OPERATOR’S MANUAL
MODEL NUMBER WE18C
ELECTRIC-POWERED, 2-IN-1,
18" ROTARY LAWN MOWER
438181
TABLE OF CONTENTS
Safety Rules.................2-4
Assembly.........................5
Pre-Operation...............5-6
Operation....................7-10
Maintenance.............10-11
Storage..........................12
Troubleshooting.............13
Warranty........................14
SAFETY RULES
WARNING: IMPORTANT SAFETY WARNINGS AND INSTRUCTIONS.
WARNING: When using electric gardening appliances, basic safety precautions
should always be followed to reduce risk of fi re, electric shock, and personal injury,
including the following.
READ ALL INSTRUCTIONS
MOWER SAFETY GUIDELINES
• The information this manual contains
will alert you to potential hazards and
prevent possible problems.
• It may not be practical or possible to warn
about all the hazards associated with operating or maintaining your lawn mower
in this manual and we would advise you
to use your own good judgment.
• Familiarize yourself with your lawn
mower, know all the lawn mower controls and how to operate them.
USER SAFETY
The symbols below may appear in this
manual and on your mower. Learn and
understand their meaning.
CAUTION
or
WARNING
DANGER: Beware of
sharp blade - keep
hands and feet away.
DANGER:
Cut hazard -
keep hands
and feet away.
Do not mow when
children or others
are present - keep
bystanders away.
To reduce risk of
electric shock, do not
expose to water or
operate on wet ground.
Beware of thrown
objects from mower
deck. Remove
objects that could be
thrown by the blade.
Turn off mower and
remove plug from mains
before service, inspection,
or if cord is damaged.
Read the
operator's
manual.
2
Mow across slopes, not
up and down. Do not mow
any slope that has an
angle of greater than 15°
SAFETY RULES
I. GENERAL OPERATION
• Read, understand, and follow all
instructions on the machine and in the
manual(s) before starting. Be thoroughly
familiar with the controls and the proper
use of the machine before starting.
• Do not put hands or feet near or under
rotating parts. Keep clear of the discharge opening at all times.
• Only allow responsible adults, who are
familiar with the instructions, to operate
the machine.
• Clear the area of objects such as rocks,
toys, wire, sticks, etc., which could be
picked up and thrown by the blade.
Stay behind the handle when the motor
is running.
• Be sure the area is clear of other people
before mowing. Stop machine if anyone
enters the area.
• Do not operate the mower when barefoot or wearing open sandals. Always
wear substantial foot wear.
• Do not pull mower backwards unless
absolutely necessary. Always look down
and behind before and while moving
backwards.
• Never direct discharged material toward
anyone. Avoid discharging material
against a wall or obstruction. Material
may ricochet back toward the operator.
Stop the blade when crossing gravel
surfaces.
• Do not operate the mower without the
entire grasscatcher, discharge guard,
rear guard or other safety protective
devices in place and working.
• Never leave a running machine unattended.
• See manufacturer’s instructions for
proper operation and installation of
accessories. Only use accessories approved by the manufacturer.
• Stop the motor when crossing gravel
drives, walks, or roads.
• Stop the motor whenever you leave the
equipment, before cleaning the mower
or unclogging the chute.
• Shut the motor off and wait until the
blade comes to complete stop before
removing grass catcher.
• Mow only in daylight or good artifi cial
light.
• Do not operate the machine while under
the infl uence of alcohol or drugs.
• Never operate machine in rain or on wet
grass. Always be sure of your footing:
keep a fi rm hold on the handle and
walk; never run.
• Disengage the self-propelled mechanism on mowers so equipped before
starting the motor.
• If the equipment should start to vibrate
abnormally, stop the motor and check
immediately for the cause.
• Vibration is generally a warning of
trouble.
• Always wear safety goggles or safety
glasses with side shields when operating mower.
II. SLOPE OPERATION
Slopes are a major factor related to slip
and fall accidents which can result in
severe injury. All slopes require extra caution. If you feel uneasy on a slope, do not
mow it.
DO:
• Mow across the face of slopes: never
up and down. Exercise extreme caution
when changing direction on slopes.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Tall
grass can hide obstacles.
