Zenith C32F33, C27F33 OPERATING GUIDE

Installation and Operating Guide | Warranty

Model Numbers | C27F33 • C32F33 | Direct View TVs

© Copyright 2002, Zenith Electronics Corporation.

2

WARNING:

TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.

NOTE TO CABLE/TV INSTALLER:

This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the
National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building, as close to
the point of the cable entry as practical.

REGULATORY INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.

CAUTION: Do not attempt to modify this product in any way without written authorization from Zenith Electronics

Corporation. Unauthorized modification could void the user’s authority to operate this product.
The responsible party for this product’s compliance is :
Zenith Electronics Corporation, 2000 Millbrook Drive, Lincolnshire, IL 60069, USA 1-847-941-8000

RECORD YOUR MODEL NUMBER
(For future reference)

The model and serial number of your new TV are
located on the back of the TV cabinet. For your
future convenience, we suggest that your record
those numbers here:

MODEL NO.______________________
SERIAL NO.________________________

WARNING

RISK OF ELECTRIC SHOCK
DO NOT OPEN

IMPORTANT SAFETY INSTRUCTIONS

3

1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.

2. Follow Instructions
All operating and use instructions should be followed.

3. Retain Instructions
The safety and operating instructions should be retained

for future reference.

4. Heed Warnings
All warnings on the product and in the operating

instructions should be adhered to.

5. Cleaning
Unplug this product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

6. Water and Moisture
Do not use this product near water for example, near a

bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.

7. Accessories
Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to
the product. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with
the product. Any mounting of the product should follow
the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.

8. Transporting Product
A product and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.

9. Attachments
Do not use attachments not recommended by the

product manufacturer as they may cause hazards.

10. Ventilation
Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the product
and to protect it from overheating, and these openings
must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.

11. Power Sources
This product should be operated only from the type of

power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your product dealer or local power company. For
products intended to operate from battery power, or
other sources, refer to the operating instructions.

12. Line-Cord Polarization
This product is equipped with a polarized alternating-

current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.

13. Power-Cord Protection
Power-supply cords should be routed so that they are

not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords
at plugs, convenience receptacles, and the point where
they exit from the product.

Important safeguards for you and your new product

Your product has been manufactured and tested with your safety in mind. However, improper use can result in
potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new
product, please read and observe the following safety points when installing and using your new product, and save
them for future reference.

Observing the simple precautions discussed in this operating guide can help you get many years of enjoyment and
safe operation that are built into your new product.

This product complies with all applicable U.S. Federal safety requirements, and those of the Canadian Standards
Association.

PORTABLE CART WARNING

(Continued on next page)

4

IMPORTANT SAFETY INSTRUCTIONS

14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to

the product, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of
the National Electrical Code (U.S.A.), ANSI/ NFPA 70
provides information with regard to proper grounding of
the mast and supporting structure, grounding of the lead­in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements
for the grounding electrode.

15. Lightning
For added protection for this product (receiver) during a

lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and

disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and
power-line surges.

16. Power Lines
An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching
such power lines or circuits as contact with them might
be fatal.

17. Overloading
Do not overload wall outlets and extension cords as this
can result in a risk of fire or electric shock.

18. Object and Liquid Entry
Never push objects of any kind into this product through

openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.

19. Servicing
Do not attempt to service this product yourself as

opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.

20. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:

a. If the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into

the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following
the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and
will often require extensive work by a qualified technician
to restore the product to its normal operation.

e. If the product has been dropped or the cabinet has

been damaged.

f. If the product exhibits a distinct change in

performance.

21. Replacement Parts
When replacement parts are required, be sure the

service technician has used replacement parts specified
by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.

22. Safety Check
Upon completion of any service or repairs to this product,

ask the service technician to perform safety checks to
determine that the product is in proper operating
condition.

23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only

as recommended by the manufacturer.

24. Heat
The product should be situated away from heat sources

such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.

Antenna Lead in Wire

Antenna Discharge Unit
(NEC Section 810-20)

Grounding Conductor
(NEC Section 810-21)

Ground Clamps
Power Service Grounding

Electrode System (NEC
Art 250, Part H)

Ground Clamp

Electric Service

Equipment

Example of Grounding According to National Electrical
Code Instructions

(Continued from previous page)

NEC- National Electrical Code

Safety Warnings ...........................................2

Important Safety Instructions ......................3

Remote/Front Panel Controls ......................6

Basic TV Setup and Operation ....................8

Turning the TV On/Off.......................................8

Selecting the Menu Language .........................8

Channel Search. ..............................................9

Memorizing the Channels with

AUTO PROGRAM ............................................9

Memorizing the Channels with

MANUAL PROGRAM .....................................10

Tuning Channels ............................................10

Adjusting Volume (Sound) ............................10

Available Features ......................................11

Setting the Clock ............................................11

Setting the OFF TIMER...................................11

Setting the ON TIMER ...................................12

Setting the Sleep Timer ..................................12

Auto Off ..........................................................12

Operating Degauss ........................................13

Key Lock .........................................................13

Fine Tuning ....................................................13

Picture Tilt ......................................................14

Favorite Channel Memory...............................14

Wide/Zoom Picture .........................................14

Picture Control ............................................15

Auto Picture Control........................................15

VM (Velocity Modulation) ...............................15

Control Temperature.......................................15

Adjusting the Picture.......................................16

Sound Control .............................................17

Enjoying Stereo/SAP Broadcasts....................17

Auto Sound Control.........................................17

Adjusting Equalizer

(OFF mode in ASC) .......................................18

Adjusting Balance ...........................................18

AVL (Auto Volume Leveler) ............................18

Adjusting the DBS

(Dynamic Bass Sound) ...................................18

Adjusting the Bass ..........................................19

Adjusting the Treble........................................19

Closed Caption ............................................20

Using Closed Captions ...................................20

Operating the Caption and Text......................21

Parental Control...........................................22

Blocking Setup ...............................................23

Antenna Connections ................................24

Connection of external equipment ...........25

Connecting a DVD player ...........................27

Product Specifications ...............................28

Maintenance ................................................29

Troubleshooting Checklist .........................30

Your Zenith Limited Warranty.....Back cover

CONTENTS

5

Setup Checklist

Step 1

Connect TV and all equipment

:See pages 24-27

Step 2

Do a channel search

:See pages 9-10

Step 3

Set up the individual features, picture, and sound to

your personal preference.

