Toyota Priustwo 2014 Owner's Manual

Download

TABLE OF CONTENTS

Before driving

When driving

Interior

features

Maintenance

and care

When trouble

arises

Vehicle

specifications

Information on the hybrid system and adjusting and operating features such as door locks, mirrors, and steering column

Driving, stopping and safe-driving information

Air conditioning and audio systems, as well as other interior features for a comfortable driving experience

Cleaning and protecting your vehicle, performing do-ityourself maintenance, and mainten ance inform a tion

What to do if the vehicle needs to be towed, gets a flat tire, or is involved in an accident

Detailed vehicle information

For owners

Index

Reporting safety defects for U.S. owners, and seat belt and SRS airbag instructions for Canadian owners

Alphabetical listing of information contained in this manual

PRIUS_OM_OM47857U_DVD_(U)

TABLE OF CONTENTS Index

Before driving

1-1. Hybrid system

Hybrid system features ........ 32

Hybrid system precautions... 38 Energy monitor/

consumption screen........... 44

Hybrid vehicle driving tips .... 58

1-2. Key information

Keys..................................... 60

1-3. Opening, closing and locking

the doors

Smart key system

(with entry function)............ 63

Smart key system

(without entry function)....... 81

Wireless remote control ....... 87

Side doors............................ 89

Back door............................. 95

1-4. Adjustable components

(seats, mirrors, steering wheel)

Front seats.......................... 101

Rear seats.......................... 104

Head restraints................... 107

Seat belts............................ 111

Steering wheel.................... 119

Inside rear view mirror........ 120

Outside rear view mirrors ... 124

1-5. Opening and closing

the windows and moon roof

Power windows................... 126

Moon roof with Solar

Panel ................................ 129

1-6. Refueling

Opening the fuel tank

cap.................................... 134

1-7. Theft deterrent system

Immobilizer system............. 138

PRIUS_OM_OM47857U_DVD_(U)

1-8. Safety information

Correct driving posture....... 140

SRS airbags ....................... 142

Front passenger occupant

classification system......... 156

Child restraint systems ....... 162

Installing child restraints ..... 167

When driving

2-1. Driving procedures

Driving the vehicle............... 182

Power (ignition) switch........ 194

EV drive mode .................... 201

Hybrid transmission ............ 204

Turn signal lever ................. 213

Parking brake...................... 214

Horn.................................... 215

2-2. Instrument cluster

Gauges and meters ............ 216

Indicators and warning

lights ................................. 221

Multi-information display..... 225

Head-up display.................. 245

2-3. Operating the lights

and windshield wipers

Headlight switch.................. 252

Fog light switch................... 258

Windshield wipers

and washer....................... 260

Rear window wiper

and washer....................... 264

Headlight cleaner switch..... 267

2-4. Using other driving systems

Cruise control..................... 268

Dynamic radar cruise

control .............................. 272

LKA (Lane-Keeping

Assist) .............................. 289

Driving assist systems........ 300

Hill-start assist control........ 305

PCS (Pre-Collision

System)............................ 307

2-5. Driving information

Cargo and luggage............. 315

Vehicle load limits............... 320

Winter driving tips............... 321

Trailer towing...................... 326

Dinghy towing..................... 327

PRIUS_OM_OM47857U_DVD_(U)

TABLE OF CONTENTS Index

Interior features

3-1. Using the air conditioning

system and defogger

Air conditioning system...... 330

Using the steering wheel

climate remote control

switches ........................... 341

Solar Ventilation System.... 343

Remote Air Conditioning

System............................. 346

Rear window and outside

rear view mirror

defoggers switch.............. 350

3-2. Using the audio system

Audio system types............ 351

Using the AUX port/USB

port................................... 356

3-3. Using the interior lights

Interior lights list.................. 357

• Front interior lights............ 358

• Personal lights.................. 359

• Rear interior light.............. 359

3-4. Using the storage features

List of storage features....... 361

• Glove boxes ..................... 362

• Console box ..................... 363

• Cup holders...................... 364

• Bottle holders ................... 366

• Auxiliary boxes................. 367

3-5. Other interior features

Sun visors........................... 368

Vanity mirrors ..................... 369

Outside temperature

display .............................. 370

Power outlets...................... 371

Seat heaters....................... 373

Armrest............................... 375

Assist grips......................... 376

Floor mats........................... 377

Luggage compartment

features ............................ 379

Garage door opener........... 385

Safety Connect................... 393

PRIUS_OM_OM47857U_DVD_(U)

Maintenance and care

When trouble arises

4-1. Maintenance and care

Cleaning and protecting

the vehicle exterior............ 402

Cleaning and protecting

the vehicle interior............. 405

4-2. Maintenance

Maintenance

requirements..................... 408

General maintenance.......... 411

Emission inspection

and maintenance (I/M)

programs........................... 415

4-3. Do-it-yourself maintenance

Do-it-yourself service

precautions....................... 416

Hood ................................... 419

Positioning a floor jack........ 422

Engine compartment........... 425

12-volt battery..................... 437

Tires.................................... 443

Tire inflation pressure ......... 453

Wheels................................ 457

Electronic key battery.......... 460

Checking and replacing

fuses................................. 462

Light bulbs........................... 473

5-1. Essential information

Emergency flashers............ 490

If your vehicle needs

to be towed....................... 491

If you think something

is wrong............................ 498

5-2. Steps to take in an emergency

If a warning light turns

on or a warning buzzer

sounds.............................. 499

If a warning message

is displayed ...................... 513

If you have a flat tire........... 530

If the hybrid system

will not start...................... 545

If you lose your keys........... 547

If the electronic key does

not operate properly......... 548

If the 12-volt battery

is discharged.................... 550

If your vehicle overheats .... 556

If the vehicle becomes

stuck................................. 561

If your vehicle has to be

stopped in

an emergency .................. 563

PRIUS_OM_OM47857U_DVD_(U)

TABLE OF CONTENTS Index

Vehicle specifications

6-1. Specifications

Maintenance data (fuel,

oil level, etc.).................... 566

Fuel information ................. 577

Tire information.................. 581

6-2. Customization

Customizable features ....... 596

6-3. Initialization

Items to initialize................. 603

For owners

Reporting safety defects

for U.S. owners................. 606

Seat belt instructions

for Canadian owners

(in French)........................ 607

SRS airbag instructions

for Canadian owners

(in French)........................ 609

Index

Abbreviation list ............... 622

Alphabetical index............ 624

What to do if... .................. 635

PRIUS_OM_OM47857U_DVD_(U)

Pictorial index

P. 258

P. 252, 255

P. 252

P. 419

P. 260

P. 124

P. 129

P. 213

P. 255

Exterior

Moon roof with Solar Panel

Windshield wipers Hood

Outside rear view mirrors

Front turn signal lights

Fog lights

PRIUS_OM_OM47857U_DVD_(U)

Daytime running lights (for the U.S.A.)

Daytime running lights(for Canada) and headlights Parking lights Front side marker lights

P. 134

P. 213

P. 350

P. 443

P. 530

P. 575

P. 581

P. 252

P. 89

Back door

P. 95

P. 264

P. 252

Rear window defoggers

Rear window wiper

Fuel filler door

License plate lights

Side doors

Tires

●Rotation

●Replacement

●Inflation pressure

●Information

: If equipped

*: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”

or “NAVIGATION SYSTEM OWNER’S MANUAL”.

