Xylem HYDROVAR HV 4.030, HYDROVAR HV 4.055, HYDROVAR HV 4.022, HYDROVAR HV 2.022, HYDROVAR HV 4.075 Operating Instructions Manual
...
Operating Instructions
V 20
12/03A-V01.4
771079412 Manual HV 2.015-4.220 ENGLISH
HV 2.015 / 2.022
HV 4.022 / 4.030 / 4.040
HV 4.055 / 4.075 / 4.110
HV 4.150 / 4.185 / 4.220
3
Index
1 Important safety instructions...................................................................................5
2 System design ...........................................................................................................8
2.1 Pressure tank ................................................................................................8
3 Product overview......................................................................................................9
3.1 Hardware configurations .............................................................................9
3.2 Operating modes..........................................................................................9
3.2.1 Actuator (for SINGLE pump operation only!) .......................................................... 9
3.2.2 Controller................................................................................................................ 9
3.2.3 Cascade Serial / Synchronous (not for SINGLE version).......................................... 10
3.2.4 Cascade Relay (not for SINGLE version)................................................................. 12
4 Type designation code............................................................................................13
5 Technical Data.........................................................................................................14
5.1 General technical data ...............................................................................15
5.2 EMC requirements (Electromagnetic compatibility)..................................16
6 Dimensions and weights ........................................................................................17
7 Modules 20
8 Mechanical components .........................................................................................22
8.1 Included mounting material ......................................................................22
8.2 Optional components.................................................................................22
8.2.1 Mounting accessories ........................................................................................... 22
8.2.2 Sensors ................................................................................................................. 22
8.2.3 Filter ..................................................................................................................... 22
• Line-coils ........................................................................................................................... 22
8.2.4 Cable entry (only HV4.150 – 4.220) ...................................................................... 22
8.2.5 Ready-made motor cables..................................................................................... 22
8.3 Assembly instructions ................................................................................23
9 Electrical installation and wiring ............................................................................25
9.1 Means of protection...................................................................................25
9.2 EMC-electromagnetic compatibility...........................................................26
9.3 Recommended Cable Types .......................................................................27
9.4 Wiring and connections .............................................................................28
9.4.1 Main voltage terminals ......................................................................................... 29
9.4.2 Motor connection................................................................................................. 30
9.4.3 Power unit ...................................................... Errore. Il segnalibro non è definito.
9.4.3.1 Solo run................................................................................................. 32
9.4.3.2 Addressing............................................................................................. 34
9.4.4 RFI – switch........................................................................................................... 36
9.4.5 Control unit .......................................................................................................... 37
9.4.5.1 Control card – HYDROVAR MASTER Inverter .......................................... 37
9.4.5.2 Relay Card.............................................................................................. 44
4
9.4.5.3 Control card – HYDROVAR SINGLE Inverter (not for HV 4.150 – HV
4.220) 46
10 Programming ........................................................................................................49
10.1 Display – Control panel of the MASTER / SINGLE Inverter .........................49
10.2 Function of the push buttons ....................................................................49
10.3 Display of the BASIC Inverter .....................................................................50
10.4 Software parameters..................................................................................51
00 MAIN MENU ....................................................................................................51
20 SUBMENU STATUS ...........................................................................................56
40 SUBMENU DIAGNOSTICS .................................................................................59
60 SUBMENU SETTINGS........................................................................................60
0100 SUBMENU BASIC SETTINGS .........................................................................61
0200 SUBMENU CONF INVERTER..........................................................................64
0300 SUBMENU REGULATION ..............................................................................72
0400 SUBMENU SENSOR ......................................................................................74
0500 SUBMENU SEQUENCE CNTR. .......................................................................77
0600 SUBMENU ERRORS ......................................................................................82
0700 SUBMENU OUTPUTS ....................................................................................83
0800 SUBMENU REQUIRED VALUES .....................................................................84
0900 SUBMENU OFFSET .......................................................................................86
1000 SUBMENU TEST RUN....................................................................................89
1100 SUBMENU SETUP .........................................................................................90
1200 SUBMENU RS485-INTERFACE.......................................................................91
11 Failure messages...................................................................................................92
11.1 BASIC Inverter.............................................................................................93
11.2 MASTER / SINGLE Inverter ..........................................................................94
11.3 Internal errors.............................................................................................97
Maintenance ..............................................................................................................99
Programming flow chart ........................................................................................ 100
Follow the pump operating and maintenance instructions
We reserve the right to alter specifications
5
1 Important safety instructions
Read and follow the operating and safety instructions carefully
before starting operations!
