Page 1
WorkCentre
3210 / 3220
Letter-size
Black-and-white
Multifunction Printer
®
Xerox WorkCentre® 3210 / 3220
Multifunction Laser Printer
Maximized efficiency,
tailored to your desktop
Page 2
WorkCentre® 3210/3220 Multifunction Laser Printer
True office productivity on your desktop. The WorkCentre 3210/3220 is a highly
compact device complete with extensive features to increase performance and
manage costs. This value-packed and reliable all-in-one print/copy/scan/fax device
has been designed with individuals and small workteams in mind.
Performance-tuned
for busy professionals
The WorkCentre 3210/3220 puts a premium on
efficiency, giving you the power and functions
you need to stay on top of heavy workloads.
• Fast output keeps pace with
high demand. Print speeds up
30
ppm
• Concurrent operation means you can quickly
scan a file when you need it, even while other
jobs are printing.
• Flexible paper handling. Reliably feed a wide
variety of media, including cardstocks, transparencies, envelopes and papers ranging from
16 to 43 lb. (60 – 163 gsm).
• Sharp, clear images and text, with up to
1200 x 1200 enhanced image quality plus
®
PCL
6 and PCL 5e printer languages. The
WorkCentre 3220 includes Adobe
3™ compatibility.
• Find your most-needed functions fast on
the user-friendly front panel with large, easyto-read buttons and a two-line LCD display.
• Set-up is a snap, thanks to an installation
video, and simplified network and driver
installation.
to 30 ppm, and a rapid first-
page-out time of less than 8.5
seconds, deliver documents fast.
®
PostScript®
Outstanding overall value
The WorkCentre 3210/3220 delivers more
for your money and helps small offices gain
efficiency while keeping costs down.
• Affordable price lets you add superior office
capabilities without breaking your budget.
• Combines critical functions. One device that
does the work of four reduces operating costs
and service calls.
• High productivity right out of the box, with
built-in networking and everything you need
to start using this multifunction printer within
a few minutes of setup.
• Choose long-lasting high-capacity print
cartridges to lower your cost per print and
minimize printer intervention.
• An array of security features such as
Secure Fax Receive, which holds a fax until
an authorized user logs in to retrieve it, along
with SNMPv3 and IPv6, ensure that private
data stays secure.
• Xerox quality, reliability and performance
are backed by Xerox Service and Support,
a standard one-year warranty and the
unmatched Xerox Total Satisfaction Guarantee.
• Front panel USB port offers convenient scan-
ning to and printing from a USB memory drive.
Conserve resources
and stay green.
• Energy Star qualified to save on
power consumption.
• Reduce paper use with auto-
matic two-sided printing on the
WorkCentre 3220.
• Adjustable power save mode
puts you in control of your multifunction printer’s power bill.
• Increase toner yield by using Toner
Saver mode on draft documents.
• One set of consumables saves
money and storage space. No more
purchasing supplies for separate
print, fax and copy machines.
• Save paper with digital workows,
letting you distribute documents
electronically instead of on paper.
• No-hassle maintenance. An all-in-one user-
replaceable print cartridge keeps intervention
to a minimum, and a robust monthly duty cycle
of up to 30,000 pages (3210) and 50,000
pages (3220) ensures reliable operation day
after day.
WorkCentre® 3210 / 3220
Quick Facts
• Up to 24 ppm and 30 ppm
• 250-sheet paper capacity,
expandable to 500 sheets
• 600 x 600 dpi (1200 x 1200
enhanced image quality)
• 360 MHz processor
• 128 MB memory
(384 MB maximum)
• Color scanning
Print / Copy / Scan / Fax
Letter / Legal
24
ppm
30
WxDxH:
17.5 x 16.2 x 15.6 in.
445.2 x 410.5 x 395.3 mm
3210: 30.45 lbs./13.8 kg
3220: 30.73 lbs./13.9 kg
Page 3
Small-office friendly
All the office-ready features you need, sized to
fit your workspace.
• Compact, quiet and lightweight. The
WorkCentre 3210/3220 fits perfectly in
tight, busy spaces.
• Color scanning quickly converts paper into
electronic documents on your network, ready
to be saved to a network or desktop folder,
inserted into an application, sent to an email
inbox (WorkCentre 3220) or stored on a USB
memory drive.
• Included scan software provides helpful
tools for editing and document manipulation, and for organizing and distributing your
scanned files.
1
2
6
3
7
4
• Edit and organize scanned files with Optical
Character Recognition scanning tools.
