Tweco 300-DC User Manual

300 AC/DC

®

ARCMASTER

INVERTER ARC WELDER

Operating Manual

Version No: AB.01 Issue Date: February 22, 2006 Manual No.: 0-4863
Operating Features:

50
60

Art # A-07238

230V460

V

INVERTER

Hz

1/3

208

V

WE APPRECIA TE YOUR BUSINESS!

Congratulations on your new Thermal Arc product. We are proud
to have you as our customer and will strive to provide you with
the best service and reliability in the industry. This product is backed
by our extensive warranty and world-wide service network. To
locate your nearest distributor or service agency call
1-800-752-7621, or visit us on the web at www.Thermalarc.com.

This Operating Manual has been designed to instruct you on the
correct use and operation of your Thermal Arc product. Your
satisfaction with this product and its safe operation is our ultimate
concern. Therefore please take the time to read the entire manual,
especially the Safety Precautions. They will help you to avoid
potential hazards that may exist when working with this product.

YOU ARE IN GOOD COMPANY!

The Brand of Choice for Contractors and Fabricators Worldwide.

Thermal Arc is a Global Brand of Arc Welding Products for
Thermadyne Industries Inc. We manufacture and supply to major
welding industry sectors worldwide including; Manufacturing,
Construction, Mining, Automotive, Aerospace, Engineering, Rural
and DIY/Hobbyist.

We distinguish ourselves from our competition through market­leading, dependable products that have stood the test of time. We
pride ourselves on technical innovation, competitive prices,
excellent delivery, superior customer service and technical support,
together with excellence in sales and marketing expertise.

Above all, we are committed to develop technologically advanced
products to achieve a safer working environment within the welding
industry.

WARNINGS

Read and understand this entire Manual and your employer’s safety practices before installing,
operating, or servicing the equipment.

While the information contained in this Manual represents the Manufacturer's best judgement,
the Manufacturer assumes no liability for its use.

ArcMaster 300 AC/DC Inverter Arc Welder
Instruction Manual Number 0-4863 for:
Part Number 10-3074

Published by:
Thermadyne Corporation
82 Benning Street
West Lebanon, New Hampshire, USA 03784
[phone]

www.thermalarc.com

Copyright 2006 by
Thermadyne Corporation

All rights reserved.

Reproduction of this work, in whole or in part, without written permission of the pub­lisher is prohibited.

The publisher does not assume and hereby disclaims any liability to any party for any
loss or damage caused by any error or omission in this Manual, whether such error
results from negligence, accident, or any other cause.

Publication Date: February 22, 2006

Record the following information for Warranty purposes:

Where Purchased: ___________________________________

Purchase Date: ___________________________________

Equipment Serial #: ___________________________________

i

TABLE OF CONTENTS

SECTION 1:

SAFETY INSTRUCTIONS AND WARNINGS ....................................................... 1-1

1.01 Arc Welding Hazards ...................................................................................... 1-1

1.02 Principal Safety Standards ............................................................................. 1-5

1.03 Precautions de Securite en Soudage à L’Arc .................................................. 1-6

1.04 Dangers Relatifs au Soudage à L’Arc .............................................................. 1-6

1.05 Principales Normes de Securite ................................................................... 1-10

SECTION 2:

INTRODUCTION ...................................................................................... 2-1

2.01 How To Use This Manual ................................................................................ 2-1

2.02 Equipment Identification................................................................................. 2-1

2.03 Receipt Of Equipment ..................................................................................... 2-1

2.04 Symbol Chart ................................................................................................. 2-2

2.05 Description ..................................................................................................... 2-3

2.06 Functional Block Diagrams ............................................................................. 2-4

2.07 Transporting Methods .................................................................................... 2-4

SECTION 3:

INSTALLATION ....................................................................................... 3-1

3.01 Environment ................................................................................................... 3-1

3.02 Location ......................................................................................................... 3-1

3.03 Electrical Input Connections ........................................................................... 3-1

3.04 Electrical Input Requirements ........................................................................ 3-2

3.05 Input Power .................................................................................................... 3-3

3.06 High Frequency Introduction .......................................................................... 3-3

3.07 High Frequency Interference .......................................................................... 3-4

3.08 Duty Cycle ...................................................................................................... 3-4

3.09 Specifications ................................................................................................. 3-5

SECTION 4:

OPERATOR CONTROLS ............................................................................. 4-1

4.01 ArcMaster 300 ACDC Controls ....................................................................... 4-1

4.02 Weld Process Selection for ArcMaster 300 ACDC .......................................... 4-3

4.03 Weld Parameter Descriptions for ArcMaster 300 ACDC ................................. 4-4

4.04 Weld Parameters for ArcMaster 300 ACDC .................................................... 4-6

4.05 Power Source Features................................................................................... 4-7

SECTION 5:

SET-UP FOR SMAW (STICK) AND GTAW (TIG) .................................................. 5-1

TABLE OF CONTENTS (continued)TABLE OF CONTENTS

SECTION 6:

SEQUENCE OF OPERATION ........................................................................ 6-1

6.01 Stick Welding ................................................................................................. 6-3

6.02 AC or DC HF TIG Welding ............................................................................... 6-3

6.03 Slope Mode Sequence .................................................................................... 6-4

6.04 Slope Mode with Repeat Sequence ................................................................ 6-4

6.05 Pulse Controls ................................................................................................ 6-5

SECTION 7:

BASIC TIG WELDING GUIDE ....................................................................... 7-1

7.01 Explanation of “Fluttery Arc” when AC TIG Welding on Aluminum ................. 7-1

7.02 Electrode Polarity ........................................................................................... 7-2

7.03 Tungsten Electrode Current Ranges ............................................................... 7-2

7.04 Tungsten Electrode Types............................................................................... 7-2

7.05 Guide for Selecting Filler Wire Diameter ......................................................... 7-3

7.06 Shielding Gas Selection .................................................................................. 7-3

7.07 TIG Welding Parameters for Low Carbon & Low Alloy Steel Pipe .................. 7-3

7.08 Welding Parameters for Aluminum ................................................................ 7-4

7.09 Welding Parameters for Steel ......................................................................... 7-4

SECTION 8:

BASIC ARC WELDING GUIDE ..................................................................... 8-1

8.01 Electrode Polarity ........................................................................................... 8-1

8.02 Effects of Stick Welding Various Materials ..................................................... 8-1

SECTION 9:

ROUTINE MAINTENANCE .......................................................................... 9-1

SECTION 10:

BASIC TROUBLESHOOTING ...................................................................... 10-1

10.01 TIG Welding Problems................................................................................ 10-1

10.02 Stick Welding Problems ............................................................................. 10-4

10.03 Power Source Problems ............................................................................. 10-7

SECTION 11:

VOLTAGE REDUCTION DEVICE (VRD) ........................................................... 11-1

11.01 VRD Specification ....................................................................................... 11-1

11.02 VRD Maintenance ....................................................................................... 11-1

11.03 Switching VRD On/Off ................................................................................ 11-2

SECTION 12:

POWER SOURCE ERROR CODES................................................................. 12-1

TABLE OF CONTENTS

APPENDIX 1: ARCMASTER 300 AC/DC ACCESSORIES ............................................... A-1

APPENDIX 2: ARCMASTER 300 AC/DC INTERCONNECT DIAGRAM................................. A-2

LIMITED WARRANTY

WARRANTY SCHEDULE

GLOBAL CUSTOMER SERVICE CONTACT INFORMATION .......................... Inside Rear Cover

ARCMASTER 300 ACDC

SECTION 1:

SAFETY INSTRUCTIONS AND WARNINGS

WARNING

PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY.
PACEMAKER WEARERS KEEP AWAY UNTIL CONSULTING YOUR DOCTOR. DO NOT LOSE THESE INSTRUCTIONS.
READ OPERATING/INSTRUCTION MANUAL BEFORE INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT.

Welding products and welding processes can cause serious injury or death, or damage to other equipment or property,
if the operator does not strictly observe all safety rules and take precautionary actions.

Safe practices have developed from past experience in the use of welding and cutting. These practices must be
learned through study and training before using this equipment. Some of these practices apply to equipment

connected to power lines; other practices apply to engine driven equipment. Anyone not having extensive
training in welding and cutting practices should not attempt to weld.

Safe practices are outlined in the American National Standard Z49.1 entitled: SAFETY IN WELDING AND CUTTING.
This publication and other guides to what you should learn before operating this equipment are listed at the end of
these safety precautions. HAVE ALL INSTALLATION, OPERATION, MAINTENANCE, AND REPAIR WORK PERFORMED

ONLY BY QUALIFIED PEOPLE.

1.01 Arc Welding Hazards

WARNING

ELECTRIC SHOCK can kill.

Touching live electrical parts can cause fatal
shocks or severe burns. The electrode and
work circuit is electrically live whenever the
output is on. The input power circuit and
machine internal circuits are also live when
power is on. In semiautomatic or automatic
wire welding, the wire, wire reel, drive roll
housing, and all metal parts touching the
welding wire are electrically live. Incorrectly
installed or improperly grounded equipment
is a hazard.

3. Insulate yourself from work and ground using dry
insulating mats or covers.

4. Disconnect input power or stop engine before
installing or servicing this equipment. Lock input
power disconnect switch open, or remove line fuses
so power cannot be turned on accidentally.

5. Properly install and ground this equipment according
to its Owner’s Manual and national, state, and local
codes.

6. Turn off all equipment when not in use. Disconnect
power to equipment if it will be left unattended or out
of service.

7. Use fully insulated electrode holders. Never dip holder
in water to cool it or lay it down on the ground or the
work surface. Do not touch holders connected to two
welding machines at the same time or touch other
people with the holder or electrode.

8. Do not use worn, damaged, undersized, or poorly
spliced cables.

1. Do not touch live electrical parts.

2. Wear dry, hole-free insulating gloves and body
protection.

February 22, 2006

9. Do not wrap cables around your body.

10.Ground the workpiece to a good electrical (earth)
ground.

1-1

ARCMASTER 300 ACDC

11.Do not touch electrode while in contact with the work
(ground) circuit.

12. Use only well-maintained equipment. Repair or replace
damaged parts at once.

13.In confined spaces or damp locations, do not use a
welder with AC output unless it is equipped with a
voltage reducer. Use equipment with DC output.

14.Wear a safety harness to prevent falling if working
above floor level.

15.Keep all panels and covers securely in place.

WARNING

ARC RAYS can burn eyes and skin; NOISE can
damage hearing.

Arc rays from the welding process produce
intense heat and strong ultraviolet rays that
can burn eyes and skin. Noise from some
processes can damage hearing.

4. Wear protective clothing made from durable, flame­resistant material (wool and leather) and foot
protection.

5. Use approved ear plugs or ear muffs if noise level is
high.

WARNING

FUMES AND GASES can be hazardous to your
health.

Welding produces fumes and gases. Breathing
these fumes and gases can be hazardous to
your health.

1. Keep your head out of the fumes. Do not breath the
fumes.

2. If inside, ventilate the area and/or use exhaust at the
arc to remove welding fumes and gases.

3. If ventilation is poor, use an approved air-supplied
respirator.

1. Wear a welding helmet fitted with a proper shade of
filter (see ANSI Z49.1 listed in Safety Standards) to
protect your face and eyes when welding or watching.

2. Wear approved safety glasses. Side shields
recommended.

3. Use protective screens or barriers to protect others
from flash and glare; warn others not to watch the
arc.

Eye protec t io n fil ter shad e se lect or f or wel din g or cutti ng

(gog gles or helmet), from AWS A6.2-73.

Weldi ng or c utt ing Electr ode S ize Filter Weldi ng or c utt ing Electrode Size F ilter

Torch soldering 2

Torch br a zing 3 or 4 Non-ferr ou s base met al All 11

Oxyg en Cutting

Light Under 1 in., 25 mm 3 or 4 Gas tung ste n ar c weldi ng All 12

Medium 1 to 6 in., 25- 150 mm 4 or 5 (T IG) All 12

Heavy Over 6 in. , 150 mm 5 or 6 Atomic hydr ogen wel ding All 12

Gas w elding

Light Under 1/8 in., 3 mm 4 or 5 Plasma arc welding

M e dium 1/8 to 1/2 in., 3- 12 mm 5 or 6

Heavy Over 1/2 in., 12 mm 6 or 8 Light 12

Shielded metal-arc

Under 5/32 in., 4 mm 10 Heavy 14

5/32 to 1/ 4 in. , 12

Over 1/ 4 in., 6.4 mm 14 Light Under 300 Amp 9

4. Read the Material Safety Data Sheets (MSDSs) and
the manufacturer’s instruction for metals,
consumables, coatings, and cleaners.

5. Work in a confined space only if it is well ventilated,
or while wearing an air-supplied respirator. Shielding
gases used for welding can displace air causing injury
or death. Be sure the breathing air is safe.

Gas metal- arc

Ferr ous base metal A ll 12

Carbon arc welding All 12

Carb on arc air go ugi ng

Pl a sma ar c cut t ing

Medium 300 to 400 A mp 12

Heavy Over 400 A mp 14

1-2

February 22, 2006

6. Do not weld in locations near degreasing, cleaning, or
spraying operations. The heat and rays of the arc can
react with vapors to form highly toxic and irritating
gases.

7. Do not weld on coated metals, such as galvanized,
lead, or cadmium plated steel, unless the coating is
removed from the weld area, the area is well ventilated,
and if necessary, while wearing an air-supplied
respirator. The coatings and any metals containing
these elements can give off toxic fumes if welded.

WARNING

WELDING can cause fire or explosion.

ARCMASTER 300 ACDC

WARNING

FLYING SPARKS AND HOT METAL can cause
injury.

Chipping and grinding cause flying metal. As
welds cool, they can throw off slag.

1. Wear approved face shield or safety goggles. Side
shields recommended.

2. Wear proper body protection to protect skin.

WARNING

Sparks and spatter fly off from the welding
arc. The flying sparks and hot metal, weld
spatter, hot workpiece, and hot equipment can
cause fires and burns. Accidental contact of
electrode or welding wire to metal objects can
cause sparks, overheating, or fire.

1. Protect yourself and others from flying sparks and
hot metal.

2. Do not weld where flying sparks can strike flammable
material.

3. Remove all flammables within 35 ft (10.7 m) of the
welding arc. If this is not possible, tightly cover them
with approved covers.

4. Be alert that welding sparks and hot materials from
welding can easily go through small cracks and
openings to adjacent areas.

5. Watch for fire, and keep a fire extinguisher nearby.

6. Be aware that welding on a ceiling, floor, bulkhead, or
partition can cause fire on the hidden side.

7. Do not weld on closed containers such as tanks or
drums.

8. Connect work cable to the work as close to the welding
area as practical to prevent welding current from
traveling long, possibly unknown paths and causing
electric shock and fire hazards.

9. Do not use welder to thaw frozen pipes.

CYLINDERS can explode if damaged.
Shielding gas cylinders contain gas under high

pressure. If damaged, a cylinder can explode.
Since gas cylinders are normally part of the
welding process, be sure to treat them
carefully.

1. Protect compressed gas cylinders from excessive heat,
mechanical shocks, and arcs.

2. Install and secure cylinders in an upright position by
chaining them to a stationary support or equipment
cylinder rack to prevent falling or tipping.

3. Keep cylinders away from any welding or other
electrical circuits.

4. Never allow a welding electrode to touch any cylinder.

5. Use only correct shielding gas cylinders, regulators,
hoses, and fittings designed for the specific
application; maintain them and associated parts in
good condition.

