Yamaha HTR-5130RDS, HTR-5130 User Manual
HTR-5130/HTR-5130RDS
HTR-5130
HTR-5130RDS
NATURAL SOUND AV RECEIVER
AMPLI-TUNER AUDIO-VIDEO
BG
YAMAHA ELECTRONICS CORPORATION, USA 6660 ORANGETHORPE AVE., BUENA PARK, CALIF. 90620, U.S.A.
YAMAHA CANADA MUSIC LTD. 135 MILNER AVE., SCARBOROUGH, ONTARIO M1S 3R1, CANADA
YAMAHA ELECTRONIK EUROPA G.m.b.H. SIEMENSSTR. 22-34, 25462 RELLINGEN BEI HAMBURG, F.R. OF GERMANY
YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE
YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND
YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN
YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
V339080Printed in Malaysia
SUPPLIED ACCESSORIES ● After unpacking, check that the following parts are included. ACCESSORIES FOURNIS ● Après le déballage, vérifier que les pièces suivantes sont incluses. MITGELIEFERTE ZUBEHÖRTEILE ● Nach dem Auspacken überprüfen, ob die folgenden Teile vorhanden sind. MEDFÖLJANDE TILLBEHÖR ● Kontrollera efter det apparaten packats upp att följande delar finns med. ACCESSORI IN DOTAZAIONE ● Verificare che tutte le parti seguenti siano contenute nell’imballaggio dell’apparecchio. ACCESORIOS INCLUIDOS ● Desembalar el aparato y verificar que los siguientes accesorios están en la caja. BIJGELEVERDE ACCESSOIRES ● Controleer na het uitpakken of de volgende onderdelen voorhanden zijn.
● Indoor FM Antenna
● Antenne FM intérieure
● UKW-Innenantenne
● FM inomhusantenn
● Antenna FM interna
● Antena FM interior
● FM Binnenantenne
● AM Loop Antenna
● Cadre-antenne AM
● MW-Rahmenantenne
● AM ramantenn
● Antenna AM ad anello
● Antena de cuadro de AM
● AM Lusantenne
● Remote Control Transmitter
● Emetteur de télécommande
● Fernbedienung
● Fjärrkontroll
● Telecomando
● Transmisor de control remoto
● Afstandbediening
TIME/
LEVEL
–+
PROGRAM
VCR
REC/PAUSE
DIR BDIR A
PRESET
–+
POWER /I
SLEEP
DELAY/CENTER
/REAR/SWFR
PROLOGIC
TV/DBS
PLAY
A/B/C/D/E
PLAY
DISC
VOLUME
TEST
ENHANCED
DVD/LD
A/B
TUNER
PHONO
EFFECT
ON/OFF
2CH
/6CH
TAPE
CD
● 75-ohm/300-ohm antenna adapter <U.K. model only>
● Adaptateur d’antenne 75 ohms/300 ohms <Modèle pour le
Royaume-Uni seulement>
● 75 Ohm/300 Ohm Antennenstecker <nur Großbritannien-
Modell>
● 75 ohm/300 ohm antennadapter <Endast modell för
brittisk>
● Adattatore per antenna da 75 e 300 ohm <Solo modello
per la Gran Bretagna>
● Adaptador de antena de 75 ohmios/300 ohmios <Modelo
para Reino Unido sólo>
● 75 ohm/300 ohm antenne-adapter <Alleen modellen voor
Groot-Brittannië>
● Batteries (size AA, R6, UM-3)
● Piles (taille AA, R6, UM-3)
● Batterien (Größe AA, R6, UM-3)
● Batterier (storlek AA, R6, UM-3)
● Batterie (dimensioni AA, R6, UM-3)
● Pilas (tamaño AA, R6, UM-3)
● Batterijen (maat AA, R6, UM-3)
2
Thank you for selecting this YAMAHA AV receiver.
