Introduction

© 2003 American Standard Inc. All rights reserved

Precedent
quality... with added flexibility.

Precedent is a flexible line of packaged
units that covers a wide variety of
applications.

Electromechanical controls are available
for simpler applications, and for the
more sophisticated, ReliaTel™
microprocessor controls. In addition to
controls, Precedent offers many other
outstanding features and option choices.

TM

. . . The same Trane

With its sleek compact cabinet, rounded
corners and beveled top, it may just be
the most aesthetically pleasing packaged
unit on the planet. And, of course,
Precedent carries the Trane reputation for
excellence, quality and reliability.

From simple applications, to the most
complex, Precedent has the solution.

RT-PRC005-EN

Contents

Introduction
Features and Benefits

Application Considerations

Selection Procedure

Model Number Description

General Data

Performance Data

Cooling Performance
Fan Performance
Heat Performance

Controls

Electric Power

Dimension and Weights

2

4

8

9

10

11

15

15
26
47

49

50

64

RT-PRC005-EN

Mechanical Specifications

73

3

Unit Cabinet

The compact cabinet with rounded
corners takes up less room and is less
costly to ship. The beveled and ribbed
top is not only aesthetically pleasing, it is
designed to prevent water from pooling.

Single Point Power

A single electrical connection powers the
unit.

Features and Benefits

Easy Access Panels

Remove two screws for access to the
standardized internal components and
wiring.

Easy-Adjust Idler Arm

With the Easy-Adjust Idler Arm, the belt
and sheaves on belt drive units can be
quickly adjusted without moving the
mounted fan motor. The result is a major
savings in time and money.

Colored And Numbered Wiring

You save time and money tracing wires
and diagnosing the unit.

Patented Condenser Coil

Precedent boasts a patented 1+1+1
Hybrid coil, permanently gapped for
easy of cleaning.

Compressors

Precedent™ contains the best
compressor technology available to
achieve the highest possible
performance. Our compressor line
includes Trane built reciprocating and
scrolls.

Easy Access Panels

Easy access panels reduce the number of
possible water entry points.

Low Ambient Cooling

All Precedent microprocessor units have
cooling capabilities down to 0°F as
standard. Electromechanical models
have cooling capabilities to 40°F as built,
or to 0°F by adding the optional low
ambient control (frostat).

Convertible Units

• The units ship in a downflow

configuration. They can be easily
converted to horizontal by simply
moving two panels.

• Units come complete with horizontal

duct flanges so the contractor doesn’t
have to field fabricate them. These
duct flanges are a time and cost saver.

Unit Base

For added water integrity, Precedent has
a raised 1
downflow supply and return to prevent
water from blowing into the ductwork.

1

/8" lip around the unit’s

Sloped Drain Pans

Every Precedent unit has a non­corrosive, removable, double-sloped
drain pan that’s easy to clean and
reversible to allow installation of drain
trap on either side of the unit.

Through the Base Condensate

Every unit includes provisions for
through the base condensate drain
connections. This allows the drain to be
connected through the roof curb instead
of a roof penetration.

Foil-Faced Insulation

All panels in the Evaporator section of
the unit have cleanable foil-faced
insulation. All edges are either captured
or sealed to ensure no fibers get into the
airstream.

4

RT-PRC005-EN

Features and
Benefits

Standardized Components

• Components are placed in the same

location on all Precedent™ units.
Familiarize yourself with one Precedent
and you are familiar with every
Precedent.

Easy Access Low Voltage Terminal Board

Precedent’s Low Voltage Terminal Board
is external to the electrical control
cabinet. It is extremely easy to locate and
attach the thermostat wire. This is
another cost and time saving installation
feature.

Low Voltage Connections

The wiring of the low voltage connections
to the unit and the zone sensors is as
simple as 1-1, 2-2, and 3-3. This simplified
system makes it easy for the installer to
wire

Single-Side Service

Single-side service is standard on all
Precedent units.

Flexible Applications

• Only two roof curbs for the 3-10 ton
Precedent line. . .simplifies curb
selection.

• Standard or High Efficiency Cooling

• Electromechanical or ReliaTel

microprocessor controls to meet either
the simple or the more complex
application.

• Airflow is outstanding. The Precedent
can replace an older machine with old
ductwork and, in many cases, improve
comfort through better air distribution.

• Belt or direct drive — standard or
oversized supply fan motors meet a
wide airflow range.

• Precedent offers ultimate flexibility.
Options and components are not pre­packaged at the factory. Units are built
to order in our standard “shortest in the
industry” ship cycle time.

RT-PRC005-EN

Micro Controls

Several years ago, Trane was the first to
introduce microprocessor controls into
the Light Commercial Market. That
design, along with immeasurable
experience, has provided the technology
for Trane’s second-generation ReliaTel™
microprocessor controls.

ReliaTel™ Micro:

• Provides unit control for heating,
cooling, and ventilating by utilizing input
from sensors that measure outdoor
and indoor temperature.

• Improves quality and reliability through
the use of time-tested microprocessor
controls and logic.

• Prevents the unit from short cycling,
considerably improving compressor
life.

• Ensures that the compressor will run for
a specific amount of time, which allows
oil to return for better lubrication,
enhancing the reliability of the
compressor.

• Reduces the number of components
required to operate the unit, thereby
reducing possibilities for component
failure.

• Eliminates the need for field-installed
components with its built-in anti-short­cycle timer, time delay relay and
minimum ‘’on’’ time controls. These
controls are factory tested to assure
proper operation.

• Requires no special tools to run the
Precedent unit through its paces during
testing. Simply place a jumper between
Test 1 and Test 2 terminals on the Low
Voltage Terminal Board and the unit will
walk through its operational steps. The
unit automatically returns control to the
zone sensor after stepping through the
test mode a single time, even if the
jumper is left on the unit.

• As long as the unit has power and the
LED is lit, the Micro is operational. The
light indicates that the Micro is
functioning properly.

• Features expanded diagnostic
capabilities when used with Trane’s
Integrated Comfort

• As an energy benefit, softens electrical
‘’spikes’’ by staging on fans,
compressors and heaters.

• The Intelligent Fallback or Adaptive
Control is a benefit to the building
occupant. If a component goes astray,
the unit will continue to operate at
predetermined temperature set points.

• Intelligent Anticipation is a standard
feature of the Micro. Functioning
constantly, the Micro and zone sensors
work together in harmony, to provide
tight comfort control.

Electromechanical Controls

TM

Systems.

• For the simpler job that does not

require a building automation system,
or expanded diagnostics capabilities,
Precedent offers electromechnical
controls. This 24-volt control includes
the control transformer, contactor
pressure lugs for power wiring.

5

Features and
Benefits

Factory-installed Options

Economizer

Equipped with either dry bulb, reference
or comparative enthalpy sensing, this
feature provides free cooling as the
outdoor temperature and/or humidity
decreases. Economizers, correctly
installed, offer a valuable energy
savings. Factory-installed economizers
save time and ensure proper installation.

Trane Communication Interface

Available factory or field-installed. This
module when applied with ReliaTel™
easily interfaces with Trane’s Integrated
Comfort

Hinged Access Doors

These doors permit easy access to the
filter, fan/heat, and compressor/control
sections. They reduce the potential roof
damage from screws or sharp access
door corners.

Through the Base Electrical Utility
Access

Factory provided through the base
openings simplify wiring and piping.
Because these utility openings
frequently minimize the number of roof
penetrations, the integrity of roofing
materials is enhanced.

Unit Mounted Disconnect or Circuit
Breaker

Codes require a method of assured unit
shutdown for servicing. Field-installed
disconnects sometimes interfere with
service access. Factory installation of unit
disconnects reduces costs, assures
proper mounting and provides the
opportunity to upgrade to unit circuit
breaker protection.

Clogged Filter/Fan Fail Switches

These sensors allow a zone sensor
service light or Integrated Comfort
System to indicate a dirty filter or a fan
that’s not working. The field installation
charges for these valuable feedback
devices often eliminate them from
consideration. Factory installation can
make such features a good investment.

TM

System.

Unit Disconnect

Convenience Outlet

Dehumidification (Hot Gas Reheat)
Option

This option allows for increased outdoor
air ventilation. It reduces humidity levels
while increasing comfort level in the air
space. Cooling can operate without a
demand for dehumidification. The hot gas
reheat coil is designed to deliver
maximum reheat temperatures and
pivot to allow for easy access cleaning.

The following options round-out the
complete line of Precedent™ options:

— 0 - 50% Manual or Motorized

Outside Air

— Hail Protection Quality Coil Guards

— Electric Heaters

— Supply and/or Return Smoke

Detectors

— High Pressure Cutout

(standard on 3-phase models with
scroll compressors and all standard
efficiency 3-ton models)

— Thermal Expansion Valve for a wider

range of applications

— Discharge Air Sensor

— Wide array of Zone Sensors and

Thermostats

— Factory built Roof Curb

— Power Exhaust

— LonTalk Communications Interface

One of Our Finest Assets:

Trane Sales Representatives are a
Support group that can assist you with:
— Product
— Application
— Service
— Training
— Special Applications
— Specifications
— Computer Programs and much more

Precedent has the features and benefits
that make it first class in the light
commercial rooftop market. Designed
with input from field contractors and
engineers, its airflow performance is
outstanding.

Precedent…The same Trane
quality…with added flexibility.

6

RT-PRC005-EN

Features and
Benefits

Quality And Reliability Testing

• All Precedent™ designs were

rigorously rain tested at the factory to
ensure water integrity.

• Actual shipping tests were performed
to determine packaging requirements.
Units were test shipped around the
country to determine the best
packaging.

• Factory shake and drop tests were
used as part of the package design
process to help assure that the unit
arrives at the job site in top condition.

• Rigging tests include lifting a unit into
the air and letting it drop one foot,
assuring that the lifting lugs and rails
hold up under stress.

• We perform a 100% coil leak test at the
factory. The evaporator and condenser
coils are leak tested at 200 psig and
pressure tested to 450 psig.

• All parts are inspected at the point of
final assembly. Sub-standard parts are
identified and rejected immediately.

• Every unit receives a 100% unit run test
before leaving the production line to
make sure it lives up to rigorous Trane
requirements.

We test designs at our factory not on our
customers!

VariTrac

™

Va riTrac

When Trane’s changeover VAV System
for light commercial applications is
coupled with Precedent, it provides the
latest in technological advances for
comfort management systems and can
allow thermostat control in every zone
served by VariTrac.

RT-PRC005-EN

Voyager or Reliatel

ReliaTel

Roof Top Unit

7

Application Considerations

Application of this product should be
within the cataloged airflow and cooling
considerations.

Low Ambient Cooling

The Precedent™ line features, with
ReliaTel™ microprocessor controls, low
ambient cooling down to 0F. With
electromechanical controls, Precedent
features low ambient cooling to 40F.
Contact your local Trane Representative
for more assistance with low ambient
cooling applications.

Barometric Relief

This product line offers an optional
barometric relief damper. for use in
conjunction with economizer option.
This accessory consists of gravity
dampers which open with increased
pressure. As the building air pressure
increases, the pressure in the unit return
air section also increases, opening the
dampers and relieving the conditioned
space.

NOTE: THE EFFECTIVENESS OF
BAROMETRIC RELIEF DAMPER
DURING ECONOMIZING OPERATION
IS SYSTEM RELATED.

PRESSURE DROP OF THE RETURN AIR
SYSTEM SHOULD BE CONSIDERED TO
CONTROL BUILDING PRESSURIZA­TION.

Clearance Requirements

The recommended clearances identified
with unit dimensions should be
maintained to assure adequate service
maximum capacity and peak operating
efficiency. Actual clearances which
appear inadequate should be reviewed
with the local Trane sales personnel.

Unit Pitch

These units have reversible sloped
condensate drain pans. Units must be
installed level, any unit slope must be
toward the side of unit where
condensate drain is connected.

Condensate Trap

The evaporator is a draw-thru
configuration. A trap must be field
provided prior to start-up on the cooling
cycle.

8

RT-PRC005-EN

Selection Procedure

Cooling Capacity

Step 1

Calculate the building’s total and sensible
cooling loads at design conditions. Use
the Trane calculation methods or any
other standard accepted method.

Factors used in unit selection:

A

Total Cooling Load: 59 MBh

B

Sensible Cooling Load: 40 MBh

C

Airflow: 2000 cfm

D

Electrical Characteristics: 460/60/3

E

Summer Design Conditions: Entering
Evaporator Coil: 80 DB, 67 WB Outdoor
Ambient: 95

F

External Static Pressure: 0.45 in. wg

Step 2

As a starting point, a rough
determination must be made of the size
of the unit. The final selection will be
made after examining the performance
at the given conditions. Divide the total
cooling load by nominal BTUH per ton
(12 MBh per ton); then round up to the
nearest unit size.

60 MBh / 12 MBh = 5 Tons

Step 3

Table PD-4 shows that a TSC060A4 has a
gross cooling capacity of 63.1 MBh and

48.2 MBh sensible capacity at 2000 cfm
and 95 DB outdoor ambient with 80 DB,
67 WB air entering the evaporator.

To Find Capacity at Intermediate
Conditions Not in the Table

When the design conditions are between
two numbers that are in the capacity
table, interpolation is required to
approximate the capacity. Note:
Extrapolation outside of the table
conditions is not recommended.

Step 4

In order to select the correct unit which
meets the building’s requirements, the
fan motor heat must be deducted from
the gross cooling capacity. The amount
of heat that the fan motor generates is
dependent on the effort by the motor ­cfm and static pressure. To determine the
total unit static pressure:

External Static (duct system)

0.45 wg

Standard Filter 1 in. 0.15 wg
from Table PD-59

Economizer 0.02 wg

(100% Return Air) from Table PD-26

Electric Heater Size 6 kW 0.05 wg
from Table PD-51

Total Static Pressure 0.67 wg

Note: The Evaporator Fan Performance
Table PD-20 has deducted the pressure
drop for a 1 in. filter already in the unit
(see note below Table PD-20). Therefore,
the actual total static pressure is 0.67 -

0.15 (from Table PD - 26) = 0.52 wg.

With 2000 cfm and 0.52 wg.
Table PD-20 shows .90 bhp for this unit.
Note below the table gives a formula to
calculate Fan Motor Heat,

4.39 x bhp = MBH.

4.39 x .90 = 3.95 MBH.

Now subtract the fan motor heat from
the gross cooling capacity of the unit:
Net Total Cooling Capacity
= 60 MBH - 3.95 = 56.05 MBH.

Net Sensible Cooling Capacity
= 48.2 MBH - 3.95 = 44.25 MBH.

Step 5

If the performance will not meet the
required load of the building’s total or
sensible cooling load, try a selection at
the next higher size unit.

Heating Capacity

Step 1

Calculate the building heating load
using the Trane calculation form or other
standard accepted method.

Step 2

Size the system heating capacity to
match the calculated building heating
load. The following are building heating
requirements:

A

Total heating load of 15 MBH

B

2000 cfm

C

460 volt/3 phase Power Supply

The electric heat accessory capacities
are listed in Table PD-62 From the table, a
6 kW heater will deliver 20.48 MBH at
480 volts. In order to determine capacity
at 460 volts, the heater voltage
correction factor from Table PD-60 must
be used. Therefore, 20.48 MBH x .9118
(voltage correction factor) = 18.80 MBH.

Air Delivery Selection

External static pressure drop through
the air distribution system has been
calculated to be 0.45 inches of water.
From Table PD-59 static pressure drop
through the economizer is 0.02 and the
6 kW heater is 0.05 inches of water (0.45
+ 0.02 + 0.05). Enter Table PD-20 for a
TSC060A4 at 2000 cfm and 0.52 static
pressure. The standard direct drive
motor at high speed will give the
desired airflow at a rated bhp of 0.90.

RT-PRC005-EN

9

Model Number Description

T S C 036 A 3 R B A ** C 0 0 0 A 1 0 0 0 1 A 1

1 2 3 4,5,6 7 8 9 10 11 12,13 14 15 16 17 18 19 20 21 22 23 24 25

DIGIT 1 - Unit Function

T = DX Cooling

DIGIT 2 - Efficiency

S = Standard Efficiency
H = High Efficiency

DIGIT 3 - Airflow

C = Convertible

DIGITS 4,5,6 - Nominal Gross Cooling
Capacity (MBh)

036 = 3 Ton
048 = 4 Ton
060 = 5 Ton
072 = 6 Ton
090 = 7½ Ton, Single Compressor
092 = 7½ Ton, Dual Compressor
102 = 8 ½ Ton
120 = 10 Ton

DIGIT 7 - Major Design Sequence

A =First

DIGIT 8 - Unit Voltage

1 = 208-230/60/1
3 = 208-230/60/3
4 = 460/60/3
W = 575/60/3
K = 380/60/3

DIGIT 9 - Unit Controls

E = Electromechanical
R = ReliaTel™Microprocessor

DIGIT 10 - Heating Capacity

0 = No Electric Heat
A = 5 kW (1 phase)
B = 6 kW (3 phase)
C = 9 kW (3 phase)
D = 10 kW (1 phase)
E = 12 kW (3 phase)
F = 14 kW (1 phase)
G = 18 kW (1 and 3 phase)
J = 23 kW (3 phase)
K = 27 kW (3 phase)
N = 36 kW (3 phase)
P = 54 kW (3 phase)

Example:Example:

Example:

Example:Example:
Model number TSC036A3RBA**C000A10001A1 describes a unit with the following characteristics: DX Cooling, 3 ton nominal cooling capacity, 208-230/60/3 power
supply, ReliaTel™ controls, 6 kW electric heater model. 0-100% dry bulb economizer without barometric relief, standard direct drive motor, standard access panels/
filters, standard condenser coil with no coil protection, through the base electric, non-fused disconnect, no convenience outlet or communications interface, standard
refrigeration coil, high pressure control, return air smoke detector, and clogged filter switch.

DIGIT 11 - Minor Design Sequence

A = First Sequence

DIGITS 12, 13 - Service Sequence

**= Factory Assigned

DIGIT 14 - Fresh Air Selection

0 = No Fresh Air
A = Manual Outside Air Damper 0-50%
B = Motorized Outside Air Damper 0-50%
C = Economizer, Dry Bulb 0-100%

without Barometric Relief

D = Economizer, Dry Bulb 0-100%

with Barometric Relief

E = Economizer, Reference Enthalpy

0-100% without Barometric Relief

F = Economizer, Reference Enthalpy

0-100% with Barometric Relief

G = Economizer, Comparative Enthalpy

0-100% without Barometric Relief

H = Economizer, Comparative Enthalpy

0-100% with Barometric Relief

DIGIT 15 - Supply Fan/Drive Type/Motor

0 = Standard Drive
1 = Oversized Motor
2 = Optional Belt Drive Motor

DIGIT 16 - Hinged Service Access/Filters

0 = Standard Panels/Standard Filters
A = Hinged Access Panels/Standard Filters
B = Standard Panels/2” Pleated Filters
C = Hinged Access Panels/2” Pleated Filters

DIGIT 17 - Condenser Coil Protection

0 = Standard Coil
1 = Standard Coil with Hail Guard
2 = Epoxy Coated Condenser Coil
3 = Epoxy Coated Condenser Coil with

Hail Guard

DIGIT 18 - Through the Base Provisions

0 = No Through the Base Provisions
A = Through the Base Electric

DIGIT 19 - Disconnect/Circuit Breaker

(3 phase only)

0 = No Disconnect or Circuit Breaker
1 = Non-Fused Disconnect
2 = Circuit Breaker

DIGIT 20 - Convenience Outlet

0 = No Convenience Outlet
A = Unpowered Convenience Outlet
B = Powered Convenience Outlet

(3 phase only)

DIGIT 21 - Communications Options

0 = No Communications Interface
1 = Trane Communications Interface
2 = LonTalk® Communications Interface
3 = Novar 2024 Controls
4 = Novar 3051 Controls

DIGIT 22 - Refrigeration System Option

0 = Standard Refrigeration System
A = Thermal Expansion Valve (TXV)
B = Dehumidification (Hot Gas Reheat Coil)

DIGIT 23 - Refrigeration Controls

0 = No Refrigeration Control
1 = High Pressure Control
2 = Frostat
3 = Crankcase Heater
4 = High Pressure Control and Frostat
5 = High Pressure Control and Crankcase

Heater
6 = Frostat and Crankcase Heater
7 = High Pressure Control, Frostat and

Crankcase Heater

DIGIT 24 - Smoke Detector

0 = No Smoke Detector
A = Return Air Smoke Detector
B = Supply Air Smoke Detector
C = Supply and Return Air Smoke

Detectors

DIGIT 25 - Monitoring Controls

0 = No Monitoring Control
1 = Clogged Filter Switch
2 = Fan Failure Switch
3 = Discharge Air Sensing Tube
4 = Clogged Filter Switch and Fan Fail

Switch
5 = Clogged Filter Switch and Discharge

Air Sensing Tube
6 = Fan Fail Switch and Discharge Air

Sensing Tube
7 = Clogged Filter and Fan Fail Switches

and Discharge Air Sensing Tube
8 = Novar Return Air Sensor

10

RT-PRC005-EN

General

(3 - 5 Ton)

Data

Standard Efficiency

Table GD - 1 — General Data

3 Ton Convertible Units 4 Ton Convertible Units 5 Ton Convertible Units

Cooling Performance

Gross Cooling Capacity 37,400 50,300 49,200 63,100 63,100 63,100

2

SEER
Nominal CFM / ARI Rated CFM 1,200/1,200 1,600/1,600 1,600/1,600 2,000/2,000 2,000/2,000 2,000/2,000
ARI Net Cooling Capacity 36,000 48,000 47,000 60,000 60,000 60,000
System Power (kW) 3.91

Compressor

No./Type 1/Recip. 1/Scroll 1/Scroll 1/Scroll 1/Scroll 1/Scroll

Outdoor Sound Rating (dB)

Outdoor Coil — Type Lanced Lanced Lanced Lanced Lanced Lanced

Tube Size (in.) O.D. 0.3125 0.3125 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 7.19 6.17 9.59 8.81 8.81 8.81
Rows/FPI 2/17 2/17 1/17 2/17 2/17 2/17

Indoor Coil — Type Lanced Lanced Lanced Lanced Lanced Lanced

Tube Size (in.) 0.3125 0.3125 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 5.67 6.68 6.17 5.00 5.00 5.00
Rows/FPI 2/16 3/16 3/16 3/16 3/16 3/16
Refrigerant Control Short Orifice Short Orifice Short Orifice Short Orifice Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT

Outdoor Fan — Type Propeller Propeller Propeller Propeller Propeller Propeller

No. Used/Diameter (in.) 1/22 1/22 1/22 1/22 1/22 1/22
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1 Direct/1 Direct/1
CFM 2550 2850 3610 3470 3470 3470
No. Motors/HP 1/.20 1/.33 1/.33 1/.33 1/.33 1/.40
Motor RPM 1115 1115 1115 1115 1115 1115

Direct Drive Indoor Fan — Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal

No. Used 1 1 1 1 1 1
Diameter x Width (in.) 10 x 10 11 x 11 11 x 11 11 x 11 11 x 11 12x11/–
Drive Type/No. Speeds Direct/2 Direct/2 Direct/2 Direct/2 Direct/2 Direct/2
No. Motors 1 1 1 1 1 1
Motor HP (Standard/Oversized) .33/.50 .60/.80 .60/.80 .90/1.00 .90/1.00 1.0/–
Motor RPM (Low/High Speed) 950/1060 930/1000 930/1000 985/1100 985/1100 935/1100
Oversized Motor RPM
(Low/High Speed) 1100/1145 1000/1100 1000/1100 1080/1135 1080/1135 —
Motor Frame Size
(Standard/Oversized) 48/48 48/48 48/48 48/48 48/48 48/—

Belt Drive Indoor Fan — Type FC Centrifugal — FC Centrifugal — FC Centrifugal —

No. Used 1 — 1 — 1 —
Diameter x Width (in.) 11 x 11 — 11 x 11 — 11 x 11 —
Drive Type/No. Speeds Belt/Variable Speed
No. Motors 1 — 1 — 1 —
Mo to r H P 1.0 0 — 1.0 0 — 1. 00 —
Motor RPM 1750 — 1750 — 1750 —
Motor Frame Size 56 — 56 — 56 —

Filters — Type Furnished

(No.) Size Recommended (in.) (2) 20 x 25 x 1 (2) 20 x 25 x 1 (2) 20 x 25 x 1 (2) 20 x 25 x 1 (2) 20 x 25 x 1 (2) 20 x 25 x 1

Refrigerant Charge (Lbs of R-22)

NOTES:

1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net
and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Certified in accordance with the Unitary Air-Conditioner Equipment
certification program, which is based on ARI Standard 210/240 except AK (380V/60 Hz).

2. SEER is rated at ARI conditions and in accordance with DOE test procedures.

3. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270. For more information refer to Table PD-51

4. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

5. TSC036A1 SEER is 10.5.

6. Belt Drive Motor is not available for TSC036A1.

7. Optional 2” Pleated Filters also available.

8. TSC036A1 System Power (kW) is 3.79.

1

TSC036A1, A3, A4, AW TSC048A1 TSC048A3, A4, AW TSC060A1 TSC060A3, A4, AW TSC060AK

5

10.7

8

3

7

4

83 86 82 84 84 84

6

Throwaway Throwaway Throwaway Throwaway Throwaway Throwaway

3.8 4.4 3.8 4.7 4.9 4.9

10.1 10.0 9.9 10.2 10.2

5.28 5.40 6.86 6.78 6.78

— Belt/Variable Speed — Belt/Variable Speed —

RT-PRC005-EN

11

General

(6 - 10 Ton)

Data

Standard Efficiency

Table GD - 2— General Data

6 To n 7 ½ To n 8 ½ To n 1 0 To n

Convertible Units Convertible Units Convertible Units Convertible Units

Cooling Performance

Gross Cooling Capacity 72,000 95,000 92,000 105,000 118,000

2

EER

1

Nominal CFM / ARI Rated CFM 2,400/2,100 3,000/2,625 3,000/2,625 3,400/3,000 4,000/3,200
ARI Net Cooling Capacity 69,000 90,000 87,000 100,000
Integrated Part Load Value (IPLV)
System Power (kW) 6.7 8.74 8.45 9.71

Compressor

No./Type 1/Scroll 1/Scroll 2/Scrolls 2/Scrolls 2/Scrolls

Outdoor Sound Rating (dB)
Outdoor Coil — Type Lanced Lanced Lanced Lanced Lanced

Tube Size (in.) O.D. 0.3125 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 13.88 17.00 17.00 19.83 25.92
Rows/FPI 2/17 3/17 2/17 2/17 2/17

Indoor Coil — Type Lanced Lanced Lanced Lanced Lanced

Tube Size (in.) 0.3125 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 9.89 9.89 9.89 12.36 12.36
Rows/FPI 2/16 3/16 3/16 3/16 4/16
Refrigerant Control Short Orifice Short Orifice Short Orifice Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT

Outdoor Fan — Type Propeller Propeller Propeller Propeller Propeller

No. Used/Diameter (in.) 1/26 1/26 1/26 1/26 1/26
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1 Direct/1
CFM 6100 6200 6500 7100 7000
No. Motors/HP 1/0.70
Motor RPM 111 5 111 5 111 5 111 5 111 5

Belt Drive Indoor Fan — Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal

No. Used 1 1 1 1 1
Diameter x Width (in.) 12 x 12 12 x 12 12 x 12 15 x 15 15 x 15
Drive Type/No. Speeds Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed
No. Motors 1 1 1 1 1
Motor HP (Standard/Oversized) 1.0 0/2.00
Motor RPM (Standard/Oversized) 1750 1750 1750 1750 1750/3450
Motor Frame Size 56 56 56 56 56

Filters — Type Furnished

10

(No.) Size Recommended (in.) (4) 16 x 25 x 2 (4) 16 x 25 x 2 (4) 16 x 25 x 2 (4) 20 x 25 x 2 (4) 20 x 25 x 2

Refrigerant Charge (Lbs of R-22)

NOTES:

1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net
and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Certified in accordance with the Unitary Air-Conditioner Equipment
certification program, which is based on ARI Standard 210/240 except AK (380V/60 Hz).

2. SEER is rated at ARI conditions and in accordance with DOE test procedures.

3. Integrated Part Load Value is rated in accordance with ARI Standard 210/240 or 360. Units are rated at 80°F ambient, 80°F entering dry bulb, and 67°F entering wet bulb ar ARI
rated cfm.

4. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270. For more information refer to Table PD-51.

5. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

6. EER shown is for downflow airflow. EER for horizontal airflow is 10.3.

7. ARI Net Cooling Capacity shown is for downflow airflow. Cooling Capacity for Horizontal airflow TSC102A is 99,000; TSC120A is 111,000.

8. Integrated Part Load Value (IPLV) shown is for downflow airflow. IPLV for Horizontal airflow TSC092A is 10.8, TSC102A is 11.5; TSC120A is 11.0.

9. System Power (kW) shown is for downflow airflow. System Power (kW) forHorizontal airflow TSC102A is 9.61; for TSC120A is 10.78.

10. Optional 2” Pleated Filters also available.

11. Outdoor motor is 0.75 hp for AK (380V/60 Hz units).

12. Standard indoor motor is 2.00 hp for AK (380V/60 Hz) units.

TSC072A3, A4, AW, AK TSC090A3,A4,AW, AK TSC092A3, A4, AW TSC102A3, A4, AW, AK TSC120A3, A4, AW, AK

10.3 10.3 10.3 10.3 10.4

3— —

4

88 90 87 86 86

11

12

1/0.70

2.00/3.00 2.00/3.00 2.00/3.00 3.00/5.00

8

11. 1

11

1/0.70 1/0.75 1/0.75

11. 9

7

8

9

Throwaway Throwaway Throwaway Throwaway Throwaway

5

7.1 11.9 6.2 Circuit 1 7.9 Circuit 1 8.4Circuit 1

3.4 Circuit 2 4.0 Circuit 2 6.6 Circuit 2

11 2 , 0 0 0

11. 5

10.77

6

7

8

9

12

RT-PRC005-EN

General

(3 - 5 Ton)

Data

High Efficiency

Table GD - 3 — General Data

3 To n 4 To n 5 To n

Convertible Units Convertible Units Convertible Units

Cooling Performance

Gross Cooling Capacity 38,000 49,800 62,100 62,400
SEER

/ EER

Nominal CFM / ARI Rated CFM 1,200/1,200 1,600/1,600 2,000/2,000 2,000/2,000
ARI Net Cooling Capacity 36,600 47,500 59,000 59,500
System Power (kW) 3.33 4.48 5.73 5.56

Compressor

No./Type 1/Climatuff Scroll 1/Climatuff Scroll 1/Climatuff Scroll 1/Climatuff Scroll

Outdoor Sound Rating (dB)
Outdoor Coil — Type Lanced Lanced Lanced Lanced

Tube Size (in.) O.D. 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 7.19 9.59 10.96 10.96
Rows/FPI 2/17 3/17 3/17 3/17

Indoor Coil — Type Lanced Lanced Lanced Lanced

Tube Size (in.) 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 6.68 6.68 7.71 7.71
Rows/FPI 3/16 4/16 4/16 4/16
Refrigerant Control Short Orifice Short Orifice Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT

Outdoor Fan — Type Propeller Propeller Propeller Propeller

No. Used/Diameter (in.) 1/22 1/22 1/22 1/22
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM 2550 3050 3170 3370
No. Motors/HP 1/.20 1/.33 1/.33 1/.33
Motor RPM 1115 111 5 111 5 111 5

Direct Drive Indoor Fan — Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal

No. Used 1 1 1 1
Diameter x Width (in.) 10 x 10 11 x 11 11 x 11 11 x 11
Drive Type/No. Speeds Direct/2 Direct/2 Direct/2 Direct/2
No. Motors 1 1 1 1
Motor HP (Standard/Oversized) .33/.50 .60/.80 .90/1.00 .90/1.00
Standard Motor RPM (Low/High Speed) 950/1060 930/1000 985/1100 985/1100
Oversized Motor RPM (Low/High Speed) 1100/1145 1000/1100 1080/1135 1080/1135
Motor Frame Size (Standard/Oversized) 48/48 48/48 48/48 48/48

Belt Drive Indoor Fan — Type FC Centrifugal FC Centrifugal — FC Centrifugal

No. Used 1 1 — 1
Diameter x Width (in.) 11 x 11 11 x 11 — 11 x 11
Drive Type/No. Speeds Belt/Variable Speed

No. Motors 1 1 — 1
Mo to r H P 1. 0 0 1.0 0 — 1.0 0
Standard Motor RPM 1750 1750 — 1750
Motor Frame Size 56 56 — 56

Filters — Type Furnished

(No.) Size Recommended (in.) (2) 20 x 25 x 1 (2) 20 x 25 x 1 (2) 20 x 30 x 1 (2) 20 x 30 x 1

Optional Hot Gas Reheat Coil - Type — — — Lanced

Tube Size (in.) OD — — — 0.375
Face Area (sq. ft) — — — 2.22
Rows/FPI — — — 2/18

Refrigerant Charge (Lbs of R-22)

Standard 5.3
Optional Hot Gas Reheat Coil — — — 10.7

NOTES:

1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is
net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Units are certified in accordance with the Unitary Air-Conditioner
Equipment certification program, which is based on ARI Standard 210/240.

2. EER and SEER are rated at ARI conditions and in accordance with DOE test procedures.

3. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270. For more information refer to Table PD-51

4. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

5. Refrigerant Charge shown is for 3 phase. 1 phase Refrigerant Charge is 8.1.

6. Belt Drive Motor is not available for THC036A1, THC048A1.

7. Optional 2” Pleated Filters also available.

8. Refrigerant Charge shown is for 3 phase. 1 phase Refrigerant Charge is 4.5.

9. TXV is supplied from the factory as standard with the Dehumidification (Hot Gas Reheat) option.

10. With Dehumidification (Hot Gas Reheat) option: Direct/2.

11. 2" pleated filters is a factory installed option. 2" pleated filters is standard with the Dehumidification (Hot Gas Reheat) option.

