Ubiquiti Networks NSM2, NSM3, NSM365, NSM5, locoM2 User guide
...
High-Power 2x2 MIMO
airMAX
Models:
NSM2/NSM3/NSM365/NSM5
locoM2/locoM5/locoM9
™
TDMA Station
Introduction
2
Introduction
Thank you for purchasing the Ubiquiti Networks™ NanoStation™M
series product. This Quick Start Guide is designed to guide you
through the installation and show you how to access the airOS
Configuration Interface. This Quick Start Guide also includes the
warranty terms and is for use with the following models:
Model Operating Frequency Ethernet Ports
NanoStationM2 2412 - 2462 MHz 2
NanoStationM3 3400 - 3700 MHz 2
NanoStationM365 3650 - 3675 MHz 2
NanoStationM5 5170 - 5875 MHz* 2
™
NanoStationlocoM9 902 - 928 MHz 1
NanoStationlocoM2 2412 - 2462 MHz 1
NanoStationlocoM5 5170 - 5875 MHz* 1
* Only 5725 - 5850 MHz supported in the USA
86©XQLWV©ZLWK©)&&©,'©6:;õ160'©RU©6:;õ0/'©DUH©DOORZHG©õ©0+]
Package Contents
2
Carrier Class
™
BaseStations
airMAX
NanoStation 24V PoE
Adapter
Power Cord Mounting Ties
4W\©
Quick Start
Guide
Products may be different from pictures and are subject to change without notice.
TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet cable and
earth grounding must be used as conditions of product warranty. TOUGHCable is designed for outdoor
installations. It is the customer’s responsibility to follow local country regulations, including operation
ZLWKLQ©OHJDO©IUHTXHQF\©FKDQQHOV©RXWSXW©SRZHU©DQG©'\QDPLF©)UHTXHQF\©6HOHFWLRQ©')6©UHTXLUHPHQWV
1
™
NanoStation
M/NanoStationloco™M Quick Start Guide
Hardware Overview
Ports
Reset
Button
Secondary
Ethernet
Port
Secondary
Main
Reset
Main
Ethernet
Port
Note: The Secondary Ethernet Port is included on
only the NanoStation M2/M3/M5.
It is capable of 24V
Power over Ethernet output, which can provide power
to a secondary device. It can be enabled using the airOS
&RQILJXUDWLRQ,QWHUIDFH©
2
LEDs
Hardware Overview
LAN2LAN1
Power The Power LED will light green when the
device is connected to a power source.
LAN1
LAN2
WAN/Main Ethernet The LAN1 Ethernet LED
will light steady green when an active Ethernet
connection is made to the Primary Ethernet Port and
flash when there is activity.
LAN/Secondary Ethernet (NanoStation M2/M3/M5
RQO\©7KH©LAN2 Ethernet LED will light steady green
when an active Ethernet connection is made to
the Secondary Ethernet Port and flash when there
LVDFWLYLW\
Signal In airOS, you can modify the wireless signal
strength threshold values for each LED on the
Advanced tab under Signal LED Thresholds. The
default values are shown below:
LED will light red when the wireless signal
strength is above -94 dBm.
LED will light amber when the wireless signal
strength is above -80 dBm.
LED will light green when the wireless signal
strength is above -73 dBm.
LED will light green when the wireless signal
strength is above -65 dBm.
3
™
NanoStation
M/NanoStationloco™M Quick Start Guide
Installation Requirements
• 10 mm wrench
• 6KLHOGHG©&DWHJRU\©©RU©DERYH©FDEOLQJ©VKRXOG©EH©XVHG©IRU©DOO©
wired Ethernet connections and should be grounded through
the AC ground of the PoE.
We recommend that you protect your networks from the
most brutal environments and devastating ESD attacks
with industrial-grade shielded Ethernet cable from Ubiquiti
Networks. For more details, visit www.ubnt.com/toughcable
Typical Deployment
NanoStationloco
Ethernet Port on
Ubiquiti Device to
Ethernet Port labeled
POE on PoE Adapter
Default IP Address
192.168.1.20
POE
LAN
NanoStation
Connect the Power Cord
to the PoE Adapter and
a power outlet
LAN or Computer to
Ethernet Port labeled
LAN on PoE Adapter
Host Computer IP Address
192.168.1.x
4
