144 MHZ FM TRANSCEIVER
Downloaded by
Amateur Radio Directory
FT-411
MKII
OPERATING MANUAL
YAESU MUSEN CO., LTD.
1-20-2 Shimomaruko, Ota-Ku, Tokyo 146-8649, Japan
YAESU U.S.A.
17210 Edwards Rd., Cerritos, CA 90703, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525 1118 ZN, Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
YAESU GERMANY GmbH
Am Kronberger Hang 2, D-65824 Schwalbach, Germany
YAESU HK LTD.
11th Floor Tsim Sha Tsui Centre, 66 Mody Rd.,
Tsim Sha Tsui East, Kowloon, Hong Kong
Contents
Specifications............................................................................................................ 2
Accessories & Options.............................................................................................. 3
Controls & Connectors ............................................................................................ 4
Top Panel ............................................................................................................. 4
Side Panel............................................................................................................. 5
Front Panel ........................................................................................................... 6
Accessories & Options.............................................................................................. 7
Battery Packs and Cases........................................................................................ 7
Battery Removal and Replacement ........................................................................ 8
Battery Chargers ................................................................................................... 8
Speaker/Microphones............................................................................................ 9
Antenna Considerations ...................................................................................... 10
FTS-17A Tone Squelch Unit Installation ............................................................. 10
Operation ............................................................................................................... 11
Preliminary Operating Information ...................................................................... 11
Squelch Setup ..................................................................................................... 11
Important Keypad Information ............................................................................ 12
VFO Frequency & Step Selection ........................................................................ 13
Transmitting ....................................................................................................... 14
Repeater Splits.................................................................................................... 14
Changing the Standard Repeater Shift ............................................................ 15
Memory Storage ................................................................................................. 16
Memory Recall & Copy ...................................................................................... 16
Hiding and Erasing Memories ............................................................................. 17
Call Channel Memory ......................................................................................... 17
Scanning............................................................................................................. 18
Memory Skip Scanning ....................................................................................... 18
Programmable Memory Scanning (PMS)............................................................. 18
Priority Channel Monitoring................................................................................ 19
Multi-Channel Priority Monitoring................................................................. 19
Tone Squelch/Pager Operation ............................................................................ 20
Power Saver........................................................................................................ 21
APO (Automatic Power-Off) ............................................................................... 22
VOX (Voice-Actuated Transmit Switching)......................................................... 22
DTMF Memories ................................................................................................ 22
System Reset ...................................................................................................... 23
In Case of Problems ............................................................................................... 24
Data Cloning .......................................................................................................... 25
Getting the Most from Your Batteries ................................................................... 26
Yaesu FT-411 MK
Ⅱ
Compact 2m Cpu-Controlled
FM Transceiver
The FT-41 1 MKⅡ is an ultra compact FM hand-held providing up to five watts of RF power
and a wealth of new features for the 2m amateur band. Slightly smaller and lighter than the
FT-23R/73R, the FT-411 MKⅡ accepts the same battery packs, and has rubber gasket seals
around all external controls and connectors keep out dust and rain or spray, assuring years
of reliable operation even in harsh environments.
Sixteen multi-function keys provide the ultimate in programmability of 49 freely tunable
memories and two vfos. All memories store repeater shifts or separate tx/rx frequencies,
CTCSS (Continuous Tone Controlled Squelch System) tone frequencies and tone encode/
decode selections with one instant-recall call channel memory and two special purpose
memories for limited subband tuning/scanning. Busy channel band or selective memory
scanning is provided along with priority channel monitoring; 1 MHz up/down stepping;
ARS (automatic repeater shift) when tuned to repeater subbands, plus a top panel rotary
dial for memory and frequency selection. The keypad serves as a DTMF encoder during
transmission, and up to 10 DTMF memories can store 15 digits each for quick playback of
commonly used numbers.
The liquid crystal display shows six frequency digits, memory selection, CTCSS tone frequency while setting*, page-received status when paged by a CTCSS tone*, and includes a
bargraph S/PO meter. Yaesu’s power saver system can be set by the operator for optimum
sampling/standby ratio, or can be turned off for packet operation. And our new APO (Automatic Power Off) system shuts off the transceiver to avoid dead batteries if you doze off
or are called away unexpectedly.
Operation under difficult conditions is simplified by a lamp button illuminating the display
and backlit translucent keypad, diatonically assigned function-dependent keypad beeps.
Please read this manual carefully to gain a clear understanding of the features of the FT-
411 MKⅡ.
: CTCSS and paging features require optional FTS-17A Tone Unit.
*
FT-411 MKII OPERATING MANUAL 1
Specifications
Downloaded by
Amateur Radio Directory
GENERAL
Frequency coverage (MHz): 144 to 147.9995 (version A)
144 to 145.9875 (version B)
Channel steps: 5, 10, 12.5, 20 & 25 kHz
Standard repeater shift: 600 kHz
Emission type: G3E
Supply voltage: 5.5 to 15.0 VDC
Current consumption: Stby (1sec Save) 7mA; Rcv: 150mA;
Transmit (6W): 1300 mA;
Auto Power Off: 6 mA
Antenna (BNC jack): YHA-16 rubber flex antenna
Case size (WHD, in mm): w/FNB/FBA-17: 55×122×32
w/FNB-11H: 55×188×32
w/FNB-12/-14: 55×155×32
Weight (approx.): 550g w/FNB-11H
RECEIVER
Circuit type: Double-conversion superheterodyne
Sensitivity (for 12dB SINAD): better than 0.158 µV (–10 dBµ)
Adjacent channel selectivity: better than 60 dB
Intermodulation: better than 65 dB
Audio output: 0.5 W @8 ohms for 5% THD (12V)
TRANSMITTER
Power output: (see RF Power Chart)
Frequency stability: better than 10 ppm
Modulation system: variable reactance
Maximum deviation: ±5 kHz
FM Noise: better than –40 dB @ 1 kHz
Spurious emissions: better than 60 dB below carrier
Audio distortion (@ 1 kHz): less than 5 %, w/3 kHz deviation
Microphone type: 2-kilohm condenser
Burst tone: 1750 Hz (except version A)
RF Power Chart
Dry Cell Case
Ni-Cd Packs
Specifications may be subject to change without notice or obligation.