PRIUS_OM_OM47857U_DVD_(U)

Camera*

Rear turn signal lights

Tail lights

Rear side marker lights

P. 377

Pictorial index

P. 142

P. 101

P. 104

P. 362

P. 107

P. 111

P. 375

P. 364

Head restraints

Interior

Seat belts

Cup holders

Armrest

SRS front passenger airbag

Glove boxes

Rear seats

SRS side airbags

Front seats

Floor mat

PRIUS_OM_OM47857U_DVD_(U)

P. 120

P. 385

P. 368

P. 142

P. 359

P. 369

P. 359

P. 393

P. 129

P. 367

P. 376

Sun visors

Front interior/personal lights

Microphone*

Assist grips

Rear interior light

SRS curtain shield airbags Vanity mirrors “SOS” button

Moon roof switch Auxiliary box

Anti-glare inside rear view mirror Garage door opener switches



: If equipped

*: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”

or “NAVIGATION SYSTEM OWNER’S MANUAL”.

PRIUS_OM_OM47857U_DVD_(U)



P. 126

P. 89

Pictorial index

Window lock switch

Door lock switch

Inside lock button

Interior

Power window switches

PRIUS_OM_OM47857U_DVD_(U)

P. 363

P. 364

P. 356

P. 371

AUX port/USB port*

Console box

Power outlet

*: Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”

or “NAVIGATION SYSTEM OWNER’S MANUAL”.

PRIUS_OM_OM47857U_DVD_(U)

Cup holders

Pictorial index

P. 371

P. 373

P. 367

Seat heater switches

Interior

Auxiliary box

PRIUS_OM_OM47857U_DVD_(U)

Power outlet

Pictorial index

P. 252

P. 213

P. 258

P. 308

P. 214

P. 134

P. 445

P. 260

P. 264

P. 216

P. 225

P. 351

P. 142

P. 215

P. 142

P. 119

SRS driver airbag

Horn

Headlight switch

Instrument panel

Windshield wipers and washer switch Rear window wiper and washer switch

Turn signal lever

Fog light switch

Gauges and meters Multi-information display

Navigation system*

Audio system*

SRS knee airbag

Fuel filler door opener

Parking brake pedal

: If equipped

:Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.

:Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”.

PRIUS_OM_OM47857U_DVD_(U)

Pre-collision braking off switch

Tire pressure warning reset switch

Tilt and telescopic steering control lever

P. 219

P. 267

P. 419

P. 343

P. 124

Pictorial index

Instrument panel

Outside rear view mirror switches

Headlight cleaner switch

Ventilation switch

Instrument panel light control dial

Hood lock release lever

PRIUS_OM_OM47857U_DVD_(U)

P. 226

P. 268

P. 272

P. 226, 230

P. 341

P. 289

“TRIP” button

Climate remote control switches

Audio remote control switches

Talk switch* Telephone switches*

1, 2

“DISP” button

Cruise control switch

Dynamic radar cruise control

LKA (Lane-Keeping Assist)

switch

Vehicle-to-vehicle distance button 



switch



: If equipped

:Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.

:Refer to “DISPLAY AUDIO SYSTEM OWNER’S MANUAL”.

PRIUS_OM_OM47857U_DVD_(U)

P. 232

P. 218

P. 194

Pictorial index

P. 245

Instrument panel

Clock adjustment buttons

MPH or km/h button

Head-up display switches

Power (ignition) switch

PRIUS_OM_OM47857U_DVD_(U)

P. 330

P. 350

P. 201

P. 206

P. 490

P. 204

P. 207

Air conditioning system

Rear window and outside rear view

mirror defoggers switch

Emergency flasher switch EV drive mode switch

Eco drive mode switch Power mode switch

Shift lever

P position switch

: If equipped

PRIUS_OM_OM47857U_DVD_(U)

Pictorial index

P. 382

P. 96

P. 381

P. 379

Luggage compartment light

Luggage compartment

Luggage cover

Auxiliary box

PRIUS_OM_OM47857U_DVD_(U)

Cargo hooks

PRIUS_OM_OM47857U_DVD_(U)

: If equipped

For your information

Main Owner’s Manual

Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find some explanations for equipment not installed on your vehicle.

All specifications provided in this manual are current at the time of printing. However, because of the Toyota policy of continual product improvement, we reserve the right to make changes at any time without notice.

Depending on specifications, the vehicle shown in the illustrations may differ from your vehicle in terms of color and equipment.

Noise from under vehicle after turning off the hybrid system

Approximately five hours after the hybrid system is turned off, you may hear sound coming from under the vehicle for several minutes. This is the sound of a fuel evaporation leakage check and, it does not indicate a malfunction.

Accessories, spare parts and modification of your Toyota

A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.

This vehicle should not be modified with non-genuine Toyota products. Modification with non-genuine Toyota products could affect its performance, safety or durability, and may even violate governmental regulations. In addition, damage or performance problems resulting from the modification may not be covered under warranty.

PRIUS_OM_OM47857U_DVD_(U)

Installation of a mobile two-way radio system

The installation of a mobile two-way radio system in your vehicle could affect electronic systems such as:

● Multiport fuel injection system/sequential multiport fuel injection system

● Cruise control system

● Anti-lock brake system

● SRS airbag system

● Seat belt pretensioner system

Be sure to check with your Toyota dealer for precautionary measures or special instructions regarding installation.

High voltage parts and cables on the hybrid vehicles emit approximately the same amount of electromagnetic waves as the conventional gasoline powered vehicles or home electronic appliances despite of their electromagnetic shielding.

Unwanted noise may occur in the reception of the mobile two-way radio.

PRIUS_OM_OM47857U_DVD_(U)

Vehicle data recordings

Your Toyota is equipped with several sophisticated computers that will record certain data, such as:

• Engine speed

• Electric motor speed (traction motor speed)

• Accelerator status

• Brake status

• Vehicle speed

• Shift position

• Hybrid battery (traction battery) status The recorded data varies according to the vehicle grade level and options

with which it is equipped. Furthermore, these computers do not record conversations, sounds or pictures.

● Data usage Toyota may use the data recorded in these computers to diagnose malfunc-

tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except:

• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased

• In response to an official request by the police, a court of law or a government agency

• For use by Toyota in a lawsuit

• For research purposes where the data is not tied to a specific vehicle or vehicle owner

● Usage of data collected through Safety Connect (U.S. mainland only)

If your Toyota has Safety Connect and if you have subscribed to those services, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.

PRIUS_OM_OM47857U_DVD_(U)

Event data recorder

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less.

The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger safety belts were buckled/fas-

tened;

• How far (if at all) the driver was depressing the accelerator and/or brake

pedal; and,

• How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in

which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a nontrivial crash situa-

tion occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

PRIUS_OM_OM47857U_DVD_(U)

● Disclosure of the EDR data

Toyota will not disclose the data recorded in an EDR to a third party except when:

• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained

• In response to an official request by the police, a court of law or a government agency.

• For use by Toyota in a lawsuit

However, if necessary, Toyota may:

• Use the data for research on vehicle safety performance

• Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner

Scrapping of your Toyota

The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.

Perchlorate Material

Special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate.

Your vehicle has components that may contain perchlorate. These components may include airbag, seat belt pretensioners, and wireless remote control batteries.

PRIUS_OM_OM47857U_DVD_(U)

CAUTION

■ General precautions while driving

Driving under the influence: Never drive your vehicle when under the influence of alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.

Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or pedestrians might make and be ready to avoid accidents.

Driver distraction: Always give your full attention to driving. Anything that distracts the driver, such as adjusting controls, talking on a cellular phone or reading can result in a collision with resulting death or serious injury to you, your occupants or others.

