TomTom 4S00 User Manual
What’s in the box1.
What’s in the box
a Your TomTom ONE XL
ACB
F
G
H
A Charging LED
B Touchscreen
C On/Off button
D Speaker
E External antenna connector
F USB connector
G RDS-TMC connector
H Memory card slot
b Memory card (SD
card)*
d Windshield Holder e Documentation
c Product code card
pack
D
E
f USB Car Charger g USB cable
* Not included in all products
2
Before You Start...2.
Before You Start...
Everyone Loves TomTom ONE XL
So never leave your ONE XL in your car when you’re not using it - it’s an easy
target for thieves.
Always take your ONE XL, the windshield holder, and the car charger with
you; don’t leave any TomTom products on display.
Always store your ONE XL in the carry case to protect the screen.
Back Up Your TomTom ONE XL
It’s always a good idea to make a backup of the contents of your
TomTom ONE XL. You can make a backup using TomTom HOME.
For more information about TomTom HOME, see Using TomTom HOME on
page 49.
Use the safety preferences
When using your ONE XL, we recommend using the Safety preferences from
the Preferences menu.
You can choose to use the safety lock. If the safety lock is enabled, only a
few buttons and features are available while you are driving. When you are
stationary, all the buttons and features are available.
Safety
preferences
You can also choose to turn the map display off.
For more information, see Safety preferences on page 33.
Troubleshooting
Always make sure that you are using the latest version of the TomTom
application on your ONE XL. You can update the application using TomTom
HOME. For more information about TomTom HOME, see Using TomTom
HOME on page 49.
If you have problems turning on your TomTom ONE XL, try resetting your
ONE XL.
To reset your ONE XL, use a straightened paper clip, or something similar, to
push the reset button. The reset button is next to the memory card slot on the
bottom of your ONE XL. Then turn your ONE XL on.
3
Secure your TomTom ONE XL
Set a password for your TomTom ONE XL so that only you can use it. Every
time you start your ONE XL you will have to enter your password.
To set the password, you have to run your ONE XL using TomTom HOME.
You can then use TomTom HOME to set the password. To set a password on
your device, do the following:
1. Connect your ONE XL to your computer and switch it on.
2. Start TomTom HOME if it does not start automatically.
If you do not have TomTom HOME installed, insert the CD that came with
your ONE XL to install it.
Alternatively, you can download TomTom HOME from www.tomtom.com.
Make sure you always have the latest version of TomTom HOME. For more
information about TomTom HOME, see Using TomTom HOME on page 49.
3. In the Planning section, select your ONE XL.
A picture of your ONE XL is shown in the main section of TomTom HOME.
4. Click the On/Off button on the picture of your ONE XL to switch it on in
TomTom HOME.
Your ONE XL starts in TomTom HOME. You can now set the password on
your ONE XL using TomTom HOME. Don't unplug your ONE XL, just use it
as you normally would by clicking the buttons shown on your computer.
5. From the Main Menu in your device, click Change preferences.
6. Click Set owner. You may have to click the arrow until you reach the page
where Set owner is shown.
If you cannot find the button Set owner, make sure that all buttons are
shown in your ONE XL. Tap the button Show ALL menu options. All
buttons will now be shown.
Set owner
You can now set the password for your ONE XL. You can also set your name
and address, which will then be shown when your ONE XL starts up.
Take care of your TomTom ONE XL
It is important to take care of your ONE XL and to clean it correctly.
• Use a soft cloth to wipe the screen of your ONE XL; do not use any liquid
cleaners.
• If your ONE XL gets wet, dry it with a soft cloth.
• Do not open the casing of your ONE XL under any circumstances. Doing so
may be dangerous and will invalidate your warranty.
4
• Do not use the memory card (SD card) with any device other than a
TomTom device. Other devices may damage the memory card.
