i
TABLE OF CONTENTS
Safety Instructions iii
Introduction 1
Image Resolution 1
Compatibility 2
Unpacking the Projector 2
Usage Guidelines 4
If You Need Assistance 5
Setting up the Projector 7
Connecting a Computer 9
Connecting a Video Player 11
Powering up the Projector and Adjusting the Image 13
Turning Off the Projector 14
Using the Projector 15
Basic Image Adjustment 15
Using the Remote Control 15
Adjusting the Projector 17
Using the Keypad and Remote Buttons 18
Using the On-Screen Menus 20
Display Menu 21
Audio Menu 23
Image Menu 24
Controls Menu 27
Language Menu
29
Status Menu 30
Maintenance & Troubleshooting 33
Cleaning the Lens 33
Replacing the Projection Lamp 33
Replacing the Batteries in the Remote Control 36
Using the Security Lock 36
Troubleshooting 37
ii
T a b l e o f C o n t e n t s
Appendix 41
Specifications 41
Accessories 42
Portable and Laptop Activation Chart 43
Using Video Mirroring with a PowerBook Computer 48
Projected Image Size 49
Index 51
iii
SAFETY INSTRUCTIONS
Please read and follow all safety instructions provided BEFORE
using your new projector. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and
may damage or impair protection provided by equipment. Please
save all safety instructions.
Safety Definitions:
•
Warning:
Statements identify conditions or practices that
could result in personal injury.
•
Caution:
Statements identify conditions or practices that could
result in damage to your equipment.
Safety Symbols:
Attention:
For information about usage of a feature, please
refer to the User’s Guide.
Warning:
Hot surface. Do not touch.
An arrow pointing to the lamp door on the projector.
Safety Terms:
•
Warning:
Don’t look directly into the lens when the lamp is
turned on.
•
Warning:
To replace the lamp, turn the projector off by
unplugging the power cord. To avoid burns, wait 30
minutes before opening the lamp door. Follow all instructions
provided in this User’s Guide.
•
Warning:
Please use the power cord provided. Connect
the power cord to a receptacle with a protective safety
(earth) ground terminal.
•
Warning:
Refer all service to qualified service personnel. Servicing your own projector will void the warranty. See the following page for the customer service contact information.
•
Caution:
Don’t block ventilation openings.
iv
S a f e t y I n s t r u c t i o n s
•
Caution:
Don’t set liquids on the projector. Spilled liquids may
damage your projector.
•
Caution:
Don’t place the projector on a hot surface or in direct
sunlight.
•
Caution:
Do not drop the projector. Transport the projector in a
vendor-approved case; refer to your Toshiba dealer or
projectors.toshiba.com
for more information.
Important Operating Considerations
Do not place the projector on a tablecloth or other soft covering
that may block the vents. In the unlikely event of the bulb rupturing, thoroughly clean the area behind the projector and discard
any edible items placed in that area.
Customer Service
Please contact your Toshiba dealer for details.
Do not place objects in
this area behind the projector
2
f
t
(
.
6
m
)
1
INTRODUCTION
The Toshiba TDP-S2 and TDP-T1 multimedia projectors are specifically designed for multipurpose use. They generate crisp,
clear images using Digital Light Processing™ (DLP) technology,
and feature an M1-DA connector for easy, built-in digital/analog
and USB connectivity. They are easy to connect, easy to use, easy
to transport, and easy to maintain. The TDP-S2 has native SVGA
800x600 resolution, the TDP-T1 has XGA 1024x768 resolution.
The user interfaces of the two products are identical; information
in this user’s guide applies to both products.
NOTE: The TDP-S2 automatically
expands 640x480 images to
800x600. You can display these
images at their native resolutions
by turning off the Auto Resize fea-
ture. See “Resize” on page 24 for
more information.
Image Resolution
TDP-S2
The SVGA resolution of the TDP-S2’s projected image is 800x600.
The projector cannot compress screen resolutions above
1024x768. If your computer’s screen resolution is higher than
1024x768, reset it to a lower resolution before you connect the
projector
.
TDP-T1
The XGA resolution of the TDP-T1’s projected image is 1024x768.
The projector cannot compress screen resolutions above
1024x768. If your computer’s screen resolution is higher than
1024x768, reset it to a lower resolution before you connect the
projector
.
NOTE: The TDP-T1 automatically
expands 640x480 and 800x600
images to 1024x768. You can dis-
play these images at their native
resolutions by turning off the Auto
Resize feature. See “Resize” on
page 24 for more information.
2
I n t r o d u c t i o n
Compatibility
The projector is compatible with a wide variety of computers and
video devices, including:
•
IBM-compatible computers, including laptops, up to 1024x768
resolution.
•
Apple® Macintosh® and PowerBook® computers up to
1024x768 resolution.
NOTE: The projector is
compatible with 1080i and 720P
HDTV formats.
•
Most standard VCRs, DVD players, HDTV sources, camcorders and laser disc players.
Unpacking the Projector
The projector comes with the items shown in Figure 1. Check to
make sure all are included.
Contact your Toshiba dealer imme-
diately if anything is missing
.
If you are experienced in setting up presentation systems, use the
Quick Start
card that was included in the shipping box. For complete details on connecting and operating the projector, refer to
this User’s Guide.
3
FIGURE 1
Shipping box contents
1. TDP-S2 or TDP-T1 projector + lens cap
7. PR Lite computer cable
2. Soft carry case 8. Audio cable adapter
3. User’s Guide, Quick Start
card, and CD
9. Mac adapter
4. Power cord 10. Composite video cable
5. Remote control 11. Audio cable
6. M1-DA analog computer
cable
12. S-video cable
1
2
3
4
5
6
7
9
10
12
8
11
4
I n t r o d u c t i o n
F
IGURE 2
Side view of projector
Usage Guidelines
•
Do not look directly into the projection lens when the lamp is
turned on. The bright light may harm your eyes.
•
Do not block the grills on the projector. Restricting the air flow
can cause it to overheat and turn off. If this happens, you must
wait a minute before attempting to turn it back on.
•
Handle the projector as you would any product with glass
components. Be especially careful not to drop it.
•
Avoid leaving the projector in direct sunlight or extreme cold
for extended periods of time. If this happens, allow it to reach
room temperature before use.
•
Transport the projector in a vendor-approved hard or soft case;
refer to your Toshiba dealer or
projectors.toshiba.com
for more
information.
connector panel
speaker
focus ring
zoom ring
power
cord
connector
keypad
Security
power
button
lock
5
If You Need Assistance
The first place to look for help is in this manual. Be sure to check
the guidelines in “Troubleshooting” on page 37.
Please contact your Toshiba dealer for details.
6
I n t r o d u c t i o n
7
SETTING UP THE PROJECTOR
1
Place the projector on a flat surface.
•
The projector must be within 10 feet (3 m) of your power
source and within 6 feet (1.8 m) of your computer.
•
If you want to project from behind a translucent screen, set
up the projector behind your screen. See “Rear Projection”
on page 28 to reverse the image.
•
If you are installing the projector on the ceiling, refer to the
installation guide that comes with the Ceiling Mount Kit for
more information. To turn the image upside down, see
“Ceiling Projection” on page 27. The Ceiling Mount Kit is
sold separately, contact your Toshiba dealer to order.
2
Position the projector the desired distance from the screen.