FEATURES
English
● 5 Speaker Configuration
(Power Amp. Section)
Main: 60W + 60W (8Ω) RMS Output
Power, 0.04% THD, 20–20,000 Hz
Center: 60W (8Ω) RMS Output Power,
0.04% THD, 20–20,000 Hz
Rear: 60W + 60W (8Ω) RMS Output
Power, 0.04% THD, 20–20,000 Hz
● Digital Sound Field Processor
● Dolby Pro Logic Surround Decoder
● Theater-like Sound Experience by the
Combination of Dolby Pro Logic and
YAMAHA DSP Technology (CINEMA DSP)
● Automatic Input Balance Control for
Dolby Pro Logic Surround
● Test Tone Generator for Easier Speaker
Balance Adjustment
● 3 Center Channel Modes
(NORMAL/WIDE/PHANTOM)
● Multi-Functions for RDS Broadcast
Reception HTR-5130RDS only
● 40-Station Random Access Preset Tuning
● Automatic Preset Tuning
● Preset Station Shifting Capability (Preset
Editing)
● IF Count Direct PLL Synthesizer Tuning
System
● 6-Channel External Decoder Input for
Dolby Digital, DTS, and Other Future
Formats
● Video Signal Input/Output Capability
● SLEEP Timer
● Remote Control Capability
CONTENTS
SUPPLIED ACCESSORIES............................2
FEA TURES .....................................................3
CAUTION ........................................................ 4
NOTES ABOUT THE REMOTE CONTROL
TRANSMITTER...............................................5
PROFILE OF THIS UNIT ................................6
SPEAKER SETUP ..........................................7
CONNECTIONS.............................................. 8
CONTROLS AND THEIR FUNCTIONS ........14
SPEAKER BALANCE ADJUSTMENT ..........19
Illustrations in this manual show the HTR-5130RDS model. Functions and parts
applicable only to the HTR-5130RDS are clearly specified.
BASIC OPERATIONS ...................................22
TUNING OPERATIONS ................................26
PRESET TUNING .........................................27
RECEIVING RDS STATIONS .......................30
USING DIGITAL SOUND FIELD
PROCESSOR (DSP) .................................... 35
SETTING THE SLEEP TIMER......................39
TROUBLESHOOTING .................................. 40
SPECIFICATIONS ........................................41
3
CAUTION : READ THIS BEFORE OPERATING YOUR UNIT.
1. To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2. Install this unit in a cool, dry, clean place – away from
windows, heat sources, sources of excessive vibration,
dust, moisture and cold. Avoid sources of humming
(transformers, motors). To prevent fire or electrical shock,
do not expose the unit to rain or water.
3. Never open the cabinet. If something drops into the set,
contact your dealer.
4. Do not use force on switches, controls or connection wires.
When moving the unit, first disconnect the power plug and
the wires connected to other equipment. Never pull the
wires themselves.
5. The openings on the unit cover assure proper ventilation of
the unit. If these openings are obstructed, the temperature
inside the unit will rise rapidly. Therefore, avoid placing
objects against these openings, and install the unit in a
well-ventilated area to prevent fire and damage.
<China, U.K. and Europe models only>
Be sure to allow a space of at least 20 cm behind, 20 cm
on the both sides and 30 cm above the top panel of the
unit to prevent fire and damage.
6. Always set the VOLUME control to “– ∞” before starting
the audio source play. Increase the volume gradually to an
appropriate level after playback has been started.
7. Do not attempt to clean the unit with chemical solvents;
this might damage the finish. Use a clean, dry cloth.
8. Be sure to read the “TROUBLESHOOTING” section
regarding common operating errors before concluding that
the unit is faulty.
9. When not planning to use this unit for long periods of time
(i.e., vacation, etc.), disconnect the AC power plug from
the wall outlet.
IMPORTANT
Please record the serial number of this unit in the space
below.
Model:
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
This unit is not disconnected from the AC power source as
long as it is connected to the wall outlet, even if this unit
itself is turned off. This state is called the standby mode.
In this state, this unit is designed to consume a very small
quantity of power.
FREQUENCY STEP switch <China and General models
only>
Because the interstation frequency spacing differs in
different areas, set the FREQUENCY STEP switch (located
on the rear panel) according to the frequency spacing in
your area.
Before setting this switch, disconnect the AC power plug of
this unit from the AC outlet.
For Canadian Customers
To prevent electric shock, match wide blade of plug to wide
slot and fully insert.
This Class B digital apparatus complies with CANADIAN
ICES-003
10.To prevent lightning damage, disconnect the AC power
plug and antenna cable when there is an electrical storm.
