Carefully read the Model No. and Serial No. located at the
back of the unit and enter the information below. Retain
this information for future reference .
Model No. __________________________
Serial No. __________________________
1
E2TE0BD_EN.book Page 2 Friday, March 5, 2010 4:49 PM
.
Introduction
Precautions
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE CO VER (OR BACK). NO USER SER VICEABLE PAR TS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The important note is located on the rear of the cabinet.
Laser Safety
This unit employs a laser. Only qualified service personnel
should remove the cover or attempt to service this unit, due to
the possibility of eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION
LOCATION: INSIDE, NEAR THE DECK MECHANISM.
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
WHEN OPEN AND INTERLOCK DEFEATED.
DO NOT STARE INTO BEAM.
Power Supply
The power supply is connected and the unit is live when the
mains cable is plugged into a 220 - 240 V~, 50 Hz AC outlet.
To operate the unit, press [B ON\STANDBY].
WARNING: LIVE PARTS INSIDE.
DO NOT REMOVE ANY SCREWS.
Caution
1. Do not attempt to open the cabinet. There are no parts
inside you can service. Refer all servicing to qualified
service personnel.
2. Slots and openings in the cabinet at the sides and
underneath are provided for ventilation. To ensure reliable
operation and to protect the unit from overheating, these
openings must not be blocked or covered.
Avoid installation in enclosed spaces such as bookcases
unless suitable ventilation is provided.
3. Keep the unit away from radiators and other heat sources.
4. Avoid use near strong magnetic fields.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
The symbol for CLASS II (Double Insulation)
5. Do not push objects of any kind into the unit through the
cabinet slots or openings as they could touch electrically
live parts or short circuit parts resulting in a fire or electric
shock.
6. To prevent fire or shock hazard, do not expose this
apparatus to dripping or splashing, no objects filled with
liquids, such as vases, should be placed on the
apparatus.
7. Do not stand the unit vertically. Use the unit in a horizontal
(flat) position only.
8. Before attempting to operate the unit, make sure that the
timer recording mode is off.
9. This product is in Stand-by mode when turned off while
the mains cable is connected.
The front panel display will not light up. This is a
Power Saving Mode (ECO) for standby.
10. Do not place any combustible objects on the device
(candles, etc.).
11. Before moving the unit, be sure to remove any media and
unplug the mains cable from the AC outlet.
12. Disconnect the mains plug to shut off the unit, if you
suspect a fault has developed, or if it will not be used for
an extended period.
13. The mains plug shall remain readily operable.
14. Read the instruction manual, and QSG to ensure correct
and safe installation and interconnection of the unit in
multimedia systems.
15. Keep a distance of 20 cm around the ventilation openings
of the apparatus.
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can
be reused. Please dispose of any materials in accordance
with your local recycling regulations.
This product consists of materials which can be recycled
and reused if disassembled by a specialised company.
EN
2
E2TE0BD_EN.book Page 3 Friday, March 5, 2010 4:49 PM
Following information is only for EU-member states:
The use of the symbol indicates that this product may not
be treated as household waste. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this
product. For more detailed information
about recycling of this product, please
contact your local city office, your
household waste disposal service or the
shop where you purchased the product.
Following information is only valid EU-member States:
Disposal of batteries and/or accumulators
The crossed out wheeled dust bin symbol indicates that
batteries and/or accumulators must be collected and
disposed of separately from household waste.
or accumulator contains more than the specified values of
lead (Pb), mercury (Hg), and/or cadmium (Cd) defined in
the Battery Directive (2006/66/EC), then the chemical
symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd)
will appear below the crossed out wheeled dust bin
symbol. By participating in separate collection of batteries,
you will help to assure the proper disposal of products and
batteries and thus help to prevent potential negative
consequences for the environment and
human health. For more detailed
information about the collection and
recycling programmes available in your
country, please contact your local city office
or the shop where you purchased the
product.
Make your contribution to the environment!!!
• Exhausted batteries do not belong in the
dustbin.
• You can dispose of them at a collection point for
exhausted batteries or special waste.
• Contact your council for details.
Do not place the unit on the furniture that is capable of
being tilted by a child and an adult leaning, pulling,
standing or climbing on it. A falling unit can cause serious
injury or even death.
If the battery
Pb, Hg, Cd
Connection to Power
Before Switching on make sure that the voltage of your
electricity supply is the same as that indicated on the rating
plate.
Mains Cord
This appliance may be fitted with a non-rewireable plug. If it is
necessary to change the fuse in a nonrewireable plug the fuse
cover must be refitted. Do not use the plug if the fuse cover is
lost or damaged. If a replacement fuse cover cannot be found,
the plug must be changed with another carrying the same
value fuse.
It is important that the colour of the replacement fuse cover
corresponds with the rating marking on the base of the plug.
If the plug has to be changed because it is not suitable for
your socket, or becomes damaged, it should be cut off and an
appropriate plug fitted following the wiring instructions below.
The plug removed must be disposed of safely as insertion into
a 13A socket is likely to cause an electrical hazard.
For your own safety read the following instructions carefully
before attempting to connect this unit to mains.
The wires in this mains lead are coloured in accordance with
the following code:
BLUE=NEUTRAL, BROWN=LIVE
Important
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
No connection is to be made to the earth terminal of the plug.
If a 13 Amp (BS 1363) Plug is used, a 5 Amp Fuse must be
fitted, or if any other type of Plug is used a 3 or 5 Amp Fuse
must be fitted, either in the Plug or Adaptor, or on the
Distribution Board.
Mains Supply: 220 - 240 V~ 50 Hz - AC only
Do not make any connection to the larger pin marked with the
letter “E” or by the symbol or coloured green or green and
yellow.
FUSE
BROWN
BLUE
(Neutral)
OUTER SHEATH OF THE WIRE
(Live)
CORD GRIP
Installation Location
For safety and optimum performance of this unit:
• Install the unit in a horizontal and stable position.
• Keep the unit away from electronic equipment such as an
amplifier, TV, etc. to prevent warping ,damage, fire and
malfunction.
• Do not place anything directly on top of the unit.
• Shield the unit from direct sunlight and keep away from
sources of intense heat. Avoid dusty or humid locations.
Avoid locations with insufficient ventilation for suitable heat
dissipation. Do not block the ventilation holes on the sides of
the unit. Avoid locations subject to strong vibration or strong
magnetic fields.
Avoid the Hazards of Electrical Shock and Fire
• Do not handle the mains cable with wet hands.
• Do not pull on the mains cable to disconnect it from the AC
outlet. Grasp it by the plug.
