enjoy the view
operating guide / warranty
hookup directory
page
5
Copyright 2000, Zenith Electronics Corporation.
machine numbers: C25A24T C27A24T
RECORD YOUR MODEL NUMBER
(Now, while you can see it)
The model and serial number of your new TV are located
on the back of the TV cabinet. For your future convenience,
we suggest that you record these numbers here:
MODEL NO.____________________________________
SERIAL NO.____________________________________
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
POWER CORD POLARIZATION:
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
NOTE TO CABLE/TV INSTALLER:
This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code
(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of the cable entry as practical.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation.
Unauthorized modification could void the user’s authority to operate this product.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Entertainment Machine is a trademark of Zenith Electronics Corporation.
206-3588
PAGE 3
IMPORTANT SAFETY INSTRUCTIONS
Important safeguards for you and your new product
Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential
electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read
and observe the following safety points when installing and using your new product, and save them for future reference.
Observing the simple precautions discussed in this booklet can help you get many years of enjoyment and safe operation
that are built into your new product.
This product complies with all applicable U.S. Federal safety requirements, and those of the Canadian Standards Association.
(Continued on next page)
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Follow Instructions
All operating and use instructions should be followed.
3. Retain Instructions
The safety and operating instructions should be retained
for future reference.
4.Heed Warnings
All warnings on the product and in the operating instructions should be adhered to.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6. Water and Moisture
Do not use this product near water - for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool.
7.Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the
product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting
accessory recommended by the manufacturer.
8. Transporting Product
A product and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
9. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
10. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not
be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in
a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other
sources, refer to the operating instructions.
12. Line-Cord Polarization
This product is equipped with a polarized alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
13. Power-Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they
exit from the product.
PORTABLE CART WARNING
206-3588
(Continued from previous page)
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National
Electrical Code (U.S.A.), ANSI/ NFPA 70 provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
15. Lightning
For added protection for this product (receiver) during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
16. Power Lines
An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be
fatal.
17. Overloading
Do not overload wall outlets and extension cords as this
can result in a risk of fire or electric shock.
18. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
19. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service
personnel.
20. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following
the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation.
e. If the product has been dropped or the cabinet has
been damaged.
f. If the product exhibits a distinct change in performance.
21. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
22. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
24. Heat
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
PAGE 4
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
Ground Clamp
Electric Service
Equipment
Example of Grounding According to National Electrical
Code Instructions
NEC - National Electrical Code
IMPORTANT SAFETY INSTRUCTIONS
206-3588
PAGE 5
Hook-Up Directory
IMPORT
ANT!!
Use this page to decide where you need to begin your setup. First, find the line below that best
describes what you want to do, then go to that page number.
Cable TV
wall jack
Cable box
In
Out
Cable TV
wall jack
Cable box
In
Out
If you are using an antenna and no other equipment, go to . . . . . . . . . . . . . . . . . . page 6
If you have cable service or a cable box and no other equipment, go to . . . . . . . . . . page 7
If you are using an antenna and have a VCR, go to . . . . . . . . . . . . . . . . . . . . . . . page 8
If you have cable service or a cable box and a VCR, go to . . . . . . . . . . . . . . . . . . . . page 9
Antenna only
Cable only
Antenna with VCR
Cable and VCR
206-3588
Mini glossary
75 OHM RF CABLE The wire that comes from an off-air antenna or cable service provider. Each end looks like a hex shaped nut with a wire
sticking through the middle, and it screws onto the threaded jack on the back of your Entertainment Machine.
300 TO 75 OHM ADAPTER A small device that connects a two-wire 300 ohm antenna to a 75 ohm RF jack. They are usually about an
inch long with two screws on one end and a round opening with a wire sticking out on the other end.
PAGE 6
Hook Up Your Antenna to the TV
If you have a 75 ohm RF cable,
then you don’t need any
adapters!
Remember, when screwing RF
cables onto jacks, clockwise
tightens, and counterclockwise
loosens.
Locate the Antenna/Cable jack on
the back of your Entertainment
Machine.
Connect the cable that runs from
the wall directly to this jack,
according to the diagram to the
right.
Remove the back of the remote
and put in two AAA batteries.
Plug in your Entertainment
Machine. Do not plug it into a
switched outlet. Your
Entertainment Machine is
designed to operate on household
current, 120-volt 60 Hertz AC do
not attempt to operate it on DC
Current.
Go to page 12 to EZ Program your
Entertainment Machine.
1
2
3
4
5
back of
remote
Flat wire antenna to
Entertainment Machine
Connect an antenna to your Entertainment Machine.
Antenna to
Entertainment Machine
206-3588
Antenna
Flat wire
(300 ohm)
Antenna
TV back
Antenna
/Cable
300/75 ohm
Adapter
TV back
S-Video
Variable
Audio Out
R
Video
R-Audio
L/Mono
TV back panel
(expanded view)
L
RF coaxial wire
(75ohm)
Antenna
/Cable
S-Video
Variable
Audio Out
R
Video
R-Audio
L/Mono
TV back panel
(expanded view)
L
Locate the Antenna/Cable jack on
the back of your Entertainment
Machine.
Connect the cable that runs from
the wall directly to this jack,
according to the diagram to the
right.
Remove the back of the remote
and put in two AAA batteries.
Plug in your Entertainment
Machine. Do not plug it into a
switched outlet. Your
Entertainment Machine is
designed to operate on household
current, 120-volt 60 Hertz AC do
not attempt to operate it on DC
Current.
Go to page 12 to Auto Program
your Entertainment Machine.
Mini glossary
CABLE SERVICE The wire that supplies all your cable TV (CATV) stations.
If you’re using a cable box, leave your TV on
channel 3 or 4 and use your cable box to change
channels.
Remember, when screwing RF cables onto jacks,
clockwise tightens, and counterclockwise loosens.
If you’re using a cable box, Auto- Program might
only find the channel your cable service is on (usually channel 3 or 4). Don’t worry, that’s all you
need!
Hook Up Your Cable Service (CATV)
Cable TV
wall jack
Cable TV
wall jack
Cable box
In
Out
RF coaxial wire (75ohm)
RF coaxial wire (75ohm)
3 4
output
switch
TV back panel
(expanded view)
TV back
TV back panel
(expanded view)
TV back
Antenna
/Cable
Video
R
L
R-Audio
L/Mono
S-Video
Variable
Audio Out
Antenna
/Cable
Video
R
L
R-Audio
L/Mono
S-Video
Variable
Audio Out
1
2
3
4
5
PAGE 7
Connect cable service to your Entertainment Machine.
With
out Cable Box
With Cable Box
206-3588
back of
remote
PAGE 8
Hook Up Your Antenna and VCR
If you have a 75 ohm RF cable,
then you don’t need any adapters!
Remember, when screwing RF
cables onto jacks, clockwise tightens, and counterclockwise loosens.
Locate the Antenna/Cable jack on
the back of your Entertainment
Machine.
Connect the cable that runs from
the wall directly to this jack,
according to the diagram to the
right.
Remove the back of the remote
and put in two AAA batteries.
Plug in your Entertainment
Machine. Do not plug it into a
switched outlet. Your
Entertainment Machine
TM
is
designed to operate on
household current, 120-volt 60
Hertz AC do not attempt to
operate it on DC Current.
Go to page 12 to Auto Program
your Entertainment Machine.
1
2
3
4
5
Connect an antenna to your Entertainment Machine.
back of
remote
TV back panel
(expanded view)
TV back
In
Out
VCR back
VCR back AV panel
In
Out
VCR back
VCR back AV panel
TV back panel
(expanded view)
TV back
Flat wire
(300 ohm)
Antenna
300/75 ohm
Adapter
Round wire (75ohm)
Antenna
RF coaxial wire
(75ohm)
not included
with TV
RF coaxial wire
(75ohm)
not included
with TV
A/V cables
not included
with TV
A/V cables
not included
with TV
Antenna
/Cable
Video
RL
R-Audio L/Mono
S-Video
Variable
Audio Out
Antenna
/Cable
Video
RL
R-Audio L/Mono
S-Video
Variable
Audio Out
output
switch
Audio
Video
Output
R
L
output
switch
Audio
Video
Output
R
L
3 4
3 4
VCR with Flat Wire
An
tenna Adapter
VCR
with
Antenna Wire
206-3588
PAGE 9
Hook Up Your Cable (CATV) and VCR
Leave your VCR and your television
tuned to channel three and use
the cable box to change channels.