All modifications must be done by qualified technicians!
Warning that failure to observe the precaution may cause electric shock
Warning that failure to observe the precaution may cause personal injury or
damage to property.
In addition to these operating instructions please pay attention to universal safety
and accident prevention regulations.
Basically the HYDROVAR must be disconnected from the power supply before any work can
be carried out on the electrical or mechanical part of the system.
Installation, maintenance and repair work may be carried out only by trained, skilled and
qualified personnel.
Unauthorized modification or changes to the system make all guarantees null and void.
During operation, the motor can be stopped by opening a digital input or manual
operation whereby the HYDROVAR and the motor remain under voltage. For safety
reasons, the HYDROVAR has to be disconnected from the power supply when carrying out
work on the machinery.
When the HYDROVAR is connected to the power supply, the components of
the power unit as well as certain components of the control unit are
connected directly to mains.
Touching these components seriously endangers life!
Before removing the HYDROVAR cover the system must be disconnected from
the power supply. After switching off the power supply wait
at least 5 minutes before starting work on or in the HYDROVAR (the
capacitors in the intermediate circuit are discharged by the internal discharge
resistors).
Voltages of up to 800 volts are possible (in case of error these also can be
higher)
6
All work, carried out on the HYDROVAR, may only be performed by
qualified and authorized staff.
Furthermore, take care not to short circuit the neighbouring
components when connecting the external control wires. All cable ends which
are not in use have to be isolated.
The HYDROVAR contains electronic safety devices which switch off the control
element in the event of a fault, whereby the motor has zero current but
remains energised and comes to a halt. The motor can also be halted by
mechanical blocking. If it is switched off electronically the motor is current
less from the mains voltage through the electronics of the HYDROVAR but is
not potential-free in the circuit.
In addition voltage fluctuations, especially power failures can cause the
system to switch itself off.
Repair of faults can cause the motor to start up again automatically!
The system may only be put into operation when it has been grounded.
In addition to that, equipotential bonding of all conductive pipes must be
ensured.
Please consider local installation standards!
High voltage tests of the HYDROVAR or the motor may damage the
electronic components! Hence bridge the in- and outgoing
terminals L1 - L2 - L3 / U-V-W before.
To avoid incorrect metering by capacitors incorporated in the electronic
part isolate the motor from the HYDROVAR.
The operating instructions must be read, understood and
followed by the operating personnel. We point out that we
accept no liability for damage and operating disorders
which are the result of non-compliance with the operating
instructions.
7
Transport, handling, storage, disposal:
• Check the HYDROVAR immediately after delivery/receipt for damage or missing parts
• The HYDROVAR unit must be transported carefully.
• Avoid serious impacts
NOTICE!
Dispose of all packing materials and the HYDROVAR unit in accordance with
local regulations. For more detailed information about the recycling of this
product, please contact your local authority, your waste disposal service
provider or the outlet where you purchased the product.
CAUTION!
Lifting aids (stacker, crane, crane mounting device, lifting blocks, sling
ropes, etc.) must be suitable to handle the weight of the HYDROVAR.
CAUTION!
It is not allowed to carry the HYDROVAR around by using the connected
cables.
Do not damage the cable during transport (do not squeeze, bend or drag).
The cable ends must be kept dry.
WARNING!
• Do not stand underneath suspended loads
• Take note of the general regulations on prevention of accidents
• The HYDROVAR must be secured against tipping over and slipping until
it has been fixed in its final location.
8
2 System design
The following diagrams show typical SINGLE and multi-pump systems using the
HYDROVAR. Connection can be made directly to a water supply. In such a case, the use of a
low pressure switch on the suction is recommended.
