Ubiquiti UAPACL User Manual

802.11ac Dual Radio

UAP-AC Outdoor

Cloud/NOC

Management

Internet

1 3 5 7 9 11 13 15 17 19 21 22

2 4 6 8 10 12 14 16 18 20 22 24

SPF1

SPF2

Access Point

Model: UAP-AC-LITE

Introduction

Thank you for purchasing the Ubiquiti Networks® UniFi®AP.

This Quick Start Guide is designed to guide you through

installation and includes warranty terms.

Package Contents

UniFi AP AC Lite Mounting Bracket Ceiling Backing Plate

Flat Head Screws

(M3x50, Qty. 4)

Gigabit PoE (24V, 0.5A)

with Mounting Bracket

Installation Requirements

• CAT5/6 cable

• Phillips screwdriver

• Drill and drill bit (6 mm for wall-mounting or 3 mm for

ceiling-mounting)

• Optional: Drywall or keyhole saw (to cut 18 mm hole for

Ethernet cable feed)

TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the customer’s

responsibility to follow local country regulations, including operation within legal frequency
channels, output power, indoor cabling requirements, and Dynamic Frequency Selection

(DFS) requirements.

Keps Nuts

(M3, Qty. 4)

Screws

(M2.9x20, Qty. 4)

Power Cord Quick Start Guide

Screw Anchors
(M3x20, Qty. 4)

802.11ac Dual Radio
Access Point

Model: UAP-AC-LITE

System Requirements

• Microsoft Windows 7/8, MacOSX, or Linux

• Java Runtime Environment 1.6 (or above)

• Web Browser: Mozilla Firefox, Google Chrome, or Microsof t

Internet Explorer 8 (or above)

• UniFi Controller software v4.6 or higher (available at:

downloads.ubnt.com/unifi)

Network Topology Requirements

• A DHCP-enabled network (for the AP to obtain an IP address

as well as for the wireless clients after deployment)

• A management station running the UniFi Controller

software, located either on-site and connected to the same
Layer-2 network, or off-site in a cloud or NOC

UAP-AC-Lite

CURRENT SITE

REFRESH RATE

Default

2 minutes

DASHBOARD

Network Health

MAP

DEVICES

CLIENTS

CALLS

STATISTICS

INSIGHTS

WLAN

www

WAN LAN

VOIP

WAN LAN WLAN VOIP

www

APS

PHONES

IP

GATEWAY

SWITCHES

XXX.XXX.XXX.XXX

0

2

4

USERS

EXTENSION

DNS

ACTIVE CLIENTS

USERS

XXX.XXX.XXX.XXX

192

162

30

0

GUESTS

CALLS IN

DOWN

GUESTS

0

0

0

3

DOWN

CALLS OUT

UP

DOWN

0

0

0

6

UP

UP

0

0

SETTINGS

On-Site

Station

or

CURRENT SITE

REFRESH RATE

Default

2 minutes

DASHBOARD

Network Health

MAP

DEVICES

CLIENTS

CALLS

STATISTICS

INSIGHTS

WLAN

www

WAN LAN

VOIP

WAN LAN WLAN VOIP

www

APS

PHONES

IP

GATEWAY

SWITCHES

0

XXX.XXX.XXX.XXX

2

4

USERS

EXTENSION

XXX.XXX.XXX.XXX

DNS

ACTIVE CLIENTS

USERS

192

162

30

0

GUESTS

CALLS IN

DOWN

GUESTS

0

0

0

3

DOWN

CALLS OUT

UP

DOWN

0

0

0

6

UP

UP

0

0

SETTINGS

O-Site

Sample Network Diagram

All UniFi devices support off-site management controllers.
For setup details, see the User Guide on the website:

documentation.ubnt.com/unifi

LAN

WAN

UAP-PRO

UniFi Switch

UniFi
Security
Gateway

1G

Hardware Overview

LED

LED Color Status

White

Flashing White

Alternating
White/Blue

Blue

Quickly
Flashing Blue

Steady Blue
with occasional
flashing

Factory default, waiting to be integrated.