• If, by accident, water is spilled on the unit, unplug the mains
cable immediately and take the unit to an authorised service
centre for servicing.
Moisture Condensation Warning
Moisture condensation may occur inside the unit when it is
moved from a cold place to a warm place, after heating a cold
room, or under conditions of high humidity. Do not use the unit
for at least 2 hours to allow the inside to dry.
About Copyright
Unauthorised copying, broadcasting, public performance and
lending of discs are prohibited. This product incorporates
copyright protection technology that is protected by U.S.
patents and other intellectual property rights. Use of this
copyright protection technology must be authorised by
Macrovision, and is intended for home and other limited
viewing uses only unless otherwise authorised by
Macrovision. Reverse engineering or disassembly is
prohibited.
E2TE0BD_EN.book Page 4 Friday, March 5, 2010 4:49 PM
Notice for the Progressive Scan Outputs
Consumers should note that not all high definition television
sets are fully compatible with this product and may cause
artifacts to be displayed in the picture. In case of picture
problems with 480 or 576 progressive scan output, it is
recommended that the user switch the connection to the
‘standard definition’ output. If there are questions regarding
your TV set compatibility with this 480p or 576p product,
please contact our customer service centre.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
®
Digital Stereo Creator enables consumers to
“Dolby
create stereo DVD-Videos with stunning Dolby Digital
sound tracks at home. The technology, when utilised
instead of PCM recording, also saves recordable disc
space, allowing for higher video resolution or extended
recording time on each DVD. DVDs mastered using Dolby
Digital Stereo Creator will play back on all DVD-Video
players.”
Note: This is true when the players are compatible with
HDMI, the HDMI Logo, and
High-Definition Multimedia
Interface are trademarks or
registered trademarks of HDMI
Licensing LLC in the United
States and other countries.
DivX®, DivX Certified®, and associated
logos are registered trademarks of
DivX, Inc. and are used under license.
DVB is a registered trademark of the DVB
Project
MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
THIS PRODUCT IS LICENSED UNDER THE MPEG-4
VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A
CONSUMER FOR (i) ENCODING VIDEO IN
COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD
(“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4
VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED BY MPEG LA TO PROVIDE
MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND COMMERCIAL USES
AND LICENSING MAY BE OBTAINED FROM MPEG LA,
L. L. C. SEE HTTP://WWW.MPEGLA.COM
Maintenance
CLEANING THE UNIT
Use a soft cloth slightly moistened with a mild detergent
solution. Do not use solutions containing alcohol, spirits,
ammonia or abrasives.
CLEANING DISCS
If a disc becomes dirty, clean it with a cleaning cloth. Wipe the
disc from the centre out. Do not wipe in a circular motion.
Do not use solvents such as benzine, thinners, commercially
available cleaners, detergent, abrasive cleaning agents or
antistatic spray intended for analogue records.
DISC HANDLING
Handle the discs so that fingerprints and dust do not adhere
to the disc surfaces.
Always store the disc in its protective case when it is not in
use.
HDD HANDLING
• HDD is a precision apparatus that is susceptible to vibration,
strong impact or dirt. Depending on the installation
environment or handling, the unit may become partially
damaged or in the worst case, recording or replaying may
not be available. Especially while the HDD is in motion, do
not subject it to vibration or strong impact or pull out the
power plug. And if a power failure occurs, the content of the
recording / replaying programme may be lost.
• HDD rotates at high speed when in operation. Be sure that
rotation has stopped and then move the unit without
subjecting it to strong impact or vibration.
EU Conformity Statement
“This product is marked with “CE” and complies therefore with
the applicable harmonized European standards listed under
the Low Voltage Directive 2006/95/EC, the EMC Directive
2004/108/EC and ErP Directive 2009/125/EC(2005/32/EC).”
Responsible for CE-marking is
TOSHIBA INFORMATION SYSTEMS (U.K.) LTD, Toshiba
Court, Weybridge Business Park, Addlestone Road,
Weybridge, Surrey, KT15 2UL, United Kingdom
EN
4
SERVICING
If the unit becomes inoperative, do not try to correct the
problem by yourself. There are no user serviceable parts
inside. Turn the unit off, unplug the mains cable, and consult
your dealer or an authorised service centre.
CLEANING THE DISC LENS
If the unit does not perform correctly even though you have
referred to “Troubleshooting” and the relevant sections in the
Owner’s Manual, the laser optical pickup unit may be dirty.
Consult your dealer or an authorised service centre for
inspection and cleaning of the laser optical pickup unit.
E2TE0BD_EN.book Page 5 Friday, March 5, 2010 4:49 PM
Accessories Supplied
• Remote control with 2 R6 (1.5 V) batteries
•RF cable
• Owner’s Manual
• Quick Setup Guide
• Helpline Sheet
Features
The following features are available with this unit.
Recording
HDDDVD
• Recording up to 36 programmes
• One-touch timer recording: [E Page 32]
• Left channel stereo recording
• Automatic chapter mark setting: [E Page 31]
• Automatic Playlist making
HDD
• 320 GB hard disc
•PDC: [E Page 34]
DVD
• Alternate recording: [E Page 34]
• Automatic finalising: [E Page 44]
• Automatic title menu making: [E Page 44]
Dubbing
HDDDVD
• High speed dubbing: [E Page 41]
• Auto recording mode dubbing: [E Page 41]
• DV dubbing: [E Pages 39-40]
Playback
HDDDVD
• Theatre surround sound: [E Page 19]
• Quick search: [E Pages 53-54]
• Variable skip: [E Page 50]
• Variable replay: [E Page 50]
• Playback from Original or a Playlist: [E Page 45]
• Virtual Surround System: [E Page 56]
• Playing back data files recorded in a USB device:
[E Page 47]
HDD
• Chasing playback during recording and simultaneous
playback and recording: [E Page52]
• Pausing a TV broadcast to resume later (Pause TV):
[E Page 52]
DVD
®
• Playing back MP3 / JPEG / DivX
files: [E Pages 46-48]
Editing
HDDDVD
• Adding or deleting chapter marks manually:
[E Page 60]
• Creating titles to a Playlist: [E Page 62]
• Deleting titles: [E Page 58]
• Deleting a scene of a title: [E Page 63]
• Editing title name: [E Page 59]
• Combining titles: [E Page 62]
• Dividing titles: [E Page 61]
• Protecting titles: [E Page 61]
DVD
• Adding or deleting chapter marks at once
(video mode DVD-RW only): [E Page 60]
E2TE0BD_EN.book Page 8 Friday, March 5, 2010 4:49 PM
Media for Recording / Playing
Media TypeDVD-RWDVD-RDVD+RWDVD+RHDD
Logo
Format Can be fo rmatted in VR or video mode
Video ModeVR Mode
Icon
Maximum Record Time
Recordable/Playable
Recording Features
Record TV
Programmes
Reuse by Deleting
the Current
Contents
Available Features
Record 16:9 Size
Pictures
Record Copy-once
Programmes
Create Chapters at
Fixed Intervals
(auto chapter)
Editing Features
Scene Delete
Edit Title Name
Create Chapters
Wherever Y ou Like
(chapter mark)
Divide a Title
Combine Titles
Hide Chapters
Delete a Title
Deleting Selected
Titles
Create a Playlist
Protect a Title
✔: AvailableGrey: Not available
*CPRM compatible disc only.
