Chapter 1: Connections and Setup
Introduction
Residential Voice Gateway Features
z Support Multiple Provisioning Mode
z Standard RJ-45 connector for 10/100BaseT Ethernet with auto-negotiation and MDIS
functions
z USB Connector for USB interface
z Two RJ-11 Foreign Exchange Station (FXS) ports for IP telephony
z Support simultaneous voice and data communications
z Two simultaneous voice conversations in the different FXS ports with different CODEC:
PCM A-law, PCM-law, G.723.1, G.729, G.729a, G.729e, G.728, G.726, BV16 and BV32
z Echo Cancellation
z Voice Active Detection (VAD)
z DTMF detection and generation
z Comfort Noise Generation (CNG)
z Support V.90 fax and modem services
z Transparent bridging for IP traffic
z RSA and 56 bit DES data encryption security
z SNMP network management support
z Remote operating firmware downloading
z Support Web pages and private DHCP server for status monitoring
z Clear LED display
z Plug and Play
What’s on the CD-ROM
Insert the Residential Voice Gateway CD-ROM into your CD-ROM drive to view troubleshooting
tips, the internal diagnostics, and other valuable information.
Note: You might need to use the CD-ROM to install the USB driver if you are connecting via the
USB port.
Illustrations contained in this document are for representation only.
1
Chapter 1: Connections and Setup
CD-ROM Contents:
z Electronic copy of this user’s guide in additional languages (PDF format)
z Adobe Acrobat Reader — application you can load to read PDF format, if you don’t have
it loaded already
z USB drivers — required if connecting by USB
z Links to Thomson and RCA web sites
DOCSIS and PacketCable are trademarks of Cable Television Laboratories, Inc.
2
Chapter 1: Connections and Setup
Computer Requirements
For the best possible performance from your Residential Voice Gateway, your personal computer
must meet the following minimum system requirements (note that the minimum requirements
may vary by cable companies):
IBM PC COMPATIBLE MACINTOSH**
CPU Pentium preferred PowerPC or higher
System RAM 16MB (32MB preferred) 24MB (32MB preferred)
Operating System Windows* NT/2000/Me/XP,
Linux
Available Disk Space 125MB 50MB
Sound Card Required for audio on CD-ROM N/A
Video VGA or better (SVGA preferred) VGA or better (SVGA built-in
CD-ROM Drive Required Required
10BaseT or 100BaseT 10BaseT or 100BaseT Ethernet
An Ethernet card makes it possible for your computer to pass data to
and from the internet. You must have an Ethernet card and software
drivers installed in your computer. You will also need a standard
Ethernet cable to connect the Ethernet card to your Residential Voice
Gateway.
Mac OS** 7.6.1 or higher
preferred)
USB (Windows 2000/ME/XP only) USB Port
The Universal Serial Bus is a high speed bus that enables your
computer to communicate simultaneously with a variety of
peripherals. However, if you have other peripherals that send and
receive a lot of information, such as speakers, printers or scanners, we
recommend using an Ethernet card to support this modem.
Illustrations contained in this document are for representation only.
3
Chapter 1: Connections and Setup
Software • A TCP/IP network protocol for each machine
• Microsoft Internet Explorer 4.0 or later or Netscape Navigator 4.0 or
later. (5.0 and 4.7 or later, respectively, are strongly
recommended.)
*Windows is a trademark of Microsoft Corporation.
**Macintosh and the Mac OS are trademarks of Apple Computer, Inc.
Wall Mounting
The number of the screw: 2 pcs
Direction for wall mounting: LED panel upward.
Dimension for the screw: TBD
There are 4 slots on the underside of the EMTA that can be used for wall mounting.
Note: When wall mounting the unit, ensure that it is within reach of the power outlet.
You will need 2 suitable screws which screw diameter would be 4.4 mm to wall mount the Cable
Modem or the Battery Pack. Two different wall mount directions could be chosen for the Battery
Pack.
To do this:
1. Ensure that the wall you use is smooth, flat, dry and sturdy and use the 4 screw holes
which are 101.6 mm apart from each other.
2. Fix the screws into wall, leaving their heads 3 mm (0.12 inch) clear of the wall surface.
4
Chapter 1: Connections and Setup
3. Remove any connections to the unit and locate it over the screw heads. When in line,
gently push the unit on to the wall and move it downwards to secure.
Illustrations contained in this document are for representation only.