1

2

3

7

4

THC036A1,A3,A4,AW THC048A1,A3,A4,AW THC060A1 THC060A3,A4,AW

12.5/— 12.0/— 11.8/— 12.0/ —

83 85 84 84

10

6

Throwaway Throwaway Throwaway Throwaway

8

Belt/Variable Speed

7. 7

6

5

— Belt/Variable Speed

7.9 8.4

9

11

RT-PRC005-EN

13

General

(6 - 10 Ton)

Data

High Efficiency

Table GD - 4— General Data

6 To n 7½ To n 8 ½ To n 1 0 To n

Convertible Units Convertible Units Convertible Units Convertible Units

Cooling Performance

Gross Cooling Capacity 73,000 94,000 103,000 117,000

2

EER

1

Nominal CFM / ARI Rated CFM 2,400/2,100 3,000/2,625 3,400/3,000 4,000/3,200
ARI Net Cooling Capacity 70,000 90,000
Integrated Part Load Value (IPLV)
System Power (kW) 6.09

Compressor

No./Type 1/Climatuff Scroll 2/Climatuff Scrolls 2/Climatuff Scrolls 2/Climatuff Scrolls

Outdoor Sound Rating (dB)

4

Outdoor Coil — Type Lanced Lanced Lanced Lanced

Tube Size (in.) O.D. 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 17.00 17.50 19.83 27.21
Rows/FPI 3/17 3/17 3/17 3/17

Indoor Coil — Type Lanced Lanced Lanced Lanced

Tube Size (in.) 0.3125 0.3125 0.3125 0.3125
Face Area (sq ft) 9.89 12.36 12.36 12.36
Rows/FPI 3/16 3/16 4/16 5/16
Refrigerant Control Short Orifice Short Orifice Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/¾ NPT 1/¾ NPT 1/¾ NPT 1/¾ NPT

Outdoor Fan — Type Propeller Propeller Propeller Propeller

No. Used/Diameter (in.) 1/26 1/26 1/26 1/26
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM 6100 6200 6600 7000
No. Motors/HP 1/0.70 1/0.70 1/0.75 1/0.75
Motor RPM 1075 1075 1075 1075

Belt Drive Indoor Fan — Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal

No. Used 1 1 1 1
Diameter x Width (in.) 12 x 12 15 x 15 15 x 15 15 x 15
Drive Type/No. Speeds Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed Belt/Variable Speed
No. Motors 1 1 1 1
Motor HP (Standard/Oversized) 1.00/2.00 2.00/3.00 2.00/3.00 3.00/5.00
Motor RPM (Standard/Oversized) 1750 1750 1750 1750/3450
Motor Frame Size 56 56 56 56

Filters — Type Furnished

9

(No.) Size Recommended (in.) (4) 16 x 25 x 2 (4) 20 x 25 x 2 (4) 20 x 25 x 2 (4) 20 x 25 x 2

Optional Hot Gas Reheat Coil — Type — — — Lanced

Tube Size (in.) OD — — — 0.375
Face Area (sq. ft.) — — — 5.19
Rows/FPI — — — 2/16

Refrigerant Charge (Lbs of R-22)

NOTES:

1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is
net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Certified in accordance with the Unitary Air-Conditioner Equipment
certification program, which is based on ARI Standard 210/240.

2. SEER is rated at ARI conditions and in accordance with DOE test procedures.

3. Integrated Part Load Value is rated in accordance with ARI Standard 210/240 or 360. Units are rated at 80°F ambient, 80°F entering dry bulb, and 67°F entering wet bulb ar
ARI rated cfm.

4. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270. For more information refer to Table PD-51.

5. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

6. EER shown is for downflow airflow. EER for horizontal airflow: THC072A - 11.3, THC092A and THC102A - 11.3, THC120A - 10.7.

7. System Power (kW) shown is for downflow airflow. System Power (kW) for horizontal airflow: THC072A - 6.2, THC092A - 7.88, THC102A - 8.58, THC120A - 10.09.

8. Integrated Part Load Value (IPLV) shown is for downflow airflow. IPLV for horizontal airflow: THC092A - 11.5, THC102A - 11.6, THC120A - 11.5.

9. Optional 2” Pleated Filters also available.

10. Net Cooling Capacity shown is for downflow airflow. Net Cooling for horizontal airflow: THC092A - 89,000, THC102A - 97,000, THC120A - 108,000.

5

THC072A3, A4, AW THC092A3, A4, AW THC102A3, A4. AW THC120A3, A4, AW

6

11. 5

3—

7

11. 5

11. 9

7. 8 3

6

10

8

7

11. 5

98,000

12.1

8.52

6

10

8

7

89 91 89 88

Throwaway Throwaway Throwaway Throwaway

10.7 6.4 Circuit 1 7.4 Circuit 1 11.0 Circuit 1

6.2 Circuit 2 7.1Circuit 2 7.3Circuit 2

11. 2

109,000

12.0

9.73

6

10

8

7

14

RT-PRC005-EN

Performance

(3, 4 Ton)

Data

Standard Efficiency

Table PD-1 — Gross Cooling Capacities (MBH) 3 Ton Single/Three Phase TSC036A1, A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1080

1200

1320

1440

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 34.6 29.0 38.6 22.3 40.6 14.7 31.2 27.3 36.6 21.1 39.5 13.8 28.2 25.6 33.4 19.6 37.8 12.9 25.1 24.1 29.6 18.2 35.5 11.9
80 35.6 35.0 38.8 27.3 41.0 20.2 32.6 32.6 36.8 26.6 39.8 19.5 30.0 30.0 33.5 25.2 38.0 18.5 27.3 27.3 29.9 23.5 35.6 17.5
85 37.6 37.6 39.2 32.5 41.5 24.7 35.6 35.6 37.2 32.2 40.1 24.2 32.8 32.8 34.2 31.0 38.2 23.8 30.1 30.1 30.7 29.3 35.8 23.0
90 39.3 39.3 39.7 37.6 42.0 29.2 37.8 37.8 37.9 37.6 40.4 29.1 35.7 35.7 35.7 35.7 38.5 28.9 33.0 33.0 32.9 32.9 36.0 28.4

75 35.6 30.9 39.0 22.8 40.9 14.9 32.2 29.2 37.3 22.1 39.8 14.1 29.0 27.5 34.3 20.7 38.2 13.1 25.9 25.9 30.4 19.0 36.0 12.1
80 36.7 36.7 39.3 28.4 41.4 20.6 34.3 34.3 37.4 28.1 40.2 20.3 31.4 31.4 34.5 26.9 38.4 19.3 28.6 28.6 30.7 25.2 36.1 18.3
85 38.7 38.7 39.7 33.9 41.9 25.3 37.0 37.0 37.9 34.0 40.5 25.0 34.5 34.5 35.3 33.2 38.7 24.8 31.5 31.5 31.7 31.6 36.3 24.2
90 40.2 40.2 40.4 39.2 42.3 30.1 38.8 38.8 38.8 38.8 40.9 30.2 37.1 37.1 37.0 37.0 39.1 30.3 34.6 34.6 34.6 34.6 36.6 30.0

75 36.4 32.6 39.4 23.5 41.1 15.1 33.2 31.0 37.7 23.0 40.1 14.3 29.8 29.3 34.9 21.8 38.5 13.4 26.8 26.8 30.9 20.0 36.3 12.4
80 37.7 37.7 39.7 29.4 41.6 20.9 35.7 35.7 37.9 29.3 40.4 21.2 32.7 32.7 35.2 28.5 38.7 19.9 29.8 29.8 31.4 26.8 36.5 19.0
85 39.4 39.4 40.2 35.2 42.1 25.9 37.9 37.9 38.5 35.6 40.8 25.7 35.9 35.9 36.2 35.3 39.1 25.7 32.9 32.9 32.9 32.9 36.7 25.3
90 40.8 40.8 40.9 40.5 42.6 30.8 39.7 39.7 39.6 39.6 41.2 31.2 38.0 38.0 38.0 38.0 39.5 31.6 35.9 35.9 35.9 35.9 37.1 31.5
75 37.0 34.1 39.7 24.0 41.3 15.3 34.1 32.8 38.0 23.7 40.3 14.5 30.6 30.6 35.5 22.7 38.7 13.6 27.7 27.7 31.4 21.0 36.6 12.6
80 38.4 38.4 40.0 30.3 41.8 21.2 36.7 36.7 38.3 30.5 40.8 21.0 33.9 33.9 35.8 30.0 39.0 20.4 30.8 30.8 32.0 28.4 36.8 19.7
85 40.0 40.0 40.6 36.3 42.4 26.4 38.7 38.7 39.0 37.0 41.2 26.7 36.8 36.8 36.8 36.8 39.4 26.6 34.2 34.2 34.2 34.2 37.0 26.4
90 41.4 41.4 41.4 41.4 42.9 31.6 40.3 40.3 40.3 40.3 41.5 32.1 38.7 38.7 38.7 38.7 39.9 32.7 36.7 36.7 36.7 36.7 37.6 33.0

85 95 105 115

Ambient Temperature (F)

Table PD-2 — Gross Cooling Capacities (MBH) 4 Ton Single Phase TSC048A1

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1440

1600

1760

1920

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 45.5 38.7 52.4 30.0 56.4 20.1 41.6 36.6 49.0 28.3 54.4 18.9 37.6 34.5 44.4 26.7 51.8 17.5 33.5 32.3 39.8 24.5 48.0 15.8
80 46.5 46.5 52.5 37.6 56.8 28.1 43.2 43.2 49.1 35.9 54.8 26.7 39.9 39.9 44.6 33.8 52.0 25.2 36.5 36.5 40.1 31.6 48.2 23.4
85 50.3 50.3 53.0 45.1 57.4 34.9 47.0 47.0 49.7 43.7 55.0 33.9 43.6 43.6 45.3 41.6 52.2 32.8 40.2 40.2 41.0 39.5 48.3 31.0
90 53.3 53.3 53.8 52.5 57.7 41.1 50.8 50.8 50.8 50.8 55.5 41.0 47.5 47.5 47.5 47.5 52.5 40.1 44.0 44.0 44.0 44.0 48.6 38.6
75 46.8 41.3 53.1 31.3 56.9 20.5 42.7 39.1 50.1 29.7 55.0 19.2 38.7 37.0 45.4 27.5 52.4 17.9 34.4 34.4 40.8 25.4 48.9 16.3
80 48.7 48.7 53.4 39.5 57.5 28.9 45.2 45.2 50.3 38.2 55.4 27.8 41.8 41.8 45.7 36.0 52.7 26.3 38.2 38.2 41.1 33.9 49.1 24.7
85 52.2 52.2 53.9 47.5 58.1 36.1 49.3 49.3 51.0 46.7 55.7 35.3 45.7 45.7 46.7 44.7 52.9 34.5 42.1 42.1 42.1 42.1 49.2 33.0
90 54.9 54.9 54.9 54.9 58.4 42.8 52.7 52.7 52.7 52.7 56.2 42.9 49.8 49.8 49.8 49.8 53.3 42.5 46.2 46.2 46.2 46.2 49.7 41.3

75 48.1 43.8 53.6 32.5 57.3 20.8 43.8 41.6 50.8 31.1 55.5 19.6 39.8 39.5 46.3 29.0 52.9 18.2 35.8 35.8 41.5 26.7 49.6 16.7
80 50.5 50.5 54.0 41.2 58.0 29.6 47.1 47.1 51.1 40.3 55.9 29.0 43.4 43.4 46.7 38.2 53.2 27.4 39.8 39.8 42.0 36.0 49.7 25.8
85 53.6 53.6 54.8 49.8 58.6 37.1 51.1 51.1 52.0 49.4 56.3 36.6 47.7 47.7 48.1 47.9 53.5 36.1 43.9 43.9 43.9 43.9 49.9 34.9
90 56.1 56.1 56.1 56.1 59.0 44.2 54.2 54.2 54.1 54.1 56.9 44.8 51.5 51.5 51.5 51.5 54.1 44.7 48.2 48.2 48.2 48.2 50.5 43.9

75 49.1 46.3 54.2 33.5 57.7 21.2 44.9 44.0 51.5 32.4 55.9 20.0 40.7 40.7 47.1 30.4 53.3 18.6 37.0 37.0 42.2 28.1 50.1 17.0
80 51.9 51.9 54.6 42.7 58.4 30.1 48.8 48.8 51.8 42.2 56.3 30.2 45.0 45.0 47.7 40.4 53.7 28.5 41.2 41.2 42.9 38.2 50.3 26.9
85 54.7 54.7 55.5 51.8 59.1 38.1 52.5 52.5 52.9 51.8 56.8 37.8 49.4 49.4 49.4 49.4 54.1 37.6 45.5 45.5 45.5 45.5 50.5 36.6
90 57.1 57.1 57.1 57.1 59.4 45.6 55.3 55.3 55.3 55.3 57.4 46.4 52.8 52.8 52.8 52.8 54.7 46.7 49.8 49.8 49.8 49.8 51.3 46.2

85 95 105 115

Ambient Temperature (F)

RT-PRC005-EN

15

Performance

(4, 5 Ton)

Data

Standard Efficiency

Table PD-3 — Gross Cooling Capacities (MBH) 4 Ton Three Phase TSC048A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1440 85 49.6 49.6 52.0 44.8 56.7 34.8 46.8 46.8 48.9 43.6 54.2 34.0 43.6 43.6 45.1 41.8 51.2 32.7 40.3 40.3 41.0 39.8 47.4 31.1

1600 85 51.4 51.4 53.0 47.3 57.7 36.7 48.7 48.7 50.0 46.4 55.0 35.5 45.6 45.6 46.3 44.8 51.9 34.6 42.1 42.1 42.1 42.1 48.2 33.0

1760 85 52.8 52.8 53.8 49.7 58.1 37.7 50.3 50.3 51.0 49.1 55.6 37.0 47.2 47.2 47.2 47.2 52.5 36.1 43.7 43.7 43.7 43.7 48.9 34.9

1920 85 53.9 53.9 54.6 51.8 58.6 38.7 51.6 51.6 51.9 51.5 56.2 38.4 48.6 48.6 48.6 48.6 53.1 37.7 45.2 45.2 45.2 45.2 49.4 36.6

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 44.8 38.6 51.4 29.8 56.1 20.1 41.0 36.6 48.2 28.2 53.7 18.9 37.3 34.7 44.2 26.4 50.8 17.6 33.4 32.7 39.6 25.2 47.1 16.0
80 46.0 46.0 51.6 37.4 56.5 27.9 42.9 42.9 48.3 35.8 54.0 26.6 39.7 39.7 44.4 34.0 51.0 25.2 36.4 36.4 40.0 32.0 47.2 23.6

90 52.5 52.5 52.9 52.2 57.2 41.6 50.2 50.2 50.1 50.1 54.6 41.1 47.2 47.2 47.2 47.2 51.5 40.1 43.9 43.9 43.9 43.9 47.7 38.6
75 46.1 41.1 52.1 31.1 56.7 20.5 42.1 39.0 49.1 29.6 54.4 19.3 38.3 37.1 45.1 27.8 51.5 18.0 34.3 34.3 40.6 25.7 47.9 16.5
80 48.1 48.1 52.4 39.3 57.2 29.0 44.9 44.9 49.2 37.9 54.7 27.7 41.5 41.5 45.4 36.2 51.7 26.3 38.1 38.1 41.0 34.2 48.0 24.8

90 54.2 54.2 54.2 54.2 58.0 43.5 51.9 51.9 51.9 51.9 55.4 43.2 49.1 49.1 49.1 49.1 52.3 42.5 45.9 45.9 45.9 45.9 48.7 41.3
75 47.2 43.5 52.8 32.3 57.3 20.9 43.3 41.5 49.8 30.9 54.9 19.7 39.1 39.1 45.8 29.1 52.0 18.3 35.6 35.6 41.3 27.1 48.5 16.8
80 49.7 49.7 53.1 41.0 57.8 30.1 46.7 46.7 50.1 40.0 55.3 28.8 43.3 43.3 46.2 38.3 52.3 27.4 39.7 39.7 41.8 36.3 48.7 25.9

90 55.5 55.5 55.5 55.5 58.7 45.3 53.4 53.4 53.4 53.4 56.1 45.2 50.7 50.7 50.7 50.7 53.1 44.7 47.6 47.6 47.6 47.6 49.5 43.8
75 48.2 45.8 53.3 33.4 57.8 21.3 44.4 43.8 50.4 32.1 55.4 20.0 40.3 40.3 46.5 30.4 52.5 18.6 36.6 36.6 41.9 28.3 49.0 17.2
80 51.0 51.0 53.7 42.7 58.3 31.1 48.1 48.1 50.7 41.9 55.7 29.6 44.7 44.7 47.0 40.3 52.8 28.4 41.1 41.1 42.6 38.3 49.2 26.9

90 56.6 56.6 56.6 56.6 59.3 47.0 54.6 54.6 54.5 54.5 56.8 47.1 52.0 52.0 52.0 52.0 53.8 46.9 49.0 49.0 49.0 49.0 50.3 46.1

85 95 105 115

Ambient Temperature (F)

Table PD-4 — Gross Cooling Capacities (MBH) 5 Ton Single/Three Phase TSC060A1, A3, A4, AW, AK

Enter.

CFMBulb6 16773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1800

2000

2200

2400

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 57.4 49.1 64.8 37.9 69.2 25.3 53.3 47.0 61.8 36.3 67.2 24.1 49.4 45.0 57.6 34.3 64.3 22.8 45.2 42.9 52.4 32.7 60.6 21.2
80 59.0 59.0 65.1 47.1 69.8 35.0 55.6 55.6 62.0 45.7 67.6 33.8 52.2 52.2 57.8 43.9 64.6 32.3 48.6 48.6 52.8 41.6 60.8 30.6
85 63.1 63.1 65.7 56.2 70.2 42.9 60.3 60.3 62.7 55.3 68.0 42.3 56.8 56.8 58.9 53.6 64.9 41.3 52.9 52.9 54.0 51.4 61.0 39.9
90 66.4 66.4 66.9 65.2 70.8 51.0 64.1 64.1 64.1 64.1 68.5 50.8 61.1 61.1 61.1 61.1 65.4 50.1 57.5 57.5 57.5 57.5 61.5 49.0
75 59.0 52.2 65.7 39.4 69.8 25.7 54.9 50.1 62.8 37.9 67.8 24.6 50.7 48.0 58.9 36.1 64.9 23.2 46.5 45.9 53.5 33.8 61.3 21.6
80 61.3 61.3 66.0 49.2 70.2 35.6 58.1 58.1 63.1 48.2 68.1 34.8 54.4 54.4 59.2 46.6 65.3 33.7 50.6 50.6 54.0 44.3 61.5 32.0
85 65.1 65.1 66.8 59.1 70.9 44.2 62.5 62.5 64.0 58.5 68.7 43.8 59.3 59.3 60.4 57.3 65.7 43.1 55.2 55.2 55.8 55.2 61.8 41.9
90 68.1 68.1 68.0 68.0 71.6 52.9 65.9 65.9 65.9 65.9 69.4 52.9 63.1 63.1 63.1 63.1 66.3 52.5 59.7 59.7 59.7 59.7 62.4 51.7
75 60.3 55.2 66.3 40.6 70.2 26.1 56.3 53.1 63.6 39.5 68.2 25.0 52.0 51.0 59.9 37.8 65.4 23.6 47.7 47.7 54.5 35.4 61.8 22.0
80 63.1 63.1 66.8 51.2 70.8 37.9 60.2 60.2 64.0 50.5 68.7 35.6 56.5 56.5 60.3 49.1 65.8 34.6 52.4 52.4 55.2 46.9 62.1 33.3
85 66.5 66.5 67.7 61.6 71.5 45.4 64.2 64.2 65.0 61.3 69.4 45.2 61.2 61.2 61.7 60.5 66.4 44.7 57.3 57.3 57.3 57.3 62.5 43.8
90 69.4 69.4 69.3 69.3 72.2 54.6 67.3 67.3 67.3 67.3 70.1 54.9 64.6 64.6 64.6 64.6 67.1 54.8 61.2 61.2 61.2 61.2 63.2 54.2
75 61.5 58.0 66.9 41.8 70.6 26.5 57.6 56.0 64.2 40.8 68.6 25.4 53.0 53.0 60.6 39.3 65.9 24.0 49.1 49.1 55.4 37.1 62.2 22.4
80 64.5 64.5 67.5 53.0 71.2 38.8 61.8 61.8 64.7 52.5 69.1 36.4 58.3 58.3 61.1 51.4 66.3 35.5 53.9 53.9 56.3 49.5 62.5 34.3
85 67.7 67.7 68.5 63.9 72.0 46.5 65.4 65.4 65.9 63.9 69.9 46.5 62.5 62.5 62.5 62.5 66.9 46.2 58.9 58.9 58.9 58.9 63.0 45.5
90 70.4 70.4 70.4 70.4 72.8 56.1 68.4 68.4 68.4 68.4 70.6 56.6 65.8 65.8 65.8 65.8 67.7 56.8 62.4 62.4 62.4 62.4 63.9 56.5

85 95 105 115

Ambient Temperature (F)

16

RT-PRC005-EN

Performance

(6, 7½ Ton)

Data

Standard Efficiency

Table PD-5 — Gross Cooling Capacities (MBH) 6 Ton Three Phase TSC072A3, A4, AW, AK

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

2160

2400

2640

2880

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 65.9 55.0 73.4 43.5 76.7 28.3 61.0 52.5 70.7 40.9 75.4 27.3 56.3 50.1 66.3 38.8 73.2 26.0 51.7 47.7 60.9 36.4 70.3 24.6
80 67.6 66.2 73.7 52.2 77.5 38.9 63.2 63.2 70.9 51.1 76.0 37.8 59.2 59.2 66.4 49.1 73.7 36.4 55.3 55.3 61.0 46.6 70.6 34.9
85 71.4 71.4 74.2 61.9 78.6 47.4 68.5 68.5 71.4 61.3 76.5 46.6 64.4 64.4 67.3 59.7 74.0 46.0 60.4 60.4 62.2 57.3 70.8 45.0
90 74.6 74.6 75.3 71.3 79.3 55.7 72.4 72.4 72.8 71.3 77.2 55.5 69.5 69.5 69.5 69.5 74.6 55.4 65.7 65.7 65.6 65.6 71.2 54.8
75 67.7 58.3 74.0 43.8 77.1 28.7 62.9 55.9 71.7 42.6 75.9 27.7 57.9 53.4 67.9 40.8 73.7 26.4 53.2 51.0 62.4 38.3 70.9 25.0
80 69.7 69.7 74.6 54.1 78.0 39.5 66.2 66.2 72.0 53.6 76.6 39.2 61.8 61.8 68.0 52.0 74.3 37.9 57.8 57.8 62.6 49.6 71.3 36.3
85 73.4 73.4 75.3 64.5 79.0 48.2 70.9 70.9 72.7 64.5 77.2 47.9 67.4 67.4 69.1 63.6 74.8 47.6 63.2 63.2 64.2 61.4 71.7 47.0
90 76.2 76.2 76.5 74.3 79.9 57.1 74.3 74.3 74.3 74.3 77.9 57.4 71.7 71.7 71.7 71.7 75.5 57.7 68.5 68.5 68.4 68.4 72.2 57.5
75 69.1 61.4 74.7 44.9 77.4 29.0 64.5 59.1 72.5 44.3 76.2 28.1 59.4 56.6 69.0 42.5 74.2 26.9 54.7 54.2 63.6 40.1 71.3 25.4
80 71.6 71.6 75.3 55.8 78.4 40.0 68.6 68.6 72.8 55.8 77.0 41.1 64.2 64.2 69.1 54.7 74.6 38.6 60.0 60.0 63.9 52.4 71.9 37.7
85 74.8 74.8 76.1 66.8 79.4 49.1 72.7 72.7 73.8 67.3 77.8 49.3 69.7 69.7 70.5 66.9 75.4 49.1 65.7 65.7 66.1 65.4 72.3 48.7
90 77.4 77.4 77.5 76.8 80.3 58.4 75.8 75.8 75.8 75.8 78.5 59.0 73.4 73.4 73.3 73.3 76.2 59.7 70.5 70.5 70.5 70.5 73.0 59.8
75 70.2 64.1 75.2 45.8 77.6 29.4 66.1 62.3 73.1 45.4 76.5 28.5 60.9 59.7 69.8 44.2 74.5 27.3 56.2 56.2 64.7 41.9 71.7 25.8
80 72.9 72.9 75.9 57.4 78.7 40.4 70.3 70.3 73.6 57.8 77.3 41.8 66.5 66.5 70.1 57.1 75.2 41.1 62.0 62.0 65.2 55.2 72.1 38.5
85 75.9 75.9 76.8 68.8 79.7 49.9 74.0 74.0 74.7 69.8 78.5 50.6 71.3 71.3 71.6 69.8 75.9 50.4 67.8 67.8 67.7 67.7 72.9 50.1
90 78.3 78.3 78.3 78.3 80.7 59.6 76.8 76.8 76.8 76.8 79.0 60.5 74.6 74.6 74.6 74.6 76.7 61.6 71.9 71.9 71.9 71.9 73.7 61.9

85 95 105 115

Ambient Temperature (F)

Table PD-6 — Gross Cooling Capacities (MBH) 7½ Ton Three Phase Single Compressor TSC090A3, A4, AW, AK

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

2700

3000

3300

3600

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 87.4 73.8 96.2 56.7 98.8 36.7 80.6 70.3 93.3 54.3 98.8 35.6 73.5 66.6 86.9 51.2 96.8 33.9 66.6 63.1 78.4 48.2 92.8 31.8
80 89.6 88.9 96.6 68.7 100.0 49.9 83.4 83.4 93.5 68.3 99.9 50.2 77.6 77.6 87.2 65.3 97.4 48.2 71.6 71.6 78.9 61.5 92.9 46.0
85 94.2 94.2 97.5 81.6 101.2 60.4 90.4 90.4 94.4 82.2 100.9 61.9 84.8 84.8 88.5 79.8 97.8 61.4 78.5 78.5 80.7 76.2 93.2 59.9
90 98.0 98.0 98.7 93.9 102.3 71.0 95.8 95.8 96.2 95.8 101.2 72.9 91.6 91.6 91.6 91.6 98.5 74.3 86.0 86.0 86.0 86.0 93.7 73.5
75 89.7 78.4 96.7 57.3 99.1 37.2 83.0 75.0 94.6 56.7 99.2 36.1 75.8 71.3 88.9 53.9 97.5 34.5 68.7 67.7 80.3 50.1 93.8 32.5
80 92.2 92.2 97.5 70.9 100.3 50.4 87.4 87.4 95.0 71.8 100.4 50.9 81.4 81.4 89.3 69.5 98.3 50.3 75.0 75.0 81.1 65.8 94.1 48.1
85 96.5 96.5 98.5 84.4 101.5 61.2 93.8 93.8 96.1 86.6 101.6 63.4 88.9 88.9 91.0 85.5 98.8 63.7 82.5 82.5 83.7 82.1 94.4 63.1
90 99.5 99.5 99.9 97.0 102.6 72.3 98.2 98.2 98.2 98.2 101.9 75.0 94.9 94.9 94.9 94.9 99.7 77.4 90.1 90.1 90.0 90.0 95.3 77.7

75 91.5 82.5 97.7 59.0 99.3 37.7 85.2 79.6 95.5 58.8 99.5 36.6 78.0 76.0 90.5 56.5 98.0 35.1 70.5 70.5 82.1 52.8 94.5 33.2
80 94.4 94.4 98.1 72.8 100.5 55.0 90.7 90.7 96.2 74.8 100.8 51.6 84.7 84.7 91.1 73.5 98.9 51.5 78.0 78.0 83.2 70.0 95.0 50.1
85 98.0 98.0 99.2 86.8 101.7 62.0 96.1 96.1 97.5 90.5 102.0 64.7 92.0 92.0 93.1 90.6 99.5 65.6 86.2 86.2 86.2 86.2 95.4 65.8
90 100.5 100.5 100.7 99.4 102.8 73.4 99.9 99.9 99.9 99.9 102.4 76.8 97.2 97.2 97.2 97.2 100.5 80.1 93.0 93.0 93.0 93.0 96.5 81.4

75 92.9 86.2 98.1 59.9 99.4 38.2 87.3 84.1 96.3 60.6 99.8 37.2 79.6 79.6 91.7 58.9 98.3 35.7 72.9 72.9 83.7 55.4 95.1 33.8
80 96.0 96.0 98.6 74.3 100.7 56.8 93.1 93.1 97.1 77.5 101.0 55.7 87.6 87.6 92.5 77.2 99.5 52.7 80.7 80.7 85.1 74.1 95.5 51.6
85 99.0 99.0 99.7 88.7 101.8 62.7 97.8 97.8 98.6 93.7 102.3 65.8 94.4 94.4 94.4 94.4 100.0 67.3 89.1 89.1 89.1 89.1 96.3 68.3
90 101.1 101.1 101.1 101.1 103.0 74.4 101.0 101.0 101.0 101.0 102.8 78.4 98.9 98.9 98.9 98.9 101.2 82.4 95.1 95.1 95.1 95.1 97.5 84.6

85 95 105 115

Ambient Temperature (F)

RT-PRC005-EN

17

Performance

(7½, 8½ Ton)

Data

Standard Efficiency

Table PD-7 — Gross Cooling Capacities (MBH) 7½ Ton Three Phase Dual Compressors TSC092A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

2700

3000

3300

3600

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 84.6 72.9 93.9 55.3 98.4 36.4 78.2 69.6 90.1 53.3 96.9 35.1 71.8 66.3 83.9 50.4 94.0 33.3 65.3 63.1 76.5 47.1 89.4 31.2
80 86.8 86.8 94.4 68.5 99.6 50.0 81.8 81.8 90.5 67.5 98.0 49.7 76.4 76.4 84.3 64.7 94.5 47.5 70.9 70.9 77.1 61.4 89.6 45.3
85 92.2 92.2 95.4 81.7 100.8 61.3 88.4 88.4 91.5 81.5 99.0 62.4 83.2 83.2 85.8 79.3 94.9 60.9 77.6 77.6 79.0 76.1 89.9 59.3
90 96.3 96.3 96.9 94.4 102.0 72.8 93.6 93.6 93.6 93.6 99.3 73.4 89.6 89.6 89.6 89.6 95.8 74.0 84.5 84.5 84.5 84.5 90.6 73.0
75 86.8 77.5 94.7 57.0 98.9 37.1 80.5 74.4 91.5 55.8 97.6 35.7 74.0 71.1 85.6 53.1 94.8 34.0 67.1 67.1 78.2 49.8 90.5 31.9
80 90.1 90.1 95.6 71.2 100.2 50.8 85.4 85.4 92.0 71.1 98.7 50.7 79.9 79.9 86.3 68.9 95.5 49.6 74.1 74.1 79.1 65.7 90.8 47.4
85 94.7 94.7 96.8 85.3 101.4 62.7 91.5 91.5 93.3 86.2 99.7 63.7 86.9 86.9 88.2 84.9 96.1 63.5 81.3 81.3 81.2 81.2 91.2 62.6
90 98.3 98.3 98.3 98.3 102.7 74.8 96.2 96.2 96.1 96.1 100.3 76.2 92.7 92.7 92.7 92.7 97.1 77.5 88.0 88.0 88.0 88.0 92.2 77.4
75 88.7 81.9 95.7 58.9 99.3 37.6 82.6 79.0 92.5 58.2 98.1 36.2 75.5 75.5 87.1 55.7 95.4 34.6 69.6 69.6 79.6 52.4 91.3 32.5
80 92.3 92.3 96.5 73.7 100.7 51.5 88.4 88.4 93.2 74.4 99.3 51.7 82.9 82.9 87.9 72.8 96.1 51.0 76.9 76.9 80.8 69.8 91.7 49.5
85 96.5 96.5 97.8 88.4 102.0 63.9 93.8 93.8 94.8 90.3 100.0 65.0 89.8 89.8 89.8 89.8 96.9 65.8 84.4 84.4 84.4 84.4 92.3 65.5
90 99.7 99.7 99.7 99.7 103.3 76.5 98.0 98.0 98.0 98.0 101.1 78.5 94.9 94.9 94.9 94.9 98.1 80.6 90.7 90.7 90.7 90.7 93.5 81.3
75 90.2 85.7 96.4 60.6 99.7 38.1 84.6 83.6 93.3 60.0 98.5 36.8 77.9 77.9 88.2 58.1 96.0 35.2 71.8 71.8 80.9 55.0 92.0 33.2
80 94.0 94.0 97.2 75.8 101.0 52.1 90.7 90.7 94.3 77.4 99.7 52.6 85.6 85.6 89.2 76.6 96.6 52.0 79.5 79.5 82.3 73.8 92.5 51.5
85 97.8 97.8 98.7 91.1 102.4 65.0 95.6 95.6 96.1 93.9 100.5 66.3 91.9 91.9 91.9 91.9 97.6 67.9 86.9 86.9 86.9 86.9 93.1 68.2
90 100.8 100.8 100.8 100.8 103.7 78.1 99.3 99.3 99.3 99.3 101.7 80.7 96.6 96.6 96.6 96.6 98.9 83.4 92.7 92.7 92.7 92.7 94.6 84.9

85 95 105 115

Ambient Temperature (F)

Table PD-8 — Gross Cooling Capacities (MBH) 8½ Ton Three Phase TSC102A3, A4, AW, AK