Versions
Compatibility
Video
DVD-RW
DVD-RW
480 min
(12 cm)
144 min
(8 cm)
1×-6×
Ver. 1.1/1.2
Ver. 1.1/1.2 CPRM compatible
Playable on
most DVD
players.
Finalisation
necessary.
(Title menu will
be created)
Playable only on VR
mode compatible
unit.
Finalisation
recommended.
✔ ✔ ✔✔✔ ✔
✔✔✔✔
✔✔✔✔
✔ ✔ ✔✔✔ ✔
Playlist OriginalPlaylist Original
✔✔✔✔✔✔✔✔
✔✔✔✔✔✔✔✔
VR
DVD-RW
DVD-RW
480 min
(12 cm)
144 min
(8 cm)
✔*✔
✔✔✔✔
✔✔✔✔✔✔
✔✔✔✔
✔✔
✔✔
✔✔
Automatically
formatted in
video mode
DVD-R
DVD-RDVD+RW
480 min
(12 cm)
144 min
(8 cm)
1×-16×
Ver. 2.0/2.1
Playable on
most DVD
players.
Finalisation
necessary.
(Title menu will
be created)
Automatically
formatted in
+VR mode
1×-4×1×-16×–
Playable on
DVD+RW
compatible
players.
Finalisation
recommended.
(Title menu will
be created)
Automatically
formatted in
+VR mode
DVD+RWDVD+R
480 min
(12 cm)
144 min
(8 cm)
DVD+R
480 min
(12 cm)
144 min
(8 cm)
Playable on
most DVD
players.
Finalisation
recommended.
(Title menu will
be created)
✔✔
–
HDD
HDD
545 hrs
(with SLP mode)
–
✔✔
DVD players with are capable of playing DVD-RW recorded in VR mode.
EN
8
DVD-V
VCD
MP3
JPEG
DivX
E2TE0BD_EN.book Page 9 Friday, March 5, 2010 4:49 PM
Discs for Playing
Disc TypeDVD-VIDEOCD-DAVideo CDCD-RW CD-R
Logo
Icon
Type of titleMP3JPEGDivX
Icon
Media
is a trademark of DVD Format/Logo Licensing Corporation.
• ABOUT DIVX VIDEO: DivX® is a digital video format created
by DivX,Inc. This is an official DivX Certified device that
plays DivX video. Visit www.divx.com for more information
and software tools to convert your files into DivX video.
• ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified
device must be registered in order to play DivX Video-onDemand (VOD) content. To generate the registration code,
locate the DivX VOD section in the device setup menu. Go
to vod.divx.com with this code to complete the registration
process and learn more about DivX VOD.
• DivX Certified
content.
• Media containing the DivX
Motion Compensation) playback feature, which is DivX
supplemental function, cannot be played back on this unit.
Unplayable Discs
The following discs will not play back on this unit.
• CD-ROM• Compact Disc-Interactive
• Video Single Disc (VSD)• DVD-ROM
• DVD-audio• Unfinalised disc
• DVD or CD contains Windows Media™ Audio files
• DVD-RW/-R recorded in non compatible recording format
•Blu-ray Disc•HD DVD
On the following disc, the sound may not be heard.
• Super audio CD - Only the sound on the CD layer can be
heard. The sound on the high-density super audio CD layer
cannot be heard.
DVD-V
DVD-VCDCDCDVCD
Files for Playing
MP3
MP3
CD-RW/-R
USB device
®
to play DivX® video, including premium
®
files with the DivX®GMC (Global
JPEG
JPEG
CD-RW/-R
USB device
USB device (not guaranteed)
(CD-I)
VCDCDCDCDCDCDCD
®
®
®
DivX
DivX
CD-RW/-R
DVD-RW/-R
DVD+RW/+R
Following discs are recommended for good recording quality
and are proven to be compatible with this unit.
However, depending on the media condition the unit may not
read the disc properly.
Performance of any other discs are not guaranteed.
• Toshiba is not liable for any damage or loss caused
directly or indirectly by the malfunction of this unit,
®
including, without limitation, any one of the following:
• Failure to record contents intended to be recorded by
the consumer.
• Failure to edit contents as intended by the consumer.
• When a DVD-RW/-R, DVD+RW/+R disc created on
this unit is used (e.g., insertion, playback, recording or
editing) in another DVD player, recorder or personal
computer drive.
• When a DVD-R W/-R, D VD+R W/+R disc that is used in
the manner described in the immediately preceding
bullet point is used again in this unit.
• When a DVD-RW/-R, DVD+RW/+R disc that was
recorded in another DVD recorder, or in a personal
computer drive is used in this unit.
• Some functions may not work with personal computer
discs.
• Discs recorded in this unit may not operate as expected
on other DVD players, recorders or personal computer
drives.
This unit uses the PAL system. However, it is also possible to
play back DVDs using other colour systems, such as NTSC.
Region Codes
This unit has been designed to play DVD with
region 2. If these region symbols do not appear on
your D VD, you cannot play bac k the DVD in this unit.
The number inside the globe refers to region of the
world.
2
Because of problems and errors that can occur during the
creation of DVD and CD software and/or the manuf acture of
DVD and CD discs, Toshiba cannot guarantee that product
will play every feature of every DVD bearing the DVD logo
and/or every CD bearing the CD logo. As one of the
creators of DVD technology, Toshiba DVD players are
manufactured using the highest standards of quality , and as
a result, such incompatibilities are rare.
EN
9
E2TE0BD_EN.book Page 10 Friday, March 5, 2010 4:49 PM
Functional Overview
Front Panel
2
1*
You can also turn on the unit by pressing these buttons.
Press to turn on the unit, or to turn the unit into the standby mode. (To completely shut down the unit, you must unplug the
AC power cord.)
