PBC (VCD)
The Playback Control function offers scenes and information which can be selected
interactively via a menu. It can also be used to display high-resolution pictures, if the disc
contains any.
Press the DVD MENU button to access the PBC menu and the PBC button to turn the PBC
function on and off.
Search function
Press SEARCH and then directly input with the number entry keys to select track, chapter or
file for playback. Press ENTER to confirm.
For DVD disc : TT --- CH--- (input desired title and chapter)
For VCD /CD disc: Disc go to --:--:-- (input desired time of disc)
Track go to--:--:-- (input desired time of track)
Select track -- (input desired track number)
For MP3/JPG disc: --- (input desired file number)
Other Connection Options
Front Panel Controls
English
Basic Playback Operations
It is important to read this instruction book prior to using your new product for the first time.
DVD Player
DTH160E
DTH161B
user
manual
EN
THOMSON
46, quai Alphonse Le Gallo
92648 Boulogne
Cedex FRANCE
5639 6410 (EN)
www.thomson.net
Connections & Setup
Safety Information Important Information
WARNING:
TO PREVENT FIRE
OR ELECTRICAL
SHOCK HAZARD,
DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROWHEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
The descriptions and characteristics in this owner’s manual are for the purpose of general reference only and not
as a guarantee. In order to provide you with the highest quality product, we may make changes or modifications
without prior notice. The English version serves as the final reference on all product and operational details
should any discrepancies arise in other languages.
MAINS CONNECTIONS
MAINS OUTLET POWER SUPPLY: 230V ~50Hz
Note: Power is fed to the unit even when it is not functioning. To
cut the power supply off, the power cable must be unplugged.
Note: The mains plug is used as the disconnect device and it shall
remain readily operable and easily accessed by the user during the
apparatus is in intended use.
In accordance with the rating plate of the unit, this unit complies with current
standards concerning electrical safety and electromagnetlc compatibillity.
Please respect the environment. Before throwing any batteries away, consult your
distributor who may be able to take them back for specific recycling.
This symbol means that your inoperative electronic appliance must be collected
separately and not mixed with the household waste. The European Union has
implemented a specific collection and recycling system for which manufacturers
are responsible.
This appliance has been designed and manufactured with high quality materials and
components that can be recycled and reused.
Electrical and electronic appliances are liable to contain parts that are necessary in order for
the system to work properly but which can become a health and environmental hazard if
they are not handled or disposed of in the proper way. Consequently, please do not throw
out your inoperative appliance with the household waste.
If you are the owner of the appliance, you must deposit it at the appropriate local
collection point or leave it with the vendor when buying a new appliance.
• If you are a professional user, please follow your supplier’s instructions.
• If the appliance is rented to you or left in your care, please contact your service provider.
Help us protect the environment in which we live!
CAUTION - LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM.
CLASS 1
LASER PRODUCT
You can contact THOMSON by dialling: 0871 712 1312
(for United Kingdom, £0.10/mn inc VAT)
www.thomson-europe.com
HELPLINE
Some points to check before you connect your TV set
• Ensure that the mains supply in your house complies with that indicated on the
identification sticker located on the back of your appliance.
• Install your appliance horizontally, away from any source of heat (fireplace) or appliances
generating strong magnetic or electric fields. The components of this appliance are
sensitive to heat. The maximum ambient temperature should not exceed 35° Celsius.
• Leave sufficient space around the appliance to allow adequate ventilation: 10 cm on
either side and at the back, as well as 7 cm above it are ideal.
• The humidity of the room should not exceed 75%. If you have to use the appliance
outdoors, do not expose it to rain or splashing water. The appliance should not be
exposed to dripping or splashing and no objects filled with liquids, such as vases, should
be placed on top of it.
• Moving it from a cold environment to a warm one is likely to cause condensation on
some components inside the appliance. Let the condensation disappear of its own accord
before turning the appliance on again.
• Before moving the player, make sure the disc tray is empty.