Battery Type
FBA-17 (6×AA cells)
FNB-17 (7.2V, 600 mAh)
FNB-11H (12V, 700 mAh)
FNB-12 (12V, 500 mAh)
FNB-14 (7.2V, 1000 mAh)
RF Output (watts)
FT-411 MKII OPERATING MANUAL2
2.5
2.5
5.0
5.0
2.5
Accessories & Options
FNB-11H 12 V, 700 mAh Ni-Cd Battery Pack
FNB-12 12 V, 500 mAh Ni-Cd Battery Pack
FNB-14 7.2V, 1000 mAh Ni-Cd Battery Pack
FNB-17 7.2V, 600 mAh Compact Ni-Cd Battery Pack
FBA-17 Compact Dry Cell Battery Case for 6 AA-size cells
NC-34B 117 VAC Compact Wall Charger for FNB-14
NC-34C 220-234 VAC Compact Wall Charger for FNB-14
NC-65B 117 VAC Compact Wall Charger for FNB
NC-65C 220-234 VAC Compact Wall Charger for FNB
NC-65F 220 VAC w/Argentine Plug Compact Wall Charger for FNB
NC-65U 220-234 VAC w/UK Plug Compact Wall Charger for FNB
NC-29 Desktop Quick Charger for all above FNB packs
NC-50 Dual-Slot Rapid Charger
CA-7 Charger Sleeve (required w/ NC-50)
PA-6 Mobile DC Adapter/Charger for 7.2 V packs (FNB-14/-17)
MH-32
MH-34
MH-37
YHA-16 Rubber flex antenna
FTS-17A CTCSS Subaudible Tone Squelch Unit
MMB-32A Mobile Hanger Bracket
A2B
C2B
B2B
External Hand Speaker/Microphone
External Hand Speaker/Microphone
Earpiece/Microphone
Availability of accessories may vary: some accessories are supplied as standard per local
regulations and requirements, others may be unavailable in some regions. Check with
your Yaesu dealer for additions to the above list.
FT-411 MKII OPERATING MANUAL 3
Controls & Connectors
TOP PANEL
EAR Jack
•
This 2-conductor mini phone jack provides audio
output for an external earphone or optional
Speaker/Mic (listed on previous page). When a
plug is installed in this jack the front panel loudspeaker is disabled.
MIC Jack
‚
This 2-conductor micro-mini phone jack accepts
microphone input from an external Speaker/Mic
or other external source. When a plug is installed in this jack the front panel microphone is disabled.
CALL/DTMF Button
ƒ
This button toggles between CALL channel and VFO or memory. Also, if the [F/M]
key is pressed just before this button, the DTMF memory mode is toggled on and off
(as indicated by a telephone icon).
DIAL Rotary Selector
„
This 20-position detented rotary switch tunes the operating (or CTCSS tone) frequency
or selects the memory channels, according to which function is selected by the keys on
the front panel. This knob duplicates some of the functions of the up and down arrow
keys for operating convenience.
‡ † …
• ‚ ƒ „
VOL/OFF Control
…
This control adjusts the volume of the receiver. Turn this control to the fully counterclockwise position (into the click stop) to turn the transceiver OFF.
SQL Control
†
This control sets the threshold level at which received signals (or noise) open the noise
squelch. For prolonged battery life and squelch sensitivity when the FTS-17A Tone
Squelch Unit is not in stalled, set this control from counterclockwise just to the point
where noise is silenced (and the BUSY/TX indicator on the front panel is off) when
the channel is clear.
ANTENNA Jack
‡
This BNC jack accepts the supplied YHA-16 rubber flex antenna, or any other antenna designed to provide 50-ohm impedance on the 2m band.
FT-411 MKII OPERATING MANUAL4
Controls & Connectors
SIDE PANELS
LAMP Button
•
Press this button to illuminate the display and keypad when
necessary.
Monitor (Burst) Button
‚
In the USA version, this button opens the squelch momentarily without disturbing the setting of the SQL control. In
the European version, this button activates the 1750 Hz Burst
tone generator.
PTT Button
ƒ
Press and hold this (Push-to-Talk) button to transmit. The
BUSY/TX indicator glows red while transmitting.
Unlock Lever
„
Slide this mechanical lever upward to release the battery for
removal.
•
‚
ƒ
„
FT-411 MKII OPERATING MANUAL 5
Controls & Connectors
FRONT PANELS
BUSY/TX Indicator Lamp
•
This LED indicator glows green when the
noise squelch is open during reception, and
red when transmitting.
Keypad
‚
These sixteen keys select the various operating features of the transceiver during reception, and generate DTMF (Dual Tone Multi
Frequency) tone pairs during transmission.
One or two beeps will sound whenever one
of the keys is pressed (if the beeper is active). The labels on the faces of the keys indicate their primary functions, while the labels
above fifteen of the keys indicate alternate
functions, which are activated by pressing the
[F/M] key first, and then another key within
three seconds. When referring to alternate key
functions in this manual, we show the alternate key label followed by the primary label
in parentheses (). Primary key functions are
referred to by the labels on the keyfaces.
Remember to press the [F/M] key first (momentarily, unless otherwise indicated) when
you want to use an alternate key function. All key functions are described in the “Operation” section, and summarized on the •FT-41 1 MKⅡ Operator’s Quick Reference Card .”
•
ƒ
‚
LCD (Liquid Crystal Display)
ƒ
The display shows the selected operating conditions as indicated in the following diagram:
Tone Encoder/Squelch Enabled
Memory Number
Memory Tune Active
Memory Skip
VFO Selection
PTT Switch Locked
Keypad Locked
Alt Key Active
S/PO Meter
Low Power
Repeater Shift
DTMF Memory Mode
Auto Power Off Active
Power Saver Active
VOX Enabled
Operating (or Tone)
Frequency
Low Battery Voltage
FT-411 MKII OPERATING MANUAL6
Accessories & Options
BATTERY PACKS AND CASES
The following rechargeable Ni-Cd battery packs are recommended for use with the FT411 MKⅡ:
FNB-11H 12V 700 mAh
FNB-12 12V 500 mAh
FNB-14 7.2V 1000 mAh
FNB-17 7.2V 600 mAh
The following battery cases are also available for operating the FT-411 MKⅡ with nonrechargeable dry cell batteries (not supplied):
FBA-17 Battery Cases for 6 ‘AA’ (UM-3) batteries
In some countries, one or more of the above may be supplied with the transceiver. If not,
contact the nearest Yaesu dealer to purchase the desired battery pack or case. We do not
recommend the use of any other type of battery with the FT-411 MKⅡ, and using another
type may affect your warranty.
The Ni-Cd packs listed above may be recharged either while attached to the transceiver or
separately, using the battery chargers described on the following pages. Each Ni-Cd pack
should be fully charged before it is used with the transceiver for the first time. Note that
most of these packs require different wall chargers: NC-34B/C for FNB-14, NC-65B/C/
F/U for FNB-11H, FNB-12 or FNB-17. Make certain that you use the correct charger for
each pack. The NC-29 Desktop Quick charger may be used with all of these Ni-Cd packs.
RF power output from the transmitter will differ in some cases according to which type of
battery is used, as shown in the RF Power Chart in the Specification.
FT-411 MKII OPERATING MANUAL 7
Accessories & Options
BATTERY REMOVAL AND REPLACEMENT
Make sure that the VOL control is set into the OFF click-stop, and remove the protec-
•
tive soft or hard case, if used.
Grasp the upper portion of the transceiver with
‚
your left hand, so that your palm is over the
speaker and your left thumb is on the UNLOCK
button.
Move the UNLOCK button in the direction in-
ƒ
dicated by the small arrowhead, while using your
right hand to slide the battery case toward the side with the UNLOCK button. The
battery case should slide smoothly out of its track.