■ General precaution regarding children’s safety

Never leave children unattended in the vehicle, and never allow children to have or use the key.

Children may be able to start the vehicle or shift the vehicle into neutral. There is also a danger that children may injure themselves by playing with the windows, the moon roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.

PRIUS_OM_OM47857U_DVD_(U)

CAUTION

■ Hybrid battery (traction battery)

Never resell, hand over or modify the hybrid battery (traction battery). To prevent accidents, hybrid batteries (traction batteries) that have been removed from a disposed vehicle are collected through Toyota dealers. Do not dispose of the battery yourself.

Unless the battery is properly collected, the following may occur, resulting in death or serious injury:

• The hybrid battery (traction battery) may be illegally disposed of or

dumped, and someone may touch a high voltage part, resulting in an electric shock.

• The hybrid battery (traction battery) is intended to be used exclusively

with your hybrid vehicle. If the hybrid battery (traction battery) is used outside of your vehicle or modified in any way, acc idents such as electric shock, heat generation, smoke generation, an explosion and electrolyte

leakage may occur. When reselling or handing over your vehicle, the possibility of an accident is extremely high because the person receiving the vehicle may not be aware of these dangers.

■ Disposal of the hybrid battery (traction battery)

If your vehicle is disposed of without the hybrid battery (traction battery) having been removed, there is a danger of serious electric shock if high voltage parts, cables and their connectors are touched. In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery (traction battery) is not disposed of properly, it may cause electric shock that can result in death or serious injury.

PRIUS_OM_OM47857U_DVD_(U)

Symbols used throughout this manual

CAUTION

NOTICE

ITOPP105

Cautions & Notices

This is a warning against something which, if ignored, may cause death or serious injury to people. You are informed about what you must or must not do in order to reduce the risk of death or serious injury to yourself and others.

This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toy ota and its equipment.

Symbols used in illustrations

Safety symbol

The symbol of a circle with a slash through it means “Do not”, “Do not do this”, or “Do not let this happen”.

Arrows indicating operations

Indicates the action (pushing, turning, etc.) used to operate switches and other devices.

Indicates the outcome of an operation (e.g. a lid opens).

PRIUS_OM_OM47857U_DVD_(U)

Before driving

1-1. Hybrid system

Hybrid system features...... 32

Hybrid system

precautions...................... 38

Energy monitor/

consumption screen......... 44

Hybrid vehicle driving

tips................................... 58

1-2. Key information

Keys................................... 60

1-4. Adjustable components

(seats, mirrors, steering wheel)

Front seats....................... 101

Rear seats........................ 104

Head restraints................. 107

Seat belts......................... 111

Steering wheel................. 119

Inside rear view mirror ..... 120

Outside rear view

mirrors............................ 124

1-3. Opening, closing and locking

the doors

Smart key system

(with entry function) ......... 63

Smart key system

(without entry function) .... 81

Wireless remote control..... 87

Side doors.......................... 89

Back door........................... 95

1-5. Opening and closing the

windows and moon roof

Power windows................ 126

Moon roof with Solar

Panel.............................. 129

1-6. Refueling

Opening the fuel tank

cap................................. 134

1-7. Theft deterrent system

Immobilizer system.......... 138

1-8. Safety information

Correct driving posture..... 140

SRS airbags..................... 142

Front passenger occupant

classification system...... 156

Child restraint systems..... 162

Installing child restraints... 167

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Your vehicle is a hybrid vehicle. It has characteristics different from

conventional vehicles. Be sure you are closely familiar with the char-

acteristics of your vehicle, and operate with care.

The hybrid system combines the use of a gasoline engine and an

electric motor (traction motor) according to driving conditions,

improving fuel efficiency and reducing exhaust emissions.

Gasoline engine Electric motor (traction motor)

Hybrid system features

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ When stopped/during start off

The gasoline engine stops

* when the vehicle is stopped. During

start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped

* and the electric motor (traction motor) is used.

When shift position is in N, the hybrid battery (traction battery) will not be charged. Thus, shift to P when the vehicle is stopped. In addition, when driving in heavy traffic, use D or B.

*: However, when the hybrid battery (traction battery) need to be

charged or while the engine is being warmed up , the gasoline engine may not stop automatically. (P. 35)

■ During normal driving

The gasoline engine is predominantly used. The electric motor (traction motor) charges the hybrid battery (traction battery) as necessary.

■ When accelerating sharply

When the accelerator pedal is depressed heavily, the power of the hybrid battery (traction battery) is added to that of the gasoline engine via the electric motor (traction motor).

■ When braking (regenerative braking)

The electric motor (traction motor) charges the hybrid battery (traction battery).

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Hybrid System Indicator represents the hybrid system power output and regenerative charging. (

P. 226)

Vehicle proximity notification system

When driving with the gasoline engine stopped, a sound, which changes in accordance with the driving speed, will be played in order to warn people nearby of the vehicle’s approach. The sound will stop when the vehicle speed exceeds approximately 15 mph (25 km/h).

■ Regenerative braking

In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery).

● The accelerator pedal is released while driving with the shift position in D

or B.

● The brake pedal is depressed while driving with the shift position in D or

■ Hybrid System Indicator

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ Conditions in which the gasoline engine may not stop

The gasoline engine starts and stops automatically. However, it may not stop automatically in the following conditions

● During gasoline engine warm-up

● When the temperature of the hybrid battery (traction battery) is high or

low

● During hybrid battery (traction battery) charging

● When the heater is switched on

*: Depending on the circumstances, the gasoline engine may also not stop

automatically in situations other than those above.

■ Charging the hybrid battery (traction battery)

● As the gasoline engine charges the hybrid battery (traction battery), the

battery does not need to be charged from an outside source. However, if the vehicle is left parked for a long time the hybrid battery (traction battery) will slowly discharge. For this reason, be sure to drive the vehicle at least once every few months for at least 30 minutes or 10 miles (16 km). If the hybrid battery (traction battery) becomes fully discharged and you are unable to jump-start the vehicle with the 12-volt battery, contact your Toyota dealer.

● If the shift position is in N, the hybrid battery (traction battery) will not be

charged. Always shift the shift position in P when the vehicle is stopped. When driving in heavy traffic, operate the vehicle with the shift position in D or B to avoid discharging the hybrid battery (traction battery).

■ Charging the 12-volt battery

P. 553

■ After the 12-volt battery has discharged or has been changed or

removed

The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your T oyot a dealer.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ Sounds and vibrations specific to a hybrid vehicle

There may be no engine sounds or vibration even though the vehicle is able to move. For safety, apply the parking brake and make sure to shift the shift position to P when parked.

The following sounds or vibrations may occur when the hybrid system is operating and are not a malfunction:

● The brake system operation sound heard from the front of the vehicle

when the driver’s door is opened.

● Motor sounds may be heard from the engine compartment.

● Sounds may be heard from the hybrid battery (traction battery) when the

hybrid system starts or stops.

● Sounds may be heard from the transmission when the gasoline engine

starts or stops, when driving at low speeds, or during idling.

● Engine sounds may be heard when accelerating sharply.

● Sounds may be heard due to regenerative braking when the brake pedal

is depressed and accelerator is loosened.

● Other sounds, such as motors and mechanical noises, may be heard

from the brake system when the brake pedal is depressed.

● Vibration may be felt when the gasoline engine starts or stops.

