VTech VSP505 User Manual

User’s manual

VSP505
DECT Cordless Headset

Congratulations

on purchasing your new VTech product. Before using this product, please read
Important safety instructions on page 21 of this manual.

This manual has all the feature operations and troubleshooting necessary to install
and operate your new VTech product. Please review this manual thoroughly to ensure
proper installation and operation of this innovative and feature rich VTech product. For
customer service or product information, visit our website at

businessphones.vtech.com or call 1 [phone].

The ENERGY STAR® program (www.energystar.gov) recognizes and
encourages the use of products that save energy and help protect our
environment. We are proud to mark this product with the ENERGY STAR®

label indicating it meets the latest energy efciency guidelines.

i

Table of Contents

Getting started .............................. 1

Parts checklist ................................. 1

Headset layout ................................ 2

Headset charger installation ........... 3

Power on the headset ..................... 3

Headset charging ............................ 3

Add and register a headset ............. 4

Replace a headset........................... 5

Headset attachments....................... 6

Headset operation ...................... 13

Make a call .................................... 13

Answer a call ................................. 13

End a call ....................................... 13

Ringer ............................................ 13

Temporary ringer silencing ............ 13

Volume control............................... 14

Call waiting .................................... 14

Mute............................................... 14

Switch a call between the SIP telephone

and the headset ......................... 14

Appendix ...................................... 15

Headset indicators ........................ 15

Headset battery ............................. 16

Troubleshooting ............................. 17

Important safety instructions.......... 21

Energy-saving charging mode ...... 22

Precautions for users of implanted

cardiac pacemakers ................... 23

Operating range............................. 23

Maintenance .................................. 23

About cordless headset ................. 24

The RBRC

®

seal ............................ 24

Warranty ........................................ 25

Warranty (continued) ..................... 26

FCC, ACTA and IC regulations ..... 27

FCC, ACTA and IC regulations

(continued) ................................. 28

Technical specications ................ 29

Index ............................................. 30

1

Parts checklist

Your headset package contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.

User’s manual

• The headset battery is not replaceable.

• To purchase a replacement power adapter, visit our website at

businessphones.vtech.com or call 1 [phone].

Cordless
headset

Headset
charger

Headset charger
power adapter

Head band

Getting started

Ear hook

Additional
earbuds (3)

Ear pad

User’s manual

Getting started

2

(on/off)
Press and hold for two seconds to power on or off.
Press to answer or end a call (page 13).
On in red when charging in the headset charger.
On in blue when fully charged in the headset charger.
Flashes once every 10 seconds in blue when in idle mode.
Flashes once every 10 seconds in red when in low battery mode.
Flashes twice every three seconds in blue while on a call.
Flashes quickly and alternately in red and blue while being registered.
Flashes four times every four seconds in blue when there is an incoming call.

Headset layout

MUTE/FLASH

While on a call, press to mute
the microphone (page 14).

While on a call, press and hold
to answer an incoming call when
you receive a call waiting alert
(page 14).

When there is an incoming call,
press to silence the ringer in the
earpiece temporarily.

Microphone

Earpiece

Rotating clip

Connect the ear hook
or head band.

+/–/VOLUME

While on a call, press to adjust
the listening volume (page 14).

When the headset is not in
use, press to adjust the ringer
volume (page 14).

RESET

inset button

3

Getting started

Headset charger installation

Install the headset charger as shown below.

Headset charger

Plug the small end of
the headset charger
power adapter into
the power jack of the
headset charger.

Plug the large end of the headset
charger power adapter into an
electrical outlet not controlled by a
wall switch.

Power on the headset

Power on the headset before use. Place the headset in the headset charger or
press and hold for two seconds. The light ashes three times in blue and you
hear three beeps when the headset is being powered on.

Headset charging

After installing the headset charger,
charge the headset in its charger. The
headset is fully charged after three
hours of continuous charging. If the

light does not turn on while

charging, you need to charge
the headset without interruption for at
least 15 minutes to give the headset
enough charge to use for a short
time. For best performance, keep the
headset in the headset charger when
not in use. See the table on page 16
for battery operating times.

