OWNER’S MANUAL

Outdoor Charcoal Barbecue Grill

Model No. CBC1232SP

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only

(outside any enclosure)

WARNING

FOR YOUR SAFETY:

1.Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

2.Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.

3.Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.

4.This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.

5.Read and follow all warnings and instructions before assembling and using the appliance.

6.Follow all warnings and instructions when using the appliance.

7.Keep this manual for future reference.

3AVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

If you are assembling this unit for someone else,

GIVE THIS MANUAL TO HIM OR HER TO READ AND SAVE FOR FUTURE REFERENCE

Table of Contents

Important Safeguards 0AGE

%XPLODED 6IEW (ARDWARE



Assembly Instructions



/PERATING )NSTRUCTIONS



First Use



Lighting Instructions



Cooking



Controlling Flare-ups



Tips



Cleaning and Care



0RODUCT 2EGISTRATION



Limited Warranty



Made from 75% Bagasse

Manufactured in China for: Blue Rhino Global Sourcing, Inc



7INSTON 3ALEM .# 53! s WWW BLUERHINO COM



(Environmentally Friendly Sugar

¥ "LUE 2HINO 'LOBAL 3OURCING )NC !LL 2IGHTS 2ESERVED



Cane Pulp By-product)



UniFlame® IS A 2EGISTERED 4RADEMARK OF "LUE 2HINO 'LOBAL 3OURCING )NC !LL 2IGHTS 2ESERVED

#"# 30 /- %&

Outdoor Charcoal Barbecue Grill Model No. CBC1232SP





WARNING







DANGER



















FOR YOUR SAFETY



























Do not store or use gasoline or other flammable liquids or vapors in the





Never operate this appliance unattended.

vicinity of this or any other appliance.





























DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property.

WARNING:

This grill is for outdoor use only, and shall not be used in a building, garage or any other enclosed area.

For residential use only. This grill is NOT for commercial use.

Never use charcoal that has been pre-treated with lighter fluid. Use only a high grade plain charcoal, charcoal/wood mixture, lump charcoal or cooking wood. The conversion to or attempted use of any other fuel source in this charcoal grill is dangerous and will void your warranty.

This grill is not intended for and should never be used as a heater. TOXIC fumes can accumulate and cause asphyxiation.

Do not use grill for indoor cooking. Toxic carbon monoxide fumes can accumulate and cause asphyxiation.

This grill is safety certified for use in the United States and Canada only. Do not modify for use in any other location. Modification will result in a safety hazard and will void the warranty.

Do NOT operate, light or use this appliance within ten (10) feet (3.05 m) of walls, structures or buildings.

Apartment Dwellers: Check with management to learn the requirements and fire codes for using an a charcoal grill in your apartment complex. If allowed, use outside on the ground floor with a ten (10) foot (3.05 m) clearance from any structure. Do not use on or under balconies.

Minimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do not use this appliance under any type of overhang or roof.

Do not use gasoline, kerosene or alcohol for lighting.

Do not use in an explosive atmosphere. Keep grill area free and clear from combustible materials, gasoline and other flammable vapors and liquids.

Do not store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.

Do not alter grill in any manner. Any altering will void your warranty.

Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.

This grill should be thoroughly cleaned and inspected on a regular basis.

Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The use of any part that is not factory authorized can be dangerous and will void your warranty.

Do not use this appliance without reading “Operating Instructions” in this manual.

Do not touch metal parts of grill until it has completely cooled (about 45 min.) to avoid burns, unless you are wearing protective gear (pot holders, gloves, BBQ mittens, etc.).

Never touch grates (charcoal or cooking), ashes or coals to see if they are hot.

Do not use on wooden decks, wooden furniture or other combustible surfaces.

Do not use in or on boats or recreational vehicles.

Position grill so wind can not carry ashes to combustible surfaces.

Do not use in high winds.

Never lean over the grill when lighting.

Do not leave a lit grill unattended. Keep children and pets away from grill at all times.

Do not attempt to move grill when in use. Allow the grill to cool (about 45 min.) before moving or storing.

When cooking, fire extinguishing materials shall be readily accessible. In the event of an oil/grease fire, do not attempt to extinguish with water. Use type BC dry chemical fire extinguisher or smother with dirt, sand or baking soda.

Always open grill lid carefully and slowly as heat and steam trapped within grill can severely burn you.

Do not leave grill unattended while preheating or burning off food residue on high. If grill has not been cleaned, a grease fire can occur that may damage the product.

Do not place empty cooking vessels on the appliance while in operation.

Use caution when placing anything on the grill while the appliance is in operation.

Never add lighting fluid to hot or even warm coals as flashback may occur causing serious injury or damage to property.

Always place your grill on a hard, non-combustible level surface. An asphalt or blacktop surface may not be acceptable for this purpose.

Do not remove the ashes until they are completely and fully extinguished.

Live hot briquettes and coals can create a fire hazard.

Always empty the ash catcher and grill after each use.

Do not place fuel (charcoal briquets, wood or lump charcoal) directly into bottom of grill. Place fuel only on the charcoal pan/grid.

Do not allow charcoal to rest on the walls of grill. Doing so will greatly reduce the life of the metal and finish of your grill.

Check to make sure the air vents are free of debris and ash before using the grill.

Make sure ash catcher is securely and completely in place before using the grill.