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

3060

3400

3740

4080

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 96.3 82.3 106.6 62.7 112.5 41.5 89.0 78.5 103.2 60.6 110.9 40.0 81.8 74.9 96.6 57.5 107.6 38.1 74.9 71.3 87.6 55.2 102.5 35.8
80 98.0 98.0 107.2 77.1 113.7 57.0 92.9 91.4 103.4 76.3 111.5 57.1 86.3 86.2 96.9 73.3 108.2 54.0 80.2 80.2 88.1 69.4 102.8 51.5
85 103.9 103.9 108.1 91.7 114.8 69.6 100.1 100.1 104.3 91.7 112.4 70.0 94.3 94.3 98.3 89.5 108.6 68.9 87.6 87.6 89.9 85.7 103.1 67.1
90 108.6 108.6 109.6 105.7 116.0 82.4 105.9 105.9 105.9 105.9 113.2 83.0 101.6 101.6 101.9 100.2 109.3 83.4 95.6 95.6 95.6 95.5 103.6 82.3
75 98.7 87.2 107.8 65.9 113.0 42.0 91.8 83.8 104.7 63.7 111.8 40.7 84.2 80.0 98.7 60.5 108.6 38.9 76.3 76.3 89.6 58.6 103.7 36.5
80 101.6 100.0 108.5 80.1 114.6 58.1 96.9 96.5 105.0 80.1 112.8 57.8 90.3 90.3 99.1 77.9 109.3 56.3 83.8 83.8 90.3 74.0 104.0 53.8
85 106.8 106.8 109.6 95.7 115.8 71.4 103.6 103.6 106.2 96.7 114.0 70.7 98.7 98.7 100.9 95.5 109.8 71.7 91.7 91.7 91.7 91.7 104.3 70.7
90 111.0 111.0 111.0 111.0 117.0 84.9 108.8 108.8 108.9 107.2 114.4 86.1 105.1 105.1 105.0 104.8 110.7 87.4 99.8 99.8 99.7 99.7 105.2 87.1
75 100.7 91.7 109.2 64.5 114.0 42.8 93.8 88.7 106.1 66.5 113.5 41.7 85.4 85.4 100.4 63.3 109.4 39.6 79.4 77.5 91.3 59.4 104.6 37.2
80 104.1 103.6 109.6 82.9 115.3 59.0 100.0 100.0 106.6 84.3 113.7 59.0 94.0 94.0 100.9 82.2 109.6 60.2 87.0 87.0 92.2 78.5 105.1 56.0
85 108.9 108.9 110.9 99.2 116.6 73.0 106.7 106.7 108.3 102.4 114.8 74.4 102.0 102.0 102.0 102.0 110.8 74.3 95.6 95.6 96.4 93.7 105.5 73.9
90 112.8 112.8 112.8 112.8 117.8 87.2 111.8 111.8 111.8 111.2 116.0 90.0 107.7 107.7 107.7 107.7 111.9 90.9 102.9 102.9 102.9 102.9 106.6 91.4
75 102.3 95.8 110.2 66.1 114.6 43.5 95.2 95.2 106.7 68.3 113.1 42.2 88.2 88.2 101.6 65.9 110.1 40.3 81.6 80.6 92.7 62.1 105.3 38.1
80 106.2 106.2 110.5 85.3 115.9 59.8 102.8 102.8 107.4 86.8 114.3 60.0 97.4 97.4 102.4 86.2 111.0 58.6 89.9 89.9 94.1 82.9 105.9 58.2
85 110.5 110.5 111.9 102.3 117.2 74.4 108.3 108.3 109.2 105.1 115.5 76.3 104.5 104.5 104.4 104.4 111.5 77.2 98.7 98.7 99.0 97.4 106.4 76.8
90 114.2 114.2 114.2 114.2 118.5 89.3 112.7 112.7 112.7 112.7 116.8 92.7 109.7 109.7 109.7 109.7 112.9 94.2 105.2 105.2 105.2 105.2 107.8 95.4

85 95 105 115

Ambient Temperature (F)

18

RT-PRC005-EN

Performance

(10 Ton)

Data

Table PD-9 — Gross Cooling Capacities (MBH) 10 Ton Three Phase TSC120A3, A4, AW, AK

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

3600

4000

4400

4800

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 109.2 95.1 119.3 71.0 123.3 46.1 101.7 91.5 115.7 69.0 122.1 44.6 93.2 87.4 108.3 66.1 119.9 42.8 84.9 83.4 99.6 62.4 114.5 40.4
80 112.4 112.4 119.9 86.9 124.6 64.8 106.9 106.9 116.3 87.4 123.4 63.2 99.8 99.8 109.3 84.9 120.2 61.3 92.8 92.8 100.9 81.3 115.0 58.9
85 118.2 118.2 121.2 103.4 126.2 76.0 114.6 114.6 117.7 105.2 124.9 77.6 108.7 108.7 111.4 104.0 121.3 78.1 102.2 102.2 103.6 100.5 115.5 77.0
90 122.6 122.6 122.9 119.0 127.7 89.9 120.1 120.1 120.1 120.1 126.3 93.0 116.2 116.2 116.2 116.2 122.7 94.7 110.7 110.7 110.7 110.7 116.6 94.3
75 112.0 101.1 120.4 72.8 123.8 46.9 104.9 98.0 117.1 72.3 122.7 45.3 96.5 94.0 111.0 70.0 120.0 43.5 87.7 87.7 102.0 66.1 115.5 41.2
80 115.8 115.8 121.6 90.8 125.3 63.0 111.4 111.4 118.0 91.7 124.1 63.4 104.9 104.9 112.2 90.7 121.3 63.4 97.3 97.3 103.5 87.0 116.2 61.7
85 120.6 120.6 123.1 108.3 126.9 77.4 118.0 118.0 119.7 110.5 125.6 79.5 113.4 113.4 114.4 110.9 121.9 80.1 106.7 106.7 106.7 106.7 116.9 80.7
90 124.5 124.5 124.9 124.9 128.4 91.9 122.9 122.9 122.6 122.6 127.2 95.7 119.3 119.3 119.3 119.3 123.3 97.3 114.3 114.3 114.3 114.3 118.3 99.2
75 114.1 106.4 120.6 73.7 124.2 47.6 107.6 104.3 118.2 75.6 123.1 46.1 99.0 99.0 112.7 73.4 120.6 44.2 91.1 91.1 103.8 69.7 116.3 42.0
80 118.2 118.2 121.9 92.4 125.8 63.8 114.7 114.7 119.3 95.4 124.7 64.4 108.7 108.7 114.0 95.7 122.0 64.9 101.4 101.4 105.7 92.5 117.0 64.1
85 122.7 122.7 123.5 110.4 127.4 78.7 120.3 120.3 121.2 115.0 126.2 81.3 116.3 116.3 116.3 116.3 122.7 82.5 110.6 110.6 110.6 110.6 118.0 84.0
90 125.4 125.4 125.4 125.4 129.0 93.8 124.7 124.7 124.2 124.2 127.9 98.0 121.5 121.5 121.5 121.5 124.3 100.5 117.0 117.0 117.0 117.0 119.6 103.4
75 115.7 111.0 121.3 75.4 124.6 48.3 109.5 109.5 119.1 77.3 123.5 46.8 102.3 102.3 114.0 76.7 121.0 45.0 94.2 94.2 105.4 73.3 116.8 42.8
80 119.8 119.8 122.8 94.9 126.3 64.5 117.0 117.0 120.3 98.7 125.1 65.4 112.0 112.0 115.5 100.1 122.5 66.1 104.7 104.7 107.7 98.0 117.7 66.0
85 123.7 123.7 124.4 113.4 127.9 80.0 121.9 121.9 122.4 118.8 126.7 82.9 118.5 118.5 118.5 118.5 124.0 85.7 113.2 113.2 113.3 113.3 119.0 87.2
90 126.4 126.4 126.5 126.5 129.5 95.6 125.6 125.6 125.4 125.4 128.4 100.2 123.7 123.7 122.9 122.9 125.8 104.8 118.9 118.9 118.9 118.9 120.8 107.5

85 95 105 115

Ambient Temperature (F)

Standard Efficiency

RT-PRC005-EN

19

Performance

(3, 4 Ton)

Data

High Efficiency

Table PD-10 — Gross Cooling Capacities (MBH) 3 Ton THC036A1, A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1080

1200

1320

1440

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 34.2 29.2 39.8 22.7 43.1 15.2 31.1 27.4 37.0 21.2 41.3 14.1 28.0 25.7 33.3 19.8 39.0 12.9 24.8 24.0 29.8 18.1 36.1 11.6
80 34.9 34.9 40.0 28.5 43.5 21.3 32.3 32.3 37.1 27.1 41.6 20.1 29.7 29.7 33.5 25.3 39.2 18.8 27.1 27.1 30.0 23.6 36.2 17.5
85 37.9 37.9 40.3 34.3 44.0 26.5 35.3 35.3 37.5 33.0 41.9 25.6 32.6 32.6 34.0 31.3 39.5 24.6 30.0 30.0 30.6 29.6 36.4 23.2
90 40.5 40.5 40.9 40.0 44.5 31.7 38.4 38.4 38.4 38.4 42.3 31.0 35.7 35.7 35.7 35.7 39.7 30.3 32.9 32.9 32.9 32.9 36.7 29.0
75 35.3 31.2 40.4 23.7 43.5 15.5 32.0 29.4 37.8 22.4 41.8 14.4 28.8 27.7 34.1 20.6 39.5 13.2 25.5 25.5 30.5 18.8 36.7 11.9
80 36.7 36.7 40.7 30.0 44.0 21.9 33.9 33.9 38.0 28.9 42.1 20.9 31.2 31.2 34.4 27.1 39.8 19.7 28.5 28.5 30.8 25.3 36.9 18.4
85 39.6 39.6 41.1 36.3 44.6 27.4 37.1 37.1 38.5 35.4 42.5 26.8 34.3 34.3 35.1 33.8 40.0 26.0 31.5 31.5 31.5 31.5 37.1 24.8
90 41.9 41.9 41.9 41.9 45.1 33.0 39.9 39.9 39.9 39.9 42.9 32.6 37.6 37.6 37.6 37.6 40.4 32.1 34.7 34.7 34.7 34.7 37.4 31.1

75 36.2 33.2 40.9 24.7 43.8 15.8 32.8 31.4 38.4 23.4 42.1 14.7 29.4 29.4 34.8 21.7 39.9 13.5 26.5 26.5 31.0 19.9 37.2 12.2
80 38.2 38.2 41.2 31.4 44.4 22.4 35.4 35.4 38.7 30.5 42.6 21.7 32.5 32.5 35.2 28.9 40.2 20.5 29.7 29.7 31.5 27.1 37.4 19.2
85 40.8 40.8 41.8 38.1 45.0 28.3 38.7 38.7 39.4 37.6 43.1 28.0 35.9 35.9 36.2 36.2 40.5 27.2 32.9 32.9 32.9 32.9 37.6 26.2
90 42.9 42.9 42.9 42.9 45.6 34.2 41.1 41.1 41.1 41.1 43.4 34.0 38.9 38.9 38.9 38.9 41.0 33.8 36.3 36.3 36.3 36.3 38.1 33.1

75 37.1 35.1 41.3 25.5 44.1 16.1 33.6 33.3 38.9 24.4 42.4 15.0 30.4 30.4 35.5 22.8 40.2 13.8 27.5 27.5 31.5 21.0 37.5 12.5
80 39.4 39.4 41.7 32.6 44.7 22.9 36.8 36.8 39.3 32.1 42.9 22.3 33.8 33.8 35.9 30.6 40.6 21.4 30.8 30.8 32.1 28.8 37.8 20.1
85 41.7 41.7 42.4 39.7 45.3 29.0 39.8 39.8 40.1 39.5 43.5 29.0 37.3 37.3 37.3 37.3 40.9 28.3 34.2 34.2 34.2 34.2 38.0 27.6
90 43.7 43.7 43.7 43.7 45.9 35.3 42.1 42.1 42.1 42.1 43.9 35.3 40.0 40.0 40.0 40.0 41.5 35.4 37.5 37.5 37.5 37.5 38.6 34.9

85 95 105 115

Ambient Temperature (F)

Table PD-11 — Gross Cooling Capacities (MBH) 4 Ton THC048A1, A3, A4, AW

Enter.

CFMBulb616773616773616773616773

Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1440

1600

1760

1920

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 45.3 39.9 51.4 30.3 54.9 19.9 41.1 37.7 48.4 28.8 53.1 18.7 37.1 35.6 43.9 26.7 51.0 17.4 33.2 33.2 39.3 24.6 47.8 16.0
80 47.1 47.1 52.0 38.4 55.5 28.1 43.8 43.8 48.7 36.9 54.6 27.2 40.3 40.3 44.3 34.9 51.3 25.6 36.9 36.9 39.8 32.8 47.9 24.1
85 50.5 50.5 52.5 46.3 56.2 34.5 47.8 47.8 49.4 45.2 54.9 34.9 44.3 44.3 45.3 43.3 51.6 33.6 40.9 40.9 40.9 40.9 48.1 32.2
90 53.1 53.1 53.5 53.5 56.9 41.4 51.2 51.2 51.2 51.2 54.6 41.4 48.4 48.4 48.4 48.4 52.0 41.2 45.0 45.0 45.0 45.0 48.6 40.2

75 46.7 42.7 52.7 31.9 55.2 20.2 42.4 40.5 49.4 30.3 54.4 19.3 38.2 38.2 45.0 28.4 51.6 17.8 34.7 34.7 40.2 26.2 48.6 16.4
80 49.2 49.2 52.8 40.4 55.9 28.2 46.0 46.0 49.8 39.4 55.2 28.4 42.3 42.3 45.6 37.5 51.9 26.9 38.7 38.7 40.9 35.3 48.7 25.4
85 52.1 52.1 53.5 48.8 56.6 35.4 49.9 49.9 50.6 48.3 55.7 36.8 46.7 46.7 47.0 46.8 52.2 35.2 43.0 43.0 42.9 42.9 49.0 34.3
90 54.5 54.5 54.8 54.8 57.4 42.7 52.8 52.8 52.8 52.8 55.2 42.9 50.5 50.5 50.5 50.5 52.9 43.5 47.4 47.4 47.4 47.4 49.6 43.0

75 47.8 45.4 53.2 33.4 55.5 20.6 43.7 43.3 50.1 31.8 54.7 19.6 39.7 39.7 46.0 30.0 51.9 18.2 36.1 36.1 41.0 27.7 49.1 16.8
80 50.6 50.6 53.4 42.1 56.2 28.7 47.8 47.8 50.5 41.5 55.7 29.4 44.1 44.1 46.7 39.9 52.4 28.1 40.4 40.4 41.9 37.8 49.3 26.7
85 53.1 53.1 54.2 50.9 57.0 36.2 51.4 51.4 51.6 51.0 56.2 38.0 48.6 48.6 48.6 48.6 52.8 36.7 44.9 44.9 44.9 44.9 49.7 36.3
90 55.1 55.1 55.7 55.7 57.7 43.8 53.9 53.9 53.9 53.9 55.6 44.3 51.9 51.9 51.9 51.9 53.5 45.6 49.2 49.2 49.2 49.2 50.5 45.7
75 48.8 48.1 53.6 34.4 55.7 20.9 45.0 45.0 50.6 33.2 55.0 20.0 41.0 41.0 46.8 31.5 52.3 18.5 37.3 37.3 41.7 29.3 49.6 17.2
80 51.7 51.7 53.9 43.5 56.4 31.7 49.3 49.3 51.2 43.5 56.0 30.1 45.8 45.8 47.6 42.3 52.8 28.9 41.8 41.8 42.8 40.2 49.8 27.9
85 53.9 53.9 54.8 52.7 57.2 36.9 52.4 52.4 52.4 52.4 56.5 39.1 50.0 50.0 50.0 50.0 53.2 38.1 46.6 46.6 46.6 46.6 50.3 38.1
90 55.7 55.7 56.3 56.3 58.0 44.8 54.7 54.7 54.7 54.7 56.0 45.6 53.0 53.0 53.0 53.0 54.0 47.4 50.5 50.5 50.5 50.5 51.2 48.1

85 95 105 115

Ambient Temperature (F)

20

RT-PRC005-EN

Performance

(5 Ton)

Data

High Efficiency

Table PD-12 — Gross Cooling Capacities (MBH) 5 Ton Single Phase THC060A1

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1800

2000

2200

2400

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 56.2 48.2 64.3 37.8 68.4 24.8 51.4 45.6 60.5 35.2 66.7 23.5 46.8 43.2 55.3 32.8 63.9 21.9 42.2 40.8 50.0 31.0 59.9 20.1
80 57.6 57.6 64.6 46.6 69.3 34.7 53.7 53.7 60.7 44.8 67.3 33.1 49.8 49.8 55.5 42.3 64.2 31.5 45.9 45.9 50.5 39.9 60.1 29.6
85 62.2 62.2 65.2 55.8 70.1 42.6 58.4 58.4 61.4 54.5 68.0 42.2 54.5 54.5 56.5 52.0 64.6 40.9 50.6 50.6 51.6 49.7 60.3 39.0
90 65.8 65.8 66.3 64.9 70.9 50.8 63.0 63.0 63.0 63.0 68.2 52.0 59.3 59.3 59.2 59.2 65.0 49.9 55.3 55.3 55.3 55.3 60.7 48.5

75 57.8 51.4 65.2 38.8 69.6 25.4 52.9 48.8 61.8 37.0 67.3 23.9 48.2 46.3 56.5 34.6 64.6 22.4 43.3 43.3 51.2 32.1 60.9 20.7
80 60.3 60.3 65.6 48.8 69.8 35.2 56.2 56.2 62.1 47.6 68.0 34.6 52.1 52.1 56.9 45.1 65.0 32.9 48.1 48.1 51.7 42.7 61.2 31.1
85 64.4 64.4 66.3 58.7 70.7 43.8 61.2 61.2 63.0 58.1 68.7 43.9 57.1 57.1 58.2 56.0 65.4 42.8 53.0 53.0 53.0 53.0 61.4 41.5
90 67.6 67.6 67.6 67.6 71.6 52.5 65.2 65.2 65.2 65.2 69.5 53.3 62.0 62.0 62.0 62.0 66.0 52.6 58.0 58.0 58.0 58.0 62.0 51.8
75 59.4 54.5 65.7 40.1 69.3 25.6 54.3 51.9 62.7 38.7 67.7 24.3 49.6 49.4 57.6 36.3 65.1 22.8 45.0 45.0 52.2 33.8 61.6 21.1
80 62.4 62.4 66.3 50.7 70.3 35.8 58.4 58.4 63.1 50.1 68.5 35.4 54.2 54.2 58.2 47.9 65.7 34.2 50.0 50.0 52.9 45.4 61.9 32.5
85 66.0 66.0 67.3 61.2 71.2 44.8 63.3 63.3 64.2 61.3 69.4 45.3 59.4 59.4 59.9 59.8 66.1 44.6 55.2 55.2 55.2 55.2 62.2 43.7
90 68.9 68.9 68.9 68.9 72.2 54.0 66.9 66.9 66.9 66.9 70.2 55.4 64.0 64.0 64.0 64.0 66.8 55.1 60.4 60.4 60.4 60.4 63.0 54.6

75 60.6 57.4 66.1 41.5 69.7 26.0 55.6 54.9 63.4 40.3 68.1 24.7 50.8 50.8 58.5 38.0 65.5 23.2 46.5 46.5 53.0 35.5 62.1 21.5
80 64.0 64.0 67.0 52.5 70.6 38.5 60.4 60.4 63.9 52.4 69.0 36.1 56.1 56.1 59.2 50.5 66.1 35.8 51.8 51.8 54.0 48.1 62.5 33.8
85 67.2 67.2 68.0 63.5 71.5 50.9 64.9 64.9 65.3 64.2 69.9 46.6 61.4 61.4 61.4 61.4 67.0 46.8 57.2 57.2 57.2 57.2 62.9 45.6
90 69.8 69.8 69.8 69.8 72.6 55.3 68.1 68.1 68.1 68.1 70.8 57.1 65.5 65.5 65.5 65.5 67.5 57.3 62.2 62.2 62.2 62.2 63.9 57.2

85 95 105 115

Ambient Temperature (F)

Table PD-13 — Gross Cooling Capacities (MBH) 5Ton Three Phase THC060A3, A4, AW

Enter.

CFMBulb616773616773616773616773

Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1800

2000

2200

2400

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 56.6 49.0 64.4 37.5 67.7 24.7 52.0 46.8 60.9 35.7 66.2 23.3 47.0 44.2 55.9 33.3 63.6 21.8 42.3 41.7 50.0 30.7 59.8 20.0
80 58.5 58.5 64.6 47.0 68.6 34.7 54.7 54.7 61.2 45.5 66.8 33.3 50.6 50.6 56.3 43.2 64.1 31.7 46.4 46.4 50.5 40.5 60.0 29.8
85 62.9 62.9 65.3 56.4 69.4 42.2 59.6 59.6 61.9 55.5 67.7 42.3 55.6 55.6 57.3 53.2 64.3 41.1 51.2 51.2 51.9 50.7 60.3 39.5
90 66.2 66.2 66.4 65.6 70.3 50.3 63.7 63.7 63.7 63.7 68.4 51.2 60.3 60.3 60.3 60.3 64.9 50.3 56.4 56.4 56.3 56.3 60.8 49.1

75 58.3 52.5 65.0 39.1 68.1 25.1 53.6 50.0 62.0 37.6 66.6 23.8 48.6 47.7 57.2 35.4 64.2 22.3 43.8 43.8 51.2 32.7 60.6 20.5
80 61.1 61.1 65.6 49.2 69.0 34.6 57.3 57.3 62.4 48.4 67.5 34.8 53.2 53.2 57.8 46.2 64.7 33.2 48.7 48.7 52.0 43.6 60.9 31.4
85 64.9 64.9 66.4 59.2 69.9 43.1 62.1 62.1 63.4 59.1 67.8 43.0 58.4 58.4 59.2 57.5 64.9 43.9 54.0 54.0 54.0 54.0 61.2 42.0
90 67.7 67.7 67.7 67.7 70.8 51.7 65.7 65.7 65.7 65.7 68.6 52.2 62.8 62.8 62.8 62.8 65.9 52.9 59.0 59.0 59.0 59.0 61.9 52.3

75 59.9 55.8 65.8 40.7 68.4 25.5 55.2 53.4 62.9 39.5 67.0 24.2 50.0 50.0 58.3 37.3 64.6 22.7 45.6 45.6 52.4 34.7 61.2 21.0
80 63.1 63.1 66.3 51.0 69.3 35.2 59.7 59.7 63.5 51.0 67.9 35.1 55.5 55.5 59.0 49.2 65.4 34.5 50.8 50.8 53.4 46.6 61.6 32.9
85 66.4 66.4 67.2 61.6 70.2 43.9 64.0 64.0 64.6 62.4 68.8 44.9 60.6 60.6 60.6 60.6 66.0 45.1 56.4 56.4 56.4 56.4 62.0 44.2
90 68.7 68.7 68.7 68.7 71.2 52.8 67.1 67.1 67.1 67.1 69.7 54.9 64.5 64.5 64.5 64.5 66.9 55.8 61.0 61.0 61.0 61.0 62.9 55.3

75 61.2 59.0 66.2 41.7 68.6 25.9 56.3 56.3 63.6 41.3 67.3 24.6 51.9 51.9 59.2 39.0 65.0 23.1 47.2 47.2 53.4 36.6 61.7 21.4
80 64.5 64.5 67.0 53.1 69.6 35.6 61.6 61.6 64.2 53.3 68.2 35.7 57.5 57.5 60.1 52.1 65.8 35.5 52.8 52.8 54.7 49.6 62.1 34.3
85 67.3 67.3 68.1 64.0 70.5 44.7 65.4 65.4 65.6 65.2 69.1 46.0 62.4 62.4 62.3 62.3 66.6 46.8 58.4 58.4 58.4 58.4 62.6 46.2
90 69.4 69.4 69.5 69.5 71.5 53.9 68.1 68.1 68.1 68.1 70.1 56.3 65.7 65.7 65.7 65.7 67.6 58.0 62.5 62.5 62.5 62.5 63.7 57.9

85 95 105 115

Ambient Temperature (F)

RT-PRC005-EN

21

Performance

(5 Ton)

Data

Table PD-14 — Gross Cooling Capacities (MBH) 5Ton THC060A3, A4, AW – Dehumidification Option

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

1000

1300

1600

1800

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 50.7 36.2 57.0 29.4 63.7 22.6 48.1 34.6 54.2 27.9 60.7 21.0 45.5 32.9 51.3 26.2 57.5 19.4 42.7 31.2 48.2 24.5 54.1 17.7
80 50.8 41.8 57.1 35.1 63.8 28.2 48.3 40.2 54.4 33.5 60.8 26.6 45.6 38.6 51.5 31.9 57.6 25.0 42.9 36.8 48.4 30.1 54.2 23.3
85 51.0 47.5 57.2 40.7 64.0 33.8 48.6 45.9 54.5 39.1 61.0 32.2 46.0 44.2 51.6 37.4 57.8 30.6 43.3 42.5 48.5 35.7 54.4 28.8
90 52.2 52.2 57.4 46.3 64.1 39.4 50.1 50.1 54.6 44.7 61.1 37.8 47.8 47.8 51.7 43.0 57.9 36.1 45.5 45.5 48.7 41.3 54.5 34.4

75 54.3 41.5 60.7 32.7 67.6 23.8 51.5 39.9 57.7 31.0 64.3 22.1 48.6 38.1 54.5 29.3 60.8 20.4 45.5 36.4 51.1 27.5 57.0 18.7
80 54.6 48.8 60.9 40.0 67.8 31.0 51.9 47.1 57.9 38.3 64.5 29.3 49.0 45.4 54.7 36.6 60.9 27.6 46.0 43.6 51.3 34.8 57.2 25.9
85 55.6 55.6 61.1 47.2 67.9 38.2 53.2 53.2 58.1 45.5 64.6 36.5 50.7 50.7 54.9 43.7 61.1 34.8 48.1 48.1 51.5 41.9 57.4 33.0
90 58.8 58.8 61.5 54.4 68.1 45.3 56.3 56.3 58.5 52.7 64.8 43.6 53.7 53.7 55.3 50.9 61.3 41.9 51.0 51.0 52.0 49.1 57.5 40.1

75 56.8 46.5 63.2 35.6 70.2 24.7 53.9 44.9 60.0 33.9 66.6 23.0 50.8 43.1 56.6 32.2 62.9 21.3 47.5 41.3 53.0 30.4 58.9 19.5
80 57.6 55.5 63.4 44.5 70.3 33.5 54.7 53.8 60.2 42.7 66.8 31.8 51.6 51.6 56.8 41.0 63.0 30.1 48.8 48.8 53.2 39.1 59.1 28.3
85 60.3 60.3 63.8 53.2 70.5 42.2 57.7 57.7 60.6 51.5 67.0 40.5 54.9 54.9 57.3 49.7 63.2 38.8 52.0 52.0 53.7 47.9 59.3 36.9
90 63.8 63.8 64.7 62.1 70.8 50.9 61.1 61.1 61.6 60.4 67.3 49.2 58.2 58.2 58.2 58.2 63.5 47.4 55.1 55.1 55.1 55.1 59.6 45.6

75 58.1 49.6 64.5 37.5 71.4 25.2 55.1 48.2 61.1 35.8 67.8 23.5 51.9 46.3 57.6 34.0 63.9 21.8 48.6 44.5 53.9 32.2 59.8 20.0
80 59.3 59.3 64.7 47.4 71.6 35.1 56.6 56.6 61.4 45.6 67.9 33.4 53.8 53.8 57.9 43.8 64.1 31.6 50.8 50.8 54.2 42.0 60.0 29.8
85 62.9 62.9 65.3 57.2 71.8 44.9 60.1 60.1 62.0 55.4 68.2 43.1 57.2 57.2 58.6 53.6 64.3 41.3 54.1 54.1 55.0 51.8 60.2 39.5
90 66.5 66.5 66.5 66.5 72.2 54.6 63.7 63.7 63.7 63.7 68.5 52.9 60.6 60.6 60.6 60.6 64.7 51.0 57.4 57.4 57.4 57.4 60.7 49.1

85 95 105 115

Ambient Temperature (F)

High Efficiency

22

RT-PRC005-EN

Performance

(6, 7½ Ton)

Data

High Efficiency

Table PD-15 — Gross Cooling Capacities (MBH) 6Ton Three Phase THC072A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

2160

2400

2640

2880

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 67.3 56.6 73.6 42.5 74.5 27.6 61.6 53.5 71.8 41.9 75.1 26.6 55.8 50.4 66.8 38.7 74.1 25.3 49.8 47.2 59.9 36.3 71.3 23.5
80 68.7 68.2 73.8 51.7 75.4 37.0 63.6 63.6 72.0 52.1 76.0 38.1 58.9 58.9 66.9 49.7 74.7 36.4 54.1 54.1 60.2 46.5 71.5 34.5
85 72.2 72.2 74.5 61.4 76.2 44.5 69.2 69.2 72.5 62.8 76.8 46.1 64.6 64.6 67.8 60.9 75.0 46.2 59.5 59.5 61.3 57.7 71.7 45.4
90 74.7 74.7 75.3 70.6 77.0 51.9 73.4 73.4 73.7 73.2 77.7 55.1 70.1 70.1 70.1 70.1 75.6 56.1 65.4 65.4 65.4 65.4 72.1 55.8
75 69.0 60.1 74.0 43.3 74.5 27.9 63.5 57.2 72.7 43.1 75.2 27.0 57.5 54.0 68.4 40.9 74.5 25.7 51.8 51.0 61.5 37.6 72.0 24.0
80 70.7 70.7 74.3 52.9 75.4 37.2 66.8 66.8 73.0 54.6 76.2 37.8 61.9 61.9 68.7 53.0 75.1 37.4 56.7 56.7 61.9 49.8 72.4 36.1
85 73.8 73.8 75.0 63.0 76.2 44.9 71.9 71.9 73.8 66.0 77.1 47.0 67.9 67.9 69.7 65.4 75.5 47.5 62.7 62.7 63.6 62.4 72.6 47.7
90 75.6 75.6 75.9 72.4 77.0 52.5 75.2 75.2 75.1 75.1 78.0 56.3 72.8 72.8 72.7 72.7 76.4 58.2 68.8 68.8 68.8 68.8 73.2 59.0
75 70.3 63.2 74.2 43.9 74.6 28.3 65.2 60.8 73.2 44.5 75.4 27.4 59.2 57.7 69.6 42.9 74.7 26.2 53.2 53.2 62.9 39.8 72.5 24.6
80 72.3 72.3 74.5 53.9 75.4 37.4 69.5 69.5 73.8 56.7 76.3 38.2 64.6 64.6 70.0 56.1 75.6 38.5 59.2 59.2 63.5 53.0 73.0 37.7
85 74.7 74.7 75.3 64.3 76.2 45.2 73.7 73.7 74.7 68.7 77.3 47.6 70.5 70.5 71.3 69.3 76.1 48.9 65.6 65.6 65.6 65.6 73.4 49.7
90 76.1 76.1 76.2 73.6 76.9 53.0 76.2 76.2 76.2 76.2 78.1 57.2 74.5 74.5 74.5 74.5 76.9 59.9 71.2 71.2 71.2 71.2 74.1 61.7
75 71.3 65.8 74.3 44.4 74.6 28.7 66.8 64.4 73.7 45.6 75.5 27.8 60.5 60.5 70.6 44.8 74.9 26.6 55.1 55.1 64.1 41.8 72.9 25.0
80 73.3 73.3 74.7 54.8 75.4 37.6 71.4 71.4 74.4 58.5 76.4 38.5 67.0 67.0 71.0 58.9 75.9 39.1 61.4 61.4 64.9 56.2 73.3 38.6
85 75.1 75.1 75.5 65.3 76.2 45.6 74.8 74.8 75.4 70.8 77.4 48.2 72.4 72.4 72.4 72.4 76.4 49.9 68.2 68.2 68.1 68.1 74.0 51.5
90 76.3 76.3 76.3 74.5 76.9 53.5 76.9 76.9 76.9 76.9 78.2 58.0 75.7 75.7 75.7 75.7 77.2 61.3 72.9 72.9 72.9 72.9 74.8 64.1

85 95 105 115

Ambient Temperature (F)

Table PD-16 — Gross Cooling Capacities (MBH) 7½ Ton Three Phase THC092A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

2700

3000

3300

3600

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 85.7 72.4 95.8 56.8 99.9 37.1 79.3 69.3 92.0 53.7 98.8 35.8 72.8 66.0 85.9 50.8 96.1 34.2 66.1 62.6 78.5 49.1 91.8 32.2
80 87.5 87.0 96.2 68.5 101.1 50.4 81.8 81.8 92.4 67.4 99.6 50.2 76.6 76.6 86.2 64.6 96.7 48.0 71.1 71.1 79.0 61.4 92.0 45.8
85 92.8 92.8 97.0 81.6 102.3 61.3 88.5 88.5 93.1 81.1 100.3 61.3 83.4 83.4 87.1 78.6 97.0 60.9 77.9 77.9 80.3 75.4 92.3 59.4
90 97.2 97.2 98.3 94.2 103.5 72.4 94.3 94.3 94.3 94.3 101.1 73.1 90.0 90.0 90.0 90.0 97.8 73.7 84.9 84.9 84.9 84.9 92.9 72.7
75 87.9 77.0 96.6 57.3 100.4 37.6 81.5 73.7 93.5 56.1 99.4 36.4 74.9 70.5 87.8 53.4 96.9 34.8 67.4 67.4 80.5 50.2 92.8 32.8
80 90.5 90.5 97.4 71.2 101.6 51.1 85.6 85.6 94.0 71.0 100.4 50.9 80.2 80.2 88.2 68.7 97.3 49.8 74.5 74.5 81.0 65.5 93.2 47.9
85 95.6 95.6 98.4 85.1 102.9 62.5 92.2 92.2 95.0 85.8 101.3 63.3 87.3 87.3 89.5 84.1 98.1 63.3 81.8 81.8 82.9 81.2 93.6 62.5
90 99.4 99.4 99.9 98.1 104.1 74.1 97.2 97.2 97.2 97.2 102.1 75.5 93.6 93.6 93.5 93.5 99.1 77.0 88.8 88.8 88.7 88.7 94.4 76.9

75 89.8 81.3 97.5 59.0 100.7 38.1 83.6 78.2 94.6 58.3 99.8 37.1 77.0 75.0 89.2 55.9 97.5 35.4 70.0 70.0 82.1 52.8 93.6 33.4
80 93.2 93.2 98.3 73.5 102.0 51.7 88.9 88.9 95.2 74.2 101.0 52.0 83.4 83.4 89.8 72.6 97.9 50.6 77.6 77.6 82.8 69.5 94.1 49.9
85 97.6 97.6 99.4 88.0 103.3 67.9 94.9 94.9 96.5 90.0 101.9 64.8 90.5 90.5 91.7 89.4 99.0 67.3 85.2 85.2 85.1 85.1 94.7 65.2
90 100.9 100.9 100.9 100.9 104.6 75.6 99.2 99.2 99.2 99.2 102.8 77.7 96.1 96.1 96.1 96.1 100.1 80.0 91.8 91.8 91.8 91.8 95.7 80.7

75 91.5 85.3 98.2 60.6 101.0 38.6 85.5 82.6 95.4 60.2 100.2 37.5 78.5 78.5 90.5 58.3 98.0 35.9 72.4 72.4 83.4 55.2 94.3 34.0
80 95.2 95.2 99.0 75.4 102.3 56.8 91.5 91.5 96.3 77.2 101.5 52.7 86.3 86.3 91.3 76.3 98.4 51.4 80.4 80.4 84.4 73.4 94.7 51.4
85 99.1 99.1 100.2 90.6 103.6 69.8 96.9 96.9 97.8 93.6 102.4 66.1 93.1 93.1 93.1 93.1 99.7 69.8 88.0 88.0 87.9 87.9 95.6 67.8
90 101.9 101.9 101.9 101.9 105.0 76.9 100.7 100.7 100.7 100.7 103.4 79.6 98.0 98.0 97.9 97.9 100.8 82.5 94.0 94.0 94.0 94.0 96.7 84.1

