E7J70BD_EN.book Page 1 Monday, May 7, 2007 3:31 PM

DVD VIDEO RECORDER

D-R17DTKB

OWNER’S MANUAL

Introduction Connections Basic Setup Playback

OPERATIONS

GUIDE

Recording

Editing

Function Setup

DVD VIDEO RECORDER D-R17DT

Others

E7J70BD_EN.book Page 2 Monday, May 7, 2007 3:31 PM

Introduction

Precautions

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

WARNING

THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The important note is located on the rear of the cabinet.

Laser Safety

This unit employs a laser. Only a qualified service personnel should remove the cover or attempt to service this unit, due to the possibility of eye injury.

CAUTION: USE OF CONTROLS OR

ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER

RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK

MECHANISM.

Caution

1. Do not attempt to open the cabinet. There are no

2. Slots and openings in the cabinet at the sides and

3. Keep the unit away from radiators and other heat

4. Avoid use near strong magnetic fields.

5. Do not push objects of any kind into the unit

6. Do not spill liquid on the unit. If liquid is spilled

Power Supply

The power supply is connected and the unit is live when the mains cable is plugged into a 220–240 V , 50 Hz AC outlet. To operate the unit, press

[ ON / STANDBY].

WARNING: LIVE PARTS INSIDE.

DO NOT REMOVE ANY SCREWS.

7. Do not stand the unit vertically. Use the unit in a

8. Before attempting to operate the unit, make sure

9. This product is in Stand-by mode when turned off

10. Do not place any combustible objects on the

11. Before moving the unit, be sure to remove any

12. Disconnect the mains plug to shut off when find

13. The mains plug shall remain readily operable.

14. Read both manual instructions to ensure correct

15. Keep the distances 20 cm around apparatus of

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

parts inside you can service. Refer all servicing to qualified service personnel.

underneath are provided for ventilation. To ensure reliable operation and to protect the unit from overheating, these openings must not be blocked or covered. Avoid installation in enclosed spaces such as bookcases unless suitable ventilation is provided.

sources.

through the cabinet slots or openings as they could touch electrically live parts or short circuit parts resulting in a fire or electric shock.

and enters the unit, consult qualified service personnel.

horizontal (flat) position only.

that the timer recording mode is off.

while the mains cable is connected.

device (candles, etc.).

discs and unplug the mains cable from the AC outlet.

troubles or not in use.

and safe installation and interconnection of the unit in multimedia systems.

ventilation openings.

E7J70BD_EN.book Page 3 Monday, May 7, 2007 3:31 PM

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

This product consists of materials which can be recycled and reused if disassembled by a specialised company. Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

Make your contribution to the environment!!!

• Exhausted batteries do not belong in the dustbin.

• You can dispose of them at a collection point for exhausted batteries or special waste.

• Contact your council for details.

For Customer Use: Carefully read the Model No. and Serial No. located at the back of the unit and enter the information below. Retain this information for future reference. Model No. _____________________ Serial No. _____________________

Connection to Power

Before Switching on make sure that the voltage of your electricity supply is the same as that indicated on the rating plate.

Mains Cord

This appliance may be fitted with a non-rewireable plug. If it is necessary to change the fuse in a nonrewireable plug the fuse cover must be refitted. If the fuse cover is lost or damaged, the plug must not be used until a replacement available from the appliance manufacturer is obtained. It is important that the colour of the replacement fuse cover corresponds with the rating marking on the base of the plug. If the plug has to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off and an appropriate plug fitted following the wiring instructions below. The plug removed must be disposed of safely as insertion into a 13A socket is likely to cause an electrical hazard. For your own safety read the following instructions carefully before attempting to connect this unit to mains. The wires in this mains lead are coloured in accordance with the following code:

BLUE=NEUTRAL, BROWN=LIVE

Important

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. No connection is to be made to the earth terminal of the plug. If a 13 Amp (BS 1363) Plug is used, a 3 Amp Fuse must be fitted, or if any other type of Plug is used a 3 or 5 Amp Fuse must be fitted, either in the Plug or Adaptor, or on the Distribution Board.

Mains Supply: 220 - 240V 50 Hz - AC only

Do not make any connection to the larger pin marked with the letter “E” or by the symbol or coloured green or green and yellow.

FUSE

BROWN

BLUE

(Neutral)

OUTER SHEATH OF THE WIRE

(Live)

CORD GRIP

Installation Location

For safety and optimum performance of this unit:

• Install the unit in a horizontal and stable position.

• Do not place anything directly on top of the unit.

• Do not place the unit directly on top of the TV.

• Shield the unit from direct sunlight and keep away from sources of intense heat. Avoid dusty or humid locations. Avoid locations with insufficient ventilation for suitable heat dissipation. Do not block the ventilation holes on the sides of the unit. Avoid locations subject to strong vibration or strong magnetic fields.

Avoid the Hazards of Electrical Shock and Fire

• Do not handle the mains cable with wet hands.

• Do not pull on the mains cable to disconnect it from AC outlet. Grasp it by the plug.

• If, by accident, water is spilled on the unit, unplug the mains cable immediately and take the unit to an authorised service centre for servicing.

Moisture Condensation Warning

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, after heating a cold room, or under conditions of high humidity. Do not use the unit for at least 2 hours to allow the inside to dry.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

Others

E7J70BD_EN.book Page 4 Monday, May 7, 2007 3:31 PM

About Copyright

Unauthorised copying, broadcasting, public performance and lending of discs are prohibited. This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorised by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorised by Macrovision. Reverse engineering or disassembly is prohibited.

Notice for the Progressive Scan Outputs

Consumers should note that not all high definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of picture problems with 525 or 625 progressive scan output, it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions regarding your TV set compatibility with this 525p or 625p DVD recorder, please contact our customer service centre.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

Declaration of Conformity

This product complies with the requirement of the directives EMC-Directive: 89 / 336 / EEC Low Voltage Directive: 2006 / 95 / EC

We declare that the following product:

DVD Video Recorder Model D-R17DTKB Trade Name: TOSHIBA

is in compliance with following Regulations.

EN55013: 2001+A1:2003, EN55020: 2002+A1:2003+A2:2005, EN61000-3-2: 2003+A2:2005, EN61000-3-3: 1995 + A1: 2001 EN60065: 2002 EN60825-1 Edition 1.2: 2001

Maintenance

CLEANING THE UNIT

Use a soft cloth slightly moistened with a mild detergent solution. Do not use solutions containing alcohol, spirits, ammonia or abrasive.

Dolby Digital Recording

Digital Recording enables consumers to

“Dolby record high-quality video with stereo sound on recordable DVD discs. The technology, when utilised instead of PCM recording, also saves recordable disc space, allowing for higher video resolution or extended recording time on each DVD. DVDs created using Dolby Digital Recording will play back on all DVD-Video players.” Note: This is true when the players are compatible with actual recordable DVD discs.

“DTS” and “DTS Digital Out” are registered trademarks of DTS, Inc.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

CLEANING DISCS

If a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the centre out. Do not wipe in a circular motion. Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analogue records.

DISC HANDLING

Handle the discs so that fingerprints and dust do not adhere to the disc surfaces. Always store the disc in its protective case when it is not in use.

SERVICING

If the unit becomes inoperative, do not try to correct the problem by yourself. There are no user serviceable parts inside. Turn the unit off, unplug the mains cable, and consult your dealer or an authorised service centre.

CLEANING THE DISC LENS

If the unit does not perform correctly even though you have referred to “Troubleshooting” and the relevant sections in the Owner’s Manual, the laser optical pickup unit may be dirty. Consult your dealer or an authorised service centre for inspection and cleaning of the laser optical pickup unit.

The DVB logo is a registered trademark of the DVB Digital Video Broadcasting Project.

E7J70BD_EN.book Page 5 Monday, May 7, 2007 3:31 PM

Accessories Supplied

• Remote control with two R6 (AA) batteries

OPEN/

INPUT

SELECT

HDMI

.@/: ABC DEF

PROG.

GHI JKL MNO

TIMER

PQRS TUV WXYZ

PROG.

SETUP

SPACE

CLEAR INFO

TEXT

DISC MENU

TOP MENU GUIDE

ENTER /OK

RETURN

DISPLAY

/BACK

PLAY

REV

FWD

SKIPSKIP STOP

1.3x/0.8x

INSTANT

PAUSE

PLAY

SKIP

TIME SLIP

REC REC MODE

ZOOM SAT.LINKREPEAT

AUDIO

SE-R0280

•RF cable

• Owner’s Manual

Owner's Manual

Introduction Connections Basic Setup Playback

• Quick Setup Guide

• Registration card

Recording

Editing

Function Setup

Others

E7J70BD_EN.book Page 6 Monday, May 7, 2007 3:31 PM

Table of Contents

Introduction ............................................ 2

Precautions ........................................................... 2

Features ................................................................ 7

Guide to the Owner’s Manual................................ 8

Functional Overview............................................ 11

Installing Batteries in the Remote Control........... 14

Guide to On-Screen Displays.............................. 15

Front Panel Display Guide .................................. 18

Connections ......................................... 19

Connections ........................................................ 19

Basic Setup........................................... 23

Initial Setting........................................................ 23

Channel Setting................................................... 23

TV View Operation .............................................. 28

DVB Menu Setting............................................... 29

Setting the Clock ................................................. 31

Recording ............................................. 32

Information on DVD Recording ........................... 32

Formatting a Disc ................................................ 33

Selecting the Sound Mode .................................. 36

Basic Recording .................................................. 37

One-Touch Timer Recording (OTR).................... 38

Timer Recording.................................................. 39

EPG..................................................................... 42

Satellite Link........................................................ 42

Settings for External Equipment.......................... 44

Setting a Disc to Protect...................................... 45

Finalising Discs ................................................... 45

Playback ................................................47

Basic Playback .................................................... 47

PBC Function for Video CDs ............................... 52

Special Playback ................................................. 53

Search ................................................................. 57

Repeat / Random / Programme Playback /

Slide Show........................................................... 58

Selecting the Format of Audio and Video ............ 60

Editing ................................................... 62

Disc Editing.......................................................... 62

Editing Discs........................................................ 62

Function Setup .....................................69

Playback .............................................................. 71

Display................................................................. 74

Video ................................................................... 74

................................................................... 75

DivX

HDMI ................................................................... 76

Reset All .............................................................. 77

Others .................................................... 78

Troubleshooting................................................... 78

Language Code ................................................... 82

Glossary .............................................................. 83

Specifications ...................................................... 84

E7J70BD_EN.book Page 7 Monday, May 7, 2007 3:31 PM

Features

This unit not only plays back DVDs and CDs but also offers features for you to record on DVD discs and edit them after that. The following features are offered with this unit.

Recording

The unit is compatible with DVD-RW, DVD+RW discs, which are recordable repeatedly, and DVD-R, DVD+R discs, which are recordable only once.

Recording up to 12 programmes:

You can programme the unit to record up to 12 programmes, up to a month in advance. Daily or weekly programme recordings are also possible.

One-touch Timer Recording:

You can set your required recording time easily. Every time [REC recording time will be increased by 30 minutes up to 8 hours. It will be turned off automatically when the recording time you set is finished.

Left channel stereo recording:

This unit can record the sound of the Left channel monaural input as Left and Right channels automatically (available only for AV3 jacks on the front panel).

Automatic Chapter marker setting:

Chapter markers will be added to recordings as you set them in the Setup menu before starting to record.

Automatic Title menu making (Video, +VR mode only):

The unit creates Title menus automatically when finalising discs.

Automatic Playlist making (VR mode DVD-RW disc only):

The unit creates a Playlist automatically after recording.

Automatic finalising (Video mode DVD-RW/-R, DVD+R disc):

You can finalise discs automatically at the end of the disc space if you set this in the Setup menu.

PDC:

This system assures that the TV programme you wish to record using timer recording will be recorded exactly from beginning to end even if the actual broadcasting time differs. This feature is only available for analogue channels.

Playback

Theatre surround sound:

When the unit is connected to an amplifier or a decoder compatible with Dolby Digital or DTS, you can enjoy theatre-quality surround sound from discs recorded with the surround sound system.

Chasing Playback during Recording and Simultaneous Playback and Recording:

You can play the already recorded part of the current recording or another title during recording.

Pausing a TV broadcast to resume later:

With [TIME SLIP] button, you can virtually pause and resume the liveTV broadcast.

I] is pressed during recording, the

Quick search:

You can easily find the part you want to watch using the search function. Search for a desired point on a disc by title, chapter / track or time.

Playback from Original or a Playlist (VR mode):

You can play back titles using either the Original list or a Playlist.

Virtual Surround System:

You can enjoy stereophonic space through your existing 2 channel stereo system.

Playing back on MP3 / JPEG / DivX

You can enjoy MP3 files which are recorded on CD-RW/-R.

files can also be recorded on DVD-RW/-R and

DivX DVD+RW/+R discs.

files:

Editing

Set / clear chapter markers (Video mode DVD-RW disc only) [ Page 65]

You can easily add chapter markers at every selected time interval in your recordings for easy editing.