● Cooling fan sounds may be heard from the air intake vent. (

● The operation sound of the air conditioning system (air conditioning com-

pressor, blower motor).

P. 39)

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ Vehicle proximity notification system

In the following cases, the vehicle proximity notification system may be difficult for surrounding people to hear.

● In very noisy areas

● In the wind or the rain

Also, as the vehicle proximity notification system is installed on the front of the vehicle, it may be more difficult to hear from the rear of the vehicle compared to the front.

■ Maintenance, repair, recycling, and disposal

Contact your Toyota dealer regarding maintenance, repair, recycling and disposal. Do not dispose of the vehicle yourself.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Take care when handling the hybrid system, as it contains a high

voltage system (about 650V at maximum) as well as parts that

become extremely hot when the hybrid system is operating. Obey

the caution labels attached to the vehicle.

Air conditioning compressor High voltage cables (orange) Power control unit and DC/

DC converter Caution label

Service plug Electric motor (traction

motor) Hybrid battery (traction bat-

tery)

Hybrid system precautions

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Hybrid battery (traction battery) air vent

There is an air intake vent on the right side of the rear seatback for the purpose of cooling the hybrid battery (traction battery). If the vent becomes blocked, the hybrid battery (traction battery) may overheat, leading to a reduction in hybrid battery (traction battery) output.

Emergency shut off system

When a certain level of impact is detected by the impact sensor, the emergency shut off system blocks off the high voltage current and stops the fuel pump to minimize the risk of electrocution and fuel leakage. If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer.

Before driving

Hybrid warning message

A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.

If a warning message is shown on the multi-information display, read the message and follow the instructions. (P. 513)

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ If a warning light comes on, a warning message is displayed or the 12-

volt battery is disconnected

The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer.

■ Running out of fuel

When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (P. 504) go off. If there is only a small amount of fuel, the hybrid system may not be able to start. (The minimum amount of fuel to add to make the low fuel level warning light go out is about 1.9 gal. [7.1 L,

1.6 Imp.gal.], when the vehicle is on a level surface. This value may vary when the vehicle is on a slope.)

■ Electromagnetic waves

● High voltage parts and cables on the hybrid vehicles incorporate electro-

magnetic shielding, and therefore emit approximately the same amount of electromagnetic waves as conventional gasoline powered vehicles or home electronic appliances.

● Your vehicle may cause sound interference in some third party-produced

radio parts.

■ Hybrid battery (traction battery)

The hybrid battery (traction battery) has a limited service life. The lifespan of the hybrid battery (traction battery) can change in accordance with driving style and driving conditions.

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

CAUTION

● Never try to open the service plug

access hole located in the luggage compartment. The service plug is used only when the vehicle is serviced and is subject to high voltage.

■ High voltage precautions

The vehicle has high voltage DC and AC systems as well as a 12-volt system. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury.

● Never touch, disassemble, remove or replace the high voltage parts,

cables or their connectors.

● The hybrid system will become hot after starting as the system uses high

voltage. Be careful of both the high voltage and the high temperature, and always obey the caution labels attached to the vehicle.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

CAUTION

■ Road accident cautions

If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury:

● Stop the vehicle in a safe place to prevent subsequent accidents.

While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off. Then, slowly release the brake pedal.

● Do not touch the high voltage parts, cables and connectors.

● If electric wires are exposed inside or outside your vehicle, an electric

shock may occur. Never touch exposed electric wires.

● If a fluid leak occurs, do not touch the fluid as it may be strong alkaline

electrolyte from the hybrid battery (traction battery). If it comes into contact with your skin or eyes, wash it off immediately with a large amount of water or, if possible, boric acid solution. Seek immediate medical attention.

● If a fire occurs in the hybrid vehicle, leave the vehicle as soon as possible.

Never use a fire extinguisher that is not meant for electric fires. Using even a small amount of water may be dangerous.

● If your vehicle needs to be towed, do so with front wheels raised. If the

wheels connected to the electric motor (traction motor) are on the ground when towing, the motor may continue to generate electricity. This may cause a fire. (P. 491)

● Carefully inspect the ground under the vehicle. If you find that liquid has

leaked onto the ground, the fuel system may have been damaged. Leave the vehicle as soon as possible.

■ Hybrid battery (traction battery)

Your vehicle contains a sealed nickel-metal hydride battery. If disposed of improperly, it is hazardous to the environment and there is a risk of severe burns and electrical shock that may result in death or serious injury.

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

NOTICE

■ Hybrid battery (traction battery) air vent

● Do not put foreign objects near the air vent. The hybrid battery (traction

battery) may overheat and be damaged.

● Clean the air vent regularly to prevent the hybrid battery (traction battery)

from overheating.

● Do not wet or allow foreign substances to enter the air vent as this may

cause a short circuit and damage the hybrid battery (traction battery).

● Do not carry large amounts of water such as water cooler bottles in the

vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer.

● If the rear seat belt becomes separated from the guide (P. 105), it could

obstruct the hybrid battery (traction battery) air vent. Set the rear seat belt into the guide to use.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

You can view the status of your hybrid system on the Display Audio

system screen, the navigation system screen or the multi-informa-

tion display.

Display Audio system screen or navigation system screen

Multi-information display

Energy monitor/consumption screen

Energy monitor

Displays the flow of energy as it changes in accordance with driving conditions.

Display Audio system

Press “CAR”.

PRIUS_OM_OM47857U_DVD_(U)

If the “Consumption” screen is displayed, touch “Energy”.

Condition Display

1-1. Hybrid system

When the vehicle is powered by the electric motor (traction motor)

When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)

When the vehicle is powered by the gasoline engine

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Condition Display

When the vehicle is charging the hybrid battery (traction battery)

When there is no energy flow

Low Full

Hybrid battery (traction battery) status

These images are examples only, and may vary slightly from actual conditions.

PRIUS_OM_OM47857U_DVD_(U)

Navigation system

STEP

1-1. Hybrid system

Press “INFO APPS” or “INFO”.

Before driving

Touch “Fuel Consumption” on the “Information” scre en .

If the “Consumption” screen is displayed, touch “Energy”.

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Condition Display

When the vehicle is powered by the electric motor (traction motor)

When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)

When the vehicle is powered by the gasoline engine

PRIUS_OM_OM47857U_DVD_(U)

Condition Display

When the vehicle is charging the hybrid battery (traction battery)

1-1. Hybrid system

Before driving

When there is no energy flow

Hybrid battery (traction battery) status

These images are examples only, and may vary slightly from actual conditions.

PRIUS_OM_OM47857U_DVD_(U)

Low Full

1-1. Hybrid system

Multi-information display

■ Names and meaning of each icons

Press the “DISP” button to display the energy monitor.

Gasoline engine Hybrid battery (traction bat-

tery) Electric motor (traction motor)

Condition Display

When the vehicle is powered by the electric motor (traction motor)

When the vehicle is powered by both the gasoline engine and the electric motor (traction motor)

PRIUS_OM_OM47857U_DVD_(U)

Condition Display

When the vehicle is powered by the gasoline engine

When the vehicle is charging the hybrid battery (traction battery)

1-1. Hybrid system

Before driving

When there is no energy flow

Low Full

Hybrid battery (traction battery) status

These images are examples only, and may vary slightly from actual conditions.

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Consumption screen

Display Audio system

Press “CAR”.

If the “Energy Monitor” screen is displayed, touch “Consumption”.

Fuel consumption in the past 30 minutes

Cruising range (P. 57) Regenerated energy in the

past 30 minutes

One symbol indicates 30 Wh. Up to 4 symbols are shown.

