OPERATING MANUAL

ViSolid 700 IQ

ViSolid 700 IQ SW

ba76040e02 07/2013

ViSolid

IQ SENSORNET TOTAL SUSPENDED SOLIDS SENSOR

700 IQ (SW)

ViSolid®700 IQ (SW)

For the most recent version of the manual, please visit www.ysi.com.

Contact YSI

1725 Brannum Lane Yellow Springs, OH 45387 USA Tel: +1 937-767-7241

800-765-4974 Email: environmental@ysi.com Internet: www.ysi.com

2 ba76040e02 07/2013

ViSolid®700 IQ (SW) Contents

ViSolid®700 IQ (SW) - Contents

1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

1.1 How to use this component operating manual . . . . . . . . 1-1

1.2 Structure of the ViSolid

solids sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

1.3 Recommended fields of application . . . . . . . . . . . . . . . . 1-2

1.4 Features of the ViSolid

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

2.1 Authorized use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

2.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . 2-2

700 IQ (SW) total suspended

700 IQ (SW) . . . . . . . . . . . . . . 1-3

3 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3.1 IQ SENSORNET system requirements . . . . . . . . . . . . . . . 3-1

3.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

3.3.1 General information . . . . . . . . . . . . . . . . . . . . . . 3-1

3.3.2 Flow direction . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

3.3.3 Sensor angle . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

3.3.4 Sensor orientation . . . . . . . . . . . . . . . . . . . . . . . 3-4

3.3.5 Distances from the ground and wall . . . . . . . . . 3-5

3.4 Installation examples . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

3.4.1 Measurement in an open pool or channel . . . . . 3-6

3.4.2 Measurement in pipelines . . . . . . . . . . . . . . . . . 3-8

3.5 Commissioning / Readiness for measuring . . . . . . . . . 3-10

3.5.1 Connect the sensor . . . . . . . . . . . . . . . . . . . . . 3-10

3.5.2 Selecting the Measuring mode . . . . . . . . . . . . 3-12

3.5.3 Setting tableViSolid

700 IQ (SW) . . . . . . . . . 3-13

4 Measuring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

4.1 Measuring operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

4.2 Calibration for TSS measurement . . . . . . . . . . . . . . . . . 4-2

4.2.1 General information . . . . . . . . . . . . . . . . . . . . . . 4-2

4.2.2 Default calibration . . . . . . . . . . . . . . . . . . . . . . . 4-3

4.2.3 Correction factor . . . . . . . . . . . . . . . . . . . . . . . . 4-5

4.2.4 User calibration . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

ba76040e02 07/2013

5 Maintenance, cleaning, accessories . . . . . . . . . . . . . 5-1

5.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

5.2 Cleaning the sensor shaft and measurement windows . 5-1

5.3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

0 - 1

Contents ViSolid®700 IQ (SW)

6 What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

7 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

7.1 Measuring characteristics . . . . . . . . . . . . . . . . . . . . . . . .7-1

7.2 Application characteristics . . . . . . . . . . . . . . . . . . . . . . .7-2

7.3 General data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3

7.4 Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4

8 Indexes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

8.1 Explanation of the messages . . . . . . . . . . . . . . . . . . . . .8-1

8.1.1 Error messages . . . . . . . . . . . . . . . . . . . . . . . . .8-1

8.1.2 Info messages . . . . . . . . . . . . . . . . . . . . . . . . . .8-2

8.2 Status info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-3

9 Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

9.1 Ordering & Technical Support . . . . . . . . . . . . . . . . . . . .9-1

9.2 Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1

10 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

10.1 Check calibration values . . . . . . . . . . . . . . . . . . . . . . . .10-1

0 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Overview

IQ Sensor Net Operating Manual

System

Operating

Manual

(Ring Binder)

IQ Sensor Operating

Manual

MIQ Module

Operating

Manual

MIQ Terminal

Operating

Manual

Component Operating Manuals

1Overview

1.1 How to use this component operating manual

Structure of the

ENSORNET operating

IQ S

manual

ba76040e02 07/2013

Fig. 1-1 Structure of the IQ SENSORNET operating manual

The IQ SENSORNET operating manual has a modular structure like the

ENSORNET system itself. It consists of a system operating manual

IQ S and the operating manuals of all the components used.

Please file this component operating manual into the ring binder of the system operating manual.

1 - 1

Overview ViSolid®700 IQ (SW)

1.2 Structure of the ViSolid®700 IQ (SW) total suspended solids sensor

Fig. 1-2 Structure of the total suspended solids sensor (example: ViSolid®700 IQ)

1 Shaft

2 Connection head

3 Optical measurement window made of sapphire

1.3 Recommended fields of application

ViSolid® 700 IQ Stationary measurement of the total suspended solids in slurries and in

water/wastewater applications.

ViSolid

700 IQ SW Stationary measurements in seawater and brackish water,

aquaculture.

The ViSolid

700 IQ (SW) is particularly well suited for applications in polluted measuring media, e.g. in wastewater treatment plants, thanks to its robust construction and its efficient ultrasound cleaning system. It provides very high measurement accuracy with low maintenance costs.

1 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Overview

1.4 Features of the ViSolid®700 IQ (SW)

Total suspended solids

measurement

The measurement of the total suspended solids in aqueous media with

the ViSolid

700 IQ (SW) is carried out as a scattered light measurement. This records the suspended proportion of total suspended solids (TSS).

Ultrasound cleaning

system

The ultrasound cleaning system ensures low maintenance and longterm reliable measurement operation. The ultrasound source integrated in the sensor excites the front face containing the measurement windows to oscillations in the ultrasound range. The resulting movement of the surface prevents the growth of pollution right from the start and, thus, ensures reliable measured values during continuous operation.

AutoRange function Within the enormously large measuring range (0 - 40000 mg/l SiO2

and 0 - 40000 mg/l TSS depending on the measured material), the AutoRange function selects the optimum resolution for the respective measured value.

SensCheck function This monitoring function that is integrated in the sensor is used to

continually check the sensor function and to register any malfunctions caused by the measuring medium. The correct operation of the ultrasound cleaning system is also continuously monitored.

ba76040e02 07/2013

1 - 3

Overview ViSolid®700 IQ (SW)

1 - 4

ba76040e02 07/2013

ViSolid®700 IQ (SW) Safety instructions

2 Safety instructions

This component operating manual contains special instructions that must be followed in the operation of the total suspended solids sensor ViSolid operating manual before carrying out any work using this sensor. In addition to this manual, the S system operating manual must be followed.

Always keep this component operating manual together with the system operating manual and any other component operating manuals in the vicinity of the IQ S

700 IQ (SW). Thus, it is essential to read this component

AFETY chapter of the IQ SENSORNET

ENSORNET system.

Special user

qualifications

General safety

instructions

Other labels

The total suspended solids sensor was developed for applications in online measurement - essentially in wastewater treatment plant applications. Thus, we assume that the operators are familiar with the necessary precautions to take when dealing with chemicals as a result of their professional training and experience.

