User manual
1. Introduction
Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2. Safety Instructions
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty
and the dealer will not accept responsibility for any ensuing defects or problems.
• Damage caused by user modifications to the device is not covered by the warranty.
• Only use the device for its intended purpose. Using the device in an unauthorised way will void the
warranty.
• Check the contents prior to assembly. Use proper tools and never use defective or deformed
parts as an improper installation may cause serious injury.
• Any included hardware is for mounting on solid brick, concrete or hard wood battens.
When mounting on wood, do not use any concrete anchors. Do not use any included hardware
for mounting on steel. If uncertain about the nature of the wall or mounting techniques, please
consult an expert.
05/05/2011 ©Velleman nv
5