11.Grounding or polarization – Precautions should be taken
so that the grounding or polarization of an appliance is not
defeated.
12.Do not connect audio equipment to the AC outlet on the
rear panel if the equipment requires more power than the
outlet is rated to provide.
13.Voltage Selector <China and General models only>
The voltage selector on the rear panel of this unit must
be set for your local main voltage BEFORE plugging
into the AC power supply.
Voltages are 110/120/220/240 V AC, 50/60 Hz.
4
For U.K. customers
Special Instructions for U.K. Model
English
If the socket outlets in the home are not suitable for the plug
supplied with this appliance, it should be cut off and an
appropriate 3 pin plug fitted. For details, refer to the
instructions described on the right.
Note: The plug severed from the mains lead must be
destroyed, as a plug with bared flexible cord is hazardous if
engaged in a live socket outlet.
IMPORTANT
THE WIRES IN MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:
Blue: NEUTRAL
Brown: LIVE
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured BLUE must be connected to the
terminal which is marked with the letter N or coloured
BLACK. The wire which is coloured BROWN must be
connected to the terminal which is marked with the letter L
or coloured RED. Making sure that neither core is
connected to the earth terminal of the three pin plug.
NOTES ABOUT THE REMOTE CONTROL TRANSMITTER
Battery installation
2
1
3
Battery replacement
When you notice a decrease in the operating range of the
remote control transmitter, the batteries are weak. Replace
both batteries with new ones.
Notes
● Use only AA, R6, UM-3 batteries for replacement.
● Be sure the polarities are correct. (See the illustration inside
the battery compartment.)
● Remove the batteries if the remote control transmitter will
not be used for an extended period of time.
● If batteries leak, dispose of them immediately. Avoid
touching the leaked material or letting it come in contact with
clothing, etc. Clean the battery compartment thoroughly
before installing new batteries.
Remote control transmitter operation range
–dB
LR
Remote control
sensor
Within approximately
6 m (19.7 feet)
30°
Notes
● There should be no large obstacles between the remote
control transmitter and the main unit.
● If the remote control sensor is directly illuminated by strong
lighting (especially an inverter type of fluorescent lamp,
etc.), it might cause the remote control transmitter not to
work correctly. In this case, reposition the main unit to avoid
direct lighting.
30°
5
PROFILE OF THIS UNIT
You are the proud owner of a Yamaha stereo receiver – an extremely sophisticated audio component. The Digital Sound Field
Processor (DSP) built into this unit takes advantage of Yamaha’s undisputed leadership in the field of digital audio processing to
bring you a whole new world of listening experiences. Follow the instructions in this manual carefully when setting up your system,
and this unit will sonically transform your room into a wide range of listening environments – movie theater, concert hall, and so on.
In addition, you get incredible realism from sources encoded with Dolby Surround using the built-in Dolby Pro Logic Surround
decoder.
Please read this owner’s manual carefully and store it in a safe place for later reference.
Digital Sound Field Processing
What is it that makes live music so good? Today’s advanced
sound reproduction technology lets you get extremely close to
the sound of a live performance, but chances are you’ll still
notice something missing: the acoustic environment of the live
concert hall. Extensive research into the exact nature of the
sonic reflections that create the ambience of a large hall has
made it possible for Yamaha engineers to bring you this same
sound in your own listening room, so you’ll feel all the sound of
a live concert.
Dolby Pro Logic Surround
This unit employs a Dolby Pro Logic Surround decoder similar
to professional Dolby Stereo decoders used in many movie
theaters. By using the Dolby Pro Logic Surround decoder, you
can experience the dramatic realism and impact of Dolby
Surround movie theater sound in your own home. Dolby Pro
Logic employs a four channel five speaker system. The Pro
Logic Surround system divides the input signal into four levels:
the left and right main channels, the center channel (used for
dialog), and the rear surround sound channel (used for sound
effects, background noise, and other ambient noises). The
center channel allows listeners seated in even less-than-ideal
positions to hear the dialog originating from the action on the
screen while experiencing good stereo imaging.
Dolby Surround is encoded on the sound track of pre-recorded
video tapes, laser discs, and some TV/cable broadcasts. When
you play a source encoded with Dolby Surround on this unit,
the Dolby Pro Logic Surround decoder decodes the signal and
distributes the surround-sound effects.
