Engineered for the serious pro audio user, the U15 is among the most
advanced, most versatile and most efficient high-powered portable P.A.
boxes available on the market today. The U15 is a radical loudspeaker
cabinet design utilizing the patented Unity™ Summation Aperture Horn
Technology invented by loudspeaker designer Tom Danley.

The U15 provides remarkably even high/mid frequency distribution from
its 60° x 60° horn assembly. The combination of that conical, constant
directivity horn, a 15-inch high power woofer and our unending attention
to details, right down to the ideal trapezoidal cabinet design, has yielded
an extremely versatile speaker. The U15's Unity™ horn combines a
single 1-inch-throat (1.75" diaphragm) compression driver with three
5-inch ceramic magnet midrange drivers firing through time-aligned slots
in the horn-wall. This seamlessly blends the mid and high frequencies
while providing exceptional power capacity and clarity from 300Hz
to 20kHz.

U15

The U15 comes with a high-definition 3-way passive crossover featuring
our exclusive PTC™ non-interruptive horn protection. However it can be
easily bi-amplified by way of a switch on the rear jackplate, and using
the optional UP15 Unity™ processor, designed specifically to optimize
the sonic characteristics of the U15. The UP15 has been developed to
ensure trouble free, "plug-and-play" operation and further offers a
subwoofer output.

The compact and ultra efficient U15 is a trapezoidal shaped, 800 watt
cabinet with a carefully chosen crossover point to seamlessly match the
directivity characteristics of the conical horn to the neodymium woofer.
With such a compact footprint and weight, the U15 easily finds its home

side fill, front or down fill or virtually

inish

,

With pre-recorded

without the need to

,

drum monitor

,

as a FOH speak
any situation where a professional quality sound reinforcement system
is required. The unparalleled sonic clarity and smooth frequency
response also mak
music the U15 has the hi-fidelity to put it on par with some of the best
studio reference monitors. But unlike traditional studio reference
monitors

atts at 4ohms

w
tight pack arraying in mind.

Looking at a polar plot for a 3 box, tight-pack array one would notice
how extremely well behaved it is. Furthermore, due to the nature of the
conical horn,
vertical, or off-axis rotation put upon it. It acts the same on all vertical

making it ideal for use upright or on its' side

,

axis
ever rotate the horn.

U15 - Black Ozite (Carpet) F
U15B - Black Ultrathane (Painted) Finish

er

es it great for music playback.

the U15 is capable if putting out a very high-efficiency 1000

,

The trapezoidal shape was designed with multi-box,

.

the polar pattern remains quite constant regardless of any

Features

att 3-Way Full Range Loudspeaker

• 2000

• Max SPL 135dB Peak (129dB Continuous)

• Unique 60

• All four component drivers mounted in a Unity™ horn are

• No self-interference between individual components

• Nine rigging points and internal standmount adapter allow

• 15mm 11-ply birch cabinet construction

• FinishMade in Canada

W

(1000 Watts Program)

° x 60° Unity™ horn assembly

(combines mid and high frequency drivers on conical horn)

mechanically time-aligned to measure and act lik

e a single

point source

for all possible mounting and flying configurations

yorkville.com

unity

Passive Series

Specifications

System Type Three-Way

Active or Passive Passive

Program Power (Watts) 1000 Watts (2000 Watts Peak)

Biampable Yes

Nominal Impedance (Ohms) 4

Sensitivity (dB @1Watt/1m) 98

Max SPL (dB) 131dB Peak (128dB Continuous)

Frequency Response (Hz +/- 3dB) 50 - 20k

Crossover Frequency (Hz) 300 / 1250

Driver Configuration 15 inch / 3x5 inch / 1.75 inch

HF Driver(s) 1.75 inch polyester

HF Impedance (Ohms) 8

HF Horn Conical Unity™ horn (1 inch throat)

HF Dispersion (°H x °V) 60 x 60

HF Protection PTC™

MF Driver(s) 3 x 5 inch ceramic 1 inch voicecoil

MF Horn Conical Unity™ horn

MF Dispersion (°H x °V) 60 x 60

LF Driver(s) 15-inch w/ 3-inch voicecoil

LF Impedance (Ohms) 4

Inputs - 1/4" Jacks 2

Inputs - Speak

Feet Yes

Flying Hardware 3/8inch x 9 (all corners)

Bar Handles 2 Side

ole Mount

P

Enclosure Materials 15mm 11-ply Birch

Grille

Covering / Finish Black Ozite (Carpet)

Optional Covering / Finishes Black Ultrathane Paint (U15B)

Processor (optional)

Dimensions (DWH xbackW, inches) 16.25 x 19.25 x 34 x 9.5

Dimensions (DWH xbackW, cm) 42 x 49 x 87 x 24

Weight (lbs/kg) 80.7 / 36.6

on 4-pin

Adapter (1 3/8"-3.5cm)

U15

2

Yes

Perforated Metal

UP15

Specifications subject to change without notice