6. Turn face away from valve outlet when opening
cylinder valve.

7. Keep protective cap in place over valve except when
cylinder is in use or connected for use.

8. Read and follow instructions on compressed gas
cylinders, associated equipment, and CGA publication
P-1 listed in Safety Standards.

10.Remove stick electrode from holder or cut off welding
wire at contact tip when not in use.

February 22, 2006

1-3

ARCMASTER 300 ACDC

WARNING

Engines can be dangerous.

WARNING

ENGINE EXHAUST GASES can kill.

4. To prevent accidental starting during servicing,
disconnect negative (-) battery cable from battery.

5. Keep hands, hair, loose clothing, and tools away
from moving parts.

6. Reinstall panels or guards and close doors when
servicing is finished and before starting engine.

WARNING

Engines produce harmful exhaust gases.

1. Use equipment outside in open, well-ventilated areas.

2. If used in a closed area, vent engine exhaust outside
and away from any building air intakes.

WARNING

ENGINE FUEL can cause fire or explosion.
Engine fuel is highly flammable.

1. Stop engine before checking or adding fuel.

2. Do not add fuel while smoking or if unit is near any
sparks or open flames.

3. Allow engine to cool before fueling. If possible, check
and add fuel to cold engine before beginning job.

4. Do not overfill tank — allow room for fuel to expand.

5. Do not spill fuel. If fuel is spilled, clean up before
starting engine.

SPARKS can cause BATTERY GASES TO
EXPLODE; BATTERY ACID can burn eyes and
skin.

Batteries contain acid and generate explosive gases.

1. Always wear a face shield when working on a battery.

2. Stop engine before disconnecting or connecting
battery cables.

3. Do not allow tools to cause sparks when working on
a battery.

4. Do not use welder to charge batteries or jump start
vehicles.

5. Observe correct polarity (+ and –) on batteries.

WARNING

STEAM AND PRESSURIZED HOT COOLANT
can burn face, eyes, and skin.

WARNING

MOVING PARTS can cause injury.

Moving parts, such as fans, rotors, and belts can cut
fingers and hands and catch loose clothing.

1. Keep all doors, panels, covers, and guards closed
and securely in place.

2. Stop engine before installing or connecting unit.

3. Have only qualified people remove guards or
covers for maintenance and troubleshooting as
necessary.

1-4

The coolant in the radiator can be very hot
and under pressure.

1. Do not remove radiator cap when engine is hot. Allow
engine to cool.

2. Wear gloves and put a rag over cap area when
removing cap.

3. Allow pressure to escape before completely removing
cap.

February 22, 2006

ARCMASTER 300 ACDC

WARNING

This product, when used for welding or
cutting, produces fumes or gases which
contain chemicals know to the State of
California to cause birth defects and, in some
cases, cancer. (California Health & Safety code
Sec. 25249.5 et seq.)

NOTE

Considerations About Welding And The Effects
of Low Frequency Electric and Magnetic Fields

The following is a quotation from the General Conclusions
Section of the U.S. Congress, Office of Technology
Assessment,
Frequency Electric & Magnetic Fields - Background Paper,
OTA-BP-E-63 (Washington, DC: U.S. Government Printing
Office, May 1989): “...there is now a very large volume of
scientific findings based on experiments at the cellular
level and from studies with animals and people which
clearly establish that low frequency magnetic fields and
interact with, and produce changes in, biological systems.
While most of this work is of very high quality, the results
are complex. Current scientific understanding does not
yet allow us to interpret the evidence in a single coherent
framework. Even more frustrating, it does not yet allow
us to draw definite conclusions about questions of
possible risk or to offer clear science-based advice on
strategies to minimize or avoid potential risks.”

To reduce magnetic fields in the workplace, use the
following procedures.

1. Keep cables close together by twisting or taping
them.

Biological Effects of Power

1.02 Principal Safety Standards

Safety in Welding and Cutting, ANSI Standard Z49.1, from
American Welding Society, 550 N.W. LeJeune Rd., Miami,
FL 33126.

Safety and Health Standards, OSHA 29 CFR 1910, from
Superintendent of Documents, U.S. Government Printing
Office, Washington, D.C. 20402.

Recommended Safe Practices for the Preparation for
Welding and Cutting of Containers That Have Held
Hazardous Substances, American Welding Society
Standard AWS F4.1, from American Welding Society, 550
N.W. LeJeune Rd., Miami, FL 33126.

National Electrical Code, NFPA Standard 70, from National
Fire Protection Association, Batterymarch Park, Quincy,
MA 02269.

Safe Handling of Compressed Gases in Cylinders, CGA
Pamphlet P-1, from Compressed Gas Association, 1235
Jefferson Davis Highway, Suite 501, Arlington, VA 22202.

Code for Safety in Welding and Cutting, CSA Standard
W117.2, from Canadian Standards Association, Standards
Sales, 178 Rexdale Boulevard, Rexdale, Ontario, Canada
M9W 1R3.

Safe Practices for Occupation and Educational Eye and
Face Protection, ANSI Standard Z87.1, from American
National Standards Institute, 1430 Broadway, New York,
NY 10018.

Cutting and Welding Processes, NFPA Standard 51B, from
National Fire Protection Association, Batterymarch Park,
Quincy, MA 02269.

2. Arrange cables to one side and away from the
operator.

3. Do not coil or drape cable around the body.

4. Keep welding power source and cables as far away
from body as practical.

ABOUT PACEMAKERS:

The above procedures are among those also
normally recommended for pacemaker
wearers. Consult your doctor for complete
information.

February 22, 2006

1-5

ARCMASTER 300 ACDC

1.03 Precautions de Securite en Soudage à L’Arc

MISE EN GARDE

LE SOUDAGE A L’ARC EST DANGEREUX

PROTEGEZ-VOUS, AINSI QUE LES AUTRES, CONTRE LES BLESSURES GRAVES POSSIBLES OU LA MORT. NE LAISSEZ
PAS LES ENFANTS S’APPROCHER, NI LES PORTEURS DE STIMULATEUR CARDIAQUE (A MOINS QU’ILS N’AIENT
CONSULTE UN MEDECIN). CONSERVEZ CES INSTRUCTIONS. LISEZ LE MANUEL D’OPERATION OU LES INSTRUC­TIONS AVANT D’INSTALLER, UTILISER OU ENTRETENIR CET EQUIPEMENT.

Les produits et procédés de soudage peuvent sauser des blessures graves ou la mort, de même que des dommages
au reste du matériel et à la propriété, si l’utilisateur n’adhère pas strictement à toutes les règles de sécurité et ne prend
pas les précautions nécessaires.

En soudage et coupage, des pratiques sécuritaires se sont développées suite à l’expérience passée. Ces pratiques
doivent être apprises par étude ou entraînement avant d’utiliser l’equipement. Toute personne n’ayant pas suivi un
entraînement intensif en soudage et coupage ne devrait pas tenter de souder. Certaines pratiques concernent les
équipements raccordés aux lignes d’alimentation alors que d’autres s’adressent aux groupes électrogènes.

La norme Z49.1 de l’American National Standard, intitulée “SAFETY IN WELDING AND CUTTING” présente les pra­tiques sécuritaires à suivre. Ce document ainsi que d’autres guides que vous devriez connaître avant d’utiliser cet
équipement sont présentés à la fin de ces instructions de sécurité.

SEULES DES PERSONNES QUALIFIEES DOIVENT FAIRE
DES TRAVAUX D’INSTALLATION, DE REPARATION,
D’ENTRETIEN ET D’ESSAI.

1. Ne touchez pas à des pièces sous tension.

2. Portez des gants et des vêtements isolants, secs et
non troués.

1.04 Dangers Relatifs au Soudage à L’Arc

AVERTISSEMENT

L’ELECTROCUTION PEUT ETRE MORTELLE.

Une décharge électrique peut tuer ou brûler
gravement. L’électrode et le circuit de soudage
sont sous tension dès la mise en circuit. Le
circuit d’alimentation et les circuits internes
de l’équipement sont aussi sous tension dès
la mise en marche. En soudage automatique
ou semi-automatique avec fil, ce dernier, le
rouleau ou la bobine de fil, le logement des
galets d’entrainement et toutes les pièces
métalliques en contact avec le fil de soudage
sont sous tension. Un équipement
inadéquatement installé ou inadéquatement
mis à la terre est dangereux.

1-6

3 Isolez-vous de la pièce à souder et de la mise à la

terre au moyen de tapis isolants ou autres.

4. Déconnectez la prise d’alimentation de l’équipement
ou arrêtez le moteur avant de l’installer ou d’en faire
l’entretien. Bloquez le commutateur en circuit ouvert
ou enlevez les fusibles de l’alimentation afin d’éviter
une mise en marche accidentelle.

5. Veuillez à installer cet équipement et à le mettre à la
terre selon le manuel d’utilisation et les codes
nationaux, provinciaux et locaux applicables.

6. Arrêtez tout équipement après usage. Coupez
l’alimentation de l’équipement s’il est hors d’usage
ou inutilisé.

7. N’utilisez que des porte-électrodes bien isolés. Ne
jamais plonger les porte-électrodes dans l’eau pour
les refroidir. Ne jamais les laisser traîner par terre ou
sur les pièces à souder. Ne touchez pas aux porte­électrodes raccordés à deux sources de courant en
même temps. Ne jamais toucher quelqu’un d’autre
avec l’électrode ou le porte-électrode.

8. N’utilisez pas de câbles électriques usés,
endommagés, mal épissés ou de section trop petite.

9. N’enroulez pas de câbles électriques autour de votre
corps.

February 22, 2006

ARCMASTER 300 ACDC

10.N’utilisez qu’une bonne prise de masse pour la mise à
la terre de la pièce à souder.

11.Ne touchez pas à l’électrode lorsqu’en contact avec le
circuit de soudage (terre).

12.N’utilisez que des équipements en bon état. Réparez
ou remplacez aussitôt les pièces endommagées.

13.Dans des espaces confinés ou mouillés, n’utilisez pas
de source de courant alternatif, à moins qu’il soit muni
d’un réducteur de tension. Utilisez plutôt une source
de courant continu.

14. Portez un harnais de sécurité si vous travaillez en hau­teur.

15.Fermez solidement tous les panneaux et les capots.

AVERTISSEMENT

LE RAYONNEMENT DE L’ARC PEUT BRÛLER
LES YEUX ET LA PEAU; LE BRUIT PEUT
ENDOMMAGER L’OUIE.

L’arc de soudage produit une chaleur et des
rayons ultraviolets intenses, susceptibles de
brûler les yeux et la peau. Le bruit causé par
certains procédés peut endommager l’ouïe.

1. Portez une casque de soudeur avec filtre oculaire de
nuance appropriée (consultez la norme ANSI Z49
indiquée ci-après) pour vous protéger le visage et les
yeux lorsque vous soudez ou que vous observez
l’exécution d’une soudure.

2. Portez des lunettes de sécurité approuvées. Des écrans
latéraux sont recommandés.

3. Entourez l’aire de soudage de rideaux ou de cloisons
pour protéger les autres des coups d’arc ou de
l’éblouissement; avertissez les observateurs de ne pas
regarder l’arc.

4. Portez des vêtements en matériaux ignifuges et
durables (laine et cuir) et des chaussures de sécurité.

5. Portez un casque antibruit ou des bouchons d’oreille
approuvés lorsque le niveau de bruit est élevé.

AVERTISSEMENT

LES VAPEURS ET LES FUMEES SONT
DANGEREUSES POUR LA SANTE.

Le soudage dégage des vapeurs et des fumées
dangereuses à respirer.

SELECTION DES NUANCES DE FILTRES OCULAIRS POUR LA PROTECTION

DES YEUX EN COUPAG E ET SO UDAGE (selon AWS á 8.2-73)

Opération de coupage

ou soudage

Brassage t endre
au chalumeau
Brassage fort
au chalumeau

Oxycoupage métaux ferr eux tout es condit ions 12

moyen de 1 á 6 po. ( 25 á 150 mm) 4 ou 5

Soudage aux gaz Soudage á l'arc Plasma (PAW) tout es dimensions 12

moyen de 1/8 á 1/2 po. (3 á 12 mm) 5 ou 6 mince 12

Soudage á l'arc avec
électrode enrobees
(SMAW)

Dimension d'élect rode ou

Epiasseur de métal ou

Intensité de courant

toutes conditions 2

tout es condit ions 3 ou 4 métaux non- ferr eux toutes condit ions 11

mince moins de 1 po. ( 25 mm) 2 ou 3

épais plus de 6 po. (150 mm) 5 ou 6

mince moins de 1/ 8 po. (3 mm) 4 ou 5

épais plus de 1/2 po. (12 mm) 6 ou 8 épais 14

moins de 5/32 po. ( 4 mm) 10 Coupage á l' ar c Plasma (PA C)

5/32 á 1/ 4 po. ( 4 á 6.4 mm) 12 mince moins de 300 amperès 9

plus de 1/4 po. ( 6.4 mm) 14 moyen de 300 á 400 amperès 12

Nuance de

fi l tr e oc u l ai re

Opération de coupage

ou soudage

Soudage á l'arc sous gaz
avec fil plein (GMAW)

Soudage á l'arc sous gaz avec
élect r ode de t ungstène (GTAW)

Soudage á l'hydrogène
at omique (AHW)
Soudage á l'arc avec
élect r ode de car bone (CAW)

Gougeage A i r - Arc av ec
élect r ode de car bone

Dimension d'élect rode ou

Epiasseur de métal ou

Intensité de courant

toutes conditions 12

toutes conditions 12

toutes conditions 12

épais plus de 400 am perès 14

Nuance de

fi l tr e oc u l ai re

February 22, 2006

1-7

ARCMASTER 300 ACDC

1. Eloignez la tête des fumées pour éviter de les respirer.

2. A l’intérieur, assurez-vous que l’aire de soudage est
bien ventilée ou que les fumées et les vapeurs sont
aspirées à l’arc.

3. Si la ventilation est inadequate, portez un respirateur
à adduction d’air approuvé.

4. Lisez les fiches signalétiques et les consignes du
fabricant relatives aux métaux, aux produits
consummables, aux revêtements et aux produits
nettoyants.

5. Ne travaillez dans un espace confiné que s’il est bien
ventilé; sinon, portez un respirateur à adduction d’air.
Les gaz protecteurs de soudage peuvent déplacer
l’oxygène de l’air et ainsi causer des malaises ou la
mort. Assurez-vous que l’air est propre à la respira­tion.

6. Ne soudez pas à proximité d’opérations de
dégraissage, de nettoyage ou de pulvérisation. La
chaleur et les rayons de l’arc peuvent réagir avec des
vapeurs et former des gaz hautement toxiques et irri­tants.

7. Ne soudez des tôles galvanisées ou plaquées au plomb
ou au cadmium que si les zones à souder ont été
grattées à fond, que si l’espace est bien ventilé; si
nécessaire portez un respirateur à adduction d’air. Car
ces revêtements et tout métal qui contient ces
éléments peuvent dégager des fumées toxiques au
moment du soudage.

1. Protégez-vous, ainsi que les autres, contre les
étincelles et du métal chaud.

2. Ne soudez pas dans un endroit où des particules
volantes ou des projections peuvent atteindre des
matériaux inflammables.

