Receiver Bootstrapping
If a receiver has not been configured before then it tries to initialize itself.
Receiver acts as a WIFI client. It uses the following WIFI connection details to join the network.
SSID: mpact_init
Security Type: wpa2
Security Key: mpact123
Upon joining the network the receiver continues with its initialization process.
The network settings and the gateway or endpoint-server way settings are needed for the receiver to complete its
initialization process. The receiver expects it to be available from a machine with following details:
IP: 192.168.1.100
Port: 8005
The receiver expects a JSON configuration file called
the bootstrap JSON file is available in the schema document [
badge_config.json
JSON Schema for Receivers.doc
to be served from this location. The schema for
].
Sample Badge_Config.JSON
{
"wifiProfiles": [{
"ssid": "wifinetwork123",
"securityKey": "abcd1234",
"securityType": "wpa2",
"wpaEnterpriseUser": "",
"wpaEnterprisePassword": "",
"wpaEnterpriseOuterIdentity": "",
"eapType": "",
"enable": true
}],
"gatewayConfigs": [{
"user": "superuser",
"password": "mpact123",
"receiverConfigURL": "http://192.168.1.100:8005/gateway-client/config/v1/receiver",
"configPullFrequencyInMins": 5,
"enable": true
}]
}
4
Bootstrap Process
Integration with Receivers
badge_config.json has
network. The end point server connection details are provided in the
The receiver would validate the badge_config.json store the details and reboot itself and join the WIFI network provided in
the
wifiProfiles
JSON file by making a GET request to the URL specified in
64 authentication, the username and password provided in the
Receiver would periodically pull the beacon filter configuration from the server with the frequency specified in the
section. After successfully joining the WIFI network the receiver would try to pull a beacon filter configuration
configPullFrequencyInMins
wifiProfiles
section that tells the receiver how to the authenticate itself and connect to the WIFI
gatewayConfigs
receiverConfigURL
user
and
attribute and use changes to beacon filter configuration if any.
JSON attribute. If the server requires basic
password
section.
sections would be used by the receiver.
Receiver Filter Configuration
The beacon filtering details as well as the event, health endpoint details are to be provided to the receiver in the JSON file.
The schema for the beacon filter JSON file is available in the schema document [
server should implement the endpoints for the following:
1. Provide beacon filter configuration requested by receiver using HTTP GET [Mandatory]
2. Provide time data
3. requested by receiver using HTTP GET [Mandatory]
4. Accept health events sent by receiver using HTTP POST [Mandatory]
5. Accept beacon data events sent by receiver using HTTP POST [Mandatory]
6. Provide firmware requested by receiver using HTTP GET [Optional]
JSON Schema for Receivers.doc
]. The
Sample Simple Receiver Filter Configuration
{
"scanIntervalInMilliseconds": 500,
"wifiTransmissionInterval": 8,
"heartbeatIntervalInSeconds": 30,
"timePullIntervalInMinutes": 5,
"bootTimeWaitInSeconds": 4,
"beaconWhiteList": [{
"uuid": "FE913213-B311-4A42-8C16-47FAEAC938AB",
"type": "mpact"
},
{
"uuid": "FE913213-B311-4A42-8C16-47FAEAC938EF",
"type": "mpact"
}
],
"profiles": [{
"name": "Location Beacons",
"profileLow": 1,
5
Integration with Receivers
"profileHigh": 1000,
"beaconType1": "Fixed",
"proximityRanges": [{
"name": "Near",
"rssiLow": null,
"rssiHigh": null,
"beaconHitCount": 1,
"sendClosestOnly": false,
"suppressRepeats": false
}]
},
{
"name": "Asset Beacons",
"profileLow": 2000,
"profileHigh": 3000,
"beaconType1": "Mobile",
"proximityRanges": [{
"name": "Near",
"rssiLow": null,
"rssiHigh": null,
"sendClosestOnly": false,
"suppressRepeats": true
}]
}
],
"serviceUrls": {
"timeService": "http://10.21.2.52:80050/gettime",
"eventService": "http://10.21.2.52:80050/event/",
"healthService": "http://10.21.2.52:80050/health/",
"firmwareService": "http://10.21.2.52:80050/firmware/"
},
"firmware": {
"downloadInSecond": "true",
"firmwareDownloadDebug": "true",
"gaugeFirmware": "2.7.6.0-057R_GAUGE-BT000311-01_9689CECC_14DDC8BE.srec",
"bleFirmware": "2.7.6.0-057R_BLE-FIRMWARE_C6D54CAF_F789E6B6.bin",
"wifiFirmware": "2.7.6.0-057R_WIFI-FW_B561BEFF_9A23DE30.bin",
"bootloader": "2.7.6.0-057R_BOOTLOADER-LOW_0613CBA3_52F02E35.bin",
"mainFirmware": "2.7.6.0-057R_MPACT-MB5000-01-WR_12B56998_E58DD0CA.elf"
}
}
6
Integration with Receivers
As mentioned earlier the
file like the one above. It would be different for different deployments based on their requirements. The meaning of each of
these attributes is available as part of schema file. Here are some important attributes and their purpose:
Attribute Name Description
scanIntervalInMilliseconds The frequency of the receiver to scan for BLE beacons
wifiTransmissionInterval The frequency of the receiver to post the filtered beacon data to
heartbeatIntervalInSeconds The frequency at which the receiver should send its health
timePullIntervalInMinutes The receiver does not have a real-time clock and synchronizes
beaconWhiteList A list of beacon UUIDs that should be processed by the receiver.