•
The distance from the lens of the projector to the screen and
the zoom setting determine the size of the projected image.
Figure 3 shows three projected image sizes. For more information about image size, see “Projected Image Size” on
page 49.
F
IGURE
3
Projected image size at minimum zoom
3
Make sure the projector and the computer are turned off.
2
.
5
f
t
.
1
0
f
t
.
6
f
t
.
5 ft
.
12 ft.
20 ft.
8
S e t t i n g u p t h e P r o j e c t o r
NOTE: Before you continue,
make sure the projector and all
other equipment is turned off. If
you’re connecting a computer,
make sure the distance between it
and the projector is 6 feet or less.
F
IGURE 4
Connector panel
F
IGURE 5
M1-DA analog computer cable
F
IGURE
6
PR Lite computer cable
in
in
S-video
composite
video
Audio in
data interface
M1-DA
data interface
PR Cable
to computer video
to projector
to computer
to USB mouse
to projector
to computer
9
Connecting a Computer
The projector ships with an M1-DA analog computer cable and a
PR Lite computer cable. If your computer has a digital output,
you can order the optional M1-DA digital computer cable. Contact your Toshiba dealer for ordering information.
1
Plug the end of the M1-DA analog computer cable
into the connector on the projector.
NOTE: Many laptop computers
do not automatically turn on their
external video port when a sec-
ondary display device such as a
projector is connected. Refer to
your computer manual for the
command that activates the exter-
nal video port. Activation com-
mands for some laptop computers
are listed in the Appendix of this
manual on page 43 or visit sup-
port.toshiba.com for more infor-
mation.
2
Plug the blue end of the M1-DA analog computer cable
into the video connector on your computer.
FIGURE 7
Connecting the projector to a computer
NOTE: If you are connecting an
older Macintosh computer that
does not have a 15-pin connector,
you must use a Mac adaptor
between the computer and the
projector. The supplied Mac
adapter will only work with the
1024x768 resolution. Please set
your Mac’s video card accordingly.
in
in
audio cable
M1-DA analog
USB
PR Lite
computer cable
computer cable
mouse
Computer 1
Computer 2
10
S e t t i n g u p t h e P r o j e c t o r
Do you want to control the computer’s mouse from the projector’s
remote or keypad?
NOTE: The USB mouse is
supported for use with
Windows 98, Windows 2000, and
Apple OS 8.5 and higher only.
1
Plug the end of the M1-DA analog computer cable
into the USB mouse connector on your computer. If your computer has a PS/2 mouse connector and not a USB mouse connector, you can purchase the optional PR Cable3 which has a
PS/2 mouse connector or the Executive Remote IR Receiver.
Contact your Toshiba dealer to order.
Do you want to play your computer’s audio on the projector?
1
Plug either end of the audio cable into the audio connector on
your computer. Only one PC audio input is available.
NOTE: You do not need to restart
your computer after connecting a
USB mouse to use it (it is hot-
pluggable).
2
Plug the other end of the audio cable into the connector
on the projector.
Now you’re ready to power up the projector and your laptop.
Skip to “Powering up the Projector and Adjusting the Image” on
page 13.
11
Connecting a Video Player
1
If your video player uses a round, one-prong composite video
connector, you’ll need only the audio cable, audio adapter,
and composite video cable that shipped with the projector.
NOTE: HDTV sources must be
connected to the projector using
the M1-DA computer cable (not a
composite or S-video cable).
•
If your video player uses a round, four-prong S-video connector, you’ll need the S-video cable in addition to the
audio cable and audio adapter.
2
Plug the composite video cable’s yellow connector into the
“video-out” connector on your video player (Figure 8). This
connector may be labeled “To Monitor.”
•
If you’re using an S-video cable, connect it to the “S-video
out” connector on the video player (Figure 9).
3
Plug the other yellow connector into the composite video connector
on the projector.
•
If you’re using S-video, plug the other end of the cable into
the “S-video” connector
on the projector (Figure 9).
F
IGURE
8
Connecting the projector to a video player using the standard video cable (with com-
posite video connector) and the audio cable and adapter
in
in
composite video
audio cable
audio
adapter
cable
12
S e t t i n g u p t h e P r o j e c t o r
F
IGURE 9
Connecting the projector to a video player using an S-video cable and the audio cable
and adapter
NOTE: The audio adapter is
provided so that the same audio
cable used to connect a computer
can be used with the adapter to
connect a VCR.
4
Plug the audio adapter’s white connector into the left “audio
out” connector on your video player. Plug the adapter’s red
connector into the right “audio out” connector on the video
player (Figure 8 and Figure 9).
5
Plug the audio adapter’s other end into the audio cable.
6
Plug the audio cable into the “audio in” connector on the
projector.
CAUTION: Your video player
may also have a “Video Out”
connector for a coaxial cable
connection. DO NOT use this to
connect to the projector.
The projector is compatible with these major broadcast video
standards: NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, and
SECAM. It automatically adjusts to optimize its performance for
the incoming video.
in
in
audio cable
S-video
audio
adapter
cable
13
Powering up the Projector and Adjusting the Image
NOTE: Always use the power cord
that shipped with the projector.
1
Remove the lens cap.
2
Plug the power cord into the side of the projector, then plug it
into your electrical outlet. A surge-protected power strip is
recommended.
3
Press the Power button on the side of the projector.
NOTE: The first time you connect
your computer to the projector, the
computer may display a message
stating that new hardware was
found. The Add New Hardware
Wizard may appear. Use the Wiz-
ard to load the correct driver (the
computer considers the projector a
Plug and Play Monitor).
•
The fans start to run, the LED on the top of the projector
(Figure 13 on page 18) lights green, and the startup screen
appears. It takes about one minute for the image to achieve
full brightness.
4
If you connected a video player, turn it on.
•
The video image should display on the projection screen. If
a computer source is active, press the
source
button on the
keypad (page 18) or the
video
button on the remote to display your video image. You can select a default source to
determine which source the projector examines first during
power-up for active video; see “Default Source” on page 28.
•
Use the
volume
buttons to adjust the volume.
5
Turn on your computer.
NOTE: With some computers,
the order in which you power up
the equipment is very important.
Most computers should be turned
on last, after all other peripherals
have been turned on. Refer to your
computer’s documentation to
determine the correct order.
•
The computer image should display on the projection
screen. If a video source is active, press the
source
button on
the keypad or the
computer
button on the remote to display
your computer’s image. Make sure your laptop’s external
video port is activated; see “Portable and Laptop Activation
Chart” on page 43 for details.
•
If necessary, make adjustments to the image using the projector’s on-screen menus. To open the menus, press the
menu
button on the keypad or remote, then select the Display or Image menu. For more information about the
menus, see page 20.
14
S e t t i n g u p t h e P r o j e c t o r
Turning Off the Projector
If you want to turn off the projector for a short period of time,
press the
standby
button on the keypad or remote. This blanks the
screen for fifteen minutes, but keeps the projector running. (You
can change the amount of time the projector stays in standby
mode; see “Standby Time” on page 27 for details.) After 15 minutes, the lamp goes out (the projector keeps running). To exit
standby mode, press the
standby
button again. (It may take several seconds for the projection lamp to reach full power and
project the image again.)
NOTE: To maximize lamp life,
allow the projector to run for at
least five minutes before turning
it off.
