Page 1
ITNLPL FRES ENG DE
MC 2.0 WR
DE Bedienungsanleitung
ENG Instruction Manual
FR Manuel d‘ Installation et d‘ Utilisation
IT Manuale d‘ Installazione e Funzionamento
ES Instalacion y operación manual
NL Handleiding
PL Instrukcja obslugi licznika
MC 2.0
Page 2
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
Introduction
Congratulations
In choosing a VDO computer, you have opted for high-quality device with the latest technology. In order to fully benefit from the potential of the
computer, we recommend that you carefully read this manual. It contains the full operating instructions and many useful tips.
We hope you enjoy cycling with your VDO bike computer.
Cycle Parts GmbH
Pack contents
First, please ensure that the contents of this pack are complete:
VDO computer universal handlebar bracket
with cable and sensor
Accessories:
spoke magnet
(clip magnet)
Cable ties
for attaching the bracket
and the sensor
rubber pad
for sensor
battery V-
for computer
Page 3
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
Table of contents
1. Display 36
2. Operation 38
3. Functions 40
3.1 Information functions, BIKE 40
3.2 Information functions, ALTI 41
3.3 Information on P-button 42
3.4 Selecting Bike 1 or Bike 2 43
3.5 Display backlight 44
3.6 Selecting the start altitude /
recalibrating the current altitude 44
3.7 Auto-start/stop of the computer 45
3.8 Start/stop of the stopwatch 45
4. Reset 46
4.1 Resetting the trip data 46
4.2 Resetting the stopwatch 46
4.3 Resetting the NAVIGATOR 47
4.4 Resetting to factory settings 47
5. Installation 48
5.1 Fitting the sensor, magnet and handlebar bracket 48
5.2 Installing the battery in the computer 49
5.3 Inserting the computer into the handlebar bracket 49
6. Basic settings 50
6.1 Selecting the language 50
6.2 Setting the units (kmh/mph, Meter/feet,
Celsius/Fahrenheit) 50
6.3 Setting the tyre size (wheel-circumference) 51
6.4 Setting the clock 53
6.5 Setting the odometer 54
6.6 Setting the navigator 55
6.7 Setting the ride time 56
6.8 Setting the start altitude/home altitude 57
6.9 Setting the current altitude/actual altitude 58
6.10 Automatic altitude adjustment during bike transport 59
6.11 Setting the altitude gain uphill 59
6.12 Setting the altitude loss downhill 60
7. Sleep mode 61
8. Terms of guarantee 62
9. Troubleshooting 63
10. Technical specifications 64
>>> P02 references at the start of a section refer to the pictures in the
picture book!
Page 4
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
1. Display
The display can be divided
into six areas:
Area
Temperature,
current altitude
Area
current uphill/
downhill gradient
Area
Current speed
Area
Data for the selected function
Area
Top line (info line) shows the name
of the selected function. Second
line (menu line) displays,
B
whether there is more
information “MORE”.
B
whether there is another
selection option “SELECT”.
Area
Indicator elements.
The d escri ption of t he indiv idual
indicators can be found on
the right-hand side.
!
Your VDO computer comes without battery built in. Before you start, please insert battery.
See also section 5.2.
Page 5
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
Stopwatch indicator
Shows that the stopwatch is still running whilst other information is
provided on the display.
Indicator bike /bike
The computer can use two different settings for two bikes.
The indicator shows which of the two bikes you have chosen to use.
The total distance is measured and stored separately for bike 1 and
bike 2.
Measurement unit (KMH or MPH)
The computer can display both KMH and MPH. Distances are
correspondingly displayed in kilometers or miles. The indicator
shows the selected measurement unit.
Display backlight
The LIGHT ICON indicates if the backlight-mode has been switched on.
Difference indicator – speed (current) to speed (average)
The computer compares the current speed with the average speed.
The indicator shows whether the current speed is
B
greater than the average speed (+1 km/h)
B
less than the average speed (-1 km/h)
B
or the same as the average speed (tolerance +/- 1 km/h)
Menu prompt indicator
When a submenu has been accessed, these indicators flash and show
that there are other selection options or that the computer is waiting
for an entry (setting mode).
