Yamaha HTR-5930 User Manual

Download

HTR-5930

AV Receive r

OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

• Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

1 Read Instructions – All the safety and operating instructions

should be read before the product is operated.

2 Retain Instructions – The safety and operating instructions

should be retained for future reference.

3 Heed Warnings – All warnings on the product and in the

operating instructions should be adhered to.

4 Follow Instructions – All operating and use instructions

should be followed.

5 Cleaning – Unplug this product from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners.

6 Attachments – Do not use attachments not recommended by

the product manufacturer as they may cause hazards.

7 Water and Moisture – Do not use this product near water –

for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

8 Accessories – Do not place this product on an unstable cart,

stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

9 A product and cart combination should be moved with care.

Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

10 Ventilation – Slots and openings in the cabinet are provided

for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

11 Power Sources – This product should be operated only from

the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

12 Grounding or Polarization – This product may be equipped

with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

13 Power-Cord Protection – Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

14 Lightning – For added protection for this product during a

lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

15 Power Lines – An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16 Overloading – Do not overload wall outlets, extension

cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

17 Object and Liquid Entry – Never push objects of any kind

into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

18 Servicing – Do not attempt to service this product yourself

as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19 Damage Requiring Service – Unplug this product from the

wall outlet and refer servicing to qualified service personnel under the following conditions:

a) When the power-supply cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the

product,

c) If the product has been exposed to rain or water,

IMPORTANT SAFETY INSTRUCTIONS

d) If the product does not operate normally by following

the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation,

e) If the product has been dropped or damaged in any

way, and

f) When the product exhibits a distinct change in perfor-

mance - this indicates a need for service.

20 Replacement Parts – When replacement parts are required,

be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

21 Safety Check – Upon completion of any service or repairs to

this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

22 Wall or Ceiling Mounting – The unit should be mounted

to a wall or ceiling only as recommended by the manufacturer.

23 Heat – The product should be situated away from heat

sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

24 Outdoor Antenna Grounding – If an outside antenna or

cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810–20)

GROUNDING CONDUCTORS (NEC SECTION 810–21)

GROUND CLAMPS

ELECTRIC SERVICE EQUIPMENT

NEC – NATIONAL ELECTRICAL CODE

MAST

GROUND CLAMP

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250. PART H)

FCC INFORMATION (for US customers)

1 IMPORTANT NOTICE: DO NOT MODIFY THIS

UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2 IMPORTANT: When connecting this product to

accessories and/or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.

3 NOTE: This product has been tested and found to comply

with the requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices.

Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA

90620.

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.

1 To assure the finest performance, please read this

manual carefully. Keep it in a safe place for future reference.

2 Install this sound system in a well ventilated, cool,

dry, clean place – away from direct sunlight, heat sources, vibration, dust, moisture, and/or cold. Allow ventilation space of at least 30 cm on the top, 20 cm on the left and right, and 20 cm on the back of this unit.

3 Locate this unit away from other electrical

appliances, motors, or transformers to avoid humming sounds.

4 Do not expose this unit to sudden temperature

changes from cold to hot, and do not locate this unit in a environment with high humidity (i.e. a room with a humidifier) to prevent condensation inside this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury.

5 Avoid installing this unit where foreign object may

fall onto this unit and/or this unit may be exposed to liquid dripping or splashing. On the top of this unit, do not place: – Other components, as they may cause damage

and/or discoloration on the surface of this unit.

– Burning objects (i.e. candles), as they may cause

fire, damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall

and liquid may cause electrical shock to the user and/or damage to this unit.

6 Do not cover this unit with a newspaper, tablecloth,

curtain, etc. in order not to obstruct heat radiation. If the temperature inside this unit rises, it may cause fire, damage to this unit, and/or personal injury.

7 Do not plug in this unit to a wall outlet until all

connections are complete.

8 Do not operate this unit upside-down. It may

overheat, possibly causing damage. 9 Do not use force on switches, knobs and/or cords. 10 When disconnecting the power cable from the wall

outlet, grasp the plug; do not pull the cord. 11 Do not clean this unit with chemical solvents; this

might damage the finish. Use a clean, dry cloth. 12 Only voltage specified on this unit must be used.

Using this unit with a higher voltage than specified

is dangerous and may cause fire, damage to this

unit, and/or personal injury. YAMAHA will not be

held responsible for any damage resulting from use

of this unit with a voltage other than specified. 13 To prevent damage by lightning, keep the power

cord and outdoor antennas disconnected from a

wall outlet or the unit during a lightning storm.

14 Do not attempt to modify or fix this unit. Contact

qualified YAMAHA service personnel when any service is needed. The cabinet should never be opened for any reasons.

15 When not planning to use this unit for long periods

of time (i.e. vacation), disconnect the AC power plug from the wall outlet.

16 Install this unit near the AC outlet and where the AC

power plug can be reached easily.

17 Be sure to read the “TROUBLESHOOTING” section

on common operating errors before concluding that this unit is faulty.

18 Before moving this unit, press STANDBY/ON to set

this unit in the standby mode, and disconnect the AC power plug from the wall outlet.

19 VOLTAGE SELECTOR (Asia and General models

only) The VOLTAGE SELECTOR on the rear panel of this unit must be set for your local main voltage BEFORE plugging into the AC wall outlet. Voltages are 110–120/220–240 V AC, 50/60 Hz.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

This unit is not disconnected from the AC power source as long as it is connected to the wall outlet, even if this unit itself is turned off by STANDBY/ON. This state is called the standby mode. In this state, this unit is designed to consume a very small quantity of power.

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to wide slot and fully insert. This Class B digital apparatus complies with Canadian ICES-003.

IMPORTANT

Please record the serial number of this unit in the space below. MODEL: Serial No.: The serial number is located on the rear of the unit. Retain this Owner’s Manual in a safe place for future reference.

We Want You Listening For A Lifetime

YAMAHA and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion – and, most importantly, without affecting your sensitive hearing.

iii

Since hearing damage from loud sounds is often undetectable until it is too late, YA M A H A and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.

CONTENTS

INTRODUCTION

FEATURES............................................................. 2

GETTING STARTED............................................ 3

Supplied accessories .................................................. 3

Installing batteries in the remote control ................... 3

CONTROLS AND FUNCTIONS ......................... 4

Front panel ................................................................. 4

Remote control........................................................... 6

Front panel display .................................................... 8

Rear panel .................................................................. 9

PREPARATION

CONNECTIONS .................................................. 10

Placing speakers....................................................... 10

Connecting speakers ................................................ 11

Information on jacks and cable plugs ...................... 13

Connecting video components................................. 14

Connecting audio components................................. 17

Connecting the FM and AM antennas ..................... 18

Connecting the power cable..................................... 19

Turning on the power............................................... 19

SETUP ................................................................... 20

Using BASIC MENU .............................................. 20

BASIC OPERATION

PLAYBACK.......................................................... 23

Basic operations....................................................... 23

Additional operations............................................... 25

SOUND FIELD PROGRAMS............................. 30

Sound field program descriptions ............................ 31

RECORDING ....................................................... 34

FM/AM TUNING ................................................. 35

Automatic tuning ..................................................... 35

Manual tuning.......................................................... 36

Automatic preset tuning........................................... 37

Manual preset tuning ............................................... 38

Selecting preset stations........................................... 39

Exchanging preset stations ...................................... 40

XM® SATELLITE RADIO TUNING ............... 41

What is XM Satellite Radio? ................................... 41

Connecting the XM Connect-and-Play

digital antenna ..................................................... 41

XM Satellite Radio controls and functions.............. 42

Activating XM Satellite Radio ................................ 43

Basic XM Satellite Radio operations....................... 44

Selecting the XM Satellite Radio search mode .......45

Setting XM Satellite Radio preset channels ............ 49

Displaying the XM Satellite Radio information...... 50

ADVANCED OPERATION

SET MENU ............................................................52

Using SET MENU................................................... 53

SOUND MENU....................................................... 53

INPUT MENU......................................................... 55

OPTION MENU...................................................... 56

REMOTE CONTROL FEATURES ...................57

Controlling this unit, a TV, or other components.... 57

Setting remote control codes ................................... 59

ADDITIONAL INFORMATION

TROUBLESHOOTING .......................................60

RESETTING THE SYSTEM...............................65

GLOSSARY...........................................................66

Audio information ................................................... 66

Sound field program information ............................ 67

Video information.................................................... 67

SPECIFICATIONS...............................................68

PREPARATIONINTRODUCTION

OPERATION

BASIC

OPERATION

ADVANCED

INFORMATION

ADDITIONAL

FEATURES

Built-in 5-channel power amplifier

◆ Minimum RMS output power [U.S.A. and Canada models]

(0.9% THD, 1 kHz, 8 Ω/6 Ω) Front: 110 W + 110 W Center: 110 W Surround: 110 W + 110 W

Sophisticated AM/FM tuner

◆ 40-station random and direct preset tuning

◆ Automatic preset tuning

◆ Preset station shifting capability (preset editing)

XM Satellite Radio (U.S.A. model only)

◆ XM Satellite Radio tuning capability (Using the “XM Connect-and-Play digital antenna” sold separately)

[Other models] (0.9% THD, 1 kHz, 6 Ω) Front: 100 W + 100 W Center: 100 W Surround: 100 W + 100 W

Other features

◆ 192-kHz/24-bit D/A converter

◆ 6 additional input jacks for discrete multi-channel input

◆ A SET MENU that allows you to optimize this unit to

suit your individual audiovisual system

Decoders and DSP circuits

◆ Proprietary YAMAHA technology for the creation of multi-channel surround sound

◆ Dolby Digital decoder

◆ Dolby Pro Logic/Dolby Pro Logic II decoder

◆ DTS decoder

◆ Virtual CINEMA DSP

◆ SILENT CINEMA

• y indicates a tip for your operation.

• Some operations can be performed by using either the buttons on the front panel or the ones on the remote control. In case the button

names differ between the front panel and the remote control, the button name on the remote control is given in parentheses.

• This manual is printed prior to production. Design and specifications are subject to change in part as a result of improvements, etc. In

case of differences between the manual and product, the product has priority.

™

◆ Component video input/output capability (3 COMPONENT VIDEO INs and 1 MONITOR OUT)

◆ Optical and coaxial digital audio signal jacks

◆ Sleep timer

◆ Night listening mode

◆ Remote control with preset remote control codes

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories.

“SILENT CINEMA” is a trademark of YAMAHA CORPORATION.

“DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc.

The XM name and related logos are registered trademarks of XM Satellite Radio Inc.

GETTING STARTED

Supplied accessories

Check that you received all of the following parts.

Remote control

POWER

STANDBY

POWERAVPOWERTVPOWER

REC

DISC SKIP

–

2CH STEREO

LEVEL TITLE

–

TEST

RETURN

MEMORY

SPEAKERS

+–+

CHVOL

INPUTMUTE

B 09

ENTER

PRESET/CH

SLEEP

TUNERMD/CD-RCD

V-AUXVCRDTV/CBLDVD

MULTI CH IN

AUDIO

CODE SET

AMP

VOLUME

–

MUTE

MOVIEENTERTAINMUSIC

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

SET MENU

SRCH MODEBAND

A-E/CAT.

DISPLAY

Batteries (2)

(AA, R06, UM-3)

Indoor FM antenna (U.S.A., Canada, China, Asia and General models)

Installing batteries in the remote control

INTRODUCTION

AM loop antenna

Indoor FM antenna (U.K., Europe, Australia and Korea models)

1 Press the part and slide the battery

compartment cover off.

2 Insert the two supplied batteries (AA, R06,

UM-3) according to the polarity markings (+ and –) on the inside of the battery compartment.

3 Slide the cover back until it snaps into place.

Notes

• Change all of the batteries if you notice a decrease in the operation range of the remote control.

• Do not use an old battery together with a new one.

• Do not use different types of batteries (such as alkaline and manganese batteries) together. Read the packaging carefully as these different types of batteries may have the same shape and color.

• If the batteries have leaked, dispose of them immediately. Avoid touching the leaked material or letting it come into contact with clothing, etc. Clean the battery compartment thoroughly before installing new batteries.

• Do not throw away batteries with general house waste; dispose of them correctly in accordance with your local regulations.

• If the remote control is without batteries for more than 2 minutes, or if exhausted batteries remain in the remote control, the contents of the memory may be cleared. When the memory is cleared, insert new batteries, set up the remote control code and program any acquired functions that may have been cleared.

CONTROLS AND FUNCTIONS

Front panel

Note

The XM Satellite Radio controlling functions in the following buttons (SEARCH MODE, XM, CATEGORY, PRESET/TUNING/CH l / h, MEMORY, and DISPLAY) are only applicable to the U.S.A. model and are operational only when “XM” is selected as the input source. For details, see “XM Satellite Radio controls and functions” on page 42.

STANDBY

/ON

PHONES

SILENT CINEMA

SPEAKERS

A/B/OFF

234 5 67 8 9 0

SEARCH MODE

EDIT

STRAIGHT

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

A/B/C/D/E

CATEGORY

l PROGRAM h

BASS/TREBLE

PRESET/TUNING/CH

SET MENU

INPUT MODE

l INPUT h

MEMORY

TUNING MODE

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

MULTI CH INPUT

ABCD FEGHI

1 STANDBY/ON

Turns on this unit or sets it to the standby mode.

Notes

• In the standby mode, this unit consumes a small amount of power in order to receive infrared-signals from the remote control.

• When you turn on this unit, there will be a 4 to 5-second delay before this unit can reproduce sound.

2 Remote control sensor

Receives signals from the remote control.

3 PRESET/TUNING

• Switches the function of PRESET/TUNING/CH l / h

between selecting preset station numbers and selecting the tuning frequency.

• Edits the assignments of present stations.

4 FM/AM

Switches the reception band between FM and AM.

5 A/B/C/D/E

Selects one of the 5 preset station groups (A to E) when “FM” or “AM” is selected as the input source.

6 PRESET/TUNING/CH l / h

• Selects one of the 8 preset station numbers (1 to 8) when “FM” or “AM” is selected as the input source. The colon (:) is displayed in the front panel display.

• Selects the tuning frequency when “FM” or “AM” is selected as the input source. The colon (:) is not displayed in the front panel display.

7 Front panel display

Shows information about the operational status of this unit.

8 MEMORY

Stores a preset station in the memory. Hold down this button for more than 3 seconds to start automatic preset tuning.

9 TUNING MODE

Switches between automatic tuning (the AUTO indicator is turned on) and manual tuning (the AUTO indicator is turned off).

0 VOLUME

Controls the output level of all audio channels.

Note

This does not affect the AUDIO OUT (REC) level.

VOLUME

(U.S.A. model)

A PHONES jack

Outputs audio signals for private listening with headphones.

Notes

• When you connect headphones, no signals are output at the SUBWOOFER OUTPUT jack or at the SPEAKERS terminals.

• All Dolby Digital and DTS audio signals are mixed down to the left and right headphone channels.

B SPEAKERS

Turns on or off the set of front speakers connected to the A and/or B terminals on the rear panel.

C STRAIGHT

Turns the sound field programs off or on. When this unit is in the “STRAIGHT” mode, 2-channel or multi-channel input signals are output directly from their respective speakers without effect processing.

D TONE CONTROL

Adjusts the bass/treble balance of the front left and right speakers in conjunction with BASS/TREBLE +/–.

E BASS/TREBLE +/–

Adjusts the bass/treble balance of the front left and right speakers in conjunction with TONE CONTROL.

F PROGRAM l / h

Selects sound field programs.

G INPUT MODE

Selects either digital or analog input signals exclusively or sets this unit to automatically detect the type of input signals and select the corresponding input signals when one component is connected via both digital and analog connections.

H INPUT l / h

Selects the desired input source.

I MULTI CH INPUT

Selects the component connected to the MULTI CH INPUT jacks as the input source.

CONTROLS AND FUNCTIONS

INTRODUCTION

Note

The input source connected to the MULTI CH INPUT jacks takes priority over the source selected with INPUT l / h on the front panel (or the input selector buttons on the remote control).

CONTROLS AND FUNCTIONS

Remote control

This section describes the function of each control on the remote control used to control this unit. To operate other components, see “REMOTE CONTROL FEATURES” on page 57.

Note

The XM Satellite Radio controlling functions in the following buttons (BAND, MEMORY, SRCH MODE, DISPLAY, cursor buttons u / d / j / i, numeric buttons and ENT.) are only applicable to the U.S.A. model and are operational only when “XM” is selected as the input source. For details, see “XM Satellite Radio controls and functions” on page 42.

■ Controlling this unit

Press AMP to control this unit.

1 Infrared signal transmitter

Outputs infrared control signals. Aim the transmitter at the component you want to operate.

2 Input selector buttons

Select the input source you want to control.

3 Sound field program selector buttons

Select sound field programs.

4 SPEAKERS A/B

Turn on or off the set of front speakers connected to the A and/or B terminals on the rear panel.

5 LEVEL

Selects the speaker channel to be adjusted.

6 Cursor buttons u / d / j / i

Select and adjust sound field program parameters or SET MENU items.

7 TEST

Outputs the test tone to adjust the speaker levels.

8 STANDBY

Sets this unit to the standby mode.

9 POWER

Turns on this unit.

0 SLEEP

Sets the sleep timer.

A MULTI CH IN

Selects the component connected to the MULTI CH INPUT jacks as the input source when using an external decoder, etc.

B CODE SET

Use to set up remote control codes.

C AMP

Sets the remote control to the operation mode of this unit.

D VOLUME +/–

Controls the output level of all audio channels.

POWERTVPOWER

REC

DISC SKIP

–

2CH STEREO

SPEAKERS

LEVEL

TITLE

–

TEST

RETURN

MEMORY

POWER

CHVO L

–

INPUTMUTE

B 09

STANDBY

TUNERMD/CD-RCD

5CH STEREOSTANDARD

NIGHT

ENTER

PRESET/CH

AUDIO

VOLU ME

+10

MULTI CH IN

–

MUTE

STRAIGHT

SRCH MODEBAND

A-E/CAT.

POWER

SLEEP

V-AU XVCRDTV/CBLDVD

CODE SET

AMP

MOVIEENTERTAINMUSIC

432

8765

ENT.

