USER MANUAL

1. Introduction

Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.

2. Safety Instructions

• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty

and the dealer will not accept responsibility for any ensuing defects or problems.

• Damage caused by user modifications to the device is not covered by the warranty.

• Only use the device for its intended purpose. Using the device in an unauthorised way will void

the warranty.

• Check the contents prior to assembly. Use proper tools and never use defective or deformed parts

as an improper installation may cause serious injury.

• Any included hardware is for mounting on solid brick, concrete or hard wood

ceilings/battens. When mounting on wood, do not use any concrete anchors. Do not use any

included hardware for mounting on steel. If uncertain about the nature of the ceiling or mounting
techniques, please consult an expert.

• Respect the product’s max. load specifications. Protect this device from shocks and abuse and

avoid brute force when operating. Check the installation on a bimonthly basis.

• An adequate mounting is essential and falls outside the responsibility of Velleman nv. Respect all

installation and operating directions of the device to be mounted/installed.

• Only use the device at an indoor location, protected from rain, moisture, splashing and dripping

liquids. Make sure the chosen location spot is able to support the weight of the bracket and
device.

• Keep fingers away from articulations to avoid injury. Keep the device out of reach of children and

unauthorized users at all times.

3. General Guidelines

Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.

4. Features

• support for projector

• easy installation

• 360° pan and 15° tilt/roll movement

• comes with all necessary plugs and screws for assembly and mounting

5. Overview

Refer to the illustrations on pages 2, 3 and 4 of this manual.

1 ceiling plate 10 bracket adaptor #2
2 projector plate 11 spring washer – M6
3 extension – 15cm 12 hex key – 5mm
4 extension – 8cm 13 hex key – 4mm
5 projector arm 14 lag bolt – 6mm
6 rubber gasket 15 concrete anchor
7 screw – M6 16 flat washer – M6
8 screw – M4 17 bolt with 2 spacers

6. Installation

P-1) Use the ceiling plate [1] to determine and indicate the position of the mounting holes.

P-2) Mount the projector arms [5] and projector plate [2] on the projector.

26/04/2011 ©Velleman® nv

projector support 9 bracket adaptor #1

P-1A) When mounting on a brick or concrete ceiling, drill holes size Ø8mm and at least

50mm deep at the indicated positions. Insert the included anchors [15] and mount
the ceiling plate [1] on the ceiling using the 3 included screws [14].

P-1B) When mounting on a wooden ceiling or ceiling batten, drill holes size Ø3mm and at

least 50mm deep at the indicated positions. Make sure all the holes are blind holes.
Mount the ceiling plate [1] on the ceiling using the 3 included screws [14].

Slide the rubber gasket [6] over the ceiling plate [1].

P-2A) Fix the projector arms [5] on the projector using the included bolts [17].

5

WB020 Rev. 02

P-2B) There are 3 ways to use the spacers of the bolts [17], as indicated.
P-2C) Make sure the height of the 3 arms is equal.
P-2D) Turn the arms towards the centre and attach the projector plate [2]. Use for each

mounting point a spring washers [11], flat washers [16] and an M6-screw [7].
Make sure all screws are secured tightly.

P-3) For Toshiba-type projectors, use following mounting instructions:

P-3A) Attach the included bracket adaptor #1 [9] to the projector using the M4-screws

[8].

P-3B) Fix the projector arms [5] on the bracket adaptor [9] and projector using the

included bolts [17] (see also P-2B and P-2C).

P-3C) Turn the arms towards the centre and attach the projector plate [2]. Use for each

mounting point a spring washers [11], flat washers [16] and an M6-screw [7].

P-3D) Make sure all screws are secured tightly.

P-4) For Philips-type projectors, use following mounting instructions:

P-4A) Slide the included bracket adaptor #2 [10] into the projector housing.
P-4B) Fix the projector arms [5] on the bracket adaptor [10] and projector using the

included bolts [17] (see also P-2B and P-2C).

P-4C) Turn the arms towards the centre and attach the projector plate [2]. Use for each

mounting point a spring washers [11], flat washers [16] and an M6-screw [7].

P-4D) Make sure all screws are secured tightly.

P-5) Mount an extension – 8cm [4] or 15cm [3] - to the ceiling plate [1] and connect the

projector plate [2] to the extension.

P-5A) Push on the two bolts of the ceiling plate (see arrows) and slide the desired

extension over the bolts until the bolts and the holes are lined up. Use the 4mm hex
key [13] to turn the bolts counter clockwise to secure them.

P-5B) Push on the two bolts of the projector plate (see arrows) and slide it into the

extension until the bolts and the holes are lined up. Use the 4mm hex key [13] to
turn the bolts counter clockwise to secure them.

7. Technical specifications

projector size 13-32cm
max. load 10kg / 22lbs
rotation angle
pan 360°

tilt and roll 15°
dimensions
ceiling bracket Ø85 x 50mm

extension Ø60 x 80mm / Ø60 x 150mm

base Ø178 x 50 mm
weight 1.2kg

Use this device with original accessories only. Velleman nv cannot be held responsible in
the event of damage or injury resulted from (incorrect) use of this device.
For more info concerning this product and the latest version of this user manual, please
visit our website www.velleman.eu
without prior notice.

© COPYRIGHT NOTICE
This manual is copyrighted. The copyright to this manual is owned by Velleman nv. All

worldwide rights reserved. No part of this manual may be copied, reproduced, translated or reduced
to any electronic medium or otherwise without the prior written consent of the copyright holder.

. The information in this manual is subject to change