1 B ON\STANDBY button*
2 Disc tray
3 A OPEN\CLOSE button*
4 Infrared sensor window
5 Display (“Off” in standby)
6 HDMI indicator
7 HDD mode indicator
8 DVD mode indicator
9 C STOP button
Button names described in the Owner’s Manual
The instructions in this manual are described mainly with the operations using the remote control. Some operations can be
carried out using the buttons on the front panel.
2748
2
1
3
1
*
56
17
10 B PLAY button*
11 I REC button
12 DV IN jack (AV4)
13 AUDIO input jacks (AV3)
14 VIDEO input jack (AV3)
15 USB input jack
16 DVD button
17 HDD button
1
910
14
1516
*111
1312
Rear Panel
13 4568927
1 ANTENNA IN
2 ANTENNA OUT
3 AUDIO OUT (DIGITAL COAXIAL) jack
4 AUDIO OUT (ANALOG L\R) jacks
5 COMPONENT VIDEO OUTPUT jacks
Note
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.
• After turning off the unit, leave the mains cable plugged for about one minute. Otherwise it may cause data loss or the unit may
not work properly.
• This unit does not have an RF modulator.
EN
10
6 AV2 (DECODER) socket
7 HDMI OUT jack
8 AV1 (TV) socket
9 Mains cable
E2TE0BD_EN.book Page 11 Friday, March 5, 2010 4:49 PM
Remote Control
1*
2
3
4
5
6
7
8
9
10
11
12*
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
1 OPEN\CLOSE A button (DVD)*
2 INPUT SELECT F button
3 Number buttons
4 SETUP button
5 TEXT button
6 VARIABLE REPLAY button
7 TOP MENU button
8 Direction
9 DISPLAY button
10 RED/GREEN/YELLOW/BLUE button
11 REV E button
12 PLAY B button*
13 SKIP H button
14 PAUSE F button
15 TIME SLIP button (HDD)
16 DUBBING button
17 SUBTITLE button
18 AD (Audio Description) button
19 HDMI button
20 B ON/STANDBY button
21 PROG. G\H buttons
22 TIMER PROG. button
23 INFO C button
24 CLEAR button
25 GUIDE button
26 VARIABLE SKIP button
27 DISC MENU button
28 ENTER/OK button
29 RETURN/BA CK button
30 FWD D button
31 STOP C button
32 SKIP G button
33 HDD button
34 DVD button
35 REC I button
36 REC MODE button
37 SAT.LINK button (HDD)
38 AUDIO D button
Button names described in the Owner’s Manual
The instructions in this manual are described mainly with the
operations using the remote control. Some operations can
be carried out using the buttons on the front panel.
The unit can also be turned on by pressing these buttons.
EN
11
E2TE0BD_EN.book Page 12 Friday, March 5, 2010 4:49 PM
Installing Batteries in the Remote
Control
Install 2 R6 (1.5 V) batteries (supplied) into the remote
control, carefully match with the polarity indicated inside the
battery compartment.
213
Caution
• Incorrect use of batteries can result in hazards such as
leakage and bursting.
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
• Make sure that the plus (+) and minus (–) ends of each
battery match the indications inside the battery
compartment.
• Remove batteries if the equipment will not be used for a
month or more.
• When disposing used batteries, please comply with
governmental regulations or the public instructions for
environmental protection that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or disassemble
batteries.
About the Remote Control
• Make sure there is no obstacle between the remote control
and the remote control sensor on the unit.
• Use within the operating range and angle as shown.
Switching HDD / DVD mode
You must select which component you want to operate first.
Press [HDD] or [DVD] on the remote control or the front
panel.
Device select indicators
indicator
button
HDD button
DVD button
HDD
Press [HDD] on the remote control or the front panel.
(Verify that the HDD indicator is lit in blue.)
DVD
Press [DVD] on the remote control or the front panel.
(Verify that the DVD indicator is lit in green.)
Within
about 7 m
7 m (30°)7 m7 m (30°)
• The maximum operable range as follows:
Line of sight:approximately 7 m
Either side of centre: approximately 7 m within 30 degrees
• Remote control operation may become unreliable if the
remote control sensor of the unit is being exposed by the
strong sunlight or fluorescent light.
• Remote controls for different devices can interf ere with each
other. Be careful when using remote controls for other
equipment located close to the unit.
• Replace the batteries when the operating range of the
remote control reduces.
EN
12
E2TE0BD_EN.book Page 13 Friday, March 5, 2010 4:49 PM
Guide to On-Screen Displays
DISPLAY Menu
HDDDVD
With a disc inserted into the unit, press [DISPLAY] to display
the on-screen display. The on-screen display shows
information about what is recorded on the disc.
1/ 51/ 5
TC
55
6611
7
This is an example screen for explanation. Displayed items
vary depending on the actual mode.
1 Indicates a disc type and format mode. (DVD
mode only)
2 Indicates a type of titles for HDD and VR mode
DVD-RW disc.
3 Indicates a channel number, station name
(analogue channel only) or selected external
input mode.
4 Indicates a media, recording mode and possible
recording time left.
5 Indicates the current title number/total number
of titles, the current chapter number/total
number of chapters, and time lapse of the
current title playback/total duration of the title.
E2TE0BD_EN.book Page 14 Friday, March 5, 2010 4:49 PM
INFO Menu
DVB
Press [INFO C] while viewing a DVB programme to display
the programme information.
3
13 Channel 4+1
2
English
1
NOW:
6
5
Castle
StereoAD Sub Entertainment27 min left
NEXT:
Burning Questions
4
11:53 Mon
11:23 – 12:20
12:20 – 12:25
1 Audio language
2 Channel number
3 Channel name
4 Current time and day
5 Next programme information
6 Current programme information
The window will automatically exit after 4 seconds, or press
[RETURN\BACK] to exit.
While the window appears, press [INFO C] again to display
more information. Press [RETURN\BACK] to exit.
Main Menu
Press [SETUP] to display the main men u. Then use [K \ L] to
select a menu and press [ENTER\OK] to display the sub
menu.
Press [RETURN\BACK] to return to previous screen.
Setup
A
B
C
D
E
G
H
1
2
3
4
5
6F
General Setting
Timer Programming
Title List
DVD Menu
HDD Me
un
Dubbing
DISC Playback Mode
USB Playback Mode
A General Setting
1
2
3
4
5
6
7
8
9
General Setting
Playback
Display
Video
Recording
Clock
Channel
DivX
HDMI
DVB Setting
Reset All
Parental Lock
Audio Out
Disc Menu Language
Audio Language
Subtitle Language
Angle Icon
Still Mode
Variable Skip/Replay
TV System
E2TE0BD_EN.book Page 16 Friday, March 5, 2010 4:49 PM
Front Panel Display Guide
1
DTV
1 DTV indicator
: Appears when the channel is in digital mode.
