB29A24ZM5

Part # Description

012-10858-04 MOLDED PLASTIC PANEL, JACK PACK 014-12254-06 CABINET REAR, TV, MOLDED PLASTIC 014-12317-04 CABINET FRONT, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND TRANSMITTER, MBR3447Z

CM151 4-7 CA - MODEL PARTS

MODEL PARTS (Continued)

138-01964-02 CABINET GRILLE, CLOTH OVER PLASTIC, LEFT 138-01964-03 CABINET GRILLE, CLOTH OVER PLASTIC, RIGHT 192-00923 LENS, IR 206-03497 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE, ASSEMBLY F-53039 KEYBOARD ASSY, 6 POSITION

LGB29A30ZM

Part # Description

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 046-10588 KNOB ARRAY, PUSH BUTTON, 6 POSITION 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 194-02663 PAD, PUSHBUTTONS 206-03496 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY, A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT F-52954 KEYBOARD ASSY, 6 BUTTON, 27V GA CHASSIS A-19058-03 CRT AND YOKE, ASSEMBLY, 27V

LGB29A30ZM5

Part # Description

012-10858-03 MOLDED PLASTIC PANEL, JACK PACK 014-12281-08 CABINET FRONT, TV, MOLDED PLASTIC 014-12282-06 CABINET REAR, TV, MOLDED PLASTIC 020-04330-43 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03496 INSTR BOOK, OPERATION GUIDE A-14323 BALUN ASSEMBLY A-18681-01 LINE CORD ASSY WITH YEONHO CONNECTOR A-18695-02 GND STRAP ASSY, CRT A-19058-01 CRT AND YOKE ASSEMBLY F-52954 KEYBOARD ASSY, 6 KEY

B32A24Z

Part # Description

009-02068 MODULE, MAIN, 32V MTSSAP CA CHASSIS, V-CHIP,

COMB FILTER 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04517-01 DEFLECTION YOKE, FINAL, COLOR TV, 32V A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL

124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03479 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A24Z6

Part # Description

009-02068-01 MODULE, MAIN, 32V MTSSAP CA CHASSIS, V-CHIP,

COMB FILTER 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04517-01 DEFLECTION YOKE, FINAL, COLOR TV, 32V A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03479 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A24ZF

Part # Description

009-02068 MODULE, MAIN, 32V MTSSAP CA CHASSIS, V-CHIP,

COMB FILTER 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04517-01 DEFLECTION YOKE, FINAL, COLOR TV, 32V A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03479 INSTR BOOK, OPERATION GUIDE 206-03555 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A30Z

Part # Description

009-02072 MODULE, MAIN, 32V STEREO CA CHASSIS, V-CHIP,

PIP, 3 JACKS 009-02107 MODULE, SINGLE PIP, CA CHASSIS

CM151 4-8 CA - MODEL PARTS

MODEL PARTS (Continued)

012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04208-01 TRANSFORMER, DEFLECTION YOKE, 110 DEGREE A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03480 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A30Z6

Part # Description

009-02072-01 MODULE, MAIN, 32V STEREO CA CHASSIS, V-CHIP,

PIP, 3 JACKS 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04208-01 TRANSFORMER, DEFLECTION YOKE, 110 DEGREE A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03480 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A30ZF

Part # Description

009-02072 MODULE, MAIN, 32V STEREO CA CHASSIS, V-CHIP,

PIP, 3 JACKS 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04208-01 TRANSFORMER, DEFLECTION YOKE, 110 DEGREE A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER

192-00912 LENS, PRIMARY CONTROLS AND IR 206-03480 INSTR BOOK, OPERATION GUIDE 206-03554 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A34Z

Part # Description

009-02075 MODULE, MAIN, 32V MTSSAP CA CHASSIS, V-

CHIP,PIP,COMB FILT 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04208-01 TRANSFORMER, DEFLECTION YOKE, 110 DEGREE A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03481 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A34Z6

Part # Description

009-02075-01 MODULE, MAIN, 32V MTSSAP CA CHASSIS, V-

CHIP,PIP,COMB FILT 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04208-01 TRANSFORMER, DEFLECTION YOKE, 110 DEGREE A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03481 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B32A34ZF

Part # Description

009-02075 MODULE, MAIN, 32V MTSSAP CA CHASSIS, V-

CHIP,PIP,COMB FILT 009-02107 MODULE, SINGLE PIP, CA CHASSIS

CM151 4-9 CA - MODEL PARTS

MODEL PARTS (Continued)

012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12284-23 CABINET FRONT, TV, MOLDED PLASTIC 014-12285-08 CABINET REAR, TV, MOLDED PLASTIC 020-04330-33 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 095-04208-01 TRANSFORMER, DEFLECTION YOKE, 110 DEGREE A81AGZ50X VACUUM TUBE, CRT,COLOR, 32 INCH DIAGONAL 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 152-00335 WEDGE, YOKE SPACER/POSITIONER 152-00335-01 WEDGE, CRT SPACER 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03481 INSTR BOOK, OPERATION GUIDE 206-03553 INSTR BOOK, OPERATION GUIDE A-15947-01 BEAM BENDER, ASSEMBLY A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-03 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A24Z

Part # Description

009-02069 MODULE, MAIN, 36V MTSSAP CA CHASSIS, V-CHIP,

COMB FILTER 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03479 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A24Z6

Part # Description

009-02069-01 MODULE, MAIN, 36V MTSSAP CA CHASSIS, V-CHIP,

COMB FILTER 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03479 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A24ZF

Part # Description

009-02069 MODULE, MAIN, 36V MTSSAP CA CHASSIS, V-CHIP,

COMB FILTER 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233 SPACE COMMAND, TRANSMITTER, MBR3447Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03479 INSTR BOOK, OPERATION GUIDE 206-03555 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A30Z

Part # Description

009-02073 MODULE, MAIN, 36V STEREO CA CHASSIS, V-CHIP,

PIP, 3 JACKS 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03480 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A30Z6

Part # Description

009-02073-01 MODULE, MAIN, 36V STEREO CA CHASSIS, V-CHIP,

PIP, 3 JACKS 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03480 INSTR BOOK, OPERATION GUIDE

CM151 4-10 CA - MODEL PARTS

MODEL PARTS (Continued)

A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A30ZF

Part # Description

009-02073 MODULE, MAIN, 36V STEREO CA CHASSIS, V-

CHIP, PIP, 3 JACKS 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-03 MOLDED PLASTIC, PANEL, JACK PACK, CA

CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00229-01 SPACE COMMAND, TRANSMITTER, BIG BUTTON,

MBR3346Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03480 INSTR BOOK, OPERATION GUIDE 206-03554 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A34Z0

Part # Description

009-02076 MODULE, MAIN, 36V MTSSAP CA CHASSIS, V-

CHIP,PIP,COMB FILT 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA

CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03481 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03481 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A34ZF

Part # Description

009-02076 MODULE, MAIN, 36V MTSSAP CA CHASSIS, V-

CHIP,PIP,COMB FILT 009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA CHASSIS 014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER 030-01532 DECORATIVE ITEM, LOGO, ZENITH 049-01368-03 SPEAKER, OVAL, 6 X 13 CM 124-00233-01 SPACE COMMAND, TRANSMITTER, MBR3457Z 192-00912 LENS, PRIMARY CONTROLS AND IR 206-03481 INSTR BOOK, OPERATION GUIDE 206-03553 INSTR BOOK, OPERATION GUIDE A-18639 CRT ASSEMBLY, WDEFLECTION YOKE AND BEAM

BENDER, 36V CTV A-18681-01 LINE CORD ASSY, WITH YEONHO CONNECTOR A-18695-04 GND STRAP ASSY, CRT F-52060 KEYBOARD ASSY, 10 POSITION

B36A34Z6

Part # Description

009-02076-01 MODULE, MAIN, 36V MTSSAP CA CHASSIS, V-

009-02107 MODULE, SINGLE PIP, CA CHASSIS 012-10858-04 MOLDED PLASTIC, PANEL, JACK PACK, CA

014-12269-12 CABINET FRONT, TV, MOLDED PLASTIC, 35V-1R 014-12270-12 CABINET REAR, TV, MOLDED PLASTIC, 3536V 020-04330-34 COIL, DEGAUSSER

CM151 4-11 CA - MODEL PARTS

CHIP,PIP,COMB FILT

CHASSIS

COMPONENT PARTS LIST

COMPONENT PARTS LIST REFERENCE CHART

Refer to the chart and Model Identifier to use the Component parts list.

Notes: The following information is for Models

in and out of warranty. Models 27” and below are Component

level repair only.

Models 32” and above are Module level repair only. Module part numbers are listed in the Model Parts List in the beginning of this section.

To Order Parts:call 1-888-3-ZENITH

fax 1-888-6-ZENITH

By Mail: ZENITH NATIONAL PARTS

SALES AND DISTRIBUTION CENTER P O Box 240007 Huntsville, AL 35824-6407

MODEL IDENTIFIER

B25A02Z A B25A10Z B B25A10Z6 C B25A10ZC B B25A10ZC6 C B25A10ZCF B B25A11Z D B25A11Z6 E B25A11ZF D B25A24Z F B25A24Z6 G B25A24ZF F B25A30ZC H B25A30ZCF H B25A74R I B25A76R I B27A10Z J B27A10Z5 a B27A10Z5 a B27A10Z6 K B27A10ZC J B27A10ZC5 a B27A10ZC5 a B27A10ZC6 K B27A10ZCF J B27A11Z L B27A11Z5 M B27A11Z6 N B27A11Z65 O B27A11ZC L B27A11ZC5 M B27A24Z P B27A24Z5 Q B27A24Z6 R B27A24Z65 S B27A24ZF P B27A24ZF5 Q B27A30Z T B27A30ZC T B27A30ZC5 U B27A30ZC6 V B27A30ZC65 W B27A30ZCF T B27A30ZCF5 U B27A34Z X B27A34Z6 Y B27A34ZF X B27A74R Z B27A74R5 Q B27A76R Z B27A76R5 Q

MODEL IDENTIFIER

CB25A25Z F CB25A25Z6 G LGB26A11ZM D LGB26A11ZM6 E LGB29A10ZM J LGB29A10ZM5 a LGB29A10ZM5 a LGB29A11ZM L LGB29A11ZM5 M LGB29A13ZM J LGB29A24ZM P

LGB29A24ZM5 Q LGB29A30ZM T LGB29A30ZM5 U

CM151 4-12 CA - COMPONENTS

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa 2C5 050-01666-13 CONNECTOR&CABLE, ASSY,

ABCDEFGHIJKLMNOPQRSTUVWXYZa 2F5 050-01665-12 CONNECTOR&CABLE, ASSY,

FGHILMNOPQRSTUVWXYZ 2K6 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDEFGHIJKLMNOPQRSTUVWXYZa 3R8 058-00546-03 PLUG, MULTIPRONG, 3

ABCDEFGHIJKLMNOPQRSTUVWXYZa 3T8 058-00546-02 PLUG, MULTIPRONG, 2

ABCDEFGHIJKLMNOPQRSTUVWXYZa 3Y3 058-00546-04 PLUG, MULTIPRONG, 4

ABCDEFGHIJKLMNOPQRSTUVWXYZa 4G9 058-00526-05 PLUG, 0.098P 5 CONTACT ABCDEFGHIJKLMNOPQRSTUVWXYZa 9S4 058-00526-04 PLUG, 0.098P 4 CONTACT ABCDEFGHIJKLMNOPQRSTUVWXYZa C0841 022-08310-16 CAP, 1000 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0842 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0843 022-08310-12A CAP, 100 MFD 20% 25V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C0851 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0852 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0853 022-08049-24A CAP, 0.10 MFD 10% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C0854 022-08310-16 CAP, 1000 MFD 20% 25V,

BCDEHJKLMNOTUVWa C0855M 022-08366-16A CAP, 4,700 PFD 10% 50V,

A C0855M 022-08366-17A CAP, 5,600 PFD 10% 50V,

FGIPQRSXYZ C0855M 022-08366-18A CAP, 6,800 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0861 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0862 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0863 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C0864 022-08310-16 CAP, 1000 MFD 20% 25V,

BCDEHJKLMNOTUVWa C0865M 022-08366-16A CAP, 4,700 PFD 10% 50V,

A C0865M 022-08366-17A CAP, 5,600 PFD 10% 50V,

FGIPQRSXYV C0865M 022-08366-18A CAP, 6,800 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1200M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1201M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1202M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1203M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1204M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1205M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1206 022-08312-03A CAP, 0.47 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1207 022-08312-03A CAP, 0.47 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1208M 022-08370-24A CAP, 22,000 PFD 10% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1209M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1210 022-08309-13A CAP, 220 MFD 20% 16V,

