Thomson DF421C, DS521E, DS521EF User Manual
Manuel
d’utilisation
Bedienungsanleitung
Manuale di
utilizzazione
User
manual·
Manual de
utilización
Gebruiksaanwijzing
·
·
·
·
·
DF 421 C - DF 421 E - DS 521 E - DS 521 EF
Bruksanvisning
Betjeningsvejledning
Folheto de
utilização
·
·
·
10 cm
10 cm
5 cm
10 cm
About this manual
This document is common to several television models. Therefore, certain functions or settings may not apply to
the model you have purchased
About the switch
The position of theON/OFF switch differs depending on the model. It may be located on the front or on the
right-hand side of your set (see the drawing inside the cover page of your manual).
About safety
To ensure your own safety and safe operation of the equipment, observe the following instructions
thoroughly.
TV setsrequire sufficient ventilation toprevent theircomponents fromoverheating, whichwill cause failure.Do not
block the ventilation openings at the rear. If you place yourTV set in a special piece of furniture, make sure there
is enough space for unhindered air circulation. Do not place the TV set in the close vicinity of a heater.
The TV set has beendesigned foruse indry rooms. Should you useit, in exceptional circumstances in the open
air (example: on the balcony, in the veranda or tent), you must absolutely protect it against moisture (dew, rain,
splash water). Before switching on a cold TV set in a warm room, you should wait until any condensation in the
screen has dried by itself.
Maximum ambient temperature: 35°C
Maximum humidity: 85%
By the end of your TV evening or when away from home for alonger period, we recommend that youturn off the
TV set with the On/Off-switch.
The mains plug must be easily accessible.
In the following cases, we recommend that you pull out the mains connector:
1. Duringa thunderstorm. Insuch acase, itis advisablethat youalsodisconnect theTV set fromthe aerial socket.
2. When odour or smoke emanates from the set.
Never attempt to open your TV set yourself.
Further information:
The TV set shielding is sufficient to prevent X-radiation to the exterior .
Any operation performed by a non skilledperson, change of high voltage or replacement of the picture tube by a
model not complying with the manufacturer specification are likely tocause considerable increase in X-radiation.
A TV set modified in such a way no longercomplies with the manufacturers’ specification and must not be used.
GB
About cleaning
The screen is to be cleaned with liquid glass cleaners.
:
Never use abrasive products.
:
Clean the cabinet with a soft cloth soaked with neutral cleaner. Do not use solvents, such as white spirit or
alcohol-based cleaning products since they may damage your television.
:
At regular intervals, clean the ventilation grids at the rear of the TV set.
About degaussing
The terrestrial magnetic field may have an influence on your TV set. This influence is revealed by the coloured
spots, which appear on the screen.
Should this be the case:
:
Turn the equipment off by means of the On/Off-switch.
:
Wait about one hour before switching the set on again.
This procedure performs automatic degaussing of thescreen. Should therestill becoloured spots onthescreen,
repeat the operation.
The pages of this publication are printed on recycled paper.
1
Contents
GB
Using the remote control
and fitting the batteries.
Page 4
About this manual 1...................
About the switch 1.....................
About safety 1........................
About cleaning 1......................
About degaussing 1...................
Basic connections 3....................
Installation
Remote control 4.......................
Navigation principles 5.................
Calling up the INSTALLATION
MAIN MENU 5........................
Calling upthe SUMMARY 5.............
Calling upa Menu 5...................
Navigating within the Menus 5...........
Installingyour television for
the first time 6.........................
Automatic installation 7.................
Programme organisation 8..............
Manual programming 9.................
Personal settings 10...................
Preferences 11........................
How to call up a menu
and how to select a
function, a setting or an
option.
Page
Daily viewing 12.......................
Picture Adjustment 12................
Sound Settings 12....................
Time 13.............................
List of Channels 14...................
Selecting Programmes 15.............
Scrolling the Programmes 15...........