Adding or Deleting Chapter Marks Manually

[ Pages 64 - 65] You can add or delete chapter marks.

Creating Titles to a Playlist (VR mode DVD-RW discs only) [ Page 67]

You can create a title to the Playlist.

Deleting Titles [ Page 63] You can delete titles which you do not need anymore.

Deleting a Scene of a Title (VR mode DVD-RW discs only) [ Page 68]

You can delete a specific scene of a title.

Editing title name [ Page 63] You can name titles or change the title name.

Combining Titles (VR mode DVD-RW discs only) [ Page 66] You can combine two titles into a single title.

Dividing Titles (VR mode DVD-RW, DVD+RW discs only) [ Page 66]

You can divide a title into two new titles.

Protecting titles (VR mode DVD-RW disc only):

To avoid accidental editing or erasing of titles, the protect function is useful when set to “ON” in the Original list.

Hiding chapters (+VR mode only):

To keep others from playing back some chapters without permission, you can hide chapters.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

Others

VD+RWW

VD+R

VCD

MP3

JPEG

DivX

E7J70BD_EN.book Page 8 Monday, May 7, 2007 3:31 PM

Compatibility

Playing back discs recorded in Video mode on any regular DVD player:

Discs recorded in Video mode can be played back on regular DVD players, including computer DVD drives compatible with DVD-Video playback. You will need to finalise the discs recorded in Video mode to play back in other DVD players. Although DVD+RW / R discs are playable on other units without finalisation in most cases, it is recommended to finalise in order to stabilise the performance.

* DVD-Video Format (Video mode) is a new format for

recording on DVD-RW/-R discs that was approved by the DVD Forum in 2000. Adoption of this format is optional for manufactures of DVD playback devices and there are DVD-Video players, DVD-ROM drives and other DVD playback devices available that cannot play back DVD-RW/-R discs recorded in the DVD-Video Format.

Others

Progressive scan system:

Unlike conventional interlace scanning, the progressive scan system provides less flickering and images in higher resolution than that of traditional television signals.

HDMI (High-Definition Multimedia Interface)

You can enjoy clearer audio/video output when connecting this unit to a display device with an HDMIcompatible port.

Guide to the Owner’s Manual

Symbols Used in the Owner’s Manual

To show what recording mode or disc type applies to each function, the following symbols appear at the beginning of each operating item.

Symbol Description

DVD-VDVD-V

Video

DVD-RWDVD-RW

DVD-RDVD-R

DDVD+R

DVD+RW

DDVD+R

DVD+R

CDCDCD

VCD

MP3

JPEG

DivX

Available to DVD-Videos

Available to DVD-RW discs in Video mode

Available to DVD-RW discs in VR mode

Available to DVD-R discs in Video mode

Available to DVD+RW discs

Available to DVD+R discs

Available to Audio CDs

Available to Video CDs

Available to CD-RW/-R discs with MP3 files

Available to CD-RW/-R, discs with JPEG files

Available to DVD-RW/-R, DVD+RW/+R

and CD-RW/-R discs with DivX

files

Symbols for Tuner Setting

The following is the description for the symbols for tuner setting used in this manual.

ANALOG : Settings only for the Analogue

DVB : Settings only for the DVB mode

mode

VD+RWW

VD+R

E7J70BD_EN.book Page 9 Monday, May 7, 2007 3:31 PM

Discs for Recording, Playing

Disc Type

Logo

Introduction Connections Basic Setup Playback

DVD-RW DVD-R DVD+RW DVD+R

Format

Icon

Maximum Record Time

Recordable/Playable

Recording Features

Record TV Programmes

Reuse by deleting the current contents

Record 16:9 size pictures

Available Features

Record copy-once programmes

Create chapters at fixed intervals (auto chapter)

Editing Features

Scene Delete

Edit Title Name

Create chapters wherever you like (chapter mark)

Divide a title

Combine titles

Hide chapters

Delete a title

Create a playlist

Protect a title

Versions

Compatibility

Automatically formatted in Video mode

DVD-RDVD-R DDVD+R

480 min (12 cm) 144 min (8 cm)

Ver. 2.0 Ver. 2.0/4× Ver. 2.0/8× Ver. 2.0/16×

Playable on most DVD players. Finalisation necessary. (Title menu will be created)

Can be formatted in VR or Video mode

Video Mode VR Mode

Video

DVD-RWDVD-RW

480 min (12 cm) 144 min (8 cm)

Ver. 1.1,1.2 Ver. 1.1/2× CPRM compatible Ver. 1.2/4× CPRM compatible

Playable on most DVD players. Finalisation necessary. (Title menu will be created)

DVD-RWDVD-RW

480 min (12 cm) 144 min (8 cm)

Playable only on VR mode compatible unit. Finalisation recommended.

✔✔✔✔✔

✔✔ ✔

✔✔✔

✔*

✔✔✔✔✔

Playlist Original

✔✔

✔✔✔✔ ✔ ✔

✔✔ ✔✔

✔ ✔

✔

✔✔✔✔ ✔ ✔

✔

Automatically formatted in +VR mode

DVD+RW DDVD+R

480 min (12 cm) 144 min (8 cm)

1×-4× 1×-16×

Playable on DVD+RW compatible players. Finalisation recommended. (Title menu will be created)

Automatically formatted in +VR mode

DVD+R

480 min (12 cm) 144 min (8 cm)

Playable on most DVD players. Finalisation recommended. (Title menu will be created)

✔✔

✔: Available Gray: Not available

*CPRM compatible disc only.

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot guarantee that product will play every feature of every DVD bearing the DVD logo and/or every CD bearing the CD logo. As one of the creators of DVD technology, Toshiba DVD players are manufactured using the highest standards of quality, and as a result, such incompatibilities are rare.

Recording

Editing

Function Setup

Others

DVD players with are capable of playing DVD-RW recorded in VR mode.

VCD

MP3

JPEG

DivX

E7J70BD_EN.book Page 10 Monday, May 7, 2007 3:31 PM

Discs for Playing

Disc Type

DVD-VIDEO CD-DA Video CD CD-RW CD-R

Logo

Icon

Typ e of

title

Icon

DVD-VDVD-V CDCDCD VCD

Files for Playing

MP3 JPEG DivX

MP3

MP3 JPEG

JPEG DivX

DivX

CD-RW/-R

Media

CD-RW/-R CD-RW/-R

DVD-RW/-R

DVD+RW/+R

is a trademark of DVD Format/Logo Licensing

Corporation.

DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.

• Official DivX

DivX

Certified product; Plays DivX® 6.0,

5, DivX® 4, DivX® 3, and DivX®VOD video content (in compliance with DivX Certified™ technical requirements).

• Discs containing the DivX (Global Motion Compensation) playback feature, which is DivX

supplemental function, cannot be

files with the DivX® GMC

played back on this unit.

* This unit cannot play back the disc contents

protected by Windows Media Digital Rights Management (DRM).

Unplayable Discs

The following discs will not play back on this unit.

• CD-ROM • Compact Disc-Interactive (CD-I)

• Video Single Disc (VSD) • DVD-ROM

• DVD-audio • Unfinalised disc

• DVD contains MP3, Windows Media™ Audio or JPEG files

On the following disc, the sound may not be heard.

• Super audio CD - Only the sound on the CD layer can be heard. The sound on the high-density super audio CD layer cannot be heard.

Colour Systems

DVDs are recorded using different colour systems throughout the world. The most common colour system, used primarily in the U.K. and other EU countries, is PAL. This unit uses the PAL system. However, it is also possible to play back DVDs using other colour systems, such as NTSC.

Region Codes

This unit has been designed to play DVD with region 2. DVD must be labelled for ALL regions or for region 2 in order to play on the unit. You cannot play back DVD that are labelled for other regions. Look for the symbols on the right on your DVD. If these region symbols do not appear on your DVD, you cannot play back the DVD in this unit.

VCD CDCDCD CDCDCD

The number inside the globe refers to region of the world. A DVD labelled for a specific region can only play back on the unit with the same region code.

Following discs are recommended for good recording quality and are proven to be compatible with this unit. However, depending on the media condition the unit may not read the disc properly. Verbatim DVD+R 8x, DVD+RW 4x, DVD-R 8x,

DVD-RW 2x JVC DVD-RW 4x Maxell DVD+R 4x/8x/16x, DVD-R 8x/16x SONY DVD+R 4x/8x/16x, DVD+RW 4x TDK DVD+R 4x/8x/16x Performance of any other discs are not guaranteed.

• Toshiba is not liable for any damage or loss caused directly or indirectly by the malfunction of this recorder, including, without limitation, any one of the following:

• Failure to record contents intended to be recorded by the consumer.

• Failure to edit contents as intended by the consumer.

• When a DVD-RW/-R, DVD+RW/+R disc created on this recorder is used (e.g., insertion, playback, recording or editing) in another DVD player, recorder or personal computer drive.

• When a DVD-RW/-R, DVD+RW/+R disc that is used in the manner described in the immediately preceding bullet point is used again in this recorder.

• When a DVD-RW/-R, DVD+RW/+R disc that was recorded in another DVD recorder, or in a personal computer drive is used in this recorder.

• Some functions may not work with personal computer discs.

• Discs recorded in this recorder may not operate as expected on other DVD players, recorders or personal computer drives.

E7J70BD_EN.book Page 11 Monday, May 7, 2007 3:31 PM

Functional Overview

Front Panel

Introduction Connections Basic Setup Playback

ON/STANDBY

I/y

(*)

The unit can also be turned on by pressing these buttons.

DVD -RW/R +RW/R RECORDING

OPEN/CLOSE

1 ON/STANDBY button

• Press to turn the unit on and off.

• If timer programmings have been set, press to set the unit in timer-standby mode.

2 Disc tray

• Place a disc when the disc tray is opened.

3 A OPEN/CLOSE button*

• Press to open or close the disc tray.

4 Infrared sensor window

• Receive signals from your remote control so that you can control the unit from a distance.

5 H (SKIP) button

• During playback, press once midway through a chapter or track to go back to the beginning of the current chapter or track. When pressed twice in quick succession, playback will start from the preceding chapter or track. During playback, press and hold for 1.5 seconds to fast reverse. When playback is paused, press to play reverse step by step. When playback is paused, press and hold for

1.5 seconds to slow reverse.

6 G (SKIP) button

• During playback, press to skip to the next chapter or track. During playback, press and hold for 1.5 seconds to fast forward. When playback is paused, press to play advance step by step. When playback is paused, press and hold for

1.5 seconds to slow forward.

1080p

1080i 720p 576p/480p

AV3

S-VIDEO VIDEO L R

RECPLAYSTOPSKIP

13* 12

7Display

• Refer to “Front Panel Display Guide” on page 18.

8HDMI indicator

• Lights up and indicates the HDMI output mode when HDMI output is on.

9 AUDIO input jacks (AV3)

• Use to connect external device with a RCA audio cable.

10 VIDEO input jack (AV3)

• Use to connect external device with a RCA video cable.

11 S-VIDEO input jack (AV3)

• Use to connect the S-video output of external device with an S-video cable.

12 I REC button

• Press once to start a recording. Press repeatedly to start one-touch timer recording.

13 B PLAY button*

• Press to start or resume playback.

14 C STOP button

• Press to stop playback or recording.

• Press to stop timer recording.

91011

Recording

Editing

Function Setup

Button names described in the Owner’s Manual

The instructions in this manual are described mainly with the operations using the remote control. Some operations can be carried out using the buttons on the front panel.

Others

E7J70BD_EN.book Page 12 Monday, May 7, 2007 3:31 PM

Rear Panel

COMPONENT

ANALOG

AUDIO OUT

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

HDMI OUT

AV2(DECODER

)

OUT

ANTENNA

PB/CB

PR/CR

ANALOGDVB-T

VIDEO OUTPUT

1 342 5 6 7 9 118 10

1 ANTENNA IN (DVB-T)

• Connect to an antenna or cable to receive DVB-T signal.

2 ANTENNA OUT (DVB-T)

• Connect to the Aerial jack on your TV, cable box or direct broadcast system to output the signal received at ANTENNA IN (DVB-T). Use the supplied RF cable.

3 ANTENNA IN (ANALOG)

• Connect to an antenna or cable to receive analogue signal.

4 ANTENNA OUT (ANALOG)

• Connect to the Aerial jack on your TV, cable box or direct broadcast system to output the signal received at ANTENNA IN (ANALOG). Use the supplied RF cable.

5 COMPONENT VIDEO OUTPUT jacks

• Connect to the component video input jacks on your TV.

• Use a commercially available Component Video cable.

)

AV1(TV

6 ANALOG AUDIO OUT jacks

• Connect to the audio input jacks on your TV. Use a commercially available Audio cable.

7 DIGITAL AUDIO OUTPUT (COAXIAL) jack

• Connect to an amplifier with a digital input jack such as a Dolby Digital decoder, DTS decoder or MPEG decoder. Use a commercially available Coaxial cable.

8 AV2 (DECODER) socket

• Connect to VCR, camcorder, or other Audio-Video equipment. Use a commercially available Scart cable.