To completely power off the projector, press the Power button. If
you want to turn the lamp back on immediately, you must allow
about a minute for the lamp to cool. The lamp won’t light if it’s
too hot.
15
USING THE PROJECTOR
This section describes how to use and make adjustments to the
projector. It also provides a reference to the keypad and remote
buttons and the options available from the on-screen menus.
Basic Image Adjustment
1
Make sure you have powered up your equipment in the right
order (page 13).
2
If the image doesn’t display completely, zoom the image
(page 17), adjust the height of the projector (page 17) or center
the image by adjusting its horizontal or vertical position
(page 26). Be sure the projector is at a 90 degree angle to the
screen.
3
If the image is out of focus, rotate the focus lens (page 17).
4
If the image appears to shimmer or if it has blurry vertical
bars after you have adjusted the focus, turn Auto Image
(page 24) off and then back on to reset the automatic sync and
tracking. If that doesn’t clear up the image, turn Auto Image
off and adjust the sync (page 25) and/or the tracking
(page 25) manually.
5
If the colors don’t look right, adjust the brightness (page 21).
Using the Remote Control
To control the computer’s mouse from the projector’s remote or
keypad, you must connect the USB mouse connector on the computer cable to the computer. See page 10 for details.
The projector ships with a remote that has four function buttons,
a disk mouse and two mouse buttons, one on the top of the
remote and one on the bottom.
Point the remote control at the projection screen or at the front of
the projector (not at the computer). The range for optimum operation is about 25 feet. If you point the remote at the projection
screen, the distance to the screen and back to the projector must
be less than or equal to 25 feet. For best results, point the remote
directly at the projector.
16
U s i n g t h e P r o j e c t o r
F
IGURE 10
Remote control
NOTE: If the remote is inactive
for several minutes, it “sleeps” to
conserve battery life. Press any
button except the disk mouse to
re-activate the remote.
Press anywhere on the edge of the disk mouse to move the cursor
on the screen. You can move the cursor at any angle by pressing
the corresponding edge of the disk. The mouse button on the top
of the remote simulates your computer’s right mouse button; the
button on the bottom simulates your computer’s left mouse button. See “Using the Keypad and Remote Buttons” starting on
page 18 for a description of the four function buttons.
If you are creating presentations in Microsoft
®
PowerPoint®, you
can use the remote’s mouse buttons to navigate through your
presentation while in Slide Show mode. To configure PowerPoint
for this, choose Options from the Tools menu, click the View Tab,
de-select the “Popup Menu on Right Mouse Click” option in the
Slide Show section, then click OK. Then, when you’re in PowerPoint’s Slide Show mode, a left click advances to the next slide
and a right click returns to the previous slide (other PowerPoint
modes are not affected).
disk mouse
right mouse button
left mouse button
(on underside of remote)
17
Adjusting the Projector
To focus the image, rotate the focus ring (Figure 11) until the
image is clear. To zoom the image, rotate the zoom ring. This
adjusts the image size without affecting focus.
FIGURE 11
Focus ring and zoom ring
The projector is equipped with a self-locking, quick-release elevator foot and button and a leveling knob (Figure 12).
To raise the projector:
1
Press and hold the elevator button (Figure 12).
2
Raise the projector to the height you want, then release the
button to lock the elevator foot into position. If necessary, turn
the leveling knob at the rear of the projector to adjust the
angle of the projected image.
FIGURE 12
Adjusting the height of the projector
focus ring
zoom ring
elevator button
elevator foot
(under finger)
leveling
knob
18
U s i n g t h e P r o j e c t o r
Using the Keypad and Remote Buttons
While the menus are displayed, the volume, source, and standby
buttons on the keypad act as menu navigation buttons. See
“Using the On-Screen Menus” on page 20 for details.
FIGURE 13
Keypad and remote buttons
Menu
Press the
menu
button to open the on-screen menus. Press
menu
again to close the menus. When you close the menus, the projector saves any changes you made. For more information about the
on-screen menus, see page 20.
Mouse buttons
Use the mouse buttons to adjust settings in the menus. See
“Using the On-Screen Menus” on page 20.
Source (keypad only) or Computer and Video (remote only)
When you have more than one source (computer and video) connected to the projector, select between them by pressing the
source
button on the keypad or the
computer
or
video
button on
the remote.
source
volume -
volume +
standby
menu
right mouse
button
left mouse
button
LED
19
Standby
When you press
standby
, the display and audio turn off and a
blank screen is displayed for 15 minutes. You can change the
amount of time the projector stays in standby mode; see
“Standby Time” on page 27 for details. The LED lights orange
while the projector is in standby.
•
If you press
standby
again within 15 minutes, the projector
returns to normal operations immediately. The LED changes
from orange to green.
•
If you press
standby
again after 15 minutes, there is about a
60 second delay before the lamp turns back on. The LED
flashes green while the lamp is re-lighting.
•
If you don’t press
standby
again, the lamp turns off after 15
minutes. The LED lights orange while the projector is in
standby.
Volume (keypad only)
To increase the volume, press
volume + .
To decrease the vol-
ume, press
volume - .
Volume adjustments are saved for each source you have connected.
20
U s i n g t h e P r o j e c t o r
Using the On-Screen Menus
The projector
has six drop-down menus that allow you to make
image adjustments and change a variety of settings. Most of these
adjustments aren’t available directly from the keypad.
NOTE: Some menu items may be
grayed out (dimmed) at certain
times. This indicates the item is
not applicable to your setup (for
example, video standards do not
apply to computer sources) or the
item is not enabled until another
selection is made (for example,
Manual Tracking is not available
until Auto Image is turned off).
To open the on-screen menus, press the
menu
button on the
keypad or remote. This changes the volume, source, and standby
buttons on the keypad to menu navigation buttons. Press the
corresponding buttons to move the cursor up, down, left, or
right, or use the disk mouse on the remote. To select a menu,
move the cursor left or right to highlight the menu you want. The
drop-down menu appears.
FIGURE 14
Keypad navigation buttons and drop-down menu
To change a menu setting, use the up and down navigation buttons on the keypad or the disk mouse on the remote to move the
cursor up and down to the item you want to change (the selected
item is highlighted), then use the left and right mouse buttons to
adjust a setting. Some submenus, such as Brightness, consist of a
slider bar you use to increase or decrease a value; some submenus, such as Standby Time, consist of options you scroll
through to select the desired one. All changes are saved when
you close the menus.
To access another menu, use the left and right navigation buttons
to move to the desired menu.
source
volume -
volume +
standby
menu
use these four buttons to navigate
Disp l ay Audio Image Cont rols Language Status
>
>
Brightness
Contrast
Tint
Color
Sharpness
Blan k scre e n blue
Reset all
through the menus
21
Display Menu
FIGURE 15
Display menu
Brightness
Adjusting the brightness changes the intensity of the image.
•
Press the left mouse button to darken the image.
•
Press the right mouse button to lighten the image.
Contrast
The contrast controls the degree of difference between the lightest
and darkest parts of the picture. Adjusting the contrast changes
the amount of black and white in the image.
•
Press the left mouse button to decrease the contrast.
•
Press the right mouse button to increase the contrast, making
the blacks appear blacker and the whites appear whiter.
Tint
The tint adjusts the red-green color balance in the projected
image.
•
Press the left mouse button to increase the amount of green in
the image.
•
Press the right mouse button to increase the amount of red in
the image.