To open the FBA-17 battery cases, place both of your thumbs on the mounting tracks on
„
top of the case and gently pry the tracks apart. Install six batteries, paying attention to the
polarity indicated inside the case. Always replace all six cells.
Do not attempt to open any of the rechargeable Ni-Cd packs.
To replace the battery case or Ni-Cd pack, repeat steps ‚ and ƒ above, simply
…
sliding the battery case in the other direction after aligning the shorter side of the
battery case with the track below the UNLOCK button.
BATTERY CHARGERS
It is not necessary to remove the battery pack from the transceiver when charging, but
transceiver operation may be impaired (by noise) while charging the battery. Therefore we
recommend having an extra battery pack on hand so that the transceiver can be used while
the spare pack is being charged.
Do not attempt to recharge dry cell batteries used in the FBA-17.
NC-34B/C
The NC-34B (117 VAC) and NC-34C (220-234 VAC) are compact chargers for recharging the FNB-14 Ni-Cd battery pack from the AC line. A completely discharged pack requires approximately 15 hours to recharge with the NC-34B/C. Do not attempt to charge
the FNB-11H, FNB-12 or FNB-17 with the NC-34B/C, as the charging voltage and
current are not correct for those packs.
NC-65B/C/F/U
The NC-65B (117 VAC), NC-65C (220-234 VAC), NC-65F (220 VAC w/Argentine plug),
and NC-65U (220-234 VAC w/UK plug), are compact chargers for recharging the FNB-
11H, FNB-12 or FNB-17 Ni-Cd battery packs from the AC line. A completely discharged
pack requires approximately 15 hours to recharge with the NC-65B/C/F/U. Do not attempt to charge the FNB-14 with the NC-65B/C/F/U, as the charging voltage and current
are not correct for this pack.
FT-411 MKII OPERATING MANUAL8
Accessories & Options
NC-29 5-hour Quick Charger
The NC-29 is a universal battery charger with quick and trickle charging modes for the
FNB-11H, FNB-12, FNB-14 and FNB-17 Ni-Cd packs. The quick mode is automati-
cally selected initially, to bring the battery pack up to full charge as fast as safely possible
using an internal timer. Three LED indicators show elapsed charging time after 1, 3 and 5
hours. The charger then automatically reverts to the trickle mode (green LED indicator), to
prevent self-discharge. The quick mode recharges a completely discharged battery in about
5 hours, depending on temperature.
CAUTION
When using the NC-29, do not remove and then replace a battery from the charger
while it is charging, as this will reset the timer and may then overcharge the battery.
PA-6 Mobile DC-DC Adapter/Charger for FNB-14 and -17
The PA-6 is a DC-DC adapter for use when operating the transceiver mobile, and for
charging the FNB-14 and FNB-17 Ni-Cd battery packs. The PA-6 recharges a completely
discharged FNB-17 in about 15 hours, or trickle charges an FNB-14 (to full charge in
about 35 hours). Care must be used to avoid overcharging the batteries, as the PA-6 does
not include a timer. The PA-6 cannot be used for charging the FNB-11H or FNB-12, as
the charging voltage is too low.
Use with 12-volt negative ground electrical systems only.
SPEAKER/MICROPHONES
The MH-32
increase operating convenience and extend communications range and signal strength.
Each is equipped with a dual plug connector which mates with the EAR and MIC jacks on
the top panel of the transceiver, disabling the internal speaker and microphone. The cable
allows the transceiver to be left clipped to your belt, or to be held overhead above obstructions for improved performance, if required. For mobile operation with the MMB-32A
Mobile Hanger, the transceiver can be left in the Hanger during operation.
A Speaker/Mic can be held close to your ear during reception; or anexternal earphone can
be connected via the Speaker/Mic plug, attenuating audio from the speaker in the Speaker/
Mic. To transmit just hold the Speaker/Mic close to your mouth and close the PTT switch
on the microphone (or on the cord of the MH-37
FT-411 MKII OPERATING MANUAL 9
and MH-34
A2B
Speaker/Mics and MH-37
C2B
B2B
Earpiece/Mic can be used to
B2B
).
Accessories & Options
ANTENNA CONSIDERATIONS
While the supplied YHA-16 rubber flex antenna is convenient for short-range operation,
the standard BNC connector allows use of a higher gain antenna for extended range base or
mobile operation. However, any antenna used with the FT-411 MKⅡ must have an impedance close to 50-ohms on the 2m band. Also, if the antenna is connected with a feedline,
use only good quality 50-ohm coaxial cable. To obtain a proper fit with some BNC plugs,
you may need to remove the rubber gasket around the antenna jack on the transceiver.
FTS-17A TONE SQUELCH UNIT INSTALLATION
The FTS-17A is a subaudible CTCSS (Continuous Tone-Controlled Squelch System) which
offers programmable selection of 38 tones for transmission and filter/detectors for reception. Transmit-only (encode) and transmit/receive (encode/decode) modes are selectable
from keys on the transceiver.
Make sure the transceiver is off. Remove the hard or soft case, if used, and remove the
battery pack.
Remove the four screws affixing the battery spring plate on the bottom of the trans-
•
ceiver and carefully remove the plate.
Connect the plug in the transceiver to the FTS-17A.
‚
Replace the battery spring plate and its four screws, and the battery pack.
ƒ
Tone Squelch operation with the FTS-17A is described on page 20.
This chapter describes the various transceiver functions in detail. After studying these
descriptions, keep the •FT-411 MKⅡ Operator’s Quick Reference Card ” handy in case
you need to refresh your memory.
This chapter describes the various transceiver functions in detail. After studying these
FT-411 MKII OPERATING MANUAL10
Operation
descriptions, keep the •FT-411 MKⅡ Operator’s Quick Reference Card” handy in case
you need to refresh your memory.
PRELIMINARY OPERATING INFORMATION
Before operating the transceiver for the first time, charge the battery pack completely (if
using Ni-Cd batteries) as described on pages 8 and 9. If using the FBA-17 battery case,
install the batteries as described on page 8.
Connect the YHA-16 rubber flex antenna to the antenna jack on the top of the transceiver.
Never operate the transceiver without an antenna connected.
For now, do not connect a Speaker/Mic or Headset (until you are familiar with basic operation).
Before proceeding, please read the Controls and Connectors chapter if you have not al-
ready, to familiarize yourself with the controls. Note especially item ‚ on page 6, which
describes the terminology used in this chapter when referring to the keys.
Except for certain special cases mentioned later, the keypad functions as a DTMF (Dual
Tone Multi Frequency) tone generator during transmission.
If you have trouble getting the transceiver to work as described, see “In Case of Prob-
lems” on page 24.
SQUELCH SETUP
Set the SQL control fully counterclockwise, rotate the VOL control out of the click-stop
and adjust for a comfortable volume on the noise or received signal. The BUSY/TX indicator LED should glow green. If a signal is present, rotate the DIAL selector on the top
panel to a channel where only noise is heard.