9 HDMI OUT jack

• Connect to a display with an HDMI compatible port.

• Use a commercially available HDMI cable.

10 AV1 (TV) socket

• Connect to the Scart socket on your TV. Use a commercially available Scart cable.

11 Mains cable

• Connect to a standard AC outlet.

Note

• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

• This unit does not have an RF modulator.

E7J70BD_EN.book Page 13 Monday, May 7, 2007 3:31 PM

Remote Control

OPEN/

INPUT

CLOSE HDMI

1* 2

4 5

11*

12 13

14 15 16

(*) The unit can also be turned on by pressing these

buttons.

1 OPEN/CLOSE button*

• Press to open or close the disc tray.

2 INPUT SELECT button

• Press to select the DVB, analogue mode or appropriate input.

3 Number buttons

• Press to select channel numbers.

• Press to select a title / chapter / track on the display.

• Press to enter values for settings in the Setup menu.

• Press to enter the characters in edit function.

4 SETUP button

• Press to display the Setup menu in stop mode.

5 DISC MENU button

• Press to display the Disc menu during playback.

• Press to change the Original and Playlist on the TV screen. (VR mode only)

6 TOP MENU button

• Press to display the Title list.

SELECT

.@/ :

ABC DEF

CLEAR INFO

ENTER

/OK

PLAY

AUDIO

PROG.

TIMER

PROG.

TEXT

RETURN /BACK

FWD

SKIPSKIP STOP

INSTANT

SKIP

GHI JKL MNO

PQRS TUV WXYZ

SETUP

SPACE

DISC MENU

TOP MENU GUIDE

DISPLAY

REV

1.3x/0.8x

PAUSE

PLAY

REC REC MODE

TIME SLIP

ZOOM SAT.LINKREPEAT

SE-R0280

17 18

25 26

29 31

30 32

7Direction U / D / L / P buttons

• Press to move the cursor and determine items or settings.

8 DISPLAY button

• Press to display the On-Screen Display.

9 RED/GREEN/YELLOW/BLUE button

• Press to follow the DVB instruction displayed on-screen.

10 REV r button

• During playback, press to fast reverse.

• When playback is paused, press to reverse slowly.

11 PLAY P button*

• Press to start or resume playback.

12 SKIP B button

• During playback, press twice in quick successions to skip to the previous chapter or track.

• When playback is paused, press to play reverse step by step.

13 PAUSE p button

• Press to pause playback or recording.

14 TIME SLIP button

• Press once to start recording the TV programme you are watching. Press again to watch the content being recorded from the beginning while recording continues. (VR mode DVD-RW discs with the recording mode of LP, EP or SLP only)

15 ZOOM button

• During playback, press to enlarge the picture on the screen.

16 REPEAT button

• Press to select the repeat mode.

17 HDMI button

• Press to set the HDMI connector's video signal output mode.

18 ON / STANDBY button

• Press to turn on or off the unit.

• Press to set the unit in timer-standby mode. In the timer-standby mode, press to cancel the mode and to turn on the unit.

19 PROG. / buttons

• Press to change the channel up or down.

20 TIMER PROG. button

• Press to display the timer programme setting menu.

21 INFO button

• Press to display the DVB programme information.

22 CLEAR button

• Press to clear the password once entered.

• Press to cancel the programming for a disc.

• Press to clear the selecting marker number in the marker setup mode.

• Press to clear the programme once entered in the timer recording setting mode.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

Others

E7J70BD_EN.book Page 14 Monday, May 7, 2007 3:31 PM

23 TEXT button

• Press to switch Teletext on or off, or transparent mode.

24 GUIDE button

• Press to call up the EPG list in DVB mode.

25 ENTER/OK button

• Press to acknowledge or approve a menu selection.

26 RETURN/BACK button

• Press to return to the previously displayed menu screen.

27 FWD f button

• During playback, press to fast forward.

• When playback is paused, press to forward slowly.

28 STOP S button

• Press to stop playing back or recording.

29 SKIP F button

• During playback, press to skip to the next chapter or track.

• When playback is paused, press to advance step by step.

30 1.3x/0.8x PLAY button

• During playback, press to playback in a slightly faster/slower speed while keeping the audio quality just as normal playback.

31 INSTANT SKIP button

• During playback, press to skip 30 seconds. (See page 53.)

32 REC I button

• Press once to start a recording.

• Press repeatedly to start a One-touch Timer Recording.

33 REC MODE button

• Press to switch the recording mode.

34 AUDIO button

• For analogue channels when receiving a bilingual broadcast, press to change the audio out setting to “Main”, “Sub” and “Main/Sub”.

• Press to change the bilingual audio source of an external equipment to “Main”, “Sub” or “Main/ Sub”. (Available only when the “External Input Audio” in the Setup menu is set to “Bilingual” in advance.)

• Press to display the audio menu during playback.

• Press to select the sound mode for DVB channels.

35 SAT.LINK button

• Press to call up the Satellite Link setting.

Button names described in the Owner’s Manual

The instructions in this manual are described mainly with the operations using the remote control. Some operations can be carried out using the buttons on the front panel.

Installing Batteries in the Remote Control

Install two R6 (AA) batteries (supplied) into the remote control, carefully match with the polarity indicated inside the battery compartment.

21 3

Caution

• Incorrect use of batteries can result in hazards such as leakage and bursting.

• Do not mix new and old batteries together.

• Do not use different kinds of batteries together.

• Make sure that the plus and minus ends of each battery match the indications inside the battery compartment.

• Remove batteries if the equipment will not be used for a month or more.

• When disposing used batteries, please comply with governmental regulations or the public instructions for environmental protection that apply in your country or area.

• Do not recharge, short-circuit, heat, burn or disassemble batteries.

About the Remote Control

• Make sure there is no obstacle between the remote control and the remote control sensor on the unit.

• Use within the operating range and angle as shown.

DVD VIDEO RECORDER D-R17DT

Within

Remote control

• The maximum operable range as follows:

Line of sight: approximately 7 m Either side of centre: approximately 7 m within

30 degrees

• Remote control operation may become unreliable if the remote control sensor of the unit is being exposed by the strong sunlight or fluorescent light.

• Remote controls for different devices can interfere with each other. Be careful when using remote controls for other equipment located close to the unit.

• Replace the batteries when the operating range of the remote control reduces.

about 7 m

E7J70BD_EN.book Page 15 Monday, May 7, 2007 3:31 PM

Guide to On-Screen Displays

DISPLAY Menu

With a disc inserted into the unit, press [DISPLAY] to display the On-Screen Display. The menu shows information about what is recorded on the disc.

1/ 5 1/ 5

55 66 11

This is an example screen for explanation. Displayed items vary depending on the actual mode.

1 Indicates a disc type and format mode.

2 Indicates a type of titles for VR mode

DVD-RW disc.

3 Indicates a channel number or selected

external input mode.

RW VR ORG

901

SP 1:53

File Name

My File

111

(only when a CD with MP3/JPEG/DivX® files is in playback)

1 Displays title/file name.

Video Info. : 480p / YCbCr Audio Info. : Bitstream

111 33

(only for the images output through the HDMI output)

1 Indicates the resolution of the HDMI

output image. 2 Indicates the HDMI video format. 3 Indicates the HDMI audio format.

• “- - -” will be displayed, when it does not have any

information.

INFO Menu

DVB

Pressing the [INFO ] while you are viewing DVB channels to display the programme information.

<OFF>

Introduction Connections Basic Setup Playback

Recording

6 Each icon means:

: Search

: Audio

: Subtitle

: Angle

: Repeat

: Marker

: Noise Reduction

: Zoom

: Surround

7 Indicates an operation status.

Note

• In some descriptions on this manual, only one disc type is indicated as an example.

Press [DISPLAY] while the On-Screen Display is displayed to display Title Name Information, File Name Information or HDMI Information.

Title Name

My Title

111

(only when DVD+RW/+R, VR mode DVD-RW/-R, or unfinalised Video mode DVD-RW/-R disc is in playback)

Press [INFO ]

<CHANNEL NUMBER and NAME/

Current and Next programme

name/programme start time>

18 : CTV1 00:26

Now: 00:00 KIDS KITCHEN

Next: 01:00 Fish

Multi-Audio Subtitles MHEG 16:9 For info press [INFO]

After 3 seconds, the window will be back to the previous screen.

Press [INFO ]

EPG

Channel: CHILDREN Open time: 00:00-01:00 KIDS KITCHEN It is a cooking competition of under twelve-year-old children. They should cook vegetable, meat or fish. Even then never seen before. Winner will be a chef at famous restaurant in London for one day.

Timer

Press [INFO ], [RETURN/BACK] or [SETUP]

Editing

Function Setup

Others

E7J70BD_EN.book Page 16 Monday, May 7, 2007 3:31 PM

Main Menu

Press [SETUP] to display the main menu. Then use

K / L] to select a menu and press [ENTER/OK] to

[

display the sub menu. These menus provide entries to all main functions of the unit.

Setup

General Setting

Timer Programming

Title List

DVD Menu

DVB Menu

CD Playback Mode

1 General Setting:

To go to General Setting menu.

2 Timer Programming:

To programme a timer recording.

3 Title List:

To call up the title list.

4DVD Menu:

To set up the DVD disc setting.

5 DVB Menu:

To set up the DVB setting.

6 CD Playback Mode:

To set up the CD playback setting.

• “CD Playback Mode” is available only when an audio CD, a video CD, a CD-RW/-R with MP3 / JPEG / DivX

General Setting Menu

files is inserted into the unit.

General Setting

1 2

Playback Display

Video

Recording Clock

Channel

DivX HDMI

Reset All

8 9

7DivX:

To set up the setting for the DivX® playback.

8HDMI:

To set up the HDMI connection setting.

9 Reset All:

To reset the setting to the factory default.

DVB Menu

Adult Lock

Language Service Preference

About

Reset All

1 Adult Lock:

To set up the PINCODE for Adult Lock.

2 Language:

To set up the Language for audio subtitle and digital Teletext for DVB.

3 Service Preference:

To set whether you receive the Teletext or Subtitle information from the DVB.

4 About:

To check the current DVB system software version of this unit.

5 Reset All:

To reset the DVB Menu setting to default.

DVD Menu / CD Playback Mode

DVD Menu

Format

Finalise Disc Protect OFF ON

Delete All Playlists

1 Playback:

To set up the unit to play discs as you prefer.

2Display:

To set up the OSD screen as you prefer.

3Video:

To set up the video setting.

4 Recording:

To set up the unit to record to discs as you prefer.

5Clock:

To set up the clock of the unit as you need.

6Channel:

To adjust the channel setting of the unit as you prefer.

CD Playback Mode

Random Play

Program Play PBC (Video CD only)

Slide Show

1 Format (DVD-RW, DVD+RW only):

Allows you to format the disc.

2 Finalise:

Allows you to finalise a disc containing recorded titles.

E7J70BD_EN.book Page 17 Monday, May 7, 2007 3:31 PM

3 Disc Protect (VR mode DVD-RW,

DVD+RW/+R disc only):

Allows you to protect a disc from accidental editing or recording.

4 Delete All Playlists (VR mode DVD-RW

disc only):

Allows you to delete Playlist.

5Random Play:

Allows you to activate the random playback feature.

6 Program Play (audio CD/video CD only):

Allows you to activate the programme playback feature.

7 PBC (Video CD only):

Allows you to select images or information on the menu screen by activating PBC (playback control) function.

8 Slide Show (JPEG files only):

Allows you to select the display time of the slide show mode.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

Others

E7J70BD_EN.book Page 18 Monday, May 7, 2007 3:31 PM

Front Panel Display Guide

1 Current status of the unit

p : Appears when disc playback is paused.

Appears also during step by step playback.

B : Appears when playing back a disc.

: Appears during slow forward playback.

: Appears when the timer programming or

One-touch Timer Recording (OTR) is set and is operating. Appears when the unit goes into the Satellite Link standby mode. Flashes when all the timer programmes are finished. Flashes when there is an error in programming.

I: Appears when recording.

Flashes when recording being paused.

: Appears when a disc is in this unit.

Display Messages

The disc tray is opening.

The PBC function of the Video CD is activated.

The disc tray is closing.

2 Title / Track and Chapter number

: Title / track number : Chapter number

3 Displays the following

• Playing back time

• Current title / chapter / track number

• Recording time / remaining time

•Clock

• Channel number

• One-touch Timer Recording (OTR) remaining time

A disc is loading.

Data is being recorded on a disc.

O O

N P

E7J70BD_EN.book Page 19 Monday, May 7, 2007 3:31 PM

Connections

Connecting to a TV

Connect the unit to a TV after considering the capabilities of your existing equipment.

Before installation, plug off your TV and this unit. Using the Scart socket

1 Make a connection for the TV signal.

Depending on the TV signal’s situation, choose one of following methods (A-C).

A: Receiving DVB-T signal:

If you are in a area that DVB-T signals are available, connect the antenna or cable to the ANTENNA IN (DVB-T) jack of this unit, then connect the ANTENNA OUT (DVB-T) jack of this unit to the Aerial jack of your TV. Use the supplied RF cable.

