516D

Vishay Sprague

Aluminum Capacitors

+ 85 °C, Miniature, Axial Lead

FEATURES

Fig.1 Component outline.

QUICK REFERENCE DATA

DESCRIPTION VALUE

Nominal case size

ØD x L in mm

Operating temperature

Rated Capacitance range, C

Tolerance on C

Rated voltage range, U

Termination 2 axial leads

Life validation test at 85 °C 2000 hours: Δ CAP ≤ 20 % from

Shelf life at 85 °C 1000 hours: Δ CAP ± 20 % from

DC leakage current rated voltage for 1 minute for

R

R

0.197” x 0.472” [5.0 x 12.0]

to 0.709” x 1.614” [18.0 x 41.0]

- 40 °C to + 85 °C

(- 25 °C to + 85 °C for

315 WVDC - 450 WVDC units)

R

0.47 µF to 10 000 µF

± 20 %

6.3 WVDC to 450 WVDC

initial measurement.

Δ DF x 2 initial specified limit.
Δ DCL ≤ initial specified limit.

initial measurement.

Δ DF 2 x initial specified limit.

Δ

DCL ≤ the initial specified limit.

6.3 WVDC to 100 WVDC units
I < 0.03 CV or 4 µA

(whichever is greater)

rated voltage for 2 minute for

6.3 WVDC to 100 WVDC units
I < 0.01 CV or 3 µA

(whichever is greater)

rated voltage for 1 minute for 160

WVDC to 450 WVDC units

I < 0.1 CV + 40 µA and CV ≤ 1000

I < 0.04 CV + 100 µA and CV > 1000

• High CV per case size

• Low cost

Available

• Solvent resistant construction (through 100 WVDC)

RIPPLE CURRENT MULTIPLIERS

TEMPERATURE

Ambient Temperature Multipliers

≤ + 70 °C 1.27

+ 85 °C 1.0

FREQUENCY (Hz)/CAPACITANCE (µF)

WVDC Cap. (µF) 50 - 60 100 - 120 300 - 400 1kHZ≤ 10 kHZ

0 - 47 0.75 1 1.35 1.57 2.00

6.3 - 100

160 - 450 1 - 100 0.80 1 1.25 1.40 1.60

100 - 470 0.80 1 1.23 1.34 1.50

1000 - 10000 0.85 1 1.10 1.13 1.15

LOW TEMPERATURE PERFORMANCE

MAXIMUM IMPEDANCE RATIO Z

Rated Voltage

(WVDC)

6.3 4.0 10.0

10.0 3.0 8.0

16.0 2.0 6.0

25.0 2.0 4.0

35.0 - 100.0 2.0 3.0

160.0 - 250.0 4.0 12.0

315.0 - 350.0 6.0 -

400.0 - 450.0 15.0 -

Z - 25 °C/Z + 20 °C Z - 40 °C/Z + 20 °C

(T)/Z(+ 20 °C)

MAXIMUM AT 120 Hz

Pb-free

DIMENSIONS in inches [millimeters]

CASE
CODE

Document Number: 42046 For technical questions contact: [e-mail]
Revision: 24-May-05 237

NOMINAL CASE SIZE

D x L

JL 0.197 x .472 [5.0 x 12.0] 0.024 [0.6] 0.56 NR 0.394 x 0.984 [10.0 x 25.0] 0.024 [0.6] 3.10

LL 0.248 x .472 [6.3 x 12.0] 0.024 [0.6] 0.74 PR 0.512 x 1.023 [13.0 x 26.0] 0.024 [0.6] 4.63

LM 0.248 x .472 [6.3 x 12.0] 0.024 [0.6] 0.91 PS 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 5.47

MM 0.315 x .630 [8.0 x 16.0] 0.024 [0.6] 1.00 QS 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 8.26

MN 0.315 x .787 [8.0 x 20.0] 0.024 [0.6] 1.70 QT 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 10.42

NP 0.394 x .827 [10.0 x 21.0] 0.024 [0.6] 2.32 RT 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 12.42

LEAD

DIAMETER

TYPICAL WEIGHT

(Grams)

CASE
CODE

NOMINAL CASE SIZE

D x L

LEAD

DIAMETER

TYPICAL WEIGHT

(Grams)

www.vishay.com

516D

Vishay Sprague

Aluminum Capacitors

+ 85 °C, Miniature, Axial Lead

DIMENSIONS in inches [millimeters]

0.78 [2.0]
Max.