SINGLE pump layout Multi pump layout
(1) pump with HYDROVAR
(2) diaphragm tank
(3) distribution panel
(4) gate valve
(5) non return valve
(6) low water control
(7) pressure gauge
(8) pressure transmitter
(9) drain tap
2.1 Pressure tank
A diaphragm pressure tank is used on the discharge side of the pump to maintain pressure
in the line when there is no water demand. This avoids the pump from continuing to run at
zero demand. With the HYDROVAR, no large tanks are required for supply purposes.
The tank must be permitted and suitable for systems pressure. The tank should have a
capacity of min. 10% of the maximum system flow rate [l/min] of one pump (also valid for
multi-pump system).
Example:
Maximum flow rate of the pump = 250 litres per minute
Minimum volume of the tank = 250 x 0.10 = 25 litres
The pre-charge pressure of the tank can be determined by using the following table:
NOTICE:
To check and set the right pre-charge pressure, please reduce the water
pressure to zero by turning the HYDROVAR off.
required pressure [bar]
pre-charge pressure [bar]
9
3 Product overview
3.1 Hardware configurations
The HYDROVAR modular concept basically consists of two main parts: the power unit and
the control card. In its BASIC configuration (consisting of only the power unit) the
HYDROVAR can be used as so called BASIC Inverter. In that configuration the HYDROVAR
can be used as a sequence pump in a multi pump system, but also as a simple soft starter
for SINGLE pump applications.
By attaching one of the additional control cards to the BASIC Inverter the HYDROVAR can
be upgraded either to the so called SINGLE or the MASTER Inverter.
BASIC Inverter – HYDROVAR BASIC unit (not available for HV 4.150 – 4.220).
Application:
- Sequence pump in a multi pump system, SINGLE pump operation as soft-starter
SINGLE Inverter – HYDROVAR BASIC Inverter with included control card for SINGLE pump
operation. This SINGLE Inverter is not able to support any optional modules like the Relay
Card.
Application:
- Simple SINGLE pump applications
MASTER Inverter – HYDROVAR BASIC Inverter including the high level control card
(supports also the optional modules like the Relay Card and all specific software features).
Application:
- SINGLE pump control including all extended features
- Multi pump system of MASTER and BASIC Inverters (up to 8 pumps)
- Multi pump system equipped with up to 8 MASTER Inverters
- Control of up to 5 fixed speed pumps when used in combination with the optional relay
card
3.2 Operating modes
3.2.1 Actuator (for SINGLE pump operation only!)
In this mode the HYDROVAR operates as an actuator according an external speed signal or
continuous operation on either one or two programmed frequencies by using the
corresponding digital input.
Please consider that this mode is only possible with a HYDROVAR MASTER or SINGLE
Inverter and is limited for SINGLE pump operation only
3.2.2 Controller
This mode is set as default operating mode and is used for a HYDROVAR in SINGLE pump
operation when there is no connection to any other HYDROVAR via the internal RS485
interface.
10
3.2.3 Cascade Serial / Synchronous (not for SINGLE version)
In these modes various combinations among the versions BASIC and MASTER Inverter are
possible.
In general each of the pumps needs to be equipped with a HYDROVAR unit. All the units
are connected via the RS485 interface and communicate via the standard MODBUSprotocol (9600 Baud, RTU, N81).
To realise a fully controlled system at least one MASTER Inverter is needed, the remaining
pumps could be fitted just with a BASIC Inverter.
The controller in the MASTER Inverter is continuously in communication with all the BASIC
Inverters. All failures are indicated on the MASTER including the date and time.
All the control is done by the MASTER Inverter including automatic change over of the lag
pumps to provide even wear and achieve even operating hours.
If the control card of a MASTER Inverter fails, each of the BASIC Inverters can be manually
started by an external switch (manual operation) in order to ensure an emergency
operation of the system.
Application Example
Each pump of the system (up to 8 pumps) is equipped with a HYDROVAR unit (at least one
MASTER Inverter and remaining ones can be BASIC Inverters). All units are connected via
the serial interface (RS485).