2.5MM, 5 CONTACT, 2 UP

2.5MM, 4 CONTACT, 2 UP

POSITION

ELECTRO

POLYESTER

ELECTRO

POLYESTER

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

POLYESTER

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1211M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1212 022-08312-03A CAP, 0.47 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1213M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC

A C1213M 022-08366-16A CAP, 4,700 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1214 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1215M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1216 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1217M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1218M 022-08352-38A CAP, 120 PFD 5% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1219M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1220M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1221M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1222 022-08309-13A CAP, 220 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1223M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C1224 022-08049-24A CAP, 0.10 MFD 10% 50V,

FGIPQRSXYZ C1401M 022-08370-22A CAP, 15,000 PFD 10% 16V,

FGIPQRSXYZ C1402M 022-08366-18A CAP, 6,800 PFD 10% 50V,

FGIPQRSXYZ C1403M 022-08370-22A CAP, 15,000 PFD 10% 16V,

FGIPQRSXYZ C1404M 022-08366-18A CAP, 6,800 PFD 10% 50V,

FGIPQRSXYZ C1406M 022-08370-24A CAP, 22,000 PFD 10% 16V,

DEFGHILMNOPQRSTUVWXYZ C1409 022-08312-07A CAP, 4.7 MFD 20% 50V,

DEFGHILMNOPQRSTUVWXYZ C1410 022-08312-07A CAP, 4.7 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1413 022-08312-08A CAP, 10 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1414 022-07669-15A CAP, 10 MFD 10% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1415 022-08312-04A CAP, 1 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1416 022-08188-05A CAP, 10 MFD 20% 25V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1417 022-08188-05A CAP, 10 MFD 20% 25V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1418 022-08312-04A CAP, 1 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1419 022-07669-14A CAP, 3.3 MFD 10% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1420 022-08049-13A CAP, 0.012 MFD 10% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1421 022-08257-21A CAP, 5600 PFD 10% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1422 022-08049-20A CAP, 0.047 MFD 10% 50V,

BCDEHJKLMNOTUVWa C1423 022-08312-04A CAP, 1 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1424 022-08257-17A CAP, 2700 PFD 10% 50V,

FGIPQRSXYZ C1425 022-08312-07A CAP, 4.7 MFD 20% 50V,

CERAMIC CHIP, LDLESS

ELECTRO

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

POLYESTER

CERAMIC CHIP, LDLESS

ELECTRO

NONPLZD ELECTROLYTIC

ELECTRO

POLYESTER

CERAMIC DISC

POLYESTER

ELECTRO

CERAMIC DISC

ELECTRO

CM151 4-13 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-12

RC REF PART# DESCRIPTION

FGIPQRSXYZ C1426 022-08188-05A CAP, 10 MFD 20% 25V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1427 022-08188-05A CAP, 10 MFD 20% 25V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1428 022-08312-07A CAP, 4.7 MFD 20% 50V,

BCDEHJKLMNOTUVWa C1429 022-08312-05A CAP, 2.2 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1430 022-08309-12A CAP, 100 MFD 20% 16V,

FGIPQRSXYZ C1431M 022-08368-20A CAP, 10,000 PFD 10% 25V,

FGIPQRSXYZ C1432 022-08312-07A CAP, 4.7 MFD 20% 50V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1433M 022-08368-20A CAP, 10,000 PFD 10% 25V,

BCDEFGHIJKLMNOPQRSTUVWXYZa C1436 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO BCDEHJKLMNOTUVWa C1437 022-08312-05A CAP, 2.2 MFD 20% 50V,

BCDEHJKLMNOTUVWa C1438 022-08312-07A CAP, 4.7 MFD 20% 50V,

BCDEHJKLMNOTUVWa C1439 022-08309-12A CAP, 100 MFD 20% 16V,

FGIPQRSXYZ C1440 022-08309-14A CAP, 330 MFD 20% 16V,

FGIPQRSXYZ C1441M 022-08368-20A CAP, 10,000 PFD 10% 25V,

FGIPQRSXYZ C1442 022-08309-11A CAP, 47 MFD 20% 16V,

FGIPQRSXYZ C1443 022-08312-03A CAP, 0.47 MFD 20% 50V,

FGIPQRSXYZ C1444M 022-08368-20A CAP, 10,000 PFD 10% 25V,

FGIPQRSXYZ C1445 022-08309-11A CAP, 47 MFD 20% 16V,

FGIPQRSXYZ C1446 022-08312-03A CAP, 0.47 MFD 20% 50V,

DEHLMNOTUVW C1455 022-08312-07A CAP, 4.7 MFD 20% 50V,

DEHLMNOTUVW C1456 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2101 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2102 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2103 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2104 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2106 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2108 022-08310-11A CAP, 47 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2109 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2111 022-07786C CAP, 1000 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2112 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGIJKLMNOPQRSZa C2201M 063-11059-09A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2202M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2203 022-08312A CAP, 0.1 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2204 022-08312A CAP, 0.1 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2205 022-08312A CAP, 0.1 MFD 20% 50V,

NONPLZD ELECTROLYTIC

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

POLYESTER

ELECTRO

POLYESTER

ELECTRO

CERAMIC DISC

22 OHM 5% 1/10W

CHIP, LDLESS

ELECTRO

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2206M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2207 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2208 022-08312-05A CAP, 2.2 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2209 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2210M 022-08370-24A CAP, 22,000 PFD 10% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2213M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2214M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2215M 022-08366-04A CAP, 470 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2216 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOPQRSTUVWXYZa C2217M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2218 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2219 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2220 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2221 022-08312A CAP, 0.1 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2222 022-08312A CAP, 0.1 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2223 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOPQRSTUVWXYZa C2224 022-08492-01A CAP, 1 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2225 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2226 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO FGIPQRSXYZ C2227 022-08310-11A CAP, 47 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2229M 022-08354-41A CAP, 160 PFD 5% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2230 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2231 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2232M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2235M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2236M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2237M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2238M 022-08366-08A CAP, 1,000 PFD 10% 50V,

HTUVWXY C2239 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C2241 022-08310-10A CAP, 33 MFD 20% 25V,

HTUVW C2242M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGIJKLMNOPQRSZa C2242M 022-08352-38A CAP, 120 PFD 5% 50V,

MOQSUWa C2254 022-07786-11C CAP, 560 PFD 10% 500V,

ABCDEFGHIJKLNPRTVXYZ C2254 022-08048-01A CAP, 0.0012 MFD 5% 50V,

HTUVWXY C2501M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC

HTUVWXY C2502 022-08309-12A CAP, 100 MFD 20% 16V,

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

POLYESTER

ELECTRO

NONPLZD ELECTROLYTIC

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

POLYESTER

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CERAMIC DISC

POLYESTER

CHIP, LDLESS

ELECTRO

CM151 4-14 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

HTUVWXY C2504 022-08309-11A CAP, 47 MFD 20% 16V,

HTUVWXY C2505 022-08312-08A CAP, 10 MFD 20% 50V,

HTUVWXY C2506 022-08309-11A CAP, 47 MFD 20% 16V,

HTUVWXY C2507M 022-08366-20 CAP, 10,000 PFD 10% 50V,

HTUVWXY C2508 022-08312-08A CAP, 10 MFD 20% 50V,

HTUVWXY C2509M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2510M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2511 022-08312A CAP, 0.1 MFD 20% 50V,

HTUVWXY C2512M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2513 022-08312-01A CAP, 0.22 MFD 20% 50V,

HTUVWXY C2514M 022-08366-20 CAP, 10,000 PFD 10% 50V,

HTUVWXY C2515 022-08310-11A CAP, 47 MFD 20% 25V,

HTUVWXY C2516M 022-08366-28 CAP, 47,000 PFD 10% 50V,

HTUVWXY C2517 022-08312-01A CAP, 0.22 MFD 20% 50V,

HTUVWXY C2518M 022-08352-14A CAP, 12 PFD 5% 50V, CERAMIC

HTUVWXY C2519M 022-08352-38A CAP, 120 PFD 5% 50V,

HTUVWXY C2520M 022-08366A CAP, 220 PFD 10% 50V,

HTUVWXY C2521M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2522M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2524 022-08312-08A CAP, 10 MFD 20% 50V,

HTUVWXY C2526 022-08312-08A CAP, 10 MFD 20% 50V,

HTUVWXY C2527 022-08312-08A CAP, 10 MFD 20% 50V,

HTUVWXY C2529M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2530 022-08312-03A CAP, 0.47 MFD 20% 50V,

HTUVWXY C2531 022-08048-01A CAP, 0.0012 MFD 5% 50V,

HTUVWXY C2532 022-08247-46A CAP, 330 PFD 5% 50V,

HTUVWXY C2534M 022-08366-08A CAP, 1,000 PFD 10% 50V,

HTUVWXY C2536M 022-08366A CAP, 220 PFD 10% 50V,

FGHIPQRSTUVWXYZ C2900 022-08312-08A CAP, 10 MFD 20% 50V,

FGHIPQRSTUVWXYZ C2904 022-08309-12A CAP, 100 MFD 20% 16V,

FGIPQRSXYZ C2906 022-08312-08A CAP, 10 MFD 20% 50V,

FGIPQRSXYZ C2907M 022-08368-20A CAP, 10,000 PFD 10% 25V,

HTUVWXY C2908 022-08312-08A CAP, 10 MFD 20% 50V,

HTUVWXY C2909 022-08312-08A CAP, 10 MFD 20% 50V,

XY C2910 022-08312-08A CAP, 10 MFD 20% 50V,

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

POLYESTER

CERAMIC DISC

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

RC REF PART# DESCRIPTION

HTUVWXY C2911 022-08309-12A CAP, 100 MFD 20% 16V,

XY C2912M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC

XY C2913 022-08309-12A CAP, 100 MFD 20% 16V,

XY C2914 022-08312-08A CAP, 10 MFD 20% 50V,

XY C2916 022-08257-24A CAP, 10,000 PFD 10% 50V,

XY C2917M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC

HTUVWXY C2918 022-08312-08A CAP, 10 MFD 20% 50V,

FGIPQRSXYZ C2919 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3201M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3202 022-08257-08A CAP, 470 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3203 022-08049-16A CAP, 0.022 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3204 022-07786-17C CAP, 2200 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3206 022-07811A CAP, 1000 PFD 10% 1000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3209 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3419 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3421 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3425 022-08310-15 CAP, 470 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3426 022-08309-13A CAP, 220 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3429 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C3460 022-08310-13A CAP, 220 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5101 022-08318-04A CAP, 1 MFD 20% 350V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5102M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5103M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5104 022-07523-01B CAP, 0.01 MFD +80 % & -20 %

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5105M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5106M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5107 022-08309-13A CAP, 220 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5108M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5109M 022-08366A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5110 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C5111 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6001M 022-08352-38A CAP, 120 PFD 5% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6003M 022-08366-04A CAP, 470 PFD 10% 50V,

ABCDEJKa C6004 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6005M 022-08366A CAP, 220 PFD 10% 50V,

ELECTRO

CHIP, LDLESS

ELECTRO

CERAMIC DISC

CHIP, LDLESS

ELECTRO

CHIP, LDLESS

CERAMIC DISC

POLYESTER

CERAMIC DISC

ELECTRO

CERAMIC CHIP, LDLESS

2000V, CERAMIC DI

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

POLYESTER

CERAMIC DISC

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

CM151 4-15 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-12

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6006 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOPQRSTUVWXYZa C6007M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6009 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6010M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6011M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6012M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6013 022-08309-13A CAP, 220 MFD 20% 16V,

ABCDEJKLMNOa C6014M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC

FGHIPQRSTUVWXYZ C6014M 022-08352-32A CAP, 68 PFD 5% 50V, CERAMIC

ABCDEJKLMNOa C6015M 022-08352-22A CAP, 27 PFD 5% 50V, CERAMIC

FGHIPQRSTUVWXYZ C6015M 022-08352-32A CAP, 68 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6016 022-08312-05A CAP, 2.2 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6017 022-08049-24A CAP, 0.10 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6018M 022-08366-12A CAP, 2,200 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6019M 022-08366-04A CAP, 470 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6020 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6021M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGIJKLMNOPQRSXYZa C6023M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

HTUVW C6023M 022-08354-41A CAP, 160 PFD 5% 50V, CERAMIC

CEGKNORSVWY C6026M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6028 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6029M 022-08368-20A CAP, 10,000 PFD 10% 25V,

CEGKNORSVWY C6030 022-08309-12A CAP, 100 MFD 20% 16V,

ABDFHIJLMPQTUXZa C6030 022-08309-16 CAP, 1000 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6031M 022-08366-12A CAP, 2,200 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6032 022-08312-04A CAP, 1 MFD 20% 50V, ELECTRO FGGILMNOPQRSTUVWXYZ C6036M 022-08366-08A CAP, 1,000 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6037 022-08257-04A CAP, 220 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6038M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6040M 022-08352-38A CAP, 120 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6041M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6042M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6043M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6045M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6046M 022-08366-04A CAP, 470 PFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6047M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