W ± 0.047

[± 1.2]

0.236 ± 1°
[6 ± 1°]

P ± 0.020

[± 0.5]

DIMENSIONS in inches [millimeters] AND PACKAGING QUANTITIES

CASE
CODE

LM B 2.063 [52.4] 0.394 [10.0] 1300

MM B 2.063 [52.4] 0.394 [10.0] 1000

MN B 2.500 [63.5] 0.394 [10.0] 1000
NP B 2.500 [63.5] 0.591 [15.0] 500
NP C 2.874 [73.0] 0.591 [15.0] 500
NR B 2.500 [63.5] 0.591 [15.0] 500
NR C 2.874 [73.0] 0.591 [15.0] 500
PR B 2.500 [63.5] 0.591 [15.0] 350
PR C 2.874 [73.0] 0.591 [15.0] 350
PS B 2.874 [73.0] 0.591 [15.0] 350

TAPING

CODE

JL B 2.063 [52.4] 0.394 [10.0] 1600
LL B 2.063 [52.4] 0.394 [10.0] 1300

TAPE WIDTH W ± 0.059 [1.5] COMPONENT PITCH P ± 0.020 [0.5] QUANTITY PER REEL

White tape for
Positive Polarity

W ± 0.059

[± 1.5]

D

0.047 [± 1.2]
Max.

SPECIFICATIONS

Blue or Yellow Tape
for Negative Polarity

ELECTRICAL DATA

ORDERING EXAMPLE*

Electrolytic capacitor 500D series

SYMBOL DESCRIPTION

µF rated capacitance

± % M = ± 20 %

DC voltage rating at 85 °C

JL see dimensions in millimeters table

6 packaging code

A termination

516D 107M 6R3 JL 6A
6A = Bulk, Uncut leads.
7B = tape and Reel. For case Codes JL, LL, LM, MM, MN,

NP, NR, PR and PS only.
7C = tape and Reel with 2.874” [73.0 mm] tape width (not

stocked) For case Codes NP, NR and PR only.
All items stating (Not stocked) are items that are not

generally stocked unless a Purchase Order is placed. Lead
time is 14 - 16 weeks for these items unless there is excess
inventory.

*Note: For lead (Pb)-free, add suffix E3 to part number.
Example: 516D107M6R3JL6AE3

ELECTRICAL DATA AND ORDERING INFORMATION

CAPACITANCE

(µF

100 516D107M6R3JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.24 110

220 516D227M6R3LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.24 200

330 516D337M6R3LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.24 250

www.vishay.com For technical questions contact: [e-mail] Document Number: 42046
238 Revision: 24-May-05

PART NUMBER

NOMINAL CASE SIZE

D x L

6.3 WVDC at + 85 °C, SURGE = 8 V

LEAD

DIAMETER

Max. DF

at + 20 °C

Max. RIPPLE

at + 85 °C

516D

Aluminum Capacitors

Vishay Sprague

+ 85 °C, Miniature, Axial Lead

ELECTRICAL DATA AND ORDERING INFORMATION

CAPACITANCE

(µF

470 516D477M6R3MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.24 330

1000 516D108M6R3NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.24 600

2200 516D228M6R3PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.24 1020

3300 516D338M6R3PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.24 1200

4700 516D478M6R3QS6A 0.630 x 1.240 [16.0 x 31.5] 0.024 [0.6] 0.24 1500

6800 516D688M6R3QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.24 1840

10000 516D109M6R3QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.24 2260

33 516D336M010JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.2 65

47 516D476M010JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.2 80

100 516D107M010LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.2 130

220 516D227M010LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.2 210

330 516D337M010MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 300

470 516D477M010MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 350

1000 516D108M010NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.2 640

2200 516D228M010PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.2 1090

3300 516D338M010PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.2 1390

4700 516D478M010QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.2 1730

6800 516D688M010QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.2 1930

10000 516D109M010RT6A 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 0.2 2350

22 516D226M016JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.16 60

33 516D336M016JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.16 70

47 516D476M016JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.16 85

100.0* 516D107M016LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.16 160

220.0* 516D227M016MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.16 260

330 516D337M016MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.16 320

470.0* 516D477M016MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.16 430

1000 516D108M016NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.16 770

2200 516D228M016PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.16 1180

3300 516D338M016QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.16 1620

4700 516D478M016QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.16 1840

6800 516D688M016RT6A 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 0.16 2310