2. VIDEO OUT socket
This socket (yellow) is also known as a composite video socket. The video cable (not supplied)
usually comes with two audio cables (white and red). The picture quality obtained using a
video connection is poorer compared to that obtained using a Scart connection.
3. AUDIO L (left) and AUDIO R (right) sockets
These are analogue audio output sockets. The AUDIO L socket and cable are white, while the
AUDIO R socket and cable are red. Connect the DVD player’s AUDIO L and R sockets to the
television set’s AUDIO L and R sockets using audio cables (not supplied).
Note: If your television set only has one audio socket connect it to the DVD player’s left
socket (white).
4. Coaxial digital audio output (COAXIAL)
This socket offers a higher level of sound quality compared to that provided using an
analogue audio connection. For 6-channel multichannel sound, connect the audio/video
amplifier or receiver to this socket using a coaxial cable (not supplied).
Remote Control
Inserting batteries in the remote control
Insert a CR2025 battery in the remote control.
• Observe the polarities indicated inside the battery compartment. Replace only with
the type of batteries specified above. Do not dispose of them in a fire or recharge
them.
• If you are not using the remote control for a long period of time, remove the
batteries.
• Please respect the environment and prevailing regulations. Before you dispose of
batteries or accumulators, ask your dealer whether they are subject to special
recycling and if they will accept them for disposal.
2 4 3 1
Play ModesBasic Playback Operations
Basic Connections
Advanced Functions
1. Basic connections (DVD player + TV + video recorder)
1. Connect the DVD player Scart socket (TV AUDIO VIDEO OUT) to the television set’s Scart
socket (AV1, EXT1, AUX1) using a Scart lead (not provided).
- OR -
1. If your television set does not have two Scart sockets, connect the DVD player to the
video recorder’s AV2 socket using a Scart lead (not provided). If you have a satellite or
cable receiver you can also connect the DVD player to the receiver’s second Scart socket.
Note: If your video recorder only has one Scart socket, but has a modulator, use the aerial
cable to connect the video recorder to the television set, adjust the video recorder’s
modulator, then connect the DVD player to the video recorder’s Scart socket.
2. Connect the video recorder (or satellite receiver) to the television set as shown in the
video recorder’s (or satellite receiver’s) user guide.
3. Connect the DVD player to the mains socket using the mains lead.
4. Switch on the devices.
Note: If one of the devices is not working, check that all the cables have been inserted
properly into the sockets which they should be connected to.
1
3 2 4
ON/STANDBY ON/OFF Function
CLEAR Clears some functions.
DISPLAY Provides playback status.
MUTE Lowers and restores the volume.
0 - 9 Number entry.
REPEAT Accesses the Repeat playback mode.
A-B Accesses the A-B repeat playback
mode.
PAUSE/STEP Freezes frame, frame advance.
OPEN/CLOSE Opens and closes the tray.
REV Searches back through the disc.
FWD Searches forward through the disc.
STOP Stops playback.
ANGLE Accesses the camera angle.
ZOOM Accesses the Zoom feature
(if available).
Navigates through the menus.
Advances to the next/ preceding
chapter or track.
ENTER/PLAY Selects item highlighted in menu.
Starts playing a disc.
SEARCH Goes to a specific play time or track
SETUP Accesses and exits the General
Setup (main) menu.
SUBTITLE Turns the subtitle on and off.
TITLE Accesses the title of the disc
PBC For VCD Disc, selects PBC
AUDIO Selects the audio language.
DVD MENU Accesses the disc’s menu (if available).
To access the PBC menu for VCD disc.
1 SENSOR - Remote sensor. Point the remote control here.
2 OPEN/CLOSE - To open and close the disc tray.
3 STOP - To stop disc playback. To switch the appliance on and off.
4 PLAY - To start playing a disc.
Operating the DVD player
1. Switch on your TV set.
2. Press the ON/STANDBY button on the remote control or press and hold the STOP button
located on the DVD player’s front panel.
Playback
1. Press the OPEN/CLOSE button on the front of the appliance or on the remote control to
open the disc tray.