Cable Signal

Antenna

RF cable (not supplied)

Antenna

RF cable (not supplied)

RF cable (supplied)

To Aerial jack of your TV

RF cable (supplied)

To Aerial jack of your TV

Cable Signal

B: Receiving ANALOG signal:

If you are in a area that DVB-T signals are not available, connect the antenna or cable to the ANTENNA IN (ANALOG) jack of this unit, then connect the ANTENNA OUT (ANALOG) jack of this unit to the Aerial jack of your TV. Use the supplied RF cable.

OUT

ANTENNA

OUT

ANTENNA

ANALOGDVB-T

Introduction Connections Basic Setup Playback

C: Receiving both DVB-T and ANALOG signal:

If you need to receive both DVB-T and ANALOG signal (for hotels that send out cable and DVB-T signals together etc.), connect the antenna or cable to the ANTENNA IN (DVB-T) jack of this unit, and connect the ANTENNA OUT (DVB-T) jack to the ANTENNA IN (ANALOG) jack of this unit, then connect the ANTENNA OUT (ANALOG) jack to the Aerial jack of your TV.

Antenna

Cable Signal

RF cable (not supplied)

PB/C

PR/C

OUT

ANALOGDVB-T

ANAL

COMPONENT

AUDIO

VIDEO OUTPUT

ANTENNA

RF cable

Recording

(supplied)

To Aerial jack of your TV

2 After you made a connection for the

TV signal, connect AV1 (TV) Scart socket of this unit to the Scart

PB/C

PR/C

ANALOGDVB-T

ANAL

COMPONENT

AUDIO

VIDEO OUTPUT

PB/CB

PR/CR

ANAL

COMPONENT

AUDIO

VIDEO OUTPUT

socket of your TV. Use a commercially available Scart cable.

Audio/Video cable (not supplied)

Scart/RCA

cable

(not supplied)

Scart adaptor (not supplied)

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

HDMI OUT

)

AV2(DECODER

ANALOG

T UT

AUDIO OUT

)

AV1(TV

Note

• If your TV does not have a Scart socket, use a commercially available Scart adaptor or Scart/RCA cable to connect.

• Connect this unit directly to the TV. If the AV cables are connected to a VCR, pictures may be distorted due to the copy protection system.

• When changing the “Video Out” setting (“SCART (RGB)”, “Component Interlace (I)” or “Component Progressive (P)”), connect to the corresponding jack on the TV. If the setting is changed, for example, to “Component Interlace (I)” or “Component Progressive (P)” while the scart cable is connected to the TV, a distorted video signal may be output.

Scart cable (not supplied)

Editing

Function Setup

Others

E7J70BD_EN.book Page 20 Monday, May 7, 2007 3:31 PM

Selecting Progressive Scan (576p/480p or Interlaced 576i/480i) Playback

• If your TV is compatible with progressive scanning (576p/480p), connect the TV to the COMPONENT VIDEO OUTPUT jacks of this unit and set “Video Out” setting to “Component Progressive (P)” in the setup menu. (See page 74.) Next, set your TV to the progressive scan mode.

• If your TV is not compatible with progressive scan, set “Video Out” setting to “Component Interlace (I)”.

• Use a commercially available adaptor if the Video input jacks of your TVs or monitors are the BNC type.

Using the COMPONENT VIDEO OUTPUT jacks and the ANALOG AUDIO OUT jacks

If your TV has Component Video input jacks, use a Component Video cable, and an Audio Cable (to connect the ANALOG AUDIO OUT jacks).

• Component connection provides the better quality picture.

1 Follow step 1 to 2 on page 19. 2 Connect COMPONENT VIDEO

OUTPUT jacks of this unit to the Component Video input jacks of your TV. Use a commercially available Component video cable.

3 Connect the AUDIO OUT jacks of this

unit to the analogue Audio input jacks of your TV. Use a commercially available Audio cable.

Component

Video IN

YPB/CBPR/C

OUT

ANTENNA

ANALOGDVB-T

Audio cable (not supplied)

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

PB/CB

PR/CR

ANALOG

COMPONENT

AUDIO OUT

VIDEO OUTPUT

AV2(DECODER

Component Video Cable (not supplied)

• After you have made the connections, set the “Video Out” setting. (See page 74.)

Note for a TV with no Scart socket:

• This unit has no RF modulator, so this type of TV cannot be used.

• Only component and HDMI connections are compatible with the Progressive Scan.

AUDIO IN

HDMI OUT

)

Connection to a TV with an HDMI Compatible Port

[HDMI CONNECTION]

A simple 1-cable connection with a device having an HDMI (high-definition multimedia interface) connector allows digital transfer of the digital images of DVD-video and other devices. This is the best method to connect this unit. It can minimise the deterioration of image quality. Use the HDMI cable (commercially available) for connection. Connect the HDMI output jack of this unit to the HDMI input jack of TV.

HDMI cable (not supplied)

To HDMI input jack

HDMI OUT

this unit

Selecting HDMI mode

Press [HDMI] to select the HDMI output mode. The output mode changes as follows every time [HDMI] is pressed. 576p (PAL)/480p (NTSC) → 720p → 1080i → 1080p (The HDMI mode that is not supported by display device will be skipped.)

Actual Output Modes by Media

Audio recording format of the disc

Dolby

Digital

LPCM

Dolby Digital

MP3 / MP2

DVD-video

DivX

For audio CD, video CD and MP3 files, 2 channel PCM will be output regardless of the “Dolby Digital” setting.

AV1(T

If the connected device is not compatible with HDMI BITSTREAM, audio will be output as PCM even if you select “Stream” in “Dolby Digital” setting (Refer to pages 71-72).

To play back the digital video images of a DVD via an HDMI connection, it is necessary that both the player and the display device (or an AV amplifier) support a copyright protection system called HDCP (highbandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of your display device (or AV amplifier) for more information.

*HDMI: High Definition Multimedia Interface

Dolby Digital setting of this unit

PCM 2channel PCM Stream Dolby Digital PCM Stream PCM 2channel PCM Stream Dolby Digital PCM Stream

HDMI IN

Actual output

2channel PCM

E7J70BD_EN.book Page 21 Monday, May 7, 2007 3:31 PM

Note

• Because HDMI is an evolving technology, it is possible that some devices with an HDMI input may not operate properly with this unit.

• When using an HDCP-incompatible display device, the image will not be viewed properly.

• Among the devices that support HDMI, some devices can control other devices via the HDMI connector; however, this unit cannot be controlled by another device vice the HDMI connector.

• The audio signals from the HDMI connector (including the sampling frequency, the number of channels and bit length) maybe limited by the device that is connected.

• Among the monitors that support HDMI, some do not support audio output (for example, projectors). In connections with device such as this unit, audio signals are not output from the HDMI output connector.

• When this unit’s HDMI connector is connected to a DVI-D compatible monitor (HDCP compatible) with an HDMI-DVI converter cable, the signals are output in digital RGB.

• If the connected equipment is not compatible with HDMI BITSTREAM, DTS sound will not be output.

• When the power failure occurs, or when you unplug the unit, some problems in the HDMI setting might occur. Please check and set the HDMI setting again.

Connecting to External Equipment

This unit has three input terminals, AV1 or AV2 on the rear panel and AV3 on the front panel. Be sure that all the units are off before making connections.

Recording from a DVD player, Satellite Box or other Audio-Video equipment with a Scart output socket (AV2)

AV output jack (Scart)

Scart cable (not supplied)

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

PB/CB

PR/CR

ANALOGDVB-T

ANALOG

COMPONENT

AUDIO OUT

VIDEO OUTPUT

ANTENNA

OUT

Note

• When you record a TV programme from a Satellite Box, you must connect a Scart cable to AV2(DECODER). (See page 42.)

• When AV2 is connected, the signal from the AV2 will be output automatically. If you want to monitor the signal from other input, you must press [DISPLAY] first. Then, select the desired input to monitor with

[INPUT SELECT ].

AV2 (DECODER)

HDMI OUT

)

AV2(DECODER

)

AV1(TV

Introduction Connections Basic Setup Playback

Recording

Recording from a camcorder or other Audio-Video equipment with no Scart output socket (AV3)

If no S-Video input jack is available, connect to VIDEO input jack on the front panel using an RCA Video cable. Change the setup when using S-VIDEO input jack. (See page 44.)

AV3 ( F r o n t )

1080p

1080i 720p 576p/480p

RECPLAYSTOP

AV3

S-VIDEO VIDEO L R

S-Video cable (not supplied)

S-VIDEO

OUT

Audio cable (not supplied)

AUDIO

OUT

Editing

Function Setup

Others

E7J70BD_EN.book Page 22 Monday, May 7, 2007 3:31 PM

Digital Audio for Better Sound Quality

Dolby Digital decoder, DTS decoder or MPEG decoder, etc.

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

PB/CB

PR/CR

ANALOGDVB-T

COMPONENT VIDEO OUTPUT

ANALOG

AUDIO OUT

HDMI OUT

AV2(DECODER

)

ANTENNA

OUT

The connections illustrated above are optional for better sound.

Digital audio

input jacks

Coaxial cable (not supplied)

)

AV1(TV

COAXIAL

1 For clear digital sound quality, use

the DIGITAL AUDIO OUTPUT (COAXIAL) jack to connect your digital audio equipment.

If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

After You Have Completed Connections

Switch the input selector on your TV to an appropriate external input channel. For details, refer to the Owner’s Manual of your TV.

Note

• Connect this unit directly to the TV. If the AV cables are connected to a VCR, pictures may be distorted due to the effects of the copy protection system.

Connecting a Dolby Digital™ decoder, DTS decoder or MPEG decoder

• Connecting multi-channel Dolby Digital decoder allows you to enjoy the Multi-channel Dolby Digital surround system as well as DTS decoder, Multichannel surround system.

• After connecting to a Dolby Digital decoder, set “Dolby Digital” to “Stream” in the Audio out menu. (See page 72.)

• After connecting to a DTS decoder, set “DTS” to “ON” in the Audio out menu. (See page 72.)

• After connecting to a MPEG decoder, set “MPEG” to “Stream” in the Audio out menu. (See page 72.)

Connecting to an MD deck or DAT deck

• The audio source recorded in Dolby Digital Multichannel surround format cannot be recorded using an MD or DAT deck as a digital sound.

• If not connected to a Dolby Digital decoder, set “Dolby Digital” to “PCM” in the Audio out menu. Playing back a DVD using incorrect settings may generate noise distortion and damage speakers.

• Set “Dolby Digital” and “MPEG” to “PCM” and set “DTS” to “OFF” in the Audio out menu for connecting to an MD or DAT deck.

• You can use ANALOG AUDIO OUT jacks for the connection of your audio system.

E7J70BD_EN.book Page 23 Monday, May 7, 2007 3:31 PM

Basic Setup

Introduction Connections Basic Setup Playback

Initial Setting

Turn on this unit for the first time, you need to follow these steps.

1 Press [ ON / STANDBY]. 2 Turn the TV on. Select the input to

which the unit is connected.

3 Select your desired channel preset

type using [U / D]. Then press [ENTER/OK].

Initial Setting

Auto Tuning

Make sure the antenna is connected to “ANTENNA IN” jack.

Digital tuning

Digital & Analog tuning

Analog tuning

The unit will start getting channels available in your area.

Digital tuning:

Only the DVB channels receivable in your area are automatically scanned and memorised.

Digital & Analog tuning:

Both analogue and DVB channels receivable in your area are scanned and memorised automatically.

Analog tuning:

Only the analogue channels receivable in your area are automatically scanned and memorised.

4 After finished channel setting,

“Clock Setting” will appear. Then press [ENTER/OK].

Initial Setting

Clock Setting

01 / 01 / 2007 (MON)

• If you want to adjust the clock, follow to step 4 on page 31 in “Manual Clock Setting”.

10:00

5 Press [ENTER/OK] to exit.

Channel Setting

Tuning of this unit to broadcast channels can be performed in two ways.

Auto Tuning (DVB & ANALOG)

Programme the tuner to scan both analogue and DVB channels you can receive in your area.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

General Setting Menu will appear.

2 Select “Channel” using [U / D], then

press [ENTER/OK].

3 Select “Auto Tuning (DVB &

ANALOG)” using [U / D], then press [ENTER/OK].

The unit will start storing channels available in your area.

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Wait for several minutes to finish channel storing.

• Analogue channels will be stored in channel 901-999 after it is scanned by this unit.

Auto Tuning (DVB & ANALOG) DVB Channel Setup ANALOG Channel Setup

4 Press [SETUP] to exit.

You can select the channels memorised only in this unit by using [PROG. / ].

To cancel auto tuning Press [RETURN/BACK] or [SETUP] during scanning.

Note

• The selection will be affected by how you receive TV channels in your local area.

• If the auto tuning is cancelled during scanning, some channels not yet tuned may not be received.

• You cannot change the channel when DVD is in any recording mode (normal recording, One-touch Timer Recording or timer recording).