Downhill-Indicator, shows declination
Uphill-Indicator, shows inclination
Page 6
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
C = CLEAR
A = ALTI
M = MENU
P = STOP-
WATCH
BIKE
FUNCTION
FUNCTION
FUNCTION
FUNCTION
C
= CLEAR
In function mode:
B
Jump back a menu level from the submenu.
B
Press and hold C for three seconds:
B
Reset trip data to zero.
B
Reset stopwatch to zero.
B
Reset navigator to zero.
In setting mode:
B
Press and hold C for three seconds:
Exit the settings menu,
return to function mode.
B
Correct an entry.
B
Jump back a digit.
M
= MENU
In function mode:
B
Access available submenu.
You can recognise a submenu by
the flashing menu indicators.
B
Confirm selection.
B
Start/stop the stopwatch.
B
Press and hold M for three seconds:
B
Open the settings menu.
In setting mode:
B
Select a setting.
B
Confirm a setting.
B
Confirm a selection made.
A
= ALTI
In function mode:
B
Altitude information is displayed.
In setting mode:
B
Scroll backwards in the menu.
B
Decrease the number to be set.
P
= STOPWATCH
In function mode:
B
Display of stopwatch and clock
In setting mode:
B
Scroll forwards in the menu.
B
Increase the number to be set.
= BIKE
In function mode:
B
Bike functions
Menu indicators on the display flash to show that there are other
selection options. In function mode, the computer is operated using
five buttons. In setting mode, the computer is operated using four
buttons.
2. Operation
To make your computer easy to use, we have developed the EMC =
Easy Menu Control system. The EMC makes your computer easier to
operate by means of full-text menu guidance, as is used on most
mobile phones.
Page 7
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
A
= ALTI
In function mode:
B
Altitude information is displayed.
B
If the submenu is open:
Scroll down in the submenu.
B
Press and hold ALTI for three seconds:
Opens the menu for recalibrating the current altitude.
In setting mode:
B
Scroll down within the setting modes.
B
Decrease a digit.
P
= STOPWATCH
In function mode:
B
Display of stopwatch and clock
In setting mode:
B
Scroll up within the setting modes.
B
Increase a digit.
= BIKE
B
Displays the bike functions, e.g. trip distance, average speed etc.
A
+ P = ALTI+P
B
Press the buttons ALTI+P to start/stop the stopwatch.
B
The stopwatch immediately appears on the display and
is started or stopped.
+
C
= BIKE+CLEAR
B
Press the buttons BIKE+CLEAR to activate the display backlight.
B
When the display backlight is activated, the LIGHT icon is
displayed.
B
When the display backlight is activated, the display is lit for a few
seconds every time a button is pressed.
ATTENTION: press the buttons BIKE + CLEAR again to switch off the
display backlight during the day.
This SAVES BATTERY POWER.
Page 8
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
3. Functions
3.1 Information functions, BIKE
CURRENT SPEED
Permanently shown on the display.
Accuracy: 0,2 KMH/MPH
TRIP DISTANCE
Shows the distance of the current trip since the last reset.
Maximum value 999.99 km or miles. If the maximum value is exceeded,
the odometer starts again at zero.
TRIP DISTANCE/MORE
MORE indicates that there is a submenu
for the main menu TRIP DISTANCE.
Open the submenu by pressing M.
In the submenu you will find (scroll by pressing ALTI A or P):
B
Total distance BIKE 1 up to max. 99,999 km or miles
B
Total distance BIKE 2 up to max. 99,999 km or miles
B
Total distance for bike 1 + bike 2 up to max. 199,999 km or miles
Exit the submenu by pressing C.
RIDE TIME
Shows the ride time for the current trip distance since the last reset.
Maximum 99:59:59 HH:MM:SS.
If the maximum value is exceeded, the ride time measurement starts
again at zero.
RIDE TIME/MORE
MORE indicates that there is a submenu for the
main menu RIDE TIME. Open the submenu by
pressing M.
In the submenu you will find (scroll by pressing ALTI A or P):
B
Total ride time bike 1 up to max. 999:59 HHH:MM
B
Total ride time bike 2 up to max. 999:59 HHH:MM
B
Total ride time bike 1 + bike 2 up to max. 1999:59 HHHH:MM
Exit the submenu by pressing C.
AVG SPEED
Shows the average speed since the last reset.
Accuracy: 2 decimal places.