The combination of the different HYDROVAR units which are used in a multi-pump-system
depends on the system requirements (i.e. in a 6 pump system 2 MASTER Inverters can be
used due to reliability reasons and 4 BASIC Inverters without control card – or just any
other combination).
Minimum requirement: 1 MASTER Inverter and the other pumps equipped with BASIC
Inverters
11
To increase the operating reliability of such a system, also a second MASTER Inverter is
recommended:
Full-featured possibility: Each pump is equipped with a MASTER Inverter
In this mode it is possible to run all pumps in cascade serial mode and synchronous mode
as well.
This configuration allows each pump of the system to become the lead pump. This also
ensures a proper operation if one MASTER Inverter fails. In this case another HYDROVAR
takes control. This ensures that the operating hours of each pump will be the same to
ensure even wear of the pumps.
12
3.2.4 Cascade Relay (not for SINGLE version)
One pump is fitted with a HYDROVAR MASTER Inverter and up to 5 slave pumps can be
switched ON and OFF on demand. For this purpose an additional relay card including 5
relays is attached to the MASTER Inverter.
However an external switchboard is needed for all the motor relays as the relays in the
HYDROVAR are not able to switch the pumps directly (just used as control contacts).
Also an automatic change over of the fixed speed pumps to provide even wear and achieve
even operating hours is possible in this mode.
This configuration is a cost effective alternative compared with other solutions using VFD’s
on each pump, but in any case care has to be taken due to the lower reliability of such a
system.
Application example
Booster sets up to 6 pumps where only one pump is speed controlled by the HYDROVAR
and the others are fixed speed (1 HYDROVAR MASTER Inverter+5 fixed speed).
13
4 Type designation code
Software version
Language
1 = Western Europe resp. all lang.
(with V01.4)
3 = Eastern/Northern Europe
Hardware version
Optional components
Optional card
Relay Card (0= without / R= included)
Bus card
Display (0= without / 1= included)
EMC protection filter
A = A- Filter (industrial environment)
B = B- Filter (domestic environment)
Enclosure class (IP Class)
2= IP 21
5= IP 55
Hardware configurations
M = Motor mounted unit
W = Wall mounted unit
1= BASIC Inverter
2= SINGLE Inverter
3= MASTER Inverter
Rated output
022= 2,2 kW 055= 5,5 kW
030= 3,0 kW 075= 7,5 kW
040= 4,0 kW 110= 11kW
150=15,0kW 185=18,5kW 220=22,0kW
Nominal mains voltage
1= 1~/1~ 230VAC 3= 3~/3~ 230VAC
2= 1~/3~ 230VAC 4= 3~/3~ 380-460VAC
Example
The mentioned HYDROVAR in this example is specified with following technical data:
Nominal mains voltage: 3~/3~ 380-460VAC
Rated output: 4 kW
Hardware configurations: Motor mounted unit - MASTER Inverter
Enclosure class: IP 55
EMC-filter: B - Filter (domestic environment)
Optional components: Display, Relay Card
Hardware version: G
Language: 1 (Western Europe) respectively all languages
Software version: V01.4
HV . - - - - - - - .
HV 4 . 0 4 0 - M 3 - 5 - B - 1 0 R 0 - G- 1 - V 0 1 . 4
14
5 Technical Data
HYDROVAR
Incoming power supply (data only for dimensioning of the power
supply line and not for calculating the efficiency of the HV)
type rated
output
Voltage limits
48-62 Hz
nominal
current input
recommended
line protection
maximum
cross-section
HV [kW] [V] [A] [A] [mm²]
2.015 1,5 14,0 20
2.022 2,2
1~230 ± 15%
20,0 25
4
4.022 2,2 7,4 13
4.030 3 9,1 13
4.040 4
3~380-460 ± 15%
11,7 16
4
4.055 5,5 17,5 20
4.075 7,5 22,1 25
4.110 11
3~380-460 ± 15%
29,9 32
4
4.150 15 39,0 50
4.185 18,5 48,1 50
4.220 22
3x380-460 ± 15%
55,9 63
25
HYDROVAR Output to the motor
type rated
output
max. output voltage nominal
current output
motor connection cables
HV [kW] [V] [A] mm²
2.015 1,5 7,0
2.022 2,2
3x Uin
10,0
4x1,5 – 4x4
4.022 2,2 5,7
4.030 3 7,3
4.040 4
3x Uin
9,0
4x1,5 – 4x4
4.055 5,5 13,5
4.075 7,5 17,0
4.110 11
3x Uin
23,0
4x2,5 – 4x4
4.150 15 30,0
4.185 18,5 37,0
4x6 – 4x25
4.220 22
3x Uin
43,0 4x10 – 4x25
Make sure that the electrical data of the HYDROVAR match those of the
electric pump. Improper combinations may cause errors and malfunction of
the protection of the electric motor.