Initializing.

Device is busy; do not touch or unplug it.
This usually indicates that a process such
as a firmware upgrade is taking place.

Indicates the device has been successfully
integrated into a network and is working
properly.

This is used to locate an AP.

When you click Locate in the UniFi
Controller software, the AP will flash. It
will also display the location of the AP on
the map.

Indicates the device is in an isolated state
(all WLANs are brought down until an
uplink is found).

Ports

Locking Notch

Cable

Main

Reset

Button

Locking Notch The Locking Notch will be used with the

Mounting Bracket to help secure the UniFi AP. (This is described
further in the Mounting Bracket section.)

Main This Gigabit Ethernet port is used to connect the power

and should be connected to the LAN and DHCP server. Power
can be provided by the Gigabit PoE Adapter (included) or
Ubiquiti Networks UniFi Switch.

Reset The Reset button serves two functions for the UniFi AP:

• Restart Press and release the Reset button quickly.

• Restore to Factory Default Settings Press and hold the
Reset button for more than five seconds.

Cable Feed Use the Cable Feed slot to feed the Ethernet cable

along the mounting surface.

Port

Feed

Mounting Bracket

Locking Tab

Mounting Bracket

Locking Tab During installation, the Locking Tab on the

Mounting Bracket moves from the Initial Position to the Final
Position, where the Locking Tab fits securely into the Locking
Notch on the UniFi AP to help prevent theft.

Initial Position Final Position

Hardware Installation

The UniFi AP can be mounted on the wall or ceiling. Perform
the steps for the appropriate installation:

Wall Mount

1. Position the Mounting Bracket at the desired location on
the wall with the arrow pointing up.

2. Use a pencil to mark the four mounting holes. Use a 6 mm
drill bit to drill the mounting holes.

3. If your Ethernet cable feeds through the wall, then cut or
drill a circle approximately 18 mm in diameter. Then feed
the CAT5/6 cable through the hole.

Note: 25 mm is the distance from the center of the

bottom mounting hole to the center of the cable hole.

Arrow

25 mm

4. Insert the Screw Anchors into the 6 mm holes. Secure the
Mounting Bracket to the wall by inserting the Screws into

the anchors.

5. Connect the Ethernet cable to the Main port. If the feed is
along the mounting surface, feed the cable through the

Cable Feed of the UniFi AP.

Cable Feed

6. Align the arrow on the UniFi AP with the arrow on the

Locking Tab of the Mounting Bracket.

Locking Tab

Arrow

7. Ensure that the UniFi AP is firmly seated on the Mounting
Bracket. Turn the UniFi AP clockwise until it locks into place
and the Locking Tab fits securely into the Locking Notch.

Ceiling Mount

1. Remove the ceiling tile.

2. Place the Ceiling Backing Plate in the center of the ceiling
tile. Mark the four mounting screw holes.

3. Mark a hole approximately 18 mm in diameter for the
Ethernet cable feed.

25 mm

Note: 25 mm is the distance from the center of the

bottom mounting hole to the center of the cable hole.

4. Use a 3 mm drill bit to drill the screw holes, and cut or drill
the hole for the Ethernet cable feed.

5. Insert the Flat Head Screws through the Mounting Bracket,
ceiling tile, and Ceiling Backing Plate. Fasten the screws
using the Keps Nuts. Then feed the Ethernet cable through
the 18 mm hole.

6. Connect the Ethernet cable to the Main port.

7. Align the arrow on the UniFi AP with the arrow on the

Locking Tab of the Mounting Bracket.

Locking Tab

Arrow

8. Ensure that the UniFi AP is firmly seated on the Mounting
Bracket. Turn the UniFi AP clockwise until it locks into place

and the Locking Tab fits securely into the Locking Notch.

9. Set the ceiling tile back into place.

Powering the UniFi AP

The UniFi AP can be powered directly by a UniFi Switch or with
the included Gigabit PoE Adapter.