Audio-visual (AV) Programmes 15......
Volume Control 15....................
Muting the Sound 15..................
Zoom (16/9 models only) 15...........
Instructions for Use
Displaying Information 15..............
Television Lock 15....................
Switching Off the Television 15.........
Teletext 16............................
Standard Functions 16................
Other Connections 17..................
Other Poss ibilities 17.................
Connecting a HiFi or AV amplifier 17....
5
/I6.3/B
GB-TBA
/
100
/
BASIC
C17 /
2
Basic connections
Basic connection s
The mains plug (1) supplies power to the television. The
television must only be plugged in to a 220-240 V - 50 Hz
power supply.It must never beplugged in to aDC source. If
the plug comes away from the lead, never attempt to plug it
in: this could cause electrocution.
Theaerialsocket (2),locatedon therear ofthetelevision, can
be used to connect an external aerial or other appliance
equipped with amodulator such as aVCR, satellite receiver,
etc.
If you connect an appliance to the aerial jack, you must give
it achannel number.To dothis,switch onthe appliance, then
use the television to find the modulator channel (see the
appliance manual). Now give it a programme number and
memorise it (see Manual Programming of channels). Then,
when you wish to use the appliance, simply select its
programme number on the television. This procedure is not
required for VCR’s not equipped with a modulator.
The SCART socket AV1 (3), located on the rear of the
television, is intended to connect a VCR or a camcorder
(VHS, 8 mm), a Canal+ decoder, a video games console or
RGB-signal emitting appliances.
The SCART socket AV2 (3), located on the rear of the
television, is intended to connect a VCR or a camcorder
(VHS, 8mm, S-VHS or Hi-8).
We strongly recommend the use of this type of connection,
which gives a better picture quality. To use the peripheral
appliance thatyou haveconnected, presstheAV keyon your
remote control (press once to select AV1; twice to select
AV2; three times for AV3: see ”Other Connections”). This
selection is automatic for some appliances. Pressing “”play”
on a VCR, or switching on a satellite receiver connected to
AV1 or AV2 will automatically switch on your television.
When you stop the VCR, if you have not changed channels
while watching the VCR, the television automatically
switches back tothe channel youwere watchingbeforehand.
If the television has been switched on from the VCR, it
switches to standby when the VCR is switched off. The
television automatically switches to 16/9 format if the
connected appliance delivers the corresponding signal.
Continental
Europe
United Kingdom
The plug isfittedwith a fusewhich protec ts your
television.Ifyour televisiondoes notwork, the fuse may
be blown. Inthis case, replaceit with anidentical5 Amp
ASTA orlr BSI (BS 1362)certified fuse.
$
Note: the mains lead ofyour television is fitted witha
moulded plug. This lead contains allthe safety equipment,
so y ou are advised when replacing itnot to usea
non-specific commercially-available model.
GB
2
3
Remotecontrol
Display of channel, time, sound (yellow
button) (and zoomfor models with zoom)
Remote control
This key isactive only when using
the Teletext
(bluekey)
Call up programme list
GB
Confirm an action or validate a
The red, green, yellow and
blue keys are also used for
the Teletext.
Reminder of picture
preferences
To leave a menu or Teletext
Volume adjustment
Selecting appliances
connected to the television
(green button)
(red button)
menu option
Sound mute
(AV1, AV2 ...)
Standby
Call up Teletext / Toptext /
Fastext function
Right/Left Selection within
menus and
Zoom Function (for models with
this function)
Go to adjustment function MENU
Move Up/Down in menus
Change programme
8
Go to programmes and enter
numerical values
For programme numbers higher
than 10,press the
remote control:”- -” appears on
the screen. Now use the
number keys on the remote
control to enter first the tens
digit then the units digit.
(purple button)
in menus
0
key on the
Please respect the environment! Beforethrowing any batteries away, consult your
distributor who may be able to take them back for specific recycling.
4