The nominal current of the motor must be lower than the rated current of the
HYDROVAR to prevent overheating or shutdown due to OVERLOAD.
The max. output current of the HYDROVAR could reach 110% of the nominal current for
max. 60 sec. before the error OVERLOAD will occur.
15
5.1 General technical data
Ambient temperature:
0° C ... +40°C
At higher temperatures a reduction of the output current or the
use of the next HYDROVAR power size is necessary.
The insulation rating of the HYDROVAR is IP55 however and in
common with other IP55 equipment, please note the following:
• Protect the HYDROVAR from direct sunlight!
• Protect the HYDROVAR from direct rainfall
• Outdoor installation without protection to keep especially
the temperature limits of the HYDROVAR is not permitted!
Storage temperature:
-25° C ... +55° C (+70°C during 24 hours max.)
Humidity:
RH max. 50% at 40°C, unlimited
RH max. 90% at 20°C, max. 30 days per year
75% average per year (class F)
Condensation is not permitted!
During long periods of inactivity or shutdown, the HYDROVAR
should remain connected to the power supply but the ext on/off
inhibited to prevent running of the pump. This will maintain
power to the internal heater and reduce internal condensation.
Air pollution:
The air may contain dry dust as found in workshops where there
is excessive dust due to machines.
Excessive amounts of dust, acids, corrosive gases, salts etc. are
not permitted
Altitude:
Max. 1000m above sea level
For installations over 1000 m above sea level, the maximum
output power has to be de-rated by 1% for every additional
100m.
If the installation site is over 2000 m above sea level, please
contact your local distributor or service contact.
Class of protection:
HV 2.015 / 2.022
HV 4.022 / 4.030 / 4.040 IP 55, NEMA 4 (indoor use only)
HV 4.055 / 4.075 / 4.110
HV 4.150 / 4.185 / 4.220
Certifications:
CE, UL, C-Tick, cUL
0
10
20
30
40
50
60
70
80
90
100
110
0 102030405060
max. ambient temperature [°C]
max. output current [%]
16
5.2 EMC requirements (Electromagnetic compatibility)
The EMC requirements in general differ between two environments which depending on
the intended use.
• First environment – class B (EN 61800-3: Class C2)
Environment that includes domestic premises, it also includes establishments directly
connected without intermediate transformers to a low-voltage power supply network
which supplies buildings used for domestic purposes e.g. houses, apartments, commercial
premises or offices in a residential building are typical examples of first environment
locations.
Be careful: The relevant EMC regulations for which the HYDROVAR is tested in the first
environment consider that the HYDROVAR is a restricted available product. That means the
voltage of the inverter is less than 1000 V, it is neither a plug in device nor a movable
device and, when used in the first environment, is intended to be installed and
commissioned only by a person or an organisation having necessary skills in installing
and/or commissioning power drive systems, including their EMC aspects.
• Second environment – class A (EN 61800-3: Class C3)
Environment that includes all establishments other than those directly connected to a low
voltage power supply network which supplies buildings used for domestic purposes e.g.
Industrial areas, technical areas of any building fed from a dedicated transformer are
typical examples of second environment locations.
The HYDROVAR complies with the general EMC regulations and is tested according
to the following standards: EN 61800-3/2004
EN 55011 (2002) Disturbance voltages / Disturbance field strength
First environment
– class B / class C2
Second Environment
– class A / class C3
Disturbance voltages OK OK
Disturbance field strength *) OK
*) Warning - In a domestic environment, this product may cause radio interference, in which case
supplementary mitigation measures may be required.
