Page 1
4G LTE Mobile Wi-Fi
Go Anywhere
Connect Everywhere
M7000
4G LTE
150 Mbps
8 Hours
Usage
tpMiFi
App
Page 2
Highlights
Share 4G LTE Connection on the Go
The M7000, with a compact, elegant design, is very suitable for travel,
business trips, outdoor activities or wherever you may be. You can enjoy
a Wi-Fi hotspot without draining your phone’s battery.
Easy Management with the tpMiFi App
With the tpMiFi App, you can easily access and manage the M7000 from your
connected iOS/Android devices. The tpMiFi app allows you to set data limits,
control which devices can access your Wi-Fi, and send messages.
4G LTE Mobile Wi-FiTP-Link
M7000
Page 3
Features
Lightning 4G LTE Convenient Hotspot 8 Hours Usage
· Lightning Generation 4G LTE – Supports 4G LTE network,
compatible with 3G network
· The Faster Connections – Reaches up to 150 Mbps download
speed and 50 Mbps upload speed, to enjoy HD movies without
interruption, download les in seconds, and hold a video chat
without dropouts
* Actual wireless data throughput will vary as a result of network conditions,
client limitations, and environmental factors
· Plug and Play – Just insert a SIM card and power on to create a
stable Wi-Fi hotspot to share on the move
· High-Speed Hotspot – Share 2.4GHz Wi-Fi at speed of 300 Mbps
with up to 10 Wi-Fi devices
· 2000 mAh – 2000 mAh rechargeable battery capacity
· 8 hours – 8 hours of 4G sharing
· 480 hours – 480 hours of standby
* Actual battery time may vary due to dierent user environments
4G LTE Mobile Wi-FiTP-Link
M7000
Page 4
Specications
· Interface: 1 micro USB port, 1 SIM card slot
· Button: Power Button, Reset Button
· LED: Wi-Fi LED, Internet LED, Battery LED
· External Power Supply: 5V/1A
· Dimensions (W x D x H): 3.7 × 2.2 × 0.8 in. (94 × 56.7 × 19.8 mm)
· Antenna: Internal Antennas
Wireless
· Network Type:
4G: FDD-LTE: B1/B3/B5/B7/B8/B20
(2100/1800/850/2600/900/800 MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
3G: HSPA+/HSPA/UMTS: B1/B5/B8(2100/850/900 MHz)
· Wireless Standards: IEEE 802.11b/g/n 2.4 GHz
· Frequency: 2.4 GHz
· Wireless Speed: Up to 300 Mbps
· Transmit Power: <20dBm
· Reception Sensitivity:
OthersHardware
· Certication: CE, RoHS
· System Requirements:
Windows 10/8/7/Vista/XP, Mac OS, Android, iOS,
Windows Phone
· Environment
Operating Temperature: 0℃~35℃ (32℉ ~95℉)
Storage Temperature: -20℃~60℃ (-4℉ ~140℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
Mobile Wi-Fi M7000
11b 11Mbps: -87.5dBm;
11g 54Mbps: -74dBm;
11n HT20 MCS7: -70dBm;
11n HT40 MCS7: -68dBm;
· Wireless Security: Support WPA-PSK/WPA2-PSK,Wireless
MAC Filtering, Enable/Disable SSID Broadcast
· DHCP: Server, Client, DHCP Client List
For more information, please visit
https://www.tp-link.com/products/details/?model=M7000_V1
or scan the QR code left
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2019 TP-Link Technologies Co., Ltd. All rights reserved.
*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles,
volume and density of trac, and client location.
*Battery life estimates obtained through testing in a laboratory setting.
Micro USB Cable
2000 mAh Battery
Quick Installation Guide
www.tp-link.com
4G LTE Mobile Wi-FiTP-Link
M7000