DO NOT:
• Do not trim near drop-offs, ditches or
embankments. The operator could lose
footing or balance.
• Do not cut excessively steep slopes.
• Do not mow on wet grass. Reduced
footing could cause slipping.
III. CHILDREN
Tragic accidents can occur if the operator is
not alert to the presence of children. Children
are often attracted to the machine and the
mowing activity . Never assume that children
will remain where you last saw them.
• Keep children out of the mowing area
and under the watchful care of another
responsible adult.
• Be alert and turn machine off if children
enter the area.
• Before and while walking backwards,
look behind and down for small children.
Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may obscure vision.
• The mower is not a toy. It can be very
dangerous; children should not use this
mower. Only responsible adults who
have read the manual and understood
all instructions should operate this
mower.
3
SAFETY RULES
IV. GENERAL SERVICE
• Never run a machine inside a closed
area.
• Never make adjustments or repairs with
the motor running.
• Keep nuts and bolts, especially blade
attachment bolts, tight and keep equipment in good condition.
• Never tamper with safety devices.
Check their proper operation regularly.
• Keep machine free of grass, leaves, or
other debris build-up. Allow machine to
cool before storing.
• Stop and inspect the equipment if you
strike an object. Repair, if necessary,
before restarting.
• Never attempt to make wheel height
adjustments while the motor is running.
• Always unplug electric mowers before
adjusting, cleaning or repairing.
• Grass catcher components are subject
to wear, damage, and deterioration,
which could expose moving parts or
allow objects to be thrown. Frequently
check components and replace with
manufacturer’s recommended parts
when necessary.
• Mower blade is sharp and can cut. Wrap
the blade or wear gloves, and use extra
caution when servicing it.
• Do not attempt to change the motor’s
electronic settings or over speed the
motor.
• Maintain or replace safety and instruction labels, as necessary.
• Only use accessories or parts approved
by the manufacturer. Non-approved
parts or accessories can cause serious
injury or damage and will void the warranty.
• This lawnmower is not to be used for
commercial use; Use only on personal
property. It should only be used on
private lawns and should not be used to
cut public parks, playing fi elds, farms,
forests or a large number of lawns.
ASSEMBLY
TO REMOVE MOWER FROM CARTON
• Remove all loose parts from carton.
• Remove lawn mower hous ing with care. Avoid touch ing blade under hous ing. Always
wear gloves or other protection when working under or lifting mower.
CAUTION: Do not operate this lawn mower without the discharge guard or an entire
approved grass catcher in place. These guards are for your protection and are required by
the American National Standards Institute and Consumer Products Safety Com mis sion.
HOW TO SET UP YOUR LAWN
MOW ER
TO UNFOLD HANDLE
IMPORTANT: Unfold handle carefully so
as not to pinch or damage control cables.
• Remove any packing material which
may be between the upper and lower
handles for shipping purposes.
• Pull up and back on the upper handle to
raise the handle into the operating position. Make certain the lower handle is
seated securely into the handle mounting bracket.
• Align the holes between the upper
handle and lower handles. Insert the
cam locks and tighten them with the
wing nuts provided.
• Secure the lower handle to the bracket
with the knob on each side.
Operator
presence
control bar
Wing nut
LIFT
UP
MOWING
POSITION
LIFT
UP
Upper
handle
Cam lock
Lower handle
Handle knob
4
PRE-OPERATION
POLARIZED APPLIANCE
CONNECTIONS
To reduce the risk of electric shock, this
appliance has a polarized plug (one blade
is wider than the other) and will require the
use of a polarized extension cord.
• The appliance plug will fi t into a polarized extension cord only one way. If the
plug does not fi t fully into the extension
cord, reverse the plug. If the plug still
does not fi t, obtain a correct polarized
extension cord.
• A polarized extension cord will require
the use of a polarized wall outlet. This
plug will fi t into the polarized wall outlet
only one way. If the plug does not fi t fully
into the wall outlet, reverse the plug. If
the plug still does not fi t, contact a qualifi ed electrician to install the proper wall
outlet.
IMPORTANT: Do not change the
equipment plug, extension cord receptacle,
or extension cord plug in any way.