MAX SPEED
Shows the maximum speed on the current trip
since the last reset. Accuracy: 2 decimal places.
Page 9
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
NAVIGATOR
The navigator is a second trip distance counter. The NAVIGATOR:
B
is independent of the trip distance counter.
B
can be reset to zero as often as you want.
B
can be set to a starting value.
B
can count forwards or backwards from this starting value.
These special options make it easier to follow instructions from
a touring book or road book.
NAVIGATOR/SET
SET indicates that there is a submenu for the
main menu NAVIGATOR. Open the submenu by
pressing M.
You can set a start value here and decide whether the NAVIGATOR
counts forwards or backwards from this start value.
3.2 Information functions, ALTI
ALTI UP
Shows the altitude gain uphill on the current trip since the last reset.
ALTI UP--MORE--
MORE indicates that there is a submenu for the
main menu ALTI UP. Open the submenu by
pressing M.
In the submenu, you will find (scroll by pressing ALTI A or P):
B
Altitude gain uphill for bike
B
Altitude gain uphill for bike
B
Total altitude gain uphill for bikes +
Exit the submenu by pressing C.
ALTI MAX
Shows the maximum altitude (highest point) reached on the
current trip.
ALTI MAX--MORE--
MORE indicates that there is a submenu for the
main menu ALTI MAX. Open the submenu by
pressing M.
In the submenu, you will find (scroll by pressing ALTI A or P):
ALTI MAX for BIKE :
highest point of all previous trips with bike 1.
ALTI MAX for BIKE :
highest point of all previous trips with bike 2.
Page 10
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
AVG CLIMB: average uphill gradient (in percent) on
the current trip.
MAX CLIMB: maximum uphill gradient
(in percent) on the current trip.
ALTI DOWN
Shows the altitude loss downhill on the current trip since the last
reset.
ALTI DOWN--MORE--
MORE indicates that there is a submenu for the
main menu ALTI DOWN. Open the submenu
by pressing M.
In the submenu, you will find (scroll by pressing ALTI A or PULSE P):
B
Altitude loss downhill for bike
B
Altitude loss downhill for bike
B
Total altitude loss downhill for bikes +
Exit the submenu by pressing C.
AVG DOWN: shows the average downhill
gradient of the current trip (in percent).
MAX DOWN: shows the maximum downhill
gradient of the current trip (in percent).
CLOCK
shows the current time.
12 hour AM/PM or 24 hour-mode possible
3.3 Information on P-button
STOPWATCH
independent stopwatch for
measuring times/intervals.
Page 11
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
Confirm with M.
SELECT BIKE---BIKE 1 or BIKE 2 is shown
Select with ALTI A or P.
Confirm with M.
Display will show BIKE 1 (or BIKE2) ---SELECT OK?
Confirm with M.
Display will show SELECT BIKE---SELECT DONE.
Press and hold C to get back to Function Menu.
3.4 Selecting Bike 1 or Bike 2 >>> P03
Your VDO Computer can be used on 2 bikes. All data is either stored for
Bike 1 or Bike 2. The selected bike is indicated in lower left part of the
display. ( )
How to select Bike or Bike
Process:
Press and hold M for 3 seconds.
SETINGS OPEN? is flashing in the display.
LANGUAGE---SELECT--- is shown.
Use P to go to SELECT BIKE---SELECT---.
Page 12
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
If the display backlight is activated and a button is pressed,
the backlight illuminates for a few seconds.
ATTENTION: press the buttons BIKE + CLEAR again to switch off the
display backlight during the day. This SAVES BATTERY POWER.
ACTUAL ALTITUDE can be used to re-calibrate the current altitude.
This can be done by entering the (known) altitude in METERS/FEET
or the AIR PRESSURE. The sea level pressure can be found online on
weather forecast websites.
Press M to confirm the ALTITUDE--ACTUAL ALTI
setting.
ACTUAL ALTI--ALTITUDE or
ACTUAL ALTI--AIR PRESSURE
is displayed.
3.5 Display backlight
3.6 Selecting the start altitude / recalibrating the actual altitude
The MC 2.0 has a display backlight.
The display backlight is activated by pressing the buttons + C.
If the display backlight is activated, the LIGHT icon appears on the
display.