Connecting to a UniFi Switch

Connect the other end of the Ethernet cable from the UniFi AP
directly to a PoE port on the UniFi Switch.

UniFi Switch Power Connection Diagram

Connecting to the PoE Adapter

1. Connect the other end of the Ethernet cable from the
UniFi AP to the Ethernet port labeled POE on the Gigabit
PoEAdapter.

2. Connect an Ethernet cable from your LAN to the Ethernet
port labeled LAN on the adapter.

3. Connect the Power Cord to the power port on the adapter.
Connect the other end of the Power Cord to a power outlet.

*640-00180-02*

640-00180-02

Mounting the PoE Adapter (Optional)

The device for operation in the band 5150 -5250 MHz is only for indoor use to
reduce the potential for harmful interference to co-channel mobile satellite systems.

1. Slide the PoE Mounting Bracket down to remove it from the

Gigabit PoE Adapter.

2. Place the PoE Mounting Bracket at the desired location and
mark the two holes. Pre-drill the holes if necessary, and
then secure the bracket using two fasteners (not included).

3. Align the slots of the Gigabit PoE Adapter with the tabs of
the PoE Mounting Bracket, and then slide the adapterdown.

Software Installation

Download and install the latest version of the UniFi Controller
software at: downloads.ubnt.com/unifi

Launch the software and follow the on-screen instructions.
Step-by-step instructions are available in the User Guide
located on our website: documentation.ubnt.com/unifi

After you have installed the software and run the UniFi
Installation Wizard, a login screen will appear for the UniFi
Controller management interface. Enter the Admin Name and
Password that you created and click Login.

You can manage your wireless network and view network
statistics using the UniFi Controller management interface.
For information on configuring and using the UniFi Controller
software, refer to the User Guide.

Specifications

Dimensions 154.5 x 154.5 x 30.15 mm

Weight 175 g (266 g with Mounting Kits)

Networking Interface (1) 10/100/1000 Ethernet Port

Buttons (1) Reset to Defaults

Antennas (2) Dual-Band Antennas, 3 dBi Each

Wi-Fi Standards 802.11 a/b/g/n/ac

Power Method Passive PoE

Power Supply 24V, 0.5A Gigabit PoE Adapter (Included)

Max. Power Consumption 6.5W

Max. TX Power

2.4 GHz
5 GHz

BSSID Up to Four per Radio

Wireless Security WEP, WPA-PSK, WPA-Enterprise

Certications CE, FCC, IC

Mounting Wall/Ceiling (Kits Included)

Operating Temperature -10 to 70° C (14 to 158° F)

Operating Humidity 5 to 95% Noncondensing

UniFi AP AC Lite

6.17 oz (9.38 oz with Mounting Kits)

(6.08 x 6.08 x 1.19")

(Pairs 4, 5+; 7, 8 Return)

20 dBm
20 dBm

(WPA/WPA2, TKIP/AES)

Safety Notices

1. Read, follow, and keep these instructions.

2. Heed all warnings.

3. Only use attachments/accessories specified by the manufacturer.

WARNING: Do not use this product in location that can

be submerged by water.

WARNING: Avoid using this product during an electrical

storm. There may be a remote risk of electric shock from
lightning.

Electrical Safety Information

1. Compliance is required with respect to voltage, frequency, and current
requirements indicated on the manufacturer’s label. Connection to a
different power source than those specified may result in improper
operation, damage to the equipment or pose a fire hazard if the
limitations are not followed.

2. There are no operator serviceable parts inside this equipment. Service
should be provided only by a qualified service technician.

3. This equipment is provided with a detachable power cord which has
an integral safety ground wire intended for connection to a grounded
safety outlet.

a. Do not substitute the power cord with one that is not the provided

approved type. Never use an adapter plug to connect to a 2-wire
outlet as this will defeat the continuity of the grounding wire.

b. The equipment requires the use of the ground wire as a part of the

safety certification, modification or misuse can provide a shock
hazard that can result in serious injury or death.

c. Contact a qualified electrician or the manufacturer if there

are questions about the installation prior to connecting the
equipment.

d. Protective earthing is provided by Listed AC adapter. Building

installation shall provide appropriate short-circuit backup
protection.

e. Protective bonding must be installed in accordance with local

national wiring rules and regulations.