The image is example only, and may vary slightly from actual conditions.

Navigation system

STEP

Press “INFO APPS” or “INFO”.

STEP

Touch “Fuel Consumption” on the “Information” screen.

If the “Energy Monitor” screen is displayed, touch “Fuel Consumption”.

Fuel consumption in the past 30 minutes

Regenerated energy in the past 30 minutes

One symbol indicates 30 Wh. Up to 4 symbols are shown.

Cruising range (P. 57)

The image is example only, and may vary slightly from actual conditions.

PRIUS_OM_OM47857U_DVD_(U)

Multi-information display

5-minute interval fuel consumption

1-1. Hybrid system

Press the “DISP” button to display the 5-minute or 1-minute fuel consumption display.

Press and hold the “DISP” button to switch between 5-minute and 1-minute fuel consumption displays.

The display will alternate with each press of the button.

Fuel consumption

Displays the average fuel consumption for the last 30 minutes in intervals of 5 minutes or the last 15 minutes in intervals of 1 minute.

Before driving

1-minute interval fuel consumption

Regenerated energy

Displays the amount of energy generated over the last 30 minutes in intervals of 5 minutes or the last 15 minutes in intervals of 1 minute.

One symbol indicates 50 Wh (5minute interval display) or 30 Wh (1-minute interval display). Up to 8 symbols are shown.

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

EV indicator*

Eco Driving Indicator Light* Average speed*

Average fuel consumption/eco savings

Use the displayed average fuel consumption as a reference.

: P. 226

:The current amount since the trip

meter was reset will be displayed. These functions can be reset by pressing and holding the “TRIP” button when either the 5-minute or 1-minute interval fuel consumption display is being shown.

The display can be switched between average fuel consumption/average speed and eco savings. (P. 234)

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Monthly fuel consumption record/Eco savings record (multiinformation display only)

Press the “DISP” button to display the monthly fuel consumption record or eco savings record.

Press and hold the “DISP” button to switch the display between monthly fuel consumption record and eco savings record.

The display will alternate with each press of the button.

Monthly fuel consumption record display Displays the average fuel consumption for the previous 6 months.

Average fuel consumption for the previous 6 months

EV indicator

Eco Driving Indicator Light* Driving distance for each

month

*: P. 226

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

Eco savings record display By setting the fuel consumption for comparison and the gasoline

price beforehand (P. 233), when the actua l fuel consumption is less than the fuel consumption for comparison, the difference is calculated and the amount of money saved or spent is displayed

: The displayed amount is intended only as a guide and may differ from

the actual amount.

Savings or consumption costs for the previous 6 months

Press the “TRIP” button to switch between the amount of money saved and spent.

EV indicator*

Eco Driving Indicator Light* Driving distance for each

month

: P. 226

■ Remaining hybrid battery (traction battery) charge display

The charge amount of the hybrid battery (traction battery) is automatically controlled by the hybrid system. For this reason, even if electricity is recovered via the regenerative braking, or electricity is generated via the gasoline engine, the displayed hybrid battery (traction battery) charge amount may not reach the highest level (level 8). However, this does not indicate a malfunction.

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ Resetting the consumption data

Display Audio system

Selecting “Clear” on the “Consumption” screen will reset the fuel consumption and the regenerated energy for the past 30 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data.

Navigation system

Multi-information display

If the “POWER” switch is turned OFF, average fuel consumption and regenerated energy data will be reset.

■ Resetting the monthly fuel consumption/eco savings record

Press and hold the “TRIP” button while the monthly fuel consumption/eco savings record is displayed. A confirmation message will be displayed. Press and hold the “TRIP” button to reset the data. Press the “DISP” button to cancel the reset operation. The screen will return to the previous display if no buttons are pressed for approximately 10 seconds.

■ Cruising range

Displays the estimated maximum distance that can be driven with the quantity of fuel remaining.

This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.

■ Odometer/trip meter/distance to empty

The odometer/trip meter/distance to empty will not be displayed while the monthly fuel consumption record or the eco savings record is being displayed.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

For economical and ecological driving, pay attention to the following points:

■ Using Eco drive mode

When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions. In addition, the operation of the air conditioning system (heating/cooling) will be minimized, improving the fuel economy. (P. 206)

■ Use of Hybrid System Indicator

Eco-friendly driving is possible by keeping the Hybrid System Indicator within Eco area. (P. 226)

■ When braking the vehicle

Make sure to operate the brakes gently and in good time. A greater amount of electrical energy can be retained when slowing down.

■ Delays

Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel consumption. Check traffic reports before leaving and avoid delays as much as possible. When encountering a delay, gently release the brake pedal to allow the vehicle to move forward slightly while avoiding overuse of the accelerator pedal. Doing so can help control excessive gasoline consumption.

■ Highway driving

Control your speed and keep at a constant speed. Also, before stopping at a toll booth or similar, allow plenty of time to release the accelerator and gently apply the brakes. A greater amount of electrical energy can be retained when slowing down.

Hybrid vehicle driving tips

PRIUS_OM_OM47857U_DVD_(U)

1-1. Hybrid system

■ Air conditioning on/off

Switch the air conditioning ( ) to off when it is not needed. Doing so can help control excessive gasoline consumption.

In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well.

In winter: Because the gasoline engine will not automatically cut out until the gasoline engine and the interior of the vehicle are warm, it will consume fuel. Also, fuel consumption can be improved by avoiding overuse of the heater.

■ Checking tire inflation pressure

Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel consumption. Also, as snow tires can cause large amounts of friction, their us e on dry roads can lead to poor fuel consumption. Use a tire that is appropriate for the season.

■ Luggage

Carrying heavy luggage can lead to poor fuel consumption. Avoid carrying unnecessary luggage. Installing a large roof rack can also cause poor fuel consumption.

■ Warming up before driving

Since the gasoline engine starts up and cuts out automatically when cold, warming up the engine is unnecessary. Moreover, frequently driving short distances will cause the engine to repeatedly warm up, which can lead to poor fuel consumption.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-2. Key information

The following keys are provided with the vehicle.

Electronic keys

• Operating the smart key system (P. 63, 81)

• Operating the wireless remote control function (P. 87)

• Operating the Remote Air Conditioning System

(P. 346)

Mechanical keys Key number plate

*: If equipped

Keys

Using the mechanical key

PRIUS_OM_OM47857U_DVD_(U)

To take out the mechanical key, push the release button and take the key out.

After using the mechanical key, store it in the electronic key. Carry the mechanical key together with the electronic key. If the electronic key battery is depleted or the entry function does not operate properly, you will need the mechanical key. (P. 548)

1-2. Key information

■ Key number plate

Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (P. 547)

■ When riding in an aircraft

When bringing an electronic key onto an aircraft, make sure you do not press any buttons on the electronic key while inside the aircraft cabin. If you are carrying an electronic key in your bag etc., ensure that the buttons are not likely to be pressed accidentally. Pressing a button may cause the electronic key to emit radio waves that could interfere with the operation of the aircraft.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-2. Key information

NOTICE

■ To prevent key damage

Observe the following:

● Do not drop the keys, subject them to strong shocks or bend them.

● Do not expose the keys to high temperatures for long periods of time.

● Do not get the keys wet or wash them in an ultrasonic washer etc.

● Do not attach metallic or magnetic materials to the keys or place the keys

close to such materials.

● Do not disassemble the keys.

● Do not attach a sticker or anything else to the surface of the electronic key.