Dis play Audio Image Controls Language Sta tus
>
>
Brightness
Contrast
Tint
Color
Sharpness
Bla nk scr een blu e
Reset all
22
U s i n g t h e P r o j e c t o r
Color
The color setting adjusts a video image from black and white to
fully saturated color.
•
Press the left mouse button to decrease the amount of color in
the image.
•
Press the right mouse button to increase the amount of color in
the image.
Sharpness
This setting adjusts the sharpness of a video image.
•
Press the left mouse button to decrease the sharpness.
•
Press the right mouse button to increase the sharpness.
Blank Screen
Blank Screen determines what color is displayed when there is no
active source and when the projector is in standby. Click the left
or right mouse button to toggle between blue and black.
Reset All
Click the left or right mouse button to reset all the options (except
Language, Video Standard, Rear and Ceiling Projection, Plug and
Play, and Standby Time) in all the menus to their original settings.
23
Audio Menu
FIGURE 16
Audio menu
Volume
NOTE: Changing the volume
using the menu is the same as
changing it using the keypad.
•
Press the left mouse button to decrease the volume.
•
Press the right mouse button to increase the volume.
Volume adjustments you make are saved for each source.
Treble
The treble setting controls the high frequencies of your audio
source.
•
Press the left mouse button to decrease the treble.
•
Press the right mouse button to increase the treble.
Treble adjustments you make are saved for each source.
Bass
The bass setting controls the low frequencies of your audio
source.
•
Press the left mouse button to decrease the bass.
•
Press the right mouse button to increase the bass.
Bass adjustments you make are saved for each source.
Display Audio Image Controls Language Status
>
>
Volume
Treble
Bass
24
U s i n g t h e P r o j e c t o r
Image Menu
FIGURE 17
Image menu
Keystone
This option helps to keep the image square as the angle of projection is changed. To adjust the keystone, highlight Keystone, then
click the left or right mouse button. This option is available for
computer sources displaying their native resolutions only, SVGA
800x600 for the TDP-S2 and XGA 1024x768 for the TDP-T1.
NOTE: Some screen savers
interfere with the operation of
Auto Image. If you’re experiencing
problems, try turning your screen
saver off, then turning Auto Image
off and back on.
Overscan
This option crops all the edges of the image to remove noise generated on the edges by your source. This option is available for
video sources only.
Auto Image
The projector automatically adjusts tracking, signal synchronization and vertical and horizontal position for most analog computers (Auto Image does not apply to video sources or digital
computer sources). If you want to adjust these features manually,
you must turn off
Auto Image
first by highlighting Auto Image in
the Image menu and clicking the left or right mouse button to
select “off”.
NOTE: When you connect an
HDTV source, the projector
automatically displays the image in
16x9 format.
Resize
This option works differently for computer and video sources.
For computer sources,
Resize
automatically resizes the image by
scaling it up or down. It only affects computer images that are not
the projector’s native resolution. When
Resize
is on, the projector
makes the best fit of the image to the computer screen. If you turn
Resize
off (by highlighting it in the Image menu and clicking the
left or right mouse button to select “off”), the image may be either
cropped or too small for the screen.
Display Audio Image Controls Language Status
>
>
Keystone
Overscan
Auto image on
Resize on
on
Manual sync
Manual tracking
Horizontal position
Vertical posi tion
25
For video sources,
Resize
allows you to select from among four
different re-sizing options. The default is
Standard
, which resizes
the image from its original version to fit a standard 4x3 aspect
ratio screen.
Widescreen Letterbox
preserves the 16x9 aspect ratio
of the original theater version, but the image is placed in a 4x3
space, so black bars appear at the top and bottom of the image.
Enhanced Widescreen
also preserves the aspect ratio of the original theater version and is designed to be used with content that is
Enhanced for Widescreen TVs. This option yields more detail
than Widescreen Letterbox.
Native
reduces the Standard size to
match the height of Enhanced Widescreen.
Manual Sync
The projector adjusts signal synchronization automatically for
most computers. But if the projected computer image looks fuzzy
or streaked, try turning
Auto Image
off then back on again. If the
image still looks bad, try adjusting the signal synchronization
manually:
1
Turn Auto Image off.
2
Highlight Manual sync, then press the left or right mouse button repeatedly until the image is sharp and free of streaks.
Manual Tracking
The projector adjusts tracking automatically to match the video
signal from your computer. However, if the display shows evenly
spaced, fuzzy, vertical lines or if the projected image is too wide
or too narrow for the screen, try turning
Auto Image
off then back
on again. If the image is still bad, try adjusting the tracking manually:
NOTE: The Manual Sync,
Manual Tracking, Horiz. Posi-
tion and Vert. Position options
are available only for analog com-
puter sources. The projector sets
these options automatically for dig-
ital computer and video sources.
1
Turn Auto Image off.
2
Highlight Manual tracking, then press the left or right mouse
button repeatedly until the fuzzy vertical bars are gone.
26
U s i n g t h e P r o j e c t o r
Horizontal position
Follow these steps to manually adjust the horizontal position:
1
Turn Auto Image off.
2
Highlight Horizontal position, then press the left mouse button to move the image right or press the right mouse button to
move the image left.
Positioning adjustments are saved when you power off the projector.
Vertical position
Follow these steps to manually adjust the vertical position.
1
Turn Auto Image off.
2
Highlight Vertical position, then press the left mouse button to
move the image down or press the right mouse button to
move the image up.
Positioning adjustments are saved when you power off the projector.
27
Controls Menu
FIGURE 18
Controls menu
Video Standard
NOTE: If you already know the
video standard used in your geo-
graphical area, it’s often best to
manually select it.
When Video standard is set to Auto, the projector attempts to
pick the video standard (NTSC, NTSC 4.43, PAL, PAL-M, PAL-N,
PAL-60, or SECAM) automatically based on the input signal it
receives. (The video standard options may vary depending on
your region of the world.) If the projector is unable to detect the
correct standard, the colors might not look right or the image
might appear “torn.” If this happens, manually select a standard
by clicking the left or right mouse button and cycling through the
standards.
Standby Time
This option lets you select how long the lamp stays on and the
blank screen is displayed when the projector enters standby
mode before the projector turns off. Select among instant, 1, 5, 10,
15 and 30 minutes and 1 and 2 hours by clicking the left or right
mouse button and cycling through the options.
Ceiling Projection
When you turn
Ceiling Projection
on, the projector turns the
image upside down for ceiling-mounted projection. Highlight
Ceiling Projection, then click the left or right mouse button to
turn this feature on and off.
Display Audio Image Controls Language Status
>
>
Video standard
Standby time 1 m inute
Ceiling projection off
Rear projection off
Default source computer 1 analog
Auto source select off
Plug and Play off
Display messages on
Display startup screen on
28
U s i n g t h e P r o j e c t o r
Rear Projection
When you turn
Rear Projection
on, the projector reverses the
image so you can project from behind a translucent screen. Highlight Rear Projection, then click the left or right mouse button to
turn this feature on and off.
Default Source
Default Source toggles among Computer 1 analog, Computer 1
digital, Computer 2, and Video. This determines which source the
projector checks first for active video during power-up. Highlight
Default Source and click the left or right mouse button to toggle
among the options.