2-prong
plug
Properly grounded
extension cord
CAUTION: In all cases, make certain
the receptacle in question is properly
grounded. If you are not sure, have a
certifi ed electrician check the receptacle.
This mower is “Double Insulated”.
WARNING: This mower is for outdoor
use only. Do not expose to rain or use in
damp locations.
• Avoid Dangerous Environment – Don’t
use lawn mowers in damp or wet loca-
tions.
• Don’t Use In Rain.
• Keep Children Away – All visitors should
be kept a safe distance from work area.
• Dress Properly – Do not wear loose
clothing or jewelry. They can be caught
in moving parts. Use of rubber gloves
and footwear is recommended when
working outdoors.
• Use Safety Glasses – Always use face
or dust mask if operation is dusty.
• Use Right Appliance – Do not use lawn
mower for any job except that for which
it is intended.
• Ground Fault Circuit Interrupter (GFCI)
protection should be provided on the
circuit(s) or outlet(s) to be used for the
lawn mower. Receptacles are available
having built-in GFCI protection and may
be used for this measure of safety.
WARNING: To prevent electric shock
use only with an extension cord suitable
for outdoor use, such as SW, SOW, STW,
STOW, SJW, SJOW, SJTW or SJTOW.
• Extension Cord – Make sure your exten-
sion cord set is in good condition. When
using an extension cord, be sure to use
one heavy enough to carry the current
you’re product will draw. An undersize
cord will cause a drop in line voltage, re-
sulting in loss of power and overheating.
The table shows the correct size to use
depending on cord length and name-
plate ampere rating. If in doubt, use the
next heavier gauge. The smaller the
gauge number the heavier the cord.
MINIMUMGAUGEFOREXTENSIONCORDS(AWG)
(WHEN USING 120 V ONLY)
Amp Rating Total Length of Cord in Feet (meters)
More Than Not More Than 25' (7.6 m) 50' (15 m) 100' (30.4 m) 150' (45.7 m)
0 6 18 16 16 14
61018161412
10 12 16 16 14 12
12 16 14 12
Not Recommended
5
PRE-OPERATION
To reduce the likelihood of disconnection of lawn mower cord from the cord set
during operation, use the extension cord
retainer supplied with the mower.
• Don’t Abuse Cord – Never pull lawn
mower by cord or yank it to disconnect
from receptacle. Keep cord from heat,
oil and sharp edges.
• Don’t Force Lawn Mower – It will do the
job better and safer at the rate for which
it was designed.
• Don’t Overreach – Keep proper footing
and balance at all times.
• Stay Alert – Watch what you are doing.
Use common sense. Do not operate
lawn mower when you are tired.
• Disconnect Lawn Mower – Disconnect
the lawn mower from the power supply
when not in use, before servicing, when
changing accessories such as blades,
and the like.
• Store Idle Lawn Mower Indoors – When
not in use, lawn mower should be stored
in an indoor dry and locked-up place
– out of reach of children.
• Maintain Lawn Mower With Care – Keep
cutting edges sharp and clean for best
and safest performance.
• Follow instructions for lubricating and
changing accessories.
• Inspect lawn mower cord periodically
and if damaged, have it repaired by an
authorized service facility.
• Inspect extension cords periodically and
replace if damaged.
• Keep handles dry, clean, and free from
oil and grease.
• Keep guards in place and in working
order.
• Keep blades sharp.
• Keep hands and feet away from cutting
area.
• Objects struck by the lawn mower blade
can cause severe injuries to persons.
The lawn should always be carefully
examined and cleared of all objects prior
to each mowing.
• If lawn mower strikes a foreign object,
follow these steps:
- Stop lawn mower. Release the switch.
- Unplug power cord.
- Inspect for damage.
- Repair any damage before restarting
and operating the lawn mower.
• Use identical replacement blades only.
SAVE THESE INSTRUCTIONS
6
OPERATION
KNOW YOUR LAWN MOWER
READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING
YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize
yourself with the location of various controls and adjustments. Save this manual for
future reference.