• Do not expose your ONE XL to high or low temperatures, which can cause
permanent damage. For example, don’t leave it in the car on hot summer
days or during cold winter nights.
5
Getting started
Switching on
Setting up
Getting started3.
Follow the instructions on the Installation Poster to dock your TomTom ONE
XL in your car.
The first time you switch on your TomTom ONE XL, it may take up to 20
seconds to start. To switch off your TomTom ONE XL, press and hold the On/
Off button for 2 seconds.
You have to answer a few questions to set up your TomTom ONE XL. Answer
the questions by tapping the screen. You will use the touchscreen for
everything you do with your ONE XL.
You can change these settings at any time using the Preferences menu. For
information about the Preferences menu, see Preferences on page 32.
Once you have answered the questions, your ONE XL will display the Driving
View. The Driving View is shown in black and white until your ONE XL locates
your current position.
For more information about the Driving View, see Driving View on page 13.
Locating your current position
Your TomTom ONE XL must be outdoors to locate your current position. The
first time you start your ONE XL, it can take up to 5 minutes to find your current
position. If it takes longer than 5 minutes, make sure that you are in an open
place without tall buildings or trees around you.
In the future, your position will be found much faster, normally within a few
seconds.
Once your ONE XL has located your current position, the Driving View is
shown in full color and shows your position on the map.
Finding your position faster
You can help your TomTom ONE XL to find your position faster by using
QuickGPSfix. QuickGPSfix contains information about the positions of the
GPS satellites. Using this information, your ONE XL can locate your position
very quickly.
To download QuickGPSfix, connect your ONE XL to your computer. TomTom
HOME downloads the information and transfers it to your ONE XL. This
information is updated reguarly, so make sure you connect to your computer
often.
5
You can also download QuickGPSfix directly to your device using a wireless
data connection on your phone. Your mobile operator may charge you for
using a wireless data connection.
Note: Your TomTom ONE XL does not transmit your position. You can,
however, send your position to TomTom Buddies. For more information, visit
www.tomtom.com/plus
Note: Some vehicles have a heat reflective shield embedded in the
windshield that may prevent TomTom ONE XL from locating your current
position. If this is a problem in your vehicle, use the TomTom External
Antenna Kit (available as an accessory).
6
Making your first trip4.
Making your first trip
Planning a route with TomTom ONE XL is very simple. To plan your first route,
follow the steps below.
Note: You should always plan your journeys before you start driving. It is
dangerous to plan routes when you are already moving.
1. Tap the screen to bring up the main menu.
2. Tap Navigate to...
For your first journey, we will navigate to an address.
3. Tap Address.
When you enter an address, you can choose from four options:
• City center - tap this button to set your destination as the center of a city
or town.
• Street and house number - tap this button to set an exact address as your
destination.
• ZIP code - tap this button to enter a ZIP code as your destination.
Note: You can enter a zip code for any country. In the UK and the Netherlands,
zip codes are detailed enough to identify a house on their own. In other
countries you can enter a zip code to identify a town or area. You will then
have to enter a street and address.
• Cross street or intersection - tap this button to set your destination as the
point where two streets meet.
7
For your first trip, we will enter an exact address.
4. Tap Street and house number.
5. Start to type the name of the town where you want to go.
As you type, the names of the towns that match what you have typed are
shown. When your destination is shown in the list, tap the name of the town
to set the destination.
6. Start to type the name of the street.
As with the name of the town, the names of the streets that match what you
have typed are shown. When your destination is shown in the list, tap the
name of the street to set the destination.
7. Now enter the house number of your destination and then tap Done.
8. Your ONE XL asks you whether you need to arrive at a particular time.
Tap YES to enter an arrival time. Your ONE XL shows you whether you will
arrive on time. For more information, see Arrival times on page 9.
The route is then calculated by your TomTom ONE XL.
9. When the route has been calculated, tap Done.
8
Arrival times
TomTom ONE XL will immediately start guiding you to your destination with
spoken instructions and visual instructions on the screen.