2 Title / Track and Chapter number
: Title / track number
: Chapter number
3 Current status of the unit
F:Appears when playback is paused.
Appears during step by step playback.
B:Appears when playing back an HDD or disc.
F B: Appears during slow forward / reverse playback.
:Appears when the timer programming or One-
touch Timer Recording (OTR) is set and operating.
Appears when the unit goes into the satellite link
standby or recording mode.
Flashes when timer programming and satellite
recording was not executed because of some
error.
I:Appears during recording.
Flashes when recording being paused.
2
3
DB
4
: Appears when a disc is in this unit.
: Appears during dubbing.
DB
4 Displays the following
• Playing back time
• Current title / chapter / track / file number
• Recording time / remaining time
•Clock
• Channel number
• One-touch Timer Recording (OTR) remaining time
• Selected HDMI video resolution
Note
• Except when satellite recording is in standby, front panel
display stays off while the power is off.
This is a new Power Save (ECO) feature.
Display Messages
EN
16
The disc tray is opening.
The PBC function of the
video CD is activated.
The disc tray is closing.
A disc is loading.
Data is being recorded on a
disc.
Appears when the satellite
link recording is in standby.
Appears when HDMI video
resolution (480p) is
selected.
Appears when HDMI video
resolution (576p) is
selected.
Appears when HDMI video
resolution (720p) is
selected.
Appears when HDMI video
resolution (1080i) is
selected.
Appears when HDMI video
resolution (1080p) is
selected.
E2TE0BD_EN.book Page 17 Friday, March 5, 2010 4:49 PM
Connections
Connecting to a TV
Connect the unit to a TV after considering the capabilities of
your existing equipment.
Before installation, unplug your TV and
this unit
Cable
Signal
or
Antenna
RF cable
(not supplied)
1
RF cable
(supplied)
2
To Aerial jack
• When changing the “Video Out” setting (“SCART (RGB)”,
“Component (Interlace)” or “Component (Progressive)”),
connect to the corresponding jack on the TV. If the setting is
changed, for example, to “Component (Interlace)” or
“Component (Progressive)” while the scart cable is
connected to the TV, a distorted video signal may be output.
Using the COMPONENT VIDEO OUTPUT
Jacks and the AUDIO OUT
(ANALOG L\R) Jacks
If your TV has component video input jacks, use a component
video cable and an audio cable (to connect the AUDIO OUT
(ANALOG L\R) jacks).
When using this type of connection, “Video Out” setting
should be set to “Component (Progressive)” or “Component
(Interlace)”. Refer to “Video Out” on page 70.
• Component connection provides the better quality picture.
Component
Audio IN
video IN
YPB/CBPR/C
R
IntroductionConnections
TVViewOperation
Basic Setup /
TV View Operation
Basic Setup /
1
Connect the antenna or cable to the ANTENNA
IN jack of this unit.
2
Connect the ANTENNA OUT jack of this unit to
the Aerial jack of your TV.
Using the Scart socket
Audio/video cable
(not supplied)
Scart/RCA cable (not supplied)
Scart adaptor
(not supplied)
Connect AV1 (TV) Scart socket of this unit to
the Scart socket of your TV.
Note
• If your TV does not have a Scart socket, use a Scart/RCA
cable to connect.
• Connect this unit directly to the TV. If the AV cables are
connected to a VCR, pictures may be distorted due to the
copy protection system.
Scart cable
(not supplied)
Audio cable
(not supplied)
2
Connect the COMPONENT VIDEO OUTPUT
1
1
Component
video cable
(not supplied)
jacks of this unit to the component video input
jacks of your TV.
Connect the AUDIO OUT (ANALOG L\R) jacks
2
of this unit to the analogue audio input jacks of
your TV.
• After you have made the connections, set the “Video Out”
setting. (See page 70.)
Selecting Progressive Scan (576p/480p or
Interlaced 576i/480i) Playback
• If your TV is compatible with progressive scanning (576p/
480p), connect the TV to the COMPONENT VIDEO
OUTPUT jacks of this unit and set “Video Out” setting to
“Component (Progressive)” in “Setup” menu. (See page 70.)
Next, set your TV to the progressive scan mode.
• If your TV is not compatible with progressive scan, set
“Video Out” setting to “Component (Interlace)”.
• Use a commercially available adaptor if the video input jacks
of your TVs or monitors are the BNC type.
• Only component and HDMI connections are compatible with
the Progressive Scan.
E2TE0BD_EN.book Page 18 Friday, March 5, 2010 4:49 PM
Using an HDMI Compatible Port
[HDMI CONNECTION]
• HDMI outputs the video / audio signals without converting to
analogue signals.
• No audio connections is required.
• Use the HDMI cable (commercially available) f or connection.
• Connect the HDMI output jack of this unit to the HDMI input
jack of TV.
HDMI cable (not supplied)
To HDMI
input jack
this unit
Selecting HDMI video resolution
Press [HDMI] to select the HDMI video resolution. The video
resolution changes as follows every time [HDMI] is pressed.
576p (PAL) / 480p (NTSC) J 720p J 1080i J 1080p
(An HDMI video resolution that is not supported by the display
device will be skipped.)
Actual Output Modes by Media
Audio recording format of
the disc
Dolby
Digital
LPCM
DVD-video
DTS
MPEG
Dolby
Digital
®
DivX
MP3
MP2
For audio CD , video CD and MP3 files, 2 channel PCM will be
output regardless of the “Dolby Digital” setting.
If the connected device is not compatible with HDMI
BITSTREAM, audio will be output as PCM even if you select
“Stream” in “Dolby Digital” setting. (See page 68.)
Dolby Digital / DTS /
MPEG setting of this
unit
PCM2 channel PCM
StreamDolby Digital
PCM
Stream
ONDTS
• Because HDMI is an evolving technology, it is possible that
some devices with an HDMI input may not operate properly
with this unit.
• When using an HDCP-incompatible display device, the
image will not be viewed properly.
• Among the devices that support HDMI, some devices can
control other devices via the HDMI connector; this unit can
be controlled by another device via the HDMI connector.
• The audio signals from the HDMI connector (including the
sampling frequency, the number of channels and bit length)
may be limited by the device that is connected.
• Among the monitors that support HDMI, some do not
support audio output (for example, projectors). In
connections with device such as this unit, audio signals are
not output from the HDMI output connector.
• When this unit’s HDMI connector is connected to a DVI-D
compatible monitor (HDCP compatible) with an HDMI-DVI
conversion cable, the signals are output in digital RGB.