:See appropriate pages

1. MUTE

Press to mute sound. Press again to restore sound.

2. POWER(or ON/OFF)

Refer to "Turning the TV On/Off".

3. NUMBER

Direct channel selection.

4. CAPTION

Selects CAPTION mode.
Refer to "Closed captions".

5. ARC

Selects 4:3 or 16:9 picture formats..

6. COLOR TEMPERATURE

Adjusts TV color temperature.

7. CHANNEL UP/DOWN (

D/E

)

• Selects the desired channel.

• Selects the desired menu option when menu is displayed

on the screen.

VOLUME UP/DOWN (

F/ G

)

• Increase or decrease volume level.

• Enters or adjusts the selected menu when menu is

displayed on the screen.

8. VCR BUTTON

Control some video cassette recorders.

9. SLEEP

Sets desired sleep time.

10.FLASHBACK

To return to the previous channel.

11.MTS

Selects to the MTS sound :

MONO, STEREO or SAP.

12.AUTO PROGRAM

Memorizes channels with AUTO PROGRAM.

13.MEMORY/ERASE

Memorizes or erases selected channel.

Remote/Front Panel Controls

6

2

3

4
5

6
7

8

9

10
11

12

1

13

on/off

tv/video menu vol ch

2 20 2114 15 7

This is a simplified representation of front panel.

power

1
4
7

caption

arc

color temp.

mute

23
56
89

tv/video

0

menu

enter

rew

ch

ch

play

apc fcr

mts

dasp

vol

ff

rec

vol

p/still stop

sleep

flashback

a.prog memory/erase

14.TV/VIDEO

Selects TV, VIDEO or COMPONENT mode.

15.MENU

Displays on-screen menus.
Exit the current menu.
Memorizes menu change.

16.ENTER (

A

)

• Memorizes menu adjustments.

• Recalls current TV mode (by remote control only).

17.APC (Auto Picture Control)

Selects factory preset picture settings.

18.FCR (Favorite Channel Review)

Selects favorite channels.
Refer to "Favorite channel memory".

19.DASP

Selects the sound appropriate for the program's character ;

Dolby virtual,Flat, Movie,Music, Sports or User.

20.STANDBY INDICATOR

Illuminates red when the TV is in standby mode. Refer to

"Turning the TV On/Off"..

21.REMOTE CONTROL SENSOR

7

enter

ch

vol

ch

vol

play

p/still stop

rec

rew

ff

sleep

apc fcr

mts

flashback

0

caption

tv/video

menu

color temp.

arc

1

23

4

56

7

89

power

mute

dasp

a.prog memory/erase

14
15

16

17
18

19

Installing Batteries in the Remote Control

The remote control is powered by batteries, requiring 'AA'
type batteries for operation. To ensure reliable operation,
change the batteries about once a year.
Caution : Batteries installed incorrectly may leak and

damage the remote control. Do not mix old and
new batteries or different types of batteries (for
example, standard and alkaline).

1. Remove the battery compartment cover by sliding it in the
direction shown.

2. Insert new batteries matching the polarity markings (+ and

-) inside the compartment.

3. Replace the battery compartment cover.

1

2

3

Before operating your TV, make sure the following have been completed.

• Your TV is connected to an antenna or a cable system.

• Your TV is plugged into a standard power outlet.

Basic TV Setup and Operation

Turning the TV On/Off

The set switches to standby mode and the standby indicator lights up
in red.
To turn the TV on from standby mode, press the TV/VIDEO, CH

D

/

E

button on the set or POWER, TV/VIDEO, CH D/Eor number
button on the remote control.
A channel number will be displayed on the screen. The on-screen
display will disappear after a few seconds.

Press the power button on the remote control, the TV reverts to
standby mode.

Selecting the Menu Language

1. Press the menu button and then use D/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Language.

3. Use the

F/G

button to select the desired language.

From this point on, the menus will appear in the language you
selected.

4. Press the menu button to remove menu.

8

Language English
Key+lock Off

Degauss Off
Caption Off
Tilt 0
Parental +ctl

++MOVE+{NEXT+MENU:EXIT

Channel Search

Channel Search memorizes all the active channels in your area. You must do a channel search before
you can use the TV.
There are two ways of memorizing channels. You can use either.
One is AUTO PROGRAM and the other is MANUAL PROGRAM.
In AUTO PROGRAM, the TV memorizes the channels in ascending numerical order. If there are
additional channels you want to add or delete, add or delete them manually.

Memorizing the Channels with AUTO PROGRAM

AUTO PROGRAM searches and memorizes all the active channels in

your area then you can select the desired channel with the

D

/

E

buttons.

Using the a.prog Button

AUTO PROGRAM the TV using the convenient a.prog button on the
remote control.

1. Press the a.prog button.

2. Use the

D

/Ebutton to select Normal or Turbo.

3. Press the

G

or a.prog button to start AUTO PROGRAM.

The AUTO PROGRAM starts now.

If you want to stop auto programming, press the enter (

A

) button.

Only the channels searched up to that time will be memorized.

Turbo auto program works faster than Normal auto program.

Notes

• If broadcast signals are poor quality, try memorize channels again

using

Normal auto program.

• AUTO PROGRAM stores all available channels regardless of

signal (RF, Cable).

• If over-the-air and Cable TV channels are duplicated, use the

number buttons (0 ~ 9) to change as

.