Auto Source Select
This setting toggles between On and Off. When this feature is Off,
the projector defaults to the source selected in Default Source. To
display another source, you must manually select one by pressing the
source
button on the keypad or the
computer
or
video
button on the remote. When this feature is On, the projector
automatically finds the active source, checking the default source
first. Highlight Auto Source Select and click the left or right
mouse button to turn this feature on and off.
Plug and Play
This setting toggles between On and Off. When it is On, most
new computers will automatically recognize the projector, then
set the monitor resolution and refresh rate accordingly. You need
to set the Plug and Play setting to Off for the projector to display
properly on some older computers. The Plug and Play setting
does not affect video images.
If the projector’s display constantly changes between the computer image and the message, “Perfecting the image”, you may
need to turn Plug and Play Off.
Display Messages
This setting toggles between On and Off. When this feature is On,
status messages such as “No signal detected” or “Standby
Active” appear in the lower-right corner of the screen. Click the
left or right mouse button to turn this feature off and not see status messages.
29
Display Startup Screen
This setting toggles between On and Off. When this feature is On,
the startup screen appears when the projector starts up and
remains until an active source is detected. Click the left or right
mouse button to turn this feature off and display a plain black or
blue screen instead of the startup screen.
Language Menu
FIGURE 19
Language menu
You can display the on-screen menus in English, French, German,
Spanish, Chinese or Japanese.
•
Move the cursor to the language you want, then click the left or
right mouse button. The menus redraw immediately.
English
Francais
Deutsch
Espanol
~
Display Audio Image Controls Language Status
>
>
30
U s i n g t h e P r o j e c t o r
Status Menu
This is a read-only window for informational purposes. To display the status window, select Show status from the menu, then
click the left or right mouse button. To remove the window, click
the left or right mouse button.
FIGURE 20
Status menu
Lamp hours used
Indicates how many hours the current lamp has been in use. The
counter starts at zero hours and counts each hour the lamp is in
use. After 2,000 hours of use, the message “Change Lamp” temporarily appears on the screen when the projector is turned on.
Change the lamp within the next 50 hours. After 2,050 hours, the
LED flashes orange and the lamp will not light. See “Replacing
the Projection Lamp” on page 33 for details.
Computer resolution
Shows your computer’s resolution setting. To change this, go to
your computer’s Control Panel and adjust the resolution in the
Display tab. See your computer’s user’s guide for details.
Horizontal refresh rate
The time period that one horizontal line is displayed.
Display Audio Image Controls Language Status
Show status
Lamp hours used
Computer resolution
Horizontal refresh rate
Vertical re fresh rat e
Mute status
Source
Software version
Startup screen version
Boot version
PR Cable version 1.0
0039
1024x768
60.03 KHz
75.04 Hz
off
computer 1 analog
1.0
1.0
1.0
>
31
Vertical refresh rate
The time period that one video frame is displayed.
Mute status
Indicates if the audio is muted.
Source
Indicates the active source, Computer 1 analog, Computer 1 digital, Computer 2, and Video.
Software version
Indicates the projector’s software version. This information is
useful when contacting Technical Support.
Startup screen version
Indicates the projector’s startup screen version. This information
is useful when contacting Technical Support.
Boot version
Indicates the projector’s boot software version. This information
is useful when contacting Technical Support.
PR Cable version
Indicates the PR Cable’s software version. This information is
useful when contacting Technical Support.
32
U s i n g t h e P r o j e c t o r
33
MAINTENANCE & TROUBLESHOOTING
This section describes how to:
•
clean the lens
•
replace the projection lamp
•
replace the batteries in the remote
•
use the security lock feature
•
troubleshoot the projector
Cleaning the Lens
Follow these steps to clean the projection lens:
1
Apply a non-abrasive camera lens cleaner to a soft, dry cloth.
•
Avoid using an excessive amount of cleaner, and don’t
apply the cleaner directly to the lens.
•
Abrasive cleaners, solvents or other harsh chemicals might
scratch the lens.
2
Lightly wipe the cleaning cloth over the lens in a circular
motion.
3
If you don’t intend to use the projector immediately, replace
the lens cap.
Replacing the Projection Lamp
WARNING: To avoid burns,
allow the projector to cool for at
least 30 minutes before you open
the lamp module door. Never
extract the lamp module while the
projector is operating.
The lamp hour counter in the Status menu counts the number of
hours the lamp has been in use. After 2,000 hours of use, the message “Change Lamp” temporarily appears on the screen when
the projector is turned on. Change the lamp within the next 50
hours. After 2,050 hours, the LED flashes orange and the lamp
will not light. You can order new lamp modules from your
Toshiba dealer. See “Accessories” on page 42 for information.
Follow these steps to replace the projection lamp:
1
Turn off the projector and unplug the power cord.
2
Wait 30 minutes to allow the projector to cool thoroughly.
34
M a i n t e n a n c e & T r o u b l e s h o o t i n g
3
Invert the projector on a soft flat surface, then insert a small
screwdriver or other flat object into the tabs on the lamp module door (Figure 21) and gently pry the door up.
WARNING: Be extremely careful
when removing the lamp module.
In the unlikely event that the bulb
ruptures, please contact your
Toshiba dealer, since small glass
fragments may be generated. The
lamp module is designed to
contain these fragments, but use
caution when removing the lamp
module.
F
IGURE 21
Removing the lamp door
CAUTION: Never operate the
projector with the lamp door open
or removed. This disrupts the air
flow and causes the projector to
overheat.
4
Pull the lamp door up and remove it.
5
Loosen the two non-removable screws on the outside of the
module (Figure 22).
FIGURE 22
Loosening the screws on the lamp module
35
6
Lift and grasp the pull tab and lift the module out (Figure 23).
Dispose of the lamp module in an environmentally proper
manner.
FIGURE 23
Removing the lamp module
WARNING: Do not drop the
lamp module or touch the glass
bulb! The glass may shatter and
cause injury.
7
Install the new lamp module, being sure to align the connectors properly.
8
Push the module in until it is flush with the bottom case of the
projector.
9
Tighten the screws on the outside of the module.
10
Replace the lamp door by inserting the hooks on the lamp
door into the slots on the projector and pressing the lamp door
into place. If the lamp door does not fit properly or bulges out,
remove the door and re-seat the lamp module.
11
Plug in the power cord and press the Power button to turn the
projector back on.
12
To reset the lamp hour counter in the Status window, press
and hold the
volume -
button, then press the
menu
button
(while still holding down the
volume -
button) for 5 seconds.
Verify that the counter was reset by pressing the
menu
button
and viewing the counter in the Status window.
pull tab
36
M a i n t e n a n c e & T r o u b l e s h o o t i n g
Replacing the Batteries in the Remote Control
The life of the batteries depends on how often and how long you
use the remote. Symptoms of low battery charge include erratic
responses when using the remote and a reduced range of operation.
Follow these steps to replace the batteries:
1
Turn the remote face down in your hand.
2
Slide the battery cover off the end of the remote.
3
Remove the old batteries and dispose of them in an environmentally proper manner.
4
Install two new AAA alkaline batteries. Make sure you install
each in the correct direction.
5
Slide the battery cover back on the remote.
Using the Security Lock
The projector has a security connector for use with a PC Guardian
Cable Lock System (Figure 24). Contact your Toshiba dealer for
ordering information. Refer to the information that came with the
lock for instructions on how to use it to secure the projector.