85 95 105 115

Ambient Temperature (F)

RT-PRC005-EN

23

Performance

(8½, 10 Ton)

Data

High Efficiency

Table PD-17 — Gross Cooling Capacities (MBH) 8½ Ton Three Phase THC102A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

3060 85 103.5 103.5 107.2 92.9 113.2 68.7 98.6 98.6 102.2 92.1 111.6 70.3 92.1 92.1 94.5 88.8 106.4 68.8 85.8 85.8 86.7 85.2 100.0 66.5

3400 85 106.6 106.6 108.9 97.4 114.0 70.2 102.6 102.6 104.4 97.8 112.8 72.9 96.5 96.5 97.6 95.6 108.0 72.4 89.9 89.9 89.8 89.8 101.8 70.8

3740 85 108.8 108.8 110.1 100.9 114.6 76.9 105.4 105.4 106.4 103.0 113.7 75.1 100.2 100.2 100.2 100.2 109.3 75.7 93.4 93.4 93.4 93.4 103.1 74.4

4080 85 110.2 110.2 110.9 103.4 115.1 79.5 107.6 107.6 107.6 107.6 114.1 76.6 103.0 103.0 103.0 103.0 109.9 77.6 96.6 96.6 96.6 96.6 104.2 77.7

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 94.0 81.8 105.7 62.8 110.8 40.9 86.3 77.8 100.7 59.7 109.7 39.3 79.0 74.2 92.4 56.0 105.5 37.1 71.8 70.5 84.0 53.1 99.6 34.6
80 96.9 96.9 106.2 77.6 112.0 56.0 90.6 90.6 101.1 75.9 110.1 55.4 84.5 84.5 92.9 72.2 106.1 53.2 78.3 78.3 84.7 68.5 99.8 50.6

90 108.4 108.4 109.0 107.7 114.4 81.6 105.0 105.0 105.0 105.0 112.6 84.9 99.9 99.9 99.9 99.9 107.3 83.9 93.5 93.5 93.5 93.5 100.8 82.6
75 96.6 87.2 107.1 64.7 111.4 41.5 88.7 83.3 102.4 62.6 110.7 40.1 81.4 79.6 94.4 59.1 106.6 37.9 74.2 74.2 85.9 55.4 101.1 35.5
80 100.9 100.9 107.7 81.0 112.7 56.9 94.9 94.9 103.0 80.4 111.7 57.5 88.3 88.3 95.2 77.1 107.3 55.7 81.8 81.8 86.8 73.4 101.4 53.1

90 110.8 110.8 110.8 110.8 115.3 83.8 108.1 108.1 108.1 108.1 114.0 88.5 103.8 103.8 103.8 103.8 108.9 88.3 97.8 97.8 97.8 97.8 102.8 87.9
75 98.9 92.5 107.4 65.9 112.0 42.2 91.2 88.7 103.7 65.4 111.1 40.7 83.5 83.5 96.3 62.2 107.5 38.7 76.9 76.9 87.5 58.4 102.2 36.2
80 103.7 103.7 108.8 84.0 113.3 57.7 98.7 98.7 104.5 84.5 112.4 58.7 91.7 91.7 97.3 81.9 108.3 57.6 85.0 85.0 88.8 78.2 102.6 55.5

90 112.3 112.3 112.1 112.1 115.9 85.7 110.4 110.4 110.4 110.4 114.9 91.4 106.5 106.5 106.5 106.5 110.2 92.3 101.3 101.3 101.3 101.3 104.4 92.7
75 100.9 97.3 108.1 67.4 112.5 42.9 93.1 93.1 104.7 67.9 111.5 41.4 86.2 86.2 97.8 65.2 108.2 39.4 79.4 79.4 88.8 61.3 103.0 36.9
80 105.9 105.9 109.5 86.2 113.8 58.4 101.6 101.6 105.8 88.2 112.8 59.6 94.9 94.9 99.1 86.5 109.2 59.6 87.9 87.9 90.6 82.8 103.5 57.8

90 112.9 112.9 112.9 112.9 116.5 87.5 112.2 112.2 112.2 112.2 115.4 93.4 108.6 108.6 108.6 108.6 111.3 95.9 103.9 103.9 103.9 103.9 105.8 97.0

85 95 105 115

Ambient Temperature (F)

Table PD-18 — Gross Cooling Capacities (MBH) 10 Ton Three Phase THC120A3, A4, AW

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

3600

4000

4400

4800

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 107.0 94.4 117.4 75.0 123.4 46.0 98.7 90.1 114.7 68.8 121.9 44.4 88.5 88.5 107.2 65.3 118.6 42.2 82.3 78.8 97.8 61.1 113.6 39.6
80 110.9 108.6 119.9 88.2 125.0 62.5 104.5 104.1 115.2 87.5 123.4 62.3 97.7 97.7 107.8 84.3 119.4 60.8 90.6 90.6 98.5 80.1 114.3 58.3
85 117.6 117.6 120.9 105.0 126.6 76.7 113.1 113.1 116.5 105.8 124.9 78.1 106.9 106.9 107.0 107.0 120.9 78.1 99.9 99.9 100.0 100.0 114.8 76.5
90 122.5 122.5 122.4 122.4 128.2 91.1 119.6 119.6 119.6 117.1 126.4 94.1 115.0 115.0 114.7 114.6 121.6 94.3 109.0 109.0 109.0 109.0 115.8 94.3

75 109.8 100.5 119.4 71.9 122.5 46.5 99.7 99.7 116.1 71.5 121.7 45.0 92.5 92.5 110.1 69.1 119.4 43.0 85.6 83.4 100.9 65.0 114.6 40.5
80 114.6 114.1 120.8 90.1 124.1 68.3 109.3 109.3 117.0 91.2 123.4 62.7 102.3 102.3 110.8 89.9 120.6 62.5 94.8 94.8 101.9 86.0 115.5 61.1
85 120.5 120.5 122.3 107.9 125.9 76.4 117.0 117.0 118.6 110.2 125.0 78.8 111.6 111.6 111.8 111.8 122.1 80.4 104.7 104.7 105.8 102.6 116.3 79.7
90 125.2 125.2 124.2 124.2 127.6 90.9 122.4 122.4 121.7 120.9 126.6 95.1 118.5 118.5 118.3 118.3 123.6 98.4 113.1 113.1 113.3 113.3 117.7 98.6

75 112.3 106.1 121.2 74.8 124.6 47.6 103.6 103.6 117.1 75.5 123.0 46.0 96.7 93.9 111.2 72.2 120.0 43.7 88.6 88.0 102.0 68.2 115.3 41.2
80 117.6 117.6 122.5 94.7 126.3 64.2 113.0 113.0 118.4 95.8 124.7 64.4 106.3 106.3 112.2 94.9 121.5 64.3 98.8 98.8 103.5 91.1 116.1 62.8
85 122.4 122.4 124.3 113.8 128.0 79.6 119.6 119.6 119.6 119.6 126.4 81.8 115.1 115.1 115.5 111.7 122.7 83.0 109.1 109.1 108.8 107.4 117.2 83.2
90 126.0 126.0 127.1 125.0 129.6 95.2 124.3 124.3 124.2 124.2 128.0 99.4 120.9 120.9 120.9 120.9 123.9 101.2 116.1 116.1 116.1 116.1 118.8 103.3

75 113.4 113.4 121.8 76.2 125.0 48.4 107.6 104.0 118.5 77.0 123.5 46.9 99.6 98.2 112.7 75.4 120.5 44.8 91.6 91.6 103.7 71.6 115.9 41.9
80 119.5 119.5 123.2 97.0 126.7 64.8 115.8 115.8 119.8 99.6 125.2 65.3 109.8 109.8 113.9 99.4 122.1 65.5 102.3 102.3 105.5 96.3 117.2 66.8
85 124.3 124.3 125.2 116.6 128.4 80.7 121.5 121.5 121.5 121.5 126.9 83.3 117.5 117.5 117.6 115.4 123.7 85.6 111.8 111.8 111.8 111.8 118.5 86.4
90 127.5 127.5 128.0 126.7 130.1 96.9 126.0 126.0 125.5 125.5 128.6 101.5 122.6 122.6 123.0 123.0 125.5 105.5 118.2 118.2 118.2 118.2 120.3 107.5

85 95 105 115

Ambient Temperature (F)

24

RT-PRC005-EN

Performance

(10 Ton)

Data

Table PD-19— Gross Cooling Capacities (MBH) 10Ton THC120A3, A4, AW – Dehumidification Option

Enter.

CFMBulb616773616773616773616773
Airflow (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC

2000

2600

3200

3600

NOTES:

1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.

2. MBH = Total Gross Capacity

3. SHC = Sensible Heat Capacity

Dry Entering Wet Bulb (F)

75 94.2 68.9 105.8 56.2 118.4 42.6 89.7 66.2 101.0 53.6 113.2 40.0 84.8 63.4 95.8 50.9 107.6 37.3 79.7 60.4 90.2 48.1 101.5 34.6
80 94.4 79.8 106.0 66.8 118.6 53.6 89.9 77.1 101.2 64.1 113.4 51.0 85.0 74.2 96.0 61.4 107.8 48.3 79.9 71.2 90.4 58.4 101.7 45.4
85 93.0 93.0 106.3 77.6 118.8 64.3 90.4 86.3 101.4 74.9 113.6 61.7 86.1 82.8 96.2 72.1 108.0 59.0 81.6 79.1 90.7 69.2 101.9 56.1
90 98.0 97.2 106.4 88.3 119.0 75.0 94.4 94.4 101.6 85.6 113.8 72.4 90.4 90.4 96.4 82.8 108.2 69.6 86.1 86.1 90.9 79.8 102.1 66.7

75 100.5 78.8 112.6 62.6 125.6 44.8 95.6 76.0 107.3 59.9 119.9 42.2 90.4 73.0 101.6 57.1 113.8 39.5 84.8 70.0 95.6 54.1 107.2 36.6
80 101.1 92.6 112.9 75.8 125.8 58.8 96.4 89.9 107.6 73.1 120.1 56.1 89.7 89.7 101.9 70.2 114.0 53.3 86.0 81.9 95.8 67.1 107.4 50.4
85 104.0 102.0 113.2 89.6 126.1 72.5 99.7 98.7 107.9 86.8 120.4 69.8 95.4 95.4 102.3 83.9 114.2 67.0 90.6 90.6 96.2 80.9 107.6 64.0
90 109.9 109.9 113.9 103.3 126.4 86.1 105.6 105.6 108.7 100.5 120.7 83.4 101.1 101.1 101.1 101.1 114.5 80.6 96.2 96.2 97.5 92.3 107.9 77.6

75 104.9 87.8 117.1 67.4 130.2 46.6 99.8 85.0 111.5 65.7 124.2 44.0 94.3 82.0 110.8 64.8 117.7 41.2 88.4 78.9 99.0 59.8 110.7 38.2
80 106.6 102.0 117.4 84.1 130.5 63.4 102.0 98.4 111.8 81.3 124.5 60.6 97.0 94.6 105.8 78.4 118.0 57.8 91.6 90.5 99.4 75.3 111.0 54.8
85 112.2 112.2 118.1 100.7 130.8 79.9 107.8 107.8 112.6 98.0 124.7 77.2 103.0 103.0 106.7 95.0 118.2 74.3 97.7 97.7 100.4 91.9 111.2 71.3
90 118.6 118.6 118.8 118.8 131.1 96.5 114.2 114.2 115.0 110.5 125.1 93.7 109.2 109.2 109.6 106.5 118.7 90.8 103.8 103.8 103.9 102.2 111.7 87.8

75 107.3 93.6 119.4 70.7 132.5 47.7 102.1 90.8 113.6 67.9 126.3 45.0 96.5 87.8 107.2 64.9 119.4 42.1 90.4 84.7 100.6 61.8 112.1 39.1
80 110.3 107.5 119.7 89.4 132.8 66.3 105.6 104.0 114.0 86.6 126.6 63.5 100.4 100.3 107.6 83.5 119.6 60.5 95.1 95.1 101.1 80.4 112.4 57.5
85 116.7 116.7 120.8 107.9 133.2 84.7 112.2 112.2 115.2 105.1 126.9 82.0 107.1 107.1 108.9 102.1 119.9 79.0 101.4 101.4 101.4 101.4 112.7 75.9
90 123.5 123.5 124.2 120.7 133.7 103.1 118.8 118.8 119.0 116.9 127.5 100.3 113.6 113.6 113.2 112.8 120.6 97.3 107.7 107.7 107.7 107.7 113.4 94.2

85 95 105 115

Ambient Temperature (F)

High Efficiency

RT-PRC005-EN

25

Performance

(3, 4, 5 Ton)

Data

Table PD-20— Direct Drive Evaporator Fan Performance 3, 4 and 5 Ton TSC036A, TSC048A, TSC060A

Tons Model No. CFM ESP BHP ESP BHP ESP BHP ESP BHP

3 TSC036A 1200 0.66 0.40 0.34 0.30 0.84 0.45 0.74 0.41

4 TSC048A 1600 0.66 0.55 0.51 0.49 1.0 0 0.75 0.74 0.64

5 TSC060A

3 TSC036A 1200 0.71 0.40 0.39 0.30 0.89 0.45 0.79 0.41

4 TSC048A 1600 0.71 0.55 0.56 0.49 1.05 0.75 0.79 0.64

5 TSC060A

Fan motor heat (MBH) = 3.72 x Fan Bhp + .24.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate
reliably and continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data
will not result in nuisance tripping or premature motor failure. Our product’s warranty will not be affected.

NOTES:

1. Data includes pressure drop due to wet coil and filters.

2. 5 ton oversized motor performance is with 12 x 11 FC blower wheel.

3. YSC060AK uses a 1.0 hp direct drive motor and 12x11 FC centrifugal blower wheel. Refer to oversized motor column for the standard

Unit High Speed Low Speed High Speed Low Speed

960 0.81 0.36 0.61 0.28 0.96 0.39 0.89 0.35
1020 0.77 0.37 0.57 0.28 0.94 0.41 0.86 0.47
1080 0.73 0.38 0.50 0.29 0.91 0.43 0.82 0.39
1140 0.69 0.39 0.42 0.29 0.88 0.44 0.77 0.40

Horizontal 1260 0.60 0.41 0.26 0.30 0.80 0.46 0.70 0.42

Horizontal 1680 0.57 0.56 0.38 0.49 0.95 0.78 0.65 0.66

Horizontal 2100 0.50 0.93 0.14 0.66 0.80 1.10 0.50 0.96

Downflow 1260 0.65 0.41 0.31 0.30 0.85 0.46 0.75 0.42

Downflow 1680 0.62 0.56 0.43 0.49 1.00 0.78 0.70 0.66

Downflow 2100 0.55 0.93 0.19 0.66 0.85 1.10 0.55 0.96

motor performance data.

1320 0.55 0.42 0.14 0.31 0.75 0.48 0.65 0.44
1380 0.49 0.42 0.05 0.31 0.70 0.49 0.59 0.45
1440 0.44 0.43 — — 0.64 0.52 0.54 0.48
1280 0.93 0.53 0.81 0.47 1.20 0.67 0.99 0.56
1360 0.87 0.54 0.75 0.47 1.15 0.68 0.94 0.58
1440 0.80 0.54 0.68 0.48 1.10 0.70 0.88 0.60
1520 0.73 0.55 0.60 0.48 1.05 0.73 0.81 0.63

1760 0.47 0.56 0.23 0.50 0.90 0.82 0.50 0.68
1840 0.37 0.57 0.13 0.50 0.83 0.83 0.35 0.70
1920 0.27 0.57 — — 0.75 0.85 0.25 0.73
1600 0.90 0.78 0.82 0.64 1.20 0.90 1.05 0.85
1700 0.85 0.82 0.68 0.65 1.15 0.94 0.95 0.89
1800 0.80 0.85 0.56 0.65 1.05 0.98 0.85 0.91
1900 0.70 0.88 0.46 0.65 0.98 1.02 0.75 0.94

3

2000 0.60 0.90 0.30 0.66 0.90 1.05 0.65 0.95

2200 0.40 0.95 0.05 0.67 0.70 1.12 0.35 0.96
2300 0.30 0.97 — — 0.60 1.17 0.15 0.97
2400 0.20 1.00 — — 0.48 1.20 — —

960 0.86 0.36 0.61 0.28 1.01 0.39 0.89 0.35
1020 0.82 0.37 0.62 0.28 0.99 0.41 0.91 0.47
1080 0.78 0.38 0.55 0.29 0.96 0.43 0.87 0.39
1140 0.74 0.39 0.47 0.29 0.93 0.44 0.82 0.40

1320 0.60 0.42 0.19 0.31 0.80 0.48 0.70 0.44
1380 0.54 0.42 0.10 0.31 0.75 0.49 0.64 0.45
1440 0.49 0.43 — — 0.69 0.52 0.59 0.48
1280 0.98 0.53 0.86 0.47 1.25 0.67 1.04 0.56
1360 0.92 0.54 0.80 0.47 1.20 0.68 0.99 0.58
1440 0.85 0.54 0.73 0.48 1.15 0.70 0.93 0.60
1520 0.78 0.55 0.65 0.48 1.10 0.73 0.86 0.63

1760 0.52 0.56 0.28 0.50 0.95 0.82 0.55 0.68
1840 0.42 0.57 0.18 0.50 0.88 0.83 0.40 0.70
1920 0.32 0.57 — — 0.80 0.85 — —
1600 0.95 0.78 0.87 0.64 1.25 0.90 1.10 0.85
1700 0.90 0.82 0.73 0.65 1.20 0.94 1.00 0.89
1800 0.85 0.85 0.61 0.65 1.10 0.98 0.90 0.91
1900 0.75 0.88 0.51 0.65 1.03 1.02 0.80 0.94

3

2000 0.65 0.90 0.35 0.66 0.95 1.05 0.70 0.95

2200 0.45 0.95 0.10 0.67 0.75 1.12 0.40 0.96
2300 0.35 0.97 — — 0.65 1.17 0.20 0.97
2400 0.25 1.00 — — 0.53 1.20 — —

External Static Pressure (Inches of Water) & Motor Power (Bhp)
Standard Motor Oversized Motor

Standard Efficiency

1

26

RT-PRC005-EN

Performance

(3 Ton)

Data

Standard Efficiency

Table PD-21 — Belt Drive Evaporator Fan Performance — 3 Ton — TSC036A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

960 — — 528 0.12 599 0.16 658 0.20 713 0.24 763 0.29 810 0.33 855 0.38 898 0.43 939 0.49
1080 — — 557 0.15 625 0.19 685 0.24 738 0.28 786 0.33 832 0.38 876 0.43 917 0.48 957 0.54
1200 — — 588 0.19 652 0.23 712 0.28 764 0.33 811 0.38 856 0.43 898 0.48 939 0.54 978 0.59
1320 552 0.18 622 0.23 681 0.27 738 0.32 790 0.38 838 0.44 882 0.49 923 0.55 962 0.60 1000 0.66
1440 588 0.23 657 0.28 713 0.33 765 0.37 817 0.43 865 0.50 909 0.56 949 0.62 987 0.68 1024 0.74

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK69 required. Field Supplied Belt may be necessary.

2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor

& Field Supplied
Low Static Drive (1) 1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-21 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

960 978 0.54 1016 0.60 1052 0.66 1086 0.72 1120 0.78
1080 995 0.59 1033 0.65 1069 0.71 1103 0.78 1136 0.84
1200 1015 0.65 1051 0.71 1086 0.77 1120 0.84 1154 0.91
1320 1036 0.72 1072 0.78 1106 0.85 1138 0.91 1171 0.98
1440 1060 0.80 1094 0.86 1128 0.93 1160 1.00 1192 1.07

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

1-HP Standard Motor &
Field Supplied High Static Drive (2)

Table PD-22 — Belt Drive Evaporator Fan Performance — 3 Ton — TSC036A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)

960 — — 588 0.15 661 0.19 725 0.24 782 0.29 832 0.35 878 0.40 919 0.46 958 0.51 996 0.56
1080 531 0.13 622 0.18 694 0.24 756 0.29 813 0.34 864 0.40 910 0.46 954 0.52 993 0.59 1031 0.65
1200 570 0.17 654 0.23 727 0.28 787 0.34 843 0.40 895 0.46 942 0.52 986 0.59 1026 0.66 1064 0.73
1320 610 0.22 687 0.28 760 0.34 821 0.40 875 0.46 925 0.53 973 0.59 1017 0.66 1058 0.73 1095 0.81
1440 651 0.27 723 0.33 793 0.40 855 0.47 908 0.53 956 0.60 1003 0.67 1047 0.75 1088 0.82 1127 0.89

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories.
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK69 required. Field Supplied Belt may be necessary.

2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

RT-PRC005-EN

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Table PD-22 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

960 1032 0.62 1066 0.67 1101 0.73 1133 0.79 1166 0.86
1080 1065 0.70 1099 0.76 1132 0.82 1164 0.89 1194 0.95
1200 1099 0.80 1133 0.86 1166 0.93 1197 0.99 1227 1.06
1320 1132 0.88 1167 0.96 1200 1.04 1230 1.11 1261 1.19
1440 1164 0.97 1199 1.05 1232 1.14 1263 1.22 1294 1.30

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

1-HP Standard Motor &
Field Supplied High Static Drive
(2)

1-HP Standard Motor &
Field Supplied High Static Drive (2)

27

Performance

(4 Ton)

Data

Standard Efficiency

Table PD-23 — Belt Drive Evaporator Fan Performance — 4 Ton — TSC048A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 — — 616 0.22 677 0.26 734 0.31 787 0.37 834 0.42 878 0.48 919 0.53 959 0.59 997 0.64
1440 596 0.23 663 0.29 719 0.33 772 0.38 823 0.44 871 0.51 914 0.57 954 0.63 993 0.69 1029 0.75
1600 647 0.31 711 0.37 764 0.42 813 0.47 860 0.53 906 0.59 951 0.66 992 0.74 1029 0.80 1065 0.87
1760 701 0.41 758 0.46 811 0.52 856 0.58 901 0.64 944 0.70 986 0.77 1027 0.85 1066 0.93 1102 1.00
1920 755 0.52 807 0.57 859 0.64 903 0.71 945 0.77 985 0.83 1024 0.89 1063 0.97 1101 1.05 1137 1.14

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK61 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-23 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 1033 0.70 1069 0.77 1103 0.83 1136 0.89 1170 0.96
1440 1066 0.81 1099 0.87 1133 0.94 1165 1.01 1196 1.08
1600 1099 0.93 1132 1.00 1166 1.07 1196 1.14 1228 1.21
1760 1136 1.08 1168 1.15 1200 1.22 1229 1.29 — —
1920 1172 1.23 1205 1.31 1236 1.39 — — — —

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Table PD-24 — Belt Drive Evaporator Fan Performance — 4 Ton — TSC048A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 604 0.20 683 0.26 756 0.32 816 0.39 869 0.45 920 0.51 967 0.57 1011 0.64 1052 0.71 1090 0.79
1440 660 0.28 731 0.34 800 0.41 862 0.48 914 0.54 963 0.61 1009 0.68 1053 0.76 1094 0.83 1133 0.91
1600 717 0.36 783 0.43 846 0.51 907 0.58 961 0.66 1008 0.73 1053 0.81 1095 0.89 1135 0.97 1174 1.05
1760 774 0.47 837 0.54 894 0.62 952 0.70 1006 0.79 1054 0.87 1098 0.95 1139 1.04 1178 1.12 1216 1.21
1920 833 0.59 892 0.67 946 0.76 998 0.85 1050 0.94 1100 1.03 1144 1.12 1185 1.21 1224 1.30 1259 1.39

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories.
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK61 required. Field Supplied Belt may be necessary.

2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.

Trane’s factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged
conditions. Using the full horsepower range of our fan motors as shown in our tabular
data will not result in nuisance tripping or premature motor failure. Our product’s
warranty will not be affected.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Table PD-24 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 1125 0.86 1160 0.94 1192 1.01 1223 1.08 1254 1.15
1440 1169 0.98 1204 1.07 1237 1.15 1269 1.23 1300 1.32
1600 1211 1.13 1247 1.21 1280 1.30 1312 1.39 1343 1.48
1760 1253 1.30 1289 1.39 1322 1.47 — — — —
1920 1295 1.48 — — — — — — — —

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

1-HP Standard Motor &
Field Supplied High Static Drive

External Static Pressure (Inches of Water)

1-HP Standard Motor &
Field Supplied High Static Drive

28

RT-PRC005-EN

Performance

(5 Ton)

Data

Standard Efficiency

Table PD-25— Belt Drive Evaporator Fan Performance — 5 Ton — TSC060A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1600 674 0.33 735 0.39 786 0.45 835 0.50 883 0.56 928 0.63 972 0.70 1011 0.77 1048 0.84 1084 0.90
1800 743 0.46 801 0.52 849 0.59 894 0.65 937 0.70 979 0.77 1021 0.85 1060 0.93 1098 1.01 1134 1.09
2000 813 0.61 866 0.68 914 0.76 956 0.83 995 0.89 1035 0.96 1073 1.02 1111 1.10 1147 1.19 1183 1.28
2200 886 0.80 933 0.87 980 0.96 1019 1.03 1057 1.11 1093 1.18 1129 1.25 1164 1.33 1198 1.40 1233 1.50
2400 959 1.03 1000 1.10 1045 1.19 1085 1.28 1121 1.36 1154 1.45 1188 1.53 1221 1.60 — — — —

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK56 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-25 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1600 1117 0.97 1150 1.04 1183 1.11 1215 1.18 1244 1.25
1800 1167 1.16 1199 1.24 1230 1.31 1259 1.39 1289 1.47
2000 1216 1.37 1249 1.47 — — — — — —
2200 — — — — — — — — — —
2400 — — — — — — — — — —

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Table PD-26 — Belt Drive Evaporator Fan Performance — 5 Ton — TSC060A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)

1600 746 0.39 812 0.47 876 0.54 934 0.62 985 0.70 1032 0.77 1074 0.85 1117 0.93 1157 1.01 1196 1.09
1800 824 0.54 883 0.62 940 0.70 996 0.79 1048 0.88 1094 0.96 1137 1.05 1176 1.14 1214 1.22 1252 1.31
2000 902 0.72 957 0.80 1008 0.90 1059 0.99 1110 1.09 1157 1.19 1200 1.28 1239 1.38 1276 1.47 1311 1.50

22009810.9310321.0310801.1311261.2311731.3412191.44————————

240010611.1911091.2911531.4011961.50 —— —— ————————

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories.
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK56 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-26 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1600 1232 1.18 1267 1.26 1299 1.35 1332 1.45 — —
1800 1289 1.41 1323 1.50 — — — — — —
2000 — — — — — — — — — —
2200 — — — — — — — — — —
2400 — — — — — — — — — —

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

RT-PRC005-EN

29

Performance

(6 Ton)

Data

Standard Efficiency

Table PD-27 — Belt Drive Evaporator Fan Performance — 6-Ton — TSC072A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)

1920 — — — — 573 0.34 630 0.41 680 0.48 726 0.55 769 0.62 811 0.70 851 0.78 889 0.87
2160 — — 548 0.35 602 0.42 656 0.50 706 0.58 751 0.65 792 0.73 832 0.81 871 0.90 908 0.99
2400 — — 584 0.45 635 0.52 682 0.60 732 0.69 777 0.77 818 0.86 856 0.95 893 1.04 930 1.13
2640 569 0.47 621 0.56 670 0.64 715 0.72 758 0.81 802 0.91 845 1.01 883 1.10 919 1.20 953 1.29
2880 612 0.60 660 0.69 706 0.78 749 0.86 789 0.96 830 1.06 870 1.16 909 1.27 945 1.37 979 1.48

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
1-HP Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
2-HP Fan Motor Heat (MBH) = 3.000 x Fan BHP+.5000

1. Field Supplied Fan Sheave AK84 and Belt AX34 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-27 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1 HP Standard Motor & Drive 1HP Standard Motor & High Static Drive Kit

1920 925 0.95 960 1.03 994 1.11 1026 1.19 1057 1.27 1087 1.36 1116 1.44 1144 1.52 1173 1.61 1200 1.70
21 6 0 9 44 1. 08 9 7 8 1. 17 101 0 1. 2 6 104 3 1. 36 10 7 3 1. 44 1104 1. 54 11 33 1. 6 3 11 62 1.7 2 11 89 1. 8 1 1 21 6 1. 91
2400 964 1.22 998 1.32 1030 1.42 1063 1.53 1092 1.63 1123 1.73 1151 1.83 1179 1.93 1206 2.03 1233 2.13
2640 986 1.39 1019 1.49 1051 1.60 1082 1.71 1112 1.81 1141 1.92 1169 2.03 1198 2.15 1225 2.26 — —
2880 1011 1.58 1043 1.69 1073 1.79 1103 1.90 1133 2.02 1161 2.13 1190 2.26 — — — — — —

2 HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

(or 2 HP Oversized Motor & Drive)

Table PD-28 — Belt Drive Evaporator Fan Performance — 6-Ton — TSC072A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1920 — — 565 0.31 627 0.39 679 0.45 726 0.52 771 0.60 814 0.69 857 0.77 899 0.85 939 0.93
2160 566 0.35 609 0.41 663 0.48 716 0.57 762 0.64 804 0.72 843 0.80 883 0.90 922 0.99 960 1.08
2400 619 0.47 660 0.54 701 0.60 751 0.69 798 0.78 839 0.87 877 0.95 914 1.04 950 1.14 984 1.24
2640 672 0.61 710 0.68 745 0.76 788 0.83 833 0.93 875 1.04 914 1.13 949 1.22 984 1.31 1016 1.42
2880 726 0.77 762 0.86 795 0.94 828 1.02 869 1.11 911 1.21 950 1.33 986 1.44 1019 1.53 1051 1.63

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop
due to other options/accessories.
1-HP Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
2-HP Fan Motor Heat (MBH) = 3.000 x Fan BHP+.5000

1. Field Supplied Fan Sheave AK84 and Belt AX34 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor
& Field Supplied
Low Static Drive (1)

External Static Pressure (Inches of Water)

1-HP Standard Motor & Drive

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range
of our fan motors as shown in our tabular data will not result in nuisance
tripping or premature motor failure. Our product’s warranty will not be
affected.

2-HP Oversized
Motor & Drive

1HP Standard Motor & High Static Drive
Kit(or 2 HP Oversized Motor & Drive)

Table PD-28 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard 1-HP Standard Motor & High Static Drive Kit
Motor& Drive (or 2 HP oversized Motor& Drive)

1920 978 1.02 1015 1.11 1051 1.20 1086 1.30 1118 1.39 1150 1.49 1180 1.58 1209 1.68 1236 1.77 1263 1.86
21 6 0 9 96 1. 17 10 34 1. 27 10 6 9 1. 36 1103 1. 46 11 36 1. 5 6 116 9 1. 67 119 9 1. 7 7 1 22 9 1. 88 1 25 8 1. 9 8 — —
2400 1020 1.35 1055 1.45 1089 1.55 1122 1.66 1154 1.76 1186 1.86 1216 1.97 1246 2.08 1276 2.20 — —
2640 1049 1.53 1081 1.65 1113 1.76 1144 1.87 1176 1.98 1207 2.10 1237 2.21 — — — — — —
2880 1081 1.74 1112 1.86 1141 1.97 1170 2.10 1199 2.22 — — ————————

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

2-HP Oversized Motor & Drive

30

External Static Pressure (Inches of Water)

RT-PRC005-EN

Performance

(6 Ton)

Data

Standard Efficiency

Table PD-29 — Belt Drive Evaporator Fan Performance — 6-Ton — TSC072,AK — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1920 - - - - 573 0.34 630 0.41 680 0.48 726 0.55 769 0.62 811 0.70 851 0.78 889 0.87
2160 - - 548 0.35 602 0.42 656 0.50 706 0.58 751 0.65 792 0.73 832 0.81 871 0.90 908 0.99
2400 - - 584 0.45 635 0.52 682 0.60 732 0.69 777 0.77 818 0.86 856 0.95 893 1.04 930 1.13
2640 569 0.47 621 0.56 670 0.64 715 0.72 758 0.81 802 0.91 845 1.01 883 1.10 919 1.20 953 1.29
2880 612 0.60 660 0.69 706 0.78 749 0.86 789 0.96 830 1.06 870 1.16 909 1.27 945 1.37 979 1.48

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 3.000 x Fan BHP+.5000

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied Low Static Drive (1) 2-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-29 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2- HP Standard Motor & Drive 2-HP Standard Motor & High Static Drive

1920 925 0.95 960 1.03 994 1.11 1026 1.19 1057 1.27 1087 1.36 1116 1.44 1144 1.52 1173 1.61 1200 1.70
2160 944 1.08 978 1.17 1010 1.26 1043 1.36 1073 1.44 1104 1.54 1133 1.63 1162 1.72 1189 1.81 1216 1.91
2400 964 1.22 998 1.32 1030 1.42 1063 1.53 1092 1.63 1123 1.73 1151 1.83 1179 1.93 1206 2.03 1233 2.13
2640 986 1.39 1019 1.49 1051 1.60 1082 1.71 1112 1.81 1141 1.92 1169 2.03 1198 2.15 1225 2.26 - ­2880 1011 1.58 1043 1.69 1073 1.79 1103 1.90 1133 2.02 1161 2.13 1190 2.26 - - - - - -

2- HP Standard Motor & High Static Drive

External Static Pressure (Inches of Water)

Table PD-30 — Belt Drive Evaporator Fan Performance — 6-Ton — TSC072,AK — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1920 - - 565 0.31 627 0.39 679 0.45 726 0.52 771 0.60 814 0.69 857 0.77 899 0.85 939 0.93
2160 566 0.35 609 0.41 663 0.48 716 0.57 762 0.64 804 0.72 843 0.80 883 0.90 922 0.99 960 1.08
2400 619 0.47 660 0.54 701 0.60 751 0.69 798 0.78 839 0.87 877 0.95 914 1.04 950 1.14 984 1.24
2640 672 0.61 710 0.68 745 0.76 788 0.83 833 0.93 875 1.04 914 1.13 949 1.22 984 1.31 1016 1.42
2880 726 0.77 762 0.86 795 0.94 828 1.02 869 1.11 911 1.21 950 1.33 986 1.44 1019 1.53 1051 1.63

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 3.000 x Fan BHP+.5000

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied Low Static Drive (1) 2-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range
of our fan motors as shown in our tabular data will not result in nuisance
tripping or premature motor failure. Our product’s warranty will not be
affected.