Limited Warranty

UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”) warrants that the
product(s) furnished hereunder (the “Product(s)”) shall be free from defects
in material and workmanship for a period of one (1) year from the date
of shipment by UBIQUITI NETWORKS under normal use and operation.
UBIQUITI NETWORKS’ sole and exclusive obligation and liability under
the foregoing warranty shall be for UBIQUITI NETWORKS, at its discretion,
to repair or replace any Product that fails to conform to the above
warranty during the above warranty period. The expense of removal and
reinstallation of any Product is not included in this warranty. The warranty
period of any repaired or replaced Product shall not extend beyond its
original term.

Warranty Conditions

The above warranty does not apply if the Product:
(I) has been modified and/or altered, or an addition made thereto,

except by Ubiquiti Networks, or Ubiquiti Networks’ authorized

representatives, or as approved by Ubiquiti Networks in writing;
(II) has been painted, rebranded or physically modified in any way;
(III) has been damaged due to errors or defects in cabling;
(IV) has been subjected to misuse, abuse, negligence, abnormal

physical, electromagnetic or electrical stress, including lightning

strikes, or accident;
(V) has been damaged or impaired as a result of using third party

firmware;
(VI) has no original Ubiquiti MAC label, or is missing any other original

Ubiquiti label(s); or
(VII) has not been received by Ubiquiti within 30 days of issuance of

the RMA.
In addition, the above warranty shall apply only if: the product has been

properly installed and used at all times in accordance, and in all material
respects, with the applicable Product documentation; all Ethernet cabling
runs use CAT5 (or above), and for outdoor installations, shielded Ethernet
cabling is used, and for indoor installations, indoor cabling requirements
are followed.

Returns

No Products will be accepted for replacement or repair without obtaining
a Return Materials Authorization (RMA) number from UBIQUITI NETWORKS
during the warranty period, and the Products being received at UBIQUITI
NETWORKS’ facility freight prepaid in accordance with the RMA process of
UBIQUITI NETWORKS. Products returned without an RMA number will not
be processed and will be returned freight collect or subject to disposal.
Information on the RMA process and obtaining an RMA number can be
found at: www.ubnt.com/support/warranty.

Disclaimer

EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN, UBIQUITI
NETWORKS, ITS AFFILIATES, AND ITS AND THEIR THIRD PART Y DATA,
SERVICE, SOFTWARE AND HARDWARE PROVIDERS HEREBY DISCLAIM
AND MAKE NO OTHER REPRESENTATION OR WARRANTY OF ANY KIND,
EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
REPRESENTATIONS, GUARANTEES, OR WARRANTIES OF MERCHANTABILITY,
ACCURACY, QUALITY OF SERVICE OR RESULTS, AVAILABILITY,
SATISFACTORY QUALITY, LACK OF VIRUSES, QUIET ENJOYMENT, FITNESS
FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT AND ANY
WARRANTIES ARISING FROM ANY COURSE OF DEALING, USAGE OR
TRADE PRACTICE IN CONNECTION WITH SUCH PRODUCTS AND SERVICES.
BUYER ACKNOWLEDGES THAT NEITHER UBIQUITI NETWORKS NOR
ITS THIRD PARTY PROVIDERS CONTROL BUYER’S EQUIPMENT OR THE
TRANSFER OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING
THE INTERNET, AND THAT THE PRODUCTS AND SERVICES MAY BE
SUBJECT TO LIMITATIONS, INTERRUPTIONS, DELAYS, CANCELLATIONS
AND OTHER PROBLEMS INHERENT IN THE USE OF COMMUNICATIONS
FACILITIES. UBIQUITI NETWORKS, ITS AFFILIATES AND ITS AND THEIR THIRD
PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTERRUPTIONS,
DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA LOSS, CONTENT
CORRUPTION, PACKET LOSS, OR OTHER DAMAGE RESULTING FROM ANY
OF THE FOREGOING. In addition, UBIQUITI NETWORKS does not warrant
that the operation of the Products will be error-free or that operation will
be uninterrupted. In no event shall UBIQUITI NETWORKS be responsible
for damages or claims of any nature or description relating to system
performance, including coverage, buyer’s selection of products (including
the Products) for buyer’s application and/or failure of products (including
the Products) to meet government or regulatory requirements.

