Weather Station: WE800 / WE900

Publication Number 38600512

- 1 -

Global Water

800-876-1172 • globalw.com

Congratulations on your purchase of the Global Water
WE800/WE900 Weather Station. This instrument has been
quality tested and approved for providing accurate and reliable
measurements. We are confident that you will find the
WE800/WE900 to be a valuable asset for your application.
Should you require assistance, our technical staff will be happy to
help.

Table of Contents

I. Checklist • • • • • • • Page 3
II. Inspection
III. Description
IV. Installing the Weather Station
V. Weather Station Calibration Information
VI. Specifications
VII. Maintenance
VIII. Troubleshooting
IX. Warranty

• • • • • • • 7

X. Appendix A: Optional Equipment Mounting Ins tructions
XI. Appendix B Weather Station Assembly D r awing

* Copyright  Global Water Instrumentatio n, I nc. 2012

• • • • • • 4

• • • • • • 4

• • • • 4

• • 5

• • • • • • 6

• • • • • • 6

• • • • • • 6

8

• 10

- 2 -

I. Checklist

WE800

a. Weather Sensors
b. Weather Sensor Manual
c. Datalogger
d. Datalogger Communication pack age ( D atalogger Manual, Software,

e. Mounting Hardware
f. Weather Station Manual
g. 12V Battery (inside Datalogger)
h. Battery charger

WE900

a. Weather Sensors
b. Weather Sensor Manual
c. Mounting Hardware
d. Weather Station Manual

Global Water

800-876-1172 • globalw.com

Cable)

- 3 -

Global Water

800-876-1172 • globalw.com

II. Inspection

a. The WE800 / WE900 unit was carefully ins pec ted and cer tified by

Global Water’s Quality Assur anc e Team before shipping. If any
damage has occurred during shipping, please notify Global Water
Instrumentation, Inc. and file a claim w ith the carrier involved.

Use the checklist to ensure that ever y thing needed to operate the
Weather Station was shipped.

III. Description

a. The Global Weather Station is a rugged and reliable sys tem for

monitoring and/or recording several weather r elated sensors. The
standard logging model can monitor and recor d up to seven 4-20 mA
sensors and one pulse output sensor, suc h as a rain gauge.

IV. Installing the Weather Station

a. Please refer to Appendix A and B prior to ins talling the Weather

Station to review any optional sensor’s mount ing instructions that may
modify the standard setup.

b. Each sensor comes equipped with mounting h ar dwar e for a 1”

diameter pipe.

c. The Weather Station stand consists of a 1” diameter stainless steel

cross bar with a T fitting and the mast (two 1” diameter tubes
connected together with a pvc insert). The top piece of the mast has a
T fitting with a 1” stub attached also.

d. Insert the bottom of the mast into a solid base and secure it. Global

Water sells a Tripod for this purpose, WE830.
e. Slide the top of the mast onto the pvc insert to complete the mast.
f. Mount the cross bar to the top of the mast us ing the at tached T fitting.

Tighten the set screw with the enclosed hex wrenc h. Ensure that the

- 4 -

Global Water

800-876-1172 • globalw.com

cross bar is level. NOTE: For best results the cross bar s hould be at

least 8’ above the ground or roof.
g. The Wind Speed and Wind Direction sensors s hould be m ounted on

the opposite ends of the cross bar. Loosen the set screw holding the

Wind Direction sensor in the elbow. Line up t he notches on the Wind

Direction Sensor, turn the sensor unt il the notches face north, and

secure the sensor.
h. The Temperature Sensor and Humidity S ens or ar e pr es s ure fitted

inside the Solar Shield. The Solar Shield has a 1” elbow that mounts

on the stub attached to the top portion of the mast. Place the elbow

on the stub and secure with the set screw.
i. If the mast is in an area of extreme wind it may be necessary t o s ec ur e

the Weather Station with guy wires (not inc luded) .

V. Weather Station Calib ration Infor mation

WE800

a. The Weather Station comes factory calibrated and the sensors are

pre-attached to the Datalogger and if remov ed s hould be r eattached to

the same channel. Refer to the Weather Sensor manual to determine

how often each sensor should have its calibration checked. Refer to

the Datalogger manual for instructions on recalibration.

WE900

a. Each Weather Sensor will have to be calibrated to your PLC, RTU, or

SCADA system. Calibration numbers have been at tached to each

sensor. Refer to the Weather Sensor manual to determine how often

each sensor should have its calibrat ion c hec k ed.

- 5 -

VI. Specifications

a. Refer to the Weather Sensor manual for indiv idual sensor

specifications.
b. Refer to the Datalogger manual for dat alogger s pec ifications.
c. Weather Station Stand

Material: 1” Stainless Steel Tube

VII. Maintenance

a. Refer to the Weather Sensor manual for indiv idual sensor

maintenance instructions.
b. Refer to the Datalogger for the datalogger’s maintenance instructions.

Global Water

800-876-1172 • globalw.com

c. P er iodic c leaning of the stand may be necessary. Use soap and

water.

