Yealink SIP-T19 E2, SIP-T19P E2 User Manual

Yealink IP PHONE

SIP-T19 E2 & SIP-T19P E2

www.yealink.com

Quick Start Guide

Applies to firmware version 53.81.0.15 or later.

(V81.90)

Packaging Contents

The following items are included in your package. If you find anything missing, contact your system
administrator.

Handset Cord

Ethernet Cable

Quick Start Guide

(1.5m CAT5E UTP Cable)

IP Phone

Handset

Stand

Power Adapter
(Optional)

Note: The models displayed on the phone differ from each other. The packaging content "IP Phone" listed above

takes a SIP-T19P E2 IP phone as an example.
We recommend that you use the accessories provided or approved by Yealink. The use of unapproved
third-party accessories may result in reduced performance.

Assembling the Phone

Assembling the Phone

1.

Attach and detach the stand, as shown below:

a) Attach the stand:

Desk Mount Method

。

180

Wall Mount Method

Note: The hookswitch tab has a lip which allows the handset to stay on-hook when the IP phone is mounted

vertically.

1

b) Detach the stand:

2. Connect the handset and optional headset, as shown below:

Note:

The headset should be purchased separately.

3. Connect the network and power, as shown below:

You have two options for network and power connections. Your system administrator will advise you
which one to use.

PC Connection
(Optional)

PC

Power Adapter
(DC 5V)

A

AC Power Option

B

PoE ( Power over
Ethernet ) Option

PC

IEEE 802.3af compliant
PoE Hub/Switch

Note:

The IP phone should be used with Yealink original power adapter (5V/600mA) only. The use of the

PC Connection
(Optional)

third-party power adapter may cause the damage to the phone. If you are connecting a PC to your phone,
we recommend that you use the Ethernet cable provided by Yealink.

If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the hub/switch
is PoE-compliant. PoE is only applicable to the SIP-T19P E2 IP phone.

2
