User’s Manual

1MP • Compact Size

Rev. 1.0

VIVOTEK

Table of Contents

Overview

Revision History ��4

Read Before Use �� 5

Package Contents �� 5

Symbols and Statements in this Document ��5

Physical Description �� 6

Install Camera to Stand �� 8

Network Deployment �� 11

IP Address: internal port �� 12

IP Address: External Port (Mapped port on the router) �� 12

Software Installation �� 14

Ready to Use ��15

Accessing the Network Camera

Using Web Browsers �� 16

Using RTSP Players ��19

Using 3GPP-compatible Mobile Devices ��20

Using VIVOTEK Recording Software �� 21

Main Page Client Settings

Conguration

System > General settings �� 32

System > Homepage layout �� 34

System > Logs �� 37

System > Parameters �� 39

System > Maintenance �� 40

Media > Image �� 44

Media > Video �� 51

Media > Video �� 52

Media > Audio�� 56

Network > General settings �� 57

Network > Streaming protocols �� 66

Initial TTL �� 69

Scope �� 69

Network > SNMP Security > User Account �� 76

Security > Security > Access List �� 84

PTZ > PTZ settings �� 89

Event > Event settings�� 93

Applications > Motion detection�� 106

Applications > Digital Input �� 109

Applications > Tampering detection ��109

Recording > Recording settings �� 110

Local storage > SD card management �� 11 5

��

(Simple Network Management Protocol) �� 75

HTTPS (Hypertext Transfer Protocol over SSL)

�� 77

4

16

22 27 31

2 - User's Manual

Local storage > Content management �� 11 6

Appendix

URL Commands for the Network Camera �� 119

Technical Specications �� 194

Technology License Notice ��195

Electromagnetic Compatibility (EMC) ��196

��

VIVOTEK

119

User's Manual - 3

VIVOTEK

Overview

VIVOTEK IP8130 is a compact cube camera designed for indoor surveillance� The elegant design makes it an ideal solution for offices, shops and homes� A built-in microphone further increases the level of surveillance by recording sound within a 5 meter radius� Moreover, the IP8131 is equipped with IR LEDs and provides clear video in completely dark environments�

The IP8130/31 supports the industry-standard H.264 compression technology, drastically reducing le

sizes and conserving valuable network bandwidth� Together with the ST7501 multi-lingual 32-channel recording software, users can set up an easy-to-use IP surveillance system with ease� VIVOTEK also provides the smart phone application iViewer, both on iPhone and Android phones, enable users to monitor live video off-site�

Revision History

■ Rev. 1.0: Initial release

4 - User's Manual

VIVOTEK

i

Read Before Use

The use of surveillance devices may be prohibited by law in your country� The Network Camera

is not only a high-performance web-ready camera but can also be part of a exible surveillance

system� It is the user’s responsibility to ensure that the operation of such devices is legal before installing this unit for its intended use�

It is important to first verify that all contents received are complete according to the Package Contents listed below� Take note of the warnings in the Quick Installation Guide before the Network Camera is installed; then carefully read and follow the instructions in the Installation chapter to avoid damage due to faulty assembly and installation� This also ensures the product is used properly as intended�

The Network Camera is a network device and its use should be straightforward for those who have basic networking knowledge� It is designed for various applications including video sharing, general security/surveillance, etc� The Configuration chapter suggests ways to best utilize the Network Camera and ensure proper operations� For creative and professional developers, the URL Commands of the Network Camera section serves as a helpful reference to customizing existing homepages or integrating with the current web server�

Package Contents

■ IP8130 or IP8131

■ Screws & Plastic Anchors

■ Power Adaptor (+12V, 1A)

■ Camera Stand

■ Software CD

■ Warranty Card

■ Quick Installation Guide

■ Ethernet cable x1

Symbols and Statements in this Document

INFORMATION: provides important messages or advices that might help prevent

inconvenient or problem situations�

NOTE: Notices provide guidance or advices that are related to the functional integrity of

the machine�

Tips: Tips are useful information that helps enhance or facilitae an installation, function,

or process�

WARNING: or IMPORTANT: These statements indicate situations that can be dangerous

or hazardous to the machine or you�

Electrical Hazard: This statement appears when high voltage electrical hazards might

occur to an operator�

User's Manual - 5

VIVOTEK

Physical Description

Front Panel

Lens

Microphone

IP8130

Status LED

MicroSD/SDHC/SDXC

Card Slot

IP8131

Lens

Status LED

IR LEDs

Microphone

Item LED status Description

LED

1 Steady Red Powered and system booting, or network failed

Red LED off Power off

2 Green LED blinks every 1 sec� Connected to network 3 Green, RED, and Orange blink consecutively

every 0�15 sec� 5 Orange blinks every 0�15 sec� Restoring defaults

Upgrading rmware

6 - User's Manual

Rear Panel

Reset Button

VIVOTEK

The back panels are identical for both models.