Recording

Editing

Function Setup

Others

E7J70BD_EN.book Page 24 Monday, May 7, 2007 3:31 PM

Auto Tuning (ANALOG)

ANALOG

Programme the tuner to scan only the channels you can receive in your area.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

General Setting Menu will appear.

2 Select “Channel” using [U / D], then

press [ENTER/OK].

3 Select “ANALOG Channel Setup”

using [U / D], then press [ENTER/OK].

4 Select “Auto Tuning” using [U / D],

then press [ENTER/OK].

The unit will start storing channels available in your area.

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Tuning (DVB & ANALOG) DVB Channel Setup ANALOG Channel Setup

ANALOG Channel Setup

Auto Tuning Manual Tuning Move

Manual Tuning (ANALOG)

ANALOG

You can preset an analogue channel manually and individually.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Channel” using [U / D], then

press [ENTER/OK].

3 Select “ANALOG Channel Setup”

using [U / D], then press [ENTER/OK].

4 Select “Manual Tuning” using

[U / D], then press [ENTER/OK].

5 Select “Position” using [U / D], then

press [P].

Manual Tuning

Position

Channel

Decoder

Skip

901

OFF

Wait for several minutes to finish channel storing.

• Analogue channels will be stored in channel 901-999 after it is scanned by this unit.

5 Press [SETUP] to exit.

You can select only the channels memorised in this unit by using [PROG. / ].

To cancel auto tuning Press [RETURN/BACK] or [SETUP] during scanning.

Note

• The selection will be affected by how you receive TV channels in your local area.

• If the auto tuning is cancelled during scanning, some channels not yet tuned may not be received.

• You cannot change the channel when DVD is in any recording mode (normal recording, One-touch Timer Recording or timer recording).

6 Select the position number you wish

to use using [the Number buttons] or [U / D], then press [L].

• You can select position number 901-999.

•With [the Number buttons], you only need to

enter the last 2 digit numbers.

7 Select “Channel” using [U / D], then

press [P].

8 Press [U / D] to start scanning.

• The tuner will begin to search up or down automatically. When a channel is found, the unit will stop searching and the picture will appear on the TV screen.

• You can select a desired channel number using [the Number buttons]. Refer to the following Channel Plan table and press the three digits to select the channel number. (To select channel 4, press [0] first and then press [0] and [4]. Or press [4] and then “– – 4” appears and wait for 2 seconds.)

• If this is the channel you want, press [L].

Channel Plan

CH Indication TV Channel

01 – 10 IRA-IRJ, GAP 21 – 69 E21 – E69 74 – 78 X, Y, Z, Z+1, Z+2

80 – 99, 100 S1 – S20, GAP

121 – 141 S21 – S41

E7J70BD_EN.book Page 25 Monday, May 7, 2007 3:31 PM

This unit can receive the Hyper and Oscar frequency bands.

• If “Skip” is set to “ON”, select “Skip” using

[U / D], then press [P]. Select “OFF” using [U / D], then press [L].

• If you want to decode scrambled signals, select

“Decoder” using [U / D], then press [P]. Select “ON” using [U / D], then press [L].

• To store another channel, repeat steps 5 to 8.

9 After completion, press [SETUP] to

exit.

To Skip a Preset Channel

ANALOG

You can set the unit to skip channels you can no longer receive or seldom watch when you access channels using [PROG. / ].

1 Follow steps 1 to 4 in “Manual

Tuning (ANALOG)” on page 24.

2 Select “Position” using [U / D], then

press [P].

3 Select the position number you wish

to skip using [the Number buttons] or [U / D], then press [L].

4 Select “Skip” using [U / D], then

press [P].

5 Select “ON” using [U / D], then

press [L].

• To skip another channel, repeat steps 2 to 5.

6 Press [SETUP] to exit.

6 Move the channel to another

position number using [U / D], then press [ENTER/OK].

• To move another channel, repeat steps 4 to 6.

7 Press [SETUP] to exit.

Auto Tuning (DVB)

DVB

You can programme the tuner to scan only the DVB channels that you can receive in your area.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

General Setting Menu will appear.

2 Select “Channel” using [U / D], then

press [ENTER/OK].

3 Select “DVB Channel Setup” using

[U / D], then press [ENTER/OK].

4 Select “Auto Tuning” using [U / D],

then press [ENTER/OK].

The unit will start storing channels available in your area.

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Tuning (DVB & ANALOG) DVB Channel Setup ANALOG Channel Setup

DVB Channel Setup

Edit Channels Auto Tuning Manual Tuning Signal Information

Introduction Connections Basic Setup Playback

Recording

Move

ANALOG

You can replace two channels.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Channel” using [U / D], then

press [ENTER/OK].

3 Select “ANALOG Channel Setup”

using [U / D], then press [ENTER/OK].

4 Select “Move” using [U / D], then

press [ENTER/OK].

5 Select the position number of which

you want to change the channel using [U / D], then press [ENTER/OK].

You cannot select a position number where “– – –” appears next to the number, because “Skip” is set to “ON” for that position number.

The tuner scans and memorise all the active DVB channels in your area.

CHANNEL SEARCH

CHANNEL 22 – 482 MHz

TV 13 RADIO 0

Channel1 Channel2 Channel3 Channel4 Channel5 Channel6 Channel7 Channel8

BACK

•Press [GREEN] after Auto Tuning is completed,

then the lowest memorised DVB channel appears on the screen, and you can use [PROG. / ] for the memorised DVB channels.

• If you press [RETURN/BACK] or [RED] during

the scanning, the screen will return to the previously displayed menu, and Auto Tuning will be cancelled.

• If you press [SETUP] during the scanning, this

operation will stop and the lowest memorised DVB channel will appear on the TV screen.

Editing

Function Setup

Others

23_31_BasicSetup_EN.fm Page 26 Tuesday, July 17, 2007 1:14 PM

Manual Tuning (DVB)

DVB

You can preset a DVB channel manually and individually.

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Manual Tuning” using

[U / D], then press [ENTER/OK].

3 Select your desired position number

using [U / D], then press

[ENTER/OK].

Manual Tuning (DVB)

Channel Auto

To switch DVB, analogue and external input (AV1/ AV2 / AV 3 ) mode.

You can switch between DVB, analogue and external input (AV1/AV2/AV3) mode by pressing [INPUT SELECT ] repeatedly. The mode changes as follows:

DVB mode Analogue mode AV 1 AV2 AV3

• You can also switch the mode by using [PROG. / ].

• You cannot select any DVB channels using [the Number buttons] when you are in analogue or external input (AV1/AV2/AV3) mode.

• You cannot select any analogue channels using [the Number buttons] when you are in DVB mode.

Edit Channels

With the EDIT CHANNELS screen, you can see all memorised DVB channels, create favourite lists, and set the viewer limitation to channels (Adult lock). To display EDIT CHANNELS screen, after following steps 1 to 3 in “Auto Tuning (DVB)” select “Edit Channels” using [U / D], then press [ENTER/OK].

• The tuner will begin to search up or down automatically. When a DVB channel is found, the unit will stop searching.

• When “Auto” is selected the unit will search for the channels which have not been stored in channels memory.

4 Press [GREEN] to activate the

setting.

To Select a Channel

You can select memorised channels by using [PROG. / ]. For DVB channels you can use the favourite lists (TV1-TV4) to loop channels only within the favourite list. (See “TV Title List” on page 27.) You can select a channel using [PROG. / ], or directly enter the channel using [the Number buttons] on the remote control.

Notes on using [the Number buttons]:

• For one or two digit number channels, the channels will be identified 2 seconds after you press the channel number, or right after you press [ENTER/OK]. For example, if you want to select channel 6, press [6] and wait for 2 seconds or press [ENTER/OK]. You can only select channels 1 to

999.

• Analogue channels will be stored in channel 901999 and DVB channels will be stored in channel 1900 after it is scanned by this unit.

Guide to EDIT CHANNELS screen

EDIT CHANNELS

# NAME 1 2 3 4

1 Channel1 2 Channel2 3 L Channel3

Channel4 5 Channel5 6 L Channel6 7 Channel7 8 Channel8

12 4 13 1

TV LIST ADULT LOCK

2 3 54

1 Channel numbers. 2 Appears when the channel is locked for the

Adult Lock.

3 Channel names. 4 Type of displayed TV title list. 5 Indicates the registered favourite list number

for the channels.

The EDIT CHANNELS screen consist of list of the all memorised DVB channels (TV LIST), and four favourite lists (TV1 - TV4). You can switch between those channels by pressing [GREEN] repeatedly.

CH List (TV List)

Favourite List (TV 1)

Favourite List (TV 2)

Favourite List (TV 3)

Favourite List (TV 4)

• If the favourite list does not have any channels, the list will be skipped.

• If there are more than one page of the CH List (TV List) or the favourite list (TV1 -TV4), you can turn the pages by using [L / P].

Note

• You cannot select “Edit Channels” when you are in analogue, or external input (AV1/AV2/AV3) mode.

• If you execute the Auto Tuning for DVB channels, the setting in the EDIT CHANNELS screen will be cleared.

E7J70BD_EN.book Page 27 Monday, May 7, 2007 3:31 PM

TV Title List

DVB

You can create 4 different favourite lists (TV1 - TV4) with your preferred DVB channels and radio stations. By setting the certain favourite list, you can loop channels only within the list when you use [PROG. / ].

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Edit Channels” using

[U / D], then press [ENTER/OK].

3 Select the DVB channel you want to

add to the favourite list using [U / D], then select the number of the favourite list you want to add to using [the Number buttons] (1, 2, 3, or 4).

• To add another channels to the favourite list, repeat steps 3.

To delete from the favourite lists:

• Select the DVB channels you want to delete from the favourite lists using [U / D] then select the number of the favourite list you want to delete from using [the Number buttons] (1, 2, 3 or 4).

4 Press [SETUP] or [RETURN/BACK]

to exit.

To set the favourite lists:

• At the step 3, press [GREEN] repeatedly to select the list you want to set, then press [SETUP] or [RETURN/BACK] to exit.

4 Select the position you want to move

the channel to using [U / D], then press [YELLOW].

• To move another channel, repeat steps 3 to 4.

5 Press [SETUP] to exit.

Note

• This function is available for only favourite lists (TV1-TV4).

Adult Lock

DVB

You can select DVB channels and radio stations to prevent access to it.

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Edit Channels” using

[U / D], then press [ENTER/OK].

3 Select the DVB channel you want to

limit the access to using [U / D], then press [BLUE].

• “L” is displayed on the left side of the channel name when the channel is locked.

• To unlock the channel, select locked channel, then press [BLUE].

4 Press [SETUP] to exit.

• After you turn off the unit once, a PINCODE will be required to view the channels.

• To set the PINCODE, refer to “PINCODE Setting for Adult Lock” on page 29.

Introduction Connections Basic Setup Playback

Recording

EDIT CHANNELS

# NAME 1 2 3 4

1 Channel1 2 Channel2 3 Channel3

Note

• Empty favourite lists will be skipped when you

switch between the lists by pressing [GREEN].

1 2 4 1 3 1

TV1 ADULT LOCK

Changing the Channel Order of the Favourite List

DVB

You can change the order of the channels in favourite list.

1 Follow the steps 1 to 2 in the “TV

Title List”.

2 Select a favourite list (TV1-TV4) by

pressing [GREEN] repeatedly.

3 Select the DVB channel you want to

move using [U / D], then press [YELLOW].

Signal Information

DVB

You can check the detailed information of the current DVB channel.

1 Follow steps 1 to 3 in “Auto Tuning

(DVB)” on page 25.

2 Select “Signal Information” using

[U / D], then press [ENTER/OK].

• Signal Information display will appear.

SIGNAL INFORMATION

CHANNEL Channel1 NETWORK NAME NETWORK1 FREQUENCY CHANNEL 22, 428.000MHz SYMBOL RATE 8K 64QAM R2/3 G1/32 BIT ERROR RATE < E-8 SERVICE ID 8261 VIDEO PID 520

QUALITY 85% SIGNAL STRENGTH 40%

AUDIO PID 521

3 Press [SETUP] to exit.

Note

• “Signal Information” is not available for analogue channel and external input (AV1/AV2/AV3).

• “Signal Information” is also not available while the PINCODE input field for locked DVB channel is displayed.

Editing

Function Setup

Others

23_31_BasicSetup_EN.fm Page 28 Friday, July 13, 2007 5:24 PM

TV View Operation

The following operations are available while viewing TV channels through this unit’s tuner.

Selecting the Audio Mode

You can switch between TV audio modes by pressing [AUDIO ] on the remote control. Each mode is indicated on the TV screen.

• During reception of analogue bilingual broadcasts

Mode Audio output

Main

Sub

Main / Sub

• During the reception of DVB broadcast, when you press [AUDIO ], sound track display will appear. Press [AUDIO ] repeatedly to change the sound track.

• If the programme does not have more than one sound track, [AUDIO ] is not effective.