Furthermore, our technicians, armed with sophisticated
measuring equipment, have even made it possible to capture
the acoustics of a variety of venues such as an actual concert
hall, theater, etc. to allow you to accurately recreate one of
several actual live performance environments, all in your own
home.
This Dolby Pro Logic Surround Decoder employs a digital
signal processing system. This system improves the stability of
sound at each channel and minimizes crosstalk between
channels, so that positioning of sounds around the room is
more accurate compared with conventional analog signal
processing systems.
In addition, this unit features a built-in automatic input balance
control. This always assures you the best performance without
manual adjustment.
Manufactured under license from Dolby Laboratories. “Dolby”,
“AC-3”, “Pro Logic” and the double-D symbol are trademarks of
Dolby Laboratories.
Dolby Pro Logic Surround + DSP
A Dolby Surround sound system shows its full ability in a large
movie theater, because movie sounds are originally designed
to be reproduced in a large movie theater using many
speakers. It is difficult to create a sound environment similar to
that of a movie theater in your listening room, because the
room size, materials of inside walls, the number of speakers,
etc. of your listening room is much different from those of a
movie theater.
Yamaha DSP technology made it possible to present you with
nearly the same sound experience as that of a large movie
theater in your listening room by compensating for lack of
presence and dynamics in your listening room with its original
digital sound fields combined with Dolby Surround sound field.
6
The combination of Dolby Pro Logic Surround and DSP is used
on the sound field program “
CINEMA DSP
The YAMAHA “CINEMA DSP” logo indicates these programs
are created by the combination of Dolby Pro Logic and
YAMAHA DSP technology.
PRO LOGIC ENHANCED”.
SPEAKER SETUP
SPEAKERS TO BE USED
This unit is designed to provide the best sound-field quality with a 5 speaker configuration. The most effective speakers to use with
this unit are main speakers, rear speakers and a center speaker. You may omit the center speaker. (Refer to the “4-Speaker
Configuration” shown below.)
The main speakers are used for the majority of the sound output as well as effect sounds. The rear speakers are used for the effect
and surround sounds, and the center speaker is for the center sounds (dialog, etc.) within programs encoded with Dolby Surround.
The center speaker needs to be equal in power to the main speakers, though the rear speakers should be slightly lower in power.
However, all the speakers should have high enough power handling to accept the maximum output of this unit.
SPEAKER CONFIGURATION
English
5-Speaker Configuration
This configuration is the most effective and recommended one.
In this configuration, the center speaker is necessary as well as
the rear speakers. If the program DOLBY PRO LOGIC or
DOLBY PRO LOGIC ENHANCED is selected, conversations
will be output from the center speaker and the ambience will be
excellent.
● Set the center channel mode to the “NORMAL” or “WIDE”
position. (For details, refer to page 20.)
Main L
Surround sound
Rear L
Center
Dialogue
Main R Main L
Rear R
SPEAKER PLACEMENT
4-Speaker Configuration
The center speaker is not used in this configuration. If the
program DOLBY PRO LOGIC or DOLBY PRO LOGIC
ENHANCED is selected, the center sound is output from the
left and the right main speakers. However, the sound effect of
other programs can be the same as that of the 5-speaker
configuration.
● Be sure to set the center channel mode to the “PHANTOM”
position. (For details, refer to page 20.)
Main R
Dialogue
Surround sound
Rear L
Rear R
The recommended 5-speaker configuration requires a pair of main speakers, a center speaker, and a pair of rear speakers
(sometimes referred to as surround speakers). When arranging your speakers, refer to the illustration and information below.
Main: Position the main speakers at equal distances away
from the listening position and at equal distances on
Main L
Center
Main R
TV set
Rear L
Rear R
Rear: Position rear speakers directly behind the listening
Center: Position the center speaker directly in front of the
either side of the center speaker.
position at a height of approximately 1.8m (6 feet) up
from the floor, facing slightly inward. If the speakers
cannot be placed behind the listening position, they
may also be placed at the side of the listening
position, facing toward the listening position.
listening position between the main speakers. (When
placing on or near a television, use a magnetically
shielded speaker to avoid unwanted interference.)