Operator presence control bar
Start button
Power
Circuit breaker
cord
Wing
nut
Extension
cord
retainer
Single point height
adjuster handle
Mulcher door
Discharge
guard
Cam lock
Handle
knob
Motor housing
MEETS CPSC SAFETY REQUIREMENTS
Our rotary walk-behind lawn mowers conform to the safety standards of the American
National Standards Institute and the U.S. Consumer Product Safety Commission.
WARNING: The blade turns when the motor is running.
Operator presence control bar – must
be held down to the handle to start the
motor. Release to stop the motor.
Start button – used for starting the motor.
Single point height adjuster – used to
adjust cutting height of lawn mower.
Mulcher door – allows con ver sion to
discharging operation.
7
OPERATION
The operation of any lawn mower can result in foreign objects thrown into
the eyes, which can result in severe eye damage. Always wear safety
glasses or eye shields while operating your lawn mower or performing any
ad just ments or repairs. We recommend standard safety glasses or a wide
vision safety mask worn over spectacles.
HOW TO USE YOUR LAWN MOWER
• Your lawn mower is equipped with an
operator pres ence control bar which
requires the operator to be positioned
behind the lawn mower handle to start
and operate the lawn mower.
CAUTION: Federal reg u la tions require
a motor control to be in stalled on this
lawn mower in order to min i mize the risk
of blade contact injury. Do not un der
any cir cum stanc es attempt to de feat the
func tion of the operator con trol. The blade
turns when the motor is running.
EXTENSION CORD RETAINER
This lawn mower is equipped with a cord
retainer in order to prevent the extension
cord from disconnecting from the power
cord while the mower is in use. The cord
retainer hangs from the cord guide bar.
NOTE: Do not plug the extension cord into
the outlet until it has been connected to the
cord retainer and plugged into the mower.
• Fold the extension cord in order to form
a tight loop near the retainer.
• Push the loop through the hole in the
retainer.
• Slide the loop over the retaining clip, and
pull down until the cord is secured.
TO START
• Press the start button.
• Hold down operator presence control
bar to handle
• Mower will begin to operate.
.
TO STOP
• To stop motor, release operator presence con trol bar.
Let the blade come to a complete stop.
CIRCUIT BREAKER
This mower is equipped with a circuit
breaker in order to protect the supply
circuit from short-circuit overloads.
FOLLOW THESE STEPS IF THE
CIRCUIT BREAKER POPS OUT:
• Release the operator presence control
bar and allow the mower to stop and
cool down for 5 minutes.
• After the mower has cooled down, press
the circuit breaker in order to reset it.
Resume operation.
FOLLOW THESE STEPS IF THE
CIRCUIT BREAKER POPS OUT AGAIN
SHORTLY AFTER THE FIRST TIME:
• Release the operator presence control
bar and allow the mower to stop and
cool down for 15 to 30 minutes.
• After the mower has cooled down, press
the circuit breaker in order to reset it.
Resume operation.
If the circuit breaker does not stay in, or if
it continues to pop out during operation,
contact the Toll-Free Helpline at 1-800849-1297.
TO ADJUST CUTTING HEIGHT
Adjust cutting height to suit your re quire ments. Me di um position is best for most
lawns. Raise wheels for low cut and lower
wheels for high cut. All four wheels are
adjusted by a single lever.
• Pull adjuster lever toward wheel. To
lower mower, move lever forward to
desired position. To raise mow er, move
the lever toward the rear.
8
Height adjuster lever
LEVER
BACKWARD
TO RAISE
MOWER
LEVER
FORWARD
TO LOWER
MOWER
OPERATION
MOWING TIPS
CAUTION: Do not use de-thatcher
blade attachments on your mower. Such
attachments are hazardous, will damage
your mower and could void your warranty.
• Under certain conditions, such as when
mowing very tall grass, raise the mower
height on the fi rst cut to reduce pushing
effort, to avoid over heat ing the motor,
and to avoid leaving clumps of grass
clippings. Make the second cut to the
desired height.
• For extremely heavy cutting, reduce the
width of cut.
• For side discharge operation, cut in a
coun ter clock wise di rec tion, start ing at
the outside of the area to be cut, in order
to spread grass clip pings more evenly
and to put less load on the motor. To
keep clip pings off of walkways, fl ower
beds, etc., make the fi rst cuts in a clock wise direction.