Main audio from both speakers

Sub audio from both speakers

• Main audio from the left speaker

• Sub audio from the right speaker

Selecting the TV Aspect Ratio

You can select the TV aspect ratio to match the format of the programme you are playing back with the unit and that of your TV screen (4:3 standard or 16:9 wide screen TV).

Display on the

TV screen

Main

Sub

Main / Sub

4 Select the desired option using

[U / D], then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

TV Aspect

4:3 Letter Box 4:3 Pan & Scan 16:9 Wide

TV Aspect Select Video Video Out

5 Press [SETUP] to exit.

Hint

If you have a standard TV:

• Select “4:3 Letter Box” for a full width picture with black bars at the top and bottom.

• Select “4:3 Pan & Scan” for a full height picture with both sides trimmed.

If you have a wide screen TV:

• Select “16:9 Wide”.

Digital Teletext Reception

DVB

Many broadcasters provide a DVB Teletext service in the form of a dedicated Teletext channel. This Digital service includes high quality text and graphics along with advanced navigation options.

• Make sure “Service Preference” is set to “Data Service”. (See page 30.)

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Video” using [U / D], then

press [ENTER/OK].

3 Select “TV Aspect” using [U / D],

then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

TV Aspect Select Video Video Out

1 Press [TEXT] to display Teletext

screen.

• Teletext for the TV channel you have selected will be displayed.

2 Use [RED] / [GREEN] / [YELLOW] /

[BLUE] to follow the instructions on screen.

3 Press [TEXT] to switch the Teletext

display off.

Note

• To use DVB Teletext, you must set “Service Preference” to “Data Service”. (See page 30.)

• To set the Teletext language, refer to “Language Setting” on page 30.

E7J70BD_EN.book Page 29 Monday, May 7, 2007 3:31 PM

EPG (Electronic Programme Guide)

DVB

Electronic programme guide (EPG) gives you a list of DVB programmes and detailed information about the programmes. To call up EPG (Electronic Programme Guide), while viewing DVB/analogue channel or external input (AV1/AV2/AV3), press [GUIDE]. You can also call up EPG by following steps.

1 In stop mode, press [SETUP]. Select

“Timer Programming” using [U / D], then press [ENTER/OK].

Introduction Connections Basic Setup Playback

DVB Menu Setting

You can make settings of the digital tuner from the DVB Menu.

PINCODE Setting for Adult Lock

DVB

You can select Adult Lock ON or OFF and also change PINCODE.

1 In stop mode, press [SETUP].

2 Select “EPG” using [U / D], then

press [ENTER/OK].

• Select the TV programme using [U / D], then press

the [ENTER/OK] to watch the selected channel or press [BLUE] to display time schedule of the DVB channel.

• From the EPG screen, you can also set the timer recording. Refer to “Timer Recording (EPG)” on page 42.

Subtitle

DVB

Many DVB channels transmit Subtitle information along with their DVB channels. With this unit, you can retrieve and display it on the screen.

• Make sure “Service Preference” is set to “Subtitle”. (See page 30.)

1 While viewing DVB channels, press

[DISPLAY].

2 Select the icon using [L / P],

then press [ENTER/OK] within 1 second, or wait for 1 second to display the selection menu.

3 Select “On” using [U / D], then

press [ENTER/OK].

Subtitle will be displayed, and if you select “Off” the subtitle will disappear.

Note

• To use subtitle, you must set “Service Preference” to “Subtitle”. (See page 30.)

• To set the subtitle language, refer to “Language Setting” on page 30.

2 Select “DVB Menu” using [U / D],

then press [ENTER/OK].

3 Select “Adult Lock” using [U / D],

then press [ENTER/OK].

DVB Me nu

Adult Lock Language Service Preference About Reset All

4 Select “ON” or “OFF” using [U / D],

then press [ENTER/OK].

5 To set the Adult Lock ON:

1) Enter your desired PINCODE using

[the Number buttons], then press [ENTER/OK].

2) For confirmation, enter the PINCODE again

using [the Number buttons].

To set the Adult Lock OFF:

Enter the PINCODE using [the Number buttons].

• While entering the PINCODE, use [L] or

[CLEAR] to clear the numbers once entered.

6 Press [SETUP] to exit.

Note

• Once the Adult Lock has been set to “ON”, PINCODE will be required in order to view or timer recording the locked channels, and to execute the “Auto Tuning” for DVB or “Edit Channels”.

• If you forgot the PINCODE, press [4], [7], [3], [7], to cancel the PINCODE.

Recording

Editing

Function Setup

Others

23_31_BasicSetup_EN.fm Page 30 Tuesday, July 17, 2007 1:13 PM

Language Setting

DVB

1 Follow steps 1 to 2 in “PINCODE

Setting for Adult Lock” on page 29.

2 Select “Language” using [U / D],

then press [ENTER/OK].

3 Select the item you want to change

the language using [U / D], then press [ENTER/OK].

DVB Menu

Adult Lock Language Service Preference About Reset All

Audio : Set the Audio language Subtitle : Set the Subtitle language Data Service: Set the Digital Teletext language

Audio Subtitle Data Service

4 Select a language using [U / D],

then press [ENTER/OK].

About

DVB

You can check the current DVB system software version of this unit.

1 Follow steps 1 to 2 in “PINCODE

Setting for Adult Lock” on page 29.

2 Select “About” using [U / D], then

press [ENTER/OK].

3 Press [SETUP] to exit.

Note

• Whenever a new software is available, it is advisable to always accept and download the software. In case new software is available, you will see a message when you switch on the DVB channel.

UPDATE

YOUR CURRENT SOFTWARE IS VERSION

1.00. VERSION 2.00 IS AVAILABLE FOR UPDATE. UPDATING IS RECOMMENDED. DO YOU WISH TO UPDATE?

YES

5 Press [SETUP] to exit.

Note

• You can also change the audio language using [AUDIO ] if it is available.

• The Audio, Subtitle and Digital Teletext language setting may not be available for some broadcast.

Service Preference Setting

DVB

Set whether you receive the Teletext or Subtitle information from the DVB.

1 Follow steps 1 to 2 in “PINCODE

Setting for Adult Lock” on page 29.

2 Select “Service Preference” using

[U / D], then press [ENTER/OK].

3 Select a desired information to

receive using [U / D], then press [ENTER/OK].

4 Press [SETUP] to exit.

Note

• This unit supports MHEG5 data service.

• This unit does not support MHP data service.

Resetting the DVB Menu Setting to Default

DVB

1 Follow steps 1 to 2 in “PINCODE

Setting for Adult Lock” on page 29

2 Select “Reset All” using [U / D],

then press [ENTER/OK].

3 Select “Yes” using [U / D], then

press [ENTER/OK].

DVB Menu

Adult Lock Language Service Preference About Reset All

“Are you sure?” will appear. Select “Yes” using

[U / D], and then press [ENTER/OK].

Reset to factory default?

Yes

4 Press [SETUP] to exit.

Note

• The PINCODE for Adult Lock will remain unchanged even after resetting the DVB Menu setting to default.

E7J70BD_EN.book Page 31 Monday, May 7, 2007 3:31 PM

Setting the Clock

Auto Clock Setting

This unit receives time signals from the analogue / DVB channels, and set the clock automatically. Set the channel tuning before setting Auto Clock.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Clock” using [U / D], then

press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Manual Clock Setting

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Clock” using [U / D], then

press [ENTER/OK].

3 Select “Clock Setting” using [U / D],

then press [ENTER/OK].

Default date will appear.

4 Press [ENTER/OK] again.

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Clock Setting

01 / 01 / 2007 ( MON )

Clock Setting Auto Clock Setting

0 : 00

Introduction Connections Basic Setup Playback

Recording

3 Select “Auto Clock Setting” using

[U / D], then press [ENTER/OK].

4 Select “ON” using [U / D], then

press [ENTER/OK].

5 Press [SETUP] to exit. 6 Press [ ON / STANDBY] to turn

off.

The Auto clock function is activated. This unit will search for the time every time when the power is turned off. Leave the unit off for about 10 seconds to give it time to set the clock.

Hint

• If you want to cancel “Auto Clock Setting,” select

“OFF” using [U / D], and then press [ENTER/OK] at step 4.

Note

• The default setting of “Auto Clock Setting” is “ON.”

• The clock may set itself automatically after you connect the antenna cable to the unit and plug in the mains cable. In this case, the current time will appear on the front panel display.

• If there are only analogue channels memorised in this unit:

- The channel assigned to “904” must receive the

PDC signal in order to set the clock automatically.

- The unit will correct the current time by receiving

PDC broadcasts whenever the power is turned off.

- Between 23:00 and 1:00, the Auto Clock function

will not operate even when the power is turned off.

• The clock cannot be set automatically if you are not receiving a channel in your area that carries a time signal. In this case, set the clock manually.

• The unit will also correct the current time automatically at 8:00 if the unit is in standby mode or if you are watching DVB channel.

5 Enter the date (day / month / year)

using [U / D].

Press [P] to move the cursor to the next field. If you wish to go back to the previous field, press [L].

6 Enter the time (hours / minutes)

using [U / D], then press [ENTER/OK].

The clock will start.

• Although seconds are not displayed, they will be counted from zero.

7 Press [SETUP] to exit.

Note

• Your clock setting will be lost if either there is a power failure or the unit is unplugged for more than 30 seconds.

Editing

Function Setup

Others

DVD-RW

DVD-R

DVD+RW

DVD+R

E7J70BD_EN.book Page 32 Monday, May 7, 2007 3:31 PM

Recording

Information on DVD Recording

Type of Discs

This unit can record on DVD-RW/-R discs and DVD+RW/+R discs. DVD-R/+R discs allow you to record programmes only once, and the recorded contents can be erased although the space left on the disc does not change. DVD-RW/+RW discs allow you to record programmes repeatedly, and the recorded contents can be erased. There are 3 recording formats: VR mode, Video mode and +VR mode. VR and Video modes are available for DVD-RW discs while as only Video mode is available for DVD-R discs. +VR mode is available for DVD+RW/+R discs.

Video mode is the same recording format as used on the pre-recorded DVD-Videos you purchase in local shops. You can play back the discs recorded in this format on most of the DVD players. You will need to finalise such discs (see page 45) before playing them back on other DVD players. Unless finalised, you can record additional materials or edit discs recorded in Video mode with this unit. VR (Video Recording) mode is a basic recording format for DVD-RW discs. You can record and edit material repeatedly. It is impossible to record additional materials on a disc formatted in VR mode and already recorded in another video system other than PAL, such as NTSC. +VR mode is a recording format for DVD+RW/+R disc. You can play back in this format on most of the DVD player.

Recording Mode

You can select a recording mode from 5 options. The recording time will vary depending on the recording mode you select as follows.

Recording

mode

XP 60 min 18 min

SP 120 min 36 min

LP 240 min 72 min

EP 360 min 108 min

SLP 480 min 144 min

• This table is intended for a standard new singlesided 12 cm / 8 cm disc. The recording times are estimates and actual recording time may differ.

• The audio and video quality becomes poorer as the recording time gets longer.

Recording time

12 cm 8 cm

Sound Quality

Video /

Restrictions on Recording

You cannot record copy-protected video using this unit. Copy-protected video includes DVD-Videos and some satellite broadcasts. If copy-protected material is detected, recording will pause or stop automatically and an error message appears on the screen. You can only record “Copy-once only” video using a DVD-RW disc in VR mode with Content Protection for Recordable Media (CPRM). When recording a TV broadcast or an external input, you can display copy control information on the screen. CPRM is a scrambling copy protection system for the protection of “copy-once” broadcast programmes. This unit is CPRM compatible, which means that you can record copy-once broadcast programmes, but you cannot then make a copy of those recordings. CPRM recordings can only be played back on DVD players that are specifically compatible with CPRM.

Information on Copy Control

Some satellite broadcasts include copy-protected information. If you wish to record them, refer to the following.

Copy-

Disc type / format

ver. 1.1 / ver. 1.2

DVD-RW

DVD-R

DVD+RW

DVD+R

ver. 1.1 / ver. 1.2 CPRM compatible

ver. 1.1 / ver. 1.2

Video

ver. 1.1 / ver. 1.2 CPRM compatible

ver. 2.0

: Recordable : Not recordable

free

Note

• This unit cannot record on CD-RW or CD-R discs.

• DVD-RW/-R, DVD+RW/+R and CD-RW/-R discs recorded on a personal computer or a DVD or CD recorder may not be played back if the disc is damaged or dirty or if there is condensation on the player’s lens.

• If you record a disc using a personal computer, even if it is recorded in a compatible format, it may not be played back because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

• Discs recorded in Video mode on this unit cannot record additional information using other DVD recorders.

once

Copyprohibited

E7J70BD_EN.book Page 33 Monday, May 7, 2007 3:31 PM

• It is not possible to use a DVD-RW disc formatted with this unit on other DVD recorder unless the content of the disc was also recorded with this unit.

• Since recording is performed using the Variable Bit Rate (VBR) method, the actual remaining time for recording may be a little shorter than the remaining time displayed on the OSD, depending on the picture you are recording.