CERAMIC CHIP, LDLESS

POLYESTER

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

CHIP, LDLESS

ELECTRO

POLYESTER

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

CHIP, LDLESS

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

ELECTRO

CERAMIC CHIP, LDLESS

CERAMIC DISC

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CHIP, LDLESS

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6048M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6049M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6050M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6051M 022-08354-41A CAP, 160 PFD 5% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6052M 022-08354-41A CAP, 160 PFD 5% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6053M 022-08354-41A CAP, 160 PFD 5% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6055M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6056M 022-08368-20A CAP, 10,000 PFD 10% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6058M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6061M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

XY C6064M 022-08366A CAP, 220 PFD 10% 50V,

XY C6065M 022-08352-19A CAP, 20 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6068M 022-08366-12A CAP, 2,200 PFD 10% 50V,

CEGKNORSVWY C6069M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

CEGKNORSVWY C6070M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6079M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6090M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6092M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6093M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6094M 022-08352-31A CAP, 62 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6095M 022-08352-28A CAP, 47 PFD 5% 50V, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa C6098 022-08312-07A CAP, 4.7 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CR2201 224-00027A CRYSTAL, QUARTZ, 3.579 MHZ ABCDEFGHIJKLMNOPQRSTUVWXYZa CR2202 224-00178 RESONATOR, CERAMIC, 503

HTUVWXY CR2501 224-00061-04 CRYSTAL, QUARTZ, 14.31818

ABCDEFGHIJKLMNOPQRSTUVWXYZa CRT0001 078-03394-09 SOCKET, CRT ABCDEFGHIJKLMNOPQRSTUVWXYZa CRY6001 224-00074-02A CRYSTAL, QUARTZ, 8 MHZ ABCDEFGHIJKLMNOPQRSTUVWXYZa CX2105 022-08311-13 CAP, 220 MFD 20% 35V,

XY CX2107 022-08310-16 CAP, 1000 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWZa CX2107 022-08310-17 CAP, 2200 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX2110 022-08311-12A CAP, 100 MFD 20% 35V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3003 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3004 022-08312-08A CAP, 10 MFD 20% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3007 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3205 022-08309-12A CAP, 100 MFD 20% 16V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3207A 022-08159 CAP, 0.68 MFD 10% 200V,

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CHIP, LDLESS

CERAMIC CHIP, LDLESS

CHIP, LDLESS

ELECTRO

KHZ

MHZ

ELECTRO

CERAMIC DISC

ELECTRO

POLYESTER

CM151 4-16 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3208 022-08317-08 CAP, 10 MFD 20% 250V,

MOQSUWa CX3210 022-08386-01 CAP, 270 PFD 10% 2000V,

XY CX3211 022-08386-08 CAP, 1000 PFD 10% 2000V,

JKLMNOPQRSTUVWZa CX3212 022-08386-05 CAP, 560 PFD 10% 2000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3215 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3216 022-08229-27 CAP, 0.013 MFD 3% 1600VDC,

XY CX3217 022-08231-11 CAP, 0.39 MFD 5% 200V,

JKLNPRTVZ CX3217 022-08231-12 CAP, 0.47 MFD 5% 200V,

ABCDEFGHI CX3217 022-08231-13 CAP, 0.56 MFD 5% 200V,

MOQSUWa CX3217 091-02053 WIRE, SOLID, BARE, 22 GA

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3218 022-08315-05A CAP, 2.2 MFD 20% 160V,

JKLMNOPQRSTUVWZa CX3219 022-08227-04A CAP, 0.022 MFD 5% 50V,

MOQSUWa CX3251 091-02053 WIRE, SOLID, BARE, 22 GA

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3253 022-08312-11A CAP, 47 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3254 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3400 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3401 022-07867-10 CAP, 0.1 MFD 20% 250VAC,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3402 022-07431-06B CAP, 0.0047 MFD 20%, CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3403 022-07811A CAP, 1000 PFD 10% 1000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3404 022-07811A CAP, 1000 PFD 10% 1000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3405 022-07811A CAP, 1000 PFD 10% 1000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3406 022-07811A CAP, 1000 PFD 10% 1000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3407 022-08444-09 CAP, 330 MFD 20% 200V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3408 022-07786-10C CAP, 470 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3409 022-08386-08 CAP, 1000 PFD 10% 2000V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3410 022-07786C CAP, 1000 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3411 022-08049-18A CAP, 0.033 MFD 10% 50V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3412 022-07786C CAP, 1000 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3413 022-08312-09A CAP, 22 MFD 20% 50V, ELECTRO ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3415 022-08008-12 CAP, .01 MFD 5% 1250V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3416 022-08310-12A CAP, 100 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3418 022-07786-01C CAP, 220 PFD 10% 500V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3420 022-08444-07 CAP, 220 MFD 20% 200V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3424 022-08310-16 CAP, 1000 MFD 20% 25V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa CX3430 022-08310-15 CAP, 470 MFD 20% 25V,

CEGKNORSVWY CX6027 022-08309-15A CAP, 470 MFD 20% 16V,

ELECTRO

CERAMIC DISC

POLYPROPYLENE

COPPER

ELECTRO

POLYESTER

COPPER

CERAMIC DISC

DISC

POLYESTER

DISC

CERAMIC DISC

ELECTRO

CERAMIC DISC

POLYESTER

CERAMIC DISC

POLYPROPYLENE

ELECTRO

CERAMIC DISC

ELECTRO

RC REF PART# DESCRIPTION

BCDEHJKLMNOTUVWa D1401 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa D2201 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa D2202 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa D2203 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa D2204 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa D2205 103-00461A DIODE, ULTRA FAST

XY D2207 103-00461A DIODE, ULTRA FAST

XY D2208 103-00461A DIODE, ULTRA FAST

XY D2209 103-00461A DIODE, ULTRA FAST

HTUVWXY D2210 103-00461A DIODE, ULTRA FAST

HTUVWXY D2211 103-00461A DIODE, ULTRA FAST

HTUVWXY D2212 103-00461A DIODE, ULTRA FAST

HTUVWXY D2501 103-00461A DIODE, ULTRA FAST

HTUVWXY D2502 103-00347-03A DIODE, LOW VOLTAGE

ABCDEFGHIJKLMNOPQRSTUVWXYZa D3410 103-00589 DIODE, FAST RECOVERY

ABCDEFGHIJKLMNOPQRSTUVWXYZa D3411 103-00589 DIODE, FAST RECOVERY

ABCDEFGHIJKLMNOPQRSTUVWXYZa D5101 103-00279-04A DIODE, ZENER, 3V 0.5W ABCDEFGHIJKLMNOPQRSTUVWXYZa D5102 103-00344-06A DIODE, LOW VOLTAGE

ABCDEFGHIJKLMNOPQRSTUVWXYZa D6001 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa D6002 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa DAG0000 A-19197 GROUNDING ASSY , WIRE AND

ABCDEFGHIJKLMNOPQRSTUVWXYZa DAG0001 A-19197 GROUNDING ASSY , WIRE AND

FGIPQRSXYV DL2200 223-00045 INTD CKT PKG, NTSC COMB

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2101 103-00347-03A DIODE, LOW VOLTAGE

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2102 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2103 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX2104 103-00339-04A DIODE, LOW VOLTAGE

SWITCHING, HIGH CONDUCTANCE

GENERAL, SILICON

RECTIFIER, 400 PIV

GENERAL

SWITCHING, HIGH CONDUCTANCE

TERMINAL, WHITE, DAG

FILTER, HYBRID

GENERAL, SILICON

SWITCHING, HIGH CONDUCTANCE

GENERAL, SILICON

CM151 4-17 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-12

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3005 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3006 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3201 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3203 103-00347-03A DIODE, LOW VOLTAGE GENERAL,

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3204 103-00461A DIODE, ULTRA FAST

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3252 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3401 103-00588A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3402 103-00588A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3403 103-00588A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3404 103-00588A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3405 103-00347-03A DIODE, LOW VOLTAGE GENERAL,

ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3406 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3407 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa DX3408 103-00344-06A DIODE, LOW VOLTAGE GENERAL ABCDEFGHIJKLMNOPQRSTUVWXYZa EX3401 038-00102 SPARK GAP, HIGH VOLTAGE, 4KV

IZ FX3401 136-00114-23A FUSE, NORMAL LAG, 4 AMP

ABCDEFGHJKLMNOPQRSTUVWXYa FX3401 136-00114-23C FUSE, NORMAL LAG, 4 AMP

IZ FX3402 136-00148-23 FUSE, NORMAL LAG, 3 AMP

ABCDEFGHJKLMNOPQRSTUVWXYa FX3402 136-00148-23C FUSE, NORMAL LAG, 3 AMP

ABCDEFGHIJKLMNOPQRSTUVWXYZa IC0804 126-03700 HEAT SINK, IC, AUDIO

ABCDEFGHIJKLMNOPQRSTUVWXYZa IC0804 221-00598-01 INTEGRATED CKT, AUDIO

FGIPQRSXYZ IC1400 221-01127 INTEGRATED CKT , MTS STEREO

BCDEHJKLMNOTUVWa IC1400 221-01382 INTEGRATED CKT , AUDIO

DEHLMNOTUVW IC1401 221-01171 INTEGRATED CKT , AUDIO/

BCDEHJKLMNOTUVWa IC1402 221-01380 INTEGRATED CKT , STEREO AMP.

Z IC2100 126-03626 HEAT SINK, TRANSISTOR,

ABCDEFGHIJKLMNOPQRSTUVWXYa IC2100 126-03626-04 HEAT SINK, TRANSISTOR,

ABCDEFGHIJKLMNOPQRSTUVWXYZa IC2100 221-00992-01 INTEGRATED CKT, VERTICAL

HTUVWXY IC2501 221-01393 INTEGRATED CKT, Y/C PIP

HTUVWXY IC2502 221-01183 INTEGRATED CKT, ANALOG

FGHIPQRSTUVWXYZ IC2901 221-01171 INTEGRATED CKT , AUDIO/

HTUVWXY IC2902 221-01171 INTEGRATED CKT , AUDIO/

ABCDEFGHIJKLMNOPQRSTUVWXYZa IC6000 126-03446-02 SHIELD, EMI,

BCDEJKLMNOa IC6000 221-01384-01 INTEGRATED CKT , 8-BIT

AFGIPQRSZ IC6000 221-01384-02 INTEGRATED CKT , 8-BIT

HTUVW IC6000 221-01386-01 INTEGRATED CKT , 8-BIT

XY IC6000 221-01387-01 INTEGRATED CKT , 8-BIT

SWITCHING, HIGH CONDUCTANCE

SILICON

SWITCHING, HIGH CONDUCTANCE

SILICON

DC

250V

AMPIFIER

POWER AMP

DECODER/VOL.LIMITER AND

MULTIPLEXING DECODER, USA

VIDEO SWITCH, 2 CHAN/2 POSIT

AND DC VOL/CONTROL

HORIZONTAL OUTPUT

DEFLECTION

CONTROLLER

MULTIPLEX/DEMULTIPLEX, TRIP

VIDEO SWITCH, 2 CHAN/2 POSIT

MICROPROCESSOR

MICROCOMPUTER

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa IC6001 221-00745-04 INTEGRATED CKT , 4K BIT

ABCDEFGHIJKLMNOPQRSTUVWXYZa IC6002 221-01177A INTEGRATED CKT , SYSTEM

ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX2200 221-01165 INTEGRATED CKT , I2C BUS

ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3400 126-03660-01 HEATSINK, TRANSISTOR ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3400 223-00028 INTD CKT PKG, HYBRID,

ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3401 126-03326-02 HEATSINK, TRANSISTOR ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3401 221-00213-09 INTEGRATED CKT, 9 VOLT, 1

ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3402 126-02131-01 HEAT SINK, TRANSISTOR ABCDEFGHIJKLMNOPQRSTUVWXYZa ICX3402 221-00213 INTEGRATED CKT, 5 VOLT, 1

ABCDEJKa IR6000 012-10795 BRACKET, IR DETECTOR

ABCDEJKa IR6000 162-00046 IR DETECTOR FGIPQRSXYZ J0001 A-18785-02 JACK ASSEMBLY, 5 PHONO/1

DEHLMNOTUVW J0001 A-18785-03 JACK ASSEMBLY, AV, 3 PHONO ABCDEFGHIJKLMNOPQRSTUVWXYZa J0003M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa J0006M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa J0007M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa J0008M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa J0009M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZ J0010M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa J0012M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa J0015M 063-11059A RESISTOR, THICK FILM CHIP,