Power Cord

Socket

1 DI2 DI+ 3 Audio GND 4 Audio Out

Ethernet 10/100 RJ45 Socket

Audio out cable is user-supplied�

General I/O Terminal Block

User's Manual - 7

VIVOTEK

0002D10766AD

IP8130

Install Camera to Stand

Attach the camera to stand and orient the shooting angle� If preferred, use the included screws to secure the the camera stand to a mounting surface�

IMPORTANT:

Record the MAC address before installing the camera�

8 - User's Manual

Digital Input Diagram

Please refer to the following illustration for the connection method�

Max. voltage: 40V

3.3V

DI+

Digital input

DI-

DI-: Ground

VIVOTEK

Connect a digital input device to the input pins of the camera� From the Applications > Digital Input page, you can let camera report the current signal status as High or Low, Open or Ground-

ed, to determine the signal’s Normal status during operation�

User's Manual - 9

VIVOTEK

Hardware Reset

Reset Button

The reset button is used to reset the system or restore the factory default settings� Sometimes resetting the system can return the camera to normal operation� If the system problems remain after reset, restore the factory settings and install again�

Reset: Press and release the reset button� Wait for the Network Camera to reboot�

Restore: Press and hold the recessed reset button until the status LED rapidly blinks� Note that all settings will be restored to factory default� Upon successful restore, the status LED will blink green and red during normal operation�

Micro SD/SDHC/SDXC Card Capacity

This network camera is compliant with Micro SD/SDHC/SDXC of 8, 16, 32GB, 64GB, or 128GB capacity SD cards�

10 - User's Manual

Network Deployment

LAN Connection

1� If you have external devices such as sensors and alarms, make connections from

general I/O terminal block�

2� Connect the camera to a switch via

Ethernet cable�

3� Connect the supplied power cable from

the camera to a power outlet�

Non-PoE Switch

VIVOTEK

POWER

COLLISION

1

LINK

RECEIVE

2

PARTITION

3

4

5

User's Manual - 11

VIVOTEK

L

A

N (

Local Area Network)

R

o

u

t

e

r

I

P

a

d

dre

s

W

A

N (Wide Area Network )

R

o

u

t

e

r

I

P

a

d

dre

s

f

r

o

m

I

S

P

Internet connection via a router

Before setting up the Network Camera over the Internet, make sure you have a router and follow the steps below�

1� Connect your Network Camera behind a router, the Internet environment is illustrated below�

Regarding how to obtain your IP address, please refer to Software Installation on page 14 for details�

IP address : 192.168.0.3 Subnet mask : 255.255.255.0 Default router : 192.168.0.1

IP address : 192.168.0.2 Subnet mask : 255.255.255.0 Default router : 192.168.0.1

Internet

Cable or DSL Modem

WAN (Wide Area Network ) Router IP address : from ISP

LINK

POWER

COLLISION

RECEIVE

1

2

PARTITION

3

4

5

LAN (Local Area Network) Router IP address : 192.168.0.1

2� In this case, if the Local Area Network (LAN) IP address of your Network Camera is 192�168�0�3, please forward the following ports for the Network Camera on the router�

■ HTTP port: default is 80; secondary HTTP port is 8080

■ RTSP port: default is 554

■ RTP port for audio: default is 5558

■ RTCP port for audio: default is 5559

■ RTP port for video: default is 5556

■ RTCP port for video: default is 5557

If you have changed the port numbers on the Network page, please open the ports accordingly on your router� For information on how to forward ports on the router, please refer to your router’s user’s manual�

3� Find out the public IP address of your router provided by your ISP (Internet Service Provider)� Use the public IP and the secondary HTTP port to access the Network Camera from the Internet� Please refer to Network Type on page 57 for details�

For example, your router and IP settings may look like this:

Device IP Address: internal

Public IP of router 122�146�57�120 LAN IP of router 192�168�2�1 Camera 1 192�168�2�10:80 122�146�57�120:8000 Camera 2 192�168�2�11:80 122�146�57�120:8001 ��

12 - User's Manual

port

IP Address: External Port (Mapped port on the router)

VIVOTEK

Congure the router, virtual server or rewall, so that the router can forward any data coming into a precongured port number to a network camera on the private network, and

allow data from the camera to be transmitted to the outside of the network over the same path�

From Forward to 122�146�57�120:8000 192�168�2�10:80 122�146�57�120:8001 192�168�2�11:80 ��

When properly congured, you can access a camera behind the router using the HTTP

request as follows: http://122�146�57�120:8000

If you change the port numbers on the Network conguration page, please open the ports

accordingly on your router� For example, you can open a management session with your

router to congure access through the router to the camera within your local network. Please consult your network administrator for router conguration if you have troubles with the conguration.

For more information with network conguration options (such as that of streaming ports),

please refer to Conguration > Network Settings� VIVOTEK also provides the automatic port forwarding feature as an NAT traversal function with the precondition that your router must support the UPnP port forwarding feature�

Internet connection with static IP

Choose this connection type if you are required to use a static IP for the Network Camera�

Please refer to LAN setting on page 57 for details�

Internet connection via PPPoE (Point-to-Point over Ethernet)

Choose this connection type if you are connected to the Internet via a DSL Line� Please refer to PPPoE on page 58 for details�

User's Manual - 13

VIVOTEK

Software Installation

Installation Wizard 2 (IW2), free-bundled software included on the product CD, helps you set up your Network Camera on the LAN�

IW

1� Install IW2 under the Software Utility directory from the software CD� Double-click the IW2 shortcut on your desktop to launch the program�

2� The program will conduct an analysis of your network environment� After your network environment is analyzed, please click Next to continue the program�

2

Installation

Wizard 2

3� The program will search for all VIVOTEK network devices on the same LAN�

4� After a brief search, the installer window will prompt� Click on the MAC and model name that matches the one printed on the product label� You can then double-click on the address to

open a management session with the Network Camera�

IP8131

0002D10766AD

00-02-D1-73-02-02 192.168.5.151 IP8131

0002D1730202

14 - User's Manual

VIVOTEK

Ready to Use

1� A browser session with the Network Camera should prompt as shown below� 2� You should be able to see live video from your camera� You may also install the 32-channel

recording software from the software CD in a deployment consisting of multiple cameras� For its installation details, please refer to its related documents�

User's Manual - 15

VIVOTEK

Accessing the Network Camera

This chapter explains how to access the Network Camera through web browsers, RTSP players, 3GPP-compatible mobile devices, and VIVOTEK recording software�

Using Web Browsers

Use Installation Wizard 2 (IW2) to access the Network Cameras on LAN� If your network environment is not a LAN, follow these steps to access the Netwotk Camera: 1� Launch your web browser (e�g�, Microsoft

2. Enter the IP address of the Network Camera in the address eld. Press Enter� 3� The live video will be displayed in your web browser�

4. If it is the rst time installing the VIVOTEK network camera, an information bar will pop up as

shown below� Follow the instructions to install the required plug-in on your computer�

®

Internet Explorer or Mozilla Firefox)�

NOTE

NOTE:

► For Mozilla Firefox users, your browser will use Apple’s Quick Time to stream the live video.

If you don’t have Quick Time on your computer, please download it rst, then launch the web

browser�

16 - User's Manual

VIVOTEK

► By default, the Network Camera is not password-protected. To prevent unauthorized access,

it is highly recommended to set a password for the Network Camera� For more information about how to enable password protection, please refer to Security on page 76�

► If you see a dialog box indicating that your security settings prohibit running ActiveX

®

Controls, please enable the ActiveX

Controls for your browser�

®

1� Choose Tools > Internet Options > Security > Custom Level�

2� Look for Download signed ActiveX

®

controls; select Enable or Prompt� Click OK�

3� Refresh your web browser, then install the ActiveX

complete installation�

®

control� Follow the instructions to

User's Manual - 17

VIVOTEK

IMPORTANT:

Currently the Network Camera utilizes 32-bit ActiveX plugin� You CAN NOT open a

•

management/view session with the camera using a 64-bit IE browser� If you encounter this problem, try execute the Iexplore�exe program from C:\

•

Windows\SysWOW64� A 32-bit version of IE browser will be installed� On Windows 7, the 32-bit explorer browser can be accessed from here:

•

C:\Program Files (x86)\Internet Explorer\iexplore�exe

Tips

• The onscreen Java control can malfunction under the following situations: A PC connects to different cameras that are using the same IP address (or the same

camera running different rmware versions). Removing your browser cookies will solve

this problem�

18 - User's Manual

VIVOTEK

Using RTSP Players

To view the MPEG-4 streaming media using RTSP players, you can use one of the following players that support RTSP streaming�

Quick Time Player

VLC

VLC media player 1� Launch the RTSP player you prefer�

mpegable Player

2� Choose File > Open URL� A URL dialog box will prompt� 3� The address format is: rtsp://<ip_address>:<rtsp_port>/<RTSP streaming access name for a

pvPlayer

specic video stream>

VIVOTEK’s network cameras support simultaneous playback of 2 to 5 video streams� The streaming access names for these streams are:

Stream 1 – live�sdp, Stream 2 – live2�sdp, Stream 3 – live3�sdp, Stream 4 – live4�sdp�

As most ISPs and players only allow RTSP streaming through port number 554, please set the RTSP port to 554� For more information, please refer to RTSP Streaming on page 67� For example:

rtsp://192.168.5.151:554/live.sdp

4� The live video will be displayed in your player�

For more information on how to configure the RTSP access name, please refer to RTSP Streaming on page 67 for details�

Video 16:38:01 2012/01/25

User's Manual - 19

VIVOTEK

Using 3GPP-compatible Mobile Devices

To view the streaming media through 3GPP-compatible mobile devices, make sure the Network Camera can be accessed over the Internet� For more information on how to set up the Network Camera over the Internet, please refer to Setup the Network Camera over the Internet on page 12�

To utilize this feature, please check the following settings on your Network Camera:

1� Because most players on 3GPP mobile phones do not support RTSP authentication, make

sure the authentication mode of RTSP streaming is set to disable�

For more information, please refer to RTSP Streaming on page 67�

2� As the the bandwidth on 3G networks is limited, you will not be able to use a large video size�

Please set the video and audio streaming parameters as listed below�

For more information, please refer to Stream settings on page 51�

Video Mode MPEG-4 Frame size 176 x 144 Maximum frame rate 5 fps Intra frame period 1S Video quality (Constant bit rate) 40kbps Audio type (GSM-AMR) 12.2kbps

3� As most ISPs and players only allow RTSP streaming through port number 554, please set

the RTSP port to 554� For more information, please refer to RTSP Streaming on page 67�

4� Launch the player on the 3GPP-compatible mobile devices (e�g�, Real Player)�

5� Type the following URL commands into the player�

The address format is rtsp://<public ip address of your camera>:<rtsp port>/<RTSP streaming access name for stream # with small frame size and frame rate>�

For example:

You can configure Stream #2 into the suggested stream settings as listed above for live viewing on a mobile device�

20 - User's Manual

VIVOTEK

Using VIVOTEK Recording Software

The product software CD also contains an ST7501 recording software, allowing simultaneous monitoring and video recording for multiple Network Cameras� Please install the recording software; then launch the program to add the Network Camera to the Channel list� For detailed information about how to use the recording software, please refer to the user’s manual of the software or download it from http://www�vivotek�com�

User's Manual - 21

VIVOTEK

Main Page

This chapter explains the layout of the main page� It is composed of the following sections: VIVOTEK INC� Logo, Host Name, Camera Control Area, Configuration Area, Menu, and Live Video Window�

VIVOTEK INC. Logo

Camera Control Area

Hide Button

Resize Buttons

Host Name

Configuration Area

Live View Window

VIVOTEK INC. Logo

Click this logo to visit the VIVOTEK website�

Host Name

The host name can be customized to t your needs. For more information, please refer to System on page 32.

Camera Control Area

Video Stream: This Network Camera supports multiple streams (stream 1 ~ 2) simultaneously� You can select either one for live viewing� For more information about multiple streams, please refer to page 81 for detailed information�

Manual Trigger: Click to enable/disable an event trigger manually� Please configure an event setting

on Application page before enable this function. A total of 3 event settings can be congured. For more

information about event setting, please refer to page 92� If you want to hide this item on the homepage, please go to Conguration> System > Homepage Layout > General settings > Customized button to deselect “show manual trigger button”�

22 - User's Manual

VIVOTEK

Conguration Area

Client Settings: Click this button to access the client setting page� For more information, please refer to Client Settings on page 27�

Conguration: Click this button to access the conguration page of the Network Camera. It is suggested

that a password be applied to the Network Camera so that only the administrator can configure the

Network Camera. For more information, please refer to Conguration on page 31.

