ET80/ET85 Battery Cover
Installation Guide
CAUTION: Be aware of the orientation of the battery cover. Failure to
replace the battery cover properly may cause damage.
1. Align the tabs on the underside of the cover with the slot around the battery
well.
2. Ensure that the chamfer on the battery cover is at the bottom left corner of the
device.
3. Carefully press down around the edges of the cover. Make sure that the cover
is seated properly.
ZEBRA and the stylized Zebra head are trademarks of
Zebra Technologies Corp., registered in many
jurisdictions worldwide. All other trademarks are the
property of their respective owners. © 2021 Zebra
Technologies Corp. and/or its affiliates.
All rights reserved. | zebra.com
MN-004281-01EN Rev A