● Do not place the keys near objects that produce magnetic fields, such as

TVs, audio systems and induction cookers, or medical electrical equipment, such as low-frequency therapy equipment.

■ Carrying the electronic key on your person

Carry the electronic key 3.9 in. (10 cm) or more away from electric appliances that are turned on. Radio waves emitted from electric appliances within 3.9 in. (10 cm) of the electronic key may interfere with the key , causing the key to not function properly.

■ In case of a smart key system malfunction or other key-related prob-

lems

Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer.

■ When a vehicle key is lost

If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

The following operations can be performed simply by carrying the

electronic key on your person, for example in your pocket.

(The driver should always carry the electronic key.)

Unlocks and locks the side doors (P. 64) Unlocks and locks the back door (P. 65) Starts and stops the hybrid system (P. 194)

Smart key system (with entry function)

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Unlocking and locking the doors

Front door handles (including front passenger door handle if equipped with entry function)

Grip the driver’s door handle to unlock the door. Grip the passenger’s door handle to unlock all the doors.

Make sure to touch the sensor on the back of the handle.

The doors cannot be unlocked for 3 seconds after the doors are locked.

*: The door unlock settings can be

changed. (P. 72)

Touch the lock sensor (the indentation on the upper part of the door handle) to lock the doors.

PRIUS_OM_OM47857U_DVD_(U)

Check to see that all the side doors and back door are securely locked.

1-3. Opening, closing and locking th e do o r s

Back door (vehicles with entry function of front and back doors)

Press the unlock button to unlock all the doors.

The doors cannot be unlocked for 3 seconds after the doors are locked.

Press the lock button to lock all the doors.

Check to see that all the side doors and back door are securely locked.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Antenna location and effective range

■ Antenna location

Vehicles with entry function of driver’s door

Antennas outside cabin Antennas inside cabin

Vehicles with entry function of front and back doors

Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage

compartment

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Effective range (areas within which the electronic key is

detected)

Vehicles with entry function of driver’s door

When locking or unlocking

the door

The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of driver’s door handle.

When starting the hybrid

system or changing “POWER” switch modes

The system can be operated when the electronic key is inside the vehicle.

Vehicles with entry function of front and back doors

When locking or unlocking

the doors

Before driving

The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handle and back door opener switch. (Only the doors detecting the key can be operated.)

When starting the hybrid

system or changing “POWER” switch modes

The system can be operated when the electronic key is inside the vehicle.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

If the door will not lock even when the topside sensor area is touched, try touching both the topside and underside sensor areas at the same time.

■ Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)

■ When the door cannot be locked by the lock sensor on the upper part

of the door handle

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

Alarm Situation Correction procedure

Interior alarm pings once and exterior alarm sounds once for 5 seconds

An attempt was made to lock the doors using the entry function while the electronic key was still inside the passenger compartment

Retrieve the electronic key from the passenger compartment and lock the doors again

An attempt was made to exit the vehicle and lock the doors without first turning the “POWER” switch off

Turn the “POWER” switch off and lock the doors again

Exterior alarm sounds once for 5 seconds

An attempt was made to lock the vehicle while a door is open

Close all of the doors and lock the doors again

■ Alarms and warning lights

A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures in response to any warning message shown on the multi-information display. (P. 524)

The following table describes circumstances and correction procedures when only alarms are sounded.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Alarm Situation Correction procedure

Interior alarm pings continuously

The “POWER” switch was turned to ACCESSORY mode while the driver’s door was open (or the driver’s door was opened while the “POWER” switch was in ACCESSORY mode)

Turn the “POWER” switch off and close the driver’s door

Interior alarm sounds continuously

When the “POWER” switch is in ON mode or ACCESSORY mode, an attempt was made to open the door and exit the vehicle, and the shift position was not in P

Shift the shift position to P and turn the “POWER” switch off

Interior and exterior alarms sound continuously

When the “POWER” switch is in ON mode or ACCESSORY mode, the driver’s door was closed after the key was carried outside the vehicle, and the shift position not in P

Shift the shift position to P, turn the “POWER” switch off and close the driver’s door again

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

Alarm Situation Correction procedure

Interior alarm pings once

The electronic key has a low battery

Replace the electronic key battery

An attempt was made to start the hybrid system without the electronic key being present, or the electronic key was not functioning normally

Start the hybrid system with the electronic key present

Interior alarm pings once and exterior alarm sounds 3 times

The driver’s door was closed after the key was carried outside the vehicle, and the “POWER” switch was not turned OFF

Turn the “POWER” switch off and close the driver’s door again

An occupant carried the electronic key outside the vehicle and closed the door while the “POWER” switch was not OFF

Bring the electronic key back into the vehicle

Before driving

: A message will be shown on the multi-information display in the instru-

ment cluster.

: If the hybrid sy stem does not start when the electronic key is inside the

vehicle, the electronic key battery may be depleted or there may be difficulties receiving signal from the key. (P. 548)

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Multi-information

display

Unlocking doors Beep

Hold the driver’s door handle to unlock only the driver’s door.

Exterior: Beeps three times Interior: Pings once

Hold the passenger’s door handle or back door opener to unlock all the doors.

Hold the front door handle or back door opener to unlock all the doors.

Exterior: Beeps twice Interior: Pings once

■ Security feature

If a door is not opened within approximately 60 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.

■ Switching the door unlock function

It is possible to set which doors the entry function unlocks.

STEP

Turn the “POWER” switch off.

STEP

When the indicator on the key surface is turned off, push and hold

or for approximately 5 seconds while pushing the but-

ton on the key.

The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat .)

STEP

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Battery-saving function

The battery-saving function will be activated in order to prevent the electronic key battery and the 12-volt battery from being discharged while the vehicle is not in operation for a long time.

● In the following situations, the smart key system may take some time to

unlock the doors.

• The electronic key has been left in an area of approximately 6 ft. (2 m) of the outside of the vehicle for 10 minutes or longer.

• The smart key system has not been used for 5 days or longer.

● If the smart key system has not been used for 14 days or longer, the

doors cannot be unlocked at any doors except the driver’s door. In this case, take hold of the driver’s door handle, or use the wireless remote control or the mechanical key, to unlock the doors.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

■ Conditions affecting operation

The smart key system, wireless remote control and immobilizer system use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and immobilizer system from operating properly. (Ways of coping: P. 548)

● When the electronic key battery is depleted

● Near a TV tower, electric power plant, gas station, radio station, large dis-

play, airport or other facility that generates strong radio waves or electrical noise

● When carrying a portable radio, cellular phone, cordless phone or other

wireless communication devices

● When the electronic key is in contact with, or is covered by the following

metallic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

● When other wireless key (that emit radio waves) is being used nearby

● When carrying the electronic key together with the following devices that

emit radio waves

• Another vehicle’s electronic key or a wireless key that emits radio waves

• Personal computers or personal digital assistants (PDAs)

• Digital audio players

• Portable game systems

● If window tint with a metallic content or metallic objects are attached to

the rear window

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Note for the entry function

● Even when the electronic key is within the effective range (detection

areas), the system may not operate properly in the following cases:

• The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is on the instrument panel, luggage cover, floor, or in the door pockets or glove box when the hybrid system is started or “POWER” switch modes are changed.

● Do not leave the electronic key on top of the instrument panel or near the

door pockets when exiting the vehicle. Depending on the radio wave reception conditions, it may be detected by the antenna outside the cabin and the door will become lockable from the outside, possibly trapping the electronic key inside the vehicle.