3. Enlevez toutes matières inflammables dans un rayon
de 10, 7 mètres autour de l’arc, ou couvrez-les
soigneusement avec des bâches approuvées.

4. Méfiez-vous des projections brulantes de soudage
susceptibles de pénétrer dans des aires adjacentes
par de petites ouvertures ou fissures.

5. Méfiez-vous des incendies et gardez un extincteur à
portée de la main.

6. N’oubliez pas qu’une soudure réalisée sur un plafond,
un plancher, une cloison ou une paroi peut enflammer
l’autre côté.

7. Ne soudez pas un récipient fermé, tel un réservoir ou
un baril.

8. Connectez le câble de soudage le plus près possible
de la zone de soudage pour empêcher le courant de
suivre un long parcours inconnu, et prévenir ainsi les
risques d’électrocution et d’incendie.

9. Ne dégelez pas les tuyaux avec un source de courant.

10.Otez l’électrode du porte-électrode ou coupez le fil au
tube-contact lorsqu’inutilisé après le soudage.

11.Portez des vêtements protecteurs non huileux, tels
des gants en cuir, une chemise épaisse, un pantalon
revers, des bottines de sécurité et un casque.

AVERTISSEMENT

LE SOUDAGE PEUT CAUSER UN INCENDIE OU
UNE EXPLOSION

L’arc produit des étincellies et des projections.
Les particules volantes, le métal chaud, les
projections de soudure et l’équipement
surchauffé peuvent causer un incendie et des
brûlures. Le contact accidentel de l’électrode
ou du fil-électrode avec un objet métallique
peut provoquer des étincelles, un
échauffement ou un incendie.

1-8

AVERTISSEMENT

LES ETINCELLES ET LES PROJECTIONS
BRULANTES PEUVENT CAUSER DES
BLESSURES.

Le piquage et le meulage produisent des
particules métalliques volantes. En
refroidissant, la soudure peut projeter du
éclats de laitier.

1. Portez un écran facial ou des lunettes protectrices
approuvées. Des écrans latéraux sont
recommandés.

2. Portez des vêtements appropriés pour protéger
la peau.

February 22, 2006

ARCMASTER 300 ACDC

1. Utilisez l’équipement à l’extérieur dans des aires
ouvertes et bien ventilées.

AVERTISSEMENT

LES BOUTEILLES ENDOMMAGEES PEUVENT
EXPLOSER

Les bouteilles contiennent des gaz protecteurs
sous haute pression. Des bouteilles
endommagées peuvent exploser. Comme les
bouteilles font normalement partie du procédé
de soudage, traitez-les avec soin.

1. Protégez les bouteilles de gaz comprimé contre les
sources de chaleur intense, les chocs et les arcs de
soudage.

2. Enchainez verticalement les bouteilles à un support
ou à un cadre fixe pour les empêcher de tomber ou
d’être renversées.

3. Eloignez les bouteilles de tout circuit électrique ou de
tout soudage.

4. Empêchez tout contact entre une bouteille et une
électrode de soudage.

2. Si vous utilisez ces équipements dans un endroit
confiné, les fumées d’échappement doivent être
envoyées à l’extérieur, loin des prises d’air du bâtiment.

AVERTISSEMENT

LE CARBURANT PEUR CAUSER UN INCENDIE
OU UNE EXPLOSION.

Le carburant est hautement inflammable.

1. Arrêtez le moteur avant de vérifier le niveau e
carburant ou de faire le plein.

2. Ne faites pas le plein en fumant ou proche d’une source
d’étincelles ou d’une flamme nue.

3. Si c’est possible, laissez le moteur refroidir avant de
faire le plein de carburant ou d’en vérifier le niveau au
début du soudage.

4. Ne faites pas le plein de carburant à ras bord: prévoyez
de l’espace pour son expansion.

5. N’utilisez que des bouteilles de gaz protecteur, des
détendeurs, des boyauxs et des raccords conçus pour
chaque application spécifique; ces équipements et les
pièces connexes doivent être maintenus en bon état.

6. Ne placez pas le visage face à l’ouverture du robinet
de la bouteille lors de son ouverture.

7. Laissez en place le chapeau de bouteille sauf si en
utilisation ou lorsque raccordé pour utilisation.

8. Lisez et respectez les consignes relatives aux bouteilles
de gaz comprimé et aux équipements connexes, ainsi
que la publication P-1 de la CGA, identifiée dans la
liste de documents ci-dessous.

AVERTISSEMENT

LES MOTEURS PEUVENT ETRE DANGEREUX
LES GAZ D’ECHAPPEMENT DES MOTEURS

PEUVENT ETRE MORTELS.

5. Faites attention de ne pas renverser de carburant.
Nettoyez tout carburant renversé avant de faire
démarrer le moteur.

AVERTISSEMENT

DES PIECES EN MOUVEMENT PEUVENT
CAUSER DES BLESSURES.

Des pièces en mouvement, tels des
ventilateurs, des rotors et des courroies
peuvent couper doigts et mains, ou accrocher
des vêtements amples.

1. Assurez-vous que les portes, les panneaux, les capots
et les protecteurs soient bien fermés.

2. Avant d’installer ou de connecter un système, arrêtez
le moteur.

3. Seules des personnes qualifiées doivent démonter des
protecteurs ou des capots pour faire l’entretien ou le
dépannage nécessaire.

Les moteurs produisent des gaz d’échappement nocifs.

February 22, 2006

1-9

ARCMASTER 300 ACDC

4. Pour empêcher un démarrage accidentel pendant
l’entretien, débranchez le câble d’accumulateur à la
borne négative.

5. N’approchez pas les mains ou les cheveux de pièces
en mouvement; elles peuvent aussi accrocher des
vêtements amples et des outils.

6. Réinstallez les capots ou les protecteurs et fermez les
portes après des travaux d’entretien et avant de faire
démarrer le moteur.

AVERTISSEMENT

DES ETINCELLES PEUVENT FAIRE EXPLOSER
UN ACCUMULATEUR; L’ELECTROLYTE D’UN
ACCUMU-LATEUR PEUT BRULER LA PEAU ET
LES YEUX.

Les accumulateurs contiennent de l’électrolyte
acide et dégagent des vapeurs explosives.

1. Portez toujours un écran facial en travaillant sur un
accumu-lateur.

2. Arrêtez le moteur avant de connecter ou de
déconnecter des câbles d’accumulateur.

3. N’utilisez que des outils anti-étincelles pour travailler
sur un accumulateur.

4. N’utilisez pas une source de courant de soudage pour
charger un accumulateur ou survolter
momentanément un véhicule.

5. Utilisez la polarité correcte (+ et –) de l’accumulateur.

AVERTISSEMENT

LA VAPEUR ET LE LIQUIDE DE
REFROIDISSEMENT BRULANT SOUS
PRESSION PEUVENT BRULER LA PEAU ET
LES YEUX.

Le liquide de refroidissement d’un radiateur
peut être brûlant et sous pression.

1. N’ôtez pas le bouchon de radiateur tant que le moteur
n’est pas refroidi.

2. Mettez des gants et posez un torchon sur le bouchon
pour l’ôter.

3. Laissez la pression s’échapper avant d’ôter
complètement le bouchon.

1.05 Principales Normes de Securite

Safety in Welding and Cutting, norme ANSI Z49.1, American
Welding Society, 550 N.W. LeJeune Rd., Miami, FL 33128.

Safety and Health Standards, OSHA 29 CFR 1910, Superintendent
of Documents, U.S. Government Printing Office, Washington, D.C.

20402.
Recommended Safe Practices for the Preparation for Welding and

Cutting of Containers That Have Held Hazardous Substances,
norme AWS F4.1, American Welding Society, 550 N.W. LeJeune
Rd., Miami, FL 33128.

National Electrical Code, norme 70 NFPA, National Fire Protection
Association, Batterymarch Park, Quincy, MA 02269.

Safe Handling of Compressed Gases in Cylinders, document P-1,
Compressed Gas Association, 1235 Jefferson Davis Highway , Suite
501, Arlington, VA 22202.

Code for Safety in Welding and Cutting, norme CSA W117.2
Association canadienne de normalisation, Standards Sales, 276
Rexdale Boulevard, Rexdale, Ontario, Canada M9W 1R3.

Safe Practices for Occupation and Educational Eye and Face
Protection, norme ANSI Z87.1, American National Standards
Institute, 1430 Broadway, New York, NY 10018.

Cutting and Welding Processes, norme 51B NFPA, National Fire
Protection Association, Batterymarch Park, Quincy, MA 02269.

1-10

February 22, 2006

ARCMASTER 300 ACDC

!

SECTION 2:

INTRODUCTION

2.01 How To Use This Manual

This Owner’s Manual applies to just specification or part
numbers listed on page i.

To ensure safe operation, read the entire manual, including
the chapter on safety instructions and warnings.

Throughout this manual, the words WARNING,
CAUTION, and NOTE may appear. Pay particular attention
to the information provided under these headings. These
special annotations are easily recognized as
follows:

WARNING

A WARNING gives information regarding
possible personal injury.

2.02 Equipment Identification

The unit’s identification number (specification or part
number), model, and serial number usually appear on a
nameplate attached to the control panel. In some cases,
the nameplate may be attached to the rear panel.
Equipment which does not have a control panel such as
gun and cable assemblies is identified only by the
specification or part number printed on the shipping
container. Record these numbers on the bottom of page
i for future reference.

2.03 Receipt Of Equipment

When you receive the equipment, check it against the
invoice to make sure it is complete and inspect the
equipment for possible damage due to shipping. If there
is any damage, notify the carrier immediately to file a
claim. Furnish complete information concerning damage
claims or shipping errors to the location in your area
listed in the inside back cover of this manual.

Include all equipment identification numbers as described
above along with a full description of the parts in error.

CAUTION

A CAUTION refers to possible equipment
damage.

NOTE

A NOTE offers helpful information concerning
certain operating procedures.

Additional copies of this manual may be purchased by
contacting Thermal Arc at the address and phone number
in your area listed in the inside back cover of this manual.
Include the manual number and equipment identification
numbers.

Electronic copies of this manual can also be downloaded
at no charge in Acrobat PDF format by going to the
Thermal Arc web site listed below and clicking on the
Literature Library link:

http://www.thermalarc.com

Move the equipment to the installation site before un­crating the unit. Use care to avoid damaging the
equipment when using bars, hammers, etc., to un-crate
the unit.

February 22, 2006

2-1

ARCMASTER 300 ACDC

2.04 Symbol Chart

Note that only some of these symbols will appear on your model.

On

Off

Dangerous Voltage

Increase/Decrease

Circuit Breaker

AC Auxiliary Power

Fuse

Amperage

Voltage

X

%

Single Phase

Three Phase

Three Phase Static
Frequency Converter­Transformer-Rectifier

Remote

Duty Cycle

Percentage

Panel/Local

Shielded Metal
Arc Welding (SMAW)

Gas Metal Arc
Welding (GMAW)

Wire Feed Function

Wire Feed Towards
Workpiece With

t1

Output Voltage Off.

Welding Gun

Purging Of Gas

Continuous Weld
Mode

Spot Weld Mode

Spot Time

t

Preflow Time

Postflow Time

t2

Hertz (cycles/sec)

Frequency

Negative

Positive

Direct Current (DC)

Protective Earth
(Ground)

Line

Line Connection

Auxiliary Power

Gas Tungsten Arc
Welding (GTAW)

Air Carbon Arc
Cutting (CAC-A)

Constant Current

Constant Voltage
Or Constant Potential

High Temperature

Fault Indication

Arc Force

Touch Start (GTAW)

Variable Inductance

2 Step Trigger
Operation

Press to initiate wirefeed and
welding, release to stop.

4 Step Trigger
Operation

Press and hold for preflow, release
to start arc. Press to stop arc, and
hold for preflow.

Burnback Time

t

IPM

MPM

Inches Per Minute

Meters Per Minute

115V 15A

2-2

Receptacle Rating­Auxiliary Power

Voltage Input

V

Art # A-04130

February 22, 2006

2.05 Description

ARCMASTER 300 ACDC

The Thermal ArcTM Model 300ACDC is a self contained
single/three-phase AC/DC arc welding power source with
Constant Current (CC) output characteristics. This unit is
equipped with a Digital Volt/Amperage Meter, gas control
valve, built in Sloper and Pulser, lift arc starter, and high­frequency arc starter for use with Gas Tungsten Arc
Welding (GTAW), Gas Tungsten Arc Welding-Pulsed
(GTAW-P) Gas Tungsten Arc Welding- Sloped (GTAW-S),
and Shielded Metal Arc Welding (SMAW) processes. The
power source is totally enclosed in an impact resistant,
flame retardant and non-conductive plastic case.

NOTE

Volt-Ampere curves show the maximum
Voltage and Amperage output capabilities of
the welding power source. Curves of other
settings will fall between the curves shown.

(V)

OCV

(V)

OCV

10V

Art # A-04980

300A )A(A5

STICK Process

300A )A(A52

LIFT TIG Process

(V)

OCV

5A

300A (A)

HF TIG Process

Figure 2-1: Model 300 ACDC Volt-Ampere curve

February 22, 2006

2-3

ARCMASTER 300 ACDC

2.06 Functional Block Diagrams

Figure 2-2 illustrates the functional block diagram of the 300 ACDC-power supply.

Input

Powe r

Main

Circuit

Switch

Filter

Input

Diode

DC Power

Drive

Circuit

Capacitor

DC Power
Primary

Voltage

Sensor

To each control circuit

+/-15VDC +18VDC

+24VDC +5VDC

Trouble
Sensing

Torch Control

Connection

(CON1)

Thermal
Detector

Circuit

To each control circuit

IGBT

Inverter

Drive

Circuit

Adjustment

+/-12VDC +15VDC

Main

Transformer

(PCB14)

Th ermal
Sensor

Circuit

Primary
Current

Sensor

Sequence

Current

circuit

Mode select Switches

Panel Circuit Board

Control

Reference

Adjustment &

Output

Diodes

Thermal
Detector

HF-UNIT

Control

Circuit

Stick Mode

VRD

Sensing

Circuit

Figure 2-2: 300 ACDC Model Functional Block Diagram

Output

Inductor

Fan Control

Gas Control

Lift Tig Mode
Output Short

Sensing

Circuit

Circuit

Circuit

Art # A-04981

Secondary

IGBT

Inverter

Coupling

Frequency

Fan

Solenoid

Coil

High

Unit

Hall Current

Transformer

(HCT1)

2.07 Transporting Methods

These units are equipped with a handle for carrying
purposes.

WARNING

ELECTRIC SHOCK can kill. DO NOT TOUCH
live electrical parts. Disconnect input power
conductors from de-energized supply line
before moving the welding power source.

WARNING

FALLING EQUIPMENT can cause serious
personal injury and equipment damage.

• Lift unit with handle on top of case.

• Use handcart or similar device of adequate capacity.

• If using a fork lift vehicle, place and secure unit on a
proper skid before transporting.

2-4

February 22, 2006

ARCMASTER 300 ACDC

SECTION 3:

INSTALLATION

3.01 Environment

The ArcMaster 300 ACDC is designed for use in adverse
environments.

Examples of environments with increased adverse
conditions are:

a. In locations in which freedom of movement is
restricted, so that the operator is forced to perform the
work in a cramped (kneeling, sitting or lying) position
with physical contact with conductive parts;

b. In locations which are fully or partially limited by
conductive elements, and in which there is a high risk of
unavoidable or accidental contact by the operator;

c. In wet or damp hot locations where humidity or
perspiration considerably reduces the skin resistance of
the human body and the insulation properties of
accessories.