• Advanced fax features such as broadcast
(multisend) faxing, fax forwarding and fax
speed dials let you replace less cost-effective
standalone fax machines with a single, wellintegrated device.
• PC/LAN Fax allows paperless faxing right
from your desktop (Windows only).
• Manage from your desktop using
CentreWare
®
Internet Services, which lets
you configure, update, view status and
receive event alerts remotely.
• Expand paper capacity as your require-
ments expand. An optional 250-sheet paper
tray gives you 500-sheet total capacity to
reduce paper-changing trips.
• Work team-ready, this multifunction printer
supports a diverse office environment with
Microsoft
Macintosh
®
Windows®, Linux and Apple®
®
systems.
1
Automatic Document Feeder holds 50 sheets.
2
Automatic two-sided printing on the WorkCentre 3220
saves paper and money.
3
Single-sheet multipurpose tray can handle envelopes,
labels, postcards and transparencies.
4
250-sheet tray provides plenty of paper capacity
for workgroup printing, copying and faxing.
5
Optional 250-sheet tray brings total capacity to
500 sheets.
10
5
6
USB memory port lets you save to, or print directly
from, a USB drive — no computer needed.
7
Paper level indicator shows the sheets remaining
in the tray.
8
Find frequently used fax numbers and email addresses
in address book. You can also print an address list.
9
Four-way directional pad eases menu navigation.
10
Copy both sides of an ID card to a single side of
paper with ID Card Copy feature.
9
8
Page 4
WorkCentre® 3210 / 3220
Speed
Duty Cycle
WorkCentre 3210 WorkCentre 3220
Up to 24 ppm (Letter/A4) Up to 30 ppm (Letter) / 28 ppm (A4)
Up to 30,000 pages / month Up to 50,000 pages / month
Paper Handling
Paper input Standard Automatic Document Feeder: 50 sheets; Custom Sizes: 5.6 x 5.8 in. to 8.5 x 14 in. / 142 x 148 mm to 216 x 356 mm
Multipurpose Tray: 1 sheet; Sizes: 3 x 5 in. to 8.5 x 14 in. / 76 x 127 mm to 216 x 356 mm
Main Tray 1: 250 sheets; Custom sizes: 3 x 5 in. to 8.5 x 14 in. / 76 x 127 mm to 216 x 356 mm
Optional Tray 2: 250 sheets; Custom sizes: 3 x 5 in. to 8.5 x 14 in. / 76 x 127 mm to 216 x 356 mm
Automatic two-sided printing NA Standard
Paper output 150 sheets
Print
First-page-out-time
Print resolution 600 x 600 dpi (1200 x 1200 enhanced image quality)
Processor 360 MHz
Memory (std / max) 128 MB / 384 MB
Connectivity 10/100 Base-TX Ethernet, USB 2.0
®
Page description languages PCL
6 and PCL®5e emulations (host-based for Mac and Linux) PCL® 6 and PCL®5e emulations, PDF 1.4, PostScript® 3™ compatibility
Print features Custom-size pages, Watermarks, Poster printing, N-Up, Fit to Page, Scaling, Overlays, Reduce/Enlarge, Toner Saver, Print from USB memory drive, Booklet printing
As fast as 9.5 seconds As fast as 8.5 seconds
Copy
First-page-out-time As fast as 11 seconds
Copy resolution Up to 600 x 600 dpi (1200 x 1200 interpolated)
Copy features Reduce/Enlarge (25 – 400%), Auto background suppression, 3 level darkness control, Collation (ADF only),
ID Card Copy, N-Up (2-up, 4-up), Clone (platen only), Poster Copying (platen only)
NA Two-sided (1:2 duplex copy), Manual 2:2 copying (no collation)
Fax Embedded fax (33.6 Kbps with MH/MR/MMR/JBIG/JPEG compression)
Fax features Secure fax receive, PC/LAN Fax (send only)*, Fax forward to fax, Junk fax barrier, Searchable address book, Auto reduction, Battery backup, Distinctive ring, Broadcast (multisend)
Scan
Scan destinations Scan to application, Network Scan to PC, Scan to USB memory drive
Scan features Scan to PC Desktop
Security
Warranty
* Windows only
Device Management
CentreWare
WebJet Admin Interface
Print Drivers
Windows
Mac OS
USB interface only) including Red Hat
Mandrake
(32/64 bit), Ubuntu 6.06-7.04, Debian 3.1-4.0, UNIX AT&T system
V (4.2) BSD4.3, HP-UX (Rel 9x & 10x), SCO 5.x, SUN OS 5.5, Sparc