SET MENU

DISPLAY

F G

Note

This does not affect the AUDIO OUT (REC) level.

(U.S.A. model)

CONTROLS AND FUNCTIONS

E MUTE

Mutes the audio output. Press again to restore the audio output to the previous volume level.

F STRAIGHT

G NIGHT

Turns on or off the night listening mode.

H SET MENU

Enters “SET MENU”.

■ Controlling the TUNER functions

To control the TUNER function, press TUNER and then BAND repeatedly to select “FM” or “AM” as the input source.

3 Numeric buttons

Select preset stations.

5 BAND

Switches the reception band between “FM” and “AM”.

6 A-E/CAT. j / i, PRESET/CH u / d

Press A-E/CAT. j / i to select a preset station group (A to E) and PRESET/CH u / d to select a preset station number (1 to 8).

■ Using the remote control

The remote control transmits a directional infrared ray. Be sure to aim the remote control directly at the remote control sensor on this unit during operation.

30º 30º

Notes

• Do not spill water or other liquids on the remote control.

• Do not drop the remote control.

• Do not leave or store the remote control in the following types of conditions: – places of high humidity, such as near a bath – places of high temperature, such as near a heater or stove – places of extremely low temperatures – dusty places

Approximately 6 m (20 ft)

INTRODUCTION

CONTROLS AND FUNCTIONS

Front panel display

Note

The XM indicator is only applicable to the U.S.A. model and lights up only when “XM” is selected as the input source. For details, see “Basic XM Satellite Radio operations” on page 44.

312 4 5 76

VCR

PCM

DIGITAL

VIRTUAL

STANDARD NIGHT

SILENT CINEMA

V-A UX

SP AB

DTV/CBL

HiFi DSP

DVD

MD/CD-R

TUNER CD

AUTO

TUNED

STEREO

MEMORY SLEEP

MUTE

LFE SL SR

VOLUME

LCR

890ACBDKFGHI J

1 Decoder indicators

The respective indicator lights up when any of the decoders of this unit function.

2 VIRTUAL indicator

Lights up when Virtual CINEMA DSP is active.

3 SILENT CINEMA indicator

Lights up when headphones are connected and a sound field program is selected.

4 Input source indicators

A corresponding cursor lights up to show the currently selected input source.

5 MEMORY indicator

Flashes to show that a station can be stored.

6 MUTE indicator

Flashes while the MUTE function is on.

7 VOLUME level indicator

Indicates the current volume level.

8 PCM indicator

Lights up when this unit is reproducing PCM (Pulse Code Modulation) digital audio signals.

9 STANDARD indicator

Lights up when the “STANDARD” program is selected.

(U.S.A. model only)

C CINEMA DSP indicator

Lights up when you select a CINEMA DSP program.

D HiFi DSP indicator

Lights up when you select a HiFi DSP program.

E Multi-information display

Shows the name of the current program and other information when adjusting or changing settings.

F AUTO indicator

Lights up when this unit is in the automatic tuning mode.

G TUNED indicator

Lights up when this unit is tuned into a station.

H STEREO indicator

Lights up when this unit is receiving a strong signal for an FM stereo broadcast while the AUTO indicator is lit.

I SLEEP indicator

Lights up while the sleep timer is on.

J Input channel indicators

Indicate the channel components of the current digital input signal.

K XM indicator

Lights up when “XM” is selected as the input source.

0 NIGHT indicator

Lights up when you select a night listening mode.

A Speaker indicators

Light up according to the set of front speakers selected.

B Headphones indicator

Lights up when headphones are connected.

Rear panel

67 8 9 0

CONTROLS AND FUNCTIONS

12 3 4 5

MULTI CH INPUT

FRONT

SURROUND

DIGITAL

SUB

INPUT

WOOFER

DVD

COAXIAL

OPTICAL

DTV/CBL

(PLAY)

MD/

DVD

CD-R

OUT

(REC)

AUDIO

1 XM jack (U.S.A. model only)

See page 41 for connection information.

2 MULTI CH INPUT jacks

See page 16 for connection information.

3 Video component jacks

See page 14 for connection information.

4 COMPONENT VIDEO jacks

See page 16 for connection information.

AUDIO

VIDEO

DVD

DTV/

OUTPUT

WOOFER

CBL

V-AUX

VCR

OUT

SUB

CENTER

COMPONENT VIDEO

PBYPR

DTV/ CBL

VCR

MONITOR OUT

SURROUND

MONITOR

OUT

INTRODUCTION

TUNER

ANT

GND

ANT

CENTER

SPEAKERS

CLASS 2 WIRING

FRONT

FRON

IMPEDANCE SELECTOR

(U.S.A. model)

0 IMPEDANCE SELECTOR

(U.S.A. and Canada models only)

See page 11 for details.

VOLTAGE SE LEC TOR (Asia and General models only)

See page 19 for details.

5 Antenna terminals

See page 18 for connection information.

6 DIGITAL INPUT jacks

See pages 14 and 15 for connection information.

7 Audio component jacks

See page 17 for connection information.

8 SUBWOOFER OUTPUT jack

See page 12 for connection information.

9 SPEAKERS terminals

See page 11 for connection information.

CONNECTIONS

Placing speakers

The speaker layout below shows the standard ITU-R* speaker setting. You can use it to enjoy CINEMA DSP and multi-channel audio sources.

ITU-R is the radio communication sector of the ITU (International Telecommunication Union).

80˚

30˚

60˚

■ Front speakers (FL and FR)

The front speakers are used for the main source sound plus effect sounds. Place these speakers an equal distance from the ideal listening position. The distance of each speaker from each side of the video monitor should be the same.

■ Center speaker (C)

The center speaker is for the center channel sounds (dialog, vocals, etc.). If for some reason it is not practical to use a center speaker, you can do without it. Best results, however, are obtained with the full system. Place the center speaker centrally between the front speakers and as close to the monitor as possible, such as directly over or under it.

■ Surround speakers (SL and SR)

The surround speakers are used for effect and surround sounds. Place these speakers behind your listening position, facing slightly inwards, about 1.8 m (6 ft) above the floor.

■ Subwoofer (SW)

The use of a subwoofer, such as the YAMAHA Active Servo Processing Subwoofer System, is effective not only for reinforcing bass frequencies from any or all channels, but also for high fidelity reproduction of the LFE (lowfrequency effect) channel included in Dolby Digital and DTS software. The position of the subwoofer is not so critical, because low bass sounds are not highly directional. But it is better to place the subwoofer near the front speakers. Turn it slightly toward the center of the room to reduce wall reflections.

1.8 m (6 ft)

Connecting speakers

Be sure to connect the left channel (L), right channel (R), “+” (red) and “–” (black) properly. If the connections are faulty, no sound will be heard from the speakers, and if the polarity of the speaker connections is incorrect, the sound will be unnatural and lack bass.

CAUTION

• Use speakers with the specified impedance shown on the rear panel of this unit.

• Before connecting the speakers, make sure that this unit is turned off.

• Do not let the bare speaker wires touch each other or do not let them touch any metal part of this unit. This could damage this unit and/or speakers.

• Use magnetically shielded speakers. If this type of speakers still creates the interference with the monitor, place the speakers away from the monitor.

(U.S.A. and Canada models only)

If you are to use 6 ohm speakers, be sure to set the IMPEDANCE SELECTOR switch on the rear panel to the upper position using a straight slot screwdriver.

Switch

position

Upper

Lower

■ Before connecting to the SPEAKERS

terminal

A speaker cord is actually a pair of insulated cables running side by side. Cables are colored or shaped differently, perhaps with a stripe, groove or ridges. Connect the striped (grooved, etc.) cable to the “+” (red) terminals of this unit and your speaker. Connect the plain cable to the “–” (black) terminals.

Remove approximately 10 mm (3/8”) of insulation from the end of each speaker cable and then twist the bare wires of the cable together to prevent short circuits.

Speaker Impedance level

FRONT A or B

CENTER

SURROUND

FRONT A or B

CENTER

SURROUND

The impedance of each speaker must be 6 Ω or higher.

The impedance of each speaker must be 8 Ω or higher.

CONNECTIONS

■ Connecting to the FRONT A SPEAKERS terminals

Red: positive (+) Black: negative (–)

1 Loosen the knob.

2 Insert the bare end of the speaker wire into

the hole on the terminal.

3 Tighten the knob to secure the wire.

Connecting the banana plug (except U.K., Europe, Korea and Asia models)

The banana plug is a single-pole electrical connector widely used to terminate speaker cables. First, tighten the knob and then insert the banana plug connector into the end of the corresponding terminal.

Banana plug

■ Connecting to the FRONT B, CENTER, and SURROUND SPEAKERS terminals

Red: positive (+) Black: negative (–)

1 Press down the tab.

2 Insert the bare end of the speaker wire into

the hole on the terminal.

PREPARATION

10 mm (3/8”)

3 Release the tab to secure the wire.

CONNECTIONS

DIGITAL

DVD

COAXIA OPTICAL

DTV-CBL

DVD

Surround speakers

MULTI CH INPUT

FRONT

SURROUND

SUB

INPUT

WOOFER

(PLAY)

MD/

CD-R

OUT

(REC)

AUDIO

DVD

DTV/

OUTPUT

SUB

WOOFER

CBL

V-AUX

VCR

OUT

CENTER

VIDEO

MONITOR

OUT

COMPONENT VIDEO

DTV/ CBL

VCR

MONITOR OUT

LeftRight

PBYPR

SURROUND

TUNER

AM ANT

GND

ANT

FRONT

CENTER

Front speakers (A)

SPEAKERS

CLASS 2 WIRING

FRON

LeftRight

IMPEDANCE SELECTOR

(U.S.A. model)

Subwoofer Center

speaker

31 2

LeftRight

Front speakers (B)

■ FRONT terminals

Connect one or two speaker systems (1, 2) to these terminals. If you use only one front speaker system, connect it to the FRONT A terminals.

■ CENTER terminals

Connect a center speaker (3) to these terminals.

■ SURROUND terminals

Connect surround speakers (4, 5) to these terminals.

■ SUBWOOFER OUTPUT jack

Connect a subwoofer with built-in amplifier (6) (such as the YAMAHA Active Servo Processing Subwoofer System) to this jack.

Speaker layout

Information on jacks and cable plugs

Audio jacks and cable plugs Video jacks and cable plugs

CONNECTIONS

AUDIO

Left and right

analog audio

cable plugs

(Red)(White) (Orange) (Yellow) (Green) (Blue) (Red)

DIGITAL AUDIO

COAXIAL

Coaxial

digital audio

cable plug

DIGITAL AUDIO

OPTICAL

Optical

digital

audio cable

plug

■ Audio jacks

This unit has three types of audio jacks (analog audio, digital audio coaxial, and digital audio optical). Connection depends on the availability of audio jacks on your other components.

AUDIO jacks

For conventional analog audio signals transmitted via left and right analog audio cables. Connect red plugs to the right jacks and white plugs to the left jacks.

DIGITAL AUDIO COAXIAL jacks

For digital audio signals transmitted via coaxial digital audio cables.

DIGITAL AUDIO OPTICAL jacks

For digital audio signals transmitted via optical digital audio cables.

Notes

• You can use the digital jacks to input PCM, Dolby Digital and DTS bitstreams. When you connect components to both the COAXIAL and OPTICAL jacks, priority is given to the signals input at the COAXIAL jack. All digital input jacks are compatible with 96-kHz sampling digital signals.

• This unit handles digital and analog signals independently. Thus audio signals input at the analog jacks are output only at the analog AUDIO OUT (REC) jacks.

• Pull out the cap from the optical jack before you connect the fiber optic cable. Do not discard the cap. When you are not using the optical jack, be sure to put the cap back in place. This cap protects the jack from dust.

VIDEO

Composite

video cable

plug

COMPONENT VIDEO

Y PB PR

Component video cable

plugs

■ Video jacks

This unit has two types of video jacks (composite video, and component video). Connection depends on the availability of input jacks on your video monitor.

VIDEO jacks

For conventional composite video signals transmitted via composite video cables.

COMPONENT VIDEO jacks

For component signals, separated into the luminance (Y) and chrominance (P separate wires of component video cables.

Video signal flow for MONITOR OUT

COMPONENT VIDEO

VIDEO

B, PR) video signals transmitted on

Input

Output

(MONITOR OUT)

PREPARATION

CONNECTIONS

Connecting video components

■ Connecting a video monitor

Connect the video input jack of your video monitor to the MONITOR OUT jack.

■ Connecting a DVD player/cable TV/ satellite tuner

Connect the coaxial digital audio signal output jack of your DVD player to the DIGITAL INPUT DVD COAXIAL jack and connect the video signal output jack of the component to the DVD VIDEO jack of this unit. Connect the optical digital audio signal output jack of your cable TV or satellite tuner to the DIGITAL INPUT DTV/CBL jack and connect the video signal output jack of the component to the DTV/CBL VIDEO jack of this unit.

• Use the AUDIO jacks of this unit for a video component which

does not have optical digital output jack. To enjoy the surround sound, use the sound field program selector buttons on the remote control (see page 30).

• If your DVD player does not have a coaxial digital output jack

but has an optical cable, connect the jack to the DIGITAL INPUT DVD OPTICAL.

• You can also connect a video monitor, DVD player, digital TV,

and cable TV to this unit using the COMPONENT VIDEO connections (see page 16).

■ Connecting a DVD recorder/VCR

Connect the audio signal input jacks of your video component to the VCR AUDIO OUT jacks of this unit. Then connect the video signal input jack of the video component to the VCR VIDEO OUT jack of this unit for picture recording. Connect the audio signal output jacks of your component to the VCR AUDIO IN jacks of this unit. Then connect the video signal output jack of the component to the VCR VIDEO IN jack of this unit to play a source from your recording component.

Notes

• Once you have connected a recording component to this unit, keep the component turned on while using this unit. If the power is turned off, this unit may distort the sound from other components.

• Be sure to connect your video source components in the same way you connect your video monitor to this unit. For example, if you connect your video monitor to this unit using a VIDEO connection, connect your video source components to this unit using the VIDEO connections.

■ Connecting another video component

Connect the video signal output jack of your component to the V-AUX VIDEO jack of this unit. Connect the audio signal output jacks of the component to the V-AUX AUDIO jacks of this unit.

Audio out

Audio

DIGITAL

INPUT

DVD

COAXIA

OPTICAL

DTV/CBL

DVD

FRONT

SURROUND

SUB

WOOFER

(PLAY)

MD/

CD-R

OUT

(REC)

out

MULTI CH INPUT

DVD player

L R

CENTER

Audio out

AUDIO

WOOFER

Video out

DVD

DTV/ CBL

V-AUX

SUB

VIDEO

COMPONEN

DTV/ CBL

VCR

MONITOR OUT

VCR

OUT

SUR

Video in

MONITOR

OUT

Video monitor

Audio out

Cable TV or

Satellite tuner

Video

out

L R

Audio out

CONNECTIONS

DIGITAL

INPUT

DVD

COAXIA

OPTICAL

DTV/CBL

DVD

CENTER

AUDIO

SUB

WOOFER

VIDEO

MONITOR

OUT

COMPONEN

DTV/ CBL

VCR

MONITOR OUT

PREPARATION

SUR

DVD

DTV/ CBL

V-AUX

VCR

OUT

MULTI CH INPUT

FRONT

SURROUND

SUB

WOOFER

(PLAY)

MD/

CD-R

OUT

(REC)

LR LR

Audio inAudio out Video outVideo in

DVD recorder or

VCR

Another video

component

L R

Audio out

Vid eo

out

DIGITAL

INPUT

DVD

COAXIA OPTICAL

DTV/CBL

DVD

CENTER

AUDIO

SUB

WOOFER

V-AUX

VIDEO

COMPONEN

MONITOR

OUT

DTV/ CBL

VCR

MONITOR OUT

SUR

DVD

DTV/ CBL

VCR

OUT

MULTI CH INPUT

FRONT

SURROUND

SUB

WOOFER

(PLAY)

MD/

CD-R

OUT

(REC)

CONNECTIONS

■ Connecting to the COMPONENT VIDEO jacks

You can enjoy high-quality pictures by connecting your video monitor and video source components to this unit using COMPONENT VIDEO connections.

Note

Be sure to connect your video source components in the same way you connect your video monitor to this unit. For example, if you connect your video monitor to this unit using a COMPONENT VIDEO connection, connect your video source components to this unit using the COMPONENT VIDEO connection.

DVD player

Cable TV or

satellite tuner

DVD recorder or

VCR

Video monitor

COMPONENT VIDEO

DTV/ CBL

VCR

MONITOR OUT

PBYPR

SURROUND

Video out

Video in

■ Connecting to the MULTI CH INPUT jacks

This unit is equipped with 6 additional input jacks (FRONT L/R, CENTER, SURROUND L/R and SUBWOOFER) for discrete multi-channel input from a multi-format player, external decoder or sound processor. Connect the output jacks on your multi-format player or external decoder to the MULTI CH INPUT jacks. Be sure to match the left and right output jacks to the left and right input jacks for the front and surround channels.

AUDIO

CENTER

Multi-format player or

external decoder

VID

DVD

DTV/ CBL

V-AUX

Surround outCenter out

DVD

DIGITAL

INPUT

MULTI CH INPUT

FRONT

SURROUND

SUB

WOOFER

Subwoofer out Front out

Notes

• When you select the component connected to the MULTI CH INPUT jacks as the input source (see page 25), this unit automatically turns off the digital sound field processor, and you cannot select sound field programs.

• This unit does not redirect signals input at the MULTI CH INPUT jacks to accommodate for missing speakers. We recommend that you connect a 5.1-channel speaker system before using this feature.

• When headphones are used, signals are output only from the front left and right channels.

Connecting audio components

MULTI CH INPUT

FRONT

CENTER

SUB

WOOFER

SURROUND

MD/

CD-R

(PLAY)

(REC)

OUT

DIGITAL

INPUT

DVD

COAXIA

DTV-CBL

OPTICAL

DVD

AUDIO

DVD

DTV/ CBL

OUT

VCR

V-AUX

OUTPUT

SUB

WOOFER

■ Connecting a CD player

Connect the output jacks of your CD player to the CD jacks of this unit.