F
IGURE
24
Installing the security lock
37
Troubleshooting
Problem: The projector is not running
•
Make sure that the power cord is properly connected to a fully
functional AC electrical outlet. Make sure that the power cord
is also properly connected to the projector.
•
If the projector is plugged into a power strip, make sure the
power strip is turned on.
•
Make sure the projector is turned on.
Problem: Projector is running, but nothing appears on projection screen
•
Make sure you have removed the lens cap on the projection
lens at the front of the projector.
•
Make sure the lamp has not been in use for over 2,050 hours.
The lamp automatically shuts off at 2,050 hours and the LED
blinks orange. See “Replacing the Projection Lamp” on
page 33.
•
Check the projector’s lamp to ensure that it is securely con-
nected in the lamp module. Make sure the lamp door is
installed. See “Replacing the Projection Lamp” on page 33.
Problem: Only the start-up screen displays
•
Verify that the cables are connected correctly. See page 9
through page 10 for connection procedures.
•
Make sure that the cables do not have any bent pins.
•
Verify that the proper input source is connected. See “Source
(keypad only) or Computer and Video (remote only)” on
page 18.
•
You might need to turn everything off and power up the
equipment again in the proper order. Refer to your computer’s documentation to determine the correct order.
•
Make sure your laptop’s external video port is turned on. See
the “Portable and Laptop Activation Chart” on page 43 or
your computer’s manual for details.
38
M a i n t e n a n c e & T r o u b l e s h o o t i n g
•
Make sure your computer’s video board is installed and con-
figured correctly.
•
Make sure your computer has a compatible video board. The
projector isn’t CGA, EGA or SXGA compatible.
If you’re using Windows 98:
1
Open “My Computer” icon, the Control Panel folder and
then the Display icon.
2
Click the Settings tab.
3
Verify that the Desktop area is set to 1024x768 or less.
Problem: Color or text not being projected
•
You might need to adjust the brightness up or down until the
text is visible. Refer to “Brightness” on page 21 for more information.
Problem: The screen resolution is not right
•
Make sure the computer’s video card is set for a resolution of
no greater than 1024x768.
Problem: Image isn’t centered on the screen
•
Move the projector to reposition the image.
•
Reposition the image using the menu. Refer to “Horizontal
position” on page 26 and “Vertical position” on page 26.
•
Be sure the projector is at a 90 degree angle to the screen.
Problem: Image is too wide or narrow for screen
•
Adjust the zoom or projector placement.
•
Adjust the resolution of your video card if it’s greater than
1024x768.
Problem: Image is out of focus
•
Turn the projection lens to focus the image.
•
Make sure the projection screen is at least 5 feet (1.5 m) from
the projector.
•
Check the projection lens to see if it needs cleaning.
39
Problem: Image and menus are reversed left to right
•
Rear projection mode is probably turned on. Turn Rear Projec-
tion off in the Controls menu. The image should immediately
return to forward projection. See “Rear Projection” on
page 28.
Problem: the projector displays vertical lines, “bleeding” or
spots
•
Adjust the brightness. See “Brightness” on page 21.
•
Check the projection lens to see if it needs cleaning.
Problem: no sound
•
Adjust volume.
•
Verify audio/input connections.
•
Adjust audio source.
Problem: Image is “noisy” or streaked
Try these steps in this order.
1
Deactivate the screen saver on your computer.
2
Turn
Auto Image
off and then back on again. See “Auto
Image” on page 24.
3
Turn
Auto Image
off and adjust the synchronization and tracking manually to find an optimal setting. See “Manual Sync”
on page 25 and “Manual Tracking” on page 25.
•
The problem could be with your computer ’s video card. If
possible, connect a different computer.
Problem: Projected colors don’t match the computer or video
player’s colors
•
Just as there are differences in the displays of different moni-
tors, there are often differences between the computer image
and the projected image. Adjust the brightness, tint and/or
contrast from the Display menu. See “Brightness” on page 21,
“Tint” on page 21 and “Contrast” on page 21.
Problem: Lamp seems to be getting dimmer
•
The lamp begins to lose brightness when it has been in use for
a long time. Replace the lamp as described in “Replacing the
Projection Lamp” on page 33.
40
M a i n t e n a n c e & T r o u b l e s h o o t i n g
Problem: Lamp shuts off
•
A minor power surge may cause the lamp to shut off. Unplug
the projector, wait at least a minute, then plug it back in.
•
Make sure the vents are not blocked.
•
Make sure the lamp has not been in use for over 2,050 hours.
The lamp automatically shuts off at 2,050 hours. See “Replacing the Projection Lamp” on page 33.
The most current troubleshooting information (including webbased and other electronic technical support) is available at
Toshiba’s Service and Support website at
support.toshiba.com.
Before calling your Toshiba dealer for assistance, please have the
following information available:
•
the projector’s serial number
•
the resolution of your computer.
41
APPENDIX
Specifications
The projector must be operated and stored within the temperature and humidity ranges specified.
Temperature
Operating
50 to 104
°
F (10 to 40° C)
Non-operating
-4 to 158
°
F (-20 to 70° C)
Humidity
Operating and non-oper. 10% to 95% relative humidity, non-condensing
Dimensions
3.9 x 10.9 x 11.2 inches (9.9 x 27.7 x 28.6 cm)
Weight
6.7 lbs. (3 kg) unpacked
Altitude
Operating 0 to 10,000 feet (3,048 meters)
Non-operating 0 to 20,000 feet (6,096 meters)
Optics
Focus Range 4.9 - 16 feet (1.5-5 m)
Lamp
Type 270-watt SHP lamp
Input Power Requirements
100-120VAC 5A;50/60Hz
200-240VAC 3A; 50Hz
Audio Input
Input Impedance 10K ohm nominal, AC coupled
Maximum Input Voltage (L
IN
+ RIN)
PEAK
< 4.5 V for THD ≤ 0.3%
L
IN
or RIN < 2.0 Vrms for THD ≤ 0.3%
Sensitivity 100 mV at 1 KHz for 88 dB SPL at 1 meter
Connector Type 3.5 mm (1/8 inch) stereo phone mini
42
A p p e n d i x
Accessories
NOTE: Use only Toshiba-
approved accessories. Other
products have not been tested with
the projector.
Power Cords (one ships with projector, type depends on country)
Optional Accessories (contact your Toshiba dealer to order)
Standard Accessories
(ship with the projector)
Quick Start card
User’s Guide
Soft Case
Shipping Box
M1-DA Analog Computer Cable 6 ft (1.8 m)
PR Lite Computer Cable 6 ft (1.8 m)
Composite Video Cable 6 ft (1.8 m)
Computer Audio Cable 6 ft (1.8 m)
Audio Adapter (RCA to 3.5mm)
Macintosh Adaptor
S-Video Cable
Executive Plus Remote
Projection Lamp Module(factory installed in projector)
Lens Cap
User Guide CD
North American Power Cord
Australian Power Cord
UK Power Cord
European Power Cord
Danish Power Cord
Swiss Power Cord
PR-Cable3
Ceiling Mount Kit
M1-DA Digital Computer Cable
43
Portable and Laptop Activation Chart
NOTE: Visit our website at projec-
tors.toshiba..com for the most cur-
rent activation chart.