● As long as the electronic key is within the effective range, the doors may

be locked or unlocked by anyone.

● Even if the electronic key is not inside the vehicle, it may be possible to

start the hybrid system if the electronic key is near the window.

● The doors may unlock if a large amount of water splashes on the door

handle, such as in the rain or in a car wash when the electronic key is within the effective range. (The door will automatically be locked after approximately 60 seconds if the doors are not opened and closed.)

● If the wireless remote control is used to lock the doors when the elec-

tronic key is near the vehicle, there is a possibility that the door may not be unlocked by the entry function. (Use the wireless remote control to unlock the doors.)

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

■ Note for locking the doors

● T ouching the door lock sensor while wearing gloves may delay or prevent

lock operation. Remove the gloves and touch the lock sensor again.

● When the lock operation is performed using the lock sensor, recognition

signals will be shown up to two consecutive times. After this, no recognition signals will be given.

● If the door handle becomes wet while the electronic key is within the

effective range, the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more separate from the vehicle while the vehicle is being washed. (Take care to ensure that the key is not stolen.)

● If the electronic key is inside the vehicle and a door handle becomes wet

during a car wash, a buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors.

● The lock sensor may not work properly if it comes into contact with ice,

snow, mud, etc. Clean the lock sensor and attempt to operate it again, or use the lock sensor on the lower part of the door handle.

● Fingernails may scrape against the door during operation of the door

handle. Be careful not to injure fingernails or damage the surface of the door.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Note for the unlocking function

● A sudden approach to the effective range or door handle may prevent the

doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.

● Gripping the door handle when wearing a glove may not unlock the door.

Remove the gloves and touch the sensor on the back of the door handle again.

● If the door handle becomes wet while the electronic key is within the

● If there is another electronic key in the detection area, it may take slightly

longer to unlock the doors after the door handle is gripped.

● Fingernails may scrape against the door during operation of the door

handle. Be careful not to injure fingernails or damage the surface of the door.

■ When the vehicle is not driven for extended periods

● To prevent theft of the vehicle, do not leave the electronic key within 6 ft.

(2 m) of the vehicle.

● The smart key system can be deactivated in advance. (P. 596)

■ To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle.

Depending on the position and holding condition of the electronic key, the key may not be detected correctly and the system may not operate properly. (The door lock prevention may not operate.)

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

■ If the smart key system does not operate properly

● Locking and unlocking the doors: Use the mechanical key. (P. 548)

● Starting the hybrid system: P. 549

■ Electronic key battery depletion

● The standard battery life is 1 to 2 years.

● If the battery becomes low, an alarm will sound in the cabin when the

hybrid system stops. (P. 69)

● As the electronic key always receives radio waves, the battery will

become depleted even if the electronic key is not used. The following symptoms indicate that the electronic key battery may be depleted. Replace the battery when necessary. (P. 460)

• The smart key system or the wireless remote control does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

● To avoid serious deterioration, do not leave the electronic key within 3 ft.

(1 m) of the following electrical appliances that produce a magnetic field:

•TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Induction cookers

• Table lamps

■ When the electronic key battery is fully depleted

P. 460

■ Customization

Settings (e.g. smart key system) can be changed. (Customizable features P. 596)

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Certification for the smart key system

For vehicles sold in the U.S.A.

FCC ID: NI4TMLF8-2 FCC ID: HYQ14ACX FCC ID: HYQ14ADF FCC ID: HYQ13CZD FCC ID: HYQ13CZE

NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

For vehicles sold in Canada

NOTE: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

CAUTION

■ Caution regarding interference with electronic devices

● People with implantable cardiac pacemakers, cardiac resynchronization

therapy-pacemakers or implantable cardioverter defibrillators should keep away from the smart key system antennas. (P. 66) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves. Then, consult your doctor to see if you should disable the entry function.

● Users of any electrical medical device other than implantable cardiac

pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators should consult the manufacturer of the device for information about its operation under the influence of radio waves. Radio waves could have unexpected effects on the operation of such

medical devices. Ask your Toyota dealer for details on disabling the entry function. On vehicles with the Display Audio system or the navigation system, the

entry function can be disabled personally. (P. 596)

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Starting and stopping the hybrid system can be performed simply by

carrying the electronic key on your person, for example in your

pocket.

(The driver should always carry the electronic key.)

Smart key system (without entry function)

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Antenna location and effective range

■ Antenna location

Antennas inside cabin

■ Effective range (areas within which the electronic key is

detected)

When starting the hybrid system or changing “POWER” switch modes

The system can be operated when the electronic key is inside the vehicle.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Conditions affecting operation

P. 74

■ Electronic key battery depletion

P. 78

■ To operate the system properly

Make sure to carry the electronic key when operating the system. Depending on the position and holding condition of the electronic key, the

key may not be detected correctly and the system may not operate properly. (The door lock prevention may not operate.)

■ Note for the smart key system

● Even when the electronic key is within the effective range (detection

areas), the system may not operate properly. For example, the electronic key is on the instrument panel, luggage cover, floor or in the door pockets or glove box when the hybrid system is started or “POWER” switch modes are changed.

● Even if the electronic key is not inside the vehicle, it may be possible to

start the hybrid system if the electronic key is near the window.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Alarm Situation Correction procedure

Exterior alarm sounds once for 5 seconds

An attempt was made to lock the vehicle while a door is open

Close all of the doors and lock the doors again

Interior alarm pings continuously

The “POWER” switch was turned to ACCESSORY mode while the driver’s door was open (or the driver’s door was opened while the “POWER” switch was in ACCESSORY mode)

Turn the “POWER” switch off and close the driver’s door

Interior alarm sounds continuously

When the “POWER” switch is in ON mode or ACCESSORY mode, an attempt was made to open the door and exit the vehicle, and the shift position was not in P

Shift the shift position to P and turn the “POWER” switch off

Interior and exterior alarms sound continuously

When the “POWER” switch is in ON mode or ACCESSORY mode, the driver’s door was closed after the key was carried outside the vehicle, and the shift position not in P

Shift the shift position to P, turn the “POWER” switch off and close the driver’s door again

■ Alarms and warning indicators

A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures in response to any warning message shown on the multi-information display. (P. 524)

The following table describes circumstances and correction procedures when only alarms are sounded.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

Alarm Situation Correction procedure

Interior alarm pings once

The electronic key has a low battery

Replace the electronic key battery

An attempt was made to start the hybrid system without the electronic key being present, or the electronic key was not functioning normally

Start the hybrid system with the electronic key present

Interior alarm pings once and exterior alarm sounds 3 times

The driver’s door was closed after the key was carried outside the vehicle, and the “POWER” switch was not turned OFF

Turn the “POWER” switch off and close the driver’s door again

An occupant carried the electronic key outside the vehicle and closed the door while the “POWER” switch was not OFF

Bring the electronic key back into the vehicle

Before driving

: A message will be shown on the multi-information display in the instru-

ment cluster.

: If the hybrid sy stem does not start when the electronic key is inside the

vehicle, the electronic key battery may be depleted or there may be difficulties receiving signal from the key. (P. 548)

■ If the electronic key does not operate properly

P. 548

■ When the electronic key battery is fully depleted

P. 460

PRIUS_OM_OM47857U_DVD_(U)

■ Customization

Settings (e.g. smart key system) can be changed. (Customizable features P. 596)

1-3. Opening, closing and locking the doors

CAUTION

■ Certification for the smart key system

P. 79

■ Caution regarding interference with electronic devices

P. 80

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

The wireless remote control can be used to lock and unlock the vehi-

cle.