Safety instructions in this operating manual are indicated by the warning symbol (triangle) in the left column. The signal word (e.g. "CAUTION") indicates the danger level:

WARNING

indicates instructions that must be followed precisely in order to prevent serious dangers to personnel.

CAUTION

indicates instructions that must be followed precisely in order to avoid slight injuries to personnel or damage to the instrument or the environment.

Note

indicates notes that draw your attention to special features.

ba76040e02 07/2013

Note

indicates cross-references to other documents, e.g. operating manuals.

2 - 1

Safety instructions ViSolid®700 IQ (SW)

2.1 Authorized use

The authorized use of the ViSolid®700 IQ (SW) consists of its use as a total suspended solids sensor in the IQ S

ENSORNET.

Please observe the technical specifications according to chapter 7

ECHNICAL DATA. Only operation according to the instructions given in

T this operating manual is considered to be authorized.

Any other use is considered to be unauthorized. Unauthorized use invalidates any claims with regard to the guarantee.

CAUTION

The sensor warms up during operation in the air. Consequently, pollution can collect in the vicinity of the measurement window due to the evaporation of liquid. Therefore, avoid any lengthy operation in the air.

CAUTION

Only connect and operate the sensor together with IQ Sensor Net accessories.

Function and

operational safety

2.2 General safety instructions

The sensor left the factory in a safe and secure technical condition.

The smooth functioning and operational safety of the sensor can only be guaranteed if the generally applicable safety measures and the specific safety instructions in this operating manual are followed during operation.

The failure-free function and operational safety of the sensor is only guaranteed under the environmental conditions that are specified in chapter 7 T

The specified temperature (chapter 7 T

ECHNICAL DATA.

ECHNICAL DATA) must be

maintained during the operation and transport of the sensor.

CAUTION

The sensor may only be opened by specialists authorized by YSI.

2 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Safety instructions

Safe operation If safe operation is no longer possible, the sensor must be taken out of

operation and secured against inadvertent operation.

Safe operation is no longer possible if the sensor:

 has been damaged in transport

 has been stored under adverse conditions for a lengthy period of

time

 is visibly damaged

 no longer operates as described in this manual.

If you are in any doubt, contact the supplier of your sensor.

Obligations of the

operator

The operator of the sensor must ensure that the following rules and regulations are followed when dealing with hazardous substances:

 EEC directives for protective labor legislation

 National protective labor legislation

 Safety regulations

 Safety data sheets of the chemical manufacturer.

ba76040e02 07/2013

2 - 3

Safety instructions ViSolid®700 IQ (SW)

2 - 4

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

3 Commissioning

3.1 IQ SENSORNET system requirements

Software statuses of the

controller and terminal

components

The operation of the ViSolid®700 IQ (SW) requires the following software versions in the IQ S

ENSORNET:

 MIQ/MC2 Controller software: Version 3.42 or higher

 MIQ/TC 2020 XT Terminal software: Version 3.42 or higher

 DIQ/S 182 Controller software: Version 3.47 or higher

 ViSolid

700 IQ (SW) Sensor software: Version 2.50 or higher

3.2 Scope of delivery

 Total suspended solids sensor, ViSolid®700 IQ (SW)

 Operating manual

3.3 Installation

3.3.1 General information

The measuring principle of the ViSolid

700 IQ (SW) (scattered light measurement) places specific requirements on the measurement location and on the installation of the sensor.

If there is a low level of total suspended solids (< 2000 mg/l SiO2 or < 1000 mg/l TSS), infrared light penetrates deep into the sample. Thus, the measuring environment can have a significant effect on the measured value displayed. Light that is reflected or scattered by the ground or wall can strike the detector in the sensor and, thus, simulate an increased level of total suspended solids.

Scattered light can be kept away from the measurement windows to a great extent by favorable positioning of the sensor. Therefore, an optimum installation position is particularly important for the measurement of lower values of total suspended solids.

Note

Always maintain a distance of at least 10 cm from the ground and wall.

The following factors affect the measurement of the TSS contents:

 Inclination of the sensor (see section 3.3.3)

ba76040e02 07/2013

3 - 1

Commissioning ViSolid®700 IQ (SW)

 Sensor orientation around its longitudinal axis (see section 3.3.4)

 Distances from the ground and wall (see section 3.3.5)

 Light-colored, heavily light-scattering surfaces in the measuring

vessel (e.g. vessel inner surfaces) or in the measuring environment.

 Unfavorable geometry of the measuring vessel or unfavorable

positioning of the sensor in the measuring vessel.

 Spatial proximity of two optical sensors.

 Very bright ambient light at the measuring location, e.g. direct

sunlight in the open channel

3 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

0 ° 20 ° 45 °

10 cm

Side view:

Marking

3.3.2 Flow direction

Generally, in flowing media, the measurement window should be clearly pitched towards the flow (angle of incidence approx. 20 to 45 °).

Exception:

If there is a high proportion of foreign bodies with fibrous or flat profiles such as, e.g. hair, twines or foliage, it can be advantageous to tilt the sensor in the direction of flow so that the measurement window is turned away from the flow.

3.3.3 Sensor angle

Fig. 3-1 Effect of the sensor angle on scattering and reflection from the ground and

wall

Note

Scattering and reflection are lowest at a sensor angle of 45° and at a minimum distance of 10 cm to the ground and walls (see section 3.3.5).

ba76040e02 07/2013

3 - 3

Commissioning ViSolid®700 IQ (SW)

Marking in this direction

Infrared beam

ViSolid 700 IQ SW

3.3.4 Sensor orientation

The sensor has a marking (arrow symbol on the shaft or glue dot on connection head). The infrared beam emerges from the front of the sensor at a small angle in the direction opposite the marking.

3 - 4

Fig. 3-2 Direction of the infrared beam relative to the marking

The angle of incidence to the ground and walls can be affected by rotating the sensor around its longitudinal axis. The sensor should be turned so that as little light as possible that is scattered or reflected by the wall or ground strikes the measurement window again.

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

Pretended additional amount of

total suspended solids [1000 mg/l SiO2]

Distance x [cm]

2.0

0,9

1.6

0,7

1.2

0,5

0.8

0,3

0.4

0,1

048121620

28 32 36 40

Aluminium (in drinking water each)

Aluminium (in water with 1000 mg/l SiO2)

Black plastic material

3.3.5 Distances from the ground and wall

Note

If there is a low level of total suspended solids (< 2000 mg/l SiO2 or < 1000 mg/l TSS), the effects of the measurement environment can simulate a higher content of total suspended solids. The effect of the measurement environment can be reduced by ensuring the optimum conditions (see section 3.3.1).

The following graphic indicates the minimum distances of the measurement windows to the ground or wall, which must be observed. The effect of the distances on the measured value has been determined for various wall materials (aluminum, black plastic) in the case of a sensor placed vertically to the wall in drinking water or water with 1000 mg/l SiO2.

ba76040e02 07/2013

Fig. 3-3 Effect of ground and wall distances on the measurement of TSS

Note

At low levels of total suspended solids, a minimum distance of at least 10 cm must be kept from the ground or wall.