Remember, when screwing in RF
cables onto jacks, clockwise
tightens and counterclockwise
loosens.
Without A/V cables, most VCRs will
not play videocassettes in stereo
sound.
Cable TV
wall jack
Round wire (75ohm)
TV back panel
(expanded view)
TV back
In
Out
VCR back
VCR back AV panel
RF coaxial wire
(75ohm)
not included
with TV
A/V cables
not included
with TV
3 4
output
switch
Antenna
/Cable
Video
RL
R-Audio L/Mono
S-Video
Variable
Audio Out
Audio
Video
Output
R
L
Cable TV
wall jack
Round wire (75ohm)
Cable box
In
Out
In
Out
VCR back
VCR back AV panel
TV back panel
(expanded view)
TV back
RF coaxial wire
(75ohm)
not included
with TV
3 4
output
switch
A/V cables
not included
with TV
Antenna
/Cable
Video
RL
R-Audio L/Mono
S-Video
Variable
Audio Out
Audio
Video
Output
R
L
3 4
output
switch
Locate the Antenna/Cable jack on
the back of your Entertainment
Machine.
Connect the cable that runs from
the wall directly to this jack,
according to the diagram to the
right.
Remove the back of the remote
and put in two AAA batteries.
Plug in your TV. Do not plug it
into a switched outlet. Your
Entertainment Machine is
designed to operate on household
current, 120-volt 60 Hertz AC do
not attempt to operate it on DC
Current.
Go to page 12 to Auto Program
your Entertainment Machine.
1
2
3
4
5
Connect cable service and a VCR to your
Entertainment Machine.
back of
remote
VCR Without Cable Box
VCR With Cable Box
206-3588
PAGE 10
Hook Up Your TV to a Super VHS VCR
Connecting an S-VHS player to your Entertainment Machine.
1
2
3
Locate the S-Video Out to TV jack on the
back of your S-VHS VCR. Connect the SVHS cable directly to this jack.
Connect this cable from the Out to TV
jack to the S-Video jack on the back of
your TV.
Find the audio and S-Video jacks on the
back of S-VHS player and connect them
following the instructions provided with
your equipment.
No S-Video cables are included with your
Zenith Entertainment Machine but they
can be purchased in most consumer
electronics stores. Without an S-Video
cable, you will not receive the Super VHS
quality picture.
206-3588
Antenna
/Cable
S-Video
Video
TV back
Variable
Audio Out
RL
R-Audio L/Mono
S-Video cable
not included
with TV
TV back panel
(expanded view)
VCR back
VCR back AV panel
output
S-Video Out
A/V cables
not included
with TV
switch
Audio Out
3 4
R L
Hook Up Your TV to a Stereo Amplifier
PAGE 11
Connecting your Entertainment Machine to a stereo amplifier.
1
2
For added audio depth and clarity, you can connect your Entertainment Machine to
a stereo amplifier.
Locate the Left/Right Audio Input jacks
on the back of your stereo amplifier.
Connect the Audio cables directly to
these jacks.
Connect these cables from the Left/Right
Variable Audio Input jacks to the
corresponding Left/Right jacks on the
back of your TV.
Audio Input
Stereo back
Stereo Amplifier back panel
TV back panel
(expanded view)
TV back
A/V cables
not included
with TV
Antenna
/Cable
Video
RL
R-Audio L/Mono
S-Video
Variable
Audio Out
RL
No Audio cables are included with your
Zenith Entertainment Machine but they
can be purchased in most consumer
electronics stores.
206-3588
Mini glossary
EZ PROGRAM EZ Program is how your Entertainment Machine finds all the channels available in your area and stores them into memory.
1
2
3
4
5
6
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
4/6
2
7
1
3/5
EZ Program
Use EZ Program to
automatically find and store
all of the stations available
in your area.
ANTENNA:
If your signal
source is an indoor/outdoor
antenna.
CABLE: If you get your signal
from a cable service.
With the remote control in hand, press the POWER button
to turn on your Entertainment Machine.
Press the MENU key so the Setup menu appears.
Using the UP/DOWN arrows on the remote control,
select EZ Program on your screen.
Press a RIGHT or LEFT arrow to reach the EZ Program screen.
Using the UP/DOWN arrows, choose either Cable TV or
Off-Air Antenna on your screen.
When you have made your selection, press a RIGHT or LEFT
arrow to begin EZ Program.
Press ENTER to return to TV viewing.
7
PAGE 12
If you are receiving your signal from an
antenna, select Antenna in the EZ Program
menu when it appears on screen. If you
have cable service, select Cable.
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
To Program
206-3588
PRG (PROGRAM)
Programs your remote to
operate other products.
FLASHBK (FLASHBACK)
Return to the
last channel viewed.
POWER
Turns TV On or Off
.
CABLE/VCR/AUX/TV
Selects remote operating mode.
CHANNEL (UP/DOWN)
Flip through
available channels.
MUTE
Turns sound Off and On
while the picture remains.
Press once to quiet sound, press
again to mute, press again to
restore sound.
ENTER
Shows the Channel/Time
display. Press after channel
numbers for instant selection.
NUMBER KEY PAD
Selects channels directly and
enters numeric values for
some options
.
MENU
Displays on-screen
menus for TV mode.
UP/DOWN ARROWS
The Up/Down arrows select options.
remote control part number
MBR3447CT
(124-233-04)
TIMER
Displays the Sleep
Timer Menu.
VOLUME LEFT/RIGHT
Adjusts the sound levels on
your Entertainment Machine.
QUIT
Removes on-screen display from
view.
TV/VCR-SOURCE
Switches between watching TV
through your antenna/cable or
through your VCR.
Keys dedicated to VCR
functions will still operate
your VCR while the remote
is in TV mode.
CC(CLOSED CAPTIONING)
Displays the closed caption menu.
LEFT/RIGHT ARROWS
The Left/Right arrows
adjust options.
LED INDICATOR LIGHT
Lights when keys are pressed.
SURF
When active,
it will “surf” through the favorite
channels you have selected in your
Entertainment Machine
.
PAGE 13
The Buttons on Your Remote
A quick list of all of the buttons on the remote and what they do.
206-3588
PRG
CABLE
VCR
SURF
FLASHBK MUTE
CHANNEL
VOLUME VOLUME
CHANNEL
123
456
7
0
MENU
A
B
RECORD
PAUSE TIMER
REWIND FFWD
PLAY
STOP
POWER
AUX TV
89
ENTER
QUIT
CC
C
TV/VCR
SOURCE
PAGE 14
Front Panel Diagram
menu
channel
volume
power
menu
channel
volume
power
To access the on screen menus, press the MENU button
repeatedly on the front panel.
Choose the menu and then the function you wish to change
using the CHANNEL UP/DOWN buttons. The Channel buttons
act as a “select” (Up/Down) function.
The VOLUME buttons act as an “adjustment” (Left/Right)
function. Use the VOLUME buttons to make changes or
adjustments.
Menus disappear after five seconds.
To get them back, push the MENU
button again.
1
2
3
1
When using the on-screen menus, the buttons on the front panel
of these models correspond to the remote control buttons
as follows:-
VOLUME = Adjust Left/Right
CHANNEL = Select Up/Down
2
There are three different front panel button styles used with this Operating Guide. Select the front
panel that resembles the Entertainment Machine you are using and learn what each button operates
and controls.
Six Button Front Panel
enter adjust select menu volume channel power
Ten Button Front Panel
ent
adj
sel
menu
vol
ch
power
To access the Setup menu, press
the MENU button repeatedly until
the Setup Menu appears on
screen.
Press the Select button to choose
the function you wish to change.
Use the ADJUST buttons to make
changes or adjustments.
Press the Enter button to clear
the screen.
The Volume and Channel rocker
buttons control Volume Up/Down
and Channel Up/Down only.
1
2
3
4
1
4
3
5
2
4
3
2
1
3
206-3588
On some models, the A/V input is designated as a channel that is one
below the lowest/one above the highest.
You’ll have to use the Channel Up/Down buttons or the Source Menu
display (see page 30)to access it. The Time/Channel display will read
“Video” in place of a channel number.