3.03 Electrical Input Connections

WARNING

ELECTRIC SHOCK can kill; SIGNIFICANT DC
VOLTAGE is present after removal of input
power.

DO NOT TOUCH live electrical parts.
SHUT DOWN welding power source, disconnect input

power employing lockout/tagging procedures. Lockout/
tagging procedures consist of padlocking line disconnect
switch in open position, removing fuses from fuse box,
or shutting off and red-tagging circuit breaker or other
disconnecting device.

Environments with adverse conditions do not include
places where electrically conductive parts, in the near
vicinity of the operator, which can cause increased hazard,
have been insulated.

3.02 Location

Be sure to locate the welder according to the following
guidelines:

·

In areas, free from moisture and dust.

·

Ambient temperature between 0 degrees C to 40
degrees C.

·

In areas, free from oil, steam and corrosive gases.

·

In areas, not subjected to abnormal vibration or
shock.

·

In areas, not exposed to direct sunlight or rain.

·

Place at a distance of 12" (304.79mm) or more from
walls or similar boundaries that could restrict natural
airflow for cooling.

WARNING

Thermal Arc advises that this equipment be
electrically connected by a qualified electrician.

Februrary 22, 2006

3-1

ARCMASTER 300 ACDC

3.04 Electrical Input Requirements

Operate the welding power source from a single or three­phase 50/60 Hz, AC power supply. The input voltage must
match one of the electrical input voltages shown on the
input data label on the unit nameplate. Contact the local
electric utility for information about the type of electrical
service available, how proper connections should be
made, and any inspection required.

The line disconnect switch provides a safe and convenient
means to completely remove all electrical power from
the welding power supply whenever necessary to inspect
or service the unit.

NOTE

These units are equipped with a three­conductor with earth power cable that is
connected at the welding power source end
for single and three phase electrical input
power.

Do not connect an input (WHITE or BLACK or RED)
conductor to the ground terminal.

Do not connect the ground (GREEN) conductor to an input
line terminal.

Refer to Figure 3-1 and:

1. Connect end of ground (GREEN) conductor to a
suitable ground. Use a grounding method that complies
with all applicable electrical codes.

2. Connect ends of line 1 (BLACK) and line 2 (WHITE)
and line 3 (RED) input conductors to a de-energized line
disconnect switch.

3. Use Table 3-1 and Table 3-2 as a guide to select line
fuses for the disconnect switch.

Input Voltage Fuse Size

208V 100 Amps
230V 100 Amps
480V 50 Amps

Table 3-1: Electrical Input Connections

NOTE

Fuse size is based on not more than 200 percent of the rated input amperage of the welding power source
(Based on Article 630, National Electrical Code).

Welding Power Supply

Ground Conductor

Ground Terminal

Line Disconnect Switch

Art # A-04982

3-2

Primary Power Cable

Figure 3-1: Electrical Input Connections

Line Fuse

February 22, 2006

ARCMASTER 300 ACDC

3.05 Input Power

Each unit incorporates an INRUSH circuit and input voltage
sensing circuit. When the MAIN CIRCUIT SWITCH is
turned on, the inrush circuit provides a pre-charging of
the input capacitors. At this point, the Bus Voltages are
checked and the welder is enabled after the input
capacitors have charged to full operating voltage (after
approximately 5 seconds).

NOTE

Note the available input power. Damage to the
welder could occur if 575VAC or higher is
applied.

The following 208-230/460V Primary Current
recommendations are required to obtain the maximum
welding current and duty cycle from this welding
equipment:

Model Lead Size Current

ARC

MASTER

300ACDC

Primary Minimum Current & Duty

Supply Primary Cycle

(Factory Circuit Size

Fitted) (Vin/Amps)

208/31
230/28
460/14

3φ

208/45

1φ

230/41
460/21
208/67
230/60
208/97
230/87

8/4 AWG

minimum

TIG STICK

300 @
25%

--

--

--

300 @
25%

--

--

300 @
25%

300 @
25%

--

--

--

--

--

3.06 High Frequency Introduction

The importance of correct installation of high frequency
welding equipment cannot be over-emphasized.
Interference due to high frequency initiated or stabilized
arc is almost invariably traced to improper installation.
The following information is intended as a guide for
personnel installing high frequency welding machines.

WARNING: EXPLOSIVES

The high frequency section of this machine
has an output similar to a radio transmitter.
The machine should NOT be used in the
vicinity of blasting operations due to the
danger of premature firing.

WARNING: COMPUTERS

It is also possible that operation close to
computer installations may cause computer
malfunction.

Table 3-2 208/230V Primary Current Circuit sizes to

achieve maximum current

Februrary 22, 2006

3-3

ARCMASTER 300 ACDC

3.07 High Frequency Interference

Interference may be transmitted by a high frequency
initiated or stabilized arc welding machine in the following
ways:

1. Direct Radiation: Radiation from the machine can
occur if the case is metal and is not properly grounded.
It can occur through apertures such as open access
panels. The shielding of the high frequency unit in
the Power Source will prevent direct radiation if the
equipment is properly grounded.

2. Transmission via the Supply Lead: Without adequate
shielding and filtering, high frequency energy may be
fed to the wiring within the installation (mains) by
direct coupling. The energy is then transmitted by
both radiation and conduction. Adequate shielding
and filtering is provided in the Power Source.

3. Radiation from Welding Leads: Radiated interference
from welding leads, although pronounced in the
vicinity of the leads, diminishes rapidly with distance.
Keeping leads as short as possible will minimize this
type of interference. Looping and suspending of leads
should be avoided where possible.

4. Re-radiation from Unearthed Metallic Objects:

A major factor contributing to interference is re­radiation from unearthed metallic objects close to the
welding leads. Effective grounding of such objects
will prevent re-radiation in most cases.

3.08 Duty Cycle

The duty cycle of a welding power source is the percentage
of a ten (10) minute period that it can be operated at a
given output without causing overheating and damage to
the unit. If the welding amperes decrease, the duty cycle
increases. If the welding amperes are increased beyond
the rated output, the duty cycle will decrease.

WARNING

Exceeding the duty cycle ratings will cause the
thermal overload protection circuit to become
energized and shut down the output until the
unit has cooled to normal operating
temperature.

CAUTION

Continually exceeding the duty cycle ratings
can cause damage to the welding power
source and will void the manufactures
warranty.

NOTE

Due to variations that can occur in
manufactured products, claimed performance,
voltages, ratings, all capacities,
measurements, dimensions and weights
quoted are approximate only. Achievable
capacities and ratings in use and operation will
depend upon correct installation, use,
applications, maintenance and service.

3-4

February 22, 2006

3.09 Specifications

Parameter 300ACDC
Rated Output

Amperes 300
Volts 22
Duty Cycle 25%
Duty Cycle

TIG 300A / 22V @ 25% 190A / 17V @

STICK 300A / 32V @ 25%

Output
Current
Range

TIG 5 - 300 (DC) 5 - 300 (AC) @

STICK 5 - 300 (DC)

Open Circuit Voltage 65V
Dimensions
Width 8.3” (210mm)
Height 16.5” (420mm)

Length 17.7” (450mm)

Weight 52.8 lb. 24 kg
Output @ Rated Load

Rated Input Voltage Three-phase Single-phase
Output Amperes 300A 300A
Output Volts 32V 32V
Duty Cycle 25% 25%
KVA 18.0 20.0
KW 12.0 12.0
Output @ No Load

Rated Input Voltage Three-phase Single-phase
KVA 0.5 0.5
KW 0.13 0.13

Input Volts Three Phase
208V 230V 460V

60% 150A / 16V @ 100%

190A / 27V @ 60%
150A / 26V @ 100%

60Hz, 50% Cleaning

5 - 300 (AC) @ 60Hz,
50% Cleaning

Amperage
Draw @ Rated
Load 45 41 21

ARCMASTER 300 ACDC

Thermal Arc continuously strives to produce the best
product possible and therefore reserves the right to
change, improve or revise the specifications or design of
this or any product without prior notice. Such updates or
changes do not entitle the buyer of equipment previously
sold or shipped to the corresponding changes, updates,
improvements or replacement of such items.

The values specified in this table are optimal values, your
values may differ. Individual equipment may differ from
the above specifications due to in part, but not exclusively,
to any one or more of the following; variations or changes
in manufactured components, installation location and
conditions and local power grid supply conditions.

Input Volts Single
Phase 208V 230V

Table 3-3: Parameter Specifications

Februrary 22, 2006

No Load Amps

1.4 1.3 0.7
Amperage
Draw @ Rated
Load 97 87

No Load Amps

2.5 2.2

3-5

ARCMASTER 300 ACDC

3-6

February 22, 2006

OPERATOR CONTROLS

4.01 ArcMaster 300 ACDC Controls

1

5

3

2

435

4

ARCMASTER 300 ACDC

SECTION 4:

1. Control Knob: This control sets the selected weld

parameter, rotating it clockwise increases the parameter
that is indicated on the digital meter. Pushing the knob
inward displays the actual welding voltage.

2 . Remote Control Socket: The 14 pin Remote Control

Socket is used to connect remote current control
devices to the welding Power Source. To make
connections, align keyway, insert plug, and rotate
threaded collar fully clockwise.

210

Art # A-04983

ABCDEFGHI J KL MN

5k ohms

Art # A-07653

E

AJ

BK I

CL NH

DMG

FE

Front view of 14
Socket Receptacle

Figure 4-2: 14-Socket Receptacle

450

Socket

Pin

A

Torch Switch Input (24V) to (connect
pins A & B to turn on welding current).

Function

Torch Switch Input (0V) to energize weld

B current (connect pins A & B to turn on

6

8

7

9

welding current).
5k ohm (maximum) connection to 5k

C

ohm remote control potentiometer.
Zero ohm (minimum) connection to 5k

D

ohm remote control potentiometer.
Wiper arm connection to 5k ohm remote

E

control potentiometer.

G Mains Earth.

Figure 4-1: ArcMaster 300 ACDC Power Source

February 22, 2006

F,H,I,J,

K,L

M

N

Not Used.
OK to move current detect signal for

robotics applications.
OK to move current detect signal for
robotics applications.

Table 4-1: Socket Pin Functions

4-1

ARCMASTER 300 ACDC

3. Positive Terminal: Welding current flows from the
Power Source via heavy duty Dinse type terminal. It
is essential, however, that the male plug is inserted
and turned securely to achieve a sound electrical
connection.

4. Negative Terminal: Welding current flows from the
Power Source via heavy duty Dinse type terminal. It
is essential, however, that the male plug is inserted
and turned securely to achieve a sound electrical
connection.

CAUTION

Loose welding terminal connections can cause
overheating and result in the male plug being
fused in the bayonet terminal.

5. Gas Outlet: The Gas Outlet is a 5/8 18 UNF female gas
fitting.

6. ON/OFF Switch: This switch connects the Primary
supply voltage to the inverter when in the ON position.
This enables the Power Supply.

WARNING

When the welder is connected to the Primary
supply voltage, the internal electrical
components maybe at 720V potential with
respect to earth.

7. Input Cable: The input cable connects the Primary
supply voltage to the equipment.

8. SMART Logic Switch: Manual slide switch mounted
on the back panel selects for proper input voltage. If
this slide is not set to the position that matches the
input voltage from the electrical source the Smart
Logic circuit will inhibit welding power source output.
The digital meter will show primary input error code.

8 . Gas Inlet: The Gas Inlet is a 5/8 18 UNF female gas

fitting.

4-2

February 22, 2006

4.02 Weld Process Selection for ArcMaster 300 ACDC

Weld Mode

ARCMASTER 300 ACDC

Weld Process

Selection

STD

SLOPE

REPEAT

SPOT

PULSE ON/OFF

STICK

Yes Yes Yes

No Yes Yes

No Yes Yes

No Yes No

No Yes Yes Pulse operation in TIG Modes

Yes Yes Yes Selects AC or DC weld current

HF

TIG

LIFT

TIG

Description

2T operation in TIG Modes using remote
devices to control contactor & current

4T operation in TIG Modes with crater fill
using a remote contactor device to control
sequence.

4T operation in TIG Modes with repeat
operation and crater fill using a remote
contactor device.

2T operation spot welding in HF TIG using
a remote contactor device.

Contactor ON/OFF

Operation

PANEL/REMOTE

February 22, 2006

Table 4-2: Weld Process selection versus Weld Mode for ArcMaster 300 ACDC

Yes No Yes Contactor operation in Stick Mode

Yes Yes Yes

Selects mode of operation Panel or
Remote

4-3

ARCMASTER 300 ACDC

4.03 Weld Parameter Descriptions for ArcMaster 300 ACDC

Art # A-07654

Figure 4-3: ArcMaster 300 ACDC Front Panel

Parameter Description

This parameter operates in TIG modes only and is used to provide gas
to the weld zone prior to striking the arc, once the torch trigger switch
has been pressed. This control is used to dramatically reduce weld

PRE-FLOW

HOT START

INITIAL CUR.

UP SLOPE

porosity at the start of a weld.

This parameter operates in all weld modes except Lift TIG mode and is
used to heat up the weld zone in TIG modes or improve the start
characteristics for stick electrodes. e.g. low hydrogen electrodes. It sets
the peak start current on top of the

HOT START

e.g.

HOT START

This parameter operates in
is used to set the start current for TIG. The Start Current remains on until
the torch trigger switch is released after it has been depressed.

This parameter operates in TIG modes only and is used to set the time
for the weld current to ramp up, after the torch trigger switch has been
pressed then released, from INITIAL CUR to PEAK or BASE current

current = 130 amps when

= 30 amps

SLOPE

BASE (WELD)

or

BASE (WELD)

REPEAT

current.

= 100 amps &

(4T) TIG modes only and

4-4

Table 4-3: ArcMaster 300 ACDC Front Panel Parameter Description

February 22, 2006

ARCMASTER 300 ACDC

PEAK CUR.

WELD

BASE (BackgroundCurrent)

SPOT TIME

PULSE WIDTH

PULSE FREQ.

AC FREQUENCY

WAVE BALANCE

This parameter sets the PEAK weld current when in
This parameter sets the TIG WELD current in

SPOT

modes when

PULSE

is off. This parameter also sets the STICK

PULSE

mode

STD, SLOPE, REPEAT

and

weld current.
This parameter sets the Background current when in Pulse TIG mode.
This parameter sets the duration of the
This parameter sets the percentage on time of the
for PEAK weld current when the
This parameter sets the

PULSE FREQUENCY

PULSE

SPOT TIME

is on.

when the

in

HF TIG

mode only

PULSE FREQUENCY

PULSE

is on.
This parameter operates in AC mode only and is used to set the
frequency for the AC weld current.
This parameter is used for aluminum AC TIG mode and is used to set the
penetration to cleaning action ratio for the AC weld current. Generally

WAVE BALANCE
BALANCE

control changes the ratio of penetration to cleaning action of

is set to 50% for AC

STICK

welding. The

WAVE

the AC TIG welding arc. Maximum weld penetration is achieved when

WAVE BALANCE

the
oxidised aluminium or magnesium alloys is achieved when the

BALANCE

WAVE BALA NCE=5 0%

control is set to 65%.

control is set to 10%. Maximum cleaning of heavily

WAVE

WAVE BALANCE=10%

10%50% 65%

(+ )(+ ) (+ )

WAVE BA L ANCE=65%

DOWN SLOPE

CRATER CUR.