Many laptop computers do not automatically turn on their external video port when a projector is connected. Activation commands for some laptop computers are listed in the following
table. (If your computer is not listed or the given command does
not work, refer to the computer’s documentation for the appropriate command.) On many laptops, the activation function key
is labeled with an icon, for example or the text CRT/LCD.
NOTE: Usually, pressing the key
commands once activates the
external video port, pressing it
again activates both the external
and internal ports, and pressing it
a third time activates the internal
port. Refer to your computer’s doc-
umentation for details on your spe-
cific model.
Computer
Key command to
activate port
Key command to
de-activate port
Toshiba* ** Ctrl-Alt-End Ctrl-Alt-Home
FN-End FN-Home
FN-F5 FN-F5
setup screen option setup screen option
Acer Ctrl-Alt-Esc (for setup) Ctrl-Alt-Esc (for setup)
AST* ** FN-D or Ctrl-D FN-D or Ctrl-D
Ctrl-FN-D Ctrl-FN-D
FN-F5 FN-F5
type from A:/IVGA/CRT type from A:/IVGA/CRT
FN-F12 FN-F12
AMS FN-F2 FN-F2
AMT setup screen setup screen
AT&T FN-F3
FN-F6
FN-F3
FN-F6
Advanced Logic
Research
Ctrl-Alt-V Ctrl-Alt-V
Altima Shift-Ctrl-Alt-C Shift-Ctrl-Alt-L
setup VGA/
Conf.Simulscan
setup VGA/
Conf.Simulscan
Ambra** FN-F12 FN-F12
FN-F5 FN-F5
F2/Choose Option/F5 F2/Choose Option/F5
44
A p p e n d i x
Amrel* ** setup menu setup menu
Shift-Ctrl-D Shift-Ctrl-D
Apple see Mac Portable and Mac PowerBook
Aspen automatic automatic
Award FN-F6 FN-F6
BCC* automatic reboot computer
Bondwell LCD or CRT options after
bootup
reboot for LCD or CRT
options to appear
Chaplet** setup screen setup screen
FN-F6 FN-F6
FN-F4 FN-F4
Chembook FN-F6 FN-F6
Commax Ctrl-Alt-#6 Ctrl-Alt-#5
Compaq* ** Ctrl-Alt-< Ctrl-Alt->
FN-F4 FN-F4
automatic automatic
mode/? (for setup option) mode/? (for setup option)
Compuadd* ** automatic automatic
Alt-F for screen setup
option
Alt-F for screen setup
option
Data General Ctrl-Alt-Command Ctrl-Alt-Command
Data General
Walkabout
2 CRT/X at DOS prompt reboot
Datavue Ctrl-Shift-M Ctrl-Shift-M
DEC** FN-F5 FN-F5
FN-F4 FN-F4
Dell** Ctrl-Alt-< Ctrl-Alt->
Ctrl-Alt-F10 Ctrl-Alt-F10
FN-F8 (CRT/LCD) FN-F8
FN-D FN-D
FN-F12 FN-F12
Digital* automatic reboot
FN-F2 FN-F2
Dolch dip switch to CRT dip switch to LCD
Computer
Key command to
activate port
Key command to
de-activate port
45
Epson dip switch to CRT dip switch to LCD
Everex* setup screen option setup screen option
For-A Ctrl-Alt-Shift-C Ctrl-Shift-Alt-L
Fujitsu FN-F10
Gateway FN-F3
FN-F1/FN-F1 again simultaneous
FN-F3
FN-F1
Grid* ** FN-F2, choose auto or
simultaneous
FN-F2
Ctrl-Alt-Tab Ctrl-Alt-Tab
Hitachi FN-F7 FN-F7
Honeywell FN-F10 FN-F10
Hyundai setup screen option setup screen option
IBM 970* automatic warm reboot
IBM ThinkPad** reboot, enter setup menu FN-F2
FN-F7, select choice from
setup menu
FN-F1, select choice
FN-F5, select choice
PS/2 SC select choice
(CRT, LCD, etc.)
Infotel FN-F12 FN-F12
Kaypro boot up, monitor plugged inunplug monitor
Kris Tech FN-F8 FN-F8
Leading Edge FN-T FN-T
Mac Portable
100
no video port: not compatible
Mac PowerBook
140, 145, 150,
170
no video port: requires a 3rd-party interface
160, 165, 180,
520, 540, 5300
Control Panel folder, PowerBook Display folder;
Activate Video Mirroring
warm reboot
210, 230, 250,
270, 280, 2300
requires Apple Docking Station or Mini Dock
Computer
Key command to
activate port
Key command to
de-activate port
46
A p p e n d i x
Magitronic FN-F4 FN-F4
Mastersport FN-F2 FN-F1
Micro Express* automatic warm reboot
Micron FN-F2 FN-F2
Microslate* automatic warm reboot
Mitsubishi SW2 On-Off-Off-Off SW2 Off-On-On-On
NCR setup screen option setup screen option
NEC* ** setup screen option setup screen option
CRT at the DOS prompt LCD at the DOS prompt
FN-F3 FN-F3
Olivetti* automatic automatic
FN-O/* FN-O/*
Packard Bell* ** FN-F0 FN-F0
Ctrl-Alt-< Ctrl-Alt->
Panasonic FN-F2 FN-F2
Prostar Ctrl-Alt-S at bootup Ctrl-Alt-S at bootup
Samsung* setup screen option setup screen option
Sanyo setup screen option setup screen option
Sharp dip switch to CRT dip switch to LCD
Sun SPARCDataview
Ctrl-Shift-M Ctrl-Shift-M
Tandy** Ctrl-Alt-Insert Ctrl-Alt-Insert
setup screen option setup screen option
Tangent FN-F5 FN-F5
Texas Instruments*
setup screen option setup screen option
Top-Link* ** setup screen option setup screen option
FN-F6 FN-F6
Toshiba* ** Ctrl-Alt-End Ctrl-Alt-Home
FN-End FN-Home
FN-F5 FN-F5
setup screen option setup screen option
Computer
Key command to
activate port
Key command to
de-activate port
47
* These manufacturers have models that automatically send video
to the external CRT port when some type of display device is
attached.
** These manufacturers offer more than one key command depend-
ing on the computer model.
Twinhead* FN-F7 FN-F7
FN-F5 FN-F5
Automatic Automatic
WinBook Ctrl-Alt-F10 Ctrl-Alt-F10
Wyse software driven software driven
Zenith** FN-F10 FN-F10
FN-F2 FN-F2
FN-F1 FN-F1
Zeos** Ctrl-Shift-D
FN-F1
Ctrl-Shift-D
FN-F1
Computer
Key command to
activate port
Key command to
de-activate port
48
A p p e n d i x
Using Video Mirroring with a PowerBook Computer
When you turn video mirroring (called SimulScan in newer PowerBooks—see below) on, the projector displays the same information that appears on your PowerBook’s built-in screen. When
video mirroring is off, the projector acts like a separate display.
To turn on video mirroring for the first time:
1
Open the Monitors control panel; click on Monitor 2.
2
Set the number of colors you want.
3
Open the Control Strip, then click on the monitor icon.
4
Select “Turn Video Mirroring On.”
Now you can turn video mirroring on and off from the Control
Strip without having to open the Monitors control panel again.
When using video mirroring and high color graphics such as
slide shows, the projected image occasionally might turn black
and white. If this happens, perform the following steps:
1
Turn off video mirroring.