The MC 2.0 can work with two different start altitudes
(example: home altitude and altitude at holiday location).
The current altitude can be set by entering the number of
METERS/FEET or the AIR PRESSURE. Please also read section 6.10.
B
Press and hold the ALTI button A for three seconds.
B
ALTITUDE SELECT? flashes on the display.
B
ALTITUDE
B ACTUAL ALTI
B HOME 1
B HOME 2
is displayed (depending on the previously accessed configuration).
B
A selection is made by pressing ALTI A or P.
B
The selection is confirmed by pressing M.
B
For the start altitudes, the query 300 appears (numerical example).
B
HOME ALTI 1 (or 2) SELECT OK ?
B
The selection is confirmed by pressing MENU.
B
The MC 2.0 confirms by displaying ALTITUDE DONE.
Page 13
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
3.7 Auto-start/stop of the computer
The MC 2.0 WR will automatically wake up form Sleep Mode,
when you continue your ride. The computer can also be manually
activated after a break by pressing a button.
A selection is made by pressing the P or ALTI
button A.
Confirm the selection by pressing M.
The digit to be set flashes.
Pressing P or ALTI A increases or reduces the digit.
The following query then appears:
ACTUAL ALTI--SELECT OK?
Confirm the selection by pressing M.
The MC 2.0 confirms by displaying ACTUAL ALTI – SET DONE.
Pressing ALTI A + P again stops the stopwatch and displays it
simultaneously on the display.
When shown on the display, the stopwatch can also be started/
stopped by pressing the M button.
3.8 Start/stop of the stopwatch
To access the stopwatch directly, simultaneously press ALTI A + P.
The stopwatch is shown directly on the display and started.
Page 14
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
B
Gain in altitude uphill
B
Average ascending gradient
B
Max ascending gradient
B
Loss in altitude downhill
B
Average descending gradient
B
Max descending gradient
Press and hold the C button for three seconds to reset the trip data
to zero before starting the next trip. TOUR DATA--RESET? is shown on
the display. If you continue to hold down the C button, the data will
be reset.
The following values are reset:
B
Trip distance
B
Ride time
B
Average speed
B
Max speed
The query STOPWATCH--RESET? appears on the display. The stopwatch
is reset to zero.
4.2 Resetting the stopwatch
The stopwatch can only be reset when shown on the display.
To reset the stopwatch, press and hold the C button for three seconds.
4 Reset
4.1 Resetting the trip data
Page 15
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
The query NAVIGATOR--RESET? appears on the display. The navigator
is reset to zero.
4.3 Resetting the NAVIGATOR
4.4 Resetting to factory settings
The navigator (nd trip section odometer) can only be reset when
shown on the display.
To reset the navigator, press and hold the C button for three seconds.
If you are absolutely sure that you want to reset the MC 2.0 to the
factory settings, then confirm the query by pressing M.
The MC 2.0 confirms by displaying RESET--DONE.
The MC . can be reset to the factory settings.
ATTENTION: this process deletes all data and all personal settings.
B
Press and hold all buttons simultaneously for three seconds.
B
The query FACTORY--RESET appears on the display.
RESET--SURE?
Page 16
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
5 Installation
5.1 Fitting the sensor, magnet and handlebar bracket >>> P01
Start by fitting the sensor and magnet.
Step Place the rubber pad under the sensor. Fit the sensor on the
same side of the forks where you later want to fit the computer to the
handlebars (right or left) using the cable ties supplied (loosely at first,
do not pull tight just yet).
ATTENTION: the sensor mark on the sensor must point to the spokes.
Depending on the room available, the sensor can be fitted at the front
of the forks, on the inner side (side showing to spokes) of the forks or
pointing backwards on the forks. >>> P02
Step Place the spoke magnet around an outer spoke. The silver
centre of the magnet points towards the sensor. Align the magnet to
the sensor mark on the sensor leaving a gap of about 1 - 5 mm.
Step Align the sensor and magnet for good and fasten them in place:
pull the cable ties tight and push the magnet in firmly.
Step Decide whether fitting to handlebars or stem and rotate the
base of the handlebar holder by 90° accordingly. To do so, undo the
screws in the bracket, take out the foot and rotate it 90°, insert and
tighten the screws again.
ATTENTION: do not overtighten the screws.