7
CONNECTIONS
CONNECTIONS WITH OTHER COMPONENTS
Never plug in this unit and other components until all connections are completed.
When making connections between this unit and other components, be sure all connections are made correctly; that is to say L (left)
to L, R (right) to R, “+” to “+” and “–” to “–”. Also, refer to the owner’s manual for each component to be connected to this unit.
* If you have YAMAHA components numbered as 1, 3, 4, etc. on the rear panel, connections can be made easily by connecting
the output (or input) terminals of each component to the same-numbered terminals on this unit.
Turntable
GND
OUTPUT
Monitor TV TV/Satellite tuner Video cassette recorder
VIDEO IN
VIDEO OUT
AUDIO OUT
VIDEO OUT
AUDIO OUT
AUDIO IN
*3
MAIN
LEVEL
-10dB 0dB
HTR-5130RDS
only
75ΩUNBAL.
FM
ANT
GND
AM
ANT
FREQUENCY
50kHz
100kHz
/10kHz
FM / AM
STEP
/ 9kHz
*1
MAIN
L
R
GND
PHONO
OUTPUT
VIDEO IN
6CH DISCRETE INPUT
SURROUND
CENTER
L
R
SUB
WOOFER
MONITOR
OUT
CD
1
AUDIO SIGNAL
TAPE/MD
IN OUT
(REC)(PLAY)
4
3
VIDEO SIGNAL
DVD/LD
TV/DBS
DVD/LD TV/DBS
VCR
IN
VCR
IN
OUT
OUT
LINE OUT
LINE IN
REAR
R
(SURROUND)
<General model>
A
IMPEDANCE SELECTOR
SET BEFORE POWER ON
B
A OR B
MAIN
A B
CENTER
REAR
MAIN
A OR B
A B:16ΩMIN. /SPEAKER
CENTER
REAR
*4
: 4ΩMIN. /SPEAKER
: 8ΩMIN. /SPEAKER
: 6Ω
MIN. /SPEAKER
: 6Ω
MIN. /SPEAKER
: 8ΩMIN. /SPEAKER
: 8Ω
MIN. /SPEAKER
: 8Ω
MIN. /SPEAKER
VIDEO OUT
AUDIO OUT
VOLTAGE SELECTOR
AC OUTLETS
I00W MAX. TOTAL
SWITCHED
*2
T o AC outlet
CD player
Tape deck,
MD recorder, etc.
*1 Ground (GND) terminal (For turntable use)
Connecting the ground wire of the turntable to the GND
terminal will normally minimize hum, but in some cases
better results may be obtained with the ground wire
disconnected.
*2 Voltage Selector <China and General models only>
The voltage selector on the rear panel of this unit must be
set for your local main voltage BEFORE plugging into the
AC power supply.
Voltages are 110/120/220/240 V AC, 50/60 Hz.
*3 MAIN LEVEL Switch HTR-5130RDS only
Normally set to “0 dB”. If desired, you can decrease the
output level of the MAIN SPEAKERS terminals by 10 dB by
setting this switch to “–10 dB”.
8
LD player,
DVD player, etc.
*4 AC OUTLETS (SWITCHED)
<Europe, Canada, U.S.A., China and General models>
.....................................................2 SWITCHED OUTLETS
<U.K. and Australia models>.......... 1 SWITCHED OUTLET
Use these to connect the power cords from your
components to this unit.
The power to the SWITCHED AC OUTLETS is controlled
by this unit’s STANDBY/ON switch or the provided remote
control transmitter’s POWER
supply power to any component whenever this unit is
turned on.
The maximum power (total power consumption of
components) that can be connected to the SWITCHED AC
OUTLETS is 100 watts.
/I key. These outlets will
Connecting an external decoder for Dolby Digital, DTS and other future formats
or a DVD player , etc.
If you have a separate Dolby Digital, DTS or other format decoder, or if you have a DVD player or other component which
incorporates a Dolby Digital, DTS, or other format decoder, its 6 channel discrete outputs can be connected to the 6CH DISCRETE
INPUT terminals of this unit.
(Example)
6CH DISCRETE OUTPUT
CENTER SURROUNDMAIN
Dolby Digital decoder
English
75ΩUNBAL.