To make a digital connection to a CD player, select the corresponding setting for DIGITAL INPUT jacks in “INPUT ASSIGN” (see page 55).

Audio out

CD player

CD recorder or

MD recorder

Audio out

Audio in

CONNECTIONS

■ Connecting a CD recorder/MD recorder

Connect the input jacks of your CD recorder or MD recorder to the MD/CD-R OUT (REC) jacks. Connect the output jacks of your CD recorder or MD recorder to the MD/CD-R IN (PLAY) jacks to play a source from your recording component.

Note

Once you have connected a recording component to this unit, keep the component turned on while using this unit. If the component is turned off, this unit may distort the sound from other components.

PREPARATION

CONNECTIONS

ANT

GND

ANT

TUNER

Connecting the FM and AM antennas

Both FM and AM indoor antennas are supplied with this unit. In general, these antennas should provide sufficient signal strength. Connect each antenna correctly to the designated terminals.

Notes

• The AM loop antenna should be placed away from this unit.

• A properly installed outdoor antenna provides clearer reception than an indoor one. If you experience poor reception quality, install an outdoor antenna. Consult the nearest authorized YAMAHA dealer or service center about outdoor antennas.

• The AM loop antenna should always be connected, even if an outdoor AM antenna is connected to this unit.

Outdoor AM antenna

Use a 5 to 10 m (16 to 32 ft) of vinyl-covered wire extended outdoors from a window.

AM loop antenna

(supplied)

Indoor FM antenna (supplied)

■ Connecting the AM loop antenna

1 Set up the AM loop antenna.

2 Press down the tab of the AM ANT terminal.

3 Insert the one of the AM loop antenna lead

wires into the AM ANT terminal.

4 Release the tab back to secure the wire.

Ground

For maximum safety and minimum interference, connect the antenna GND terminal to a good earth ground. A good earth ground is a metal stake driven into moist earth.

5 Repeat steps 2 through 4 to connect the

other lead wire to the GND terminal.

Once you have properly connected the AM loop antenna to this unit, orient the AM loop antenna for the best reception when you tune into AM stations.

CONNECTIONS

IMPEDANCE SELECTOR

Connecting the power cable

Once all connections are complete, plug the power cable into the AC wall outlet.

Power cable

(U.S.A. model)

CAUTION

IMPEDANCE SELECTOR (U.S.A. and Canada models only)

Before connecting the power cable into the AC wall outlet, check that the impedance selector setting is correct.

VOLTAGE SELECTOR (Asia and General models only)

The VOLTAGE SELECTOR on the rear panel of this unit must be set for your local voltage BEFORE plugging the power cable into the AC wall outlet. Improper setting of the VOLTAGE SELECTOR may cause damage to this unit and create a potential fire hazard.

Select the switch position (upper or lower) according to your local voltage using a straight slot screwdriver.

Voltages are 110-120/220-240 V AC, 50/60 Hz.

VOLTAGE

SELECTOR

Turning on the power

When all connections are complete, turn on this unit.

STANDBY/ON

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

l PROGRAM h

BASS/TREBLE

POWER

REC

DISC SKIP

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

STANDBY

POWERPOWER

AVTV

AUDIO

Press STANDBY/ON on the front panel (or POWER on the remote control) to turn on this unit.

STANDBY

/ON

Front panel

Press STANDBY/ON on the front panel again (or press STANDBY on the remote control) to set this unit to the standby mode.

Memory back-up

The memory back-up circuit prevents the stored data from being lost even if this unit is in the standby mode. However, the stored data will be lost in case the power cable is disconnected from the AC wall outlet or if the power supply is cut off for more than one week.

MEMORY

SET MENU

l INPUT h

INPUT MODE

POWER

SLEEPTUNERMD/CD-RCD

V-AUXVCRDTV/CBLDVD

MULTI CH IN

CODE SET

AMP

Remote control

TUNING MODE

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

MULTI CH INPUT

POWER

PREPARATION

110V-120V

220V-240V

SETUP

–

– –

SETUP

The “BASIC MENU” feature is a useful way to set up your system quickly and with minimal effort.

• If you wish to configure this unit manually using more precise adjustments, use the detailed parameters in “SOUND MENU” (see page 53).

• Altering any parameters in “SETUP” resets all parameters manually adjusted in “SOUND MENU” (see page 53).

• Initial settings are indicated in bold under each parameter.

3 Press i to enter “1 SETUP”.

ENTER

PRESET/CH

“ROOM” appears in the front panel display.

A-E/CAT.

Using BASIC MENU

Note

Before you begin:

• Press SPEAKERS on the front panel repeatedly (or press SPEAKERS A/B on the remote control) to select the front speakers you want to use.

• Make sure you disconnect your headphones from this unit.

AMP

+–+

VOLUME

CHVO L

SPEAKERS

–

INPUT

MUTE

MUSIC

5CH STEREOSTANDARD

NIGHT

+10

ENTER

A-E/CAT.

PRESET/CH

–

MUTE

2CH STEREO

LEVEL TITLE

–

TEST

RETURN

MEMORY

(U.S.A. model)

1 Press AMP and then SET MENU.

AMP

“BASIC MENU” appears in the front panel display. If the front panel display shows anything other than “BASIC MENU”, press SET MENU repeatedly until “BASIC MENU” appears.

MOVIEENTERTAIN

432

8765

STRAIGHT

ENT.

SET MENU

SRCH MODEBAND

5-7,9,11,13-15

DISPLAY

2-6,8,10,12,13

SET MENU

SRCH MODE

4 Press j / i to select the desired setting.

ENTER

PRESET/CH

Select the size of the room where you have installed your speakers. In general, the room sizes are defined as follows:

Choices: S, M, L [U.S.A. and Canada models] S (small) 16 x 13 ft, 200 ft2 (4.8 x 4.0 m, 20 m2) M (medium) 20 x 16 ft, 300 ft L (large) 26 x 19 ft, 450 ft [Other models] S (small) 3.6 x 2.8 m, 10 m M (medium) 4.8 x 4.0 m, 20 m L (large) 6.3 x 5.0 m, 30 m

A-E/CAT.

(6.3 x 5.0 m, 30 m2)

(7.9 x 5.8 m, 45 m2)

2 2 2

5 Press d to enter “SUBWOOFER” and then

press j / i to select the desired setting.

ENTER

PRESET/CH

A-E/CAT.

Choices: YES, NONE

• Select “YES” if you have a subwoofer in your system.

• Select “NONE” if you do not have a subwoofer in your system.

ENTER

PRESET/CH

A-E/CAT.

2 Press i to enter “BASIC MENU”.

ENTER

PRESET/CH

“1 SETUP” appears in the front panel display.

A-E/CAT.

SETUP

– –

–

6 Press d to confirm your selection and then

press j / i to select the number of speakers connected to this unit.

ENTER

PRESET/CH

A-E/CAT.

Choice Display Speakers

2spk

3spk

4spk

5spk

LL C R

SL SB SR

LL CR

SL SB SR

LL C R

SL SB SR

LL C R

SL SBSBSR

Front L/R

Front L/R, Center

Front L/R, Surround L/R

Front L/R, Center, Surround L/R

ENTER

PRESET/CH

A-E/CAT.

7 Press d to confirm your selection.

ENTER

PRESET/CH

A-E/CAT.

9 Press d to confirm your selection.

ENTER

PRESET/CH

If you selected “SET” in the previous step, you will hear a test tone from each speaker in turn. “CHECK:TestTone” appears in the front panel display for a few seconds and then “CHECK OK?” appears in the front panel display.

The indicator of the speaker currently outputting the test tone flashes in the front panel display.

A-E/CAT.

10 Press j / i to select the desired setting.

ENTER

PRESET/CH

Choices: YES, NO

• Select “YES” to complete the setup procedure if the test tone levels from each speaker were satisfactory.

• Select “NO” to proceed to the speaker level adjustment menu to balance the output level of each speaker.

A-E/CAT.

11 Press d to confirm your selection.

PREPARATION

“iSET CANCEL” appears in front panel display.

8 Press j / i to select the desired setting.

ENTER

PRESET/CH

A-E/CAT.

• If you selected “YES” in the previous step, the setup procedure is completed and the display

ENTER

PRESET/CH

A-E/CAT.

returns to the “BASIC MENU”.

• If you selected “NO” in the previous step, the speaker level adjustment display appears in the front panel display.

Choices: SET, CANCEL

• Select “SET” to apply the settings you made.

• Select “CANCEL” to cancel the setup procedure without making any changes.

You can also press SET MENU repeatedly to cancel the setup procedure.

SETUP

–

– –

–

12 Press j / i to adjust the balance between the

front left and right speakers.

ENTER

PRESET/CH

A-E/CAT.

13 Press d / u to select a speaker and then j / i

to adjust the balance.

Press i to increase the value. Press j to decrease the value.

ENTER

PRESET/CH

A-E/CAT.

ENTER

PRESET/CH

A-E/CAT.

• Select “C” to adjust the balance between the front left and center speakers.

• Select “SL” to adjust the balance between the front left and surround left speakers.

• Select “SR” to adjust the balance between the surround left and surround right speakers.

• Select “SWFR” to adjust the balance between the front left speaker and the subwoofer.

14 To confirm the settings, press d / u

repeatedly until “2 SP LEVEL” appears in the front panel display.

ENTER

PRESET/CH

A-E/CAT.

15 Press d repeatedly until the menu

disappears.

ENTER

PRESET/CH

A-E/CAT.

PLAYBACK

CAUTION

Extreme caution should be exercised when you play back CDs encoded in DTS. If you play back a CD encoded in DTS on a DTS-incompatible CD player, you will only hear some unwanted noise that may damage your speakers. Check whether your CD player supports CDs encoded in DTS. Also, check the sound output level of your CD player before you play back a CD encoded in DTS.

Basic operations

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

l PROGRAM h

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

2667 53

REC

DISC SKIP

+–+

CHVO L

–

MUTE

INPUT

2CH STEREO

MUSIC

5CH STEREOSTANDARD

SPEAKERS

LEVEL

1 Turn on the video monitor connected to this

unit.

2 Press SPEAKERS on the front panel

repeatedly (or press AMP and then SPEAKERS A/B on the remote control) to select the front speakers you want to use.

The respective speaker indicators lights up in the front panel display.

SPEAKERS

A/B/OFF

AMP

SET MENU

INPUT MODE

AUDIO

NIGHT +10

VOLUME

MUTE

–

l INPUT h

SLEEPTUNERMD/CD-RCD

V-AUXVCRDTV/CBLDVD

MULTI CH IN

CODE SET

AMP

MOVIEENTERTAIN

432

8765

STRAIGHT

ENT.

SET MENU

TUNING MODE

MEMORY

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

MULTI CH INPUT

2 5

SPEAKERS

3 Press INPUT l / h on the front panel

repeatedly (or press one of the input selector buttons on the remote control) to select the desired input source.

NPU

Front panel

MD/CD-RCD

V-AU XVCRDTV/CBLDVD

Remote control

The name of the currently selected input source appears in the front panel display for a few seconds.

Selected input source

VCR

V-AU X

DTV/CBL

DVD

MD/CD-R

TUNER CD

DVD AUTO

Selected input source Input mode

Note

If you are to select an input source connected via digital connections, set “INPUT MODE” to “AUTO” or “DTS” (see page 26).

4 Start playback on the selected component or

select a broadcast station.

• When a multi-channel signal (Dolby Digital or DTS) is input digitally, this unit decodes the signal and reproduces surround sound.

• Refer to the operating instructions for the source component.

• See page 35 for details about FM/AM tuning instructions.

• See page 41 for details about XM Satellite Radio tuning instructions.

OPERATION

BASIC

Remote controlFront panel

PLAYBACK

5 Rotate VOLUME on the front panel (or press

VOLUME +/– on the remote control) to adjust the volume to the desired output level.

VOLUME

–

Note

If you connected a recording component to the VCR OUT, or MD/CD-R OUT (REC) jacks, and you notice distortion or low volume during playback from other components, try turning on the recording component.

6 Press TONE CONTROL on the front panel

repeatedly to select “BASS” or “TREBLE” and then press BASS/TREBLE +/– to adjust the corresponding frequency response level.

TONE CONTROL

BASS/TREBLE

7 Press PROGRAM l / h on the front panel

repeatedly (or press one of the sound field program selector buttons on the remote control repeatedly) to select the desired sound field program.

The name of the selected sound field program appears in the front panel display. See page 31 for details about sound field programs.

l PROGRAM h

Front panel

2CH STEREO

MUSIC

SPEAKERS

Remote control

MOVIEENTERTAIN

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

• Select “BASS” to adjust the low-frequency response.

• Select “TREBLE” to adjust the high-frequency response.

Notes

• Speaker and headphone adjustments are stored

independently.

• When “TONE BYPASS” (see page 55) is set to “AUTO”,

and “BASS” and “TREBLE” are set to 0 dB, audio output automatically bypasses the tone control circuitry of this unit.

• If you increase or decrease the high-frequency or low-

frequency sound to an extreme level, the tonal quality of the surround speakers may not match that of the front left and right speakers.

• TONE CONTROL is not effective when the component

connected to the MULTI CH INPUT jacks is selected as the input source (see page 25).

The Roxy Thtr

Currently selected

surround field program

Notes

• Choose a sound field program based on your listening preference, not merely on the name of the program.

• When you select an input source, this unit automatically selects the last sound field program used with the corresponding input source.

• Sound field programs cannot be selected when the component connected to the MULTI CH INPUT jacks is selected as the input source (see page 25).

• When sampling frequencies higher than 48 kHz are input, this unit is automatically set to the “STEREO” mode.

• To display information about the currently selected input source in the front panel display, see page 28 for details.

Additional operations

■ Listening with headphones using SILENT CINEMA

SILENT CINEMA allows you to enjoy multi-channel music or movie sound, including Dolby Digital and DTS sources, through ordinary headphones. SILENT CINEMA activates automatically whenever you connect headphones to the PHONES jack while listening to CINEMA DSP or HiFi DSP sound field programs (see page 31). When activated, the SILENT CINEMA indicator lights up in the front panel display.

Notes

• SILENT CINEMA does not activate when the component

connected to the MULTI CH INPUT jacks is selected as the input source.

• SILENT CINEMA is not effective when “2CH STEREO” (see

page 31) is selected or when this unit is in the “STRAIGHT” mode (see page 33).

• The sound from the LFE channel will be mixed and output from

the headphones.

■ Muting the audio output

Press MUTE on the remote control to mute the audio output.

Press MUTE again to resume the audio output.

MUTE

PLAYBACK

■ Selecting the MULTI CH INPUT component as the input source

Use this feature to select the component connected to the MULTI CH INPUT jacks (see page 16) as the input source.

Press MULTI CH INPUT on the front panel (or MULTI CH IN on the remote control) so that “MULTI CH INPUT” appears in the front panel display.

MULTI CH INPUT

Front panel

MULTI CH IN

Remote control

Note

When “MULTI CH INPUT” is shown in the front panel display, no other source can be played. To select another input source with INPUT l / h on the front panel (or one of the input selector buttons on the remote control), press MULTI CH INPUT (or MULTI CH IN on the remote control) so that “MULTI CH INPUT” disappears from the front panel display.

■ Using the night listening mode

The night listening mode is designed to improve listenability at lower volumes or at night.

Press AMP on the remote control and then press NIGHT to select “NIGHT ON”.

OPERATION

BASIC

• You can also rotate VOLUME on the front panel or VOLUME +/– on the remote control to resume the audio output.

• You can adjust the muting level by using “AUDIO MUTE” in “OPTION MENU” (see page 56).

• The MUTE indicator flashes in the front panel display when the audio output is muted and disappears from the front panel display when the audio output is resumed.

Note

If you change the input source or the sound field program while the audio output is being muted, this unit resumes the audio output.

AMP

NIGHT

+10

When a night listening mode is selected, the NIGHT indicator lights up in the front panel display.

Notes

• You can use the night listening mode with any of the sound field programs.

• The night listening mode may vary in effectiveness depending on the input source and the surround sound settings you use.

PLAYBACK

–

■ Selecting the input modes

This unit comes with a variety of input jacks. Do the following to select the type of input signals you want to use.

• We recommend setting “INPUT MODE” to “AUTO” in most cases.

• You can adjust the default input mode of this unit by using the “INPUT MODE” parameter in “INPUT MENU” (see page 55).

Notes

• To play DTS-encoded CDs when using a digital audio connection, be sure to set “INPUT MODE” to “DTS”.

• Depending on the player, DTS decoding may not be performed correctly even if you make a digital connection between this unit and the player.

1 Press INPUT l / h on the front panel to

select the desired input source.

NPU

2 Press INPUT MODE on the front panel

repeatedly to select the desired input mode.

INPUT MODE

■ Adjusting speaker levels during playback

You can adjust the output level of each speaker while listening to a music source. This is also possible when playing sources input at the MULTI CH INPUT jacks.

1 Press AMP on the remote control and then

press LEVEL repeatedly to select the speaker you want to adjust.

AMP

• Select “FRONT L” to adjust the front left speaker

output level.

• Select “CENTER” to adjust the center speaker

output level.

• Select “FRONT R” to adjust the front right speaker

output level.

• Select “SUR. R” to adjust the surround right

speaker output level.

• Select “SUR. L” to adjust the surround left speaker

output level.

• Select “SWFR” to adjust the subwoofer output

level.

Once you press LEVEL on the remote control, you can also select the speaker by pressing u / d.

LEVEL

TITLE

BAND

Currently selected

input sources

VCR

V-AU X

DTV/CBL

DVD

MD/CD-R

TUNER CD

DVD AUTO

Currently selected

input source

AUTO Automatically selects input signals in

the following order:

1) Digital signals

2) Analog signals

DTS Selects only digital signals encoded in

DTS. If no DTS signals are input, no sound is output.

ANALOG Selects only analog signals. If no

analog signals are input, no sound is output.

Note

When “INPUT MODE” is set to “AUTO”, this unit automatically switches to the appropriate decoder if a Dolby Digital or DTS signal is detected.

