Heating
Cooling
Dehumidifying
all in ONE solution
and
Digitemp for superior climate control
The all-in-one solution for Heating,
Superior Climate Contr
ol
Cooling and Dehumidifying
benefits of climate control in the car or
at work. Your customers can now enjoy
this comfort at home too with Digitemp.
Installing climate control, an advanced form of air conditioning can bring a sense of comfort and
style to a home, fulfilling the expectations of modern family life.
By providing precise control of temperature, humidity
and airflow the Digitemp climate control solution can
dramatically reduce the effects of asthma allergies
and other chest disorders.
Digitemp can contribute towards a good night’s
sleep by eliminating many of the irritations caused
by an uncomfortable climate and poor air quality.
By keeping windows closed in summer, security is
improved and external noise is significantly reduced.
Digitemp is the new range of revolutionary climate control solutions from Xpelair. An innovative "all-in-one" design, Digitemp requires no external condenser or pipe work usually associated with air conditioning systems.
Operated using an infrared remote control, Digitemp provides a very
flexible approach to air temperature control with the facility to automatically
cool, dehumidify and heat air by means of efficient air-to-air reverse heat
technology. For added flexibility, the stylish "slimline" wall mounted units
can be installed at high or low level to maximise floor space.
The benefits of a system that
doesn't require an unsightly
condenser are clear.
n No need for planning permission
to install
n Ideal for use in apartments and
multi-storey locations due to cost
effective installation
otentially suitable for installation
n P
in listed buildings
n Only external evidence are two
discreet grilles
n No unsightly condenser to tarnish
the external façade of the building
P
Designed for low cost installation, Digitemp is easy to fit by an installer
requiring only two holes to an external wall. A patented folding grille
system means it can be installed entirely from inside the property making
it ideal for use in private dwellings, apartments and multi-storey locations.
key benefits
n Available as an ‘all-in-one’ air
conditioning and heating unit in two sizes - 2.1kW and 2.45kW*
n Also available as a cooling only air
conditioning unit in two sizes -
2.1kW and 2.45kW
n All-in-one’ models can operate in
cooling, dehumidification or heating modes to maximise comfort
n Easy installation from within the room -
patented folding grille system eliminates the need for external access
n The electronic control system includes
infrared remote control night function and automatic operation
n Can be installed at high or low level
for maximum flexibility & usable space
n Economic and efficient, Digitemp
operates combining low power consumption when cooling with a high efficiency heating capacity
n Digitemp uses a three speed fan
including night mode for super-quiet operation
n F
actory sealed refrigerant system
eliminates the need to connect hoses
n Self-diagnostic programme for
all maintenance requirements
n 2 year warranty
* kW ratings are for cooling mode only. Heating capacity for the 2.1kW and 2.45kW are 1.9kW and
2.03kW respectively.
environmental benefits
total comfort at
Water and space heating account for more than 60 percent of a home’s energy cost so, when looking for savings, this is a great place to start!
Digitemp will deliver up to 260% more heating or 200% more cooling
energy than it consumes. Using optimum heat pump efficiency, Digitemp
can give you 2.6kW of heating or 2.2kW of cooling, using less than
1kW of electricity.
All units benefit from R410a refrigerant, which as well as being the highest
performing gas available, has an Ozone Depletion Power (ODP) rating of
"0". All these factors combine to give Digitemp a capacity over absorption
energy efficiency rating of up to A.
Digitemp is sound insulated resulting in a quiet operation at only 37
decibels. The air quality is improved too; Digitemp uses a fine filter to
clean the air
Eco-friendly Digitemp creates an indoor environment that is healthy
and brings comfort to life.
, removing irritants like dust and pollen.
your fingertips
The automatic control system
provides precise climate control at
the press of a button. All operational
modes are programmable using the
infrared handset - no need to move
to adjust the room temperature.
For peace of mind, Digitemp uses an
automatic inbuilt diagnostic system
which displays the condition of the
unit through a series of LED's. The
self-diagnostic programme indicates
when maintenance is required.
Digitemp has a night function with
reduced fan speed for quiet operation
to help ensure a restful night’s sleep.