2. Put the disc in with the printed side upwards (in the case of a single-sided disc).
3. Press OPEN/CLOSE again to close the disc tray. Play starts automatically. If a menu
appears, one of its options can be selected to start playing the disc. Select it and press
ENTER.
4. Press STOP to stop playback.
Notes: The player stores the point where playback was interrupted. If you press PLAY
again, playback resumes from this point. To stop playback completely or to start again
from the beginning, press STOP twice.
If the player is left in STOP mode for more than five minutes without any user interaction,
a screen saver is activated.
Accelerated play
While the disc is playing, press the REV or FWD button one or more times to vary the speed
and direction of the accelerated play.
Still image
While the disc is playing, press PAUSE once for freeze frame.
Note: After five minutes in PAUSE with no user interaction, the player goes into screen
saver mode.
Frame advance (all discs except audio CD, mp3, WMA and DivX)
1. While the disc is playing, press PAUSE once.
2. Press PAUSE a number of times to advance forward image by image.
3. Press PLAY to resume normal playback.
Variable slow motion (DVD and VCD only)
1. While the disc is playing, press PAUSE once.
2. Press the REV or FWD button a number of times to vary the speed and direction of the
slow motion.
3. Press PLAY to resume normal playback.
Note: Reverse slow motion is not possible with a Video CD.
Changing chapter/track
While the disc is playing, press the / button to go immediately to the next or previous
chapter, or to the next or previous track.
For audio CD and VCD only: enter the track number with the number buttons and then
press ENTER.
Zoom (DVD, VCD, DivX and JPEG discs only)
1. While a disc is playing, press ZOOM until you reach the zoom size you require.
2. Move from one area to another using the buttons.
Note: for JPEG discs, press ZOOM and then REV or FWD until you reach the zoom size
you require. Press ZOOM again to quit the zoom function.
Repeat playback
While the disc is playing, press the REPEAT button repeatedly to select a play mode:
DVD: Repeat Chapter, Repeat Title, Repeat Off;
VCD and audio CD: Repeat Track, Repeat All, Repeat Off;
A-B repeat
To repeat a sequence between two points A and B, press A-B at the beginning of the
sequence you want to repeat. Then press A-B again at the end of the sequence.
The sequence is played repeatedly until you press A-B to resume normal playback.
Advanced Functions
Audio (DVD, VCD and audio CD)
Some discs have several audio tracks used for different languages or different audio formats.
To change the language or audio format during play, press the AUDIO button one or more
times to select one of the available audio formats or languages.
Note: This option is only available if the disc offers a number of dialogue languages or
audio formats.
Status menu
Press the DISPLAY button a number of times during playback to show in turn:
DVD: Title elapsed time, Title remaining time, Chapter elapsed time, Chapter remaining
time, Display Off.
VCD and audio CD: Single elapsed time, Single remaining time, Total elapsed time, Total
remaining time, Display Off.
mp3 and DivX: Single elapsed time, Single remaining time.
mp3, WMA, JPEG & DivX Files
mp3 is an audio file format which compresses recorded music. It was developed in
collaboration with THOMSON . The main advantage of the mp3 format is that it means CDquality music tracks can be stored on a personal computer in user-friendly compressed files.
WMA (Windows Media Audio) is another audio file format developed by Microsoft.
JPEG files are image files. Make sure that they have a resolution of less than 5 megapixels.
Your player is an Official DivX Certified™ product that plays DivX®5, DivX®4, DivX®3, and
DivX®VOD video content, in compliance with DivX Certified™ technical requirements.
Displaying JPEG files or playing mp3 or WMA or DivX files
Before inserting a disc, check that it is compatible with the player.
1. Open the tray by pressing the OPEN/CLOSE button.
2. Place the disc with the printed side facing up and close the tray. The disc’s contents are
displayed.
3. Select a folder using the buttons on the remote control, then press ENTER to see
the folder’s contents.
4. Select a file using the buttons on the remote control, then press ENTER to start
playback.