EN 61000-4-2 (2001) Electrostatic discharge
EN 61000-4-3 (2002) Electromagnetic field immunity test
EN 61000-4-4 (2001) Burst immunity test
EN 61000-4-5 (2001) Surge immunity test
EN 61000-4-6 (1996) Immunity of conducted RF-Disturbance
17
6 Dimensions and weights
HV 2.015 / 2.022
HV 4.022 / 4.030 / 4.040
All dimensions in millimetres! Drawings are not to scale!
Lifting aids must have the proper dimensions.
Type Weight [kg]
BASIC
MASTER /
SINGLE
HV 2.015
HV 2.022
HV 4.022
HV 4.030
HV 4.040
4,00 4,40
a … minimum centre-distance between HYDROVAR units 300 [mm]
b … expansion space for maintenance 300 [mm]
18
HV 4.055 / 4.075 / 4.110
All dimensions in millimetres! Drawings are not to scale!
Lifting aids must have the proper dimensions.
Type Weight [kg]
BASIC
MASTER /
SINGLE
HV 4.055
HV 4.075
HV 4.110
7,70 8,10
a … minimum centre-distance between HYDROVAR units 430 [mm]
b … expansion space for maintenance 300 [mm]
19
HV 4.150 / 4.185 / 4.220
All dimensions in millimetres! Drawings are not to scale!
Lifting aids must have the proper dimensions.
Type Weight [kg]
MASTER
HV 4.150
HV 4.185
HV 4.220
14,00
a … minimum centre-distance between HYDROVAR 550 [mm]
b … expansion space for maintenance 300 [mm]
20
4
5
7 Modules
Regarding the application the specific configuration for the HYDROVAR can be chosen. Due
to this possibility the HYDROVAR can be configured regarding the reliability and cost
effectiveness for each type of application.
HV 4.022 / 4.030 / 4.040 HV 4.055 / 4.075 / 4.110
HV 4.150 / 4.185 / 4.220
6
4
1
5
6
1 2 3
21
(1)
Power unit
Without one of the control cards it can be used as BASIC Inverter or as simple soft
starter in a SINGLE pump application!
When using a SINGLE or MASTER configuration the power unit is fitted with an
additional control card (4)
(2)
Filter card (not available for HV4.150-4.220, standard is class A)
Ensures EMC compliance for domestic environments. (Class B)
(3)
Mounting Kit
Consists of the metal and plastic cover to fix the control card and the display (and
the additional Relay Card if used). By the pre-mounted cable-clips, the screen of all
signal cables has to be connected to HYDROVAR-ground to avoid any interferences
on the signals
(4)
Control card
either for MASTER or SINGLE Inverter
(5)
Display unit
2 line plain text indication for programming and read out.
(6)
Relay Card
The optional Relay Card allows to control up to 5 fixed speed pumps (can be only
used in combination with the MASTER Inverter).
22
8 Mechanical components
8.1 Included mounting material
Included
components
Cable gland +
Lock nut
closing glad Motor
PTC
Mounting
clamps
Centring
bit
M M M M M M M M
12 16 20 25 40 12 16 50
Cable diameter
[mm]
3,7 - 7
4,5 - 10
7 - 13
9 - 17
15 - 23
2.015 – 2.022
2 (3) 2 2
3 1 1 4 1
4.022 – 4.040
2 (3)
2 2 3 1 1 4 1
4.055 – 4.110
2 (3)
2 2 3 1 1 4 1
4.150 – 4.185 4 (5) 2 2 4 2 1 1 4 1
4.220 4 (5) 2 2 4 2 1 1 4 1
( ) max. available cable entries
8.2 Optional components
8.2.1 Mounting accessories
Mounting ring
Available for diameters: 140 mm
155 mm
CAUTION!
If the HYDROVAR is mounted on a
motor with a plastic fan cover, a
stainless-steel mounting ring must be
used to support the weight of the
HYDROVAR.