BCJKa J1406M 063-11059A RESISTOR, THICK FILM CHIP,

BCJKa J1407M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGIJKLMNOPQRSZa J2201M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGIJKLMNOPQRSZa J2202M 063-11059A RESISTOR, THICK FILM CHIP,

HTUVWXY J2501M 063-11059A RESISTOR, THICK FILM CHIP,

HTUVWXY J2502M 063-11059A RESISTOR, THICK FILM CHIP,

HTUVWXY J2504M 063-11059A RESISTOR, THICK FILM CHIP,

HTUVWXY J2510M 063-11059A RESISTOR, THICK FILM CHIP,

HTUVWXY J2512M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEHJKLMNOTUVWa J2902M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa KX3401 195-00161 RELAY, SPST, 12 VDC COIL ABCDEFGHIJKLMNOPQRSTUVWXYZ L1200 020-03907-25A COIL, 120 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L1201 020-04277-09A COIL, 0.82 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L1202 020-04278B COIL, RCF, TUNABLE, 7.0 MM ABCDEFGHIJKLMNOPQRSTUVWXYZa L1203 020-03907-12A COIL, 10 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L1204 020-04277-39A COIL, 10 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L1205 020-04277-23A COIL, 12 MICROHENRY, RCF,

SERIAL EEPROM

RESET

CONTROL NTSC

VOLTAGE REGULATOR

AMP, LINEAR, REGULATOR

MOUNTING

Y-C

0 OHM 5% 1/10W

FIXED

CM151 4-18 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa L1206 020-04506A COIL, RCF, FIXED, SHIELDED ABCDEFGHIJKLMNOPQRSTUVWXYZa L1207 020-04277-23A COIL, 12 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L2201 020-04129-22 COIL, 15 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L2202 020-04129-16 COIL, 4.7 MICROHENRY, RCF,

HTUVWXY L2501 091-02053 WIRE, SOLID, BARE, 22 GA

HTUVWXY L2502 020-03907-12A COIL, 10 MICROHENRY, RCF,

HTUVWXY L2503 020-03907-12A COIL, 10 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L3405 020-04462-18A COIL, 33 MICROHENRY, RCF,

HTUVWXY L3407 020-03907-21A COIL, 56 MICROHENRY, RCF,

ABCDEFGIJKLMNOPQRSZa L3407 020-03907-24A COIL, 100 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L5101 020-03907-28A COIL, 220 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L5102 063-10246-46 RESISTOR, FILM, 1.2M OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa L5103 149-00583-01 CORE, FERRITE BEAD CEGKNORSVWY L6000 020-03907-24A COIL, 100 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L6001 020-04129-16 COIL, 4.7 MICROHENRY, RCF,

FGHIPQRSTUVWXYZ L6002 020-04277-10A COIL, 1.0 MICROHENRY, RCF,

ABCDEJKLMNOa L6002 020-04277-20A COIL, 6.8 MICROHENRY, RCF,

ABCDEFGHIJKLMNOPQRSTUVWXYZa L6003 020-04129-08 COIL, 1 MICROHENRY, RCF,

FGHILMNOPQRSTUVWXYZ L6004 020-04129-08 COIL, 1 MICROHENRY, RCF,

FGHILMNOPQRSTUVWXYZ L6005 020-04129-08 COIL, 1 MICROHENRY, RCF,

ABCDEJK L6005 091-02053 WIRE, SOLID, BARE, 22 GA

ABCDEFGHIJKLMNOPQRSTUVWXYZa L6007 020-04129-16 COIL, 4.7 MICROHENRY, RCF,

MOQSUWa LX3201 022-08231-10 CAP, 0.33 MFD 5% 200V,

ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3202 149-00540-01 CORE, FERRITE ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3262 020-04073-03 COIL, RCF ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3401 095-04593 TRANSFORMER, LINE CHOKE ABCDEFGHIJKLMNOPQRSTUVWXYZaLX3403 149-00540-01 CORE, FERRITE ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3404 149-00540-01 CORE, FERRITE ABCDEFGHIJKLMNOPQRSTUVWXYZa LX3410 149-00549 CORE, FERRITE, WITH

HTUVWXY PIP 009-02107 MODULE, SINGLE PIP, CA

HTUVWXY PIPA 058-00605-10 PLUG, MULTIPRONG, 10

HTUVWXY PIPB 058-00605-10 PLUG, MULTIPRONG, 10

ABCDEFGHIJKLMNOPQRSTUVWXYZa Q0800 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q1200 121-01261A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q1201 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q1202 121-01310A TRANSISTOR, NPN, SILICON FGIPQRSXYZ Q1401 121-01310A TRANSISTOR, NPN, SILICON FGIPQRSXYZ Q1402 121-01310A TRANSISTOR, NPN, SILICON FGIPQRSXYZ Q1403 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2201 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2202 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2203 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2204 121-01310A TRANSISTOR, NPN, SILICON

FIXED

COPPER

FIXED

10% 1/2W

FIXED

COPPER

FIXED

POLYPROPYLENE

CAPTIVATED THRU-LEAD

CHASSIS

POSITION

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2205 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2206 121-01311A TRANSISTOR, PNP, SILICON XY Q2207 121-01390 TRANSISTOR, NPN, SILICON ABCDEHJKLMNOTUVWa Q2208 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q2209 121-01311A TRANSISTOR, PNP, SILICON HTUVWXY Q2210 121-01391A TRANSISTOR, PNP, SILICON HTUVWXY Q2501 121-01310A TRANSISTOR, NPN, SILICON HTUVWXY Q2502 121-01310A TRANSISTOR, NPN, SILICON HTUVWXY Q2503 121-01310A TRANSISTOR, NPN, SILICON HTUVWXY Q2504 121-01310A TRANSISTOR, NPN, SILICON HTUVWXY Q2505 121-01311A TRANSISTOR, PNP, SILICON XY Q2902 121-01311A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3201 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3202 121-01264-01A TRANSISTOR, NPN SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3402 121-01340A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3403 121-01340A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q3404 121-01102A TRANSISTOR, PNP, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5101 121-01291-01 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5102 121-01291-01 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5103 121-01291-01 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q5104 121-01140A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q6001 121-01310A TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa Q6002 121-01310A TRANSISTOR, NPN, SILICON XY Q6003 121-01390 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa QX3203 121-01383 TRANSISTOR, NPN, SILICON ABCDEFGHIJKLMNOPQRSTUVWXYZa QX3203 126-03626-01 HEAT SINK, TRANSISTOR,

ABCDEFGHIJKLMNOPQRSTUVWXYZa QX3401 121-01348 TRANSISTOR, NPN, SILICON,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R0843 063-10235-60 RESISTOR, FILM, 330 OHM 5%

FGIPQRSXYZ R0851M 063-11059-73A RESISTOR, THICK FILM CHIP,

BCDEHJKLMNOTUVWa R0851M 063-11059-89A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R0852M 063-11059-57A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R0853 063-10235-12 RESISTOR, FILM, 3.3 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R0854M 063-11059-29A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R0861M 063-11059-73A RESISTOR, THICK FILM CHIP,

A R0861M 063-11059-76A RESISTOR, THICK FILM CHIP,

BCDEHJKLMNOTUVWa R0861M 063-11059-89A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R0862M 063-11059-57A RESISTOR, THICK FILM CHIP,

A R0862M 063-11059-59A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R0863 063-10235-12 RESISTOR, FILM, 3.3 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R0864M 063-11059-29A RESISTOR, THICK FILM CHIP,

CEGKNORSVWY R1200M 063-11059-97A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1201M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1202M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1203M 063-11059-39A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1204M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1205M 063-11059-25A RESISTOR, THICK FILM CHIP,

HORIZONTAL OUTPUT

80V/1A

1/4W

10K OHM 5% 1/10W

47K OHM 5% 1/10W

2.2K OHM 5% 1/10W

1/4W

150 OHM 5% 1/10W

10K OHM 5% 1/10W

13K OHM 5% 1/10W

47K OHM 5% 1/10W

2.2K OHM 5% 1/10W

2.7K OHM 5% 1/10W

1/4W

150 OHM 5% 1/10W

100K OHM 5% 1/10W

10K OHM 5% 1/10W

100 OHM 5% 1/10W

390 OHM 5% 1/10W

1.5K OHM 5% 1/10W

100 OHM 5% 1/10W

CM151 4-19 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-12

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1206M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1207M 063-11059-09A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1208M 063-11059-09A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1209M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1210M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1211M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1212M 063-11059-61A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1213M 063-11059-46A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1214M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1215M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1216M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1217M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1218M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1219M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1220M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1221M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1222M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1223M 063-11059-97A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R1224M 063-11059-87A RESISTOR, THICK FILM CHIP,

ABDFHIJLMPQTUXZa R1225 063-10235-98 RESISTOR, FILM, 12K OHM 5%

BCDEFGHIJKLMNOPQRSTUVWXYZa R1401 063-10235-48 RESISTOR, FILM, 100 OHM 5%

BCDEFGHIJKLMNOPQRSTUVWXYZa R1402 063-10235-48 RESISTOR, FILM, 100 OHM 5%

BCDEFGHIJKLMNOPQRSTUVWXYZa R1404M 063-11244-76A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1405M 063-11059-61A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1406M 063-11059-97A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1407M 063-11059-60A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1408M 063-11059-61A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1409M 063-11060-21A RESISTOR, THICK FILM CHIP, 1

DEHLMNOTUVW R1412 063-10235-74 RESISTOR, FILM, 1.2K OHM 5%

FGIPQRSXYZ R1412 063-10235-80 RESISTOR, FILM, 2.2K OHM 5%

DEHLMNOTUVW R1413 063-10235-74 RESISTOR, FILM, 1.2K OHM 5%

FGIPQRSXYZ R1413 063-10235-80 RESISTOR, FILM, 2.2K OHM 5%

DEHLMNOTUVW R1416 063-10235-94 RESISTOR, FILM, 8.2K OHM 5%

BCDEHJKLMNOTUVWa R1417 063-10243-56 RESISTOR, FILM, 220 OHM 5%

BCDEHJKLMNOTUVWa R1418M 063-11059-57A RESISTOR, THICK FILM CHIP,

100 OHM 5% 1/10W

22 OHM 5% 1/10W

100 OHM 5% 1/10W

10K OHM 5% 1/10W

3.3K OHM 5% 1/10W

750 OHM 5% 1/10W

1K OHM 5% 1/10W

4.7K OHM 5% 1/10W

10K OHM 5% 1/10W

1K OHM 5% 1/10W

220 OHM 5% 1/10W

150 OHM 5% 1/10W

220 OHM 5% 1/10W

1K OHM 5% 1/10W

100K OHM 5% 1/10W

39K OHM 5% 1/10W

1/4W

61.9K OHM 1% 1/10W

3.3K OHM 5% 1/10W

100K OHM 5% 1/10W

3K OHM 5% 1/10W

3.3K OHM 5% 1/10W

MEG OHM 5% 1/10W

1/4W

1/2W

2.2K OHM 5% 1/10W

RC REF PART# DESCRIPTION

BCDEHJKLMNOTUVWa R1420M 063-11059-73A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1421M 063-11059-71A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1422M 063-11059-73A RESISTOR, THICK FILM CHIP,

BCDEFGHIJKLMNOPQRSTUVWXYZa R1425M 063-11060-21A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1440M 063-11059-73A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1441M 063-11059-97A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1442M 063-11059-49A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1443M 063-11059-41A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1444M 063-11059-25A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1445M 063-11059-37A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1446 063-10235-68 RESISTOR, FILM, 680 OHM

FGIPQRSXYZ R1447M 063-11059-49A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1448M 063-11059-41A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1449M 063-11059-25A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1450M 063-11059-37A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R1451 063-10235-68 RESISTOR, FILM, 680 OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2101 063-10235-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2102M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2103 063-10235-96 RESISTOR, FILM, 10K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2104 063-10236-26 RESISTOR, FILM, 180K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2105 063-10236-24 RESISTOR, FILM, 150K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2106 063-10236-41 RESISTOR, FILM, 750K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2107M 063-11059-89A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2108 063-10236-10 RESISTOR, FILM, 39K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2109M 063-11059-77A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2110M 063-11059-77A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2111M 063-11059-89A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2112M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHI R2113 063-10235-84 RESISTOR, FILM, 3.3K OHM

JKLMNOPQRSTUVWXYZa R2113 063-10235-86 RESISTOR, FILM, 3.9K OHM

ABCDEFGHIJKLMNOPQRSTUVWZa R2114 063-10235-90 RESISTOR, FILM, 5.6K OHM

XY R2114 063-10235-92 RESISTOR, FILM, 6.8K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2118 063-10565-61 RESISTOR, FILM, 360 OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2119 063-10565-61 RESISTOR, FILM, 360 OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2120M 063-11059-39A RESISTOR, THICK FILM CHIP,

