Weed Eater GBI 30V, GBI 22V User Manual
Specifications and Main Features
- Model: GBI 22V
- Engine Type: 2 Cycle Air Cooled
- Fuel Tank Capacity: 16.6 fl. oz (470 cc)
- Displacement:22cc
- Muffler: Lo Tone
- Velocity: 155 mph (as a blower)
- Engine RPM: Idle 3800-4600, Operating – 6400 – 7000
- Ignition : Solid State
- Ignition Timing: Fix no time
- Carburetor: All Position Diaphragm.
- On/Off Switch: Positive Rocker Switch
- Starter: Auto Rewind
- Lubrication : Gasoline/Oil Mixture 40:1
- Weight: 12lbs (5.5kg)
- Volume: 350 cu.ft/min (as a blower)
- Other Models Operating Capacity:
- GBI 30V : Velocity 170 mph, Operating RPM 7400-8000
- GBI 80V: Volume 360 cu.cu.ft/min (as a blower)
- Spark Plug Type: Champion RCJ-8Y
- Spark Plug GAP: 0.025” (0.63 mm)
- Module Air Gap: 0.010" - 0.014” (0.25 - 0.35 mm)
---
Frequently Asked Questions
- Q: What kind of fuel is suitable to be used in a GBI 22V?
A: The fuel mixture is a combination of gasoline without lead and a high walk 2 cycle engine oil at a rate of 40:1.
- Q: After how long should I change the spark plug?
A: It is advisable to change it after every year
- Q: What about wet debris? Is the use of blower permitted?
A: This unit is designed to only for dry debris including leaves, grasses and small twigs. Never try to vacuum water or other liquid substances for it would cause damage to the engine.
- Q: I want to use a unit as a vacuum cleaner, how do I go about this?
A: Remove the blower tube attach vacuum tubes alongside the vacuum bag assembly. It is important to ensure that vacuum inlet cover is fastened before turning the unit on.
- Q: The unit will not turn on, what do I do?
A: Most often there are a few things amiss such as the ignition switch not being in the right position which is ON or the spark plug isn’t functioning well. The fuel tank might not be filled. Check these factors and then refer to the manual.
- Q: The air filter does not seem to be working fine, how do I clean it?
A: It is advised to cleanse the air filter primarily after every 5 hours of operation or after every 5 tanks of fuel. Remember not to clean air filters using gasoline or any other flammable solvents.
- Q: I am trying to find attachments to the unit for cleaning gutters, are there any?
A: The unit supports a Gutter cleaning attachment kit.