5
Chapter 1: Connections and Setup
Residential Voice Gateway TWG850 Overview
Front Panel
The following illustration shows the front panel of the TWG850 machine:
The LEDs on the front panel are described in the table below (from left to right):
Cable
Tel 2 Tel 1 WirelessMessage
Boot-up
Operation
Start-up
Operation
Normal
Operation
Operation
ON ON ON ON
0.25
ON
sec
ON FLASH X FLASH FLASH X X X From power ON to system initialization complete
ON ON ON
ON
1 sec
X X X OFF OFF OFF OFF FLASH
X X X OFF OFF OFF FLASH FLASH
X X X OFF OFF OFF FLASH FLASH
X X X OFF OFF FLASH FLASH FLASH
X X X OFF FLASH FLASH FLASH FLASH
X X X FLASH FLASH FLASH FLASH FLASH
X X Enter Normal Operation Mode Registration complete
X X X X X X X
X X X X X X
X X X X X
X X X X
X X X
X X
X X X X X Wink X X No service
X X X 3 seconds ON followed by a flash OFF
ON
X
OFF
ON
FLASH
Activity
0.25 second
1 second
FLASH
OFF
FLASH
X X X X X
Cable
Link
ON ON ON
OFF
FLASH
ON
OFF
X X X X
PC
Internet Description
Link
X X X
FLASH
ON
OFF
FLASH
ON
X X
X X X
Power on 0.25 sec
Following system initialization complete to (before) DS
scanning
Tuning
(Searching downstream signal)
Ranging - Awaiting Response
(DS carrier acquire, ranging in process but RNG-RSP has
not been detected)
Any RNG-RSP detected
(Normalizing power level and timing offset)
Connecting
(Ranging complete, DHCP in progress)
Configuring (DHCP complete, configuration file download
in process)
Registering and Baseline Privacy Initializing
(configuration file download complete, initialize BPI if BPI is
ON, registration in process)
NO Cable Link
CM is registered
NO Ethernet/USB carrier present
X
Ethernet/USB TX/RX traffic
Ethernet/USB carrier present, no traffic
NO Cable Link
Cable BSS/OSS has set the CM into de-activated state
CM is registered
Internet ON-OFF switch off/No RF DS/US network traffic
RF DS/US network traffic
No message is delivered by the MSO
Email is available fro the user on the server
(Implementation of the message waiting LED will be via
Proprietary MIB)
Wireless initiate fail or disable
Wireless initiate success or enable
TX/RX Wireless Traffic
NACO =OFF
BPI unauthorized (when BPI is ON)
6
Tel 2 Tel 1 WirelessMessage
MTA
initialization
MTA
Operation
Download
Operation
OFF FLASH MTA DHCP
FLASH OFF MTA SNMP/TFTP
FLASH FLASH RSIP
ON ON Both Lines On-Hook
ON FLASH Tel1 Off-hook, Tel2 On-hook
FLASH ON Tel1 On-hook, Tel2 Off-hook
FLASH FLASH
X X X FLASH FLASH FLASH FLASH FLASHSW
X X X From Right to Left
Rear Panel
Chapter 1: Connections and Setup
Cable
Cable
Activity
<CM Normal Operation>
Link
PC
Link
Internet Description
Both Lines Off-Hook
A software download and while updating the FLASH
memory
15VDC: 15V DC-IN Power connector
TEL1 & TEL2 Telephony RJ-11 connector
ETHERNET: Ethernet 10/100BaseT RJ-45 connector
USB: USB Connector
REBOOT EMTA: Reboot this Residential Voice Gateway
CABLE: F-Connector
Illustrations contained in this document are for representation only.