Limitation of Liability

EXCEPT TO THE EXTENT PROHIBITED BY LOCAL LAW, IN NO EVENT WILL
UBIQUITI OR ITS SUBSIDIARIES, AFFILIATES OR SUPPLIERS BE LIABLE FOR
DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL OR OTHER DAMAGES
(INCLUDING LOST PROFIT, LOST DATA, OR DOWNTIME COSTS), ARISING
OUT OF THE USE, INABILITY TO USE, OR THE RESULTS OF USE OF THE
PRODUCT, WHETHER BASED IN WARRANTY, CONTRACT, TORT OR OTHER
LEGAL THEORY, AND WHETHER OR NOT ADVISED OF THE POSSIBILIT Y OF
SUCH DAMAGES.

Note

Some countries, states and provinces do not allow exclusions of implied
warranties or conditions, so the above exclusion may not apply to you.
You may have other rights that vary from country to country, state to
state, or province to province. Some countries, states and provinces do not
allow the exclusion or limitation of liability for incidental or consequential
damages, so the above limitation may not apply to you. EXCEPT TO
THE EXTENT ALLOWED BY LOCAL LAW, THESE WARRANTY TERMS DO
NOT EXCLUDE, RESTRICT OR MODIFY, AND ARE IN ADDITION TO, THE
MANDATORY STATUTORY RIGHTS APPLICABLE TO THE LICENSE OF ANY
SOFTWARE (EMBEDDED IN THE PRODUCT) TO YOU. The United Nations
Convention on Contracts for the International Sale of Goods shall not apply
to any transactions regarding the sale of the Products.

Compliance

FCC

Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions.

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including
interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Operations of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the
interference at his own expense.

This radio transmitter (FCC: SWX-UAPACL) has been approved by FCC
to operate with the antenna types listed below with the maximum
permissible gain and required antenna impedance for each antenna type
indicated. Antenna types not included in this list, having a gain greater
than the maximum gain indicated for that type, are strictly prohibited for
use with this device.

Antenna Information: Dual-band antenna, Gain: 3 dBi

Industry Canada

CAN ICES-3(B)/NMB-3(B)

To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically
radiated power (e.i.r.p.) is not more than that permitted for successful
communication.

This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that
may cause undesired operation of the device.

Users should also be advised that high-power radars are allocated
as primary users (i.e. priority users) of the bands 5250-5350 MHz and
5650-5850 MHz and that these radars could cause interference and/or
damage to LE-LAN devices. This radio transmitter (IC: 6545A-UAPACL) has
been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included
in this list, having a gain greater than the maximum gain indicated for that
type, are strictly prohibited for use with this device.

Antenna Information: Dual-band antenna, Gain: 3 dBi

CAN ICES-3(B)/NMB-3(B)

Pour réduire le risque d’interférence aux autres utilisateurs, le type
d’antenne et son gain doivent être choisies de façon que la puissance
isotrope rayonnée équivalente (PIRE) ne dépasse pas ce qui est nécessaire
pour une communication réussie.

Cet appareil est conforme à la norme RSS Industrie Canada exempts de
licence norme(s). Son fonctionnement est soumis aux deux conditions
suivantes:

1. Cet appareil ne peut pas provoquer d’interférences et

2. Cet appareil doit accepter toute interférence, y compris les
interférences qui peuvent causer un mauvais fonctionnement du
dispositif.