Making Discs Playable in Other DVD Players (Finalise)

After recording, you must finalise the disc to play it back in other players. (See page 45.) You cannot finalise discs in other DVD recorders.

After finalising

• After DVD-R discs are finalised:

- A Title menu is created automatically.

- Undo finalising is not possible.

- Additional recording or editing is not possible.

• After DVD-RW (Video mode) discs are finalised:

- A Title menu is created automatically.

- Undo finalising is possible. (See page 45.)

- Additional recording or editing is possible if you

undo finalise. (See page 45.)

• After DVD-RW (VR mode) discs are finalised:

- A Title menu is not created.

- Undo finalising is possible. (See page 45.)

- Additional recording or editing is possible if you

undo finalise. (See page 45.)

• After DVD+RW discs are finalised:

- A Title menu is created automatically.

- Undo finalising is possible. (See page 45.)

- Additional recording or editing is possible even

without undo finalising.

• After DVD+R discs are finalised:

- A Title menu is created automatically.

- Undo finalising is not possible.

- Additional recording or editing is not possible.

Formatting a Disc

Choosing the Recording Format of a Blank DVD-RW Disc

Video

DVD-RWDVD-RW

When inserting a brand-new DVD-RW/+RW disc, the unit automatically starts to initialise the disc. DVD+RW disc will always be formatted in +VR mode, and DVD-RW disc will be formatted either Video or VR mode according to the recording format mode setting of the unit. Before insert a brand-new DVD-RW disc, you need to set the recording format to the desired mode. You can also manually format a DVD-RW disc once it has been used.

DVD-RWDVD-RW

1 In stop mode, press [SETUP]. 2 Select “DVD Menu” using [U / D],

then press [ENTER/OK].

“DVD Menu” menu will appear.

3 Select “Format” using [U / D], then

press [ENTER/OK].

Format menu will appear.

4 Select “Format Mode” using [U / D],

then press [ENTER/OK].

5 Select “Video mode” or “VR mode”

using [U / D], then press [ENTER/OK].

DVD Menu

Format Mode

Format Finalise

Video mode

Disc Protect OFF ON

VR mode

Delete All Playlist

Video mode

DVD Player Compatibility mode.

VR mode

Editing possibility mode.

Introduction Connections Basic Setup Playback

Recording

Editing

6 Press [SETUP] to exit. 7 Insert a blank disc.

Formatting will start.

8 Formatting is complete.

“100%” is indicated.

Note

• The recording format setting is effective only for DVD-RW discs. You cannot change the recording format for a DVD-R disc and DVD+RW/+R disc.

• You cannot mix two formats on one DVD-RW disc. If you insert a disc that has been recorded before, the recording format cannot be changed even if you change it in the Setup menu.

Function Setup

Others

VD+R

VD+RWW

VD+R

E7J70BD_EN.book Page 34 Monday, May 7, 2007 3:31 PM

Make Recording Compatible

DVD+RWDVD+RW DDVD+R

Use this feature to make the unfinalised +VR mode discs recorded on other unit recordable on this unit. When you make an additional recording on this unit with “Make Recording Compatible” set to “ON”, the title list is automatically converted to this unit’s style.

DVD+R

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Recording” using [U / D],

then press [ENTER/OK].

3 Select “Make Recording Compatible”

using [U / D], then press [ENTER/OK].

4 Select “ON” or “OFF” using [U / D],

then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise

Make Recording Compatible

Aspect Ratio (Video mode)

Make Recording Compatible

OFF

Bilingual Recording Audio External Input Audio

4 Select your desired setting using

[U / D], then press [ENTER/OK].

General Setting

Playback Display Video

Aspect Ratio (Video mode)

Recording Clock Channel DivX HDMI Reset All

Auto (default): It will be recorded with whichever the

ratio that the programme you started to record is broadcasted with.

4:3 : Recorded in the aspect ratio of 4:3. 16:9 : Recorded in the aspect ratio of 16:9.

Auto Chapter Recording Audio Select (XP) Auto Finalise

Auto

Aspect Ratio (Video mode)

4 : 3

Make Recording Compatible

16 : 9

Bilingual Recording Audio External Input Audio

5 Press [SETUP] to exit.

Note

• For VR mode DVD-RW disc, the image will be recorded in whichever the ratio that the programme you record is broadcasted with, regardless of the “Aspect Ratio (Video mode)” setting.

• For DVD+RW/+R disc, the image will always be recorded in aspect ratio of 4:3.

Setting Auto Chapter

Video

DVD-RWDVD-RW

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

ON: Title list will be replaced when you make

additional recordings to the discs recorded by other units.

OFF: Prohibiting additional record to the disc that has

a title list created by other units.

5 Press [SETUP] to exit.

Setting Aspect Ratio for Video Mode Recording

Video

DVD-RWDVD-RW

You can set aspect ratio for video mode recording.

DVD-RDVD-R

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Recording” using [U / D],

then press [ENTER/OK].

3 Select “Aspect Ratio (Video mode)”

using [U / D], then press [ENTER/OK].

DDVD+R

DVD+R

The unit inserts a chapter mark periodically (every 15 minutes by default) during recording. Using the Auto Chapter menu, you can set this function off or change the time period.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Recording” using [U / D],

then press [ENTER/OK].

3 Select “Auto Chapter” using [U / D],

then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise Aspect Ratio (Video mode) Make Recording Compatible Bilingual Recording Audio External Input Audio

E7J70BD_EN.book Page 35 Monday, May 7, 2007 3:31 PM

4 If you wish to set “Auto Chapter” off,

select “OFF” using [U / D], then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter

Recording Audio Select (XP)

OFF

Auto Finalise

5 minutes

Aspect Ratio (Video mode)

10 minutes

Make Recording Compatible

15 minutes

Bilingual Recording Audio

30 minutes

External Input Audio

60 minutes

If you wish to change the time period for Auto Chapter, select the required time period using [U / D], then press [ENTER/OK].

5 Press [SETUP] to exit.

Note

• You cannot set or clear chapter markers on DVD-R discs manually.

Reformatting a Disc Manually

Video

DVD-RWDVD-RW

If you are using a DVD-RW/+RW disc, you can format the disc by performing “Format”. You can format DVDRW disc for either Video mode recording or VR mode recording. DVD+RW disc can be format in order to erase all content of the disc.

DVD-RWDVD-RWVRDVD+RWDVD+RW

5 Select “Yes” using [U / D], then

press [ENTER/OK].

e.g.) VR mode DVD-RW

DVD Menu

Format Finalise Disc Protect OFF ON Delete All Playlist

Formatting will start. If you want to cancel formatting, select “No”.

Start Format Mode

Are you sure?

Yes

6 Formatting is complete.

Note

• It is not possible to use a disc formatted with this unit on other DVD recorder. When you use a disc with another DVD recorder, format a disc using that DVD recorder.

Introduction Connections Basic Setup Playback

Recording

Note

• When you reformat the disc, the contents of the disc are erased.

• Make sure that the recording format is set to the desired mode. (See steps 1 to 6 in “Choosing the Recording Format of a Blank DVD-RW Disc” on page 33.)

Insert a recordable disc.

1 In stop mode, press [SETUP]. 2 Select “DVD Menu” using [U / D],

then press [ENTER/OK].

3 Select “Format” using [U / D], then

press [ENTER/OK].

4 Select “Start” using [U / D], then

press [ENTER/OK].

For DVD+RW, use [U / D] to select “Yes”, then press [ENTER/OK].

A pop up window will appear and prompt you to confirm.

Editing

Function Setup

Others

VD+RWW

VD+R

VD+RWW

VD+R

VD+RWW

VD+R

E7J70BD_EN.book Page 36 Monday, May 7, 2007 3:31 PM

Selecting the Sound Mode

This unit can receive bilingual broadcasts.

You can switch between modes by pressing [AUDIO ] on the remote control. Each mode is indicated on the TV. When you record a DVB channel, only output sound channel will be recorded.

Setting External Input Audio

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

When the external input audio is a bilingual broadcast, you can choose “Stereo” or “Bilingual” to record on a DVD. This setting is only for recording external input (AV1/AV2/AV3).

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Recording” using [U / D],

then press [ENTER/OK].

3 Select “External Input Audio” using

[U / D], then press [ENTER/OK].

DVD+RW

Setting Bilingual Recording Audio

Video

DVD-RWDVD-RW

DVD-RDVD-R DDVD+R

DVD+RW DDVD+R

DVD+R

You can select either “Main” or “Sub” audio to record a bilingual broadcast in Video mode or +VR mode. This setting is only for recording analogue channel.

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Recording” using [U / D],

then press [ENTER/OK].

3 Select “Bilingual Recording Audio”

using [U / D], then press [ENTER/OK].

4 Select “Main” or “Sub” using

[U / D], then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise

Bilingual Recording Audio

Aspect Ratio (Video mode)

Main

Make Recording Compatible

Sub

Bilingual Recording Audio External Input Audio

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise Aspect Ratio (Video mode) Make Recording Compatible Bilingual Recording Audio External Input Audio

4 Select “Stereo” or “Bilingual” using

[U / D], then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

Auto Chapter Recording Audio Select (XP) Auto Finalise

External Input Audio

Aspect Ratio (Video mode)

Stereo

Make Recording Compatible

Bilingual

Bilingual Recording Audio External Input Audio

5 Press [SETUP] to exit.

Hint

• If you select “Stereo”: The audio will be recorded as “stereo audio”.

• If you select “Bilingual”: The audio will be recorded as “bilingual audio” (see “Setting Bilingual Recording Audio” for more detail).

5 Press [SETUP] to exit.

Note

• If you are recording onto a VR mode disc, both “Main” and “Sub” will be recorded regardless of your setting here. And when you play back, you can choose either audio format or a combination of both as your playback audio.

Recording Audio Select (XP)

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

You can enjoy high quality sound recording. This function works only when the recording mode is set at XP.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 In stop mode, press [SETUP]. Select

“General Setting” using [U / D], then press [ENTER/OK].

2 Select “Recording” using [U / D],

then press [ENTER/OK].

3 Select “Recording Audio Select

(XP)” using [U / D], then press [ENTER/OK].

VD+RWW

VD+R

E7J70BD_EN.book Page 37 Monday, May 7, 2007 3:31 PM

4 Select “PCM” or “Dolby Digital”

using [U / D], then press [ENTER/OK].

General Setting

Playback Display Video Recording Clock Channel DivX HDMI Reset All

PCM: Records PCM audio for the best

Dolby Digital: Records Dolby Digital audio for good

quality sound.

Auto Chapter Recording Audio Select (XP)

Recording Audio Select (XP)

Auto Finalise

PCM

Aspect Ratio (Video mode)

Dolby Digital

Make Recording Compatible Bilingual Recording Audio External Input Audio

5 Press [SETUP] to exit.

Note

• “PCM” stands for Pulse Code Modulation. It changes analogue sound to digital sound without compressing audio data.

• When the recording mode is set at other than XP, the unit records “Dolby Digital” audio automatically even if you selected “PCM”.

Basic Recording

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

Follow the steps below to record a TV programme.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

1 Press [ ON / STANDBY] to turn on

the unit.

Turn on the TV and be sure to select the input to which the unit is connected.

2 Press [OPEN / CLOSE O] to open the

disc tray.

3 Place the disc on the disc tray with

its label facing up. Be sure to align the disc with the disc tray guide.

Disc tray guide

4 Press [OPEN / CLOSE O] to close

the disc tray.

5 Select the recording mode using

[REC MODE].

(See page 32.)

6 Select the desired channel to record

using [PROG. [the Number buttons].

/ ] or

7 Press [REC I] to start recording.

The “●” mark will be displayed for 5 seconds.

To pause the recording, press [PAUSE p]. Press [PAUSE p] or [REC recording.

I] again to restart the

8 Press [STOP S] to stop the recording.

This operation may take a few moments to complete.

Hint

• You can change the channel while in the REC pause mode.

Note

• Recording starts immediately and continues until the disc is full or you stop recording.

• You cannot change the recording mode in the REC or REC pause mode.

• If you want to monitor the programme that you are recording, make sure the device such as a Satellite Box is turned off or press [DISPLAY] when it is connected to AV2.

• NTSC recording is prohibited in this unit.

• Up to 99 titles can be recorded on the DVD-RW/-R discs.

• Up to 49 titles can be recorded on the DVD+RW/+R discs.

Introduction Connections Basic Setup Playback

Recording

Editing

Function Setup

Others

VD+RWW

VD+R

E7J70BD_EN.book Page 38 Monday, May 7, 2007 3:31 PM

One-Touch Timer Recording (OTR)

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

This is a simple way to set the recording time in blocks of 30 minutes. Check that the disc you are recording onto has enough space remaining for the time you set.

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

1 Turn on the unit and insert a

recordable disc.

Make sure that the TV input is set on the unit.

2 Select the recording mode using

[REC MODE].

(See page 32.)

3 Select the desired channel to record

using [PROG. [the Number buttons].

/ ] or

4 Press [REC I] repeatedly until the

desired recording time (30 minutes to 8 hours) appears on the TV screen.