10.0* 516D106M025JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.14 40

22.0* 516D226M025JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.14 65

33 516D336M025JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.14 80

47.0* 516D476M025LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.14 100

100.0* 516D107M025LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.14 170

220 516D227M025MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.14 280

330 516D337M025MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.14 380

470 516D477M025NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.14 510

1000 516D108M025PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.14 900

Document Number: 42046 For technical questions contact: [e-mail]
Revision: 24-May-05 239

PART NUMBER

NOMINAL CASE SIZE

D x L

6.3 WVDC at + 85 °C, SURGE = 8 V

10 WVDC at + 85 °C, SURGE = 13 V

16 WVDC at + 85 °C, SURGE = 20 V

25 WVDC at + 85 °C, SURGE = 32 V

LEAD

DIAMETER

Max. DF

at + 20 °C

Max. RIPPLE

at + 85 °C

www.vishay.com

516D

Vishay Sprague

Aluminum Capacitors

+ 85 °C, Miniature, Axial Lead

ELECTRICAL DATA AND ORDERING INFORMATION

CAPACITANCE

(µF

2200 516D228M025QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.14 1480

3300 516D338M025QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.14 1710

4700 516D478M025RT6A 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 0.14 2170

10 516D106M035JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.12 45

22.0* 516D226M035JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.12 70

33 516D336M035LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.12 90

47 516D476M035LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.12 120

100 516D107M035MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.12 210

220 516D227M035MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.12 340

330 516D337M035NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.12 460

470 516D477M035NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.12 610

1000 516D108M035PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.12 1060

2200 516D228M035QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.12 1580

3300 516D338M035QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.12 2050

0.47 516D474M050JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.1 5

1 516D105M050JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.1 10

2.2 516D225M050JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.1 23

3.3 516D335M050JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.1 28

4.7 516D475M050JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.1 34

10 516D106M050JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.1 50

22 516D226M050LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.1 85

33 516D336M050LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.1 110

47 516D476M050LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.1 130

100.0* 516D107M050MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.1 220

220 516D227M050NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.1 410

330 516D337M050NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.1 560

470 516D477M050PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.8] 0.1 730

1000 516D108M050QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.1 1260

2200 516D228M050RT6A 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 0.1 1920