Currently selected input mode

2 Press j / i on the remote control to adjust the

speaker output level.

ENTER

PRESET/CH

The control range is from +10 dB to –10 dB for the center and surround speakers, and from 0 dB to –20 dB for the front speakers and subwoofer.

Notes

• This operation will override the level adjustments made in

“SETUP” (see page 20).

• You cannot adjust speaker levels if “SPEAKER SET” in

“SOUND MENU” (see page 53) is set to “NONE”.

• You cannot adjust the subwoofer level if “BASS” in

“SPEAKER SET” (see page 53) in the set menu is set to “FRNT”.

• If you use LEVEL to adjust speaker levels, the speaker levels

you previously set with the test tone will also change.

• If you select “SETUP” (see page 20) and then select “SET”,

speaker levels change in response to any changes you make in “SETUP”.

A-E/CAT.

PLAYBACK

– –

■ Using the test tone

Use the test tone to set speaker levels so that the volume from each speaker is identical when heard from your listening position. This is also possible when playing sources input at the MULTI CH INPUT jacks.

1 Press AMP on the remote control and then

press TEST.

The unit will output a test tone.

AMP

TEST

RETURN

MEMORY

2 Press u / d repeatedly to select a speaker to

adjust.

ENTER

PRESET/CH

• Select “TEST LEFT” to adjust the front left speaker output level.

• Select “TEST CENTER” to adjust the center speaker output level.

• Select “TEST RIGHT” to adjust the front right speaker output level.

• Select “TEST SUR.R” to adjust the surround right speaker output level.

• Select “TEST SUR.L” to adjust the surround left speaker output level.

• Select “TEST SUBWOOFER” to adjust the subwoofer output level.

A-E/CAT.

Notes

• You cannot use the test tone if headphones are connected to the PHONES jack. Remove the headphones from the PHONES jack.

• This operation will override the level adjustments made in “SETUP” (see page 20).

• You cannot adjust speaker levels if “SPEAKER SET” in “SOUND MENU” (see page 53) is set to “NONE”.

• You cannot adjust the subwoofer level if “BASS” in “SPEAKER SET” (see page 53) in the set menu is set to “FRNT”.

• If you use TEST to adjust speaker levels, the speaker levels you previously adjust during playback will also change.

• If you select “SETUP” (see page 20) and then select “SET”, speaker levels change in response to any changes you make in “SETUP”.

Depending on the source, the speaker levels set with the test tone may not be to your liking. In this case, adjust the speaker levels while listening to the source.

OPERATION

BASIC

3 Press j / i on the remote control to adjust the

speaker output level.

ENTER

PRESET/CH

A-E/CAT.

The control range is from +10 dB to –10 dB for the center and surround speakers, and from 0 dB to –20 dB for the front speakers and subwoofer.

4 Press TEST on the remote control when you

have completed your adjustment.

The test tone halts.

TEST

RETURN

MEMORY

PLAYBACK

–

■ Displaying information about the input source

You can display the format, sampling frequency, channel and bit rate of the current input signal.

1 Press one of the input selector buttons on

the remote control to select the desired input source.

2 Press AMP on the remote control and then

press STRAIGHT to select “STRAIGHT”.

AMP

STRAIGHT

ENT.

3 Press u / d to display the following

information about the input source.

ENTER

PRESET/CH

A-E/CAT.

FORMAT

Signal format display. When this unit cannot detect a digital signal, it automatically switches to analog input. Display status: Analog, Digital, Dolby Digital, DTS, PCM, Unknown Digital

Note

“Unknown Digital” appears when this unit detects any undecodable digital signal.

CHANNEL

Number of source channels in the input signal (front/ surround/LFE). For example, a multi-channel soundtrack with 3 front channels, 2 surround channels and LFE, is displayed as “3/2/LFE”.

SAMPLING

Sampling frequency. Display status: 32kHz, 44.1kHz, 48kHz, 64kHz,

88.2kHz, 96kHz

BITRATE

Bit rate.

When you are displaying information about the input source, this unit is in the “STRAIGHT” mode (see page 33). To turn back the sound field program on, press STRAIGHT again.

PLAYBACK

■ Using the sleep timer

Use this feature to automatically set this unit to the standby mode after a certain amount of time. The sleep timer is useful when you are going to sleep while this unit is playing or recording a source.

Press SLEEP on the remote control repeatedly to set the amount of time.

Each time you press SLEEP, the front panel display changes as shown below.

SLEEP

SLEEP 120min

SLEEP 90min

SLEEP 60minSLEEP 30minSLEEP OFF

The SLEEP indicator flashes while you are switching the amount of time for the sleep timer. Once the sleep timer is set, the SLEEP indicator lights up in the front panel display, and the display returns to the selected sound field program.

SLEEP

SLEEP 120min

Flashes

■ Playing video sources in the background

You can combine a video image from a video source with sound from an audio source. For example, you can enjoy listening to classical music while viewing beautiful scenery from the video source on the video monitor.

Press the input selector buttons on the remote control to select a video source and then an audio source.

TUNERMD/CD-RCD

V-AU XVCRDTV/CBLDVD

Note

If you want to enjoy an audio source input at the MULTI CH INPUT jacks together with a video source, first select the video source and then press MULTI CH INPUT on the front panel (or MULTI CH IN on the remote control) to select the component connected to the MULTI CH INPUT jacks as the input source (see page 25).

Audio sources

Video sources

OPERATION

BASIC

SLEEP

The Roxy Thtr

Lights up

To cancel the sleep timer, press SLEEP on the remote control repeatedly until “SLEEP OFF” appears in the front panel display.

The SLEEP indicator turns off and “SLEEP OFF” disappears after a few seconds.

The sleep timer setting can also be canceled by pressing STANDBY/ON on the front panel (or STANDBY on the remote control) to set this unit to the standby mode.

SOUND FIELD PROGRAMS

This unit is equipped with a variety of precise digital decoders that allow you to enjoy multi-channel playback from almost any stereo or multi-channel sound source. This unit is also equipped with a YAMAHA digital sound field processing (DSP) chip containing several sound field programs which you can use to enhance your playback experience.

Notes

• Choose a sound field program based on your listening preference, not merely on the name of the program.

• When you select an input source, this unit automatically selects the last sound field program used with the corresponding input source.

• Sound field programs cannot be selected when the component connected to the MULTI CH INPUT jacks is selected as the input source (see page 25).

• When sampling frequencies higher than 48 kHz are input, this unit is automatically set to the “STEREO” mode.

■ Front panel operations

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

INPUT MODE

PROGRAM l / h

Press PROGRAM l / h on the front panel repeatedly.

The name of the selected sound field program appears in the front panel display.

TUNING MODE

MEMORY

DISPLAY

SET MENU

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

■ Remote control operations

+–+

CHVO L

INPUT

MUSIC

B 09

AMP

VOLUME

–

MUTE

MOVIEENTERTAIN

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

–

MUTE

2CH STEREO

SPEAKERS

(U.S.A. model)

Press AMP on the remote control and then press one of the sound field program selector buttons repeatedly.

The name of the selected sound field program appears in the front panel display.

AMP

Sound field program selector buttons

Sound field program descriptions

Remote

control

button

2CH STEREO

MUSIC

ENTERTAIN

MOVIE

STANDARD

5CH STEREO

Program Features

2CH STEREO

Concert Hall

The Roxy Thtr

Game

TV Sports

Movie Spacious

Movie Dramatic

STANDARD

5CH STEREO

Downmixes multi-channel sources to 2 channel or plays back 2-channel sources as they are.

HiFi DSP processing. This program produces the excitement of a live concert hall.

HiFi DSP processing. The program reproduces the dynamic rock music environment of “The Roxy Theatre”, one of the hottest rock clubs in L.A. The listener’s virtual seat is at the center-left of the hall.

CINEMA DSP processing. This program adds the dynamics and thrills of the threedimensional surround sound effect.

CINEMA DSP processing. This program enhances the experience of watching sports by producing the ambient sounds of the crowd and the stadium.

CINEMA DSP processing. This program offers clear dialog with a wide sound field for movie scenes. It is ideal for any type of movie, live music and game contents.

CINEMA DSP processing. This program creates a live sound field by emphasizing the dramatic scene changes of action movies and games.

Standard processing for the selected decoder.

Using this program increases the listening position range. This is a sound field suitable for background music at parties.

SOUND FIELD PROGRAMS

OPERATION

BASIC

The sound field programs are compatible with all Dolby Digital, DTS, and Dolby Surround sources. Set “INPUT MODE” to “AUTO” (see page 26) to enable this unit to automatically switch to the appropriate digital decoder according to the input signal.

Notes

• The sound field programs of this unit are recreations of real-world acoustic environments made from precise measurements taken in the actual concert hall, music venue, movie theater, etc. Thus, you may notice variations in the strength of the reflections coming from the front, back, left and right.

• Choose a sound field program based on your listening preference, not merely on the name of the program itself.

SOUND FIELD PROGRAMS

– –

■ Enjoying 2-channel sources using the standard decoders

Signals input from 2-channel sources can also be played back on multi-channels.

Press AMP on the remote control and then STANDARD on the remote control repeatedly to select a decoder.

AMP

You can select from the following decoders depending on the type of source you are playing and your personal preference.

STANDARD Functions

PRO LOGIC

PLII Movie

PLII Music

Dolby Pro Logic processing for any sources

Dolby Pro Logic II processing for movie sources

Dolby Pro Logic II processing for music sources

You can also select a decoder by pressing j / i on the remote control while the decoder type is displayed in the front panel display.

STANDARD

■ Editing sound fields parameters

You can enjoy good quality sound with the factory preset parameters. Although you do not have to change the initial settings, you can change some of the parameters to better suit the input source or your listening room.

1 While listening to a source, press AMP on the

remote control and then press u / d to select the parameters.

ENTER

PRESET/CH

A-E/CAT.

2 Press j / i to change parameter value.

ENTER

PRESET/CH

Note

You cannot change parameter values when “MEM. GUARD” in “OPTION MENU” is set to “ON” (see page 56).

A-E/CAT.

SOUND FIELD PROGRAMS

For 2CH STEREO:

Direct DIRECT

Function: 2-channel stereo direct. Bypasses the

decoders and DSP processors of this unit for pure hi-fi stereo sound when playing 2-channel analog sources.

Choices: AUTO, OFF

• The “AUTO” setting bypasses the decoders and DSP processors only when “BASS” and “TREBLE” are set to 0 dB (see page 24).

• When multi-channel signals (Dolby Digital and DTS) are input, they are downmixed to 2 channels and output from the front left and right speakers.

• The low-frequency signals input from the front left and right speakers are redirected to the subwoofer in the following cases: – “BASS” is set to “BOTH” (see page 54). – “FRONT” is set to “SML” (see page 54) and “BASS” is set to

“SWFR” (see page 54).

For PRO LOGIC II Music:

Panorama PANORAMA

Function: Sends stereo signals to the surround

speakers as well as the front speakers for a wraparound effect.

Choices: OFF, ON

Dimension DIMENSION

Function: Gradually adjusts the sound field either

towards the front or towards the rear.

Control range: –3 (towards the rear) to +3 (towards the

front), initial setting is STD (standard).

Center width CT WIDTH

Function: Adjusts the center image from all three

front speakers to varying degrees. A larger value adjusts the center image towards the front left and right speakers.

Control range: 0 (center channel sound is output only

from center speaker) to 7 (center channel sound is output only from front left and right speakers), initial setting is 3.

■ Using Virtual CINEMA DSP

Virtual CINEMA DSP allows you to enjoy the CINEMA DSP programs without surround speakers by creating virtual speakers. If you set “SURR”

to “NONE” (see page 54), Virtual

CINEMA DSP activates automatically whenever you select a CINEMA DSP program (see page 31).

Note

Virtual CINEMA DSP will not activate even when “SURR” is set to “NONE” (see page 54) in the following cases:

– When “2CH STEREO” (see page 31) is selected or when this

unit is in the “STRAIGHT” mode.

– When the component connected to the MULTI CH INPUT

jacks is selected as the input source (see page 25).

– When headphones are connected to the PHONES jack.

■ Listening to unprocessed input signals

When this unit is in the “STRAIGHT” mode, multichannel sources are decoded straight into the appropriate channels without any additional effect processing. 2channel stereo sources are output from only the front left and right speakers.

1 Press AMP on the remote control and then

STRAIGHT to select “STRAIGHT”.

AMP

STRAIGHT

ENT.

2 To deactivate the “STRAIGHT” mode, press

STRAIGHT on the remote control again so that “STRAIGHT” disappears from the front panel display.

The sound field program is turned back on.

You can also select “STRAIGHT” by pressing STRAIGHT on the front panel.

OPERATION

BASIC

RECORDING

Recording adjustments and other operations are performed from the recording components. Refer to the operating instructions for those components.

Notes

• When this unit is set to the standby mode, you cannot record between other components connected to this unit.

• The settings of TONE CONTROL (see page 24), VOLUME, speaker levels (see page 26) and the sound field programs (see page 31) do not affect recorded material.

• The source connected to the MULTI CH INPUT jacks of this unit cannot be recorded.

• Digital signals input at the DIGITAL INPUT jacks are not output at the analog AUDIO OUT (REC) jacks for recording. Therefore, if your source component is connected to provide only digital signals, you cannot record the source.

• A given input source is not output on the same OUT (REC) channel.

• Check the copyright laws in your country to record from CDs, radio, etc. Recording of copyrighted material may infringe copyright laws.

• The XM Satellite Radio signals cannot be output at the AUDIO OUT (REC) jacks.

Do a test recording before you start an actual recording.

If you play back a video source that uses scrambled or encoded signals to prevent it from being dubbed, the picture itself may be disturbed due to those signals.

SILENT CINEMA

(U.S.A. model)

VOLUME

STANDBY

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

INPUT MODE

TUNING MODE

MEMORY

DISPLAY

SET MENU

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

1 Turn on all the connected components.

2 Press INPUT l / h on the front panel

repeatedly (or press one of the input selector buttons on the remote control) to select the source component you want to record from.

NPU

POWER

TV AVTV

REC

(U.S.A. model)

POWER

STANDBY

POWERPOWER

SLEEPTUNERMD/CD-RCD

V-AUXVCRDTV/CBLDVD

MULTI CH IN

Front panel Remote control

3 Start playback on the selected source

MD/CD-RCD

V-AU XVCRDTV/CBLDVD

component or select a broadcast station.

4 Start recording on the recording component.

FM/AM TUNING

There are 2 tuning methods: automatic and manual. Automatic tuning is effective when station signals are strong and there is no interference. If the signal from the station you want to select is weak, tune into it manually. You can also use the automatic and manual preset tuning features to store up to 40 stations (A1 to E8: 8 preset station numbers in each of the 5 preset station groups). Furthermore, you can recall any preset stations and exchange the assignment of two preset stations with each other.

Automatic tuning

Automatic tuning is effective when station signals are strong and there is no interference.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

PRESET/TUNING/CH

FM/AMPRESET/TUNING

A/B/C/D/E

CATEGORY

PROGRAM

BASS/TREBLE

2413

1 Press INPUT l / h repeatedly so that

“TUNER” is displayed in the front panel display.

NPU

2 Press FM/AM to select the reception band

(FM or AM).

FM/AM

TUNING MODE

MEMORY

DISPLAY

SET MENU

INPUT MODE

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

3 Press TUNING MODE so that the AUTO

indicator lights up in the front panel display.

TUNING MODE

DISPLAY

AUTO/MAN'L

Lights up

AUTO

1440

kHz

No colon (:)

If a colon (:) appears in the front panel display, automatic tuning is not possible. Press PRESET/ TUNING to turn the colon (:) off.

PRESET/TUNING

SEARCH MODE

EDIT

4 Press PRESET/TUNING/CH l / h once to

begin automatic tuning.

When this unit is tuned into a station, the TUNED indicator lights up and the frequency of the received station is shown in the front panel display.

•Press h to tune into a higher frequency.

•Press l to tune into a lower frequency.

OPERATION

BASIC

PRESET/TUNING/CH

SET MENU

1530

Lights up

AUTO

TUNED

kHz

FM/AM TUNING

Manual tuning

If the signal received from the station you want to select is weak, tune into it manually.

Note

Manually tuning into an FM station automatically switches the tuner to monaural reception to increase the signal quality.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

PRESET/TUNING/CH

FM/AMPRESET/TUNING

A/B/C/D/E

CATEGORY

PROGRAM

INPUT MODE

BASS/TREBLE

2413

1 Press INPUT l / h repeatedly so that

“TUNER” is displayed in the front panel display.

NPU

2 Press FM/AM to select the reception band

(FM or AM).

FM/AM

TUNING MODE

MEMORY

DISPLAY

SET MENU

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

3 Press TUNING MODE so that the AUTO

indicator disappears from the front panel display.

TUNING MODE

DISPLAY

AUTO/MAN'L

1440

kHz

No colon (:)

If a colon (:) appears in the front panel display, manual tuning is not possible. Press PRESET/ TUNING to turn the colon (:) off.

PRESET/TUNING

SEARCH MODE

EDIT

4 Press PRESET/TUNING/CH l / h to tune

into the desired station manually.

•Press h to tune into a higher frequency.

•Press l to tune into a lower frequency.

• Hold down the button to continue searching.

PRESET/TUNING/CH

SET MENU

FM/AM TUNING

Automatic preset tuning

You can use the automatic preset tuning feature to store FM stations with strong signals up to 40 (A1 to E8: 8 preset station numbers in each of the 5 preset station groups) of those stations in order. You can then recall any preset station easily by selecting the preset station number.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

213

1 Press INPUT l / h repeatedly so that

“TUNER” is displayed in the front panel display.

NPU

2 Press FM/AM to select “FM” as the reception

band.

FM/AM

TUNING MODE

MEMORY

DISPLAY

SET MENU

INPUT MODE

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

3 Press and hold MEMORY for more than 3

seconds.

The preset station number as well as the MEMORY and AUTO indicators flashes. After approximately 5 seconds, automatic presetting starts from the current frequency and proceeds toward the higher frequencies.