Table PD-30 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2- HP Standard Motor & Drive 2-HP Standard Motor & High Static Drive

1920 978 1.02 1015 1.11 1051 1.20 1086 1.30 1118 1.39 1150 1.49 1180 1.58 1209 1.68 1236 1.77 1263 1.86
2160 996 1.17 1034 1.27 1069 1.36 1103 1.46 1136 1.56 1169 1.67 1199 1.77 1229 1.88 1258 1.98 - ­2400 1020 1.35 1055 1.45 1089 1.55 1122 1.66 1154 1.76 1186 1.86 1216 1.97 1246 2.08 1276 2.20 - ­2640 1049 1.53 1081 1.65 1113 1.76 1144 1.87 1176 1.98 1207 2.10 1237 2.21 - - - - - ­2880 1081 1.74 1112 1.86 1141 1.97 1170 2.10 1199 2.22 - - --------

2- HP Standard Motor & High Static Drive

External Static Pressure (Inches of Water)

RT-PRC005-EN

31

Performance

(7½ Ton)

Data

Standard Efficiency

Table PD-31 — Belt Drive Evaporator Fan Performance — 7½-Ton — TSC090,092A3,A4,AW,AK — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2400 — — — — 652 0.54 701 0.63 750 0.72 794 0.81 834 0.90 873 0.98 909 1.08 945 1.17
2700 — — 652 0.63 699 0.70 743 0.79 787 0.89 830 0.99 871 1.09 908 1.19 943 1.29 977 1.39
3000 656 0.71 703 0.81 747 0.91 789 0.99 827 1.10 867 1.20 906 1.31 944 1.43 980 1.54 1013 1.65
3300 713 0.93 755 1.03 797 1.15 836 1.24 873 1.34 908 1.45 944 1.57 980 1.69 1016 1.82 1050 1.94
3600 771 1.19 809 1.29 848 1.42 885 1.53 921 1.63 954 1.74 986 1.87 1019 1.99 1052 2.13 1085 2.26

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories.
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750.

1. Field Supplied Motor Sheave 1VL40L x 7/8 and Fan
Sheave AK71 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied Low Static Drive (1) 2-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-31 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2- HP Standard Motor & Drive 2-HP Standard Motor & High Static Drive

2400 980 1.27 1013 1.37 1046 1.47 1076 1.57 1106 1.68 1137 1.78 1166 1.89 1194 1.99 1220 2.08 1248 2.19
27 00 1010 1.4 9 104 3 1. 60 1074 1.71 110 5 1.8 2 11 34 1. 93 11 63 2 .04 1192 2 .16 1 219 2 .27 1 246 2. 39 12 73 2.5 1
3000 1045 1.76 1076 1.87 1105 1.98 1134 2.09 1163 2.21 1192 2.34 1219 2.45 1247 2.58 1272 2.71 1299 2.84
3300 1081 2.06 1111 2.18 1141 2.30 1168 2.42 1197 2.55 1222 2.66 1249 2.79 1276 2.92 1301 3.06 1326 3.19
3600 1116 2.39 1148 2.53 1177 2.66 1204 2.79 1232 2.93 1257 3.05 1283 3.19 1309 3.32 — — — —

External Static Pressure (Inches of Water)

Kit (or 3-HP Oversized Motor & Drive)

3-HP Oversized Motor & Drive

Table PD-32 — Belt Drive Evaporator Fan Performance — 7½-Ton — TSC090,092A3,A4,AW,AK — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2-HP Standard Motor & Field Supplied 2-HP Standard Motor & Drive
Low Static Drive (1)

2400 — — 673 0.56 718 0.63 769 0.72 814 0.82 855 0.90 893 0.98 929 1.08 965 1.18 999 1.29
2700 702 0.68 738 0.76 773 0.83 817 0.92 862 1.02 904 1.13 941 1.23 975 1.32 1009 1.42 1041 1.52
3000 771 0.91 805 1.00 837 1.08 870 1.17 912 1.26 951 1.38 989 1.51 1025 1.62 1056 1.72 1088 1.82
3300 842 1.19 873 1.29 903 1.38 930 1.47 963 1.57 100 0 1.68 1037 1.80 1073 1.94 1106 2.08 1136 2.19
3600 913 1.53 942 1.63 970 1.74 996 1.84 1021 1.94 1052 2.04 1086 2.16 1121 2.29 1153 2.44 1184 2.59

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop
due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750.

1. Field Supplied Motor Sheave 1VL40L x 7/8 and Fan Sheave AK71 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

3-HP Oversized Motor

& Drive

2-HP Standard Motor & High Static
Drive Kit (or 3-HP Oversized Motor)

Table PD-32 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2400 1035 1.39 1070 1.50 1104 1.60 1137 1.70 1168 1.81 1201 1.92 1232 2.03 1261 2.14 1291 2.26 1319 2.38
2700 1073 1.64 1104 1.76 1136 1.87 1167 1.99 1198 2.11 1228 2.22 1258 2.34 1287 2.46 1315 2.58 1343 2.69
3000 1117 1.93 1146 2.05 1176 2.17 1205 2.31 1233 2.44 1261 2.56 1289 2.69 1317 2.82 1344 2.95 1372 3.08
3300 1165 2.30 1194 2.41 1220 2.52 1248 2.66 1275 2.79 1301 2.93 1326 3.07 1352 3.22 1378 3.36 — —

360012152.7312422.8612692.9812953.1013193.2213453.35————————

2-HP Standard Motor & Drive (or 3-HP Oversized Motor & Drive)

External Static Pressure (Inches of Water)

2-HP Standard Motor & High Static Drive Kit

3-HP Oversized Motor & Drive

32

RT-PRC005-EN

Performance

(8½ Ton)

Data

Standard Efficiency

Table PD-33— Belt Drive Evaporator Fan Performance — 8½-Ton — TSC102A3,A4,AW, AK —DownflowAirflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 — — — — — — 613 0.60 655 0.72 695 0.84 733 0.95 769 1.08 802 1.21 833 1.34
3060 — — — — 611 0.64 650 0.74 688 0.85 725 0.98 761 1.11 796 1.25 828 1.38 861 1.52
3400 — — 612 0.68 651 0.79 689 0.91 724 1.02 759 1.15 792 1.29 825 1.43 856 1.58 887 1.72
3740 622 0.76 659 0.86 693 0.97 729 1.10 764 1.23 795 1.35 826 1.49 857 1.64 887 1.79 916 1.96
4080 671 0.96 706 1.08 738 1.19 770 1.32 804 1.46 834 1.60 864 1.74 892 1.88 920 2.04 948 2.20

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to stnadard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750.

1. Field Supplied Fan Sheave AK79 and Belt AX38 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied 2-HP Standard Motor

Low Static Drive (1) & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-33 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 863 1.48 892 1.63 920 1.78 946 1.93 973 2.08 999 2.24 1025 2.39 1050 2.55 1073 2.71 1098 2.88
3060 891 1.66 919 1.81 946 1.96 973 2.12 999 2.29 1024 2.46 1048 2.63 1072 2.80 1096 2.98 1119 3.14
3400 917 1.87 946 2.03 974 2.18 1001 2.34 1026 2.52 1051 2.69 1074 2.86 1099 3.05 1121 3.23 1143 3.41
3740 945 2.11 974 2.28 1001 2.44 1028 2.61 1054 2.78 1079 2.96 1103 3.14 1126 3.32 — — — —
4080 976 2.38 1002 2.56 1029 2.73 1055 2.91 1081 3.09 1105 3.26 1130 3.45 — — — — — —

2-HP Standard Motor & Drive 3-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

Table PD-34 — Belt Drive Evaporator Fan Performance — 8½-Ton — TSC102A3,A4,AW, AK —Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 — — 598 0.57 646 0.67 689 0.78 734 0.90 781 1.04 826 1.18 865 1.31 898 1.44 928 1.56
3060 616 0.69 654 0.77 693 0.86 735 0.98 773 1.10 812 1.23 855 1.39 897 1.55 934 1.70 969 1.85
3400 675 0.92 711 1.01 743 1.10 781 1.22 819 1.36 853 1.49 886 1.62 925 1.79 964 1.97 1000 2.14
3740 735 1.20 770 1.30 799 1.40 830 1.51 865 1.65 899 1.79 930 1.94 960 2.09 994 2.26 1028 2.44
4080 796 1.53 828 1.65 857 1.76 883 1.86 913 1.99 945 2.15 977 2.30 1006 2.47 1034 2.63 1061 2.79

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750.

1. Field Supplied Fan Sheave AK79 and Belt AX38 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied 2-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

3-HP Oversized Motor & Drive

Table PD-34 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 956 1.67 982 1.79 1008 1.91 1033 2.03 1056 2.14 1079 2.26 1102 2.38 1125 2.50 1146 2.62 1168 2.74
3060 999 1.99 1026 2.12 1052 2.26 1078 2.39 1101 2.52 1124 2.66 1146 2.79 1168 2.92 1188 3.05 1209 3.18
3400 1034 2.32 1067 2.49 1094 2.64 1120 2.79 1145 2.94 1168 3.09 1191 3.24 1213 3.39 — — — —
3740 1063 2.63 1098 2.84 1129 3.03 1158 3.21 1185 3.39 — — ————————
4080 1093 2.99 1125 3.19 1157 3.40 — — — — — — ————————

RT-PRC005-EN

2-HP Standard Motor & Drive 3-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

33

Performance

(10 Ton)

Data

Standard Efficiency

Table PD-35 — Belt Drive Evaporator Fan Performance — 10-Ton — TSC120A3,A4,AW,AK — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3200 — — — — — — — — 718 0.97 754 1.10 789 1.25 822 1.38 856 1.53 887 1.67
3600 — — — — — — 731 1.08 764 1.20 797 1.33 829 1.48 860 1.63 892 1.79 922 1.95
4000 — — 715 1.09 747 1.21 782 1.35 814 1.49 844 1.63 874 1.77 903 1.93 932 2.09 960 2.27
4400 741 1.27 773 1.40 803 1.53 834 1.67 864 1.82 894 1.98 922 2.13 948 2.28 975 2.44 1001 2.62
4800 803 1.62 833 1.76 861 1.90 887 2.04 916 2.20 945 2.38 972 2.55 997 2.71 1022 2.87 1046 3.04

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop
due to other options/accessories
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.
5-HP Fan Motor Heat (MBH) = 2.950 x Fan BHP+.470.

1. Field Supplied Motor Sheave 1VM50 x 7/8”, Fan Sheave AK89 and Belt AX40 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

3-HP Standard Motor & Field Supplied

Low Static Drive (1)

External Static Pressure (Inches of Water)

3-HP Standard Motor & Drive

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-35 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3200 917 1.82 945 1.97 973 2.14 999 2.30 1024 2.47 1048 2.65 1072 2.82 1095 3.00 1117 3.17 1140 3.36
3600 951 2.11 979 2.27 1007 2.43 1033 2.60 1059 2.78 1082 2.95 1107 3.14 1130 3.33 1152 3.52 1173 3.71
4000 988 2.44 1015 2.62 1042 2.79 1068 2.97 1093 3.15 1117 3.33 1142 3.52 1164 3.70 1187 3.91 1209 4.11
4400 1028 2.81 1053 3.00 1078 3.19 1103 3.38 1128 3.57 1152 3.77 1176 3.96 1198 4.15 1221 4.36 1243 4.56
4800 1071 3.23 1095 3.42 1119 3.62 1142 3.83 1166 4.04 1189 4.25 1212 4.46 1233 4.66 1256 4.88 1277 5.09

3-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

5-HP Oversized Motor & Drive

Table PD-36— Belt Drive Evaporator Fan Performance — 10-Ton — TSC120A3,A4,AW,AK — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3200 — — — — 730 1.00 771 1.13 807 1.26 844 1.39 886 1.55 926 1.72 965 1.89 1000 2.06
3600 729 1.13 761 1.22 792 1.32 829 1.45 865 1.60 898 1.74 930 1.89 965 2.06 1002 2.24 1038 2.43
4000 802 1.52 833 1.63 860 1.73 890 1.86 923 2.01 956 2.17 986 2.32 1015 2.48 1044 2.65 1077 2.85
4400 876 1.99 905 2.12 931 2.24 955 2.35 983 2.49 1014 2.66 1045 2.84 1072 3.01 1098 3.18 1125 3.36
4800 950 2.56 977 2.70 1002 2.84 1025 2.96 1048 3.08 1074 3.24 1102 3.43 1131 3.63 1156 3.81 1181 4.00

For Standard Evaporator Fan Speed (RPM), reference Table PD-48.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.
5-HP Fan Motor Heat (MBH) = 2.950 x Fan BHP+.470.

1. Field Supplied Motor Sheave 1VM50 x 7/8”, Fan
Sheave AK89 and Belt AX40 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

3-HP Standard Motor & Field Supplied

Low Static Drive (1)

3-HP Standard Motor & Drive 5-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-36 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3200 1029 2.20 1057 2.35 1084 2.49 1108 2.63 1132 2.77 1155 2.91 1177 3.05 1198 3.18 1219 3.32 1239 3.46
3600 1072 2.62 1106 2.81 1134 2.98 1160 3.15 1185 3.31 1209 3.47 1231 3.63 1252 3.78 1274 3.94 1295 4.10
4000 1111 3.05 1143 3.26 1174 3.47 1204 3.68 1232 3.88 1260 4.09 1283 4.27 1306 4.46 1327 4.63 1349 4.81
4400 1152 3.55 1182 3.76 1211 3.99 1241 4.21 1270 4.44 1299 4.68 1327 4.91 1352 5.14 1377 5.37 1400 5.57
4800 1205 4.19 1229 4.39 1253 4.58 1280 4.81 1309 5.06 1336 5.31 1363 5.56 — — — — — —

3-HP Standard Motor & Drive

5-HP Oversized Motor & Drive

34

External Static Pressure (Inches of Water)

RT-PRC005-EN

Performance

(3, 4, 5 Ton)

Data

High Efficiency

Table PD-37— Direct Drive Evaporator Fan Performance — 3, 4, and 5 Ton — THC036A, THC048A,
THC060A

External Static Pressure (Inches of Water) & Motor Power (Bhp)

Unit High Speed Low Speed High Speed Low Speed

Tons Model No. CFM ESP BHP ESP BHP ESP BHP ESP BHP

3 THC036A 1200 0.55 0.40 0.29 0.30 0.74 0.44 0.65 0.41

Horizontal 1260 0.51 0.41 0.19 0.30 0.70 0.45 0.61 0.42

4 THC048A 1600 0.60 0.55 0.44 0.49 0.94 0.75 0.68 0.64

Horizontal 1680 0.51 0.56 0.32 0.49 0.89 0.78 0.59 0.66

5 THC060A 2000 0.74 0.90 0.45 0.66 1.03 1.05 0.81 0.95

Horizontal 2100 0.64 0.93 0.30 0.66 0.94 1.10 0.68 0.96

3 THC036A 1200 0.60 0.40 0.34 0.30 0.79 0.44 0.70 0.41

Downflow 1260 0.56 0.41 0.24 0.30 0.75 0.45 0.66 0.42

4 THC048A 1600 0.65 0.55 0.49 0.49 0.99 0.75 0.73 0.64

Downflow 1680 0.56 0.56 0.37 0.49 0.94 0.78 0.64 0.66

5 THC060A 2000 0.79 0.90 0.50 0.66 1.08 1.05 0.86 0.95

Downflow 2100 0.69 0.93 0.35 0.66 0.99 1.10 0.73 0.96

Fan motor heat (MBH) = 3.72 x Fan Bhp + .24.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate
reliably and continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will
not result in nuisance tripping or premature motor failure. Our product’s warranty will not be affected.
NOTE:

1. Data includes pressure drop due to wet coil and filters.

2. 5 ton oversized motor performance is with 12 x 11 FC blower wheel.

960 0.74 0.36 0.56 0.28 0.89 0.38 0.82 0.35
1020 0.69 0.37 0.49 0.28 0.85 0.39 0.77 0.36
1080 0.65 0.38 0.44 0.29 0.82 0.41 0.74 0.38
1140 0.61 0.39 0.37 0.29 0.77 0.43 0.69 0.40

1320 0.46 0.42 0.10 0.31 0.67 0.47 0.57 0.44
1380 0.41 0.43 0.00 0.31 0.64 0.48 0.52 0.45
1440 0.34 0.44 — — 0.57 0.51 0.45 0.48

1280 0.90 0.53 0.79 0.47 1.16 0.67 0.95 0.56
1360 0.83 0.54 0.71 0.47 1.11 0.68 0.90 0.58
1440 0.76 0.54 0.65 0.48 1.06 0.70 0.85 0.60
1520 0.69 0.55 0.56 0.48 1.01 0.73 0.77 0.63

1760 0.42 0.56 0.17 0.50 0.84 0.82 0.42 0.68
1840 0.31 0.57 0.05 0.50 0.75 0.83 0.29 0.70
1920 0.21 0.57 — — 0.67 0.85 0.18 0.73
1600 1.04 0.78 0.94 0.64 1.37 0.90 1.23 0.85
1700 0.97 0.80 0.81 0.65 1.29 0.94 1.13 0.89
1800 0.92 0.85 0.70 0.65 1.21 0.98 1.02 0.91
1900 0.82 0.88 0.61 0.65 1.20 1.02 0.92 0.94

2200 0.51 0.94 0.15 0.67 0.83 1.12 0.47 0.96
2300 0.42 0.95 — — 0.73 1.17 0.23 0.97
2400 0.31 0.97 — — 0.60 1.20 — —

960 0.79 0.36 0.56 0.28 0.94 0.38 0.82 0.35
1020 0.74 0.37 0.54 0.28 0.90 0.39 0.82 0.36
1080 0.70 0.38 0.49 0.29 0.87 0.41 0.79 0.38
1140 0.66 0.39 0.42 0.29 0.82 0.43 0.74 0.40

1320 0.51 0.42 0.15 0.31 0.72 0.47 0.62 0.44
1380 0.46 0.43 0.05 0.31 0.69 0.48 0.57 0.45
1440 0.39 0.44 — — 0.62 0.51 0.50 0.48
1280 0.95 0.53 0.84 0.47 1.21 0.67 1.00 0.56
1360 0.88 0.54 0.76 0.47 1.16 0.68 0.95 0.58
1440 0.81 0.54 0.70 0.48 1.11 0.70 0.90 0.60
1520 0.74 0.55 0.61 0.48 1.06 0.73 0.82 0.63

1760 0.47 0.56 0.22 0.50 0.89 0.82 0.47 0.68
1840 0.36 0.57 0.10 0.50 0.80 0.83 0.34 0.70
1920 0.26 0.57 — — 0.72 0.85 — —

1600 1.09 0.78 0.99 0.64 1.42 0.90 1.28 0.85
1700 1.02 0.80 0.86 0.65 1.34 0.94 1.18 0.89
1800 0.97 0.85 0.75 0.65 1.26 0.98 1.07 0.91
1900 0.87 0.88 0.66 0.65 1.25 1.02 0.97 0.94

2200 0.56 0.94 0.20 0.67 0.88 1.12 0.52 0.96
2300 0.47 0.95 — — 0.78 1.17 0.28 0.97
2400 0.36 0.97 — — 0.65 1.20 — —

Standard Motor Oversized Motor

1

RT-PRC005-EN

35

Performance

(3 Ton)

Data

High Efficiency

Table PD-38 — Belt Drive Evaporator Fan Performance — 3 Ton — THC036A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

960 — — 528 0.12 599 0.16 658 0.20 713 0.24 763 0.29 810 0.33 855 0.38 898 0.43 939 0.49
1080 — — 557 0.15 625 0.19 685 0.24 738 0.28 786 0.33 832 0.38 876 0.43 917 0.48 957 0.54
1200 — — 588 0.19 652 0.23 712 0.28 764 0.33 811 0.38 856 0.43 898 0.48 939 0.54 978 0.59
1320 552 0.18 622 0.23 681 0.27 738 0.32 790 0.38 838 0.44 882 0.49 923 0.55 962 0.60 1000 0.66
1440 588 0.23 657 0.28 713 0.33 765 0.37 817 0.43 865 0.50 909 0.56 949 0.62 987 0.68 1024 0.74

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK69 required. Field Supplied Belt may be necessary.

2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor

& Field Supplied
Low Static Drive (1) 1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-38 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

960 978 0.54 1016 0.60 1052 0.66 1086 0.72 1120 0.78
1080 995 0.59 1033 0.65 1069 0.71 1103 0.78 1136 0.84
1200 1015 0.65 1051 0.71 1086 0.77 1120 0.84 1154 0.91
1320 1036 0.72 1072 0.78 1106 0.85 1138 0.91 1171 0.98
1440 1060 0.80 1094 0.86 1128 0.93 1160 1.00 1192 1.07

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

1-HP Standard Motor &
Field Supplied High Static Drive (2)

Table PD-39— Belt Drive Evaporator Fan Performance — 3 Ton — THC036A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)

960 — — 588 0.15 661 0.19 725 0.24 782 0.29 832 0.35 878 0.40 919 0.46 958 0.51 996 0.56
1080 531 0.13 622 0.18 694 0.24 756 0.29 813 0.34 864 0.40 910 0.46 954 0.52 993 0.59 1031 0.65
1200 570 0.17 654 0.23 727 0.28 787 0.34 843 0.40 895 0.46 942 0.52 986 0.59 1026 0.66 1064 0.73
1320 610 0.22 687 0.28 760 0.34 821 0.40 875 0.46 925 0.53 973 0.59 1017 0.66 1058 0.73 1095 0.81
1440 651 0.27 723 0.33 793 0.40 855 0.47 908 0.53 956 0.60 1003 0.67 1047 0.75 1088 0.82 1127 0.89

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.

NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK69 required. Field Supplied Belt may be necessary.

2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

36

External Static Pressure (Inches of Water)

Table PD-39— Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

960 1032 0.62 1066 0.67 1101 0.73 1133 0.79 1166 0.86
1080 1065 0.70 1099 0.76 1132 0.82 1164 0.89 1194 0.95
1200 1099 0.80 1133 0.86 1166 0.93 1197 0.99 1227 1.06
1320 1132 0.88 1167 0.96 1200 1.04 1230 1.11 1261 1.19
1440 1164 0.97 1199 1.05 1232 1.14 1263 1.22 1294 1.30

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

1-HP Standard Motor &

Field Supplied High Static Drive (2)

External Static Pressure (Inches of Water)

1-HP Standard Motor &
Field Supplied High Static Drive (2)

RT-PRC005-EN

Performance

(4 Ton)

Data

High Efficiency

Table PD-40 — Belt Drive Evaporator Fan Performance — 4 Ton — THC048A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 — — 626 0.23 686 0.27 744 0.32 796 0.38 843 0.43 885 0.49 927 0.54 967 0.60 1005 0.66
1440 609 0.24 674 0.30 730 0.34 783 0.39 834 0.45 882 0.52 924 0.58 964 0.64 1002 0.70 1038 0.76
1600 661 0.32 724 0.38 776 0.44 825 0.49 872 0.54 919 0.61 962 0.68 1002 0.75 1039 0.82 1076 0.89
1760 716 0.42 775 0.48 825 0.54 870 0.60 915 0.66 958 0.72 999 0.79 1040 0.87 1078 0.95 1113 1.03
1920 771 0.53 825 0.59 875 0.66 918 0.73 959 0.79 1000 0.86 1039 0.92 1078 1.00 1116 1.09 1151 1.17

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK61 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-40 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 1041 0.72 1076 0.78 1110 0.84 1143 0.91 1176 0.98
1440 1074 0.83 1108 0.89 1141 0.96 1174 1.03 1205 1.10
1600 1109 0.95 1142 1.02 1175 1.09 1207 1.17 1236 1.24
1760 1147 1.10 1179 1.17 1211 1.25 1241 1.32 — —
1920 1186 1.26 1218 1.34 1249 1.42 — — — —

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

Table PD-41 — Belt Drive Evaporator Fan Performance — 4 Ton — THC048A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)

1280 617 0.21 696 0.27 767 0.34 826 0.40 879 0.46 930 0.52 976 0.59 1020 0.66 1060 0.73 1098 0.80
1440 674 0.29 745 0.35 815 0.42 874 0.49 925 0.56 974 0.63 1020 0.70 1064 0.77 1104 0.85 1142 0.92
1600 733 0.38 799 0.45 862 0.53 922 0.60 975 0.68 1020 0.75 1065 0.83 1107 0.91 1147 0.99 1186 1.07
1760 793 0.49 854 0.56 911 0.65 969 0.73 1023 0.82 1069 0.90 1112 0.98 1152 1.07 1191 1.15 1230 1.24
1920 853 0.62 911 0.70 964 0.79 1018 0.88 1069 0.97 1118 1.06 1161 1.15 1201 1.25 1239 1.34 1275 1.43

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK61 required. Field Supplied Belt may be necessary.

2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Table PD-41 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1280 1132 0.88 1167 0.95 1199 1.03 1231 1.10 1260 1.17
1440 1179 1.01 1213 1.09 1245 1.17 1277 1.26 1307 1.34
1600 1223 1.15 1258 1.24 1291 1.33 1322 1.42 — —

176012671.3313011.42 —— —— ——
1920 —— —— —— —— ——

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor

1-HP Standard Motor &

1-HP Standard Motor & Field
Supplied High Static Drive (2)

External Static Pressure (Inches of Water)

Field Supplied High Static Drive(2)

RT-PRC005-EN

37

Performance

(5 Ton)

Data

High Efficiency

Table PD-42— Belt Drive Evaporator Fan Performance — 5 Ton — THC060A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1600 — — 703 0.36 757 0.41 806 0.47 854 0.52 899 0.58 944 0.65 985 0.73 1023 0.79 1060 0.86
1800 706 0.42 760 0.47 815 0.54 861 0.60 904 0.66 947 0.72 988 0.78 1028 0.86 1067 0.94 1104 1.02
2000 773 0.57 821 0.62 873 0.69 918 0.76 958 0.83 998 0.90 1036 0.96 1073 1.02 1111 1.10 1147 1.19
2200 840 0.75 885 0.80 930 0.87 977 0.95 1016 1.03 1053 1.10 1089 1.17 1124 1.24 1158 1.31 1191 1.39
2400 909 0.96 950 1.02 990 1.08 1034 1.16 1074 1.25 1110 1.00 1143 1.42 1177 1.50 — — — —

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK56 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-42 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1600 1093 0.92 1126 0.99 1160 1.06 1190 1.13 1222 1.20
1800 1138 1.10 1171 1.17 1203 1.25 1232 1.32 1262 1.39
2000 1182 1.28 1215 1.37 1246 1.46 — — — —
2200 1226 1.48 — — — — — — — —
2400 — — — — — — — — — —

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

PD-43 — Belt Drive Evaporator Fan Performance — 5 Ton — THC060A3,A4,AW — Downflow Airflow — Dehumidification (Hot Gas Reheat)

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1000 — — 537 0.13 608 0.17 667 0.21 721 0.25 770 0.30 817 0.35 861 0.39 905 0.45 944 0.50
1200 517 0.15 588 0.19 652 0.23 712 0.28 764 0.33 811 0.38 856 0.43 898 0.48 939 0.54 978 0.59
1400 576 0.21 645 0.26 702 0.31 756 0.36 808 0.41 856 0.48 900 0.54 941 0.59 979 0.65 1017 0.71
1600 640 0.31 703 0.36 757 0.41 806 0.47 854 0.52 899 0.58 944 0.65 985 0.73 1023 0.79 1060 0.86

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.

NOTES:

Data includes pressure drop due to standard filters and wet coils.
Data does not include pressure drop due to reheat coil.
1 HP Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. BAYLSDR008A Required.

2. BAYLSDR008A Required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Low

Static Drive Accessory Kit (1)

External Static Pressure (Inches of Water)

1-HP Standard Motor & Low
Static Drive Accessory Kit (2)

1-HP Standard
Motor & Drive

Trane’s factory supplied motors, in commercial equipment, are
definite purpose motors, specifically designed and tested to
operate reliably and continuously at all cataloged conditions.
Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature
motor failure. Our product’s warranty will not be affected.

PD-43 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1000 985 0.56 1021 0.62 1058 0.68 1093 0.74 1126 0.80
1200 1015 0.65 1051 0.71 1086 0.77 1120 0.84 1154 0.91
1400 1052 0.77 1088 0.84 1121 0.90 1153 0.97 1185 1.04
1600 1093 0.92 1126 0.99 1160 1.06 1190 1.13 1222 1.20

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

1-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

38

RT-PRC005-EN

Performance

(5 Ton)

Data

High Efficiency

Table PD-44 — Belt Drive Evaporator Fan Performance — 5 Ton — THC060A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)

1600 707 0.35 774 0.42 837 0.50 898 0.57 953 0.65 1001 0.72 1045 0.80 1087 0.87 1129 0.95 1168 1.03
1800 778 0.48 840 0.56 897 0.64 953 0.72 1008 0.81 1058 0.89 1102 0.98 1143 1.06 1181 1.15 1219 1.23
2000 850 0.65 908 0.73 961 0.81 1012 0.90 1062 1.00 1111 1.09 1157 1.19 1198 1.28 1237 1.37 1274 1.47
2200 923 0.84 978 0.93 1028 1.02 1075 1.12 1120 1.22 1166 1.32 1211 1.43 — — — — — —

24009971.0710491.1710961.2711401.3711831.48 —— ————————

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. Field Supplied Fan Sheave AK56 required. Field Supplied Belt may be necessary.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors,
specifically designed and tested to operate
reliably and continuously at all cataloged
conditions. Using the full horsepower range of our
fan motors as shown in our tabular data will not
result in nuisance tripping or premature motor
failure. Our product’s warranty will not be
affected.

Table PD-44 — Continued

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1600 1206 1.12 1241 1.20 1275 1.28 1306 1.37 1338 1.46
1800 1256 1.32 1291 1.41 1326 1.50 — — — —
2000—— —— —— —— ——
2200——————————
2400——————————

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

External Static Pressure (Inches of Water)

1-HP Standard Motor

Table PD-45— Belt Drive Evaporator Fan Performance — 5 Ton — THC060A3,A4,AW — Horizontal Airflow — Dehumidification (Hot Gas Reheat)

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1000 507 0.11 599 0.16 671 0.21 735 0.26 792 0.31 843 0.37 889 0.42 931 0.48 971 0.54 1007 0.59
1200 570 0.17 654 0.23 727 0.28 787 0.34 843 0.40 895 0.46 942 0.52 986 0.59 1026 0.66 1064 0.73
1400 638 0.25 711 0.31 782 0.38 844 0.44 896 0.51 946 0.58 993 0.65 1037 0.72 1078 0.79 1117 0.86
1600 707 0.35 774 0.42 837 0.50 898 0.57 953 0.65 1001 0.72 1045 0.80 1087 0.87 1129 0.95 1168 1.03

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 1600 CFM.

NOTES:

Data includes pressure drop due to standard filters and wet coils.
Data does not include pressure drop due to reheat coil.
1 HP Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.

1. BAYLSDR008A Required.

2. BAYLSDR008A Required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Low

Static Drive Accessory Kit (1)

External Static Pressure (Inches of Water)

1-HP Standard Motor & Low
Static Drive Accessory Kit (2)

1-HP Standard Motor & Drive

Trane’s factory supplied motors, in commercial equipment,
are definite purpose motors, specifically designed and
tested to operate reliably and continuously at all cataloged
conditions. Using the full horsepower range of our fan
motors as shown in our tabular data will not result in
nuisance tripping or premature motor failure. Our product’s
warranty will not be affected.