POST-FLOW

SAUVEGA RDER CHA RG ER

(-)(-) (-)

Balanced with 50% penetration

and 50% cleaning

Maximum Penetrati on and

90%50% 35%

re du c e d cle aning

Maximum Cleaning and

reduced penetration

This parameter operates in TIG modes only and is used to set the time
for the weld current to ramp down, after the torch trigger switch has
been pressed, to

CRATER CUR.

This control is used to eliminate the
crater that can form at the completion of a weld.
This parameter operates in

SLOPE

or

REPEAT

(4T) TIG modes only and
is used to set the finish current for TIG. The CRATER Current remains on
until the torch trigger switch is released after it has been depressed.

This parameter operates in TIG modes only and is used to adjust the
post gas flow time once the arc has extinguished. This control is used to
dramatically reduce oxidation of the tungsten electrode.

The SAVE/LOAD buttons are used to save and retrieve a total number of
5 programs into the 300ACDC memory.

February 22, 2006

Table 4-3 (continued): ArcMaster 300 ACDC Front Panel Parameter Description

4-5

ARCMASTER 300 ACDC

4.04 Weld Parameters for ArcMaster 300 ACDC

Weld Mode

Weld Parameter

PRE-FLOW 0.0 to 1.0 sec 0 sec 0.1 sec No Yes Yes
HOT START 0 to 70A 20A 1A Yes Yes No
INITIAL CUR. 5 to 300A 30A 1A No Yes Yes
UP SLOPE 0 to 15 sec 1 sec 0.1 sec No Yes Yes
PULSE PEAK CUR. 5 to 300A 120A 1A No Yes Yes
PULSE BASE CUR. 5 to 300A 80A 1A No Yes Yes
WELD CUR. 5 to 300A 80A 1A Yes Yes Yes
SPOT TIME 0.5 to 5.0 sec 2 sec 0.1 sec No Yes Yes
PULSE WIDTH 15 to 80% 50% 1% No Yes Yes

PULSE FREQ. 0.5 to 500Hz 100.0Hz

AC FREQUENCY 15 to 150Hz 60Hz 1Hz Yes Yes Yes
WAVE BALANCE 10 to 65% 50% 1% Yes Yes Yes
DOWN SLOPE 0 to 25 sec 3 sec 0.1 sec No Yes Yes
CRATER CUR. 5 to 300A 30A 1A No Yes Yes
POST-FLOW 0.0 to 60 sec 10 sec 0.1 sec No Yes Yes

Parameter

Range

Factory

Setting

Incremental

Unit

See Table

Table 4-5

STICK

No Yes Yes

HF

TIG

LIFT

TIG

Table 4-4: Weld Parameters for ArcMaster 300 ACDC

PULSE FREQ.

Range Incremental Unit

0.5 to 20Hz 0.1Hz

20 to 100Hz 1Hz

100 to 500Hz 5Hz

Table 4-5: PULSE FREQ. Range and Incremental Units

4-6

February 22, 2006

ARCMASTER 300 ACDC

4.05 Power Source Features

Feature Description

New Digital Control Almost all welding parameters are adjustable
Touch Panel Switches Touch switches eliminate mechanical damage
Front Control Cover Protects front panel controls
Digital Meter

Intelligent Fan Control

ON/OFF Switch Primary voltage Supply ON/OFF switch located on rear panel
Voltage Reduction

Device (VRD)

Control Knob

Self Diagnosis Using
Error Codes

Displays selected weld parameter value
Displays weld current when welding
Displays weld current for 20 seconds after weld has been completed
A selected weld parameter value can be adjusted at any time even while welding
The intelligent cooling system is designed to reduce dust and foreign material
build-up, while providing optimum cooling.
Fan speed reduces approximately 30 seconds after machine is turned on
Fan speed increases when internal components reach operating temperature

Reduces the OCV when the power supply is not in use. Eliminates the need for
add-on voltage reducers and has no effect on arc starting.
VRD fully complies to IEC 60974-1
When Stick mode is selected the green VRD light is ON when not welding and
red when welding.

When in TIG modes VRD is off.
For the selected weld parameter, rotating the knob clockwise increases the
parameter
Rotating the knob counter-clockwise decreases the parameter
A selected weld parameter value can be adjusted at any time even while welding

Pushing the knob in displays actual arc voltage.
An error code is displayed on the

Digital Meter

when a problem occurs with
Primary supply voltage or internal component problems. Refer to
troubleshooting guide.

Save/Load Function A total number of 5 programs can be saved into the 300ACDC memory.

SAVE the Current Weld Parameters into Memory.
Press the SAVE button.
Select a memory location by rotating the control knob, 1 to 5 is displayed on
the meter.

After selecting the desired mem-ory location (ie 1 to 5), press the right scroll
button and the machine will give a beep to confirm the weld parameters from
the control panel are saved.
LOAD (retrieve) a Program to Control Panel.
Press the LOAD button.
Select a memory location by rotating the control knob, 1 to 5 is displayed on
the meter.

After selecting the desired memory location (ie 1 to 5), press the right scroll
button and the machine will give a beep to confirm the weld parameters are
loaded onto the control panel.

February 22, 2006

Table 4-6:Power Source Features

4-7

ARCMASTER 300 ACDC

4-8

February 22, 2006

SECTION 5:

SET-UP FOR SMAW (STICK) AND GTAW (TIG)

Conventional operating procedures apply when using the
Welding Power Source, i.e. connect work lead directly to
work piece and electrode lead is used to hold electrode.
Wide safety margins provided by the coil design ensure
that the Welding Power Source will withstand short-term
overload without adverse effects. The welding current
range values should be used as a guide only. Current
delivered to the arc is dependent on the welding arc
voltage, and as welding arc voltage varies between
different classes of electrodes, welding current at any one
setting would vary according to the type of electrode in
use. The operator should use the welding current range
values as a guide, then finally adjust the current setting
to suit the application.

WARNING

ARCMASTER 300 ACDC

Art #A-07655

Before connecting the work clamp to the work
and inserting the electrode in the electrode
holder make sure the Primary power supply
is switched off.

CAUTION

Remove any packaging material prior to use.
Do not block the air vents at the front or rear
or sides of the Welding Power Source.

CAUTION

DO NOT change the Weld Mode or Weld
Process Mode until after POST-FLOW time has
finished.

Figure 5-1: 300 ACDC AC/DC Set-up

February 22, 2006

5-1

ARCMASTER 300 ACDC

5-2

February 22, 2006

ARCMASTER 300 ACDC

SECTION 6:

SEQUENCE OF OPERATION

NOTE:

Scroll Buttons are used to select the parameters to be set. The LED’s show which function is being
adjusted on the weld sequence graph. Refer to the Symbols Table located in the front of the manual for
Symbol descriptions.

Art # A-07654

February 22, 2006

Figure 6-1a: 300 ACDC Front Panel

6-1

ARCMASTER 300 ACDC

1

9

Art # A-07656

10

2

8

3

4

6

5

7

Figure 6-1b: 300 ACDC Front Panel

1. Pulse Function:

Pressing this button enables the TIG current pulse
functions.

2. Remote Current function:

Pressing this button enables remote current func­tions.

3. TIG Mode Functions:

Pressing this button scrolls through the output TIG
function modes (Standard, Slope, Slope w/repeat,
Spot).

4. Digital LED Display:

Welding amperage and parameter values are
displayed in this window. Internal warnings such as
over temperature, low or high input voltage applied
are signaled to the operator by a warning sound and
error message on the screen.

5. Save/Load Buttons:

By using the Save & Load buttons the operator can
easily save up to 5 welding parameter programs.

6. Control Knob: Allows the operator to adjust the out­put amperage within the entire range of the power
source and sets each parameter value.

7. Process Button:

This button selects between STICK, HF TIG and Lift
TIG mode.

8. Scroll Buttons:

Used to select the parameters to be set. The LED's
show which function is being adjusted on the
Sequence Graph.

9. AC/DC Button:

Selects between AC or DC welding output.

10.Contactor Function:

Pressing this button enables Contactor functions.

6-2

February 22, 2006

ARCMASTER 300 ACDC

6.01 Stick Welding

· Connect work lead to negative terminal

· Connect electrode lead to positive terminal

· Switch machine on

· Set

AC

or DC weld current. If AC is selected then set

AC FREQ

· Connect remote control device if required.

Use the Scroll Buttons to move to the parameter to be
set. The LED will show which function is being adjusted
on the weld sequence graph. Use the control knob to
adjust each parameter.

· Set

· Set

Commence welding

to 60Hz &

HOT START
WELD

current

WAVE BALANCE

to 50%.

6.02 AC or DC HF TIG Welding

· Connect work lead to positive terminal

· Connect TIG torch to negative terminal

· Switch machine on

· Set

AC

or DC weld current. If AC is selected then set

AC FREQ

· Connect remote control device. . See section 4.01,

2. Remote Control Socket, for complete details of
the remote device.

Use the Scroll Buttons to move to the parameter to be
set. The LED will show which function is being adjusted
on the weld sequence graph. Use the control knob to
adjust each parameter.

· Set

· Set

· Set

· Set

&

WAVE BALANCE

PRE-FLOW
HOT START
POST-FLOW
WELD

current

time

current

time

· Set

POST-FLOW

Slope Mode Parameters if required

· Set

INITIAL CUR

· Set

UP SLOPE

· Set (WELD)

· Set

BASE

current

· Set

DOWN SLOPE

· Set

CRATER CUR

Pulse Mode parameters if required

· Set

PULSE WIDTH

·

Set PEAK CURRENT

· Set

PULSE FREQ

Commence welding

time

current

time

PEAK CUR

time

current

% for

current

PEAK CURRENT

February 22, 2006

6-3

ARCMASTER 300 ACDC

6.03 Slope Mode Sequence

Switch
Closed

Switch
Open

Switch
Closed

Art # A-04989

Switch
Open

Initial

Up

Slope

Weld Current

Current

Preflow

Figure 6-2: Slope Mode Sequence

1. To start the Slope Sequence, close remote switch
contacts. Once the welding arc is established the
Power Source will maintain the initial current setting
as long as the remote switch contacts are closed.

a. In the HF TIG mode, after Preflow time, High

Frequency is present at the torch. When the torch
is positioned close to the work the welding current
will transfer to the work and establish the arc at
the initial current setting.

b. In the Lift TIG mode, after Preflow time, Lift Start

current is present at the torch. When the electrode
is touched to the work and lifted off, the welding
arc is established at the initial current setting.

Down

Slope

Final

Current

Postflow

2. Open Remote Switch – current increases to weld
current. Once welding arc has reached weld current
the power source will maintain weld current as long
as the remote switch contacts are open.

3. Close Remote Switch – Welding current decreases to
final current setting. Once final welding current is
reached the power source will maintain final current
setting as long as the remote switch contacts are
closed.

4. Open Remote Switch – Welding arc stops and post
flow begins.

6.04 Slope Mode with Repeat Sequence

The repeat function is operated during the down slope
cycle of the Slope Sequence and is active through the
down slope period only. During the down slope period,
by opening the Remote Switch contacts, the current will
increase back to weld current. Within the Down Slope
period the repeat function can be operated as many times
as desired. To continue slope cycle and end slope
sequence close remote switch contacts and allow weld
current to reach final current setting. Once final current
setting is reached, opening the Remote Switch again will
turn off the welding arc and post flow begins.

6-4

February 22, 2006

6.05 Pulse Controls

ARCMASTER 300 ACDC

(Pulse Width) (Pulse Frequency)

Art # A-04990

(Peak Current)

(Base)

Background

Current

Figure 6-3: Pulse Controls

The Pulse controls are used primarily to control heat input. Pulse offers a number of advantages as follows:

1) Control puddle – size and fluidity (especially out of position).

2) Increase penetration

3) Travel speed control

4) Better consistent quality

5) Decreased distortion on lighter or thinner materials.
Pulse-current provides a system in which the welding current continuously changes between two levels. During the

periods of Peak current, heating and fusion takes place, and during the background (base) current periods, cooling
and solidification take place. Pulse Width is the time in one cycle the current remains at the peak current setting.
Pulse Frequency, measured in Hertz, is the number of cycles per second the current travels between peak and background
current settings. It is as if the foot rheostat were moved up and down to increase and decrease the welding current on
a regular basis. The faster you move the foot rheostat up and down the faster the frequency.

February 22, 2006

6-5

ARCMASTER 300 ACDC

6-6

February 22, 2006

SECTION 7:

BASIC TIG WELDING GUIDE

ARCMASTER 300 ACDC

7.01 Explanation of “Fluttery Arc” when
AC TIG Welding on Aluminum

The following will assist in understanding the
phenomenon of Arc Flutter, also referred to as Arc
Rectification.

The basic thesis is that the fluttering is caused by lack of
oxide in the weld pool.

The oxide layer on the plate reduced the energy for
electron emission. Electron emission from the weld pool
(DC+) causes the oxide layers to be disrupted, the so­called “cleaning action”. However once the cleaning action
has produced a mirror like surface on the weld pool, the
effect of the oxide layer is limited because the oxide layer
has dissipated. This makes electron emission from the
weld pool more difficult and increases the chance of arc
instability.

AC TIG on aluminum

1. The Problem: Arc appears unstable and pulses or flutters. ie. appears to rapidly change welding current

This idea is supported by the observation that once
fluttering starts it can be made to stop by working the arc
away from the mirror like weld pool to an area of oxide
coated material. As soon as this is done the arc settles
back to a stable condition. So while the arc is “consuming”
oxide coated plate the instability does not occur. But once
the arc is stationary, the pool becomes thoroughly
“cleaned” by election emission, the fluttering begins.

Tests conducted on various types of AC TIG power
sources, Fluttery Arc is not confined to one type of power
source or it’s design, both conventional and inverter types
suffer from the same problem.

.

Conditions that accentuate arc flutter: Conditions that minimizes arc flutter:

· Cold work piece, · Preheat the work piece,

· Very short arc length, · Increase the arc length,

· Weld pool crater about 0.39” to

0.47” (10 to 12mm) diameter,

· Arc field in one spot to produce
“mirror” clean weld pool,

· Increased cleaning action.
ie. Prolonged oxide emission from a

stationary weld pool increases the
likelihood of arc flutter,

· Accentuated when tungsten running
near its current capacity, ie. Molten ball
on end.

Table 7-1: Reduction of Arc Flutter

2. Conclusion: Fluttery arc in AC TIG is a physical phenomenon independent of machine design.

· Introduce filler rod material to the
weld pool, which introduces oxides.

· Move the weld pool around to
introduce oxides to the weld pool.

· Decrease the cleaning action by
turning the
50% or move the weld pool around.

· Use a larger diameter tungsten
electrode.

WAVE BALANCE

to below

February 22, 2006

7-1

ARCMASTER 300 ACDC

7.02 Electrode Polarity

Connect the TIG torch to the - / TORCH terminal and the work lead to the + / WORK terminal for direct current straight
polarity. Direct current straight polarity is the most widely used polarity for DC TIG welding. It allows limited wear of
the electrode since 70% of the heat is concentrated at the work piece.

