Zebra ZD62142-T2EF00EZ Product Data Sheet
SPECIFICATION SHEET
ZD620 PERFORMANCE DESKTOP THERMAL TRANSFER PRINTER
ZD620 4-Inch Performance Desktop
Thermal Transfer Printer
MAXIMUM PRINT QUALITY, EFFICIENCY AND MANAGEABILITY
When print quality, productivity, application flexibility and management simplicity matter, the Zebra ZD620 delivers. As the next
generation in Zebra’s thermal transfer desktop line, the ZD620 replaces Zebra’s popular GX Series and ZD500 printers, rising above
conventional desktop printers with premium print quality and state of the art features. Oering the most standard features of any
Zebra desktop printer, the ZD620 is designed to meet a wide variety of application requirements. An optional 10-button user interface
with a color LCD takes all the guesswork out of printer setup and status. The ZD620 runs Link-OS® and is supported by our powerful
Print DNA suite of applications, utilities and developer tools that deliver a superior printing experience through better performance,
simplified remote manageability and easier integration. The Zebra ZD620 — delivering the print speed, print quality and printer
manageability you need to keep your operations moving forward.
DEPLOYMENT AND APPLICATION FLEXIBILITY
Backwards compatibility with virtually any existing printer
With the ZD620, whether you are currently using a Zebra or
competitive printer, you’ll be able to use the same label formats
and applications you’re using today. The ZD620 supports both EPL
and ZPL printer languages. And with on printer Virtual Devices, part
of Zebra’s Print DNA suite of tools and utilities, the ZD620 can use
languages normally associated with other printer brands.
Comprehensive connectivity options
With comprehensive connection options, you can connect the
ZD620 to your existing wired and wireless networks, or directly
to any PC. Every ZD620 comes with Ethernet, Serial, USB 2.0
and USB Host, as well as Bluetooth Low Energy (BLE), which
enables printing from any iOS device. Wireless models include
fast 802.11ac Wi-Fi and Bluetooth 4.1. And using the included Print
Touch tag (NFC), users can simply tap a compatible mobile device
on the ZD620 to pair and print — as well as instantly access
PREMIER PRINTING PERFORMANCE
Best-in-class print speeds
The ZD620 delivers best-in-class print speeds — 8ips @ 203
dpi and 6ips @ 300 dpi — for maximum printer throughput
and productivity.
EASY TO USE PRACTICALLY NO TRAINING REQUIRED
New at-a-glance five LED status icons take
the guesswork out of printer status
The standard three-button user interface with five LED status
icons replaces the typical single button/single light interface
common in desktop printers. Users can instantly see what’s
needed to keep printers up and running, from replenishing
media to resolving printer issues.
Configuration is a snap with the optional
color LCD and 10-button user interface
It’s easy to set up and configure the ZD620 with the optional
10-button user interface and color LCD. The display changes
color when the printer is paused or in an error state, so users
can instantly identify and resolve an issue before productivity
is impacted.
Zebra’s extensive knowledge base of how-to videos.
Movable sensor for comprehensive media compatibility
While Zebra Certified Printer Supplies provide optimal printer
performance, the ZD620’s movable media sensor lets you use
virtually any media from any manufacturer, giving you the flexibility
to utilize supplies you may have on hand or continue to utilize an
existing supplies provider.
EASY TO MANAGE
Easily manage all your printers — all from a single location
The ZD620 supports Zebra Link-OS, a one-of-a-kind enterprise
printer operating system that makes it easier than ever to manage
and troubleshoot your networked printers from one remote
location. With optional Printer Profile Manager Enterprise, you
can manage one printer, a group of specific printers or all printers
anywhere in the world. Instantly discover every Link-OS printer
on your network, including the ZD620 and other Zebra mobile,
desktop and industrial printers — there’s no need to walk through
the facility to locate, configure or troubleshoot printers. And an
intuitive browser-based interface lets you see printer status at a
glance, complete with information that allows you to quickly triage
printer issues to minimize downtime.
SPECIFICATION SHEET
ZD620 PERFORMANCE DESKTOP THERMAL TRANSFER PRINTER
Seamless integration with your device management system
With our MDM Connectors, you can easily integrate networked
ZD620 printers into your AirWatch or SOTI MobiControl device
management system.
Easily configure non-networked printers
The USB Host port makes it easy to connect to all your external
devices, including keyboards and scanners, and can also be
utilized to upgrade printer firmware automatically and set up
new printer configurations.
Maximize uptime with Zebra Visibility Services
If you’re still tracking your printers manually, then you are likely
missing out on information that could save you money. With
Zebra, you can choose powerful visibility service options that
deliver critical insight into the information you need to prevent
printer downtime. Our Asset Visibility Service (AVS) provides the
basic health information and proactive steps required to keep
your ZD620 printers up and running — all for just pennies a day.
The full-featured Operational Visibility Service (OVS) allows you
to monitor just about any aspect of your Zebra printer, as well
service and repair status. See the current status and disposition
of all of your printers, printers at a specific site, specific printer
models or a specific printer — and much more.
INNOVATIVE FEATURES FOR THE LOWEST TCO
Zebra Print DNA – transforming printers from the inside
Print DNA is the genetic code that injects business-catalytic
capabilities into our Link-OS printers through a unique combination
of innovative applications, utilities and developer tools. The result
is a superior printing experience through better performance,
simplified remote manageability and easier integration.
Lower your costs with a high capacity ribbon
Intelligent dual-ribbon handling allows the ZD620 to accept either
74 m/244 ft. or high capacity 300 m/ 984 ft. ribbons. The 300 m
ribbon reduces ribbon changes by 75 percent for fewer workflow
disruptions. And since the high capacity ribbon costs less per meter
than the standard ribbon, you’ll also save on the cost of supplies.
A new level of print quality for desktop printing
The ZD620 brings Zebra’s advanced industrial printer technology
to the compact desktop printer. Previously available only on
industrial printers, the ZD620’s Media dancer maintains even
tension on the media roll to ensure maximum quality on every
label regardless of print speed.
Sharp 300 dpi printing
With 300 dpi printing, you can support more applications. The
high image quality enables printing of small 2D labels or labels that
require graphics, such as a logo or icon. And if you don’t need 300
dpi printing today, you can easily add it at any time, right on site.
Tidier and safer installations
When you choose the optional power supply accessory, the power
supply and all but one power cord are hidden from view, improving
aesthetics as well as worker and customer safety.
Consistently exceptional Zebra Certified Supplies
Printing supplies can impact everything from printhead lifespan
to operational eciency. That’s why we design, produce and
rigorously pretest our own line of thermal printing supplies to
ensure consistent, optimized performance in your Zebra printer
—and peace of mind for you. For industry-leading quality, service
and thermal printing expertise, choose Zebra Certified Supplies.
Maximize the Availability of Your Printers
TM
with Zebra OneCare
Zebra OneCare Support Services enable your critical business
operations. With multiple service levels to choose from, you can
protect your investment while achieving maximum uptime and
peak performance. Get unmatched support — direct from the
manufacturer — with live agent telephone technical support,
comprehensive coverage including accidental damage, and
defined repair & turn-around times. Plus optional services
like Device Commissioning, Onsite Repair, Battery Refresh &
Replacement Services and Express Shipping let you tailor your
service plan to your individual business needs.
Services
THE ZD620 MAXIMUM EFFICIENCY, PRINT QUALITY AND PRINTER MANAGEMENT.
FOR MORE INFORMATION, VISIT WWW.ZEBRA.COM/ZD620 OR
OUR GLOBAL CONTACT DIRECTORY AT WWW.ZEBRA.COM/CONTACT