Step Guide the cable ties through the slot in the handlebar bracket,
place around the handlebars or the stem and pull (do not pull tight
just yet).
Step If fitting to handlebars: align the computer angle to achieve
optimum readability. Now pull the cable ties tight. Snip off protruding
ends with clippers.
Page 17
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
5.2 Installing the battery in the computer >>> P04
5.3 Inserting the computer into the handlebar bracket >>> P05
Your VDO computer comes without battery built in.
Before you start, please insert battery.
Step Place the battery in the computer casing with the +terminal
pointing up.
Step Make sure that the battery does not tilt.
Step Ensure that the rubber seal lies flat on the battery
compartment lid.
The VDO twist-click system securely connects the computer to the
handlebar bracket.
Step Place the computer into the bracket in a 10 o’clock position.
Step Twist the computer to the right until reaching the 12 o’clock
position and click it into the bracket system.
Step Insert the battery compartment lid into the opening and use
a coin to turn it to the right as far as it will go (approx. ⅓ turn).
TIP for changing batteries: VDO recommends changing the battery
annually.
When the battery is changed, all settings and all trip totals are
saved.
Step To remove the computer, twist it to the left
(do not push or pull).
How to remember: Rigid to the Right, Loose to the Left
Page 18
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
Press and hold M for three seconds.
When you set the language for the first time,
the following appears:
SETTINGS--OPEN?, followed by LANGUAGE ---SELECT---.
Confirm the selection by pressing M.
LANGUAGE--ENGLISH is shown on the display.
Press ALTI A or P to scroll until your language
is shown in display.
Confirm the selection by pressing M.
ENGLISH (or your selected language) --SELECT OK?
appears in the display.
Confirm the selection by pressing M.
The MC 2.0 confirms by displaying SELECT--DONE-LANGUAGE. To exit settings mode,
press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
This area enables you to set the units for:
B
Speed and distance (KMH or MPH)
B
Altitude (meters or feet)
B
Temperature (Celsius or Fahrenheit)
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to DIMENSION---SET---.
Confirm the selection by pressing M.
6 Basic settings
6.1 Setting the language
6.2 Setting the dimensions
Page 19
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
SPEED--KMH or MPH appears on the display.
Press ALTI A or P to select KMH or MPH.
Confirm the selection by pressing M.
ALTITUDE--METER or FEET is shown on the display.
Press ALTI A or P to select METER or FEET.
Confirm the selection by pressing M.
TEMPERATURE--CELSIUS or FAHRENHEIT is shown
on the display.
Press ALTI A or P to select CELSIUS or FAHRENHEIT.
Confirm the selection by pressing M.
Query, DIMENSION SET OK?
Press M to confirm the DIMENSION or C to go back
and change it.
The MC 2.0 confirms by displaying DIMENSION SET
DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
6.3 Setting the tyre size (wheel-circumference) >>> P05
This area is used to set the tyre circumference (tyre roll circumference).
The tyre circumference can be separately set for bike 1 and bike 2. The
tyre circumference can be manually entered in mm or automatically
determined from a table with tyre sizes.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to WHEEL SIZE---SET---.
Confirm the selection by pressing M.
Page 20
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
WHEEL SIZE--BIKE 1 or BIKE 2 is shown on the
display.
Press ALTI A or P to select BIKE 1 or BIKE 2.
Confirm the selection by pressing M.
WHEEL SIZE--MANUAL SET or TYRE SELECT is
shown on the display.
Press ALTI A or P to select MANUAL SET or
TYRE SELECT list.
Confirm the selection by pressing M.
If MANUAL SET is selected:
The tyre size in mm flashes (if MPH is selected, the
size is displayed in inches). Press ALTI A to reduce
the tyre circumference or P to increase it.
Once you have set the correct tyre circumference,
press M to confirm your setting.
BIKE 1 (or BIKE 2) SET OK? is shown on the display.
Press M in confirmation or C to make a correction.
The MC 2.0 confirms by displaying WHEEL SIZE--SET DONE.
If TYRE SELECT is selected:
Press ALTI A or P to scroll through the tyre list.
Once your tyre type is displayed (e.g. 700 x 23 C)
confirm it by pressing M.
700 x 23 C--SELECT OK? is shown on the display.
Press M to confirm the selection or C to change it.
