Yaskawa RC5 User Manual
YASKAWA - RC5
Power Regenerative Unit
Instruction Manual
Type:
Models:
To properly use the product, read this manual thoroughly and retain
for easy reference, inspection, and maintenance. Ensure the end user
receives this manual.
CIMR-R5U
200 V Class, Three-Phase Input: 3.7 to 37 kW
400 V Class, Three-Phase Input: 3.7 to 75 kW
MANUAL NO. TOEP C710656 01C
This Page Intentionally Blank
Copyright 2008 YASKAWA ELECTRIC CORPORATION. All rights reserved.
All rights reserved. No part of this publication may be reproduced, stored in a retrieva l system, or transmitted, in any form or by any means, mechanical,
electronic, photocopying, recording, or otherwise, without the prior written permission of Yaskawa. No patent liability is assumed with respect to the use of the
information contained herein. Moreover, because Yaskawa is constantly striving to im prove its high-quality products, the information contained in this manual
is subject to change without notice. Every precaution has been taken in the prepa ration of this manual. Yaskawa assumes no responsibility for errors or
omissions. Neither is any liability assumed for damages resulting from the use of the information contained in this publication
2 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
Table of Contents
I. PREFACE.......................................................................................................................................... 3
i.1 Conditions of Acceptability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
NEC, CEC and UL Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CSA Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
i.2 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Supplemental Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
i.3 Notes for Safe Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Receiving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Maintenance and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warning Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1. RECEIVING ..................................................................................................................................... 11
1.1 Section Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.2 Inspection Checkpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Receiving Checkpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checking the Nameplate Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2. INSTALLATION............................................................................................................................... 15
2.1 Section Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.2 Checking Installation Site. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installation Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Controlling the Ambient Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Protecting the Power Regenerative Unit from Foreign Matter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3 Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Models of 200 V/400 V 30 kW and Lower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Models of 200 V/400 V 37 kW and Higher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.5 Removing and Replacing the Front Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6 Removing and Replacing the LCD Monitor/Digital Operator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Removing the LCD Monitor/Digital Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Replacing the LCD Monitor/Digital Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3. WIRING............................................................................................................................................ 23
3.1 Section Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.2 Connection Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Connection Diagram with Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3 Selecting Peripheral Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Selecting Heavy Duty or Standard Duty RC5 Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Main Circuit Input Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Power Coordination and Current Suppression Reactors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Wiring Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.4 Wiring Main Circuit Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Required Wire Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Closed-Loop Connectors Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.5 External Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Main Circuit Terminal Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Control Circuit Terminal Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 3
4. OPERATION.................................................................................................................................... 33
4.1 Section Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.2 Checks Prior to Main Power Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.3 Setting the Power Supply Voltage Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.4 Using the Digital Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.5 Digital Operator Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Navigating Digital Operator Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Operation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.6 Power On/Off Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.7 Run Command Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Auto Run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Manual Run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5. MAINTENANCE AND INSPECTION............................................................................................... 45
5.1 Section Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.2 Periodic Inspection and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Daily Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Periodic Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Periodic Maintenance of Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6. TROUBLESHOOTING .................................................................................................................... 49
6.1 Fault Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.2 Minor Fault Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6.3 Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7. SPECIFICATIONS........................................................................................................................... 55
A. PARAMETER LIST ......................................................................................................................... 59
Revision History
4 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
i
Preface
YASKAWA’s RC5 is a power regenerative unit which has both braking and regenerative functions. This instruction
manual describes installation, maintenance and inspection, troubleshooting, and specifications of the RC5. Read this
instruction manual thoroughly before operation.
I.1 CONDITIONS OF ACCEPTABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
I.2 SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
I.3 NOTES FOR SAFE OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 3
i.1 Conditions of Acceptability
i.1 Conditions of Acceptability
◆ NEC, CEC and UL Compliance
In order to comply with the NEC, CEC and UL, the following conditions of use must be strictly adhered to:
■ Surge Protector Installation
• An MOV must be installed on the input of the RC5 Unit.
■ Current Suppression Reactor Installation
• The Current Suppression Reactor must be installed as shown in Figure 3.1.
■ Terminal Blocks
• The Power Terminal Blocks of the RC5 unit are for factory wiring use only.
■ Installation Environment
• Install the RC5 Unit in a protective enclosure suitable to its environment.
◆ CSA Standards Compliance
The RC5 is CSA certified as following.