Using the Auto Program Menu

1. Press the menu button and use D/Ebutton to select the menu

shown to the right.

2. Press the

G

and then use D/Ebutton to select Auto program.

3. Press the

G

button to enter the Auto program mode.

4. Use the

D

/Ebutton to select Normal auto program or Turbo

auto program.

5. Press the

G

button button to start AUTO PROGRAM.

The AUTO PROGRAM starts now.

9

+Auto+program++Normal

Channels of general wireless TV Channels of Cable TV

Auto +program TV15

Å:STOP

10

%

Auto +program
Manual+program
Favorite+channel

++MOVE+{NEXT+MENU:EXIT

Normal+auto+program
Turbo+auto+program

++MOVE+{NEXT+}BACK

Normal +auto +program

Basic TV Setup and Operation

Memorizing Channels with Manual Program

Using Memory/Erase button

MANUAL PROGRAM the TV using the convenient memory/erase
button on the remote control.

1. Use the

D

/Eor NUMBER buttons to select the channel number

you want to memorize or erase.

2. Press the memory/erase button.

The on screen display appears as shown right.

3. Use the memory/erase button to select

Memory or Erase.

4. Press the enter (

A

) button to remove menu.

Using the Manual Program Menu

1. Press the menu button and then use D/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Manual

program.

3. Press the

G

button to enter the Manual program mode.

4. Use the

F/G

to select Memory or Erase.

5. Use the

E

button to select Channel.

6. Use the

F/G

or NUMBER buttons to select the channel number

you want to memorize or erase.

7. Use the

E

button to select Name.You can make a channel name.

8. Use the

F/G

button to select a word position and then D/Ebutton

to enter blank, number

0 to 9 and the alphabet A to Z.

9. Repeat steps 4 to 8 to memorize or erase other channels.

Channel Tuning

Use the D/Ebutton to easily select the next higher or lower channel
then the channel being viewed, or NUMBER buttons to directly select
the desired channel.

Adjusting Volume (Sound)

Use theGbutton to increase the volume level or Fbutton to decrease
the volume level.

To turn off the sound, press the mute button.
The word

Mute is displayed (it’s not displayed in the Caption mode).

Using Mute is convenient if you need to answer telephone calls.
To restore the muted sound, press the mute button again or vol

F/G

button.

10

Mute

oVolume 15

+Manual++TV14++Memory

Auto +program
Manual+program
Favorite+channel

++MOVE+{NEXT+MENU:EXIT

Memory®Erase
Channel TV14
Fine 0
Name

_____

++MOVE+}{

+ADJUST+

Å

BACK

Memory®iErase Memory

A vailable Features

Setting the Clock

Before using the on/off timer features, set the current time on the
clock.

Auto Clock Setup

The time is set automatically through from a PBS broadcast signal.
The PBS channel signal includes information for the correct time and
daylight saving time.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Clock .

3. Press the

G

button and then use the D/Ebutton to select the time

zone of your viewing area. Your choices are:

E.S.T (Eastern

Standard Time)

, C.S.T (Central Standard Time), M.S.T

(Mountain Standard Time)

, P.S.T (Pacific Standard Time),

Alaska, and Hawaii.

4. Press the

G

button and then use the D/Ebutton to set PBS

channel.

5. Press the menu button to remove menu.

Manual Clock Setup

1. Press the menu button and then use D/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Clock .

3. Press the

G

button and then use the D/Ebutton to select manual.

4. Press the

G

button and then use the D/Ebutton to set the hours.

5. Press the

G

button and then use the D/Ebutton to set the

minutes.

6. Press the menu button to remove menu.

Setting the Off Timer

Off Timer automatically switches the TV to standby mode at the preset
time.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Off-timer.

3.

Run/Hold is used to activate or deactivate preset on/off times.

Use the

F/G

button to select Hold or Run.

4. Press the

E

button.

5. Press the

G

button and then use the D/E button to set the hours.

6. Press the

G

button and then use the D/Ebutton to set the

minutes.

7. Press the menu button to remove menu.

Note

• If the same time is set for both on time and off time, only off time

operates.

11

Clock+++Manual

__:__+AM

Off_timer Hold

__:__+AM

On_timer Hold

__:__+AM
On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+{NEXT+MENU:EXIT

Clock+++Manual

__:__+AM
Off_timer Hold

__:__+AM
On_timer Hold

__:__+AM
On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+{NEXT+MENU:EXIT

Clock

__:__+AM
Off_timer Hold

__:__+AM
On_timer Hold

__:__+AM
On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+}{+ADJUST+ÅBACK

Clock+++Manual

__:__+AM

Clock+++Manual

11:00+AM
Off_timer Hold

__:__+AM
On_timer Hold

__:__+AM
On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+}{+ADJUST+ÅBACK

Off_timer

Hold

Setting the On Timer

On Timer automatically turns the TV on at the preset time and tunes to
the specified channel.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Use the

G

and then D/Ebutton to select On-timer.

3. Repeat OFF TIMER steps 3 to 6.

4. Press the

E

button to select On Pr. and then use the F/Gbutton to

select the desired channel.

5. Press the

E

button to select Volume and then use the F/Gbutton

to adjust the volume level.

6. Press the menu button to remove menu.

Notes

• If you don’t press any button within 2 hours after turning on the TV
with the ON TIMER function, the TV will automatically switch back
to standby mode.

• TV must be in standby mode for the On Timer to work.

Setting the Sleep Timer

You don't have to remember to switch the TV to standby mode before
you go to sleep. The Sleep Timer automatically turns the TV off after
the preset sleep time expires.
Use the Sleep button to select the desired sleep time.
Each time you press this button, preset sleep time settings are
displayed one by one as shown below. The Sleep Timer begins to
count down from the number of minutes selected.

Notes

• After a few seconds, the desired sleep time setting will disappear
and the TV turn-off function will operate automatically.