Adjust the SQL control just to the point where the noise is silenced and the LED is extinguished. If the SQL control is set further clockwise, sensitivity to weak signals will be
reduced. Now, whenever a signal reaches the receiver that is strong enough to open the
squelch, the indicator will glow green.
Note that while receiving, one or more bargraph segments may appear along the bottom of
the display, indicating signal strength on the receiving frequency. This indication is not
affected by the squelch setting, so even squelched signals may have some indication. If you
notice more than one or two bargraph segments appearing while the squelch is still closed,
try reducing the squelch control setting (if you want to hear weak signals).
The Monitor switch on the USA versions (just above the PTT switch) allows you to check
for channel activity beneath the squelch level and to adjust the volume without having to
adjust the squelch: just press the Monitor switch and the squelch will open.
Above the Monitor switch (the Burst switch on European versions) is the Lamp switch.
Press it to light the display and keypad.
FT-411 MKII OPERATING MANUAL 11
Operation
IMPORTANT KEYPAD INFORMATION
If the keypad beeper is enabled, each key on the keypad produces its own beep (or combination) when the key action is accepted. If you don’t hear a beep when a key is pressed,
either the volume is set too low, or the keystroke was not accepted. During transmission,
key tones are the DTMF tone pairs (which are also transmitted).
Pressing the [F/M] key (at the lower right corner of the keypad) momentarily activates the
alternate keypad functions, labelled on the panel just above each key. If no key is pressed
within three seconds of pressing the [F/M] key, the keys return to their standard functions,
labelled on each keyface. Throughout this manual, when we say “press the [F/M] key” we
mean press it just momentarily (less than ½ second), unless specified otherwise.
The keypad can be locked to prevent inadvertent changes in frequency and functions, by
pressing the [F/M] followed by the [LOCK(6)] key. When the keypad is locked a small “L”
in reversed letters is displayed in the lower left corner, and the keypad tones (while receiving) are then as follows:
Feel free to use the keypad as a piano when the keypad is locked (who said we would
couldn’t fit a piano in a hand-held?). The only key combination that will affect transceiver
operation is [F/M] followed by [LOCK(6)] within three seconds, which unlocks the keypad.
When unlocked, the tones produced by the
the direction of the arrow, and some keys sound twice in certain conditions.
You can expect operation to become easier as you become accustomed to the tone(s) associated with each key and function. If you want to disable the keypad beeper, press [F/M],
[TSET(2)], [F/M] and [TSET(2)] again. Repeat these four keystrokes to turn it back on
(we recommend you keep it on at least while learning the key functions).
The keypad locking feature can be modified, if desired, to allow transmission when the
keypad is locked. To do this, make sure the lock is off, turn off the transceiver, then press
and hold the [LOCK (6)] key while turning it back on. Now pressing [F/M] and then
[LOCK(6)] will toggle between keypad lock, keypad+PTT lock, and all unlock. A tiny
“PTT” icon appears at the lower left when the PTT is locked.
[p] / [q]
keys are changed to audibly indicate
FT-411 MKII OPERATING MANUAL12
Operation
VFO FREQUENCY & STEP SELECTION
Make sure the keypad is unlocked, and press the [PRI(VFO)] button, if necessary, to select
the VFO mode (see box below). The FT-41 1 MKⅡ has two vfos, labelled “ A” and “B”, either
of which can be used for all of the procedures described in this manual. You can change vfos
with the [PRI(VFO)] button at any time, allowing one to serve as a 50th memory.
You have several ways to tune the FT-411 MKⅡ: in selectable channel steps or 1 MHz steps
with the
Use the DIAL knob to tune the displayed VFO frequency at the current channel step rate.
You can also press the
[q]
press an
[p] / [q]
key for more than ½-second scanning will start. This is described later, so for now, just
[p] or [q]
keys or DIAL knob, and direct keypad frequency entry.
[p] / [q]
key again to stop (if you have to).
keys momentarily to do this, but if you press an
[p]
or
To change the MHz range of the VFO, you can press the [F/M] key followed by an
[q]
key (or turn the DIAL knob). Note the beeps when using the
when moving up, and ( ) when moving down. When done press [F/M] again, or just wait
three seconds.
You can also enter a frequency directly just by keying in the 1 MHz and the kHz digits. If
you are using 5 or 10 kHz steps enter four digits. Otherwise just three digits will do. Partial
entries can be cancelled with the [PRI(VFO)] key.
Tuning steps are factory preset to 5 kHz (vers. A) or 25 kHz (vers. B). To change to another
step size press [F/M] and then [STEP(7)] and use the DIAL knob or
select 5, 10, 12.5, 20 or 25 kHz steps (displayed at the right. the “5” or “P” at the left is the
scan mode indicator, described later). Once the desired step is displayed, press [STEP(7)]
by itself to return to the VFO frequency display.
VFO and Memory Modes
To tune your operating frequency, the transceiver must be in what we call the VFO
mode (as opposed to the Memory mode). If a small “A” or “B” is displayed to the left
of the frequency, the VFO mode is selected. Otherwise, if a Memory number (or a “C”,
“L” or “U”) appears in the shaded box in the upper left-hand corner of the display, the
Memory Mode is selected.
[p] / [q]
[p] / [q]
[p]
or
keys: ( )
keys to
FT-411 MKII OPERATING MANUAL 13
Operation
TRANSMITTING
Press [F/M] and then [LOW(3)] to toggle between high and low power output. The pitch of
the keypad beeper will indicate whether high or low power is being selected, and “LOW”
is displayed above the 1 MHz digit when low power is selected (we recommend using low
power whenever possible to minimize possible interference to other stations and prolong
battery life).
When you wish to transmit, wait until the channel is clear (BUSY/TX lamp off), and squeeze
the PTT switch. During transmission the BUSY /TX lamp glows red, and relative transmit-
ter power output is indicated graphically along the bottom of the display. Release the PTT
switch to receive.
If using a version B (in Europe), press the BURST switch (above the PTT switch) to
transmit a 1750 Hz tone to access repeaters that require it.
REPEATER SPLITS
The ARS (Automatic Repeater Shift) feature in the FT-411 MKⅡ provides repeater shift of
the transmit frequency whenever you are tuned to a standard repeater subband (see diagram below). When enabled, a small “–” or “+” displayed above the 10’s of kHz of the
frequency indicates that repeater shift is active, and closing the push-to-talk switch changes
the display to the (shifted) transmit frequency.
The ARS function is disabled at the factory. It is toggled on and off by pressing [F/M], [RPT
SET(RPT)], [F/M] and [RPT SET(RPT)] (that is, each key, twice alternately). Pressing [F/
M] and [RPT SET(RPT)] the first time displays the repeater shift offset (default 600 kHz,
but adjustable) at the right, and if ARS is now enabled, an “A” at the left. With this display,
pressing only the [F /M] key toggles ARS between enabled and disabled states, and [RPT
SET(RPT)] returns the display to the operating frequency. So after pressing [F/M] and [RPT
SET(RPT)] the first time, if you want to leave ARS as it is, just press [RPT SET(RPT)].