Cable/Antenna Input: This setting allows you to change cable or
antenna channels and to view videocassettes on channel 3 (or 4)
in mono sound.
Video Input: This setting allows stereo playback of videocassettes. The
television cannot change channels in the Video mode, but the VCR can.
To view the current input source, press ENTER on your remote.
The Time/Channel display should appear in the upper right
hand corner of the screen. If the display reads ‘Video,’ then the
source is an A/V input. If the display reads a channel number,
then the source is your Cable or Antenna.
CHANNEL UP/DOWN arrows: Use these arrows to change the channels.
Auto program will have found all channels available to you.
NUMBER Key Pad: To skip to any channel, enter the number of the
channel using the NUMBER key pad, then press ENTER.
FLASHBACK: To instantly return to the last channel viewed,
press FLASHBACK.
Volume Right/Left: To adjust the volume level, use the volume
Right/Left arrows.
Press MUTE.toquiet the sound (Soft Mute).
Press MUTE a second time to remove the sound entirely (MUTE).
Press MUTE a third time to restore the sound.
PAGE 15
Basic Television Operation
Channel Changing
Audio
CH 12
10:55 AM
MONO
Channel or Video
(Indicates Source)
Time
Audio Mode
Source
Introducing you to the basics of your Entertainment Machine.
206-3588
PAGE 16
Setup Menu
Function What it does
Setup Adjust the basic chacateristics of your
Entertainment Machine.
EZ Program Automatically finds and stores active channels to flip
through using Channel Up/Down.
Add/Del/Surf Manually pick and choose which active channels will
appear when flipping through using Channel Up/Down.
Use the Surf feature to select just the channels you
wish to have on your favorite channel scan.
Clock Set Sets the current time on your Entertainment Machine.
Captions Switches the Captions feature On and Off and EZ Mute.
Captions/Text Displays closed captions or text when available.
Options are Caption 1, Caption 2, Caption 3, Caption
4, Text 1, Text 2, Text 3,
and Text 4.
Language Selects language for on-screen menus. Your options
are English, Spanish, or French.
Special Features Customize your Entertainment Machine’s functions.
EZ Timer Program a time for your Entertainment Machine to
turn itself on or off, or to turn itself off after a certain amount of time.
Ch. Labels Label your channels with their network names (ABC,
CBS, NBC, etc.).
XDS Display Extended Data Service displays Channel, Time, and
Network Label, (Data is provided at the sole discretion
of the broadcaster).
Parental Controls Use V-Chip technolgy to block channels according to
ratings.
EZ Demo Your Entertainment Machine will show you what it’s
capable of by running through all of its options and
menus automatically.
Audio Menu Customize the sound to suit your room and your taste.
Your options are: Bass, Treble, Balence, Audio Mode,
Front Surround, EZ SoundRite, Speakers, and EZ Sound.
Video Menu Adjust your picture for any viewing situation. your
options are: Contrast, Brightness, Color, Tint,
Sharpness, Color Temperature, and EZ Picture.
Source Menu Choose from the available sources for the min picture.
12
17
18
19
20
21
22
23
24
25
27
28
29
30
Go to page
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
To Program
This is an example of what
on-screen menus look like.
Here are descriptions of the menu options found in the Setup menu.
206-3588
1
2
3
4
5
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
5
2
4
1
3
PAGE 17
Setting Add/Del/Surf
Customize your channel selection.
Press the MENU key on the remote so the Setup menu appears.
Select theAdd/Del/Surf menu using the UP/DOWN arrows.
Using either the NUMBER key pad or the CHANNEL UP/DOWN
arrows on the remote, select a channel. (If adding a deleted
channel, you will need to use the NUMBER key pad.)
Using the RIGHT/LEFT arrows, select either Add, Surf or
Delete for that particular channel.
To continue, select another channel and repeat step 4.
If you are finished, press ENTER to return to TV viewing.
You can add or delete a channel without the remote control.
Please refer to page 14 on working the menus with the
buttons on the front of your Entertainment Machine.
If you delete a channel, it isn’t gone for good. Just select it
using the NUMBER key pad on the remote or add it later.
Mini glossary
ADD This function lets you add new channels to the list that you'll scroll through when using your remote.
DELETE This function lets you remove channels that you don't watch from the list you'll scroll through.
SURF This function creates a customized list of your favorite channels.
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
Ch 9 Added
206-3588
1
2
3
4
5
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
5
2
4
1
3
PAGE 18
Clock Set
Set the clock on your Entertainment Machine.
Press the MENU key on the remote control so that
the Setup menu appears onscreen.
Using the UP/DOWN arrows on the remote control,
select Clock Set on your screen.
Press a RIGHT or LEFT arrow to adjust the time or enter
the time using the digits on the remote control.
Press the FLASHBK button to select AM or PM.
Press ENTER to return to TV viewing.
You can use the NUMBER key pad to simply insert the time
(AM or PM is selected with the Flashback key).
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
8:55 AM
FLSHBK
206-3588
1
2
3
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
EZ Mute
3
2
4
1
PAGE 19
Captions
Turn the captions feature on your
Entertainment Machine on or off.
Press the MENU key on the remote control
so that the Setup menu appears.
Using the UP/DOWN arrows on the remote control,
select Captions on your screen.
Press a RIGHT/LEFT arrow to switch the captions
feature on, off or EZ Mute.
Press ENTER to continue.
4
Use the captions feature when you have to listen
to a phone call and still want to follow what’s
happening on your favorite show.
206-3588
Press the MENU key on the remote control so that the Setup
menu appears.
Using the UP/DOWN arrows on the remote control,
select Captions/Text on your screen.
Press a RIGHT/LEFT arrow to choose any of the following
options: Caption 1, Caption 2, Caption 3, Caption 4,
Text 1, Text 2, Text 3 or Text 4.
Press ENTER to return to TV viewing.
1
2
3
4
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
Caption 1
4
1
2
3
PAGE 20
Select closed captioning or text that
appears at the bottom of your screen.
Captions / Text
Captions come in handy when the television
is on mute.
Standard Closed Captioning is
available using the Caption 1 option.
Not all programming has closed captioning
or text available.
206-3588
Press the MENU key on the remote control so that
the Setup menu appears.
Using the UP/DOWN arrows on the remote control,
select Language on your screen.
Press a RIGHT/LEFT arrow to choose any of the following options: English, Spanish,
or French.
Press ENTER to return to regular TV viewing.
1
2
3
4
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Setup Menu
EZ Programac
Agr/Bor/Surf
Ajuste Reloj
Subtít
Subtít/Texto
Language
Spanish
4
1
2
3
PAGE 21
Language Options
Choose the language you want all of the
menus to appear in.
206-3588
EZ Timer, Sleep Timer Setup
Press the MENU key repeatedly until the Special Features
menu appears on screen.
Select EZ TIMER, using the UP/DOWN arrow keys.
Press a RIGHT/LEFT arrows to choose the time (10 minutes
up to 4 hours) that you want your TV to turn itself off.
If you want the TV to turn on and off automatically every
day use the UP/DOWN arrow keys, select ON TIME and use
the RIGHT/LEFT keys to set the time you want the TV to
turn itself on.
Once again, using the UP/DOWN arrow keys, select OFF
TIME. Use the RIGHT/LEFT keys to set the time you want
the TV to turn itself off.
Using the UP/DOWN arrow keys, select ON/OFF TIMER. Use
the RIGHT/LEFT keys to select ON or OFF. The Timer
feature is now set.
Press ENTER to return to normal viewing.
1
2
3
4
5
6
Set your
Entertainment
Machine to
automatically
turn on and off.
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
3
7
1
2
PAGE 22
7
Special
Features
EZ Timer
Ch Labels
XDS Display
Adv. TV Ctrl
EZ Demo
EZ Timer
Sleep Timer
On Time
Off Time
On/Off Timer
0:30
Special
Features
EZ Timer
Ch Labels
XDS Display
Adv. TV Ctrl
EZ Demo
EZ Timer
Sleep Timer
On Time
Off Time
On/Off Timer
0:30
11:56 AM
9:30 PM
On
FLSHBK
206-3588
Press the MENU key repeatedly until the Special Features
menu appears on screen.
Select CH LABELS, using the UP/DOWN arrow keys.