7.03 Tungsten Electrode Current Ranges

Electrode Diameter AC Current (Amps) DC Current (Amps)

0.040” (1.0mm) 30 – 70 30 – 60
1/16” (1.6mm) 60 – 95 60 – 115
3/32” (2.4mm) 125 – 150 100 – 165

1/8” (3.2mm) 130 – 225 135 – 200
5/32” (4.0mm) 190 – 280 190 – 280
3/16” (4.8mm) 250 – 340 250 – 340

Table 7-2: Current ranges for various tungsten electrode sizes

7.04 Tungsten Electrode Types

Electrode Type

(Ground Finish)

Thoriated 2%

Zirconated 1%

Ceriated 2%

Welding Application Features Color

DC welding of mild steel,
stainless steel and copper.

High quality AC welding of
aluminium, magnesium and
their alloys.

AC & DC welding of mild steel,
stainless steel, copper,
aluminium, magnesium and
their alloys

Table 7-3: Tungsten electrode types

Excellent arc starting, Long life,
High current carrying capacity.

Self cleaning, Long life,
Maintains balled end, High
current carrying capacity.

Longer life, More stable arc,
Easier starting, Wider current
range, Narrower more
concentrated arc.

Code

Red

White

Grey

7-2

Februrary 22, 2006

ARCMASTER 300 ACDC

7.05 Guide for Selecting Filler Wire Diameter

NOTE

The filler wire diameter specified in Table 7-4 is a guide only, other diameter wires may be used according
to the welding application

Filler Wire Diameter

1/16” (1.6 mm) 30-95 20 - 90
3/32” (2.4 mm) 125-160 65 - 115

1/8” (3.2 mm) 180-240 100 - 165

3/16” (4.8 mm) 220-320 200-350

7.06 Shielding Gas Selection

Alloy

Aluminium & alloys Welding Argon, Argoshield 80T, 81T
Carbon Steel Welding Argon
Stainless Steel Welding Argon, Argoshield 71T, 80T, 81T
Nickel Alloy Welding Argon, Argoshield 71T
Copper Welding Argon, Argoshield 81T
Titanium Welding Argon, Argoshield 80T, 81T

AC Current Range DC Current Range

(Amps) (Amps)

Table 7-4: Filler wire selection guide

Shielding Gas

Argoshield is a registered trademark of BOC Gases

Limited.

Table 7-5: Shielding gas slection

7.07 TIG Welding Parameters for Low Carbon & Low Alloy Steel Pipe

Electrode Type &

Diameter

Thoriated 2%

3/32” (2.4 mm)

Thoriated 2%

3/32” (2.4 mm)

Thoriated 2%

3/32” (2.4 mm)

Table 7-6: TIG welding parameters for low carbon & low alloy steel pipe

Current Range DC

Amperes

120 - 170 Yes

100 - 160 Yes

90 - 130 No

Filler Rod for

Root Pass

Joint Preparation

February 22, 2006

7-3

ARCMASTER 300 ACDC

7.08 Welding Parameters for Aluminum

Base Metal

Thickness

0.040” 30-45 0.040” 1/16” Butt/Corner

1.0mm 35-50 1.0mm 1.6mm Lap/ Fillet

0.045” 40-60 0.040” 1/16” Butt/Corner

1.2mm 45-70 1.0mm 1.6mm Lap/ Fillet
1/16” 60-85 1/16” 1/16” Butt/Corner

1.6mm 70-95 1.6mm 1.6mm Lap/ Fillet

1/8” 3/32” 3/32”

3.2mm 2.4mm 2.4mm

3/16” 180-225 1/8” 1/8” Butt/Corner

4.8mm 190-240 3.2mm 3.2mm Lap/ Fillet

¼” 240-280 3/16” 3/16” Butt/Corner

6.4mm 250-320 4.8mm 4.8mm Lap/ Fillet

AC Current for

Aluminum

125-150
130-160

Table 7-7: AC TIG welding parameters

Tungsten
Electrode
Diameter

1/8”

3.2mm

Filler Rod

Diameter

(if required)

Argon Gas

Flow Rate
Liters/min

5-7

5-7

7

10

10

13

Joint Type

Butt/Corner

Lap/Fillet

7.09 Welding Parameters for Steel

Base Metal

Thickness

0.040” 35-45 20-30 0.040” 1/16” Butt/Corner

1.0mm 40-50 25-35 1.0mm 1.6mm Lap/ Fillet

0.045” 45-55 30-45 0.040” 1/16” Butt/Corner

1.2mm 50-60 35-50 1.0mm 1.6mm Lap/ Fillet
1/16” 60-70 40-60 1/16” 1/16” Butt/Corner

1.6mm 70-90 50-70 1.6mm 1.6mm Lap/ Fillet

1/8” 80-100 65-85 1/16” 3/32” Butt/Corner

3.2mm 90-115 90-110 1.6mm 2.4mm Lap/ Fillet
3/16” 115-135 100-125 3/32” 1/8” Butt/Corner

4.8mm 140-165 125-150 2.4mm 3.2mm Lap/ Fillet

¼” 160-175 135-160 1/8” 5/32” Butt/Corner

6.4mm 170-200 160-180 3.2mm 4.0mm Lap/ Fillet

DC Current

for Mild

Steel

DC Current for

Stainless

Steel

Tungsten

Electrode

Diameter

Filler Rod

Diameter

(if required)

Argon Gas
Flow Rate
Liters/min

5-7

5-7

7

7

10

10

Joint Type

7-4

Table 7-8: DC TIG welding parameters

Februrary 22, 2006

SECTION 8:

BASIC ARC WELDING GUIDE

8.01 Electrode Polarity

Stick electrodes are generally connected to the ‘+’ terminal
and the work lead to the ‘-’ terminal but if in doubt consult
the electrode manufacturers literature.

8.02 Effects of Stick Welding Various Materials

ARCMASTER 300 ACDC

1. High tensile and alloy steels: The two most prominent

effects of welding these steels are the formation of a
hardened zone in the weld area, and, if suitable
precautions are not taken, the occurrence in this zone
of under-bead cracks. Hardened zone and under-bead
cracks in the weld area may be reduced by using the
correct electrodes, preheating, using higher current
settings, using larger electrodes sizes, short runs for
larger electrode deposits or tempering in a furnace.

2. Manganese steels: The effect on manganese steel of

slow cooling from high temperatures is to embrittle
it. For this reason it is absolutely essential to keep
manganese steel cool during welding by quenching
after each weld or skip welding to distribute the heat.

3. Cast Iron: Most types of cast iron, except white iron,

are weldable. White iron, because of its extreme
brittleness, generally cracks when attempts are made
to weld it. Trouble may also be experienced when
welding white-heart malleable, due to the porosity
caused by gas held in this type of iron.

4. Copper and alloys: The most important factor is the
high rate of heat conductivity of copper, making
preheating of heavy sections necessary to give proper
fusion of weld and base metal.

5. Types of Electrodes: Arc Welding electrodes are
classified into a number of groups depending on their
applications. There are a great number of electrodes
used for specialized industrial purposes, which are
not of particular interest for everyday general work.
These include some low hydrogen types for high
tensile steel, cellulose types for welding large diameter
pipes, etc. The range of electrodes dealt with in this
publication will cover the vast majority of applications
likely to be encountered; are all easy to use and all will
work on even the most basic of welding machines.

February 22, 2006

8-1

ARCMASTER 300 ACDC

Metals being

Electrode Comments

joined

Mild steel 6013 Ideal electrodes for all general purpose work.

Features include out standing operator appeal,
easy arc starting and low spatter.

Mild steel 7014 All positional electrode for use on mild and

galvanized steel furniture, plates, fences, gates,
pipes and tanks etc. Especially suitable for
vertical-down welding.

Cast iron 99% Nickel Suitable for joining all cast irons except white cast

iron.

Stainless steel 318L-16 High corrosion resistance. Ideal for dairy work,

etc. On stainless steels.
Copper, Bronze,
Brass, etc.

Bronze

5.7 ERCUSI-A

Easy to use electrode for marine fittings, water

taps and valves, water trough float arms, etc.

Also for joining copper to steel and for bronze

312-16High Alloy Steels,
Dissimilar Metals,
Crack Resistance.
All Hard-To-Weld

It will weld most problematical jobs such as
springs, shafts, broken joins mild steel to
stainless and alloy steels.
Not suitable for Aluminum.

Table 8-1: Types of Electrodes

8-2

February 22, 2006

ARCMASTER 300 ACDC

SECTION 9:

ROUTINE MAINTENANCE

The only routine maintenance required for the power supply is a thorough cleaning and inspection, with the frequency
depending on the usage and the operating environment.

WARNING

Disconnect primary power at the source before opening the enclosure. Wait at least two minutes before
opening the enclosure to allow the primary capacitors to discharge.

To clean the unit, open the enclosure and use a vacuum cleaner to remove any accumulated dirt and dust. The unit
should also be wiped clean, if necessary; with solvents that are recommended for cleaning electrical apparatus.

CAUTION

Do not blow air into the power supply during cleaning. Blowing air into the unit can cause metal particles to
interfere with sensitive electrical components and cause damage to the unit.

February 22, 2006

9-1

ARCMASTER 300 ACDC

Warning!
Disconnect input power before maintaining.

Visual check of
regulator and pressure

Visually inspect the torch
body and consumables

Each Use

Visual check of torch
Consumable parts

Weekly

Visually inspect the
cables and leads.
Replace as needed

Maintain more often
if used under severe
conditions

Visually inspect the Wire
feed mechanisms

Replace all
broken parts

3 Months

Gas and
air lines

6 Months

Visually check and
use a vacuum to carefully

clean the interior

Clean
exterior
of power supply

9-2

Art # A-06950

February 22, 2006

ARCMASTER 300 ACDC

g

p

j

SECTION 10:

BASIC TROUBLESHOOTING

WARNING

There are extremely dangerous voltages and power levels present inside this product. Do not attempt to
open or repair unless you are an Accredited Thermal Arc Service Agent and you have had training in power
measurements and troubleshooting techniques.

If major complex subassemblies are faulty, then the Welding Power Source must be returned to an Accredited Thermal
Arc Service Agent for repair.

The basic level of troubleshooting is that which can be performed without special equipment or knowledge.

10.01 TIG Welding Problems

Weld quality is dependent on the selection of the correct consumables, maintenance of equipment and proper welding
technique.

Description Possible Cause Remedy

1 Excessive bead build-

up or poor
penetration or poor
fusion at edges of
weld.

2 Weld bead too wide

and flat or undercut at
edges of weld or
excessive burn
throu

3 Weld bead too small

or insufficient
penetration or ripples
in bead are widely
s

4 Weld bead too wide or

excessive bead build
up or excessive
penetration in butt

5 Uneven leg length in

fillet joint.

h.

aced apart.

oint.

Welding current is too low. Increase weld current and/or

faulty joint preparation.

Welding current is too high. Decrease weld current.

Travel speed too fast. Reduce travel speed.

Travel speed too slow. Increase travel speed.

Wrong placement of filler rod. Re-position filler rod.

Table 10-1: TIG Welding Problems

February 22, 2006

10-1

ARCMASTER 300 ACDC

Description Possible Cause Remedy

6 Electrode melts when

arc is struck.

7 Dirty weld pool. A Electrode contaminated

8 Electrode melts or

oxidizes when an arc
is struck.

9 Poor weld finish. Inadequate shielding gas. Increase gas flow or check

10 Arc flutters during TIG

welding.

A Electrode is connected to

the ‘+’ terminal.

WAVE BALANCE

B

than 50%.

through contact with work
piece or filler rod material.

B Gas contaminated with air. B Check gas lines for cuts and

A No gas flowing to welding

region.

B Torch is clogged with dust. B Clean torch.
C Gas hose is cut. C Replace gas hose.

D Gas passage contains

impurities.

E Gas regulator turned off. E Turn on.
F Torch valve is turned off. F Turn on.

G The electrode is too small

for the welding current.

WAVE BALANCE

H

above 50%.

A Tungsten electrode is too

large for the welding
current.

B Absence of oxides in the

weld pool.

is greater

is set

A Connect the electrode to the

‘-’ terminal.

B Reduced

below 50% or increase the
electrode size.

A Clean the electrode by

grinding off the
contaminates.

loose fitting or change gas
cylinder.

A Check the gas lines for kinks

or breaks and gas cylinder
contents.

D Disconnect gas hose from

torch then raise gas
pressure and blow out
impurities.

G Increase electrode diameter

or reduce the welding
current.

H Reduced

below 50% or increase the
electrode size.

gas line for gas flow
problems.

A Select the right size

electrode. Refer to Basic
TIG Welding guide.

B Refer Basic TIG Welding

Guide for ways to reduce
arc flutter.

WAVE BALANCE

WAVE BALANCE

to

to

10-2

Table 10-1 (continued): TIG Welding Problems

February 22, 2006

Description Possible Cause Remedy

11 Welding arc can not

be established.

12 Arc start is not

smooth.

ARCMASTER 300 ACDC

A Work clamp is not

connected to the work piece
or the work/torch leads are
not connected to the right

welding terminals.
B Torch lead is disconnected. B Connect it to the ‘-‘ terminal.
C Gas flow incorrectly set,

cylinder empty or the torch

valve is off.
A Tungsten electrode is too

large for the welding

current.
B The wrong electrode is

being used for the welding

job.

D Incorrect shielding gas is

being used.

E Poor work clamp

connection to work piece.

A Connect the work clamp to

the work piece or connect
the work/torch leads to the
right welding terminals.

C Select the right flow rate,

change cylinders or turn
torch valve on.

A Select the right size

electrode. Refer to Basic
TIG Welding Guide.

B Select the right electrode

type. Refer to Basic TIG
Welding Guide.
Select the correct rate for

CC Gas flow rate is too high.

the welding job.
Refer to Basic TIG Welding
Guide.

D Select the right shielding

gas. Refer to Basic TIG
Welding Guide.

E Improve connection to work

piece.

February 22, 2006

Table 10-1 (continued): TIG Welding Problems

10-3

ARCMASTER 300 ACDC

y

p

10.02 Stick Welding Problems

Descri

tion Possible Cause

1 Gas pockets or voids

in weld metal
(Porosity).

2 Crack occurring in

weld metal soon after
solidification
commences.

3 A gap is left by failure

of the weld metal to fill
the root of the weld.

Remed

A Electrodes are damp. A Dry electrodes before use.
B Welding current is too high. B Reduce welding current.
C Surface impurities such as

C Clean joint before welding.

oil, grease, paint, etc.

A Rigidity of joint. A Redesign to relieve weld

joint of severe stresses or
use crack resistance
electrodes.

B Insufficient throat thickness. B Travel slightly slower to

allow greater build up in
throat.

C Cooling rate is too high. C Preheat plate and cool

slowly.
A Welding current is too low. A Increase welding current
B Electrode too large for joint. B Use smaller diameter

electrode.
C Insufficient gap. C Allow wider gap.

D Incorrect sequence. D Use correct build-up

sequence.

Table 10-2: Stick Welding Problems

Art # A-04991

Incorrect sequence

Insufficient
gap

Figure 10-1: Example of insufficient gap or incorrect sequence

10-4

February 22, 2006

ARCMASTER 300 ACDC

y

p

Descri

tion Possible Cause

4 Portions of the weld

run do not fuse to the
surface of the metal or
edge of the joint.

Remed

A Small electrodes used on

heavy cold plate.

A Use larger electrodes and

pre-heat the plate.
B Welding current is too low. B Increase welding current.
C Wrong electrode angle. C Adjust angle so the welding

arc is directed more into the

base metal.

D Travel speed of electrode is

too high.

E Scale or dirt on joint

surface.