The MC 2.0 confirms by displaying WHEEL SIZE-SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
Page 21
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
6.4 Setting the clock >>> P06
This area enables you to set the current time.
The time can be set in 24 or 12-hour format.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to CLOCK---SET---.
Press M in confirmation.
CLOCK 24-H--MODE or 12-H--MODE appears on the
display.
Press ALTI A or P to make a selection.
Press M in confirmation.
CLOCK---SET HOURS appears on the display.
The hour flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
CLOCK---SET MINUTES appears on the display.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
CLOCK––SET OK? query.
Press M in confirmation.
The MC 2.0 confirms by displaying CLOCK--SET
DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
Page 22
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
This area enables you to set the total distance cycled. The information
is separately provided for bike 1 and bike 2. At the start of the season,
you can reset the total distance cycled to zero, for example.
ATTENTION: the total distance is SAVED when the battery is
changed. The data is not lost.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to ODOMETER---SET---.
Press M in confirmation.
ODOMETER ODO BIKE 1 or ODO BIKE 2 is shown on
the display.
Press ALTI A or P to make a selection.
Press M in confirmation.
ODO BIKE 1 (or 2)--SET KM or SET MILE is shown on
the display.
The first digit flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
The second digit now flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
Continue the setting process until all digits have
been set.
ODO BIKE 1 (or BIKE 2)--SET OK? Press M to confirm
or C to make a correction.
The MC 2.0 confirms by displaying ODO BIKE 1
(or BIKE 2) SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
6.5 Setting the total distance
Page 23
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
6.6 Setting the navigator
The navigator is directly set from the function menu.
Process:
NAVIGATOR---SET--- is shown on the display.
Press M in confirmation.
NAVIGATOR––FORWARD or BACKWARD appears on
the display.
Press ALTI A or P to make a selection.
Press M in confirmation.
NAVIGATOR--SET DISTANCE appears on the display.
The distance in KM or MILES flashes.
The first digit flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
The second digit now flashes.
Press ALTI A to reduce the value or P to increase it. Once you have
set the correct value, press M to confirm your setting.
Continue the setting process until all digits have been set.
NAVIGATOR––SET OK? query
Press M in confirmation.
The MC 2.0 confirms by displaying NAVIGATOR--SET DONE. Once the
setting is complete, the MC 2.0 automatically switches back to
function mode.
Page 24
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
The total ride time can be separately set for bike 1 and bike 2. Before
the start of the season, you can reset the total ride time to zero.
ATTENTION: the total ride time is SAVED when the battery is
changed. The data is not lost.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to RIDE TIME ---SET---.
Press M in confirmation.
RIDE TIME--TIME BIKE 1 or TIME BIKE 2 is shown on
the display.
Press ALTI A or P to make a selection.
Press M in confirmation.
TIME BIKE 1--SET HOURS appears on the display.
The hours flash.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
TIME BIKE 1--SET MINUTES appears on the display.
The minutes flash.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
TIME BIKE 1--SET OK?
Press M in confirmation.
The MC 2.0 confirms by displaying TIME BIKE 1--SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
6.7 Setting the ride time
Page 25
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
6.8 Setting the start altitude/home altitude
You can enter two different start altitudes in the MC 2.0. One start
altitude can, for example, be your home start altitude. The second
start altitude can, for example, be the start altitude of a holiday
location. Before starting each trip, you can use the start altitude to
quickly and easily re-calibrate the current air pressure in line with the
start altitude set.
Topic: re-calibration
The MC 2.0 measures the altitude using the air pressure. The
air pressure changes depending on the weather. The changed
air pressure leads to an incorrect altitude reading. Through
recalibration, the currently measured air pressure is calculated
back to the set start altitude.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to HOME ALTI---SET---.
Press M in confirmation.
HOME ALTI--HOME ALTI 1 or HOME ALTI 2 appears
on the display.
Press ALTI A or P to make a selection.
Press M in confirmation.
HOME ALTI 1--SET METER or SET FEET appears on
the display. The meter or feet number flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
HOME ALTI 1--SET OK?
Press M in confirmation.
The MC 2.0 confirms by displaying HOME ALTI 1--SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
Page 26
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
ACTUAL ALTI--ALTITUDE or AIR PRESSURE appears
on the display.