8.2.2 Sensors
• pressure-transducer • temperature-sensor
• differential-pressure-transducer • flow indicator
• level-sensor
(orifice plate, inductive flow meter)
8.2.3 Filter
• Line-coils
8.2.4 Cable entry (only HV4.150 – 4.220)
• Multiple cable entry (M50)
8.2.5 Ready-made motor cables
Available for HV 2.015 – 4.220
23
8.3 Assembly instructions
HV 2.015 – HV 4.110 HV 4.150 – HV 4.220
display
actual value sensor
motor conduit box
4 mounting clamps
centering bit
4 screws
M5x70
motor cable
HYDROVAR – top cover
4 screws (to fit cover)
M4x50 M5x20
PTC
motor fan cover
motor
4 screws
M6x70
24
To remove the HYDROVAR – cover, the 4 fastening screws must be opened.
• Ensure that there is no liquid on the unit before you open the cover.
• Centre the HYDROVAR on the motor fan cover using the rubber centre bit.
•
If the HYDROVAR is mounted on a motor with plastic fan cover, a stainless
steel mounting ring must be used.
• The HYDROVAR is installed on the motor fan cover by using the mounting brackets, the
four screws and the relevant washers*.
• The HYDROVAR has to be centred and then the four screws must be tightened.
• Tighten each fastening screw until the two bottom teeth in the brackets start to grip the
fan cover.
• After the electrical components are connected, the top cover of the HYDROVAR can be
mounted and tightened by the four fastening screws.
• Make sure of a good connection of the ground wire.
• Ensure HYDROVAR cover gasket is in place before tightening the fastening screws.
• Ensure that the mounting of the cable glands is done properly and use closing plugs
for cable entries which are not in use.
*For HV4.150-4.220: Measure the right distance with the acceptance, the clamp and
the screw together
Adjust the length for smaller motor sizes
Please take care about sharp edges and
remove them properly
Max. Length
A
djust the length for smaller motor
sizes
25
9 Electrical installation and wiring
All installations and maintenance has to be performed by properly
trained and qualified personnel with proper tools!!
Use personal protection equipment.
In case of a failure, the electrical power has to be disconnected or
switched off. Wait at least 5 minutes for capacitor discharge before
servicing the HYDROVAR.
Otherwise it can cause shock, burns or death.
9.1 Means of protection
Ask your power supply company which means of protection are required.
Applicable:
• protective earthing
• AC and DC residual current operated protective devices (RCD)
• TN systems
Protective earthing:
• Please note that a current to earth can occur due to the capacitors in the input filter.
• A suitable protection unit has to be selected (according local regulations).
Residual current device (RCD/RCCB):
• When using an RCD, make sure that it also releases in the event of a short circuit inside
the DC-part of the HYDROVAR to earth!
o SINGLE phase HYDROVAR => use pulse sensitive RCDs
o three phase HYDROVAR => use AC/DC sensitive RCDs
• The RCD has to be installed according local regulations!
Automatic circuit breaker:
• Use automatic circuit breaker with C-type characteristic curve
• Rating of the line-protection (see chapter Technical Data)
Internal protective devices of the HYDROVAR:
• The malfunctions short circuit, under- and overvoltage, overload and the
overheating of the electronic components are monitored internally by the
HYDROVAR.
External protective devices:
• Additional protective functions like motor overheat and low water protection, are
controlled by external equipment.
26
9.2 EMC-electromagnetic compatibility
To ensure the electromagnetic compatibility the following points must be observed for
cable installation:
Earth / ground to ensure EMC
• Protection earth
It is important to connect the HYDROVAR to PE, because of the earth leakage
current.
• HF earth connection
Ground cables should be as short as possible and with lowest impedance.
Signal cables
Control and signal cables should be screened types to prevent disturbances from outside.
The screen should be only connected to ground on one end; to prevent ground loops. The
screen should be connected to HYDROVAR GND (use pre mounted cable-clips).
For small cable diameters the cable clips can be squeezed to ensure fixing.
To connect a screen with lowest impedance to ground, remove the insulation from the
signal cable and connect the screen to ground.
