Wheelock SLS Specification

U

L

®

Series SLS Strobe

Description:

The Series SLS Strobe has a wide operating voltage
range and automatic sychronization wich makes it a
universal solution for all types of applications. The Series
SLS can be mounted outdoors when used with a DB
backbox.

Voltage: 10-60 VDC

Current: 220mA at 24VDC (includes
current surge suppression)

Light Source: Xenon

Light Output: 15 CD (Based on red lens)

IP Rating: IP65 when used with deep
base

Color: Off White

Flash Rate: 1 Hz

Synchronization: 1ms over 30 min

Anti-tamper
(where fitted): Normally closed contacts.
Contacts open when strobe
removed from base

Features:

Wide operating voltage up to 60VDC

Current surge suppression

Automatic synchronization

High efficiency

Constant base performance over voltage range

Strobe can be locked onto base

Tamper switch for security applications

Weatherproof when used with deep base (DB)

Specification and Ordering Information:

Model
Number

SLS-A-DC 4087 Amber Lens

SLS-R-DC 4088 Red Lens

SLS-B-DC 4089 Blue Lens

Order

Code

Description

273 Branchport Avenue
Long Branch, NJ 07740
Phone: [phone]
Fax: [phone]
www.cooperwheelock.com

WE ENCOURAGE AND SUPPORT NICET CERTIFICATION

3 YEAR WARRANTY

Made in USA

SLS 09/06