TO CONVERT MOWER
Your lawn mower was shipped ready to
be used as a mulcher. To convert to side
discharging:
• Open mulcher door and install dis charge
defl ector under door as shown.
• Mower is now ready for discharging
operation.
• To convert to mulching operation, dis charge defl ector must be removed and
mulcher door must be closed.
Open mulcher door
• When using a lawn mower in moist,
heavy grass, clumps of cut grass may
not enter the grass catcher. Reduce
ground speed (push ing speed) and/or
run the lawn mower over the area a
second time.
• If a trail of grass clipping is left on the
right side of a rear discharge lawn mower, mow in a clockwise direction with a
small overlap to collect the clippings on
the next pass.
• Pores in cloth grass catchers can
become fi lled with dirt and dust with use
and the catcher will collect less grass.
To prevent this, regularly hose catcher
off with water and let dry before use.
Discharge defl ector
MULCHING MOWING TIPS
IMPORTANT: For best performance, keep
mower housing free of built-up grass and
trash. See "CLEANING" in the Maintenance section of this manual.
9
OPERATION
• The special mulching blade will recut the
grass clip pings many times and reduce
them in size so that as they fall onto the
lawn they will disperse into the grass
and not be noticed. Also, the mulched
grass will bio de grade quickly to provide
nu tri ents for the lawn. Always mulch with
your highest motor (blade) speed as this
will provide the best recutting action of
the blades.
• Avoid cutting your lawn when it is wet.
Wet grass tends to form clumps and
in ter feres with the mulch ing action.
• For best results, adjust the lawn mower
cutting height so that the lawn mower
cuts off only the top one-third of the
grass blades. If the lawn is overgrown it
will be necessary to raise the height of
cut to reduce pushing effort and to keep
from over load ing the motor and leaving
clumps of mulched grass. For ex tremely
heavy grass, reduce your width of cut
by overlapping previously cut path and
mow slowly.
MAX 1/3
• Certain types of grass and grass
con di tions may re quire that an area be
mulched a second time to com pletely
hide the clip pings. When doing a sec ond
cut, mow across (per pen dic u lar) to the
fi rst cut path.
• Change your cutting pattern from week
to week. Mow north to south one week
then change to east to west the next
week. This will help prevent matting and
graining of the lawn.
MAINTENANCE
BEFORE
EACH
USE
Check for Loose Fasteners
Clean / Inspect Grass Catcher
Check Tires
Clean Lawn Mower *
Check / Sharpen / Replace Blade **
Lubrication
* Use a scraper to clean under deck ** Replace blades more often when mowing in sandy soil
GENERAL RECOMMENDATIONS
The warranty on this lawn mower does not
cover items that have been subjected to
operator abuse or negligence. To receive
full value from the war ranty, operator
must maintain mower as instructed in this
manual.
Some adjustments will need to be made
periodically to properly maintain your unit.
All adjustments in the Service and Adjustments section of this manual should be
checked at least once each season.
• Once a year, check blade for wear.
• Follow the Maintenance Sched ule in this
manual.
AFTER
EACH
USE
EVERY
10
HOURS
EVERY
25 HOURS
OR SEASON
BEFORE EACH USE
• Check for loose fasteners.
LUBRICATION
Keep unit well lubricated.
IMPORTANT: Do not oil or grease plastic
wheel bearings. Viscous lu bri cants will
attract dust and dirt that will short en the life
of the self-lu bri cat ing bearings. If you feel
they must be lu bri cated, use only a dry,
pow dered graphite type lubricant sparingly.
BEFORE
STORAGE
10
MAINTENANCE
Trailing
edge
Mulcher door
hinge rod
Spray
lubricant
Handle bracket mounting pins
LAWN MOWER
Always observe safety rules when performing any main te nance.
IMPORTANT: Always unplug electric mowers before servicing, cleaning or removing
material from lawn mower.
TIRES
• Keep tires free of gasoline, oil, or insect
control chemi cals which can harm rubber.
• Avoid stumps, stones, deep ruts, sharp
objects and other hazards that may
cause tire damage.