Press a RIGHT/LEFT arrows repeatedly to choose the correct
Call Letters or Channel Letters from the 84 selections
included.
Enter the next channel you wish to label and repeat 3 until
all of the channels have a Channel Label.
Press ENTER to return to normal viewing.
Channel Labels
1
2
3
4
5
Choose preset labels
or call letters for
your channels.
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Special
Features
EZ Timer
Ch Labels
XDS Display
Parental Ctrl
EZ Demo
Ch 5 None
2
1
5
3
If your cable service should change your channel lineup at any
time, you can reset all of the labels again.
PAGE 23
Special
Features
AM
Ch 5 A&E
9:22
Stereo
Channel/Time Display with Channel Label
206-3588
PAGE 24
Mini glossary
XDS Extended Data Service - - if provided by the broadcaster, may show some or all of the following information:
Channel/Time/Audio display/Network label, if present. Title of program, Length of program in hours and minutes and the Time
remaining on the program in hours and minutes.
XDS Display Menu
Press MENU on the remote repeatedly until the Special Features
menu appears.
Highlight the XDS Display option using the Select UP and DOWN
arrows.
Use either the RIGHT or LEFT arrow to specify On or Off.
On - - XDS Display will appear as channels are changed.
Off - - XDS Display will not appear when channels are changed.
Press QUIT to return to TV viewing.
1
2
3
4
Use the Extended Data Service to show in-depth program information.
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Special
Features
EZ Timer
Ch Labels
XDS Display
Parental Ctrl
EZ Demo
On
2
5
3
1
At the time of this printing, XDS data is only being carried by
some broadcasting stations and as a result, is only available on
some channels.
Even though XDS data may be present, it may not be available
during commercial or network breaks.
Ch 25 - PBS
7:15
Stereo
NOVA
Length 01:00 Time Left 00:45
Rating:
TV-14
PM
206-3588
IAAT
Parental Control
Aux. Block:
Allows you to block the signal sent by equipment connected to the TV Audio/Video input jacks such as a
VCR, a DVD Player, Laser Disc Player, etc. So, if you do not wish somebody to watch a videotape, a Laser
Disc, etc, just set the Aux. Block to Sources Blocked.
MPAA: The Motion Picture Association of America’s Rating system has been included for those people who may be
more familiar with this rating system. (See layout on next page). There are six levels of settings. They are:
G and Above, PG and Above, PG-13 and Above, R and Above, NC-17 and Above and X. Press
LEFT/RIGHT arrows on the remote to access.
Age Block: You may wish to use these ratings instead. They are divided into two groups, General and Children.
GENERAL: These settings are: TV-G and Above, TV-PG and Above, TV-14 and Above and TV-MA.
CHILDREN: These settings are: TV-Y and Above and TV-Y7. Press LEFT/RIGHT arrows on the remoteto
access.
Content Block: Once again, there are six designated blocks that you can access. They are: Dialog, Language, Sex Scenes,
Violence, F Violence and No Rating. These settings allow you the option to block the program “Content”
based on individual parameters such as: Strong Dialog, Bad Language, Sex Scenes, Violence Scenes or
Fantasy Violence Scenes and then to select an age level as well. Press LEFT/RIGHT arrows on the remoteto
access.
NOTE: If you choose TV-PG, all of the more restrictive ratings will be automatically blocked. This means
that the viewer will not be able to see TV-PG, TV-14, or TV-MA rated programming.
Set Hours: Use this setting to enter the amount of hours you wish the Parental Control feature to be active.
Set Password: Select a secret password or code, using the number keys on the remote control. Don’t forget the password.
It is the only way you can access the Parental Control menu and change the rating selections. It is also
the only way you can turn the Parental Control feature off.
Lock On Off: This setting gives you the option to have the Parental Control feature active all the time or allow
you to turn it on or off as needed.
Parental Control allows the user the capability of defining which program rating they consider acceptable
to the younger or more sensitive viewer. It can be preset and turned either on or off by the user who
specifies the secret 4-digit code. The number of hours blocked can be specified. General audience and
children viewer blocks can both be programmed into the TV’s memory. Viewer ratings are specified for
both TV and the motion picture industry; both rating systems can be used. These ratings are based mainly on the ages of children.
Below are listed explanations of each of the blocking options and a guide to help you access and select the
Parental Control option best suited for your viewing environment.
Simply specifying one content block such as Sex
Scenes, will not automatically block another content
in the programs from appearing.
Even if you choose to leave the Aux inputs unblocked, the
ratings you specify will automatically restrict the programming that appears from the video sources.
This feature offers a wide variety of options and settings that restrict or “block” undesirable
programming from appearing on your TV screen.
AN OVERVIEW
PAGE 25
206-3588
IAAT
Parental Control (Continued)
1
2
3/4
5
6
7
Determine the
programs and
video sources
your family
can or cannot
access.
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
9
3/4
1
2/5/6
206-3588
PAGE 26
Special
Features
EZ Timer
Ch Labels
XDS Display
Parental Ctrl
EZ Demo
To Block
Setup Menu
EZ Program
Add/Del/Surf
Clock Set
Captions
Caption/Text
Language
To Program
TV-PG and above
Parental
Control
Aux. Block
MPAA
Age Block
Content Blk
Set Hours
Set Password
Lock On/Off
To Block
Content
Block
Dialog
Language
Sex Scenes
Violence
F Violence
No Rating
Press the MENU key repeatedly until the Special Features
menu appears on screen.
Select Parental Control, using the UP/DOWN arrow keys.
Press the RIGHT/LEFT arrows to select Block Channels.
Using the UP/DOWN arrow buttons, select MPAA to block
channels according to the MPAA guidelines. Select Age
Block to block according to Age and Content Block to
block channels according to program content.
If you wish to block a video source (VCR or DVD, etc),
press the UP/DOWN arrow keys and select AUX. BLOCK and
repeat 3.
To set the hours you wish the Parental Control feature to
be on, press the UP/DOWN arrow keys and select SET
HOURS.
Use the SET PASSWORD feature to insert a four digit code
that will make sure no one else can change your settings.
Finally set the lock to ON to complete the blocking out of
the channels or video sources.
Press ENTER to return to normal viewing.
8
9
For a complete restriction coverage you should set restrictions
for both General and Children in the Age Block Option.
Mini glossary
MOTION PICTURE ASSOCIATION OF AMERICA (MPAA) RATING SYSTEM
G General Audiences Content not offensive to most viewers.
PG Parental Guidance Content is such that parents may not want their children to view the program.
Suggested
PG-13 Parental Guidance Program is inappropriate for preteens, with a greater degree of offensive material
Suggested than a PG rated program.
R Restricted viewing Not for children under age 17. Strong elements of sex and/or violence.
NC-17 Restricted Viewing Not for children under age 17 under any circumstances. Strong sexual content.
X Hard Core Films Same as NC-17 rating.
Note: Zenith Electronics Corporation is not liable for any program content that appears when using this rating system; as always, user discretion is advised.
EZ Demo Menu
1
2
3
4
Your Entertainment Machine
will show you all of your
Menu options.
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Special
Features
EZ Timer
Ch Labels
XDS Display
Parental Ctrl
EZ Demo
On
1
4
3
206-3588
PAGE 27
Press the MENU key on the remote control repeatedly
until the Special Featuresmenu appears.
Using the UP/DOWN arrows on the remote control,
select EZ Demo on your screen.
Press a RIGHT/LEFT arrow to turn the EZ DEMO on or off.
Press ENTER to continue.
2
Audio Menu
Personalize the sound
coming from your
Entertainment Machine.
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
Audio Menu
Bass
Treble
Balance
Audio Mode
Front Surr
EZ SoundRite
Speakers
EZ Sound
4
3
1
2
PAGE 28
Press the MENU key on the remote control repeatedly until
the Audio menu appears.
Use the UP/DOWN arrows on the remote control to make your
selection.
Press a RIGHT/LEFT arrow to make an adjustment. Changing
the Bass, Treble and Balance levels will alter the sound
emanating from the TV’s speakers.
• Select Audio Mode if you want to change the sound from
Mono, 2nd Audio/SAP or Stereo.
• Front Surround gives a senes that the sound is open and
expanded.
• EZ SoundRite scans for changes in sound level during commercials, then adjusts the sound to match your current
audio levels. This will make sure that the volume level will
be consistent whether you are watching commercials or a
regular TV program.
