Prof ess iona l Perf orm ance for the Ho me

™

Overchilled Chardonnay will underwhelm any

pairing. And there are no recipes calling for not-quite-fresh cilantro. Refrigeration is every bit as crucial

to the kitchen as broilers and burners. So Viking offers a complete line of refrigeration products to

complement the high-performance kitchen with exceptional features and design.

The refrigerator/freezers keep fruits, vegetables, and meats in ideal climate conditions. Freestanding

models deliver roomy cold storage to existing cabinet space, while all-refrigerator and all-freezer units offer

extra-large capacity and dedicated performance. Refrigerated drawers add 5.8 cubic feet of convenient cold

storage to your cabinetry. And undercounter wine cellars keep bottles chilled within easy reach. The undercounter

ice machine supplies more than enough ice for just about any occasion. Refrigerated beverage centers

provide handy cold storage indoors or out. And the beverage dispenser keeps refreshments quite refreshed.

These marvels of the modern kitchen are available in both the Professional and Designer Series

with an incredible array of options – guaranteeing that both your vegetables

and your kitchen are incredibly fresh.

Frost-free refrigerator professional features

ProChill™Temperature Management System

• Variable speed single compressor system includes

the quietest, most technologically advanced

compressor available

• Electronic controls maintain temperature within

1 degree F (.83 degree C)

• Multi-channel airflow system removes odors and

excess humidity

Fresh food items are at or above waist level, allowing less

bending and stooping to retrieve food

Three drawers – two moisture-controlled produce drawers

plus the full-width Convertible Meat Savor™/Produce

Drawer – make up the colder-than-fresh-food-section Chill

Zone

Convertible Meat Savor/Produce Drawer with precision ball-

bearing glides can be set for either produce or long-term

fresh meat storage with its separate temperature control

Quick chill option chills foods and beverages in minutes

Two moisture-adjustable, see-through produce drawers

with precision ball-bearing glides for large item storage

• Moisture can be adjusted for fresh, leafy vegetables

or crisp fruits and vegetables

• Easy access – even with door at 90 degree opening

One full-width and four half-width tempered glass shelves

are adjustable to allow customized shelf placement

Two magnetically sealed in-the-door dairy compartments

with see-through, lift-up covers

Additional storage in five large aluminum door bins with

tempered glass fronts – four are adjustable

Full lighting illuminates interior when door opens

Frost-free freezer professional features

Full-extension main freezer compartment pulls out like a

drawer for easy access to bulky frozen foods

• Opens quietly and easily, with ball bearing rollers

which glide on a steel track

• Positive self-closing feature ensures a good seal

• Upper freezer basket slides independently of main

freezer compartment; ideal for fragile or frequently

used items

Adaptive defrost controls the timing of the defrost

periods, instead of an electromechanical defrost timer

• Extends to 96 hours – improves food storage

because the unit defrosts less often

Factory installed automatic ice maker features

large capacity ice bucket

• Ice container slides out with upper freezer basket

for easy access to ice

• Ice container is “positively located” so it is always

in position to catch dispensing cubes when the

freezer drawer is closed

Built-in 36" wide bottom-mount refrigerator/freezers

DDBB363 36" Wide

Designer Model

VCBB363/VIBB363 36" Wide

Professional Model

These refrigerator/freezers don’t just store your food. They protect it. A range of steady temperatures maintains the freshness of

all your essential items – everything from cheese to meat. Variable moisture settings provide the perfect environment for both fresh,

leafy greens and crisp summer fruits. And the freezer rolls out like a drawer, allowing easy access to even the bulkiest items.

All this and a compressor so quiet, you’ll never know it’s there.

VIBB363 – 36" wide Professional integrated bottom-mount model in Stainless Steel

Door alarm sounds

and glows when freezer

drawer has been open

for three minutes.

The three drawer Chill Zone may

be set up to five degrees colder

than refrigerator temperature.

• Ice maker is deactivated when the freezer is

open, ensuring ice will not dispense when

drawer is open

Door alarm sounds and glows to warn that fresh food

door and/or freezer drawer have been ajar for three

minutes and that the temperature has risen above

normal operating range

Easy maintenance and cleanup

Front venting sealed refrigeration system works silently

and efficiently

• Top mounted to allow full use of space in bottom

rear of unit

24" depth keeps items in back within easy reach

Spillproof tempered glass shelves contain spills and

leaks, preventing leakage to lower shelves and drawers

• Removable for take-to-the-sink cleanup

The Meat SavorTM/Produce Drawer’s

separate temperature control can be

set on “Cold” to keep vegetables crisp,

or on “Max Cold” for longer-term fresh

meat storage.

Power interruption switch behind removable top grille

completely turns off power to unit for safe cleaning and

light bulb replacement

Adjustable height lower kickplate removes to provide

easy access to evaporator pan

Professional-style construction

Design and basic dimensions provide built-in appearance

with standard cabinetry

Exterior moisture control system prevents condensation

• Tubes from warm side of the sealed system run around

perimeter of door and bottom drawer – preventing

condensation without electric components for true

energy efficiency

Easy-opening doors

• Hinges are hidden to provide a uniform appearance

• Heavy-duty, commercial-style handles on

Professional model; distinctive, ergonomically

designed handles on Designer model

• Must be ordered either right- or left-hinge

(specify R or L after model number)

Dual magnet door seal system with spring-loaded

self-closing feature

Door stops are factory set at 110 degree swing; easily

adjust to 90 or 120 degree swing

White interior with stylish accents

Removable upper grille

Black lower kickplate

Thin wall and door construction, coupled with high-density

insulation, provides maximum interior space

Refrigerated items are located at or

above waist level, allowing less bending

to retrieve frequently used items.

DDBB363R – 36" wide

Designer bottom-mount

model in Stainless Steel

Four independent, front adjustable levelers make installation

quick and easy

True 24" deep product – door and cabinet design allows

refrigerator to fit flush into 24" deep installation cutout, allowing

a uniform installation that blends into cabinetry (VIBB and

DDBB models)

Standard accessories

See-through egg bin with carrier holds up to 24 eggs

Glass butter tray and cover

Installation accessory

72" wide stainless steel upper grille kit (Professional –

PBRTGK72SS; Designer – DBRTGK72SS)

• For use with installation of two 36" wide bottom-mount

refrigerator/freezers side-by-side

• Creates a “single unit” look

Optional accessories

Professional stainless steel side panel kits

Designer stainless steel side panel kits

Stainless steel top kit

Side panel hardware kit; Designer model only

• Allows custom side panels to be mounted on

right- and left-hand sides of unit

Two magnetically sealed in-the-door dairy compartments

with see-through, lift-up covers

Additional storage in four large, adjustable aluminum

door bins with tempered glass fronts

Full lighting illuminates interior when door opens

Frost-free freezer professional features

Adaptive defrost controls the timing of the defrost periods,

instead of an electromechanical defrost timer

• Extends to 96 hours – improves food storage because

the unit defrosts less often

Factory installed automatic ice maker features

full-width, large capacity bucket

• Transparent drawer front allows viewing of ice supply

(non-dispenser model)

• Slide-out ice drawer provides convenient access and

is positioned for easy reach

Three adjustable wire shelves for custom storage

Two slide-out, large capacity wire baskets provide easy

storage viewing; dispenser model has one basket

Additional storage with three large aluminum door bins with

tempered glass fronts

Door alarm sounds and glows to warn that fresh food and/or

freezer door have been ajar for three minutes and that the

temperature has risen above normal operating range

Frost-free refrigerator professional features

ProChill™Temperature Management System

• Variable speed single compressor system includes

the quietest, most technologically advanced

compressor available

• Electronic controls maintain temperature within

1 degree F (.83 degree C)