VIII. Trouble Shooting

a. Refer to Weather Sensor and Datalogger manuals for more

information.
Other issues

b. Call us for tech support: 800-876-1172 or [phone] (many

problems can be solved over the phone). Fax: [phone] or

Email: [e-mail].

Be prepared to describe the problem being experienced, including

specific details of the application and installation and any additional

pertinent information.
c. In the event that the equipment needs to be returned to the factory for

any reason, please call to obtain a RMA # (Return Mater ial

Authorization). Do not return items without a RMA # Weather

Stationed on the outside of the pack age.

- 6 -

Include a written statement describing the problems.

Send the package with shipping prepaid to G lobal Water’s factory

address. Insure the shipment, as the warr anty does not cover damage

incurred during transit.
d. When calling for tech support, please hav e the following information

ready;

IX. Warranty

a. Global Water Instrumentation, Inc. warrants that its products are free

from defects in material and workmanship under normal use and

service for a period of one year from date of s hipment from factory.

Global Water’s obligations under this w ar r anty are limited to, at Global

Water’s option: (I) replacing or (II) repairing; any products determined

to be defective. In no case shall Global Water ’s liability exceed the

products original purchase price. This w ar r anty does not apply to any

equipment that has been repaired or altered, ex c ept by Global Water

Instrumentation, Inc., or which has been s ubjec t to misuse, negligence

or accident. It is expressly agreed that this warranty will be in lieu of

all warranties of fitness and in lieu of the warr anty of merchantability.
b. The warranty begins on the date of the produc t’s invoice.

Global Water

800-876-1172 • globalw.com

1. Model #.

2. Unit serial number.

3. P.O.# the equipment was purchased on.

4. Global Water’s sales number or the inv oic e num ber .

5. Repair instructions and/or s pec ific problems relating to the
product.

- 7 -

Global Water

800-876-1172 • globalw.com

X. Appendix A: Optional E quipment Mounting Instr uctions

Datalogger Mounting Instructions

a. The optional mounting hardware is locat ed on the rear of the

Datalogger enclosure.

b. Loosen the nut so the retaining bolt can be rem ov ed and the fitting can

placed around the mast. Global Water rec ommends that the
Datalogger be attached to the lower port ion of the mast.

c. P lac e the Datalogger on the mast with the cables coming out the

bottom of the unit.

d. Secure the bolt in the fitting and tighten the nut to secure the

Datalogger to the mast.

Barometric Pressure Sensor Mounting In st ruct ions

a. If the Barometric Pressure Sensor was installed at Global Water, it

was installed inside the Datalogger enclosur e.

b. If the sensor is being installed in the f ield Global Water recommends

that it be attached to the lid of the Datalogger with tape in such a way
that the enclosure can open and close freely. The cable c an either be
cut, stripped, and connected to t he Datalogger on a free channel or
the cable can be run out of the enclosure through a f r ee s train relief,
run back into the enclosure through a different strain relief, and
connected to a free channel on the Datalogger.

c. E ns ur e that a strain relief hole is open, or the pressure valv e is open to

allow airflow or the Pressure Sensor will r ead inc or r ec tly.

Solar Radiation Sensor Mounting Instructions

a. The Solar Radiation Sensor comes with mounting hardware similar to

the Wind Direction and Wind Speed Sensors .

b. The T fitting and stub should be mounted on the upper por tion of the

mast and secured at a height and in a direction where the s ens or will
not be shaded by any other sensor of object . Tighten the T fitting’s set
screws with the enclosed hex wrench to secur e the stub in place.

c. The Solar Radiation Sensor has a 1” elbow that mounts on the stub.

Place the elbow on the stub and secure with t he set s c r ew .

d. Use the bubble level and three mount ing s c r ews to level the sensor

- 8 -

Global Water

800-876-1172 • globalw.com

Tipping Bucket Mounting Instructions

a. See Tipping Bucket manual for installat ion ins tructions.

Solar Panel Mount in g Ins t r uc tions

a. The Solar Panel comes with mounting hardwar e similar to the Wind

Direction and Wind Speed Sensors.

b. The T fitting and stub may be mounted any where on t he m as t as long

as the solar panel faces the sun’s general pat h ac r os s the sky, refer to
the solar panel manual for further instructions, available online at,

www.globalw.com, in the downloads sect ion. Tighten the T fitting’s set

screws with the enclosed hex wrench to secur e the stub in place.

Weather Station Orientation

a. For optimal results set your weather s tation up so that the Wind Speed

and Wind Directions Sensors are to the Eas t and West.

b. Place the Solar Shield with all of it ’s s ens or s in the sam e hem is pher e

you are in (IE if you are in the North hemisphere place it on the North
side)

c. P lac e the Solar Radiation sensor on the side closest to the sun, be

sure to level the sensor to get accurat e r es ults.

d. Place the Solar Panel under the Radiation Sensor and angle it panel

so you get maximum coverage.

- 9 -

Global Water

800-876-1172 • globalw.com

Appendix B: Weather Station Assembly Drawing

- 10 -