2
Open the Monitors control panel.
3
Move the white menu bar to Monitor 2 to set the projector as
the primary monitor.
4
Restart the PowerBook.
Using SimulScan
Some newer PowerBooks display images on an external monitor
or projector differently than previous ones. When using
SimulScan, the projector displays the same information that
appears on your PowerBook
To select SimulScan:
1
Open the Control Panel, then double-click Monitors and
Sound.
2
In the Resolution list, choose the SimulScan mode, then click
OK.
3
If this changes your display settings, a dialog box appears.
Click OK to confirm the change.
49
Projected Image Size
NOTE: Use the graph and tables
to help you determine projected
image sizes.
F
IGURE 25
Projected image size
Table 1:
Image Size, Width and Height-maximum image size
Distance to
Screen (feet)
Diagonal
(feet)
Width
(feet)
Height
(feet)
4.9 3.0 2.4 1.8
8 5.0 4.0 3.0
12 7.4 6.0 4.5
16 9.9 7.9 6.0
20 12.4 9.9 7.4
30 18.6 14.9 11.2
Table 2:
Image Size, Width and Height-minimum image size
Distance to
Screen (feet)
Diagonal
(feet)
Width
(feet)
Height
(feet)
4.9 2.5 2.0 1.5
8 4.0 3.2 2.4
12 6.0 4.8 3.6
16 8.0 6.4 4.8
20 10.0 8.0 6.0
30 15.0 12.0 9.0
50
A p p e n d i x
51
INDEX
A
accessories, ordering 42
activation commands for laptop com-
puters 43
adjusting
brightness 21
color 22
contrast 21
height of the projector 17
tint 21
volume 19, 23
altitude limits 41
assistance. See Technical Support
audio adapter, connecting 12
audio cable, connecting 10
Audio menu 23
Audio menu options
Bass 23
Treble 23
Volume 23
Auto Source Select 28
B
bass 23
Blank Screen 22
brightness, adjusting 21
buttons on keypad
Menu 18
Source 18
Standby 19
Volume 19
C
cables
audio 10
audio adapter 12
composite video 11
M1-DA analog computer cable 3,
8, 9
ordering 42
power 42
S-video 11, 42
ceiling-mounted projection 27
centering the image 17, 26
cleaning the projection lens 33
color, adjusting 22
colors
don’t match monitor colors 39
not displayed 38
compatibility
IBM-compatible 2
Macintosh 2
composite video cable
connecting 11
computers
connecting 9
computers, compatible 2
connecting
audio adapter 12
audio cable 10
computers 9
power cord 13
remote 10
USB mouse 10
video player 11–12
contrast, adjusting 21
Controls menu 27
Controls menu options
Auto Source Select 28
Ceiling Projection 27
Default Source 28
Display Messages 28
Display Startup Screen 29
Plug and Play 28
Rear Projection 28
Standby Time 27
Video Standard 27
52
I n d e x
D
Default Source 28
Display menu 21
Display menu options
Blank Screen 22
Brightness 21
Color 22
Contrast 21
Reset All 22
Sharpness 22
Tint 21
Display Messages 28
Display Startup Screen 29
displaying
on-screen menus 18
startup screen 29
status messages 28
E
elevator button/foot 17
F
focusing the image 17
fuzzy lines 25
H
HDTV 2, 11, 24
height adjustment 17
I
IBM-compatible computers
compatibility 2
adjusting 13, 15
centering 26
colors don’t match computer’s 39
focusing 17
fuzzy lines 25
has lines or spots 39
not centered 38
not displayed 37
out of focus 38
quality 38–39
resolution 1
reversed 28, 39
size 7, 49
streaked 39
too wide or too narrow 38
zooming 17
Image menu 24
Image menu options
Auto Image 24
Horiz. Position 26
Keystone 24
Manual Sync 25
Manual Tracking 25
Overscan 24
Resize 24
Vert. Position 26
K
keypad 18
keystone correction 24
53
L
lamp
ordering 42
replacing 33
turns off unexpectedly 40
lamp hour counter 30, 33, 35
Language menu 29
language, selecting for menus 29
laptop computers
activation sequence to allow
secondary display 43
compatibility 9
connecting 9
LED 13, 18, 19, 30, 33
lens
cap 42
cleaning 33
leveling knob 17
leveling the projector 17
M
M1-DA analog computer cable 3, 8, 9
Macintosh computers
compatibility 2
connecting 9
Menu button 20
menus. See on-screen menus
monitor, projected colors don’t match
39
mouse
buttons on keypad 18, 20
buttons on remote 15, 20
connecting USB 10
N
NTSC video 27
O
on-screen menus
Audio menu 23
changing language of 29
Controls menu 27
Display menu 21
displaying 20
Image menu 24
Language menu 29
making changes to menu
functions 20
Status menu 30
overscan 24
P
PAL video 27
Plug and Play 28
power cord
connecting 13
ordering 42
power up sequence 13, 37
PowerPoint slides, advancing with the
remote 10, 16
project from behind the screen 28
projector
project from behind the screen 28
setting up 7
specifications 41
turning off 14
turning on 13
54
I n d e x
R
rear projection 28
remote control
advancing PowerPoint slides
with 10, 16
connecting 10
controlling the computer with 10,
15
replacing the batteries 36
using 15, 18
replacing projection lamp module 33
re-positioning the image on the screen
26
resetting adjustments 22
resetting the lamp hour counter 35
resizing video 24
resolution 1
S
safety guidelines iii
SECAM video 27
security lock 36
sharpness 22
SimulScan, using with PowerBooks 48
Source button 18
specifications 41
Standby button 19
Standby Time 27
startup screen 29
Status menu 30
S-video
connecting 11
ordering cable 42
T
Technical Support
information to have on hand
before you call 40
temperature limits 41
test pattern 37
text not visible 38
tint, adjusting 21
treble 23
troubleshooting 37
turning off the projector 14
turning on the projector 13
U
USB mouse 10
V
vertical lines displayed 25, 39
video mirroring on a PowerBook 48
video resizing 24
video standards 27
Volume buttons 19
volume, adjusting 19, 23
W
widescreen video 25
Z
zooming the image 17
Part Number 010-0249-00
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
Safety Certifications
UL, CUL, TÜV, NOM, IRAM
EN 55022 Warning
This is a Class A product. In a domestic environment it may cause radio
interference, in which case the user may be required to take adequate measures.
The typical use is in a conference room, meeting room or auditorium.
Declaration of Conformity
Manufacturer: Toshiba Corporation
1-1, Shibaura 1-Chome, Minato-ku, Tokyo, Japan
We declare under our sole responsibility that the TDP-S2 and TDP-T1 projectors
conform to the following directives and norms:
Directive 89/336/EEC, Amended by 93/68/EEC
EMC: EN 55022 (1992) Class A
EN 55024 (1998)
Directive 73/23/EEC, Amended by 93/68/EEC
Safety: EN 60950: 1992 + A1 + A2 + A3 + A4: 1997
EN61000-3-2
EN61000-3-3
August, 2000
Trademarks
Apple, Macintosh, and PowerBook are trademarks or registered trademarks of
Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of
International Business Machines, Inc. Microsoft, PowerPoint, and Windows are
trademarks or registered trademarks of Microsoft Corporation. Digital Light
Processing is a trademark or registered trademark of Texas Instruments.
Loading...