Press ALTI A or P to make a selection.
Press M in confirmation.
If ALTITUDE is selected:
ACTUAL ALTI--SET METER or FEET appears on the
display. The meter or feet number flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
ACTUAL ALTI––SET OK?
Press M in confirmation.
The MC 2.0 confirms by displaying ACTUAL ALTI--SET DONE.
This area enables you to set the current altitude.
The current altitude is set if the air pressure has changed due to the
weather and the altitude shown on the display no longer corresponds
to the actual current altitude (e.g. the altitude details shown at the
summit).
There are two ways of setting the current altitude. Enter the current
altitude in meters/feet or the sea level pressure. On entering the sea
level pressure, the current altitude is calculated.
Details of the sea level pressure can be found on weather-pages in
Internet.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT--- appears on the display.
Press ALTI A to scroll to ACTUAL ALTI--- SET ---.
Press M in confirmation.
6.9 Setting the current altitude/actual altitude
Page 27
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
If AIR PRESSURE is selected:
AIR PRESSURE--SET PRESSURE appears on the
display. The air pressure number flashes.
Press ALTI A to reduce the value or P to increase
it. Once you have set the correct value, press M to
confirm your setting.
Dimension of Air Pressure is hPa.
AIR PRESSURE--SET OK?
Press M in confirmation.
The MC 2.0 confirms by displaying ACTUAL ALTI--SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS CLOSE? flashes. The MC 2.0 switches back to function mode.
6.10 Adjusting the altitude when transporting the bike
6.11 Setting the altitude gain uphill
The MC 2.0 has a movement sensor. If the bike is transported with
MC 2.0 on mount (e.g. by car), the movement sensor will adjust the
current altitude if the air pressure changes during transportation.
To do this, the MC 2.0 WL must be positioned in the handlebar bracket.
The altitude gain uphill can be separately set for BIKE 1 and BIKE 2.
Before the start of the season, you can reset the total altitude gain
to zero.
ATTENTION: the total altitude gain is SAVED when the battery is
changed. The data is not lost.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT---appears on the display.
Press P to scroll to ALTI UP---SET---.
Press M in confirmation.
Page 28
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
ALTI UP--ALTI UP 1 or 2 is shown on the display.
Press ALTI A or P to make a selection.
Press M in confirmation.
ALTI UP 1--SET METER or FEET appears on the display.
The first digit of the altitude reading flashes.
Press ALTI A to reduce the value or P to increase it.
Once you have set the correct value, press M to confirm your setting.
The second digit flashes.
Press ALTI A to reduce the value or P to increase it.
Once you have set the correct value, press M to confirm your setting.
Continue the setting process until all digits have been set.
ALTI UP 1--SET OK?
Press M in confirmation.
The MC 2.0 confirms by displaying ALTI UP 1--SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
The altitude loss downhill can be separately set for bike 1 and bike 2.
Before the start of the season, you can reset the total altitude loss to
zero.
ATTENTION: the total altitude loss is SAVED when the battery is
changed. The data is not lost.
Process:
Press and hold M for three seconds. SETTINGS--OPEN? flashes.
LANGUAGE---SELECT--- appears on the display.
Press P to scroll to ALTI DOWN---SET---.
Press M in confirmation.
6.12 Setting the altitude loss downhill
Page 29
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
ALTI DOWN--ALTI DOWN 1 or 2 is shown on the
display.
Press ALTI A or P to make a selection.
Press M in confirmation.
ALTI DOWN 1--SET METER or FEET appears on the display.
The first digit of the altitude reading flashes.
Press ALTI A to reduce the value or P to increase it.
Once you have set the correct value, press M to confirm your setting.
The second digit flashes.
Press ALTI A to reduce the value or P to increase it.
Once you have set the correct value, press M to confirm your setting.
Continue the setting process until all digits have been set.
ALTI DOWN 1--SET OK?
Press M in confirmation.
The MC 2.0 confirms by displaying ALTI DOWN 1--SET DONE.
To exit settings mode, press and hold the C button for three seconds.
SETTINGS--CLOSE? flashes. The MC 2.0 switches back to function mode.
7. Sleep mode
The MC 2.0 has a sleep mode to save the battery.
The MC 2.0 goes into sleep mode after five minutes
if no speed signals are received.