• Multi-channel airflow system removes odors and

excess humidity

Moisture-controlled crisper(s) and the full-width

Convertible Meat Savor™/Produce Drawer make up the

colder-than-fresh-food-section Chill Zone

Convertible Meat Savor/Produce Drawer with precision

ball-bearing glides can be set for either produce or long-

term fresh meat storage with its separate temperature

control

Quick chill option chills foods and beverages in minutes

Moisture-adjustable, see-through produce drawer(s)

with precision ball-bearing glides for large item storage

• Moisture can be adjusted for fresh, leafy vegetables

or crisp fruits and vegetables

• Easy access – even with door at 90 degree opening

Five adjustable, full-width tempered glass shelves

Conveniently located deli drawer(s) store meats and

cheeses at waist level

Built-in 42" and 48"wide side-by-side refrigerator/

DDSB483 48" Wide

Designer Model

VCSB483/VISB483

48" Wide

Professional Model

DDSB423 42" Wide

Designer Model

VCSB423/VISB423 42" Wide

Professional Model

DDSB483D 48" Wide

Designer Model

with Dispenser

VCSB483D/VISB483D 48" Wide Professional Model with Dispenser

DDSB423D 42" Wide

Designer Model

with Dispenser

VCSB423D/VISB423 42" Wide

Professional Model

with Dispenser

Quantity, it is said, has a quality all its own. And you’ll be well prepared for any feast with the tremendous capacity and

exceptional features of these side-by-side models. From the ripest watermelon to the most tender tenderloin, every item is moisture

controlled and temperature perfect. Five tempered glass shelves, two in-the-door dairy compartments, and four adjustable door bins

create a veritable refrigerated pantry. And the freezer provides large capacity adjustable storage with adaptive defrost so you can

forget about freezer burn. What’s missing? Only unwanted moisture, odors, and noise.

VCSB423 – 42" wide

Professional side-by-side

model in Stainless Steel

freezers

The 42" wide side-by-side

refrigerator/freezers have

room for everything from

pineapples to parfaits.

Two dairy compartments

with see-through, lift-up covers

provide additional storage for

special dairy products

(48" wide model shown).

The full-width, large capacity

ice bucket holds ice in an easily

accessible slide-out drawer

(non-dispenser model).

Easy maintenance and cleanup

Front venting sealed refrigeration system works

quietly and efficiently

• Top mounted to allow full use of space in bottom

rear of unit

24" depth keeps items in back within easy reach

Spillproof, tempered glass shelves contain spills to

aid cleanup

• Removable for take-to-the-sink cleanup

Power interruption switch behind removable top grille

completely turns off power to unit for safe cleaning and

light bulb replacement

Adjustable height lower kickplate removes to provide

easy access to evaporator pan

Professional-style construction

Design and basic dimensions provide built-in

appearance with standard cabinetry

Exterior moisture control system prevents

condensation

• Tubes from the warm side of the sealed system

run through center post of cavity – preventing

condensation without electric components for

true energy efficiency

Easy-opening doors

• Hinges are hidden to provide a uniform appearance

• Heavy-duty, commercial-style handles on

Professional model; distinctive, ergonomically

designed handles on Designer model

Dual magnet door seal system with spring-loaded

self-closing feature

Door stops are factory set at 110 degree swing;

easily adjust to 90 or 120 degree swing

White interior with stylish accents

Removable upper grille

Black lower kickplate

Thin wall and door construction, coupled with high-

density insulation, provides maximum interior space

Four independent, front adjustable levelers make

installation quick and easy

True 24" deep product – door and cabinet design

allows refrigerator to fit flush into 24" deep installation

cutout, allowing a uniform installation that blends into

cabinetry (VISB and DDSB models)

Five adjustable, full-width

tempered glass shelves, which

contain spills for easy cleanup,

allow customized shelf place-

ment (48" wide model shown).

The integrated model

provides the ability

to install the door

flush with standard

24" wide countertop

(VISB483D shown).

Electronic Temperature Control System maintains the desired

temperature within 1 degree (48" wide model shown).

Large fruits and

vegetables store

easily in the two

moisture adjustable

produce drawers

(48" wide model

shown).

Ice and water dispenser features (select models)

Through-the-door dispenser provides cubed ice,

crushed ice, and chilled water

Convenient location and operation

• Positioned for easy, one-hand operation

• Reduces need for opening door and also

conserves energy

Reversing ice dispenser motor clears jams

Premium water filter provides a cleaner ice and water

supply by filtering bad tastes, odors, sediment, and

harmful contaminants

• Conveniently located in bottom of refrigerator

compartment for easy removal and installation

of replacement cartridges

Standard accessories

See-through egg bin with carrier holds up to 24 eggs

Glass butter tray and cover

Optional accessories

Professional stainless steel side panel kits

Designer stainless steel side panel kits

Stainless steel top kits

Side panel hardware kit; Designer models only

• Allows custom side panels to be mounted on right-

and left-hand sides of unit

Replacement water filter for dispenser models

DDSB483 – 48" wide

Designer side-by-side

model in Stainless Steel

Built-in 30" and 36" wide all-refrigerators and all-

VCRB304/VIRB304 & VCFB304/VIFB304

30" Wide Professional Models

ProChill™Temperature Management System

Variable speed single compressor system includes

the quietest, most technologically advanced com-

pressor available

Electronic controls maintain temperature to within

1 degree F (.83 degree C)

Multi-channel airflow system removes odors and

excess humidity

Professional features – All-refrigerator

Convertible Meat Savor™/Produce Drawer with precision

ball-bearing glides can be set for either produce or

long-term fresh meat storage with its separate

temperature control

Quick chill option chills foods and beverages in minutes

Two moisture-adjustable, see-through produce drawers

with precision ball bearing glides for large item storage

• Moisture can be adjusted for fresh, leafy

vegetables or crisp fruits and vegetables

• Easy access – even with door at 90 degree opening

Adjustable, tempered glass shelves allow customized

shelf placement

• 30" wide models have four full-width shelves

• 36" wide models have four half-width shelves and

two full-width shelves

Two conveniently located deli drawers store meats

and cheeses

Two magnetically sealed in-the-door dairy

compartments with see-through, lift-up covers

Additional storage in large, adjustable aluminum

door bins with tempered glass fronts

• 30" wide models have four full-width door bins

• 36" wide models have two half-width door bins

and three full-width door bins

Full lighting illuminates interior when door opens

Professional features – All-freezers

Adaptive defrost controls the timing of the defrost

periods, instead of an electromechanical defrost timer

• Extends to 96 hours – improves food storage

temperatures because the unit defrosts less often

Factory installed automatic ice maker features

full-width, large capacity ice drawer with two

separate ice pans

Six adjustable half-width wire shelves for custom storage

Two full-width slide-out, large capacity wire baskets

with tempered glass fronts

Additional storage with large adjustable aluminum

door bins with tempered glass fronts

• 30" wide models have three full-width door bins

• 36" wide models have four half-width door bins

and one full-width door bin

VCRB364/VIRB364 & VCFB364/VIFB364

36" Wide Professional Models

DDRB304 & DDFB304

30" Wide Designer Models

DDRB364 & DDFB364

36" Wide Designer Models

Whether it’s sorbet for the white linen set or burgers for the block party, Viking all-refrigerators and all-freezers provide dedicated

cold storage to handle any occasion. And of course their premium features and exacting temperature controls are up to the task.

So when you finally decide to broil that duck, you won’t have to dig for it – and it won’t taste freezer-burned.

VCRB364R – 36" wide Professional all-refrigerator and VCFB304L – 30" wide Professional all-freezer

freezers

Meat Savor™/Produce Drawer

features its own temperature

control and enough space to

store an entire deli tray.

DFRB304R – 30" wide custom front all-refrigerator and DFFB304L – 30" wide custom front all-freezer

Easy maintenance and cleanup

Front venting sealed refrigeration system works

quietly and efficiently

• Top mounted to allow full use of space in the

bottom rear of the unit

24" depth keeps items in back within comfortable reach

Power interruption switch behind removable top grille

completely turns off power to unit for safe cleaning

and light bulb replacement

Adjustable height lower kickplate removes to provide

easy access to evaporator pan

Professional-style construction

Design and basic dimensions provide built-in

appearance with standard cabinetry

Exterior moisture control system prevents condensation

• Tubes from the warm side of the sealed system

run through center post of cavity – preventing

condensation without electric components for

true energy efficiency

Dual magnet door seal system with spring-loaded

self-closing feature

Door stops are factory set at 110 degree swing; easily

adjust to 90 or 120 degree swing

Thin wall and door construction, coupled with high-

density insulation, provides maximum interior space

Four independent, front adjustable levelers make

installation quick and easy

True 24" deep product-door and cabinet design allow

refrigerator or freezer to fit flush into 24" deep installation

cabinetry (VIRB, VIFB, DDRB, and DDFB models)

Standard accessories – All-refrigerators

See-through egg bin with carrier holds up to 24 eggs

Glass butter tray and cover

Installation accessories

Professional grille kits in 60", 66", and 72" widths

Designer grille kits in 60", 66", and 72" widths

Energy Star

All-freezer models are Energy Star qualified

The all-refrigerator and all-freezer

models combine exceptional

features with extra large capacity.