3.3 516D335M063JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 31

4.7 516D475M063JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 37

10.0* 516D106M063JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 55

22 516D226M063LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.08 90

33 516D336M063LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.08 120

47.0* 516D476M063MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.08 160

100 516D107M063MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.08 260

220 516D227M063NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.08 480

330 516D337M063PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.08 650

470 516D477M063PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.08 840

1000 516D108M063QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.08 1330

PART NUMBER

NOMINAL CASE SIZE

D x L

25 WVDC at + 85 °C, SURGE = 32 V

35 WVDC at + 85 °C, SURGE = 44 V

50 WVDC at + 85 °C, SURGE = 63 V

63 WVDC at + 85 °C, SURGE = 79 V

LEAD

DIAMETER

Max. DF

at + 20 °C

Max. RIPPLE

at + 85 °C

www.vishay.com For technical questions contact: [e-mail]
240 Revision: 24-May-05

Document Number: 42046

516D

Aluminum Capacitors

Vishay Sprague

+ 85 °C, Miniature, Axial Lead

ELECTRICAL DATA AND ORDERING INFORMATION

CAPACITANCE

(µF

0.47 516D474M100JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 10

1 516D105M100JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 18

2.2 516D225M100JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 28

3.3 516D335M100JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 34

4.7 516D475M100JL6A 0.197 x 0.472 [5.0 x 12.0] 0.024 [0.6] 0.08 40

10 516D106M100LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.08 60

22 516D226M100MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.08 120

33 516D336M100MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.08 150

47 516D476M100MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.08 190

100 516D107M100NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.08 340

220 516D227M100PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.08 560

330 516D337M100PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.08 750

470 516D477M100QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.08 970

1 516D105M160LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.2 13

2.2 516D225M160LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.2 23

3.3 516D335M160MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 33

4.7 516D475M160MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 39

10 516D106M160MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.2 60

22 516D226M160NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.2 120

33 516D336M160PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.2 170

47 516D476M160PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.2 230

100 516D107M160QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.2 430

1 516D105M200LL6A 0.248 x 0.472 [6.3 x 12.0] 0.024 [0.6] 0.2 13

2.2 516D225M200LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.2 23

3.3 516D335M200MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 33

4.7 516D475M200MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 39

10 516D106M200NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.2 70

22 516D226M200PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.2 140

33 516D336M200PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.2 170

47 516D476M200PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.2 230

100 516D107M200QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.2 430

1 516D105M250LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.2 14

2.2 516D225M250MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 27

3.3 516D335M250MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 33

4.7 516D475M250MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.2 45

10 516D106M250NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.2 70

22 516D226M250PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.2 140

33 516D336M250PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.2 190

47 516D476M250QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.2 260

100 516D107M250QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.2 430

Document Number: 42046 For technical questions contact: [e-mail]
Revision: 24-May-05 241

PART NUMBER

NOMINAL CASE SIZE

D x L

100 WVDC at + 85 °C, SURGE = 125 V

160 WVDC at + 85 °C, SURGE = 200 V

200 WVDC at + 85 °C, SURGE = 250 V

250 WVDC at + 85 °C, SURGE = 300 V

LEAD

DIAMETER

Max. DF

at + 20 °C

Max. RIPPLE

at + 85 °C

www.vishay.com

516D

Vishay Sprague

Aluminum Capacitors

+ 85 °C, Miniature, Axial Lead

ELECTRICAL DATA AND ORDERING INFORMATION

CAPACITANCE

(µF

1 516D105M315LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.2 14

2.2 516D225M315MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.2 27

3.3 516D335M315MN6A 0.315 x .0787 [8.0 x 20.0] 0.024 [0.6] 0.2 36

4.7 516D475M315MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.2 45

10 516D106M315NR6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.2 80

22 516D226M315PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.2 150

33 516D336M315QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.2 210

47 516D476M315QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.2 260

1 516D105M350LM6A 0.248 x 0.630 [6.3 x 16.0] 0.024 [0.6] 0.25 12

2.2 516D225M350MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.25 24

3.3 516D335M350MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.25 32

4.7 516D475M350NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.25 46

10 516D106M350PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.25 85

22 516D226M350PS6A 0.512 x 1.240 [13.0 x 31.5] 0.024 [0.6] 0.25 140

33 516D336M350QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.25 190

47 516D476M350QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.25 260

1 516D105M400MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.25 14

2.2 516D225M400MN6A 0.315 x 0.787 [8.0 x 20.0] 0.024 [0.6] 0.25 28

3.3 516D335M400NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.25 38

4.7 516D475M400NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.25 46

10 516D106M400PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.25 85

22 516D226M400QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.25 150

33 516D336M400QT6A 0.630 x 1.633 [16.0 x 41.5] 0.031 [0.8] 0.25 210

47 516D476M400RT6A 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 0.25 290

1 516D105M450MM6A 0.315 x 0.630 [8.0 x 16.0] 0.024 [0.6] 0.25 14

2.2 516D225M450MN6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.25 31

3.3 516D335M450NP6A 0.394 x 0.827 [10.0 x 21.0] 0.024 [0.6] 0.25 38

4.7 516D475M450NP6A 0.394 x 1.024 [10.0 x 26.0] 0.024 [0.6] 0.25 50

10 516D106M450PR6A 0.512 x 1.024 [13.0 x 26.0] 0.024 [0.6] 0.25 85

22 516D226M450QS6A 0.630 x 1.240 [16.0 x 31.5] 0.031 [0.8] 0.25 150

33 516D336M450QT6A 0.709 x 1.614 [18.0 x 41.0] 0.031 [0.8] 0.25 230

Note

* These values are normally stocked. Other ratings available as special order.

PART NUMBER

NOMINAL CASE SIZE

D x L

315 WVDC at + 85 °C, SURGE = 365 V

350 WVDC at + 85 °C, SURGE = 400 V

400 WVDC at + 85 °C, SURGE = 450 V

450 WVDC at + 85 °C, SURGE = 500 V

LEAD

DIAMETER

Max. DF

at + 20 °C

Max. RIPPLE

at + 85 °C

www.vishay.com For technical questions contact: [e-mail]
242 Revision: 24-May-05

Document Number: 42046