Table 10-2 (continued): Stick Welding Problems

Lack of fusion caused by dirt,
electrode angle incorrect,
rate of travel too high

D Reduce travel speed of

electrode.

E Clean surface before

welding.

Art # A-04992

Lack of inter-run
fusion

Lack of side fusion, scale
dirt, small electrode,
amperage too low

Figure 10-2: Example of lack of fusion

Lack of root fusion

February 22, 2006

10-5

ARCMASTER 300 ACDC

)

g

p

p

y

Descri

tion Possible Cause Remed

5 Non-metallic particles

are trapped in the
weld metal (slag
inclusion

.

A Non-metallic particles may

be trapped in undercut from
previous run.

B Joint preparation too

restricted.

C Irregular deposits allow slag

to be trapped.

D Lack of penetration with

slag trapped beneath weld
bead.

E Rust or mill scale is

reventing full fusion.

F Wrong electrode for position

in which welding is done.

A If bad undercut is present,

clean slag out and cover
with a run from a smaller
diameter electrode.

B Allow for adequate

penetration and room for
cleaning out the slag.

C If very bad, chip or grind

out irregularities.

D Use smaller electrode with

sufficient current to give
adequate penetration. Use
suitable tools to remove all
sla

from corners.

E Clean joint before welding.

F Use electrodes designed for

position in which welding is
done, otherwise proper
control of slag is difficult.

Not cleaned, or
incorrect
electrode

Table 10-2 (continued): Stick Welding Problems

Art # A-04993

Slag trapped in
undercut

Slag trapped in root

Figure 10-3: Examples of slag inclusion

10-6

February 22, 2006

10.03 Power Source Problems

Description Possible Cause Remedy

1 The welding arc

cannot be established.

2 Maximum output

welding current can
not be achieved with
nominal Mains supply
voltage.

3 Welding current

reduces when
welding.

4 No gas flow when the

torch trigger switch is
depressed.

ARCMASTER 300 ACDC

A The Primary supply voltage

has not been switched ON.

B The Welding Power Source

switch is switched OFF.

C Loose connections

internally.

Defective control circuit. Have an Accredited Thermal

A Loose welding cable

connections.

B Incorrect welding cable size. B Use proper size and type of

C Improper input connections. C Refer to Section 2.05

D Poor electrode condition. D Replace electrode.

E Wrong welding polarity. E Verify output torch

A Gas hose is cut. A Replace gas hose.
B Gas passage contains

impurities.

C Gas regulator turned off. C Turn gas regulator on.

D Torch trigger switch lead is

disconnected or
switch/cable is faulty.

A Switch ON the Primary

supply voltage.

B Switch ON the Welding

Power Source.

C Have an Accredited Thermal

Arc Service Agent repair the

connection

Arc Service Agent repair the

connection

A Tighten all welding cable

connections.

cable.

Electrical Input

Requirements.

connections.

B Disconnect gas hose from

the rear of Power Source

then raise gas pressure and

blow out impurities.

D Reconnect lead or repair

faulty switch/cable.

February 22, 2006

Table 10-3: Power Source Problems

10-7

ARCMASTER 300 ACDC

Description Possible Cause Remedy

5 Gas flow won’t shut

off.

6 The TIG electrode has

been contaminated
due to the gas flow
shutting off before the
programmed

FLOW

time has

elapsed.

POST-

Strike an arc to complete the

A Weld Mode (

REPEAT

changed before

FLOW

finished.

B Gas valve is faulty. B Have an Accredited Thermal

C Gas valve jammed open. C Have an Accredited Thermal

D

POST-FLOW

to 60 sec.
The Weld Process Mode
(STICK, HF TIG or LIFT TIG)
was changed before

FLOW

finished.

STD, SLOPE

or

SPOT

) was

POST-

gas time had

control is set

gas time had

POST-

A

,

D Reduce

weld cycle.
OR
Switch machine off then on
to reset solenoid valve
sequence.

Arc Service Agent repair or
replace the gas valve

Arc Service Agent repair or
replace the gas valve

POST-FLOW

Do not change Weld
Process Mode before the

POST-FLOW

finished.

gas time had

time.

10-8

Table 10-3 (continued): Power Source Problems

February 22, 2006

VOLTAGE REDUCTION DEVICE (VRD)

11.01 VRD Specification

Description Notes

VRD Open Circuit Voltage 15.3 to 19.8V Open circuit voltage between welding

VRD Resistance 148 to 193 ohms The required resistance between

VRD Turn OFF Time 0.2 to 0.3

SECTION 11:

ArcMaster

300ACDC

terminals.

welding terminals to turn ON the
welding power.
The time taken to turn OFF the welding

seconds

Table 11-1: VRD Specification

power once the welding current has
stopped.

ARCMASTER 300 ACDC

11.02 VRD Maintenance

Routine inspection and testing (power source):
An inspection of the power source, an insulation resistance test and an earth resistance test should be carried out
a. For transportable equipment, at least once every 3 months;
b. For fixed equipment, at least once every 12 months.
The owners of the equipment shall keep a suitable record of the periodic tests.

NOTE

A transportable power source is any equipment that is not permanently connected and fixed in the position
in which it is operated.

In addition to the above tests and specifically in relation to the VRD fitted to this machine, the following periodic tests
should also be conducted by an accredited Thermal Arc service agent.

Description IEC 60974-1 Requirements

VRD Open Circuit Voltage Less than 20V; at Vin=230V
VRD Turn ON Resistance Less than 200 ohms
VRD Turn OFF Time Less than 0.3 seconds

Table 11-2: Periodic Tests

If this equipment is used in a location or an environment with a high risk of electrocution then the above tests should
be carried out prior to entering this location.

February 22, 2006

11-1

ARCMASTER 300 ACDC

11.03 Switching VRD On/Off

Switch the machine Off.
A) Remove the clear plastic cover from the control panel (see Figure 11-1).

• Lift up the cover so it rests on the top of the unit

• Place a small flat bladed screw driver between the cover hinge on the front panel

• Gently lift the cover hinge out of the front cover mounting hole

• Remove the control's clear plastic cover

2

3

1

2

Art # A-07079

Figure 11-1: VRD ON/OFF Step A

B) Remove the four mounting screws from the the control panel (see Figure 11-2).

Art # A-07080

1

2

1

1

1

11-2

Figure 11-2: VRD ON/OFF Step B

February 22, 2006

ARCMASTER 300 ACDC

!

!

C) Access the VRD control by gently prying back the front panel controls to reveal the VRD on/off potentiometer (see

Figure 11-3).

CAUTION

DO NOT pull back the front panel with excessive force as this will unplug control PCB. Plugging the control
PCB back into the front panel controls can only be achieved by removing the side covers.

VR1

Art # A-07081

Figure 11-3: VRD ON/OFF Step C and D

D) Turning the VRD ON/OFF (see Figure 11-3)

• To turn VRD ON: rotate the trim potentiometer on the display PCB fully clockwise. When VRD is turned ON check
that it operates as per VRD Specifications on page 11-1.

• To turn VRD OFF: rotate the trim potentiometer on the display PCB fully counter clockwise.

WARNING

The VRD ON/OFF trim potentiometer MUST ONLY be positioned fully clockwise OR fully counter clockwise
as the VRD function will be unknown for every other position.

February 22, 2006

11-3

ARCMASTER 300 ACDC

11-4

February 22, 2006

SECTION 12:

POWER SOURCE ERROR CODES

Description Possible Cause Remedy Remarks

1 E01 error code

displayed
Temperature sensor
TH1 (protects
IGBTs) is greater
than 80ºC for about
1 second.

2 E02 error code

displayed
Temperature sensor
TH2 (protects
secondary diodes)
is greater than 80ºC
for about 1 second.

3 E03 error code

displayed
Primary (input)
current too high.

E04 error code

4 TIG torch cable

displayed
Output voltage
exceeds the
secondary voltage
specification.

A The Welding Power

Source’s duty cycle
has been exceeded.

B Fan ceases to

operate.

C Air flow is restricted

by vents being
blocked.

A The Welding Power

Source’s duty cycle
has been exceeded.

B Fan ceases to

operate.

C Air flow is restricted

by vents being
blocked.

A Primary current is

too high because
welding arc is too
long.

B Mains supply

voltage is more than
10% below nominal
voltage .

and/or work lead are
too long or leads
are coiled.

ARCMASTER 300 ACDCR

A Let Power Source

cool down then
keep within its duty
cycle.

B Have an Accredited

Thermal Arc Service
Agent investigate.

C Unblock vents then

let Power Source
cool down.

A Let Power Source

cool down then
keep within its duty
cycle.

B Have an Accredited

Thermal Arc Service
Agent investigate

C Unblock vents then

let Power Source
cool down.

A Reduce length of

welding arc.

B Have an Accredited

Thermal Arc Service
Agent or a qualified
electrician check for
low Mains voltage.

Reduce the length
of the TIG torch
cable and/or work
lead or un-coiled
leads.

Weld current
ceases. Buzzer
sounds constantly.
Fan operates at max
speed.
E01 resets when
TH1 decreases to
70ºC for about 30
seconds.

Weld current
ceases. Buzzer
sounds constantly.
Fan operates at max
speed.
E02 resets when
TH2 decreases to
70ºC for about 30
seconds.

Weld current
ceases. Buzzer
sounds constantly.
Fan operates at max
speed.
Switch machine off
then on to reset E03
error.

Weld current
ceases. Buzzer
sounds constantly.
Switch machine off
then on to reset E04
error.

February 22, 2006

Table 12-1 Power Source Error Codes

12-1

ARCMASTER 300 ACDC

E11 error code

5 Primary supply

displayed
Over Primary supply
(input) voltage at

voltage is greater
than the nominal

voltage plus 10%.
primary capacitors
is exceeded for one
second.
E14 error code

6

displayed
Under mains supply
(input) voltage
warning primary

Mains supply

voltage is less than

the nominal

operating voltage

less 10%.
capacitors is
reduced for one
second.

7 Mains supply

E12 error code
displayed
Under mains supply
(input) voltage

voltage is down to a

dangerously low

level.
primary capacitors
is reduced for one
second.

E81 error code

8 When 3 phase

displayed
Wrong Primary
supply (input)
voltage connected.

machine is first

turned on with the

wrong Primary

supply (input)

voltage connected.

Have an Accredited
Thermal Arc Service
Agent or a qualified
electrician check the
Primary voltage.

Have an Accredited
Thermal Arc Service
Agent or a qualified
electrician check the
Mains voltage.

A Have an Accredited

Thermal Arc Service
Agent or a qualified
electrician check the
Mains voltage.

B Have an Accredited

Thermal Arc Service
Agent or a qualified
electrician check the
primary cable and
fuses.

Have an Accredited
Thermal Arc Service
Agent or a qualified
electrician check the
Mains voltage.

Weld current
ceases. Buzzer
sounds contstantly.
Error code E11
automatically will
reset when the
voltage reduces.
Weld current
available. Buzzer
sounds
intermittently.
Error code E14
automatically will
reset when the
voltage increases.

Weld current
ceases. Buzzer
sounds contstantly.
Error code E12
automatically will
reset when the
voltage increases.

No weld current is
available. Buzzer
sounds constantly.
Switch machine off.

12-2

Table 12-1 (continued): Power Source Error Codes

February 22, 2006

ARCMASTER 300 ACDCR

E82 error code

9 The Primary supply

displayed
Rated voltage
selection circuit

(input) voltage
fluctuates and is not

stable.
abnormality.
E83 error code

10 The Primary supply

displayed
CPU checks mains
supply (input)

(input) voltage

fluctuates and is not

stable.
voltage when the
on/off switch on
rear panel of
machine is turned
ON.
E85 error code

11

displayed
Pre-charge
abnormality.

Due to malfunction

inside the Welding

Power Source,

primary capacitors

are not charging
E93 error code

12 Memory chip

displayed

(EEPROM) error.
Memory chip
(EEPROM) on
control PCB can not
read/write weld
parameters.

Have an Accredited
Thermal Arc Service
Agent or a qualified
electrician check the
Mains voltage.

Have an Accredited
Thermal Arc Service
Agent check
connector plug on
input PCB and the
Mains voltage

Have an Accredited
Thermal Arc Service
Agent service the
machine

Have an Accredited
Thermal Arc Service
Agent check the
control PCB.

No weld current is
available. Buzzer
sounds constantly.
Switch machine off
then on to reset E82

No weld current is
available. Buzzer
sounds constantly.
Switch machine off
then on to reset E83
error.

No weld current is
available. Buzzer
sounds constantly.
Switch machine off
then on to reset E85

Weld current
ceases. Buzzer
sounds constantly.
Switch machine off.

February 22, 2006

Table 12-1 (continued): Power Source Error Codes

12-3

ARCMASTER 300 ACDC

E94 error code

13 The Welding Power

displayed
Temperature sensor
TH1 for IGBTs or
sensor TH2 for

Source’s
temperature
sensors have
malfunctioned.

secondary diodes

Have an Accredited
Thermal Arc Service
Agent check or
replace the
temperature
sensors

Weld current
ceases. Buzzer
sounds constantly.
Switch machine off.

are open circuit.
E99 error code

14 Weld current

displayed

A Main on/off switch

on machine has

been turned off
Mains supply
(input) voltage has
been turned off but

Mains supply

(input) voltage has

been turned off.
control circuit has
power from the
primary capacitors.

Table 12-1 (continued): Power Source Error Codes

A Turn on/off switch

on.

B Have an Accredited

Thermal Arc Service
Agent or a qualified
electrician check the
Mains voltage and
fuses.

ceases. Buzzer
sounds constantly.
Must switch
machine off then on
to reset E99 error.