Note

If an optimum installation is not possible due to the structural conditions at the measuring location (e.g. in narrow pipelines), the effects of the measurement environment can be compensated by user calibration (see section 4.2.4).

3 - 5

Commissioning ViSolid®700 IQ (SW)

3.4 Installation examples

As a rule, the ViSolid®700 IQ (SW) will measure interference-free when the distances and angles etc. specified are observed. However, interferences at the measuring location (see section 3.3.1) may require special adaptations of the installation.

3.4.1 Measurement in an open pool or channel

Measurement in a pool The total suspended solids sensor can be suspended in the pool on a

chain (e.g. with EH/F 170 swing mounting assembly and EH/U 170 sensor holder). Make sure the sensor cannot bump against any walls or obstacles.

Alternatively, the sensor can be immersed in the sample using a pendulum mounting assembly, e.g. EH/P 170 pendulum mounting assembly, (please note the minimum immersion depth).

3 - 6

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

min. 10 cm

Ground

Marking in this direction

Direction of flow

min. 10 cm

Immersion depth min. 7 cm

45 °

Measurement in a

channel

In an open channel, the sensor can be immersed in the sample using a wall mounting assembly, e.g. EH/W 170 wall mounting assembly, (please note the minimum immersion depth).

Mount the sensor rigidly in the channel. At the same time, tilt the sensor approx. 45 ° against the direction of the flow.

ba76040e02 07/2013

Fig. 3-4 Total suspended solids sensor in an open channel with wall mounting

assembly, EH/W 170

Note

For exceptions to the direction of flow, see section 3.3.2 F

DIRECTION.

LOW

3 - 7

Commissioning ViSolid®700 IQ (SW)

ADA-DF 9

EBST 700-DU/N

ca. 25 cm

straight pipe

Marking aid in this direction

Swivel nut

Infrared beam

Direction

of flow

3.4.2 Measurement in pipelines

Note

If deposits occur on the pipe walls, the calibration should be repeated at regular intervals.

Example:

45 ° pipe installation

The pipe should be straight for a length of approx. 25 cm beyond the installation location. Angled or tapered pipes can cause interference effects in the case of low levels of total suspended solids.

Fig. 3-5 Total suspended solids sensor in the pipe with EBST 700-DU/N flow-thru

adapter

3 - 8

Fig. 3-5 shows the installation of the EBST 700-DU/N flow-thru adapter for installation in a pipeline (DN 50). The infrared beam points in the opposite direction to the direction of flow. The marking on the sensor points towards the pipeline (see Fig. 3-5).

Note

For exceptions to the direction of flow, see section 3.3.2 F

DIRECTION.

LOW

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

Infrared beam

EBS 700-DU/N

Marking aid in this direction

ADA-DF 9

Example:

90 ° pipe installation

Marking aid

Fig. 3-6 Total suspended solids sensor in a pipe (90 °)

The following points must be observed for a right-angled installation in the pipe (Fig. 3-6):

 Rotate the sensor so that the marking on the sensor points in the

direction of the pipe axis

 Select a position where the pipe diameter is as large as possible as

the installation location (see section 3.3.5 D

GROUND AND WALL).

ISTANCES FROM THE

Note

In a 90° pipe installation with low levels of total suspended solids (< 2000 mg/l SiO2 or < 1000 mg/l TSS), the effects of the measurement environment can have a particularly significant effect on the measured value. Ensure the optimum conditions of the measurement environment (see section 3.3.1).

1 Connect the SACIQ (SW) sensor connection cable to the plug

head connector of the sensor and screw it tight (see section

3.5.1).

2 Attach a marking aid (adhesive strips or similar) in the same

position as the marking on the sensor to the plug head connector.

ba76040e02 07/2013

3 - 9

Commissioning ViSolid®700 IQ (SW)

Marking

Marking aid

Fig. 3-7 Marking aid

3 Install the sensor in the flow-thru adapter with the aid of the

ADA-DF 9 adapter (see operating manual of the adapter). To ensure the correct position, loosen the coupling ring on the EBST 700-DU/N somewhat and align the marking aid as shown in Fig. 3-5. Then, tighten the coupling ring.

3.5 Commissioning / Readiness for measuring

3.5.1 Connect the sensor

Connection cable A sensor connection cable of the SACIQ or SACIQ SW type is required

to connect the sensor. The cable is available in different lengths. Compared to the standard model SACIQ, the SACIQ SW sensor connection cable is optimized regarding its corrosion resistance in seawater and brackish water and adapted for use in conjunction with the ViSolid accessories is given in the YSI catalog and on the Internet.

Note

How to connect the SACIQ (SW) sensor connection cable to the terminal strip of an MIQ module is described in chapter 3 I of the IQ S

700 IQ SW. Information on this and other IQ SENSORNET

NSTALLATION

ENSORNET system operating manual.

3 - 10

Are the plug

connections dry?

Before connecting the sensor and sensor connection cable, please make sure that the plug connections are dry. If moisture gets into the plug connections, first dry the plug connections (dab them dry or blow them dry using compressed air).

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

SACIQ

Note

Do not suspend the sensor on the sensor connection cable. Use a sensor holder or an armature. Information on this and other

ENSORNET accessories is given in the YSI catalog and on the

IQ S Internet.

Connecting the sensor

to the sensor

connection cable

4 Take the protective caps off the plug connections of the sensor

and the SACIQ sensor connection cable, and keep them safe.

5 Plug the socket of the SACIQ (SW) sensor connection cable

onto the plug head connector of the sensor. At the same time, rotate the socket so that the pin in the plug head connector (1) clicks into one of the two holes in the jack.

6 Then screw the coupling ring (2) of the sensor connection

cable onto the sensor up to the stop.

Fig. 3-8 Connect the sensor

ba76040e02 07/2013

3 - 11

Commissioning ViSolid®700 IQ (SW)

3.5.2 Selecting the Measuring mode

Specify the following data in the Measuring mode setting

 Matrix type (1 or 2)

 Display (TSS or SiO2)

 Unit (mg/l or %)

Determining the matrix

type

Measurement in mg/l

TSS (total suspended

solids)

Measurement in mg/l

SiO2 (silicon dioxide)

Determine the matrix type for your application with the aid of the following table:

Measuring medium: Matrix type 1Matrix type

Outflow of preclarification X

Activated slurry X

Return slurry X

Primary slurry X

Sediment slurry X

Concentrated slurry X

Measuring medium: Matrix type 1Matrix type

SiO2 content: 0 ... 25000 mg/l X

SiO2 content: 15000 ... 300000 mg/l X

3 - 12

Note

If the matrix type for a measuring medium cannot be determined using this table, select matrix type 1 and then carry out a user calibration (see section 4.2.4). If the graph of the value pairs corresponds to one of the forms 1 to 3 (see section 4.2.4), matrix type 1 is suitable. If the graph of the value pairs corresponds to form 4, matrix type 2 must be selected.