DFSB483 – 48" wide custom front side-by-side model with custom handles

Exterior options

Viking refrigerator/freezers may also be ordered with

a custom front exterior option

Custom front models blend seamlessly into cabinetry

with locally supplied front panels; customer may

purchase Viking Professional or Designer handles, or

opt for custom handles

Special features

Fully integrated depth allows refrigerator to fit flush

with countertops or cabinet and drawer fronts

Concealed trim allows refrigerator to be fully

integrated with no visible cabinet trim exposed

Small size top grille retains the look of a professional

product

Grille is designed for easy attachment of a locally

supplied custom grille to further conceal refrigerator;

instructions are provided with each product, with

details on how to easily fabricate the custom grille

Optional accessories

Professional handle kits

• Available in stainless steel or brass

Designer handle kits

• Available in stainless steel or brass

Top grille kits and center trim kit

• For use with installation of two refrigerators

and/or freezers

! Side panel hardware kit

• Allows custom side panels to be mounted on

right- and left-hand sides of unit

DFBB363 36" Wide Custom Front Model Custom Handles

Custom front models

Viking refrigerators and freezers are available in stainless steel and 13 exclusive color finishes. But your kitchen design may call

for an integrated look. Our custom front refrigerator/freezers blend seamlessly into any cabinetry.

DFRB304 & DFFB304 30" Wide Custom Front Models Designer Handles

DFRB364 & DFFB364 36" Wide Custom Front Models Professional Handles

Custom front models may be purchased with Professional or Designer handles, or used with custom handles.

DFSB483 48" Wide Custom Front Model Custom Handles

DFSB423 42" Wide Custom Front Model Custom Handles

DFSB423D 42" Wide Custom Front Model with Dispenser Custom Handles

DFSB483D 48" Wide Custom Front Model with Dispenser Custom Handles

Freestanding 36" wide refrigerator/freezers

Frost-free freezer professional features

Factory installed automatic ice maker

Adaptive defrost

Bottom-mount models have two slide-out baskets

Side-by-side models:

• Non-dispenser model has five door bins; three tilt

outward for easy access

• Dispenser model has four door bins; three tilt

outward for easy access

All models shown with optional top grille accessory.

Viking freestanding cabinet-depth refrigerator/freezers deliver professional performance into standard cutouts. At 36" wide

and 24" deep, these models fit perfectly into your existing kitchen cabinetry – and they really make the space work with surprising

storage capacity and an array of ultra-premium features.

Design features

“Cabinet Depth” design (24" deep side panels)

integrates with surrounding cabinetry

Optional accessory kits available to create “built-in”

or “wrapped” looks

Frost-free refrigerator professional features

Temperature adjustable Meat Savor™/Produce

Drawer can be set for either produce or long-term fresh

meat storage with its separate temperature control

Two moisture-adjustable, see-through produce drawers

Side-by-side models have separate adjustable

temperature control for door bin area

Four slide-out adjustable tempered glass spillproof

shelves (all models); one stationary glass shelf (bottom-

mount models only)

In-the-door dairy compartment with cover

Additional storage in large door bins

• Bottom-mount models have four door bins (three

half-width, one full width)

• French door bottom-mount models have five

door bins; two bins store gallon containers

• Side-by-side models have five door bins; three

bins store gallon containers

VCFF036 36" Wide

French Door

Bottom-Mount

Professional Model

VCBF036 36" Wide

Bottom-Mount

Professional Model

VCSF036 36" Wide

Side-by-Side

Professional Model

VCSF036D 36" Wide

Side-by-Side

Professional Model

with Dispenser

DDFF036 36" Wide

French Door

Bottom-Mount

Designer Model

DDBF036 36" Wide

Bottom-Mount

Designer Model

DDSF036 36" Wide

Side-by-Side

Designer Model

DDSF036D 36" Wide

Side-by-Side

Designer Model

with Dispenser

VCBF036R – 36" wide Professional bottom-mount model shown with optional top grille and side trim kit accessories to create “built-in” look

The French-door bottom-mount model

offers grand access to cold storage and

convenient waist-high freezer space.

DDBF036L – 36" wide Designer bottom-mount model shown with optional top grille and side panel accessories to create “wrapped” look

Max ice feature automatically adjusts

freezer temperature to optimal

setting for maximum ice production.

Electronic control features

Electronic controls with digital temperature

readouts maintain the selected temperatures in both

refrigerator and freezer compartments

Water filter indicator light illuminates when water filter

needs replacing (select models)

Max ice feature sets freezer temperature to optimal

setting for maximum ice production

Door open alarm warns when door has been ajar for

five minutes

High temperature alarm warns if refrigerator or freezer

temperatures exceed normal operating temperatures

Vacation mode allows the freezer to defrost less

frequently, conserving energy

Ice and water dispenser features (select models)

Internal filtered water dispensing

Premium water filter provides cleaner water supply

by filtering bad tastes, odors, sediment, and harmful

contaminants

Through-the-door dispenser provides cubed ice,

crushed ice, and chilled water in easy one-hand

operation

Lock prevents unwanted dispensing and allows for

easy cleaning

Auto nightlight illuminates dispenser area when

room is dark

Heavy-duty stainless steel doors reveal tremendous adjustable

storage and professional features including digital controls.

Standard accessories

See-through egg bin with carrier holds up to 24 eggs

Glass butter tray

Optional accessories

Replacement water filter

Side trim and top grille kits for “built-in” look

! Side panel, top grille, and top kits for “wrapped” look

Energy Star

All models are Energy Star qualified

After the premium water filter removes

bad tastes and contaminants, the

dispenser provides ice and chilled water

with easy one-hand operation.

24" wide refrigerated drawers

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Adjustable leveling legs

Custom front model

Blends seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking

Professional or Designer handles, or opt for custom

handles

Optional accessories

Professional handle kit for custom front model

• Available in stainless steel or brass

Designer handle kit for custom front model

• Available in stainless steel or brass

Four-piece pan set with lids

Adjustable divider for upper drawer

Adjustable divider for lower drawer

Equipped with a range of professional features including automatic cycle defrost, full-extension drawer glides, and LED lighting,

Viking refrigerated drawers deliver 5.8 cubic feet of convenient cold storage to any standard 24" undercounter space.

Professional features

5.8 cubic feet of storage

Inside temperature can be adjusted from 33 to

45 degrees F (.6 to 7.2 degrees C)

Stainless steel interior

Full extension drawer glides

Vertical storage of wine bottles or two-liter drink

bottles in bottom drawer

Hidden touchpad control with LED digital

temperature readout

Interior LED lighting

Automatic cycle defrost

DURD140D

Designer Model

DFRD140D

Custom Front

Model

VURD140D

Professional Model

Free up precious

cold real estate with

plenty of extra room

for tall bottles and

large containers.

DFRD140D – 24" wide custom front refrigerated drawers with custom handles

15" wide refrigerated beverage centers

Professional features

Two full-depth adjustable wire shelves pull out for

easy access

One full-depth, tempered glass shelf creates a

distinct temperature zone for wine storage

Inside temperature can be adjusted from 39-42

degrees F (4.0-5.6 degrees C) to 54-56 degrees F

(12-13 degrees C)

Wine rack in bottom cradles five bottles horizontally

Interior light turns on when door is opened or by switch

Automatic cycle defrost

3.0 cubic feet of storage

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Available in black or white interior

Reversible glass door shipped standard right-hinge

(Professional models); Designer models and solid door

units must be ordered either right- or left-hinge (specify

R or L after the model number)

Can be installed as a single unit, double stacked, or

side-by-side in standard depth residential cabinets

Adjustable leveling legs

Agency-certified Professional outdoor model

With the same features as the indoor unit, a stainless

steel exterior cabinet surrounds the unit and forms a

water-resistant seal

Insulated electrical terminals, sealed electrical

contacts, and a water-resistant thermostat provide

optimal performance in all weather elements

Normal operating range is between 40 and 110 degrees

F (4.4 and 43.4 degrees C); it is recommended that the

unit be shut off in temperatures above 110 degrees F

(43.4 degrees C) and below 40 degrees F (4.4 degrees C)

Custom front models

Blend seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking Professional

or Designer handles, or opt for custom handles

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

Trim kit for 18" wide cutout

VUAR151F

Professional Model

Fluted Glass

VUAR150D

Professional Model

Solid Door

VUAR151

Professional Model

Clear Glass

DUAR151F

Designer Model

Fluted Glass

DUAR151

Designer Model

Clear Glass

DUAR150D

Designer Model

Solid Door

All models

available with

black or

white interior.