Language: Click this button to choose a language for the user interface� Language options are available in: English, Deutsch, Español, Français, Italiano,

日本語

, Português,

簡体中文

, and

繁體中文

� Please

note that you can also change a language on the Conguration page; please refer to page 31.

Hide Button

You can click the hide button to hide the control panel or display the control panel�

Resize Buttons

:

Click the Auto button, the video cell will resize automatically to t the monitor.

Click 100% is to display the original homepage size� Click 50% is to resize the homepage to 50% of its original size� Click 25% is to resize the homepage to 25% of its original size�

Live Video Window

■ The following window is displayed when the video mode is set to H�264 / MPEG-4:

H.264 / MPEG-4 Protocol and Media Options

Video Title

Title and Time

Zoom Indicator

Video (TPC-AV)

Video 17:08:56 2012/11/25

x4.0

Video Title: The video title can be congured. For more information, please refer to Video Settings on page 51�

H�264 / MPEG-4 Protocol and Media Options: The transmission protocol and media options for H�264 /

MPEG-4 video streaming. For further conguration, please refer to Client Settings on page 27.

2012/11/25 17:08:56

Time

Video and Audio Control Buttons

Time: Display the current time. For further conguration, please refer to Media > Image > Genral settings on page 44�

Title and Time: The video title and time can be stamped on the streaming video. For further conguration, please refer to Media > Image > General settings on page 44�

User's Manual - 23

VIVOTEK

Audio will project from

Global View: Click on this item to display the Global View window� The Global View window contains a

full view image (the largest frame size of the captured video) and a oating frame (the viewing region of the current video stream). The oating frame allows users to control the e-PTZ function (Electronic Pan/

Tilt/Zoom)� For more information about e-PTZ operation, please refer to E-PTZ Operation on page 89� For more information about how to set up the viewing region of the current video stream, please refer to page 89�

The viewing region of the current video stream

The largest frame size

PTZ Panel: This Network Camera supports both “digital“ (e-PTZ) pan/tilt/zoom control� Please refer to PTZ settiings on page 89 for detailed information�

Video and Audio Control Buttons: Depending on the Network Camera model and Network Camera

conguration, some buttons may not be available.

Snapshot: Click this button to capture and save still images� The captured images will be displayed in a pop-up window� Right-click the image and choose Save Picture As to save it in JPEG (*�jpg) or BMP (*�bmp) format�

Digital Zoom: Click and uncheck “Disable digital zoom” to enable the zoom operation� The navigation

screen indicates the part of the image being magnied. To control the zoom level, drag the slider bar. To

move to a different area you want to magnify, drag the navigation screen�

Pause: Pause the transmission of the streaming media� The button becomes the Resume button after clicking the Pause button�

Stop: Stop the transmission of the streaming media� Click the Resume button to continue transmission�

Start MP4 Recording: Click this button to record video clips in MP4 file format to your computer� Press the

Stop MP4 Recording button to end recording� When you exit the web browser, video

recording stops accordingly. To specify the storage destination and le name, please refer to MP4 Saving Options on page 28 for details�

Volume: When the Mute function is not activated, move the slider bar to adjust the volume on the local computer�

Mute: Turn off the volume on the local computer� The button becomes the Audio On button after clicking the Mute button�

Talk: Click this button to talk to people around the Network Camera� Audio will project from

the external speaker connected to the Network Camera� Click this button transmission�

24 - User's Manual

again to end talking

VIVOTEK

Mic Volume: When the Mute function is not activated, move the slider bar to adjust the microphone volume on the local computer�

Mute: Turn off the Mic volume on the local computer� The button becomes the Mic On button after clicking the Mute button�

Full Screen: Click this button to switch to full screen mode� Press the “Esc” key to switch back to normal

mode�

■ The following window is displayed when the video mode is set to MJPEG:

Video Title

Title and Time

Video (HTTP-V)

Video 17:08:56 2012/06/25

2012/06/25 17:08:56

Time

Video Control Buttons

Video Title: The video title can be congured. For more information, please refer to Media > Image on page 44�

Time: Display the current time� For more information, please refer to Media > Image on page 44�

Title and Time: Video title and time can be stamped on the streaming video� For more information, please refer to Media > Image on page 44

�
