ZALMAN ZM460-APS User Manual

▣

The following safety precautions and directions for use are meant to prevent accident and injury.
Please read thoroughly before using the product.

1. Safety Precautions

Warnings

Serious injury or death can occur.

▶

Opening the cover of the product while the power cord
is plugged into the outlet can result in electrocution or

critical damage to the product.

▶Handling the power cord with wet hands can result

in electrocution.

▶Inserting fingers or metallic objects into the cooling

fan can result in injury or electrocution.

Cautions

Minor injury can occur. May degrade product
conditions or cause malfunction.

▶Operating in an extremely cold or hot environment

can degrade product performance and lifespan.

▶ Allowing liquid to get into the product can result in

malfunction.

▶Operating in a humid or non-ventilated environment

can reduce product lifespan.

2. Components

3. Notes on Installation

1) One Power Supply

2) One FAN Multi-connector (ZM-MC1)

󳢹 (For supplying power to an extra fan. See page 5 for details.)

3) One S-ATA power convert cable

4) One PCI-Express VGA SLI sub-Cable for power conversion

5) One Power Cord for AC Power Source (Not included in some countries)

6) One User's Manual

7) Zalman Cable Tie

※ To ensure safe and easy installation, first read the Safety Precautions above, then read the

following notes.

▣ Plugging the main power connector P1 into the main board while the product is connected to the

AC power source may result in damage to the main board.

▣ Do not insert the DC output connectors with too much force into devices as the shape of the connector

is meant to prevent incorrect insertion.

▣ After installation, if the Power On light on the case does not light up when the main power button

is pressed, some devices may be plugged in incorrectly or the main board may be faulty.
Please double-check the installation.

* For more information on the product, please visit our website at www.zalman.co.kr.

- 1 -

- 2 -

* For more information on the product, please visit our website at www.zalman.co.kr.

4. The Zalman Advantage

With the goal of enhancing your computing environment, all Zalman Tech products are ultra-quiet.
This product is an ultra quiet 460W ATX Ver. 2.03 / ATX12V Ver. 2.01 power supply supporting
SLI-capable Intel LGA775 Pentium 4 & AMD Athlon 64/64 FX CPU equipped systems.

By implementing heat-sensor circuitry that controls the cooling fan’s speed (rpm) in relation to
the temperature within the power supply, noise has been greatly reduced.
The graph below shows the CNPS characteristics of our product.

※CNPS (Computer Noise Prevention System) refers to a system that reduces a conventional

computer’s noise (30dB or more) to an inaudible level (20dB or less). In order to create a true
noise-free computer, Zalman’s other noise-free products should be used together with this product.

▣ CNPS (Computer Noise Prevention System) with Auto Control Cooling Fan

By implementing Active PFC, the power factor (PF) is improved from 75% (Passive PFC) to 96%
(230VAC, Full load), while harmful harmonic frequencies are reduced below regulatory requirements.

▣ Improving Power Factor & Eliminating Harmonics through Active PFC

Designed with a high switching frequency and low power-loss circuitry, the efficiency of this
product exceeds 80%

(230VAC, Full load).

▣

High Efficiency Design

◈

Fig.1: Noise Level(dB) Changes In relations to Power Supply's Internal Temperature

Noise Level of ZM460-APS (in dB)

※

The graph above shows that the ZM460-APS in “Noiseless” or “Silent” mode can operate when
the power supply's internal temperature is kept below 56

℃

. This information is in compliance
with the 2nd Revision of ISO7779, an international standard for noise level measurement.
Results may vary for different system configuration and/or the test environment.