MEMORY

MAN'L/AUTO FM

Flash

AUTO

MEMORY

A1:FM 87.5 MHz

Flashes

When automatic preset tuning is completed, the front panel display shows the frequency of the last preset station.

You can select the preset station group and the preset station number where the first received station will be stored by pressing A/B/C/D/E on the front panel and then PRESET/TUNING/CH l / h.

Notes

• Any stored station data existing under a preset station number is cleared when you store a new station under the same preset station number.

• If the number of received stations does not reach 40 (E8), automatic preset tuning automatically stops after searching for all the available stations.

• Only FM stations with sufficient signal strength are stored automatically by automatic preset tuning. If the station you want to store is weak in signal strength, tune into it manually and store it as described in “Manual preset tuning” on page 38.

OPERATION

BASIC

FM/AM TUNING

Manual preset tuning

You can also store up to 40 stations (A1 to E8: 8 preset station numbers in each of the 5 preset station groups) manually.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

INPUT MODE

3 2,54

1 Tune into a station automatically or manually.

See pages 35 and 36 for tuning instructions.

630

When this unit is tuned into a station, the front panel display shows the frequency of the station received.

2 Press MEMORY.

The MEMORY indicator flashes in the front panel display for approximately 5 seconds.

TUNING MODE

MEMORY

DISPLAY

SET MENU

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

TUNED

kHz

4 Press PRESET/TUNING/CH l / h to select a

preset station number (1 to 8) while the MEMORY indicator is flashing.

•Press h to select a higher preset station number.

•Press l to select a lower preset station number.

PRESET/TUNING/CH

SET MENU

Flashes

TUNED

MEMORY

Preset station number

630

kHz

5 Press MEMORY while the MEMORY indicator

is flashing.

The station band and frequency appear in the front panel display with the preset station group and number you have selected.

MEMORY

MAN'L/AUTO FM

MEMORY

MAN'L/AUTO FM

MEMORY

Flashes

3 Press A/B/C/D/E repeatedly to select a preset

station group (A to E) while the MEMORY indicator is flashing.

The preset station group letter appears. Check that the colon (:) appears in the front panel display.

A/B/C/D/E

CATEGORY

Flashes

TUNED

MEMORY

Preset station

group

Colon (:)

630

kHz

TUNED

630

kHz

The displayed station has been stored as C3.

6 Repeat steps 1 through 5 to store other

stations.

Notes

• Any stored station data existing under a preset station number is cleared when you store a new station under the same preset station number.

• The reception mode (stereo or monaural) is stored along with the station frequency.

FM/AM TUNING

–

Selecting preset stations

You can tune into any desired station simply by selecting the preset station group and number under which it was stored.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

2CH STEREO

MUSIC

5CH STEREOSTANDARD

SPEAKERS

LEVEL

TITLE

ENTER

–

TEST

RETURN

MEMORY

PRESET/CH

(U.S.A. model)

When performing this operation with the remote control, press TUNER to select “FM” or “AM” as the input source.

TUNING MODE

MEMORY

DISPLAY

A-E/CAT.

MOVIEENTERTAIN

STRAIGHT

ENT.

SET MENU

SRCH MODEBAND

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

432

8765

SET MENU

INPUT MODE

NIGHT

+10

2 Press PRESET/TUNING/CH l / h on the

front panel (or PRESET/CH u / d on the remote control) to select the desired preset station number (1 to 8).

The preset station group and number appear in the front panel display along with the station band and frequency.

PRESET/TUNING/CH

SET MENU

Front panel

87.5

You can select the desired preset station number (1 to 8) directly by pressing the numeric buttons on the remote control.

ENTER

A-E/CAT.

PRESET/CH

Remote control

MHz

OPERATION

BASIC

1 Press A/B/C/D/E on the front panel (or A-E/

CAT. j / i on the remote control) repeatedly to select the desired preset station group (A to E).

The preset station group letter appears in the front panel display and changes each time you press the button.

A/B/C/D/E

CATEGORY

Front panel

ENTER

A-E/CAT.

PRESET/CH

Remote control

FM/AM TUNING

Exchanging preset stations

You can exchange the assignments of two preset stations with each other. The example below describes the procedure to exchange preset station “E1” with “A5”.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

INPUT MODE

2,4 3 3

1 Select preset station “E1” using A/B/C/D/E

and PRESET/TUNING/CH l / h.

See “Selecting preset stations” on page 39.

2 Press and hold PRESET/TUNING for more

than 3 seconds.

“E1” and the MEMORY indicator flash in the front panel display.

PRESET/TUNING

SEARCH MODE

EDIT

TUNING MODE

MEMORY

DISPLAY

SET MENU

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

3 Select preset station “A5” using A/B/C/D/E

and PRESET/TUNING/CH l / h.

“A5” and the MEMORY indicator flash in the front panel display. See “Selecting preset stations” on page 39.

A/B/C/D/E

CATEGORY

Flashes

90.6

PRESET/TUNING/CH

SET MENU

Flashes

MEMORY

MHz

4 Press PRESET/TUNING again.

“EDIT E1–A5” appears in the front panel display and the assignments of the two preset stations are exchanged.

PRESET/TUNING

SEARCH MODE

EDIT

Flashes

87.5

Flashes

EDIT E1-A5

MEMORY

MHz

XM® SATELLITE RADIO TUNING

What is XM Satellite Radio?

XM Satellite Radio is the satellite radio service with millions of listeners across the United States, broadcasting live daily. The XM Satellite Radio channel lineup includes more than 150 digital channels of choice from coast to coast: 67 commercial-free music channels, featuring hip hop to opera, classical to country, bluegrass to blues; 33 channels of premier sports, talk, comedy, children’s and entertainment programming; and more than 20 channels of the traffic and weather information for major metropolitan areas nationwide.

Because XM Satellite Radio is a subscription service, you will need to set up an account and activate service with XM using your XM Satellite Radio ID number. To check your ID number, follow “Activating XM Satellite Radio” on page 43. For further information on XM Satellite Radio services, visit the XM Satellite Radio website at “http://www.xmradio.com/”.

Notes

• The XM Satellite Radio service is only available in the 48 contiguous United States (not available in Alaska and Hawaii).

• XM Connect-and-Play digital antenna and monthly subscription are sold separately. For details, visit the XM Satellite Radio website at “http://www.xmradio.com/”.

■ Information from XM Satellite Radio Inc.

Hardware and required basic monthly subscription sold separately. Premium Channel available at additional monthly cost. Installation costs and other fees and taxes, including a one-time activation fee may apply. Subscription fee is consumer only. All fees and programming subject to change. Channels with frequent explicit language are indicated with an “XL”. Channel blocking is available for XM radio receivers by calling “1-800-XM-RADIO (1-800-967-2346)”. Subscriptions subject to Customer Agreement available at xmradio.com. Only available in the 48 continuous United States. © 2005 XM Satellite Radio Inc. All rights reserved. All other trademarks are the property of their respective owners.

Connecting the XM Connect-andPlay digital antenna

Connect the XM Connect-and-Play digital antenna accessory (sold separately) to the XM jack on the rear panel of this unit. For details, see the operating instructions provided with the XM Connect-and-Play digital antenna.

XM Connect-and-Play digital antenna

MULTI CH INPUT

FRONT

SURROUND

DIGITAL

INPUT

WOOFER

COAXIAL OPTICAL

DTV/CBL

(PLAY)

DVD

(U.S.A. model)

Notes

• For information on obtaining the XM Connect-and-Play digital antenna, visit the XM Satellite Radio website at “http://www.xmradio.com/” or consult your local retailer that sells XM Ready products.

• To ensure the optimal reception of the XM Satellite Radio signals, the XM Connect-and-Play digital antenna must be placed at or near a southerly facing window with no obstacles in the path to the sky. You can mount it indoors or outdoors.

CENTER

SUB

MD/

CD-R

OUT

(REC)

AUDIO

OPERATION

BASIC

XM® SATELLITE RADIO TUNING

XM Satellite Radio controls and functions

Note

The following controls are available only when “XM” is selected as the input source. Press INPUT l / h on the front panel repeatedly so that “TUNER” is displayed in the front panel display and then press XM on the front panel repeatedly (or press TUNER on the remote control and then press BAND repeatedly) to select “XM” as the input source.

■ Front panel functions

(U.S.A. model)

SEARCH MODE

EDIT

STRAIGHT

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

A/B/C/D/E

CATEGORY

l PROGRAM h

BASS/TREBLE

PRESET/TUNING/CH

SET MENU

INPUT MODE

MEMORY

l INPUT h

TUNING MODE

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

MULTI CH INPUT

12 3 4 5 6

1 SEARCH MODE (PRESET/TUNING)

Changes the search mode between the All Channel Search, Category Search, and Preset Search modes (see page 45).

2 XM (FM/AM)

Switches the reception band to XM.

3 CATEGORY (A/B/C/D/E) (All Channel Search mode)

Changes the channel category while staying in the All Channel Search mode.

(Category Search mode)

Changes the channel category.

(Preset Search mode)

Changes the preset channel group (A to E).

4 PRESET/TUNING/CH l / h (All Channel Search mode)

Searches for a channel within all channels. Press and hold for quick search.

(Category Search mode)

Searches for a channel within the selected category. Press and hold for quick search.

(Preset Search mode)

Changes the preset channel number (1 to 8).

5 MEMORY

Stores a preset channel in the memory (see page 49).

6 DISPLAY (TUNING MODE)

Switches the XM information such as channel number/name, category, artist name/song title in the front panel display (see page 50).

■ Remote control functions

INPUT

MUTE

2CH STEREO

LEVEL

TITLE

BAND

–

TEST

RETURN

MEMORY

(U.S.A. model)

1 Numeric buttons (All Channel Search or Category Search mode)

Use 1 to 9 and 0 to enter a channel number directly.

(Preset Search mode)

Use 1 to 8 to enter a preset channel number directly.

2 BAND

Switches the reception band to XM.

3 A-E/CAT. j / i, PRESET/CH u / d (All Channel Search mode)

Press A-E/CAT. j / i to change the channel category. Press PRESET/CH u / d to search for a channel within all channels. Press and hold for quick search.

(Category Search mode)

Press A-E/CAT. j / i to change the channel category. Press PRESET/CH u / d to search for a channel within the selected category. Press and hold for quick search.

(Preset Search mode)

Press A-E/CAT. j / i to change the preset channel group (A to E). Press PRESET/CH u / d to change the preset channel number (1 to 8).

4 MEMORY

Stores a preset channel in the memory (see page 49).

5 ENT.

Confirms an entered channel number in the Direct Number Access mode (see page 48).

6 SRCH MODE

Changes the search mode between the All Channel Search, Category Search, and Preset Search modes (see page 45).

7 DISPLAY

Switches the XM information such as channel number/name, category, artist name/song title in the front panel display (see page 50).

SPEAKERS

MUTE

MOVIEENTERTAIN

MUSIC

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

ENTER

PRESET/CH

A-E/CAT.

SET MENU

SRCH MODE

DISPLAY

5 6

XM® SATELLITE RADIO TUNING

Activating XM Satellite Radio

To sign up for an account with the XM Satellite Radio service, an XM Satellite Radio ID number is required. Follow the procedure below to check your ID number, and then visit the website at “http://activate.xmradio.com/” or call “1-800-XM-RADIO (1-800-967-2346)” with a major credit card handy for signing up.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

131

1 Press INPUT l / h on the front panel

repeatedly so that “TUNER” is displayed in the front panel display and then press XM on the front panel repeatedly to select “XM” as the input source.

TUNING MODE

MEMORY

DISPLAY

SET MENU

INPUT MODE

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

2 Check the XM Satellite Radio reception level

and adjust the orientation of the XM Connectand-Play digital antenna for a better percentage of the reception level.

You can display the XM Satellite Radio reception level by using “XM ANT.” in “OPTION MENU” (see page 56).

Notes

• If “CHECK ANTENNA” appears in the front panel display, the XM Connect-and-Play digital antenna may not be connected to the XM jack on the rear panel of this unit properly. See “Connecting the XM Connect-and-Play digital antenna” on page 41 and check the connection.

• “XM ANT.” in “OPTION MENU” (see page 56) cannot be adjusted by using the remote control. Instead, you need to adjust the orientation of the XM Connect-and-Play digital antenna connected to the XM jack of this unit for a better percentage of the reception level.

3 Press PRESET/TUNING/CH l / h on the

front panel to select channel “0”.

PRESET/TUNING/CH

SET MENU

OPERATION

BASIC

NPU

FM/AM

Note

You cannot select channel “0” if the All Channel Search mode (see page 45) is not selected.

4 Check the XM Satellite Radio ID number

displayed in the front panel display and write it down.

ID:_____________________________________

XM® SATELLITE RADIO TUNING

Basic XM Satellite Radio operations

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

INPUT MODE

REC

AUDIO

DISC SKIP

+–+

CHVO L

–

MUTE

INPUT

2CH STEREO

MUSIC

5CH STEREOSTANDARD

NIGHT

SPEAKERS

LEVEL

TITLE

ENTER

–

TEST

RETURN

MEMORY

PRESET/CH

(U.S.A. model)

SET MENU

VOLUME

+10

TUNING MODE

MEMORY

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

SLEEPTUNERMD/CD-RCD

V-AUXVCRDTV/CBLDVD

MULTI CH IN

CODE SET

AMP

–

MUTE

MOVIEENTERTAIN

432

8765

STRAIGHT

ENT.

SET MENU

SRCH MODEBAND

A-E/CAT.

DISPLAY

(U.S.A. model)

VOLUME

1 Press INPUT l / h on the front panel

repeatedly so that “TUNER” is displayed in the front panel display and then press XM on the front panel repeatedly (or press TUNER on the remote control and then press BAND repeatedly) to select “XM” as the input source.

The XM indicator lights up in the front panel display and the XM Satellite Radio information (such as channel number/name, category, artist name/song title) for the currently selected channel appears in the front panel display.

NPU

Front panel

TUNER

Remote control

• When you select “XM” as the input source, this unit automatically recalls the previously selected channel.

• You can change the kind of channel information by pressing DISPLAY on the remote control repeatedly (see page 50).

Note

The XM Satellite Radio signals cannot be output at the AUDIO OUT (REC) jacks.

FM/AM

LEVEL

TITLE

BAND

2 Search for a channel by using one of the XM

Satellite Radio search modes.

See “Selecting the XM Satellite Radio search mode” on page 45 for details.

3 Set XM Satellite Radio preset channels, if

desired.

See “Setting XM Satellite Radio preset channels” on page 49 for details.

4 Display the XM Satellite Radio information in

the front panel display.

See “Displaying the XM Satellite Radio information” on page 50 for details.

XM® SATELLITE RADIO TUNING

–

Selecting the XM Satellite Radio search mode

You can search for the desired channel using one of the three search modes (All Channel Search, Category Search, and Preset Search modes). You can also enter the channel number directly to select the desired channel by using the Direct Number Access mode (see page 48).

■ All Channel Search mode

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

342

2CH STEREO

MUSIC

5CH STEREOSTANDARD

SPEAKERS

LEVEL TITLE

BAND

ENTER

–

TEST

RETURN

MEMORY

PRESET/CH

(U.S.A. model)

TUNING MODE

MEMORY

DISPLAY

A-E/CAT.

MOVIEENTERTAIN

432

8765

STRAIGHT

ENT.

SET MENU

SRCH MODE

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

SET MENU

INPUT MODE

NIGHT

+10

3 Press CATEGORY on the front panel (or

A-E/CAT. j / i on the remote control) repeatedly to change the channel category.

A/B/C/D/E

CATEGORY

Front panel Remote control

ENTER

PRESET/CH

A-E/CAT.

4 Press PRESET/TUNING/CH l / h on the

front panel (or PRESET/CH u / d on the remote control) repeatedly to search for a channel within all channels.

PRESET/TUNING/CH

SET MENU

Front panel

You can search for a channel quickly by pressing and holding PRESET/TUNING/CH l / h on the front panel (or PRESET/CH u / d on the remote control).

ENTER

A-E/CAT.

PRESET/CH

Remote control

OPERATION

BASIC

1 Select “XM” as the input source.

See “Basic XM Satellite Radio operations” on page 44 for details.

2 Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control) repeatedly to select “ALL CH SEARCH”.

PRESET/TUNING

SEARCH MODE

EDIT

Front panel Remote control

SET MENU

SRCH MODE

XM® SATELLITE RADIO TUNING

–

■ Category Search mode

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

SET MENU

INPUT MODE

(U.S.A. model)

VOLUME

TUNING MODE

MEMORY

DISPLAY

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

3 Press CATEGORY on the front panel (or

A-E/CAT. j / i on the remote control) repeatedly to change the channel category.

A/B/C/D/E

CATEGORY

Front panel

ENTER

PRESET/CH

A-E/CAT.

Remote control

342

MOVIEENTERTAIN

MUSIC

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

SET MENU

ENTER

PRESET/CH

SRCH MODE

A-E/CAT.

DISPLAY

2CH STEREO

SPEAKERS

LEVEL

TITLE

BAND

–

TEST

RETURN

MEMORY

(U.S.A. model)

1 Select “XM” as the input source.

See “Basic XM Satellite Radio operations” on page 44 for details.

2 Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control) repeatedly to select “CAT SEARCH”.

PRESET/TUNING

SEARCH MODE

EDIT

Front panel Remote control

SET MENU

SRCH MODE

4 Press PRESET/TUNING/CH l / h on the

front panel (or PRESET/CH u / d on the remote control) repeatedly to search for a channel within the selected channel category.

PRESET/TUNING/CH

SET MENU

Front panel

You can search for a channel quickly by pressing and holding PRESET/TUNING/CH l / h on the front panel (or PRESET/CH u / d on the remote control).

ENTER

A-E/CAT.

PRESET/CH

Remote control

■ Preset Search mode

–

Prior to selecting a preset channel in the Preset Search mode, you must preset XM Satellite Radio channels. For details, see “Setting XM Satellite Radio preset channels” on page 49.

All preset channels (A1 to E8) recalls “001 Preview” by the initial factory setting.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

TUNING MODE

MEMORY

DISPLAY

SET MENU

INPUT MODE

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

342

MOVIEENTERTAIN

MUSIC

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

SET MENU

ENTER

PRESET/CH

SRCH MODE

A-E/CAT.

