Yealink MCore MCore Quick Start Guide

MCore
www.yealink.com
English | 简体中文
Quick Start Guide (V1.0)
MCore
Bracket
+
Power Adapter
We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in poor performance.
Screwdriver
Machine Screw
HDMI Cable×2
2
Expansion Screw
and Self-tapping Screw
1.8M
+ +
4 4
Velcro×2
Quick Start Guide
MCore Connection
2
Push the buttons to open
1
Display/Projector
Display/Projector
3 4
When starting up the MCore for the first time, you need to connect a mouse to complete the initial
configuration. We recommend that you use the wireless mouse and keyboard kit.
MCore itself has integrated cable lock feature, and no additional cable lock box is needed to lock
the cable.
1
USB device
USB device
USB device
USB device
Internet
MTouch
Fasten the Mcore with screws
MCore Installation
.
Mount on the Wall
60mm
60mm
Before mounting the bracket, you need to confirm the direction of the MCore installation. Once the bracket is mounted, the installation direction of the MCore cannot be changed.
.
Stick to the Table
You can stick the MCore on the top, sides or bottom of the table.
2
包装清单
MCore 挂架版
电源适配器
我们推荐使用由Yealink提供或经Yealink认可的配件和线缆,使用未经认可的第三方配件和线缆可能 会导致性能的下降。
螺丝刀
机械螺丝 快速入门指南
1.8M HDMI 线×2
膨胀螺丝
和自攻螺丝
+ +
+
2
魔术贴x2
4 4
连接MCore
2
按下两边按钮打开
1
3
显示设备
显示设备
USB设备
USB设备
4
USB设备
USB设备
连接网络
MTouchⅡ
用螺丝锁住MCore
首次启动时,你需要在MCore上接一个鼠标来完成初始化配置,我们推荐使用无线键鼠套装。
MCore已集成锁线功能,不需要额外的锁线盒来锁住线缆。
3
安装MCore
.
挂墙
60mm
60mm
固定挂墙架前,需确认MCore要安装的方向,挂墙架一旦固定,MCore的安装方向随之固定。
.
固定在桌子上
MCore可贴在桌子的表面,两侧或底部。
4
Regulatory Notices
Operating Ambient Temperatures
Operating temperature: +32 to 104°F (0 to 40°C) Relative humidity: 5% to 90%, noncondensing Storage temperature: -22 to +160°F (-30 to +70°C)
Warranty
Our product warranty is limited only to the unit itself, when used normally in accordance with the operating instructions and the system environment. We are not liable for damage or loss resulting from the use of this product, or for any claim from a third party. We are not liable for problems with Yealink device arising from the use of this product; we are not liable for financial damages, lost profits, claims from third parties, etc., arising from the use of this product.
Explanation of the symbols DC symbol
is the DC voltage symbol.
WEEE Warning symbol
To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately.
Restriction of Hazardous Substances Directive (RoHS)
This device complies with the requirements of the EU RoHS Directive. Statements of compliance can be obtained by contacting support@yealink.com.
Safety Instructions
Save these instructions. Read these safety instructions before use!
General Requirements
Before you install and use the device, read the safety instructions carefully and observe the situation during operation. During the process of storage, transportation, and operation, please always keep the device dry and clean, avoid collision and crash. Please attempt not to dismantle the device by yourself. In case of any discrepancy, please contact the appointed maintenance center for repair. Please refer to the relevant laws and statutes while using the device. Legal rights of others should be respected as well.
Environmental Requirements
Place the device at a well-ventilated place. Do not expose the device under direct sunlight. Keep the device dry and free of dusts. Do not place the device on or near any inflammable or fire-vulnerable object, such as rubber-made materials. Keep the device away from any heat source or bare fire, such as a candle or an electric heater.
Operating Requirements
Do not let a child operate the device without guidance. Do not let a child play with the device or any accessory in case of accidental swallowing. Please use the accessories provided or authorized by the manufacturer only. The power supply of the device shall meet the requirements of the input voltage of the device. Please use the provided surge protection power socket only. Before plugging or unplugging any cable, make sure that your hands are completely dry. Do not spill liquid of any kind on the product or use the equipment near water, for example, near a bathtub, washbowl, kitchen sink, wet basement or near a swimming pool.
During a thunderstorm, stop using the device and disconnect it from the power supply. Unplug the power plug and the Asymmetric Digital Subscriber Line (ADSL) twisted pair (the radio frequency cable) to avoid lightning strike.
If the device is left unused for a rather long time, disconnect it from the power supply and unplug the power plug. When there is smoke emitted from the device, or some abnormal noise or smell, disconnect the device from the power supply, and unplug the power plug immediately. Contact the specified maintenance center for repair. Do not insert any object into equipment slots that is not part of the product or auxiliary product. Before connecting a cable, connect the grounding cable of the device first. Do not disconnect the grounding cable until you disconnect all other cables.
Cleaning Requirements
Before cleaning the device, disconnect it from the power supply. Use a piece of soft, dry and anti-static cloth to clean the device. Keep the power plug clean and dry.
Troubleshooting
The unit cannot supply power to device other than Yealink device. There is a bad connection with the plug.
1. Clean the plug with a dry cloth.
2. Connect it to another wall outlet. The usage environment is out of operating temperature range.
1. Use in the operating temperature range. The cable between the unit and the Yealink device is connected incorrectly.
1. Connect the cable correctly. You cannot connect the cable properly.
1. You may have connected a wrong Yealink device.
2. Use the correct power supply. Some dust, etc., may be in the port.
1. Clean the port. Contact your dealer or authorized service facility for any further questions.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
IC Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause interference; and (2) this device must accept any interference, including interference that may cause undesired operation of the device. CAN ICES-3(B) Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage; (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.NMB-3(B)
Contact Information
YEALINK NETWORK TECHNOLOGY CO.,LTD.
309, 3rd Floor, No.16, Yun Ding North Road, Huli District, Xiamen City, Fujian, P.R. C
YEALINK (EUROPE) NETWORK TECHNOLOGY B.V.
Strawinskylaan 3127, Atrium Building, 8th floor, 1077ZX Amsterdam, The Netherlands
YEALINK (USA) NETWORK TECHNOLOGY CO., LTD.
999 Peachtree Street Suite 2300, Fulton, Atlanta, GA, 30309, USA
Made in China
About Yealink
Yealink is a global leading provider of enterprise communication and collaboration solutions, offering video
conferencing service to worldwide enterprises. Focusing on research and development, Yealink also insists on
innovation and creation. With the outstanding technical patents of cloud computing, audio, video and image
processing technology, Yealink has built up a panoramic collaboration solution of audio and video conferencing
by merging its cloud services with a series of endpoints products. As one of the best providers in more than 140
countries and regions including the US, the UK and Australia, Yealink ranks No.1 in the global market share of
SIP phones shipments.
Technical Support
Visit Yealink WIKI (http://support.yealink.com/) for the latest firmware, guides, FAQ, Product documents, and
more. For better service, we sincerely recommend you to use Yealink Ticketing system
(https://ticket.yealink.com) to submit all your technical issues.
Web: www.yealink.com
©2020
430104001308
Copyright TECHNOLOGY CO.,LTD
YEALINK(XIAMEN) NETWORK
.All rights reserved.