Factory settings Measuring mode: Mtrx.type1:mg/l TSS

Measuring range: AutoRange

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

3.5.3 Setting tableViSolid®700 IQ (SW)

Setting Selection/values Explanation

Measuring mode (see section 3.5.2)

 Mtrx.type1:mg/l TSS

 Matrix type1:% TSS

 Mtrx.type2:mg/l TSS

 Matrix type2:% TSS

 Mtrx.type1:mg/l SiO2

 Matrix type1:% SiO2

 Mtrx.type2:mg/l SiO2

 Matrix type2:% SiO2

– Content of total suspended solids in mg/l

– Content of total suspended solids in %

– Content of total suspended solids in mg/l

– Content of total suspended solids in %

– Content of SiO

in mg/l

in %

in mg/l

in %

Signal averaging 1 ... 600 secs Response time of the signal filter.

Depending on the sample matrix, the measured values may oscillate more or less (e.g. due to foreign bodies or air bubbles). The signal filter reduces the limits of variation of the measured value. The signal filter is characterized by the signal averaging time. This is the time after which 90 % of a signal change is displayed.

Ultrasonic cleaning Ein / Ein

Aus / Ein Puls / Ein

Switches on or off the ultrasound cleaning and SenseCheck functions (Pulse = pulse operation).

Ein / Aus Aus / Aus Puls / Aus

Save and quit The system confirms the saving of the

settings and the display switches to the next higher level.

Quit The display switches to the next higher level

without saving the new settings.

TSS measuring mode:

 Default calibration The factory calibration data for TSS are used

(see section 4.2.2).

Calibration data

 User calibration User entered calibration data are used (see

section 4.2.4).

TSS measuring mode:

0.50 ... 2.00 The Correction factor setting enables a simple calibration (see section 4.2.3).

Correction factor

ba76040e02 07/2013

3 - 13

Commissioning ViSolid®700 IQ (SW)

Setting Selection/values Explanation

TSS measuring mode:

Menu selection: User calibration

 Basic settings

 Value pairs 1..3

 Value pairs 4..6

 Value pairs 7..8

Selection between the use of the basic settings and the entry of calibration value pairs.

For the selection of the value pairs, fields open for the entry of the values TSS value 1 to TSS value 8. and the individual values SiO2 value 1 to SiO2 value 8.

Starting with TSS value 1, determine and enter the content of total suspended solids in mg/l TSS, and, in the case of SiO2 value 1, enter the related measured SiO2 value.

The input precision is 1 mg/l in each case.

Note: The values must be entered in descending order. If this sequence is not kept to, a calibration error is displayed after leaving the menu. All the entered values become invalid.

TSS measuring mode:

Measuring ranges

The setting AutoRange = automatic changeover of the measuring range can be selected in all measuring modes.

 0 ... 400.0 mg/l

 0 ... 4000 mg/l

 0 ... 25000 mg/l

 0 ... 400.0 ppm

 0 ... 4000 ppm

 0 ... 2.500 %

 0 ... 4000 mg/l

 0 ... 40000 mg/l

 0 ... 4000 ppm

 0 ... 4.000 %

 0 ... 40.00 %

 0 ... 100.0 %

Measuring range for the measuring mode

Mtrx.type1:mg/l TSS

Measuring ranges for the Matrix type1:% TSS measuring mode

Measuring ranges for the Mtrx.type2:mg/l TSS measuring mode

Measuring ranges for the Matrix type2:% TSS measuring mode

3 - 14

ba76040e02 07/2013

ViSolid®700 IQ (SW) Commissioning

Setting Selection/values Explanation

Measuring mode SiO2:

Measuring ranges

 0 ... 400.0 mg/l

 0 ... 4000 mg/l

Measuring ranges for the Mtrx.type1:mg/l SiO2 measuring mode

 0 ... 25000 mg/l

Measuring ranges for the Matrix type1:% SiO2 measuring mode

The setting AutoRange =

 0 ... 400.0 ppm

 0 ... 4000 ppm

 0 ... 2.500 %

automatic changeover of the measuring range

 0 ... 4000 mg/l

 0 ... 40000 mg/l

Measuring ranges for the Mtrx.type2:mg/l SiO2 measuring mode

can be selected in all measuring modes.

 0 ... 4000 ppm

 0 ... 4.000 %

Measuring ranges for the Matrix type2:% SiO2 measuring mode

 0 ... 30.00 %

Carrying out settings Switch to the main settings menu from the measured value display with

<S>. Then navigate to the setting menu (setting table) of the sensor.

The exact procedure is described in the relevant IQ S

ENSORNET

system operating manual.

ba76040e02 07/2013

3 - 15

Commissioning ViSolid®700 IQ (SW)

3 - 16

ba76040e02 07/2013

ViSolid®700 IQ (SW) Measuring

4 Measuring

The ViSolid®700 IQ (SW) measures the light scattered and reflected by the total suspended solids in the measuring medium. The level of total suspended solids that corresponds to the amount of light measured is displayed. As different suspended solids scatter and reflect light in different ways, the display of a suspended solid contents in mg/l must be referred to a standard. A factory calibration to SiO2 is stored in the sensor.

4.1 Measuring operation

1 Immerse the sensor in the measuring medium.

2 Read the measured value on the terminal of the IQ S

ET system.

ENSOR

Note

Large temperature differences between the sensor and measuring medium can falsify the measurement result. Thus, as a precaution during commissioning, wait for 15 minutes before using the measured value.

Note

The allowed temperature of the measuring medium is 0 ... 60 °C. The ultrasound cleaning system automatically switches off if the temperature of the measuring medium increases to more than 60 °C. When the temperature drops below 60 °C, it switches itself on again. Switching off at temperatures above 60 °C prevents any overheating, for example if the minimum immersion depth of the sensor is not maintained.

ba76040e02 07/2013

4 - 1

Measuring ViSolid®700 IQ (SW)

4.2 Calibration for TSS measurement

4.2.1 General information

Why calibrate? The following factors can change with time and affect the measurement

results:

 the optical characteristics, e.g. color and particle size, and the

density of the measuring medium (e.g. dependent on the season)

 the conditions at the measuring location (e.g. due to growing

deposits on the ground and walls)

The effect of the measurement environment can be reduced by ensuring the optimum conditions (see section 3.3.1) and can be compensated by a user calibration (see section 4.2.4).

When to calibrate? A new calibration is required if there is any change of the

characteristics of the measuring medium or any change of the environment at the measuring location.

How is a calibration

carried out?

Note

Calibration data that are entered are stored in the controller and, thus, assigned to the measuring location (and not the sensor). Thus, if the sensor is replaced, no new calibration is required.

The actual level of total suspended solids of your measuring medium is determined by a reference measurement (e.g. gravimetric according to DIN 38414).

If the reference measurements do not deviate from the optically

determined level of total dissolved solids of the ViSolid

700 IQ (SW),

the sensor is already optimally adapted to the measuring situation.

If the reference measurements deviate from the optically determined

level of total dissolved solids of the ViSolid

700 IQ (SW), a calibration

is required.

