P ARTS LIST
DC0740 SERIES
M
DC0740B (Panel Type Door - Black)
DC0740S (Panel Type Door - Stainless)
DC0740W (Wrap Type Door - Stainless)
P ART # 632356
NORCOLD 12/12/2007
Page 2
REFRIGERATOR ASSEMBLY - DC0740 SERIES
37
17
36
18
16
15
14
13
13
1
2
4
5
3
6
7
8
19
20
21
9
22
6
12
11
35
Wrap Type Door
32
31
30
29
28
27
26
33
10
Panel Type Door
32
31
30
29
28
27
26
33
34
25
38
24
23
37
DC0740 SERIES PARTS LIST - PAGE 2
Page 3
REFRIGERATOR ASSEMBLY - DC0740 SERIES
NO. PART # DESCRIPTION DC0740B DC0740S DC0740W
1 422513700 COVER-CONTROL/BLACK X
422513710 COVER-CONTR OL/STAINLESS X X
2 163010702 POWER SUPPLY-DC X X X
3 160220100 KNOB-THERMOSTAT X X X
4 300207400 PLATE LATCH X X X
5 501042700 B OLT/SCREW X X X
6 160932620 HINGE X X X
7 416027200 BUSHING-RUBBER/CABINET/COOLING UNIT TUBING X X X
8 404006300 BUSHING-"I"/PLASTIC/CABINET/COOLING UNIT TUBING X X X
9 645109400 HOLDER-SHELF/REAR X X X
10 422601400 FRAME-CABINET BOTTOM/BLACK X
422601410 FRAME-CABINET BOTTOM/STAINLESS X X
11 427401100 SUPPORT-LOWER CABINET/RH X X X
12 427401010 SUPPORT-LOWER CABINET/LH X X X
13 80830431610 SCREW-BOTTOM LEG X X X
14 160928900 FAN ONLY-50 CYCLE/40 WATT X X X
15 422305000 HO LDER-THERMISTER/AT EVAPORATOR X X X
16 605505420 THERMISTE R-EVAPORATOR X X X
17 161011400 COOLING UNIT X X X
18 500013600 SCREW X X X
19 160203000 ICE CUBE TRAY X X X
20 433003800 DRAINAGE PAN X X X
21 523003610 SHELF-UPPER/HOLDS DRAINAGE PAN X X X
22 523003600 SH ELF-LOWER X X X
23 323012520 FRAME-CABINET SIDE/RH/BLACK X
323012530 FRAME-CABINET SIDE/RH/STAINLES S X X
24 322376501 COVER-CABINET FRAME/F RON T/4 SIDES X X X
25 323012420 FRAME-CABINET SIDE/LH/BLACK X
323012430 FRAME-CABINET SIDE/LH/BLACK X X
26 160057500 DOOR ASSY-WITHOUT DOOR POCKET/PANEL TYPE/BLACK X
160057510 DOOR ASSY-WITHOUT DOOR POCKET/PANEL TYPE/STAINLESS X
160057520 DOOR ASSY-WITHOUT DOOR POCKET/STAINLESS/WRAP TYPE X
27 422603500 DOOR FRAME COVER-BOTTOM/BLACK X
422603510 DOOR FRAME COVER-BOTTOM/STAINLESS X X
28 160948700 DOOR FRAME ASSY-PANEL TYPE/BLACK (FOAM LINER) X
160948710 DOOR FRAME ASSY-PANEL TYPE/STAINLESS (FOAM LINER) X
160949100 DOOR FRAME ASSY-WRAP TYPE/STAINLESS (FOAM LINER) X
29 520004410 SPRING-TRAVE L LATCH X X X
30 505503420 PIN LATCH X X X
Continued on Page 4
DC0740 SERIES PARTS LIST - PAGE 3
Page 4
REFRIGERATOR ASSEMBLY - DC0740 SERIES (Continued from Page 3)
NO. PART # DESCRIPTION DC0740B DC0740S DC0740W
31 422513900 HANDLE -D OOR/BLACK X
422513910 HANDLE -D OOR/STAINLE S S X X
32 422114500 COVER LATCH-BLACK X
422114510 COVER LATCH-STAINLESS X X
33 422114600 COVER PLATE-BLACK X
422114610 COVER PLATE-STAINLESS X X
34 302313440 DOOR PANEL-BLACK X
302313450 DOOR PANEL-STAINLESS X
35 422508710 DOOR POCKET-DOOR SHELF BIN X X X
36 422508610 PARTITION-DOOR PO CKET X X X
37 323011900 FRAME-CABINET/TOP/BOTTOM/BLACK X
323011910 FRAME-CABINET/TOP/BOTTOM/STAINLESS X X
38 323012400 FRAME-CABINET/LH/FLUSH MOUNT KIT/BLACK/0740 X
323012410 FRAME-CABINET/LH/FLUSH MOUNT KIT/STAINLESS/0740 X X
323012500 FRAME-CABINET/RH/FLUSH MOUNT KIT/BLACK/0740 X
323012510 FRAME-CABINET/RH/FLUSH MOUNT KIT/STAINLESS/0740 X X
NS 606901100 FERRITE CORE X X X
NS = NOT SHOWN