DISPLAY

2CH STEREO

SPEAKERS

LEVEL TITLE

BAND

–

TEST

RETURN

MEMORY

(U.S.A. model)

1 Select “XM” as the input source.

See “Basic XM Satellite Radio operations” on page 44 for details.

XM® SATELLITE RADIO TUNING

3 Press CATEGORY on the front panel (or

A-E/CAT. j / i on the remote control) repeatedly to change the preset channel group (A to E).

A/B/C/D/E

CATEGORY

Front panel

ENTER

A-E/CAT.

PRESET/CH

Remote control

4 Press PRESET/TUNING/CH l / h on the

front panel (or PRESET/CH u / d on the remote control) repeatedly to change the preset channel number (1 to 8).

PRESET/TUNING/CH

SET MENU

Front panel

You can also select the preset channel number directly by pressing the numeric buttons (1 to 8) on the remote control.

ENTER

A-E/CAT.

PRESET/CH

Remote control

OPERATION

BASIC

2 Press SEARCH MODE on the front panel (or

SRCH MODE on the remote control) repeatedly to select “PRESET SEARCH”.

PRESET/TUNING

SEARCH MODE

EDIT

Front panel Remote controlFront panel

SET MENU

SRCH MODE

XM® SATELLITE RADIO TUNING

■ Direct Number Access mode

+–+

CHVO L

INPUT

MUSIC

ENTER

PRESET/CH

SLEEPTUNERMD/CD-R

V-AUXVCRDTV/CBLDVD

MULTI CH IN

AUDIO

CODE SET

AMP

VOLUME

–

MUTE

MOVIEENTERTAIN

432

5CH STEREOSTANDARD

8765

STRAIGHT

NIGHT

ENT.

+10

SET MENU

SRCH MODEBAND

A-E/CAT.

DISPLAY

REC

DISC SKIP

–

MUTE

2CH STEREO

SPEAKERS

LEVEL

TITLE

–

TEST

RETURN

MEMORY

(U.S.A. model)

1 Select “XM” as the input source.

See “Basic XM Satellite Radio operations” on page 44 for details.

3 Press the numeric buttons on the remote

control to enter the desired three-digit channel number.

For example, to enter the number 123, press the numeric buttons as shown below.

2CH STEREO

MUSIC

ENTERTAIN

3 2

The display changes as follows.

<XM> --1

2 Press SRCH MODE on the remote control

repeatedly to select “ALL CH SEARCH” or “CAT SEARCH”.

SET MENU

SRCH MODE

<XM> -12

<XM>123

Press the numeric buttons and ENT. on the remote control to enter the desired one-digit or two-digit channel number.

For example, to enter the number 12, press the numeric buttons as shown below.

2CH STEREO

MUSIC

• If no button is pressed within a few seconds after you enter a one-digit or two-digit number, this unit automatically confirms the entered channel number.

• Pressing a button other than the numeric buttons or ENT. cancels the Direct Number Access mode procedure.

STRAIGHT

ENT.

XM® SATELLITE RADIO TUNING

–

Setting XM Satellite Radio preset channels

You can use this feature to store up to 40 XM Satellite Radio channels (A1 to E8: 8 preset channel numbers in each of the 5 preset channel groups). You can then recall any preset channel easily by selecting the preset channel group and number as described in “Preset Search mode” on page 47.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

2,5

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

2CH STEREO

LEVEL TITLE

BAND

–

TEST

RETURN

MEMORY

CATEGORY

SPEAKERS

PRESET/TUNING/CH

A/B/C/D/E

MUSIC

5CH STEREOSTANDARD

NIGHT

B 09

ENTER

PRESET/CH

(U.S.A. model)

1 Search for a channel you want to set as a

preset channel by using one of the XM Satellite Radio search modes.

See “Selecting the XM Satellite Radio search mode” on page 45 for details.

TUNING MODE

MEMORY

DISPLAY

SET MENU

INPUT MODE

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

2,54

MOVIEENTERTAIN

432

8765

STRAIGHT

ENT.

+10

SET MENU

SRCH MODE

A-E/CAT.

DISPLAY

2 Press MEMORY on the front panel (or

MEMORY on the remote control).

The MEMORY indicator flashes in the front panel display for approximately 5 seconds.

MEMORY

MAN'L/AUTO FM

Front panel Remote control

MEMORY

Flashes

TEST

RETURN

MEMORY

Note

You must proceed to and carry out steps 3 through 5 while the MEMORY indicator is flashing in the front panel display.

3 Press CATEGORY on the front panel (or

A-E/CAT. j / i on the remote control) repeatedly to select a preset channel group (A to E) while the MEMORY indicator is flashing.

The preset channel group letter appears in the front panel display.

A/B/C/D/E

CATEGORY

Front panel

ENTER

A-E/CAT.

PRESET/CH

Remote control

OPERATION

BASIC

Flashes

[040] Deep Tra

MEMORY

Currently selected channel number

C [040] Deep

Currently selected preset channel group

XM® SATELLITE RADIO TUNING

–

4 Press PRESET/TUNING/CH l / h on the

front panel (or PRESET/CH u / d on the remote control) repeatedly to select a preset channel number (1 to 8) while the MEMORY indicator is flashing.

The preset channel number appears in the front panel display.

PRESET/TUNING/CH

SET MENU

Front panel

ENTER

A-E/CAT.

PRESET/CH

Remote control

Flashes

MEMORY

C5 [040] Deep

Currently selected preset channel number

5 Press MEMORY on the front panel (or

MEMORY on the remote control) to set the selected XM Satellite Radio channel as a preset channel while the MEMORY indicator is flashing.

A colon (:) appears next to the preset channel number for confirmation, and the MEMORY indicator turns off in the front panel display.

MEMORY

MAN'L/AUTO FM

Front panel

TEST

RETURN

MEMORY

Remote control

Displaying the XM Satellite Radio information

You can display the XM Satellite Radio information (such as channel number/name, category, artist name/song title) for the currently selected channel in the front panel display.

(U.S.A. model)

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

SPEAKERS

STRAIGHT

A/B/OFF

EFFECT

TONE CONTROL

FM/AMPRESET/TUNING

PROGRAM

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

INPUT MODE

TUNING MODE

MEMORY

DISPLAY

SET MENU

AUTO/MAN'LMAN'L/AUTO FM

INPUT

MULTI CH INPUT

DISPLAY

LEVEL TITLE

BAND

–

TEST

RETURN

MEMORY

ENTER

PRESET/CH

A-E/CAT.

SET MENU

SRCH MODE

DISPLAY

(U.S.A. model)

Note

If a status message or an error message appears in the front panel display, see the “XM Satellite Radio (U.S.A. model only)” section in “TROUBLESHOOTING” on page 63 for appropriate remedies.

■ Displaying the XM Satellite Radio information in the front panel display

Press DISPLAY on the front panel or on the remote control repeatedly to toggle between the following XM Satellite Radio information display modes.

VOLUME

DISPLAY

TUNING MODE

Note

C5 [040] Deep :

Colon (:)

DISPLAY

AUTO/MAN'L

Front panel

DISPLAY

Remote control

Channel number/name

Channel category

Artist name/song title

Once you set a new preset channel, the one previously stored in the same preset channel group and number is cleared.

When the channel number/name is displayed:

[040] Deep Tra

When the channel category is displayed:

<CAT>Rock

When the artist name/song title is displayed:

Coldplay / Clo

• The front panel display can indicate up to 14 alphanumeric characters at once. You can set whether to display the XM Satellite Radio information in the front panel display in a continuous manner or by 14 alphanumeric characters at once by using the “SCROLL” parameter in “OPTION MENU” (see page 56).

• If the XM Satellite Radio information contains a character that cannot be recognized by this unit, the character will be replaced with a space.

XM® SATELLITE RADIO TUNING

OPERATION

BASIC

Note

If you press DISPLAY while the XM Satellite Radio information display is scrolling from right to left in the front panel display, the XM Satellite Radio information display mode toggles as described above.

SET MENU

You can use the following parameters in “SET MENU” to adjust a variety of system settings and customize the way this unit operates. Change the initial settings (indicated in bold under each parameter) to reflect the needs of your listening environment.

■ BASIC MENU

Use this feature to set up your system quickly and with minimal effort (see page 20).

■ SOUND MENU

Use this menu to manually adjust any speaker settings, alter the quality and tone of the sound output by the system.

Parameter Features Page

1 SPEAKER SET

2 SP DISTANCE

3 LFE LEVEL

4 D. RANGE

5 TC.BYPASS

Selects the size of each speaker, the speakers for low-frequency signal output, and the crossover frequency.

Adjusts the delay time of each speaker.

Adjusts the output level of the LFE channel for Dolby Digital or DTS signals.

Adjusts the dynamic range of Dolby Digital or DTS signals.

Adjusts the tone bypass settings.

■ INPUT MENU

Use this menu to manually reassign the input jacks, select the input mode or rename the input source.

Parameter Features Page

1 INPUT ASSIGN

2 INPUT MODE

Assigns the input jacks of this unit according to the component to be used.

Selects the initial input mode of the source.

■ OPTION MENU

Use this menu to manually adjust the optional system parameters.

Parameter Features Page

1 DISPLAY SET

Adjusts the brightness of the display.

2 MEM. GUARD

3 AUDIO MUTE

4 XM RADIO SET

Locks sound field program parameters and other “SET MENU” settings.

Adjusts the muting level.

Displays the current reception level of the XM Connect-and-Play digital antenna.

Note

The “XM RADIO SET” parameter is only applicable to the U.S.A. model.

SET MENU

Using SET MENU

Use the remote control to access and adjust each parameter.

AMP

+–+

VOLUME

CHVO L

SPEAKERS

–

INPUT

MUTE

MUSIC

5CH STEREOSTANDARD

STRAIGHT

NIGHT

+10

SET MENU

SRCH MODE

ENTER

A-E/CAT.

DISPLAY

PRESET/CH

–

MUTE

2CH STEREO

LEVEL TITLE

BAND

–

TEST

RETURN

MEMORY

• You can change the “SET MENU” parameters while this unit is reproducing sound.

• You can use NEXT (A/B/C/D/E) and SET MENU +/– (PRESET/TUNING/CH l / h) on the front panel to change these settings, if “TUNER” is not selected as the input source. Press NEXT to select the category or field you wish to change, and SET MENU +/– to change the parameters.

1 Press AMP.

2 Press SET MENU repeatedly to display the

desired menu and then press i to enter the menu.

Once you press SET MENU, you can also select the menu by pressing u / d.

3 Press u / d repeatedly to select the item and

then press j / i to change the parameter.

Depending on the menu item, press u / d to select a sub item, and then press j / i to change the parameter.

4 To exit, press u / d repeatedly until the

menu disappears.

MOVIEENTERTAIN

432

8765

ENT.

SOUND MENU

Use this menu to manually adjust any speaker settings.

Notes

• If you select “SETUP” (see page 20) and then select “SET” after adjusting the “SOUND MENU” parameters, the “SETUP” parameters override the “SOUND MENU” parameters. Do not enter “SETUP” unless you wish to change the “SOUND MENU” parameters. If you accidentally enter “SETUP”, select “CANCEL” to exit from “SETUP”.

• Some menu item settings have no effect when the unit is reproducing a source with a digital signal sampling frequency greater than 48 kHz.

■ Speaker settings 1 SPEAKER SET

Use this feature to manually adjust any speaker setting.

If you are not satisfied with the bass sounds from your speakers, you can change these settings according to your preference.

Center speaker 1A CENTER

Choices: LRG (large), SML (small), NON (none)

• Select “LRG” if you have a large center speaker. The

entire range of the center channel signals is directed to the center speaker.

• Select “SML” if you have a small center speaker. The

low-frequency signals of the center channel are directed to the speakers selected with “1D BASS”.

• Select “NON” if you do not have a center speaker. The

entire range of the center channel signals is directed to the front left and right speakers.

Front speakers 1B FRONT

Choices: LRG (large), SML (small)

• Select “SML” if you have small front speakers. The

low-frequency signals of the front channel are directed to the speakers selected with “1D BASS”.

• Select “LRG” if you have large front speakers. The

entire range of the front left and right channel signals is directed to the front left and right speakers.

OPERATION

ADVANCED

SET MENU

Surround left/right speakers 1C SURR

Choices: LRG (large), SML (small), NON (none)

• Select “LRG” if you have large surround left and right speakers. The entire range of the surround channel signals is directed to the surround left and right speakers.

• Select “SML” if you have small surround left and right speakers. The low-frequency signals of the surround channel are directed to the speakers selected with “1D BASS”.

• Select “NON” if you do not have surround speakers. This will set this unit to the Virtual CINEMA DSP mode (see page 33).

Bass out 1D BASS

Use this feature to select the speakers that output the LFE (low-frequency effect) and the low-frequency signals. Choices: SWFR (subwoofer), FRNT (front), BOTH

• Select “SWFR” if you connected a subwoofer. The LFE signals as well as the low-frequency signals of other speakers set to “SML” or to “NON” are directed to the subwoofer.

• Select “FRNT” if you did not connect a subwoofer. The LFE signals, the low-frequency signals of the front left and right channels, and the low-frequency signals of other speakers set to “SML” or to “NON” are all directed to the front left and right speakers regardless of the “1B FRONT” setting.

• Select “BOTH” if you connected a subwoofer. The low-frequency signals of any source are output from the subwoofer. The LFE signals as well as the lowfrequency signals of other speakers set to “SML” or to “NON” are directed to the subwoofer. The lowfrequency signals of the front left and right channels are directed to the front left and right speakers and the subwoofer regardless of the “1B FRONT” setting.

■ Speaker distance 2 SP DISTANCE

Use this feature to manually adjust the distance of each speaker and the delay applied to the respective channel. Ideally, each speaker should be the same distance from the main listening position. However, this is not possible in most home situations. Thus, a certain amount of delay must be applied to the sound from each speaker so that all sounds will arrive at the listening position at the same time.

Unit UNIT

Choices: meters, feet Initial setting: [U.S.A. and Canada models]: feet [Other models]: meters

• Select “meters” to adjust speaker distances in meters.

• Select “feet” to adjust speaker distances in feet.

Speaker distances

Control range: 0.30 to 24.00 m (1.0 to 80.0 ft) Control step: 0.10 m (0.5 ft) Initial settings: 3.00 m (10.0 ft)

• Select “FRONT” to adjust the distance of the front speaker.

• Select “CENTER” to adjust the distance of the center speaker.

• Select “SURR” to adjust the distance of the surround speaker.

Notes

• “CENTER” and “SURR” cannot be adjusted if “1A CENTER”

and “1C SURR” are set to “NON” respectively.

• No delay will be set if you set the same distance for “FRONT”,

“CENTER”, and “SURR”.

■ Low-frequency effect level 3 LFE LEVEL

Use this feature to adjust the output level of the LFE (lowfrequency effect) channel according to the capacity of your subwoofer or headphones. The LFE channel carries low-frequency special effects which are only added to certain scenes. This setting is effective only when this unit decodes Dolby Digital or DTS signals. Control range: –20 to 0 dB Control step: 1 dB

Speaker SP LFE

Adjusts the speaker LFE level.

Headphone HP LFE

Adjusts the headphone LFE level.

Notes

• Adjust the LFE level according to the capacity of your

subwoofer or headphones.

• Depending on the settings of “1D BASS”, some signals may not

be output at the SUBWOOFER OUTPUT jack.

■ Dynamic range 4 D.RANGE

Use this feature to select the amount of dynamic range compression to be applied to your speakers or headphones. This setting is effective only when the unit is decoding Dolby Digital and DTS signals. Choices: MIN (minimum), STD (standard), MAX

(maximum)

Speaker SP D.R

Adjusts the speaker compression.

Headphone HP D.R

Adjusts the headphone compression.

• Select “MIN” if you regularly listen at low volume levels.

• Select “STD” for general use.

• Select “MAX” to preserve the greatest amount of dynamic range.

■ Tone bypass 5 TC.BYPASS

Use this feature to select whether audio output bypasses tone control circuitry when “BASS” and “TREBLE” are set to 0 dB (see page 24). Choices: AUTO, OFF

• Select “AUTO” if you want signals to bypass tone control circuitry to provide the purest signal possible.

• Select “OFF” if you do not want signals to bypass tone control circuitry.

SET MENU

INPUT MENU

Use this menu to reassign input jacks or select the input mode.

■ Input assignment 1 INPUT ASSIGN

Use this feature to assign the input jacks according to the component to be used if the initial settings of this unit do not correspond to your needs. Change the following parameters to reassign the respective jacks and effectively connect more components. Once the input jacks are reassigned, you can select the corresponding component by using INPUT l / h on the front panel (or the input selector buttons on the remote control).

For COMPONENT VIDEO jacks [A][B][C]

Choices: [A] DVD, DTV/CBL, VCR, V-AUX

[B] DVD, DTV/CBL, VCR, V-AUX [C] DVD, DTV/CBL, VCR, V-AUX

For OPTICAL INPUT jacks 1 2

Choices: (1) DVD, DTV/CBL, CD, VCR, MD/CD-R,

V- AU X

(2) DVD, DTV/CBL, CD, VCR, MD/CD-R,

V- AU X

For COAXIAL INPUT jack 3

Choices: (3) DVD, DTV/CBL, CD, VCR, MD/CD-R,

V- AU X

OPERATION

ADVANCED

Note

• You cannot select a specific item more than once for the same type of jack.

• When you connect a component to both the COAXIAL and OPTICAL jacks, priority is given to the signals input at the COAXIAL jack.

■ Input mode 2 INPUT MODE

Use this feature to designate the input mode for sources connected to the DIGITAL INPUT jacks when you turn on this unit (see page 26). Choices: AUTO, LAST

• Select “AUTO” to allow this unit to automatically

detect the type of input signal and select the appropriate input mode.

• Select “LAST” to set this unit to automatically select

the last input mode used for that source.

SET MENU

OPTION MENU

Use this menu to adjust the optional system parameters.

