Yamaha CDR1000
Yamaha CDR1000
Professional Audio CD Recorder
Professional Audio CD Recorder
At last, recording direct to
CDR1000
Professional
Audio CD
Recorder
compact disc is as easy as
tape-based formats.
It’s simple. It’s fast. And it’s fully professional. It’s the Yamaha CDR1000 Professional Audio CD
Recorder, a fully professional CD recorder that’s fully compatible with CD-R and CD-RW. Finally, the
convenience of tape-based recording formats has come to the CD. And Yamaha is leading the way with this
unique 2-unit rack-mount device destined for the great recording studios and composing suites of the world.
Uncompromising in every way, the CDR1000 features everything professionals demand in today’s fast-paced,
ultra high-tech recording environments. Key features like…
■ Apogee UV22 Super CD 16-bit Encoding
■ Sampling rate converter (30 – 50kHz to 44.1kHz)
■ Word clock input for AES/EBU pass-through
■ Versatile digital and analog I/O configurations, including digital signal cascade output
■ High-precision automatic recording start function
■ Manual and automatic track number increment functions
■ Easy index recording function
■ Audio Delay, Fade In/Fade Out, and Auto Finalize
■ Wireless remote controller, footswitch connector for recording start, parallel I/O port, and much more
Front Panel
Rear Panel
Apogee UV22:
The Professional Standard
The CDR1000 incorporates Apogee UV22 Super CD Encoding,
a superior processing technology adopted by major recording
studios all over the world. UV22 permits high-quality 16-bit
encoding of sources originally recorded at higher bit
resolutions without the need for peripheral gear.
Simple Sampling Rate Conversion
Another handy feature built right into the CDR1000 is a
sampling rate converter capable of handling a wide range of
digital sources, everything from 30kHz to 50kHz. (With
44.1kHz sources the converter is bypassed.)
Versatile Recording, Indexing
And Other Features
It’s easy to get a good recording every time with the CDR1000.
A high-precision recording start feature ensures professional
takes without missing a beat. Also, an audio delay feature lets
you “back-track” up to 5 seconds by buffering the input.
Track incrementing is set up for ease of use, as well. You can
select either manual or automatic indexing. The threshold level
for auto track increment can be set to –96 or to any value
between –70 and –30dB, when the input signal goes below the
threshold for more than three seconds. What’s more, a handy
index recording function lets you place multiple sound effect
libraries within a single track.
And the CDR1000 is not only the ideal CD recorder, it’s also a
high-quality CD playback source, with the convenience of
being able to configure a fully digital system without having to
change the master/slave clock settings. What’s more, a word
clock input is provided for AES/EBU pass-through.
Flexible I/O Options
The CDR1000’s input and output options include everything
discerning professionals demand in order to handle all types
of CD recording and playback situations.
The selection of inputs includes coaxial, AES/EBU, and analog
balanced XLR connectors with a +4dB/-10dBV switch.
Available outputs include coaxial, AES/EBU and analog XLR
(+4dB) connectors.
Other key features of the CDR1000 include easy to read 16segment level meters with peak hold function, quad-speed
finalize capability for improved editing efficiency, and
selectable copy protect functions including PERMIT (unlimited
copy), ONCE (SCMS compatible) and PROTECT (no copy).
Convenient Start/Stop
Options, And More
The CDR1000 comes with a full-function wireless remote
controller that provides for convenience in accessing all main
operating features in a variety of CD recording and playback
situations. A foot switch connector is also provided for recording
start and stop control by foot using an optional foot switch.
A digital signal cascade output function with synchronized
recording lets you easily create duplicates using multiple
machines.
Also, a parallel I/O port allows for external control by input
and output pulse.
I/O Functions
Input Play, Pause, Stop, Rec Standby, Track Inc
Output Play, Pause, Stop
Suggested Application
BNC BNC
WORD CLOCK
OUT
STEREO OUT
DIGITAL (AES/EBU)
2TR IN
DIGITAL1 (AES/EBU)
2TR IN
DIGITAL2 (COAXIAL)
DIGITAL IN
(AES/EBU)
DIGITAL OUT
(AES/EBU)
CDR1000
WORD CLOCK
IN
DIGITAL OUT
(COAXIAL)
Multitrack
Recorder
D24
Multitrack
Recorder
D24
WORD CLOCK
OUT
Sync
AES/EBU
8ch
AES/EBU
8ch
WORD CLOCK
IN
Digital Mixing Console
02R
This heavyweight multitrack recording and mastering system is about the simplest professional studio setup around. Two Yamaha D24 Multitrack
Recorders provide 16 channels of multitrack recording and playback using handy MO disks, run through the global standard Yamaha 02R Digital
Mixing Console, complete with multiple effects and automated mixing capabilities built right in. Once the mix is perfect, simply master it to CD
using the CDR1000. The signal remains all digital from start to finish!
Specifications
System
Compact Disc Recordable
Playback format
CD
Recording formats
CD-R, CD-RW (Audio and Data discs)
Quantization
16-bit linear
Sampling Frequency
44.1kHz
Frequency Response
20 Hz – 20kHz (+1/-3dB)
Fs Converter
30kHz – 50kHz (automatically converted to 44.1kHz)
Frequency Response
20 Hz – 20kHz
Wow and Flutter
Unmeasurable
Recording/Playback (Analog)
S/N 97dB
Dynamic Range 97dB
THD 0.01%
Dimensions (WxHxD)
480 x 101 x 389mm (18 3/5" x 4" x 15 1/3")
I/O Configuration
Analog Input
Connector XLR 3-31 Type
Input Impedance 20kΩ (balanced)
Nominal Input Level +4dB/-10dBV (selectable)
Maximum Input Level +18dB/+4dBV (Rec Level at Nominal)
Analog Output
Connector XLR 3-32 Type
Output Impedance 150Ω (balanced)
Nominal Output Level +4dB
Maximum Output Level +18dB
Head Phone Output
Connector 1/4-inch Stereo Jack
Load Impedance 40Ω + 40Ω
Maximum Output Level 100mW + 100mW
AES/EBU Input
Connector XLR 3-31 Type
Input Impedance 110Ω
AES/EBU Output
Connector XLR 3-32 Type
Output Impedance 110Ω
Coaxial Input (IEC60958)
Connector Phono
Input Impedance 75Ω
Coaxial Output (IEC60958)
Connector Phono
Output Impedance 75Ω
Weight
8kg (17lbs., 9oz)
Power Consumption
33W
Accessories
Power Cord, Remote Controller (Wireless type)
Option
Foot Switch FC-5
YAMAHA Web Site
http://www.yamaha.co.jp/english/
http://www.yamaha.co.jp/product/proaudio/homeenglish/
Control I/O
Connector D-Sub 9pin
Foot Switch Input
1/4-inch Monaural Jack
UV22 is a trademark and Apogee is a registered trademark of Apogee Electronics corporation.
Specifications subject to change without notice.