The following calibration options are available:

 Calibration by adapting the Correction factor setting

if the values displayed with Default calibration deviate from the actual values by a specific factor

 Performance of a User calibration

if the values displayed with Default calibration and Correction factor no longer agree with the actual values

4 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Measuring

TS [1000 mg/l]

SiO2 [1000 mg/l ]

0,9

0,7

0,5

0,3

0,1

678910

4.2.2 Default calibration

Default calibration for

matrix type 1

The factory calibration curve for matrix type 1 was determined by measurements of typical activated and return slurries and can be used for similar applications after adaptation of the Correction factor setting (see section 4.2.3).

Note

Below the smallest value, the calibration curves are extended to the zero point and, above the largest value, they are extended to the end of the measuring range.

Value pairs 1 2 345678910

Total suspended solids

17.57 15.55 11.62 8.80 6.21 4.42 3.39 2.40 0.77 0.25

[1000 mg/l] TSS

SiO2 value

7.16 7.05 6.52 5.85 4.86 3.91 3.22 2.60 1.37 0.61

[1000 mg/l] SiO2

ba76040e02 07/2013

Fig. 4-1 Default calibration for matrix type 1

4 - 3

Measuring ViSolid®700 IQ (SW)

SiO2 [1000 mg/l ]

678910

TSS [1000 mg/l]

0,9

0,7

0,5

0,3

0,1

100

0,9

0,7

0,5

0,3

0,1

Default calibration for

matrix type 2

The factory calibration curve for matrix type 2 was determined by measurements of typical decaying slurries and can be used for similar applications after adaptation of the Correction factor setting (see section 4.2.3).

Value pairs 1 2 3 4 5 6 7 8 9 10

Total suspended solids

100 59.40 32.00 20.70 14.90 9.97 5.26 2.37 1.48 0.41

[1000 mg/l] TSS

SiO2 value

7.62 7.16 6.26 5.60 5.00 4.28 3.19 1.73 1.13 0.32

[1000 mg/l] SiO2

4 - 4

Fig. 4-2 Default calibration for matrix type 2

Influences If there is a low level of total suspended solids (< 2000 mg/l SiO2 or

< 1000 mg/l TSS), the effects of the measurement environment can simulate a higher content of total suspended solids. The effect of the measurement environment is minimized by exactly observing the installation position (see section 3.3.1).

If an optimum installation is not possible due to the structural conditions at the measuring location (e. g. in narrow pipelines), interference effects can be compensated by a User calibration (see section 4.2.4).

ba76040e02 07/2013

ViSolid®700 IQ (SW) Measuring

TSS [1000 mg/l]

SiO2 [1000 mg/l ]

0,9

0,7

0,5

0,3

0,1

Correction factor 1.00

Correction factor 0.50

FN = FA * SR/S

4.2.3 Correction factor

The setting of the Correction factor provides a simple option for adapting the calibration to the current conditions.

With the Correction factor setting you correct the measured value and have it indicated on the display.

A change of the Correction factor setting is practical if the measured

values of the ViSolid

700 IQ (SW) are generally too high or too low in

comparison to reference measurements by a specific factor.

ba76040e02 07/2013

Fig. 4-3 Effect of the Correction factor on the displayed measured value

The Correction factor is calculated using the following formula:

Variable Explanations

Correction factor, to be recalculated

Correction factor, currently set in the Calibration data menu

TSS value, newly determined from reference measurement

TSS value, newly determined from measurement with

ViSolid

700 IQ (SW)

4 - 5

Measuring ViSolid®700 IQ (SW)

FN = FA * SR/S

Determining the

Correction factor

1 Bring the sensor into the measuring position.

2 In the setting table of the TSS sensor, note down the currently

set Correction factor as the value for F

3 Switch to the measured value display with <M>.

4 When the measured value is stable, read the TSS value,

convert it into the unit (mg/l) if necessary, and note it down as the value for Sv.

5 Take a sample as close to the same time as the TSS

measurement as possible and as close to the sensor as possible.

6 Determine the level of total suspended solids of the sample

according to a reference procedure (e. g. gravimetric according DIN 38414), convert it into the unit (mg/l) if necessary, and note it down as the value for S

7 Calculate the Correction factor.

Setting the Correction

factor

8 Set the new Correction factor in the Calibration data menu (see

section 3.5.3).

Note

The Correction factor setting affects each TSS measuring mode and all calibration data. Also, if there is a change of the measuring mode or calibration data, the Correction factor is retained. Therefore, after every change of the settings in the Calibration data menu, check the Correction factor.

4 - 6

ba76040e02 07/2013

ViSolid®700 IQ (SW) Measuring

SiO2 [mg/l]

TSS [mg/l]

SiO2 [mg/l ]

TSS [mg/l]

SiO2 [mg/l ]

TSS [mg/l]

SiO2 [mg/l]

TSS [mg/l]

4.2.4 User calibration

The displayed values of total suspended solids are calculated with the aid of the stored calibration data. In the mg/l TSS measuring mode, the value mg/l SiO2 marked with "#" is displayed as the secondary measured value.

The determination of the calibration value pairs is carried out by reference measurements according to an independent procedure. At the point of time of the calibration, the measuring medium should be in a state representative of the later measurement (type and amount of total suspended solids, coloration, etc.). The results from the calibration

are manually entered in the setting table of the ViSolid

700 IQ (SW).

Effect of the

measurement

environment on the

graph of the value pairs

TSS (laboratory) - SiO2

(ViSolid

700 IQ (SW))

Graphs of the value pairs Explanations

Form 1:

The graph has a gradient > 0 at every point. A calibration is possible for the whole range.

Form 2: The graph has a gradient > 0 at every point. At very low levels of TSS, the effect of the measurement environment leads to slightly increased values of SiO2. A calibration is possible for the whole range.

Form 3: The graph has a gradient < 0 in the range of smaller levels of TSS. The effect of the measurement environment leads to greatly increased values of SiO2 in the range of smaller TSS below the point (A). A calibration is only possible in the range TSS > A.

ba76040e02 07/2013

Form 4: The graph has a gradient < 0 in the range of greater levels of total suspended solids. A calibration for matrix type 1 is only possible in the range of TSS < B. For measurements in the range of TSS > B, select matrix type 2.

4 - 7

Measuring ViSolid®700 IQ (SW)

Note

A measurement of the total suspended solids will deliver ever more accurate measurement results the closer the composition of the measuring medium corresponds to the status at the time of the calibration. If there is a fundamental change of the characteristics of the sample, a new calibration may be necessary.

Procedure of the

calibration

1 Bring the sensor into the measuring position.

2 In the setting table of the TSS sensor, select the

mg/l TSS measuring mode and the AutoRange measuring range (see section 3.5.3).

3 Switch to the measured value display with <M>.

4 When the measured value is stable, read the SiO2 value

(marked with "#"), convert it into the unit (mg/l) if necessary, and note it down.

5 Take a sample as close to the same time as the SiO2

measurement as possible and as close to the sensor as possible.