• To view the remaining sleep time, press the sleep button once
and the remaining sleep time will be displayed.

• To cancel the sleep timer, select the

Sleep --- setting with sleep

button.

• “SLEEP 1” will be displayed one minute before the TV is due to
turn off.

Auto Off

If there is no input signal, the TV is switched to standby mode
automatically in 10 minutes.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Auto off.

3. Use the

F/G

button to select On or Off.

4. Press the menu button to remove menu.

Available Features

12

--- → 10 → 20 → 30 → 60 → 90 → 120 → 180 → 240

Sleepeeeee___

Clock+++Manual

__:__+AM

Off_timer Hold

__:__+AM

On_timer Hold

__:__+AM
On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+{NEXT+MENU:EXIT

Clock+++Manual

__:__+AM

Off_timer Hold

__:__+AM

On_timer Hold

__:__+AM

On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+{NEXT+MENU:EXIT

Clock+++Manual

11:00+AM

Off_timer Hold

__:__+AM

On_timer Hold

__:__+AM

On +Pr. TV13
Volume 30
Auto +off Off

++MOVE+}{+ADJUST+ÅBACK

On_timer

Hold

Operating Degauss

In this TV, the magnetic field of the earth may influence the color purity
of the picture. The picture can also be disturbed by other nearby
magnetic influences or perhaps because of the location of the TV
itself. Stripes may appear on the screen or the color may not be equal
in the corners. Use Degauss to reset the color purity.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Degauss.

3. Use the

F/G

button to select On or Off.

4. Press the menu button to remove menu.

Notes

• Do not use Degauss too often or the life of CRT may be shortened.

• If are unable to correct problem by degaussing, try again after about

4 minutes.

Key Lock

The TV can be set up so that the remote control is needed to operate
it. This feature can be used to prevent unauthorized viewing.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Key lock.

3. Use the

F/G

button to select On or Off.

4. Press the menu button to remove menu.

Notes

• With the key lock on, the display

Key lock appears on the screen if

any button on the front panel is pressed while viewing the TV.

• This TV is programmed to remember which option it was last set to
even if you switch the TV from standby mode.

Fine Tuning Adjustment

Fine Tuning adjusts the picture to a stable condition when it is poor, for
example, a horizontal stripe, twisted picture or no color in program.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Manual

program.

3. Press the

G

button.

4. Use the

D

/Ebutton to select Fine.

5. Use the

F/G

button to adjust the picture to the desired appearance.

6. Press the menu button to remove menu.

Notes

• To remove the memorized fine tuning setting, reprogram the fine­tuned channel with AUTO PROGRAM or MANUAL PROGRAM.

• If a finely tuned channel is memorized, the color of the channel number
changes to yellow.

13

Auto +program
Manual+program
Favorite+channel

++MOVE+{NEXT+MENU:EXIT

Memory®Erase
Channel TV14
Fine 0

Name

_____

++MOVE+}{

+ADJUST+

Å

BACK

Fine 0

Language English
Key+lock Off
Degauss Off
Caption Off
Tilt 0
Parental +ctl

++MOVE+{NEXT+MENU:EXIT

Language English
Key+lock Off
Degauss Off
Caption Off
Tilt 0
Parental +ctl

++MOVE+{NEXT+MENU:EXIT

Available Features

14

Picture Tilt

The picture on the TV screen may tilt to left or right if the TV is moved
to another direction. Picture Tilt can be used to correct any uneven
picture tilt.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select Tilt.

4. Use the

F/G

button to adjust the Tilt.

5. Press the menu button to remove menu.

Favorite Channel Memory

Favorite channel memory is a convenient feature that lets you quickly
scan up to eight channels of your choice without having to wait for the
TV to scan through all the in-between channels.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2.Press the

G

and then use D/Ebutton to select Favorite

channel

.

3. Press the

G

button to enter the Favorite channel mode.

4. Use the

D

/Ebutton to memorize a favorite channel.

5. Use the

F/G

button to select the desired channel number.

6. Repeat steps 4 to 5.

7. Press the menu button to remove menu.

To select a favorite channel, press fcr repeatedly (Favorite Channel
Review) button. Eight favorite channels programmed appear on the
screen one by one.

Wide / Zoom Picture

You can select the desired picture format (4:3 or 16:9).

1. Use the arc button to select your desired picture format.

• 4:3

Is the standard picture format size.

• 16:9

You can view either the cinema picture format 16:9 or standard

picture format 4:3 in the 16:9 mode.

16:9 is viewed as is, 4:3 image is expanded to the left and right to fill

the 16:9 screen.

Auto +program
Manual+program
Favorite+channel

++MOVE+{NEXT+MENU:EXIT

TV

13

_____

TV

19

_____

TV

17

_____

TV

111

_____

TV

16

_____

TV

12

_____

TV

13

_____

TV

18

_____

++MOVE+}{+ADJUST+ÅBACK

TV113

_____

Language English
Key+lock Off
Degauss Off
Caption Off
Tilt 0
Parental +ctl

++MOVE+{NEXT+MENU:EXIT

Picture Appearance Control

Auto Picture Control

You can select preprogrammed picture modes.

Using the apc Button

1. Press the apc button.

2. Use the apc button to select

Clear, Optimum, Soft or User.

3. Press the enter (

A

) button to remove menu.

VM (V elocity Modulation)

If you select VM High, the TV will automatically enhance the
sharpness of the image's edges.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select VM.

3. Use the

F/G

button to select Low, High or Off.

4. Press the menu button to remove menu.

Color Temperature

Specify the picture color appearance.

Using the Color temp. Button

1. Press the Color temp. button.

2. Use the

Color temp. button to select Neutral, Warm, or Cool.

3. Press the enter (

A

) button to remove menu.

Using the picture appearance menu

1. Press the menu button and then use D/Ebutton to select the

menu shown to the right.

