Phaser® 3635MFP
Black-and-White Multifunction Printer
Phaser 3635MFP/S
A powerful workgroup multi-tasker that offers printing, copying and advanced scanning.
3635MFP/S 3635MFP/X
Output Speed
Single-Sided Up to 35 ppm 8.5 x 11 in.
Up to 33 ppm A4 (210 x 297 mm)
Automatic Two-Sided Up to 18 ppm 8.5 x 11 in.
Up to 18 ppm A4 (210 x 297 mm)
Paper Handling - Input
Duplex Automatic Document Feeder
Capacity* 50 sheets
Sizes Standard Selectable Sizes: 5.5 x 8.5 in., 8.5 x 11 in. to 8.5 x 14 in., A4, A5, JIS B5, 7.25 x 10.5, 8.5 x 13, Oficio
Weights 12 lb. bond to 28 lb. bond (50 to 120 gsm)
Bypass Tray
Capacity* 50 sheets
Sizes Custom Sizes: 3.9 x 5.8 in. to 8.5 x 14 in. (98 x 148 mm to 216 x 356 mm)
This configuration adds embedded and LAN Fax and a convenience stapler.
Weights 16 lb. bond to 43 lb. bond (60 to 163 gsm)
Media Types Plain paper
Recycled Bond Lightweight Heavyweight Envelopes Labels Transparencies Punched Letterhead Pre-printed Archive
* Paper capacities are based on 20 lb/75 gsm stock; capacities will vary with different weight stocks.
Detailed Specifications 1
Phaser 3635MFP
Tray 1
Capacity* 500 sheets
Sizes Standard Selectable Sizes: 8.5 x 11 in., 8.5 x 14 in., A4, A5, ISO B5, JIS B5, 7.25 x 10.5 in., 8.5 x 13 in., Oficio
Weights 16 lb. bond to 28 lb. bond (60 to 105 gsm)
Media Types Plain paper
Recycled Lightweight Punched Letterhead Pre-printed Archive
Tray 2 (Optional)
Capacity* 500 sheets
Sizes Standard Selectable Sizes: 8.5 x 11 in., 8.5 x 14 in., A4, A5, ISO B5, JIS B5, 7.25 x 10.5 in., 8.5 x 13 in., Oficio
Weights 16 lb. bond to 28 lb. bond (60 to 105 gsm)
Media Types Plain paper
Recycled Lightweight Punched Letterhead Pre-printed Archive
Paper Handling - Output
Standard Output 250 sheets
Finishing Offline Convenience Stapler: 20-sheet, single position (available with 3635MFP/X only)
Print
First-Page-Out-Time As fast as 9 seconds
Print Resolution 600 x 600 dpi (up to 1200 x 1200 enhanced image quality)
Memory (Std/max) 256 MB / 512 MB
Processor 360 MHz
Hard Drive 80 GB
®
Language Support Postscript
PCL PCL
3™ compatibility
®
5e emulation
®
6 emulation
Connectivity 10/100 Base-T Ethernet, USB 2.0
* Paper capacities are based on 20 lb/75 gsm stock; capacities will vary with different weight stocks.