10K OHM 5% 1/10W

8.2K OHM 5% 1/10W

10K OHM 5% 1/10W

1 MEG OHM 5% 1/10W

10K OHM 5% 1/10W

100K OHM 5% 1/10W

1K OHM 5% 1/10W

470 OHM 5% 1/10W

100 OHM 5% 1/10W

330 OHM 5% 1/10W

5% 1/4W

1K OHM 5% 1/10W

470 OHM 5% 1/10W

100 OHM 5% 1/10W

330 OHM 5% 1/10W

5% 1/4W

1/4W

10K OHM 5% 1/10W

5% 1/4W

47K OHM 5% 1/10W

5% 1/4W

15K OHM 5% 1/10W

47K OHM 5% 1/10W

1K OHM 5% 1/10W

5% 1/4 W

5% 1/4W

5% 1/2W

390 OHM 5% 1/10W

CM151 4-20 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2121 063-10235-94 RESISTOR, FILM, 8.2K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2122 063-10235-88 RESISTOR, FILM, 4.7K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2123M 063-11059-33A RESISTOR, THICK FILM CHIP,

XY R2201M 063-11059-27A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWZa R2201M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGIJKLMNOPQRSZ R2202M 063-11059-47A RESISTOR, THICK FILM CHIP,

a R2202M 063-11059A RESISTOR/ THICK FILM CHIP/

ABCDEFGHIJKLMNOPQRSTUVWZa R2203M 063-11059-60A RESISTOR, THICK FILM CHIP,

XY R2203M 063-11059-61A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2204M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2205M 063-11059-60A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2206M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWZa R2207M 063-11059-60A RESISTOR, THICK FILM CHIP,

XY R2207M 063-11059-61A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2208M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2209M 063-11059-47A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2210 063-10235-66 RESISTOR, FILM, 560 OHM 5%

JKLMNOPQRSTUVWZa R2211M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIXY R2211M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2212M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2213M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2214M 063-11059-83A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2215M 063-11059-47A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2216 063-10235-24 RESISTOR, FILM, 10 OHM 5%

JKLMNOPQRSTUVWZa R2217M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIXY R2217M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2218M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2219M 063-11059-47A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2220 063-10235-48 RESISTOR, FILM, 100 OHM 5%

JKLMNOPQRSTUVWZa R2221M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIXY R2221M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2222M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2223 063-10235-48 RESISTOR, FILM, 100 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2224M 063-11059-77A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2225M 063-11059-61A RESISTOR, THICK FILM CHIP,

1/4W

220 OHM 5% 1/10W

120 OHM 5% 1/10W

0 OHM 5% 1/10W

820 OHM 5% 1/10W

0 OHM 5% 1/10W

3K OHM 5% 1/10W

3.3K OHM 5% 1/10W

1K OHM 5% 1/10W

3K OHM 5% 1/10W

1K OHM 5% 1/10W

3K OHM 5% 1/10W

3.3K OHM 5% 1/10W

1K OHM 5% 1/10W

820 OHM 5% 1/10W

1/4W

1K OHM 5% 1/10W

1.5K OHM 5% 1/10W

100 OHM 5% 1/10W

220 OHM 5% 1/10W

27K OHM 5% 1/10W

820 OHM 5% 1/10W

1/4W

1K OHM 5% 1/10W

1.5K OHM 5% 1/10W

220 OHM 5% 1/10W

820 OHM 5% 1/10W

1/4W

1K OHM 5% 1/10W

1.5K OHM 5% 1/10W

220 OHM 5% 1/10W

1/4W

15K OHM 5% 1/10W

3.3K OHM 5% 1/10W

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2226 063-10235-88 RESISTOR, FILM, 4.7K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2227M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2228 063-10235-64 RESISTOR, FILM, 470 OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2229M 063-11059-57A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2230M 063-11059-97A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2231M 063-11059-39A RESISTOR, THICK FILM CHIP,

ABCDEFGHI R2232M 063-11059-49A RESISTOR, THICK FILM CHIP,

JKLMNOPQRSTUVWXYZa R2232M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2233 063-10235-48 RESISTOR, FILM, 100 OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2234M 063-11059-73A RESISTOR, THICK FILM CHIP,

JKLMNOPQRSTUVWXYZa R2235 063-10243-74 RESISTOR, FILM, 1.2K OHM

ABCDEFGHI R2235 063-10243-79 RESISTOR, FILM, 2K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2236M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2237M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2238M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2239M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2240M 063-11059-46A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2241M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2242M 063-11060-13A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2243M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2244M 063-11059-97A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2245M 063-11059-17A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R2246M 063-11059-83A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2247M 063-11059-25A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R2248M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2249M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2250M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2251 063-10235-48 RESISTOR, FILM, 100 OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2252M 063-11059-87A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2254M 063-11059-25A RESISTOR, THICK FILM CHIP,

XY R2255 063-10235-60 RESISTOR, FILM, 330 OHM

XY R2256M 063-11059-33A RESISTOR, THICK FILM CHIP,

XY R2257M 063-11059-33A RESISTOR, THICK FILM CHIP,

XY R2258M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2259M 063-11059-39A RESISTOR, THICK FILM CHIP,

5% 1/4W

1K OHM 5% 1/10W

5% 1/4W

2.2K OHM 5% 1/10W

100K OHM 5% 1/10W

390 OHM 5% 1/10W

1K OHM 5% 1/10W

1.5K OHM 5% 1/10W

5% 1/4W

10K OHM 5% 1/10W

5% 1/2W

1/2W

10K OHM 5% 1/10W

1K OHM 5% 1/10W

1.5K OHM 5% 1/10W

1K OHM 5% 1/10W

750 OHM 5% 1/10W

10K OHM 5% 1/10W

470K OHM 5% 1/10W

1K OHM 5% 1/10W

100K OHM 5% 1/10W

47 OHM 5% 1/10W

27K OHM 5% 1/10W

100 OHM 5% 1/10W

10K OHM 5% 1/10W

150 OHM 5% 1/10W

5% 1/4W

39K OHM 5% 1/10W

100 OHM 5% 1/10W

5% 1/4W

220 OHM 5% 1/10W

390 OHM 5% 1/10W

CM151 4-21 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-12

RC REF PART# DESCRIPTION

ABCDEHJKLMNOTUVWa R2260M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEHJKLMNOTUVWa R2261M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEHJKLMNOTUVWa R2262M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2263 063-10236-32 RESISTOR, FILM, 330K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2264 063-10236-44 RESISTOR, FILM, 1M OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R2265M 063-11059-73A RESISTOR, THICK FILM CHIP,

R2265M 063-11059-73A RESISTOR/ THICK FILM CHIP/

HTUVWXY R2266 063-10235-64 RESISTOR, FILM, 470 OHM 5%

HTUVWXY R2267M 063-11059-83A RESISTOR, THICK FILM CHIP,

HTUVWXY R2268M 063-11059-97A RESISTOR, THICK FILM CHIP,

ABCDEJKLMNOa R2269M 063-11059-09A RESISTOR, THICK FILM CHIP,

FGHIPQRSTUVWZ R2269M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2501M 063-11059-49A RESISTOR, THICK FILM CHIP,

HTUVWXY R2502M 063-11059-65A RESISTOR, THICK FILM CHIP,

HTUVWXY R2504M 063-11059-49A RESISTOR, THICK FILM CHIP,

HTUVWXY R2505M 063-11059-35A RESISTOR, THICK FILM CHIP,

HTUVWXY R2507M 063-11059-25A RESISTOR, THICK FILM CHIP,

HTUVWXY R2508M 063-11059-77A RESISTOR, THICK FILM CHIP,

HTUVWXY R2509M 063-11060-61A RESISTOR, THICK FILM CHIP,

HTUVWXY R2510M 063-11059-37A RESISTOR, THICK FILM CHIP,

HTUVWXY R2511M 063-11059-65A RESISTOR, THICK FILM CHIP,

HTUVWXY R2512M 063-11059-37A RESISTOR, THICK FILM CHIP,

HTUVWXY R2513M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2516M 063-11059-41A RESISTOR, THICK FILM CHIP,

HTUVWXY R2517M 063-11059-41A RESISTOR, THICK FILM CHIP,

HTUVWXY R2518M 063-11059-41A RESISTOR, THICK FILM CHIP,

HTUVWXY R2519M 063-11059-65A RESISTOR, THICK FILM CHIP,

HTUVWXY R2520 063-10235-72 RESISTOR, FILM, 1K OHM 5%

HTUVWXY R2521M 063-11059-37A RESISTOR, THICK FILM CHIP,

HTUVWXY R2523M 063-11059-57A RESISTOR, THICK FILM CHIP,

HTUVWXY R2524M 063-11059-49A RESISTOR, THICK FILM CHIP,

HTUVWXY R2525M 063-11059-33A RESISTOR, THICK FILM CHIP,

HTUVWXY R2529 063-10235-64 RESISTOR, FILM, 470 OHM 5%

HTUVWXY R2530M 063-11059-84A RESISTOR, THICK FILM CHIP,

HTUVWXY R2531M 063-11060-04A RESISTOR, THICK FILM CHIP,

100 OHM 5% 1/10W

150 OHM 5% 1/10W

5% 1/4W

1/4W

10K OHM 5% 1/10W

1/4W

27K OHM 5% 1/10W

100K OHM 5% 1/10W

22 OHM 5% 1/10W

10K OHM 5% 1/10W

1K OHM 5% 1/10W

4.7K OHM 5% 1/10W

1K OHM 5% 1/10W

270 OHM 5% 1/10W

100 OHM 5% 1/10W

15K OHM 5% 1/10W

4.7M OHM 5% 1/10W

330 OHM 5% 1/10W

4.7K OHM 5% 1/10W

330 OHM 5% 1/10W

10K OHM 5% 1/10W

470 OHM 5% 1/10W

4.7K OHM 5% 1/10W

1/4W

330 OHM 5% 1/10W

2.2K OHM 5% 1/10W

1K OHM 5% 1/10W

220 OHM 5% 1/10W

1/4W

30K OHM 5% 1/10W

200K OHM 5% 1/10W

RC REF PART# DESCRIPTION

HTUVWXY R2532M 063-11059-51A RESISTOR, THICK FILM CHIP,

HTUVWXY R2533M 063-11059-59A RESISTOR, THICK FILM CHIP,

HTUVWXY R2534 063-10235-48 RESISTOR, FILM, 100 OHM

HTUVWXY R2535 063-10235-48 RESISTOR, FILM, 100 OHM

HTUVWXY R2539M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2540M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2541M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2542M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2543M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2544M 063-11059-73A RESISTOR, THICK FILM CHIP,

HTUVWXY R2545 063-10235-96 RESISTOR, FILM, 10K OHM

HTUVWXY R2546M 063-11059-75A RESISTOR, THICK FILM CHIP,

HTUVWXY R2547M 063-11059A RESISTOR, THICK FILM CHIP,

HTUVWXY R2549 063-10565-12 RESISTOR, FILM, 3.3 OHM 5%

FGHIPQRSTUVWXYZ R2901M 063-11059-71A RESISTOR, THICK FILM CHIP,

FGHIPQRSTUVWXYZ R2902M 063-11059-57A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R2907 063-10235-72 RESISTOR, FILM, 1K OHM 5%

FGIPQRSXYZ R2908 063-10235-40 RESISTOR, FILM, 47 OHM 5%

FGIPQRSXYZ R2909 063-10235-83 RESISTOR, FILM, 3K OHM 5%

FGIPQRSXYZ R2910M 063-11059-73A RESISTOR, THICK FILM CHIP,

FGIPQRSXYZ R2911 063-10235-45 RESISTOR, FILM, 75 OHM 5%

FGIPQRSXYZ R2912 063-10235-45 RESISTOR, FILM, 75 OHM 5%

DEFGHILMNOPQRSTUVWXYZ R2914 063-10235-40 RESISTOR, FILM, 47 OHM 5%

HTUVWXY R2915M 063-11059-71A RESISTOR, THICK FILM CHIP,

DEFGHILMNOPQRSTUVWXYZ R2916 063-10235-45 RESISTOR, FILM, 75 OHM 5%

HTUVW R2917M 063-11059-60A RESISTOR, THICK FILM CHIP,

XY R2917M 063-11059-61A RESISTOR, THICK FILM CHIP,

XY R2918M 063-11059-60A RESISTOR, THICK FILM CHIP,

XY R2919M 063-11059-41A RESISTOR, THICK FILM CHIP,

XY R2920M 063-11059-49A RESISTOR, THICK FILM CHIP,

XY R2921M 063-11059-49A RESISTOR, THICK FILM CHIP,

XY R2922M 063-11059-73A RESISTOR, THICK FILM CHIP,

XY R2923M 063-11059-51A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3201M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3202M 063-11059-29A RESISTOR, THICK FILM CHIP,