One-touch Timer Recording will start.

0:30

Normal

Recording

1:00

DVD+RW

• When One-touch Timer Recording is finished and the power is turned off, the unit will switch to the timer-standby mode automatically if a timer recording has been programmed. Press [ ON / STANDBY] to cancel the timer-standby mode to use the unit continuously.

• If you want to monitor the programme that you are recording, make sure the device such as a Satellite Box is powered off or press [DISPLAY] when it is connected to AV2.

8:00 7:30

• When the unit reaches the specified time, it will be turned off automatically.

• To change the recording length during Onetouch Timer Recording, press [REC repeatedly until the desired length appears.

• To cancel One-touch Timer Recording within the specified time, press [STOP S].

Hint

• The remaining recording time will appear on the TV screen during One-touch Timer Recording. Press [DISPLAY] to see it on the TV screen.

• The remaining recording time will be displayed on the front panel display during One-touch Timer Recording.

• Unlike the timer recording, you can perform the following operations during One-touch Timer Recording.

- Turn off the power. (One-touch timer recording will

be cancelled.)

-Use [REC

Note

• You cannot use the pause function during Onetouch Timer Recording.

• The unit will be turned off automatically under the following conditions.

- No space remains on the disc.

- If a power failure occurs.

I] or [STOP S] on the remote control.

VD+RWW

VD+R

E7J70BD_EN.book Page 39 Monday, May 7, 2007 3:31 PM

Timer Recording

Video

DVD-RWDVD-RW

DDVD+R

DVD+R

DVD-RWDVD-RWVRDVD-RDVD-R DDVD+R

DVD+RW

You can set the unit to record up to 12 programmes, up to a month in advance. Daily or weekly programme recordings are also available.

• Be sure to set the clock before entering a timer programming.

Insert a recordable disc.

1 In stop mode, press [TIMER PROG.].

Timer Programming list will appear.

2 Select “New Program” using

[U / D], then press [ENTER/OK].

Timer Programming

0:00 THU 06/12

STTL

End

Start

Date 06/12 07/12

7:00 9:00

9:00 9:30

New Program

• If there are 7 programmes or more, use

[SKIP B / F] to turn the page.

190

PDC

1/1

3 Enter the date using [U / D], then

press [P].

Each time you press [D] at the current date, the timer recording date will change as follows.

e.g., 1st January

01/01

Daily

M-F

(Mon.-Fri.)

W-SAT

W-FRI

5 Select the channel number to record

using [U / D], then press [P].

To record from the external input, select “AV1”, “AV2”, or “AV3”.

6 Select the recording mode using

[U / D], then press [P].

Refer to “Recording Mode” on page 32.

7 For DVB channel recording:

Select “STTL” to “ON” or “OFF” using [U / D].

If you set “STTL” to “ON”, subtitle will be recorded too.

• When analogue channel is selected, “PDC” will be displayed instead of “STTL”.

For analogue channel recording: Select “PDC” to “ON” or “OFF” using [U / D].

Refer to “PDC (Programme Delivery Control)” on page 40.

• When DVB channel is selected, “STTL” will be displayed instead of “PDC”.

8 Press [ENTER/OK] when all

information required is entered.

Your programme setting is stored.

• To set another programme, repeat steps 2 to 8.

• To exit, press [TIMER PROG].

• When 2 or more programmes are overlapped, “Timer program overlapped” appears, and the overlapped programme will be displayed in blue. To correct the timer programme, refer to “Checking, Cancelling or Correcting the Timer Programming Information” on page 40.

9 Press [ ON / STANDBY] to set a

timer programming.

Timer Programming

0:00 THU 06/12

STTL

End

Start

Date 06/12 07/12 07/12

7:00 9:00 17:00

9:00 9:30 18:00

New Program

18 190 901

PDC

Introduction Connections Basic Setup Playback

Recording

Editing

W-SUN

31/01

Timer Programming

0:00 THU 06/12

Date

01/01

901

Start

- - : - Mode

End

- - : - PDC OFF

SP 2:00

1/1

4 Enter the time to start and to end

using [U / D], then press [P].

1/1

The icon will appear on the front panel display and the unit enters to the timer-standby mode.

Note

• If you have not set the clock, the clock setting window will appear instead of the Timer Programming list. Continue from step 4 in “Manual Clock Setting” on page 31 before programming the timer.

•Press [L / P] to move the cursor in the Timer Programming list.

• Cancel the timer-standby mode by pressing [ ON / STANDBY] before operation. When finished operating, press [ ON / STANDBY] to resume the timer-standby mode.

Function Setup

Others

E7J70BD_EN.book Page 40 Monday, May 7, 2007 3:31 PM

PDC (Programme Delivery Control)

Programme Delivery Control (PDC) assures that the TV programmes you have programmed for timer recording are recorded exactly from beginning to end, even if the actual broadcasting time differs from the scheduled time due to a delayed start or extension of the programme duration. Furthermore, if a programme is interrupted, the recording will also be interrupted automatically and resumed when the programme starts again.

If the PDC signal drops out because the broadcast signal is weak, or if a broadcasting station does not transmit a regular PDC signal, the timer recording is performed in normal mode (without PDC) even if it was programmed for PDC. If the starting time of the PDC timer recording is between 0:00 and 3:59 on a given day, the PDC function will operate from 20:00 on the previous day to 4:00 on the next day. If the starting time of the PDC timer recording is between 4:00 and 23:59 on a given day, the PDC function will operate from 0:00 on the given day to 4:00 on the next day. This means that if the relevant programme is broadcasted within this period, it is recorded correctly. If the timer is not programmed correctly, the incorrect timer setting stays in effect unless you cancel it. To cancel an incorrect timer setting, refer to “Checking, Cancelling or Correcting the Timer Programming Information” below.

Note

• This feature is only available for analogue channels.

Checking, Cancelling or Correcting the Timer Programming Information

1 Press [ ON / STANDBY]. 2 Press [TIMER PROG.].

Timer Programming list will appear.

3 Check the information on the list you

want to edit.

4 A) To delete the timer programme:

1) Select the programme you want to delete using

[U / D], then press [ENTER/OK].

2) Select “Delete” using [U / D], then press

[ENTER/OK]. Confirmation window will appear.

3) Select “Yes” using [U / D], then press

[ENTER/OK].

B) To correct the timer programme:

1) Select the programme you want to correct

using [U / D], then press [ENTER/OK].

2) Select “Program Change” using [U / D], then

press [ENTER/OK].

3) Correct the timer programme by using

[U / D / L / P], then press [ENTER/OK].

5 Press [TIMER PROG.] to exit. 6 Press [ ON / STANDBY] to return

to the timer-standby mode.

To check the timer programming in process Press [TIMER PROG.].

Note

• If a timer recording is proceeding, that programme is highlighted in red. In such a case, you cannot select any other programmes.

To Stop the Timer Recording in Progress

On the front panel of the unit, press [

S (STOP)

Note

• [STOP S] on the remote control is not effective.

] to stop the recording.

If the Timer Programming Did Not Complete Correctly

The error number appears on the Timer Programming list.

Timer Programming

0:00 THU 06/12

Date

Start

7:00

New Program

End

9:00CH901

06/12

E40

The error programme will be displayed in grey with an asterisk and have an error number.

The error numbers indicate:

E1–E22, E37–E39: Recording error E23–E24: Unrecordable disc E25 : • Copy prohibited programme

E26–E28: Copy prohibited programme E29 : Disc protected E30 : Disc full E31 : Already recorded 99 titles (Video

E32 : Already recorded 99 titles (VR mode) E33 : Already recorded 999 chapters E34 : No space for Control Information E35 : PCA (Power Calibration Area) full E36 : Already finalised Video format disc E40 : • There are some unrecorded parts due

E41 : Power failure E42 : No disc E43 : Already 49 titles recorded (+VR mode) E44 : Already 254 chapters recorded

E45 : Copy prohibited programme E46 : It is impossible to record additionally on

The error programme will be deleted once you check the error in the programme list, or once you cancel the timer-standby mode and re-enter it.

• Cannot record because of the NTSC / PAL-60 signal is received.

mode)

the overlapped timer programmes.

• Recording did not start at the start time.

(+VR mode)

a disc recorded by other units when setting “Make Recording Compatible” to “OFF”. (+VR mode)

STTL

PDC

1/1

E7J70BD_EN.book Page 41 Monday, May 7, 2007 3:31 PM

Hints for the Timer Recording

• If there is a power failure or the unit is unplugged for more than 30 seconds, the clock setting and all timer settings will be lost.

• If a disc is not inserted or if a inserted disc is not recordable (finalised DVD-RW/-R, finalised DVD+R, a fully recorded disc, etc.), flashes and timer recording cannot be performed. In some cases, will appear momentarily around the start point as the unit attempts to record. Please insert a recordable disc.

• When all timer recordings are complete, the icon flashes. To play back or eject the recorded disc, press [ ON / STANDBY], and then press [PLAY P] or [OPEN / CLOSE O].

• You cannot make any DVD operation during DVD timer recording.

• If the Start and End times are same, the length of the recording will be set for 24 hours. If the disc becomes full during recording, the unit will turn itself off. To continue recording, press [ ON / STANDBY] to cancel the timer-standby mode, insert a recordable disc and press [ ON / STANDBY] again.

• When 2 or more programmes are overlapped, “Timer program overlapped” appears, and the overlapped programme will be displayed in blue. To correct the timer programme refer to “Checking, Cancelling or Correcting the Timer Programming Information” on page 40.

• If the Start time is earlier and the End time is later than the current time, the recording will start immediately after you press [ ON / STANDBY].

Priority of overlapped settings

The unit records programmes according to priority if the timer programmes overlap.

If the starting time is same:

• The timer programming set first (PROG. 1) has priority.

PROG. 1

PROG. 2

Actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. 1 PROG. 2

PROG. 2 recording will start after PROG. 1 recording is completed.

If the recording time is partially overlapped:

• The timer programming with the earlier start time (PROG. 2) has priority. PROG. 1 will start after PROG. 2 recording is complete.

PROG. 1

PROG. 2

Actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. 2 PROG. 1

If the recording time entirely overlaps:

• The shorter timer programming (PROG. 1) is not recorded.

PROG. 1

PROG. 2

Actual recording

PROG. 2

Note for DVD recording

• If the recording time of two programmes are overlapped, or the End time of a programme and the Start time of another is same, the first 2 minutes (at the longest) of the subsequent programme will be cut off.

If the End time of the programme currently being recorded and the Start time of the subsequent programme are same:

• If PROG. 1 is a DVD recorded programme, the beginning of PROG. 2 may be cut off.

PROG. 1

PROG. 2

Actual recording

PROG. 2PROG. 1

The first 2 minutes (at the longest) will be cut off.*

* If the cut off time exceeds 3 minutes, the error

number “E40” will appear in the Timer Programming list.

Introduction Connections Basic Setup Playback

Recording

Editing

When the starting time and the ending time for each programmes are different:

• A programme that has earlier start time has priority.

PROG. 1

PROG. 2

PROG. 3

Actual recording

The first 2 minutes (at the longest) will be cut off.

PROG. 1

PROG. 3

PROG. 2

Function Setup

Others

E7J70BD_EN.book Page 42 Monday, May 7, 2007 3:31 PM

Timer Recording (EPG)

With EPG system, you can programme DVB channel recording much easier. You only choose a programme and enter the selection.

1 While viewing DVB channel, press

[GUIDE].

List of DVB channels will be displayed.

2 Select a desired channel using

[U / D], then press [ENTER/OK].

EPG

7:00

Channel1

Channel2

Channel3

Channel4

Channel5

CHANGE TO

Time schedule of the DVB channel will be displayed.

• If you press [BLUE] instead of [ENTER/OK]

after you select a channel using [U / D], you can watch the selected channel.

10:00

9:00

10:00

6:01

12:01

6:00

10:00

9:00

10:00

Current Program1 Next Program1

Current Program2 Next Program2

Current Program3 Next Program3

Current Program4 Next Program4

Current Program5 Next Program5

3 Select a desired programme using

[U / D], then press [ENTER/OK].

Satellite Link

You can set the unit to start recording whenever it detects the video scart control from the external tuner.

Preparing for the Satellite Link Timer Recording:

[Preparation of the external tuner]

• The external tuner should be equipped with some kind of timer function. Using timer function of the tuner, set it to be turned on when it comes to the time you want to start recording, and off when it comes to the time you want to finish recording. (Refer to the tuner’s manual on how to set the timer.)

• Make sure to turn off the external tuner when you finish setting.

[Preparation of this unit]

• Make sure to select the desired Recording mode beforehand.

Scart cable (not supplied)

ANTENNA

PB/CB

PR/CR

OUT

ANALOGDVB-T

VIDEO OUTPUT

External tuner

(not supplied)

COAXIAL

DIGITAL AUDIO OUTPUT

PCM/BITSTREAM

AV2(DECODER

ANALOG

COMPONENT

AUDIO OUT

HDMI OUT

)

AV1(TV

EPG

Channel3

Thursday 2/22

Program1