With adjustable shelves and adjustable temperature control, the 15" wide beverage centers offer handy cold storage.

Always have your whites, lagers, or juices on hand and chilled to refreshing perfection. Indoors or out, these

models can turn a small space into a big time.

VUAR150R – 15" wide

Professional refrigerated

beverage center

DFUR151F

Custom Front Model

Professional Handle

Fluted Glass

DFUR151

Custom Front Model

Designer Handle

Clear Glass

DFUR151F

Custom Front Model

Designer Handle

Fluted Glass

DFUR151

Custom Front Model

Professional Handle

Clear Glass

Clear or fluted glass available.

24" wide refrigerated beverage centers

Professional features

Top wire shelf has 6 1/2" flip-up section to chill or store

open wine bottles or large containers

Two full-depth, tempered glass shelves, combined

with the top wire shelf, hold 148 12-oz. cans

Full-depth shelves create distinct temperature zones

for wine storage

Inside temperature can be adjusted from 39-42

degrees F (4.0-5.6 degrees C) to 54-56 degrees F

(12-13 degrees C)

Two wine shelves in bottom cradle 14 bottles

horizontally

• Shelves can be removed to store large bottles

Interior light turns on when door is opened or by switch

Automatic cycle defrost

6.1 cubic feet of storage

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Available in black or white interior

Reversible glass door shipped standard right-hinge

(Professional models); Designer models and solid door

units must be ordered either right- or left-hinge (specify

R or L after model number)

Can be installed as a single unit, double stacked, or side-

by-side in standard depth residential cabinets

Adjustable leveling legs

Agency-certified Professional outdoor model

With the same features as the indoor unit, a stainless

steel exterior cabinet surrounds the unit and forms a

water-resistant seal

Insulated electrical terminals, sealed electrical

contacts, and a water-resistant thermostat provide

optimal performance in all weather elements

Normal operating range is between 40 and110 degrees F

(4.4-43.4 degrees C); it is recommended that the unit be

shut off in temperatures above 110 degrees F (43.4

degrees C) and below 40 degrees F (4.4 degrees C)

Custom front models

Blend seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking Professional

or Designer handles, or opt for custom handles

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

VUAR140

Professional Model

Clear Glass

VUAR140F

Professional Model

Fluted Glass

VUAR140D/VUAR140T

Professional Model

Solid Door

DUAR140D

Designer Model

Solid Door

DUAR140

Designer Model

Clear Glass

DUAR140F

Designer Model

Fluted Glass

Select models

available with

black or

white interior.

Whether pulling the cork on a buttery Chardonnay or popping open a soda, the proper temperature makes all the difference.

The 24" wide beverage centers offer enough capacity to keep any party going, and adjustable temperature controls ensure

every sip poured will be exactly cold enough.

VUAR140D – 24" wide

Professional refrigerated

beverage center

in Stone Gray

DFUR140

Custom Front Model

Designer Handle

Clear Glass

DFUR140F

Custom Front Model

Designer Handle

Fluted Glass

DFUR140 Custom Front Model Professional Handle

Clear Glass

DFUR140F

Custom Front Model

Professional Handle

Fluted Glass

DFRI140D

Custom Front Model

Custom Handle

24" wide refrigerated beverage centers with ice maker

Professional features

Inside temperature can be adjusted from 33 to 45

degrees F (0.6 to 7.2 degrees C) in beverage section

and 5 to 15 degrees F (-15 to -9.4 degrees C) in

ice maker section

Automatic cycle defrost

6.1 cubic feet of storage

• One full-depth removable wire shelf

• Three door shelves

Ice maker producer 2 lb. of ice per day

Ice bin stores up to 5 lb. of ice

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Can be installed as a single unit, double stacked, or

side-by-side in standard depth residential cabinets

Adjustable leveling legs

Agency-certified Professional outdoor model

With the same features as the indoor unit, a stainless

steel exterior cabinet surrounds the unit and forms a

water-resistant seal

Insulated electrical terminals, sealed electrical

contacts, and a water-resistant thermostat provide

optimal perfor mance in all weather elements

Custom front models

Blend seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking Professional

or Designer handles, or opt for custom handles

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

DURI140D

Designer Model

Solid Door

Keep the night sparkling with a steady supply of crisp, clean ice and cold refreshment. The beverage centers equipped with ice maker

offer a one-stop party armory. And the outdoor model will even keep those summer nights cool.

DFRI140D

Custom Front Model

Custom Handle

VURI140D/VURI140T Professional Model

Solid Door

Select models

available with

black or

white interior.

DUR1140D – 24" wide Designer refrigerated

beverage center

with ice maker

Shaken, stirred, or bottled –

the 24” beverage center

with ice maker ensures every

drink you serve will be

perfectly refreshing.

Built-in 30" wide full-height wine cellars

Professional features

Temperature control

Exclusive TriTemp™Storage System provides three

independent temperature zones

• Preserves different types of wine at optimal

serving temperatures

• Settings are adjustable in each zone from

43 to 65 degrees F (6 to 18 degrees C)

Electronic control center constantly monitors

and maintains the set temperature in each zone within

1.5 degrees F (.83 degrees C)

Exclusive glass control pad

Shelving/Capacity

15 shelves accommodate up to 150 full-size wine

bottles horizontally, keeping corks moist

• Stores standard, magnum, and half-size bottles

• Full-width shelves pull out for easy access

and are fully removable for easy cleaning

• Exclusive – two convertible wine shelves adjust

for bottle display, and are excellent for allowing

bottles to settle before serving

• Shelves are coated to reduce vibration and

hold bottles snugly in place

Solid maple facings may be finished to coordinate with

surrounding cabinetry

Protection

Maintains constant 60% humidity level

Ultraviolet-resistant tempered glass and black interior

protects wine from harmful light

Lower zone has raised maple facings for additional

ultraviolet protection

Low-intensity interior lighting

• Displays wine with minimal heat and light output

• Turns on when door is opened or by switch

High-temperature and open-door alarms may be

connected to a home security system

Keyed lock on door provides extra security

Easy maintenance and cleanup

Removable shelves and upper grille for easy cleaning

Power interruption switch completely turns off power

to unit for safe cleaning and light tube replacement

Front venting sealed refrigeration system works silently

and efficiently

Adjustable height lower kickplate removes to provide

easy access to evaporator pan

DDWB300F

Designer Model

Fluted Glass

DDWB300

Designer Model

Clear Glass

VCWB300

Professional Model

Clear Glass

The Viking wine cellars are

available in a clear glass door

or fluted glass door.

VCWB300F

Professional Model

Fluted Glass

Viking full-height wine cellars provide the most secure environment for your most precious liquid assets. Adjustable temperate

zones, humidity control, and ultraviolet protection keep up to 150 bottles of your favorite varietals safe from harmful light,

heat, and vibration. And you won’t have to negotiate any dark staircases to find tonight’s perfect pairing.

Lower zone has raised

maple facings for

additional UV protection.

Exclusive TriTemp™storage system

preserves different types of wine at

optimal serving temperatures.