1.2K OHM 5% 1/10W

2.7K OHM 5% 1/10W

5% 1/4W

10K OHM 5% 1/10W

5% 1/4W

12K OHM 5% 1/10W

0 OHM 5% 1/10W

1/2W

8.2K OHM 5% 1/10W

2.2K OHM 5% 1/10W

1/4W

10K OHM 5% 1/10W

1/4W

8.2K OHM 5% 1/10W

1/4W

3K OHM 5% 1/10W

3.3K OHM 5% 1/10W

3K OHM 5% 1/10W

470 OHM 5% 1/10W

1K OHM 5% 1/10W

10K OHM 5% 1/10W

1.2K OHM 5% 1/10W

4.7K OHM 5% 1/10W

150 OHM 5% 1/10W

CM151 4-22 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3203 063-11087-64 RESISTOR, FILM, 470 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3204 063-11087-66 RESISTOR, FILM, 560 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3205 063-11087-66 RESISTOR, FILM, 560 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3412M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3414 063-10235-80 RESISTOR, FILM, 2.2K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3418 063-10235-88 RESISTOR, FILM, 4.7K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3419 063-10235-88 RESISTOR, FILM, 4.7K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R3440 063-10243-48 RESISTOR, FILM, 100 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5101M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5102M 063-11059-17A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5103 063-10244-22 RESISTOR, FILM, 120K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5105M 063-11059-27A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5106M 063-11059-17A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5107 063-10243-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5108M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5109M 063-11059-17A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5110 063-10244-22 RESISTOR, FILM, 120K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5112M 063-11059-27A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5113M 063-11059-17A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5114 063-10235-64 RESISTOR, FILM, 470 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5115 063-10243-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5116 063-10243-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5117M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5118M 063-11059-17A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5119 063-10244-22 RESISTOR, FILM, 120K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5120M 063-11059-27A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5121M 063-11059-17A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5123 063-10243-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5124M 063-11059-71A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5125 063-10235-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5126 063-10244-28 RESISTOR, FILM, 220K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R5127 063-10243-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6001M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6002M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6003M 063-11059-73A RESISTOR, THICK FILM CHIP,

1/2W

10K OHM 5% 1/10W

1/4W

1/2W

1K OHM 5% 1/10W

47 OHM 5% 1/10W

1/2W

120 OHM 5% 1/10W

47 OHM 5% 1/10W

1/2W

1K OHM 5% 1/10W

47 OHM 5% 1/10W

1/2W

120 OHM 5% 1/10W

47 OHM 5% 1/10W

1/4W

1/2W

1K OHM 5% 1/10W

47 OHM 5% 1/10W

1/2W

120 OHM 5% 1/10W

47 OHM 5% 1/10W

1/2W

8.2K OHM 5% 1/10W

1/4W

1/2W

4.7K OHM 5% 1/10W

220 OHM 5% 1/10W

10K OHM 5% 1/10W

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6004M 063-11059-89A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6005M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6006M 063-11059-29A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6008M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6012 063-10236-12 RESISTOR, FILM, 47K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6015 063-10235-72 RESISTOR, FILM, 1K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6016 063-10235-72 RESISTOR, FILM, 1K OHM 5%

ABCDEJKa R6017M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEJKa R6018 063-10235-96 RESISTOR, FILM, 10K OHM 5%

ABCDEJKa R6019M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEJKa R6020M 063-11059-56A RESISTOR, THICK FILM CHIP,

a R6021 063-10235-72 RESISTOR/ FILM/ 1K OHM 5%

ABCDEJK R6021M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEJKa R6022M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEJKa R6023M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEJKa R6024M 063-11059-56A RESISTOR, THICK FILM CHIP,

ABCDEJKa R6025M 063-11059-56A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6026 063-10235-96 RESISTOR, FILM, 10K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6027 063-10235-80 RESISTOR, FILM, 2.2K OHM 5%

ABCDEJKa R6028 063-10235-60 RESISTOR, FILM, 330 OHM 5%

ABCDEJKa R6029M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6030 091-02053 WIRE, SOLID, BARE, 22 GA

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6031M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6032M 063-11059-77A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6033M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6034M 063-11060-21A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6035M 063-11060-21A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6036M 063-11059A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6037M 063-11059-83A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6039M 063-11059-33A RESISTOR, THICK FILM CHIP,

XY R6040M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6041 063-10235-56 RESISTOR, FILM, 220 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6042M 063-11059-37A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6043 063-10235-56 RESISTOR, FILM, 220 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6044M 063-11059-37A RESISTOR, THICK FILM CHIP,

47K OHM 5% 1/10W

4.7K OHM 5% 1/10W

150 OHM 5% 1/10W

10K OHM 5% 1/10W

1/4W

10K OHM 5% 1/10W

1/4W

1K OHM 5% 1/10W

2K OHM 5% 1/10W

1/4W

1K OHM 5% 1/10W

2K OHM 5% 1/10W

1/4W

10K OHM 5% 1/10W

COPPER

1K OHM 5% 1/10W

15K OHM 5% 1/10W

0 OHM 5% 1/10W

1 MEG OHM 5% 1/10W

0 OHM 5% 1/10W

27K OHM 5% 1/10W

220 OHM 5% 1/10W

4.7K OHM 5% 1/10W

1/4W

330 OHM 5% 1/10W

1/4W

330 OHM 5% 1/10W

CM151 4-23 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-12

RC REF PART# DESCRIPTION

BCDEJKLMNOa R6045M 063-11059-57A RESISTOR, THICK FILM CHIP,

A R6045M 063-11059-61A RESISTOR, THICK FILM CHIP,

FGHIPQRSTUVWXYZ R6045M 063-11059-65A RESISTOR, THICK FILM CHIP,

BCDEJKLMNOa R6046M 063-11059-56A RESISTOR, THICK FILM CHIP,

A R6046M 063-11059-61A RESISTOR, THICK FILM CHIP,

FGHIPQRSTUVWXYZ R6046M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6047M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6048M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6049 063-10235-56 RESISTOR, FILM, 220 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6050M 063-11059-33A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6053M 063-11059-53A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6058M 063-11059-87A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6059M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6060M 063-11059-65A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6061M 063-11059-57A RESISTOR, THICK FILM CHIP,

FGHILMNOPQRSTUVWXYZ R6069M 063-11060-13A RESISTOR, THICK FILM CHIP,

FGHILMNOPQRSTUVWXYZ R6070M 063-11060-13A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6072 063-10235-96 RESISTOR, FILM, 10K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6080 063-10236-41 RESISTOR, FILM, 750K OHM 5%

HTUVWXY R6082M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEFGIJKLMNOPQRSZa R6082M 063-11059-41A RESISTOR, THICK FILM CHIP,

XY R6083M 063-11059-60A RESISTOR, THICK FILM CHIP,

XY R6084M 063-11059-73A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa R6090M 063-11059-49A RESISTOR, THICK FILM CHIP,

ABCDEFGHI RX2115 063-11110-04 RESISTOR, FILM, 1.5 OHM 5%

JKLMNOPQRSTUVWXYZa RX2115 063-11110-06 RESISTOR, FILM, 1.8 OHM 5%

ABCDEFGHI RX2116 063-11110-04 RESISTOR, FILM, 1.5 OHM 5%

JKLMNOPQRSTUVWXYZa RX2116 063-11110-06 RESISTOR, FILM, 1.8 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX2117 063-10235-10 RESISTOR, FILM, 2.7 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX2124 063-11214-16 RESISTOR, FILM, 0.51 OHM 5%

HTUVWXY RX2503 091-02053 WIRE, SOLID, BARE, 22 GA

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3008 063-10936-37 RESISTOR, FILM, 2.21K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3009M 063-11059-97A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3010M 063-11059-25A RESISTOR, THICK FILM CHIP,

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3016 063-10936-72 RESISTOR, FILM, 4.32K OHM

2.2K OHM 5% 1/10W

3.3K OHM 5% 1/10W

4.7K OHM 5% 1/10W

2K OHM 5% 1/10W

3.3K OHM 5% 1/10W

4.7K OHM 5% 1/10W

1/4W

220 OHM 5% 1/10W

1.5K OHM 5% 1/10W

39K OHM 5% 1/10W

4.7K OHM 5% 1/10W

2.2K OHM 5% 1/10W

470K OHM 5% 1/10W

1/4W

100 OHM 5% 1/10W

470 OHM 5% 1/10W

3K OHM 5% 1/10W

10K OHM 5% 1/10W

1K OHM 5% 1/10W

1/2W

1/4W

1/2W

COPPER

1% 1/4W

100K OHM 5% 1/10W

100 OHM 5% 1/10W

1% 1/4W

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3022 063-10936-72 RESISTOR, FILM, 4.32K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3207 063-10243-45 RESISTOR, FILM, 75 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3208 063-10565-10 RESISTOR, FILM, 2.7 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3209 063-10460-44A RESISTOR, WIREWOUND, 6.8

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3211 063-10565 RESISTOR, FILM, 1 OHM 5%

ABCDEFGHIXY RX3212 063-10235-88 RESISTOR, FILM, 4.7K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3214 063-10244-04 RESISTOR, FILM, 22K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3215 063-10832-69B RESISTOR, FILM, 750 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3216 063-11160-60B RESISTOR, FILM, 330 OHM 5%

JKLNPRTVZ RX3217 063-10442-28A RESISTOR, WIREWOUND, 1.5

ABCDEFGHI RX3217 063-10442-37A RESISTOR, WIREWOUND, 3.6

MOQSUWa RX3217 063-11164-02B RESISTOR, FILM, 1.2 OHM 5%

XY RX3217 063-11164-10B RESISTOR, FILM, 2.7 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3218 063-10243-48 RESISTOR, FILM, 100 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3400 063-11264-01 RESISTOR, CARBON

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3401 063-10444-20A RESISTOR, WIREWOUND, 0.68

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3403 063-10442-04A RESISTOR, WIREWOUND, 0.15

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3404 063-11088-26 RESISTOR, FILM, 180K OHM

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3405 063-11164-02B RESISTOR, FILM, 1.2 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3406 063-10235-40 RESISTOR, FILM, 47 OHM 5%

IZ RX3407 063-11156-40B RESISTOR, FILM, 47 OHM 5%

ABCDEFGHJKLMNOPQRSTUVWXYa RX3407 063-11160-35B RESISTOR, FILM, 30 OHM 5%

IZ RX3408 063-11156-32B RESISTOR, FILM, 22 OHM 5%

ABCDEFGHJKLMNOPQRSTUVWXYa RX3408 063-11160-24B RESISTOR, FILM, 10 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3409 063-10565-28 RESISTOR, FILM, 15 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX3417 063-10444-52B RESISTOR, WIREWOUND, 15

K RX3423 063-11160-48B RESISTOR, FILM, 100 OHM 5%

ABCDEFGHIJKLMNOPQRSZa RX3423 063-11160-52B RESISTOR, FILM, 150 OHM 5%

HTUVWXY RX3427 063-10442-60B RESISTOR, WIREWOUND, 33

K RX3427 063-11160-48B RESISTOR, FILM, 100 OHM 5%

ABCDEFGHIJKLMNOPQRSZa RX3427 063-11160-52B RESISTOR, FILM, 150 OHM 5%

ABCDEHJKLMNOTUVWa RX3428 063-10235-54 RESISTOR, FILM, 180 OHM 5%

FGIPQRSXYZ RX3428 063-10243-45 RESISTOR, FILM, 75 OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX5104 063-10837B RESISTOR, FILM, 15K OHM 5%

1% 1/4W

1/2W

OHM 10% 10W

12W

5% 14W

12W

1W

2W

OHM 5% 5W

3W

1/2W

COMPOSITION, 5.6M OHM 20% 1/2W

OHM 10% 5W

OHM 5% 5 WATT

5% 1/2W

3W

1/4W

1W

2W

1W

2W

1/2W

OHM 10% 5 WATT

2W

OHM 5% 5W

2W

1/4W

1/2W

2W

CM151 4-24 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

COMPONENT PARTS LIST

SEE REFERENCE CHART ON PAGE 4-128

RC REF PART# DESCRIPTION

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX5111 063-10837B RESISTOR, FILM, 15K OHM 5%