Detailed Specifications 2
Phaser 3635MFP
Printing Features Custom page size
Automatic two-sided printing Watermark Secure print Sample set Delayed print Cover selection Paper selection by attribute Toner saver N-Up Mirror image Negative image Image rotation Saved settings Booklet creation Fit to new paper size Collation Print to Hard Drive Print from Hard Drive Print from USB memory drive
®
Print Drivers Microsoft
Mac OS Sun Microsystems Solaris™ 9/10 Linux Red Hat Fedora™ Core 4 SUSE IBM AIX HP-UX 11.0/11i Novell NetWare SCO
Windows® 2000//2003 Server/XP/XP Professional/Vista
®
X version 10.3
®
5
®
®
ES
®
(IP only)
Font Capability 136 PostScript® fonts
45 PCL
®
fonts
Copy
Document Scanner Duplex Automatic Document Feeder with 50-sheet capacity
Sides (input:output) 1:1, 1:2, 2:2 and 2:1
Quantity 1 to 999
Resolution 600 x 600 dpi
Concurrency Concurrent scanning and printing
First-Copy-Out-Time As fast as 9 seconds
Detailed Specifications 3
Phaser 3635MFP
Copy Features Automatic two-sided
Collation Reduce/Enlarge 25 to 400% (from Platen and ADF) Book Copying Mixed-size Originals Edge Erase Image Shift Margin Shift Booklet Creation Covers Auto Paper Select Lighten/Darken Transparency Separators Multi-up ID Card Copy Copy to hard drive Background Suppression Color touch screen interface
Foreign Device Interface Interface to third-party access control devices, coin machines and card readers
Supports a variety of vending stations available through the Xerox Custom Application Service
Fax
Embedded Fax, LAN Fax (Available with 3635MFP/X – 1 line)
Fax Speed 33.6 Kbps
Memory Up to 40 GB of the 80 GB hard drive
Resolution Up to 600 x 600 dpi (superfine) resolution
Compression MH, MR, MMR, JPEG and JBIG
Fax Features Auto reduction
Junk fax barrier Memory fax Polling Background suppression Mailboxes Secure Fax Fax reports
Fax Send Features Audio line monitor
Auto fax transmission reduction Fax broadcast Fax from platen Priority send Transmission options (Report/header) Delay fax Priority fax Batch transmission Color Fax send Address book
Fax Receive Features Auto answer delay
Junk fax prevention One or two-sided printing Fit to page Secure receive Fax forward to fax / email Fax memory receive Color fax receive
Detailed Specifications 4
Phaser 3635MFP
Network Server Fax Enablement (Optional)
Fax Send Features One- or two-sided scanning
Phone number entry Add to send list (50 numbers maximum) Delay send (specific time) Resolution selection (super fine/600 x 600, super fine/400 x 400, fine/200 x 200, standard/200 x 100 dpi) Original type (photo and text, photo, text)
Fax Print Features One- or two-sided printing
Quantity Collate on/off Secure print on/off
Fax Vendors Multiple vendors, certified by the Xerox Alliance Partner Program
For details, visit www.xerox.com
Scan
Capability Black-and-white and color scanning
Concurrency Scan while the system is printing copy or network print jobs, or while it is transferring scan to network or fax jobs
Input Speed Scan at 35 ipm (images per minute) black-and-white (8.5 x 11) / 33 ipm (A4)
Scan at 24 ipm color (8.5 x 11) / 22 ipm (A4) @ 300 dpi
Resolution 600 x 600 dpi (black-and-white only)
400 x 400 dpi (black-and-white only) 300 x 300 dpi 200 x 200 dpi 100 x 100 dpi 72 x 72 dpi
Maximum Scan Area 8.6 x 11.9 in. / 219 x 303 mm
Network Protocol FTP
HTTP HTTPS SMB
File Formats TIFF
Multipage TIFF PDF JPEG
Supported Scan Destinations
Scan to Email Direct document email from device•
Scan to Network Uses templates to send scanned images to predefined locations
Scan to Email Scan to Network Scan to USB Memory Drive / Thumb Drive Scan to PC Desktop SE
Manual or directory Exchange/Notes/LDAP address searching• “From” field auto-populated from LDAP (only when authentication is used)•
Scan to USB Scans can be loaded directly onto a user’s portable USB storage device
Scanning Solutions
®
Scan to PC Desktop
SE A desktop and server-based offering that provides document imaging, archiving, editing and organization tools•
ScanSoft PaperPort – image viewing and file management software• ScanSoft OmniPage (for desktop/client installation) – OCR and file format conversion software• Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox • WorkCentre to individual desktops
Detailed Specifications 5
Phaser 3635MFP
Accounting
Xerox Standard Accounting
Tracking Copy, Print, Fax and Scan usage
Accounting Up to 500 User accounts
Up to 250 General accounts Up to 250 Group accounts
Features Enable/disable via the web UI or the GUI in tools, admin can manage the feature remotely via the web UI,
Data can be exported via a CSV file, user required to enter XSA ID into the print driver when submitting a print job, similar to secure print.