• If the connected equipment is not compatible with HDMI
BITSTREAM, DTS sound will not be output.
• When the power failure occurs, or when you unplug the unit,
some problems in the HDMI setting might occur.
Please check and set the HDMI setting again.
Copyright protection system
To play back the digital video images of a DVD via an HDMI
connection, it is necessary that both the player and the display
device (or an AV amplifier) support a copyright protection
system called HDCP (high-bandwidth digital content
protection system). HDCP is copy protection technology that
comprises data encryption and authentication of the
connected AV device. This unit supports HDCP. Please read
the operating instructions of your display device (or AV
amplifier) for more information.
* HDMI: High Definition Multimedia Interface
EN
18
E2TE0BD_EN.book Page 19 Friday, March 5, 2010 4:49 PM
Connecting to External Equipment
This unit has four input terminals. Press [INPUT SELECT F]
repeatedly to select the external input mode, then press
[PROG. G\H] repeatedly to select AV1, AV2, AV3 or
DV(AV4). Be sure that all the units are switched off before
making connections.
Recording from a DVD player, Satellite
Box or other Audio-Video equipment
with a Scart output socket (AV2)
AV output jac k
(Scart)
AV2 (DECODER)
Note
• When you record a TV programme from a Satellite Box /
decoder, you m ust connect a Scart cable to A V2 (DECODER).
(See page 37.)
• The signal from the external device will be output
automatically when the TV is connected to AV1 and the
external device is connected to A V2 using a Scart cable with
its power on. (However, it will not be output when this unit’s
power is turned off.)
If you want to monitor this unit’s signal, press [DISPLAY]
or turn the external device off. (The signal from this unit can
only be monitored during playback.)
If you want to monitor the signal from other input, press
[DISPLAY], then press [INPUT SELECT F] to select the
desired external input mode, then select the desired input
channel using [PROG. G\H].
Recording from a camcorder or other
Audio-Video equipment with no Scart
output socket (AV3/DV(AV4))
Connect to AUDIO input jacks on the front panel using an
RCA audio cable.
Connect to VIDEO input jack on the front panel using an RCA
video cable.
When connecting a DV-camcorder, use DV input jack of
DV(AV4) (Front).
AV3/DV(AV4) (Front)
Video cable
(not supplied)
Scart cable (not supplied)
Audio cable
(not supplied)
DV cable
(4-pin)
(not supplied)
Note
• When connecting an external device of monaural output to
this unit, use AUDIO L jack of AV3.
Digital Audio for Better Sound Quality
Dolby Digital decoder,
DTS decoder or
MPEG deco der, etc.
Coaxial cable
(not supplied)
DIGITAL COAXIAL
The connections illustrated above are
optional for better sound
For clear digital sound quality, use the AUDIO OUT
(DIGITAL COAXIAL) jack to connect your digital
audio equipment.
If the audio format of the digital output does not match the
capabilities of your receiver, the receiver will produce a strong,
distorted sound or no sound at all.
Connecting a Dolby Digital™ decoder,
DTS decoder or MPEG decoder
• Connecting multi-channel Dolby Digital decoder allows you
to enjoy the Multi-channel Dolby Digital surround system as
well as DTS decoder, Multi-channel surround system.
• After connecting to a Dolby Digital decoder, set “Dolby
Digital” to “Stream” in “Audio Out” menu. (See page 68.)
• After connecting to a DTS decoder, set “DTS” to “ON” in
“Audio Out” menu. (See page 68.)
• After connecting to a MPEG decoder, set “MPEG” to
“Stream” in “Audio Out” menu. (See page 68.)
Connecting to an MD deck or DAT deck
• The audio source recorded in Dolby Digital Multi-channel
surround format cannot be recorded using an MD or DAT
deck as a digital sound.
• If not connected to a Dolby Digital decoder, set “Dolby
Digital” to “PCM” in “Audio Out” menu. Playing back a DVD
using incorrect settings may generate noise distortion and
damage speakers.
• Set “Dolby Digital” and “MPEG” to “PCM” and set “DTS” to
“OFF” in “Audio Out” menu for connecting to an MD or DAT
deck.
• You can use AUDIO OUT (ANALOG L\R) jacks for the
connection of your audio system.
E2TE0BD_EN.book Page 20 Friday, March 5, 2010 4:49 PM
Basic Setup / TV View Operation
Also you can customize the memorised channel at “General
Setting”.
Initial Setting
When you turn on this unit for the first time, y ou need to follow
these steps.
1 Press [B ON\STANDBY].
2 Turn the TV on. Select the input to which the
unit is connected.
3 Select your desired tuning type according to
your area using [K \ L], then press
[ENTER\OK].
Auto Tuning
Make sure the antenna is
connected to “ANTENNA IN” jack.
Digital tuning
Digital & Analog tuning
Analog tuning
The unit will start getting channels available in your area.
Refer to following pages for details.
• Refer to “Manual Tuning (ANALOG)” on page 21.
• Refer to “Manual Tuning (DVB)” on page 22.
• Refer to “Skip a Preset Channel” on page 22.
• Refer to “Move” on page 22.
Selecting the TV Aspect Ratio
Use this feature to adjust the aspect ratio of the video source
which is different from your TV’s ratio to fit your TV monitor
without distorting the picture.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
2 Select “Video” using [ K \ L], then press
[ENTER\OK].
3 Select “TV Aspect” using [K \ L], then press
[ENTER\OK].
Digital tuning:
Only the DVB channels receivable in your area are
automatically scanned and memorised.
Digital & Analog tuning:
Both analogue and DVB channels receivable in your area
are scanned and memorised automatically.
Analog tuning:
Only the analogue channels receivable in your area are
automatically scanned and memorised.
• If no channel has been memorised, the antenna
confirmation display will appear. Press [ENTER\OK] to start
auto scanning again or press [RETURN\BACK] to cancel
the initial settings.
4 After finishing channel setting, “Clock Setting”
will appear.
Clock Setting
01 / 01 / 2010 (FRI)
• The current date and time will appear automatically.
If the current date and time are correct, press
•
[RETURN\BACK]
[ENTER\OK]
page 70
Note
• After “Initial Setting”, if you need to unplug the mains cable,
make sure to turn off the power first and leave it in standby
mode for at least 1 minute before attempting to unplug.
Otherwise, it may cause data loss.
If you want to set each item of “Initial Setting” again, you can
set them at “General Setting”.
• Refer to “Auto Tuning (DVB & ANALOG)” on this page.
• Refer to “Auto Tuning (ANALOG)” on page 21.