serviceURLs These are the URL endpoints where the receiver would post the
receiverConfigURL
the server. This attribute is a multiple of
scanIntervalInMilliseconds
and
post beacon data every (500*8)ms.
message.
its time with the server time. The frequency at which the receiver
should updates its time.
information.
timeService
the time information by using a HTTP GET method. The data
format expected by the receiver is part of the JSON schema file.
healthService
asynchronous events as well as health information by using
HTTP POST method. The POST data format is available as part
of the JSON schema file.
eventService
periodic beacon data events by using HTTP POST method. The
POST data format is available as part of the JSON schema file.
firmwareService
pull and update its firmware by using a HTTP GET method.
specified in the bootstrap file would serve a beacon filter configuration JSON
. So if
scanIntervalInMilliseconds
: This is the URL from where the receiver would pull
: This is the URL where the receiver would send
: This is the URL where the receiver would send
: This is the URL from where the receiver would
wifiTransmissionInterval
is 500 then the receiver would
is 8
7
Integration with Receivers
Sample Response From Server For Time Request By Receiver
{
"time": 1580853295594
}
Sample HeartBeat Event Sent By Receiver
{
"timestamp": 1567799222930,
"firmware": "2.7.6.0-057R_MPACT-MB5000-01-WR.bin",
"type": "HeartBeat",
"receiver": {
"type": "FR",
"identity": {
"mac": "40:83:DE:D9:61:EB"
}
}
}
Sample Asynchronous Event Sent By Receiver
{
"timestamp": 1567799770734,
"firmware": "2.7.6.0-057R_MPACT-MB5000-01-WR.bin",
"type": "Reboot.Unforced",
"details": {
"bootCode": 12
},
"receiver": {
"type": "FR",
"identity": {
"mac": "40:83:DE:D9:61:EB"
}
}
}
8
Integration with Receivers
Sample Beacon Data Sent by Receiver
{
"beacons": [{
"major": 100,
"uuid": "fe913213-b311-4a42-8c16-47faeac938ef",
"bl": 90,
"ts": 1553191045018,
"mac": "a0:e6:f8:79:d4:13",
"rssi": -52,
"minor": 0
}, {
"major": 100,
"uuid": "fe913213-b311-4a42-8c16-47faeac938ef",
"bl": 90,
"ts": 1553191045080,
"mac": "a0:e6:f8:79:d8:6f",
"rssi": -56,
"minor": 0
}],
"receiver": {
"type": "FR",
"identity": {
"mac": "40:83:DE:D9:6A:69"
}
}
}
9
Integration with Receivers
Sample Receiver Filter Configuration With Support For SuperBeacons
{
"scanIntervalInMilliseconds": 500,
"wifiTransmissionInterval": 8,
"heartbeatIntervalInSeconds": 30,
"timePullIntervalInMinutes": 5,
"bootTimeWaitInSeconds": 4,
"superBeaconFilters": {
"rssiLow": -80,
"rssiHigh": -30
},
"superBeaconProfiles": [{
"name": "Location Beacons1",
"profileLow": 700,
"profileHigh": 730,
"proximityRanges": [{
"name": "Near",
"rssiLow": null,
"rssiHigh": -30
}]
}, {
"name": "Location Beacons2",
"profileLow": 2000,
"profileHigh": 2500,