VCWB300R – 30" wide Professional wine cellar

Exclusive glass

control pad

Professional-style construction

Design and basic dimensions provide built-in

appearance with standard cabinetry

Dual magnet/spring assist door seal system

automatically closes wine cellar door

Door stops are factory set at 110 degree swing;

easily adjust to 90 or 120 degree swing

Must be ordered either right- or left-hinge

(specify R or L after model number)

Custom front models

Blend seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking

Professional or Designer handles, or opt for

custom handles

Fully integrated depth allows wine cellar to fit flush

with countertops or cabinet and drawer fronts

Concealed trim allows wine cellar to be fully

integrated with no visible cabinet trim exposed

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

Professional stainless steel side panel kits

Designer stainless steel side panel kits

! Side panel hardware kit; Designer models only

• Allows custom side panels to be mounted on

right- and left-hand sides of unit

Stainless steel top kit

The Viking custom front wine cellars

are available in a clear glass door

or fluted glass door.

DFWB300F

Custom Front Model

Designer Handle

Fluted Glass

DFWB300

Custom Front Model

Designer Handle

Clear Glass

DFWB300F Custom Front Model Professional Handle

Fluted Glass

DFWB300 Custom Front Model Professional Handle

Clear Glass

Coated shelves reduce

vibration and hold bottles

snugly in place.

The Electronic Control Center maintains the desired temperature in each zone within 1.5 degrees F.

DFWB300R – 30" wide custom front wine cellar with custom handle

15" wide wine cellars

Professional features

Six wire shelves store up to 24 wine bottles horizontally,

keeping corks moist

• Roller rack shelves extend for easy loading

and unloading

• Shelves are coated to reduce vibration and hold

bottles snugly in place

• Shelves can be removed to store large bottles

• Locks on racks prevent shelves from being

removed inadvertently

Inside temperature can be adjusted from 40-43

degrees F (4.4-6.1 degrees C) to 64-66 degrees F

(17.8-18.9 degrees C)

• Preserves different types of wine at optimal

serving temperatures

Ultraviolet-resistant tempered glass and black interior

protect wine from harmful light

Maple wood facings provide additional ultraviolet

protection and may be finished to coordinate with

surrounding cabinetry

Low intensity interior lighting

• Displays wine with minimal heat and light output

• Turns on when door is opened or by switch

Keyed lock on glass door models provides extra security

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Can be installed as a single unit, double stacked, or

side-by-side in standard depth residential cabinets

Must be ordered either right- or left-hinge (specify R

or L after the model number)

Adjustable leveling legs

Custom front models

Blend seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking

Professional or Designer handles, or opt for

custom handles

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

Trim kit for 18" wide cutout

VUWC152F

Professional Model

Fluted Glass

DUWC152

Designer Model

Clear Glass

DUWC152F

Designer Model

Fluted Glass

VUWC152D

Professional Model

Solid Door

VUWC152

Professional Model

Clear Glass

DUWC152D

Designer Model

Solid Door

Cellar temperature is a far cry from refrigerator temperature, and room temperature for serving isn’t quite room temperature for

most homes. So what’s the casual, yet discerning wine collector to do? Install a Viking 15" wide wine cellar. This undercounter

model stores up to 24 bottles at the perfect serving temperature, corks moist, ready for toasting.

VUWC152R – 15" wide Professional undercounter wine cellar

DFUW152

Custom Front Model

Designer Handle

Clear Glass

DFUW152F

Custom Front Model

Designer Handle

Fluted Glass

DFUW152 Custom Front Model Professional Handle

Clear Glass

DFUW152F

Custom Front Model

Professional Handle

Fluted Glass

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Must be ordered either right- or left-hinge (specify R

or L after model number)

Can be installed as a single wine cellar, double

stacked, or side-by-side in standard depth residential

cabinets

Adjustable leveling legs

Custom front models

Blend seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking

Professional or Designer handles, or opt for

custom handles

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

Professional features

Six wire shelves store up to 54 wine bottles horizontally,

keeping corks moist

• Roller rack shelves extend for easy loading

and unloading

• Shelves are coated to reduce vibration and hold

bottles snugly in place

• Shelves can be removed to store large bottles

• Locks on racks prevent shelves from being

removed inadvertently

Inside temperature can be adjusted from 40-43

degrees F (4.4-6.1 degrees C) to 64-66 degrees F

(17.8-18.9 degrees C)

• Preserves different types of wine at optimal

serving temperatures

Ultraviolet-resistant tempered glass and black interior

protect wine from harmful light

Maple wood facings provide additional ultraviolet

protection and may be finished to coordinate with

surrounding cabinetry

Low-intensity interior lighting

• Displays wine with minimal heat and light output

• Turns on when door is opened or by switch

Keyed lock on glass door models provides extra security

VUWC142

Professional Model

Clear Glass

VUWC142D

Professional Model

Solid Door

VUWC142F

Professional Model

Fluted Glass

DUWC142

Designer Model

Clear Glass

DUWC142F

Designer Model

Fluted Glass

DUWC142D

Designer Model

Solid Door

24" wide wine cellars

Not every wine enthusiast has the luxury of subterranean storage. But thanks to Viking 24"wide wine cellars, your collection

can go undercounter instead of underground. Store up to 54 bottles horizontally at the perfect temperature, so you can pull

every cork with confidence.

VUWC142R – 24" wide Professional undercounter wine cellar

DFUW142

Custom Front Model

Professional Handle

Clear Glass

DFUW142F

Custom Front Model

Professional Handle

Fluted Glass

DFUW142

Custom Front Model

Designer Handle

Clear Glass

DFUW142F

Custom Front Model

Designer Handle

Fluted Glass

15" wide ice machine

Professional features

Produces up to 35 lb. of clear ice in 24 hours

3/4" cube thickness

35 lb. capacity ice bin

Draining process automatically removes old ice

• Ice collects in the bin, then gradually melts

through the drain to ensure a constant supply

of fresh ice

Heavy-duty ice scoop

Equipped with cleaning mode

Professional-style construction

Undercounter or freestanding installation

Heavy-duty, commercial-style handle on Professional

model; distinctive, ergonomically designed handle on

Designer model

Permanently lubricated sealed compressor and

pump ensure long life and professional performance

Stainless steel ice cutter

Must be ordered either right- or left-hinge (specify

R or L after model number)

Adjustable leveling legs

Agency-certified Professional outdoor model

Stainless steel exterior cabinet surrounds unit and

forms water-resistant seal

Insulated electrical terminals, sealed electrical

contacts, and a water-resistant thermostat provide

optimal performance in all weather elements

Normal operating range is between 45 and 110

degrees F (7.2 and 42 degrees C); it is recommended

that the unit be shut off in temperatures above 110

degrees F (43.4 degrees C) and below 40 degrees F (4.4

degrees C)

Kickplate and covered ice bin fronts are stainless steel

Custom front model

Blends seamlessly into cabinetry with locally supplied

front panels; customer may purchase Viking Professional

or Designer handles, or opt for custom handles

Optional accessories

Professional handle kit for custom front models

• Available in stainless steel or brass

Designer handle kit for custom front models

• Available in stainless steel or brass

Trim kit for 18" wide cutout

Sealed reservoir drain pump

• For use when a floor drain is not available

Draining process melts old

ice, ensuring a constant

supply of clear ice.

The Replacement Collection icon indicates this

product can be installed in existing cutouts with

little or no cabinetry alterations.

Never underestimate the ice cube, for ice is truly the life of any party. No matter how lively the conversation is, nobody’s sticking

around for tepid margaritas. The Viking ice machine ensures you have a steady supply of crisp, clean ice all night long. So you

can concentrate on your mixology instead of dashing out to the convenience store.

VUIM150DR – 15" wide Professional ice machine

VUIM150/VUIM150T Professional Model

DUIM150

Designer Model

DFIM150

Custom Front Model

24" wide refrigerated beverage dispensers

Professional features

Built-in or portable models available

Spacious interior holds up to one half-barrel

Includes an easy-to-clean and use stainless steel

dispensing tower

Threaded tower tap handle allows custom handles

to be installed

Portable model is easily moved by four heavy-duty

casters, two that may be locked

Packaged with a filled 5 lb. (2.3 kg) CO2cylinder,

keg coupler, air line with clamps, and a single-gauge

regulator

Agency-certified for outdoor use

Stainless steel exterior cabinet surrounds the unit and

forms a water-resistant seal

Insulated electrical terminals, sealed electrical

contacts, and a water-resistant thermostat provide

optimal performance in all weather elements

Normal operating range is between 40 and 110

degrees F (4.4 and 43.4 degrees C); it is recommended

that the unit be shut off in temperatures above 110

degrees F (43.4 degrees C) and below 40 degrees F

(4.4 degrees C)

Factory set for the ideal beverage storage

temperature of 38 degrees F (3.3 degrees C)

Temperature adjustable from 35 to 54 degrees F

(2 to 12 degrees C)

Optional accessories

1-qt. cleaning kit to clean lines and faucet

• Includes 1-qt. cleaner, tap and line cleaner,

faucet wrench, and faucet brush

4-oz. bottle of tap and line cleaning solution

Faucet lock with keyed entry

VRBD140T

Portable Model

There are a number of excellent reasons to own a Viking beverage dispenser: the Super Bowl, Final Four, Indy 500, Masters,

World Series, and every weekend in between. Available as a built-in or portable unit, the beverage dispenser keeps a half-barrel

of your favorite frosty beverage on tap. Now that’s entertainment.