■ Products
CLASS 3211 06
INDUSTRIAL CONTROL EQUIPMENT
Motor Controllers Miscellaneous
CLASS 2411 02
ELEVATOR EQUIPMENT
Enclosed Elevator and Escalator Electrical Equipment
■ Applicable Requirements
CAN/CSA C22.2 No.0.4-04
Bonding of Electrical Equipment
CAN/CSA C22.2 No.14-05
Industrial Control Equipment
CSA B44.1-04/ASME A17.5-2004
Elevator and Escalator Electrical Equipment
Figure i.1
CSA B44.1 /
ASME A17.5
Figure i.1 CSA B44.1-04/ASME A17.5-2004 Mark
4 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
i.2 Safety Information
W ARNING
DANGER
W ARNING
CAUTION
NOTICE
i.2 Safety Information
Read this instruction manual thoroughly before installation, operation, maintenance or inspection of the RC5. In this manual, NOTES FOR SAFE
OPERATION are classified as “WARNING” or “CAUTION.”
◆ Supplemental Safety Information
General Precautions
• Some drawings in this manual are shown with the protective cover or shields removed, in order to describe detail with more clarity. Make sure all covers and shields
are replaced before operating this product.
• This manual may be modified when necessary because of improvement of the product, modification, or changes in specifications.
• Such modifications are denoted by a revised manual No.
• To order a copy of this manual, if your copy has been damaged or lost, contact your YASKAWA representative.
• YASKAWA is not responsible for any modification of the product made by the user, since that will void your guarantee.
Read and understand this manual before installing, operating or servicing this drive. The drive must be installed according to this manual and local
codes.
The following conventions are used to indicate safety messages in this manual. Failure to heed these messages could result in serious or possibly
even fatal injury or damage to the products or to related equipment and systems.
Indicates a hazardous situation, which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
WARNING! will also be indicated by a bold key word embedded in the text followed by an italicized safety message.
Indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury.
CAUTION! will also be indicated by a bold key word embedded in the text followed by an italicized safety message.
Indicates a property damage message.
NOTICE: will also be indicated by a bold key word embedded in the text followed by an italicized safety message.
Even items described in a Caution may result in a vital accident in some situations. In either case, follow these important notes.
Note: These are steps to be taken to insure proper operation.
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 5
i.3 Notes for Safe Operation
CAUTION
CAUTION
W ARNING
CAUTION
i.3 Notes for Safe Operation
◆ Receiving
Do not install or operate any power regenerative unit which is damaged or has missing parts.
Failure to observe this caution may result in personal injury or equipment damage (Refer to page 12)
◆ Installation
Lift the cabinet by the base. When moving the unit, never lift by the front cover or the front panel.
Otherwise, the main unit may be dropped causing damage to the unit. (Refer to page 16)
Mount the power regenerative unit on nonflammable material (i.e. metal).
Failure to observe this caution can result in a fire. (Refer to page 16)
When mounting units in an enclosure, install a fan or other cooling device to keep the intake air temperature below 45°C.
Overheating may cause a fire or damage to the unit. (Refer to page 16)
In order to comply to UL regulations, the MOV and current suppression reactor must be installed on the input of the R5 unit.
Refer to the installation diagram. (Refer to page 16)
◆ Wiring
Only commence wiring after verifying that the power supply is turned OFF.
Failure to observe this warning can result in an electric shock or a fire. (Refer to page 24)
Wiring should be performed only by qualified personnel.
Failure to observe this warning can result in an electric shock or a fire. (Refer to page 24)
Make sure to ground the ground terminal before connecting the other terminals.
Failure to observe this warning can result in an electric shock or a fire. (Refer to page 24)
Install adequate branch short circuit protection according to applicable codes.
Failure to comply could result in damage to the drive.
The device is suitable for circuits capable of delivering up to 100 kA RMS Symmetrical Amperes, 240 Vac maximum (200 V Class), 480 Vac
maximum (400 V Class) or equivalent to the SCCR rating of the VFD to which it is connected - whichever value is less.
R5 Series of Power Regenerative devices shall be connected to a VFD which incorporates Solid State Short Circuit Protection Circuitry and was
found to comply with the High Fault Current Short Circuit Test.
Verify that the power regenerative unit rated voltage coincides with the AC power supply voltage.
Failure to observe this caution can result in personal injury or a fire. (Refer to page 24)
Do not perform a withstand voltage test of the power regenerative unit.