5. Press the STOP button to stop playback.
6. To go back to the folder list, press the button in stop mode.
Note: During playback you can use the / button to go back to the previous file or
go on to the next one.
Audio cable (red
and white)
Video cable
(yellow)
Coaxial cable
Player Menus
mp3, WMA, JPEG & DivX Files
Player Menus
Menu Language
To change the language of the player menus, choose the language using the buttons
and press ENTER to confirm.
VOD
Refer to “To rent (or purchase) DivX VOD files”.
The Dolby Digital Setup menu
Dolby and the double-D symbol are trademarks of Dolby
Laboratories. Manufactured under license from Dolby Laboratories.
Dynamic
You can use this function to control the different sound levels via dynamic compression. It
improves the quality of the sound track at a low volume and quietens the loudest sounds.
Select an option using the buttons, and press ENTER to confirm.
Note:This function is available only on DVD discs recorded in Dolby Digital.
Player Menus
Player Menus Additional Information Additional Information
Trou bleshooting
The appliance does not switch on.
• Make sure it is plugged into a mains
socket.
• Press the button on the remote
control or the STOP button on the
front of the appliance.
It is impossible to read the disc.
• Insert the disc with the printed side
facing up.
• Check that the disc can actually be
played by this device (see below).
• Check that the disc’s regional code
matches the player’s regional code.
This player’s regional code is 2.
• Clean the disc (see below).
There is no picture.
• Check you have switched on the TV
set.
• Check the connections.
• Select the AV input assigned to the
player on the TV.
The picture is of poor quality (with
snow or lines).
• Check the connections.
There is no sound or the sound is of
poor quality.
• Check the connections.
•Turn on the audio equipment
connected to the player, if any.
The remote control does not work or
works only intermittently.
• Check that batteries are inserted or
change them.
• Aim the remote control at the appliance.
The infrared beam must not be blocked or
interrupted.
The subtitles do not appear.
• Check that the DVD disc provides subtitles.
• Refer to the section on how to display
subtitles.
The disc menu language is not the
correct one.
• The disc menu language has not been set
up.
• The language of your choice is not
available on the disc.
You have forgotten your password
(Parental control).
• Open the disc tray, press CLEAR and then
enter 00001 with the numeric buttons.
Turn off the player and then turn it on
again.
Precautions
Use
• If your appliance has been stored in a cool place for any length of time, during a journey
for example, wait for about 2 hours before using it.
• The openings located on the top and bottom are for ventilation and must not be
obstructed.
• During thunderstorms, we recommend that you isolate the appliance from the electrical
supply so that it is not damaged by electrical or electromagnetic surges.
• This appliance is designed for continuous use. Switching off the DVD player to stand-by
mode does not disconnect it from the mains supply. To completely isolate the equipment,
remove the plug from the mains socket as some components remain connected to the
electrical supply.
• If you notice any burning or smoke, disconnect the appliance immediately to avoid any
risk of electrocution.
• Do not attempt to look inside the appliance through the disk tray opening or any other
opening. You may be electrocuted or exposed to laser radiation.
• This appliance is for domestic use only and must not be used for industrial purposes.
•Total or partial copying of recordings protected by copyright legislation, without the
explicit permission of the holder of the rights, contravenes current legislation. Copying or
downloading music files for sale or any other business purpose constitutes or could
constitute a violation of copyright law.
Cleaning
• Use a soft, dry, clean cloth. Regularly dust the vents at the back or sides.
• Using solvents, abrasive or alcohol-based products risks damaging the appliance.
• If an object or liquid enters inside the appliance, unplug it immediately and have it
checked by an authorised engineer.
Handling and caring for discs
• Handle your discs with care. Hold the disc with your fingers at the edges or through the
hole.
• Insert the disc with the label facing up (for a single-sided disc).
• Place the disc properly into the tray in the allotted holder.
• Use a soft cloth to clean discs if necessary, always wiping from the centre to the edge.
• Always put discs back in their cases after use and store in a vertical position.