• The Speakers feature allows you to switch the internal
speakers of the TV On and Off. Many people who use a
home stereo system with their TV use this feature.
• EZ Sound allows you to choose an appropriate listening
setting based on different audio options.They are: Custom,
Normal, Stadium, News, Music and Theater. Normal resets
all audio settings to the original levels.
Press ENTER to return to TV viewing.
1
2
3
Not all programming is broadcast in stereo.
4
206-3588
1
2
3
4
5
6
Customize the way your picture
looks using the Video menu.
Video Menu
Contrast
Brightness
Color
Tint
Sharpness
Color T emp
EZ Picture
Digital Preset
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
4
3/6
1
2/5
PAGE 29
Press the MENU key repeatedly until the Video menu appears.
Your options are:
• Contrast: Adjusts the level of difference between white and black in
the TV picture. The more contrast, the brighter the picture appears.
• Brightness: Increases or decreases amount of white in the TV picture.
• Color: Adjusts levels of all colors in the TV picture.
• Tint: Balance between amount of red and green in the TV picture.
• Sharpness: Raise or lower the definition of the TV picture. The lower
the level, the softer the images will appear.
• Color Temperature: select between a warm or a cool color layout to
the overall picture.
• EZ Picture: Choose either Custom or Preset.
Custom allows you to set the picture the way you want.
Preset moves all the above options back to their original,
factory-set levels.
Use the UP/DOWN arrows on the remote control to make your selection.
Using the RIGHT/LEFT arrows to adjust the level to your preference.
Press ENTER, QUIT or MENU one more time to return to TV viewing,
or repeat to set the other menu options.
Using the Up/Down arrow, select EZ Picture on your screen.
Use the RIGHT/LEFT arrows to choose an appropriate viewing setting
based on video image options included in your EZ Picture feature.
They are: Custom, Normal, Movie, Digital Preset, Video Game, Sports,
Weak Signal and Night Time.
Video Menu
206-3588
Source Menu
Choose between Antenna/Cable
and Video Sources.
Source Menu
Main Source
Video
PAGE 30
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7089
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
3
2
1
Press the MENU key on the remote control repeatedly until
the Source Menu appears on screen. It will show that the
source of the picture on your screen is either coming from
your Antenna Cable or from your Video (e.g. Video can be a
VCR, a DVD player, etc.).
Press a RIGHT/LEFT arrow to make an adjustment., changing
the signal source from Antenna/Cable to your Video or vice
versa.
Press ENTER to clear the screen.
1
2
3
206-3588
PAGE 31
Programming the Remote
The device you want to program
should be ON.
On the chart in this manual, find the
type of device you’re programming and
then find the brand name. Make a
note of the three-digit code—you’ll
need it soon.
Press and hold the PRG key. It’s
recessed so it doesn’t get pushed
accidentally. When indicator light
behind the PRG button turns on, you
can release the button.
Push the button with the name of the
device you’re programming (VCR,
CABLE, TV).
Using the number pad, enter the
three digit code found on the chart in
the Reference section.
Press ENTER to save the code The
indicator light will flash three times
and turn off if the code was
accepted.
Aim the remote at the device and
push the POWER button. It should
turn off. If not, try the other codes
listed and continue from step three.
Note: After programming, to operate
the device you have just programmed,
press the proper Mode button first.
Programming your Zenith remote
will allow you to use one remote
to work up to 7 different devices!
Not all devices will work with your
Zenith remote control.
1
2
3
4
5
6
7
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7
0
89
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
3
Indicator Light
6
4
5
Program your remote to work with a vast range of A/V devices.
7
206-3588
Amplifier Volume Override
Control the volume on your home audio system without changing modes.
PAGE 32
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7
0
89
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
3
2
1
2
3
Select the code that operates
your amplifier and program it into
the mode in which you want the
volume to appear (e.g. CABLE
mode), as described on the
“Programming the Remote” on
page 31.
Press and hold PRG, using a blunt
instrument, on your remote until
the indicator light stays lit.
Press 4-9-9; then ENTER on the
remote. The indicator light will
flash three times if code is
accepted.
The audio system volume/mute
now appears in all modes
4
If you can’t find the code for your amplifier,
use the Auto Find feature on page 34.
3
206-3588
Aux+1, Aux+2, Aux+3
Control up to seven devices with your remote!
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7
0
89
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
6
4
2
1
2
3
4
5
6
7
3
5
Refer to the chart in this manual
to find the type and brand name
of the device you're programming.
Press and hold the PRG key until
the indicator light turns on.
Press the AUX key and the 1 on
the number pad at the same time
(for AUX +1).
Using the number pad, enter the
three-digit code for the device
you've selected.
Press Enter to save the code.
Aim the remote at the device and
press POWER. It should turn on.
Repeat the steps for AUX+2, and
AUX+3.
Programming your Zenith remote
will allow you to use one remote
to work up to 7 different devices!
Not all devices will work with your
Zenith remote control.
PAGE 33
206-3588
PRG
POWER
CABLE
VCR
AUX TV
ENTER
FLASHBK MUTE
CHANNEL
CHANNEL
VOLUME VOLUME
123
456
7
0
89
MENU
REWIND FFWD
RECORD
QUIT
A
B
C
CC
TV/VCR
SOURCE
PAUSE TIMER
PLAY
STOP
SURF
4/6
5/7
4
Remote Control Auto-Find
Use the remote control to search all possible codes.
Turn on the device you’re
programming for the
remote control.
Press and hold the PRG key until
the indicator light turns on.
Press the key for the device you’re
trying to program (CABLE, VCR,
TV).
Enter the code 0-0-0 (zero-zerozero), then press the ENTER key
right away.
Aim the remote at the correct
device and press the POWER
button. Allow a second to pass,
then push the POWER button
again. Repeat un
til the device
turns off. (This is a trial and error
process, so it may be necessary to
repeat these steps until the
remote finds your code.)
Push ENTER to save the code.
Press POWER to turn the device
back on.
1
2
3
4
5
6
7
If Programming the Remote did not find your code, try this procedure to automatically find
the code for your device.
2
Indicator Light
3
PAGE 34
206-3588
Find the codes you need to program your remote. On this page: TVs, VCRs and Satellite Receivers.