■ Display settings 1 DISPLAY SET

Dimmer DIMMER

Use this feature to adjust the brightness of the front panel display. Choices: – Control step: 1

• Press j to make the front panel display dimmer.

• Press i to make the front panel display brighter.

■ Memory guard 2 MEM. GUARD

Use this feature to prevent accidental changes to sound field program parameter values and other system settings. Choices: ON, OFF

• Select “OFF” to turn off the “MEM. GUARD” feature.

• Select “ON” to protect:

Note

When “MEM. GUARD” is set to “ON”, you cannot select and adjust any other “SET MENU” items.

■ Audio mute 3 AUDIO MUTE

Use this feature to adjust how much the mute function reduces the output volume. Choices: MUTE, –50 dB, –20 dB

• Select “MUTE” to completely mute all the audio

• Select “–50 dB” to reduce the current volume by

• Select “–20 dB” to reduce the current volume by

4 to 0

– Sound field program parameters – All “MENU” items – All speaker levels

output.

50 dB.

20 dB.

■ XM Radio setting 4 XM RADIO SET

XM Radio antenna XM ANT.

Use this feature to check the current reception level of the XM Connect-and-Play digital antenna connected to the XM jack of this unit (see page 41). For the best reception, orient the XM Connect-and-Play digital antenna so that a value of 60% or more is displayed here. Display status: NONE, 0 to 100%

Notes

•“NONE” is displayed if the XM Connect-and-Play digital antenna is not connected to this unit. In this case, check the antenna connections (see page 41).

• The “XM ANTENNA” parameter cannot be adjusted by using the remote control. Instead, you need to adjust the orientation of the XM Connect-and-Play digital antenna connected to the XM jack of this unit for a better percentage of the reception level.

XM Radio information display scroll SCROLL

Use this feature to set whether to scroll the XM Satellite Radio information display in a continuous manner or by 14 alphanumeric characters at once (see page 50). Choices: CONT, ONCE

• Select “CONT” to scroll the XM Satellite Radio

information display in a continuous manner.

• Select “ONCE” to scroll the XM Satellite Radio

information display by 14 alphanumeric characters at once.

REMOTE CONTROL FEATURES

In addition to controlling this unit, the remote control can also operate other audiovisual components made by YAMAHA and other manufacturers. To control other components, you must set up remote control with the appropriate remote control codes (see page 59).

Controlling this unit, a TV, or other components

■ Controlling this unit

Press AMP to control this unit.

POWERPOWER

AVTV

+–+

CHVO L

INPUT

MUSIC

B 09

ENTER

PRESET/CH

STANDBY

5CH STEREOSTANDARD

NIGHT

AUDIO

+10

VOLUME

MUTE

A-E/CAT.

POWER

SLEEPTUNERMD/CD-RCD

MULTI CH IN

CODE SET

–

STRAIGHT

SET MENU

SRCH MODEBAND

V-AUXVCRDTV/CBLDVD

AMP

MOVIEENTERTAIN

432

8765

ENT.

DISPLAY

POWER

REC

DISC SKIP

–

MUTE

2CH STEREO

SPEAKERS

LEVEL

TITLE

–

TEST

RETURN

MEMORY

(U.S.A. model)

Notes

These buttons always control this unit.

These buttons control this unit only when AMP is pressed.

■ Controlling a TV

Press DTV/CBL to control your TV.

POWERPOWER

INPUT

MUSIC

STANDBY

AVTV

AUDIO

+–+

CHVO L

5CH STEREOSTANDARD

NIGHT

+10

ENTER

PRESET/CH

VOLUME

MUTE

A-E/CAT.

–

POWER

SLEEPTUNERMD/CD-RCD

V-AUXVCRDTV/CBLDVD

MULTI CH IN

CODE SET

AMP

MOVIEENTERTAIN

432

8765

STRAIGHT

ENT.

SET MENU

SRCH MODEBAND

DISPLAY

POWER

DTV/CBL *1

REC

DISC SKIP

–

MUTE

2CH STEREO

SPEAKERS

LEVEL TITLE

–

TEST

RETURN

MEMORY

(U.S.A. model)

Notes

To control your TV, you must set the appropriate remote control code for DTV/CBL.

These buttons always control your TV regardless of whether you press DTV/CBL or not.

OPERATION

ADVANCED

Remote control Digital TV/Cable TV

TV POWER Turns on or off the power.

TV VOL +/–

Increases or decreases the volume level.

TV CH +/– Changes the channel number.

TV MUTE Mutes the audio output.

TV INPUT Changes the input source.

These buttons control your TV only when DTV/CBL is pressed. For details, see the “Digital TV/Cable TV” column on page 58.

REMOTE CONTROL FEATURES

■ Controlling other components

2CH STEREO

SPEAKERS

LEVEL

TITLE

–

TEST

RETURN

MEMORY

–––

INPUTMUTE

MUTE

5CH STEREOSTANDARD

NIGHT

+10

ENTER

A-E/CAT.

PRESET/CH

Tuner (XM)

Preset channels (1-8)/

direct number access

MOVIEENTERTAINMUSIC

432

8765

STRAIGHT

ENT.

SET MENU

SRCH MODEBAND

DISPLAY

Category/group

Once you set the appropriate remote control codes (see page 59), use the input selector buttons to select the component you want to control. Note that some buttons may not correctly operate the selected component.

Notes

This button functions only when the original remote control of the component has a POWER button.

These buttons can operate your VCR when the remote control code of your VCR is set in VCR and DTV/CBL is selected.

When you use this button to record a source, press it twice

POWERTVPOWER

REC

DISC SKIP

–

POWER

CHVO L

INPUTMUTE

STANDBY

TUNERMD/CD-RCD

AUDIO

+–+

VOLUME

MUTE

POWER

SLEEP

V-AUXVCRDTV/CBLDVD

MULTI CH IN

CODE SET

–

4 5

AMP

repeatedly to prevent a malfunction.

Remote

control

1 AV P OWE R 2 REC/

DISC SKIP

DVD player VCR

Power

Disc skip

Power

Rec

p Play Play

w Search backward Search backward

f Search forward Search forward

AUDIO Audio

e Pau se Pause b Skip backward Skip backward Skip backward a Skip forward Skip forward Skip forward s Stop Stop

3 0-9, +10

4 TITLE 5 PRESET/CH u

Numeric buttons Numeric buttons Numeric buttons Numeric buttons Numeric buttons Preset stations (1-8)

Title Band Band

Up VCR channel up Preset up (1-8) Preset/channel up

PRESET/CH d Down VCR channel down Preset down (1-8) Preset/channel down

A-E/CAT. j Left Preset down (A-E)

A-E/CAT. i Right Preset up (A-E) Category/group up ENTER Select

6 RETURN 7 ENT. 8 MENU 9 DISPLAY

Return Memory

Title/Index Enter Enter Index Index Enter

Menu Search mode

Display Display Display Display Display

Digital TV/ Cable TV

Power

*2, 3

Rec

Play

backward

forward

Pause

Stop

CD player

Power

Disc Skip Rec (MD)

Play Play

Search backward Search backward

Search forward Search forward

Pause Pause

Stop Stop

MD/CD recorder

Power

Tu ne r (FM/AM)

7 8

down

REMOTE CONTROL FEATURES

Setting remote control codes

You can control other components by setting the appropriate remote control codes. You can set the remote control codes for each input source. For a complete list of available remote control codes, refer to “LIST OF REMOTE CONTROL CODES” at the end of this manual.

The following table shows the default component (Library: component category) and the remote control code for each input source.

Remote Control Code Default Settings

Input

source

CD CD YAMAHA 199

MD/CD-R CD-R YAMAHA 499

TUNER

DVD DVD YAMAHA 699

DTV/

CBL*2

Library

(component

category)

Manufacturer

Default

code

TUNER YAMAHA Fixed

–––

1 While holding down CODE SET, press one of

the input selector buttons to select the component you want to set up.

CODE SET

While holding

down

MD/CD-RCD

V-AU XVCRDTV/CBLDVD

Note

You need to hold down CODE SET throughout this procedure.

2 While holding down CODE SET, press the

numeric buttons (0 to 9) to enter the threedigit remote control code for the component to be used.

Refer to “LIST OF REMOTE CONTROL CODES” at the end of this manual.

MOVIEENTERTAIN

432

5CH STEREOSTANDARD

8765

CODE SET

While holding

down

2CH STEREO

SPEAKERS

MUSIC

VCR – – –

V- AU X – – –

You can control this unit only.

You can only set TV remote control codes in DTV/CBL.

Note

You may not be able to operate your YAMAHA component even if a YAMAHA remote control code is initially set as listed above. In this case, try setting other YAMAHA remote control codes.

Notes

• If the manufacturer of your component has more than one code, try each of them until you find the correct one.

• You can only assign one remote control code to each input selector button.

OPERATION

ADVANCED

TROUBLESHOOTING

Refer to the table below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off this unit, disconnect the power cable, and contact the nearest authorized YAMAHA dealer or service center.

■ General

Problem Cause Remedy

This unit fails to turn on or enters the standby mode soon after the power is turned on.

No sound Incorrect input or output cable

The power cable is not connected or the plug is not completely inserted.

The speaker impedance setting is incorrect.

The protection circuitry has been activated.

This unit has been exposed to a strong external electric shock (such as lightning or strong static electricity).

connections.

No appropriate input mode has been selected.

No appropriate input source has been selected.

Speaker connections are not secure. Secure the connections.

The front speakers to be used have not been selected properly.

The volume is turned down. Turn up the volume.

The sound is muted. Press MUTE or VOLUME +/– on the remote control

Signals this unit cannot reproduce are being input from a source component, such as a CD-ROM.

Connect the power cable firmly.

Set the speaker impedance to match your speakers.

Make sure that all speaker wire connections on this unit and on all speakers are secure and that the wire for each connection does not touch anything other than its respective connection.

Set this unit to the standby mode, disconnect the power cable, plug it back in after 30 seconds and then use it normally.

Connect the cables properly. If the problem persists, the cables may be defective.

Select an appropriate input mode.

Select an appropriate input source with INPUT l / h on the front panel (or the input selector buttons on the remote control) and MULTI CH INPUT on the front panel (or MULTI CH IN on the remote control).

Select the front speakers with SPEAKERS on the front panel or SPEAKERS A/B on the remote control.

to resume audio output and then adjust the volume.

Play a source whose signals can be reproduced by this unit.

See

page

—

9, 11

—

13-17

23, 25

—

TROUBLESHOOTING

Problem Cause Remedy

The sound suddenly goes off.

Sound is heard from the speaker on one side only.

Only the center speaker outputs substantial sound.

No sound is heard from the center speaker.

No sound is heard from the surround speakers.

No sound is heard from the subwoofer.

The protection circuitry has been activated because of a short circuit, etc.

The sleep timer has turned off this unit. Turn on this unit, and play the source again.

The sound is muted. Press MUTE or VOLUME +/– on the remote control

Incorrect cable connections. Connect the cables properly. If the problem persists,

Incorrect settings in “SP LEVEL”. Adjust the “SP LEVEL” settings.

When playing a monaural source with a CINEMA DSP program, the source signal is directed to the center channel, and the front and surround speakers output effect sounds.

“CENTER” in “SET MENU” is set to “NONE”.

One of the HiFi DSP programs (except for 5ch Stereo) has been selected.

“SURR” in “SPEAKER SET” is set to “NONE”.

This unit is in the “STRAIGHT” mode and a monaural source is being played back.

“BASS” in “SPEAKER SET” is set to “FRNT” when a Dolby Digital or DTS signal is being played.

“BASS” in “SPEAKER SET” is set to “SWFR” or “FRNT” when a 2-channel source is being played.

The source does not contain lowfrequency bass signals.

Check that the impedance selector setting is correct.

Check that the speaker wires are not touching each other and then turn this unit back on.

to resume audio output.

the cables may be defective.

Set “CENTER” to “SML” or “LRG”.

Try another sound field program.

Set “SURR” to “SML” or “LRG”.

Press STRAIGHT on the front panel so that “STRAIGHT” disappears from the front panel display.

Set “BASS” to “SWFR” or “BOTH”.

Set “BASS” to “BOTH”.

See

page

9, 11

—

13-17

INFORMATION

ADDITIONAL

TROUBLESHOOTING

Problem Cause Remedy

Dolby Digital or DTS sources cannot be played. (Dolby Digital or DTS indicator in the front panel display does not light up.)

A humming sound is heard.

The volume level cannot be increased, or the sound is distorted.

The sound effect cannot be recorded.

A source cannot be recorded by an analog component connected to the AUDIO OUT (REC) jacks.

The sound field parameters and some other settings of this unit cannot be changed.

This unit does not operate properly.

“CHECK SP WIRES” appears in the front panel display.

There is noise interference from digital or radio frequency equipment.

The picture is disturbed.

This unit suddenly enters the standby mode.

The connected component is not set to output Dolby Digital or DTS digital signals.

“INPUT MODE” is set to “ANALOG”. Set “INPUT MODE” to “AUTO” or “DTS”.

Incorrect cable connections. Connect the audio cables firmly. If the problem

The component connected to the AUDIO OUT (REC) jacks of this unit is turned off.

It is not possible to record the sound effect with a recording component.

The source component is not connected to the analog AUDIO IN jacks of this unit.

“MEM. GUARD” in “OPTION MENU” is set to “ON”.

The internal microcomputer has been frozen by an external electric shock (such as lightning or excessive static electricity) or by a power supply with low voltage.

Speaker cables are short-circuited. Make sure all speaker cables are connected correctly.

This unit is too close to the digital or highfrequency equipment.

The video source uses scrambled or encoded signals to prevent dubbing.

The internal temperature becomes too high and the overheat protection circuitry has been activated.

Make an appropriate setting following the operating instructions for your component.

persists, the cables may be defective.

Turn on the power of the component.

Connect the source component to the analog AUDIO IN jacks.

Set “MEM. GUARD” to “OFF”.

Disconnect the power cable from the AC wall outlet and then plug it in again after about 30 seconds.

Move this unit further away from such equipment.

Wait about 1 hour for this unit to cool down and then turn it back on.

See

page

—

14, 17

—

■ Tuner

TROUBLESHOOTING

Problem Cause Remedy

FM stereo reception is noisy.

There is distortion, and clear reception cannot be obtained even with a

good FM antenna.

The desired station cannot be tuned into with the automatic tuning method.

Previously preset stations can no longer be tuned into.

The desired station cannot be tuned into with the automatic tuning method.

There are continuous

crackling and hissing noises.

There are buzzing and whining noises.

The characteristics of FM stereo broadcasts may cause this problem when the transmitter is too far away or the antenna input is poor.

There is multi-path interference. Adjust the antenna position to eliminate

The signal is too weak. Use a high-quality directional FM antenna.

This unit has been disconnected for a long period.

The signal is weak or the antenna connections are loose.

Noises result from lightning, fluorescent lamps, motors, thermostats and other electrical equipment.

A TV set is being used nearby. Move this unit away from the TV set.

Check the antenna connections.

Try using a high-quality directional FM antenna.

Use the manual tuning method.

multi-path interference.

Use the manual tuning method.

Set preset stations.

Tighten the AM loop antenna connections and orient it for the best reception.

Use the manual tuning method.

Use an outdoor antenna and a ground wire. This will help somewhat, but it is difficult to eliminate all noise.

See

page

—

37, 38

—

■ XM Satellite Radio (U.S.A. model only)

If an operation takes longer than usual or an error occurs, one of the following messages may appear in the front panel display. In this case, read the cause and follow the corresponding remedies.

Status message Cause Remedy

CHECK ANTENNA

UPDATING

NO SIGNAL

OFF AIR

<XM> - - -

- - - / - - -

<CAT> - - -

The XM Connect-and-Play digital antenna is not connected to the XM jack of this unit or does not work properly.

The XM user encryption code is being updated.

The signal is too weak. Check the XM Connect-and-Play digital antenna

It takes longer than four seconds for audio or text data to be decoded.

The XM Satellite Radio channel you selected is not currently broadcasting any signals.

The Channel Station ID (SID) is no longer available.

No artist name or song title is available.

No channels are available for the selected category.

Check the XM Connect-and-Play digital antenna connections and orient it for the best reception level.

Wait until the encryption code is updated.

connections and orient it for the best reception level.

Wait until the decoding process has finished.

Check the channel number again or select another XM Satellite Radio channel.

Select another channel category by pressing CATEGORY on the front panel (or A-E/CAT. j / i on the remote control) repeatedly.

See

page

—

INFORMATION

ADDITIONAL

TROUBLESHOOTING

■ Remote control

Problem Cause Remedy

The remote control does not work nor function properly.

Wrong distance or angle. The remote control functions within a maximum

Direct sunlight or lighting (from an inverter type of fluorescent lamp, etc.) is striking the remote control sensor of this unit.

The batteries are weak. Replace all batteries.

The remote control code is not correctly set.

Even if the remote control code is correctly set, there are some models that do not respond to the remote control.

range of 6 m (20 ft) and no more than 30 degrees offaxis from the front panel.

Reposition this unit.

Set the remote control code correctly using “LIST OF REMOTE CONTROL CODES” at the end of this manual.

Try setting another code for the same manufacturer using “LIST OF REMOTE CONTROL CODES” at the end of this manual.

See

page

—

RESETTING THE SYSTEM

Use this feature to reset all the parameters of this unit to the initial factory settings.

Notes

• This procedure completely resets all the parameters of this unit including the “SET MENU” parameters.

• The initial factory settings are activated next time you turn on this unit.

To cancel the initialization procedure at any time without making any changes, press STRAIGHT repeatedly to select “CANCEL” and then press STANDBY/ON on the front panel.

(U.S.A. model)

VOLUME

STANDBY

SILENT CINEMA

/ON

PHONES

SEARCH MODE

EDIT

STRAIGHT

SPEAKERS

A/B/OFF

TONE CONTROL

EFFECT

FM/AMPRESET/TUNING

l PROGRAM h

BASS/TREBLE

PRESET/TUNING/CH

A/B/C/D/E

CATEGORY

TUNING MODE

MEMORY

DISPLAY

l INPUT h

AUTO/MAN'LMAN'L/AUTO FM

MULTI CH INPUT

SET MENU

INPUT MODE

2,31,2,4

1 Press STANDBY/ON on the front panel to set

this unit to the standby mode.