7
Chapter 1: Connections and Setup
Residential Voice Gateway DWG855 Overview
Front Panel
The following illustration shows the front panel of the DWG855 machine:
The LEDs on the front panel are described in the table below (from left to right):
Power
Boot-up
Operation
DOCSIS
Start-up
Operation
MTA
initialization
Operation
8
Internet Ethernet
DS US Online 1 2 3 4
ON ON ON ON
ON 0.25 second
ON FLASH FLASH FLASH X X X X X X X X X
ON ON ON
ON
1 second
ON FLASH OFF OFF X X X X X X X X X
ON ON FLASH OFF X X X X X X X X X
ON ON ON FLASH X X X X X X X X X
ON ON ON ON X X X X X X X X X Operational (NACO=ON)
ON FLASH FLASH OFF X X X X X X X X X Operational(NACO=OFF)
ON ON ON ON X X X X FLASH OFF OFF X X MTA DHCP
ON ON ON ON X X X X OFF FLASH OFF X X MTA SNMP/TFTP
ON ON ON ON X X X X FLASH FLASH OFF X X RSIP
ON X X X
ON X X X X X X X X X X X
ON ON ON ON ON ON X ON ON Power on 0.25 sec
X X X X X X X X X
OFF
OFF
OFF
ON
ON
ON
FLASH
FLASH
FLASH
FLASH
ON
ON
ON
Tel 1 Tel 2 Battery Wireless USB Description
OFF
ON
ON
X X X X X
OFF
ON
FLASH
ON
From power ON to
system initialization
complete
Following system
initialization complete
to (before) DS scanning
During DS scanning and
acquiring SYNC
From SYNC completed,
receiving UCD to
ranging completed
During DHCP,
configuration file
download, registration,
and Baseline Privacy
initialization
No Ethernet Link
Ethernet Link
TX/RX Ethernet Traffic
Ethernet Collision CPE
No USB Link
USB Link
TX/RX USB Traffic
USB driver is not ready
Chapter 1: Connections and Setup
Power
CPE
Operation
AC Good
Battery Good
AC Good
Battery Low
AC Good
Battery Bad
AC Fail
Battery Good
AC Fail
Battery Low
AC Fail
Battery Bad
Internet Ethernet
DS US Online 1 2 3 4
ON X X X X X X X X X X
ON ON ON Both Lines On-Hook
ON FLASH ON
ON ON FLASH
ON FLASH FLASH
ON ON ON Both Lines On-Hook
ON FLASH ON
<CM Normal Operation>
ON ON FLASH
ON FLASH FLASH
ON ON ON Both Lines On-Hook
ON FLASH ON
ON ON FLASH
ON
FLASH OFF
< All LEDs may be unlit due to lack of battery power>
Tel1 Tel2 Battery Wireless USB Description
OFF
ON
FLASH
ON
ON
FLASH
FLASH FLASH
ON Both Lines On-Hook
FLASH
ON
FLASH
ON Both Lines On-Hook
FLASH
FLASH
OFF
ON
FLASH
<CM Normal
OFF
OFF
< All LEDs may
be unlit due to
OFF
lack of battery
Operation>
OFF
power>
No Wireless Link
Wireless Link
X
TX/RX Wireless Traffic
Wireless is not installed
or disable
Tel1 Off-hook, Tel2
On-hook
Tel1 On-hook, Tel2
Off-hook
Both Lines Off-Hook
Tel1 Off-hook, Tel2
On-hook
Tel1 On-hook, Tel2
Off-hook
Both Lines Off-Hook
Tel1 Off-hook, Tel2
On-hook
Tel1 On-hook, Tel2
Off-hook
Both Lines Off-Hook
Tel1 Off-hook, Tel2
On-hook
Tel1 On-hook, Tel2
Off-hook
Both Lines Off-Hook
Tel1 Off-hook, Tel2
On-hook
Tel1 On-hook, Tel2
Off-hook
Both Lines Off-Hook
Both Lines On-Hook
Tel1 Off-hook, Tel2
On-hook
Tel1 On-hook, Tel2
Off-hook
Both Lines Off-Hook
SW
Download
Operation
ON FLASH FLASH ON X X X X X X X X X
Illustrations contained in this document are for representation only.
A software download
and while updating the
FLASH memory
9
Chapter 1: Connections and Setup
Rear Panel
TEL1 & TEL2 Telephony RJ-11 connector
ETHERNET 1-4: Ethernet 10/100BaseT RJ-45 connector
USB: USB Connector
REBOOT EMTA: Reboot this Residential Voice Gateway
CABLE: F-Connector
Rating 100-240V: Power connector
Installing the Battery
This section provides you information of installing batteries into the modem. Follow the steps
below:
1. Unplug the power cord of the power adapter from the modem if you have plugged it.
2. Remove the cover of the rear panel. There are two spare drives for you to install the
battery.
10
Chapter 1: Connections and Setup
3. Insert the battery into the rear battery drive with the direction that the following picture
shows.
4. Put back the cover of the rear panel.
5. Now, the cable modem is on with the power of the battery. It is not necessary for you to
use power adapter again.
Illustrations contained in this document are for representation only.
11
Chapter 1: Connections and Setup
Relationship among the Devices
This illustration shows a cable company that offers DOCSIS- and PacketCable-compliant
voice/data services.
What the Modem Does
The Residential Voice Gateway provides high-speed Internet access as well as cost-effective,
toll-quality telephone voice and fax/modem services over residential, commercial, and
education subscribers on public and private networks via an existing CATV infrastructure. It can
inter-operate with the PacketCable compliant headend equipment and provide the IP-based
voice communications. The IP traffic can transfer between the Residential Voice Gateway and
DOCSIS compliant headend equipment. The data security secures upstream and downstream
communications.
What the Modem Needs to Do Its Job
The Right Cable Company: Make sure your local cable company provides data services that
use cable TV industry-standard Euro-DOCSIS or DOCSIS-compliant and Euro-PacketCable
or PacketCable-compliant technology.
12
Loading...