Otherwise, press [F/M] to change it and press [RPT SET(RPT)] once more when finished.
When the ARS feature is inactive (either disabled, or outside of the standard repeater
subbands) the [RPT SET(RPT)] button manually activates offset of the transmitting frequency from the receiving frequency for plus or minus shift. Just press [RPT SET(RPT)]:
FT-411 MKII OPERATING MANUAL14
Operation
once for minus shift, or twice for plus shift (“–” or “+” displayed above the 10 kHz frequency digit). When you press the PTT switch to transmit (or [F/M] and [REV(9)] to
reverse transmit and receive frequencies), the display will shift down or up by the programmed offset, if in band (or else ‘Err’ is displayed). Pressing [RPT SET(RPT)] again
returns you to simplex operation.
CHANGING THE STANDARD REPEATER SHIFT
As mentioned above, 600 kHz repeater offset is programmed in the transceiver, and can be
easily reprogrammed as desired. If you have one or two repeaters in your area with nonstandard splits, you can program separate transmit and receive frequencies in memory as
described later. However, if most or all of the repeaters you use have an offset different
than 600 kHz, you can reprogram the standard offset (as used by the [RPT SET(RPT)]
button and ARS) instead.
Changing the shift offset is the same as described above for changing the state of the ARS
feature, except that you use the DIAL knob,
change the shift offset when it is displayed (that is, after pressing [F /M] and [RPT
SET(RPT)]). Any repeater offset must be a multiple of 50 kHz. If you use the keypad to
enter the new offset you will start with the 10’s of MHz digit, so if the new offset is less
than 1 MHz, you will have to enter two 0’s, followed by the 100’s of kHz and 10’s of kHz
digits. For example, press [BELL(0)], [BELL(0)], [LOCK(6)], [BELL(0)] to select 600
kHz offset (the 1’s of kHz digit is assumed to be always zero, and so is not entered). After
selecting the desired offset, make sure the ARS feature is set as desired (“A” at the left if
enabled), and then press [RPT SET(RPT)] to return to the VFO frequency display.
[p] / [q]
keys or numeric keypad entry to
FT-411 MKII OPERATING MANUAL 15
Operation
MEMORY STORAGE
The FT-411 MKⅡ offers forty-six general purpose memories, numbered 1 through 46, and
three special memories, labelled C, L and U. All of these memories can store separate
receive and transmit frequencies or repeater shift, and tone squelch data (if the optional
FTS-17A is installed). The C memory is recalled instantly whenever the [CALL/DTMF]
button on the top panel is pressed (for use as an emergency or call channel), and the L and
U memories are used for PMS operation, described later.
To store a frequency in memory:
Select the desired frequency (and repeater split, if desired) in the VFO mode as de-
•
scribed above.
Press and hold the [F/M] key for ½-second (until the second beep sounds). A Memory
‚
number appears blinking in the shaded box at the upper left corner of the display.
Within five seconds of step ‚, use the DIAL knob or
ƒ
desired Memory for storage. If you select one that was already being used, it will be
overwritten with new data in the next step.
Press [F/M] again to store the displayed data into the selected Memory: the Memory
„
number will stop blinking for a second, and then disappear as operation continues in
the VFO mode.
When storing split-frequency memories you have the choice of either the Repeater Split
method, described previously, or of storing separate transmit and receive frequencies. To
store a separate transmit frequency, just store the receive frequency as described above,
and then tune to the desired transmit frequency, press [F/M] again for ½-second, and then
press and hold the PTT switch while pressing [F/M] once more (the transmitter is not
activated in this case). By either method the results will be the same in operation, except
that storing a separate transmit frequency applies only to one memory, while the offset
method applies to all (when the [RPT SET(RPT)] button is pressed).
[p] / [q]
keys to select the
MEMORY RECALL & COPY
There are two ways to recall stored memories. If you know the memory number, just enter
it on the keypad and then press [SKIP(MR)] (the “L” memory is 47 for this purpose, while
the “U” memory is 48).
If you aren’t sure of the memory number, press the [SKIP(MR)] to select the Memory mode
(a Memory number/letter is displayed at the upper left), and then use the DIAL knob or
/ [q]
keys to select the desired memory. Naturally, vacant memories are not displayed.
For split-frequency memories, “–” or “+” will be displayed to remind you of the shift if
stored by the offset method. If you stored a memory with a separate transmit frequency, “–+”
are displayed together. In either case, you can press [F/M] and [REV(9)] to check the trans-
mit frequency without transmitting (and press these keys again to return).
FT-411 MKII OPERATING MANUAL16
[p]
Operation
You can retune a selected memory by pressing the [SKIP(MR)] key: a dotted underline
(.....) appears under the channel box at the upper left, and you can tune the displayed
memory frequency in the same ways as described for the vfos. If you want to store the new
memory settings in the current, or another memory, just follow steps ‚ - „ of the memory
storage procedure above: operation will be left on the memory.
If you want to copy memory data to a vfo (overwriting previous data), you can do so while
the memory retune feature is active: just press [F/M] and the [PRI(VFO)] key to copy to
the last-used VFO.
If you don’t want to save your changes to the memory, press only the [SKIP(MR)] key to
return to the original memory data.
HIDING AND ERASING MEMORIES
As already mentioned, storing data in a memory automatically over-writes data that was
previously stored there. However, if you regularly move from one area to another, you may
not want to use the same memories all the time, or you may wish to change your operating
memories without having to rewrite them from scratch. This can be done by masking certain memories so that they are completely hidden from operation, and recalling them only
when desired for operation.
To completely mask a memory, recall it and press the [F/M] key for ½-second (until the
memory number blinks). Then press the [SKIP(MR)] key. This causes the display to change
to memory 1, and the previously-selected memory is no longer selectable manually, or by
scanning (as described later). Note that you cannot hide memory 1.
To unmask a hidden memory for operation, recall any memory and press [F/M] for ½second. Then select the memory number to be restored, and press [SKIP(MR)].
When you have hidden memories, avoid accidentally overwriting them.
CALL CHANNEL MEMORY
The call channel memory can be instantly recalled by pressing the [CALL/DTMF] button
on the top panel. “C” appears in the memory window at the upper left corner of the display.
As mentioned earlier, you can store the same kinds of data in the CALL channel as in the
general purpose memories: just follow steps • and ‚ of the memory storage procedure,
and then press the [CALL/DTMF] button. Also, if storing a separate transmit frequency,
press the [CALL/DTMF] button while holding the PTT switch when storing the transmit
frequency (after storing the receive frequency - the transceiver will stay in the VFO mode).
FT-411 MKII OPERATING MANUAL 17
Operation
SCANNING
Before starting the scanner, make sure the SQL control is set to squelch off the noise on a
clear channel. Scanning is activated and deactivated by the
hold either key for more than ½-second to start the scanner. If the transceiver is in the VFO
mode (or on the CALL channel), the whole band will be scanned. If in the memory mode,
only the memories will be scanned.
