U-Line U-2224DWRINT-00A, U-2224ZWCINT-00B, U-2224BEVINT-00B, U-2224RINT-00B, U-2218RGLS-00B Quick Start Guide

QUICK START GUIDE

2000 Series

• 115 V / 60 Hz

QUICK START GUIDE

u-line.com

WELCOME TO U-LINE

Congratulations on your U-Line purchase. Your product comes from a company with over ve decades of premium modular

ice making, refrigeration, and wine preservation experience. U-Line continues to be the American leader, delivering versatility

and exibility for multiple applications including residential, light commercial, outdoor and marine use. U-Line’s complete

product collection includes Wine Captain® Models, Beverage Centers, Clear Ice Machines, Nugget Ice Machines, Crescent Ice

Makers, Glass & Solid Door Refrigerators, Drawer Models, Freezers, Combo® Models, and more.

U-Line has captivated those with an appreciation for the ner things with exceptional functionality, style, inspired innovations

and attention to even the smallest details. We are known and respected for our unwavering dedication to product design,

quality and selection. U-Line is headquartered in Milwaukee, Wisconsin and has shipped product to ve continents for over

two decades and is proud to have the opportunity to ship to you.

PRODUCT INFORMATION

Looking for additional information on your product? User Guides, Spec Sheets, CAD Drawings, Compliance Documentation,

and Product Warranty information are all available for reference and download at u-line.com.

PROPERTY DAMAGE / INJURY CONCERNS

In the unlikely event property damage or personal injury is suspected related to a U-Line product, please take the following

steps:

1. U-Line Customer Care must be contacted immediately at +1.800.779.2547.

2. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been

altered or repaired in the eld without prior written approval from U-Line, claims will not be eligible.

GENERAL INQUIRIES

U-Line Corporation

8900 N. 55th Street

Milwaukee, Wisconsin 53223 USA

Monday - Friday 8:00 am to 4:30 pm CST

T: +1.414.354.0300

F: +1.414.354.7905

Email: [e-mail]

u-line.com

SERVICE & PARTS ASSISTANCE

Monday - Friday 8:00 am to 4:30 pm CST

T: +1.800.779.2547

F: +1.414.354.5696

Service Email: [e-mail]

Parts Email: [e-mail]

CONNECT WITH US

Designed, engineered and assembled in WI, USA

QUICK START GUIDE

D

e

s

i

g

n

e

d

,

e

n

g

i

n

e

e

r

e

d

,

a

n

d

a

s

s

e

m

b

l

e

d

i

n

M

i

l

w

a

u

k

e

e

,

W

I

,

U

S

A

t

o

b

e

r

e

m

o

v

e

d

b

y

e

n

d

c

o

n

s

u

m

e

r

o

n

l

y

2

*

v

i

s

i

t

u

-

l

i

n

e

.

c

o

m

f

o

r

d

e

t

a

i

l

s

1 year + 1 with registration*

u-line.com

This Quick Start Guide covers the basics of installation and general use of your product. For more details,

see the complete User Guide & Service Manual on u-line.com.

Contents

1. Safety and Warning

2. Environmental Requirements

2. Electrical

3. Door Swing

4. Door Adjustments

5. General Installation

6. Integrated Panel Installation

8. Control Operation

10. First Use

10. Sabbath Mode

11. Warranty

This product is eligible for an additional one-year warranty at no charge when you register your product on u-line.com.

See complete warranty for details.

QUICK START GUIDE

QUICK START GUIDE

u-line.com

u-line.com

Safety and Warning

NOTICE

Please read all instructions before installing,

operating, or servicing the appliance.

Use this appliance for its intended purpose only and follow

these general precautions with those listed throughout this

guide:

SAFETY ALERT DEFINITIONS

Throughout this guide are safety items labeled with a

Danger, Warning or Caution based on the risk type:

DANGER

!

Danger means that failure to follow this safety

statement will result in severe personal injury or

death.

DANGER

!

This unit contains R600a (Isobutane) which is a

flammable hydrocarbon. It is safe for regular

use. Do not use sharp objects to expedite

defrosting. Do not service without consulting the

“R600a specifications” section included in the

User Guide. Do not damage the refrigerant

circuit.

WARNING

!

Service must be done by factory authorized

service personnel. Any parts shall be replaced

with like components. Failure to comply could

increase the risk of possible ignition due to

incorrect parts or improper service.

WARNING

!

WARNING

!

Warning means that failure to follow this safety

statement could result in serious personal injury

or death.

CAUTION

!

Caution means that failure to follow this safety

statement may result in minor or moderate

personal injury, property or equipment damage.

CALIFORNIA PROPOSITION 65

This product contains chemicals known to the

state of California to cause cancer and birth

defects or other reproductive harm.

www.P65warnings.CA.gov

1

QUICK START GUIDE

QUICK START GUIDE

u-line.com

removing power plug, or direct wiring can cause

Never use an extension cor d to con nect power to

appliances and is not recommended for your unit because

Environmental Requirements

This model is intended for indoor/interior applications only

and is not to be used in installations that are open/

exposed to natural elements.

This unit is designed to operate between 50°F (10°C) and

100°F (38°C). Higher ambient temperatures may reduce

the unit’s ability to reach low temperatures and/or reduce

ice production on applicable models.

For best performance, keep the unit out of direct sunlight

and away from heat generating equipment.

u-line.com

Electrical

WARNING

!

SHOCK HAZARD — Electrical Grounding

Required. Never attempt to repair or perform

maintenance on the unit until the electricity has

been disconnected.

Never remove the round grounding prong from

the plug and never use a two-prong grounding

adapter.

In climates where high humidity and dew points are

present, condensation may appear on outside surfaces.

This is considered normal. The condensation will

evaporate when the humidity drops.

CAUTION

!

Damages caused by ambient temperatures of

40°F (4°C) or below are not covered by the

warranty.

Altering, cutting or removing power cord,

serious injury, fire, loss of property and/or life,

and will void the warranty.

the unit.

Always keep your working area dry.

NOTICE

Electrical installation must observe all state and

local codes. This unit requires connection to a

grounded (three-prong), polarized receptacle

that has been placed by a qualified electrician.

The unit requires a grounded and polarized 115 VAC,

60 Hz, 15A power supply (normal household current). An

individual, properly grounded branch circuit or circuit

breaker is recommended. A GFCI (ground fault circuit

interrupter) is usually not required for fixed location

it could be prone to nuisance tripping. However, be sure

to consult your local codes.

2