• Refer to “Auto Tuning (DVB)” on page 22.
• Refer to “Clock” on page 70.
and follow to “A Clock Setting” on
.
0 : 00
to exit, if they are incorrect, press
TV Aspect
Video Out
4 Select the desired option using [K \ L], then
press [ENTER\OK].
46!SPECT
,ETTER"OX
0AN3CAN
7IDE
5 Press [SETUP] to exit.
Note
If you have a standard TV:
• Select “4:3 Letter Box” for a full width picture with black
bars at the top and bottom.
• Select “4:3 Pan & Scan” for a full height picture with both
sides trimmed.
If you have a wide screen TV:
• Select “16:9 Wide”.
Channel Setting
You can retune this unit or edit the channel setting with
following methods.
Auto Tuning (DVB & ANALOG)
DVBA NALOG
Programme the tuner to scan both analogue and DVB
channels you can receive in your area.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
“General Setting” menu will appear.
2 Select “Channel” using [K \ L], then press
[ENTER\OK].
20
EN
E2TE0BD_EN.book Page 21 Friday, March 5, 2010 4:49 PM
3 Select “Auto Tuning (DVB & ANALOG)” using
[K \ L], then press [ENTER\OK].
The unit will start storing channels available in your area.
General Setting
Playback
Display
Video
Recording
Clock
Channel
DivX
HDMI
DVB Setting
Reset All
Wait for several minutes to finish channel storing.
Auto Tuning (DVB & ANALOG)
DVB Channel Setup
ANALOG Channel Setup
4 Press [SETUP] to exit.
You can select only the channels memorised in this unit
by using [PROG. G\H].
To cancel auto tuning
Press [SETUP] during scanning.
Note
• The number of TV channels you can get is different depends
on your local area.
• If the auto tuning is cancelled during scanning, some
channels not yet tuned may not be received.
Auto Tuning (ANALOG)
ANALOG
Programme the tuner to scan only the analogue channels you
can receive in your area.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
2 Select “Channel” using [K \ L], then press
[ENTER\OK].
3 Select “ANALOG Channel Setup” using [K \ L],
then press [ENTER\OK].
4 Select “Auto Tuning” using [K \ L], then press
[ENTER\OK].
The unit will start storing channels available in your area.
!.!,/'#HANNEL3ETUP
!UTO4UNING
-ANUAL4UNING
-OVE
Wait for several minutes to finish channel storing.
5 Press [SETUP] to exit.
You can select only the channels memorised in this unit
by using [PROG. G\H].
• If you are using a satellite receiver, or a cable box, turn it on
and select SKY NEWS before commencing tuning. If the
SKY NEWS channel is not available to you, choose another
channel that you can recognise easily, and move this
reception to preset 6 after the automatic tuning has finished.
Instructions on page 22 explain how to move channels.
Manual Tuning (ANALOG)
ANALOG
You can preset an analogue channel manually and
individually.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
2 Select “Channel” using [K \ L], then press
[ENTER\OK].
3 Select “ANALOG Channel Setup” using [K \ L],
then press [ENTER\OK].
4 Select “Manual Tuning” using [K \ L], then
press [ENTER\OK].
5 Select “Position” using [K \ L], then press [1].
Position
Channel
Decoder
Skip
OFF
ON
1
1
6 Select the position number you want to use
using [the Number buttons] or [K \ L], then
press [0].
• You can select position number 1-99.
•With [the Number buttons], press “0” first to enter a
single digit number.
7 Select “Channel” using [K \ L], then press [1].
8 Press [K \ L] to start scanning.
• The tuner will begin to search up or down automatically.
When a channel is found, the unit will stop searching
and the picture will appear on the TV screen.
• You can select a desired channel number using
[the Number buttons]. Refer to the following Channel
Plan table and press the three digits to select the
channel number. (To select channel 4, press [0] first and
then press [0] and [4]. Or press [4] and then “– – 4”
appears and wait for 2 seconds.)
• If desired channel is found, press [0].
Channel Plan
CH IndicationTV Channel
1 – 10IRA - IRJ, GAP
21 – 69E21 – E69
74 – 78X, Y, Z, Z+1, Z+2
• The number of TV channels you can get is different depends
on your local area.
• If the auto tuning is cancelled during scanning, some
channels not yet tuned may not be received.
• Sorting of TV channels from 1 to 6 will be performed
automatically as follows.
1: BBC12: BBC23: ITV
4: CH45: CH56: SKY NEWS
This unit can receive the Hyper and Oscar frequency
bands.
• If you want to decode scrambled signals, select
“Decoder” using [K \ L], then press [1]. Select “ON”
using [K \ L], then press [0].
• If “Skip” is set to “ON”, select “Skip” using [K \ L], then
press [1]. Select “OFF” using [K \ L], then press [0].
• To store another channel, repeat steps
5 to 8.
9 Press [SETUP] to exit.
EN
21
E2TE0BD_EN.book Page 22 Friday, March 5, 2010 4:49 PM
Skip a Preset Channel
ANALOG
You can set the unit to skip channels. You can no longer
receive or watch when you access channels using
[PROG. G\H].
1 Follow steps 1 to 4 in “Manual Tuning
(ANALOG)” on page 21.
2 Select “Position” using [K \ L], then press [1].
3 Select the position number using
[the Number buttons] or [K \ L], then press [0].
4 Select “Skip” using [K \ L], then press [1].
5 Select “ON” using [K \ L], then press [0].
• To skip another channel, repeat steps 2 to 5.
6 Press [SETUP] to exit.
Move
ANALOG
You can replace two channels.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
2 Select “Channel” using [K \ L], then press
[ENTER\OK].
3 Select “ANALOG Channel Setup” using [K \ L],
then press [ENTER\OK].
4 Select “Move” using [K \ L], then press
[ENTER\OK].
5 Select the position number to change the
channel using [K \ L], then press [ENTER\OK].
You cannot select a position number where “– – –”
appears next to the number , because “Skip” is set to “ON”
for that position number.
6 Move the channel to another position number
using [K \ L], then press [ENTER\OK].
• To move another channel, repeat steps 5 to 6.
7 Press [SETUP] to exit.
The tuner scans and memorises all the active DVB
channels (TV / Radio) in your area.
Channel Search
S.No. TV Channel
14
E4
13
More4
32
Film4+1
28
ITV4
75
CITV
34
SETANTA SPORT
Channel 69 UHF 858000KHz/8M
Progress
Exit
OK
S.No. Radio Channel
102
Teletext Cars
729
RadioMusicShop
728
Heart
100%
RETURN
Back
5 Press [ENTER\OK] to exit.
• After auto tuning is completed, the lowest memorised
DVB channels appears on the screen.