• Do not close the tray with two discs in it or with a disc not sitting correctly in the holder.
• Do not play cracked, chipped or warped discs nor try to repair them with adhesive tape or
glue.
• Do not write on a disc.
• Do not move the player when a disc is being played.
• Do not scratch discs or store them in places exposed to direct sunlight, high humidity or
high temperatures.
• Do not use aerosol cleaners, benzene, anti-static liquids or any other solvent for cleaning
discs. When cleaning, wipe gently with a soft damp (water only) cloth from the centre to
the edge, avoiding circular motions, which could cause scratches and interference during
playback.
Additional Information
Guarantee
• The type and production number of your appliance are printed on the guarantee
certificate supplied with your appliance. Keep this certificate as well as the invoice. These
documents are required in the event of claiming your guarantee rights.
• All repairs during the guarantee period must be carried out by an authorised engineer for
our brand. If this condition is not met, your rights will no longer be valid.
• Never open the appliance yourself, since this may put you at risk or damage the
equipment. THOMSON does not accept any liability if the appliance is used in any way
other than in accordance with this manual.
DISCLAIMER OF WARRANTIES: TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, DECLARATIONS AND WARRANTIES OF NON-INFRINGEMENT OF COPYRIGHT OR
OTHER INTELLECTUAL PROPERTY RIGHTS RESULTING FROM THE USE OF THE PRODUCT
IN CONDITIONS OTHER THAN THOSE SPECIFIED ABOVE ARE HEREBY DISCLAIMED.
Discs and files you can play
In spite of progress made to ensure playability of all discs types, it is not possible to
guarantee playback of discs which are not in conformity with DVD, CD, VCD or SVCD
standards. This unit may not play some recordings or files on CD-R, CD-RW, DVD-R, DVD-RW,
DVD+R, DVD+RW due to differences in recording formats, software used and disc types.
DVD-Video, DVD-R, DVD-RW, DVD+R, DVD+RW, VCD - Video Compact Disc, SVCD - Super
Video Compact Disc, Audio CDs, CD-R, CD-RW, DivX files, mp3 files, WMA (Windows Media
Audio) files, Kodak Picture CDs, JPEG files
Additional Information
DVD copy protection
In accordance with the DVD standard, your DVD player is equipped with a Copy Protection
system, which can be switched on and off by the DVD disc itself, in order to make any
recording of the relevant DVD disc onto a videotape of very poor picture quality, or even
impossible. “This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for home use
only unless otherwise authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.”
Note on DivX files
Before playing DivX or mpeg4 files, please be sure of their origin and that you have legally
purchased or rented the contents. Pirate copying is illegal and may result in sanctions. Private
copies of your own material for your own use may be legal in some countries. Make sure you
are aware of any applicable laws.
DTS - is a digital sound compression technique developed by Digital Theater Sound Systems
for digital audio multichannel signals. “DTS” and “DTS Digital Out” are registered
trademarks of Digital Theater Systems inc.
Technical data
Power requirements: AC 230V, 50 Hz
Power consumption: 15W
Net Weight: 1.1 kg
Operating temperature: 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity: 5 % to 90 % (no condensation)
THOMSON Multimedia Sales Europe
46, quai A. Le Gallo
92648 Boulogne Cedex
FRANCE
322 019 464 RCS NANTERRE
http://www.thomson-europe.com
© Copyright THOMSON 2006
In case of malfunction due to electrostatic discharge, reset the apparatus by
disconnecting from mains supply.
DVD+Rewritable
mp3, WMA, JPEG & DivX Files
Playing JPEG and mp3 music files at the same time
You can display JPEG files while listening to mp3 music files recorded on the same disc.
1. Insert the disc containing the two types of file in the player.
2. Select an mp3 music file using the buttons, then press ENTER to confirm your
selection.
3. Then select a JPEG image file using the buttons, then press ENTER to confirm your
selection.
Note: To delete your selection, press the CLEAR button.