The scanner pauses (and the decimal point blinks) whenever a signal is detected which is
strong enough to open the squelch. You have a choice of two scan-resume modes: either
Pause mode, in which the scanner pauses for as long as the carrier keeps the squelch open,
or the 5-second duration mode, in which the scanner pauses for five seconds and then
resumes scanning whether or not the signal is still present.
To set the scan-resume mode, press [F/M] and then [STEP(7)]. A small “P” or “5” at the
left indicates the current mode. Press [F/M] to change it, or just press [STEP(7)] alone to
return to the frequency display.
You can stop the scanner manually by pressing the PTT or an
turning the DIAL knob.
NOTE: The scanner checks about 14 channels per second. To prevent this process from
being interrupted by the power saver, saver operation is automatically suspended
during scanning, resulting in some increase in power drain.
[p] / [q]
[p] or [q]
keys. Just press and
key, or by
MEMORY SKIP SCANNING
When you have some busy channels stored in memories you may wish to skip them when
scanning other memories, but still have them available for manual selection. You can mark
a memory to be skipped by pressing [F/M] and then [SKIP(MR)] while the memory is
recalled. A tiny arrowhead will be displayed just to the right of the memory number box,
and this memory will be skipped during scanning (although you can still recall it manually).
To unmask a scan-skip memory, just repeat the same steps you took to mask it: select the
memory manually, and press [F/M] and [SKIP(MR)].
PROGRAMMABLE MEMORY SCANNING (PMS)
In addition to band and memory scanning, the FT-411 MKⅡ can scan between two frequencies of your choice stored in the special memories labelled “L” and “U”:
Store the lower edge of the desired scanning range in memory “L”, and the upper edge
•
in memory “U”.
With either memory “U” or “L” recalled, press the [SKIP(MR)] key. A dotted under-
‚
line will appear at the bottom of the memory number box at the upper left.
You can now tune or scan as described previously, between the nearest multiples of 100
kHz (xxx.000, xxx.100, xxx.200, etc.) below memories “L” and “U”.
FT-411 MKII OPERATING MANUAL18
Operation
To cancel PMS operation, stop scanning, if necessary (DIAL knob,
PTT), and press the [SKIP(MR)] key to return to regular memory operation, or the
[PRI(VFO)] key to return to VFO mode.
[p] / [q]
keys or
PRIORITY CHANNEL MONITORING
Priority monitoring allows automatic checking for activity on a memory every five seconds while operating on a vfo or other memories. When a signal appears on the priority
memory while receiving, operation will automatically shift to that memory, for as long as a
carrier is received. If you transmit while paused on the priority memory, priority monitoring is cancelled and operation stays on the priority memory.
The squelch must first be preset, and the frequency to be monitored must be stored in a
memory (this MUST be memory 1 if you will be operating on other memories during
priority monitoring).
Press the [PRI(VFO)] key to operate on a vfo, or else select the memory you want to
operate on, and then press [F/M] and [PRI(VFO)]. A ‘P’ will appear in the memory window at the upper left corner of the display, and about every five seconds the displayed
frequency will shift to the priority memory briefly while the receiver checks for a signal.
As long as no signal appears on the priority memory to open the squelch, you can tune,
scan, transmit and receive on the vfo, or select and operate on other memories. If a station
you wish to talk with appears on the priority memory, press the PTT switch momentarily
while receiving his signal, to stop priority checking. Otherwise, when a signal appears on
the priority memory, checking will pause and the decimal on the display will blink; then
priority monitoring will resume (according to how you set the scan resume mode - either
after a 5-second pause, or after the carrier drops). To cancel priority monitoring manually,
press either the [SKIP(MR)] or [PRI(VFO)] key.
Note that you can use any other memory as a priority channel in the above procedure when
operation during priority monitoring is to be on the vfo.
MULTI-CHANNEL PRIORITY MONITORING
The priority monitoring function described above can be used to sequentially check multiple memory channels. After storing the memories, mask (hide) those you do not want
checked, as described under “Memory Skip Scanning” on page 18. Then activate scanning of these memories by pressing an
mode. You can now press [F/M] and [PRI(VFO)] to activate priority monitoring of the
memories while operating on the vfo. Each time the priority system checks a memory, it
will be one higher or lower than the one checked previously.
When operating on the vfo while priority monitoring one or more memories, you can activate vfo scanning by holding an
FT-411 MKII OPERATING MANUAL 19
[p] or [q]
[p] or [q]
key for ½-second from the memory
key for ½-second.
Operation
TONE SQUELCH/PAGER OPERATION
The FT-41 1 MKⅡ can be used to silently monitor for calls on busy channels, and to transmit
CTCSS tones, when the optional FTS-17A Tone Squelch Unit is installed. The transmit
(encode) function superimposes a subaudible tone (at a frequency too low to be heard) on
the transmitted carrier, while the decode function monitors receiver audio through a narrow
filter at the same subaudible frequency, keeping the squelch closed until a matching tone is
received. If the paging bell feature is activated, an incoming signal with the matching tone
will cause the speaker to sound an alerting “ring,” and a small bell icon will blink above the
10’s of MHz digit on the display (so that you know if a call came in while you were busy
elsewhere). Installation instructions for the FTS-17A are in the ‘Installation’ chapter.
To check or set the CTCSS tone frequency and paging ring status, press [F/M]+[TSET(2)].
The tone frequency will be displayed (in Hz). To change the tone frequency, rotate the
DIAL knob or press the
require (if only 88.5 is displayed, the FTS-17A is not installed). Also, a lower-case “b” is
displayed at the right if the keypad beeper is activated: it MUST be activated if the paging
ring is to sound when a CTCSS call is received. Press the [F/M] key to toggle the keypad/
ring tones on, if desired, and then press [TSET(2)] to return to the operating frequency
display.
With the keypad/ring tones turned on as just described, you must also activate the paging
bell if you want to use this feature. Press [F/M] and then [BELL(0)]: a small bell icon
appears above the 10’s of kHz digit when activated. This icon will blink after a call is
received.
[p] / [q]
keys until the display shows the tone frequency you
To activate tone squelch press [F/M] and then the [TONE(1)] key. A tiny “T” will appear at
the top of the display above the decimal, and the tone generator will be activated for transmission. Press [F/M] and [TONE(1)] again and “SQ” will be displayed next to the “T” as
tone squelch is activated for both transmission and reception. Now only a matching tone
frequency will open the squelch. Pressing [F/M] and [TONE(1)] once more turns off the
tone squelch features.
Once you have the tone squelch set up the way you want it, you can store it in any memory.
Afterwards, to change the stored settings, just recall the memory, reset the tone frequency
or function, and store the memory again (press and hold [F/M] ½-second, and then press it
again momentarily).
