IM-EN-FC11-A
User Guide
Field Communicator
FC-11
1.54
Table of contents
1 |
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . . 1 |
|
|
1.1 |
Kit contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 2 |
|
1.2 |
FC-11 parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 3 |
2 Connecting to the refractometer system . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 4 |
||
|
2.1 |
Connecting to a PR-43 refractometer . . . . . . . . . . . . . . . . . . . . . |
. . . . 4 |
|
2.2 |
Connecting to a PR-33-AC refractometer . . . . . . . . . . . . . . . . . . |
. . . . 5 |
|
2.3 |
Connecting to a PR-33-S refractometer . . . . . . . . . . . . . . . . . . . . |
. . . . 5 |
|
2.4 |
Connecting to an Indicating transmitter DTR / a PR-23 system |
. . . . . 5 |
|
2.5 |
Connecting to a Divert Unit / a DD-23 system . . . . . . . . . . . . . . |
. . . . 6 |
|
2.6 |
Connecting to a computer via USB . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 6 |
|
2.6.1 |
Accessing data on FC-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 7 |
|
2.7 |
Connecting to a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 7 |
|
2.8 |
Initiating the connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 7 |
3 |
Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 9 |
|
|
3.1 |
Using FC-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 9 |
|
3.1.1 |
Powering on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 9 |
|
3.1.2 |
Battery and charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . . 9 |
|
3.1.3 |
Touch screen display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 10 |
|
3.1.4 |
Command structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 11 |
|
3.2 |
Viewing and logging process data . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 12 |
|
3.2.1 |
View measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 12 |
|
3.2.2 |
View optical image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 13 |
|
3.2.3 |
Logging process data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 14 |
|
3.3 |
Viewing and changing the instrument(s) . . . . . . . . . . . . . . . . . . |
. . . 16 |
|
3.3.1 |
Instrument diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 16 |
|
3.3.2 |
Changing instrument parameters . . . . . . . . . . . . . . . . . . . . . . . |
. . . 16 |
|
3.3.3 |
Instrument verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 17 |
|
3.3.4 |
Instrument hardware and software information . . . . . . . . . . . |
. . . 17 |
|
3.3.5 |
Instrument backup and restore . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 17 |
|
3.3.6 |
Field calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 18 |
|
3.4 |
FC-11 settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 18 |
|
3.5 |
Service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. . . 19 |
3.5.1 |
Entering service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
19 |
3.5.2 |
Instrument program update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
3.5.3 |
Exiting service mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
20 |
4 Maintenance and troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
21 |
4.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1.1 Updating FC-11 software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.2 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1 Description |
1 |
1 Description
FC-11FieldCommunicatorisahandterminalforcontrollingVaisalaK-PATENTS®process instrumentsremotely. FieldCommunicatorisaperfectsolutionwhenyouwanttoview and log the measurement or diagnostics data or trends, or need to configure or verify your refractometer in field environment. The device has a touch screen and the user interface is like that of smartphones.
Figure 1.1 Using FC-11
© Copyright Vaisala 2020. All rights reserved.
2 |
FC-11 Field Communicator instruction manual |
1.1 Kit contents
4
5
6
3 9
2
7
1
8
Figure 1.2 FC-11 kit contents
1.FC-11 Field Communicator
2.PR-8817 Protective rubber cover
3.PR-8815 Micro-USB charger
4.PR-8812 Carrying case for FC-11 Field Communicator
5.PR-8814 Ethernet cable, RJ-45 10/100, 0.5 m / 1.6 ft
6.PR-8330-001 Ethernet cable for PR-33-AC, 1 m / 3.3 ft
7.PR-8811 Power adapter cable for PR-23 Indicating transmitter DTR
8.PR-8818 USB memory stick
9.PR-8813 Standard USB to micro-USB cable, 0.5 m / 1.6 ft
All kit items are also available as spare parts.
Document/Revision No. IM-EN-FC11/A |
Effective: March 1, 2020 |
1 Description |
3 |
1.2 FC-11 parts
8 7 6
1 2
4 5
3
Figure 1.3 FC-11 parts
1.Micro-USB connector (for charging and connecting to a computer)
2.not in use
3.DTR power connection
4.USB connector (for a memory stick)
5.Ethernet connector
6.Button
7.Touchscreen
8.not in use
© Copyright Vaisala 2020. All rights reserved.
4 |
FC-11 Field Communicator instruction manual |
2 Connecting to the refractometer system
FieldCommunicatorFC-11canbeconnectedanddisconnectedwithoutshuttingdown either the refractometer system or the communicator.
2.1 Connecting to a PR-43 refractometer
If connecting directly to a PR-43 refractometer, use Split Cable PR-8444. If the refractometer is connected to a network, connect via a network hub/switch with a standard RJ-45 Ethernet cable. If you want to connect to a Compact user interface CI or to a Multichannel user interface MI, Ethernet Cable for Interfaces PR-8330 is needed.
FC-11
RJ45 |
Cable PR-8444 |
|
P4-042 |
mA |
|
Power |
|
|
|
|
|
|
|
|
Figure 2.1 Connecting to a PR-43 refractometer
In a Vaisala K-PATENTS junction box Ethernet Cable PR-8822 is used to connect with FC-11. A Power Cable PR-8819 can be used to power the FC-11 from the junction box and there’s a cradle where FC-11 can be placed and left to log inside the junction box (see the junction box manual for further information).
Document/Revision No. IM-EN-FC11/A |
Effective: March 1, 2020 |
2 Connecting to the refractometer system |
5 |
2.2 Connecting to a PR-33-AC refractometer
The connection is made over ethernet with the PR-8330-001 cable for the PR-33-AC refractometer. If you want to keep the PR-33-AC connected to another device or net- work,theconnectioncanalsobemadetoanetworkhub/switchwithastandardRJ-45 Ethernet cable.
Figure 2.2 Connecting to a PR-33-AC refractometer
2.3 Connecting to a PR-33-S refractometer
Withstand-aloneinstallations,connecttheFieldCommunicatorwithastandardether- net cable to the PoE switch that powers the refractometer(s). If your refractometer(s) are in a factory network, connect to the network with a standard ethernet cable.
2.4Connecting to an Indicating transmitter DTR / a PR-23 system
Theconnectionismadewithastandardethernetcable. Oneendofthecableisplugged into your transmitter’s ethernet output, the other end goes into the FC-11.
Power Adapter PR-8811 is connected to (3) on the handset and to the EXTENSION connector in the DTR.