Les utilisateurs devraient également noter que radars haute puissants
sont alloués comme principaux utilisateurs (c’est-à-dire les utilisateurs de
priorité) des bandes 5250-5350 MHz et 5650 à 5850 MHz et que ces radars
pourraient causer des interférences ou dommages aux dispositifs LAN. Cet
émetteur radio (IC: 6545A-UAPACL) a été approuvée par Industrie Canada
pour l’exploitation avec l’antenne types énumérés ci-dessous avec le gain
maximal admissible et requis l’impédance de l’antenne pour chaque type
d’antenne indiqué. Types d’antenne non inclus dans cette liste, ayant un
gain supérieur au gain maximal indiqué pour ce type, sont strictement
interdits pour une utilisation avec cet appareil. Immédiatement suite à la
remarque, le fabricant doit fournir une liste de tous les types d’antenne
approuvé pour une utilisation avec l’émetteur, ce qui indique le gain
maximal d’antenne permis (en dBi) et requis d’impédance pour chacun.

Informations d’antenne: Antenne bi-bande, Gain: 3 dBi

RF Exposure Warning

The antennas used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be
located or operating in conjunction with any other antenna or transmitter,
except as listed for this product’s certification.

Les antennes utilisées pour ce transmetteur doivent être installé en
considérant une distance de séparation de toute personnes d’au moins
20 cm et ne doivent pas être localisé ou utilisé en conflit avec tout autre
antenne ou transmetteur.

CE Marking

CE marking on this product represents the product is in compliance with all
directives that are applicable to it.

Alert Sign (!) Follows CE Marking

Alert sign must be indicated if a restriction on use applied to the product
and it must follow the CE marking.

RoHS/WEEE Compliance Statement

English

European Directive 2002/96/EC requires that the equipment bearing
this symbol on the product and/or its packaging must not be disposed
of with unsorted municipal waste. The symbol indicates that this
product should be disposed of separately from regular household waste
streams. It is your responsibility to dispose of this and other electric and
electronic equipment via designated collection facilities appointed by the
government or local authorities. Correct disposal and recycling will help
prevent potential negative consequences to the environment and human
health. For more detailed information about the disposal of your old
equipment, please contact your local authorities, waste disposal service, or
the shop where you purchased the product.

Deutsch

Die Europäische Richtlinie 2002/96/EC verlangt, dass technische
Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit diesem
Symbol versehen ist, nicht zusammen mit unsortiertem Gemeindeabfall
entsorgt werden darf. Das Symbol weist darauf hin, dass das Produkt
von regulärem Haushaltmüll getrennt entsorgt werden sollte. Es
liegt in Ihrer Verantwortung, dieses Gerät und andere elektrische
und elektronische Geräte über die dafür zuständigen und von der
Regierung oder örtlichen Behörden dazu bestimmten Sammelstellen zu
entsorgen. Ordnungsgemäßes Entsorgen und Recyceln trägt dazu bei,
potentielle negative Folgen für Umwelt und die menschliche Gesundheit
zu vermeiden. Wenn Sie weitere Informationen zur Entsorgung Ihrer
Altgeräte benötigen, wenden Sie sich bitte an die örtlichen Behörden oder
städtischen Entsorgungsdienste oder an den Händler, bei dem Sie das
Produkt erworben haben.

Español

La Directiva 2002/96/CE de la UE exige que los equipos que lleven este
símbolo en el propio aparato y/o en su embalaje no deben eliminarse
junto con otros residuos urbanos no seleccionados. El símbolo indica
que el producto en cuestión debe separarse de los residuos domésticos
convencionales con vistas a su eliminación. Es responsabilidad suya
desechar este y cualesquiera otros aparatos eléctricos y electrónicos a
través de los puntos de recogida que ponen a su disposición el gobierno y
las autoridades locales. Al desechar y reciclar correctamente estos aparatos
estará contribuyendo a evitar posibles consecuencias negativas para el
medio ambiente y la salud de las personas. Si desea obtener información
más detallada sobre la eliminación segura de su aparato usado, consulte a
las autoridades locales, al servicio de recogida y eliminación de residuos de
su zona o pregunte en la tienda donde adquirió el producto.

