450Mbps
Wireless N Router
450 Mbps, the Fastest
11N Router
TL-WR94 0N
450Mbps
Multi-mode5dBi Antennas
Wireless Speed
Highlights
The Best Choice on 11N
Enjoy reliable Wi-Fi with the TL-WR940N. The Wireless N router creates
strong Wi-Fi connections for devices throughout your home. Its 3 x 3 MIMO
technology strengthens your wireless signal, and the fast Ethernet ports
create high-speed wired connections for lag-free gaming and streaming.
Power
Power
On/O
Wireless N Speed & Range
Complying with the IEEE 802.11n standard, TL-WR940N can establish a
wireless network and get up to 18X the speed and 6X the range of
conventional 11g products. Also, with transmission rates up to 450Mbps.
Reset
Tabl etSmartphone Laptop DesktopGame Console
Wi-Fi/
WPS
WAN Port
Connect to Internet
LAN Ports
Connect to Computers, TVs and Game Consoles
LAN
TP-Link 450Mbps Wireless N Router
TL-WR940N
Features
Reliability
· Wireless N Speed – 450Mbps Wi-Fi speed meets your daily
internet needs
· 802.11n – Backward compatible with 802.11b/g products
· Easy Bandwidth Management – Bandwidth Control allocates
necessary speed of each connected device to ensure quality
of multimedia streaming
Ease of Use Security
· Intuitive Web UI– Ensures quick and simple installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android or iOS device
· Guest Network – Keep your main network secure by creating a
separate network for friends and visitors
· Access Control – Establish a whitelist or blacklist to allow or
block certain devices from accessing the internet
· Parental Controls – Manage when and how children devices can
access the internet
· Encryptions for Secure Network – WPA-PSK/WPA2- PSK
encryptions provide active protection against security threats
TP-Link 450Mbps Wireless N Router
TL-WR940N
Specications
Hardware
· Ethernet Ports: 4 10/100Mbps LAN Ports, 1 10/100Mbps WAN Port
· Buttons: Power On/O Button, Reset Button, Wi-Fi/WPS Button
· Antennas: 3 xed Omni Directional Antennas
· External Power Supply: 9VDC / 0.6A
· Dimensions (W x D x H): 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Power Power
On/O
Wireless
· Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
· Frequency: 2.4-2.4835GHz
· Signal Rate:
11n: Up to 450Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
· Reception Sensitivity:
450M: -68dBm@10% PER
216M: -70dBm@10% PER
130M: -78dBm@10% PER
Reset
Wi-Fi/
WPS
WAN Port
54M: -74dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -93dBm@8% PER
LAN Ports
· Wireless Function: Enable/Disable Wireless Radio, WMM,
Wireless Statistics
· Wireless Security: WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
TP-Link 450Mbps Wireless N Router
TL-WR940N
Specications
OthersSoftware
· Working Modes: Wireless Router, Range Extender, Access Point
· WAN Type: Dynamic IP, Static IP, PPPoE, PPTP(Dual Access), L2TP(Dual
Access), Bigpond
· DHCP: Server, DHCP Client List, Address Reservation
· Quality of Service: WMM, Bandwidth Control
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, Comexe, NO-IP
· Access Control: Parental Controls, Local Management Control, Host list,
Access Schedule, Rule Management
· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· Management: Access Control, Local Management, Remote Management
· Certication
CE, FCC, RoHS, Wi-Fi
· System Requirements
Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
· Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
· Guest Network: 2.4GHz guest network
For more information, please visit
http://www.tp-link.com/en/products/details/TL-WR940N.html
or scan the QR code left
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2017 TP-Link Technologies Co., Ltd. All rights reserved.
TP-Link Technologies Co., Ltd.
Building 24 (oors 1, 3, 4, 5) and 28 (oors 1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China
www.tp-link.com
Storage Humidity: 5%~90% non-condensing
· Package Contents
450Mbps Wireless N Router TL-WR940N
Power Adapter
RJ-45 Ethernet Cable
Quick Installation Guide
www.tp-link.com
TP-Link 450Mbps Wireless N Router
TL-WR940N