When you plan a route, your ONE XL asks you if you need to arrive by a
particular time:
Tap YES to enter an arrival time.
Your ONE XL calculates your arrival time and shows you whether you will
arrive on time.
You can also use this information to work out when you need to leave. If your
ONE XL shows you that you will arrive 30 minutes early, you can wait and
leave in 30 minutes time, rather than arrive early.
Your arrival time is constantly recalculated during your trip. The status bar
shows whether you will arrive on time or late, as shown below:
You will arrive 55 minutes before the arrival time you entered.
If the estimated arrival time is more than five minutes before
the time you entered, it is shown in green.
You will arrive 3 minutes before the arrival time you entered.
If the estimated arrival time is less than 5 minutes before the
time you entered, it is shown in yellow.
You will arrive 19 minutes late.
If the estimated arrival time is later than the time you entered,
it is shown in red.
9
What are the other navigation options?
When you tap Navigate to..., you can set your destination in many ways, not
just by entering the address. The other options are listed below:
Tap this button to navigate to your Home location.
You will probably use this button more than any other.
Home
Favorite
Recent
destination
Point of
Interest
Point on map
For information about setting your Home location, see Change Home
location on page 35.
Tap this button to select a Favorite as your destination.
For more information about Favorites, see Favorites on page 20.
Tap this button to select your destination from a list of places you have
recently used as destinations.
Tap this button to navigate to a Point of Interest (POI).
For more information about POIs and navigating to a POI, see Points of
Interest on page 24.
Tap this button to select a point on the map as your destination using the
map browser.
For more information about the map browser, see Using the Map on
page 18.
Tap this button to enter a destination with latitude and longitude values.
Latitude
Longitude
Tap this button to navigate to the current position of a TomTom Buddy.
Don’t forget that the Buddy may move before you reach him.
TomTom
Buddy
For more information about TomTom Buddies, see TomTom PLUS on
page 47.
Planning in advance
You can also use your ONE XL to plan trips in advance by selecting both your
starting point and your destination. You could, for example, do the following:
• Find out how long a trip is going to take before you start.
• Check the route of a trip you are planning.
• Check a route for someone who is coming to you and explain the route to
them.
To plan a route in advance, follow these steps:
1. Tap the screen to bring up the main menu.
10
Advanced
planning
2. Tap Advanced planning.
3. Select the starting point for your trip in the same way as you would normally
select your destination.
4. Set the destination for your trip.
5. Choose the type of route that should be planned.
• Fastest route - the route which takes the least time.
• Shortest route - the shortest distance between the locations you set. This
may not be the quickest route, especially if the shortest route is through
a town or city.
• Avoid freeways - a route which avoids freeways.
• Walking route - a route designed for making the trip on foot.
• Bicycle route - a route designed for making the trip on a bicycle.
• Limited speed - a route for a vehicle which can only drive at a limited
speed. You have to specify the maximum speed.
6. Your TomTom ONE XL plans the route between the two locations you
selected.
More information about a route
To find out about your route in detail, tap the Details button on the route
summary screen.
You can then select from the following options:
Tap this button for a list of all the turn instructions on the route.
This is particularly useful if you need to explain a route to someone else.
Browse as
text
11
Tap this button to see each turn in the trip. Tap the right and left arrows to
move forwards and backwards through the trip.
Browse as
images
Browse map
of route
Show route
demo
Show route
summary
Tap the screen to turn off the 3D display and view the map from above.
Tap this button to see an overview of the route using the map browser.
For more information about the map browser, see Using the Map on
page 18.
Tap this button to watch a demo of the trip. You can interrupt the demo at
any time by tapping the screen.
Tap this button to open the route summary screen.
You can access these options for the route you last planned by tapping View
route in the Main Menu.
12
Driving View
Driving View5.
A Buttons to zoom in and zoom out on your position.