BLADE CARE
For best results, blade must be kept sharp.
Re place a bent or dam aged blade.
CAUTION: Use only a replacement
blade approved by the manufacturer of
your mower. Using a blade not approved
by the manufacturer of your mower is
hazardous, could damage your mower and
void your warranty.
TO REMOVE BLADE
1. Use a wood block between blade and
mower hous ing to prevent blade from
turning when re mov ing blade nut.
NOTE: Protect your hands with gloves
and/or wrap blade with heavy cloth.
2. Remove blade nut by turning counter-
clockwise.
3. Remove blade and attaching hardware
(nut, square wash er, insulator wash er).
Insulator
washer
Blade
nut
Blade
Square washer
TO REPLACE BLADE
1. Be sure the trailing edge of blade (opposite sharp edge) is up toward the
motor.
2. Install the square washer and insulated
washer; secure with blade nut.
3. Use block of wood between blade and
lawn mower housing and tighten the
blade nut, turning clockwise.
• The recommended tightening torque is
35-40 ft. lbs.
TO SHARPEN BLADE
NOTE: We do not recommend sharp en ing
blade. An un bal anced blade will cause
eventual damage to lawn mower or motor.
CLEANING
WARNING: To reduce the risk of
electric shock, do not expose the mower
to water.
IMPORTANT: For best performance, keep
mower housing free of grass build-up and
trash. Clean the underside of your mower
after each use.
• Clean the underside of your lawn mower
by scraping to remove buildup of grass
and trash.
• Clean motor cover often to keep trash
from accumulating.
• Keep fi nished surfaces and wheels free
of all gasoline, oil, etc.
11
STORAGE
Immediately prepare your lawn mower for storage at the end of the season or if the unit
will not be used for 30 days or more.
LAWN MOWER
When lawn mower is to be stored for a period of time, clean it thor oughly, remove all
dirt, grease, leaves, etc. Store in a clean,
dry area.
• Clean entire lawn mower (See “CLEAN ING” in the Maintenance section of this
manual).
• Lubricate as shown in the Main te nance
section of this manual.
• Be sure that all nuts, bolts, screws, and
pins are securely fas tened. Inspect
moving parts for damage, breakage and
wear. Replace if necessary.
• Touch up all rusted or chipped paint
surfaces; sand lightly before painting.
HANDLE
You can fold your lawn mower han dle for
storage.
1. Loosen the two cam locks on sides of
the upper handle and allow handle to
fold down to the rear.
2. Loosen the two handle knobs on sides
of the lower handle, lift the sides of
the lower handle past the enges of the
handle brackets and pivot entire handle
as sem bly forward and allow it to rest on
mower.
• When setting up your handle from the
storage position, the lower han dle will
require manually locking into the mowing
position.
IMPORTANT: When folding the handle for
storage or transportation, be sure to fold
the handle as shown or you may damage
the control cables.
Operator
presence
control bar
FOLD
FORWARD
FOR
STORAGE
MOWING
POSITION
Upper
handle
Cam lock
Lower handle
Handle knob
EXTENSION CORD
• Wipe extension cord to remove any
foreign substances such as oil or stains.
IMPORTANT: Replace extension cord if
cut or damaged in any way.
• Wind cord in a series of equal loops to
prevent it from tangling.
OTHER
• If possible, store your unit indoors and
cover it to protect it from dust and dirt.
• Cover your unit with a suitable pro tec tive
cover that does not retain mois ture. Do
not use plastic. Plas tic cannot breathe,
which allows con den sa tion to form and
will cause your unit to rust.
12
TROUBLESHOOTING
PROBLEM CAUSE CORRECTION
Does not start 1. Start button not depressed. 1. Press start button and hold
down operator presence
control bar to handle.
2. Extension cord not 2. Reconnect extension cord
connected to power cord. and use cord retainer to keep
the cord in place.
3. Extension cord not 3. Connect extension cord to a
connected to power source. live and properly grounded
120V AC, 60 Hz receptacle.
4. Circuit breaker has tripped. 4. Wait 5 minutes for motor to
cool down. Push circuit
breaker to reset.
5. Loose blade or broken 5. Tighten blade bolt or
blade adapter. replace blade adapter.