ABCDEFGHIJKLMNOPQRSTUVWXYZa RX5122 063-10837B RESISTOR, FILM, 15K OHM 5%

ABCDEJKa SW0001 085-01832 SWITCH, PUSH-BUTTON, NON

ABCDEJKa SW0002 085-01832 SWITCH, PUSH-BUTTON, NON

ABCDEJKa SW0003 085-01832 SWITCH, PUSH-BUTTON, NON

ABCDEJKa SW0004 085-01832 SWITCH, PUSH-BUTTON, NON

ABCDEJKa SW0005 085-01832 SWITCH, PUSH-BUTTON, NON

ABCDEJKa SW0006 085-01832 SWITCH, PUSH-BUTTON, NON

ABCDEFGHIJKLMNOPQRSTUVWXYZa THX3415 063-10710A RESISTOR, THERMISTOR CEGKNORSVWY TU6000 175-02721 TUNER, VARACTOR, 181

ABDFHIJLMPQTUXZa TU6000 175-02771 TUNER, VARACTOR, 181

ABCDEFGHIJKLMNOPQRSTUVWXYZa TX3204 064-01242 EYELET, ROLLED FLANGE ADEUWa TX3204 095-04372-01 SWEEP XFMR, COLOR FINAL,

ABCDEFGHIJKLMNOPQRSTUVWXYZa TX3204 095-04601-01 SWEEP XFMR, COLOR, FINAL,

ABCDEFGHIJKLMNOPQRSTUVWXYZa TX3205 095-04477-01 TRANSFORMER, HORIZONTAL

ABCDEFGHIJKLMNOPQRSTUVWXYZa TX3401 064-01242 EYELET, ROLLED FLANGE ABCDEFGHIJKLMNOPQRSTUVWXYZa TX3401 095-04574 TRANSFORMER, CHOPPER ABCDEFGHIJKLMNOPQRSTUVWXYZa U1200 224-00160 FILTER, SURFACE ACOUSTIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa U1201 224-00139-01A FILTER, 4.5 MHZ CERAMIC

ABCDEFGHIJKLMNOPQRSTUVWXYZa U1202 224-00023A CERAMIC FILTER , 4.5 MHZ

HTUVWXY W0130 063-10235-70 RESISTOR, FILM, 820 OHM 5%

BCDEHJKLMNOTUVWa ZD1405 103-00279-21A DIODE, ZENER, 12V 0.5W FGIPQRSXYZ ZD2901 103-00279-10A DIODE, ZENER, 5.1V 0.5W FGIPQRSXYZ ZD2902 103-00279-18A DIODE, ZENER, 9.1V 0.5W DEFGHILMNOPQRSTUVWXYZ ZD2903 103-00279-18A DIODE, ZENER, 9.1V 0.5W ABCDEFGHIJKLMNOPQRSTUVWXYZa ZD6001 103-00279-36A DIODE, ZENER, 33V 0.5W ABCDEFGHIJKLMNOPQRSTUVWXYZa ZDX3004 103-00472A DIODE, ZENER, 12V 0.5W ABCDEFGHIJKLMNOPQRSTUVWXYZa ZDX3401 103-00279-24A DIODE, ZENER, 15V 0.5W

2W

LOCKING, SPST

CHANNEL, SINGLE IC, WORLD STAN

MINI

DRIVER

WAVE

BANDPASS

TRAP

1/4W

RC REF PART# DESCRIPTION

CM151 4-25 CA - COMPONENTS

Critical safety components are identified by the letter “X” in their component designators and are shaded. Replace only with part numbers specified.

CM151 5-1 CA - EXPLODED VIEWS

SECTION 5

MECHANICAL EXPLODED VIEWS

25/26V Table Top Set Exploded View

REF DESCRIPTION LGB26A11ZM LGB26A11ZM6

1 FRONT CABINET 014-12296-17 014-12296-17 2 SPEAKER 049-01368-03 049-01368-03 3 KNOB ARRAY 046-10578 046-10578 4 IR LENS 192-00916 192-00916 5 CRT ASSEM BLY A63AFW38X A63AFW38X 6 YOKE 095-04456-06 095-04456-06

COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR

8 REAR CABINET 014-12297-09 014-12297-09 9 REMOTE CONTROL 124-00233 124-00233

7 MAIN MODULE

REF DESCRIPTION B25A02Z B25A10Z B25A10Z6 B25A10ZC B25A10ZC6 B25A10ZCF B25A11Z B25A11Z6 B25A11ZF

1 FRONT CABINET 014-12296-17 014-12296-17 014-12296-17 014-12296-17 014-12296-17 014-12296-17 014-12296-17 014-12296-17 014-12296-17 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KNOB ARRAY 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 4 IR LENS 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 5 CRT ASSEM BLY A63AFW38X A63AFW38X A63AFW38X A63AFW38X A63AFW38X A63AFW38X A63AFW38X A63AFW38X A63AFW38X 6 YOKE 095-04456-06 095-04456-06 095-04456-06 095-04456-06 095-04456-06 095-04456-06 095-04456-06 095-04456-06 095-04456-06

COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMP ONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REP AIR

8 REAR CABINET 014-12297-08 014-12297-08 014-12297-08 014-12297-08 014-12297-08 014-12297-08 014-12297-09 014-12297-09 014-12297-09 9 REMOTE CONTROL 124-00213-23 124-00213-23 124-00213-23 124-00213-23 124-00213-23 124-00213-23 124-00233 124-00233 124-00233

7 MAIN MODULE

3

4

2

7

5

6

8

9

C

MBR3492Z

124-00213-23

MBR3447Z

124-00233

CM151 5-2 CA - EXPLODED VIEWS

25V Table Top Set Exploded View

8

1

7

6

5

9

3

4

2

MBR3447Z

124-00233

REF DESCRIPTION B25A24Z B25A24Z6 B25A24ZF

1 FRONT CABINET 014-12187-14 014-12187-14 014-12187-14 2 SPEAKER 049-1368-03 049-1368-03 049-1368-03 3 KEYBOARD ASSEMBLY F-50826 F-50826 F-50826 4 IR LENS 192-00858-01 192-00858-01 192-00858-01 5 CRT ASSEMBLY A63AFW38X A63AFW38X A63AFW38X 6 YOKE 095-04456-06 095-04456-06 095-04456-06 7 REAR CABINET 014-12181-09 014-12181-09 014-12181-09

COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

9 REMOTE CONTROL 124-00233 124-00233 124-00233

8 MAIN MODULE

CM151 5-3 CA - EXPLODED VIEWS

25V Table Top Set Exploded View

8

4

2

1

7

6

5

9

MBR3346Z

124-00229-01

REF DESCRIPTION B25A30ZC B25A30ZCF CB25A25Z CB25A25Z6

1 FRONT CABINET 014-12229-17 014-12229-17 014-12229-17 014-12229-17 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-50825 F-50825 F-50825 F-50825 4 IR LENS 192-00887 192-00887 192-00887 192-00887 5 CRT ASSEM BLY A63AFW38X A63AFW38X A63AFW38X A63AFW38X 6 YOKE 095-04456-06 095-04456-06 095-04456-06 095-04456-06 7 REAR CABINET 014-12230-03 014-12230-03 014-12230-03 014-12230-03

COMPONENT COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

9 REMOTE CONTROL 124-00229-01 124-00229-01 124-00233 124-00233

8 MAIN MODULE

CM151 5-4 CA - EXPLODED VIEWS

27/29V Table Top Set Exploded View

8

3

4

2

1

6

5

7

C

MBR3492Z

124-00213-23

MBR3345Z

124-00229

REF DESCRIPTION B27A10Z B27A10Z5 B27A10ZC5 B27A10Z6 B27A10ZC B27A10ZC6 B27A10ZCF LGB29A10ZM

1 FRONT CABINET 014-12305-08 014-12305-08 014-12305-08 014-12305-08 014-12305-08 014-12305-08 014-12305-08 014-12305-08 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KNOB ARRAY 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 046-10578 4 IR LENS 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 192-00916 5 YOKE & CRT ASSEM BLY A-19058-03 A-19058-01 A-19058-01 A-19058-03 A-19058-03 A-19058-03 A-19058-03 A-19058-03 6 REAR CABINET 014-12304-03 014-12304-03 014-12304-03 014-12304-03 014-12304-03 014-12304-03 014-12304-03 014-12304-03

COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEV EL REPAIR LEVEL REPAIR LEV EL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 129-00213-23 129-00213-23 129-00213-23 129-00213-23 129-00213-23 129-00213-23 129-00213-23 124-00213-23

7 MAIN MODULE

REF DESCRIPTION LGB29A10ZM5 LGB29A13ZM

1 FRONT CABINET 014-12305-08 014-12305-08 2 SPEAKER 049-01368-03 049-01368-03 3 KNOB ARRAY 046-10578 046-10578 4 IR LENS 192-00916 192-00916 5 YOKE & CRT ASSEM BLY A- 19058-01 A-19058-03 6 REAR CABINET 014-12304-03 014-12304-03

COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00213-23 129-00229

7 MAIN MODULE

CM151 5-5 CA - EXPLODED VIEWS

3

4

2

1

7

6

5

8

MBR3447Z

124-00233

C

MBR3492Z

124-00213-23

27/29V Table Top Set Exploded View

REF DESCRIPTION B27A11Z B27A11Z5 B27A11Z6 B27A11Z65 B27A11ZC B27A11ZC5 CB27A10Z CB27A10ZC

1 FRONT CABINET 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 4 IR LENS 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 5 YOKE & CRT ASSEM BLY A-19058-03 A-19058-01 A-19058-03 A-19058-01 A-19058-03 A-19058-01 A-19058-01 A-19058-01 6 REAR CABINET 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06

COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00233 124-00233 124-00233 124-00233 124-00233 124-00233 124-00213-23 124-00213-23

7 MAIN MODULE

REF DESCRIPTION LGB29A11ZM LGB29A11ZM5

1 FRONT CABINET 014-12281-08 014-12281-08 2 SPEAKER 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-52954 F-52954 4 IR LENS 192-00912 192-00912 5 YOKE & CRT ASSEM BLY A-19058-03 A-19058-01 6 REAR CABINET 014-12282-06 014-12282-06

COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00233 124-00233

7 MAIN MODULE

CM151 5-6 CA - EXPLODED VIEWS

27/29V Table Top Set Exploded View

3

4

2

1

7

8

5

6

MBR3447Z 124-00233

REF DESCRIPTION B27A24Z B27A24Z5 B27A24Z6 B27A24Z65 B27A24ZF B27A24ZF5 LGB29A24ZM LGB29A24ZM5

1 FRONT CABINET 014-12317-04 014-12317-04 014-12317-04 014-12317-04 014-12317-04 014-12317-04 014-12317-04 014-12317-04 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-53039 F-53039 F-53039 F-53039 F-53039 F-53039 F-53039 F-53039 4 IR LENS 192-00923 192-00923 192-00923 192-00923 192-00923 192-00923 192-00923 192-00923 5 YOKE & CRT ASSEM BLY A-19058-03 A-19058-01 A-19058-03 A-19058-01 A-19058-03 A-19058-01 A-19058-03 A-19058-01 6 REAR CABINET 014-12254-06 014-12254-06 014-12254-06 014-12254-06 014-12254-06 014-12254-06 014-12254-06 014-12254-06

COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00233 124-00233 124-00233 124-00233 124-00233 124-00233 124-00233 124-00233

7 MAIN MODULE

CM151 5-7 CA - EXPLODED VIEWS

8

3

4

2

1

7

6

5

MBR3346Z

124-00229-01

27/29V Table Top Set Exploded View

REF DESCRIPTION B27A30Z B27A30ZC B27A30ZC5 B27A30ZC6 B27A30ZC65 B27A30ZCF B27A30ZCF5 LGB29A30ZM LGB29A30ZM5

1 FRONT CABINET 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 014-12281-08 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 F-52954 4 IR LENS 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 5 YOKE & CRT ASSEM BLY A- 19058-03 A-19058-03 A-19058-01 A-19058-03 A-19058-01 A-19058-03 A-19058-01 A-19058-03 A-19058-01 6 REAR CABINET 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06 014-12282-06

COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00229-01 124-00229-01 124-00229-01 124-00229-01 124-00229-01 124-00229-01 124-00229-01 124-00229-01 124-00229-01

7 MAIN MODULE

CM151 5-8 CA - EXPLODED VIEWS

27V Table Top Set Exploded View

3

4

2

1

7

8

5

6

MBR3457Z 124-00233

REF DESCRIPTION B27A34Z B27A34Z6 B27A34ZF

1 FRONT CABINET 014-12347 014-12347 014-12347 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-53039 F-53039 F-53039 4 IR LENS 192-00923 192-00923 192-00923 5 YOKE & CRT ASSEM BLY A-19112 A-19112 A-19112 6 REAR CABINET 014-12254-06 014-12254-06 014-12254-06

COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00233-01 124-00233-01 124-00233-01