FTS-17A Tone Frequency Chart (Hz)
67.0
71.9
74.4
77.0
79.7
82.5
85.4
88.5
91.5
94.8
97.4
100.0
103.5
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
162.2
167.9
173.8
179.9
186.2
192.8
203.5
210.7
218.1
225.7
233.6
241.8
250.3
FT-411 MKII OPERATING MANUAL20
Operation
POWER SAVER
The Power Saver allows the transceiver to monitor a frequency for activity while drawing
as much as 400% less current than is required for normal squelched reception. This is done
by removing power from all circuits (except a timer and the display) for programmable
intervals. Between these intervals, the receiver is enabled for 30 ms to check the displayed
frequency for activity. A tiny “S” is displayed below the 10’s of kHz digit when the Power
Saver feature is enabled. During power saving, the “S” flashes on and off.
When a signal appears the receiver functions normally. However, if the carrier drops for
more than about 3 seconds, power saving resumes automatically. If the PTT switch is
closed at any time during power saver operation, the transmitter activates as usual. If no
station responds to the transmission within 3 seconds after releasing the PTT switch,power
saving resumes.
If no “S” appears below the 10’s of kHz digit, power saving is disabled. To enable it, press
[F/M] and then [SAVE(4)], and wait a few seconds. Normally you will want to keep it
enabled, but if you use the transceiver for packet operation you will want it disabled, as it
might otherwise interfere with packet reception. To disable power saving, press [F/M]
followed by [SAVE(4)] and then the “[BELL(0)]” key quickly (“OFF” will be displayed
for a few seconds before the display returns to the operating frequency.
Remember that power saving only occurs when the squelch is closed (BUSY/TX lamp
off). As shipped from the factory, power saving provides a 1:6.7 duty cycle (30 ms receive,
200 ms sleep). This ratio can be reprogrammed from the keypad for 1:1 to 1:33.3. To do
this, first select the ratio you want from the chart below and note its corresponding key
number, then press [F/M], [SAVE(4)] and the number you selected (quickly). The display
will show the resulting save time in decimal seconds, and then will return to the operating
frequency. Turning the transceiver on and off does not affect the state (or programmed
ratio) of the power saver.
POWER SAVER INTERVALS
Key Nr.
EXAMPLE: to program a save ratio of 10:1
Save Time (ms)
1
2
3
4
5
6
7
8
9
Press [F/M] followed by [SAVE(4)] and then (immediately) the [APO(5)] key. The display shows 0.30 indicating 300 ms save time, and the returns to the operating frequency.
30
70
100
200 (default)
300
500
700
800
1000
Save/Rcv Ratio
1:1
2.3:1
3.3:1
6.7:1
10:1
16.7:1
23.3:1
26.7:1
33.3:1
Avg. Current Consump. (mA)
23.0
16.2
13.8
10.4
9.1
7.9
7.4
7.2
7.0
FT-411 MKII OPERATING MANUAL 21
Operation
APO (AUTOMATIC POWER-OFF)
This feature automatically puts the transceiver to sleep if the keypad/DIAL knob, PTT or
[CALL/DTMF] buttons are not used for a selectable period of 10, 20 or 30 minutes. One
minute before going to sleep, a warning melody will sound ( ), and
the APO clock icon will begin to blink. If no key is pressed within the next minute, the
display will change to “OFF,” with the clock icon blinking. If power saving is also enabled, the small “S” will blink to the left of the clock icon, even though power saving is
NOT active in this condition.
The APO clock icon appears at the bottom right corner of the display whenever the APO
feature is enabled. To toggle it on and off, press [F/M] and then [APO(5)].
To check the current setting of the APO timer, turn off the transceiver and then press and
hold the “[APO(5)]” key while turning it back on. The display will show the current timer
setting (in minutes) before changing to the frequency display. If you want to change the
timer setting, turn the transceiver off again, and then press and hold either the “[TONE(1)],”
“[TSET(2)]” or “[LOW(3)]” key, for 10-, 20- or 30-minute APO time, respectively, while
switching the transceiver back on.
VOX (VOICE-ACTUATED TRANSMIT SWITCHING)
When the optional YH-2 Headset is connected to the EAR and MIC jacks on the top panel,
VOX can be activated for hands-free operation. Press [F/M] once and then [VOX(8)] repeatedly to toggle the VOX system between low sensitivity (“Lo” displayed), high sensitivity (“Hi” displayed) and off (“OFF” displayed). After making your selection, wait a few
seconds for the display to return to the operating frequency. Use low sensitivity when in a
noisy area where other sounds might otherwise trigger the transmitter. When the VOX is
enabled (with either high or low sensitivity), a tiny reverse “V” is displayed in the upper
right corner.
NOTE: The VOX system is not designed work with the internal microphone or with exter-
nal speaker/microphones.
DTMF MEMORIES
The FT-411 MKⅡ provides ten memories, numbered 0 through 9, for storage of DTMF
tone sequences of up to 15 digits each, for storage of commonly used remote DTMF control sequences or telephone numbers to be used on autopatching systems.
A special mode must be activated to use the DTMF memory features. This mode is toggled
on and off by pressing [F/M] and then the [CALL/DTMF] button on the top panel. A small
telephone icon is displayed above the rightmost frequency digit when this mode is active.
FT-411 MKII OPERATING MANUAL22
Operation
To store a DTMF memory:
Activate the DTMF memory mode as just described.
•
Press and hold the [F/M] key for ½-second (until the second beep sounds).
‚
Within 5 seconds of step ‚, press a numbered key corresponding to the DTMF memory
ƒ
number you want to store. The display will change to the following:
selected DTMF memory number (0-9)
serial digit number (01 to 15) in this memory
DTMF tone code* stored in this digit
: DTMF codes are displayed as 0-9, A, b, C, d, E (for *), F (for #) and “–” for empty (none stored).
*
Again press and hold [F/M] for ½-second, and then key in the numbers of the DTMF
„
sequence you want to store. As you do so, the serial digit number in the center of the
display will increment automatically as the entered code is displayed at the right. If
you make a mistake press the PTT switch and repeat this step.
After entering the desired DTMF sequence, press the [CALL/DTMF] key on to top
…
panel briefly, and then press the numbered key corresponding to the memory number
stored, to replay the stored codes in the loudspeaker.
Turn the DIAL knob to select another DTMF memory to store, if desired, and repeat
†
steps „ and ….
Press the [CALL/DTMF] button to return to the frequency display.
‡
To recall a stored DTMF memory on the air, first make sure the DTMF memory mode is
activated (the telephone icon is displayed). Then close the PTT switch and press the number of the DTMF memory to transmit.
CAUTION:When the DTMF memory mode is active, the keypad cannot be used to trans-
mit individual DTMF codes. Turn the DTMF memory mode off ([F/M] and
then [CALL/DTMF]) if you do not have the required DTMF sequence stored
in memory, and then enter the DTMF digits individually.
SYSTEM RESET
To reset all programmable features and setting to their factory defaults, turn off the transceiver and then press and hold both the [PRI(VFO)] and [SKIP(MR)] keys while switching it back on.
FT-411 MKII OPERATING MANUAL 23
In Case of Problem
The basic features of this transceiver are not complicated, but it is still possible to get lost,
at least until you have had the chance to learn all of the functions of the keypad and display.