FM
ANT
GND
AM
ANT
FREQUENCY
50kHz
/ 9kHz
100kHz
/10kHz
FM / AM
STEP
MAIN
L
R
GND
PHONO
<General model>
SUB
WOOFER
6CH DISCRETE INPUT
SURROUND
CENTER
SUB
WOOFER
MONITOR
OUT
CD
1
AUDIO SIGNAL
TAPE/MD
IN OUT
(REC)(PLAY)
4
3
L
R
VIDEO SIGNAL
DVD/LD
TV/DBS
DVD/LD TV/DBS
DIGITAL
IN
DIGITAL
OUT
VCR
IN
OUT
VCR
OUT
IN
DOLBY DIGITAL
RF (AC-3 RF) IN
RF Demodulator
DOLBY DIGITAL
RF (AC-3 RF) OUT
VIDEO OUT
AUDIO OUT
Notes
● The laserdisc player (or other unit) must be also connected
to the DVD/LD (or TV/DBS) AUDIO SIGNAL input terminals
of this unit to play a source encoded with Dolby Pro Logic
Surround or in normal stereo (or monaural).
● The discrete signals input to this unit cannot be recorded by
a tape deck, MD recorder or VCR. To record a source
played on the laserdisc player (or another unit), it must be
connected to the DVD/LD (or TV/DBS) AUDIO/VIDEO
SIGNAL input terminals of this unit.
Laserdisc player or other unit with
Dolby Digital RF (AC-3 RF) output
● If you made no connection to the SUB WOOFER input
terminal of this unit or you will not use a subwoofer, you
should be able to make a setting on the decoder to
distribute SUB WOOFER channel signals to the right and
left MAIN output terminals.
For details, refer to the owner’s manual supplied with the
decoder.
9
CONNECTING SPEAKERS
Main speakers A
Right Left
Subwoofer system
<General model>
OUTPUT
SUB
WOOFER
SPEAKERS
MAIN
A
IMPEDANCE SELECTOR
SET BEFORE POWER ON
B
REAR
R
CENTER
(SURROUND)
CAUTION
SEE INSTRUCTION MANUAL FOR CORRECT SETTING.
A OR B
MAIN
A B
CENTER
REAR
MAIN
A OR B
A B:16ΩMIN. /SPEAKER
CENTER
REAR
Left
: 4ΩMIN. /SPEAKER
: 8ΩMIN. /SPEAKER
: 6Ω
MIN. /SPEAKER
: 6Ω
MIN. /SPEAKER
: 8ΩMIN. /SPEAKER
: 8Ω
MIN. /SPEAKER
: 8Ω
MIN. /SPEAKER
Main speakers B
Right
Center speaker
Note
Use speakers with the specified impedance shown on the
rear of this unit.
Note on main speaker connections:
One or two speaker systems can be connected to this unit. If
you use only one speaker system, connect it to either the
SPEAKERS A or B terminals.
Note on subwoofer connection:
You may wish to add a subwoofer to reinforce low frequencies
or to output low bass sound from the subwoofer channel when
reproducing discrete signals.
Connect the SUBWOOFER OUTPUT terminal of this unit to
the input terminal of the subwoofer amplifier, and connect the
speaker terminals of the subwoofer amplifier to the subwoofer.
With some subwoofers, including the Yamaha Active Servo
Processing Subwoofer System, the amplifier and subwoofer
are in the same unit.
Right Left
Rear speakers
10
How to Connect:
Connect the SPEAKERS terminals to your speakers with wire of the proper gauge, cut as short as possible. If the connections are
faulty, no sound will be heard from the speakers. Make sure that the polarity of the speaker wires is correct, that is the + and –
markings are observed. If these wires are reversed, the sound will be unnatural and lack bass.
Caution
Do not let the bare speaker wires touch each other or any metal part of this unit. This could damage this unit and/or
speakers.
English
To connect to the MAIN SPEAKERS terminals
Red: positive (+)
Black: negative (–)
1 Unscrew the knob.
2
1
3
To connect to the REAR and CENTER SPEAKERS
terminals
Red: positive (+)
Black: negative (–)
2 Insert the bare wire.
[Remove approx. 5mm
(1/4”) insulation from
the speaker wires.]