Signal cables must be installed separate from motor- and power- supply cables
If signal cables are installed in parallel to power supply cables (motor cables) for a longer
distance, the distance between these cables should be more than 200mm.
Do not cross power cables and control cables - if this is not possible, cross them only in an
angle of 90°.
Pre-mounted cable-clips
27
Motor cables
To ensure the EMC compatibility and minimize noise level and leakage currents, keep the
motor cable as short as possible (use shielded cables only if the total length exceeds 1.5
meters).
Additional component line choke (coil)
Line coils are available as an option and should be mounted between the HYDROVAR and
the main fuse. The Line coil should be as near as possible to the HYDROVAR (max. 30cm).
Advantages:
• better efficiency
• reduction of harmonic currents
For the following applications additional line chokes are strongly recommended:
• high short circuit currents
• compensation-plants without a coil
• asynchronous motors which are responsible for a voltage drop >20% of the line
voltage
EMC summary
• Install potential equalization according to local regulations
• Do not install the power-cables in parallel to signal-cables
• Use screened signal-cables
• Connect both ends of the screen of the motor cable to ground
• Connect only one end of the screen of a signal-cable to ground
• Motor-cable as short as possible
• Pigtails should be prevented
9.3 Recommended Cable Types
To ensure the above mentioned points and to guarantee EMC compatibility and correct
function of the HYDROVAR the recommended cable types should be used.
Application Recommended cable-type
- Motor-cables HV 2.015-2.022
HV 4.022 – 4.030- 4.040
HV 4.055-4.075
HV 4.110
HV 4.150 – 4.185
HV 4.220
4G1,5 + (2 x 0.75)
4G1,5 + (2 x 0,75)
4G2,5 + (2 x 0,75)
4G 4 + (2 x 0,75)
4G6 + (2 x 0,75)
4G10 + (2 x 0,75)
- Control- and signal- cables
JE-Y(ST)Y … BD
JE-LiYCY … BD
- Cables connected to RS485 interface JE-Y(ST)Y 2 x 2 x 0,8 BD
28
9.4 Wiring and connections
Remove the screws holding the top cover of the HYDROVAR.
Lift off the top cover. The following parts can be seen on a HYDROVAR MASTER / SINGLE
Inverter:
HV 2.015 / 2.022 HV 4.022 / 4.030 / 4.040 HV 4.055 / 4.075 / 4.110
(A) Power supply (B) Motor connections (C) Terminal block:
- START/STOP_PTC
(D) RS-485 Interface (E) Status-Relays - SOLORUN
- User interface - RS-485 Interface
- Internal interface (F) optional Relay Card
F
D
E
C
A
B
A
B
F
E D C
A
B
D
C
F
E
29
9.4.1 Main voltage terminals
The power supply is connected to the power section:
Terminal L + N (1 x 230 VAC, SINGLE-phase)
Terminal L1+ L2 + L3 (3 x 400 VAC, three-phase)
HV 2.015 / 2.022 HV 4.022 / 4.030 / 4.040
HV 4.055 / 4.075 / 4.110 HV 4.150 / 4.185 / 4.220
L1-L2-L3
3x400 VAC
Motor connection
U-V-W
(Crimp connection 6,3mm)
L - N
1x230 VAC
Motor
connection
U-V-W
Power supply
L1-L2-L3
3x400 VAC
Power suppl
y
30
9.4.2 Motor connection
Mounting of the PTC
Method A : Method B :
1. The cover of the conduit box must be opened and the terminal block inside removed
2. Fix the PTC (Method A or B)
3. Replace the terminal block
4. Electrical connection of the motor cables
The PTC must be fixed to the metal body of the motor. This is necessary to measure
the right temperature of the motor!
The connection of the motor cable depends on the type of motor and can be done in staror delta connection.
The right connection of the motor has to be selected as shown on the motor label
according to the output voltage of the HYDROVAR.
star - connection
delta - connection
U
V
H
Y
D
R
O
V
A
U
V
W
PTC
PTC
U
V
W
U
V
W
H
Y
D
R
O
V
A
PTC
motor block
PTC
terminal block
rubber gasket
cover of the
Loading...