It may cause semi–conductor elements to be damaged. (Refer to page 24)
Connect the power coordinating reactor and the power suppressing reactor as described in this instruction manual.
Improper connection may cause a fire. (Refer to page 24)
Verify that the rated voltage of the power regenerative unit coincides with the rated voltage of the power regenerative unit to be
connected.
Failure to observe this caution can result in a fire. (Refer to page 24)
Tighten terminal screws.
Failure to observe this caution can result in a fire. (Refer to page 24)
6 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
i.3 Notes for Safe Operation
W ARNING
CAUTION
W ARNING
CAUTION
◆ Operation
Only turn ON the input power supply after replacing the front cover or the terminal cover. Do not remove the cover while power is on.
Failure to observe this warning can result in an electric shock. (Refer to page 34)
Never operate the digital operator or other switches when your hand is wet.
Failure to observe this warning can result in an electric shock. (Refer to page 34)
Never touch the terminals while power is on, even if the power regenerative unit stops.
Failure to observe this warning can result in an electric shock. (Refer to page 34)
Never touch the heatsink or input reactors since their temperature may be very high.
Failure to observe this caution can result in harmful burns to the body. (Refer to page 34)
All the parameters of the power regenerative unit have been preset at the factory. Do not change the settings unnecessarily.
The power regenerative unit may be damaged. (Refer to page 34)
◆ Maintenance and Inspection
Never touch high-voltage terminals in the power regenerative unit.
Failure to observe this warning can result in an electric shock. (Refer to page 46)
Perform maintenance or inspection only after verifying that the CHARGE LED goes OFF, after the main circuit power supply is turned
OFF.
The capacitors are still charged and can be dangerous. (Refer to page 46)
Only authorized personnel should be permitted to perform maintenance, inspections or parts replacement.
[Remove all metal objects (watches, bracelets, etc.) before operation.] (Use tools which are insulated against electric shock.)
Failure to observe this warning can result in an electric shock. (Refer to page 46)
Never modify the product.
Failure to observe this warning can result in an electric shock or personal injury and will invalidate the guarantee. (Refer to page 46)
The power regenerative unit employs semi-conductor elements. Do not touch the CMOS elements.
They are easily damaged by static electricity. (Refer to page 46)
Do not connect or disconnect wires or connectors while power is applied to the circuit.
Failure to observe this caution can result in personal injury. (Refer to page 46)
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 7
i.3 Notes for Safe Operation
Model CIMR-R5U23P7
656RC5
WARNING
-Riskofelectricshock.
Read manual before installing.
Wait 5 minutes for capacitor discharge after
disconnecting power supply.
To conform to requirements, make sure to
ground the supply neutral.
AVERTISSEMENT
- Risque de décharge électrique
Lisez le manuel avant installation.
Attendez 5 minutes après la coupure de l’ alimentation
électrique afin que les condensateurs soient complètement décharges.
Assurez vous de connecter a la masse le fil du neutre
afin d’ être en accord avec la règlementation .
◆ Warning Label
A warning label is displayed on the front cover of the power regenerative unit, as shown below. Follow these instructions when handling the power
regenerative unit.
■ Warning Label
8 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
1
Receiving
This chapter describes how to verify the RC5 after delivery to the user.
1.1 SECTION SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
1.2 INSPECTION CHECKPOINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 11
1.1 Section Safety
CAUTION
1.1 Section Safety
Do not install or operate any power regenerative unit which is damaged or has missing parts.
Failure to observe this caution may result in personal injury or equipment damage.
12 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
1.2 Inspection Checkpoints
1.2 Inspection Checkpoints
◆ Receiving Checkpoints
Table 1.1 Checkpoints
Checkpoints Description
Does the power regenerative unit model number correspond with the
purchase order?
Are any parts damaged? Visually check the exterior and verify that there was no damage during transport.
Is hardware properly seated and securely tightened?
If any of the above checkpoints are not satisfactory, contact your YASKAWA representative.
◆ Checking the Nameplate Data
■ Nameplate Data
Example of standard domestic model CIMR-R5U2011.
Figure1.1
Check the model number on the nameplate on the side of the RC5. (Refer to Figure 1.2.)
Remove the front cover of the power regenerative unit.
Check all visible hardware with appropriate tools.