Programming Codes
TVs TV/VCRS
VCRs
Admiral . . . . . . . . 121
Adventura . . . . . . 154
Bell & Howell . . . . 121
Citizen . . . . . . . . 121
Curtis Mathes . . . . 121
Daewoo . . . . . . . 148 149
Electra . . . . . . . . 121
Funai . . . . . . . . . 154
Goldstar . . . . . . . 153 172
Kurazai . . . . . . . . 121
Lodgenet. . . . . . . 121
Logik . . . . . . . . . 121
Majestic . . . . . . . 121
Memorex . . . . . . . 121
Montgomery Ward . 121
Teknika . . . . . . . . 121
Telerent. . . . . . . . 121
Signature 2000 . . . 121
XR-1000 . . . . . . . 121
Symphonic. . . . . . 154
Zenith . . . . . . . . 101 121 149
152
Zenith TV/VCR . . . 150 153 154
172
Admiral . . . . . . . 261
Akai . . . . . . . . . . 292 717 718
719 720
Audio Dynamics . . 726
Bell & Howell . . . . 247
Broksonic . . . . . . 221 250 255
729
Candle . . . . . . . . 727
Canon . . . . . . . . 704
Capeheart . . . . . . 728
Citizen . . . . . . . . 727
Craig . . . . . . . . . 212
Curtis Mathes . . . 259 266 725
727
Daewoo . . . . . . . 244 246 248
254 703 729
Daytron . . . . . . . 246
DBX . . . . . . . . . . 726
Electrohome. . . . . 730
Emerson . . . . . . . 203 221 243
250 293 721
722 729 730
731 732
Fisher . . . . . . . . . 211 212 213
247 265 274
General Electric . . 216 220 266
282 701 702
725
Goldstar . . . . . . . 253
Go Video . . . . . . . 256 262 263
700
Harman Kardon. . . 296
Hitachi . . . . . . . . 257 270 273
292 705 706
707 708
J.C. Penny . . . . . . 268 2726
Jensen . . . . . . . . 292
JVC . . . . . . . . . . 224 225 258
268 292 299
726
Kenwood . . . . . . . 268 292 726
727
Magnavox . . . . . . 275
Marantz . . . . . . . 267 268 726
727
Memorex . . . . . . . 212 298
MGA . . . . . . . . . . 297 730
Mitsubishi . . . . . . 276 277 278
279 280 296
297 730
Montgomery Ward . 216 219 249
291 730
Multi Tech . . . . . . 727
NEC . . . . . . . . . . 267 268 269
281 292 709
726
Orion . . . . . . . . . 250
Panasonic . . . . . . 245 251 259
713 714 715
716
Pentax . . . . . . . . 708 727
Philco. . . . . . . . . 275
Pioneer . . . . . . . 210 282 726
Portland . . . . . . . 246 727
ProScan . . . . . . . 216 260 266
282 725
Quasar . . . . . . . . 259 295
Radio Shack . . . . . 213 265 730
RCA . . . . . . . . . . 216 220 228
240 242 249
260 266 282
283 284 285
286 287 288
708 710 711
725
Realistic . . . . . . . 212 213 265
730
Saisho. . . . . . . . . 722
Salora . . . . . . . . . 297
Samsung . . . . . . . 220 230
Sansui . . . . . . . . 289 292 709
726
Sanyo . . . . . . . . 212 247 294
Scott . . . . . . . . . 243 290 729
Sears . . . . . . . . . 211 212 213
265 274
Sharp . . . . . . . . . 261 730
Signature 2000 . . . 216 219 249
Sony . . . . . . . . . 232 723 724
Sylvania . . . . . . . 275 297
Tatung . . . . . . . . 268 292
Teac . . . . . . . . . . 268
Teknika . . . . . . . . 272
Toshiba . . . . . . . . 213 274 290
297
Vector Research . . 726 727
Victor . . . . . . . . . 726
Video Concepts . . . 726 727
XR 1000 . . . . . . . 243
Yamaha. . . . . . . . 726
Zenith . . . . . . . . 201 224 225
229
PAGE 35
Satellite Receivers
Alphastar. . . . . . . 516
Chaparral. . . . . . . 501 502
Cheyenne. . . . . . . 502
Dishnet . . . . . . . . 515
Drake . . . . . . . . . 503
General Electric. . . 510 517
General Instrument 504 505
Hitachi . . . . . . . . 519 520
Hughes Network . . 514
JVC . . . . . . . . . . 518
Macom . . . . . . . . 314
Magnavox . . . . . . 521
Philips . . . . . . . . 521
PrimeStar. . . . . . . 513
ProScan. . . . . . . . 510 517
RCA DSS . . . . . . . 373
RCA . . . . . . . . . . 510 517
Realistic . . . . . . . 506
Sierra I . . . . . . . . 502
Sierra II . . . . . . . 502
Sierra III. . . . . . . 502
Sony. . . . . . . . . . 511
STS1. . . . . . . . . . 507
STS3 . . . . . . . . . 508
Toshiba . . . . . . . . 509 512
Uniden . . . . . . . . 522
United . . . . . . . . 344
Zenith Drake. . . . . 312 330
Zenith. . . . . . . . . 312 328 351
378 500
206-3588
PAGE 36
Programming Codes
Find the codes you need to program your remote. On this page: Cable, DVD Players, CD Players, Tape Decks
and Audio Tuners and Amplifiers.
DVD Players
Audio CD Players
Audio Tape Decks
Cable Boxes
Audio Tuners/Amps
Allegro . . . . . . . . 358 362
Allegro A/B Switch 361
Archer. . . . . . . . . 325
Century . . . . . . . . 325
Citizen . . . . . . . . 325
Comtronic . . . . . . 326
Garrard . . . . . . . . 325
Gemini . . . . . . . . 305 331 338
General Electric. . . 367
General Instrument 304 305 306
307 308 309
310 318
Hamlin . . . . . . . . 302 303 345
365 366
Jasco . . . . . . . . . 325
Jerrold . . . . . . . . 304 307 308
309 310 318
360 363
Kale Vision . . . . . 335
Macom . . . . . . . . 321
Magnavox . . . . . . 327 334
NSC . . . . . . . . . . 335 339 368
369 370
Oak . . . . . . . . . . 311 332 342
Panasonic . . . . . . 313 320
Paragon . . . . . . . 333
Philips . . . . . . . . 325 327 347
350 352 354
355
Pioneer . . . . . . . . 315 343
RCA . . . . . . . . . . 341
Regency . . . . . . . 329
Samsung . . . . . . . 326 335
Scientific Atlanta . 316 323 336
337 364
Signal. . . . . . . . . 326
SL Marx. . . . . . . . 326
Sprucer . . . . . . . . 313
Standard Comp . . . 335
Stargate . . . . . . . 326 379
Teleview . . . . . . . 326
Texscan . . . . . . . 339 356 371
Tocom . . . . . . . . 317 318 346
Unika . . . . . . . . . 325 348 362
Universal . . . . . . 325 358 362
Vid Tech . . . . . . . 340
Video Way . . . . . . 349
Viewstar . . . . . . . 327 354 355
372
Zenith HT-2000. . . 353
Zenith PM . . . . . . 374
JVC . . . . . . . . . . 965
Mitsubishi . . . . . . 964
Pioneer . . . . . . . . 963
Sony . . . . . . . . . 962
Toshiba . . . . . . . . 961
Zenith . . . . . . . . 960
ADC . . . . . . . . . . 940
ADO . . . . . . . . . . 939
Aiwa. . . . . . . . . . 938
Akai . . . . . . . . . . 937
Denon . . . . . . . . 935
Dynatech. . . . . . . 953
Emerson . . . . . . . 952
Fisher . . . . . . . . . 438 933 951
General Electric. . . 932
Goldstar . . . . . . . 460
Hitachi . . . . . . . . 950
JVC . . . . . . . . . . 949 954
Kenwood . . . . . . 441 931 948
Luxman . . . . . . . . 930
Magnavox . . . . . . 421 422 433
434
Marantz. . . . . . . . 929 947
MCS . . . . . . . . . . 928
Mitsubishi . . . . . . 927
Nakamichi . . . . . . 925 926
Onkyo . . . . . . . . 923 924 946
Optimus . . . . . . . 920 921 922
Panasonic . . . . . . 431 432 945
Philips . . . . . . . . 421 433 434
Pioneer . . . . . . . . 431 435 944
Quasar . . . . . . . . 432
Radio Shack . . . . . 431 441
RCA . . . . . . . . . . 437 943 909
Sanyo . . . . . . . . . 438 439
Sears . . . . . . . . . 936
Sharp . . . . . . . . . 441 442
Sherwood . . . . . . 449
Sony. . . . . . . . . . 420 443 444
445 934
Soundesign . . . . . 461 498 901
902
Sylvania . . . . . . . 433
Teac . . . . . . . . . 418 419
Technics . . . . . . . 432
Toshiba . . . . . . . . 961
Yamaha . . . . . . . 414 941 942
Zenith . . . . . . . . 460 461 498
901 502
Sony. . . . . . . . . . 452
Citizen . . . . . . . . 914
General Electric. . . 916
Goldstar . . . . . . . 460 474
Hitachi . . . . . . . . 919
JVC . . . . . . . . . . 908 420 484
Luxman . . . . . . . 467
Marantz. . . . . . . . 903 913
Memorex . . . . . . . 485
Nad . . . . . . . . . . 904
Nakamichi . . . . . . 493
Onkyo . . . . . . . . 471 906
Optimus . . . . . . . 905
Panasonic . . . . . . 912
Pioneer . . . . . . . . 470 485 907
Proton . . . . . . . . 910
Quasar . . . . . . . . 912
RCA . . . . . . . . . . 909
Sharp . . . . . . . . . 483 917 918
Sherwood . . . . . . 900
Sony. . . . . . . . . . 486 489 490
491 492
Soundesign . . . . . 461 498 901
902
Toshiba . . . . . . . . 915
Techniques. . . . . . 912
Victor . . . . . . . . . 908
Zenith . . . . . . . . 460 461 498
901 902
206-3588
PAGE 37
A complete list of the button functions on your remote control.