Locks all the doors

Check to see that all the side doors and back door are securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.

Operates Remote Air Conditioning System

(P. 346) Sounds the alarm

(press and hold) (P. 88)

*: If equipped

Wireless remote control

Before driving

■ Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice)

■ Door lock buzzer (vehicles with entry function)

If an attempt to lock the doors is made when a door is not fully closed, a buzzer sounds continuously for 5 seconds. Fully close the door to stop the buzzer, and lock the vehicle once more.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

When is pressed for longer than about one second, an alarm will sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.

To stop the alarm, press any button on the electronic key.

■ Panic mode

■ Security feature

P. 72

■ Conditions affecting operation

P. 74

■ If the wireless remote control does not operate properly

Locking and unlocking the doors: Use the mechanical key. (P. 548)

■ Electronic key battery depletion

P. 78

■ When the electronic key battery is fully depleted

P. 460

■ Customization

Settings (e.g. door unlocking function) can be changed. (Customizable features P. 596)

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

The vehicle can be locked and unlocked using the entry function,

wireless remote control or door lock switch.

■ Entry function (if equipped)

P. 63

■ Wireless remote control

P. 87

■ Door lock switch

Locks all the doors Unlocks all the doors

■ Inside lock buttons

Locks the door Unlocks the door

The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.

Side doors

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

Locking the front doors from the outside without a key

STEP

Move the inside lock button to the lock position.

STEP

Close the door.

The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle.

The key may not be detected correctly and the door may be locked.

Rear door child-protector lock

The door cannot be opened from inside the vehicle when the lock is set.

Unlock Lock

These locks can be set to prevent children from opening the rear doors. Push down on each rear door switch to lock both rear doors.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

Automatic door locking and unlocking systems

The following functions can be set or canceled:

Function Operation

Shift position linked door locking function

Shift position linked door unlocking function

Speed linked door locking function

Driver’s door linked door unlocking function

Shifting the shift position out of P locks all doors.

Shifting the shift position to P unlocks all doors.

All doors are locked when the vehicle speed is approximately 12 mph (20 km/h) or higher.

All doors are unlocked when the driver’s door is opened within 10 seconds after turning the “POWER” switch off.

■ Setting and canceling the functions

To switch between setting and canceling, follow the procedure below:

STEP

Close all the doors and switch the “POWER” switch to ON

STEP

mode. (Perform within 20 seconds.)

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

STEP

Shift the shift position to P or N, and press and hold the door lock switch (

or ) for about 5

seconds then release.

The shift position corresponding to the desired function to be set are shown as follows.

Use the same procedure to cancel the function.

Function Shift position

Shift position linked door locking function

Shift position linked door unlocking function

Speed linked door lo cking function

Driver’s door linked door unlocking function

Door lock switch

position

When the setting or canceling operation is complete, all doors are locked and then unlocked.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

■ Using the mechanical key

The doors can also be locked and unlocked with the mechanical key. (P. 548)

■ If a wrong key is used

The key cylinder rotates freely to isolate inside mechanism.

■ Customization

Settings (e.g. unlocking function using a key) can be changed. (Customizable features P. 596)

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

CAUTION

■ To prevent an accident

Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury.

● Always use a seat belt.

● Always lock all the doors.

● Ensure that all doors are properly closed.

● Do not pull the inside handle of the doors while driving.

The doors may be opened and the passengers are thrown out of the vehi-

cle and it may result in serious injury or death.

Be especially careful for the front doors, as the doors may be opened even

if the inside lock buttons are in locked position.

● Set the rear door child-protector locks when children are seated in the rear

seats.

■ When opening or closing a door

Check the surroundings of the vehicle such as whether the vehicle is on an incline, whether there is enough space for a door to open and whether a strong wind is blowing. When opening or closing the door , hold the door handle tightly to prepare for any unpredictable movement.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

The back door can be locked/unlocked and opened by the following

procedures.

■ Locking and unlocking the back door

Entry function

P. 63

Wireless remote control

P. 87

Door lock switch

P. 89

■ Opening the back door from outside the vehicle

Raise the back door while pushing up the back door opener switch.

Back door

Before driving

When closing the back door

PRIUS_OM_OM47857U_DVD_(U)

Lower the back door using the back door handle, and make sure to push the back door down from the outside to close it.

Be careful not to pull the back door sideways when closing the back door with the handle.

1-3. Opening, closing and locking the doors

On Off

STEP

Remove the cover. (vehicles with center auxiliary box type B only)

Move the lever.

STEP

■ Luggage compartment light

The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on.

■ If the back door opener is inoperative

The back door can be unlocked from the inside.

Open the center deck board. (P. 379)

STEP

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

CAUTION

■ Caution while driving

● Keep the back door closed while driving.

If the back door is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a serious health hazard. Make sure to close the back door before driving.

● Before driving the vehicle, make sure that the back door is fully closed. If

the back door is not fully closed, it may open unexpectedly while driving, causing an accident.

● Never let anyone sit in the luggage compartment. In the event of sudden

braking, sudden swerving or a collision, they are susceptible to death or serious injury.

■ When children are in the vehicle

Observe the following precautions. Failure to do so may result in death or serious injury.

● Do not allow children to play in the luggage compartment.

If a child is accidentally locked in the luggage compartment, they could have heat exhaustion or other injuries.

● Do not allow a child to open or close the back door.

Doing so may cause the back door to move unexpectedly, or cause the child’s hands, head, or neck to be caught by the closing back door.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

CAUTION

● The back door may suddenly shut if it is

not opened fully. It is more difficult to open or close the back door on an incline than on a level surface, so beware of the back door unexpectedly opening or closing by itself. Make sure that the back door is fully open and secure before using the luggage compartment.

■ Operating the back door

Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury.

● Remove any heavy loads, such as snow and ice, from the back door

before opening it. Failure to do so may cause the back door to suddenly

shut again after it is opened.

● When opening or closing the back door, thoroughly check to make sure

the surrounding area is safe.

● If anyone is in the vicinity, make sure they are safe and let them know that

the back door is about to open or close.

● Use caution when opening or closing the back door in windy weather as it

may move abruptly in strong wind.

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking th e do o r s

CAUTION

● When closing the back door, take extra

care to prevent your fingers etc. from being caught.

● When closing the back door, make sure

to press it lightly on its outer surface. If the back door handle is used to fully close the back door, it may result in hands or arms being caught.

● Do not pull on the back door damper stay to close the back door, and do

not hang on the back door damper stay. Doing so may cause hands to be caught or the back door damper stay to break, causing an accident.

● If a bicycle carrier or similar heavy object is attached to the back door, it

may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended.

Before driving

PRIUS_OM_OM47857U_DVD_(U)

1-3. Opening, closing and locking the doors

NOTICE

● Do not attach any foreign objects, such

as stickers, plastic sheets, or adhesives to the damper stay rod.

● Do not touch the damper stay rod with

gloves or other fabric items.

● Do not attach any accessories other

than genuine Toyota parts to the back door.

● Do not place your hand on the damper

stay or apply lateral forces to it.

Damper stays

■ Back door damper stays

The back door is equipped with damper stays that hold the back door in place.

Observe the following precautions. Failure to do so may cause damage to the back door damper stay, resulting in malfunction.

100

PRIUS_OM_OM47857U_DVD_(U)

Toyota Priustwo 2014 Owner's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1-1. Hybrid system

1-2. Key information

1-3. Opening, closing and locking the doors