4. Press ENTER to start playing the two files at the same time.
5. Press the STOP button to stop playback.
Repeat playback
While the disc is playing, press the REPEAT button repeatedly to select a play mode:
JPEG, mp3 and WMA: Repeat One, Repeat Folder, Folder (=Off),
DivX: Repeat One, Repeat All, Repeat Off.
To rent (or purchase) DivX®VOD files
DivX VOD files are downloaded after paying a rental from certain commercial websites. Prior
to downloading a VOD you need to input the registration number of your DVD player on the
purchase form on the site.
Follow the instructions below to find the registration number of your player: press the SET
UP button. Select the VOD option from the General Setup Menu and press ENTER.
Write down this VOD 8-character registration number so that you can fill in the form on the
website you purchase your DivX VOD files from.
Note: If you cannot play a DivX VOD file recorded on a CD-R disc after downloading it,
the rental period allocated during purchasing from the website may have expired. It is
also possible that the recorded file is not compatible with your player because of
different versions or incorrect download parameters.The parameters used when copying
to CD-R may be another reason for this. Since it is not possible here to supply all the
information, parameters and advice relating to the use of DivX VOD files, we recommend
that you visit specialist websites such as www.divx.com/vod.
In order to display properly subtitles in some Eastern European languages, you need to
select the correct character set. During DivX playback, press several times the TITLE/
MENU button on the remote control to choose a character set: Czech, Slovak, Hungarian,
Polish or Default (for Western European language)
Using the player’s menus
Press the SET UP button to display the player’s main menu. Select a menu icon using the
buttons. Then select one of the available options using the buttons. Press the button
to access the submenu and use the buttons to select an option. Then press ENTER to
confirm your selection. Return to a previous menu using the button.
To exit from the player menus, press the SET UP button again.
The General Setup menu
TV Display
Depending on the format of the DVD disc, you can choose the picture format best suited to
the format of your TV screen.
Select a format using the buttons and press ENTER to confirm:
Normal/PS: reproduces a 4:3 picture without distortion,
Normal/LB: gives best reproduction of pictures recorded in this format (i.e. with horizontal
bands at the top and bottom of the screen) or in 16:9,
Widescreen: reproduces 16:9 format films in full on a 16:9 screen.
TV Type
In addition to PAL DVDs and VCDs, you can enjoy NTSC films as well (a 50Hz or 60Hz PAL
compatible TV set is required). If the pictures from the DVD being played appear in black and
white on your screen, try changing the colour standard.
Set the function to PAL or NTSC and press ENTER to confirm.
The Preferences Setup menu
Note: The Preferences Setup menu is not available when there is a disc in the player.
Audio
To change the dialogue language, choose the language using the buttons and press
ENTER to confirm.
Subtitle
To change the subtitle language, choose the language using the buttons and press
ENTER to confirm.
Disc menu
To change the language of the disc menus, choose the language using the buttons
and press ENTER to confirm.
Ratings
You can control access to the player and the type of discs your family can watch with the
rating function. There are eight levels of parental control.
Note: The disc publisher is responsible for coding scenes according to the rating limits. In
Europe, very few discs have coded scenes.
1. Select the rating level using the buttons.
2. Press ENTER to enter the Password Setup menu.
Note: To access the Ratings submenu, you must input a four-digit password. If you have
not chosen one yet, you are prompted to do so when you try to access it (see option
Password).
Password
This option allows you to set or change the password.
1. Press ENTER to enter the Change Password menu.
2. To change the password, enter the current four-digit password in the “Old Password”
box. Then enter the new password in the “New Password” box. You are then prompted
to enter it again in the “Confirm Password” box to confirm and press ENTER.
Note: Password is not defined until you set it.
Additional Information
Additional Information
Regional coding
Your DVD player has been designed to process regional management information that
is stored on DVD discs. DVD discs that have different regional codes to that of your
player cannot be played. The regional code for your player is 2 (Europe, the Middle
East, South Africa, Japan). ALL means all regions. When you buy a disc check that it
bears the correct logo.
Loading...