2. Press the

G

and then the use

D

/

E

button to select Color Temp.

3. Use the

F/G

button to select Neutral, Warm, or Cool.

4. Press the menu button to remove menu.

15

+Auto+picture + + +Clear

+Color+Te mp. + + +Neutral

Contrast 100
Brightness 60
Color 60
Sharpness 50
Tint 0
VM High
Color+Temp. 50

++MOVE+}{+ADJUST+ÅBACK

Contrast 100
Brightness 60
Color 60
Sharpness 50
Tint 0
VM Low

Color+Temp. Neutral

++MOVE+}{+ADJUST+ÅBACK

VM High

ColorrTemp. Neutral

Picture Appearance Control

Adjusting the Picture Appearance

This is the function to manually adjust the desired picture levels:

Contrast, Brightness, Color, Sharpness, Tint of the image to your

preference. If the picture settings you adjust are not satisfactory, you
can also select a factory preset picture setup.

1. Press the menu button and then use

D

/

E

button to select the

menu shown to the right.

2. Press the

G

and then use D/Ebutton to select the desired picture

menu option.

3. Press the

G

button.

4. Use the

F/G

button to adjust the level.

The setting of highlighted menu option is displayed.

5. Press the menu button to remove menu.

16

Contrast 100
Brightness 60
Color 60
Sharpness 50
Tint High
VM High
Color+Temp. Neutral

++MOVE+{NEXT+MENU:EXIT

Contrast 100
Brightness 60
Color 60
Sharpness 50
Tint 0
VM High
Color+Temp. Neutral

++MOVE+}{+ADJUST+ÅBACK

Contrast 100

Stereo/SAP Broadcasts Setup

This TV can receive MTS stereo programs and any SAP (Secondary
Audio Program) that accompanies the stereo program, as the system
to be transmitted one additional sound signal as well as the original
one. MTS function doesn't operate in the video mode.

Using the mts Button

1. Use the mts button to select your desired MTS mode.

Each time you press this button, the

MONO, STEREO, or SAP

mode appear in turn.

2. Press the enter (

A

) button.

Notes

• Stereo or SAP can only be received when the TV station transmits

those signals, even though you have selected

STEREO or SAP.

• Mono sound is automatically received if the broadcast is only in

Mono; even though

STEREO or SAP has been selected.

• Select

MONO if you want to listen to mono sound in remote fringe

areas during stereo/SAP broadcasting.

Auto Sound Control

You can enjoy the best sound without any special adjustment because
the TV set automatically adjusts the sound appropriate to viewing
program character.

Using the dasp Button

1. Press thedasp button.

2. Use the dasp button to select

Dolby virtual, Flat, Movie, Music,

Sports or User.

3. Press the enter (

A

) button to remove menu.

Using the Audio Menu

1. Press the menu button and then use D/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use the

D

/

E

button to select DASP.

3. Use the

F/G

button to select Dolby virtual, Flat, Movie, Music,

Sports or User.

4. Press the menu button to remove menu.

Sound Control

17

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

+DASP+ + +++Flat

Adjusting the Equalizer (User Mode In ASC)

1. Press the menu button and then use D/Ebutton to select the
menu shown to the right.

2. Press the

G

and then use

D

/

E

button to select Equalizer.

3. Use the

G

button to select the Equalizer mode.

4. Use the

F/G

button to select the sound band and then use the

D

/

E

button to select the desired level.

5. Press the menu button to remove menu.

Adjusting Balance

1. Press the menu button and then use D/Ebutton to select the
menu shown to the right.

2. Press the

G

and then use

D

/

E

button to select Balance.

3. Use the

F/G

button to adjust the balance level.

4. Press the menu button to remove menu.

AVL (Auto V olume Leveler)

AVL automatically maintains an equal volume level; even if you
change channels.

Using the Audio Menu

1. Press the menu button and then use D/Ebutton to select the
menu shown to the right.

2. Press the

G

and then use

D

/

E

button to select AVL.

3. Use the

F/G

button to select On or Off.

4. Press the menu button to remove menu.

Adjusting the DBS (Dynamic Bass Sound)

1. Press the menu button and then use D/Ebutton to select the
menu shown to the right.

2. Press the

G

and then use

D

/

E

button to select DBS.

3. Use the

F/G

button to select On or Off.

4. Press the menu button to remove menu.

Sound Control

18

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

}{+MOVE++++ADJUST+ÅBACK

0.1

0.5 1.5 5.0 10 kHz

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

Adjusting Bass

This function is to increase or decrease bass.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use

D

/

E

button to select DASP.

3. Use the

F/G

button to select Dolby virtual.

4. Use the

D

/

E

button to select Bass.

5. Use the

F/G

button to adjust the bass level.

6. Press the menu button to remove menu.

Adjusting T reble

This function is to increase or decrease treble.

1. Press the menu button and then use

D

/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use

D

/

E

button to select DASP.

3. Use the

F/G

button to select Dolby virtual.

4. Use the

D

/

E

button to select Treble.

5. Use the

F/G

button to adjust the treble level.

6. Press the menu button to remove menu.

19

Bass 50
Treble 50
Balance 0
DASP Dolby+virtual

++MOVE+}{+ADJUST+ÅBACK

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

Bass 50

Bass 50
Treble 50
Balance 0
DASP Dolby+virtual

++MOVE+}{+ADJUST+ÅBACK

Equalizer
Balance 0
AVL Off
DASP Flat
DBS Off

++MOVE+{NEXT+MENU:EXIT

Treble 50

Closed captioning is a process which converts the audio portion of a television program into written
words, which then appear on the television screen in a form similar to subtitles. Closed captions allow
viewers to read the dialogue and narration of television programs.