Zenith Product Codes
TV Mode VCR Mode Cable Mode AUX Mode
KEY NAME Zenith Code 101 Zenith Code 201 Zenith Code 353 Zenith Code 960
POWER TV On/Off VCR On/Off Cable Box On/Off AUX On/Off
CABLE Selects Cable Selects Cable Selects Cable Selects Cable
VCR Selects VCR Selects VCR Selects VCR Selects VCR
AUX Selects Aux Selects AUX Selects Aux Selects AUX
TV Selects TV Selects TV Selects TV Selects TV
SURF Surf On/Off VCR AM/PM Cable FC/Fav Ch AUX Audio
FLASHBK TV Flashback VCR Flashback Cable Flashback AUX Frame/Time
MUTE TV Mute TV Mute TV Mute TV Mute
CHANNEL UP TV Channel Up VCR Channel Up Cable Channel Up AUX Skip >>
CHANNEL DN TV Channel Dn VCR Channel Dn Cable Channel Dn AUX Skip <<
VOLUME (RIGHT) TV Volume Up TV Volume Up TV Volume Up TV Volume Up
VOLUME (LEFT) TV Volume Dn TV Volume Dn TV Volume Dn TV Volume Dn
1 TV Digit 1 VCR Digit 1 Cable Digit 1 AUX Digit 1
2 TV Digit 2 VCR Digit 2 Cable Digit 2 AUX Digit 2
3 TV Digit 3 VCR Digit 3 Cable Digit 3 AUX Digit 3
4 TV Digit 4 VCR Digit 4 Cable Digit 4 AUX Digit 4
5 TV Digit 5 VCR Digit 5 Cable Digit 5 AUX Digit 5
6 TV Digit 6 VCR Digit 6 Cable Digit 6 AUX Digit 6
7 TV Digit 7 VCR Digit 7 Cable Digit 7 AUX Digit 7
8 TV Digit 8 VCR Digit 8 Cable Digit 8 AUX Digit 8
9 TV Digit 9 VCR Digit 9 Cable Digit 9 AUX Digit 9
0 TV Digit 0 VCR Digit 0 Cable Digit 0 AUX Digit 0
ENTER TV Enter VCR Enter Cable Enter Aux Display
MENU TV Menu VCR Menu Cable Menu AUX Program
UP ARROW TV Select Up VCR Select Up Cable Up Arrow AUX Part
DOWN ARROW TV Select Dn VCR Select Dn Cable Dn Arrow AUX Random
LEFT ARROW TV Adjust Left VCR Adjust Left Cable Left Arrow AUX x3 FAST <
RIGHT ARROW TV Adjust Right VCR Adjust Right Cable Right Arrow AUX x3 FAST >
QUIT/ TV Seq Sound (Menu Quit)VCR Quit Cable Quit AUX Clear
A TV PIP VCR+ Day Up AUX Repeat-Side
B TV PIP Swap VCR Channel Map Day Down AUX Repeat-A-B
C TV PIP Freeze VCR Search Cable Pg Up AUX Repeat-Chap
CC TV Closed Captions VCR Memory Cable Pg Down AUX Memory
TIMER TV Timer VCR Timer Cable Timer AUX Still
TV/VCR/SOURCE TV Sources TV Tuner or VCR Tuner Cable Info AUX TV/Disc
RECORD VCR Record VCR Record Cable Buy AUX Edit
PAUSE VCR Pause VCR Pause Cable Guide AUX Pause
REWIND VCR Rewind VCR Rewind VCR Rewind AUX Scan <<
PLAY VCR Play VCR Play VCR Play AUX Play
STOP VCR Stop VCR Stop VCR Stop AUX Stop/Eject
FFWD VCR Fast Forward VCR Fast Forward VCR Fast Forward AUX Scan >>
References: 124-233-04 and µP 221-1445-01
Some of the functions, such as PIP, shown above, may not be available on your TV.
206-3588
Glossary
A complete list of definitions for words found in this guide.
PAGE 38
75 OHM RF CABLE The wire that comes from an off-air antenna or cable service provider.
The end looks like a hex-shaped nut with a wire sticking through the
middle. It screws onto the threaded jack on the back of your TV.
300 TO 75 OHM A small device that connects a two-wire
300 ohm antenna to a
ADAPTER 75 ohm RF jack. They are usually about an inch long with two screws on
one end and a round opening with a wire sticking out on the other end.
A/V CABLES Audio/Video cables. Three cables bunched together—right audio (red),
left audio (white), and video (yellow). A/V cables are used for stereo
playback of videocassettes and for higher quality picture and sound
from other A/V devices.
ADD This function lets you add new channels to list that you'll scroll through
when using your remote.
ANTENNA The physical receiver of television signals sent over the air. A large
metal piece of equipment does not always have to be visible for your
home to be using an antenna.
AUTO PROGRAM Auto Program has your Entertainment Machine automatically find all the
channels available in your area.
BLOCK Restrict or censor a channel for a set length of time.
DELETE This function lets you remove channels that you don't watch from the
list you'll scroll through using your remote.
INPUT Refers to the jack that receives a signal from a TV, VCR or other
A/V device.
JACK A connection on the back of a TV, VCR, or any other A/V device.
MONO SOUND Mono (monaural) sound is one channel of sound. On more than one
speaker, all the speakers play the same audio.
OUTPUT Refers to the jack that sends a signal out of a VCR, DVD, or other
A/V device.
SECOND AUDIO Second Audio Programming (SAP) is another, separate, audio channel
PROGRAMMING/SAP available with some programming. Choosing SAP often refers to listening
to audio in another language, such as Spanish or French.
SIGNAL Picture and sound traveling through cable, or on the air, to your
television screen.
STEREO SOUND Stereo (stereophonic) sound refers to audio that’s divided into right and
left sides.
TUNER Device that picks up the signal and turns them into
picture and sound.
206-3588
Some quick and easy tips to fixing problems yourself.
SOLUTIONS
• Check your antenna connection or location.
• Check your antenna direction and/or location.
• Make sure the wire from your antenna to your Entertainment Machine is
properly connected.
The following may cause image problems or distortion:
Electrical appliances, powerful lights, cars, trucks; computers or
portable phones; medical equipment
• If possible increase the distance between your Entertainment MachineTMand
the offending appliance. Or shut one of them off.
• Check volume control.
• Make sure the TV is not Muted.
• Try another channel. The problem may be the broadcast, not your
Entertainment MachineTM.
• Are the Audio A/V cables properly installed?
• Are the wires for external speakers (if you have external speakers) properly installed?
• Are you in TV or cable tuning mode and should be in the other?
• Make sure output channels on all A/V equipment are on the same channel (3 or 4).
• Check that all connections are tight.
• Is the AC power plugged in?
• Check that your AC power outlet works. (Test it by plugging in something
else or try another plug.)
• Make sure your brightness and audio controls are set properly.
• Try another channel. The problem may be with the broadcast.
• Check the color control in the Video menu.
• Try another channel. The problem may be with the broadcast.
• The CC (closed caption) option may be in Text mode. Select OFF in the Captions/
Text menu.
• Your program is in letterbox. This means that the shape of your TV is a
square, but the program is a rectangle. Because this format is a
direct representation of film as you see it in the movies, you are actually seeing
MORE of the program when you see those bars.
• Make sure the batteries are fresh and installed properly.
• Remove batteries for 30 seconds and replace.
• Try unplugging the TV, waiting about five minutes, and then plugging it back in
and trying again.
PAGE 39
Troubleshooting
206-3588
SYMPTOMS
Snowy picture and poor sound.
Multiple images or ‘ghost shadows.’
Interference: Sharp lines across
the screen and poor sound.
Normal picture but no sound.
No picture and poor sound.
No picture and no sound
No color, but the sound is O.K.
Picture has a big black box
on it, but the sound is O.K.
Picture has two horizontal
black bars, one on top and
one on bottom.
Remote control doesn’t work.
Menu options won’t change.
1. Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of
lukewarm water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost
dry, and then use it to wipe the screen.
2. Make sure the excess water is off the screen, and then let it air-dry before you turn on your
Entertainment Machine.
1. Use a soft cloth with a mild soap solution to wipe the cabinet.
2. Rinse the cloth and wipe the cabinet again.
3. Let the cabinet air-dry before turning the Entertainment Machine on.
Use a quality wood cleaner and polish. This will protect the Entertainment Machine from dirt and dust, as
well as keep the cabinet looking new.