Table PD-45 — Continued

External Static Pressure (Inches of Water)

1-HP Standard Motor & Drive

39

RT-PRC005-EN

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1000 1042 0.65 1078 0.70 1110 0.76 1142 0.82 1175 0.89
1200 1099 0.80 1133 0.86 1166 0.93 1197 0.99 1227 1.06
1400 1153 0.94 1188 1.02 1221 1.10 1253 1.18 1284 1.27
1600 1206 1.12 1241 1.20 1275 1.28 1306 1.37 1338 1.46

1. 10 1. 20 1. 30 1. 4 0 1. 5 0

Performance

(6 Ton)

Data

High Efficiency

Table PD-46— Belt Drive Evaporator Fan Performance — 6 Ton — THC072A3,A4,AW* — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1920 — — — — 588 0.35 643 0.43 693 0.50 738 0.57 782 0.65 823 0.73 862 0.81 90 0 0.89
2160 — — 564 0.37 618 0.44 672 0.52 721 0.60 765 0.68 806 0.76 847 0.85 885 0.93 922 1.02
2400 — — 602 0.47 652 0.54 701 0.63 750 0.72 794 0.81 834 0.90 873 0.98 909 1.08 945 1.17
2640 589 0.50 642 0.59 690 0.67 734 0.76 779 0.85 822 0.95 864 1.05 901 1.15 936 1.24 971 1.34
2880 634 0.63 682 0.74 728 0.82 770 0.91 810 1.01 851 1.11 892 1.22 930 1.33 965 1.44 999 1.54

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop
due to other options/accessories
1-HP Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
2-HP Fan Motor Heat (MBH) = 3.000 x Fan BHP+.5000

1. Field Supplied Fan Sheave AK84 and Belt AX34 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-46 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard 1-HP Standard Motor & High Static Drive Kit

1920 937 0.98 971 1.06 1004 1.14 1037 1.22 1068 1.30 1097 1.38 1127 1.47 1154 1.55 1182 1.64 1210 1.74
2160 957 1.12 991 1.21 1024 1.30 1057 1.40 1087 1.49 1117 1.58 1146 1.67 1174 1.76 1201 1.85 1227 1.95
2400 980 1.27 1013 1.37 1046 1.47 1076 1.57 1106 1.68 1137 1.78 1166 1.89 1194 1.99 1220 2.08 1248 2.19
2640 1004 1.44 1036 1.55 1067 1.65 1098 1.77 1129 1.88 1158 1.99 1185 2.10 1214 2.22 — — — —
2880 1030 1.64 1061 1.75 1092 1.86 1123 1.98 1151 2.09 1181 2.22 ————————

Motor & Drive (or 2 HP Oversized Motor & Drive)

2-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

Table PD-47 — Belt Drive Evaporator Fan Performance — 6 Ton — THC072A3,A4,AW — Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1920 — — 580 0.33 641 0.41 692 0.47 738 0.54 783 0.63 827 0.71 870 0.79 912 0.88 951 0.96
2160 578 0.37 623 0.43 679 0.51 731 0.59 775 0.67 817 0.74 857 0.83 896 0.93 935 1.02 974 1.12
2400 633 0.49 673 0.56 718 0.63 769 0.72 814 0.82 855 0.90 893 0.98 929 1.08 965 1.18 999 1.29
2640 688 0.64 725 0.71 762 0.79 808 0.87 853 0.98 894 1.09 931 1.17 966 1.26 1000 1.36 1032 1.47
2880 743 0.81 778 0.90 811 0.98 848 1.06 891 1.16 932 1.28 970 1.40 1004 1.49 1037 1.59 1068 1.69

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop
due to other options/accessories
1-HP Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
2-HP Fan Motor Heat (MBH) = 3.000 x Fan BHP+.5000

1. Field Supplied Fan Sheave AK84 and Belt AX34 required.

2. Field Supplied Fan Sheave AK54 and Belt AX30.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive

Low Static Drive (1)

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

2-HP Oversized

Motor & Drive

1-HP Standard Motor & High Static
Drive Kit (or 2-HP Oversized Motor)

Table PD-47 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

1-HP Standard 1-HP Standard Motor & High Static Drive Kit
Motor & Drive (or 2 HP Oversized Motor & Drive)

1920 990 1.05 1026 1.14 1062 1.24 1096 1.33 1130 1.43 1160 1.52 1190 1.61 1218 1.71 1247 1.80 1273 1.90
2160 1010 1.21 1047 1.31 1082 1.40 1116 1.50 1150 1.61 1182 1.71 1211 1.81 1242 1.92 1271 2.03 1298 2.14
2400 1035 1.39 1070 1.50 1104 1.60 1137 1.70 1168 1.81 1201 1.92 1232 2.03 1261 2.14 1291 2.26 — —
2640 1065 1.59 1097 1.71 1129 1.82 1161 1.93 1192 2.05 1223 2.16 1252 2.27 — —
2880 1099 1.80 1130 1.93 1159 2.05 1188 2.18 1217 2.30 — — ————

2-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

2-HP Oversized Motor &
Field Supplied Drive (2)

40

RT-PRC005-EN

Performance

(7½ Ton)

Data

High Efficiency

Table PD-48 — Belt Drive Evaporator Fan Performance — 7½-Ton — THC092A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2-HP Standard Motor & Field Supplied
Low Static Drive (1)

2400 — — — — — — 583 0.50 627 0.61 669 0.72 708 0.83 743 0.95 776 1.08 808 1.21
2700 — — — — — — 611 0.60 653 0.71 693 0.83 731 0.95 768 1.07 801 1.20 832 1.33
3000 — — — — 604 0.61 643 0.71 682 0.83 719 0.95 755 1.08 791 1.21 824 1.35 856 1.48
3300 — — 599 0.63 639 0.74 678 0.86 713 0.97 748 1.09 783 1.23 815 1.37 848 1.52 880 1.66
3600 601 0.68 640 0.79 675 0.89 713 1.02 748 1.14 780 1.26 811 1.40 844 1.55 874 1.70 904 1.86

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750

1. Field Supplied Fan Sheave AK79 and Belt AX38 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

2-HP Standard Motor & Drive

Table PD-48— Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2400 839 1.34 868 1.48 898 1.61 926 1.75 953 1.89 980 2.04 1006 2.18 1032 2.34 1056 2.49 1080 2.64
2700 862 1.48 891 1.62 918 1.77 946 1.92 971 2.07 998 2.23 1023 2.38 1049 2.54 1074 2.70 1097 2.86
3000 886 1.63 915 1.78 942 1.93 968 2.09 994 2.25 1019 2.42 1044 2.59 1067 2.75 1092 2.93 1115 3.09
3300 910 1.81 939 1.96 967 2.12 993 2.28 1019 2.45 1043 2.62 1066 2.79 1091 2.98 1113 3.15 1136 3.34
3600 933 2.01 962 2.17 990 2.33 1016 2.49 1042 2.66 1067 2.84 1091 3.02 1114 3.21 1137 3.39 1158 3.58

2-HP Standard Motor & Drive

External Static Pressure (Inches of Water)

3-HP Oversized Motor & Drive

Table PD-49 — Belt Drive Evaporator Fan Performance — 7½-Ton — THC092A3,A4,AW—Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2400 — — — — 603 0.52 653 0.63 707 0.75 754 0.88 792 0.99 825 1.09 857 1.19 886 1.30
2700 — — 595 0.56 644 0.66 686 0.77 732 0.89 780 1.03 824 1.17 863 1.30 895 1.42 925 1.54
3000 605 0.65 644 0.73 684 0.82 726 0.94 765 1.06 806 1.20 849 1.35 891 1.51 929 1.66 962 1.80
3300 658 0.84 694 0.93 728 1.02 767 1.15 805 1.28 840 1.40 876 1.55 916 1.71 955 1.89 991 2.06
3600 711 1.07 746 1.18 776 1.27 809 1.38 846 1.52 880 1.66 912 1.80 943 1.95 980 2.13 1016 2.30

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750

1. Field Supplied Fan Sheave AK79 and Belt AX38 required..

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied

Low Static Drive (1)

External Static Pressure (Inches of Water)

2-HP Standard Motor & Drive

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-49 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2400 913 1.40 941 1.51 966 1.61 991 1.71 1017 1.82 1040 1.92 1064 2.04 1087 2.14 1110 2.26 1132 2.37
2700 954 1.66 981 1.77 10 06 1.89 1030 2.00 1054 2.12 1077 2.24 1100 2.36 1121 2.47 1144 2.60 1164 2.71
30 00 99 2 1.94 1019 2. 07 10 45 2 .20 1069 2. 32 10 94 2 .46 1116 2. 58 113 8 2 .71 1160 2. 84 1181 2. 97 12 02 3. 10
3300 1025 2.22 1055 2.38 1082 2.53 1108 2.67 1132 2.82 1156 2.96 1178 3.11 1200 3.25 1221 3.39 — —

360010522.5010852.6911172.8811443.0511703.2111933.37————————

RT-PRC005-EN

2-HP Standard Motor & Drive

3-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

41

Performance

(8½ Ton)

Data

High Efficiency

Table PD-50— Belt Drive Evaporator Fan Performance — 8½-Ton — THC102A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 - - -- -- -- 584 0.53 626 0.64 668 0.76 708 0.88 746 1.00 781 1.12 814 1.26 845 1.40
3060 - - -- -- -- 626 0.68 665 0.78 703 0.90 740 1.04 775 1.17 810 1.30 843 1.44 875 1.58
3400 - - -- 628 0.72 669 0.84 706 0.96 741 1.08 775 1.21 809 1.36 841 1.51 873 1.65 904 1.81
3400 641 0.81 677 0.92 713 1.04 749 1.17 781 1.30 813 1.43 845 1.58 875 1.73 905 1.89 935 2.06
4080 693 1.03 726 1.15 758 1.27 792 1.41 824 1.56 854 1.69 883 1.83 912 1.99 940 2.16 968 2.33

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750

1. Field Supplied Fan Sheave AK79 and Belt AX38 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied

External Static Pressure (Inches of Water)

Low Static Drive (1)

2-HP Standard Motor & Drive

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-50 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 874 1.54 904 1.69 930 1.84 958 2.00 983 2.14 1010 2.30 1035 2.46 1060 2.62 1084 2.78 1109 2.95
3060 905 1.73 933 1.89 960 2.05 986 2.20 1010 2.37 1035 2.54 1059 2.71 1083 2.89 1107 3.06 1131 3.24
3400 933 1.96 962 2.11 990 2.27 1016 2.44 1041 2.62 1065 2.79 1089 2.97 1112 3.15 1134 3.34 -- -­3400 964 2.22 992 2.39 1018 2.55 1045 2.72 1071 2.90 1095 3.08 1118 3.26 1141 3.45 -- -- -- -­4080 995 2.51 1023 2.69 1048 2.86 1075 3.05 1100 3.23 1124 3.41 -- -- -- -- -- -- -- --

2-HP Standard Motor & Drive

3-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

Table PD-51 — Belt Drive Evaporator Fan Performance — 8½-Ton — THC102A3,A4,AW —Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 — — 612 0.60 660 0.71 703 0.81 751 0.95 798 1.09 841 1.23 877 1.36 909 1.48 939 1.60
3060 631 0.72 667 0.80 709 0.91 750 1.03 788 1.15 830 1.29 873 1.45 914 1.62 951 1.77 983 1.92
3400 692 0.96 726 1.05 760 1.15 800 1.29 836 1.42 870 1.56 907 1.71 945 1.88 984 2.06 1020 2.24
3740 754 1.26 786 1.36 815 1.46 850 1.59 886 1.74 918 1.88 949 2.03 980 2.19 1015 2.37 1052 2.57
4080 817 1.61 848 1.72 874 1.83 903 1.95 935 2.10 968 2.26 998 2.42 1026 2.58 1054 2.75 1085 2.94

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.

NOTES:NOTES:

NOTES:

NOTES:NOTES:

Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
2-HP Fan Motor Heat (MBH) = 2.000 x Fan BHP+.5000.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.4750

1. Field Supplied Fan Sheave AK79 and Belt AX38 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

2-HP Standard Motor & Field Supplied

Low Static Drive (1)

2-HP Standard Motor & Drive 3-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-51 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2720 967 1.72 994 1.84 1018 1.96 1042 2.07 1066 2.19 1089 2.31 1112 2.43 1134 2.55 1155 2.67 1176 2.79
3080 1012 2.06 1039 2.19 1065 2.32 1090 2.46 1113 2.59 1136 2.73 1158 2.86 1179 2.99 1199 3.12 1220 3.26
3400 1052 2.41 1083 2.58 1109 2.73 1135 2.88 1159 3.04 1183 3.19 1204 3.33 — — — — — —

374010862.7711192.9611493.1511783.34—— —— ————————
4080 1117 3.14 1151 3.36 — — — — — — — — ————————

2-HP Standard Motor & Drive

3-HP Oversized Motor & Drive

42

External Static Pressure (Inches of Water)

RT-PRC005-EN

Performance

(10 Ton)

Data

High Efficiency

Table PD-52— Belt Drive Evaporator Fan Performance — 10-Ton — THC120A3,A4,AW — Downflow Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3-HP Standard Motor & Field Supplied Low Static Drive (1)
3200 — — — — — — — — 734 1.03 770 1.17 804 1.31 839 1.45 871 1.60 901 1.74
3600 — — — — 714 1.02 749 1.14 782 1.27 815 1.41 847 1.57 879 1.73 909 1.89 939 2.04
4000 — — 734 1.16 768 1.30 803 1.44 834 1.58 863 1.72 894 1.87 923 2.04 952 2.21 979 2.39
4400 764 1.36 795 1.49 825 1.63 857 1.79 888 1.95 916 2.10 943 2.25 970 2.41 997 2.59 1024 2.78
4800 828 1.74 857 1.88 884 2.02 913 2.18 942 2.36 970 2.53 996 2.70 1021 2.86 1045 3.03 1070 3.22

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.
5-HP Fan Motor Heat (MBH) = 2.950 x Fan BHP+.470.

1. Field Supplied Motor Sheave 1VM50 x 7/8 inch, Fan Sheave AK89,
and Belt AX40 required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

3-HP Standard Motor & Drive

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

Table PD-52 — Continued

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3200 931 1.89 959 2.06 986 2.22 1012 2.39 1037 2.56 1061 2.74 1084 2.91 1108 3.09 1131 3.28 1153 3.46
3600 969 2.21 997 2.37 1024 2.54 1050 2.72 1074 2.89 1098 3.08 1122 3.27 1145 3.46 1166 3.65 1188 3.85
4000 1007 2.57 1034 2.74 1062 2.93 1087 3.11 1112 3.29 1136 3.47 1159 3.66 1182 3.86 1204 4.07 1226 4.28
4400 1050 2.97 1075 3.17 1101 3.36 1126 3.55 1150 3.75 1173 3.94 1198 4.15 1219 4.34 1241 4.54 1264 4.77
4800 1095 3.42 1119 3.62 1143 3.83 1166 4.05 1189 4.26 1212 4.47 1235 4.68 1258 4.90 1280 5.12 1300 5.32

External Static Pressure (Inches of Water)

5-HP Oversized Motor & Drive

Table PD-53— Belt Drive Evaporator Fan Performance—10- Ton— THC120A3,A4,AW— Downflow Airflow— Dehumidification (Hot Gas Reheat)

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2000 — — — — — — 568 0.43 613 0.53 653 0.64 691 0.75 727 0.86 763 0.98 797 1.10
2400 — — — — — — 606 0.56 650 0.67 691 0.78 728 0.90 763 1.02 796 1.16 826 1.29
2800 — — 564 0.50 607 0.60 649 0.71 689 0.83 728 0.95 766 1.08 801 1.21 833 1.35 864 1.50
3200 576 0.57 618 0.67 659 0.79 697 0.90 734 1.03 770 1.17 804 1.31 839 1.45 871 1.60 901 1.74

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.

NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
Data does not include pressure drop due to reheat coil.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.

1. BAYLSDR010A Required.

2. BAYLSDR010A Required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

3-HP Standard Motor & Low
Static Drive Accessory Kit (1)

3-HP Standard Motor & Low
Static Drive Accessory Kit (2)

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors, specifically
designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full
horsepower range of our fan motors as shown in our
tabular data will not result in nuisance tripping or
premature motor failure. Our product’s warranty will
not be affected.

Table PD-53 — Continued

1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2000 828 1.22 859 1.35 888 1.48 917 1.61 945 1.75 971 1.88 998 2.03 1023 2.19 1048 2.35 1072 2.50
2400 858 1.43 888 1.56 916 1.70 945 1.85 972 1.99 998 2.14 1023 2.29 1050 2.45 1073 2.60 1097 2.76
2800 894 1.65 921 1.79 949 1.95 975 2.11 1001 2.27 1027 2.43 1051 2.59 1076 2.75 1100 2.92 1123 3.09
3200 931 1.89 959 2.06 986 2.22 1012 2.39 1037 2.56 1061 2.74 1084 2.91 1108 3.09 1131 3.28 — —

External Static Pressure (Inches of Water)

3 HP Standard Motor & Drive

RT-PRC005-EN

43

Performance

(10 Ton)

Data

High Efficiency

Table PD-54— Belt Drive Evaporator Fan Performance — 10-Ton — THC120A3,A4,AW —Horizontal Airflow

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3-HP Standard Motor & Field Supplied 3-HP Standard Motor
Low Static Drive (1) & Drive

3200 — — — — 748 1.06 787 1.19 824 1.32 864 1.47 906 1.64 946 1.81 983 1.97 1015 2.13
3600 746 1.18 777 1.27 811 1.39 849 1.54 883 1.68 916 1.82 950 1.98 987 2.16 1024 2.35 1060 2.55
4000 822 1.59 850 1.70 879 1.81 912 1.95 946 2.12 977 2.28 10 06 2.43 1035 2.60 1067 2.79 1101 2.99
4400 898 2.09 925 2.21 950 2.32 977 2.46 1008 2.63 1039 2.81 1067 2.98 1094 3.16 1121 3.33 1147 3.52
4800 974 2.69 1000 2.83 1023 2.95 1046 3.07 1072 3.23 1101 3.42 1130 3.62 1156 3.81 1181 4.00 1206 4.19

For Standard Evaporator Fan Speed (RPM), reference Table PD-50.
NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-54 to determine additional static pressure drop due to other options/accessories
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.
5-HP Fan Motor Heat (MBH) = 2.950 x Fan BHP+.470.

1. Field Supplied Motor Sheave 1VM50 x 7/8 inch, Fan Sheave AK89,
and Belt AX40 required

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

External Static Pressure (Inches of Water)

Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at
all cataloged conditions. Using the full horsepower range of our fan motors as
shown in our tabular data will not result in nuisance tripping or premature motor
failure. Our product’s warranty will not be affected.

5-HP Oversized Motor & Drive

Table PD-54 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3200 1044 2.28 1072 2.42 1097 2.57 1122 2.71 1145 2.84 1168 2.99 1189 3.12 1210 3.27 1231 3.41 1250 3.54
3600 1093 2.74 1124 2.92 1151 3.09 1176 3.25 1201 3.42 1224 3.58 1246 3.74 1268 3.90 1289 4.06 1308 4.20
4000 1135 3.21 1167 3.42 1198 3.63 1227 3.84 1254 4.05 1278 4.23 1301 4.41 1323 4.60 1344 4.77 1365 4.95
4400 1177 3.73 1207 3.96 1239 4.19 1268 4.42 1297 4.67 1324 4.90 1351 5.12 1376 5.35 1398 5.56 1420 5.75

480012294.3912544.5912824.8313105.0713385.3213655.58————————

3-HP Standard Motor & Drive

5-HP Oversized Motor & Drive

External Static Pressure (Inches of Water)

Table PD-55— Belt Drive Evaporator Fan Performance — 10-Ton — THC120A3,A4,AW —Horizontal Airflow — Dehumidification (Hot Gas Reheat)

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

2000 — — — — 584 0.43 639 0.53 682 0.62 721 0.71 755 0.79 787 0.88 818 0.97 849 1.06
2400 — — 578 0.48 627 0.57 683 0.70 734 0.83 776 0.94 812 1.05 845 1.15 876 1.26 904 1.36
2800 596 0.58 640 0.67 686 0.79 728 0.90 776 1.04 822 1.19 865 1.34 900 1.47 932 1.60 962 1.73
3200 671 0.85 706 0.93 748 1.06 787 1.19 824 1.32 864 1.47 906 1.64 946 1.81 983 1.97 1015 2.13

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.

***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.***MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT IS 3200 CFM.

NOTES:NOTES:

NOTES:

NOTES:NOTES:
Data includes pressure drop due to standard filters and wet coils.
Data does not include pressure drop due to reheat coil.
3-HP Fan Motor Heat (MBH) = 2.900 x Fan BHP+.475.

1. BAYLSDR010A Required.

2. BAYLSDR010A Required.

.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00

3-HP Standard Motor & Low

Static Drive Accessory Kit (1)

External Static Pressure (Inches of Water)

Static Drive Accessory Kit (2)

3-HP Standard Motor & Low

Trane’s factory supplied motors, in commercial
equipment, are definite purpose motors, specifically
designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full
horsepower range of our fan motors as shown in our
tabular data will not result in nuisance tripping or
premature motor failure. Our product’s warranty will
not be affected.

3-HP Oversized Motor & Drive

Table PD-55 — Continued

1. 10 1. 20 1. 30 1. 4 0 1.5 0 1. 6 0 1. 7 0 1. 8 0 1. 9 0 2 . 0 0

CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP

3-HP Standard Motor & Low

Static Drive Accessory Kit (2)

2000 877 1.15 906 1.24 933 1.33 961 1.43 988 1.54 1014 1.64 1038 1.74 1063 1.85 1087 1.96 1111 2.07
2400 931 1.47 958 1.58 983 1.68 1008 1.78 1032 1.89 1056 2.00 1080 2.11 1103 2.22 1126 2.34 1149 2.46
2800 989 1.84 1015 1.97 1040 2.09 1064 2.21 1087 2.34 1110 2.46 1132 2.58 1154 2.71 1176 2.83 1196 2.95
3200 1044 2.28 1072 2.42 1097 2.57 1122 2.71 1145 2.84 1168 2.99 1189 3.12 1210 3.27 — — — —

44

External Static Pressure (Inches of Water)

3-HP Standard Motor & Drive

RT-PRC005-EN

Performance
Data

Table PD-56— Standard Motor & Sheave/Fan Speed (Rpm)

Tons Model No. Open Open Open Open Open Open Closed
3 T#C036A NA 745 819 894 968 1043 1117
4 T#C048A NA 833 916 1000 1083 1167 1250
5 T#C060A NA 897 987 1077 1166 1256 1346
6 T#C072A N/A 723 779 835 890 946 1002
7½ TSC090,092A N/A 835 891 946 1002 1057 1113
8½ T#C102A N/A 787 847 908 968 1029 1089
10 T#C120A N/A 908 969 1029 1090 1150 1211

Factory set at 3 turns open.

Table PD-57— Standard Motor & High Static Drive Accessory Sheave/Fan Speed (Rpm)

Tons Model No. Open Open Open Open Open Open Closed
6 T#C072A3,A4,AW N/A 831 895 959 1022 1086 1150
6 TSC072AK N/A 958 1022 1086 1150 1214 1278
7½ TSC090,092A N/A 958 1022 1086 1150 1214 1278

Factory set at 3 turns open.

U n i t 6 Tu r n s 5 Tu r n s 4 Tu r n s 3 Tu r n s 2 Tu r n s 1 Tu r n

Un i t 6 Tu r n s 5 Tu r n s 4 Tu r n s 3 Tu r n s 2 Tu r n s 1 Tu r n

Table PD-58— Oversized Motor & Drive Sheave/Fan Speed (Rpm)

Tons Model No. Open Open Open Open Open Open Closed
6 T#C072A3,A4,AW N/A 958 1022 1086 1150 1214 1278
7½ TSC090,092A N/A 1068 1150 1232 1315 1397 1479
8½ T#C102A N/A 958 1022 1086 1150 1214 1278
10 T#C120A 1050 1135 1200 1275 1350 1425 N/A

Factory set at 3 turns open.

Table PD-59— Outdoor Sound Power Level - dB (ref. 10

Unit Octave Center Frequency Overall
Tons Model No. 63. 125 250 500 1000 2000 4000 8000 dBA
3 T*C036A 86 83 81 80 78 74 69 68 83

4 TSC048A3,A4,AW 90 84 78 77 76 72 70 68 82

5 THC060A 94 87 82 81 78 74 72 69 84

6 THC072A 91 95 90 87 84 79 75 68 89

7½ TSC092A 89 93 88 85 81 76 72 66 87

8½ THC102A 91 95 90 87 84 79 75 68 89

10

Note:
Tests follow ARI270-95.

TSC048A1 92 87 84 83 81 76 72 69 86

THC048A 92 86 83 82 81 75 72 69 85
TSC060A 94 87 83 82 79 75 73 69 84

TSC072A 90 94 90 87 83 78 74 67 88

TSC090A 92 95 91 88 84 80 75 68 90

THC092A 92 96 92 89 85 80 76 69 91
TSC102A 88 92 87 84 80 75 72 65 86

TSC120A 91 88 84 82 81 76 73 67 86
THC120A 94 89 87 85 84 78 75 69 88

Un i t 6 Tu r n s 5 Tu r n s 4 Tu r n s 3 Tu r n s 2 Tu r n s 1 Tu r n

-12

Watts)

# Indicates both Standard and High Efficiency.

RT-PRC005-EN

45

Performance
Data

Table PD-60 — Static Pressure Drops Through Accessories (Inches Water Column) — 3 - 10 Tons

Tons Model No. CFM Filters1Reheat Pleated Filters 100% OA 100% RA 100%OA 100%RA 5-6 9-15 17-36 54

3 960 0.02 — 0.04 0.05 0.01 0.05 0.0 0 .013 .016 .019 —

4 T#C048A 1600 0.05 — 0.09 0.12 0.04 0.12 0.01 .036 .045 .053 —

5 1400— .05 — ————————

6 T#C072A 2400 0.06 — 0.09 0.11 0.02 0.08 0.02 0.02 0.020 0.034 —

TSC090, 092A 3000 0.10 — 0.13 0.14 0.05 0.12 0.05 0.05 0.042 0.063 —
7½ 3600 0.14 — 0.18 0.21 0.07 0.25 0.08 0.08 0.077 0.102 —

8½ T#C102A 3400 0.08 — 0.11 0.19 0.06 0.18 0.06 0.06 0.032 0.041 —

10 T#C120A 4000 0.11 — 0.15 0.26 0.07 0.30 0.08 0.08 0.045 0.056 0.070

10 THC120A 3200 0.07 0.15 0.10 0.17 0.05 0.14 0.05 0.05 0.028 0.036 0.042

NOTES:

1. Tested with standard filters (3-5 tons 1" filters, 6-10 tons 2” filters). Difference in

2. OA = Outside Air and RA = Return Air.

3. Nominal kW ratings at 240, 480, 600 volts.

Unit Standard Through 2 Inch OA/RA Dampers

Coil (WC) Downflow Horizontal

960 0.03 — 0.05 0.05 0.01 0.05 0.0 0 .013 .016 .019 —

TSC036A 1200 0.04 — 0.07 0.07 0.02 0.07 0.01 .020 .025 .030 —

1440 0.06 — 0.10 0.10 0.03 0.10 0.01 .029 .036 .043 —

THC036A 1200 0.03 — 0.05 0.07 0.02 0.07 0.01 .020 .025 .030 —

1440 0.04 — 0.07 0.10 0.03 0.10 0.01 .029 .036 .043 —
1280 0.04 — 0.06 0.08 0.03 0.08 0.01 .023 .029 .034 —

1920 0.08 — 0.12 0.17 0.06 0.17 0.02 .052 .064 .077 —
1600 0.10 — 0.15 0.12 0.04 0.12 0.01 .036 .045 .053 —

TSC060A 2000 0.15 — 0.22 0.18 0.07 0.18 0.02 .056 .070 .083 —

2400 0.22 — 0.29 0.26 0.10 0.26 0.04 .081 .100 .120 —
1000— .03 — ————————
1200— .04 — ————————

THC060A 1600 0.04 .07 0.07 0.12 0.04 0.12 0.01 .036 .045 .053 —

1800— .09 — ————————
2000 0.06 .10 0.10 0.18 0.07 0.18 0.02 .056 .070 .083 —
2200— .12 — ————————
2400 0.09 .14 0.14 0.26 0.10 0.26 0.04 .081 .100 .120 —
1920 0.04 — 0.07 0.10 0.01 0.06 0.02 0.02 0.011 0.021 —

2880 0.09 — 0.12 0.13 0.04 0.10 0.04 0.04 0.033 0.052 —
2400 0.06 — 0.09 0.11 0.02 0.08 0.02 0.02 0.020 0.034 —

2400 0.04 — 0.06 0.11 0.02 0.08 0.02 0.02 0.016 0.021 —

THC092A 3000 0.06 — 0.09 0.14 0.05 0.12 0.05 0.05 0.025 0.032 —

3600 0.09 — 0.13 0.21 0.07 0.25 0.08 0.08 0.036 0.046 —
2720 0.05 — 0.08 0.12 0.03 0.09 0.04 0.04 0.020 0.026 —

4080 0.12 — 0.16 0.30 0.07 0.31 0.09 0.09 0.047 0.059 —
3200 0.07 — 0.10 0.17 0.05 0.14 0.05 0.05 0.028 0.036 0.042

4800 0.16 — 0.20 0.34 0.09 0.35 0.10 0.10 0.065 0.081 0.106
2000—0.09— ————————
2400—0.10— ————————
2800—0.13— ————————

3600—0.19— ————————
4000 0.11 0.22 0.15 0.26 0.07 0.30 0.08 0.08 0.045 0.056 0.070
4400—0.27— ————————
4800 0.16 0.31 0.20 0.34 0.09 0.35 0.10 0.10 0.065 0.081 0.106

pressure drop should be considered when utilizing optional 2”pleated filters.

Economizer with Electric Heater

2

Accessory (kW)

3

Table PD-61— Electric Heater Voltage
Correction Factors (Applicable to
Auxiliary Heat Capacity)

46

Nominal Distribution Capacity
Voltage Voltage Multiplier

208 0.751

240 230 0.918

240 1.000

380 380 1.000

440 0.840

480 460 0.918

480 1.000
540 0.810

600 575 0.918

600 1.000

RT-PRC005-EN

Performance
Data

Table PD-62— Auxiliary Electric Heat Capacity

2

Total

Tons Model No. Input

Unit kW MBH No. of kW MBH kW MBH

T#C036A1 10.00 34.14 2 5.00 17.07 5.00 17.07

3

T#C036A3, A4, AW 12.00 40.97 2 6.00 20.48 6.00 20.48

T#C048A1 13.80 47.11 2 8.80 30.04 5.00 17.07

4

T#C048A3, A4, AW 12.00 40.97 2 6.00 20.48 6.00 20.48

T#C060A1 13.80 47.11 2 8.80 30.04 5.00 17.07

5

T#C060A3, A4, AW 12.00 40.97 2 6.00 20.48 6.00 20.48

TSC060AK 10.90 37.23 2 5.45 18.61 5.45 18.61

6 27.00 92.18 2 18.00 61.45 9.00 30.73

7 1/2 36.00 122.90 2 18.00 61.45 18.00 61.45

8 1/2 T#C102A3, A4, AW 18.00 61.45 1 18.00 61.45 —- —-

10 T#C120A3, A4, AW 27.00 92.18 2 18.00 61.45 9.00 30.73

NOTES:

1. Does not include indoor fan power or heat.

2. Heaters are rated at 240v, 380v, 480v. and 600v. For other than rated voltage, CAP = x rated cap.

T#C072A3, A4, AW 18.00 61.45 1 18.00 61.45 —- —-

TSC072AK 16.90 57.72 2 11.30 38.60 5.60 19.13

T#SC090A3, A4, AW 18.00 61.45 1 18.00 61.45 —- —-

TSC090AK 16.90 57.72 2 11.30 38.60 5.60 19.13

T#C092A3, A4, AW 18.00 61.45 1 18.00 61.45 —- —-

TSC102AK 16.90 57.72 2 11.30 38.60 5.60 19.13

TSC120AK 22.60 77.18 2 11.30 38.60 11.30 38.60

1

5.00 17.07 1 5.00 17.07 — —

13.80 47.11 2 8.80 30.04 5.00 17.07

6.00 20.48 1 6.00 20.48 — —

17.40 59.40 2 8.70 29.70 8.70 29.69

5.00 17.07 1 5.00 17.07 — —

10.00 34.14 2 5.00 17.07 5.00 17.07

17.60 60.09 2 8.80 30.04 8.80 30.04

6.00 20.48 1 6.00 20.48 — —

17.40 59.40 2 8.70 29.70 8.70 29.70

5.00 17.07 1 5.00 17.07 — —

10.00 34.14 2 5.00 17.07 5.00 17.07

17.60 60.09 2 8.80 30.04 8.80 30.04

6.00 20.48 1 6.00 20.48 — —

17.40 59.40 2 8.70 29.70 8.70 29.70

23.00 78.52 2 14.30 48.82 8.70 29.70

7.50 25.61 2 3.25 11.10 3.25 11.10

14.4 49.18 2 7.20 24.59 7.20 24.59

9.00 30.73 1 9.00 30.73 —- —-

36.00 122.90 2 18.00 61.45 18.00 61.45

11.30 38.60 1 11.30 38.60 — —

22.60 77.18 2 11.30 38.60 11.30 38.60

9.00 30.73 1 9.00 30.73 —- —-

27.00 92.18 2 18.00 61.45 9.00 30.73

11.30 38.60 1 11.30 38.60 — —

22.60 77.18 2 11.30 38.60 11.30 38.60

9.00 30.73 1 9.00 30.73 —- —-

27.00 92.18 2 18.00 61.45 9.00 30.73

36.00 122.90 2 18.00 61.45 18.00 61.45

9.00 30.73 1 9.00 30.73 —- —-

27.00 92.18 2 18.00 61.45 9.00 30.73

36.00 122.90 2 18.00 61.45 18.00 61.45

22.60 77.18 2 11.30 38.60 11.30 38.60

18.00 61.45 1 18.00 61.45 —- —-

36.00 122.90 2 18.00 61.45 18.00 61.45

54.00 184.36 2 36.00 122.90 18.00 61.45

16.90 57.72 2 11.30 38.60 11.30 38.60

33.80 115.43 2 22.50 76.84 11.30 38.60

1

Output

Stages Input

Voltage

Rated Voltage

( )

2

Stage1 Stage 2

1

Output

1

Input1Output

1

RT-PRC005-EN

47

Performance
Data

Table PD-63 — 3-5 Tons Air Temperature Rise Across Electric Heaters (Degrees F)

3 Ton 4 Ton 5 Ton

1200 CFM 1600 CFM

kW Stages T#C036A1 T#C036A3,A4,AW T#C048A1 T#C048A3,A4,AW T#C060A1 T#C060A3,A4,AW TSC060AK

5.00 1 13.2 — 9.9 — 7.9 — —

6.00 1 — 15.8 — 11.9 — 9.5 —

7.502——————11.9

10. 00 2 2 6.3 — 19 .8 — 15 .8 — —

10.902——————17.2

12.00 2 — 31.6 — 23.7 — 19.0 —

13.80 2 36.4 — 27.3 — 21.8 — —

14.402——————22.8

17.40 2 — 45.8 — 34.4 — 27.5 —

17.60 2 — — 34.8 — 27.8 — —

23.00 2 — — — — — 36.4 —

For minimum design airflow, see airflow performance table for each unit.
To calculate temp rise at different air flow, use following formula:
NOTE:

1. Minimum allowable aiflow with a 17.4 or 17.6 KW heater is 1440 cfm.

Single Phase Three Phase Single Phase Three Phase Single Phase Three Phase

Temp. Rise across Elect. Htr =

Table PD-64 — 6-10 Tons Air Temperature Rise Across Electric Heaters (Degrees F)

6Ton 7½Ton 8½Ton 10 Ton

2000 CFM 3000 CFM 3400 CFM

kW Stages T#C072A3, A4, AW TSC072AK T#C092A3, A4, AW TSC090AK T#C102A3, A4, AW TSC102AK T#C120A3,A4,AW TSC120AK

9.00 1 14.2 — 9.5 — 8.4 — — —

11. 3 0 1 — 1 4 . 9 — 11 . 9 — — — —

16.90 2 — 22.3 — 17.8 — 15.7 — 13.4

18.00 1 28.5 — 19.0 — 16.7 — 14.2 —

22.60 2 — 29.8 — 23.8 — 21.0 — 17.9

27.00 2 42.7 — 28.5 — 25.1 — 21.3 —

33.80 2 — — — — — — — 26.7

36.00 2 56.9 — 37.9 — 33.5 — 28.5 —

54.00 2 — — — — — — 42.7 —

For minimum design airflow, see airflow performance table for each unit.
To calculate temp rise at different air flow, use following formula:
NOTE:

1. Minimum allowable aiflow with a 17.4 or 17.6 KW heater is 1440 cfm.

T#C090A3, A4, AW

Temp. Rise across Elect. Htr =

1

KW x 3414

1.08 x CFM

kW x 3414

1.08 x CFM

2000 CFM

1

4000 CFM

Table PD-65— Hot Gas Reheat Temperature Rise

SCFM Leaving Evaporator Dry Bulb [F]

5 To ns 35 40 45 50 55 60 65

1000 23.7 23.6 23.4 23.2 23.0 22.8 22.5
1200 22.6 22.4 22.2 22.0 21.8 21.6 21.3
1400 21.4 21.2 21.0 20.9 20.7 20.4 20.2
1600 20.3 20.1 19.9 19.7 19.5 19.3 19.0
1800 19.1 18.9 18.7 18.5 18.4 18.1 17.8
200 0 17.9 17.8 17.6 17.4 17.2 16.9 16.6
2200 16.8 16.6 16.4 16.2 16.0 15.7 15.4
2400 15.6 15.4 15.2 15.1 14.9 14.6 14.3

10 Tons 35 40 45 50 55 60 65

2000 26.0 26.5 26.9 27.4 27.9 28.3 28.6
2400 23.5 24.1 24.7 25.3 25.9 26.4 26.9
2800 21.1 21.8 22.5 23.3 24.0 24.6 25.1
3200 18.7 19.5 20.3 21.2 22.0 22.7 23.4
3600 16.2 17.2 18.1 19.1 20.1 20.8 21.6
4000 13.8 14.9 15.9 17.0 18.1 19.0 19.8
4400 11.3 12.5 13.7 14.9 16.1 17.1 18.1
4800 8.9 10.2 11.5 12.9 14.2 15.3 16.3

NOTES:

1. Temperature rise does not account for indoor fan heat.

2. 70 deg OD Ambient Temperature.