SLEEP MODE appears on the display.
Pressing any button or continue the ride will wake up the MC 2.0 WR.
Page 30
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
8. Terms of guarantee
Cycle Parts GmbH
Le Quartier Hornbach 13
67433 Neustadt/Weinstrasse (Germany)
If you have any technical questions, please do not hesitate to call our
hotline during standard office hours on:
+ () - -
+ () - -
Additional technical information is available at:
www.vdocyclecomputing.com
We reserve the right to make technical changes in the course
of further development.
VDO Cycle Parts offers a 3-year guarantee on your VDO computer,
starting from date of purchase. This guarantee covers material and
processing defects on the computer itself, the sensor/transmitter
and the handlebar bracket. Cables, batteries and mounting materials
are not covered by the guarantee. The guarantee is only valid if the
affected components have not been opened (exception: computer’s
battery compartment), no force has been used and there is no sign of
wilful damage.
Please store the purchase receipt in a safe place as it must be
submitted in the event of a complaint.
If your complaint is legitimate, you will receive a comparable
replacement device. You are not entitled to a replacement of the
identical model if the model in question is no longer in production
due to a model change. Please contact the dealer from whom you
purchased the device for all complaints and guarantee claims.
Alternatively, send your complaint directly to:
Page 31
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
9. Troubleshooting
Error Possible cause Correction
Half segments on the display
(e.g. after a battery change)
Computer software not running
correctly after battery change
Take out the battery, wait a few seconds,
place battery back again
No speed displayed Distance from sensor to magnet too great Correct the sensor and magnet positions
No speed displayed Computer not properly clicked
into the handlebar bracket
Place the computer head in the handlebar
bracket and twist it until it clicks
No speed displayed Wheel circumference is not correctly set or
is at zero
Set the wheel circumference
Display becomes weak Battery dead Check the battery, replace if nec.
Display becomes weak Temperatures under 5° make the display
sluggish
At normal temperatures the display
will work normally again
Incorrect altitude displayed
(current altitude incorrect)
Air pressure has changed but the current
altitude has not been recalibrated in line
with the new air pressure
Recalibrate the current altitude
Page 32
MC 2.0 WR VDO CYCLECOMPUTING
DE ENG FR ESIT NL PL
Speed range:
For wheel size 2155 mm,
min. 2.0 km/h, 1.5 Mph,
max. 199,8 km/h, 124 Mph
Ride time measurement range:
Up to 99:59:59 HH:MM:SS.
Stopwatch measurement range:
Up to 99:59:59 HH:MM:SS.
Trip distance odometer measurement range:
Up to value 999.99 km or mi
NAVIGATOR measurement range:
from -999.99 to +999.99 km or mi
Total distance or total distance measurement range:
Up to value 99,999 km or mi
Total distance ODO + ODO measurement range:
Up to value 199,999 km or mi
Altitude measurement range:
-999 m to +4999 m (-999 to 16 400 feet)
Wheel circumference setting range:
From 100 mm to 3999 mm (3.9 to 157.4 inches)
Computer:
Approx. 54 H x 49 W x 15 D mm, weight: approx. 45 g
Handlebar bracket:
Weight: approx. 10 g
Computer battery:
3V, type 2032
Computer battery service life:
400 ride hours, approx. 8,000 km (5000 m)
Display operating temperature:
-10°C to +60°C (14 °F to 140 °F)
10. Technical specifications
Page 33
ITNLPL FRES ENG DE
www.vdocyclecomputing.com MC 2.0 WR
GB
Correct Disposal of This Product
(Waste Electrical & Ele ctronic Equipment)
(Applicable in the European Union and other European countries with
separate collection systems) . This marking shown on the product or its
literature, indicates that it should not be disposed with other household
wastes at the end of it s working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please
separate this from other ty pes of wastes and recycle it responsibly to
promote the sustain-able reuse of material resources. Household users
should contact either the retailer where they purchased this product,
or their loca l government office, for det ails of where and how they can
take this item for environmentally safe recycling. Business users should
contact their supplier and check the terms and conditions of the
purchase contrac t. This product should not b e mixed with other
commercial wastes for disposal.
Page 34
MC 2.0
www.cyclecomputing.com
CP82000
Loading...