If you leave your Entertainment Machine dormant for a long time (such as a vacation), it’s a good idea
to unplug the power to protect against possible damage from lightning or power surges. If you use an
off-air antenna, you may also want to disconnect it from the back of your TV before leaving.
Maintenance
Caring for your Entertainment Machine.
PAGE 40
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time
you will have with your new Entertainment Machine. Be sure to turn the power off and pull out
the plug before you begin any cleaning.
Screen Cleaning
Extended Absence
If you unplug your Entertainment Machine,
you may have to reset the clock using
the Clock Set menu described earlier.
Cabinet Cleaning
Wood Cabinets
206-3588
Index
Find what you want quickly.
FEATURE. . . . . . . . . . . . . . . . . . . . . . . PAGE
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6, 8
Amplphier Volume Override . . . . . . . . . . . . . . . . . . 32
Audio Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Auxiliary Remote Functions . . . . . . . . . . . . . . . . . . 33
Basic Television Operation. . . . . . . . . . . . . . . . . . . 15
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Button Functions on Remote . . . . . . . . . . . . . . . . . 13
Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 9
Captions and Text Menu . . . . . . . . . . . . . . . . . . 19-20
Ch. Add/Del/Surf. . . . . . . . . . . . . . . . . . . . . . . . . 17
Ch. Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
EZ Demo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
EZ Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Front Panel Diagram. . . . . . . . . . . . . . . . . . . . . . . 14
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Hook-Up Directory. . . . . . . . . . . . . . . . . . . . . . . . . 5
Language Menu. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Parental Control . . . . . . . . . . . . . . . . . . . . . . . 25-26
Programming the Remote . . . . . . . . . . . . . . . . . . . 31
Programming Codes . . . . . . . . . . . . . . . . . . . . . . . 36
Remote Control Diagram . . . . . . . . . . . . . . . . . . . . 13
Remote Control Auto Find . . . . . . . . . . . . . . . . . . . 41
Safety Information . . . . . . . . . . . . . . . . . . . . . . . 2-4
Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Source Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Stereo Amplifier Hookup. . . . . . . . . . . . . . . . . . . . 11
Super VHS Hookup. . . . . . . . . . . . . . . . . . . . . . . . 10
Timer Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 39
VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-10
Video Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
XDS Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Zenith Product Codes . . . . . . . . . . . . . . . . . . . . . . 37
PAGE 41
206-3588
PAGE 42
ORDER TODAY!
CALL OR FAX TOLL-FREE
1.800.255.6790
Fax 1.888.693.6484
email: parts.sales@zenith.com
Broken or lost remote? Need a second remote or more functions?
Order direct from Zenith!!
• Operates TV, VCR, CD, DVD, DIVX, DSS & Cable Box
• Operates PIP and Most Screen Menus
• Extended Range & MORE!!!
Orders 1 year or more after product purchase may receive upgraded models.
Other Remotes with 3, 4, 5 & 7 Functions Available Upon Request
Set up your game room or spare room in style!! Sturdy black
wall mounts keep the TV off your furniture and in easy view.
All mounts have 90 degree and 10 degree tilt angles.
• ALGW27 fits most 25” to 27” TVs - ONLY $59.99
• ALGW20 fits most 19” and 20” TVs - ONLY $49.99
• ALGw13 fits most 13” Televisions - ONLY $39.99
Available in White, just add “-WH” to part number (e.g. ALGW27-WH)
FOR ALL ORDERS ADD $6.95
SHIPPING & HANDLING
TELEVISION WALL MOUNTS
2
1
3
Recommended Video Accessories
Use Your Visa or MasterCard to Order
PLEASE ALLOW 3 - 4 WEEKS FOR DELIVERY
zenith
Receive Local programming NOT available on your Satellite
system!!! Perfect backup antenna for cable outages. Enhanced
quality picture and stereo sound in weak signal areas.
• Amplified VHF/UHF/FM Antenna includes 4 feet of 75 ohm
cable for easy hookup.
ONLY $34.95
PLUS $6.95
SHIPPING & HANDLING
INDOOR AMPLIFIED ANTENNA
ATS 775
ZENITH 5 FUNCTION REMOTE
ONLY $19.99
PLUS $6.95
SHIPPING & HANDLING
ZEN 525
Direct-View Color TV Welcome into the Zenith family! We believe that you will be pleased with your new Zenith Entertainment Machine. Please read this warranty carefully,
it is a “LIMITED WARRANTY” as defined under Federal Law. This warranty gives you specific legal rights, and you may also have other rights that vary
from state to state within the U.S.A.
ZENITH RESPONSIBILITY
Service Labor During a period of 90 days from effective warranty date, Zenith will provide service labor by a Zenith authorized service center when needed as
determined by Zenith, as a result of manufacturing defects.
Parts New or remanufactured replacements for factory-defective parts will be supplied by a Zenith authorized service center for one year from effective
warranty date (color picture tube — two years). Such replacement parts are warranted for the remaining portion of the original warranty period.
Home Service Warranty service for 21” diagonal (U.S.A.) or larger screen size models is provided in the home in most cases. (Some repairs may require the unit to
be taken by the servicer to the repair facility and returned, at no additional charge.)
Not Covered This warranty covers manufacturing defects and does not cover installation, adjustment of customer controls in the home, installation or repair of
home antenna systems, cable converters or cable company-supplied equipment; it also does not cover damage due to misuse, abuse, negligence, acts
of God or other causes beyond the control of Zenith. Any alteration of the product after manufacture voids this warranty in its entirety.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND ZENITH SHALL NOT BE LIABLE FOR
ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST REVENUES OR PROFITS IN
CONNECTION WITH THE PRODUCT. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU.
OWNER’S RESPONSIBILITY
Effective Warranty Date Warranty begins on the date of original consumer purchase. For your convenience, keep the dealer’s dated bill of sale or delivery ticket as evidence of
the purchase date.
Operating Guide Read your Operating Guide carefully so that you will understand the operation of your set and how to adjust the customer controls.
Carry-In Service Models under 21” diagonal (U.S.A.) screen size must be taken to a Zenith authorized service center for warranty service and must be picked up by the
owner.
Antenna Reception problems caused by inadequate home antenna or faulty antenna connections are the owner’s responsibility.
Important Product Registration—Please fill out and mail your Product Registration Card. It is imperative that Zenith know how to reach you promptly if we
should discover a safety problem that could affect you.
Warranty Service For warranty service information, contact any Zenith authorized service center. Parts and service labor that are Zenith’s responsibility (see above) will
be provided without charge. Other service is at the owner’s expense. If you have any problem in obtaining satisfactory warranty service, call or write
the Zenith Response Center. You must provide the model number, serial number and date of purchase or date of original installation. Before you ask
for warranty service, read “Maintenance and Troubleshooting” in your operating guide. You might avoid a service call.
Additional Zenith Picture Tube Protection Plan Available
Zenith offers you the opportunity to obtain additional long-term protection against failure of the picture tube in your new Entertainment
Machine. Our Picture Tube Protection Plan enables you to avoid any unexpected picture tube repair expenses and keep your Entertainment
Machine in top condition. It guarantees you a genuine Zenith replacement picture tube and
service from a Zenith authorized service center.
ZENITH ELECTRONICS CORPORATION
Zenith Response Center
201 James Record Rd., Building 3,
Huntsville, AL 35824
Telephone (256) 772-1515
Mon-Fri, 7:00 a.m.-8:00 p.m. CST
Sat. 8:00 a.m.-5:00 p.m. CST
www.zenith.com
ZENITH CONSUMER SERVICES FACTORY OWNED SERVICE CENTERS
801 E. Roosevelt Rd
Lombard, IL 60148
(630)705-2830
Home & Carry-in Service
Television/VCR
Parts and Accessories
PTV/Camcorders
201 James Record Rd.
Building 4
Huntsville, AL 35824
(256) 774-4025
Service Hours:
M-F 8-6, Sat 9-2
Will accept UPS Shipments
Your Zenith Warranty
© Copyright 2000, Zenith Electronics Corporation.
Be sure to send in the Product Registration Card. We will send you an application for the Protection Plan near the expiration
of the two-year manufacturer’s warranty on the picture tube. For additional information call (256) 774-4088.
206-3588
Rev. A
Loading...