If the display shows nothing at all, check the power switch (VOL control), and if necessary,
remove the battery pack and check that the contacts are clean. If all appears to be physically in order, recharge or replace the batteries.
The display includes enough symbols and function indicators to let you know what is
going on as long as power is applied, so it is well worthwhile to study the display diagram
on page 6 carefully. For example, if the frequency display changes unexpectedly when you
transmit (or if ‘Err’ appears), check for a small ‘+’ or ‘–’ at the upper righthand corner.
Also, if only a few seemingly non-sensical digits appear, try switching the set off and back
on to clear any special display modes, such as tone squelch, repeater offset, channel step or
DTMF memory setting.
Most illegal commands will cause two beeps to sound. If pressing a key appears to do
nothing, first check for a small ‘L’ in reverse type at the lower left, which indicates if the
keypad is locked. If so, press [F/M] and then [LOCK(6)] to unlock the keys. If the ‘L’ is not
there, press [F/M] or [CALL/DTMF] on the top panel, which will terminate many partially
entered commands. If you still cannot enter data, check the BUSY/TX indicator to see if it
is red, indicating that the transceiver is transmitting. Releasing the PTT switch should
return the set to receive. If still nothing happens, switch the transceiver off, and then back
on.
If you find the stored data is definitely non-sensical or far from what you want, try the
System Reset procedure described on the previous page.
To avoid confusion resulting from inadvertent key presses, set the keypad lock on (press
[F/M] and [LOCK(6)]) if you set the transceiver down while it is on, and then remember to
set the lock back off when you wish to enter data.
FT-411 MKII OPERATING MANUAL24
DATA Cloning
Downloaded by
Amateur Radio Directory
It is possible to copy all of the stored data from one transceiver to another (both must be
FT-41 1 MKⅡ’s, of course) without having to re-enter everything from the keypad. To do
this, you will need to construct a cable with two 2.5 mm micro phone plugs, and follow the
procedure here:
Turn off both transceivers and connect the MIC jacks together with the cable just
•
described.
Press and hold the [F/M] key while turning on each transceiver. The displays will flash
‚
all segments.
Press the
ƒ
flashing, and remain either on or off (either is okay).
Press the
„
now be displayed on the other transceiver, and all other data will be transferred in a
few seconds.
If “Err” is displayed on the destination transceiver, switch the power off and back on
again (while holding the [F/M] key), and repeat steps ƒ and „.
When the data has been transferred successfully, turn off both transceivers and remove
…
the cable.
[q]
key on the transceiver that is to receive data. The display will stop
[p]
key on the transceiver that is to send its data. Data from memory 1 will
2.5mm micro phone plug 2.5mm micro phone plug
FT-411 MKII OPERATING MANUAL 25
Shield Cable (as short as practical)
Getting the Most from Your Batteries
How long the batteries last between charges or replacement depends largely on your operating habits, and how you care for the batteries (if using a rechargeable Ni-Cd pack). The
FT-41 1 MKⅡ offers a variety of ways to conserve battery consumption, and thus to extend
the charge life of the batteries. Knowing how to use these features properly can be critical
in emergencies. Here is a summary of the features to consider if battery life is a concern:
l Make sure that the set is off when not in use. This can also prevent premature battery
pack failure from over-discharge.
l Unless monitoring for calls, activate the APO feature so that power drain is minimized
if you doze or are called away. Set the APO time for a 10 minute shutoff, increasing
this time only if necessary.
l Always use the power saver feature to monitor for calls (except packet). If you can
ensure your callers will make calls at least ½-second long, you can make maximum
use of this feature by setting the save time to 500 ms (there is little benefit in setting it
any longer).
l Choose a quiet frequency and close the squelch on background noise when monitoring
for a call. The FTS-17A Tone Squelch option is useful for creating your own quiet
channel if the entire band is crowded.
l Use the lowest possible volume setting when listening to signals. In noisy environ-
ments, use an earphone or the YH-2 headset so you can keep the volume low.
l Using the LOW power setting requires about 60% less current when transmitting, so it
is a good idea to develop the habit of always using this setting, switching to high power
only if low power fails to get through. If you live in a location where high power is
almost always needed, consider replacing the antenna with a higher gain type instead
of opting for high power (the result on transmit is the same, with the added benefit of
better reception). Make sure that any external antenna is designed for 50-ohms impedance on the operating frequency.
As the battery discharges, the voltage drop when transmitting will increase. When the
voltage becomes critical, a tiny battery icon appears at the lower right corner of the display,
indicating that the batteries should be replaced or recharged as soon as possible.
If using rechargeable batteries, do not keep operating once the battery icon has come on, as
this could cause over-discharge of the cells and destroy the pack. However, recharging NiCd batteries often, with little use in between charges, can also shorten the useful charge life
of the cells. Therefore the best way to get the most out of your Ni-Cds is to use the battery
pack just until the battery icon comes on, and then immediately give the pack a full recharge. Unfortunately this is not always convenient, since it can be hard to tell exactly
when the charge will run out. One solution to this problem is to carry an extra, fully charged
pack with you if you do not wish to have operation interrupted.
FT-411 MKII OPERATING MANUAL26
Getting the Most from Your Batteries
Power and Charge Life Chart
Battery Model
Dry Cell Case
FBA-17 (UM-3 × 6)
7.2 V Ni-Cd Packs
FNB-17 (600 mAh)
FNB-14 (1000 mAh)
12 V Ni-Cd Packs
FNB-11H (700 mAh)
FNB-12 (500 mAh)
Operating 6 sec transmit, 6 sec receive and 48 seconds standby, with VOL set for 0.25 W
*
Power (Watts)
2.5
2.5
2.5
5.0
5.0
receive audio, Power Saver ON and set for 300 ms intervals (1:10 duty cycle)
Charge Life* (hours, approx.)
6.0 (w/ Manganese)
18.0 (w/ Alkaline)
5.5
12.0
4.5
4.0
FT-411 MKII OPERATING MANUAL 27
Note
FT-411 MKII OPERATING MANUAL28
CAUTION!
Changes or modifications to this device not expressly approved by Yaesu Musen
could void the user's authorization to operate this device.
1. Changes or modifications to this device not expressly approved by
Yaesu Musen could void the user's authorization to operate this device.
2. This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions; (1) this device may not cause
harmful interference, and (2) this device must accept any interference
including interference that may cause undesired operation.
3. The scanning receiver in this equipment is incapable of tuning, or
readily being altered, by the User to operate within the frequency bands
allocated to the Domestic public Cellular Telecommunications Service
in Part 22.
This device complies with RSS-210 of Industry Canada. Operation is
subject to the following two conditions; (1) this device may not cause
interference. and (2) this device must accept any interference, including
interference that may cause undesirable operation of the device.
Copyright 1999
Downloaded by
Amateur Radio Directory
Yaesu Musen Co., Ltd.
All rights reserved.
Printed in Japan
No portion of this manual
may be reproduced
without the permission of
Yaesu Musen Co., Ltd.
9904o-0K
E 2 5 8 0 1 5 0 0
Loading...
