Toyota PRIUS 2011 Reference Guide
PRIUS
2011
QUICK REFERENCE
GUIDE
2011
Prius
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental
operations so you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for
the Owner’s Manual located in your vehicle’s glove box. We
strongly encourage you to review the Owner’s Manual and
supplementary manuals so you will have a better understanding
of your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota Motor Sales,
U.S.A., Inc. wish you many years of satisfied driving in your
new Prius.
A word about safe vehicle operations
!
This Quick Reference Guide is not a full description of Prius
operations. Every Prius owner should review the Owner’s
Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in
color throughout the Owner’s Manual. Each box contains safe
operating instructions to help you avoid injury or equipment
malfunction.
All information in this Quick Reference Guide is current at
the time of printing. Toyota reserves the right to make
changes at any time without notice.
INDEX
OVERVIEW
FEATURES/OPERATIONS
Engine maintenance 9
Fuel tank door release and cap 8
Hood release 8
Indicator symbols 4-5
OVERVIEW
Instrument cluster 4
Instrument panel 2-3
Keyless entry
Light control-Instrument panel 9
Smart Key system
1
1,2
6
7
Air Conditioning/Heating 16
Audio 18-19
Auto lock/unlock functions
1
10
Clock 23
Cruise control 20
Dynamic Radar Cruise Control 20-21
EV-Drive Mode 12
Garage door opener (HomeLink®)
3
23
Hill-start Assist Control (HAC) 23
Hybrid Synergy Drive System 10
Lights1& turn signals 15
LKA (Lane Keep Assist) 21
Moonroof 17
Multi-information display
2
22
FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Parking brake 12
Power outlets 19
Seat adjustments-Front 13
Seat heaters 16
Seat-Folding down rear seat 13
Seats-Head restraints 13
Solar ventilation system 17
Steering wheel switches 19
Telephone controls (Bluetooth®)22
Tilt and telescopic steering wheel 12
Transmission 11
Windows-Power 14
Windshield wipers & washers 14
SAFETY AND
EMERGENCY FEATURES
Doors-Child safety locks 25
Door locks 25
Seat belts 24
Seat belts-Shoulder belt anchor 24
Spare tire & tools 25
Tire Pressure Monitoring (warning) System 24
1
Visit your Toyota dealer for information on customizing this feature.
2
Programmable by customer. Refer to the Owner’s Manual for instructions and
more information.
3
HomeLink®is a registered trademark of Johnson Controls, Inc.
1
OVERVIEW
Instrument panel
Steering wheel controls
Steering wheel audio controls
Voice command button
1,2
“TRIP” button
Multi-information display button
Steering wheel climate controls
Cruise control
“LKA” switch
Distance switch
Telephone controls
1
1
1
1,2
Headlight and turn signal controls/Headlight, turn signal and front fog
light controls
1
Wiper and washer controls
Mph or km/h button
Advanced Parking Guide System/Intelligent Parking Assist pre-support
1,2
switch
Power button
Multi-information display
Audio system or navigation system-integrated audio system
1,2
2
Air Conditioning system
OVERVIEW
FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Air Conditioning controls
Outside rearview mirror
“EV” switch
1
1
/Rear window defogger button
“ECO MODE” switch
“PWR MODE” switch
Emergency flasher button
Shift lever
“P” position switch
Tilt and telescopic steering lock release lever
Fuel filler door opener
Power rearview mirror control
Headlight cleaner switch
Solar ventilation switch
1
1
Instrument panel light control
1
If equipped
2
For vehicles with a navigation system, refer to the “Navigation System
Owner’s Manual.”
3
OVERVIEW
Instrument cluster
Service indicators and reminders
Fuel gauge
Transmission shift position indicator
Multi-information display
Instantaneous fuel consumption
Speedometer
Indicator symbols
For details, refer to “Indicators and warning lights,” Section 2-2, 2011
Owner’s Manual.
Brake system warning
1
Brake system warning light (yellow indicator)
1
Driver seat belt reminder
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
Charging system warning
1
Front passenger occupant classification or front
passenger airbag ON/OFF indicator
Malfunction/Check Engine indicator
1
Low fuel level warning
Open door warning
Airbag SRS warning
1
If indicator does not turn off within a few seconds of starting hybrid system, there
may be a malfunction. Have vehicle inspected by your Toyota dealer.
1
4
Master warning
Low Tire Pressure Warning
Electric power steering system warning
1
1
1
Theft deterrent/Engine immobilizer system indicator
Headlight low/high beam indicator
Turn signal indicator
READY indicator
EV Drive Mode indicator
Eco Mode indicator
Power Mode indicator
Front fog light indicator
Slip indicator/Hill-start Assist Control indicator
1
OVERVIEW
FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Cruise control indicator
2
Lane Keep Assist indicator
Anti-lock Brake System warning
Automatic headlight leveling system warning
Pre-Collision System warning light
High coolant temperature warning light
2
If this light flashes, refer to “Cruise control,” Section 2-4, 2011 Owner’s Manual.
1
1
1
1
5
OVERVIEW
Keyless entry
Locking operation
Push
Unlocking operation
Push ONCE: Driver door
TWICE: All doors
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will
relock for safety.
Remote Air Conditioning system operation (if equipped)
Will automatically shut off
after three minutes, or if a
door is opened.
Panic button
Push and hold
Push and hold
6
Smart Key system (if equipped)
Start function
Green indicator ON
OVERVIEW
Depress
brake pedal
Carrying
Push
Power (without starting Hybrid System)
Without depressing the brake pedal, pressing the “POWER” switch will
change the operation mode in succession from:
ACCESSORY
ON
OFF
Locking operation (if equipped)
Power ON; Hybrid System is not engaged.
All systems OFF.
Accessories such as the radio will operate.
Unlocking operation
(if equipped)
Carry remote to lock
All-door lock
Touch
Carry remote to unlock
Driver door unlock*
Grasp
Back door lock/unlock (if equipped)
FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Carry remote to
lock/unlock
Push
Unlock
Push
Lock
* Driver door unlocking function can be programmed to unlock driver door
only, or all doors. Grasping passenger door handle will unlock all doors.
NOTE: Doors may also be locked/unlocked using remote.
7