6 Determine the level of total suspended solids of the sample

according to a reference procedure (e.g. gravimetric according to DIN 38414) and note it down together with the measured value of SiO2 as the TSS/SiO2 value pair in mg/l.

Note

At least one value pair and a maximum of eight value pairs can be entered for a valid calibration. Keeping to the descending order of values is very important. Not keeping to the order will result in a calibration error.

4 - 8

7 For a multi-point calibration:

Repeat the determination of the value pair for various concentrations of the sample.

Note

Samples of different concentrations of total suspended solids can be obtained from the sample taken by:

 diluting it with water

 depositing the total suspended solids and decanting off the

remaining water

Before measuring the samples, make sure that the total suspended solids are actually in suspension.

ba76040e02 07/2013

ViSolid®700 IQ (SW) Measuring

8 Sort the value pairs in descending order and, if necessary,

enter them in a table and diagram (see chapter 10).

Note

Below the smallest value, the calibration curve is extended to the zero point and, above the largest value, it is extended to the end of the measuring range.

9 Check the form of the calibration curve.

If the calibration curve corresponds to form 3,

 change the conditions at the measuring location and

determine the calibration values again or

 do not carry out any measurements in the range below the

turning point (A).

10 In measuring mode with matrix type 1:

If individual calibration values lie outside the measuring range,

Entering the Calibration

data

 change the conditions at the measuring location and

determine the calibration values again or

 select measuring mode for matrix type 2

Note

The entry of calibration values that exceed the measuring range leads to a calibration error. The size of the measuring range is dependent on the selected measuring mode (matrix type) (see section 3.5.3).

11 Switch to the setting table of the TSS sensor.

12 Change to the Calibration data menu with <> and

<OK>.

13 Select the User calibration menu item with <> and

<OK>.

14 Select the Menu selection menu item with <> and

<OK>.

15 Select the Value pairs 1..3 menu item with <> and

<OK>.

ba76040e02 07/2013

Note

For examples of valid value pair data, see section 4.2.2. A maximum of 8 value pairs can be entered for the User calibration.

4 - 9

Measuring ViSolid®700 IQ (SW)

16 Select the TSS value 1 menu item with <> and <OK>.

17 Enter the value for the contents of total suspended solids (TSS

in mg/l) from the reference measurement with <> and <OK>.

18 Select the SiO2 value 1 menu item with <> and <OK>.

Results after entry of

Calibration data

19 Enter the associated SiO2 value (SiO2 in mg/l) measured with

the ViSolid

700 IQ (SW) with <> and <OK>.

20 Repeat steps 13 - 18 until the required number of value pairs

(between 1 and 8) has been entered.

21 Terminate the entry of the calibration data with Save and quit.

Note

To simplify the settings when entering the calibration data, standardized high resolutions of 1 mg/l are possible. However, it is not sensible to use these in all cases.

The calibration data entered are evaluated by the system. The entry of the calibration value pairs can have the following results:

Possible displays Log book entries

(meaning/actions)

Measured value display Successful new valid calibration value pairs

were entered for the sensor.

"----" Calibration value pairs not accepted.

Sensor blocked for measurement.

4 - 10

– Enter the values again making sure that

they are entered in descending order

– Viewing the log book entry.

Note

Information on the contents and structure of the log book and how you can call it up is given in the L

OG BOOK chapter of the IQ SENSORNET

system operating manual.

ba76040e02 07/2013

ViSolid®700 IQ (SW) Maintenance, cleaning, accessories

5 Maintenance, cleaning, accessories

5.1 General information

WARNING

Contact with the sample can be dangerous for the user! Depending on the type of sample, suitable protective measures must be taken (protective clothing, protective goggles, etc.).

The ViSolid maintenance. The continuously running ultrasound system prevents the accumulation of pollution right from the start.

Note

If the sensor remains in the sample for any length of time when the system is not operating, we recommend to clean the shaft and measurement windows.

700 IQ (SW) sensor does not usually require any

Cleaning agents

5.2 Cleaning the sensor shaft and measurement windows

During normal operation (e.g. municipal wastewater), cleaning is recommended:

 if there is any pollution (according to visual check)

 if the sensor was not in operation for a lengthy period of time but was

immersed in the measuring medium

 if the measured values are suspected of being incorrect (usually too

low)

 if the SensCheck message appears in the log book (when using

samples of matrix type 1)

 for regular cleaning (when using samples of matrix type 2)

 if there is any suspicion that the measurement window is polluted,

e.g. by dried on dirt during operation in the open air

Contamination Cleaning agents

Sludge and loosely adhering dirt or biological films

Soft cloth or soft brush, warm tap water with detergent

ba76040e02 07/2013

Salt and / or lime deposits Acetic acid (volume percentage

= 20 %), soft cloth or soft sponge

CAUTION

Acetic acid irritates the eyes and the skin. When handling acetic acid, always wear protective gloves and protective goggles.

5 - 1

Maintenance, cleaning, accessories ViSolid®700 IQ (SW)

Note

We do not recommend unscrewing the sensor from the sensor connection cable when cleaning the sensor shaft and measurement window. Otherwise, moisture and/or dirt can get into the plug connection where it can cause contact problems.

If you need to disconnect the sensor from the sensor connection cable, please note the following points:

 Before disconnecting the sensor from the SACIQ (SW) sensor

connection cable, remove any larger pieces of contamination from the sensor, particularly in the area of the plug connection (brush it off in a bucket of tap water, wash it off with a hose or wipe it off with a cloth).

 Unscrew the sensor from the SACIQ (SW) sensor connection cable.

 Always place a protective cap on the plug head of the sensor and on

the SACIQ (SW) sensor connection cable so that no moisture or dirt can get into the contacting surfaces. It is included in the standard scope of delivery of the SACIQ SW sensor connection cable.

Cleaning

 In corrosive environments, close the socket of the sensor

connection cable with the screwable SACIQ-Plug when it is dry in order to protect the electrical contacts from corrosion. The protective plug is available as an accessory (see section 5.3 A

CCESSORIES).

CAUTION

1 Pull the sensor out of the sample.

2 Remove any coarse pollution from the sensor (by brushing it off

in a bucket of tapwater, spraying it off with a hose or wiping with a cloth).

3 Clean the sensor shaft and the measurement window as

described in the section C

4 Then, rinse it thoroughly with tap water.

LEANING AGENTS.

5 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Maintenance, cleaning, accessories

5.3 Accessories

Description Model Order no.

Screwable plug for sensor connection cable

Note

Information on other IQ S

ENSOR NET accessories is given in the YSI

catalog and on the Internet.

SACIQ-Plug 480 065Y

ba76040e02 07/2013

5 - 3

Maintenance, cleaning, accessories ViSolid®700 IQ (SW)

5 - 4

ba76040e02 07/2013

ViSolid®700 IQ (SW) What to do if ...