6. Operator presence control 6. Press start button and hold
bar in released position. down operator presence
control bar to handle.
7. Operator presence control 7. Replace operator presence
bar defective. control bar.
Loss of power 1. Rear of lawn mower 1. Raise cutting height.
housing or cutting blade
dragging in heavy grass.
2. Cutting too much grass. 2. Raise cutting height.
3. Buildup of grass, leaves, 3. Clean underside of mower
and trash under mower. housing.
4. Walking speed too fast. 4. Cut at slower walking speed.
Poor cut – 1. Worn, bent or loose blade. 1. Replace blade. Tighten
uneven blade bolt.
2. Buildup of grass, leaves 2. Clean underside of
and trash under mower. mower housing.
Excessive 1. Worn, bent or loose blade. 1. Replace blade. Tighten
vibration blade bolt.
Grass catcher 1. Cutting height too low. 1. Raise cutting height.
not fi lling 2. Lift on blade worn off. 2. Replace blade.
(If so equipped) 3. Catcher not venting air. 3. Clean grass catcher.
Hard to push 1. Grass is too high or wheel 1. Raise cutting height.
height is too low.
2. Lawn mower housing or 2. Raise lawn mower housing
or cutting blade dragging one (1) setting higher.
in grass.
3. Grass catcher too full. 3. Empty grass catcher.
4. Handle height position not 4. Adjust handle height to suit.
right for you.
13
WARRANTY
The Manufacturer warrants to the original consumer purchaser that this product as
manufactured is free from defects in materials and workmanship. For a period of
two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing
parts, any part which we fi nd to be defective due to materials or work man ship. This
Warranty is subject to the following limitations and exclusions.
1.This warranty does not apply to the engine, transaxle/transmission components,
battery (except as noted below) or com po nents parts thereof. Please refer to the
applicable manufacturer's warranty on these items.
2.Transportation charges for the movement of any power equipment unit or at tach ment are the responsibility of the purchaser. Transportation charges for any
parts sub mit ted for replacement under this warranty must be paid by the purchaser unless such return is requested by the manufacturer.
3.Battery Warranty: On products equipped with a Battery, we will replace, without
charge to you, any battery which we fi nd to be defective in manufacture, during
the fi rst ninety (90) days of ownership. After ninety (90) days, we will exchange
the Battery, charging you 1/12 of the price of a new Battery for each full month
from the date of the original sale. Battery must be maintained in accordance with
the in struc tions furnished.
4.The Warranty period for any products used for rental or commercial purposes is
limited to 45 days from the date of original purchase.
5.This Warranty applies only to products which have been properly assembled,
adjusted, operated, and maintained in accordance with the instructions fur nished.
This Warranty does not apply to any product which has been subjected to al ter ation, misuse, abuse, improper assembly or installation, delivery damage, or to
normal wear of the product.
6.Exclusions: Excluded from this Warranty are belts, blades, blade adapters, normal wear, normal adjustments, standard hardware and normal maintenance.
7.In the event you have a claim under this Warranty, you must return the product to
an authorized service dealer.
LIMITED WARRANTY
Should you have any unanswered questions concerning this Warranty, contact:
Weed Eater
Customer Service Department
9335 Harris Corners Parkway
Charlotte, NC 28269 USA
giving the model number, serial number and date of purchase of your product and
the name and address of the au tho rized dealer from whom it was pur chased.
THIS WARRANTY DOES NOT APPLY TO INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WAR RAN TIES ARE LIMITED TO THE SAME
TIME PERIODS STATED HEREIN FOR OUR EXPRESSED WARRANTIES.
Some areas do not allow the limitation of consequential damages or lim i ta tions
of how long an implied Warranty may last, so the above lim i ta tions or exclusions
may not apply to you. This Warranty gives you specifi c legal rights, and you may
have other rights which vary from locale to locale.
This is a limited Warranty within the meaning of that term as defi ned in the Magnuson-Moss Act of 1975.
In Canada contact:
Weed Eater
Customer Service Department
5855 Terry Fox Way
Mississauga, Ontario L5V 3E4
14
SERVICE NOTES
15
Loading...