Using Closed Captions

Captions are the subtitles of the dialogue and narration of television
programs. For prerecorded programs, program dialogue can be
arranged into captions in advance. It's possible to caption a live
program by using a process called “real-time captioning”, which
creates captions instantly. Real-time captioning is normally done by
professional reporters using a machine shorthand system and
computer for translation into English.
Captioning is an effective system for the hearing-impaired, and it can
also aid in teaching language skills.

• The picture at left shows a typical caption.

Caption Tips

• Not all TV broadcasts include closed caption signals.

• Sometimes TV stations broadcast two different caption signals on the same channel. By selecting from

CC 1 to CC 4, you can choose which signal you view. Mode 1 is usually the signal with the captions,
while another mode 2 might show demonstration or programming information.

• Your TV might not receive caption signals normally in the following situations.
Poor reception conditions are encountered:

An old, bad or illegally recorded tape is played.
Strong, random signals from a car or airplane interfere with the TV signal.
The signal from the antenna is weak.
The program wasn't captioned when it was produced, transmitted or taped.

Closed Caption

A

IGNITION:
Picture may flutter, drift, suffer from black spots or horizontal
streaking. Usually caused by interference from automobile ignition
systems, neon lamps, electrical drills and other electrical
appliances.

A

GHOSTS:
Ghosts are caused when the TV signal splits and follows two paths.
One is the direct path and the other is reflected off tall buildings,
hills or other objects. Changing the direction or position of the
antenna may improve reception.

A

SNOW:
If your receiver is located at the weak, fringe area of a TV signal,
your picture may be marred by small dots. It may be necessary to
install a special antenna to improve the picture.

FOLLOW ME

20

1

2
3
4
5

Using the Text Function

Text services give a wide variety of information on all kind of subjects
(ex. captioned program lists, weather forecasts, stock exchange
topics, news for hearing-impaired---) through the full TV screen.
But not all stations offer text services, even though they might offer
captioning.

Note:In the event you receive a poor signal, an empty black box may

appear and disappear, even when the text mode is selected.
This is a normal occurrence in such an event.

Operating the Caption and Text

Using the Caption Button

1. Press the caption button.

2. Use the caption button to select

Off, Mode 1~4,or Text 1~4.

3. Press the enter (

A

) button to remove menu.

Using the Menu

1. Press the menu button repeatedly until the menu is displayed as

shown to the light.

2. Press the G and then

D/E

button to select Caption.

3. Use the

F/G

button to select Off, CC 1~4,or Text 1~4.

4. Press the menu button to remove menu.

Note:This TV is programmed to remember which mode it was last set

to, even if you turn the TV off.

21

Language English
Key+lock Off
Degauss Off
Caption Off
Tilt 0
Parental +ctl

++MOVE+{NEXT+MENU:EXIT

Language English
Key+lock Off
Degauss Off

Caption Off
Tilt 0
Parental +ctl

++MOVE+}{+ADJUST+ÅBACK

Caption Off

+Caption+ + +++Off

The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the
broadcast station. The default setting is to allow all programs to be viewed. Viewing can be blocked by
the type of program and by the categories chosen to be blocked. It is also possible to block all program
viewing for a time period. To use the Parental Control Function, the following must be set.

1. Ratings and categories to be blocked.

2. Number of hours to lock the television viewing control.

3. Set a password.

4. Enable the lock.

V-Chip Rating and Categories

Rating guidelines are provided by broadcast stations. Most television programs and television movies can
be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or
direct-to-video movies use the Movie Rating System (MPAA) only.

For Movies Previously Shown in Theaters
Movie Ratings:

• Unblocked

• G and Above (general audience)

• PG and Above (parental guidance suggested)

• PG-13 and Above (13 years and up)

• R and Above (restricted)

• NC-17 and Above (18 years and up)

• X (adult)

If you set PG-13 and Above, G and PG movies will be available; PG-13, R, NC-17, and X will be blocked.

For Television programs including made-for-TV movies:
General TV Ratings:

• Unblocked

• TV-G and Above (general audience) (individual categories do not apply)

• TV-PG and Above (parental guidance suggested)

• TV-14 and Above (14 years and up)

• TV-MA (mature audience)

Children TV Ratings:

• Unblocked

• TV-Y and Above (youth) (individual content categories do not apply)

• TV-Y7 (youth, 7 years and up)

Content Categories:

• Dialog - sexual dialogue (applies to TV-PG and Above, TV-14)

• Language - adult language (applies to TV-PG and Above, TV-14 and Above, TV-MA)

• Sex scenes - sexual situations (applies to TV-PG and Above, TV-14 and Above, TV-MA)

• Violence (applies to TV-PG and Above, TV-14 and Above, TV-MA)

• F Violence - fantasy violence (applies only to TV-Y7)

• No Rating (blocks all viewing)

Parental Control

22

Blocking Setup

1. Press the MENU button and then use D/Ebutton to select the

menu shown to the right.

2. Press the

G

and then use the

D

/

E

button to select Parental ctl.

3. Press the

G

button.
If Parental is already set, enter the password when requested.
Age block and Content block options, also have sub menus; repeat
steps 3 to 4 in sub menu, to set type of blocking and rating.

4. Use the

D

/

E

buttons to select the types of blocking to be set. Use

the

F/G

buttons to select the types of ratings to block.

MPAA, Age, and/or Content block may be set.

Press the menu button to return from

Age block or Content

block

.

5. Use the

D

/

E

buttons to select the Set hours.

Use the

F/G

buttons to set the number of hours for the blocking.
(Up to 99)
Use the

D

/

E

buttons to select the Set password option. Enter a
four digit password. Enter it again when requested.
A new password may be chosen each time blocking is set up.

6. Use the

D

/

E

buttons to select the Lock on/off menu option. Use

the

F/G

buttons to turn the lock On. Press the menu button to save

the blocking setups and exit.