Figure 1.1 Nameplate Data
■ Model Designation
Figure1.2
CIMR - R5 U 2 011 1 A
Power Regenerative
Unit
VS - 656RC5 Series
Symbol
U
A
Symbol
2 3-phase 200 V class
4 3-phase 400 V class
■ Protective Structure
Specifications
Standard domestic model
Japan standard model
Volta ge
Symbol Max. applicable motor output
3P7 3.7kW
5P5
to
37
“P” indicates the decimal point.
Figure 1.2 Model Designation
• Open Chassis Type (IEC IP00)
Protected so that parts of the human body cannot reach electrically charged parts from the front when the Power regenerative unit is mounted in a
control panel.
• Enclosed Wall-mounted Type (IEC IP20, NEMA 1)
The power regenerative unit is structured so that the power regenerative unit is shielded from the exterior, and can thus be mounted to the interior
wall of a standard building (not necessarily enclosed in a control panel). The protective structure conforms to the standards of NEMA 1 in the
USA.
Version (Enter the specifications
form number when special specifications are required.)
No.
0 Open chassis (IEC IP00)
1
5.5kW
37kW
Protective Structure
Enclosed wall-mounted
(IEC IP20, NEMA1)
to
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 13
1.2 Inspection Checkpoints
This page intentionally blank.
14 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
2
Installation
This chapter describes the configuration, location and space when mounting the RC5.
2.1 SECTION SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2.2 CHECKING INSTALLATION SITE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3 CLEARANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.5 REMOVING AND REPLACING THE FRONT COVER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6 REMOVING AND REPLACING THE LCD MONITOR/DIGITAL OPERATOR. . . . . . . . . . . . . . . . . . . . . . 22
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 15
2.1 Section Safety
CAUTION
2.1 Section Safety
Lift the cabinet by the base. When moving the unit, never lift by the front cover or the front panel.
Otherwise, the main unit may be dropped causing damage to the unit.
Mount the power regenerative unit on nonflammable material (i.e. metal).
Failure to observe this caution can result in a fire.
When mounting units in an enclosure, install a fan or other cooling device to keep the intake air temperature below 45°C.
Overheating may cause a fire or damage to the unit.
16 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
2.2 Checking Installation Site
2.2 Checking Installation Site
◆ Installation Site
Install the power regenerative unit under the following conditions.
NOTICE: Do not install the power regenerative unit to an area greater than pollution degree 2 (UL standard).
Typ e Ambient Operating Temperature Humidity
Enclosed wall-mounted –10 to +40°C 90% RH or less (no condensation)
Open chassis –10 to +45°C 90% RH or less (no condensation)
Protection covers are attached to the top and bottom of the power regenerative unit. Be sure to remove the protection covers before installing a 200
or 400 V Class power regenerative unit with an output of 30 kW or less in a panel.
To ensure proper performance and long operating life, follow the recommendations below when choosing a location for installing the RC5. Make
sure the power regenerative unit is protected from the following conditions:
• Extreme cold and heat.
Use only within ambient temperature range: -10°C to +40°C
• Rain, moisture. (For enclosed wall-mounted type)
• Oil sprays, splashes
• Salt spray.
• Direct sunlight. (Avoid using outdoors.)
• Corrosive gases or liquids.
• Dust or metallic particles in the air. (For enclosed wall-mounted type)
• Physical shock, vibration.
• Magnetic noise. (Example: welding machines, power devices, etc.)
• High humidity.
• Radioactive materials.
• Combustibles: thinners, solvents, etc.
◆ Controlling the Ambient Temperature
To enhance the reliability of operation, the power regenerative unit should be installed in an environment free from extreme temperature increases. If
the power regenerative unit is installed in an enclosed environment, such as a box, use a cooling fan or air conditioner to maintain the internal air
temperature below 45°C.
◆ Protecting the Power Regenerative Unit from Foreign Matter
Place a cover over the power regenerative unit during installation to shield it from metal power produced by drilling.
Always remove the cover from the power regenerative unit after completing installation. Otherwise, ventilation will be reduced, causing the power
regenerative unit to overheat.
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 17
2.3 Clearances
50 mm or more (1.97 in)
30 mm or more (1.18 in)
*
30 mm or more
(1.18 in)
50 mm or more (1.97 in)
*
120mmormore
(4.72 in)
120mmormore
(4.72 in)
Air
Air
(b) Side View
(a) Front View
2.3 Clearances
Install the RC5 vertically and allow sufficient clearances for effective cooling as shown in Figure 2.1.