Superior Climate Control
the range
Four models are available
in the range providing the
choice between cooling
nly and heating or cooling.
o
These are available in two
capacities, with a maximum
of 2.45kW cooling.
Wall mounted (low or high level) heating, cooling and
dehumidifying climate control solutions
COOLING ONLY
AIR CONDITIONING
AND HEATING
Catalogue ref. Unit 91173AA 91174AA 91175AA 91154AA
Product code WA210 WA245 WHP210 WHP245
Cooling Capacity kW
Heating Capacity kW - - 1.9 2.03
EER (Energy Efficiency Ratio) 2.66 2.66 2.23 2.23
COP (Coefficient of P
Max. Absorbed P
Dehumidification Capacity I/h 1.0 1.2 1.0 1.2
gy Efficiency Class
Ener
Energy Efficiency Class Heating - - C F
Room Air Volume m3/h 350 390 350 390
Fan Speed Settings
Noise Levels dB(A) 37 39 37 39
Refrigerant Type R410a R410a R410a R410a
Max Range of Infrar
Power Supply Volts 230 230 230 230
Dimensions (mm)
Wall Hole diameter (min) mm 155 155 155 155
erformance)
ower Rating W 930 1320 930 1320
Cooling
emote Contr
ed R
ol
m8 8 8 8
Hz 50 50 50 50
Width
Height 400 400 400 400
Depth 280 280 280 280
eight
W
2.1 2.45 2.1 2.45
1.88
870
43
-
A
3
-
CA C
3
870 870 870
46 43 46
2.64
3
3
installation guide...
Key points to remember.
There are some essential issues relating to the application and installation
of the equipment which must be observed for problem free operation:
n The maximum length of ducting is one metre
n The unit must be mounted against an outside wall
n Where possible the unit should be positioned towards the centre of
the selected wall and check weight specification
n The diameter of the supplied ducting must not be reduced or restricted
n The insulated duct must be used on the right hand side the product
(viewed from the outside) and with the insulation adjacent to the
rear of the unit
n It is essential that the units are installed perfectly level, failure to do
so can lead to malfunction of the drip tray float valve causing
water damage
n The units with reverse heat pumps must be provided with a means
of drainage since the ice that forms on the coil is melted off every
30 minutes - this cannot be evaporated in the way the other
condensate is discharged
n Care must be taken to ensure that the inlet and outlets are not
obstructed in any way
n Only the inlet and outlet grilles supplied with the equipment must
be used
n When the unit is mounted at high level, it is necessary to activate the
room temperature differentiation function, this compensates for the
stratification of heat
n The cored holes must be angled slightly downwards towards the
outside to prevent any condensate running back into the unit
, such as by plants and bushes
For added flexibility Digitemp can be
installed at high or low level to
maximise floor space. The refrigerant
system is factory sealed so installation
does not involve opening the system
or connection of any hoses.
The modular approach means that
maintenance only affects one unit /
room at a time, the remainder of the
building is unaffected.
Air flow in heating mode (shown on high level installation)
Superior Climate Control
Air flow in cooling mode (shown on low level installation)
...it couldn’t be simpler!
Installing Digitemp from within the room at high or low levels requires only a standar
Designed for low cost installation, Digitemp is simple to fit requiring only
two discreet holes to an external wall. Using a patented folding grille
system, Digitemp can be installed entirely from inside the property making
it ideal for apartments and multi-storey locations - eliminating the cost of
erecting scaffolding.
When operating in cooling only mode, condensate is removed through
water evaporation on the condenser therefore a drainage pipe is not
necessary. In models with a heating function, the unit requires condensate
to be removed through a small drainage pipe.
d 13 amp electrical supply.
Only external evidence is two discreet grilles
1 Select the position of the unit
(see diagram for optimum
positioning). Where possible
the unit should be positioned
towards the centre of the
selected external wall
2 Drill holes for vents at a
sloping angle to the external
wall to allow for drainage in
heating mode
3 Fix the bracket
4 From within the room, feed
the discreet folding grilles
through the inlet and
outlet vents
5 Hard wire the unit to a
ring main spur