or Solaris 2.5; Xerox Global Print Driver™; Xerox Mobile Express
Driver™ (WorkCentre 3220)
Media Handling
Main Tray 1 and optional Tray 2: 16 – 28 lb. / 60 – 105 gsm;
Multipurpose Tray: 16 – 43 lb. bond / 60 – 163 gsm; ADF: 16 –
28 lb. / 60 – 105 gsm; Plain paper, envelopes, labels, card stock,
transparencies
Operating Environment
Operating: 50º to 90º F / 10º to 32º C; Storage: 14 º to 104 º F /
-20º to 40 º C; Relative humidity: 20 to 80%; Sound pressure levels:
Printing: 3210: 49 dB(A), 3220: 50 dB(A), Standby: 26 dB(A);
Warm-up time (from Power Save): Less than 2 seconds; Warm-up
time (from power on): Less than 54 seconds
®
Internet Services, CentreWare Web,
®
2000/XP (32/64 bit)/Vista/2003 Server/2008 Server,
®
X version 10.3 and above; Various Linux® OS (via
®
9.2-10.1, SUSE® 8.2-9.2, Mandriva 2005/2006/2007
fax, Up to 200 group dial/broadcast locations, 200 speed dial locations, Delayed fax, Memory receive, Color fax send, Fax reports, Up to 300 x 300 dpi, 4 MB (225 pages)
NA Fax forward to email, Two-sided fax receive
Scan to application, Network Scan to PC, Scan to USB memory drive,
Scan to email
®
SE Personal Edition; PDF; JPEG; TIFF; Multi-page TIFF; BMP; Color Scanning; USB, TWAIN, WIA drivers, Up to 4800 x 4800 enhanced dpi
IP Filtering, SNMPv3, Port Control, IPv6, Secure IPP, Scan-to-email with user authentication, Secure fax receive
One-year return to depot, Xerox Total Satisfaction Guarantee
Supplies
Standard-capacity print cartridge:
2,000 pages 106R01485
High-capacity print cartridge:
4,100 pages 106R01486
1
Average standard pages. Declared Yield in accordance with ISO/IEC 19752.
Yield will vary based on image, area coverage and print mode.
1
1
Options
256 MB Memory 098N02189
Additional Paper Tray 098N02204
Wireless Network Adapter
– N. America Power Converter 097S03740
– European Power Converter 097S03741
– UK Power Converter 097S03742
Supplies Recycling Program
Consumables for the WorkCentre 3210/3220 are part of
the Xerox Green World Alliance Supplies Recycling Program.
For more information, please visit the Green World Alliance
website at www.xerox.com/gwa
®
8-9, Fedora™ Core 1-4,
Electrical
Power: 110–127 VAC, 50/60 Hz or 220–240 VAC, 50/60 Hz; Power
consumption: Standby: 60 W; Printing: 450 W; Power save: 12 W;
ENERGY STAR
®
qualified
Dimensions (WxDxH)
17.5 x 16.2 x 15.6 in. / 445.2 x 410.5 x 395.3 mm; Weight: 3210:
30.45 lbs / 13.8 kg, 3220: 30.73 lbs / 13.9 kg; Package Dimensions
(WxDxH): 23 x 21.7 x 20.7 in. / 584 x 551 x 526 mm; Weight:
39.24 lbs / 17.8 kg
Certifications
Listed UL 60950-1/CSA 609501-1-03, CE Mark applicable to
Directives 2006/95/EC, 2004/108/EC, and 99/5/EC, FCC Part 15
Class B, FCC Part 68
What Comes In The Box
• WorkCentre 3210/3220
• Print Cartridge (2,000 pages
1
)
• Software (Scan to PC Desktop SE Personal Edition with
Single license for support for OmniPage and PaperPort)
• Documentation CD (with User Manual, Quick Installation
Guide and Warranty Statement)
• Fax cord, power cord, USB cable
For more information, call 1-877-362-6567 or visit us at www.xerox.com/ofce
© 2009 Xerox Corporation. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Xerox Corporation. XEROX®, CentreWare®, WorkCentre® and
the sphere of connectivity design are trademarks of Xerox Corporation in the U.S. and/or other countries. Adobe® and PostScript® 3™ are registered trademarks or trademarks of Adobe Systems,
Incorporated. PCL® is a registered trademark of Hewlett-Packard. As an ENERGY STAR® partner, Xerox Corporation has determined that this product meets the ENERGY STAR guidelines for energy
efciency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. All other trademarks are the property of their respective manufacturers. The information in this brochure is subject
to change without notice. 6/09 610P729879A W3XBR-01UB
Loading...