3. For units with the Dehumidification (Hot Gas Reheat) option.

3

48

RT-PRC005-EN

60

70

80

90

60

70

80

90

TM

50 60 70 80

COOL

50 60 70 80

FAN

AUTO ON

50 60 70 80

OFF AUTO

HEAT

TM

ReliaTel™ Controlled Units

Zone Sensors are the building
occupant’s comfort control devices for
Precedent™ units with the Micro control:

Manual
Changeover —

Heat, Cool or Off
System Switch. Fan
Auto or Off Switch.
One temperature
setpoint lever.

Manual/Automatic Changeover —
Auto, Heat, Cool or Off System
Switch. Fan Auto
or Off Switch. Two
temperature
setpoint levers.
Optional Status
Indication LED
lights, System On,
Heat, Cool, or
Service.

Remote Sensor
— Sensor(s)

available for all
zone sensors to
provide remote
sensing
capabilities.

Integrated
Comfort

available with
optional
temperature
adjustment and
override buttons to
provide central
control through a
Trane Integrated
Comfort

RT-PRC005-EN

TM

System — Sensor(s)

TM

system.

Zone Controls

Programmable Night Setback —

Auto or manual changeover with seven­day programming. Keyboard selection
of Heat, Cool, Fan, Auto, or On. All

programmable sensors have System
On, Heat, Cool, Service LED/indicators as
standard. Night Setback Sensors have
one (1) Occupied, one (1) Un-occupied,
and two (2) Override programs per day.

Humidity Sensor — Field installed,
wall-mounted
(BAYSENS036) or
duct-mounted
(BAYSENS037)
humidity sensor is
used to control
activation of the
hot gas reheat
dehumidification
option. The
humidity sensor
can be set for
humidity levels
between 40% and 60% relative humidity
adjusting the ReliaTel Options Module.

CO2 Sensing — The CO2 sensor shall
have the ability to to monitor space
occupancy levels within the building by
measuring the
parts per million
of CO2 (Carbon
Dioxide) in the
air. As the CO2
levels increase,
the outside air
damper
modulates to
meet the CO2
space
ventilation
requirements.
The CO2
accessory shall
be available as field installed.

Electromechanically Controlled
Units

Conventional Thermostats are the
building occupant’s comfort control
devices for electromechanically
controlled units.

Manual Changeover — One Heat,
One Cool
Thermostat.
Heat, Cool or Off
System Switch.
Fan Auto or On
Switch. Set Point
Dial. Adjustable
Heat Anticipator.

Automatic Changeover — One Heat,
Two Cool Thermostat. Off, Auto System
Switch. Auto/On Fan Switch.

Programmable Electronic Night Setback
Thermostat —

Heating setback
and cooling
setup with 7-day,
5-1-1
programming
capability.
Available in Two
heating/cooling
or one heating/
cooling versions
with automatic changeover.

49

Electrical

(Standard

Data

Efficiency)

Table ED-1 — Unit Wiring — Standard Efficiency

Tons Model No. Voltage Range Ampacity Circuit Breaker

3 TSC036A3 187-253 17.9 25 20.3 30 20.6 30

4 TSC048A4 414-506 12.8 20 14.4 20 13.6 20

5 TSC060A4 414-506 16.0 25 16.3 25 15.6 25

6 TSC072A4 414-506 17.6 25 18.2 25 — —

7½

8½ TSC102A4 414-506 24.0 30 25.5 35 — —

10 TSC120A4 414-506 26.9 35 28.9 35 — —

NOTES:

1. HACR breaker per NEC.

2. Optional Belt Drive motor applies to 3-5 ton models only.
The standard motor for 6-10 ton models is belt drive.

Unit Operating Circuit Size Or Maximum Circuit Size Or Maximum Circuit Size or Maximum

TSC036A1 187-253 25.3 40 27.7 40 N/A N/A

TSC036A4 414-506 9.2 15 10.4 15 10.6 15
TSC036AW 517-633 7.7 15 8.3 15 8.3 15

TSC048A1 187-253 34.0 50 36.1 50 N/A N/A
TSC048A3 187-253 23.9 35 26.0 40 25.3 35

TSC048AW 517-633 9.8 15 10.6 15 10.0 15
TSC060A1 187-253 47.3 60 49.0 60 N/A N/A
TSC060A3 187-253 31.5 50 33.2 50 30.3 45

TSC060AW 517-633 12.2 15 12.8 20 11.8 15
TSC060AK 342-418 19.6 30 — — — —

TSC072A3 187-253 32.7 50 34.0 50 — —

TSC072AW 517-633 12.8 20 13.6 20 — —
TSC072AK 342-418 23.2 35 — — — —
TSC090A3 187-253 42.7 60 45.8 60 — —
TSC090A4 414-506 22.6 35 24.1 35 — —
TSC090AW 517-633 17.6 25 18.8 25 — —
TSC090AK 342-418 28.4 40 29.9 45 — —
TSC092A3 187-253 38.9 50 42.0 50 — —
TSC092A4 414-506 20.5 25 22.0 25 — —
TSC092AW 517-633 15.5 20 16.7 20 — —
TSC102A3 187-253 45.1 60 48.2 60 — —

TSC102AW 517-633 19.5 25 20.7 25 — —
TSC102AK 342-418 32.6 40 35.6 45 — —
TSC120A3 187-253 52.6 60 56.6 60 — —

TSC120AW 517-633 21.8 25 23.5 30 — —
TSC120AK 342-418 32.6 40 35.6 45 — —

Unit Minimum Maximum Fuse Minimum Maximum Fuse Minimum Maximum Fuse

Standard Indoor Fan Motor Oversize Indoor Fan Motor Belt Dri ve Indoor Fan Motor

1

Ampacity Circuit Breaker

1

Optional

Ampacity Circuit Breaker

2

1

50

RT-PRC005-EN

Electrical

(High

Data

Efficiency)

Table ED-2 — Unit Wiring — High Efficiency

Tons Model No. Voltage Range Ampacity Circuit Breaker

3 THC036A3 187-253 16.7 25 19.1 25 19.4 25

4 THC048A4 414-506 11.0 15 12.6 15 11.8 15

5 THC060A4 414-506 14.7 20 15.0 20 14.3 20

6 THC072A4 414-506 17.5 25 18.1 25 — —

7½ THC092A4 414-506 19.4 25 20.9 25 — —

8½ THC102A4 414-506 21.4 25 22.9 30 — —

10 THC120A4 414-506 25.3 30 27.3 35 — —

NOTES:

1. HACR breaker per NEC.

Unit Operating Circuit Size Or Maximum Circuit Size Or Maximum Circuit Size or Maximum

THC036A1 187-253 23.9 40 26.3 40 N/A N/A

THC036A4 414-506 8.3 15 9.5 15 9.7 15
THC036AW 517-633 7.0 15 7.6 15 7.6 15
THC048A1 187-253 29.4 45 31.5 50 N/A N/A
THC048A3 187-253 21.2 30 23.3 35 22.6 35

THC048AW 517-633 8.3 15 9.1 15 8.5 15
THC060A1 187-253 39.5 60 41.2 60 N/A N/A

THC060A3 187-253 30.0 45 31.7 45 28.8 45

THC060AW 517-633 11.8 15 12.4 15 11.4 15
THC072A3 187-253 34.8 50 36.1 50 — —

THC072AW 517-633 13.5 20 14.3 20 — —
THC092A3 187-253 38.1 50 41.2 50 — —

THC092AW 517-633 14.8 15 16.0 20 — —
THC102A3 187-253 42.3 50 45.4 60 — —

THC102AW 517-633 16.6 20 17.8 20 — —
THC120A3 187-253 48.6 60 52.6 60 — —

THC120AW 517-633 19.9 25 21.6 25 — —

Unit Minimum Maximum Fuse Minimum Maximum Fuse Minimum Maximum Fuse

Standard Indoor Fan Motor Oversize Indoor Fan Motor Belt Dri ve Indoor Fan Motor

1

Ampacity Circuit Breaker

1

Optional

Ampacity Circuit Breaker

2

1

RT-PRC005-EN

51

Electrical

(Standard

Data

Efficiency)

Table ED-3 — Unit Wiring With Electric Heat (Single Point Connection) —208/230 Volts — Standard Efficiency

Standard Indoor Motor Oversize Indoor Motor

To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or

Tons With Model No. kW Rating1Stages MCA Max Circuit Breaker

2

MCA Max Circuit Breaker

208/230 Volts Single Phase

3 TSC036A1 BAYHTRR110A 7.5/10.0 2 48.0/55.0 50/60 51.0/58.0 60/60

4 TSC048A1

5 TSC060A1

BAYHTRR105A 3.8/5.0 1 25.5/28.9 40/40 28.5/31.9 40/40

BAYHTRR114A 10.4/13.8 2 65.1/74.8 70/80 68.1/77.8 70/80

BAYHTRR105A 3.8/5.0 1 34.0/34.0 50/50 36.1/36.1 50/50
BAYHTRR110A 7.5/10.0 2 49.6/56.6 50/60 52.3/59.3 60/60
BAYHTRR114A 10.4/13.8 2 66.8/76.4 70/80 69.4/79.0 70/80
BAYHTRR118A 13.2/17.6 2 84.0/96.1 90/100 86.6/98.8 90/100

BAYHTRR105A 3.8/5.0 1 47.3/47.3 60/60 49.0/49.0 60/60
BAYHTRR110A 7.5/10.0 2 52.9/59.9 60/60 55.0/62.0 60/70
BAYHTRR114A 10.4/13.8 2 70.0/79.6 80/80 72.1/81.8 80/90
BAYHTRR118A 13.2/17.6 2 87.3/99.4 90/100 89.4/101.54 90/110

208/230 Volts Three Phase

3 TSC036A3 BAYHTRR312A 9.0/12.0 2 34.1/39.0 35/40 37.1/42.0 40/45

4 TSC048A3 BAYHTRR312A 9.0/12.0 2 35.8/40.6 40/45 38.4/43.3 40/45

5 TSC060A3

BAYHTRR306A 4.5/6.0 1 18.5/20.9 25/25 21.5/23.9 30/30

BAYHTRR318A 13.1/17.4 2 48.3/55.3 50/60 51.3/58.3 60/60

BAYHTRR306A 4.5/6.0 1 23.9/23.9 35/35 26.0/26.0 40/40

BAYHTRR318A 13.1/17.4 2 49.9/56.9 50/60 52.5/59.5 60/60

BAYHTRR306A 4.5/6.0 1 31.5/31.5 50/50 33.2/33.2 50/50
BAYHTRR312A 9.0/12.0 2 39.0/43.9 50/50 41.1/46.0 50/50
BAYHTRR318A 13.1/17.4 2 53.1/60.1 60/70 55.3/62.3 60/70
BAYHTRR323A 17.3/23.0 2 67.8/76.9 70/80 69.9/79.0 70/80

2

BAYHTRS309A 6.8/9.0 1 32.7/33.4 50/50 34.0/35.0 50/50

6 TSC072A3 BAYHTRS318A 13.5/18.0 1 53.1/60.4 60/70 54.8/62.0 60/70

TSC090A3 BAYHTRS318A 13.5/18.0 1 54.8/62.0 60/70 58.6/65.9 60/70

7½

TSC092A3 BAYHTRS318A 13.5/18.0 1 54.8/62.0 60/70 58.6/65.9 60/70

8½ TSC102A3 BAYHTRT318A 13.5/18.0 1 54.8/62.0 60/70 58.6/65.9 60/70

10 TSC120A3 BAYHTRT327A 20.3/27.0 2 82.1/93.0 90/100 87.1/98.0 90/100

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRS327A 20.3/27.0 2 76.6/87.5 80/90 78.3/89.1 80/90
BAYHTRS336A 27.0/36.0 2 100.1/114.5 110/125 101.8/116.1 110/125

BAYHTRS309A 6.8/9.0 1 42.7/42.7 60/60 45.8/45.8 60/60

BAYHTRS327A 20.3/27.0 2 78.3/89.1 80/90 82.1/93.0 90/100
BAYHTRS336A 27.0/36.0 2 101.8/116.1 110/125 105.6/120.0 110/125

BAYHTRS309A 6.8/9.0 1 38.9/38.9 50/50 42.0/42.0 50/50

BAYHTRS327A 20.3/27.0 2 78.3/89.1 80/90 82.1/93.0 90/100
BAYHTRS336A 27.0/36.0 2 101.8/116.1 110/125 105.6/120.0 110/125

BAYHTRT309A 6.8/9.0 1 45.1/45.1 60/60 48.2/48.2 60/60

BAYHTRT327A 20.3/27.0 2 78.3/89.1 80/90 82.193.0 90/100
BAYHTRT336A 27.0/36.0 2 101.8/116.1 110/125 105.6/120.0 110/125

BAYHTRT318A 13.5/18.0 1 58.6/65.9 60/70 63.6/70.9 70/80

BAYHTRT336A 27.0/36.0 2 105.8/120.0 110/125 110.6/125.0 125/125
BAYHTRT354A 40.6/54.0 2 152.5/141.7 175/150 157.5/146.7 175/150

52

RT-PRC005-EN

Electrical

(Standard

Data

Efficiency)

Table ED-4 — Unit Wiring With Electric Heat (Single Point Connection) — Standard Efficiency

Standard Indoor Motor Oversize Indoor Motor

To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or

Tons With Model No. kW Rating1Stages MCA Max Circuit Breaker

2

MCA Max Circuit Breaker

380 Volts Three Phase

5 TSC060AK BAYHTRR418A 10.9 2 26.1 30 — —

6 TSC072AK BAYHTRS427A 16.9 2 38.3 40 — —

7½

TSC090AK BAYHTRS427A 16.9 2 38.3 40 40.1 45

8½ TSC102AK

10 TSC120AK BAYHTRT436A 22.6 2 50.9 60 54.4 60

BAYHTRR412A 7.5 2 19.6 30 — —

BAYHTRR423A 14.4 2 32.8 35 — —

BAYHTRS418A 11.3 1 27.6 35 — —

BAYHTRS436A 22.6 2 49.0 50 — —

BAYHTRS418A 11.3 1 28.4 40 29.9 45

BAYHTRS436A 22.6 2 49.0 50 50.9 60

BAYHTRT427A 16.9 2 38.8 40 40.1 45
BAYHTRT436A 22.6 2 49.0 50 50.9 60

BAYHTRT427A 16.9 2 40.1 45 43.6 45

BAYHTRT454A 33.8 2 72.3 80 75.8 80

460 Volts Three Phase

3 TSC036A4 BAYHTRR412A 12.0 2 19.4 20 20.9 25

4 TSC048A4 BAYHTRR412A 12.0 2 20.1 25 22.1 25

5 TSC060A4

6 TSC072A4 BAYHTRS418A 18.0 1 30.3 35 31.0 35

TSC090A4 BAYHTRS418A 18.0 1 31.0 35 32.9 35

7½

TSC092A4 BAYHTRS418A 18.0 1 31.0 35 32.9 35

8½ TSC102A4 BAYHTRT418A 18.0 1 31.0 35 32.9 35

10 TSC120A4 BAYHTRT427A 27.0 2 46.4 50 48.9 50

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V, unit

2. HACR type circuit breaker per NEC.

BAYHTRR406A 6.0 1 10.4 15 11.9 15

BAYHTRR418A 17.4 2 27.5 30 29.0 30

BAYHTRR406A 6.0 1 12.8 20 14.4 20

BAYHTRR418A 17.4 2 28.3 30 30.3 35

BAYHTRR406A 6.0 1 16.0 25 16.3 25
BAYHTRR412A 12.0 2 21.6 25 22.0 25
BAYHTRR418A 17.4 2 29.8 30 30.1 35
BAYHTRR423A 23.0 2 38.3 40 38.6 40

BAYHTRS409A 9.0 1 17.6 25 18.2 25

BAYHTRS427A 27.0 2 43.8 45 44.5 45
BAYHTRS436A 36.0 2 57.3 60 58.0 60

BAYHTRS409A 9.0 1 22.6 35 24.1 35

BAYHTRS427A 27.0 2 44.5 45 46.4 50
BAYHTRS436A 36.0 2 58.0 60 59.9 60

BAYHTRS409A 9.0 1 20.5 25 22.0 25

BAYHTRS427A 27.0 2 44.5 45 46.4 50
BAYHTRS436A 36.0 2 58.0 60 59.9 60

BAYHTRT409A 9.0 1 24.0 30 25.5 35

BAYHTRT427A 27.0 2 44.5 45 46.4 50
BAYHTRT436A 36.0 2 58.0 60 59.9 60

BAYHTRT418A 18.0 1 32.9 35 35.4 40

BAYHTRT436A 36.0 2 59.9 60 62.4 70
BAYHTRT454A 54.0 2 70.8 80 73.3 80

2

RT-PRC005-EN

53

Electrical

(Standard

Data

Efficiency)

Table ED-5 — Unit Wiring With Electric Heat (Single Point Connection) — 575 Volts — Standard Efficiency

Standard Indoor Motor Oversize Indoor Motor

To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or

Tons With Model No. kW Rating

1

Stages MCA Max Circuit Breaker

2

MCA Max Circuit Breaker

575 Volts Three Phase

3 TSC036AW BAYHTRRW12A 12.0 2 15.8 20 16.6 20

4 TSC048AW BAYHTRRW12A 12.0 2 16.3 20 17.3 20

5 TSC060AW

6 TSC072AW BAYHTRSW18A 18.0 1 23.8 25 24.8 25

TSC090AW BAYHTRSW18A 18.0 1 24.8 25 26.3 30

7½

TSC092AW BAYHTRSW18A 18.0 1 24.8 25 26.3 30

BAYHTRRW06A 6.0 1 8.6 15 9.3 15

BAYHTRRW18A 17.4 2 22.3 25 23.1 25

BAYHTRRW06A 6.0 1 9.8 15 10.6 15

BAYHTRRW18A 17.4 2 22.8 25 23.8 25

BAYHTRRW06A 6.0 1 12.2 15 12.8 20
BAYHTRRW12A 12.0 2 17.1 20 17.8 20
BAYHTRRW18A 17.4 2 23.6 25 24.3 25
BAYHTRRW23A 23.0 2 30.3 35 31.0 35

BAYHTRSW09A 9.0 1 13.0 20 14.0 20

BAYHTRSW27A 27.0 2 34.6 35 35.6 40
BAYHTRSW36A 36.0 2 45.4 50 46.4 50

BAYHTRSW09A 9.0 1 17.6 25 18.8 25

BAYHTRSW27A 27.0 2 35.6 40 37.1 40
BAYHTRSW36A 36.0 2 46.4 50 47.9 50

BAYHTRSW09A 9.0 1 15.5 20 16.7 20

BAYHTRSW27A 27.0 2 35.6 40 37.1 40
BAYHTRSW36A 36.0 2 46.4 50 47.9 50

2

8½ TSC102AW BAYHTRTW27A 27.0 2 35.6 40 37.1 40

10 TSC120AW BAYHTRTW27A 27.0 2 37.1 40 39.3 40

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRTW18A 18.0 1 24.8 25 26.3 30

BAYHTRTW36A 36.0 2 46.4 50 47.9 50

BAYHTRTW18A 18.0 1 26.3 30 28.4 30

BAYHTRTW36A 36.0 2 47.9 50 50.0 50
BAYHTRTW54A 54.0 2 56.6 60 58.8 60

54

RT-PRC005-EN

Electrical

(Standard

Data

Efficiency)

Table ED-5 — Unit Wiring With Electric Heat (Single Point Connection) — Optional Belt Drive — Standard Efficiency

Optional Belt Drive Indoor Motor

To Use Heater Heater Control Max Fuse Size Orr

Tons With Model No. kW Rating1Stages MCA Max Circuit Breaker

2

208/230 Volts Single Phase

3 TSC036A1 BAYHTRR110A N/A N/A N/A N/A

4 TSC048A1

5 TSC060A1

BAYHTRR105A N/A N/A N/A N/A

BAYHTRR114A N/A N/A N/A N/A

BAYHTRR105A N/A N/A N/A N/A
BAYHTRR110A N/A N/A N/A N/A
BAYHTRR114A N/A N/A N/A N/A
BAYHTRR118A N/A N/A N/A N/A

BAYHTRR105A N/A N/A N/A N/A
BAYHTRR110A N/A N/A N/A N/A
BAYHTRR114A N/A N/A N/A N/A
BAYHTRR118A N/A N/A N/A N/A

208/230 Volts Three Phase

3 TSC036A3 BAYHTRR312A 9.0/12.0 2 37.5/42.4 40/45

4 TSC048A3 BAYHTRR312A 9.0/12.0 2 37.5/42.4 40/45

5 TSC060A3

BAYHTRR306A 4.5/6.0 1 21.9/24.3 30/30

BAYHTRR318A 13.1/17.4 2 51.6/58.6 60/60

BAYHTRR306A 4.5/6.0 1 25.3/25.3 35/35

BAYHTRR318A 13.1/17.4 2 51.6/58.6 60/60

BAYHTRR306A 4.5/6.0 1 30.3/30.3 45/45
BAYHTRR312A 9.0/12.0 2 37.5/42.4 45/45
BAYHTRR318A 13.1/17.4 2 51.6/58.6 60/60
BAYHTRR323A 17.3/23.0 2 66.3/75.4 70/80

460 Volts Three Phase

3 TSC036A4 BAYHTRR412A 12.0 2 21.1 25

4 TSC048A4 BAYHTRR412A 12.0 2 21.1 25

5 TSC060A4

BAYHTRR406A 6.0 1 12.1 15

BAYHTRR418A 17.4 2 29.3 30

BAYHTRR406A 6.0 1 13.6 20

BAYHTRR418A 17.4 2 29.3 30

BAYHTRR406A 6.0 1 15.6 25
BAYHTRR412A 12.0 2 21.1 25
BAYHTRR418A 17.4 2 29.3 30
BAYHTRR423A 23.0 2 37.8 40

575 Volts Three Phase

3 TSC036AW BAYHTRRW12A 12.0 2 16.6 20

4 TSC048AW BAYHTRRW12A 12.0 2 16.6 20

5 TSC060AW

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRRW06A 6.0 1 9.3 15

BAYHTRRW18A 17.4 2 23.1 25

BAYHTRRW06A 6.0 1 10.0 15

BAYHTRRW18A 17.4 2 23.1 25

BAYHTRRW06A 6.0 1 11.8 15
BAYHTRRW12A 12.0 2 16.6 20
BAYHTRRW18A 17.4 2 23.1 25
BAYHTRRW23A 23.0 2 29.8 30

RT-PRC005-EN

55

Electrical
Data

(High Efficiency)

Table ED-7 — Unit Wiring With Electric Heat (Single Point Connection) — 208/230 Volts — High Efficiency

Standard Indoor Motor Oversize Indoor Motor

To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or

Tons With Model No. kW Rating

1

Stages MCA Max Circuit Breaker

2

MCA Max Circuit Breaker

208/230 Volts Single Phase

3 THC036A1 BAYHTRR110A 7.5/10.0 2 48.0/55.0 50/60 51.0/58.0 60/60

4 THC048A1

5 THC060A1

BAYHTRR105A 3.8/5.0 1 25.5/28.9 40/40 28.5/31.9 40/40

BAYHTRR114A 10.4/13.8 2 65.1/74.8 70/80 68.1/77.8 70/80

BAYHTRR105A 3.8/5.0 1 29.4/30.5 45/45 31.5/33.1 50/50
BAYHTRR110A 7.5/10.0 2 49.6/56.6 50/60 52.3/59.3 60/60
BAYHTRR114A 10.4/13.8 2 66.8/76.4 70/80 69.4/79.0 70/80
BAYHTRR118A 13.2/17.6 2 84.0/96.1 90/100 86.6/98.8 90/100

BAYHTRR105A 3.8/5.0 1 39.5/39.5 60/60 41.2/41.2 60/60
BAYHTRR110A 7.5/10.0 2 52.9/59.9 60/60 55.0/62.0 60/70
BAYHTRR114A 10.4/13.8 2 70.0/79.6 80/80 72.1/81.8 80/90
BAYHTRR118A 13.2/17.6 2 87.3/99.4 90/100 89.4/101.5 90/100

208/230 Volts Three Phase

3 THC036A3 BAYHTRR312A 9.0/12.0 2 34.1/39.0 35/40 37.1/42.0 40/45

4 THC048A3 BAYHTRR312A 9.0/12.0 2 35.8/40.6 40/45 38.4/43.3 40/45

5 THC060A3

BAYHTRR306A 4.5/6.0 1 18.5/20.9 25/25 21.5/23.9 25/25

BAYHTRR318A 13.1/17.4 2 48.3/55.3 50/60 51.3/58.3 60/60

BAYHTRR306A 4.5/6.0 1 21.2/22.5 30/30 23.3/25.1 35/35

BAYHTRR318A 13.1/17.4 2 49.9/56.9 50/60 52.5/59.5 60/60

BAYHTRR306A 4.5/6.0 1 30.0/30.0 45/45 31.7/31.7 45/45
BAYHTRR312A 9.0/12.0 2 39.0/43.9 45/45 41.1/46.0 45/50
BAYHTRR318A 13.1/17.4 2 53.1/60.1 60/70 55.3/62.3 60/70
BAYHTRR323A 17.3/23.0 2 67.8/76.9 70/80 69.9/79.0 70/80

2

6 THC072A3 BAYHTRS318A 13.5/18.0 1 53.1/60.4 60/70 54.8/62.0 60/70

7½ THC092A3 BAYHTRT318A 13.5/18.0 1 54.8/62.0 60/70 58.6/65.9 60/70

8½ THC102A3 BAYHTRT318A 13.5/18.0 1 54.8/62.0 60/70 58.6/65.9 60/70

10 THC120A3 BAYHTRT327A 20.3/27.0 2 82.1/93.0 90/100 87.1/98.0 90/100

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRS309A 6.8/9.0 1 34.8/34.8 50/50 35.7/35.7 50/50

BAYHTRS327A 20.3/27.0 2 76.6/87.5 80/90 78.3/89.1 80/90
BAYHTRS336A 27.0/36.0 2 100.1/114.5 110/125 101.8/116.1 110/125

BAYHTRT309A 6.8/9.0 1 38.1/38.1 50/50 44.2/44.2 50/50

BAYHTRT327A 20.3/27.0 2 78.3/89.1 80/90 82.1/93.0 90/100
BAYHTRT336A 27.0/36.0 2 101.8/116.1 110/125 105.6/120.0 110/125

BAYHTRT309A 6.8/9.0 1 42.3/42.3 50/50 44.2/44.2 50/50

BAYHTRT327A 20.3/27.0 2 78.3/89.1 80/90 82.1/93.0 90/100
BAYHTRT336A 27.0/36.0 2 101.8/116.1 110/125 105.6/120.0 110/125

BAYHTRT318A 13.5/18.0 1 58.6/65.9 60/70 63.6/70.9 70/80

BAYHTRT336A 27.0/36.0 2 105.6/120.0 110/125 110.6/125.0 125/125
BAYHTRT354A 40.6/54.0 2 152.5/141.7 175/150 157.5/146.7 175/150

56

RT-PRC005-EN

Electrical
Data

(High Efficiency)

Table ED-8 — Unit Wiring With Electric Heat (Single Point Connection) — 460 Volts — High Efficiency

Standard Indoor Motor Oversize Indoor Motor

To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or

Tons With Model No. kW Rating

1

Stages MCA Max Circuit Breaker

2

MCA Max Circuit Breaker

460 Volts Three Phase

3 THC036A4 BAYHTRR412A 12.0 2 19.4 20 20.9 25

4 THC048A4 BAYHTRR412A 12.0 2 20.1 25 22.1 25

5 THC060A4 BAYHTRR412A 12.0 2 21.6 25 22.0 25

6 THC072A4 BAYHTRS418A 18.0 1 30.3 35 31.0 35

7½ THC092A4 BAYHTRT418A 18.0 1 31.0 35 32.9 35

BAYHTRR406A 6.0 1 10.4 15 11.9 15

BAYHTRR418A 17.4 2 27.5 30 29.9 30

BAYHTRR406A 6.0 1 11.1 15 13.1 15

BAYHTRR418A 17.4 2 28.3 30 30.3 35

BAYHTRR406A 6.0 1 14.7 20 15.0 20

BAYHTRR418A 17.4 2 29.8 30 30.1 35
BAYHTRR423A 23.0 2 38.3 40 38.6 40

BAYHTRS409A 9.0 1 17.5 25 18.1 25

BAYHTRS427A 27.0 2 43.8 45 44.5 45
BAYHTRS436A 36.0 2 57.3 60 58.0 60

BAYHTRT409A 9.0 1 19.4 25 20.9 25

BAYHTRT427A 27.0 2 44.5 45 46.4 50
BAYHTRT436A 36.0 2 58.0 60 59.9 60

2

8½ THC102A4 BAYHTRT418A 18.0 1 31.0 35 32.9 35

10 THC120A4 BAYHTRT427A 27.0 2 46.4 50 48.9 50

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRT409A 9.0 1 21.4 25 22.9 30

BAYHTRT427A 27.0 2 44.5 45 46.4 50
BAYHTRT436A 36.0 2 58.0 60 59.9 60

BAYHTRT418A 18.0 1 32.9 35 35.4 40

BAYHTRT436A 36.0 2 59.9 60 62.4 70
BAYHTRT454A 54.0 2 70.8 80 73.3 80

RT-PRC005-EN

57

Electrical
Data

(High Efficiency)

Table ED-9 — Unit Wiring With Electric Heat (Single Point Connection) — 575 Volts — High Efficiency

Standard Indoor Motor Oversize Indoor Motor

To Use Heater Heater Control Max Fuse Size Or Max Fuse Size Or

Tons With Model No. kW Rating1Stages MCA Max Circuit Breaker

2

MCA Max Circuit Breaker

575 Volts Three Phase

3 THC036AW BAYHTRRW12A 12.0 2 15.8 20 16.6 20

4 THC048AW BAYHTRRW12A 12.0 2 16.3 20 17.3 20

5 THC060AW

6 THC072AW BAYHTRSW18A 18.0 1 23.8 25 24.8 25

7½ THC092AW BAYHTRTW27A 27.0 2 35.6 40 37.1 40

BAYHTRRW06A 6.0 1 8.6 15 9.3 15

BAYHTRRW18A 17.4 2 22.3 25 23.1 25

BAYHTRRW06A 6.0 1 9.1 15 10.1 15

BAYHTRRW18A 17.4 2 22.8 25 23.8 25

BAYHTRRW06A 6.0 1 11.8 15 12.4 15
BAYHTRRW12A 12.0 2 17.1 20 17.8 20
BAYHTRRW18A 17.4 2 23.6 25 24.3 25
BAYHTRRW23A 23.0 2 30.3 35 31.0 35

BAYHTRSW09A 9.0 1 13.5 20 14.3 20

BAYHTRSW27A 27.0 2 34.6 35 35.6 40
BAYHTRSW36A 36.0 2 45.4 50 46.4 50

BAYHTRTW18A 18.0 1 24.8 25 26.3 30

BAYHTRTW36A 36.0 2 46.4 50 47.9 50

2

8½ THC102AW BAYHTRTW27A 27.0 2 35.6 40 37.1 40

10 THC120AW BAYHTRTW27A 27.0 2 37.1 40 39.3 40

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRTW18A 18.0 1 24.8 25 26.3 30

BAYHTRTW36A 36.0 2 46.4 50 47.9 50

BAYHTRTW18A 18.0 1 26.3 30 28.4 30

BAYHTRTW36A 36.0 2 47.9 50 50.0 50
BAYHTRTW54A 54.0 2 56.6 60 58.8 60

58

RT-PRC005-EN

Electrical
Data

(High Efficiency)

Table ED-10 — Unit Wiring With Electric Heat (Single Point Connection) — Optional Belt Drive — High
Efficiency

Belt Drive Indoor Motor

Tons With Model No. kW Rating

To Use Heater Heater Control Max Fuse Size Or

1

Stages MCA Max Circuit Breaker

208/230 Volts Single Phase

3 THC036A1 BAYHTRR110A N/A N/A N/A N/A

4 THC048A1

5 THC060A1

BAYHTRR105A N/A N/A N/A N/A

BAYHTRR114A N/A N/A N/A N/A

BAYHTRR105A N/A N/A N/A N/A
BAYHTRR110A N/A N/A N/A N/A
BAYHTRR114A 1N/A N/A N/A N/A
BAYHTRR118A N/A N/A N/A N/A

BAYHTRR105A N/A N/A N/A N/A
BAYHTRR110A N/A N/A N/A N/A
BAYHTRR114A N/A N/A N/A N/A
BAYHTRR118A N/A N/A N/A N/A

208/230 Volts Three Phase

3 THC036A3 BAYHTRR312A 9.0/12.0 2 37.5/42.4 40/45

4 THC048A3 BAYHTRR312A 9.0/12.0 2 37.5/42.4 40/45

5 THC060A3

BAYHTRR306A 4.5/6.0 1 21.9/24.3 25/25

BAYHTRR318A 13.1/17.4 2 51.6/58.6 60/60

BAYHTRR306A 4.5/6.0 1 22.6/24.3 35/35

BAYHTRR318A 13.1/17.4 2 51.6/58.6 60/60

BAYHTRR306A 4.5/6.0 1 28.8/28.8 45/45
BAYHTRR312A 9.0/12.0 2 37.5/42.4 45/45
BAYHTRR318A 13.1/17.4 2 51.6/58.6 60/60
BAYHTRR323A 17.3/23.0 2 66.3/75.4 70/80