Network Accounting Enablement (Optional)
Enhanced Network Accounting with up to the minute data on how the device is being used; comprehensive management and enterprise scale tracking and reporting of device usage of copy, print, scan and server fax. Various options available through Xerox Alliance Partner solutions. For details visit www.xerox.com
Accounting Control Xerox Standard Accounting
Network Accounting (with third party integration) Supports Foreign Device Interface
Security
Security Features Audit log
Fax security HTTPS (secure scan and network server) Image overwrite security Network authentication Secure Print User authentication
Device Management
®
Xerox CentreWare
Web
A Web-based server application for network administrators that permits Web browser-based device management • from any workstation, whether running Windows or UNIX or any other operating system Works with any SNMP-managed printer from any manufacturer• Provides help with device discovery and installations, health checks and troubleshooting, and device upgrades, • as well as basic Accounting and asset management•
®
Xerox CentreWare
Internet Services - Integrated Device Web Page
Device Status Web server embedded
Tray status/contents• Consumables status•
Print Queue Viewing Complete job print queue management – hold, release, promote and delete
Job Submission Print-ready files (PS, PCL, TIFF, PDF)
Output feature selection
Device Administration Allows simple, remote installation setting of configuration options and management of the device
Browsers Windows
Microsoft® Internet Explorer Macintosh
®
XP, 2000: Netscape Navigator®, Firefox
®
9.x/OS X: Netscape Navigator® 6.x, Apple® Safari™, Firefox
®
®
Linux: Netscape® 6.x
Detailed Specifications 6
Phaser 3635MFP
Xerox CentreWare® for HP® OpenView
Provides for the identification of Xerox printers/devices in the general discovery performed by HP OpenView• Provides the ability to see the current status of discovered Xerox printers/devices under a Xerox PrinterMap and IP • Map via color coded icons Provides traps and message updates to the OpenView alarm browser and the ability to launch CentreWare • Internet Services for device management directly from OpenView
®
Xerox CentreWare
Xerox CentreWare
Xerox Novell Distributed Print Services Solution (NDPS)
for Tivoli® NetWare
Provides for the identification of printers/devices in the general discovery performed by Tivoli NetView• Provides the ability to see the discovered Xerox printers/devices in a Xerox Printers Set in addition to the • Printers SmartSet Provides full integration with the NetView and Event Browser and Tivoli Enterprise Console (TEC)•
®
for Unicenter TNG
Provides added identification to the general discovery performed by Unicenter TNG and the ability to see the • device under a Unicenter TNG Business Process View Provides full integration with event management and the choice to integrate with problem management and • advanced Help Desk
Group of applications that allows an administrator to install and centrally manage printers from anywhere on a Novell network
®
Device Specifications
Duty Cycle
Up to 75,000 pages / month
Electrical Requirements
220-240 VAC, 50/60 Hz 110-127 VAC, 50/60 Hz ENERGY STAR
Power Consumption
Average 600 watts
Standby 55 watts
Power save 15 watts
Warm up
25 seconds (maximum)
(from power save)
Maximum
50° to 90° F (10° to 32° C)
Temperature Range
Recommended
61° to 86° F (16° to 30° C)
Temperature Range
Maximum
20% to 80%
Humidity Range
®
qualified
Recommended Humidity Range
30% to 70%
Detailed Specifications 7
Phaser 3635MFP
Dimensions and Weights Width Depth Height Weight
Product 18.6 in. / 472 mm 18.8 in. / 478 mm 21.4 in. / 543 mm 48.6 lbs / 22.1 kg
Package 23.6 in. / 599 mm 23.6 in. / 599 mm 27.8 in. / 707 mm 62.17 in. / 28.2 kg
Certifications
Listed to UL 60950-1/CSA 22.2 No. 60950-1-03, Class 1 Laser Product, FCC Part 15, Class A, CE marked in accor­dance with Low Voltage Directive, 2006/95/EC and EMC Directive 2004/108/EC, CB Certified against IEC 60950, Section 508 ADA
What Comes in the Box
Phaser 3635MFP Multifunction Printer• Print cartridge (5,000 print capacity)• Printer Installer and Utilities CD, Software and documentation CD, Registration card, Warranty booklet• Power cord•
Supplies and Options Description Order Number
High Capacity Print Cartridge – approx. 10,000* 108R00795
Standard Print Cartridge – approx. 5,000 pages** 108R00793
Network Accounting Enablement 098S04928
Network Fax Server Enablement 098S04931
256 MB Memory Upgrade 098N02189
Paper Tray 098N02190
Stand 097N01674
Foreign Device Interface Kit 097N01676
Staple Cartridge 108R00823
* Declared Yield in accordance with ISO/IEC 19752. Yield will vary based on image, area coverage and media used. ** Yield will vary depending on job run length, media size and orientation