Extinguished coals and ashes should be placed a safe distance from all structures and combustible materials.

With a garden hose, completely wet the surface beneath and around grill to extinguish any ashes, coals or embers which may have fallen during the cooking or cleaning process.

Always wear protective gloves when adding fuel (charcoal briquets, wood or lump charcoal) to retain desired heat level.

Keep all electrical cords away from a hot grill.

Always use a meat thermometer to ensure food is cooked to a safe temperature.

Never cover entire cooking area with aluminum foil.

Use protective gloves when assembling this product.

Do not force parts together as this can result in personal injury or damage to the product.

Death, serious injury or damage to property may occur if the above is not followed exactly.



PAGE NO

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.









Parts List

1

,ID (ANDLE









2

"RAND 0LATE









3

!IR 6ENT









4

Lid









5

Warming Rack









6

4OP (INGE









7

"OTTOM (INGE









8

Cooking Grid









9

Charcoal Grid









10

3IDE (ANDLE









11

"OTTOM "OWL









12

Side Shelf









13

Control Knob Assembly









14

Charcoal Grid Support



2OD











15

#ONTROL 0ANEL









16

Control Knob









17

!SH 2ECEIVER 3LIDE









18

!SH 2ECEIVER









19

,EG 3UPPORT #UP









20

,EFT ,EG









21

7HEEL ,EG









22

Bottom Shelf









23

7HEEL









24

(UB #AP









25

!XLE



Exploded View

1

2

3

4

5

8

6

10

7



9

11

14

13

12

15

17

14

16

18

19

19 20

21

23

24

22

25

23

24

Hardware

A

3CREW

- X .ICKEL 0LATED 0HILLIPS 4RUSS (EAD

PC















B

3CREW

- X .ICKEL 0LATED 0HILLIPS 4RUSS (EAD

PCS















C

3CREW

- X .ICKEL 0LATED 0HILLIPS 4RUSS (EAD

PCS















D

3CREW

- X .ICKEL 0LATED 0HILLIPS 4RUSS (EAD

PCS















%

3CREW

- X .ICKEL 0LATED 0HILLIPS 4RUSS (EAD

PCS















F

Nut

- .ICKEL 0LATED

PCS















G

Cap Nut

- .ICKEL 0LATED

PCS















(

Wing Nut

- .ICKEL 0LATED

PCS















I

Wing Nut

- .ICKEL 0LATED

PCS















J

Washer

.ICKEL 0LATED

PCS















K

Washer

.ICKEL 0LATED

5 pcs















L

Washer

!LUMINUM

PCS















M

Washer

.ICKEL 0LATED

PCS

















N

Washer

(EAT 2ESISTANT

PCS

























/

Lock Washer

.ICKEL 0LATED

PCS

























0

Lock Washer

.ICKEL 0LATED

PCS



























Q

0IN

X .ICKEL 0LATED

PCS



























R

#OTTER 0IN

X "LACK #OATED

PCS



























Tools Required for Assembly (Included)







0HILLIPS (EAD 3CREWDRIVER



PC



- - 7RENCH

PCS

Outdoor Charcoal Barbecue Grill Model No. CBC1232SP

Assembly Instructions

1

DO NOT RETURN PRODUCT TO STORE.

2

Attach Brand Plate, Air Vent and Lid Handle

For assistance call 1.800.762.1142 TOLL FREE 0LEASE HAVE



YOUR OWNER S MANUAL AND MODEL NUMBER AVAILABLE FOR



REFERENCE

&OR %ASIEST !SSEMBLY

s 4O AVOID LOSING ANY SMALL COMPONENTS OR HARDWARE ASSEMBLE YOUR PRODUCT ON A HARD LEVEL SURFACE THAT DOES NOT HAVE CRACKS OR OPENINGS

s #LEAR AN AREA LARGE ENOUGH TO LAYOUT ALL COMPONENTS AND HARDWARE

s 7HEN APPLICABLE TIGHTEN ALL HARDWARE CONNECTIONS BY HAND FIRST /NCE THE STEP IS COMPLETED GO BACK AND FULLY TIGHTEN ALL HARDWARE

s &OLLOW ALL STEPS IN ORDER TO PROPERLY ASSEMBLE YOUR PRODUCT

4O COMPLETE ASSEMBLY YOU WILL NEED s "AG OF CHARCOAL

4YPICAL ASSEMBLY APPROXIMATELY MINUTES

B

x 1

(

x 3

I

x 2

L

N

/ 0

x 2

x 2

x1

x2







3 Attach Side Handle and Ash Receiver Slide

4 Attach Legs and Leg Support Cups

C

I

K

x 3



L







x 1

N





x 1

0

x 2

x2

x1

D



x 4



M

x 4

0

x 4





Uniflame CBC1232SP User Manual

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

5

Attach Bottom Plate, Axle, Wheels and Hub Caps

6

Insert Ash Receiver



Note: !SH 2ECEIVER MUST ALWAYS BE INPLACE BEFORE LIGHTING

%





x 2



F

x 2



L

x 2









I



x 2

0

x 2







K

x 2







7

Attach Adjustable Knob Assembly and Charcoal Grid

8

Attach Control Panel and Control Knob

Support Rods



PAGE NO

5

B

G

J

x 2

x 2

x 2

N

/

x 2

A

x 2

B

x 1

x 4

J

/

x4

x4