2

RT-PRC005-EN

460 Volts Three Phase

3 THC036A4 BAYHTRR412A 12.0 2 21.1 25

4 THC048A4 BAYHTRR412A 12.0 2 21.1 25

5 THC060A4 BAYHTRR412A 12.0 2 21.1 25

BAYHTRR406A 6.0 1 12.1 15

BAYHTRR418A 17.4 2 29.3 30

BAYHTRR406A 6.0 1 12.1 15

BAYHTRR418A 17.4 2 29.3 30

BAYHTRR406A 6.0 1 14.3 20

BAYHTRR418A 17.4 2 29.3 30
BAYHTRR423A 23.0 2 37.8 40

575 Volts Three Phase

3 THC036AW BAYHTRRW12A 12.0 2 16,6 20

4 THC048AW BAYHTRRW12A 12.0 2 16.6 20

5 THC060AW

NOTES:

1. Heater kW ratings are at 208/240 for 208/230V unit

2. HACR type circuit breaker per NEC.

BAYHTRRW06A 6.0 1 9.3 15

BAYHTRRW18A 17.4 2 23.1 25

BAYHTRRW06A 6.0 1 9.3 15

BAYHTRRW18A 17.4 2 23.1 25

BAYHTRRW06A 6.0 1 11.4 15
BAYHTRRW12A 12.0 2 16.6 20
BAYHTRRW18A 17.4 2 23.1 25
BAYHTRRW23A 23.0 2 29.8 30

59

Electrical
Data

Table ED-11 — Electrical Characteristics — Evaporator Fan Motor — 60 Cycle — Standard and Oversized

Standard Evaporator Fan Motor Oversized Evaporator Fan Motor

Tons Model No. No. Volts Phase HP FLA LRA No. Volts Phase HP FLA LRA

Unit

T#C036A1 1 208-230 1 .33 2.30 3.90 1 208-230 1 .50 4.70 9.80

3 T#C036A3 1 208-230 1 .33 2.30 3.90 1 208-230 1 .50 4.70 9.80

T#C036A4 1 460 1 .33 1.10 2.00 1 460 1 .50 2.30 5.20
T#C036AW 1 575 1 .33 1.10 1.80 1 460 1 .50 1.70 3.60

T#C048A1 1 208-230 1 .60 3.60 6.60 1 208-230 1 .80 5.70 13.60
T#C048A3 1 208-230 1 .60 3.60 6.60 1 208-230 1 ..80 5.70 13.60

4 T#C048A4 1 460 1 .60 1.70 2.80 1 460 1 .80 3.30 7.20

T#C048AW 1 575 1 .60 1.50 2.40 1 575 1 .80 2.30 5.80
T#C060A1 1 208-230 1 .90 6.20 14.0 1 208-230 1 1.00 7.90 16.40
T#C060A3 1 208-230 1 .90 6.20 14.0 1 208-230 1 1.00 7.90 16.40

5 T#C060A4 1 460 1 .90 2.90 6.60 1 460 1 1.00 3.2 8.20

T#C060AW 1 575 1 .90 2.10 4.90 1 575 1 1.00 2.4 5.00
TSC060AK 1 380 1 1.00 4.3 8.3 — — ————
T#C072A3 1 208-230 3 1.00 5.0 0 32.20 1 208-230 3 2.00 6.30 48.00

6 T#C072A4 1 460 3 1.0 0 2.50 16.10 1 460 3 2.00 3.10 24.00

T#C072AW 1 575 3 1.0 0 1.70 13.20 1 575 3 2.00 2.50 18.20
TSC072AK 1 380 3 2.0 4.9 35.0 — — ————
T#C090A3 1 208-230 3 2.00 6.30 48.00 1 208-230 3 3.00 9.40 83.00
T#C090A4 1 460 3 2.00 3.10 24.00 1 460 3 3.00 4.60 42.0 0
T#C090AW 1 575 3 2.00 2.50 18.20 1 575 3 3.00 3.70 31.00
TSC090AK 1 380 3 2.0 4.9 35.0 1 380 3 3.0 6.4 51.1

7½ T#C092A3 1 208-230 3 2.00 6.30 48.00 1 208-230 3 3.00 9.40 83.00

T#C092A4 1 460 3 2.00 3.10 24.00 1 460 3 3.00 4.60 42.0 0
T#C092AW 1 575 3 2.00 2.50 18.20 1 575 3 3.00 3.70 31.00
T#C102A3 1 208-230 3 2.00 6.30 48.0 0 1 208-230 3 3.00 9.40 83.00

8½ T#C102A4 1 460 3 2.00 3.10 24.00 1 460 3 3.00 4.60 42.00

T#C102AW 1 575 3 2.00 2.50 18.20 1 575 3 3.00 3.70 31.00
TSC102AK 1 380 3 2.0 4.9 35.0 1 380 3 3.0 6.4 51.1
T#C120A3 1 208-230 3 3.00 9.40 83.0 0 1 208-230 3 5.00 13.40 112.00

10 T#C120A4 1 460 3 3.00 4.60 42.00 1 460 3 5.00 6.60 56.00

T#C120AW 1 575 3 3.00 3.70 31.00 1 575 3 5.00 5.40 44.0
TSC120AK 1 380 3 3.0 6.4 51.1 1 380 3 5.0 10.8 66.5

Amps Amps

60

Table ED-12 — Electrical Characteristics — Evaporator Fan Motor — 60 Cycle — Optional Belt Drive

Tons Model No. No. Volts Phase HP FLA LRA

3 T#C036A3 1 208-230 3 1.00 5.00 32.20

4

5

Unit

T#C036A4 1 460 3 1.00 2.50 16.10

T#C036AW 1 575 3 1.00 1.70 13.20

T#C048A3 1 208-230 3 1.00 5.00 32.20
T#C048A4 1 460 3 1.00 2.50 16.10

T#C048AW 1 575 3 1.00 1.70 13.20

T#C060A3 1 208-230 3 1.00 5.00 32.20
T#C060A4 1 460 3 1.00 2.50 16.10

T#C060AW 1 575 3 1.00 1.70 13.20

Amps

RT-PRC005-EN

Electrical
Data

Table ED-13— Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle — Standard Efficiency

Compressor Motors Condenser Fan Motors

Tons Model No. No. Volts Phase HP

3 TSC036A3 1 208-230 3 3.1 3450

4 TSC048A3 1 208-230 3 3.9 3450 14.6 91.0 1 1 .33 2.0 6.6

5 TSC060A3 1 208-230 3 5.1 3450 18.6 128.0 1 1 .33 2.0 6.6

6 TSC072A4 1 460 3 6 3450 10.1 75 1 1 .70 2.50 5.80

7½ TSC092A3 2 208-230 3 4/2.8 3450 14.7/10.3 91/77 1 1 .70 3.85 9.30

8½ TSC102A4 2 460 3 5.1/2.8 3450 10.0/5.4 63/39 1 1 .75 2.8 6.8

10 TSC120A4 2 460 3 5.1/3.9 3450 9.5/7.4 63/46 1 1 .75 2.8 6.8

NOTES:

1. Amp draw for each motor; multiply value by number of motors to determine total amps.

2. HP for each compressor.

Unit

TSC036A1 1 208-230 1 3.1 3450 17.2 104.0 1 1 .20 1.5 2.5

TSC036A4 1 460 3 3.1 3450
TSC036AW 1 575 3 3.1 3450 4.9 30.4 1 1 .20 .5 1.2
TSC048A1 1 208-230 1 3.9 3450 22.7 131.0 1 1 .33 2.0 6.6

TSC048A4 1 460 3 3.9 3450 7.9 46.0 1 1 ..33 1.2 2.5
TSC048AW 1 575 3 3.9 3450 6.1 37.0 1 1 .33 .7 1.5
TSC060A1 1 208-230 1 5.1 3450 31.3 144.0 1 1 .33 2.0 6.6

TSC060A4 1 460 3 5.1 3450 9.5 63.0 1 1 .33 1.2 2.5
TSC060AW 1 575 3 5.1 3450 7.5 49.0 1 1 .33 .7 1.5
TSC060AK 1 380 3 5.1 3450 11.4 64 1 1 .40 1.1 4.3
TSC072A3 1 208-230 3 6 3450 18.6 156 1 1 .70 3.85 9.30

TSC072AW 1 575 3 6 3450 7.7 54 1 1 .70 1.54 3.60
TSC072AK 1 380 3 6 3450 12.2 70 1 1 .75 2.5 7.7

TSC090A3 1 208-230 3 7.5 3450 26.0 172 1 1 .70 3.85 9.30
TSC090A4 1 460 3 7.5 3450 13.6 90 1 1 .70 2.50 5.80
TSC090AW 1 575 3 7.5 3450 10.9 62.3 1 1 .70 1.54 3.60
TSC090AK 1 380 3 7.5 3450 16.4 92.5 1 1 .75 2.5 7.7

TSC092A4 2 460 3 4/2.8 3450 7.6/5.4 50/39 1 1 .70 2.50 5.80
TSC092AW 2 575 3 4/2.8 3450 5.8/4.2 37/31 1 1 .70 1.54 3.60

TSC102A3 2 208-230 3 5.1/2.8 3450 18.6/10.3 128/77 1 1 .75 4.0 9.4

TSC102AW 2 575 3 5.1/2.8 3450 8.2/4.2 49/31 1 1 .75 2.4 6.2
TSC102AK 1 380 3 5.1/2.8 3450 12.1/6.6 64/39 1 1 .75 2.5 7.7
TSC120A3 2 208-230 3 5.1/3.9 3450 18.6/14.7 128/91 1 1 .75 4.0 9.4

TSC120AW 2 575 3 5.1/3.9 3450 7.8/.58 49/37 1 1 .75 2.4 6.2
TSC120AK 1 380 3 5.1/3.9 3450 11.5/9.0 64/54 1 1 .75 2.5 7.7

2

RPM RLA LRA No. Phase HP FLA LRA

11.3 74.0 1 1 .20 1.5 2.5

6.0 37.6 1 1 .20 .6 1.3

Amps

1

Amps

RT-PRC005-EN

61

Electrical
Data

T

able ED-14 — Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle — High Efficiency

Tons Model No. No. Volts Phase HP2RPM RLA LRA No. Phase HP FLA LRA

3 THC036A4 1 460 3 2.8 3450 5.3 39.0 1 1 .20 0.6 1.3

4 THC048A4 1 460 3 3.5 3450 6.5 44.0 1 1 .33 1.2 2.5

5 THC060A4 1 460 3 4.5 3450 7.8 59.6 1 1 .33 1.2 2.5

6 THC072A4 1 460 3 5.7 3450 10 75 1 1 .70 2.50 5.80

7½ THC092A4 2 460 3 3.5/3.3 3450 6.4/5.8 44/44 1 1 .70 2.50 5.80

8½ THC102A4 2 460 3 3.9/3.5 3450 7.1/6.4 50/44 1 1 .75 2.8 6.8

10 THC120A4 2 460 3 4.8/3.5 3450 9.0/6.4 59.6/44 1 1 .75 2.8 6.8

NOTES:

1. Amp draw for each motor; multiply value by number of motors to determine total amps.

2. HP for each compressor.

Unit Amps

THC036A1 1 208-230 1 2.8 3450 16.1 88.0 1 1 .20 1.5 2.5
THC036A3 1 208-230 3 2.8 3450 10.3 77.0 1 1 .20 1.5 2.5

THC036AW 1 575 3 2.8 3450 4.3 31.0 1 1 .20 0.5 1.2

THC048A1 1 208-230 1 3.5 3450 19.0 109.0 1 1 .33 2.0 6.6
THC048A3 1 208-230 3 3.5 3450 12.5 88.0 1 1 .33 2.0 6.6

THC048AW 1 575 3 3.5 3450 4.9 34.0 1 1 .33 0.7 1.5

THC060A1 1 208-230 1 4.5 3450 25.0 169.0 1 1 .33 2.0 6.6
THC060A3 1 208-230 3 4.5 3450 17.4 124.0 1 1 .33 2.0 6.6

THC060AW 1 575 3 4.5 3450 6.2 49.4 1 1 .33 0.9 1.5

THC072A3 1 208-230 3 5.7 3450 20.7 156 1 1 .70 3.85 9.30

THC072AW 1 575 3 5.7 3450 8.2 54 1 1 .70 1.54 3.60

THC092A3 2 208-230 3 3.5/3.3 3450 12.4/12.4 88/88 1 1 .70 3.85 9.30

THC092AW 2 575 3 3.5/3.3 3450 4.8/4.8 34/34 1 1 .70 1.54 3.60

THC102A3 2 208-230 3 3.9/3.5 3450 14.7/12.4 91/88 1 1 .75 4.0 9.4

THC102AW 2 575 3 3.9/3.5 3450 5.4/4.8 37/34 1 1 .75 2.4 6.2

THC120A3 2 208-230 3 4.8/3.5 3450 17.3/12.4 124/88 1 1 .75 4.0 9.4

THC120AW 2 575 3 4.8/3.5 3450 7.1/4.8 49.4/34 1 1 .75 2.4 6.2

Compressor Motors Condenser Fan Motors

1

Amps

1

62

Table ED-15— Electrical Characteristics — Power Exhaust

Accessory
Tons Model No. Volts Phase HP RPM
6-10 BAYPWRX026 208-230 1 0.87 1075 5.7 16.3
6-10 BAYPWRX027 460 1 0.87 1075 3.3 6.8
6-10 BAYPWRX028 575 1 0.87 1075 2.3 5.4

Note:

1. Two speed.

1

FLA LRA

RT-PRC005-EN

Jobsite Connections

DISCONNECT

SWITCH

(BY OTHERS)

ZONE SENSOR
OR THERMOSTAT

ROOFTOP

UNIT

For specific wiring information, see the installation instructions.
All wiring except power wires is low voltage.
All customer supplied wiring to be copper and must conform to applicable electrical codes (such as NEC or CEC) and local electrical codes. Wiring shown dotted is to be
furnished and installed by the customer.

Zone Sensors — Typical Number Of Wires

A— Manual Changeover ...................................... 4

Manual/Auto Changeover ............................. 5

Manual/Auto Changeover with

Status Indication LED’s ..........................10

Programmable Night Setback with

Status Indication LED’s ............................ 7

Thermostats — Typical Number of WiresThermostats — Typical Number of Wires

Thermostats — Typical Number of Wires

Thermostats — Typical Number of WiresThermostats — Typical Number of Wires
A — 3 wires, 24-volts, Cooling Only

4 wires, 24-volts, with Electric Heat

B— 3 Power Wires + 1 Ground Wire (three phase)

2 Power Wires + 1 Ground Wire (single phase)

RT-PRC005-EN

63

Dimensional

All dimensions are in inches/millimeters.

3 - 5 Tons Standard Efficiency
3 and 4 Tons High Efficiency

Data

(3-5 Tons)

5 Tons High Efficiency

64

RT-PRC005-EN

Dimensional

All dimensions are in inches/millimeters.

Downflow Airflow Supply/Return
Through the Base Utilities

Data

(3-5 Tons)

Horizontal Airflow Supply/Return

Unit Clearance and Roof Opening

RT-PRC005-EN

65

Dimensional

All dimensions are in inches.

Data

37 1/8”
928 MM

(3-5 Tons)

Downflow Duct Connections — Field Fabricated

66

RT-PRC005-EN

Dimensional

All dimensions are in inches.

6 Tons Standard and High Efficiency
7½ Tons Standard Efficiency

Data

(6-10 Tons)

7½ Tons High Efficiency
8½ and 10 Tons Standard and High Efficiency

RT-PRC005-EN

67

Dimensional

All dimensions are in inches.

6-10 Tons — Downflow Airflow Supply and Return;
Through the Base Utilities

Data

(6-10 Tons)

6-10 Tons — Horizontal Airflow Supply and Return

6-10 Tons — Unit Clearance and Roof Opening

Return

Supply

68

RT-PRC005-EN

Dimensional

All dimensions are in inches.

6-10 Tons — Roof Curb

Data

(6-10 Tons)

6-10 Tons — Downflow Duct Connections —

Field Fabricated

RT-PRC005-EN

ALL FLANGES 1 1/4” (31 MM)

69

Dimensional

(3-5 Tons Options/

All dimensions are in inches.

Data

Accessories)

Economizer , Manual or Motorized Fresh Air Damper

Swing Diameter for Hinged Doors Option

Barometric Relief Damper Hood

See Page 65 for Through the Base Utilities Information

70

RT-PRC005-EN

Dimensional

(6-10 Tons Options/

All dimensions are in inches.

Data

Accessories)

6-10 Tons — Power Exhaust

6-10 Tons — Economizer and Barometric
Relief Damper Hoods

6-10 Tons — Swing Diameter for Hinged
Door(s) Option

See Page 68 for Through the Base Utilities Information

RT-PRC005-EN

71

Weights

Table W-1— Maximum Unit And Corner Weights (Lbs) And Center Of Gravity Dimensions (In.)

Tons Model No. Shipping

3

4

5

6

7½ TSC092A 899 756 261 202 131 162 39 21

8½

10

NOTES:

1. Corner weights are given for information only.

2. Weights are approximate.

Unit

TSC036A 501 409 132 104 79 94 31 19

THC036A 518 426 139 108 84 95 32 19
TSC048A 526 434 140 110 91 94 33 19
THC048A 560 468 146 113 97 111 31 20
TSC060A 543 451 149 114 88 99 31 18
THC060A 610 518 165 124 105 124 31 19

TSC072A 824 681 236 177 119 150 38 21
THC072A 861 718 235 182 128 173 38 22

TSC090A 897 754 257 188 129 180 37 22

THC092A 1000 857 289 222 148 197 38 21

TSC102A 978 835 281 223 149 181 40 21
THC102A 1036 893 294 233 159 207 39 22

TSC120A 1052 909 306 241 164 197 40 21
THC120A 1125 982 323 253 178 229 39 22

Maximum Weights (Lbs) Corner Weights (Lbs)

2

Net A B C D Length Width

1

Center of Gravity (In.)

72

Table W-2 — Factory-installed Options Net Weights (Lbs)

Accessory 3-5 Tons 6-10 Tons
Economizer 26 36
Barometric Relief 7 10
Powered Exhaust — 80
Motorized Outside Air Damper 20 30
Manual Outside Air Damper 16 26
Roof Curb 70 115
Oversized Motor 5 8
Belt Drive Motor 31 —
Smoke Detector, Return 7 7
Smoke Detector, Supply 5 5
Coil Guards 12 20
Hinged Doors 10 12
Powered Convenience Outlet 38 38
Through the Base Electrical 8 13
Electric Heaters 15 30
Unit Mounted Circuit Breaker 5 5
Unit Mounted Disconnect 5 5
Novar Control 8 8
Dehumidification (Hot Gas Reheat) Coil 15 25

NOTES:

1.Weights for options not listed are < 5 lbs.

2.Net weight should be added to unit weight when ordering
factory-installed accessories.

Net Weight

1,2

RT-PRC005-EN

Mechanical Specifications

General

The units shall be convertible airflow.
The operating range shall be between
115°F and 0°F in cooling as standard
from the factory for units with
microprocessor controls. Operating
range for units with electromechanical
controls shall be between 115°F and
40°F. Cooling performance shall be
rated in accordance with ARI testing
procedures. All units shall be factory
assembled, internally wired, fully
charged with R-22, and 100 percent run
tested to check cooling operation, fan
and blower rotation, and control
sequence before leaving the factory.
Wiring internal to the unit shall be
colored and numbered for simplified
identification. Units shall be UL listed
and labeled, classified in accordance to
UL 1995/CAN/CSA No. 236-M90 for
Central Cooling Air Conditioners.
Canadian units shall be CSA Certified.

Casing

Unit casing shall be constructed of zinc
coated, heavy gauge, galvanized steel.
Exterior surfaces shall be cleaned,
phosphatized, and finished with a
weather-resistant baked enamel finish.
Unit’s surface shall be tested 1000
hours in a salt spray test in compliance
with ASTM B117. Cabinet construction
shall allow for all maintenance on one
side of the unit. Service panels shall
have lifting handles and be removed
and reinstalled by removing only a
single fastener while providing a water
and air tight seal. All exposed vertical
panels and top covers in the indoor air
section shall be insulated with a
cleanable foil-faced, fire-retardent
permanent, odorless glass fiber
material. The base of the unit shall be
insulated with 1/2 inch, 1 pound density
foil-faced, closed-cell material. All
insulation edges shall be either
captured or sealed.The unit’s base pan
shall have no penetrations within the
perimeter of the curb other than the
raised 1
return openings to provide an added
water integrity precaution, if the
condensate drain backs up. The base of
the unit shall have provisions for forklift
and crane lifting, with forklift
capabilities on three sides of the unit.

1

/8 inch high downflow supply/

Unit Top

The top cover shall be one piece
construction or where seams exist, it
shall be double-hemmed and gasket­sealed. The ribbed top adds extra
strength and prevents water from
pooling on unit top.

Filters

One inch, throwaway filters shall be
standard on all 3-5 ton units. The filter
rack can be converted to two inch
capability. Two inch filters shall be factory
supplied on all 6-10 ton units. Optional 2­inch pleated filters shall be available.

Compressors

All 3 ton standard units shall have direct­drive, hermetic, reciprocating type
compressors. The reciprocating type
compressors have a centrifugal oil pump
providing positive lubrication to moving
parts. Motor shall be suction gas-cooled
and shall have a voltage utilization range
of plus or minus 10 percent of unit
nameplate voltage. Crankcase heater,
internal temperature, and current­sensitive motor overloads shall be
included for maximum protection.
Compressors shall have internal spring
isolation and sound muffling to minimize
vibration transmission and noise. Low
pressure switches shall be standard.

3 ton high efficiency and 4-10 ton
standard and high efficiency units shall
have direct-drive, hermetic, scroll type
compressors with centrifugal type oil
pumps. Motor shall be suction gas­cooled and shall have a voltage
utilization range of plus or minus 10
percent of unit nameplate voltage.
Internal overloads shall be provided with
the scroll compressors.

Refrigerant Circuits

Each refrigerant circuit offers a choice of
independent fixed orifice expansion
devices or thermal expansion valve.
Service pressure ports, and refrigerant
line filter driers are factory-installed as
standard. An area shall be provided for
replacement suction line driers.

Evaporator and Condenser Coils

Internally finned, 5/16” copper tubes
mechanically bonded to a configured
aluminum plate fin shall be standard.
Coils shall be leak tested at the factory to
ensure the pressure integrity. The
evaporator coil and condenser coil shall

be leak tested to 200 psig and pressure
tested to 450 psig. The condensor coil
shall have a patent pending 1 + 1 + 1
hybrid coil designed with slight gaps for
ease of cleaning. A removeable,
reversible, double-sloped condensate
drain pan with provision for through the
base condensate drain is standard.

Outdoor Fans

The outdoor fan shall be direct-drive,
statically and dynamically balanced,
draw-through in the vertical discharge
position. The fan motor shall be
permanently lubricated and shall have
built-in thermal overload protection.

Indoor Fan

All 3-5 ton 3-phase units offer a choice of
direct-drive, FC, centrifugal fans or belt
driven, FC centrifugal fans with
adjustable motor sheaves. 3-5 ton direct
drive oversized motors shall be available
for high static operations. All 6-10 ton
units shall have belt drive motors with
an adjustable idler-arm assembly for
quick-adjustment to fan belts and motor
sheaves. All motors shall be thermally
protected. All indoor fan motors meet
the U.S. Energy Policy Act of 1992
(EPACT).

Controls

Unit shall be completely factory-wired
with necessary controls and contactor
pressure lugs or terminal block for
power wiring. Unit shall provide an
external location for mounting a fused
disconnect device.

A choice of microprocessor or
electromechanical controls shall be
available.

Microprocessor controls provide for all
24 volt control functions. The resident
control algorithms shall make all
heating, cooling, and/or ventilating
decisions in response to electronic
signals from sensors measuring indoor
and outdoor temperatures. The control
algorithm maintains accurate
temperature control, minimizes drift
from set point, and provides better
building comfort. A centralized
Microprocessor shall provide anti-short
cycle timing and time delay between
compressors to provide a higher level of
machine protection.

RT-PRC005-EN

73

Mechanical
Specifications

24-volt electromechanical control circuit
shall include control transformer and
contactor pressure lugs for power
wiring. Units shall have single point
power entry as standard.

Accessories/Options

Electric Heaters — Factory or field-

installed electric heat modules shall be
available for installation within basic
unit. Electric heater elements shall be
constructed of heavy-duty nickel
chromium elements internally delta
connected for 240 volt, wye connected
for 480 and 600 volt. Staging shall be
achieved through the unitary control
processor (UCP). Each heater package
shall have automatically reset high limit
control operating through heating
element contactors. All heaters shall be
individually fused from the factory,
where required, and shall meet all NEC
and CEC requirements when properly
installed. Power assemblies shall provide
single-point connection. Electric heat
modules shall be UL listed or CSA
certified.

Roof Curb — The roof curb shall be
designed to mate with the unit’s
downflow supply and return and provide
support and a water tight installation
when installed properly. The roof curb
design shall allow field-fabricated
rectangular supply/return ductwork to be
connected directly to the curb. Curb
design shall comply with NRCA
requirements. Curb shall be shipped
knocked down for field assembly and
shall include wood nailer strips.

Economizer — This accessory shall be
either field or factory-installed and shall
be available with or without barometric
relief. The assembly includes fully
modulating 0-100 percent motor and
dampers, minimum position setting,
preset linkage, wiring harness with plug,
spring return actuator and fixed dry bulb
control. The barometric relief shall
provide a pressure operated damper that
shall be gravity closing and shall prohibit
entrance of outside air during the
equipment “off” cycle. Optional solid
state or differential enthalpy control shall
be available for either factory or field
installation. The factory-installed
economizer arrives in the shipping
position and shall be moved to the

74

operating position by the installing
contractor.

Powered Exhaust — The field installed
powered exhaust, available for 6-10 ton
units, shall provide exhaust of return air,
when using an economizer, to maintain
better bulding pressurization.

Remote Potentiometer — The minimum
position setting of the economizer shall
be adjusted with this accessory.

Manual Outside Air Damper — Factory
or field-installed rain hood and screen
shall provide up to 50 percent outside air.

Motorized Outside Air Dampers —
Factory or field-installed manually set
outdoor air dampers shall provide up to
50 percent outside air. Once set, outdoor
air dampers shall open to set position
when indoor fan starts. The damper shall
close to the full closed position when
indoor fan shuts down.

Discharge Air Sensing — This factory or
field-installed option provides true
discharge air sensing in heating models.
This sensor is a status indicator readable
through Tracer® or Tracker®. This option
is available for microprocessor
controlled units.

Oversized Motors — Factory or field­installed direct drive oversized motors
shall be available for high static
applications.

Through the Base Electrical Access —
An electrical service entrance shall be
factory provided allowing electrical
access for both control and main power
connections inside the curb and through
the base of the unit. Option will allow for
field installation of liquid-tight conduit
and an external field-installed disconnect
switch.

Through the Base Electrical with
Disconnect Switch — Factory-installed 3-

pole, molded case, disconnect switch
with provisions for through the base
electrical connections are available. The
disconnect switch will be installed in the
unit in a water tight enclosure with
access through a swinging door. Factory
wiring will be provided from the switch
to the unit high voltage terminal block.
The switch will be UL/CSA agency
recognized. Note: The disconnect switch
will be sized per NEC and UL guidelines
but will not be used in place of unit
overcurrent protection.

Through the Base Electrical with Circuit
Breaker — This option is a factory-

installed, thermal magnetic, molded
case, HACR Circuit Breaker with
provisions for through the base electrical
connections. The circuit breaker will be
installed in a water tight enclosure in the
unit with access through a swinging
door. Factory wiring will be provided
from the switch to the unit high voltage
terminal block. The circuit breaker will
provide overcurrent protection, be sized
per NEC and UL guidelines, and be
agency recognized by UL/CSA.

Powered or Unpowered Convenience
Outlet — This factory-installed option is a

GFCI, 120v/15amp, 2 plug, convenience
outlet, either powered or unpowered.
When the convenience outlet is
powered, a service receptacle disconnect
will be available. The convenience outlet
is powered from the line side of the
disconnect or circuit breaker, and
therefore will not be affected by the
position of the disconnect or circuit
breaker. This option can only be ordered
when the Through the Base Electrical
with either the Disconnect Switch or
Circuit Breaker option is ordered.

Clogged Filter/Fan Failure Switch — A
dedicated differential pressure switch is
available, factory-installed, to achieve
active fan failure indication and/or
clogged filter indication. These
indications will be registered with either
a zone sensor with status indication
lights or an Integrated Comfort™
System. This option is available for
microprocessor controlled units.

Reference or Comparative Enthalpy —
Factory-installed Reference or
Comparative Enthalpy option shall be
available when a factory-installed
Economizer is ordered. This option is
available for microprocessor controlled
units.

High Pressure Cutout — This factory­installed option is offered for units that
do not have High Pressure cutout as
standard. All 3-phase units with scroll
compressors include High Pressure
Cutout as standard.

Hinged Access Doors — Sheet metal
hinges are available factory-installed on
the Filter/Evaporator, Supply Fan/Heat,
and the Compressor/Control Access
Doors.

RT-PRC005-EN

Mechanical
Specifications

Supply and/or Return Air Smoke
Detector — With this option factory-

installed, if smoke is detected, all unit
operation will be shut down. Reset will
be manual at the unit. Return Air Smoke
Detectors require minimum allowable
airflow when used with certain models.
See the Installation, Operation, and
Maintenance (IOM) manual for the
models affected and the minimum
allowable airflow required. This option is
available for microprocessor controlled
units.

Black Epoxy Coated Condenser Coil —
The coil provides corrosion protection to
condenser coils for seacoast application.
The protection is a factory-applied
thermoset vinyl coating, bonded to
normal aluminum fin stock. The uniform
thickness of the bonded vinyl layer
exhibits excellent corrosion protection in
salt spray tests performed in accordance
with ASTM B117.

Dehumidification Option — The
dehumidification (hot gas reheat) option
shall be a factory-installed option that
provides increased dehumidification. The
option shall consist of a hot-gas reheat
coil located on the leaving air side of the
evaporator coil prepiped and circuited.

The option shall be equipped with
crankcase heater(s), low pressure
switch(es), Frostat™, and a thermostatic
expansion valve(s) (TXV) as standard.

Control Options

Trane Communication Interface — This

factory or field-installed option shall be
provided to interface microprocessor
controlled units with the Trane Integrated
Comfort

LonTalk® Communication Interface —

This factory or field-installed option shall
be provided to allow the unit to
communicate as a Tracer™LCI-R device
or directly with generic LonTalk Network
Building Automation System Controls.

Zone Sensor — This field-installed
control shall be provided to interface
with the Micro equipped units and shall
be available in either manual, automatic
programmable with night setback, with
system malfunction lights, or remote
sensor options.

TM

systems.

Thermostat — Two stage heating and
cooling operation or one stage heating
and cooling shall be available, for field
installation, in either manual or
automatic changeover. Automatic
programmable electronic with night set
back shall also be available.

Differential Pressure Switches — These
factory or field-installed sensors allow
individual fan failure and dirty filter
indication for microprocessor controlled
units. The fan failure switch will disable
all unit functions and “flash” the Service
LED on the zone sensor. The dirty filter
switch will light the Service LED on the
zone sensor and will allow continued
unit operation.

Enthalpy Control — Replaces the dry
bulb control with a wet bulb changeover
controller which has a fully adjustable
set point. Enthalpy control offers a
higher level of comfort control, along
with energy savings potential, than the
standard dry bulb control. This is due to
the additional wet bulb sensing
capability. This option shall be available
for microprocessor controlled units. It
can be field-installed, or factory-installed
with the factory-installed economizer.

Differential Enthalpy — Replaces the
standard dry bulb control with two
enthalpy sensors that compare total heat
content of the indoor air and outdoor air
to determine the most efficient air
source. This control option offers the
highest level of comfort control, plus
energy efficiency, available. This option
shall be available for microprocessor
controlled units. It can be field-installed,
or factory-installed with the factory­installed economizer.

Low Ambient Cooling — All
microprocessor units shall have cooling
capabilities down to 0°F as standard.
Electromechanical models have cooling
capabilites to 40°F as built, or to 0°F by
adding the optional low ambient (frostat)
control.

Thermal Expansion Valve — All units
shall have a short orifice refrigerate
control metering device. For more exact
refrigerant flow, when using unit in low
airflow applications, a Thermal
Expansion Valve option shall be
available.

Novar Unit Controls — Optional Novar
rooftop unit controls shall be factory
installed and tested. The Novar
electronic thermostat module will
interface to the unit microprocesser and
will control the unit to the desired stage
of cooling or heating.

Novar Return Air Sensor — This option,
when used in conjunction with Novar
Controls, will contain a factory provided
and wired zone temperature snesor
located in the return air stream.

CO2 Sensing — The CO2 sensor shall
have the ability to to monitor space
occupancy levels within the building by
measuring the parts per million of CO2
(Carbon Dioxide) in the air. As the CO2
levels increase, the outside air damper
modulates to meet the CO2 space
ventilation requirements. The CO2
accessory shall be available as field
installed.

Ventilation Override Accessory —With
the Ventilation Override Accessory
installed, the unit can be set to transition
to up to 3 different pre-programmed
sequences for Smoke Purge,
Pressurization, and Exhaust. The
transition occurs when a binary input on
the RTOM is closed (shorted). This would
typically be a hard wired relay output
from a smoke detector of fire control
panel. The ventilation override accessory
shall be available as field installed.

Humidity Sensor (BAYSENS036) —Field
installed, wall-mounted humidity sensor
is used to control activation of the hot
gas reheat dehumidification option. The
humidity sensor can be set for humidity
levels between 40% and 60% relative
humidity by adjusting the ReliaTel
Options Module.

Humidity Sensor (BAYSENS037) —Field
installed, duct-mounted humidity sensor
is used to control activation of the hot
gas reheat dehumidification option. The
humidity sensor can be set for humidity
levels between 40% and 60% relative
humidity by adjusting the ReliaTel
Options Module.

RT-PRC005-EN

75

*High Efficiency Units only

Trane
A business of American Standard Companies
www.trane.com

For more information contact your local dealer
(distributor), local district office, or e-mail us at
[e-mail]

Literature Order Number

File Number

Supersedes

Stocking Location

RT-PRC005-EN

PL-UN-RT-TSC/THC 3-10 TONS-PRC0 05-EN-03-03

PL-UN-RT-TSC/THC 3-10 TONS-PRC0 05-EN-02-03

March Publication Electronic Only

Trane has a policy of continuous product and product data improvement and reserves the right to change
design and specifications without notice.