VRBD140T – 24" wide portable beverage dispenser

VRBD140TR – 24" wide built-in beverage dispenser

stainless steel

biscuit

stone gray

graphite gray

black

white

almond

Design integrity

Consistency in both performance and design should be a major consideration when building or remodeling a home. With the complete

Viking indoor or outdoor kitchen, every single product works together in form and function with the same level of excellence. It’s something

Viking calls Design Integrity™.

Viking is the only company that offers complete ultra-premium kitchens – so Viking is also the only company that can offer truly

consistent design, while delivering the quality and performance that makes Viking the true market leader. Across all product categories,

the knobs, handles, bezels, curves, angles, and lines all match. This enables the designer to create a perfectly harmonious kitchen in

one of three Viking product offerings – Professional Indoor, Designer Indoor, or Professional Outdoor.

You wouldn’t install mismatched cabinets and drawers or countertops. Yet design differences are even more dramatic between multiple

appliance manufacturers. Traditional or contemporary. Stainless steel or color finishes. No matter the look you’re going for, no one can

match the Viking kitchen and Viking Design Integrity.

Exclusive finishes

Professional indoor refrigeration products

Built-in refrigerator/freezers and solid door undercounter

products

• Available in Stainless Steel (SS), Black (BK), White (WH),

Almond (AL), Biscuit (BT), Stone Gray (SG), Graphite

Gray (GG), Burgundy (BU), Lemonade (LE), Mint

Julep (MJ), Forest Green (FG), Viking Blue (VB),

Cobalt Blue (CB), and Eggplant (EP)

• Built-in refrigerator/freezers may be ordered with

Brass Trim Option (BR) for nameplate, door

handle/brackets, and side trim

• Undercounter products may be ordered with Brass Trim

Option (BR) for nameplate and door handle/brackets

Freestanding refrigerator/freezers and Refrigerated

drawers available in Stainless Steel (SS) only

Refrigerated beverage centers and undercounter wine

cellars also available in a clear or fluted glass door with a

stainless steel frame

• May be ordered with Brass Trim Option (BR)

for nameplate and door handle/brackets

Built-in full-height wine cellars

• Available in a clear or fluted glass door with a

stainless steel frame

• May be ordered with Brass Trim Option (BR)

for nameplate and door handle/brackets

Professional outdoor refrigeration products

Refrigerated beverage centers, ice machines, and

beverage dispensers are available in solid door option

only, in Stainless Steel (SS)

May be ordered with Brass Trim Option (BR) for

nameplate and door handle/brackets

burgundy

lemonade

mint julep

forest green

viking blue

cobalt blue

eggplant

Single Stacked Side-by-side

Refrigerated beverage centers and undercounter wine cellars – installation configurations

Indoor refrigeration products

• Two-year full covers complete unit

• Six-year full – sealed refrigeration system (all products)

and automatic ice maker (refrigerator/freezers)

• Twelve-year limited – sealed refrigeration system

(includes compressor, condenser, dryer/strainer,

evaporator, and connecting tubing)

• Ninety-day limited – cosmetic parts such as glass,

painted items, and decorative items

Outdoor refrigeration products

• One-year full covers complete unit

• Five-year limited – sealed refrigeration system

• Ninety-day limited – cosmetic parts such as glass,

painted items, and decorative items

Warranty highlights

Designer refrigeration products

Built-in refrigerator/freezers and solid door undercounter

products

• Available in Black (BK), White (WH), Stainless Steel (SS),

Biscuit (BT), Stone Gray (SG), and Graphite Gray (GG)

• May be ordered with Brass Trim Option (BR) for

door handles

Built-in refrigerator/freezers also available in custom

front models

Freestanding refrigerator/freezers

• Available in Stainless Steel (SS) only

Refrigerated drawers available in Stainless Steel (SS) and

custom front models

Refrigerated beverage centers and undercounter wine

cellars also available in a clear or fluted glass door with a

stainless steel frame, or custom front frame

• May be ordered with Brass Trim Option (BR) for

nameplate and door handle/brackets

Built-in full-height wine cellars

• Available in a clear or fluted glass door with a

stainless steel frame or custom front frame

• May be ordered with Brass Trim Option (BR) for door

handle (clear or fluted door models only)

All brass components have a durable, protective coat-

ing for maintenance-free normal use

Viking uses the most up-to-date process and best materials

available to produce all color finishes, however, slight color

variation may be noticed because of inherent differences in

painted parts and porcelain parts, as well as differences in

room lighting, product locations, and other factors

Basic specifications – built-in bottom-mount refrigerator/freezers

* Custom front models (with 3/4" panels) fit flush in 25" deep cabinet openings with no protrusion into room, except for handles. They can be installed in standard 24" deep openings with the door face and top grille protruding 3/4" into the room.

VCBB363

Professional

VIBB363

Professional Integrated

Description

3 6 " W I D E B U I L T - I N

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

36" (91.4 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

35 1/2" (90.2 cm) minimum; 35 3/4" (90.8 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 15.2 cu. ft. (430.4 L); Freezer – 5.1 cu. ft. (144.4 L); Total capacity – 20.3 cu. ft. (574.8 L)

Approximate Shipping Weight

565 lb. (254.3 kg)

9.9 amps

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

36" (91.4 cm)

DDBB363

Designer

DFBB363

Custom Front

B O T T O M - M O U N T R E F R I G E R A T O R / F R E E Z E R S

(59.4 cm) (61.0 cm) (67.3 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To end of handle bracket – 26" (66.0 cm)

490 lb. (221 kg)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

25" (63.5 cm)*

Basic specifications – built-in side-by-side refrigerator/freezers

VCSB423

Professional

VISB423

Professional Integrated

Description

4 2 " W I D E B U I L T - I N

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

42" (106.7 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

41 1/2" (105.4 cm) minimum; 41 3/4" (106 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 15.0 cu. ft. (424.8 L); Freezer – 9.0 cu. ft. (254.9 L); Total capacity – 24.0 cu. ft. (679.7 L)

Approximate Shipping Weight

652 lb. (293.4 kg)

9.9 amps

VCSB423D

Professional

VISB423D

Professional Integrated

Description

4 2 " W I D E B U I L T - I N S I D E - B Y - S I D E

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

42" (106.7 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

41 1/2" (105.4 cm) minimum; 41 3/4" (106 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 15.0 cu. ft. (424.8 L); Freezer – 8.6 cu. ft. (243.4 L); Total capacity – 23.6 cu. ft. (667.9 L)

Approximate Shipping Weight

676 lb. (304.2 kg)

11.5 amps

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

42" (106.7 cm)

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

42" (106.7 cm)

DDSB423

Designer

DFSB423

Custom Front

S I D E - B Y - S I D E R E F R I G E R A T O R / F R E E Z E R S

DDSB423D

Designer

DFSB423D

Custom Front

R E F R I G E R A T O R / F R E E Z E R S W I T H I C E A N D W A T E R D I S P E N S E R

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To end of handle bracket – 26" (66.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To end of handle bracket – 26" (66.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

25" (63.5 cm)*

642 lb. (289 kg)

595 lb. (267.8 kg)

665 lb. (299.3 kg)

605 lb. (272.3 kg)

(59.4 cm) (61.0 cm) (67.3 cm)