3 Tighten the knob and
secure the wire.
1 Press the tab.
1
3
2 Insert the bare wire.
[Remove approx. 5mm
(1/4”) insulation from
the speaker wires.]
3 Release the tab and
2
secure the wire.
<U.S.A., Canada, Australia, China and General models
only>
Banana Plug connections are also possible. Simply insert the
Banana Plug connector into the corresponding terminal.
11
SUBWOOFER OUTPUT terminal
OUTPUT
SUB
WOOFER
This terminal is for connecting to the input terminal of an
amplifier driving a subwoofer.
This terminal outputs low frequencies from the main and center
channels. (The cut-off frequency of signals output from this
terminal is 150 Hz.)
When 6 channel discrete signals are input to this unit and are
selected as the input source, this terminal outputs signals from
the subwoofer channel.
IMPEDANCE SELECTOR switch
Be sure to switch this only when the power to this unit is not
on.
Select the position whose requirements your speaker system
meets.
WARNING
Do not change the IMPEDANCE SELECTOR switch
setting while the power to this unit is on, otherwise this
unit may be damaged.
IF THIS UNIT FAILS TO TURN ON WHEN THE STANDBY/
ON SWITCH IS PRESSED, the IMPEDANCE SELECTOR
switch may not be set to either end closely. If so, set the
switch to either end closely.
<General model>
VOLTAGE SELECTOR
IMPEDANCE SELECTOR
SET BEFORE POWER ON
A OR B
: 4ΩMIN. /SPEAKER
MAIN
A B
: 8ΩMIN. /SPEAKER
CENTER
: 6Ω
MIN. /SPEAKER
: 6Ω
MIN. /SPEAKER
REAR
MAIN
A OR B
: 8ΩMIN. /SPEAKER
A B:16ΩMIN. /SPEAKER
: 8Ω
MIN. /SPEAKER
CENTER
REAR
: 8Ω
MIN. /SPEAKER
AC OUTLETS
(Left position)
Main: If you use one pair of main speakers, the impedance
of each speaker must be 4Ω or higher.
If you use two pairs of main speakers, the impedance
of each speaker must be 8Ω or higher.
Center: The impedance of the speaker must be 6Ω or higher.
Rear: The impedance of each speaker must be 6Ω or
higher.
(Right position)
Main: <Except for Canada model>
If you use one pair of main speakers, the impedance
of each speaker must be 8Ω or higher.
If you use two pairs of main speakers, the impedance
of each speaker must be 16Ω or higher.
<Canada model only>
The impedance of each speaker must be 8Ω or
higher.
Center: The impedance of the speaker must be 8Ω or higher.
Rear: The impedance of each speaker must be 8Ω or
higher.
IMPEDANCE SELECTOR
12
I00W MAX. TOTAL
SWITCHED
ANTENNA CONNECTIONS
● Each antenna should be connected to the designated terminals correctly, referring to the following diagram.
● Both AM and FM indoor antennas are included with this unit. In general, these antennas will probably provide sufficient signal
strength. Nevertheless, a properly installed outdoor antenna will give clearer reception than an indoor one. If you experience poor
reception quality, an outdoor antenna may result in improvement.
English
Outdoor FM antenna
75-ohm/300-ohm
antenna adapter
75-ohm coaxial cable
75-ohm/300-ohm
antenna adapter
300-ohm feeder
Indoor FM
antenna
(included)
FM
ANT
GND
AM
ANT
75Ω
UNBAL.
Outdoor AM antenna
AM loop
antenna
(included)
Ground
Connecting the AM loop antenna
12 3
Orient so that the best
reception is obtained.
* The AM loop antenna should be placed apart from the main unit. The antenna may be hung on a wall.
* The AM loop antenna should be kept connected, even if an outdoor AM antenna is connected to this unit.
GND terminal
For maximum safety and minimum interference, connect the
GND terminal to a good earth ground. A good earth ground is a
metal stake driven into moist earth.
Notes
● When connecting the indoor FM
antenna, insert its connector into
the FM ANT terminal firmly.
● If you need an outdoor
FM antenna to improve
FM reception quality, either
300-ohm feeder or coaxial cable
may be used. In locations
troubled by electrical interference, coaxial cable is
preferable.
13
Loading...