Français

La directive européenne 2002/96/CE exige que l’équipement sur lequel
est apposé ce symbole sur le produit et/ou son emballage ne soit pas jeté
avec les autres ordures ménagères. Ce symbole indique que le produit
doit être éliminé dans un circuit distinct de celui pour les déchets des
ménages. Il est de votre responsabilité de jeter ce matériel ainsi que tout
autre matériel électrique ou électronique par les moyens de collecte
indiqués par le gouvernement et les pouvoirs publics des collectivités
territoriales. L’élimination et le recyclage en bonne et due forme ont pour
but de lutter contre l’impact néfaste potentiel de ce type de produits
sur l’environnement et la santé publique. Pour plus d’informations sur le
mode d’élimination de votre ancien équipement, veuillez prendre contact
avec les pouvoirs publics locaux, le service de traitement des déchets, ou
l’endroit où vous avez acheté le produit.

Italiano

La direttiva europea 2002/96/EC richiede che le apparecchiature
contrassegnate con questo simbolo sul prodotto e/o sull’imballaggio non
siano smaltite insieme ai rifiuti urbani non differenziati. Il simbolo indica
che questo prodotto non deve essere smaltito insieme ai normali rifiuti
domestici. È responsabilità del proprietario smaltire sia questi prodotti sia
le altre apparecchiature elettriche ed elettroniche mediante le specifiche
strutture di raccolta indicate dal governo o dagli enti pubblici locali. Il
corretto smaltimento ed il riciclaggio aiuteranno a prevenire conseguenze
potenzialmente negative per l’ambiente e per la salute dell’essere umano.
Per ricevere informazioni più dettagliate circa lo smaltimento delle vecchie
apparecchiature in Vostro possesso, Vi invitiamo a contattare gli enti
pubblici di competenza, il servizio di smaltimento rifiuti o il negozio nel
quale avete acquistato il prodotto.

Declaration of Conformity

Česky
[Czech]

Dansk
[Danish]

Nederlands
[Dutch]

English

Eesti
[Estonian]

Suomi
[Finnish]

Français
[French]

Deutsch
[German]

Ελληνική
[Greek]

Magyar
[Hungarian]

Íslenska
[Icelandic]

Italiano
[Italian]

Latviski
[Latvian]

Lietuviškai
[Lithuanian]

UBIQUITI NETWORKS tímto prohlašuje, že toto UBIQUITI
NETWORKS zařízení, je ve shod se základními požadavky a dalšími
příslušnými ustanoveními směrnice 1999/5/ES.

Hermed, UBIQUITI NETWORKS, erklærer at denne UBIQUITI
NETWORKS enhed, er i overensstemmelse med de væsentlige krav
og øvrige relevante krav i direktiv 1999/5/EF.

Hierbij verklaart UBIQUITI NETWORKS, dat deze UBIQUITI
NETWORKS apparaat, in overeenstemming is met de essentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EC.

Hereby, UBIQUITI NETWORKS, declares that this UBIQUITI
NETWORKS device, is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.

Käesolevaga UBIQUITI NETWORKS kinnitab, et antud UBIQUITI
NETWORKS seade, on vastavus olulistele nõuetele ja teistele
asjakohastele sätetele direktiivi 1999/5/EÜ.

Täten UBIQUITI NETWORKS vakuuttaa, että tämä UBIQUITI
NETWORKS laite, on yhdenmukainen olennaisten vaatimusten ja
muiden sitä koskevien direktiivin 1999/5/EY.

Par la présente UBIQUITI NETWORKS déclare que l’appareil
UBIQUITI NETWORKS, est conforme aux exigences essentielles et
aux autres dispositions pertinentes de la directive 1999/5/CE.