6 What to do if ...

Mechanical damage to

the sensor

Display always shows

"0"

TSS display does not

correspond to the TSS

value according to the

laboratory

determination

Cause Remedy

– Return the sensor

Cause Remedy

– First calibration value pair

incomplete

– Enter the TSS value for the

first calibration value pair

Cause Remedy

– Correction factor incorrectly set – Set up the correction factor

again: Correction factor = TSS value (laboratory) / TSS value (display)

Display of OFL

Display of "----"

Display of main

parameter TSS: "----"

Secondary parameter

SiO2: "OFL"

Cause Remedy

– Measuring range exceeded

– First calibration value pair

incomplete

– Two identical SiO2 values

entered one after the other

– See log book

– Enter the SiO2 value for the

first calibration value pair

– Enter the value pairs in

descending order

Cause Remedy

– Measured value invalid

– Incorrect calibration value

entered

– See log book

– Correct the calibration

values and enter them again

Cause Remedy

– The optical measuring range for

SiO2 is exceeded. The display of a valid TSS measured value is

– See log book

(message code EA6243, see section 8.1.1)

not possible.

ba76040e02 07/2013

6 - 1

What to do if ... ViSolid®700 IQ (SW)

Measured value

Cause Remedy

fluctuating heavily

– There are bubbles of gas in the

medium in front of the measurement windows

– Check the installation

position of the sensor (see section 3.3 and section 3.4)

Measured values too low

Measured values too

high

– Signal averaging time too short

for low values of total suspended

– Increase signal averaging

time

solids

– Inhomogeneous measuring

medium

Cause Remedy

– Measurement window dirty – Clean the measurement

window (see section 5.2)

Cause Remedy

– There are bubbles of gas in the

medium in front of the measurement windows

– Check the installation

position of the sensor (see section 3.3 and section 3.4)

– Light scattering on the walls – Check the installation

position of the sensor (see section 3.3 and section 3.4)

– If necessary, compensate

for any effects that cannot be cleared by calibration

6 - 2

– Measurement window dirty – Clean the measurement

window (see section 5.2)

ba76040e02 07/2013

ViSolid®700 IQ (SW) Technical data

7 Technical data

7.1 Measuring characteristics

Measuring principle Procedure for measuring scattered light.

Measurement in following units:

 mg/l TSS (total suspended solids)

 % TSS (total suspended solids)

Measuring ranges and

resolutions

 mg/l SiO

 % SiO

Measured parameter Measuring ranges Resolution

mg/l TSS 0 ... 400.0 mg/l

0 ... 4000 mg/l 0 ... 25000 mg/l 0 ... 40000 mg/l

% TSS 0 ... 400.0 ppm

0 ... 4000 ppm 0 ... 2.500 % 0 ... 4.000 % 0 ... 40.00 % 0 ... 100.0 %

mg/l SiO

0 ... 400.0 mg/l 0 ... 4000 mg/l 0 ... 25000 mg/l 0 ... 40000 mg/l

% SiO

0 ... 400.0 ppm 0 ... 4000 ppm 0 ... 2.500 % 0 ... 4.000 % 0 ... 30.00 %

0.1 mg/l 1 mg/l 1 mg/l 1 mg/l

0.1 ppm 1 ppm

0.001 %

0.01%

0.1%

0.1 mg/l 1 mg/l 1 mg/l 1 mg/l

0.1 ppm 1 ppm

0.001 %

0.01 %

ba76040e02 07/2013

7 - 1

Technical data ViSolid®700 IQ (SW)

7.2 Application characteristics

Allowed

Measuring medium 0 °C ... + 60 °C (32 ... 140 °F)

temperature range

Storage/transport - 5 °C ... + 65 °C (23 ... 149 °F)

Allowed pH range of the

4 ... 12

measuring medium

Pressure resistance Sensor with connected SACIQ (SW) sensor connection cable:

Max. allowed overpressure 106 Pa (10 bar)

Max. allowed underpressure temporarily 5 x 10

The sensor fulfills all requirements according to article 3(3) of the directive 97/23/EC ("pressure equipment directive").

Type of protection Sensor with connected SACIQ (SW) sensor connection cable:

IP 68, 10 bar (10

Pa)

Depth of immersion min. 10 cm; max. 100 m depth

Operating position see section 3.3 I

NSTALLATION

Pa (0,5 bar)

Fields of application Water and wastewater monitoring

7 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Technical data

365

Socket SACIQ...

59.5

40.0

204

ViSolid 700 IQ SW:

ViSolid 700 IQ:

365

7.3 General data

Dimensions (in mm)

Weight (without sensor

Connection technique Connection using SACIQ (SW) sensor connection cable

connection cable)

Material

ViSolid® 700 IQ approx. 990 g

VisoTurb

700 IQ SW approx. 1420 g

Shaft:

– ViSolid

700 IQ

700 IQ SW

V4A stainless steel 1.4571 *

POM

Sensor head:

– ViSolid

700 IQ

700 IQ SW

V4A stainless steel 1.4571 *

Titanium

Measurement window Sapphire

Plug head connector housing POM

Plug, 3-pole ETFE (blue) Tefzel

* Stainless steel can be susceptible to corrosion at chloride concentrations of ≥ 500 mg/l and more. We recommend to use SW sensors for applications in such test solutions.

ba76040e02 07/2013

7 - 3

Technical data ViSolid®700 IQ (SW)

Material

Shaft V4A stainless steel 1.4571 *

Measurement window Sapphire

Plug head connector housing POM

Plug, 3-pole ETFE (blue) Tefzel

* Stainless steel can be susceptible to corrosion at chloride concentrations of ≥ 500 mg/l and more.

Cleaning system Ultrasound principle

Automatic sensor

monitoring

(SensCheck function)

Instrument safety

 Identification of any measurement fault (in matrix type 1)

 Identification of any failure of the cleaning system

Applicable norms – EN 61010-1

– UL 3111-1

– CAN/CSA C22.2 No. 1010.1

7.4 Electrical data

Nominal voltage max. 24 VDC

via the IQ S see chapter the IQ S operating manual)

Power consumption 1.5 W

Protective class III

ENSORNET (details

ENSORNET system

TECHNICAL DATA of

7 - 4

ba76040e02 07/2013

ViSolid®700 IQ (SW) Indexes

8Indexes

8.1 Explanation of the messages

This chapter contains a list of all the message codes and related message texts that can occur in the log book of the IQ S

system for the ViSolid

700 IQ (SW) sensor.

Note

Information on

 the contents and structure of the log book and

 the structure of the message code

ENSORNET

is given in the L

OG BOOK chapter of the IQ SENSORNET system

operating manual.

Note

All message codes of the ViSolid

"342".

8.1.1 Error messages

Message code Message text

EA2342 Sensor temperature too high!

* Check process and application

EA3342 Sensor temperature too low!

* Check process and application

EA6342 Meas. range exceeded or undercut

* Check process * Select other meas. range * Submerse sensor in sample * Select bubble-free spot for measurement * Remove any foreign matter from sensor * Avoid influence of large foreign matter * Clean sensor * Increase signal average time

700 IQ (SW) end with the number

EA7342 Ultrasound cleaning system switched off

* Check sample temperature * Submerse sensor in sample

ba76040e02 07/2013

8 - 1

Indexes ViSolid®700 IQ (SW)

Message code Message text

EC2342 User calibration error,

check TSS/SiO2 pairs of variates * All TSS values within measuring range? (see operating manual) * At least one value pair entered? * All TSS and SiO2 values entered? * All TSS/SiO2 pairs in descending order? * Pair 1 = highest TSS and SiO2 value?