VCSB483

Professional

VISB483

Professional Integrated

Description

Basic specifications – built-in side-by-side refrigerator/freezers

4 8 " W I D E B U I L T - I N

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

48" (121.9 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

47 1/2" (120.7 cm) minimum; 47 3/4" (121.3 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 18.5 cu. ft. (523.9 L); Freezer – 8.9 cu. ft. (252.0 L); Total capacity – 27.4 cu. ft. (775.9 L)

Approximate Shipping Weight

715 lb. (321.8 kg)

9.9 amps

VCSB483D

Professional

VISB483D

Professional Integrated

Description

4 8 " W I D E B U I L T - I N S I D E - B Y - S I D E

Overall Width

Overall Height from Bottom

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

48" (121.9 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

47 1/2" (120.7 cm) minimum; 47 3/4" (121.3 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 18.5 cu. ft. (523.6 L); Freezer – 8.6 cu. ft. (243.4 L); Total capacity – 27.1 cu. ft. (767.0 L)

Approximate Shipping Weight

735 lb. (330.8 kg)

11.5 amps

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

48" (121.9 cm)

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

48" (121.9 cm)

DDSB483

Designer

DFSB483

Custom Front

S I D E - B Y - S I D E R E F R I G E R A T O R / F R E E Z E R S

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To end of handle bracket – 26" (66.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

25" (63.5 cm)*

DDSB483D

Designer

DFSB483D

Custom Front

R E F R I G E R A T O R / F R E E Z E R S W I T H I C E A N D W A T E R D I S P E N S E R

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To end of handle bracket – 26" (66.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

25" (63.5 cm)*

705 lb. (317.3 kg)

650 lb. (292.5 kg)

730 lb. (328.5 kg)

675 lb. (303.8 kg)

(59.4 cm) (61.0 cm) (67.3 cm)

Basic specifications – built-in all-refrigerators and all-freezers

VCRB364/VCFB364

Professional

VIRB364/VIFB364

Professional Integrated

Description

3 6 " W I D E B U I L T - I N

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

36" (91.4 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

35 1/2" (90.2 cm) minimum; 35 3/4" (90.8 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

VCFB Only – 1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 22.8 cu. ft. (645.2 L); Freezer – 19.1 cu. ft. (540.5 L)

Approximate Shipping Weight

570 lb. (256.5 kg)

9.5 amps

VCRB304/VCFB304

Professional

VIRB304/VIFB304

Professional Integrated

Description

3 0 " W I D E

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

30" (76.2 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To front edge of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 11/16" (62.7 cm) To end of handle bracket – 27 1/4" (69.2 cm)

29 1/2" (74.9 cm) minimum; 29 3/4" (75.6 cm) maximum

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz – 5' (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

VCFB Only – 1/4" copper tubing – 20 psi minimum; 120 psi maximum

Overall Interior Capacity

Refrigerator – 18.2 cu. ft. (515.1 L); Freezer – 15.9 cu. ft. (450.0 L)

Approximate Shipping Weight

505 lb. (227.3 kg)

9.1 amps

Note: See Installation Instructions for information on dual installations.

VIFB Only – 1/4" copper tubing – 20 psi 120 psi maximum

VIRB – 505 lb. (227.3 kg); VIFB – 530 lb.

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

30" (76.2 cm)

VIFB Only – 1/4" copper tubing – 20 psi 120 psi maximum

VIRB – 570 lb. (256.5 kg); VIFB – 585 lb.

To front edge of side trim – 23 3/8" To front of top grille – 24" To end of handle bracket – 26 1/2"

36" (91.4 cm)

VIRB – 9.9 amps; VIFB – 6.5 amps

DDRB364/DDFB364

Designer

DFRB364/DFFB364

Custom Front

A L L - R E F R I G E R A T O R S A N D A L L - F R E E Z E R S

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To front edge of door trim – 26" (66.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

DDFB Only – 1/4" copper tubing – 20 psi minimum; 120 psi maximum

DFFB Only – 1/4" copper tubing – 20 psi minimum; 120 psi maximum

DDRB304/DDFB304

Designer

DFRB304/DFFB304

Custom Front

B U I L T - I N A L L - R E F R I G E R A T O R S A N D A L L - F R E E Z E R S

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24" (61.0 cm) To front edge of door trim – 26" (66.0 cm)

To front edge of side trim – 23 3/8" (59.4 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

DDFB Only – 1/4" copper tubing – 20 psi minimum; 120 psi maximum

DFFB Only – 1/4" copper tubing – 20 psi minimum; 120 psi maximum

495 lb. (222.8 kg)

465 lb. (209.3 kg)

555 lb. (249.8 kg)

515 lb. (231.8 kg)

minimum;

(238.5 kg)

(59.4 cm) (61.0 cm) (67.3 cm)

minimum;

(263.3 kg)

(59.4 cm) (61.0 cm) (67.3 cm)

9.1 amps

9.5 amps

Basic specifications – freestanding refrigerator/freezers

VCBF036/VCFF036 Professional and DDBF036/DDFF036 Designer

Description

3 6 " W I D E F R E E S T A N D I N G B O T T O M - M O U N T R E F R I G E R A T O R /

Overall Width

Overall Height

Overall Depth from Rear to Front of Door

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Inlet Water Requirement

35 5/8" (90.5 cm)*

70 1/8" (178.1 cm)**

26 3/4" (67.9 cm)

36" (91.4 cm)

70 1/2" (179.0 cm)

24" (61.0 cm)

115VAC/60Hz, 15 amp dedicated circuit; 3-wire cord with grounded 3-prong plug attached to product

1/4" copper tubing inlet waterline; 35 psi minimum; 100 psi maximum

Overall Interior Capacity

Bottom-mount Refrigerator – 14.4 cu. ft. (407.0 L) Freezer – 5.5 cu. ft. (156.0 L) Total capacity – 19.9 cu. ft. (563.0 L)

Approximate Shipping Weight

327 lb. (148.7 kg)

7.9 amps

* Adding accessory side panels increases overall width to 35 7/8" (91.1 cm) ** Adding accessory tops/grilles increases overall height to 71 7/8" (182.6 cm)

French-door bottom-mount Refrigerator – 14.1 cu. ft. (399.0 L) Freezer – 5.5 cu. ft. (156.0 L) Total capacity – 19.6 cu. ft. (555.0 L)

VCSF036/VCSF036D Professional and DDSF036/DDSF036D Designer

F R E E Z E R S

3 6 " W I D E F R E E S T A N D I N G S I D E - B Y - S I D E R E F R I G E R A T O R / F R E E Z E R S

70" (178.0 cm)**

Non-dispenser – 7.8 amps; Dispenser – 9.4 amps

Non-dispenser Refrigerator – 13.5 cu. ft. (382.0 L) Freezer – 8.0 cu. ft. (229.0 L) Total capacity – 21.5 cu. ft. (611.0 L)

Dispenser Refrigerator – 13.5 cu. ft. (382.0 L) Freezer – 8.1 cu. ft. (229.0 L) Total capacity – 21.6 cu. ft. (611.0 L)

314 lb. (141.3 kg)

Basic specifications – refrigerated drawers

VURD140

Professional

DFRD140

Custom Front

Description

2 4 " W I D E R E F R I G E R A T E D D R A W E R S

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Electrical Requirements

Maximum Amp Usage

Interior Capacity

23 7/8" (60.6 cm)

34 1/4" (87.0 cm) minimum 35" (88.9 cm) maximum

26 7/8" (68.3 cm) to end of handle

24" (61.0 cm)

34 1/2" (87.6 cm) minimum 35 1/8" (89.2 cm) maximum

115VAC/60Hz

5.8 cu. ft. (164.2 L)

Approximate Shipping Weight

180 lb. (81.8 kg)

3.3 amps

DURD140

Designer

25 3/8" (64.5 cm) to end of handle

24 1/16" (61.4 cm) to front of custom panel

15" undercounter beverage centers

VUAR150/VUAR150T/VUAR151

Professional

DUAR150/DUAR151 and

DFUR150/DFUR151 Designer

Description

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Maximum Storage Capacity

14 3/4" (37.5 cm)

34 1/4" (87.0 cm) minimum; 35" (88.9 cm) maximum

26 1/8" (66.4 cm) to end of handle

15" (38.1 cm)*

34 1/2" (87.6 cm) minimum; 35 1/8" (89.2 cm) maximum

24" (61.0 cm)

115VAC/60Hz

3.0 cu. ft. (84.9 L)

Approximate Shipping Weight

110 lb. (49.5 kg)

3.0 amps

1 5 " W I D E R E F R I G E R A T E D B E V E R A G E C E N T E R S

* 15" (38.1 cm) width for cabinet only. If door is recessed between cabinets, cutout must be 15 1/4" (38.7 cm).