23

MPAA Unblocked
Age+block
Content+blk
Set+hours

}{+

00+Hours

Set+password

}{+

To +set

Lock+on ®off Must+set+hours

++MOVE+}{+ADJUST+ÅBACK

Language English
Key+lock Off
Degauss Off
Caption Off
Tilt 0
Parental +ctl

++MOVE+{NEXT+MENU:EXIT

MPAA Unblocked

Antenna Connections

24

Connecting an Outdoor Antenna

For the best reception, we recommend you use an outdoor antenna.
Severely weathered antennas and antenna cables can reduce the signal quality. Before making any
connections, inspect all antenna hardware. Any service center can explain the various outdoor antennas
available to you.

Connecting a CATV Cable

If you subscribe to a CATV system, make the antenna connection as described below.

1. Remove the 300 to 75 ohm adapter or the cable from the TV, if attached.

2. Connect the CATV cable (75 ohm coaxial cable) to the 75 ohm antenna jack.

300 Ohm Flat Wire

1. Connect the 300 ohm flat wire to the screws on
the 300 ohm to 75 ohm adapter.

2. Push the end of 300 ohm to 75 ohm adapter
onto the 75 ohm antenna jack.

75 Ohm Coaxial Cable

1. Connect the 75 ohm coaxial cable directly to
the 75 ohm antenna jack.

75 ohm
Antenna Jack

from cable TV source

Combination
VHF/UHF Antennas

300 ohm
Flat Wire

300 to 75
ohm Adapter

75 ohm
CATV Cable

75 ohm
Antenna
Jack

75 ohm
Coaxial
Cable

75 ohm CATV Cable

300 to 75
ohm Adapter

300 ohm Flat Wire

300 to 75 ohm
Adapter

1.

2.

TV rear

You can connect additional equipment, such as VCRs, camcorders etc. to your TV.
Connection panels shown here may be somewhat different from your TV.

Here is an example drawing of a typical jackpack layout.

1. IN 1 JACKS : Connect external equipment outputs (VCR, LASER DISC, CAMCORDER) to these
inputs. Use the TV/VIDEO button to select

VIDEO-1.

2. IN 2 JACKS : Connect external equipment outputs (VCR, LASER DISC, CAMCORDER) to these
inputs. Use the TV/VIDEO button to select

VIDEO-2.

3. IN 3 JACKS : Connect external equipment outputs (VCR, LASER DISC, CAMCORDER) to these
inputs. Use the TV/VIDEO button to select

VIDEO-3.

4. OUT JACKS: Connect external equipment inputs (VCR, Audio amplifier) to these outputs for recording
or monitoring the selected program.

5. §/ EARPHONE JACK

Note:This TV is programmed to remember which mode it was last set to, even if you turn the TV off.

External Equipment Connections

Connecting AUDIO/VIDEO IN Jacks

1. Connect the audio/video output jacks of the VCR to
IN 1 or IN 2(A/V) jacks on the back of TV.
If you connect the video jack only, you can't hear the
sound from the TV.

2. Use the TV/VIDEO button to select

VIDEO-1 or

VIDEO-2.

Note: If you connect the audio/video output jacks of

the VCR to the IN 3(A/V) jacks on the side of
the TV, select

VIDEO-3.

3. Press the PLAY button on the VCR.
The video playback appears on the TV screen.

Note: If using a monaural VCR, connect the output jack of VCR to the AUDIO L/MONO IN jack of TV so

that the sound can be heard from both speakers. If you connect it to the AUDIO R IN jack of TV,
the sound is heard only from right speaker.

25

OUT

IN1

AUDIO

(L/MONO) (R)

VIDEO

TV

TV

Playback VCR

OUT

IN1

AUDIO

(L/MONO) (R)

VIDEO

COMPONENT

DVD IN(480i)

Y

PB PR

IN2

VIDEO (L/MONO) (R)VIDEO

1

4

2

EARPHONE

VIDEO

AUDIO

S-VIDEO

L/MONO

R

IN 3

3

5

VIDEO

L/MONO

AUDIO

R

IN 3

External Equipment Connection and Setup

26

S-VHS VCR Connection

1. Connect the S-VHS output jack of the VCR to the
S-VIDEO jack on the side of the TV.

2. Connect the audio/video output jacks of the VCR
to the IN 3(A/V) jacks on the side of the TV.

3. Use the TV/VIDEO button to select

VIDEO-3.

Note: If you connect the S-VHS/audio output jacks

on the VCR to the S-VIDEO jack and IN 1 or
IN 2 audio jacks on the back of the TV, select

VIDEO-1 or VIDEO-2.

4. Press the PLAY button on the VCR.
Video playback is visible on the TV screen.

VCR Recording Setup for TV
Programs

1. Connect the audio/video input jacks of the
recording VCR to the OUT (A/V) jacks on the TV
connection panel.

2. Select the channel number on the TV.

3. Set the recording VCR to record.

VCR Recording Setup for a VCR

1. Connect the output jacks of the playback VCR
to the IN 1 or IN 2 (A/V) jacks on the back of
the TV (or IN 3 jacks on the side of TV ).

2. Connect the input jacks of the recording VCR
to the OUT (A/V) jacks on the back of the TV.

3. Use the TV/VIDEO button to select

VIDEO-1 or

VIDEO-2.

If you connect it to the IN 3 (A/V) jacks on the
side of TV, you should select

VIDEO-3.

4. Press the PLAY button on the playback VCR
and set the recording VCR to record.

Note: When the input jacks on the front panel and back panel are connected to

external equipment at the same time, the input jacks on the front panel have priority over the
input jacks on the back panel of the TV.

OUT

IN1

AUDIO

(L/MONO) (R)

VIDEO

Recording VCR

Recording VCR

TV

TV

TV

Playback VCR

Playback VCR

VIDEO

AUDIO

S-VIDEO

L/MONO

R

IN 3

OUT

AUDIO

(L/MONO) (R)

VIDEO

IN1

DVD Player Connection and Setup

27

• Connect component video inputs to Y, PB, PR(480i) and audio IN2 to audio (L/R) inputs.