12-4

February 22, 2006

ARCMASTER 300 AC/DC

APPENDIX 1: ARCMASTER 300 AC/DC ACCESSORIES

ACCESSORIES PART NO. DESCRIPTION

Stick Kit 10-4082 Work clamp with 25’ #1 cable, and stick electrode

with 25’ #1cable

TIG Kit 10-4081 Includes regulator/flowmeter with 12’ gas hose, 12.5’

200 Amp TIG torch, accessory kit includes 1 ea of
0040”x7”, 1/16”x7”, 3/32”x7” 2% Tungsten with
collet & collet bodies, 1 ea 1/4”, 5/16”, 3/8” alumina

cup, 15’ cable with clamp & T50 dinse plug
TWECO® TC900 Water Cooler* 4010-1010 TC900-G cooler w/gear pump

4010-1011 TC900-V cooler w/vane pump

Dinse Connector 10-2020 T50mm Dinse style male plug

AVAILABLE 2nd QUARTER
Hand Held Pendant 10-2005 Includes contactor On/Off switch and current control

with 25ft cable and 14-pin male plug
Foot Control 10-2008 Contactor On/Off and current control with 15ft cable

and 14-pin male plug

10-2007 Contactor On/Off and current control with 25ft cable

and 14-pin male plug

Extension Cable 10-2030 3ft with 14-pin male plug and 14-pin female cable

receptacle
10-2031 15ft with 14-pin male plug and 14-pin female cable

receptacle

10-2032 25ft with 14-pin male plug and 14-pin female cable

receptacle

10-2033 50ft with 14-pin male plug and 14-pin female cable

receptacle
10-2034 75ft with 14-pin male plug and 14-pin female cable

receptacle

Torch Switch On/Off 10-2001 25ft torch mounted with 14-pin male plug
Torch Switch On/Off
w/current control

10-2003 25ft torch mounted with 14-pin male plug - adapts to

10-2004 25ft torch mounted with 14-pin male plug - adapts to

600298
600299
Running Gear/Cylinder Cart 205199

*Note: For detailed information see Tweco MIG Water cooler product information

10-2002 25ft torch mounted with 14-pin male plug - adapts to

5/8”-7/8” torch

7/8”-1-1/8” torch handle

1-1/8”-1-3/8” torch handle

Rotary amperage control 5k 15’ velcro for TD14

Rotary amperage control 5k 25’ velcro for TD14

For welding power source and/or gas cylinders

February 22, 2006

A-1

ARCMASTER 300 AC/DC

APPENDIX 2: ARCMASTER 300 INTERCONNECT DIAGRAM

Line1

Line2

Line3

Ground

+

PCB21

E

Filter

Circuit Board

[WK-4917]

SIDE CHASSIS 1

REAR

PANEL

N

P

R2

460V

CN1

2

1

1

2 3

1

CN2

2

3

4

CN1

5
6

S2

230V

FAN1

+-

1

AJ

FE

2

3

4

L105

CON1

EC

CN11

EB

SOL1

A : Contactor Control /+24VDC
B : Contactor Control /Contactor Clouser To"A"
C : 0 To +10Vdc Output To Remote Control
D : Remote Control Circuit Common
E : 0 To +10Vdc Intput From Remote Control
F : Not Used
G : Chassis Ground
H : Not Used
I : Not Used
J : Not Used
K : Not Used
L : Not Used
M : OK to Move(Current Detect Signal)
N : OK to Move(Current Detect Signal)

BKI

CL NH

DMG

S1

1

2 3 45

CN3

1
2

3

CN4

4

CN31CN30

Connect Circuit Board

[WK-5551]

CN131 CN130

CN17
CN17

TB0

1
2

CN14CN13

1
2

CN27

3

Circuit Board

CN15

4

CN27

[WK-5550]

5

1
2

3

1
2

D1

+

(1)

K(7)

G(6)

R(3)

(0)

S(4)

T(5)

-

(2)

1
2

3

4
5

PCB4
Detect

Circuit Bo

CN32
CN32

ard

[WK-4819]

CN5 CN6 CN4

CN30CN31

PCB5

CN130CN131

CN132
CN132

CN18
CN18

PCB7

Filter

1
2

CN20

3

CN3

P

P

TB1

R2

R2

N

N

TB2

TB3

PCB2

Link

Circuit Board

[WK-5597]

TB4

CN2

CN1

1

2 3

1

2 3

CN7

CN1CN6CN5

PCB3

Control

Souce

Circuit Board

[WK-5548]

CN18

123

CN7

1
2

3

4

CN20

12

123

[WK-5493]

CN33

TB13

UB3

TB14

TB15

PCB1
Main

Circuit

Board

TB1

G1

1

E1

2

3

1

G2

2

E2

3

4

TB2

TB3

TB18

TB19

TB20

TB4

G3

1

E3

2

3

G4

1

E4

2

3

4

CT1
CT2
CT3
CT4

E1

E5

G1

123 456

CN20

CN912CN8

123

C

CE

PCB8

E

IGBT

Gate

Circuit

Board

[WK-5479]

CN1

CN2

C

CE

PCB9

E

IGBT

Gate

Circuit

Board

[WK-5479]

CN1

CN2

E2

G5

123 4567

PCB6

Control

Circuit Board

[WK-5549]

TH2 TH1

C

G

E
C

G

E
C

G

E
C

G

E
C

G

E
C

G

E

C

G

E
C

G

E
C

G

E
C

G

E
C

G

E
C

G

E

G2

CN21

Q1

Q2

Q3

Q4

Q5

Q6

Q7

Q8

Q9

Q10

Q11

Q12

E6

TB10

TB11

TB12

G4
E4

G3
E3

TB5

UB1

TB6

TB7

G7
E7

G8
E8

E7

G6

123 456

CN19

123

PGND

P+21V

C

CE

E

[WK-5479]

1
2

3

1
2

3

4

C

CE

E

[WK-5479]

1
2

3

1
2

3

4

G7

CN22

PCB10

IGBT

Gate

Circuit

Board

CN1

CN2

PCB11

IGBT

Gate

Circuit

Board

CN1

CN2

E3

G3

123 4567

C

G

E
C

G
E

C

G

E
C

G

E
C

G

E
C

G

E

C

G

E
C

G

E
C

G

E
C

G

E
C

G

E
C

G

E

E8

G8

CN23

Q13

Q14

Q15

Q16

Q17

Q18

Q19

Q20

Q21

Q22

Q23

Q24

CN17

CN17

CN21

CN21

CN1

CN1

E4

G4

1

1
2

2

3

3

4

4
5

5
6

6
7

7

1

1
2

2

3

3

4

4

1

1
2

2

3

3

4

4

A-2

Art # A-07657

February 22, 2006

ARCMASTER 300 AC/DC

UB2

UB4

TB7

TB21

TB8

TB17

1

2 3 45

TB16

TB22

CT3

SG

S+15V

CN8

[WK-5594]

CT2

CT1

CT2

L1

CT4

CT3

EB

PCB14

TRANS

Board

TB35

TB33

TB34

TB30

TB32

TB31

AC4

AC3

AC2

1

2 3 45678 9

CN9

DIODE Snubber

Circuit Board

[WK-5606]

AC1

AC2

AC4

SH.DET-

SH.DET+

PCB15

D6

D7

D2

D3

D4

D5

P

N

P+21V
PGND

S+15V

SG

/RY_ON

FCH1

PCB18

IGBT Gate

Circuit Board

[WK-3367]

CN1

1

2 3 45

G10

TB1 TB2

TB1 TB2

1
2

3

CN1

4

Super Inpose

1
2

Circuit Board

CN2

[WK-5569]

1
2

CN3

3

1

2 3 4567

PCB17

IGBT Snubber

Circuit Board

[WK-5570]

G1

G1

E1

E1

G2

G2

E2

E2

E9

G9

E10

RY+15V

/RY_ON

R3

12

CN5

PCB16

CN4

RY+15V

Q25

CN6

1
2

3

SH.DET-

1
2

3

4
5
6
7

8

Q26

G1

E1

G2

E2

1

2 3 45

CN1

PCB20

Filter Circuit

CN3

Board

[WK-5499]

CC1

CC2

CC1

HF.UNIT1

AC1 AC3

G9
E9

G11

E11

G10

E10

G12

E12

IS

-15

+15

4

3

2

1

HCT1

G1

PCB19

E1

IGBT Gate

Circuit Board

G2

[WK-3367]

E2

1

2 3 45

G12

SIDE CHASSIS 3

R1

R2

R6

FRONT
PANEL

Ground

+

GND

CN1

E12

EB

SH.DET+

E11

+

TO1

G11

Ground

TO2

R2

AC3

AC1

+Output

Terminal

-Output

Terminal

February 22, 2006

+15

-15
IS

GND

1
2

3

4
5
6

PCB12

Panel

Circuit Board

[WK-5527]

CN2

CN1

123 4

PCB13

Encoder

Board

[WK-5528]

CN1

123 4

SIDE CHASSIS 2

R2

UB2UB1

R3

UB4UB3

Art # A-07657

A-3

LIMITED WARRANTY

y

r

t

f

f

r

y

y

This information applies to Thermal Arc products that were purchased in the USA and Canada.

April 2006

LIMITED WARRANTY: Thermal Arc

®

, Inc., A Thermadyne Company ("Thermal Arc"),
warrants to customers of authorized distributors ("Purchaser") that its pro ducts will be free
of defects in workmanship or material. Should any failure to conform to this warrant
appear within the warranty period stated below, Thermal Arc shall, upon notification
thereof and substantiation that the product has been stored, installed, operated, and
maintained in accordance with Thermal Arc's specifications, instructions,
recommendat ions and recognized stan dard industry practic e, and not subject to misu se,
repair, neglect, alteration, or damage, correct such defects by suitable repair o
replacement, at Thermal Arc's sole option, of any components or parts of the produc
determined by Thermal Arc to be defective.

This warranty is exclusive and in lieu of any warranty o
merchantability, fitness for any particular purpose, or other warranty o
quality, whether express, implied, or statutory.

Limitation of liability: Therma l Arc shall not under an y circumstances be lia ble for special,
indirect, incidental, or consequential damages, including but not limited to lost profits and
business interruption. The remedies of the purchaser set forth herein are exclusive, and
the liability of Thermal A rc with respect to any co ntract, or anything done in connection
therewith such as the performance or breach thereof, or from the manufacture, sale,
delivery, resale, or use of any goods covered by or furnished by Thermal Arc, whethe
arising out of contract, tort, in cluding negligence or strict liability, or under any warranty,
or otherwise, shall not exceed the price of the goods upon which such liability is base d.

No employee, agent, or representative of Thermal Arc is authorized to change this
warranty in any way or grant any other warranty, and Thermal Arc shall not be bound b
any such attempt. Correction of non-conformities, in the manner and time provided
herein, constitutes fulfillment of thermal’s obligations to purchaser with respect to the
product.

This warranty is void, and seller bears no liability hereunder, if purchaser used
replacement parts or accessories which, in Thermal Arc's sole judgment, impaired the
safety or performance of any Thermal Arc product. Purchaser’s rights under this warrant
are void if the product is sold to purchaser by unauthorized persons.

The warranty is effective for the time stated below beginning on the date that the
authorized distributor delivers the products to the Purchaser. Notwithstanding the
foregoing, in no event shall the warranty period extend more than the time stated plus
one year from the date Thermal Arc delivered the product to the authorized distributor.

Warranty repairs or replacement claims under this limited warranty must be submitted to
Thermal Arc via an authorized Thermal Arc repair facility within thirty (30) days of
purchaser's discovery of any defect. Thermal Arc shall pay no transportation costs of any
kind under this warranty. Transportation charges to send products to an authorized
warranty repair facility shall be the responsibility of the Purchaser. All returned goods
shall be at the Purchaser's risk and expense. This warranty dated April 1

®

supersedes all previous Thermal Arc warranties. Thermal Arc

is a Registered

st

2006

Trademark of Thermal Arc, Inc .

WARRANTY SCHEDULE

This information applies to Thermal Arc products that were purchased in the USA and Canada.

April 2006

ENGINE DRIVEN WELDERS WARRANTY PERIOD LABOR
Scout, Raider, Explorer

Original Main Power Stators and Inductors .................................................................................. 3 years

Original Main Power Rectifiers, Control P.C. Boards................................................................... 3 years

All other original circuits and components including, but not limited to, relays,

switches, contactors, solenoids, fans, power switch semi-conductors..........................................1 year

Engines and associated components are NOT warranted by Thermal Arc, although

most are warranted by the engine manufacturer............................................................. See the Engine’s Warranty for Details

GMAW/FCAW (MIG) WELDING EQUIPMENT WARRANTY PERIOD LABOR
Fabricator 131, 181; 190, 210, 251, 281; Fabstar 4030;
PowerMaster 350, 350P, 500, 500P; Excelarc 6045.
Wire Feeders; Ultrafeed, Portafeed

Original Main Power Transformer and Inductor............................................................................5 years 3 years

Original Main Power Rectifiers, Control P.C. Boards, power switch semi-conductors.................3 years 3 years

All other original circuits and components including, but not limited to, relays,

switches, contactors, solenoids, fans, electric motors...................................................................1 year

GTAW (TIG) & MULTI-PROCESS INVERTER WELDING EQUIPMENT WARRANTY PERIOD LABOR
160TS, 300TS, 400TS, 185AC/DC, 200AC/DC, 300A C/ DC, 400GT S W, 400MST,
300MST, 400MSTP

Original Main Power Magnetics....................................................................................................5 years 3 years

Original Main Power Rectifiers, Control P.C. Boards, power switch semi-conductors.................3 years 3 years

All other original circuits and components including, but not limited to, relays,

switches, contactors, solenoids, fans, electric motors...................................................................1 year

PLASMA WELDING EQUIPMENT WARRANTY PERIOD LABOR
Ultima 150

Original Main Power Magnetics.................................................................................................... 5 years 3 years

Original Main Power Rectifiers, Control P.C. Boards, power switch semi-conductors................. 3 years 3 years

Welding Console, Weld Controller, Weld Timer ........................................................................... 3 years 3 years

All other original circuits and components including, but not limited to, relays,

switches, contactors, solenoids, fans, electric motors, Coolant Recirculator................................1 year

SMAW (Stick) WELDING EQUIPMENT WARRANTY PERIOD LABOR
Dragster 85

Original Main Power Magnetics.....................................................................................................1 year 1 year

Original Main Power Rectifiers, Control P.C. Boards....................................................................1 year 1 year

All other original circuits and components including, but not limited to, relays,

switches, contactors, solenoids, fans, power switch semi-conductors..........................................1 year

160S, 300S, 400S

Original Main Power Magnetics....................................................................................................5 years 3 years

Original Main Po w e r Rect ifiers, Control P.C. Bo a rds ........ ................... ................... ................... .. 3 years 3 years

All other original circuits and components including, but not limited to, relays,

switches, contactors, solenoids, fans, power switch semi-conductors..........................................1 year

GENERAL ARC EQUIPMENT WARRANTY PERIOD LABOR

Water Recirculators....................................................................................................................... 1 year 1 year

Plasma Welding Torches.............................................................................................................180 days 180 days

Gas Regulators (Supplied with power sources).......................................................................... 180 days Nil

MIG and TIG Torches (Supplied with power sources)..................................................................90 days Nil

Replacement repair parts.............................................................................................................90 days Nil

MIG, TIG and Plasma welding torch consumable items...................................................................Nil Nil

3 years
3 years

1 year

1 year

1 year

1 year

1 year

1 year

GLOBAL CUSTOMER SERVICE CONTACT INFORMATION

Thermadyne USA

2800 Airport Road
Denton, Tx 76207 USA
Telephone: [phone]
800-426-1888
Fax: [phone]
Email: [e-mail]

Thermadyne Canada

2070 Wyecroft Road
Oakville, Ontario
Canada, L6L5V6
Telephone: [phone]
Fax: [phone]

Thermadyne Europe

Europe Building
Chorley North Industrial Park
Chorley, Lancashire
England, PR6 7Bx
Telephone: [phone]
Fax: [phone]

Thermadyne Asia Sdn Bhd

Lot 151, Jalan Industri 3/5A
Rawang Integrated Industrial Park - Jln Batu Arang
48000 Rawang Selangor Darul Ehsan
West Malaysia
Telephone: 603+ 6092 2988
Fax : 603+ 6092 1085

Cigweld, Australia

71 Gower Street
Preston, Victoria
Australia, 3072
Telephone: [phone]
Fax: [phone]

Thermadyne Italy

OCIM, S.r.L.
Via Benaco, 3
20098 S. Giuliano
Milan, Italy
Tel: [phone]
Fax: [phone]

Thermadyne, China

RM 102A
685 Ding Xi Rd
Chang Ning District
Shanghai, PR, 200052
Telephone: [phone]
Fax: [phone]

Thermadyne International

2070 Wyecroft Road
Oakville, Ontario
Canada, L6L5V6
Telephone: [phone]
Fax: [phone]

World Headquarters

Thermadyne Holdings Corporation
Suite 300, 16052 Swingley Ridge Road
St. Louis, MO 63017

Telephone: [phone]
Fascimile: [phone]
Email: [e-mail]

www.thermalarc.com