"proximityRanges": [{
"name": "Near",
"rssiLow": null,
"rssiHigh": -30
}]
}],
"superBeaconWhiteList": [{
"uuid": "FE913213-B311-4A42-8C16-47FAEAC938DB",
"type": "ibeacon"
},
{
"uuid": "FE913213-B311-4A42-8C16-47FAEAC938EF",
"type": "mpact"
}
],
"beaconWhiteList": [{
"uuid": "FE913213-B311-4A42-8C16-47FAEAC938EF",
"type": "mpact"
}],
"profiles": [{
10
Integration with Receivers
"name": "Location Beacons",
"profileLow": 1,
"profileHigh": 100,
"beaconType1": "Mobile",
"proximityRanges": [{
"name": "Near",
"rssiLow": null,
"rssiHigh": null,
"sendClosestOnly": false,
"suppressRepeats": false
}]
}, {
"name": "Asset Beacons",
"profileLow": 2500,
"profileHigh": 3000,
"beaconType1": "Fixed",
"proximityRanges": [{
"name": "Near",
"rssiLow": null,
"rssiHigh": null,
"sendClosestOnly": false,
"suppressRepeats": true
}]
}],
"serviceUrlsHostName": {
"timeService": "http://rcvr-test.mweng.lan:8005/gettime",
"eventService": "http://rcvr-test.mweng.lan:8005/event/",
"healthService": "http://rcvr-test.mweng.lan:8005/health/",
"firmwareService": "http://rcvr-test.mweng.lan:8005/firmware/"
},
"serviceUrls": {
"timeService": "http://10.21.2.52:80050/gettime",
"eventService": "http://10.21.2.52:80050/event/",
"healthService": "http://10.21.2.52:80050/health/",
"firmwareService1": "http://10.21.2.52:80050/firmware/"
},
"firmware": {
"downloadInSecond": "true",
"firmwareDownloadDebug": "true",
"gaugeFirmware": "2.7.6.0-057R_GAUGE-BT000311-01_9689CECC_14DDC8BE.srec",
"bleFirmware": "2.7.6.0-057R_BLE-FIRMWARE_C6D54CAF_F789E6B6.bin",
"wifiFirmware": "2.7.6.0-057R_WIFI-FW_B561BEFF_9A23DE30.bin",
"bootloader": "2.7.6.0-057R_BOOTLOADER-LOW_0613CBA3_52F02E35.bin",
"mainFirmware": "2.7.6.0-057R_MPACT-MB5000-01-WR_12B56998_E58DD0CA.elf"
}
}
11
Integration with Receivers
Sample Beacon Data Sent By Receiver With SuperBeacons
{
"beacons": [{
"major": 2002,
"uuid": "FE913213-B311-4A42-8C16-47FAEAC938DB",
"bl": -1,
"ts": 1570812881878,
"mac": "a0:e6:f8:6c:70:62",
"sbMAC": "a4:34:f1:9f:ef:49",
"rssi": -86,
"rssiAt1m": -63,
"minor": 61
}, {
"major": 2501,
"uuid": "fe913213-b311-4a42-8c16-47faeac938ef",
"bl": -1,
"ts": 1570812882018,
"mac": "a0:e6:f8:6c:71:17",
"rssi": -73,
"rssiAt1m": -53,
"minor": 32
}, {
"major": 2500,
"uuid": "fe913213-b311-4a42-8c16-47faeac938ef",
"bl": -1,
"ts": 1570812882534,
"mac": "a0:e6:f8:6c:6f:5d",
"rssi": -73,
"rssiAt1m": -53,
"minor": 90
}],
"superBeacons": [{
"sbVer": 3,
"sbBL": 83,
"sbTS": 1570812881878,
"sbChnl": 39,
"sbRSSI": -63,
"sbMAC": "a4:34:f1:9f:ef:49",
"sbRSSIAt1m": -50
}, {
"sbVer": 2,
"sbBL": 85,
"sbTS": 1570812881879,
"sbChnl": 39,
"sbRSSI": -81,
"sbMAC": "a4:34:f1:9f:ee:37",
12
"sbRSSIAt1m": -50
}],
"receiver": {
"type": "FR",
"identity": {
"mac": "40:83:DE:D9:AE:BB"
}
}
}
Integration with Receivers
13
www.zebra.com
Loading...