•

Note: This TV is programmed to remember which mode it was last set to, even if you turn the TV off.

1. How to connect

DVD Connection Panel

Note:

2. How to use

• Turn on the DVD.

• Turn the TV on and use the TV/VIDEO button on the remote control or TV/VIDEO

button on the front panel to select

COMPONENT.

• Press PLAY on the DVD, see DVD operation manual.

AUDIO

PB PRY (R) (L)

Y

IN2

PB PR

DVD IN (480i)

VIDEO

(L/MONO) AUDIO(R)

COMPONENT

TV Connection Panel

TV INPUT

Y PBP

R

DVD OUTPUT

Cb

B -Y

Pb
P

B

Cr

R -Y

Pr

P

R

Y
Y
Y
Y

Product Specifications

28

Model

C27F33 Horizontal size (inches) 32.7

Height (inches) 23.6
Thickness (inches) 20
Weight (pounds) 116.8

C32F33 Horizontal size (inches) 35.3

Height (inches) 26.9
Thickness (inches) 21.5
Weight (pounds) 174.2

Power requirements AC 120 V
Television system NTSC
Television channels VHF : 2 ~ 13, UHF : 14 ~ 69

Cable : 01 ~ 125

Power consumption See the back of the TV
External antenna impedance 75 Ω
Audio output 7W + 7W
Speaker outputs 8 Ω X 2
External input ports Video input jacks 3 sets

Video output jacks 1 set
S-video input port 1 set
Component input jacks 1 set
Earphone jack (1)

Maintenance

29

Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of
time you will have with your new TV. Be sure to turn the power off and pull out the plug before
you begin any cleaning.

1. Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth
in a mixture of lukewarm water and a little fabric softener or dish washing
detergent. Wring the cloth until it’s almost dry, and then use it to wipe the
screen.

2. Make sure the excess water is off the screen, and then let it air-dry before you
turn on your TV.

1. Use a soft cloth with a mild soap solution to wipe the cabinet.

2. Rinse the cloth and wipe the cabinet again.

3. Let the cabinet air-dry before turning the TV on.

If you leave your TV dormant for a long time (such as a vacation), it’s a good idea
to unplug the power to protect against possible damage from lightning or power
surges. If you use an off-air antenna, you may also want to disconnect it from the
back of your TV before leaving.

Screen Cleaning

Cabinet Cleaning

Extended Absence

T roubleshooting Checklist

SYMPTOMS

No power

No picture or sound

Poor picture but good sound

Poor reception

Lines in picture

Ghosts (multiple images)

Remote control does not work.

Cannot tune desired channel.

CHECK THESE THINGS

Is power cord plugged in?
Is television turned on?

Check batteries in remote control.
Try another channel (station trouble).

Check antenna connectings.
Check for local interference.

Adjust the antenna.
Adjust the picture control.

Program channel using AUTO
PROGRAM.

30

Notes

31

P/N : 3828VA0343G (MC022A)

206-03834

ZENITH ELECTRONICS CORPORATION
Direct-View TV Limited Warranty - USA

Zenith will repair or replace your product, at Zenith’s option, if it proves to be defective in material or
workmanship under normal use, during the warranty period (“Warranty Period”) listed below, effective from the
date (“Date of Purchase”) of original consumer purchase of the product. This warranty is good only to the
original purchaser of the product and effective only when used in the United States, excluding U.S. Territories.

THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN
DURATION TO THE EXPRESSED WARRANTY PERIOD ABOVE. ZENITH WILL NOT BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL OR PUNITIVE DAMAGES OF ANY NATURE, EVEN
IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, INCLUDING WITHOUT LIMITATION, LOST
REVENUES OR PROFITS, LOST OR CORRUPTED PROGRAMMING OR DATA, OR ANY OTHER DAMAGE
WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. Some states do not allow the exclusion or

limitation of incidental or consequential damages or limitation on how long an implied warranty lasts, so the
above exclusion or limitation may not apply to you. This warranty gives you specific legal rights and you may
also have other rights that may vary from state to state.

THIS LIMITED WARRANTY DOES NOT APPLY TO:

1. Damages or operating problems that result from shipping, installation, adjustment of user controls,
calibration, maintenance or failure to maintain, or separate system components; and

2. Damages or operating problems that result from normal wear and tear, misuse, abuse, operation outside
environmental specifications or contrary to the requirements or precautions in the Operating Guide, accident,
lightning strikes or other natural causes, unauthorized modification or alteration, incorrect electrical current or
voltage, reception problems caused by inadequate home antenna or faulty antenna connections, computer
software, institutional or commercial use, or other causes not arising out of defect in material or
workmanship.

3. Therefore, the cost of repair or replacement of such a defective product shall be borne by the

consumer.

CUSTOMER INTER-ACTIVE CENTER NUMBERS:

WARRANTY PERIOD:

LABOR: 90 days from the Date of Purchase.

Parts: One year from the Date of Purchase.

Picture Tube: Two years from the Date of

Purchase.

* Parts replaced are warranted for the remaining

portion of the original warranty period.

HOW SERVICE IS HANDLED:

In-Home Service: Please retain dealer’s dated bill of sale

or delivery ticket as evidence of the Date of Purchase for
proof of warranty, and submit a copy of the bill of sale to
the service person at the time warranty service is provided.

Please call 1-877-9Zenith (1-877-993-6484) to locate
your nearest Zenith Authorized Service Center.

Replacement parts may be new or factory remanufactured.

Call 1-877-9Zenith (1-877-993-6484) (Monday~ Friday,
7 AM ~ 8 PM CT and Saturday, 8 AM ~ 5 PM CT) and select
appropriate option from the menu.

Or visit our website at http://www.zenithservice.com

For nearest Authorized Service Center,
Where to buy, Product Assistance, or
Customer Assistance