DUAR: 24 5/8" (62.5 cm) to end of handle DFUR: 23 7/16" (59.5 cm) to front of custom panel

VUAR140/VUAR140T/VUAR141

Professional

DUAR140/DUAR141 and DFUR140/

Designer

Description

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Maximum Storage Capacity

23 7/8" (60.6 cm)

34 1/4" (87.0 cm) minimum; 35" (88.9 cm) maximum

26 7/8" (68.3 cm) to end of handle

24" (61.0 cm)*

34 1/2" (87.6 cm) minimum; 35 1/8" (89.2 cm) maximum

24" (61.0 cm)

115VAC/60Hz

6.1 cu. ft. (172.7 L)

Approximate Shipping Weight

140 lb. (63.0 kg)

3.3 amps

2 4 " W I D E R E F R I G E R A T E D B E V E R A G E C E N T E R S

* 24" (61.0 cm) width for cabinet only. If door is recessed between cabinets, cutout must be 24 1/4" (61.6 cm).

DUAR: 25 3/8" (64.5 cm) to end of handle DFUR: 24 3/16" (61.4 cm) to front of

Inlet Water Requirements

–

Basic specifications – 24" undercounter beverage centers

DFUR141

2 4 " W I D E R E F R I G E R A T E D B E V E R A G E C E N T E R S W I T H I C E M A K E R

26 7/8" (68.3 cm) to end of handle

custom panel

VURI140D/VURI140T

Professional

DURI140D

Designer

DFRI140D

Custom Front

25 3/4" (64.5 cm) to end of handle 24 3/16" (61.4 cm) to front of

custom panel

1/4" copper tubing inlet waterline; 35 psi minimum; 100 psi maximum

Basic specifications – wine cellars

VUWC152

Professional

DUWC152/DFUW152

Designer

Description

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Maximum Storage Capacity

14 3/4" (37.5 cm)

34 1/4" (87.0 cm) minimum; 35" (88.9 cm) maximum

26 1/8" (66.4 cm) to end of handle

15" (38.1 cm)*

34 1/2" (87.6 cm) minimum; 35 1/8" (89.2 cm) maximum

24" (61.0 cm)

115VAC/60Hz

24 bottles

Approximate Shipping Weight

110 lb. (49.5 kg)

3.0 amps

1 5 " W I D E U N D E R C O U N T E R W I N E C E L L A R S

* 15" (38.1 cm) width for cabinet only. If door is recessed between cabinets, cutout must be 15 1/4" (38.7 cm). ** 24" (61.0 cm) width for cabinet only. If door is recessed between cabinets, cutout must be 24 1/4" (61.6 cm).

DUWC: 24 5/8" (62.5 cm) to end of handle DFUW: 23 7/16" (59.5 cm) to front of

Description

3 0 "

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

30" (76.2 cm)

82 3/4" (210.2 cm) minimum; 84 1/16" (213.5 cm) maximum

To rear of side trim – 22 3/16" (56.4 cm) To front of top grille – 24 1/2" (62.2 cm) To front edge of handle – 27" (68.6 cm)

29 1/2" (74.9 cm)

82 7/8" (210.5 cm) minimum; 84 1/16" (213.5 cm) maximum

24" (61.0 cm)

115VAC/60Hz; 5 ft. (152.4 cm); 3-wire cord with grounded 3-prong plug attached to product

Maximum Storage Capacity

150 bottles

Approximate Shipping Weight

560 lb. (252 kg)

2.0 amps

VCWB300

Professional

To front edge of To front of top To front edge of

30" (76.2 cm)

VUWC142

Professional

DUWC142 and DFUW142

Designer

2 4 " W I D E U N D E R C O U N T E R W I N E C E L L A R S

custom panel

26 7/8" (68.3 cm) to end of handle DUWC: 25 3/8" (64.5 cm) to end of handle

DFUW: 24 3/16" (61.4 cm) to front of custom panel

54 bottles

23 7/8" (60.6 cm)

24" (61.0 cm)**

140 lb. (63.0 kg)

3.3 amps

W I D E F U L L H E I G H T W I N E C E L L A R S

DDWB300

Designer

DFWB300

Custom Front

side trim – 23 13/16" (60.5 cm) grille – 24" (61.0 cm)

handle – 26" (66.0 cm)

To front edge of side trim – 23 13/16" (60.5 cm) To front of top grille – 24 3/4" (62.9 cm) To front edge of door trim – 24" (61.0 cm)

25" (63.5 cm); can be installed in 24" openings – door faces and grille will protrude 3/4" (1.9 cm)

Basic specifications – ice machines

VUIM150/VUIM150T

Professional

DUIM150

Designer

Description

1 5 " W I D E I C E M A C H I N E S

Overall Width

Overall Height

Overall Depth from Rear

Cutout Width

Cutout Height

Cutout Depth

Electrical Requirements

Maximum Amp Usage

Maximum Storage Capacity

14 3/4" (37.5 cm)

34 1/4" (87.0 cm) minimum 35" (88.9 cm) maximum

27 1/8" (68.9 cm) to end of handle bracket

15" (38.1 cm)*

34 1/2" (87.6 cm) minimum 35 1/8" (89.2 cm) maximum

24" (61.0 cm)

115VAC/60Hz

35 lb. (16 kg.)

Approximate Shipping Weight

110 lb. (49.5 kg)

3.0 amps

25 5/8" (65.1 cm) to edge of handle

* 15" (38.1 cm) width for cabinet only. If door is recessed between cabinets, cutout must be 15 1/4" (38.7 cm).

VRBD140T

Professional Portable

VUBD140T

Professional Undercounter

2 4 " W I D E B E V E R A G E D I S P E N S E R S

Overall Width

24 5/8" (62.5 cm)

Overall Height (to top of tower)

52" (132.1 cm)

Overall Depth from Rear (to end of handle brackets)

115VAC/60Hz

Electrical Requirements

Maximum Amp Usage

Maximum Storage Capacity

1/2 barrel – 15.5 gal. (58.7 L)

Approximate Shipping Weight

Description

27 5/8" (70.2 cm)

3.3 amps

177 lb. (79.7 kg)

23 7/8" (60.6 cm)

47 3/4" (121.3 cm) minimum

48 3/4" (123.8 cm) maximum

26 7/8" (68.3 cm)

24 3/4" (62.9 cm)

Cutout Width (without casters)

Cutout Height (without casters)

Cutout Depth

24" (61.0 cm)

35 9/16" (90.3 cm)

24" (61.0 cm)*

34 1/8" (87.9 cm) minimum 35 1/8" (89.2 cm) maximum

Beverage dispensers

* 24" (61.0 cm) width for cabinet only. If door is recessed between cabinets, cutout must be 24 1/4" (61.6 cm).

Notes

All models with standard equipment are design-certified for residential installation.

To receive the most current specification sheets, call Dimension Express from your fax machine at (775) 833-3600, or visit their Web site at www.dexpress.com. Enter the code #8051 for Viking products. This will send you information on how to use the system and the corresponding model code numbers. Dimension Express customer service number is (775) 833-3633.

All refrigeration products

Look for the Replacement Collection icon throughout this brochure, indicating Viking products that can be installed in existing cutouts with little or no cabinetry alterations.

V i k i ng R an ge C or po r at io n

1 1 1 Fro n t St r e e t

Gr e enwo o d, M i ssis sipp i 389 3 0 USA

( 6 6 2 ) 45 5 - 1 2 00

F o r p ro d u ct in f o rm at i o n ,

c a l l 1- 8 8 8- V I KI N G 1 ( 84 5 - 4 6 4 1 ) ,

o r v i s i t th e Vi ki n g We b s it e at

v i k i n g r a n g e . c o m

M 1 1 0 7F 6 0 0 7 8 E

Viking High-Performance Kitchen User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