If the headset will not be used for a long time, press and hold for two seconds to
power off the headset. The

light ashes three times in red and you hear three beeps

when the headset is being powered off.

1. Place the tip of the headset
in the small cradle on the
headset charger.

2. The magnet holds
the top of the
headset in place.
The

light turns

on when charging.

Getting started

4

Add and register a headset

Each newly purchased headset (VSP505) must be registered to a compatible VTech
VSP series SIP telephone before use.

The telephone base recognizes and counts a headset the same as a handset. You
can place the headset charger anywhere you have an available power outlet.

You can register one headset to one VTech SIP telephone. If the telephone already
has a headset registered, you need to follow the deregistration instructions on page 5
or in your telephone user’s manual before adding a new headset.

To register a headset:

1. Place the non-registered headset in the headset charger and allow it to charge for
at least 15 minutes before beginning registration.

2. On the telephone, press MENU and then select User settings > DECT headset.

3. Lift the cordless headset out of its charging base, and then place it back in the
charger. The

light on the headset ashes slowly and alternately in red and blue.

4. On the telephone’s DECT headset menu, select 1. Register.

It takes about 60 seconds to complete the registration process. The

light on the

headset turns red when it is registered but not fully charged, or turns blue if it is
registered and fully charged.

If the registration process is successful, you hear a dial tone when you press

on

the headset. If the registration fails, you hear “Not registered” when you press

on

the headset. The

light on the headset ashes slowly and alternately in red and

blue. To reset the headset, remove it from the headset charger and then place it back
into its charger. Try the registration process again.

• You cannot register a headset if any other system handset or headset is in use.
You can only register one headset to the telephone base at a time.

• The headset must be deregistered before registering it to another telephone
system.

Getting started

5

Replace a headset

If you want to replace a headset, you must deregister the headset that is registered to
the telephone base.

To make deregistration easier, read all of the instructions on this page before you begin.

To deregister the headset:

1. Ensure the headset is in the charger.

2. On the telephone, press MENU and then select User settings > DECT headset.

3. On the telephone’s DECT headset menu, select 2. Deregister.

The deregistration process takes up to 10 seconds to complete. There is a

conrmation tone from the telephone base. The

light ashes slowly and alternately

in red and blue when the deregistration process completes.
If the deregistration process is successful, you hear “Not registered” when you press

on the headset. The deskset screen displays “DECT headset is deregistered”. If

the deregistration fails, you may need to:

• remove and replace the headset in the charger and repeat the deregistration
instructions.

-OR-

• reset the headset and repeat the deregistration instructions.

To reset:

• Pick up the registered headset and press the RESET inset button with a paper clip

or similar object.

You cannot deregister a headset if any system handset or headset is in use.

6

Getting started

Headset attachments

Earbud

There are four earbuds provided. The headset comes with one earbud attached.

To remove the earbud from the headset earpiece:

Hold both sides of the earbud and then pull the earbud until it separates from the
earpiece.

To attach the earbud to the headset earpiece:

1. Choose an appropriate earbud.

2. Press the earbud towards the earpiece until it clicks into place. Move the earbud

around so that the protruding bump on the earbud is pointing towards your mouth
when placed on your ear. The protruding bump on the earbud holds the headset
securely in your ear.

Protruding bump

Getting started

7

Headset attachments (continued)

Ear hook

A exible ear hook is provided. Before use, adjust the hook to t your ear comfortably.

To attach the ear hook to the headset:

1. Remove any headset attachment (earbud excluded) connected to the headset.

2. Insert the ear hook [A] into the rotating clip [B] on the headset until it clicks into place.

3. Hook the headset on your right ear. Adjust the angle of the headset until the

microphone is pointing towards your mouth. Firmly grip the earpiece with one hand
whenever adjusting the headset microphone up or down.

[A]

[B]

Getting started

8

Headset attachments (continued)

To adjust the headset to wear on the left ear:

1. Hold the headset with one hand.

Lift the ear hook upward.

2. Twist the ear hook 180 o clockwise.

3. Push the ear hook downward. 4. Hook the headset on your left ear.

Adjust the angle of the headset
until the microphone is pointing towards
your mouth.