EI1342 Operational voltage too low

* Check installation and cable lengths, Follow installation instructions * Power unit(s) overloaded, add power unit(s) * Defective components, replace components

EI2342 Operational voltage too low, no operation possible

* Check installation and cable lengths, Follow installation instructions * Power unit(s) overloaded, add power unit(s) * Check terminal and module connections * Defective components, replace components

ES1342 Component hardware defective

* Contact service

ESD342 SensCheck: Measurement interfered

* Submerse sensor in sample * Select bubble-free spot for measurement * Remove any foreign matter from sensor * Avoid influence of large foreign matter * Clean sensor * Increase signal average time

ESE342 SensCheck: Ultrasound cleaning system has failed

* Return sensor for repair

8.1.2 Info messages

Message code Message text

IA1342 Ultrasound cleaning system switched on

* Check sensor visually * Clean sensor if necessary

8 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Indexes

8.2 Status info

The status info is a piece of coded information about the current state of a sensor. Each sensor sends this status info to the controller. The status info of sensors consists of 32 bits, each of which can have the value 0 or 1.

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Status info,

general structure

ViSolid

700 IQ (SW)

1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (general)

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 (internal)

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

The bits 0 - 15 are reserved for general information. The bits 16 - 21 are reserved for internal service information.

You obtain the status info:

 via a manual query in the menu, Einstellungen/Setup/Service/List of

all components (see system operating manual)

 via an automated query

– of a superordinate process control (e. g. when connected to the

Profibus)

– of the IQ Data Server (see operating manual of the

ENSORNET software pack)

IQ S

Note

The evaluation of the status info, e.g. in the case of an automated query, has to be made individually for each bit.

Status bit Explanation

Status info

ba76040e02 07/2013

Bit 0 Component hardware defective

Bit 1 SensCheck: Measurement interfered

Bit 2 SensCheck: Ultrasound cleaning system has

failed

Bit 3-31 -

8 - 3

Indexes ViSolid®700 IQ (SW)

8 - 4

ba76040e02 07/2013

ViSolid®700 IQ (SW) Contact Information

9 Contact Information

9.1 Ordering & Technical Support

Telephone

: (937) 767-1058

Fax

Mail: YSI Incorporated

Internet

When placing an order please have the following information available:

YSI account number (if available) Name and Phone Number Model number or brief description Billing and shipping address Quantity Purchase Order or Credit Card

: (800) 897-4151

(937) 767-7241 Monday through Friday, 8:00 AM to 5:00 PM ET

: environmental@ysi.com

1725 Brannum Lane Yellow Springs, OH 45387 USA

: www.ysi.com

9.2 Service Information

YSI has authorized service centers throughout the United States and Internationally. For the nearest service center information, please visit

www.ysi.com

directly at 800-897-4151.

When returning a product for service, include the Product Return form with cleaning certification. The form must be completely filled out for an YSI Service Center to accept the instrument for service. The Product Return form may be downloaded at www.ysi.com ‘Support‘ tab.

and click ‘Support’ or contact YSI Technical Support

and clicking on the

ba76040e02 07/2013

9 - 1

Contact Information ViSolid®700 IQ (SW)

9 - 2

ba76040e02 07/2013

ViSolid®700 IQ (SW) Appendix

TS [1000 mg/l]

SiO2 [1000 mg/l]

0,9

0,7

0,5

0,3

0,1

02468101214161820

10 Appendix

10.1 Check calibration values

By checking the value pairs, possible calibration errors can already be avoided before the entry of the calibration value pairs.

Carry out a check using the EC2342 message text:

* All TSS values within measuring range? (see operating manual) * At least one value pair entered? * All TSS and SiO2 values entered? * All TSS/SiO2 pairs in descending order? * Pair 1 = highest TSS and SiO2 value?

Sequence Max. value -> Min. values

Value pairs 12345678

Total suspended solids [mg/l] TSS

SiO2 value [mg/l] SiO2

Note

For examples of valid value pair data, see section 4.2.2.

ba76040e02 07/2013

The graph of the value pairs must not contain any turning point in the required measuring range (see section 4.2.4).

10 - 1

Appendix ViSolid®700 IQ (SW)

10 - 2

ba76040e02 07/2013

1) The tissue in plants that brings water upward from the roots;

2) a leading global water technology company.

We're 12,500 people unified in a common purpose: creating innovative solutions to meet our world's water needs. Developing new technologies that will improve the way water is used, conserved, and re-used in the future is central to our work. We move, treat, analyze, and return water to the environment, and we help people use water efficiently, in their homes, buildings, factories and farms. In more than 150 countries, we have strong, long-standing relationships with customers who know us for our powerful combination of leading product brands and applications expertise, backed by a legacy of innovation.

For more information on how Xylem can help you, go to www.xyleminc.com

Xylem |' m|zīlə

YSI 1725 Brannum Lane Yellow Springs, OH 45387 Tel: +1 937-767-7241; 800-765-4974 Fax: +1 937-767-1058 Email: environmental@ysi.com Web: www.ysi.com

©Xylem Inc

Xylem ViSolid 700 IQ User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1Overview

1.1 How to use this component operating manual

1.2 Structure of the ViSolid®700 IQ (SW) total suspended solids sensor

1.3 Recommended fields of application

1.4 Features of the ViSolid®700 IQ (SW)

2 Safety instructions

2.1 Authorized use

2.2 General safety instructions

3 Commissioning

3.1 IQ SENSORNET system requirements

3.2 Scope of delivery

3.3 Installation

3.3.1 General information

3.3.2 Flow direction

3.3.3 Sensor angle

3.3.4 Sensor orientation

3.3.5 Distances from the ground and wall

3.4 Installation examples

3.4.1 Measurement in an open pool or channel

3.4.2 Measurement in pipelines

3.5 Commissioning / Readiness for measuring

3.5.1 Connect the sensor

3.5.2 Selecting the Measuring mode

3.5.3 Setting tableViSolid®700 IQ (SW)

4 Measuring

4.1 Measuring operation

4.2 Calibration for TSS measurement

4.2.1 General information

4.2.2 Default calibration

4.2.3 Correction factor

4.2.4 User calibration

5 Maintenance, cleaning, accessories

5.1 General information

5.2 Cleaning the sensor shaft and measurement windows

5.3 Accessories

6 What to do if ...

7 Technical data

7.1 Measuring characteristics

7.2 Application characteristics

7.3 General data

7.4 Electrical data

8Indexes

8.1 Explanation of the messages

8.1.1 Error messages

8.1.2 Info messages

8.2 Status info

9 Contact Information

9.1 Ordering & Technical Support

9.2 Service Information

10 Appendix

10.1 Check calibration values