STANDBY

/ON

2 Press and hold STRAIGHT on the front panel

and then press STANDBY/ON to turn on this unit.

The advanced setup menu appears in the front panel display.

While holding

STRAIGHT

EFFECT

down

STANDBY

/ON

3 Press STRAIGHT on the front panel

repeatedly to select “RESET”.

STRAIGHT

EFFECT

PRESET -RESET

Select “CANCEL” to cancel the initialization procedure without making any changes.

4 Press STANDBY/ON on the front panel to

confirm your selection and set this unit to the standby mode.

STANDBY

/ON

INFORMATION

ADDITIONAL

GLOSSARY

Audio information

■ Dolby Digital

Dolby Digital is a digital surround sound system that gives you completely independent multi-channel audio. With 3 front channels (front L/R and center), and 2 surround stereo channels, Dolby Digital provides 5 full-range audio channels. With an additional channel especially for bass effects, called LFE (Low Frequency Effect), the system has a total of 5.1-channels (LFE is counted as 0.1 channel). By using 2-channel stereo for the surround speakers, more accurate moving sound effects and surround sound environment are possible than with Dolby Surround. The wide dynamic range from maximum to minimum volume reproduced by the 5 full-range channels and the precise sound orientation generated using digital sound processing provide listeners with unprecedented excitement and realism. With this unit, any sound environment from monaural up to a 5.1-channel configuration can be freely selected for your enjoyment.

■ Dolby Pro Logic II

Dolby Pro Logic II is an improved technique used to decode vast numbers of existing Dolby Surround sources. This new technology enables a discrete 5-channel playback with 2 front left and right channels, 1 center channel, and 2 surround left and right channels instead of only 1 surround channel for conventional Pro Logic technology. There are three modes available: “Music mode” for music sources, “Movie mode” for movie sources and “Game mode” for game sources.

■ Dolby Surround

Dolby Surround uses a 4-channel analog recording system to reproduce realistic and dynamic sound effects: 2 front left and right channels (stereo), a center channel for dialog (monaural), and a surround channel for special sound effects (monaural). The surround channel reproduces sound within a narrow frequency range. Dolby Surround is widely used with nearly all video tapes and laser discs, and in many TV and cable broadcasts as well. The Dolby Pro Logic decoder built into this unit employs a digital signal processing system that automatically stabilizes the volume on each channel to enhance moving sound effects and directionality.

■ DTS (Digital Theater Systems) Digital Surround

DTS digital surround was developed to replace the analog soundtracks of movies with a 5.1-channel digital sound track, and is now rapidly gaining popularity in movie theaters around the world. Digital Theater Systems Inc. has developed a home theater system so that you can enjoy the depth of sound and natural spatial representation of DTS digital surround in your home. This system produces practically distortion-free 5.1-channel sound (technically, left, right and center channels, 2 surround channels, plus an LFE 0.1 channel as a subwoofer, for a total of 5.1channels).

■ ITU-R

ITU-R is the radio communication sector of the ITU (International Telecommunication Union). ITU-R recommends a standard speaker placement which is used in many critical listening rooms, especially for mastering purposes.

■ LFE 0.1 channel

This channel reproduces low-frequency bass signals. The frequency range of this channel is from 20 Hz to 120 Hz. This channel is counted as 0.1 because it only enforces a low-frequency range compared to the full-range reproduced by the other 5 channels in Dolby Digital or DTS 5.1-channel systems.

■ PCM (Linear PCM)

Linear PCM is a signal format under which an analog audio signal is digitized, recorded and transmitted without using any compression. This is used as a method of recording CDs and DVD audio. The PCM system uses a technique for sampling the size of the analog signal per very small unit of time. Standing for “Pulse Code Modulation”, the analog signal is encoded as pulses and then modulated for recording.

■ Sampling frequency and number of quantized bits

When digitizing an analog audio signal, the number of times the signal is sampled per second is called the sampling frequency, while the degree of fineness when converting the sound level into a numeric value is called the number of quantized bits. The range of rates that can be played back is determined based on the sampling rate, while the dynamic range representing the sound level difference is determined by the number of quantized bits. In principle, the higher the sampling frequency, the wider the range of frequencies that can be played back, and the higher the number of quantized bits, the more finely the sound level can be reproduced.

Sound field program information Video information

GLOSSARY

■ CINEMA DSP

Since the Dolby Surround and DTS systems were originally designed for use in movie theaters, their effect is best felt in a theater having many speakers designed for acoustic effects. Since home conditions, such as room size, wall material, number of speakers, and so on, can differ so widely, it is inevitable that there are differences in the sound heard. Based on a wealth of actually measured data, YAMAHA CINEMA DSP uses YAMAHA original DSP technology to combine Dolby Pro Logic, Dolby Digital and DTS systems to provide the audiovisual experience of movie theater in the listening room of your own home.

■ SILENT CINEMA

YAMAHA has developed a natural, realistic sound effect DSP algorithm for headphones. Parameters for headphones have been set for each sound field program so that accurate representations of all the sound field programs can be enjoyed on headphones.

■ Virtual CINEMA DSP

YAMAHA has developed a Virtual CINEMA DSP algorithm that allows you to enjoy DSP surround effects even without any surround speakers by using virtual surround speakers. It is even possible to enjoy Virtual CINEMA DSP using a minimal two-speaker system that does not include a center speaker.

■ Component video signal

With the component video signal system, the video signal is separated into the Y signal for the luminance and the PB

R signals for the chrominance. Color can be

and P reproduced more faithfully with this system because each of these signals is independent. The component signal is also called the “color difference signal” because the luminance signal is subtracted from the color signal. A monitor with component input jacks is required in order to output component signals.

■ Composite video signal

With the composite video signal system, the video signal is composed of three basic elements of a video picture: color, brightness and synchronization data. A composite video jack on a video component transmits these three elements combined.

INFORMATION

ADDITIONAL

SPECIFICATIONS

AUDIO SECTION

• Minimum RMS Output Power for Front, Center, Surround [U.S.A. and Canada models]

1 kHz, 0.9% THD, 8 Ω/6 Ω ............................................ 110 W

[Other models]

1 kHz, 0.9% THD, 6 Ω ................................................... 100 W

• Maximum Output Power [Europe model]

1 kHz, 0.7% THD, 4 Ω ................................................... 105 W

• Maximum Power [Asia, China, Korea and General models]

1 kHz, 10% THD, 6 Ω ..................................................... 110 W

• Dynamic Power [U.S.A. and Canada models] (Impedance Selector: 8 Ω)

(IHF, 8/6/4/2 Ω) ......................................... 120/140/160/180 W

[Other models]

(IHF, 6/4/2 Ω) .................................................... 105/135/165 W

• Frequency Response

CD, etc. to Front L/R ............................ 10 Hz to 100 kHz, –3 dB

• Total Harmonic Distortion

1 kHz, 50 W, 6 Ω, Front L/R .................................... 0.06% or less

• Signal to Noise Ratio (IHF-A Network)

CD (250 mV) to Front L/R, Effect Off .................100 dB or more

• Residual Noise (IHF-A Network)

Front L/R ................................................................ 150 µV or less

• Channel Separation (1 kHz/10 kHz) CD, etc. (5.1 kΩ terminated) to Front L/R

................................................................... 60 dB/45 dB or more

• Tone Control (Front L/R)

BASS Boost/Cut .................................................... ±10 dB/100 Hz

TREBLE Boost/Cut .............................................. ±10 dB/20 kHz

• Phones Output .......................................................... 400 mV/470 Ω

• Input Sensitivity/Input Impedance

CD, etc. ................................................................. 200 mV/47 kΩ

MULTI CH INPUT ............................................... 200 mV/47 kΩ

• Output Level/Output Impedance

AUDIO OUT (REC) ............................................ 200 mV/1.2 kΩ

SUBWOOFER OUTPUT ........................................... 4 V/1.2 kΩ

FM SECTION

• Tuning Range

[U.S.A. and Canada models] .......................... 87.5 to 107.9 MHz

[Other models] ............................................ 87.50 to 108.00 MHz

• 50 dB Quieting Sensitivity (IHF, 100% mod.)

Mono ................................................................. 2.8 µV (20.2 dBf)

• Signal to Noise Ratio (IHF)

Mono/Stereo ............................................................. 73 dB/70 dB

• Harmonic Distortion (1 kHz)

Mono/Stereo ................................................................ 0.5%/0.5%

AM SECTION

• Tuning Range

[U.S.A. and Canada models] .............................. 530 to 1710 kHz

[Asia and General models] ................. 530/531 to 1710/1611 kHz

[Other models] .................................................... 531 to 1611 kHz

GENERAL

• Power Supply

[U.S.A. and Canada models] ............................. 120 V AC, 60 Hz

[Australia model] ............................................... 240 V AC, 50 Hz

[U.K. and Europe models] ................................. 230 V AC, 50 Hz

[Korea model] .................................................... 220 V AC, 60 Hz

[China model] .................................................... 220 V AC, 50 Hz

[Asia and General models]

............................................. 110-120/220–240 V AC, 50/60 Hz

• Power Consumption

[U.S.A. and Canada models] ................................. 240 W/320 VA

[Other models] .................................................................... 240 W

• Standby Power Consumption

[U.S.A. and Canada models] ............................................... 0.5 W

[Other models] ..................................................................... 0.7 W

• Dimensions (W x H x D) .................................. 435 x 151 x 315 mm

(17-1/8” x 5-15/16” x 12-7/16”)

• Weight .............................................................. 9.0 kg (19 lbs 13 oz)

* Specifications are subject to change without notice.

VIDEO SECTION

• Video Signal Type

[U.S.A., Canada, Korea and General models] .................... NTSC

[Other models] ....................................................................... PAL

• Component Signal Level .............................................. 1 Vp-p/75 Ω

• Signal to Noise Ratio ................................................ 50 dB or more

• Frequency Response (MONITOR OUT)

Video Signal ............................................. 5 Hz to 10 MHz, –3 dB

Component Signal .................................... 5 Hz to 60 MHz, –3 dB

LIST OF REMOTE CONTROL CODES

ADMIRAL 292, 293 AIWA 294, 276, 283,

284 AKAI 295, 296 ALBA 296 AOC 297 BELL&HOWELL 292 BESTAR 298 BLAUPUNKT 229, 222 BLUE SKY 298 BRANDT 223 BROCSONIC 297 BUSH 296 CLATRONIC 298 CRAIG 224 CROSLEX 225 CURTIS MATHIS 297, 226 DAEWOO 297, 298, 224,

227, 228 DAYTRON 239 DUAL 298 DWIN 293 EMERSON 297, 224, 239,

232 FERGUSON 223, 265, 266 FIRST LINE 298 FISHER 295, 233 FRABA 298 FUNAI 277, 278 GE 293, 297, 234,

235, 236 GOODMANS 296, 298, 223 GRUNDIG 229, 238, 249 HITACHI 297, 239, 242,

243, 285 ICE 296 IRRADIO 296 ITT/NOKIA 244, 245 JC PENNY 293, 297, 234,

237 JVC 296, 246, 247,

286 KENDO 298 KTV 297, 239 LG/GOLDSTAR 297, 298,

239, 237 LOEWE 298, 248 LXI 293, 297, 225,

226, 233 MAGNAVOX 297, 225, 239 MARANTZ 298 MATSUI 295 MEMOREX 297 MITSUBISHI 299, 297, 259,

287 NEC 297, 252, 282 NOKIA 244, 245 NOKIA OCEANIC 245 NORDMENDE 265, 266 ONWA 296

PANASONIC 234, 235, 236,

PHILCO 297, 225, 239 PHILIPS 225 PIONEER 226, 235, 254,

PORTLAND 297, 256 PROSCAN 293 PROTON 297 QUASAR 234, 235 RADIO SHACK299, 293, 297 RCA 293, 297, 234,

SABA 223, 269, 265,

SAMPO 297 SAMSUNG 297, 239, 248,

SANYO 295, 233, 279,

SCHNEIDER 296 SCOTT 297 SHARP 292, 239, 232,

SIEMENS 229 SIGNATURE 292 SONY 263, 214 SYLVANIA 297, 225 TELEFUNKEN 269, 264, 265,

THOMSON 223, 266 TOSHIBA 292, 226, 267,

VIDECH 297, 242 WARDS 297, 239, 232 YAMAHA 299, 292, 253,

VCR

ADMIRAL 395 AIWA 396, 397, 398,

AKAI 322, 323, 324 AUDIO DYNAMIC 392, 394 BELL&HOWELL 393 BLAUPUNKT 325, 326 BROCSONIC 327 BUSH 322 CANON 325, 328 CGM 396, 332 CITIZEN 396 CRAIG 396, 363 CURTIS MATHIS 397, 328,

DAEWOO 328, 334, 335 DBX 392, 394 DIMENSIA 333 DYNATECH 397 EMERSON 327, 334, 396,

FISHER 393, 336 FUNAI 397 GE 328, 333, 387

253, 288, 211

255, 268

256, 257, 258

266

262, 275

272, 273, 274, 212

213, 216

266

215

242

329

333

397

GO VIDEO 353 GOODMANS 334, 337 GRUNDIG 332, 338 HITACHI 325, 333, 349,

342, 343 INSTANT REPLAY 325, 328 ITT/NOKIA 393 JC PENNY 392, 393, 394,

328, 333, 349,

396, 363 JVC 392, 394, 344,

345, 346, 347 KENDO 396 KENWOOD 392, 394, 396 LG/GOLDSTAR 396, 388 LOEWE 396, 337 LUXOR 395 LXI 393, 396, 397,

336, 349 MAGNAVOX 325, 326, 328 MARANTZ 392, 394 MARTA 396 MATSUI 396 MEMOREX 328, 336, 396,

397 MINOLTA 333, 349 MITSUBISHI 399, 344, 348,

359, 352, 353 MTC 363, 397 MULTITECH 397, 348, 354 NEC 392, 394, 344,

383 NOKIA 393, 395 NOKIA OCEANIC 395 OKANO 323 OLYMPIC 325, 328 ORION 327 PANASONIC 325, 328, 355,

378, 384, 385,

386 PENTAX 333, 349 PHILCO 325, 328, 397 PHILIPS 325, 326, 328,

337, 356, 357 PHONOLA 337 PILOT 396 PIONEER 325 QUASAR 325, 328 RCA/PROSCAN 325, 326,

328, 333, 335,

349, 358, 369,

363, 397 REALISTIC 393, 397, 328,

336, 359, 362,

396, 363 SAMSUNG 354, 358, 363,

364, 365, 366 SANSUI 394 SANYO 393, 336, 367 SCHNEIDER 337 SCOTT 399, 335, 336,

348, 359, 352,

354, 358 SELECO 322 SHARP 395, 362, 382

SIEMENS 393 SIGNATURE 2000 395, 397 SONY 368, 379, 372,

373, 374, 375

SYLVANIA 397, 325, 326,

328 SYMPHONIC 397 TANDBERG 334 TANDY 397 TAS H IRO 3 9 6 TATUNG 392, 394 TEAC 392, 394, 397 TECHNICS 325, 328 TEKNIKA 396 TELEFUNKEN 376, 377 THOMAS 397 THORN 393, 396 TOSHIBA 335, 369, 389 TOTEVISON 363, 396 UNITECH 363 UNIVERSUM 396, 327, 376 VIDEOSONIC 363 W.WHOUSE 396 WARDS 395, 396, 336,

362 YAMAHA 399, 392, 393,

394 ZENITH 344, 368, 379,

396, 397

DVD player

DENON 623, 624 FUNAI 625 HITACHI 626 JVC 627 KENWOOD 628 LG/GOLD STAR 645 MITSUBISHI 629 ONKYO 632, 633, 634 PANASONIC 623, 635 PHILIPS 699, 647 PIONEER 636, 637, 638 RCA 639 SAMSUNG 642 SHARP 643 SONY 644 THOMSON 646 TOSHIBA 634 YAMAHA 699, 622, 623,

647

MD player

YAMAHA 599

CD player

YAMAHA 199

CD recorder

YAMAHA 499

APPENDIX

YAMAHA ELECTRONICS CORPORATION, USA

YAMAHA CANADA MUSIC LTD. YAMAHA ELECTRONIK EUROPA G.m.b.H. YAMAHA ELECTRONIQUE FRANCE S.A. YAMAHA ELECTRONICS (UK) LTD. YAMAHA SCANDINAVIA A.B. YAMAHA MUSIC AUSTRALIA PTY, LTD.

135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA

J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN

6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.

SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, GERMANY

RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE

YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD18 7GQ, ENGLAND

17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA

Printed in China

WG72080

Yamaha HTR-5930 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

FEATURES

GETTING STARTED

Supplied accessories

Installing batteries in the remote control

CONTROLS AND FUNCTIONS

Front panel

Remote control

Front panel display

Rear panel

CONNECTIONS

Placing speakers

Connecting speakers

Information on jacks and cable plugs

Connecting video components

Connecting audio components

Connecting the FM and AM antennas

Connecting the power cable

Turning on the power

SETUP

Using BASIC MENU

PLAYBACK

Basic operations

Additional operations

SOUND FIELD PROGRAMS

Sound field program descriptions

RECORDING

FM/AM TUNING

Automatic tuning

Manual tuning

Automatic preset tuning

Manual preset tuning

Selecting preset stations

Exchanging preset stations

XM® SATELLITE RADIO TUNING

What is XM Satellite Radio?

XM Satellite Radio controls and functions

Activating XM Satellite Radio

Basic XM Satellite Radio operations

Selecting the XM Satellite Radio search mode

Setting XM Satellite Radio preset channels

Displaying the XM Satellite Radio information

SET MENU

Using SET MENU

SOUND MENU

INPUT MENU

OPTION MENU

REMOTE CONTROL FEATURES

Controlling this unit, a TV, or other components

Setting remote control codes

TROUBLESHOOTING

RESETTING THE SYSTEM

GLOSSARY

Audio information

Sound field program information Video information

SPECIFICATIONS

LIST OF REMOTE CONTROL CODES