Figure 2.1
Note: 1. The clearances required at top/bottom and both sides are common in open chassis type (IP00) and enclosed wall–mounted type (NEMA 1).
Figure 2.1 Clearances
2. Remove the top and bottom covers to use the open chassis type of 200 V/400 V 30 kW or less.
3. When installing the models of 200 V/400 V 37 kW or more equipped with eyebolts, extra spacing will be required on either side. For detailed dimensions, contact your
YASKAWA representative.
4. Ensure sufficient space for the sections at the upper and lower parts marked with * in order to permit the flow of intake/exhaust air to / from the unit.
18 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
2.4 Dimensions
W1
W
-
H2
4
d
H1
H
D
2.4 Dimensions
◆ Models of 200 V/400 V 30 kW and Lower
Figure 2.2 shows a 200 V 3.7 kW model. Use open chassis type 200 V/400 V 30 kW and lower with the top and bottom covers removed.
Figure2.2
◆ Models of 200 V/400 V 37 kW and Higher
Figure 2.3 shows a 200 V 37 kW model.
Figure2.3
W1
W
Figure 2.2 Dimensions of RC5
STATUS
RUN
READY
:LIGHT
:BLINK
:LIGHTOFF
RUN
ALARM
EF
OLOH
OVUV
OC
CPF
H1
H
H2
4-d
Figure 2.3
D
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 19
2.4 Dimensions
Vol tag e RC5 CIMR–R5U
23P7
25P5
27P5
2011
200V Class
400V Class
400V Class
2015 6
2018
2022
2030
2037
43P7
45P5
47P5
4011
4015
4018
4030
4037
4045
4055
4075
Table 2.1 RC5 Dimensions mm (in) and Approx. Mass (kg)
Dimensions
mm (in)
Mounting Dimension mm (in)
W H D W1 H1 H2
140
(5.51
200
(7.87)
250
(9.84)
325
(12.80)
140
(5.51
200
(7.87)
250
(9.84)
325
(12.80)
280
(11.02)
300
(11.81)
380
(14.96)
400
(15.75
450
(17.72)
280
(11.02)
300
(11.81)
380
(14.96)
450
(17.72)
635
25.0)
180
(7.09)
205
(8.07)
225
(8.86)
285
(11.22)
180
(7.09)
205
(8.07)
225
(8.86)
285
(11.22)
285
(11.22)
285
(11.22)
285
(11.22)
126
(4.96)
186
(7.32)
236
(9.29)
275
(10.83)
126
(4.96)
186
(7.32)
236
(9.29)
275
(10.83)
275
(10.83)
275
(10.83)
275
(10.83)
266
(10.47)
285
(11.22)
365
(14.37)
435
(17.13)
266
(10.47)
285
(11.22)
365
(14.37)
435
(17.13)
610
(24.02)
7.0
(0.28)
8.0
(0.32)
7.5
(0.30)
27.5
(1.08)
7.5
(0.30)
7.0
(0.28)
8.0
(0.32)
7.5
(0.30)
7.5
(0.30)
Approx. Mass
(kg)
Mounting Hole
d
4.5 M5
5.5
10
M6
11
23 IP00
3.5
4
M5
6
M6
10.54022
25
26
M6 IP00
34
36
Enclosure Type
IP20
IP20
Note: RC5 is offered in the following enclosure types:
• IP20: 23P7 to 2030
• IP20: 43P7 to 4030
• IP00: 2037
• IP00: 4037 to 4075
20 YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual
2.5 Removing and Replacing the Front Cover
2.5 Removing and Replacing the Front Cover
To remove the front cover, first move the LCD monitor/digital operator in the direction shown by arrow 1. Then squeeze the cover in the direction
shown by arrows 2 on both sides and lift in the direction shown by arrow 3.
Figure2.4
1
Front Cover
2
3
2
Figure 2.4 Removing and Replacing the Front Cover
Note: Do not replace the front cover with the LCD monitor/digital operator connected. The LCD monitor/digital operator will not be connected to the power regenerative unit.
Replace the front cover first and then install the LCD monitor/digital operator on the cover. Refer to Removing and Replacing the LCD Monitor/Digital Operator on
page 22 for replacing the LCD monitor/digital operator.
YASKAWA ELECTRIC TOEP C710656 01C YASKAWA - RC5 Instruction Manual 21
Loading...