B Your current position.
C The name of the next major road or road sign information, if applicable.
D The next instruction.
This area shows you what to do and when you will have to do it.
Tap this area to repeat the last spoken instruction and to change the
volume.
E The name of the next street to turn onto.
F Information about your trip.
Normally this area shows the remaining trip time, remaining distance, and
arrival time. To set which information is displayed, tap Status bar
preferences in the Preferences menu.
G Indicator of the strength of the GPS signal.
For more information about GPS, see How Does Navigation Work? on
page 51.
13
Menus
Main menu
Menus6.
Tap the screen at any time when TomTom ONE XL displays the Driving View
to open the Main Menu.
• Navigate to...
Tap this button to start planning a route.
• Find alternative...
Tap this button if you want to avoid part of your route, travel via a specific
location or calculate an alternative route.
• TomTom Traffic
Tap this button to enable or disable traffic information. For more
information, see TomTom Traffic on page 45.
• Add favorite
Tap this button to create a Favorite.
• Change preferences
This button opens the Preferences menu. You can change many things
about the way TomTom ONE XL looks and behaves. For more information,
see Preferences on page 32.
Hidden buttons and features
When you first start using your TomTom ONE XL, not all of the buttons will be
displayed in the menu.
Many buttons and some more advanced features are hidden because you will
not need these features very often.
To show all buttons and features, tap Show ALL menu options in the
Preferences menu.
14
To hide these buttons again, tap Show fewer menu options in the Preferences
menu.
15
Finding alternative routes7.
Finding alternative routes
Find alterna-
tive...
Calculate
alternative
Once you have planned a route, you may want to change something about the
route, without changing your destination.
Why change the route?
Maybe for one of these reasons:
• You can see a roadblock or a line of traffic ahead.
• You want to travel via a particular location, to pick someone up, stop for
lunch or fill up with gas.
• You want to avoid a difficult intersection or a road you don’t like.
Ta p Find alternative... in the Main Menu to change the route that is
currently planned.
Then tap one of the options below.
Tap this button to calculate an alternative to the route already planned.
Your ONE XL will look for another route from your current location to your
destination.
If you decide you would prefer to use the original route after all, tap
Recalculate original.
Avoid
roadblock
Why would I need to do this?
Apart from the roads near your position and near your destination, the new
route will use totally different roads to reach your destination. This is an
easy way of calculating a totally different route.
Tap this button if you can see a roadblock or a line of traffic ahead. You then
have to choose how much of the route ahead you want to avoid.
Choose from the different options: 100m, 500m, 2000m, 5000m. Your ONE
XL will recalculate your route avoiding the section of the route for the
distance you selected.
Don’t forget that once a new route is calculated, you may have to turn off
the road you are on very soon.
If the roadblock suddenly clears, tap Recalculate original to return to your
original route.
16
Tap this button to change your route so that it passes a particular location,
perhaps to pick someone up on the way.
Travel via...
Recalculate
original
Avoid part of
route
You choose the location you want to pass in the same way as you choose a
destination. So you can select from all the same options: for example,
Address, Favorite, Point of Interest and Point on map.
Your ONE XL will calculate a new route to your destination that passes the
location you chose.
Using this button, you can only travel via one location. If you want to pass
more than one, use an Itinerary. For more information, see Itinerary
planning on page 29.
Tap this button to return to the original route without any deviations for
roadblocks or to travel via particular locations.
Tap this button to avoid a part of the route. Use this button if you see that
your route includes a road or junction you don’t like, or which is wellknown for traffic problems.
You then choose the road you want to avoid from a list of the roads on your
route.
Tap this button to recalculate your route so that it avoids traffic problems as
much as possible. Your ONE XL will check if there are any traffic problems
on your route and work out the best route to avoid the problems.
Minimize
traffic delays
For more information about using TomTom Traffic, see TomTom Traffic on
page 45.
17
Loading...