Hiermit erklärt UBIQUITI NETWORKS, dass sich dieses UBIQUITI
NETWORKS Gerät, in Übereinstimmung mit den grundlegenden
Anforderungen und den anderen relevanten Vorschriften der
Richtlinie 1999/5/EG befindet.

Δια του παρόντος, UBIQUITI NETWORKS, δηλώνει ότι αυτή η
συσκευή UBIQUITI NETWORKS, είναι σε συμμόρφωση με τις
βασικές απαιτήσεις και τις λοιπές σχετικές διατάξεις της οδηγίας
1995/5/ΕΚ.

Ezennel UBIQUITI NETWORKS kijelenti, hogy ez a UBIQUITI
NETWORKS készülék megfelel az alapvető követelményeknek és
más vonatkozó 1999/5/EK irányelv rendelkezéseit.

Hér, UBIQUITI NETWORKS, því yfir að þetta UBIQUITI NETWORKS
tæki er í samræmi við grunnkröfur og önnur viðeigandi ákvæði
tilskipun 1999/5/EC.

Con la presente, UBIQUITI NETWORKS, dichiara che questo
dispositivo UBIQUITI NETWORKS, è conforme ai requisiti essenziali
ed alle altre disposizioni pertinenti della direttiva 1999/5/CE.

Ar šo, UBIQUITI NETWORKS, deklarē, ka UBIQUITI NETWORKS
ierīce, ir saskaņā ar būtiskajām prasībām un citiem attiecīgiem
noteikumiem Direktīvā 1999/5/EK.

UBIQUITI NETWORKS deklaruoja, kad šis UBIQUITI NETWORKS
įrenginys atitinka esminius reikalavimus ir kitas 1999/5/EB
Direktyvos nuostatas.

Malti
[Maltese]

Norsk
[Norwegian]

Slovensky
[Slovak]

Svenska
[Swedish]

Español
[Spanish]

Polski
[Polish]

Português
[Portuguese]

Română
[Romanian]

Hawnhekk, UBIQUITI NETWORKS, tiddikjara li dan il-mezz
UBIQUITI NETWORKS huwa konformi mar-rekwiżiti essenzjali u
dispożizzjonijiet rilevanti oħrajn ta ‘Direttiva 1999/5/EC.

Herved UBIQUITI NETWORKS, erklærer at denne UBIQUITI
NETWORKS enheten, er i samsvar med de grunnleggende kravene
og andre relevante bestemmelser i direktiv

Týmto

UBIQUITI NETWORKS

NETWORKS

zariadenie, je v súlade so základnými požiadavkami a

ďalšími relevantnými ustanoveniami smernice 1999/5/ES.

Härmed UBIQUITI NETWORKS, intygar att denna UBIQUITI
NETWORKS enhet är i överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av
direktiv 1999/5/EG.

Por medio de la presente UBIQUITI NETWORKS declara que este
dispositivo UBIQUITI NETWORKS, cumple con los requisitos
esenciales y cualesquiera otras disposiciones aplicables o exigibles
de la Directiva 1999/5/CE.

Niniejszym, Ubiquiti Networks, oświadcza, że urządzenie UBIQUITI
NETWORKS, jest zgodny z zasadniczymi wymaganiami oraz
pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.

UBIQUITI NETWORKS declara que este dispositivo UBIQUITI
NETWORKS, está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.

Prin prezenta, UBIQUITI NETWORKS declară că acest dispozitiv
UBIQUITI NETWORKS este în conformitate cu cerințele esențiale și
alte prevederi relevante ale Directivei 1999/5/CE.

Online Resources

Support support.ubnt.com
Community community.ubnt.com
Downloads downloads.ubnt.com

1999/5/EF.

, prehlasuje, že toto

UBIQUITI

©2015 Ubiquiti Networks, Inc. All rights reserved. Ubiquiti, Ubiquiti
Networks, the Ubiquiti U logo, the Ubiquiti beam logo, and UnIFi are
trademarks or registered trademarks of Ubiquiti Networks, Inc. in the United
States and in other countries. All other trademarks are the property of their
respective owners. AI052115