7 MAIN MODULE

CM151 5-9 CA - EXPLODED VIEWS

32V Table Top Set Exploded View

REF DESCRIPTION B32A24Z B32A24Z6 B32A24ZF B32A30Z B32A30Z6 B32A30ZF

1 FRONT CABINET 014-12284-23 014-12284-23 014-12284-23 014-12284-23 014-12284-23 014-12284-23 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-52060 F-52060 F-52060 F-52060 F-52060 F-52060 4 IR LENS 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 5 CRT A81AGZ50X A81AGZ50X A81AGZ50X A81AGZ50X A81AGZ50X A81AGZ50X 6 YOKE 095-04517-01 095-04517-01 095-04517-01 095-04208-01 095-04208-01 095-04208-01 7 REAR CABINET 014-12285-08 014-12285-08 014-12285-08 014-12285-08 014-12285-08 014-12285-08 8 MAIN MODULE 009-02068 009-02068-01 009-02068 009-02072 009-02072-01 009-02072 9 REMOTE CONTROL 124-00233 124-00233 124-00233 124-00229-01 124-00229-01 124-00229-01

REF DESCRIPTION B32A34Z B32A34Z6 B32A34ZF

1 FRONT CABINET 014-12284-23 014-12284-23 014-12284-23 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-52060 F-52060 F-52060 4 IR LENS 192-00912 192-00912 192-00912 5 CRT A81AGZ50X A81AGZ50X A81AGZ50X 6 YOKE 095-04208-01 095-04208-01 095-04208-01 7 REAR CABINET 014-12285-08 014-12285-08 014-12285-08 8 MAIN MODULE 009-02075 009-02075 009-02075 9 REMOTE CONTROL 124-00233-01 124-00233-01 124-00233-01

8

3

4

2

1

7

6

5



MBR3457Z

124-00233

MBR3447Z

124-00233

MBR3346Z

124-00229-01

CM151 5-10 CA - EXPLODED VIEWS

36V Table Top Set Exploded View

REF DESCRIPTION B36A24Z B36A24Z6 B36A24ZF B36A30Z B36A30Z6 B36A30ZF B36A34Z B36A34Z6 B36A34ZF

1 FRONT CABINET 014-12269-12 014-12269-12 014-12269-12 014-12269-12 014-12269-12 014-12269-12 014-12269-12 014-12269-12 014-12269-12 2 SPEAKER 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 049-01368-03 3 KEYBOARD ASSEMBLY F-52060 F-52060 F-52060 F-52060 F-52060 F-52060 F-52060 F-52060 F-52060 4 IR LENS 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 192-00912 5 YOKE & CRT ASSEM BLY A- 18639 A-18639 A-18639 A-18639 A-18639 A-18639 A-18639 A-18639 A-18639 6 REAR CABINET 014-12270-12 014-12270-12 014-12270-12 014-12270-12 014-12270-12 014-12270-12 014-12270-12 014-12270-12 014-12270-12 7 MAIN MODULE 009-02069 009-02069-01 009-02069 009-02073 009-02073-01 009-02073 009-02076 009-02076-01 009-02076 8 REMOTE CONTROL 124-00233 124-00233 124-00233 124-00229-01 124-00229-01 124-00229-01 124-00233-01 124-00233-01 124-00233-01

3

4

2

1

7

6

5

MBR3457Z

124-00233

MBR3447Z

124-00233

MBR3346Z

124-00229-01

CM151 5-11 CA - EXPLODED VIEWS

25/27V Traditional Console Set Exploded View

8

1

2

3

4

5

6

7

MBR3447Z

124-00233

REF DESCRIPTION B25A74R B25A74LK B27A74R B27A74R5

1 ESCUTCHEON 057-09067-09 057-09067-09 057-09067-09 057-09067-09 2 MAIN CABINET 014-12191-03 014-12191-03 014-12326 014-12326 3 SPEAKER 049-01302-03 049-01302-03 049-01334-02 049-01334-02 4 CRT A63AGDO1X A63AGDO1X A63AGDO1X A63AGDO1X 5 YOKE 095-03797-05 095-03797-05 095-03797-05 095-03797-05 6 BACK COVER 014-12297-08 014-12297-08 014-12297-08 014-12297-08

COMPONENT COMPONENT COMPONENT COMPONENT

LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR LEVEL REPAIR

8 REMOTE CONTROL 124-00233 124-00233 124-00233 124-00233

7 MAIN MODULE

CM151 5-12 CA - EXPLODED VIEWS

25/27V Console Set Exploded View

1

2

8

5

4

6

7

3

MBR3447Z

124-00233

REF DESCRIPTION B25A76R B27A76R B27A76R5

1 ESCUTCHEON 057-09067-08 057-09055-42 057-09055-42 2 MAIN CABINET 014-12333 014-12327 014-12327 3 SPEAKER 049-01302-03 049-01334-02 049-01334-02 4 CRT ASSEM BLY A63AGDO1X A63AGDO1X A63AGDO1X 5 YOKE 095-04456-05 095-03797-05 095-03797-05 6 BACK COVER 014-11639-19 014-11639-20 014-11639-20

COMPONENT COMPONENT COMPONE NT

LEVE L REPA IR LE VEL REPAIR LEV EL REP AIR

8 REMOTE CONTROL 124-00233 124-00233 124-00233

7 MAIN MODULE

CRITICAL SAFETY COMPONENTS ARE IDENTIFIED BY THE LETTER “X“ IN THEIR COMPONENT DESIGNATORS. REPLACE ONLY WITH PART NUMBERS SPECIFIED.

ALL SYMBOLS WITH “M” ON END OF DESIGNATOR INDICATE SURFACE MOUNTED COMPONENT

SECTION 6

SCHEMATICS

Interconnect Diagram

CA SHEET 16-1

HORIZONTAL YOKE HI HORIZONTAL YOKE LOW VERTICAL YOKE LOW VERTICAL YOKE HI

DAG GROUND

DEGAUSS DEGAUSS

SPKR

RIGHT SPEAKER

LEFT SPEAKER

SPKR

FILAMENT

GROUND

+215V

FILAMENT

GROUND

+215V

G + UP B + UP FBLNK

R G B

SW + PIP

GND

VIN PIP

R + UP

FLYBACK

VRAMP

GND

+5 V

GND

+9 VSW

GND SCL SDA

3R8

AC LOW

AC HIGH

ULUL

Y/C

OUT LOUT R

IN LIN RVID

A-18785-03

JACKPACK IS SOLDERED TO MAIN CHASSIS

KEYBOARD VARIES BY MODEL SOME HAV E FE W ER KEYS, SEE MODEL BOM FOR KEYBOARD APPLICATION SPECIFICS.

GROUND

KEY 2

KEY 1

IR DATA

+5V SIDE Y

LEFT INT SPKR HI

RIGHT INT SPKR HI

LEFT INT SPKR LOW

RIGHT INT SPKR LOW

FOCUS

G2

A-18785-02

G2

FOCUS

GND

VCC

OUT

IR1

6K2

SW3

SW6 SW5

SW2

SW4

SW1

MENU CH-UP CH-DWN VOL-UPVOL-DWN ON/OFF

6K2

6P2

ENTER ADJ LEFT ADJ RIGHT SELECT

MENU

VOL DOWN VOL UP CH DOWN CH UP POWER

9-2107

SDA

SCL

GND

+9 VSW

GND

+5 V

GND

VRAMP

FLYBACK

R + UP

VIN PIP

GND

SW + PIP

BGR

FBLNK

B + UP

G + UP

PIPA

1

PIPB

1

IC2501

1

169

81

IC2502

B-OUT

G-OUT

R-OUT

+9V GND

GND

+9V

R-OUT

G-OUT

B-OUT

GROUND

+5VSTDEY

CONTROL

CLOCK

DATA

QX3251

TX3401

TU6000

TGND

4G9

J1

IC1402

9S4

IC804

2F5

IC2100

TX3204

QX3203

3Y3

FX3401

IC6000

IR6000

PIPB1

PIPA1

2K6

FX3402

SW6SW3SW2SW1 SW4 SW5

5C2

2C5

1

ICX3401

IN

G

OUT

1

ICX3412

1

IC1400

EX3401

1

ICX2200

12

1

BCE

EB

C

1

LX3401

3T8

3R8

1

DL2200

EB

C

Q5103

E

B

C

Q5101

5F2

CRT1

EB

C

Q5102

MODEL SCR AUDIO PIP JACKS

B25A02Z

25

Mono N one 0

B25A10Z 25

Stereo None 0

B25A10Z6 25

Stereo None 3

B25A10ZC 25

Stereo None 0

B25A10ZC6 25

Stereo None 3

B25A10ZCF 25

Stereo None 0

B25A11Z 25

Stereo None 3

B25A11Z6 25

Stereo None 3

B25A11ZF 25

Stereo None 3

B25A24Z 25

MTS/SAP None 6

B25A24Z6 25

MTS/SAP None 6

B25A24ZF 25

MTS/SAP None 6

B25A30ZC 25

Stereo 1 Tuner 3

B25A30ZCF 25

Stereo 1 Tuner 3

B25A74R 25

MTS/SAP None 6

B25A74LK 25

MTS/SAP None 6

B25A76R 25

MTS/SAP None 6

B27A10Z 27

Stereo None 0

B27A10Z5 27

Stereo None 0

B27A10Z6 27

Stereo None 3

B27A10ZC 27

Stereo None 0

B27A10ZC5 27

Stereo None 0

B27A10ZC6 27

Stereo None 3

B27A10ZCF 27

Stereo None 0

B27A11Z 27

Stereo None 3

B27A11Z5 27

Stereo None 3

B27A11Z6 27

Stereo None 3

B27A11Z65 27

Stereo None 3

B27A11ZC 27

Stereo None 3

B27A11ZC5 27

Stereo None 3

B27A13Z 27

Stereo None 0

B27A24Z 27

MTS/SAP None 6

B27A24Z5 27

MTS/SAP None 6

B27A24Z6 27

MTS/SAP None 6

B27A24Z65 27

MTS/SAP None 6

B27A24ZF 27

MTS/SAP None 6

B27A24ZF5 27

MTS/SAP None 6

B27A30Z 27

Stereo 1 Tuner 3

B27A30ZC 27

Stereo 1 Tuner 3

B27A30ZC5 27

Stereo 1 Tuner 3

B27A30ZC6 27

Stereo 1 Tuner 3

B27A30ZC65 27

Stereo 1 Tuner 3

B27A30ZCF 27

Stereo 1 Tuner 3

B27A30ZCF5 27

Stereo 1 Tuner 3

B27A34Z 27

MTS/SAP 1 Tuner 6

B27A34Z6 27

MTS/SAP 1 Tuner 6

B27A34ZF 27

MTS/SAP 1 Tuner 6

B27A74R 27

MTS/SAP None 6

B27A76R 27

MTS/SAP None 6

COMPONENT LEVEL R EPAIR ONL Y

&$&KD V VLV0 RGH O ,Q IR UPD WLR Q

MODEL SCR AUDIO PIP JACKS

CB25A25Z25MTS/SAP None 6 CB25A25Z625MTS/SAP None 6 CB27A10Z

27

Stereo N one 0 CB27A10ZC27Stereo N one 0 CB27A25Z27MTS/SAP None 6 LGB26A11ZM25Stereo N one 3 LGB26A11ZM625Stereo N one 3 LGB29A10ZM27Stereo N one 0 LGB29A10ZM527Stereo N one 3 LGB29A11ZM27Stereo N one 3 LGB29A11ZM527Stereo N one 3 LGB29A13ZM27Stereo N one 0 LGB29A24ZM27MTS/SAP None 6 LGB29A24ZM527MTS/SAP None 6 LGB29A30ZM27Stereo 1 Tuner 3 LGB29A30ZM527Stereo 1 Tuner 3

B32A24Z

32

MTS/SAP None 6 B32A24Z632MTS/SAP None 6 B32A24ZF32MTS/SAP None 6 B32A30Z

32

Stereo 1 Tuner 3

B32A30Z6

32

Stereo 1 Tuner 3

B32A30ZF

32

Stereo 1 Tuner 3

B32A34Z

32

MTS/SAP 1 Tuner 3 B32A34Z632MTS/SAP 1 Tuner 3 B32A34ZF32MTS/SAP 1 Tuner 3 B36A24Z

36

MTS/SAP None 6 B36A24Z636MTS/SAP None 6 B36A24ZF36MTS/SAP None 6 B36A30Z

36

Stereo 1 Tuner 3

B36A30Z6

36

Stereo 1 Tuner 3

B36A30ZF

36

Stereo 1 Tuner 3

B36A34Z

36

MTS/SAP 1 Tuner 6 B36A34Z636MTS/SAP 1 Tuner 6 B36A34ZF36MTS/SAP 1 Tuner 6

MODULE LEVEL R EPAIR ONL Y

COMPONENT LEVEL R EPAIR ONL Y

&$0RGHO,QIRUPDW LRQFRQWLQXHG

Zenith B27A11Z, B25A11Z, B25A74R, B25A76R, B27A11ZC Service Manuallines

Specifications and Main Features

Frequently Asked Questions

User Manual