• You can use [PROG. G\H] to change the DVB
channels.
Note
• If you press [RETURN\BACK] or [SETUP] during the
scanning, auto tuning will be cancelled.
Manual Tuning (DVB)
DVB
You can preset a DVB channel manually and individually.
1 Follow steps 1 to 3 in “Auto Tuning (DVB)” on
this page.
2 Select “Manual Tuning” using [K \ L], then
press [ENTER\OK].
3 Select your desired position number using
[K \ L], then press [ENTER\OK].
ChannelAuto
• The tuner will begin to search up or down automatically.
When a DVB channel is found, the unit will stop
searching.
• When “Auto” is selected, the unit will search for the
channels which have not been stored in channels
memory.
4 Press [SETUP] to activate the setting.
Auto Tuning (DVB)
DVB
You can programme the tuner to scan only the DVB channels
that you can receive in your area.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
2 Select “Channel” using [K \ L], then press
[ENTER\OK].
3 Select “DVB Channel Setup” using [K \ L], then
press [ENTER\OK].
4 Select “Auto Tuning” using [K \ L], then press
[ENTER\OK].
The unit will start storing channels available in your area.
$6"#HANNEL3ETUP
%DIT#HANNELS
!UTO4UNING
-ANUAL4UNING
3IGNAL)NFORMATION
EN
22
Service Update
DVB
This unit has “Service Update” function which searches and
stores newly availab le digital channels automatically at 8:00. If
a new channel is found, a message will appear on the screen
when you turn on the DVB channel at first time after storing a
new channel. Press any button to clear the message.
E2TE0BD_EN.book Page 23 Friday, March 5, 2010 4:49 PM
TV View Operation
The following operations are available while viewing TV
channels through this unit’s tuner.
Select a Channel
DVBANALOG
To switch DVB, analogue and external input (AV1/AV2/AV3/
DV(AV4)) mode.
Press [INPUT SELECT F] repeatedly to select DVB,
analogue or external input mode.
The mode changes as follows:
DVB modeAnalogue modeExternal input mode
You can select external input mode (AV1/AV2/AV3/DV(AV4))
by pressing [PROG. G\H] repeatedly.
The mode changes as follows:
External input mode (with [PROG. G\H] buttons)
AV1AV2AV3DV(AV4)
You can select a channel using [PROG. G\H] or directly
enter the channel using [the Number buttons].
Notes on using [the Number buttons]:
• For one or two-digit number channels, the channels will be
identified for 2 seconds after you press the channel number.
You can only select channels 1~899 (Digital) or 1~99
(Analogue).
If you cannot get a “Station Name” of Analogue channel, it is
not indicated with a channel number.
Quick Select
DVB
With “Quick Select” menu, you can select your favourite DVB
channel quickly. Refer to “Edit Group Lists” on page 24.
1 Press [ENTER\OK] while watching a DVB
channel.
• “Quick Select” menu will appear.
Quick Select
Group:All
S.No. Channel Name
2 Channel4
3 ITV2
4 ITV3
13 Channel4+1
19 More4
28 ITV4
29 E4
View
OK
RETURN
Exit
2 Press [0 \ 1] to select your favourite group list.
(“All”, “Group 1” - “Group 8”)
• “All” shows a list of all the memorised DVB channels.
• If the favourite group does not have any channels, the
group will be skipped.
You can switch between TV audio modes by pressing
[AUDIO D]. Each mode is indicated on the TV screen.
Audio mode during reception of analogue bilingual
broadcasts:
ModeAudio output
MainMain audio from both speakersMain
SubSub audio from both speakersSub
Main / Sub
• Main audio from the left speaker
• Sub audio from the right speaker
• If the programme does not have more than one sound track,
[AUDIO D] is not effective.
Display on the
TV screen
Main/Sub
EN
23
E2TE0BD_EN.book Page 24 Friday, March 5, 2010 4:49 PM
Edit Channels
DVB
With “Edit Channels” menu, you can sort all the memorised
DVB channels into the group lists (“Quick Select”) or set the
viewer limitation (“Adult Lock”), etc.
1 In stop mode, press [SETUP]. Select “General
Setting” using [K \ L], then press [ENTER\OK].
2 Select “Channel” using [K \ L], then press
[ENTER\OK].
3 Select “DVB Channel Setup” using [K \ L], then
press [ENTER\OK].
4 Select “Edit Channels” using [K \ L], then
press [ENTER\OK].
• “Edit Channels” menu will appear.
2
Edit Channels
S.No. Channel Name
5
1
Five
England Crystal Palac594000kHz/8M
Re NameSkipLockDelete
5
OK
1...8
Move
Add To Fav.
Fav. Skip Lock Del.
2
RETURN
Exit
Del. Fav.
0
3
4
1 Channel number
2 Channel name
3 Channel setting
1 to 8: The number of the favourite group list
: Skip Channels
: Adult Lock
: Delete Channels
4 Channel information
5 Operation Guide
5 Press [RETURN\BACK] to exit.
Edit Group Lists
DVB
You can sort each DVB channel into 8 diff erent fa vourite g roup
lists (“Group 1” - “Group 8”). With “Quick Select” menu, you
can select your fav ourite DVB channel quickly. Refer to “Quick
Select” on page 23.
1 Follow steps 1 to 4 in “Edit Channels” on this
page.
2 Select the DVB channel you want to add to the
favourite group list using [K \ L], then select
the number of the favourite group list you want
to add using [the Number buttons] ([1] - [8]).
Edit Channels
S.No. Channel Name
5
Five
England Crystal Palac594000kHz/8M
Re NameSkipLockDelete
OK
• The number you selected will appear.
•Press [0] to cancel from the favourite group list.
1...8
Move
Add To Fav.
Fav. Skip Lock Del.
2
Exit
RETURN
Del. Fav.
0
3 Press [RETURN\BACK] to exit.
Skip Channels
DVB
You can set the unit to skip the unwanted DVB channels when
you use [PROG. G\H].
1 Follow steps 1 to 4 in “Edit Channels” on this
page.
2 Select the DVB channel y o u want to skip using
[K \ L], then press [GREEN].
Edit Channels
S.No. Channel Name
5
Five
England Crystal Palac594000kHz/8M
Re NameSkipLockDelete
OK
1...8
Move
Add To Fav.
Fav. Skip Lock Del.
RETURN
Exit
Del. Fav.
0
24
• “ ” will appear.
•Press [GREEN] to cancel. “ ” will disappear.
3 Press [RETURN\BACK] to exit.
EN
